i-Launcher guide
For
Samsung Camera
Digital Imaging Div. CS Team
Installing i-Launcher
1
1.
Enter the Settings menu.
menu (Methods vary depending on the Model.
Model Dial or Menu Key)
2.
Select Connectivity → i-Launcher(PC Software) → On (default “On”)
3.
Turn off the camera.
4
4.
Connect the camera to your computer with the USB cable.
cable
You must plug the small end of the USB cable into your camera. If the cable is reversed, it may
damage your files.
files The manufacturer is not responsible for any loss of data.
data
5. Turn on the camera.
6. When the pop-up window prompts you to install i-Launcher, select Yes.
• If a pop-up window prompting you to run iLinker.exe appears, run it first.
• When you connect the camera to a computer with i-Launcher installed, the
program will launch automatically.
7. Follow the on-screen instructions to complete the installation.
• An i-Launcher shortcut will appear on the computer.
• Before installing the program
program, ensure that the PC is connected to a network.
network
• To install i-Launcher on your Mac OS computer, click Devices → i-Launcher → Mac → iLinker.
Available programs when using i-Launcher
Option
p
Description
p
Multimedia Viewer
You can view files with Multimedia Viewer.
Firmware Upgrade
You can update the firmware of your camera.
Map Download
Manager
You can download the Map file of your camera. (GPS model only)
PC Auto Backup
i-Launcher provides a link for downloading the PC Auto Backup
program when
h you connectt the
th camera to
t a computer.
t You
Y can
send photos or videos that you captured with the camera to a PC
wirelessly.
If you use a Mac OS computer, only Firmware Upgrade and PC Auto Backup are available.
Using i-Launcher
i L
i-Launcher
h allows
ll
you to play
l back
b k files
fil with
i h Multimedia
M l i di Viewer
Vi
and
d provides
id a lilink
k to d
download
l d
the PC Auto Backup program.
• The requirements are recommendation only.
only ii-Launcher
Launcher may not work properly even when the
computer meets the requirements, depending on the condition of your computer.
• If your computer does not meet the requirements, videos may not play correctly
Windows OS Requirements
MAC OS Requirements
Opening i-Launcher
O your computer, select
On
l
S
Start → Allll Programs → S
Samsung → i-Launcher
i
h → Samsung
S
i
i-Launcher.
h
On your Mac, click Applications → Samsung → i-Launcher
Using Multimedia Viewer
Multimedia Viewer allows you to play back files. From the Samsung ii-Launcher
Launcher screen, click
Multimedia Viewer
• Multimedia Viewer supports the following formats: - Videos: MP4 (Video: H.264, Audio: AAC),
WMV (WMV 7/8/9)
7/8/9), AVI (MJPEG) - Photos: JPG
JPG, GIF
GIF, BMP
BMP, PNG,
PNG TIFF,
TIFF MPO
• Files that have been recorded with other manufacturers’ devices may not play back smoothly.
Viewing
Photos
Viewing
Videos
Updating the firmware
Before upgrading the firmware
1. Make sure you use fully charged batteries. If fully charged batteries are not used, or the power is cut during a
firmware upgrade, the main board may be seriously damaged, resulting in camera malfunction.
If camera malfunction is caused during a firmware upgrade for the reasons given above,
above the main board may
have to be serviced by a Samsung service center, which may result in major repair charges.
2. Before upgrading the firmware, make sure that you format the memory card on your PC or camera and then
download the necessaryy firmware file.
3. To upgrade firmware there should be sufficient free space on the memory card for the size of the firmware file.
If the firmware upgrade is not completed because of insufficient memory space, delete some of the files saved
on the memory to secure more free space and then try again. (over 100MB recommended)
4. Do not operate the camera, remove the batteries, or cut the power while upgrading firmware.
Operate the camera only after the firmware upgrade is complete.
5 Once
5.
O
th
the firmware
fi
is
i upgraded,
d d it is
i nott possible
ibl tto restore
t
th
the earlier
li version
i
off th
the fi
firmware.
When the firmware is upgraded, all the camera settings are set to their default values.
Since all the files stored in the internal memory(not Memory card) will be deleted, ensure that files are copied
to other storage devices before upgrading firmware.
6. Before downloading firmware, make sure you read the Software Use Terms Conditions.
The act of downloading the firmware is taken to mean that you have agreed to the Software Use Terms and
Conditions.
※ Should you need further detailed information, or if you experience difficulty in upgrading firmware, do not
proceed with the process on your own. Visit a Samsung service center near you.
Updating the firmware
How to Upgrade the Firmware
3. Please read precaution before upgrade firmware.
1. Connect with Camera and PC via cable and
PC recognize camera
2. From the Samsung i-Launcher screen, click
Firmware Upgrade.
4. Downloading from Server
Updating the firmware
5 Finish do
5.
downloading
nloading and disconnect with
ith camera
9. The firmware version will display on the LCD
9
screen. Press and hold the shutter button to
start the firmware update process.
10. The display will show “Firmware is updating...”
Once the firmware update process is
complete, the camera will automatically power
off.
ff
7. Disconnect the Camera from the PC
8. Power On the Camera
