MULTIMEDIA DATA/VIDEO PROJECTORS
Brightness
2500lm
Instant
Shutdown
A snap to show, quicker to stow.
The fast-draw projector.
4000hr
Lamp Life
Specifications
XD430U
Model
0.55”1-Chip DMD, 12deg. DDR, DDP2000
Display technology
1024˜768(total 786,432 pixels), 550 Video lines
Resolution
2500lm
Brightness (Max)
2000 : 1(on/off)
Contrast
Picture Size
40”~300”(100”=3.2m)
Source lamp
184W (Shut Off Time 4000Hrs) with Low Mode
230W (Shut Off Time 2000Hrs)
Computer
compatibility
640˜480 ~1280˜1024
True: 1024˜768, Sync on green available
Video
compatibility
NTSC/NTSC4.43/PAL(including PAL-M, N)/SECAM/PAL-60,
Component Video: 480i/p(525i/p), 576i/p(625i/p),
720p(750p), 1080i(1125i 60Hz), 1080i(1125i 50Hz)
**
XD430U
MOBILE XGA PROJECTOR
Input and Output Terminals
1
2
3
4
5
6
7
1 USB terminal for Page up/down
2 PC / Component Video output
8
3 Serial RS-232C
4 PC / Component Video input
(mini D-sub 15pin)
mini D-sub 15pin˜2
Video input terminals
Video: RCA˜1㧗S-video˜1, Audio: stereo mini jack(ø3.5)˜1
Output terminals
RGB: mini D-sub 15pin˜1, DC Out: 5V 1.5A(MAX)
Audio: stereo mini jack(ø3.5)˜1
Communication
terminals
RS-232C(D-sub 9pin)˜1
Audio speaker
5 S-Video / RCA
6 Audio input‫ޓ‬
9
PC input terminals
2W mono
261˜87˜265mm(excluding height adjustment)
Dimension
W˜H˜D
2.6kg/5.7lbs
7 Audio output
8 DC Out
Weight
Power supply
AC100 - 240V, 50/60Hz
9 Security Hook
Optional lamp
VLT-XD430LP
All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
Approximate figure representing average operational life cycle
*
**
100.2
Dimensions
101.0
6q
18.0
187.0
87.0
100.0
260.8
263.4
Unit:mm 㧔in.㧕
Screen size and Projection distance
As seen from the side
Screen size chart
Screen (4:3 aspect ratio)
Diagonal size Width (W)
H
Hd
XD435U
XD430U
Lw~Lt
Height (H)
Distance from screen ( L)
Screen (16:9 aspect ratio)
Height projected
( )
Maximum Zoom Minimum Zoom image Hd
Diagonal size Width (W)
Height (H)
inch
cm
inch
cm
inch
cm
inch
m
40
102
32
81
24
61
50
1.3
60
152
48
122
36
91
76
80
203
64
163
48
122
101
100
254
80
203
60
152
150
381
120
305
90
200
508
160
406
250
635
200
300
762
240
Distance from screen ( L)
Height projected
( )
Maximum Zoom Minimum Zoom image Hd
inch
cm
inch
cm
inch
cm
inch
cm
inch
m
inch
m
60
1.5
3.5
8.8
40
102
34.9
89
19.6
50
55
1.4
66
1.7
6.7
17.1
1.9
91
2.3
5.2
13.3
60
152
52.3
133
29.4
75
82
2.1
99
2.5
10.1
25.7
2.6
121
3.1
7.0
17.7
80
203
69.7
177
39.2
100
110
2.8
132
3.3
13.5
34.3
126
3.2
151
3.8
8.7
22.1
100
254
87.2
221
49.0
125
137
3.5
165
4.2
16.9
42.9
229
189
4.8
227
5.8
13.1
33.2
150
381
130.7
332
73.5
187
206
5.2
247
6.3
25.3
64.3
120
305
252
6.4
302
7.7
17.4
44.2
200
508
174.3
443
98.1
249
275
7.0
329
8.4
33.7
85.7
508
150
381
315
8.0
378
9.6
21.8
55.3
250
635
217.9
553 122.6
311
343
8.7
412
10.5
42.2 107.1
610
180
457
378
9.6
–
–
26.1
66.3
300
762
261.5
664 147.1
374
412
10.5
–
–
50.6 128.6
inch
m
The above numbers are approximate, and may be slightly different from the actual measurements.
