Assembly Manual & User Guide
TABLE OF CONTENTS
INTRODUCTION.................................................................................................................. 1
1.1 MINIMUM SYSTEM REQUIREMENTS
1.1.1 Apple Mac Requirements
1.1.2 PC Requirements
1.1.3 Supported Optical Drives
1.2 PACKAGE CONTENTS
1.3 ABOUT THIS MANUAL
1.4 FRONT VIEW
1.4.1 Front Features
1.5 REAR VIEW
1.5.1 Connection
1.6 QUICK START
SUPPORT RESOURCES.................................................................................................... 4
2.1 TROUBLESHOOTING
2.2 EJECTING DISCS
2.3 CONTACTING TECHNICAL SUPPORT
OWC MERCURY PRO
TABLE OF CONTENTS
INTRODUCTION
1.1 MINIMUM SYSTEM REQUIREMENTS
1.1.1 Apple Mac Requirements
1.1.2 PC Requirements
•USB 3.1 Gen 1 (backwards compatible
to USB 2.0): OS X 10.6 or later
•USB 3.1 Gen 1 (backwards compatible
to USB 2.0): Windows XP® or later
1.1.3 Supported Optical Drives
•5.25” SATA optical drives — CD, DVD, and Blu-ray™ — up to 7.7” (19.5cm) deep.
•Media support, read/write speeds, and other features will vary based on the optical
drive mechanism installed.
1.2 PACKAGE CONTENTS
Power supply
OWC Mercury Pro
USB 3.1 Gen 1 cable
(Standard-A to Standard-B)
1.3 ABOUT THIS MANUAL
The images and descriptions will vary slightly between this manual and the unit shipped.
Functions and features may change depending on the firmware version. Please visit the
product web page for the most recent product specifications.
OWC MERCURY PRO
1
INTRODUCTION
1.4 FRONT VIEW
Manual eject hole
Eject button
IMPORTANT: The look and placement of features will vary based on the specific brand
and model of optical drive that was pre-installed into your Mercury Pro enclosure. Not
all drives have Blu-ray or M-Disc® support as seen above.
Eject button
Press to open the disc tray.
Manual eject hole If the disc tray cannot be opened by the eject button or
through software eject commands, insert a straightened
paper clip into the manual eject hole and press to open the
disc tray manually.
OWC MERCURY PRO
2
INTRODUCTION
1.5 REAR VIEW
1
2
3
4
1.USB 3.1 Gen 1 port — Connect the included USB 3.1 Gen 1 (Standard-A to Standard-B)
cable here.
2.DC Power — Connect to the included power supply here.
3.Kensington® Security Slot — Connect a security tether here.
4.Power Switch — Use this switch to power the drive on or off.
1.6 QUICK START
Plug the power supply into the DC power port on the OWC Mercury Pro and into a power
outlet. Connect the included USB 3.1 Gen 1 cable to your computer and the Mercury Pro,
then power on the Mercury Pro using the Power switch.
Notes: always unmount and eject the disc before powering off the optical drive.
OWC MERCURY PRO
3
INTRODUCTION
SUPPORT RESOURCES
2.1 TROUBLESHOOTING
Begin your troubleshooting by verifying that the power cable is connected to the OWC
Mercury Pro and to a power source. If the power cable is connected to a power strip, make
sure that the power switch on the strip is turned on. Next, verify that both ends of your data
cable is securely plugged into the computer and the OWC Mercury Pro. If the Mercury Pro is
still not working properly, try using a different USB 3.1 Gen 1 cable and see if that helps. You
can also connect the Mercury Pro to a different computer to eliminate the possibility that
the problem is with the computer and not the drive or the cable.
If problems persist, see our online FAQs at: www.owcdigital.com/faq
If you would like to contact Technical Support please see Section 2.3.
2.2 EJECTING DISCS
In Windows, ejecting an optical disc from your OWC Mercury Pro optical drive can be done
by pressing the eject button on the front of the unit.
In OS X, the eject button is disabled by the operating system, so ejecting a disc can be done
in the following ways:
1. Drag the desktop icon of the disc to the trash.
2. Open Finder, then click the eject button next to the disc icon in the “Devices” sidebar.
2.3 CONTACTING TECHNICAL SUPPORT
Phone: M–F, 8am–5pm CST
(866) 692-7100 (N. America) | +1 (815) 383-4751 (Int’l)
Chat: M–F, 8am–8pm CST
www.owcdigital.com/support
Email: Answered within 48 hours
www.owcdigital.com/support
OWC MERCURY PRO
4
SUPPORT RESOURCES
Changes:
The material in this document is for information purposes only and subject to change without notice.
While reasonable efforts have been made in the preparation of this document to assure its accuracy,
OWC, its parent, partners, affiliates, officers, employees, and agents assume no liability resulting from
errors or omissions in this document, or from the use of the information contained herein. OWC
reserves the right to make changes or revisions in the product design or the product manual without
reservation and without obligation to notify any person of such revisions and changes.
FCC Statement:
Warning! Modifications not authorized by the manufacturer may void the user’s authority to operate
this device.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference with radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at his own expense.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference with radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Health And Safety Precautions:
Use proper anti-static precautions while performing the installation of your drives into this drive
enclosure. Failure to do so can cause damage to your drive mechanisms and/or the drive enclosure.
Read this user guide carefully and follow the correct procedures when setting up the device. Do
not attempt to disassemble or modify the device. To avoid any risk of electrical shock, fire, shortcircuiting or dangerous emissions, never insert any metallic object into the device. If it appears to be
malfunctioning, contact technical support.
Never expose your device to rain, or use it near water or in damp or wet conditions. Never place
objects containing liquids on the drive, as they may spill into its openings. Doing so increases the risk
of electrical shock, short-circuiting, fire or personal injury.
General Use Precautions:
To avoid damage, do not expose the device to temperatures outside the range of 5° C to 40° C (41° F
to 104° F). Always unplug the device from the electrical outlet if there is a risk of lightning or if it will
be unused for an extended period of time. Otherwise, there is an increased risk of electrical shock,
short-circuiting or fire.
•
Do not use the device near other electrical appliances such as televisions, radios or speakers.
Doing so may cause interference which will adversely affect the operation of the other products.
•
Do not place the device near sources of magnetic interference, such as computer displays,
televisions or speakers. Magnetic interference can affect the operation and stability of drives.
•
Do not place heavy objects on top of the device.
•
Protect your device from excessive exposure to dust during use or storage. Dust can build up
inside the device, increasing the risk of damage or malfunction.
For up-to-date product and warranty information, please visit the product web page.
Copyrights and Trademarks:
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form
or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior
written consent of OWC.
© 2017 OWC. All rights reserved.
OWC is a trademark of New Concepts Development Corporation, registered in the U.S. Patent and
Trademark Office and/or in Canada. The OWC logo is a trademark of New Concepts Development
Corporation. Apple, Mac, and OS X are trademarks of Apple Inc., registered in the U.S. and other
countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Blu-ray and the Blu-ray Disc logo are
trademarks of the Blu-ray Disc Association. M-Disc is a registered trademark of Millenniata, Inc. Other
marks may be the trademark or registered trademark property of their owners.
R4 03/06/17 DM
OWCMANMRSU3NUG
Copyright 2017 OWC. All Rights Reserved.
OWC’s Limited Warranty is not transferable and subject to limitations.
Was this manual useful for you? yes no
Thank you for your participation!
