RE-455X
PRODUCT NAME
ITEM CODE
UPC CODE
RE-455X
0213B002AA
013803049718
VISUALIZER
FEATURES:
s
s
s
s
s
s
s
s
s
s
s
s
s
s
Suggested List Price:
RE-455X: $2,299.00
SPECIFICATIONS:
CONTENTS OF KIT:
s
s
s
s
s
s
RE-455X Visualizer
VGA Cable
AC Cable (with Connector)
Dust Cover
User’s Manual
Warranty Card
PACKAGING INFORMATION:
CARTON TYPE
HxWxD
24.1 x 25.6 x 12.6 in.
XGA Resolution
Display Paper Documents and 3-D Objects
Superior Canon Optics: 12x Optical Power Zoom Lens
Connects Easily to your Projector, Computer Monitor, TV, VCR,
or DVD Recorder
Convenient Front Panel Controls
White Paper Mode
Zoom Preset
Image Freeze
Auto and Manual Focusing, Exposure, and White Balance
l One Shot Auto Focus
Adjustable Twin Fluorescent Lamps
VGA Input/Output
S-Video and Composite Output
RS-232C Terminal
Foldable Design for Excellent Portability
WEIGHT
29.1 lbs.
OPTICAL:
FOCAL LENGTH
F/NUMBER
ZOOM RATIO
FOCUSING
APERTURE
IMAGE CAPTURE:
IMAGING DEVICE
PIXELS
IMAGING FRAME RATE
SCANNING SYSTEM
SYNCHRONIZATION
WHITE BALANCE
ELECTRONIC SHUTTER SPEED
IMAGE SIZE
OUTPUT SIGNAL:
COMPOSITE OUTPUT
S-VIDEO OUTPUT
RGB
LIGHTING:
ARM LIGHTS (2)
TERMINALS:
COMPOSITE OUTPUT
S-VIDEO OUTPUT
RGB INPUT
RGB OUTPUT
RS-232C
DIMENSIONS:
IN USE (W x H x D)
FOLDED (W x H x D)
WEIGHT
POWER SOURCE
POWER CONSUMPTION
f=5.4-64.8mm (Excluding Close-up Lens)
F1.8-F2.8 (Excluding Close-up Lens)
12x Power Zoom (Excluding Close-up Lens)
Auto/Manual/One Shot
Auto Iris Servo System
1/3 inch CCD
1,024 x 768 (XGA)
15 Frames/Second
Progressive Scanning
Internal Synchronization
Auto/Manual
1/15-1/10,000 second
12.05" x 9.06" to 1.24" x 0.93"
NTSC, 380 x 320 TV Lines (S/N: 42 dB)
NTSC, 420 x 350 TV Lines (S/N: 44 dB)
XGA (1,024 x 768), Non-interlaced, 60Hz
(S/N: 38 dB)
Fluorescent, 6W Each
RCA jack
4-pin Mini DIN
15-pin Mini D-sub
15-pin Mini D-sub
8-pin Mini DIN
28.43 x 20.66 x 21.89 in
19.13 x 20.66 x 7.20 in
20.7 lbs. (9.4 kg)
100-240V AC, 50/60 Hz
23W
All prices, specifications, and availabilities subject to change without prior notice.
Effective: August 31, 2005
