Audio Visual Centre &
Digital Music Receiver
driven by sound.
Make every trip a thrilling
multimedia experience.
Multimedia Entertainment - MirrorLink T M
Multimedia Entertainment - MirrorLink T M
Connect and
drive with MirrorLinkTM.
Explore another dimension.
Control your multimedia world via the speedy, responsive 3D-style graphical
interface. Choose your background wallpaper or bring your music to life with
colourful, eye-grabbing visualisations.
Connect your smartphone.
CONTROL
Now you can safely access many of your smartphone’s capabilities from behind
the wheel. Just connect your MirrorLinkTM certified smartphone via USB to the
XAV-601BT Audio Visual Centre. Compatible applications and content from your
phone are displayed directly on the head unit’s large, colourful touchscreen while
your phone is being charged.
Maximum convenience
and ease of use.
PROJECT
MirrorLinkTM means even safer, more convenient driving. Normally, it’s difficult to
access your phone’s contacts, content, applications and music collection from
behind the wheel. But with the XAV-601BT Audio Visual Centre it’s easier and
more intuitive. ‘Car Mode’ displays an optimised view of you smartphone’s menu,
allowing sure, simple access to your content and applications. So now interacting
with your phone is safer and less hassle while you’re on the road.
Fast, accurate touchscreen.
You’re always in touch. Accurately control all your entertainment experiences
using the speedy, responsive touchscreen.
Use your favourite navigation apps.
Navigation apps* for your mobile are getting smarter and more popular every
day. There’s a growing range of services to help you reach your destination safely
and get more out of your journey. However accessing them on your smartphone
can be frustrating while you’re on the move. The XAV-601BT makes map views
and navigation clearer and more positive, thanks to the high resolution WVGA
display that shows every detail. Audio directions are heard easily through your
car’s speakers.
*Apps availability depends also on smartphone vendors.
Maximum entertainment.
MirrorLinkTM turns every trip into a maximum entertainment experience. Access
your phone’s apps and music collection while you’re driving - quickly, surely and
safely. Turn every trip into a driving adventure: everything you need is right there
inside your smartphone.
6
Maximum connectivity.
With Bluetooth® it’s easier to make and safely receive hands - free phone calls
while you’re on the road. Just key in the name of a contact in your phone’s
address book to launch a call. Ready for some entertainment? Connect your
smartphone, iPod/iPhone or MP3 player for a superior soundtrack.
Bright, detailed display.
See more with the super-bright, detail-packed 6.1” WVGA display that offers a
superior view of DVDs, videos and photos. It’s the surer, more convenient way to
enjoy your favourite content.
7
Audio Visual Centre
Supplied accessories:
Recommended accessories:
XA-MC10
XA-R800C
RM-X271
RC-202IPV
Audio Visual Centre
XAV-601BT
XAV-63
MirrorLink™ compatible Bluetooth® Audio
Visual Centre with 15.5cm (6.1”) WVGA
touchscreen and Dual USB.
Audio Visual Centre with 15.5cm (6.1”)
WVGA touchscreen and Front USB.
•Compatible with MirrorLink™ certified smartphones
•Music and video streaming from iPhone
•TomTom navigation expandable
•Removable front panel for anti-theft security
•Dynamic Colour Illuminator to match your dashboard
•Bluetooth® for hands-free talking and music streaming
•External microphone for better voice capture
•Dual USB for direct control of connected smart-phone, iPod/iPhone/
Walkman®, plus playback compatibility with USB flash drives
•MP3/WMA/AAC/WAV/WMV/H.264/Xvid/JPEG
and MPEG-4 Simple Profile codec compatible
•High resolution 15.5cm/6.1” WVGA touchscreen
•Dynamic Reality Amplifier with 4 x 52W high power output
•Digital Clarity Tuner for improved FM stereo reception
•SensMe™ organises your music into different moods
•Quick, easy searches through all your music tracks with ZAPPIN™
•Centre Speaker Organiser and Intelligent Time Alignment technologies
for high quality sound
•Low-pass and high-pass filters for flexible sound customisation
•Zone by Zone function for rear seat entertainment
•3 × 5 Volt pre-out for system expandability
Supplied accessory:
Recommended accessories:
RM-X170
XA-R800C
•Music and video streaming from iPhone
•MP3/WMA/AAC/Xvid/JPEG and MPEG-4 Simple Profile codec compatible
•High resolution 15.5cm/6.1” WVGA touchscreen
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus
playback compatibility with USB flash drives
•Dynamic Reality Amplifier with 4 x 52W high power output
•Digital Clarity Tuner for improved FM stereo reception
•SensMe™ organises your music into different moods
•Quick, easy searches through all your music tracks with ZAPPIN™
•Centre Speaker Organiser and Intelligent Time Alignment technologies for
high quality sound
•Low-pass and high-pass filters for flexible sound customisation
•2 × 2 Volt pre-out for system expandability
RC-202IPV
See for yourself!
Scan the QR code with your
smartphone to see MirrorLink™ in
action with the XAV-601BT AV Centre
Head Unit.
Time alignment
8
Removable front panel.
Wallpaper customisation.
The front panel can be removed entirely, helping keep your unit safe from prying
eyes and prevent thefts. A case for storing the removed front panel is provided with
the unit.
Pick from a choise of animated wallpapers; you can even set your favourite
image as wallpaper - simply download it through a USB flash drive.
Virtual 5.1 channel surround.
Control for demanding music
lovers.
Advanced Sound Engine (ASE) combines advanced digital audio technologies by
Sony to give you unprecedented power over creating perfect in-car sound with
any music source. Centre Speaker Organiser recreates the power and precision
of 5.1 channel surround sound by placing an additional ‘virtual’ speaker right in
the centre of your dashboard.
The XAV-601BT and the XAV-63 make it easy to sculpt audio settings to match
your listening tastes. Time Alignment minutely adjusts the timing of sound from
each amplifier channel to compensate for the driver’s position inside the vehicle.
7 presets allow instant recall of favourite equalisation settings to suit any style
of music.
9
Digital Music Receiver with Tune Tray
Digital Music Receiver
Discreet, hidden compartment
for digital media players.
Digital Music Receiver with front
USB connection.
Forget messy cables and loose players rattling around in the glove compartment. With Tune Tray
it’s easy to store your MP3 player or USB flash drive safely and discreetly inside the head unit.
No fuss, no untidy wires. Just great sounding music that you’re in control of.
1
2
Supplied accessory:
Recommended accessories:
RM-X305
XA-MC10
Recommended accessory:
XA-50WM
10
XA-50WM
3
Have you already switched over your listening from CD to MP3? With Digital
Media Players by Sony it’s easy to access your music collection on USB
devices, Walkman® and other mobile MP3 players. The DSX-A50BT also lets
make and receive wireless calls more safely using Bluetooth® technology. Both
models shown below feature a removable front panel to help protect your head
unit from the risk of theft.
4
DSX-S300BTX
DSX-A50BT
Bluetooth® Digital Music Receiver with Tune
Tray and Double USB.
Bluetooth® Digital Music Receiver with Front
USB and partial detachable panel.
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•Built-in microphone for hands free calls
•Tune Tray behind front panel securely stores your music player
•Double (Front + Inside) USB connection for iPod, iPhone, Walkman® and
other MP3 players
•Easy to read, informative 4-line Full-Dot OEL display
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•SensMe™ Channels organises your music into different moods
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Device Inside Alert’ gives visual and audible reminder when digital music player
is left in vehicle
•Blue/Red key illumination
•Steering Wheel Control Adapter Ready
•Supplied XA-50IP iPod adapter and RM-X305 card remote control
•Optional XA-50WM Walkman® adapter and XA-MC10 external microphone
Supplied accessory:
RM-X231
•Bluetooth® for hands-free talking and music streaming
•Built-in microphone for hands-free calls
•Dynamic Reality Amp with 4 × 50W high power output
•Digital Clarity Tuner for improved FM stereo reception
•Front USB for connection to Walkman®, USB flash drives and other
compatible devices
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ for easy music searches
•Partial Detachable Panel
•Blue key illumination
•2 x 2 Volt pre-outs for system expandability
•Steering Wheel Control Adapter Ready
DSX-S100
DSX-A30
Digital Music Receiver with Tune Tray
and Inside USB.
Digital Music Receiver with front USB and
partial detachable panel.
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Tune Tray behind front panel securely stores your music player
•Inside USB connection for iPod, Walkman® and other MP3 players
•Front Auxiliary input for easy MP3 player connection
•Informative 2-line high contrast LCD display
•Device Inside Alert gives visual and audible reminder when digital music
player is left in vehicle
•Blue key illumination
•Steering Wheel Control Adapter Ready
•Supplied XA-50IP iPod adapter
•Optional XA-50WM Walkman® adapter
•Dynamic Reality Amp with 4 × 50W high power output
•Built-in microphone for hands-free calls
•Digital Clarity Tuner for improved FM stereo reception
•Front USB for connection to Walkman®, USB flash drives and other
compatible devices
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ for easy music searches
•Partial Detachable Panel
•Red key illumination
•1 x 2 Volt pre-outs for system expandability
•Steering Wheel Control Adapter Ready
11
CD Receiver
keep in rhythm.
Your music library follows
you anywhere you go.
CD Receiver
CD Receiver
Connect and control
your smartphone.
Your whole world within easy reach.
Keep your apps with you.
Now you can control and enjoy favourite Android or iOS apps directly from your in-car head unit.
Hook up your smartphone via Bluetooth® or USB cable. Then install App Remote by Sony on your
mobile and you’re ready to go. Interact with the mobile’s menu through the head unit’s controls.
Launch navigation apps and listen to clear directions through your car speakers. Tune in to internet
radio stations from around the world. Even let your passengers enjoy listening to music from video
apps like YouTube.
Handling your smartphone and using the touchscreen while you’re driving is a distraction that puts your safety at serious risk. App Remote puts your digital world in easy reach,
with safe fingertip control using the head unit’s buttons and controls.
Maximum customisation.
App Remote lets you choose from a wide range of applications that can launched directly from the
CD receiver, from social network apps like Facebook to navigation and Google searches. Seeing
your app on screen - and hearing through the car’s speakers - turns every trip into a real pleasure.
In perfect harmony.
App Remote seamlessly integrates your in-car entertainment system with applications installed on
your smartphone. Scroll through apps from the head unit’s front panel or fingertip controls on your
steering wheel. And as well as controlling your smartphone from the head unit, passengers can
also control head unit functions from the smartphone.
Informative 2-line display.
Get even more from your radio listening experience. The generouslysized, high-contrast display offers detailed information including
radio station name and DAB Dynamic Label messages. To maximise
display size, the head unit’s front panel flips down to reveal the CD
loading slot.
Get the whole story.
App Remote turns your smartphone into an additional display, showing extra information about
the album cover, the song or radio station information you’re listening to.
Choose your favourite lighting.
Dynamic Colour Illuminator lets you select the lighting that best matches your car’s controls. Pick
from a choice of over 35,000 shades - or let the colours adapt rhythmically in sync with the song
you’re listening to.
Convenience and safety while driving.
Receive and hear text messages safely while you’re driving. When a text arrives on your phone,
App Remote automatically turns down the volume if music’s playing, then reads the sender’s
name and message aloud through your car speakers. So now you can stay in touch with what’s
happening without taking your eyes off the road - or your hands off the wheel. The feature can be
switched off any time you don’t want other passengers to hear your private messages.
14
DAB/DAB+/DMB-R radio reception.
Enjoy an even wider range of digital radio entertainment. The CDX-DAB700U and CDX-DAB500U
pull in your favourite digital stations and analogue broadcasts (FM/AM) for clear reception while
you’re on the road. It’s the first head unit from Sony that’s compatible with regular DAB transmissions
as well as newer DAB+ and DMB-R standards that offer improved transmission efficiency. The
receiver comes supplied with a compact, highly sensitive DAB antenna that adheres discreetly
inside the windscreen to offer excellent signal reception. The powerful adhesive film allows quick,
easy installation, with no need to drill holes or make other modifications to your vehicle.
15
CD Receiver 2DIN & 1DIN
CD Receiver 2DIN & 1DIN
CDX-DAB500U
In-car CD receiver with Front USB for
iPod/iPhone/Walkman® connection and
DAB/DAB+/DMB‑R tuner.
App Remote also
available as 2DIN.
Supplied
accessory:
Enjoy all the benefits of App Remote technology with the doubleDIN WX-GT90BT that includes all the winning features of Sony’s
CD Receiver range. App Remote integrates the head unit with your
smartphone (iOS or Android), while Bluetooth lets you make and
receive safe hands-free calls. Dynamic Colour Illuminator adds a
dynamic extra splash of personality to your in-dash lighting.
•DAB/DAB+/DMB‑R and FM/MW/LW radio reception
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•2×2 Volt pre-outs for system expandability
RM-X211
Supplied
accessories:
RM-X231
External
microphone
Supplied
accessories:
RM-X211
DAB antenna
16
WX-GT90BT
MEX-GS600BT
App Remote for iOS and Android
Smartphone integration, variable
illumination Bluetooth® in-car 2DIN CD
receiver with Front USB for iPod/iPhone/
Walkman®.
App Remote for iOS and Android
Smartphone integration, variable illumination
Bluetooth® in-car CD receiver with Rear USB
for iPod/iPhone/Walkman®.
•App Remote technology to interact with iOS and Android smartphones
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•External microphone for better voice capture
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•3×4 Volt pre-outs for system expandability
Supplied
accessories:
RM-X231
External
microphone
•App Remote technology to interact with iOS and Android smartphones
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•External microphone for better voice capture
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Rear USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•3×5 Volt pre-outs for system expandability
CDX-DAB700U
MEX-BT4100U
Variable illumination in-car CD receiver
with Front USB for iPod/iPhone/Walkman®
connection and DAB/DAB+/DMB-R tuner.
App Remote for iOS and Android
Smartphone integration, variable illumination
Bluetooth® in-car CD receiver with Front USB
for iPod/iPhone/Walkman®.
•DAB/DAB+/DMB-R and FM/MW/LW radio reception
•Easy-fit high-sensitivity DAB antenna included
•2-line flip-down display
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4 x 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•SensMe™ channels organizes your music into different moods
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•3 x 2 Volt pre-outs for system expandability
Supplied
accessories:
RM-X231
External
microphone
•App Remote technology to interact with iOS and Android smartphones
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access and built-in phone book memory
•External microphone for better voice capture
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•3×2 Volt pre-outs for system expandability
17
CD Receiver 2DIN & 1DIN
Recommended
accessory:
XA-MC10
CD Receiver 2DIN & 1DIN
MEX-BT3100U
CDX-GT570UI
App Remote for iOS and Android Smartphone
integration, Bluetooth® in-car CD receiver with
Front USB for iPod/iPhone/Walkman® connection.
App Remote for iOS Smartphone integration,
in-car CD receiver with Front USB for iPod/
iPhone/Walkman®.
•App Remote technology to interact with iOS and Android smartphones
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access and built-in phone book memory
•Built-in microphone for hands free calls
•Double illumination: blue and red, switchable
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•2×2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
CDX-GS500R
CDX-GT470UM
App Remote for iOS Smartphone integration,
variable illumination in-car CD receiver with
Rear USB for iPod/iPhone/Walkman®.
In-car CD receiver with Front USB and
Front Aux-in.
•App Remote technology to interact with iOS smartphones
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Rear USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•3×5 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
Also available in
green and amber key
illumination:
CDX-GT474UM and
CDX-GT472UM
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•1×2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
CDX-GT575UI
CDX-GT270MP
App Remote for iOS Smartphone integration,
variable illumination in-car CD receiver with
Front USB for iPod/iPhone/Walkman®.
In-car CD receiver with Front Aux-in.
•App Remote technology to interact with iOS smartphones
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•2×2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
18
Also available in red
key illumination:
CDX-GT574UI
•App Remote technology to interact with iOS smartphones
•Dynamic Reality Amp with 4×52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume
between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•1×2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
•Dynamic Reality Amp with 4×52W high power output
•Digital Clarity Tuner for improved FM stereo reception
•Front Auxiliary input to connect compatible MP3 player
•1×2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
19
In-car Components
play it better.
Enjoy your car audio loud,
deep and crystal clear.
Speakers
Speakers
XS-H20S
XS-GTX6932
Component tweeter.
6 x 9” 3-Way Coaxial Speaker.
•Peak power: 130W (Crossover
network connected)
•Rated power: 40W (Crossover
network connected)
•Frequency response: 5k-32KHz
•Tetron fibre soft dome tweeter
•Neodymium magnet
XS-GTR1720
XS-GT6938F
17cm 2-Way Coaxial Speaker.
6 x 9” 3-Way Coaxial Speaker.
•Peak power: 320W
•Rated power: 75W
•Frequency response: 45-32KHz
•Mica reinforced cellular woofer cone
for tight, deep bass
•Aluminium dome tweeter for crystal
clear high
•Bi-amp: dual speaker terminals allow
separate connection of woofer and
tweeter
•Peak power: 420W
•Rated power: 50W
•Frequency response: 40-22KHz
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•MRC (Mica Reinforced Cellular) tweeter
cone for crisp, clear mid/highs
XS-GTX1622S
XS-GT6928F
16cm 2-Way Separate Speaker.
6 x 9” 2-Way Coaxial Speaker.
•Peak power: 260W
•Rated power: 60W
•Frequency response: 50-30KHz
•Surface, angle and flush mounting
tweeter installation options
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•Soft-dome tweeter for smooth, natural
highs
22
•Peak power: 500W
•Rated power: 85W
•Frequency response: 30-30KHz
•Stroke stabiliser surround
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•PEN (Polyethylene naphthalate) Mica
reinforced cellular tweeter cone for
crisp, clear mid/highs
•Peak power: 400W
•Rated power: 50W
•Frequency response: 40-22KHz
•Stroke stabiliser surround
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•MRC (Mica Reinforced Cellular) tweeter
cone for crisp, clear mid/highs
23
Speakers
Speakers
XS-GT1738F
XS-GT1328F
17cm 3-Way Coaxial Speaker.
13cm 2-Way Coaxial Speaker.
•Peak power: 260W
•Rated power: 40W
•Frequency response: 50-24KHz
•Easy-fit design for simple installation
with wide range of vehicles
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
XS-GT1728F
XS-GT1038F
17cm 2-Way Coaxial Speaker.
10cm 3-Way Coaxial Speaker.
•Peak power: 250W
•Rated power: 40W
•Frequency response: 50-24KHz
•Easy-fit design for simple installation
with wide range of vehicles
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
•Peak power: 210W
•Rated power: 30W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
XS-GT1338F
XS-GT1028F
13cm 3-Way Coaxial Speaker.
10cm 2-Way Coaxial Speaker.
•Peak Power: 230W
•Rated Power: 35W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
24
•Peak Power: 220W
•Rated Power: 35W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
•Peak power: 200W
•Rated power: 30W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for
rich, deep bass
•PEI (Polyetherimide) balanced dome
tweeter for smooth, clear highs
25
Subwoofers
Subwoofers
XS-GTX121LC
XS-GTR121L
12” Compact Size Boxed Subwoofer.
12” Dimpled Cone Subwoofer.
Dimensions
430mm
185.4mm
370mm
•Peak power: 1000W
•Rated power: 300W
•Frequency response: 30Hz-1000Hz
•5-sided polypropylene capless cone for
lower distortion and louder, deeper bass
•Stroke stabiliser rubber surround
•Compact design for installation flexibility
270mm
XS-GTX121LS
XS-GTR101L
12” Slim Size Boxed Subwoofer.
10” Dimpled Cone Subwoofer.
Dimensions
445mm
365mm
•Peak power: 1000W
•Rated power: 300W
•Frequency response: 42Hz-1000Hz
•5-sided polypropylene capless cone for
lower distortion and louder, deeper bass
•Stroke stabiliser rubber surround
•Shallow design for Installation flexibility
175mm
26
•Peak power: 2000W
•Rated power: 400W
•Frequency response: 35Hz-1000Hz
•Dimpled woofer cone for light weight
and high sound pressure level bass
•5-sided polypropylene capless cone
for lower distortion and louder, deeper bass
•Injected Polypropylene diaphragm
•Thermoplastic olefin surround
•Peak power: 1700W
•Rated power: 370W
•Frequency response: 35Hz-1000Hz
•Dimpled woofer cone for light weight
and high sound pressure level bass
•5-sided polypropylene capless cone
for lower distortion and louder, deeper bass
•Injected Polypropylene diaphragm
•Thermoplastic olefin surround
27
Amplifiers
Amplifiers
XM-GTR4A
XM-GTR3301D
Asymmetric 4/3 Channel Stereo Power Amplifier.
Class D Mono Power Amplifier.
•Peak power: 1200W
•Rated power: 60W × 2 (4Ω) + 125W × 2 (4Ω),
60W × 2 (4Ω) + 340W × 1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•High-pass filter: 50-300Hz, variable
•Subsonic filter for rear channel: 15Hz
•Low boost (40Hz, +10dB)
XM-GTR7040
XM-GTX6021
4/3/2 Channel Stereo Power Amplifier.
2/1 Channel Stereo Power Amplifier.
•Peak power: 700W
•Rated power: 70W × 4 (4Ω), 70W x 2
(4Ω)+160W x 1 (4ΩBTL), 160W x 2(4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•High-pass filter: 50-300Hz, variable
•Subsonic filter for front and rear channel: 6-70Hz,
variable
•Low boost (40Hz, +10dB)
•Peak power: 350W (4Ω)
•Rated power: 60W × 2 (4Ω), 150W x 1 (4ΩBTL)
•Low-pass filter: 80Hz
XM-GTR2202
XM-GTX6041
2/1 Channel Stereo Power Amplifier.
4/3/2 Channel Stereo Power Amplifier.
•Peak power: 1400W
•Rated power: 220W x 2 (4Ω, 540W x1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•Subsonic filter: 6-70Hz, variable
•Low boost (40Hz, +10dB)
28
•Peak power: 1100W (2Ω)
•Rated power: 600W (2Ω), 330W (4Ω), 220W x 2
(4Ω, 540W x1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•Subsonic filter: 6-70Hz, variable
•Low boost (40Hz, +10dB)
•Peak power: 600W
•Rated Power: 60W x 2 (4Ω) + 140W x
1(4ΩBTL), 140W x 2 (4ΩBTL)
•Low-pass filter: 80Hz
•High-pass filter: 80Hz
29
Accessories
Glossar y
XA-R800C
Rear view camera.
•Adjustable parking guidelines
•Colour CCD sensor lens with 16:9 aspect ratio
•Flexible mounting options with adjustable tilt
•3m camera cable supplied
•138 degrees horizontal and 92 degrees vertical
viewing area
XA-MC10
Hands-free external microphone for
enhanced sound quality.
•Optional external unidirectional microphone for
DSX-S300BTX and MEX-BT3100U
•Also compatible with XAV-601BT •4m cable and mounting clip
RC-202IPV
USB and Video connection cable.
•Supports on-screen audio/video playback from iPod/iPhone,
including album artwork
•Provides device control and charging
•0.9m extended cable length for easy connectivity and
placement of iPod/iPhone
Advanced Audio Distribution Profile (A2DP)
Industry standard protocol enables wireless music
streaming from mobile phones and other Bluetooth®
devices to compatible head unit.
Advanced Audio Coding (AAC)
AAC is a standardised compression method for
digital audio. AAC achieves better quality sound with
smaller file sizes when compared to the MP3 format
at the same bit rate. AAC is used as the standard
audio format for many popular entertainment
devices including the Sony PlayStation® 3.
Advanced Sound Engine
Includes features like Intelligent Time Alignment
(ITA), Center Speaker Organizer (CSO) and three
selectable levels of Rear Bass Enhancer to enable
you to enjoy multi-channel sound to the fullest.
Xvid
Efficient digital video codec that permits high quality
video compression at low bit-rates. Allows nearDVD quality video playback with smaller file size
than conventional formats.
Dual USB
For those end-users who keep for example a USB
drive in the Tune Tray while carrying around another
portable player or smart phone such as the iPhone
that’s constantly updated with new tunes, the front
and second USB connections come quite handy.
Hands-Free Profile (HFP)
Industry standard connection supports hands-free
mobile calls with Bluetooth® phone and compatible
head units.
High-pass and low-pass filters
High-pass filters only allow high frequencies to pass
through, suppressing low-end frequencies for a
lighter bass sound. Low-pass filters attenuate high
frequencies for a more powerful bass sound.
Intelligent Time Alignment
Adjusts timing of sound reaching the driver from
different amplifier channels for an optimum listening
experience.
XA-50WM
Walkman® adaptor for DSX.
•Connects your Walkman® directly to any Xplod™
DSX-S series head unit
•Compact size with no messy cables
•Fits inside Xplod™ DSX-S series Tune Tray
30
3-band equaliser (EQ3)
The EQ3 graphic equalizer features 7 preset modes
(Xplod, Vocal, Club, Jazz, New Age, Rock and
Custom). Custom mode allows adjustment of 3
frequency bands to suit your taste in music.
7-band equaliser (EQ7)
EQ7 offers 7 equalizer options, and 7 preset modes
(Xplod, Vocal, Edge, Cruise, Space, Gravity and
Custom) to create the perfect listening environment
for your music. Custom mode lets you adjust music to
fit your individual listening preference.
Made for iPod/iPhone
Confirms that an electronic device or accessory
has been designed to connect specifically to iPod
or iPhone and has been certified by the developer
to meet Apple performance standards. Apple is
not responsible for operation of the device or its
compliance with safety and regulatory standards.
Phone Book Access Profile (PBAP)
Allows wireless access to mobile phone’s contact
list via Bluetooth® directly from head unit. Phone
book contacts are listed alphabetically for quick,
easy searches.
Windows Media Audio (WMA)
WMA files can be easily played through the new and
improved head unit technologies.
W-VGA
With over three times the resolution of previous
LCD Screens, W-VGA combines the high-resolution
of a TFT display with an improved high-brightness
backlight that provides up to 190% the colour purity
of previous models.
Class D
Class D Amplifiers distribute power with the use of
output transistors as switches. These transistors
switch between “off” and “on” when too much
or little voltage runs through them. By effectively
managing and controlling the flow of power, Class
D Amplifiers deliver higher power output with
reduced current and less heat dissipation, ensuring
outstanding audio performance.
Dual Voice Coils
Offers greater flexibility during installation by giving
the choice of parallel or series connection.
Gold plated terminals
Offer superior electrical connection and cleaner
signal transfers, while also eliminating corrosion.
Highly Oriented Polyolefin (HOP)
The HOP diaphragm achieves a much broader
playback frequency bandwidth and improved
transition characteristics – which means clearer,
distortion-free sound is reproduced.
Marine Series
The seaborne can now customise their sound
experience with the new range of Marine Series
speakers, designed for the boat/yacht interiors.
Furnished from special materials like stainless steel
screws and customised waterproof coating, you will
be able to enjoy quality sound experience anywhere.
31
Marine
feel every
sound wave.
Enjoy top audio quality as you
hit the open waters.
Marine
Marine
CDX-HR910UI
XS-MP1621
Marine CD/MP3/WMA/AAC player with
Rear USB for iPod/iPhone and Walkman®
connection.
6” Marine 2-Way Coaxial Speaker.
Audio features
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Rear USB for direct control of connected iPod/iPhone/
Walkman®, plus playback compatibility with USB flash
drives
•Quick-BrowZer™ and ZAPPIN™ for easy music
searches
•Aux-In (Rear / RCA)
Marine Features
•Conformal coating for circuit board
•Plastic cover for chassis
•Anti-rust reinforcement (anti-rust screw for front and
sub panel)
•Splash-proof (IPx5)
•UV exposure resistant (ASTM G154)
•Salt fog exposure resistant (ASTM B117)
•Memory backup feature
•Direct sunlight viewable display (white LCD)
XS-MP1611
6” Marine Dual Cone Speaker.
•Peak power: 140W
•Rated power: 40W
•Frequency response: 40Hz – 20kHz
•Sensitivity: 90dB/W/m
•Water resistant design - IPx5 certified
•UV resistant – tested under ASTM G154
•Salt resistant – tested under ASTM B117
CDX-MR60UI
GDM-616
Marine CD/MP3/WMA/AAC player with
Rear USB for iPod/iPhone and Walkman®
connection.
Waterproof Car Stereo Cover.
Audio features
•4 × 52W S-MOSFET high power output
•Rear USB for direct control of connected iPod/
iPhone/Walkman®, plus playback compatibility with
USB flash drives
•Flip-down, detachable faceplate with 2-line, direct
sunlight white LCD display
•Quick-BrowZer™ and ZAPPIN™ for easy music
searches
Marine Features
•Conformal coating for circuit board
•Plastic cover for chassis
•Anti-rust reinforcement (anti-rust screw for front and
sub panel)
•UV exposure resistant (ASTM G154)
•Memory backup feature
•Direct sunlight viewable display (white LCD)
34
RM-X60M
•Peak power: 160W
•Rated power: 45W
•Frequency response: 35Hz – 26kHz
•Sensitivity: 91dB/W/m
•Water resistant design - IPx5 certified
•UV resistant – tested under ASTM G154
•Salt resistant – tested under ASTM B117
•Front mask opening type DIN
•Compatible with all single DIN head units
•Durable injection moulded polycarbonate frame
•Weatherproofed with O-ring seal
RM-X60M
GMD-616
RM-X60M
Marine Remote Commander.
•10.1cm (4”) mounting diameter with scrolling LCD display
•Compatible with iPod control-ready head units
•Splash-proof IPX7 compliant design
35
Sony and the Sony logo are trademarks
of Sony Corporation.
Xperia is the trademark or registered
trademark of Sony Mobile Communications AB.
All other trademarks are trademarks or
registered trademarks of Sony Corporation
or the respective companies.
iPhone, iPod, iPod classic, iPod nano and
iPod touch are trademarks of Apple inc.,
registered in the U.S. and other countries.
“Made for iPod” and “Made for iPhone”
mean that an electronic accessory has been
designed to connect specifically to iPod or
iPhone, respectively, and has been certified
by the developer to meet
Apple performance standards.
Apple is not responsible for the operation of
this device or its compliance with safety and
regulatory standards. Please note that the
use of this accessory with iPod or iPhone may
affect wireless performance.
MirrorLink™ and the MirrorLink™ logo are
certification marks of the Car Connectivity
Consortium LLC.
Unauthorised use is strictly prohibited.
Specifications and design are subject to
change without notice.
Compatible features vary by model.
Operation requires MirrorLink™-certified
smartphones.
Availability of MirrorLink™ - certified
smartphone and app vary by area.
Navigation application’s operation speed
may vary by smartphone.
The map shown in the video is simulated for
illustration purposes.
iPhone connectivity requires RC-202IPV cable.
Not all iPhone apps are compatible with
Passenger App Control.
Passenger App Control is compatible with all
models up to iPhone 4S.
Sony AVC’s top screen may vary according
to region.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
