Compaq 610 Notebook PC - OK

Compaq 610 Notebook PC - OK
Compaq 610
Notebook PC
Essential Mobility
Compaq recommends Windows Vista® Business
Compaq 610 Notebook PC
A comfortable fit
for any budget
More than you bargained for
Stay connected
A comfortable fit for any budget, the
Compaq 610 Notebook PC helps keep you
connected and productive so your office
goes with you.
The Compaq 610 helps you stay
connected at hotspot locations by
offering Wi-Fi Certified WLAN4 and
optional integrated Bluetooth® wireless
technologies. With Wi-Fi Certified
WLAN, integrated microphone and
integrated 2 MP Webcam,9 you can
experience web conferencing and other
multi-media content with no additional
hardware to buy or carry; while
Bluetooth® technology provides
wireless short-range connectivity
between other Bluetooth devices such
as printers and mice.
Highly portable design
With its attractive design and a starting
weight of only 5.5 lb /2.49 kg, the Compaq
610 is the perfect business partner. The
16:9 ratio, 15.6-inch diagonal LED-backlit
high-definition12 widescreen display
produces brighter images similar to HDTV
and is more power efficient than regular
LCD screens.
Productivity on the move
Experience new levels of system
responsiveness when running multiple
applications and smarter battery
performance designed to help extend
mobility with an Intel® Core™2 Duo
Processor.2 Enjoy Intel’s integrated
graphics solution7 which balances memory
usage between graphics and the system.
The DVD+/-RW SuperMulti DL LightScribe
Drive3 makes your storage media stand
out with custom labels that you can burn
directly to your disc, and the integrated SD
Card reader helps you easily share files
from smartphones, cameras or other
devices.
Business-focused
To help protect your data by
reducing physical shocks to your
hard drive, the Compaq 610
features DriveGuard. In addition,
DriveLock helps protect data on
your hard drive from unauthorized
access in the event your notebook is
lost or stolen. Plus, Fast Charge8
technology recharges your notebook
battery to 90% within 90 minutes to
get you back to business faster.
Compaq 610 Notebook PC
Compaq recommends Windows Vista® Business
Operating system
Preinstalled:
1
Genuine Windows Vista®Business 32
Genuine Windows Vista Business with
®
downgrade to Windows XP Professional custom
installed1,13
1
Genuine Windows Vista Home Basic 32
Genuine Windows Vista Home Premium 321
Supported:
Windows Vista Business 64
Certified:
SUSE Linux Enterprise Desktop 11
FreeDOS
®
TM
2
Processor2
Intel Core 2 Duo T5870(to 2 GHz, 2 MB L2 cache)
®
®
Intel Celeron Processor 560 (2.13 GHz, 1MB L2 cache)
Chipset
Mobile Intel® GME965 or GLE960
Memory
DDR2 SDRAM, 800 MHz, two dual channel10 SODIMM memory slots, supports 1024/2048 MB, up to 4096
MB total11 (4 GB requires GME965 chipset)
Hard drive(s)6
Removable media3
Display
SATA 160/320GB 5400 rpm (with DriveGuard)
12.7-mm optical drive: DVD+/–RW SuperMulti Dual-Layer LightScribe
15.6-inch diagonal LED-backlit HD12 16:9 widescreen (1366x768), 15.6-inch diagonal LED-backlit HD12
BrightView 16:9 widescreen (1366x768)
Graphics7
Integrated: Intel GMA X3100, up to 384 MB shared system memory
Audio
Wireless support4
Communications
Expansion slots
Ports and
connectors
Input device
Software
Security
Dimensions
(h × w × d)
Weight
Power
Warranty
High Definition Audio, mono speaker, stereo headphone/line out, stereo microphone in, integrated
microphone
5
Intel 802.11a/b/g, Broadcom 802.11 b/g, Bluetooth™ 2.1+EDR, HP Wireless Assistant
Marvell Ethernet (10/100 NIC), 56K v.92 modem (optional)
1 ExpressCard/34 slot, Secure Digital (SD)/MultiMediaCard (MMC) slot
3 USB 2.0 ports, VGA, stereo microphone in, stereo headphone/line out, power connector, RJ-11/modem,
RJ-45/ethernet
Full-sized keyboard, Touchpad with scroll zone, VoIP ready4 – integrated microphone with optional
4,9
integrated 2 MP Webcam
HP Recovery Manager (Windows Vista only), SoftPaq Download Manager, HP Webcam software, Roxio
Creator Business (select models)
DriveLock, Disk Sanitizer, Computrace BIOS support, Kensington lock slot
1.26 in (at front) x 14.64 in x 10.01 in / 32 mm (at front) x 371.8 mm x 254.3 mm
Starting at 5.5 lb /2.49 kg (or 5.0 lb / 2.26 kg with no optical drive; weight will vary by configuration)
8
6-cell (47 WHr) Lithium-Ion battery, 65W AC Adapter, Fast Charge
Limited 1-year warranty, 1-year limited warranty on primary battery. HP Care Pack Services extend service
contracts which go beyond your standard warranties. For more details visit:
http://www.hp.com/go/lookuptool.
Compaq 610 Notebook PC
Compaq recommends Windows Vista® Business
Integrated 2MP
Webcam
15.6-inch diagonal LEDbacklit HD12 widescreen
display
Full-sized keyboard
3 USB 2.0 ports
Secure Digital
(SD) slot
Compaq 610 Notebook PC
Compaq recommends Windows Vista® Business
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Certain Windows Vista product features require advanced or additional hardware. See
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To
download the tool, visit www.windowsvista.com/upgradeadvisor.
Dual Core is a new technology designed to improve performance of certain software products. Not all
customers or software applications will necessarily benefit from use of this technology. 64-bit
computing on Intel architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel® 64 architecture. Processors will
not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance
will vary depending on your hardware and software configurations. See www.intel.com/info/em64t for
more information
Do not copy copy-right protected materials. Intended for creation and storage of your original material
and other lawful uses. Double Layer discs can store more data than single layer discs. Double-layer
discs burned with this drive may not be compatible with many existing single-layer DVD drives and
players. LightScribe creates a monochrome image. LightScribe media required and sold separately.
Note that DVD-RAM cannot read or write to 2.6 GB Single Sided/5.2 GB Double Sided – Version 1.0
media.
WiFi access point and Internet service required and not included. Availability of public wireless
access points limited. VoIP requires a separately purchased service contract.
The specifications for the 802.11n WLAN are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11n WLAN devices.
For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 8 GB (for XP) and 10
GB (for Vista) of system disk is reserved for the system recovery software.
Shared video memory (UMA) uses part of the total system memory for video performance. System
memory dedicated to video performance is not available for other use by programs.
Fast Charge recharges your primary battery up to 90% within 90 minutes when the system is off.
Sold separately or purchased as an optional feature.
Dual Channel is only supported when the system is configured with DDR2 symmetric memory (ie:
2x256).
32-bit operating systems can only address ~3.2 GB. To fully utilizing memory configurations of 4 GB
or more, a 64-bit operating system is required.
HD content required to view HD images
Windows Vista Business disk may be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions) and
is expected to order at least 25 customer systems with the same custom image.
© 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without
notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be
liable for technical or editorial errors or omissions contained herein. Bluetooth is a trademark of its proprietor and used by
Hewlett-Packard Company under license. Microsoft, Windows and Vista are trademarks or trademarks of the Microsoft
group of companies. Intel and Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
U.S. and other countries. To learn more, visit www.hp.com
February 2009
