hp digital projector vp6100 series hp digital projector

hp digital projector vp6100 series hp digital projector
hp digital
projector
vp6100 series
hp digital projector vp6100 series
Create clear, sharp, detailed on-screen images in your office, classroom or small meeting room with
a HP Digital Projector vp6100 series projector. Powerful yet quiet, they are portable and easy to
operate and HP quality ensures durability.
Ideal for people working in education, mobile professionals and first-time users who need a good
value projector which offers high brightness and is simple to set up and use. Its portability makes
it easy to move between different locations and to share with other users.
Produce big results for a small investment and see your presentations come to life.
• High brightness of 1500* or even 2000** lumens improves visibility of the projected image
and gives you flexibility to present in different lighting conditions.
• Make a powerful impact: distinct 800 x 600 SVGA resolution* or 1024 x 768 XGA resolution**
ensure text is easy to read, graphics are precise and images are realistic and accurate.
• A high contrast ratio of 1200:1 enhances the clarity of projected text and images to produce
projections that are easy to see and understand.
Be as mobile as you need with this conveniently portable and easy-to-use projector.
• Get going quickly as the on-screen display is intuitive and the menus are quickly understood
and mastered.
• No tiresome delays as the presentation source (a PC, VCR, PDA or other device) is automatically
detected and the resolution is automatically scaled.
• Maintain seamless control by keeping track of your presentations via an external monitor.
• Weighing only 3 kg (6.6 lb), the projector is easily portable and can be ceiling-mounted.
Its compact design makes it easy to store securely.
Engineered for robustness and durability to deliver performance you can depend on.
• Quiet operation means a better experience for you and your audience and for enhanced audio
you can use the small, effective 3 watt speaker.
• Convey your message dynamically using the S-video or component inputs for clear, smooth video
projections to create presentations with impact.
• Integrate all the components of your presentation seamlessly using the various ports available:
Connect your computer, PDA, video or DVD player or even a game console.
* HP Digital Projector vp6110
**HP Digital Projector vp6120
hp digital projector vp6100 series
hp digital
projector
vp6100 series
technical specifications
ordering information
brightness
HP Digital Projector vp6110: 1500 lumens
HP Digital Projector vp6120: 2000 lumens
native display resolution
HP Digital Projector vp6110: Native SVGA (800 x 600)
HP Digital Projector vp6120: Native XGA (1024 x 768)
resolutions supported through scaling
HP Digital Projector vp6110: Scales up from VGA (640 x 480) and scales down from XGA (1024 x 768)
HP Digital Projector vp6120: Scales up from SVGA (800 x 600) and scales down from SXGA (1280 x 1024)
weight
3 kg
dimensions
HP Digital Projector vp6110/vp6120: 308 x 238 x 95 mm; packaged: 460 x 455 x 293 mm
images technology
HP Digital Projector vp6110/vp6120: DLP technology with 0.55" 12 degrees tilt DMD
image contrast
HP Digital Projector vp6110/vp6120: 1200:1 Full on/off
noise level
HP Digital Projector vp6110/vp6120: 35 dB(A) under 25º C; 32 dB(A) in lamp saving mode
audio
One 4 ohm 3W speaker
colour
24-bit, 16.7 million colours
L1595A
hp digital projector vp6110,
user manual on CD, quick set-up
guide, warranty information, video
port instruction card, power cord,
VGA cable, RCA cable, PC audio cable,
credit card remote control, battery
L1596A
hp digital projector vp6120,
as above
accessories & supplies
L1624A
lamp module vp6100
L1629A
carry case vp6100
L1630A
ceiling mount kit vp6100
L1631A
remote control premium with
USB cable
lens
F/2.6, f=23.2 to 28.38 mm with 1.2:1 manual zoom and manual focus
L1633A
screen mobile 60" standard
projection size
HP Digital Projector vp6110: 0.74 to 4.76 m (diagonal)
HP Digital Projector vp6120: 0.95 to 6.09 m (diagonal)
L1634A
cable, component video 1.8 m
L1635A
cable, S-video 1.8 m
throw distance
1.5 to 8 m
frequency
HP Digital Projector vp6110/vp6120: horizontal frequency: 15-81 kHz, vertical frequency: 50-100 Hz
keystoning
±7º (14º total) vertical keystoning except 1080i/1035i
Advanced electronic keystone correction
signal interface
HP Digital Projector vp6110/vp6120: Input: 15-pin VGA input connector, YPbPr RCA jack (green/red/blue),
video RCA jack (yellow), audio RCA jack (white/red), 3.5 mm stereo mini jack, S-video connector, UART
mini-DIN 8-pin connector; output: B-type USB terminal for mouse port, 15-pin VGA output connector
user interface
Wireless IR remote controller: Power light – blue; lamp light – orange; temperature light – orange
OSD: Buttons on the top case include the following functions: “Power On/Off”, “OSD navigation”,
“Menu access”, “Enter”
product certification
Europe (EN 60950), USA/Canada (cULus), Mexico (NOM-1-NYCE), Singapore (PSB), Russia GOST, Poland
(B mark), China (CCC), Japan (SHOAN)
video compatibility
S-video, composite, component, HDTV (up to 1080i)
power consumption
330 watts maximum
power supply
Input voltage 100 to 240 VAC (± 10%), 50/60 Hz (± 3 Hz)
lamp
Lamp life: up to 3,000 hours in lamp saver mode
250 watt UHP projector bulb
Lamp power supply is automatically shut-off when door is open
mounting capability
HP Digital Projector vp6110/vp6120: Ceiling and tripod mountable
mounting environmental
10 to 90% RH, 10 to 35º C
warranty
2 year warranty on projector with pick-up and return service and 90 days warranty on light bulb
http://www.hp.com
For more information, please call your local HP sales office or representative: Austria: 0810/006080 (local rate call), Algeria: (0)61 56 45 43, Bahrain:
800 728, Belgium: (078) 15 20 30 (0.0496 EUR/min), Luxembourg: (+352) 263 160 34, Bulgaria: (+359) 2960 1940, Croatia: (+385 1) 60 60 200,
Czech Republic: (00 420 2) 261 108 108 (Prague), Denmark: 45991700 or 70101125, Egypt: 532 5222, Estonia: (+372) 6505 263, Finland: (+358)
0205350 or 0205 350, France: (1) 69 82 6060, Germany: 0180 532 6222 (12 Cent/min), Greece: (01) 678 96 00, Hungary: (+36) 1 382-1111,
Iceland: (354) 570 1000, Ireland: + 353 1 6158200, Israel: (972) 9 8304848, Italy: (02) 92121, Kazakhstan: +7 (3272) 980 824, Latvia: (371) 800
80 12, Lithuania: (370) 2 787 333, Middle East: 00971 4 883 4427, Morocco (African Region): +212 22 40 47 47, Netherlands: (020) 5476666,
Norway: 22 735600, Poland: infolinia: 0-800 122 622, Portugal: (808) 206 001, Romania: (+401) 205 3300, RSA: (27)11 785 1000, Russia: +7
(095) 797 35 00, Saudi Arabia: 800 124 4646, Serbia/Montenegro: +381 11 334 21 02, Slovakia: +421-2-50222111, Slovenia: +3861 2307 420,
Spain: (91) 6311600, Sweden: (08) 444 2000, Switzerland: 0848 88 44 66, Tunisia: 71 891 222, Turkey: +90 (216) 579 71 71, UAE: 8004910,
UK: 08705 474747, Ukraine: +380 44 490 61 20.
service & support
U4802A/E
hp care pack: 3 years
advanced unit replacement service
The information contained in this
document is subject to change without
notice. All other products mentioned
herein may be trademarks of their
respective companies.
Microsoft, Windows and MS Windows
are U.S. registered trademarks of
Microsoft Corporation. Pentium is a U.S.
registered trademark of Intel Corporation.
© Copyright Hewlett-Packard 2003
Printed in the EU 06/03
5981-7476EEE
