BlackBerry Device Software
Version: 5.0
Update Guide
SWD-558417-0327093017-001
Contents
1
Updating the BlackBerry Device Software..............................................................................................................................
4
2 Permitting users to update the BlackBerry Device Software using the BlackBerry Desktop Software.........................
Send the BlackBerry Desktop Software installation file to users..............................................................................................
Create the BlackBerry Device Software update instructions for users that use the BlackBerry Desktop Software...........
5
5
6
3 Permitting users to update the BlackBerry Device Software using the BlackBerry Web Desktop Manager................
Install the BlackBerry Device Software........................................................................................................................................
Create a shared network folder to access the BlackBerry Device Software............................................................................
Configure the BlackBerry Administration Service to display BlackBerry Device Software pages........................................
Add a shared network folder to the BlackBerry Administration Service..................................................................................
Configure the BlackBerry Administration Service to find the BlackBerry Device Software...................................................
Create a BlackBerry Device Software configuration...................................................................................................................
Create a software configuration for the BlackBerry Device Software......................................................................................
Assign a software configuration to a group.................................................................................................................................
Assign a software configuration to a user account.....................................................................................................................
Create the BlackBerry Device Software update instructions for users that use the BlackBerry Web Desktop Manager
...........................................................................................................................................................................................................
7
7
8
8
9
9
9
10
11
11
4 Updating the BlackBerry Device Software over the wireless network................................................................................
Architecture: components..............................................................................................................................................................
Types of BlackBerry Device Software update packages.............................................................................................................
Features of wireless BlackBerry Device Software updates................................................................................................
Approximate duration of downloading and installing BlackBerry Device Software updates over the wireless network
..................................................................................................................................................................................................
BlackBerry device memory requirements for BlackBerry Device Software updates over the wireless network..................
Battery power requirements for BlackBerry Device Software updates over the wireless network.......................................
Permitting the wireless service provider to update the BlackBerry Device Software over the wireless network...............
Permit wireless service providers to send BlackBerry Device Software update requests to BlackBerry devices........
Permit BlackBerry device users to cancel BlackBerry Device Software updates from the wireless service provider
..................................................................................................................................................................................................
Permit BlackBerry device users to send BlackBerry Device Software update requests to the wireless service provider
..................................................................................................................................................................................................
13
14
15
15
11
16
17
17
18
18
18
19
Create instructions for how users can request BlackBerry Device Software updates from the wireless service
provider....................................................................................................................................................................................
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network................
Configure the BlackBerry Administration Service to display BlackBerry Device Software pages................................
Search for BlackBerry Device Software on the BlackBerry Infrastructure.......................................................................
Resolve conflicts that occur if you assign multiple BlackBerry Device Software bundles to groups and user accounts
..................................................................................................................................................................................................
Create a BlackBerry Device Software configuration..........................................................................................................
Create a software configuration for the BlackBerry Device Software..............................................................................
Assign a software configuration to a group........................................................................................................................
Assign a software configuration to a user account............................................................................................................
How a user can respond to a BlackBerry Device Software update request from the BlackBerry Enterprise Server
..................................................................................................................................................................................................
Monitoring BlackBerry Device Software update requests.................................................................................................
Preventing BlackBerry Device Software updates over the wireless network based on the network connection type
..................................................................................................................................................................................................
Best practice: Preventing possible BlackBerry device issues during the BlackBerry Device Software update process
...........................................................................................................................................................................................................
26
5 Updating the BlackBerry Device Software at a central computer.......................................................................................
Install the BlackBerry Device Software........................................................................................................................................
Create a shared network folder to access the BlackBerry Device Software............................................................................
Configure the BlackBerry Administration Service to display BlackBerry Device Software pages........................................
Add a shared network folder to the BlackBerry Administration Service..................................................................................
Configure the BlackBerry Administration Service to find the BlackBerry Device Software...................................................
Create a BlackBerry Device Software configuration...................................................................................................................
Create a software configuration for the BlackBerry Device Software......................................................................................
Assign a software configuration to a group.................................................................................................................................
Assign a software configuration to a user account.....................................................................................................................
Update the BlackBerry Device Software at a central computer................................................................................................
27
27
28
28
29
29
29
30
31
31
31
6 Permitting users to update the BlackBerry Device Software using the application loader tool.....................................
Send the BlackBerry Device Manager installation file to users' computers............................................................................
Install the BlackBerry Device Software........................................................................................................................................
Create a shared network folder to access the BlackBerry Device Software............................................................................
Create the BlackBerry Device Software update instructions for users that use the application loader tool.......................
33
33
34
34
35
19
19
20
20
21
21
22
22
23
23
24
24
7 Pushing the BlackBerry Device Software and BlackBerry Desktop Software to users' computers................................
Create a shared network folder to access the BlackBerry Device Software............................................................................
Save the BlackBerry Device Software installation file to the network drive............................................................................
Save the BlackBerry Desktop Software installation file to the network drive.........................................................................
Send the installation files for the BlackBerry Desktop Software and BlackBerry Device Software to users using a thirdparty application.............................................................................................................................................................................
36
36
36
37
8 Managing the distribution of BlackBerry Device Software...................................................................................................
Change how to install, update, or remove the BlackBerry Device Software............................................................................
Change how the BlackBerry Enterprise Server sends standard application settings to BlackBerry devices.......................
Change how a job sends the BlackBerry Device Software to BlackBerry devices..................................................................
Change how a job sends standard application settings to BlackBerry devices......................................................................
38
38
39
40
42
9 Troubleshooting...........................................................................................................................................................................
Verify that the BlackBerry Device Software update process completed..................................................................................
A user cannot start the update process using the link to the application loader tool............................................................
44
44
44
10 Glossary.........................................................................................................................................................................................
45
11 Provide feedback.........................................................................................................................................................................
46
12 Legal notice..................................................................................................................................................................................
47
37
Updating the BlackBerry Device Software
Update Guide
Updating the BlackBerry Device Software
1
To make the new features of the BlackBerry® Enterprise Server available to users in your organization, you can update the
BlackBerry® Device Software on BlackBerry devices at the same time that you upgrade the BlackBerry Enterprise Server software.
Update option
Description
Permit users to update the BlackBerry
Device Software using the BlackBerry®
Desktop Software.
You can use this option if users installed the BlackBerry Desktop Software on their
computers.
If you permit users to use the BlackBerry Desktop Software to update the BlackBerry
Device Software, they can update the BlackBerry Desktop Software simultaneously.
Permit users to update the BlackBerry
You can use this option if you want users to update the BlackBerry Device Software
Device Software using the BlackBerry® themselves, you do not want users to install the BlackBerry Desktop Software, or
Web Desktop Manager.
you prefer that users use a UI to update the BlackBerry Device Software.
Update the BlackBerry Device Software You can use this option if you want to update BlackBerry Device Software on
over the wireless network.
BlackBerry devices without requring that users connect their BlackBerry devices to
their computers, and if the wireless network in your organization's environment
permits the use of additional bandwidth. Users respond to UI prompts to complete
the BlackBerry Device Software update.
Update the BlackBerry Device Software You can use this option if you want to update the BlackBerry Device Software for
at a central computer.
users using the BlackBerry Administration Service.
Permit users to update the BlackBerry
You can use this option if you want users to update the BlackBerry Device Software
Device Software using the application
themselves, you do not want users to install the BlackBerry Desktop Software, and
loader tool.
do not mind that users use a command prompt window to update the BlackBerry
Device Software.
Push the BlackBerry Device Software
You can use this option if you want to update the BlackBerry Device Software and
and BlackBerry Desktop Software to
BlackBerry Desktop Software simultaneously.
users' computers.
For more information about the BlackBerry Device Software and BlackBerry Desktop Software, visit www.blackberry.com/support.
4
Update Guide
Permitting users to update the BlackBerry Device Software using the BlackBerry Desktop Software
Permitting users to update the BlackBerry Device Software
using the BlackBerry Desktop Software
2
To permit users to update the BlackBerry® Device Software at computers that host the BlackBerry® Desktop Software, you can
make the BlackBerry Device Software installation file available and instruct users to update the BlackBerry Device Software using
the application loader tool that is installed with the BlackBerry Desktop Software. After the update process completes, the
application loader tool connects to the messaging server to provision the BlackBerry devices.
This update option applies only if users have installed BlackBerry Desktop Software version 4.1 or later on their computers.
Advantages of this update process include:
•
You can automate the BlackBerry Device Software upgrade process so that users do not have to complete update tasks for
BlackBerry devices that they connect to their computers using a USB connection.
•
You can update BlackBerry devices remotely.
Disadvantages of this update process include:
•
Users' computers must have the BlackBerry Desktop Software installed.
•
You cannot use software configurations to manage BlackBerry Device Software updates.
•
You cannot require that users update the BlackBerry Device Software.
•
This update process increases traffic to the computer that hosts the shared network folder.
Send the BlackBerry Desktop Software installation file to users
You can send the BlackBerry® Desktop Software installation file to users so that they can install the BlackBerry Desktop Software
and use it to synchronize organizer data items and manage message forwarding on their computers.
If users require the S/MIME Support Package for BlackBerry® devices to synchronize certificates and private keys, you can send
them the BlackBerry Desktop Software so that they can install the certificate synchronization tool.
1.
If your organization's environment includes the BlackBerry® Enterprise Server for Microsoft® Exchange, send users an email
message that specifies the location of the installation file in the shared network folder and one of the following installation
types:
• for the BlackBerry® Desktop Manager only: \\<shared_network_folder>\setup.exe /s
• for the BlackBerry Desktop Manager and certificate synchronization tool of the BlackBerry Desktop Manager: \
\<shared_network_folder>\setup.exe /s /v "INSTALLLEVEL=125"
2.
If your organization's environment includes the BlackBerry® Enterprise Server for IBM® Lotus® Domino® or BlackBerry®
Enterprise Server for Novell® GroupWise®, send users an email message that specifies the location of the installation file
in the shared network folder and the installation type: \\<shared_network_folder>\setup.exe /s
The software installs automatically.
5
Update Guide
Create the BlackBerry Device Software update instructions for users that use the BlackBerry Desktop Software
Create the BlackBerry Device Software update instructions for users that use
the BlackBerry Desktop Software
You can create update instructions for users so that they can update the BlackBerry® Device Software on their computers using
the BlackBerry® Desktop Manager.
Before you begin:
•
Obtain the BlackBerry Device Software installation file from your organization's service provider.
•
Set up a shared network folder that users can access from their computers.
•
Extract the BlackBerry Device Software installation files to the shared network folder.
1.
2.
Create an email message that specifies the location of the shared network folder.
Consider providing the following instructions in the email message:
• Install the BlackBerry Device Software on your computer.
• Open the BlackBerry Desktop Manager.
• Connect your BlackBerry device to your computer.
• In the BlackBerry Desktop Manager, use the application loader tool to update the BlackBerry Device Software.
• Do not disconnect your BlackBerry device from your computer until the update process completes.
• If prompted, type your BlackBerry device password. Click Next.
• If the BlackBerry device uses a serial connection, complete the instructions on the screen.
• If your organization's environment includes the BlackBerry® Enterprise Server for Microsoft® Exchange or BlackBerry®
Enterprise Server for IBM® Lotus® Domino®, if prompted, select the Provision the device during the loading
process option. Select the messaging server that the user account is located on.
• If your organization's environment includes the BlackBerry® Enterprise Server for Novell® GroupWise®, if prompted,
select the Do not provision the device during the loading process option. After the update completes, activate the
BlackBerry device over the wireless network.
3.
Send the email message.
After you finish: To verify that the update process completed, instruct users to check the version information in the BlackBerry
device options on the About screen.
6
Update Guide
Permitting users to update the BlackBerry Device Software using the BlackBerry Web Desktop Manager
Permitting users to update the BlackBerry Device Software
using the BlackBerry Web Desktop Manager
3
To permit users to update the BlackBerry® Device Software using the BlackBerry® Web Desktop Manager instead of the
BlackBerry® Desktop Manager, you can install the BlackBerry Device Software on a shared network folder, create a software
configuration, and instruct users to update the BlackBerry Device Software using the BlackBerry Web Desktop Manager.
Advantages of this update process include:
•
You can automate the BlackBerry Device Software update process so that users do not have to complete update tasks for
BlackBerry devices that they connect to their computers using a USB connection.
•
You can use software configurations and application control policies to control when software updates occur and to specify
which users receive the updates.
•
You can update BlackBerry devices remotely.
•
Users do not require BlackBerry® Desktop Software on their computers to perform this update option.
Disadvantages of this update process include:
•
You cannot require that users update the BlackBerry Device Software.
•
This update option increases traffic to the shared network folder.
Install the BlackBerry Device Software
You must install the BlackBerry® Device Software on a computer so that you can create a software configuration. You use the
software configuration to distribute the BlackBerry Device Software using the BlackBerry® Web Desktop Manager, BlackBerry
Administration Service, BlackBerry® Desktop Manager, or over the wireless network.
Before you begin:
•
Obtain the latest BlackBerry Device Software version for the BlackBerry devices in your organization's environment from
your organization's service provider. The versions must be compatible with the BlackBerry devices and service provider that
your organization uses.
•
Verify that users and the BlackBerry Administration Service can access the computer that you want to install the BlackBerry
Device Software on.
1.
2.
3.
4.
Copy the BlackBerry Device Software installation file to the computer.
Double-click the .exe file.
Complete the instructions on the screen.
When prompted, do not start the application loader tool.
7
Update Guide
Create a shared network folder to access the BlackBerry Device Software
Create a shared network folder to access the BlackBerry Device Software
You can create a shared network folder on the computer where the BlackBerry® Device Software is installed so that BlackBerry
device users and the BlackBerry Administration Service can access the BlackBerry Device Software. The shared network folder
that you create for the BlackBerry Device Software cannot be the same shared network folder that you create for applications.
1. On the computer where the BlackBerry Device Software is installed, navigate to <drive>:\Program Files\Common Files
\Research In Motion.
2. Share the folder with write permissions for the account that is running the BlackBerry Administration Service - Application
Server service.
3. To decrease bandwidth over your organization's LAN, verify that the shared network folder is located in close proximity to
users' computers.
After you finish: Verify that the AppLoader subfolder is writable.
Configure the BlackBerry Administration Service to display BlackBerry
Device Software pages
By default, the BlackBerry® Administration Service does not display the BlackBerry® Device Software pages that permit you to
create the BlackBerry Device Software configuration. If you display the BlackBerry Device Software pages in the BlackBerry
Administration Service, the values change for the following IT policy rules in the Wireless Software Upgrades policy group, and
you cannot view or change the IT policy rules:
•
The Allow Non Enterprise Upgrade IT policy rule changes to the default value (No).
•
The Disallow Device User Requested Upgrade IT policy rule changes to the default value (Yes).
•
The Disallow Device User Requested Rollback IT policy rule changes to the default value (Yes).
1.
2.
3.
4.
5.
In the BlackBerry Administration Service, on the Servers and components menu, expand BlackBerry Solution topology
> BlackBerry Domain > Component view > BlackBerry Administration Service.
Click BlackBerry Administration Service.
Click Edit component.
In the Software management section, in the BlackBerry Device Software deployment managed by BlackBerry
Administration Service drop-down list, click Yes.
Click Save All.
After you finish: If you change the BlackBerry Device Software deployment managed by BlackBerry Administration
Service drop-down list to No, the Allow Non Enterprise Upgrade, Disallow Device User Requested Upgrade, and Disallow Device
User Requested Rollback IT policy rules display in the Wireless Software Upgrades policy group and are set to the default values.
8
Update Guide
Add a shared network folder to the BlackBerry Administration Service
Add a shared network folder to the BlackBerry Administration Service
You can add a shared network folder to the BlackBerry® Administration Service so that the BlackBerry Administration Service
can find the BlackBerry® Device Software that you installed.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Add shared network drive.
3. In the Shared network drive section, perform the following actions:
• In the Name field, type a name for the shared network folder.
• In the Server file path field, type the path to the shared network folder (for example, \\<server>
\<shared_network_folder>, where <server> is the name of the computer that hosts the shared network folder.
4.
Click Save.
Configure the BlackBerry Administration Service to find the BlackBerry
Device Software
To create a BlackBerry® Device Software configuration, you must use the BlackBerry Administration Service to scan the shared
network folder to find the BlackBerry Device Software that you want users to install.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Manage shared network drives.
3. Click a shared network folder.
4. Click Execute shared network drive scan.
After you finish: To verify that the BlackBerry Administration Service found of all the BlackBerry Device Software bundles that
you installed in the shared network folder, on the BlackBerry Device Software bundles tab, verify that the list of BlackBerry
Device Software bundles is complete.
Create a BlackBerry Device Software configuration
You create a BlackBerry® Device Software configuration so that you can create a software configuration that includes the
BlackBerry Device Software, and distribute the BlackBerry Device Software to users.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Create BlackBerry Device Software configuration.
3. In the Configuration data section, type a name and description for the BlackBerry Device Software configuration.
9
Update Guide
Create a software configuration for the BlackBerry Device Software
4.
5.
6.
7.
8.
Click Save.
In the Configuration data section, click the BlackBerry Device Software configuration that you created.
Click Edit BlackBerry Device Software configuration.
In the Native application settings section, change the settings to meet your organization's requirements.
On the BlackBerry Device Software bundles tab, click Add BlackBerry Device Software bundles to BlackBerry Device
Software configuration.
9. Search for the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
10. Select the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
11. Click Add to BlackBerry Device Software configuration.
12. Click Save all.
Create a software configuration for the BlackBerry Device Software
You can create a software configuration for the BlackBerry® Device Software so that you can distribute the BlackBerry Device
Software to users in your organization and they can install it on their BlackBerry® devices.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software.
2. Click Create a software configuration.
3. In the Configuration data section, type a name for the BlackBerry Device Software configuration.
4. In the Disposition for unlisted applications drop-down list, perform one of the following actions:
• To permit users to install applications that are not included in the software configuration, click Optional.
• To prevent users from installing applications that are not included in the software configuration, click Disallowed.
5.
If you set Disposition for unlisted applications to Optional, in the Application control policy for unlisted
applications drop-down list, click the application control policy for the applications that you did not include in the software
configuration.
6. Click Save.
7. In the Configuration data section, click the name of the software configuration.
8. Click Edit software configuration.
9. In the BlackBerry Device Software configuration section, in the Name drop-down list, click the BlackBerry Device
Software configuration.
10. Click Save all.
After you finish: To make the BlackBerry Device Software available to users, assign the software configuration to the groups or
user accounts that require it.
10
Update Guide
Assign a software configuration to a group
Assign a software configuration to a group
1.
2.
3.
4.
5.
6.
7.
8.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Group.
Click Manage groups.
Click a group.
Click Edit group.
On the Software configuration tab, in the Available software configurations list, click a software configuration.
Click Add.
Repeat steps 5 and 6 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
Assign a software configuration to a user account
1.
2.
3.
4.
5.
6.
7.
8.
9.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand User.
Click Manage users.
Search for a user account.
In the search results, click the display name for the user account.
Click Edit user.
On the Software configuration tab, in the Available software configurations list, click the appropriate software
configuration.
Click Add.
Repeat steps 6 and 7 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
Create the BlackBerry Device Software update instructions for users that use
the BlackBerry Web Desktop Manager
You can create update instructions for BlackBerry® device users so that they can update the BlackBerry® Device Software when
they use the BlackBerry® Web Desktop Manager.
Before you begin: Provide users with their login information for theBlackBerry Web Desktop Manager.
11
Update Guide
Create the BlackBerry Device Software update instructions for users that use the BlackBerry Web Desktop Manager
1.
2.
Create an email message that specifies the web address for the BlackBerry Web Desktop Manager UI.
Consider providing the following instructions in the email message:
• Connect your BlackBerry device to your computer.
• Do not disconnect the BlackBerry device from the computer until the update process completes.
• If prompted, type your BlackBerry device password. Click Next.
• If the BlackBerry device uses a serial connection, complete the instructions on the screen.
• If your organization's environment includes the BlackBerry® Enterprise Server for Microsoft® Exchange or BlackBerry®
Enterprise Server for IBM® Lotus® Domino®, if prompted, select the Provision the device during the loading
process option. Select the messaging server that the user account is located on.
• If your organization's environment includes the BlackBerry® Enterprise Server for Novell® GroupWise®, if prompted,
select the Do not provision the device during the loading process option. After the update process completes, activate
the BlackBerry device over the wireless network.
3.
Send the email message.
12
Update Guide
Updating the BlackBerry Device Software over the wireless network
Updating the BlackBerry Device Software over the wireless
network
4
To update the BlackBerry® Device Software over the wireless network, you can use the BlackBerry Administration Service to
search for and configure updates that match the BlackBerry device and carrier, or you can permit your organization's wireless
service provider to update the BlackBerry Device Software.
You can use the BlackBerry Administration Service to search for BlackBerry Device Software on the BlackBerry® Infrastructure,
create a software configuration, and send a required BlackBerry Device Software update to BlackBerry devices. When BlackBerry
devices download the BlackBerry Device Software update from the BlackBerry Infrastructure, users can choose to complete the
BlackBerry Device Software update immediately, or users can defer the BlackBerry Device Software update for up to 72 hours.
This update option applies only when you update from BlackBerry Device Software version 4.5 or later.
If you do not want to control BlackBerry Device Software updates using the BlackBerry Administration Service, you can permit
your organization's wireless service provider to update the BlackBerry Device Software using the BlackBerry® Provisioning
System administration web site. The wireless service provider can only send optional BlackBerry Device Software updates. By
default, wireless service providers are not permitted to update the BlackBerry Device Software over the wireless network. You
can also permit users to request BlackBerry Device Software updates from the wireless service provider.
For more information about the actions that the user is required to complete to perform a BlackBerry Device Software update
that the wireless server provider sends to them, visit www.blackberry.com/go/docs to read the BlackBerry Smartphone User
Guide for the BlackBerry device models that are used in your organization's environment.
Advantages of this update process include:
•
You can use software configurations and application control policies to control when software updates occur and to specify
which users can update the BlackBerry Device Software.
•
You or the wireless service provider can update BlackBerry devices remotely.
•
Users do not require the BlackBerry® Desktop Software on their computers to perform the update option.
Disadvantages of this update process include:
•
This update option increases wireless network traffic.
•
This update option might take an unexpected amount of time to complete.
13
Architecture: components
Update Guide
Architecture: components
Component
Description
availability server
The availability server is designed to manage and store information about the
availability of BlackBerry® Device Software update packages.
upgrade package server
upgrade details server
software upgrade database
14
The availability server is designed to provide you with information about the latest
approved BlackBerry Device Software update packages and recommended upgrade
paths.
The upgrade package server is designed to store and send BlackBerry Device
Software update packages to BlackBerry devices. It controls the rate at which
subscribers can download BlackBerry Device Software update packages. Research
In Motion administrators upload BlackBerry Device Software update packages to
this server after they approve them.
The upgrade details server is designed to provide the BlackBerry device with a list
of the update files that are required for a specific wireless BlackBerry Device
Software update.
The software upgrade database is the primary database that contains the BlackBerry
Device Software update information and metadata that the BlackBerry®
Infrastructure processes.
Types of BlackBerry Device Software update packages
Update Guide
Types of BlackBerry Device Software update packages
BlackBerry® Device Software update packages that Research In Motion makes available on the BlackBerry® Infrastructure can
introduce new features and address known software issues on BlackBerry devices.
Type
Description
platform update
•
•
•
applies to applications on the BlackBerry device other than Java® applications
(for example, the software for the JVM, native support libraries for the JRE,
operating system, and wireless transceiver)
is typically 500 KB or less
typically requires up to 5 minutes to download over the wireless network
partial software update
•
•
•
applies to wireless transceiver code
is typically less than 1 MB
typically requires up to 15 minutes to download over the wireless network
complete software update
•
•
•
applies to existing BlackBerry® Device Software on the BlackBerry device
is typically more than 1 MB
typically requires 1 to 2 hours to download over the wireless network
Features of wireless BlackBerry Device Software updates
Feature
Description
approval of software update packages
that are available
Research In Motion and wireless service providers approve BlackBerry® Device
Software update packages before RIM makes the packages available on the
BlackBerry® Infrastructure.
automatic detection of when new
upgrade packages are available
•
•
control of BlackBerry Device Software
updates
The BlackBerry® Enterprise Server communicates with the BlackBerry
Infrastructure once daily to check for new BlackBerry Device Software update
packages.
The BlackBerry Enterprise Server makes new BlackBerry Device Software
update packages available through the BlackBerry Administration Service.
If you have the appropriate administrative role and permissions on the BlackBerry
Enterprise Server, you can perform the following actions:
15
Types of BlackBerry Device Software update packages
Update Guide
Feature
Description
•
•
automatic backup and restore of data on •
BlackBerry devices
•
send BlackBerry Device Software update requests to supported BlackBerry
devices; users must accept the update within 72 hours, after which their
BlackBerry devices retrieve and install the update packages automatically
control the update process by permitting or restricting upgrade requests to
specific sources and network connection types
The BlackBerry device is designed to back up user data and applications
automatically during the software update process.
The BlackBerry device is designed to restore the backed-up user data and
applications after the update process completes.
Approximate duration of downloading and installing BlackBerry Device Software updates
over the wireless network
The duration of the BlackBerry® Device Software update process depends on the type of update, size of the software update
package, wireless network conditions, and network type.
Type of update
Size of update
package
Approximate
duration of
download
Duration of installation for an Duration of installation for a
average amount of
large amount of BlackBerry
BlackBerry device data
device data (approx 25 MB)
(approx 12 MB)
platform update
500 KB
2 minutes
•
installing the wireless
software update – 5
minutes
•
installing the wireless
software update – 5 minutes
partial software
update
8 MB
15 minutes
•
backing up the
•
BlackBerry device data –
15 to 30 minutes
•
installing the wireless
software update – 30 to
45 minutes
•
restoring the BlackBerry
device data – 15 to 30
minutes
backing up the BlackBerry
device data – 45 minutes
installing the wireless
software update – 30 to 45
minutes
restoring the BlackBerry
device data – 45 minutes
•
•
16
BlackBerry device memory requirements for BlackBerry Device Software updates over the wireless network
Update Guide
Type of update
Size of update
package
Approximate
duration of
download
Duration of installation for an Duration of installation for a
average amount of
large amount of BlackBerry
BlackBerry device data
device data (approx 25 MB)
(approx 12 MB)
complete
software update
15 MB
30 minutes
•
•
•
backing up the
•
BlackBerry device data –
15 to 30 minutes
•
installing the wireless
software upgdate – 30 to
45 minutes
•
restoring the BlackBerry
device data – 15 to 30
minutes
backing up the BlackBerry
device data – 45 minutes
installing the wireless
software update – 30 to 45
minutes
restoring the BlackBerry
device data – 45 minutes
BlackBerry device memory requirements for BlackBerry Device Software
updates over the wireless network
The BlackBerry® device must have 16 MB of RAM and at least 64 MB of flash memory available to start and complete a BlackBerry®
Device Software update over the wireless network.
If the amount of available flash memory on the BlackBerry device decreases to less than 400 KB, the BlackBerry device runs the
LMM automatically to identify and delete unreferenced and cached data associated with BlackBerry device applications such as
the message list, organizer data, and data for third-party applications.
If the update process requires more memory, the LMM deletes medium-priority items such as very old email messages and outof-date calendar entries.
If the minimum amount of memory required is still not available, the BlackBerry device user must delete items manually.
Battery power requirements for BlackBerry Device Software updates over
the wireless network
The battery power level on a BlackBerry® device must be 50 percent or greater for the BlackBerry device to retrieve update
packages over the wireless network. If the battery power level is below the minimum requirement, the update process suspends.
If the battery power level returns to 50 percent, the BlackBerry device continues to retrieve the update package from the BlackBerry
Infrastructure.
17
Update Guide
Permitting the wireless service provider to update the BlackBerry Device Software over the wireless network
Permitting the wireless service provider to update the BlackBerry Device
Software over the wireless network
If you want the wireless service provider to control BlackBerry® Device Software updates using the BlackBerry® Provisioning
System administration web site, you must configure the appropriate IT policy rule. If you permit the wireless service provider to
control BlackBerry Device Software updates, you cannot control BlackBerry Device Software updates using the BlackBerry
Administration Service. The wireless service provider can send only optional BlackBerry Device Software updates to BlackBerry
devices.
Permit wireless service providers to send BlackBerry Device Software update requests to
BlackBerry devices
Before you begin: Verify that you did not configure the BlackBerry® Administration Service to display the BlackBerry® Device
Software pages.
1.
2.
3.
4.
5.
6.
In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Allow Non Enterprise Upgrade IT policy rule to Yes.
Click Save all.
Permit BlackBerry device users to cancel BlackBerry Device Software updates from the
wireless service provider
Users can cancel a BlackBerry® Device Software update over the wireless network if the BlackBerry device installed the BlackBerry
Device Software update, and if you permit the BlackBerry device to accept and complete update cancellation requests. The default
period for the user to request the cancellation of a BlackBerry Device Software update is 24 hours after the update process
completes.
Before you begin: Verify that you did not configure the BlackBerry Administration Service to display BlackBerry Device Software
pages.
1.
2.
3.
4.
18
In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
Update Guide
5.
6.
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
On the Wireless Software Upgrades tab, set the Disallow Device User Requested Rollback IT policy rule to No.
Click Save all.
Permit BlackBerry device users to send BlackBerry Device Software update requests to the
wireless service provider
Before you begin: Verify that you did not configure the BlackBerry® Administration Service to display BlackBerry® Device
Software pages.
1.
2.
3.
4.
5.
6.
In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Disallow Device User Requested Upgrade IT policy rule
to No.
Click Save all.
Create instructions for how users can request BlackBerry Device Software updates from the
wireless service provider
You can create update instructions for BlackBerry® device users so that they can request BlackBerry® Device Software updates
over the wireless network from the wireless service provider.
1. Create an email message that includes the following instructions:
• On the BlackBerry device, in the Options menu, click Advanced Options. Click Wireless Upgrade. Complete the
instructions on the screen.
• Do not remove the battery from the BlackBerry device until the update process completes.
• If prompted, type the BlackBerry device password.
2.
Send the email message.
Using the BlackBerry Enterprise Server to update the BlackBerry Device
Software over the wireless network
If you want to control BlackBerry® Device Software updates, you can configure the BlackBerry Administration Service to display
the required administration pages. If you configure this option, wireless service providers are not permitted to send BlackBerry
Device Software updates and users cannot request BlackBerry Device Software updates from their BlackBerry devices. You can
send only required BlackBerry Device Software updates using the BlackBerry Administration Service.
19
Update Guide
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
By default, only the security and enterprise administrative roles can perform BlackBerry Device Software update tasks and manage
the update process using the BlackBerry Administration Service.
Configure the BlackBerry Administration Service to display BlackBerry Device Software pages
By default, the BlackBerry® Administration Service does not display the BlackBerry® Device Software pages that permit you to
create the BlackBerry Device Software configuration. If you display the BlackBerry Device Software pages in the BlackBerry
Administration Service, the values change for the following IT policy rules in the Wireless Software Upgrades policy group, and
you cannot view or change the IT policy rules:
•
The Allow Non Enterprise Upgrade IT policy rule changes to the default value (No).
•
The Disallow Device User Requested Upgrade IT policy rule changes to the default value (Yes).
•
The Disallow Device User Requested Rollback IT policy rule changes to the default value (Yes).
1.
2.
3.
4.
5.
In the BlackBerry Administration Service, on the Servers and components menu, expand BlackBerry Solution topology
> BlackBerry Domain > Component view > BlackBerry Administration Service.
Click BlackBerry Administration Service.
Click Edit component.
In the Software management section, in the BlackBerry Device Software deployment managed by BlackBerry
Administration Service drop-down list, click Yes.
Click Save All.
After you finish: If you change the BlackBerry Device Software deployment managed by BlackBerry Administration
Service drop-down list to No, the Allow Non Enterprise Upgrade, Disallow Device User Requested Upgrade, and Disallow Device
User Requested Rollback IT policy rules display in the Wireless Software Upgrades policy group and are set to the default values.
Search for BlackBerry Device Software on the BlackBerry Infrastructure
You can search the BlackBerry® Infrastructure for the BlackBerry® Device Software that is available to download so that you can
download the BlackBerry Device Software and configure the BlackBerry® Enterprise Server to update the BlackBerry Device
Software over the wireless network.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Search for new wireless BlackBerry Device Software bundles.
3. Search for the BlackBerry Device Software bundle that you want the users in your organization to update on their BlackBerry
devices.
4. Click Edit BlackBerry Device Software supported bundles.
5. In the New support type drop-down list, click Support for each BlackBerry Device Software version that you want to support.
6. Click Save all.
20
Update Guide
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
Resolve conflicts that occur if you assign multiple BlackBerry Device Software bundles to
groups and user accounts
When you apply a software configuration that includes a BlackBerry® Device Software configuration to groups or user accounts,
the BlackBerry® Enterprise Server sends the BlackBerry Device Software bundle that is the highest priority on the list to the
BlackBerry devices. To resolve conflicts, you can set priorities for the BlackBerry Device Software bundles if more than one
BlackBerry Device Software bundle in a BlackBerry Device Software configuration applies to a BlackBerry device.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Manage BlackBerry Device Software bundles.
3. Search for the BlackBerry Device Software that you want to set the priority for.
4. Click Set priority of BlackBerry Device Software bundles.
5. Click the up and down arrows to move the BlackBerry Device Software bundles higher or lower in the list. Place the BlackBerry
Device Software bundles that are priorities higher in the list.
6. Click Save.
Create a BlackBerry Device Software configuration
You create a BlackBerry® Device Software configuration so that you can create a software configuration that includes the
BlackBerry Device Software, and distribute the BlackBerry Device Software to users.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Create BlackBerry Device Software configuration.
3. In the Configuration data section, type a name and description for the BlackBerry Device Software configuration.
4. Click Save.
5. In the Configuration data section, click the BlackBerry Device Software configuration that you created.
6. Click Edit BlackBerry Device Software configuration.
7. In the Native application settings section, change the settings to meet your organization's requirements.
8. On the BlackBerry Device Software bundles tab, click Add BlackBerry Device Software bundles to BlackBerry Device
Software configuration.
9. Search for the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
10. Select the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
11. Click Add to BlackBerry Device Software configuration.
12. Click Save all.
21
Update Guide
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
Create a software configuration for the BlackBerry Device Software
You can create a software configuration for the BlackBerry® Device Software so that you can distribute the BlackBerry Device
Software to users in your organization and they can install it on their BlackBerry® devices.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software.
2. Click Create a software configuration.
3. In the Configuration data section, type a name for the BlackBerry Device Software configuration.
4. In the Disposition for unlisted applications drop-down list, perform one of the following actions:
• To permit users to install applications that are not included in the software configuration, click Optional.
• To prevent users from installing applications that are not included in the software configuration, click Disallowed.
5.
If you set Disposition for unlisted applications to Optional, in the Application control policy for unlisted
applications drop-down list, click the application control policy for the applications that you did not include in the software
configuration.
6. Click Save.
7. In the Configuration data section, click the name of the software configuration.
8. Click Edit software configuration.
9. In the BlackBerry Device Software configuration section, in the Name drop-down list, click the BlackBerry Device
Software configuration.
10. Click Save all.
After you finish: To make the BlackBerry Device Software available to users, assign the software configuration to the groups or
user accounts that require it.
Assign a software configuration to a group
1.
2.
3.
4.
5.
6.
7.
8.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Group.
Click Manage groups.
Click a group.
Click Edit group.
On the Software configuration tab, in the Available software configurations list, click a software configuration.
Click Add.
Repeat steps 5 and 6 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
22
Update Guide
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
Assign a software configuration to a user account
1.
2.
3.
4.
5.
6.
7.
8.
9.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand User.
Click Manage users.
Search for a user account.
In the search results, click the display name for the user account.
Click Edit user.
On the Software configuration tab, in the Available software configurations list, click the appropriate software
configuration.
Click Add.
Repeat steps 6 and 7 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
How a user can respond to a BlackBerry Device Software update request from the BlackBerry
Enterprise Server
A BlackBerry® Device Software update request provides BlackBerry device users with the following information:
•
•
•
BlackBerry Device Software version
approximate size of the BlackBerry Device Software update package
description of the BlackBerry Device Software update package (optional)
When the BlackBerry device receives a BlackBerry Device Software update request from the BlackBerry® Enterprise Server, the
user can accept or defer the BlackBerry Device Software update.
Response
Description
accept the update request
•
•
The BlackBerry device starts the download process.
The user can monitor the progress of the BlackBerry Device Software download
on the BlackBerry device and continue to use the BlackBerry device, where
this option is permitted by the wireless technology.
23
Update Guide
Response
defer the update request
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
Description
•
When the BlackBerry Device Software download process completes, the
update application checks conditions on the BlackBerry device (for example,
battery life, available memory, network connection) to verify that the update
can proceed, and prompts the user to install the BlackBerry Device Software
update package.
•
A prompt appears on the BlackBerry device every 24 hours to remind the user
to install the BlackBerry Device Software update package.
After 72 hours, the BlackBerry device downloads and installs the BlackBerry
Device Software update package automatically.
•
Monitoring BlackBerry Device Software update requests
If you send BlackBerry® Device Software updates to BlackBerry devices using the BlackBerry® Enterprise Server, you can monitor
the status and progress of the associated jobs and tasks using the BlackBerry Administration Service. For more information about
viewing the status of jobs and tasks and stopping jobs, visit www.blackberry.com/go/serverdocs to read the BlackBerry Enterprise
Server Administration Guide.
Preventing BlackBerry Device Software updates over the wireless network based on the
network connection type
You can prevent BlackBerry® devices from starting or completing BlackBerry® Device Software updates over specific types of
network connections. You might choose to place restrictions for the following reasons:
•
•
•
•
conserve network bandwith
prevent added cost of network usage
verify that BlackBerry Device Software updates only occur over network connections that you consider to be efficient and
reliable
increase security
Upgrading BlackBerry Device Software over a serial bypass connection
If your organization's environment includes an enterprise Wi-Fi® network and a remote BlackBerry® Router in a DMZ, the
environment is designed to bypass the BlackBerry® Infrastructure. If your organization's environment is designed to bypass the
BlackBerry Infrastructure and you have the appropriate administrator role and permissions for the BlackBerry® Enterprise
Server, you can permit BlackBerry device users to download BlackBerry Device Software update packates over a Wi-Fi connection.
24
Update Guide
Using the BlackBerry Enterprise Server to update the BlackBerry Device Software over the wireless network
After the BlackBerry Infrastructure sends the BlackBerry Device Software update package to the BlackBerry Enterprise Server,
the BlackBerry Enterprise Server sends an update request to BlackBerry devices over the wireless network.
To perform the wireless update over a serial bypass connection, the users must connect their BlackBerry devices to computers
that run the BlackBerry® Device Manager.
Prevent BlackBerry device users from downloading BlackBerry Device Software update packages over a
Wi-Fi® connection
1.
2.
3.
4.
5.
6.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Disallow Patch Download Over WiFi IT policy rule to Yes.
Click Save all.
Prevent BlackBerry device users from downloading BlackBerry Device Software update packages over a
WAN connection
1.
2.
3.
4.
5.
6.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Disallow Patch Download Over WAN IT policy rule to Yes.
Click Save all.
Prevent BlackBerry device users from downloading BlackBerry Device Software update packages over a
roaming WAN connection
1.
2.
3.
4.
5.
6.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Disallow Patch Download Over Roaming WAN IT policy
rule to Yes.
Click Save all.
25
Update Guide
Best practice: Preventing possible BlackBerry device issues during the BlackBerry Device Software update process
Prevent BlackBerry device users from downloading BlackBerry Device Software update packages over an
international roaming WAN connection
1.
2.
3.
4.
5.
6.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Policy.
Click Manage IT policies.
Click an IT policy.
Click Edit IT policy.
On the Wireless Software Upgrades tab, change the value of the Disallow Patch Download Over International Roaming
WAN IT policy rule to Yes.
Click Save all.
Best practice: Preventing possible BlackBerry device issues during the
BlackBerry Device Software update process
Scenario
Best practice
The BlackBerry® Device Software update process might not
complete if the user turns off the BlackBerry device.
The BlackBerry Device Software update process might not
complete if the user removes the expandable memory from
the BlackBerry device.
A user cannot make an emergency call on the BlackBerry
device.
Do not turn off the BlackBerry device after the BlackBerry
Device Software update process starts.
Do not remove the expandable memory after the BlackBerry
Device Software update process starts.
Pause or cancel the current BlackBerry Device Software
update process to make an emergency call on the BlackBerry
device.
A user does not receive incoming calls on the BlackBerry
Pause or cancel the current BlackBerry Device Software
device.
update process to receive incoming calls on the BlackBerry
device.
The BlackBerry device might have slow response times and
If the content protection feature is turned on or the BlackBerry
requires user attention if the content protection feature is
device resets after it installs an application, type the password
turned on.
for the BlackBerry device.
The BlackBerry device loses all of its user data if the user starts Do not update the BlackBerry Desktop Software until the
to update the BlackBerry® Desktop Software.
BlackBerry Device Software update process completes.
26
Update Guide
Updating the BlackBerry Device Software at a central computer
Updating the BlackBerry Device Software at a central
computer
5
If you update the BlackBerry® Device Software for users or if you want users to update the BlackBerry Device Software, you or
the users can update the BlackBerry Device Software at a central computer that can access the BlackBerry Administration Service.
Advantages of this update process include:
•
You can monitor the software update process at the central computer.
•
You can use software configurations and application control policies to control when the software updates occur and to
which users.
•
You can update multiple BlackBerry devices simultaneously.
•
You can update BlackBerry devices for users that do not have BlackBerry® Desktop Manager installed on their computers.
•
You can share a single software location among multiple central computers.
A disadvantage of this update process is that you cannot require that users update the BlackBerry Device Software.
Install the BlackBerry Device Software
You must install the BlackBerry® Device Software on a computer so that you can create a software configuration. You use the
software configuration to distribute the BlackBerry Device Software using the BlackBerry® Web Desktop Manager, BlackBerry
Administration Service, BlackBerry® Desktop Manager, or over the wireless network.
Before you begin:
•
Obtain the latest BlackBerry Device Software version for the BlackBerry devices in your organization's environment from
your organization's service provider. The versions must be compatible with the BlackBerry devices and service provider that
your organization uses.
•
Verify that users and the BlackBerry Administration Service can access the computer that you want to install the BlackBerry
Device Software on.
1.
2.
3.
4.
Copy the BlackBerry Device Software installation file to the computer.
Double-click the .exe file.
Complete the instructions on the screen.
When prompted, do not start the application loader tool.
27
Update Guide
Create a shared network folder to access the BlackBerry Device Software
Create a shared network folder to access the BlackBerry Device Software
You can create a shared network folder on the computer where the BlackBerry® Device Software is installed so that BlackBerry
device users and the BlackBerry Administration Service can access the BlackBerry Device Software. The shared network folder
that you create for the BlackBerry Device Software cannot be the same shared network folder that you create for applications.
1. On the computer where the BlackBerry Device Software is installed, navigate to <drive>:\Program Files\Common Files
\Research In Motion.
2. Share the folder with write permissions for the account that is running the BlackBerry Administration Service - Application
Server service.
3. To decrease bandwidth over your organization's LAN, verify that the shared network folder is located in close proximity to
users' computers.
After you finish: Verify that the AppLoader subfolder is writable.
Configure the BlackBerry Administration Service to display BlackBerry
Device Software pages
By default, the BlackBerry® Administration Service does not display the BlackBerry® Device Software pages that permit you to
create the BlackBerry Device Software configuration. If you display the BlackBerry Device Software pages in the BlackBerry
Administration Service, the values change for the following IT policy rules in the Wireless Software Upgrades policy group, and
you cannot view or change the IT policy rules:
•
The Allow Non Enterprise Upgrade IT policy rule changes to the default value (No).
•
The Disallow Device User Requested Upgrade IT policy rule changes to the default value (Yes).
•
The Disallow Device User Requested Rollback IT policy rule changes to the default value (Yes).
1.
2.
3.
4.
5.
In the BlackBerry Administration Service, on the Servers and components menu, expand BlackBerry Solution topology
> BlackBerry Domain > Component view > BlackBerry Administration Service.
Click BlackBerry Administration Service.
Click Edit component.
In the Software management section, in the BlackBerry Device Software deployment managed by BlackBerry
Administration Service drop-down list, click Yes.
Click Save All.
After you finish: If you change the BlackBerry Device Software deployment managed by BlackBerry Administration
Service drop-down list to No, the Allow Non Enterprise Upgrade, Disallow Device User Requested Upgrade, and Disallow Device
User Requested Rollback IT policy rules display in the Wireless Software Upgrades policy group and are set to the default values.
28
Update Guide
Add a shared network folder to the BlackBerry Administration Service
Add a shared network folder to the BlackBerry Administration Service
You can add a shared network folder to the BlackBerry® Administration Service so that the BlackBerry Administration Service
can find the BlackBerry® Device Software that you installed.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Add shared network drive.
3. In the Shared network drive section, perform the following actions:
• In the Name field, type a name for the shared network folder.
• In the Server file path field, type the path to the shared network folder (for example, \\<server>
\<shared_network_folder>, where <server> is the name of the computer that hosts the shared network folder.
4.
Click Save.
Configure the BlackBerry Administration Service to find the BlackBerry
Device Software
To create a BlackBerry® Device Software configuration, you must use the BlackBerry Administration Service to scan the shared
network folder to find the BlackBerry Device Software that you want users to install.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Manage shared network drives.
3. Click a shared network folder.
4. Click Execute shared network drive scan.
After you finish: To verify that the BlackBerry Administration Service found of all the BlackBerry Device Software bundles that
you installed in the shared network folder, on the BlackBerry Device Software bundles tab, verify that the list of BlackBerry
Device Software bundles is complete.
Create a BlackBerry Device Software configuration
You create a BlackBerry® Device Software configuration so that you can create a software configuration that includes the
BlackBerry Device Software, and distribute the BlackBerry Device Software to users.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software > BlackBerry
device software.
2. Click Create BlackBerry Device Software configuration.
3. In the Configuration data section, type a name and description for the BlackBerry Device Software configuration.
29
Update Guide
Create a software configuration for the BlackBerry Device Software
4.
5.
6.
7.
8.
Click Save.
In the Configuration data section, click the BlackBerry Device Software configuration that you created.
Click Edit BlackBerry Device Software configuration.
In the Native application settings section, change the settings to meet your organization's requirements.
On the BlackBerry Device Software bundles tab, click Add BlackBerry Device Software bundles to BlackBerry Device
Software configuration.
9. Search for the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
10. Select the BlackBerry Device Software that you want to add to the BlackBerry Device Software configuration.
11. Click Add to BlackBerry Device Software configuration.
12. Click Save all.
Create a software configuration for the BlackBerry Device Software
You can create a software configuration for the BlackBerry® Device Software so that you can distribute the BlackBerry Device
Software to users in your organization and they can install it on their BlackBerry® devices.
1. In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand Software.
2. Click Create a software configuration.
3. In the Configuration data section, type a name for the BlackBerry Device Software configuration.
4. In the Disposition for unlisted applications drop-down list, perform one of the following actions:
• To permit users to install applications that are not included in the software configuration, click Optional.
• To prevent users from installing applications that are not included in the software configuration, click Disallowed.
5.
If you set Disposition for unlisted applications to Optional, in the Application control policy for unlisted
applications drop-down list, click the application control policy for the applications that you did not include in the software
configuration.
6. Click Save.
7. In the Configuration data section, click the name of the software configuration.
8. Click Edit software configuration.
9. In the BlackBerry Device Software configuration section, in the Name drop-down list, click the BlackBerry Device
Software configuration.
10. Click Save all.
After you finish: To make the BlackBerry Device Software available to users, assign the software configuration to the groups or
user accounts that require it.
30
Update Guide
Assign a software configuration to a group
Assign a software configuration to a group
1.
2.
3.
4.
5.
6.
7.
8.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand Group.
Click Manage groups.
Click a group.
Click Edit group.
On the Software configuration tab, in the Available software configurations list, click a software configuration.
Click Add.
Repeat steps 5 and 6 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
Assign a software configuration to a user account
1.
2.
3.
4.
5.
6.
7.
8.
9.
In the BlackBerry® Administration Service, on the BlackBerry solution management menu, expand User.
Click Manage users.
Search for a user account.
In the search results, click the display name for the user account.
Click Edit user.
On the Software configuration tab, in the Available software configurations list, click the appropriate software
configuration.
Click Add.
Repeat steps 6 and 7 for each software configuration that you want to assign.
Click Save all.
Related topics
Managing the distribution of BlackBerry Device Software, 38
Update the BlackBerry Device Software at a central computer
Before you begin:
•
Verify that the central computer can access the BlackBerry® Administration Service.
•
To decrease bandwidth over your organization's LAN, verify that the shared network folder is located in close proximity to
the central computer.
31
Update Guide
1.
2.
3.
4.
5.
32
Update the BlackBerry Device Software at a central computer
Connect a BlackBerry device to the central computer.
In the BlackBerry Administration Service, on the Devices menu, expand Attached devices.
Click Device software.
In the Application loader section, click Automatic installation of applications on the BlackBerry device.
Complete the instructions on the screen.
Update Guide
Permitting users to update the BlackBerry Device Software using the application loader tool
Permitting users to update the BlackBerry Device Software
using the application loader tool
6
To permit users to update the BlackBerry® Device Software on computers that do not have the BlackBerry® Desktop Software
installed, you can make the BlackBerry Device Software installation file available to users and instruct them to update the
BlackBerry Device Software using the application loader tool.
Advantages of this update process include:
•
You can automate the BlackBerry Device Software update process so that users do not have to complete update tasks for
BlackBerry devices that they connect to their computers using a USB connection.
•
You can update BlackBerry devices remotely.
•
Users do not require theBlackBerry Desktop Software on their computers.
Disadvantages of this update process include:
•
You cannot manage BlackBerry Device Software updates using software configurations.
•
You cannot require that users update the BlackBerry Device Software.
•
This update option increases traffic to the network drive.
After users update the BlackBerry Device Software, the application loader tool connects to the messaging server to provision the
BlackBerry devices.
Send the BlackBerry Device Manager installation file to users' computers
You can send the BlackBerry® Device Manager to users so that they can perform actions such as charge their BlackBerry devices,
synchronize organizer items using the BlackBerry Router, and update the BlackBerry® Device Software on their computers.
Note: If you send the BlackBerry Device Manager installation file to computers that host the BlackBerry® Desktop Manager,
the installation process of the BlackBerry Device Manager removes the BlackBerry Desktop Manager automatically and users
lose the BlackBerry device management options that the BlackBerry Desktop Manager provides.
1. Visit www.blackberry.com/support/downloads to download the installation file for the BlackBerry Device Manager.
2. Copy the installation file that you downloaded to a shared network folder.
3. Send users an email message that includes the following information:
• location of the installation file in the shared network folder
• instructions to double-click the .msi file
33
Update Guide
Install the BlackBerry Device Software
Install the BlackBerry Device Software
You must install the BlackBerry® Device Software on a computer so that you can create a software configuration. You use the
software configuration to distribute the BlackBerry Device Software using the BlackBerry® Web Desktop Manager, BlackBerry
Administration Service, BlackBerry® Desktop Manager, or over the wireless network.
Before you begin:
•
Obtain the latest BlackBerry Device Software version for the BlackBerry devices in your organization's environment from
your organization's service provider. The versions must be compatible with the BlackBerry devices and service provider that
your organization uses.
•
Verify that users and the BlackBerry Administration Service can access the computer that you want to install the BlackBerry
Device Software on.
1.
2.
3.
4.
Copy the BlackBerry Device Software installation file to the computer.
Double-click the .exe file.
Complete the instructions on the screen.
When prompted, do not start the application loader tool.
Create a shared network folder to access the BlackBerry Device Software
You can create a shared network folder on the computer where the BlackBerry® Device Software is installed so that BlackBerry
device users and the BlackBerry Administration Service can access the BlackBerry Device Software. The shared network folder
that you create for the BlackBerry Device Software cannot be the same shared network folder that you create for applications.
1. On the computer where the BlackBerry Device Software is installed, navigate to <drive>:\Program Files\Common Files
\Research In Motion.
2. Share the folder with write permissions for the account that is running the BlackBerry Administration Service - Application
Server service.
3. To decrease bandwidth over your organization's LAN, verify that the shared network folder is located in close proximity to
users' computers.
After you finish: Verify that the AppLoader subfolder is writable.
34
Update Guide
Create the BlackBerry Device Software update instructions for users that use the application loader tool
Create the BlackBerry Device Software update instructions for users that use
the application loader tool
You can create update instructions for BlackBerry® device users so that they can update the BlackBerry® Device Software when
they use the BlackBerry® Device Manager and application loader tool.
1. Create an email message that specifies the following loading commands based on the type of connection that a BlackBerry
device uses:
• for a USB connection, \\<shared_computer_name>\Research In Motion\Apploader\loader.exe /defaultUSB /forceload
• for a serial connection, \\<shared_computer_name>\Research In Motion\Apploader\loader.exe
2.
Consider providing the following instructions in the email message:
• Connect your BlackBerry device to your computer.
• Do not disconnect your BlackBerry device from your computer until the update process completes.
• If prompted, type the BlackBerry device password. Click Next.
• If the BlackBerry device uses a serial connection, complete the instructions on the screen.
• If your organization's environment includes the BlackBerry® Enterprise Server for Microsoft® Exchange or BlackBerry®
Enterprise Server for IBM® Lotus® Domino®, if prompted, select the Provision the device during the loading
process option. Select the messaging server that the user account is located on.
• If your organization's environment includes the BlackBerry® Enterprise Server for Novell® GroupWise®, if prompted,
select the Do not provision the device during the loading process option.
• If your organization's environment includes the BlackBerry Enterprise Server for Novell GroupWise, after the update
process completes, activate your BlackBerry device over the wireless network.
3.
Send the email message.
35
Update Guide
Pushing the BlackBerry Device Software and BlackBerry Desktop Software to users' computers
Pushing the BlackBerry Device Software and BlackBerry
Desktop Software to users' computers
7
You can use third-party applications to create a single executable file that contains the BlackBerry® Desktop Software and
BlackBerry® Device Software, and send the executable file to the computers of the users in your organization. The executable
file uses the application loader tool on the computer to update the BlackBerry Device Software on BlackBerry devices.
You can use this update option if you update from BlackBerry Device Software version 3.5 or earlier.
Advantages of this update process include:
•
You can install the BlackBerry Device Software and BlackBerry Desktop Software on computers automatically.
•
You can set an IT policy to require that users update the BlackBerry Device Software.
A disadvantage of this update process is that you must distribute large update packages over your organization's LAN.
The executable file installs the BlackBerry Desktop Software and BlackBerry Device Software on the computers of users in your
organization. To update the BlackBerry Device Software on BlackBerry devices, users can connect their BlackBerry devices to
their computers and start the BlackBerry® Desktop Manager.
Create a shared network folder to access the BlackBerry Device Software
You can create a shared network folder on the computer where the BlackBerry® Device Software is installed so that BlackBerry
device users and the BlackBerry Administration Service can access the BlackBerry Device Software. The shared network folder
that you create for the BlackBerry Device Software cannot be the same shared network folder that you create for applications.
1. On the computer where the BlackBerry Device Software is installed, navigate to <drive>:\Program Files\Common Files
\Research In Motion.
2. Share the folder with write permissions for the account that is running the BlackBerry Administration Service - Application
Server service.
3. To decrease bandwidth over your organization's LAN, verify that the shared network folder is located in close proximity to
users' computers.
After you finish: Verify that the AppLoader subfolder is writable.
Save the BlackBerry Device Software installation file to the network drive
Before you begin: Obtain the BlackBerry® Device Software installation files from your organization's service provider.
1.
2.
36
On the network drive, in the installation folder, create a folder that is named Device.
Save the BlackBerry Device Software installation file to the folder.
Update Guide
Save the BlackBerry Desktop Software installation file to the network drive
Save the BlackBerry Desktop Software installation file to the network drive
1.
2.
3.
4.
5.
6.
7.
Download the BlackBerry® Desktop Software installation file from www.blackberry.com/support/downloads.
Save the installation file that you downloaded to the network drive.
If necessary, extract the installation files from the .exe file to the network drive.
On the network drive, open setup.ini.
At the bottom of setup.ini, type [INSTALL_OPTIONS].
To add the installation settings, use install.txt, which is included with the BlackBerry Desktop Software installation files.
Save setup.ini.
Send the installation files for the BlackBerry Desktop Software and
BlackBerry Device Software to users using a third-party application
You can update the BlackBerry® Desktop Software and BlackBerry® Desktop Manager by pushing the software to users' computers
using a third-party application.
1. If your organization's environment includes BlackBerry® Enterprise Server for Microsoft® Exchange, to record the customized
settings in the BlackBerry Desktop Software installation files so that you can create a custom software package, at a command
prompt, type one of the following commands:
• For BlackBerry Desktop Manager users, type \\<shared computer name>\setup.exe /s
• For BlackBerry Desktop Manager users who also use the certificate synchronization tool, type \\<shared computer
name>\setup.exe /s /v "INSTALLLEVEL=125"
2.
3.
4.
If your organizaton's environment includesBlackBerry® Enterprise Server for IBM® Lotus® Domino® or BlackBerry®
Enterprise Server for Novell® GroupWise®, to record the customized settings in the BlackBerry Desktop Software installation
files so that you can create a custom software package, at a command prompt, type \\<shared computer name>
\setup.exe /s.
Package the customized installation files for the BlackBerry Desktop Software and BlackBerry® Device Software using a
third-party application for software packaging.
Send the installation files using a third-party application for software distribution.
After you finish: To make sure that users update the BlackBerry Device Software, set the Force Load Count IT policy rule and
the Force Load Message IT policy rule. For more information, see the BlackBerry Enterprise Server Policy Reference Guide.
37
Managing the distribution of BlackBerry Device Software
Update Guide
Managing the distribution of BlackBerry Device Software
8
Change how to install, update, or remove the BlackBerry Device Software
You can change the settings that the BlackBerry® Administration Service uses to install or upgrade the BlackBerry® Device
Software on BlackBerry devices or remove the BlackBerry Device Software from BlackBerry devices. If you change the default
distribution settings for the BlackBerry Device Software, your organization's environment might experience a performance impact.
1. In the BlackBerry Administration Service, on the Devices menu, expand Deployment jobs.
2. Click Specify BlackBerry Device Software distribution settings.
3. Click Edit distribution settings.
4. Perform any of the following tasks:
Task
Steps
Change the recurrence day for
installing, updating, or removing the
BlackBerry Device Software.
a.
Click the Edit icon for the recurrence day.
b.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, select the recurrence days.
c.
In the Start time drop-down list, click the appropriate option. If necessary,
change the start time and end time.
d.
Click the Update icon.
Add a recurrence day for installing,
updating, or removing the BlackBerry
Device Software.
5.
38
By default, the recurrence day is Every day and the start time is All day.
To add more than one recurrence day, the schedules for the separate recurrence
days cannot overlap.
a.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, select the recurrence days.
b.
In the Start time drop-down list, click the appropriate option. If necessary,
change the start time and end time.
c.
Click the Add icon.
On the System throttling tab, in the Maximum number of simultaneous tasks per BlackBerry Administration Service
instance field, type the maximum number of BlackBerry Device Software tasks that you want the BlackBerry Enterprise
Server to process at the same time.
The default value is 1000.
Update Guide
6.
7.
8.
9.
Change how the BlackBerry Enterprise Server sends standard application settings to BlackBerry devices
To turn on throttling for all BlackBerry Device Software tasks in jobs, on the Job throttling tab, click Enabled to reduce
load on system.
If necessary, in the Default throttling for all BlackBerry Device Software tasks in each job in a time window section,
in the Maximum number of simultaneous tasks per BlackBerry Administration Service instance field, type the
maximum number of BlackBerry Device Software tasks that you want the BlackBerry Enterprise Server to process at the
same time.
The default value is 25.
If necessary, in the Total number of tasks per time window per BlackBerry Administration Service instance field, type
the total number of BlackBerry Device Software tasks that you want the BlackBerry Enterprise Server to process during each
processing interval.
The default value is 150.
Click Save all.
Change how the BlackBerry Enterprise Server sends standard application
settings to BlackBerry devices
BlackBerry® Device Software configurations include standard application settings that you can use to control calendar, email,
and contact list settings on BlackBerry devices. You can change how the BlackBerry® Enterprise Server sends the settings to and
updates the settings on BlackBerry devices. If you change the default distribution settings for the standard application settings,
your organization's environment might experience a performance impact.
1. In the BlackBerry Administration Service, on the Devices menu, expand Deployment jobs.
2. Click Specify BlackBerry Device Software application distribution settings.
3. Click Edit distribution settings.
4. Perform any of the following tasks:
Task
Steps
Change the recurrence day for
sending or updating standard
application settings.
a.
Click the Edit icon for the default recurrence day.
b.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, click the recurrence days.
c.
In the Start time drop-down list, click the appropriate recurrence option.
If necessary, change the start time and end time.
d.
Click the Update icon.
By default, the recurrence day is Every day and the start time is All day.
39
Change how a job sends the BlackBerry Device Software to BlackBerry devices
Update Guide
5.
6.
7.
8.
9.
Task
Steps
Add a recurrence day for sending or
updating standard application
settings.
To add more than one recurrence day, the schedules for the separate recurrence
days cannot overlap.
a.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, click the recurrence days.
b.
In the Start time drop-down list, click the appropriate recurrence option.
If necessary, change the start time and end time.
c.
Click the Add icon.
On the System throttling tab, in the System throttling across all jobs section, in the Maximum number of simultaneous
tasks per BlackBerry Administration Service instance field, type the maximum number of tasks that you want the
BlackBerry Enterprise Server to process at the same time.
The default value is 1000.
To turn on throttling for all tasks for standard application settings in jobs, on the Job throttling tab, click Enabled to reduce
load on system.
If necessary, in the Default throttling for all BlackBerry Device Software application settings tasks in each job in a
time window section, in the Maximum number of simultaneous tasks per BlackBerry Administration Service
instance field, type the maximum number of tasks for standard application settings that you want the BlackBerry Enterprise
Server to process at the same time.
The default value is 25.
If necessary, in the Total number of tasks per time window per BlackBerry Administration Service instance field, type
the total number of tasks for standard application settings that you want the BlackBerry Enterprise Server to process during
each processing interval.
The default value is 150.
Click Save all.
Change how a job sends the BlackBerry Device Software to BlackBerry
devices
You can change how the BlackBerry® Administration Service installs, updates, or removes the BlackBerry® Device Software in a
specific job on BlackBerry devices. You can change the distribution settings for a job for the BlackBerry Device Software only if
the job is not running. If you change the default distribution settings for BlackBerry Device Software, your organization's
environment might experience a performance impact.
1. In the BlackBerry Administration Service, on the Devices menu, expand Deployment jobs.
2. Click Manage deployment jobs.
3. Search for a job.
40
Change how a job sends the BlackBerry Device Software to BlackBerry devices
Update Guide
4.
5.
6.
In the search results, click the ID of the appropriate job.
Click Edit job.
On the BlackBerry Device Software Distribution tab, perform any of the following tasks:
Task
Steps
Change the recurrence day for
installing, updating, or removing
BlackBerry Device Software.
a.
Click the Edit icon for the recurrence day.
b.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, click the number of recurrence days.
c.
In the Start time drop-down list, click the appropriate option. If necessary,
change the start time and end time.
d.
Click the Update icon.
Add a new recurrence day for
installing, updating, or removing
BlackBerry Device Software.
By default, the recurrence day is Every day and the start time is All day.
To add more than one recurrence day, the schedules for the separate recurrence
days cannot overlap.
a.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, click the recurrence days.
b.
In the Start time drop-down list, click the appropriate recurrence option.
If necessary, change the start time and end time.
c.
Click the Add icon.
7.
To turn on throttling for all BlackBerry Device Software tasks in jobs, on the Default throttling enablement for all
BlackBerry Device Software tasks in each job in a time window section, click Enabled to reduce load on system.
8. If necessary, in the Default throttling for all BlackBerry Device Software tasks in each job in a time window section,
in the Maximum number of simultaneous tasks per BlackBerry Administration Service instance field, type the
maximum number of BlackBerry Device Software tasks in the job that you want the BlackBerry® Enterprise Server to process
at the same time.
The default value is 25.
9. If necessary, in the Total number of tasks per time window per BlackBerry Administration Service instance field, type
the total number of BlackBerry Device Software tasks in the job that you want the BlackBerry Enterprise Server to process
during each processing interval.
The default value is 150.
10. Click Save all.
41
Change how a job sends standard application settings to BlackBerry devices
Update Guide
Change how a job sends standard application settings to BlackBerry devices
BlackBerry® Device Software configurations include standard application settings that you can use to control calendar, email,
and contact list settings on BlackBerry devices. You can change how the BlackBerry Administration Service sends settings and
updates in jobs to BlackBerry devices. If you change the default distribution settings for the standard application settings in
BlackBerry Device Software configurations, your organization's environment might experience a performance impact.
1. In the BlackBerry Administration Service, on the Devices menu, expand Deployment jobs.
2. Click Manage deployment jobs.
3. Search for a job.
4. In the search results, click the ID of the appropriate job.
5. Click Edit job.
6. On the BlackBerry Device Software Application Settings Distribution tab, perform any of the following tasks:
Task
Steps
Change the recurrence day for
sending or updating standard
application settings.
a.
Click the Edit icon for the recurrence day.
b.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, select the number of recurrence days.
c.
In the Start time drop-down list, click the appropriate recurrence option.
If necessary, change the start time and end time.
d.
Click the Update icon.
Add a recurrence day for sending or
updating standard application
settings.
7.
42
By default, the recurrence day is Every day and the start time is All day.
To add more than one recurrence day, the schedules for the separate recurrence
days cannot overlap.
a.
In the Scheduled deployment day(s) drop-down list, click the appropriate
recurrence option. If necessary, click the recurrence days.
b.
In the Start time drop-down list, click the appropriate recurrence option.
If necessary, change the start time and end time.
c.
Click the Add icon.
To turn on throttling for all tasks for standard application settings in the job, in the Default throttling enablement for all
BlackBerry Device Software application tasks in each job in a time window section, click Enabled to reduce load on
system.
Update Guide
Change how a job sends standard application settings to BlackBerry devices
8.
If necessary, in the Default throttling for all BlackBerry Device Software Application Settings tasks in each job in a
time window section, in the Maximum number of simultaneous tasks per BlackBerry Administration Service
instance field, type the maximum number of tasks for standard application settings in the job that you want the BlackBerry®
Enterprise Server to process at the same time.
The default value is 25.
9. If necessary, in the Total number of tasks per time window per BlackBerry Administration Service instance field, type
the total number of tasks for standard application settings in the job that you want the BlackBerry Enterprise Server to
process during each processing interval.
The default value is 150.
10. Click Save all.
43
Update Guide
Troubleshooting
Troubleshooting
9
Verify that the BlackBerry Device Software update process completed
You can verify that users updated the BlackBerry® Device Software.
1.
2.
3.
4.
5.
In the BlackBerry Administration Service, on the BlackBerry solution management menu, expand User.
Click Manage users.
Search for a user account.
In the search results, click the PIN for the user account.
On the Device information page, in the Software section, verify that the version information in the Version field is correct.
A user cannot start the update process using the link to the application loader
tool
Possible cause
The permissions for the application loader tool might not be set to shared.
Possible solution
1.
2.
Connect the user's BlackBerry® device to a computer that hosts the BlackBerry Administration Service.
At the command prompt, type \\<shared_network_drive>\Research In Motion\Apploader\loader.exe.
If the application loader tool starts, the permissions for the application loader tool are shared successfully.
44
Update Guide
Glossary
Glossary
10
.alx file
A .alx file is the application descriptor that provides information about a BlackBerry Java® Application and the location of
the application's .cod files to a BlackBerry device.
.cod file
A .cod file contains compiled and packaged application code that a BlackBerry device uses to run a BlackBerry Java®
Application.
LAN
A local area network (LAN) is a computer network shared by a group of computers in a small area, such as an office building.
Any computer in this network can communicate with another computer that is part of the same network.
LMM
The Low Memory Manager (LMM) is an application on the BlackBerry device that deletes medium-priority items, such as old
email messages and out-of-date calendar entries, when the amount of available flash memory on the BlackBerry device is
less than 400 KB.
messaging server
A messaging server sends and processes messages and provides collaboration services, such as updating and communicating
calendar and address book information.
S/MIME
Secure Multipurpose Internet Mail Extensions
45
Update Guide
Provide feedback
To provide feedback on this deliverable, visit www.blackberry.com/docsfeedback.
46
Provide feedback
11
Update Guide
Legal notice
Legal notice
12
©2009 Research In Motion Limited. All rights reserved. BlackBerry®, RIM®, Research In Motion®, SureType®, SurePress™ and
related trademarks, names, and logos are the property of Research In Motion Limited and are registered and/or used in the U.S.
and countries around the world.
IBM, Domino, and Lotus are trademarks of International Business Machines Corporation. Microsoft is a trademark of Microsoft
Corporation. Novell and GroupWise are trademarks of Novell, Inc. All other trademarks are the property of their respective owners.
The BlackBerry smartphone and other devices and/or associated software are protected by copyright, international treaties, and
various patents, including one or more of the following U.S. patents: 6,278,442; 6,271,605; 6,219,694; 6,075,470; 6,073,318;
D445,428; D433,460; D416,256. Other patents are registered or pending in the U.S. and in various countries around the world.
Visit www.rim.com/patents for a list of RIM (as hereinafter defined) patents.
This documentation including all documentation incorporated by reference herein such as documentation provided or made
available at www.blackberry.com/go/docs is provided or made accessible "AS IS" and "AS AVAILABLE" and without condition,
endorsement, guarantee, representation, or warranty of any kind by Research In Motion Limited and its affiliated companies
("RIM") and RIM assumes no responsibility for any typographical, technical, or other inaccuracies, errors, or omissions in this
documentation. In order to protect RIM proprietary and confidential information and/or trade secrets, this documentation may
describe some aspects of RIM technology in generalized terms. RIM reserves the right to periodically change information that
is contained in this documentation; however, RIM makes no commitment to provide any such changes, updates, enhancements,
or other additions to this documentation to you in a timely manner or at all.
This documentation might contain references to third-party sources of information, hardware or software, products or services
including components and content such as content protected by copyright and/or third-party web sites (collectively the "Third
Party Products and Services"). RIM does not control, and is not responsible for, any Third Party Products and Services including,
without limitation the content, accuracy, copyright compliance, compatibility, performance, trustworthiness, legality, decency,
links, or any other aspect of Third Party Products and Services. The inclusion of a reference to Third Party Products and Services
in this documentation does not imply endorsement by RIM of the Third Party Products and Services or the third party in any way.
EXCEPT TO THE EXTENT SPECIFICALLY PROHIBITED BY APPLICABLE LAW IN YOUR JURISDICTION, ALL CONDITIONS,
ENDORSEMENTS, GUARANTEES, REPRESENTATIONS, OR WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY CONDITIONS, ENDORSEMENTS, GUARANTEES, REPRESENTATIONS OR WARRANTIES OF
DURABILITY, FITNESS FOR A PARTICULAR PURPOSE OR USE, MERCHANTABILITY, MERCHANTABLE QUALITY, NONINFRINGEMENT, SATISFACTORY QUALITY, OR TITLE, OR ARISING FROM A STATUTE OR CUSTOM OR A COURSE OF DEALING
OR USAGE OF TRADE, OR RELATED TO THE DOCUMENTATION OR ITS USE, OR PERFORMANCE OR NON-PERFORMANCE
OF ANY SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD PARTY PRODUCTS AND SERVICES REFERENCED HEREIN, ARE
HEREBY EXCLUDED. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR PROVINCE. SOME JURISDICTIONS
MAY NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES AND CONDITIONS. TO THE EXTENT
PERMITTED BY LAW, ANY IMPLIED WARRANTIES OR CONDITIONS RELATING TO THE DOCUMENTATION TO THE EXTENT
THEY CANNOT BE EXCLUDED AS SET OUT ABOVE, BUT CAN BE LIMITED, ARE HEREBY LIMITED TO NINETY (90) DAYS FROM
THE DATE YOU FIRST ACQUIRED THE DOCUMENTATION OR THE ITEM THAT IS THE SUBJECT OF THE CLAIM.
47
Update Guide
Legal notice
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, IN NO EVENT SHALL RIM BE LIABLE
FOR ANY TYPE OF DAMAGES RELATED TO THIS DOCUMENTATION OR ITS USE, OR PERFORMANCE OR NONPERFORMANCE OF ANY SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD PARTY PRODUCTS AND SERVICES REFERENCED
HEREIN INCLUDING WITHOUT LIMITATION ANY OF THE FOLLOWING DAMAGES: DIRECT, CONSEQUENTIAL, EXEMPLARY,
INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR AGGRAVATED DAMAGES, DAMAGES FOR LOSS OF PROFITS OR REVENUES,
FAILURE TO REALIZE ANY EXPECTED SAVINGS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, LOSS OF
BUSINESS OPPORTUNITY, OR CORRUPTION OR LOSS OF DATA, FAILURES TO TRANSMIT OR RECEIVE ANY DATA, PROBLEMS
ASSOCIATED WITH ANY APPLICATIONS USED IN CONJUNCTION WITH RIM PRODUCTS OR SERVICES, DOWNTIME COSTS,
LOSS OF THE USE OF RIM PRODUCTS OR SERVICES OR ANY PORTION THEREOF OR OF ANY AIRTIME SERVICES, COST OF
SUBSTITUTE GOODS, COSTS OF COVER, FACILITIES OR SERVICES, COST OF CAPITAL, OR OTHER SIMILAR PECUNIARY
LOSSES, WHETHER OR NOT SUCH DAMAGES WERE FORESEEN OR UNFORESEEN, AND EVEN IF RIM HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, RIM SHALL HAVE NO OTHER
OBLIGATION, DUTY, OR LIABILITY WHATSOEVER IN CONTRACT, TORT, OR OTHERWISE TO YOU INCLUDING ANY LIABILITY
FOR NEGLIGENCE OR STRICT LIABILITY.
THE LIMITATIONS, EXCLUSIONS, AND DISCLAIMERS HEREIN SHALL APPLY: (A) IRRESPECTIVE OF THE NATURE OF THE
CAUSE OF ACTION, DEMAND, OR ACTION BY YOU INCLUDING BUT NOT LIMITED TO BREACH OF CONTRACT, NEGLIGENCE,
TORT, STRICT LIABILITY OR ANY OTHER LEGAL THEORY AND SHALL SURVIVE A FUNDAMENTAL BREACH OR BREACHES
OR THE FAILURE OF THE ESSENTIAL PURPOSE OF THIS AGREEMENT OR OF ANY REMEDY CONTAINED HEREIN; AND (B)
TO RIM AND ITS AFFILIATED COMPANIES, THEIR SUCCESSORS, ASSIGNS, AGENTS, SUPPLIERS (INCLUDING AIRTIME
SERVICE PROVIDERS), AUTHORIZED RIM DISTRIBUTORS (ALSO INCLUDING AIRTIME SERVICE PROVIDERS) AND THEIR
RESPECTIVE DIRECTORS, EMPLOYEES, AND INDEPENDENT CONTRACTORS.
IN ADDITION TO THE LIMITATIONS AND EXCLUSIONS SET OUT ABOVE, IN NO EVENT SHALL ANY DIRECTOR, EMPLOYEE,
AGENT, DISTRIBUTOR, SUPPLIER, INDEPENDENT CONTRACTOR OF RIM OR ANY AFFILIATES OF RIM HAVE ANY LIABILITY
ARISING FROM OR RELATED TO THE DOCUMENTATION.
Prior to subscribing for, installing, or using any Third Party Products and Services, it is your responsibility to ensure that your
airtime service provider has agreed to support all of their features. Some airtime service providers might not offer Internet browsing
functionality with a subscription to the BlackBerry® Internet Service. Check with your service provider for availability, roaming
arrangements, service plans and features. Installation or use of Third Party Products and Services with RIM's products and services
may require one or more patent, trademark, copyright, or other licenses in order to avoid infringement or violation of third party
rights. You are solely responsible for determining whether to use Third Party Products and Services and if any third party licenses
are required to do so. If required you are responsible for acquiring them. You should not install or use Third Party Products and
Services until all necessary licenses have been acquired. Any Third Party Products and Services that are provided with RIM's
products and services are provided as a convenience to you and are provided "AS IS" with no express or implied conditions,
endorsements, guarantees, representations, or warranties of any kind by RIM and RIM assumes no liability whatsoever, in relation
thereto. Your use of Third Party Products and Services shall be governed by and subject to you agreeing to the terms of separate
licenses and other agreements applicable thereto with third parties, except to the extent expressly covered by a license or other
agreement with RIM.
Certain features outlined in this documentation require a minimum version of BlackBerry® Enterprise Server, BlackBerry® Desktop
Software, and/or BlackBerry® Device Software.
48
Update Guide
Legal notice
The terms of use of any RIM product or service are set out in a separate license or other agreement with RIM applicable thereto.
NOTHING IN THIS DOCUMENTATION IS INTENDED TO SUPERSEDE ANY EXPRESS WRITTEN AGREEMENTS OR WARRANTIES
PROVIDED BY RIM FOR PORTIONS OF ANY RIM PRODUCT OR SERVICE OTHER THAN THIS DOCUMENTATION.
Certain features outlined in this documentation might require additional development or Third Party Products and Services for
access to corporate applications.
This product contains a modified version of HTML Tidy. Copyright © 1998-2003 World Wide Web Consortium (Massachusetts
Institute of Technology, European Research Consortium for Informatics and Mathematics, Keio University). All Rights Reserved.
This product includes software developed by the Apache Software Foundation (www.apache.org/) and/or is licensed pursuant
to one of the licenses listed at (www.apache.org/licenses/). For more information, see the NOTICE.txt file included with the
software.
Research In Motion Limited
295 Phillip Street
Waterloo, ON N2L 3W8
Canada
Research In Motion UK Limited
Centrum House
36 Station Road
Egham, Surrey TW20 9LF
United Kingdom
Published in Canada
49
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
