How to project to a wireless display with
Miracast / Intel WiDi ?
0
Prepared by MSI NB FAE Team | Version: 2.0 | Date: 2015/04/07
Requirements:

Windows 8.1 operating system.

Notebook with supported Intel graphcis, Intel Chipset, WiFi adapter that supports Miracast
and has latest Intel graphics driver installed.
An display (TV for example) that supports Miracast or a TV paired with a TV adapter that
supports Miracast.

Note:


It’s suggested to use 5GHz band for the wireless connection to avoid the signal
interference of the crowded 2.4 GHz band.
Models which is bundled with Intel WiDi’s supported wireless adapter (Intel® Dual Band
Wireless-AC 3160/7260) supports Intel WiDi.
1. Turn your television on.
2. Turn your notebook on, and open the Charms menu of Windows 8.1 by swiping the right side
of the screen.
3. Select “Devices” > “Project”.
4. Click “Add a wireless display”.
| 1
5. PC and devices windows shows up and displays the devices available for use. Select your
external TV from the list.
6.
A PIN displays on your Television screen. Enter this PIN in the Windows 8.1 screen that displays
on your computer. To establish the connection, click “Next”.
| 2
