P10S-I - Thomas
Motherboard
P10S-I
E12025
Revised Edition V3
September 2016
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
ii
Contents
Notices....................................................................................................................... vii
Federal Communications Commission Statement..........................................vii
Canadian Department of Communications Statement....................................vii
REACH .......................................................................................................vii
Safety information..................................................................................................... viii
Electrical safety.............................................................................................. viii
Operation safety............................................................................................. viii
Australia statement notice................................................................................ix
Specifications Summary............................................................................................ xi
Chapter 1:
Product Introduction
1.1Welcome!..................................................................................................... 1-2
1.2
Package contents....................................................................................... 1-2
1.3
Serial number label..................................................................................... 1-3
1.4
Special features.......................................................................................... 1-3
1.4.1
Product highlights........................................................................ 1-3
1.4.2
Innovative ASUS features............................................................ 1-4
Chapter 2:
Hardware Information
2.1
Before you proceed.................................................................................... 2-2
2.2
Motherboard overview................................................................................ 2-3
2.3
2.4
2.2.1
Placement direction..................................................................... 2-3
2.2.2
Screw holes................................................................................. 2-3
2.2.3
Motherboard layout...................................................................... 2-4
2.2.4
Layout contents............................................................................ 2-5
Central Processing Unit (CPU).................................................................. 2-7
2.3.1
Installing the CPU........................................................................ 2-7
2.3.2
Installing the CPU heatsink........................................................ 2-10
2.3.3
Uninstalling the CPU heatsink and fan...................................... 2-11
2.3.4
Installing the CPU heatsink in rack............................................ 2-11
System memory........................................................................................ 2-13
2.4.1Overview.................................................................................... 2-13
2.4.2
Memory configurations............................................................... 2-13
2.4.3
Installing a DIMM on a single clip DIMM socket........................ 2-14
iii
Contents
2.5
2.6
Expansion slots......................................................................................... 2-15
2.5.1
Installing an expansion card...................................................... 2-15
2.5.2
Configuring an expansion card.................................................. 2-15
2.5.3
Interrupt assignments................................................................ 2-16
2.5.4
PCI Express x16 slot (x16 Gen3 link)........................................ 2-17
2.5.5
Installing the Baseboard Management Card.............................. 2-18
Onboard LEDs........................................................................................... 2-19
2.7Jumpers..................................................................................................... 2-22
2.8Connectors................................................................................................ 2-25
2.8.1
Rear panel connectors............................................................... 2-25
2.8.2
Q-Code table.............................................................................. 2-26
2.8.3
Internal connectors.................................................................... 2-28
Chapter 3:
Starting up for the first time....................................................................... 3-2
3.2
Powering off the computer......................................................................... 3-3
3.2.1
Using the OS shut down function................................................. 3-3
3.2.2
Using the dual function power switch........................................... 3-3
Chapter 4:
4.1
4.2
4.3
BIOS Setup
Managing and updating your BIOS........................................................... 4-2
4.1.1
ASUS CrashFree BIOS 3 utility................................................... 4-2
4.1.2
ASUS EzFlash Utility................................................................... 4-3
4.1.3
BUPDATER utility........................................................................ 4-4
BIOS setup program................................................................................... 4-6
4.2.1
iv
Powering Up
3.1
BIOS menu screen....................................................................... 4-7
4.2.2
Menu bar...................................................................................... 4-7
4.2.3
Menu items.................................................................................. 4-8
4.2.4
Submenu items............................................................................ 4-8
4.2.5
Navigation keys............................................................................ 4-8
4.2.6
General help................................................................................ 4-8
4.2.7
Configuration fields...................................................................... 4-8
4.2.8
Pop-up window............................................................................ 4-8
4.2.9
Scroll bar...................................................................................... 4-8
Main menu................................................................................................... 4-9
Contents
4.4
Advanced menu........................................................................................ 4-10
4.4.1
Trusted Computing.................................................................... 4-11
4.4.2
Chipset Configuration................................................................ 4-11
4.4.3
Platform Configuration............................................................... 4-19
4.4.4
CPU Configuration..................................................................... 4-28
4.4.5
SATA Configuration .................................................................. 4-32
4.4.6
Network Stack Configuration .................................................... 4-34
4.4.7
CSM Configuration .................................................................... 4-35
4.4.8
iSCSI Configuration .................................................................. 4-36
4.5
Security Menu............................................................................................ 4-37
4.6
Boot Menu.................................................................................................. 4-39
4.7
Monitor Menu............................................................................................. 4-41
4.8
Tool menu.................................................................................................. 4-41
4.9
Save & Exit menu...................................................................................... 4-42
4.10
Server Mgmt menu.................................................................................... 4-43
4.11
Event Logs menu...................................................................................... 4-46
Chapter 5:
5.1
RAID Configuration
Setting up RAID........................................................................................... 5-2
5.1.1
RAID definitions........................................................................... 5-2
5.1.2
Installing hard disk drives............................................................. 5-3
5.1.3
Setting the RAID mode in BIOS................................................... 5-3
5.1.4
RAID configuration utilities........................................................... 5-3
5.2Intel® Rapid Storage Technology enterprise SATA Option
ROM Utility................................................................................................... 5-4
5.2.1
Creating a RAID set..................................................................... 5-5
5.2.2
Deleting a RAID set..................................................................... 5-7
5.2.3
Resetting disks to Non-RAID....................................................... 5-8
5.2.4
Exiting the Intel® Rapid Storage Technology enterprise
SATA Option ROM utility............................................................. 5-9
5.2.5
Rebuilding the RAID.................................................................... 5-9
5.2.6
Setting the Boot array in the BIOS Setup Utility......................... 5-11
5.3Intel® Rapid Storage Technology enterprise (Windows)....................... 5-12
5.3.1
Creating a RAID set................................................................... 5-13
5.3.2
Changing a Volume Type.......................................................... 5-15
5.3.3
Deleting a volume...................................................................... 5-16
5.3.4Preferences................................................................................ 5-17
v
Contents
Chapter 6:
6.1
Driver Installation
RAID driver installation.............................................................................. 6-2
6.1.1
Creating a USB flash drive with RAID driver................................ 6-2
6.1.2
Installing the RAID controller driver............................................. 6-2
6.2Management applications and utilities installation................................. 6-5
6.3
Running the Support DVD ......................................................................... 6-5
6.3.1
Drivers menu tab.......................................................................... 6-6
6.3.2
Utilities menu tab......................................................................... 6-6
6.3.3
Manual menu............................................................................... 6-7
6.3.4
Contact information menu............................................................ 6-7
6.3.5
Installing the Intel® Chipset device Software driver...................... 6-8
6.4
Installing the Intel® I210 Gigabit Adapters driver................................... 6-10
6.5
Installing the VGA driver.......................................................................... 6-13
Appendix
P10S-I block diagram............................................................................................... A-2
ASUS contact information....................................................................................... A-3
vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
•
This device may not cause harmful interference, and
•
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required to
assure compliance with FCC regulations. Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user’s authority to operate
this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
This class B digital apparatus complies with Canadian ICES-003.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of
Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS
REACH website at http://csr.asus.com/english/REACH.htm.
vii
Safety information
Electrical safety
•
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
•
When adding or removing devices to or from the system, ensure that the power cables for
the devices are unplugged before the signal cables are connected. If possible, disconnect
all power cables from the existing system before you add a device.
•
Before connecting or removing signal cables from the motherboard, ensure that all power
cables are unplugged.
•
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
•
Make sure that your power supply is set to the correct voltage in your area. If you are
not sure about the voltage of the electrical outlet you are using, contact your local power
company.
•
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
•
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
•
Before using the product, make sure all cables are correctly connected and the power cables
are not damaged. If you detect any damage, contact your dealer immediately.
•
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots,
sockets and circuitry.
•
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
•
Place the product on a stable surface.
•
If you encounter technical problems with the product, contact a qualified service technician
or your retailer.
DO NOT throw the motherboard in municipal waste. This product has been designed to enable
proper reuse of parts and recycling. This symbol of the crossed out wheeled bin indicates that
the product (electrical and electronic equipment) should not be placed in municipal waste.
Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the
crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
viii
Australia statement notice
From 1 January 2012 updated warranties apply to all ASUS products, consistent with the
Australian Consumer Law. For the latest product warranty details please visit https://www.asus.
com/support. Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at https://
www.asus.com/support.
ix
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text
Italics
<Key>
Indicates a menu or an item to select.
Used to emphasize a word or a phrase.
Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Command
Example: <Ctrl> + <Alt> + <Del>
Means that you must type the command exactly as shown,
then supply the required item or value enclosed in brackets.
Example: At DOS prompt, type the command line:
format A:/S
x
Specifications Summary
Processor Support / System Bus
Core Logic
Form Factor
1 x Socket LGA1151
Intel® Xeon® processor E3-1200 v5 product family
Intel® Core™ i3 processors
Intel® Pentium™ processors
Intel® Celeron™ processors
Intel® C232 Chipset
Mini-ITX, 6.7” x 6.7”
Fan Speed Control
Rack Ready
ASUS Features (Rack and Pedestal
dual use)
ASWM Enterprise
Total Slots
Voltage
Memory
Capacity
Memory Type
Memory Size
Total PCI/PCI-E Slots
Slot Location 1
Expansion
Slots
(follow SSI
Location
number)
Slot Location 2
Slot Location 3
Slot Location 4
Slot Location 5
Slot Location 6
Slot Location 7
SATA Controller
Storage
SAS Controller
2 (2 Channels)
1.2V
Maximum up to 32GB
DDR4 2133 ECC/non-ECC UDIMM
16GB
1
1 x PCI-E x16 (x16 Gen3 Link)
Intel® C232:
-6 x SATA 6Gb/s ports (4 by 1 mini-SAS HD
Connector) with 1 x M.2 connector (NGFF
2242, PCI-E Gen3X4 link or SATA signal,
gray SATA port will disable when M.2 is SATA
signal)
-Intel® RSTe (Windows & Linux)
- (Support software RAID 0, 1, 10 & 5)
Optional Kits:
-ASUS PIKE II 3008-8i 8-port SAS 12G RAID
card
-
ASUS PIKE II 3108-8i 8-port SAS 12G HW
RAID card
* Refer to www.asus.com for the complete list of supported CPUs.
(continued on the next page)
xi
Networking
LAN
Graphic
VGA
TPM Header
PSU Connector
Onboard I/O
Connectors
Management
Header
USB Connector/
Header
Software
ASWM Enterprise
Front LAN LED
M.2 Connector
External USB Port
VGA Port
RJ-45
Monitoring
1 x USB 3.0 connector (Type A USB socket)
PS/2 KB/Mouse
Chassis Intruder
Management
Solution
Onboard header for optional management card
3 x 4 pin headers
1
1
2
1
2 x USB 3.0
2 x USB 2.0
1
2 x GbE LAN +
1 x Mgmt LAN
1
Fan Header
SMBus connector
Rear I/O
Connectors
2 x Intel® I210AT +
1 x Mgmt LAN
Aspeed AST2400 32MB
1
20-pin ATX power connector +
4-pin ATX 12V power connector
Out of Band
Remote
Management
CPU Temperature
Optional ASMB8-iKVM for KVM-over-Internet
FAN RPM
Environment
Operation temperature:
10oC – 35oC (50oF – 95oF)
Non operation temperature:
-40oC – 70oC (-40oF – 158oF)
Non operation humidity:
20% – 90% (Non condensing)
Specifications are subject to change without notice.
xii
Chapter 1:
Product Introduction
Chapter 1:
Product Introduction
1.1Welcome!
Thank you for buying an ASUS® P10S-I motherboard!
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard and hardware devices on it, check the items in
your package with the list below.
1.2
Package contents
Check your motherboard package for the following items.
Items
I/O Shield
SATA 6G cable
Cables
COM port cable
Support CD
Application CD
ASWM Enterprise SDVD
Metal Plate for LGA1151
Accessory
Packaging Qty.
Standard Gift Box Pack
1
2
1
1
1
1
1 pc per carton
Standard Bulk Pack
1
-10 pcs per carton
1 pc per carton
1 pc per carton
1
10 pcs per carton
If any of the above items is damaged or missing, contact your retailer.
1-2
Chapter 1: Product Introduction
1.3
Serial number label
Before requesting support from the ASUS Technical Support team, you must take note of the
motherboard's serial number containing 12 characters xxS2xxxxxxxx shown as the figure
below. With the correct serial number of the product, ASUS Technical Support team members
can then offer a quicker and satisfying solution to your problems.
P10S-I
xxS2xxxxxxxx
1.4
Special features
1.4.1
Product highlights
Made
in
China
合格
Latest processor technology
This motherboard supports the latest Intel® Xeon® Processor E3-1200 v5/ Core™ i3 series
in LGA1151 package, which has memory and PCI Express controller integrated to support
2-channel (4 DIMMs) DDR4 memory and 16 PCI Express 3.0 lanes. The Intel® Xeon® E31200 v5 have improve CPU performance and integrated voltage regulators making it one of
the most powerful and energy efficient CPU in the world.
Intel® Turbo Boost
Intel® Turbo Boost automatically allows the processor to run faster than the marked frequency
if the processor is operating below its power, current, and temperature specification
limits. This technology increases performance of both multi-threaded and single-threaded
workloads.
Intel® Hyper Threading
The thread-level parallelism on each processor makes more efficient use of the processor
resources, higher processing throughout and improved performance on today's multithreaded software.
Intel® EM64T
The motherboard supports Intel® processors with the Intel® EM64T (Extended Memory 64
Technology). The Intel® EM64T feature allows your computer to run on 64-bit operating
systems and access larger amounts of system memory for faster and more efficient
computing.
DDR4 memory support
The motherboard supports DDR4 memory that features faster clock frequencies and higher
data transfer rates of 2133 MT/s (million transfers per second). DDR4 offers a lower voltage
standard of 1.2V that reduces memory power demand and provides improved performance.
ASUS P10S-I
1-3
PCI Express 3.0
PCI Express 3.0 (PCIe 3.0) is the PCI Express bus standard that provides twice the
performance and speed of PCIe 2.0. It provides an optimal graphics performance,
unprecedented data speed, and seamless transition with its complete backward compatibility
to PCIe 1.0/2.0 devices.
Intel® I210AT LAN Solution
The motherboard comes with two Gigabit LAN controllers and ports which provide a total
solution for your networking needs. The onboard Intel® I210AT Gigabit LAN controllers use
the PCI Express interface and could achieve network throughput close to Gigabit bandwidth.
Enhanced Intel SpeedStep Technology (EIST)
The Enhanced Intel SpeedStep Technology (EIST) intelligently manages the CPU resources
by automatically adjusting the CPU voltage and core frequency depending on the CPU
loading and system speed or power requirement.
Serial ATA III technology
The motherboard supports the Serial ATA III 6 Gb/s technology through the Serial ATA
interface and Intel® C232 chipset. Get enhanced scalability, faster data retrieval, double the
bandwidth of current bus systems with up to 6Gbps data transfer rates.
USB 2.0 technology
The motherboard implements the Universal Serial Bus (USB) 2.0 specification that
dramatically increases the connection speed from the 12 Mbps bandwidth on USB 1.1 to a
fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.
USB 3.0 technology
The motherboard implements the USB 3.0 technology with data transfer speeds of up to
5Gbps, faster charging time for USB-chargeable devices, optimized power efficiency, and
backward compatibility with USB 2.0.
Temperature, fan, and voltage monitoring
The CPU temperature is monitored to prevent overheating and damage. The system fan
rotations per minute (RPM) is monitored for timely failure detection. The chip monitors the
voltage levels to ensure stable supply of current for critical components.
1.4.2
Innovative ASUS features
ASUS Fan Speed technology
The ASUS Fan Speed technology smartly adjusts the fan speeds according to the system
loading to ensure quiet, cool, and efficient operation.
1-4
Chapter 1: Product Introduction
Chapter 2:
Hardware Information
2.1
Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
2-2
•
Unplug the power cord from the wall socket before touching any component.
•
Use a grounded wrist strap or touch a safely grounded object or a metal object, such
as the power supply case, before handling components to avoid damaging them due
to static electricity.
•
Hold components by the edges to avoid touching the ICs on them.
•
Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
•
Before you install or remove any component, ensure that the power supply is switched
off or the power cord is detached from the power supply. Failure to do so may cause
severe damage to the motherboard, peripherals, and/or components.
Chapter 2: Hardware Information
2.2
Motherboard overview
Before you install the motherboard, study the configuration of your chassis to ensure that the
motherboard fits into it.
To optimize the motherboard features, we highly recommend that you install it in an ATX 1.1
compliant chassis.
Ensure to unplug the chassis power cord before installing or removing the motherboard.
Failure to do so can cause you physical injury and damage motherboard components!
2.2.1
Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
2.2.2
Screw holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the
chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
Place this side towards
the rear of the chassis
ASUS P10S-I
2-3
2.2.3
2-4
Motherboard layout
Chapter 2: Hardware Information
2.2.4
Layout contents
Slots/Sockets
Page
1.
CPU sockets
2-7
2.
DDR4 sockets
2-13
3.
PCI Express x16 slot
2-17
Onboard LEDs
Page
1.
Standby Power LED (SBPWR1)
2-19
2.
Location LED (LOCLED1)
2-19
3.
CATT ERR LED (CATTERR1)
2-20
4.
Baseboard Management Controller LED (BMCLED1)
2-20
5.
CPU Warning LED (ERRCPU1)
2-21
Jumpers
Page
1.
Clear RTC RAM (3-pin CLRTC1)
2-22
2.
VGA controller setting (3-pin VGA_SW1)
2-23
3.
LAN controller setting (3-pin LAN_SW1, LAN_SW2)
2-23
4.
ME firmware force recovery setting (3-pin ME_RCVR1)
2-24
5.
PCH_MFG1 setting (3-pin PCH_MFG1)
2-24
Rear panel connectors
Page
1.
PS/2 keyboard/mouse port
2-25
2.
RJ-45 port for iKVM
2-25
3.
Video Graphics Adapter port
2-25
4.
RJ-45 ports for LAN 12
2-25
5.
USB 2.0 ports 3 and 4
2-25
6.
USB 3.0 ports 1 and 2
2-25
ASUS P10S-I
2-5
Internal connectors
Page
1.
erial ATA 6.0 Gbps connectors (7-pin SATA 6Gbps_5
S
connector [Light Blue], SATA 6Gbps_6 connector [Gray])
2-28
2.
Mini-SAS HD connector (SATA1234)
2-28
3.
USB 2.0 connector (10-1 pin USB78)
2-29
4.
2-29
USB 3.0 connector (A-Type USB3_5)
5.
Front fan connectors (4-pin CPU_FAN1, FRNT_FAN1-2)
2-30
6.
Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
2-30
7.
Trusted Platform Module connector (14-1 pin TPM1)
2-31
8.
Power Supply SMBus connector (5-pin PSUSMB1)
2-31
9.
M.2 (NGFF) connector (NGFF1)
2-32
10.
Chassis Intrusion (2-pin INTRUSION)
2-32
11.
ATX power connectors (20-pin EATXPWR1, 4-pin EATX12V1)
2-33
12.
Hard disk activity LED connector (4-pin HDLED1)
2-33
13.
System panel connector (20-1 pin PANEL1)
2-34
14.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
2-35
15.
Serial port connector (10-1 pin COM1)
2-36
16.
ystem Management Bus (SMBUS) connector
S
(5-1 pin SMBUS1)
2-36
2-6
Chapter 2: Hardware Information
2.3
Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1151 socket designed for the Intel® Xeon®
E3-1200 v5 and Intel® Core™ i3 processor.
2.3.1
•
Upon purchase of the motherboard, ensure that the PnP cap is on the socket and
the socket contacts are not bent. Contact your retailer immediately if the PnP cap
is missing, or if you see any damage to the PnP cap/socket contacts/motherboard
components. ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.
•
The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.
Installing the CPU
To install the CPU:
1.
Locate the CPU socket on the motherboard.
Before installing the CPU, ensure that the socket box is facing toward you and the load
lever is on your right.
ASUS P10S-I
2-7
2.
Press the load lever with your thumb
(A), then move it to the right (B) until it is
released from the retention tab.
Load lever
Do not remove the PnP cap yet from
the CPU socket. Doing so may bend
the pins of the socket.
Retention tab
3.
Lift the load lever until the load plate is
completely lifted.
Load plate
4.
Position the CPU above the socket,
ensuring that the gold triangle mark is
on the bottom-left corner of the socket,
then fit the CPU notches to the socket's
alignment keys.
The CPU fits in only one orientation.
DO NOT force the CPU into the
socket to prevent bending the pins on
the socket and damaging the CPU.
CPU notches
Gold
triangle
mark
Alignment
key
Alignment
key
2-8
Chapter 2: Hardware Information
5.
Close the load plate (A), ensuring
that the front edge of the load plate
slides under the retention lock (B)
then push down the load lever (C).
Load lever
Retention
lock
6.
Insert the load lever under the retention tab to remove the PnP cap from the CPU
socket.
Load lever
Retention tab
7.
Apply some Thermal Interface Material
to the exposed area of the CPU that the
heatsink will be in contact with, ensuring
that it is evenly spread in a thin layer.
Some heatsinks come with preapplied Thermal Interface Material. If
so, skip this step.
The Thermal Interface Material is
toxic and inedible. DO NOT eat it. If
it gets into your eyes or touches your
skin, wash it off immediately and seek
professional medical help.
ASUS P10S-I
2-9
2.3.2
Installing the CPU heatsink
The Intel LGA1151 processor requires a specially designed CPU heatsink to ensure
optimum thermal condition and performance.
®
•
When you buy a boxed Intel® processor, a specially designed CPU heatsink or a
CPU heatsink with a CPU fan assembly is included depending on the package. If you
buy a CPU separately, ensure that you use only Intel® certified multi‑directional CPU
heatsink or CPU heatsink with CPU fan.
•
Use an LGA1151-compatible CPU heatsink and CPU fan assembly only. The
LGA1151 socket is incompatible with the LGA775 and LGA1366 sockets in size and
dimension.
If you purchased a separate CPU heatsink and fan assembly, ensure that the Thermal
Interface Material is properly applied to the CPU heatsink or CPU before you install the
heatsink and fan assembly.
Ensure that you have installed the motherboard to the chassis before you install the CPU
fan and heatsink assembly.
To install the CPU heatsink and fan:
1.
Place the heatsink on top of the installed
CPU, making sure that the four fasteners
match the holes on the motherboard.
2.
Push down two fasteners at a time in
a diagonal sequence to secure the
heatsink and fan assembly in place.
Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan
connector.
3.
Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1.
DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if
you fail to plug this connector.
2-10
Chapter 2: Hardware Information
2.3.3
Uninstalling the CPU heatsink and fan
To uninstall the CPU heatsink and fan:
1. Disconnect the CPU fan cable from the
connector on the motherboard.
2.
Rotate each fastener counterclockwise.
3.
Pull up two fasteners at a time in a
diagonal sequence to disengage the
heatsink and fan assembly from the
motherboard.
4.
Carefully remove the heatsink and fan assembly from the motherboard.
2.3.4
Installing the CPU heatsink in rack
The Intel LGA1151 processor requires a specially designed heatsink to ensure optimum
thermal condition and performance.
®
1.
•
Ensure that you use qualified heatsink assembly only.
•
Ensure that you have applied the thermal interface material to the top of the CPU
before installing the heatsink and fan.
Peel off the sticker on the heatsink metal
plate and affix the plate to the back of
the motherboard, matching the standoffs
to the heatsink screw holes.
ASUS P10S-I
2-11
2.
2-12
Use a Phillips screwdriver to tighten
the four heatsink screws using the
recommended sequence below.
•
Ensure that the heatsink is not skewed or tilted, otherwise the CPU will overheat.
•
Do not overtighten the screws. Doing so can damage the CPU.
Chapter 2: Hardware Information
2.4
System memory
2.4.1Overview
The motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory Modules
(DIMM) sockets.
A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT
install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.
The figure illustrates the location of the DDR4 DIMM sockets:
2.4.2
Memory configurations
You may install Unbuffered DDR4 DIMMs into the DIMM sockets using the memory
configurations in this section.
UDIMM
DIMM Slot Per DIMM Populated
Channel
per Channel
1
1
DIMM Type
Unbuffered DDR4
Speed
Rank per DIMM
2133
Single Rank, Dual Rank
Always install DIMMs with the same CAS latency. For optimum compatibility, it is
recommended that you obtain memory modules from the same vendor.
ASUS P10S-I
2-13
2.4.3
Installing a DIMM on a single clip DIMM socket
1.
Unlock a DIMM socket by pressing the
retaining clip outward.
2.
Align a DIMM on the socket such that
the notch on the DIMM matches the
DIMM slot key on the socket.
DIMM notch
DIMM slot key
Unlocked retaining clip
A DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM
into a socket in the wrong direction to avoid damaging the DIMM.
3.
Hold the DIMM by both of its ends
then insert the DIMM vertically into the
socket. Apply force to both ends of the
DIMM simultaneously until the retaining
clip snaps back into place and the
DIMM cannot be pushed in any further
to ensure proper sitting of the DIMM.
Locked Retaining Clip
Always insert the DIMM into the socket vertically to prevent DIMM notch damage.
•
To install two or more DIMMs, refer to the user guide bundled in the motherboard
package.
•
Refer to the user guide for qualified vendor lists of the memory modules.
Removing a DIMM from a single clip DIMM socket
1.
Press the retaining clip outward to
unlock the DIMM.
2.
Remove the DIMM from the socket.
Support the DIMM lightly with your fingers when pressing the retaining clips. The DIMM
might get damaged when it flips out with extra force.
2-14
Chapter 2: Hardware Information
2.5
Expansion slots
In the future, you may need to install expansion cards. The following subsections describe the
slots and the expansion cards that they support.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do
so may cause you physical injury and damage motherboard components.
2.5.1
Installing an expansion card
To install an expansion card:
1.
Before installing the expansion card, read the documentation that came with it and
make the necessary hardware settings for the card.
2.
Remove the system unit cover (if your motherboard is already installed in a chassis).
3.
Remove the bracket opposite the slot that you intend to use. Keep the screw for later
use.
4.
Align the card connector with the slot and press firmly until the card is completely
seated on the slot.
5.
Secure the card to the chassis with the screw you removed earlier.
6.
Replace the system cover.
2.5.2
Configuring an expansion card
After installing the expansion card, configure it by adjusting the software settings.
1.
Turn on the system and change the necessary BIOS settings, if any. See Chapter 4 for
information on BIOS setup.
2.
Assign an IRQ to the card. Refer to the tables on the next page.
3.
Install the software drivers for the expansion card.
When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that
the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI
groups, making the system unstable and the card inoperable.
ASUS P10S-I
2-15
2.5.3
Interrupt assignments
Standard Interrupt assignments
IRQ
Priority
Standard function
0
1
System Timer
1
2
Keyboard Controller
2
-
Programmable Interrupt
3*
-
--
4*
9
Communications Port (COM1)
5*
10
Print Port (LPT1)
6
-
--
7*
-
--
8
3
System CMOS/Real Time Clock
9*
4
ACPI Mode when used
10*
5
IRQ Holder for PCI Steering
11*
6
IRQ Holder for PCI Steering
12*
7
PS/2 Compatible Mouse Port
13
8
Numeric Data Processor
14*
-
--
15*
-
--
* These IRQs are usually available for ISA or PCI devices.
2-16
Chapter 2: Hardware Information
2.5.4
PCI Express x16 slot (x16 Gen3 link)
The onboard PCIE 1 provides one x16 Gen3 link to CPU. This slot supports VGA cards and
various server class high performance add-on cards.
No.(Slot location) Short Description
1 (slot 7)
ASUS P10S-I
PCIE1
1 x PCI-E x16 (x16 Gen3 link)
2-17
2.5.5
Installing the Baseboard Management Card
Follow the steps below to install an optional ASMB8 Management Card on your motherboard.
1.
Locate the Baseboard Management Card header on the motherboard.
2.
Orient and press the Management Card in place.
The motherboard illustration is for reference only. The motherboard layout and appearance
may vary depending on the model, but the installation steps remain the same.
2-18
Chapter 2: Hardware Information
2.6
Onboard LEDs
1.
Standby Power LED (SBPWR1)
The motherboard comes with a standby power LED. The green LED lights up to
indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder
that you should shut down the system and unplug the power cable before removing or
plugging in any motherboard component. The illustration below shows the location of
the onboard LED.
2.
Location LED (LOCLED1)
The Location LED is an onboard LED that lights up when the Location Button on the front
panel is pressed. This LED helps you visually locate the server among other servers
especially when you are located at the back of the server rack.
ASUS P10S-I
2-19
3.
CATT ERR LED (CATTERR1)
The CATT ERR LED indicates that the system has experienced a fatal or catastrophic
error and cannot continue to operate.
4.
Baseboard Management Controller LED (BMCLED1)
The green heartbeat LED blinks per second to indicate that the ASMB8 is working
normally. The BMC LED works with the ASUS ASMB8 management device and
indicates its initiation status. When the PSU is plugged and the system is OFF, ASUS
ASMB8 management device starts system initiation for about one (1) minute. The BMC
LED blinks after system initiation finishes.
2-20
•
The heartbeat LED functions only when you install the ASUS ASMB8 Management
card.
•
Every time after the AC power is replugged you have to wait for about 60 seconds for
the system to power on.
Chapter 2: Hardware Information
5.
CPU Warning LED (ERRCPU1)
The CPU warning LED lights up to indicate that a CPU error or failure has occurred.
ASUS P10S-I
2-21
2.7Jumpers
1.
Clear RTC RAM (3-pin CLRTC1)
This jumper allows you to clear the CMOS memory system setup parameters by
erasing the CMOS Real Time Clock (RTC) RAM data. The onboard button cell battery
powers the RAM data in CMOS, which include system setup information such as
system passwords.
To erase the RTC RAM:
1.
Turn OFF the computer and unplug the power cord.
2.
Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap on pins
2–3 for about 5–10 seconds, then move the cap back to pins 1–2.
3.
Plug the power cord and turn ON the computer.
4.
Hold down the <Del> key during the boot process and enter BIOS setup to
reenter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
2-22
•
If the steps above do not help, remove the onboard battery and short the two pins
again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the
battery.
•
Due to chipset behavior, AC power off is required to enable C.P.R. function. You must
turn off and on the power supply or unplug and plug the power cord before rebooting
the system.
Chapter 2: Hardware Information
2.
VGA controller setting (3-pin VGA_SW1)
This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2
to activate the VGA feature.
3.
LAN controller setting (3-pin LAN_SW1, LAN_SW2)
These jumpers allows you to enable or disable the onboard Intel® I210 Gigabit LAN
controllers. Set to pins 1-2 to activate the Gigabit LAN feature.
ASUS P10S-I
2-23
4.
ME firmware force recovery setting (3-pin ME_RCVR1)
This jumper allows you to force Intel Management Engine (ME) boot from recovery
mode when ME become corrupted.
5.
PCH_MFG1 setting (3-pin PCH_MFG1)
This jumper allows you to update the BIOS ME block select.
2-24
Chapter 2: Hardware Information
2.8Connectors
2.8.1
Rear panel connectors
1.
PS/2 keyboard/mouse port (purple/green). This port is for a PS/2 keyboard or
mouse.
2.
RJ-45 port for iKVM. This RJ-45 port functions only when you enable ASMB8
Management card.
3.
Video Graphics Adapter port. This port is for a VGA monitor or other VGA-compatible
devices.
4. RJ-45 ports for LAN 12. These ports allows Gigabit connection to a Local Area
Network (LAN) through a network hub. Refer to the table below for the LAN port LED
indications.
5.
USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are available
for connecting USB 2.0 devices.
6.
USB 3.0 ports 1 and 2. These two 4-pin USB ports are available for connecting USB 3.0
devices.
ACT/LINK
LED
LAN port LED indications
Activity/Link LED
SPEED
LED
Speed LED
Status
Description
Status
Description
OFF
No link
OFF
10 Mbps connection
GREEN
Linked
ORANGE 100 Mbps connection
BLINKING
Data activity GREEN
1 Gbps connection
SPEED
LED
ACT/LINK
LED
Dedicated Management LAN port (DM_LAN1) LED indications
Activity/Link LED
Status
Description
Speed LED
Status
SPEED
LED
Description
OFF
No link
OFF
10 Mbps connection
ORANGE
Linked
ORANGE
100 Mbps connection
BLINKING
Data activity
GREEN
1 Gbps connection
ASUS P10S-I
ACT/LINK
LED
DM LAN port
2-25
2.8.2
Action
Q-Code table
PHASE
Security Phase
Normal boot
PEI(Pre-EFI
initialization) phase
POST CODE
TYPE
DESCRIPTION
1
2
3
4
5
6
10
11
15
19
0
10
1B
1C
1D
1E
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
50
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
First post code(POWER_ON_POST_CODE)
Load BSP microcode(MICROCODE_POST_CODE)
Perform early platform initialization
Set cache as ram for PEI phase(CACHE_ENABLED_POST_CODE)
Establish Stack
CPU Early init.(CPU_EARLY_INIT_POST_CODE)
PEI Core Entry
PEI cache as ram CPU initial
NB initialize before installed memory
SB initialize before installed memory
MRC_INITIALIZATION_START
MRC_CMD_PLOT_2D
MRC_FAST_BOOT_PERMITTED
MRC_RESTORE_NON_TRAINING
MRC_PRINT_INPUT_PARAMS
MRC_SET_OVERRIDES_PSPD
MRC_SPD_PROCESSING
MRC_SET_OVERRIDES
MRC_MC_CAPABILITY
MRC_MC_CONFIG
MRC_MC_MEMORY_MAP
MRC_JEDEC_INIT_LPDDR3
MRC_RESET_SEQUENCE
MRC_PRE_TRAINING
MRC_EARLY_COMMAND
MRC_SENSE_AMP_OFFSET
MRC_READ_MPR
MRC_RECEIVE_ENABLE
MRC_JEDEC_WRITE_LEVELING
MRC_LPDDR_LATENCY_SET_B
MRC_WRITE_TIMING_1D
MRC_READ_TIMING_1D
MRC_DIMM_ODT
MRC_EARLY_WRITE_TIMING_2D
MRC_WRITE_DS
MRC_WRITE_EQ
MRC_EARLY_READ_TIMING_2D
MRC_READ_ODT
MRC_READ_EQ
MRC_READ_AMP_POWER
MRC_WRITE_TIMING_2D
MRC_READ_TIMING_2D
MRC_CMD_VREF
MRC_WRITE_VREF_2D
MRC_READ_VREF_2D
MRC_POST_TRAINING
MRC_LATE_COMMAND
MRC_ROUND_TRIP_LAT
MRC_TURN_AROUND
MRC_CMP_OPT
MRC_SAVE_MC_VALUES
MRC_RESTORE_TRAINING
MRC_RMT_TOOL
MRC_WRITE_SR
MRC_DIMM_RON
MRC_RCVEN_TIMING_1D
MRC_MR_FILL
MRC_PWR_MTR
MRC_DDR4_MAPPING
MRC_WRITE_VOLTAGE_1D
MRC_EARLY_RDMPR_TIMING_2D
MRC_FORCE_OLTM
MRC_MC_ACTIVATE
(continued on the next page)
2-26
Chapter 2: Hardware Information
Action
PHASE
PEI(Pre-EFI
initialization) phase
Normal boot
POST CODE
51
52
58
5A
5B
5C
5D
5F
60
61
68
69
70
71
7D
7E
7F
55
32
34
36
4F
60
61
62
63
68
DXE(Driver
69
Execution
Environment) phase 6A
70
71
72
78
79
90
91
92
93
94
95
96
97
98
99
9A
9B
9C
9D
BDS(Boot Device
b2
Selection) phase
b3
b4
b6
b7
A0
A1
A2
A3
FF~00
A8
A9
AB
AD
AE
Operating system AA
phase
AC
ASUS P10S-I
TYPE
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
MRC Progress
Progress
DESCRIPTION
MRC_RH_PREVENTION
MRC_GET_MRC_DATA
MRC_RETRAIN_CHECK
MRC_SA_GV_SWITCH
MRC_ALIAS_CHECK
MRC_ECC_CLEAN_START
MRC_DONE
MRC_CPGC_MEMORY_TEST
MRC_TXT_ALIAS_CHECK
MRC_ENG_PERF_GAIN
MRC_MEMORY_TEST
MRC_FILL_RMT_STRUCTURE
MRC_SELF_REFRESH_EXIT
MRC_NORMAL_MODE
MRC_SSA_PRE_STOP_POINT
MRC_NO_MEMORY_DETECTED
MRC_SSA_STOP_POINT
MRC_MEM_INIT_DONE
CPU Init.
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
Progress
CPU Init.
CPU Init.
DXE Initial Program Load(IPL)
DXE Core Started
DXE NVRAM Init.
SB run-time init.
DXE CPU Init
NB Init.
NB Init.
NB Init.
SB Init.
SB Init.
SB Init.
ACPI Init.
CSM Init.
BDS started
Connect device event
PCI Bus Enumeration.
PCI Bus Enumeration.
PCI Bus Enumeration.
PCI Bus Enumeration.
PCI Bus Enumeration.
Console outout connect event
Console input connect event
AMI Super IO start
AMI USB Driver Init.
AMI USB Driver Init.
AMI USB Driver Init.
AMI USB Driver Init.
Legacy Option ROM Init.
Reset system
USB hotplug
NVRAM clean up
NVRAM configuration reset
IDE, AHCI Init.
IDE, AHCI Init.
IDE, AHCI Init.
IDE, AHCI Init.
Wait BMC ready(duration: 120 seconds).
BIOS Setup Utility password verify
BIOS Setup Utility start
BIOS Setup Utility input wait
Ready to boot event
Legacy boot event
APIC mode
Progress
PIC mode
2-27
2.8.3
Internal connectors
1.Serial ATA 6.0 Gbps connectors (7-pin SATA 6Gbps_5 connector [Light Blue],
SATA 6Gbps_6 connector [Gray])
Supported by the Intel® C232 chipset, these connectors are for the Serial ATA signal
cables for Serial ATA hard disk drives that allows up to 6Gb/s of data transfer rate.
If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 10,
or RAID 5 configuration.
The actual data transfer rate depends on the speed of Serial ATA hard disks installed.
When the M.2 connector is operating in SATA mode, SATA connector 6 (SATA 6 Gbps_6)
will be disabled.
2.
Mini-SAS HD connector (SATA1234)
This motherboard comes with one mini Serial Attached SCSI (SAS) connector, the
storage technology that supports both Serial Attached SCSI and Serial ATA. Each
connector supports up to four devices.
2-28
Chapter 2: Hardware Information
3.
USB 2.0 connector (10-1 pin USB78)
This connector is for USB 2.0 ports. Connect the USB module cable to this connector.
This USB connector complies with USB 2.0 specification that supports up to 480 Mbps
connection speed.
4.
USB 3.0 connector (A-Type USB3_5)
This connector allows you to connect a USB 3.0 device allowing you to enjoy all
the benefits of USB 3.0 including faster data transfer speeds of up to 5Gbps, faster
charging time for USB-chargeable devices, optimized power efficiency, and backward
compatibility with USB 2.0.
ASUS P10S-I
2-29
5.
Front fan connectors
(4-pin CPU_FAN1, FRNT_FAN1-2)
The fan connectors support cooling fans. Connect the fan cables to the fan connectors
on the motherboard, ensuring that the black wire of each cable matches the ground pin
of the connector.
6.
•
DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow
inside the system may damage the motherboard components.
•
These are not jumpers! DO NOT place jumper caps on the fan connectors!
•
All fans feature the ASUS Smart Fan technology.
Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
The SGPIO1 connector is used for the Intel Rapid Storage Technology Enterprise
SGPIO interface that controls the LED pattern generation, device information, and
general purpose data.
2-30
Chapter 2: Hardware Information
7.
Trusted Platform Module connector (14-1 pin TPM1)
This connector supports a Trusted Platform Module (TPM) system, which can securely
store keys, digital certificates, passwords, and data. A TPM system also helps enhance
network security, protects digital identities, and ensures platform integrity.
8.
Power Supply SMBus connector (5-pin PSUSMB1)
This connector allows you to connect SMBus (System Management Bus) to the PSU
(power supply unit) to read PSU information. Devices communicate with an SMBus
host and/or other SMBus devices using the SMBus interface.
This connector functions only when you enable the ASUS ASMB8.
Power supply is required to meet PMBus specification and customized BMC FW may be
needed. Please contact ASUS if your need further support.
ASUS P10S-I
2-31
9.
M.2 (NGFF) connector (NGFF1)
This connector allows you to install an M.2 device.
This connector supports type 2242 devices on both PCI-E and SATA interface.
•
The M.2 (NGFF) device is purchased separately
•
When the M.2 connector is operating in SATA mode, SATA connector 6 (SATA 6
Gbps_6) will be disabled.
10. Chassis Intrusion (2-pin INTRUSION)
These leads are for the intrusion detection feature for chassis with intrusion sensor or
microswitch. When you remove any chassis component, the sensor triggers and sends
a high level signal to these leads to record a chassis intrusion event. The default setting
is short CHASSIS# and GND pin by jumper cap to disable the function.
2-32
Chapter 2: Hardware Information
11. ATX power connectors (20-pin EATXPWR1, 4-pin EATX12V1)
These connectors are for the ATX power supply plugs. The power supply plugs are
designed to fit these connectors in only one orientation. Find the proper orientation and
push down firmly until the connectors completely fit.
•
DO NOT forget to connect the 20-pin and the 4-pin power plugs; otherwise, the system
will not boot up.
•
Use of a power supply unit (PSU) with a higher power output is recommended when
configuring a system with more power-consuming devices. The system may become
unstable or may not boot up if the power is inadequate.
•
This motherboard supports ATX2.0 PSU or later version.
•
Ensure that your PSU can provide at least the minimum power required by your
system.
12. Hard disk activity LED connector (4-pin HDLED1)
This LED connector is for the storage add-on card cable connected to the SATA or
SAS add-on card. The read or write activities of any device connected to the SATA or
SAS add-on card causes the front panel LED to light up.
ASUS P10S-I
2-33
13. System panel connector (20-1 pin PANEL1)
This connector supports several chassis-mounted functions.
1. System power LED (3-pin PLED)
This 3-pin connector is for the system power LED. Connect the chassis power
LED cable to this connector. The system power LED lights up when you turn on
the system power, and blinks when the system is in sleep mode.
2. Message LED (2-pin MLED)
This 2-pin connector is for the message LED cable that connects to the front
message LED. The message LED is controlled by Hardware monitor to indicate
an abnormal event occurrence.
3. System warning speaker (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning speaker. The
speaker allows you to hear system beeps and warnings.
4. Hard disk drive activity LED (2-pin +HDLED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED
cable to this connector. The IDE LED lights up or flashes when data is read from
or written to the HDD.
5. Power button/soft-off button (2-pin PWRSW)
This connector is for the system power button. Pressing the power button turns
the system on or puts the system in sleep or soft-off mode depending on the
BIOS settings. Pressing the power switch for more than four (4) seconds while the
system is ON turns the system OFF.
6. Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot
without turning off the system power.
2-34
Chapter 2: Hardware Information
14. Auxiliary panel connector (20-2 pin AUX_PANEL1)
This connector is for additional front panel features including front panel SMB, locator
LED and switch, chassis intrusion, and LAN LEDs.
1. Front panel SMB (6-1 pin FPSMB)
These connectors connect the front panel SMBus cable.
2. LAN activity LED (2-pin LAN1LINK and 2-pin LAN2LINK)
These connectors are for Gigabit LAN activity LEDs on the front panel.
3. Locator LED (2-pin AUX_LOCLED1 and 2-pin AUX_LOCLED2)
These connectors are for the Locator LED1 and LED2 on the front panel. Connect
the Locator LED cables to these 2-pin connectors. The LEDs will light up when
the Locator button is pressed.
4. Locator Button/Switch (2-pin AUX_BMCLOCBNT)
These connectors are for the locator button on the front panel. This button queries
the state of the system locator.
ASUS P10S-I
2-35
15. Serial port connector (10-1 pin COM1)
This connector is for the serial COM port. Connect the serial port module cable to one
of these connectors, then install the module to a slot opening at the back of the system
chassis.
Ensure to connect the COM port cable to the serial port connector (COM1) to use the serial
COM port.
16. System Management Bus (SMBUS) connector (5-1 pin SMBUS1)
This connector controls the system and power management-related tasks. This
connector processes the messages to and from devices rather than tripping the
individual control lines.
2-36
Chapter 2: Hardware Information
Chapter 3:
Powering Up
Chapter 3:
Powering Up
3.1
Starting up for the first time
1.
After making all the connections, replace the system case cover.
2.
Be sure that all switches are off.
3.
Connect the power cord to the power connector at the back of the system chassis.
4.
Connect the power cord to a power outlet that is equipped with a surge protector.
5.
Turn on the devices in the following order:
a.Monitor
b.
External storage devices (starting with the last device on the chain)
c.
System power
6.
After applying power, the system power LED on the system front panel case lights up.
For systems with ATX power supplies, the system LED lights up when you press the
ATX power button. If your monitor complies with “green” standards or if it has a “power
standby” feature, the monitor LED may light up or switch between orange and green
after the system LED turns on.
The system then runs the power-on self-test or POST. While the tests are running, the
BIOS beeps or additional messages appear on the screen. If you do not see anything
within 30 seconds from the time you turned on the power, the system may have failed
a power-on test. Check the jumper settings and connections or call your retailer for
assistance.
The following shows the possible beep codes and its corresponding error condition
BIOS Beep codes
Beep
7.
3-2
Error condition
1 short
Power supply surges detected during the previous power on.
1 short
No Keyboard Detected.
1 short, 2 short
No DIMM Detected.
1 short, 8 short
No VGA Detected.
2 long
Chassis Intrusion.
2 long
BIOS-image Crash Detected.
At power on, hold down the <Del> key to enter the BIOS Setup. Follow the instructions
in Chapter 4.
Chapter 3: Powering Up
3.2
Powering off the computer
3.2.1
Using the OS shut down function
Using Windows® Server 2008 R2:
1. Click the Start button, move the cursor to the triangle on the right of Log off, then click
Shut Down.
2. From the Shutdown Event Tracker, select the option that best describes why you
want to shut down the computer.
3.
Ensure that the Planned check box is checked.
4.
If necessary, key in comments.
5.Click OK.
Using Windows® Server 2012:
1. Press <Ctrl>+<Alt>+<Del>.
2. Click on the Power icon on the lower right side of the screen.
3. Select Shut down.
4.
In the Shutdown Event Tracker, select the Other (Planned) option in the selection
lists. Otherwise, select the option that best describes why you want to shut down the
computer.
5.Click Continue.
3.2.2
Using the dual function power switch
While the system is ON, press the power switch for less than four (4) seconds to put the
system to sleep mode or to soft-off mode, depending on the BIOS setting.
Pressing the power switch for more than four (4) seconds lets the system enter the soft-off
mode regardless of the BIOS setting.
ASUS P10S-I
3-3
3-4
Chapter 3: Powering Up
Chapter 4:
BIOS Setup
4.1
Managing and updating your BIOS
The following utilities allow you to manage and update the motherboard Basic Input/Output
System (BIOS) setup:
1.
ASUS CrashFree BIOS 3
To recover the BIOS using a bootable USB flash disk drive when the BIOS file fails or
gets corrupted.
2.
ASUS EzFlash
Updates the BIOS using a USB flash disk.
3.
BUPDATER
Updates the BIOS in DOS mode using a bootable USB flash disk drive.
Refer to the corresponding sections for details on these utilities.
Save a copy of the original motherboard BIOS file to a bootable USB flash disk drive in
case you need to restore the BIOS in the future. Copy the original motherboard BIOS using
the BUPDATER utility.
4.1.1
ASUS CrashFree BIOS 3 utility
The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file
when it fails or gets corrupted during the updating process. You can update a corrupted BIOS
file using a USB flash drive that contains the updated BIOS file.
Prepare a USB flash drive containing the updated motherboard BIOS before using this
utility.
When downloading or updating the BIOS file, rename it as P10SI.CAP for this
motherboard.
Recovering the BIOS from a USB flash drive
To recover the BIOS from a USB flash drive:
1.
Insert the USB flash drive with the original or updated BIOS file to one USB port on the
system.
2.
The utility will automatically recover the BIOS. It resets the system when the BIOS
recovery finished.
DO NOT shut down or reset the system while recovering the BIOS! Doing so would cause
system boot failure!
The recovered BIOS may not be the latest BIOS version for this motherboard. Visit the
ASUS website at www.asus.com to download the latest BIOS file.
4-2
Chapter 4: BIOS Setup
4.1.2
ASUS EzFlash Utility
The ASUS EzFlash Utility feature allows you to update the BIOS using a USB flash disk
without having to use a DOS‑based utility.
Download the latest BIOS from the ASUS website at www.asus.com before using this
utility.
The succeeding BIOS screens are for reference only. The actual BIOS screen displays
may not be the same as shown.
To update the BIOS using EzFlash Utility:
1.
Insert the USB flash disk that contains the latest BIOS file to the USB port.
2.
Enter the BIOS setup program. Go to the Tool menu to select ASUS EzFlash Utility
and press <Enter> to enable it.
ASUS Tek. EzFlash Utility
Current Platform
Platform : P10S-I
Version : 0200
Build Date :07/20/2015
FS0
New Platform
Platform : P10S-I
Version : 0206
Build Date :08/01/2015
System Volume Information
P10S-I BIOS
Windows
<DIR>
<DIR>
<DIR>
[Up/Down/Left/Right]:Switch [Enter]:Choose [q]:Exit
3.
Press <Tab> to switch to the Drive field.
4.
Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS
then press <Enter>.
5.
Press <Tab> to switch to the Folder Info field.
6.
Press the Up/Down arrow keys to find the BIOS file then press <Enter>.
7.
Reboot the system when the update process is done.
ASUS P10S-I
4-3
•
This function can support devices such as a USB flash disk with FAT 32/16 format and
single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent system
boot failure!
Ensure to load the BIOS default settings to ensure system compatibility and stability. Press
<F5> and select Yes to load the BIOS default settings.
4.1.3
BUPDATER utility
The succeeding BIOS screens are for reference only. The actual BIOS screen displays may
not be the same as shown.
The BUPDATER utility allows you to update the BIOS file in DOS environment using a
bootable USB flash disk drive with the updated BIOS file.
Updating the BIOS file
To update the BIOS file using the BUPDATER utility:
1.
Visit the ASUS website at www.asus.com and download the latest BIOS file for the
motherboard. Save the BIOS file to a bootable USB flash disk drive.
2.
Download the BUPDATER utility (BUPDATER.exe) from the ASUS support website at
www.asus.com/support to the bootable USB flash disk drive you created earlier.
3.
Boot the system in DOS mode, then at the prompt, type:
BUPDATER /i[filename].CAP
where [filename] is the latest or the original BIOS file on the bootable USB flash disk
drive, then press <Enter>.
A:\>BUPDATER /i[file name]CAP
4-4
Chapter 4: BIOS Setup
The utility verifies the file, then starts updating the BIOS file.
ASUS Tek. EzFlash Utility
Current Platform
Platform : P10S-I
Version
: 0200
Build date: 07/20/2015
Start Programming Flash.
New Platform
Platform : P10S-I
Version
: 0206
Build date: 08/01/2015
DO NOT SHUTDOWN THE SYSTEM!!!
Write
75%
DO NOT shut down or reset the system while updating the BIOS to prevent system boot
failure!
The utility returns to the DOS prompt after the BIOS update process is completed.
4.
Reboot the system from the hard disk drive.
The BIOS update is finished! Please restart your system.
C:\>
ASUS P10S-I
4-5
4.2
BIOS setup program
This motherboard supports a programmable firmware chip that you can update using the
provided utility described in section 4.1 Managing and updating your BIOS.
Use the BIOS Setup program when you are installing a motherboard, reconfiguring your
system, or prompted to “Run Setup.” This section explains how to configure your system
using this utility.
Even if you are not prompted to use the Setup program, you can change the configuration of
your computer in the future. For example, you can enable the security password feature or
change the power management settings. This requires you to reconfigure your system using
the BIOS Setup program so that the computer can recognize these changes and record them
in the CMOS RAM of the firmware chip.
The firmware chip on the motherboard stores the Setup utility. When you start up the
computer, the system provides you with the opportunity to run this program. Press <Del>
during the Power-On Self-Test (POST) to enter the Setup utility; otherwise, POST continues
with its test routines.
If you wish to enter Setup after POST, restart the system by pressing <Ctrl>+<Alt>+<Del>,
or by pressing the reset button on the system chassis. You can also restart by turning the
system off then back on. Do this last option only if the first two failed.
The Setup program is designed to make it as easy to use as possible. Being a menu-driven
program, it lets you scroll through the various sub-menus and make your selections from the
available options using the navigation keys.
4-6
•
The default BIOS settings for this motherboard apply for most conditions to ensure
optimum performance. If the system becomes unstable after changing any BIOS
settings, load the default settings to ensure system compatibility and stability. Press
<F5> and select Yes to load the BIOS default settings.
•
The BIOS setup screens shown in this section are for reference purposes only, and
may not exactly match what you see on your screen.
•
Visit the ASUS website (www.asus.com) to download the latest BIOS file for this
motherboard.
Chapter 4: BIOS Setup
4.2.1
BIOS menu screen
Menu items
Menu bar
Configuration fields
General help
Navigation keys
4.2.2
Menu bar
The menu bar on top of the screen has the following main items:
Main For changing the basic system configuration
Advanced
For changing the advanced system settings
Security
For changing the security settings
Boot For changing the system boot configuration
Monitor or displaying the system temperature, power status, and changing
F
the fan settings
Tool For configuring options for special functions
Save & Exit
For selecting the save & exit options
Server Mgmt
For changing the server mgmt settings
Event Logs
For changing the event log settings
To select an item on the menu bar, press the right or left arrow key on the keyboard until the
desired item is highlighted.
ASUS P10S-I
4-7
4.2.3
Menu items
The highlighted item on the menu bar displays the specific items for that menu. For example,
selecting Main shows the Main menu items. The other items (Advanced, Event Logs, Boot,
Monitor, Security, Tool, Save & Exit, Server Mgmt, and Event Logs) on the menu bar have
their respective menu items.
4.2.4
Submenu items
A solid triangle before each item on any menu screen means that the item has a submenu.
To display the submenu, select the item and press <Enter>.
4.2.5
Navigation keys
At the bottom right corner of a menu screen are the navigation keys for the BIOS setup
program. Use the navigation keys to select items in the menu and change the settings.
4.2.6
General help
At the top right corner of the menu screen is a brief description of the selected item.
4.2.7
Configuration fields
These fields show the values for the menu items. If an item is user-configurable, you can
change the value of the field opposite the item. You cannot select an item that is not userconfigurable. A configurable field is enclosed in brackets, and is highlighted when selected.
To change the value of a field, select it and press <Enter> to display a list of options.
4.2.8
Pop-up window
Select a menu item and press <Enter> to display a pop-up window with the configuration
options for that item.
4.2.9
Scroll bar
A scroll bar appears on the right side of a menu screen when there are items that do not fit
on the screen. Press the Up/Down arrow keys or <Page Up> /<Page Down> keys to display
the other items on the screen.
4-8
Chapter 4: BIOS Setup
4.3
Main menu
When you enter the BIOS Setup program, the Main menu screen appears. The Main menu
provides you an overview of the basic system information, and allows you to set the system
date and time.
System Date [Day xx/xx/xxxx]
Allows you to set the system date to [Day mm/dd/yyyy].
Where:
Day = Day of the week
mm = Month (numeric value)
dd = Day (numeric value)
yyyy = Year (numeric value)
System Time [xx:xx:xx]
Allows you to set the system time to [hh/mm/ss].
Where:
hh = Hour (numeric value)
mm = Minutes (numeric value)
ss = Seconds (numeric value)
ASUS P10S-I
4-9
4.4
Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Take caution when changing the settings of the Advanced menu items. Incorrect field
values can cause the system to malfunction.
4-10
Chapter 4: BIOS Setup
4.4.1
Trusted Computing
Configuration
Security Device Support [Enabled]
Allows you to enable or disable the BIOS support for security device.
Configuration options: [Disabled] [Enabled]
Device Select [Auto]
Allows you to restrict support to selected device. Auto will support both devices.
Configuration options: [TPM 1.2] [TPM 2.0] [Auto]
4.4.2
Chipset Configuration
System Agent (SA) Configuration
Allows you to set System Agent (SA) parameters.
VT-d [Enabled]
Allows you to enable virtualization technology function on memory control hub.
Configuration options: [Enabled] [Disabled]
ASUS P10S-I
4-11
Above 4GB MMIO BIOS assignment [Disabled]
Allows you to enable or disable above 4GB Memory Mapped IO BIOS assignment. When
aperture size is set to 2048 MB, this is disabled automatically.
Configuration options: [Enabled] [Disabled]
DMI/OPI Configuration
DMI Max Link Speed [Auto]
Allows you to set the DMI speed.
Configuration options: [Auto] [Gen1] [Gen2] [Gen3]
DMI Vc1 Control [Disabled]
Allows you to enable or disable DMI Vc1.
Configuration options: [Enabled] [Disabled]
DMI Vcm Control [Enabled]
Allows you to enable or disable DMI Vcm.
Configuration options: [Enabled] [Disabled]
DMI Link ASPM Control [L1]
This item is for the control of the Active State Power Management on SA side of the
DMI link.
Configuration options: [Disabled] [L1]
4-12
Chapter 4: BIOS Setup
PEG Port Configuration
PEG 0:1:0
Enable Root Port [Auto]
Allows you to enable or disable the root port.
Configuration options: [Disabled] [Enabled] [Auto]
Max Link speed [Auto]
Allows you to configure PEG 0:1:0 Max Speed.
Configuration options: [Auto] [Gen1] [Gen2] [Gen3]
Max Link Width [Auto]
Allows you to force PEG link to retrain selected value.
Configuration options: [Auto] [Force X1] [Force X2] [Force X4] [Force X8]
Power Down Unused Lanes [Auto]
Allows you to power down unused lanes.
[Disabled] No power saving.
[Auto]
BIOS will power down unused lanes based in the max
possible link width.
ASPM [Auto]
Allows you to control ASPM support for the PEG 0. This has no effect if
PEG is not the currently active device.
Configuration options: [Disabled] [Auto] [ASPM L0s] [ASPM L1] [ASPM
L0sL1]
PEG0 Max Payload size [Auto]
Allows you to set the PEG0 max payload size.
Configuration options: [Auto] [128 TLP] [256 TLP]
ASUS P10S-I
4-13
Program PCIe ASPM after OpRom [Disabled]
Allows you to select when to program the PCIe ASPM.
[Disabled]
PCIe ASPM will be programmed before OpROM.
[Enabled]
PCIe ASPM will be programmed after OpROM.
Memory Configuration
Allows you to change memory information settings.
Maximum Memory Frequency [Auto]
Allows you to set the maximum memory frequency.
Configuration options: [Auto] [1067] [1333] [1600] [1867] [2133] [2400] [2667] [2933]
[3200]
Max TOLUD [Dynamic]
Allows you to set the maximum value of TOLUD. Dynamic assignment would adjust
TOLUD automatically based on largest MMIO length of installed graphic controller.
Configuration options: [Dynamic] [1 GB] [1.25 GB] [1.5 GB] [1.75 GB] [2 GB] [2.25 GB]
[2.5 GB] [2.75 GB] [3 GB] [3.25 GB] [3.5 GB]
Memory Scrambler [Enabled]
Set this item to enable or disable memory scrambler support.
Configuration options: [Disabled] [Enabled]
Memory Remap [Enabled]
Allows you to enable or disable memory remap above 4GB.
Configuration options: [Enabled] [Disabled]
4-14
Chapter 4: BIOS Setup
PCH-IO Configuration
Allows you to set PCH-IO parameters.
PCI Express Configuration
PCI Express Clock Gating [Enabled]
Allows you to enable or disable PCI Express Clock Gating for each root port.
Configuration options: [Disabled] [Enabled]
DMI Link ASPM Control [Enabled]
Allows you to enable or disable the control of Active State Power Management on SA
side of the DMI link.
Configuration options: [Disabled] [Enabled]
ASUS P10S-I
4-15
USB Configuration
Allows you to set the USB Configuration settings.
USB Precondition[Disabled]
Allows you to precondition work on USB host controller and root ports for faster
enumeration.
Configuration options: [Enabled] [Disabled]
xDCI Support [Disabled]
Allows you to enable or disable xDCI (USB OTG Device).
Configuration options: [Disabled] [Enabled]
USB Port Disable Override [Disabled]
Allows you to enable or disable the corresponding USB port from reporting a Device
Connection to the controller.
Configuration options: [Disabled] [Select Per-Pin]
CLKRUN# Logic [Enabled]
Allows you to enable or disable the CLKRUN# logic to stop the PCI clocks.
Configuration options: [Disabled] [Enabled]
Serial IRQ Mode [Continuous]
Allows you to configure Serial IRQ mode.
Configuration options: [Quiet] [Continuous]
High Precision Timer [Enabled]
Allows you to enable or disable the High Precision Event Timer.
Configuration options: [Disabled] [Enabled]
4-16
Chapter 4: BIOS Setup
Intel Server Platform Services
Intel TXT Information
ASUS P10S-I
4-17
PCI/PCIE Subsystem Settings
Allows you to configure PCI, PCI-X, and PCI Express Settings.
PCI Latency Timer [32 PCI Bus Clocks]
Allows you to set the value to be programmed into PCI Latency Timer Register.
Configuration options: [32 PCI Bus Clocks] [64 PCI Bus Clocks] [96 PCI Bus Clocks] [128 PCI
Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus
Clocks]
PERR# Generation [Disabled]
Allows you to enable or disable PCI Device tp generation PERR#.
Configuration options: [Disabled] [Enabled]
SERR# Generation [Disabled]
Allows you to enable or disable PCI Device tp generation SERR#.
Configuration options: [Disabled] [Enabled]
Load RT32 Image [Enabled]
Allows you to enable or disable RT32 Image Loading.
Configuration options: [Disabled] [Enabled]
VGA Priority [Offboard Device]
This allows you to prioritize between the onboard and offboard video device to be found.
Configuration options: [Onboard Device] [Offboard Device]
PCIe slot opROM option
PCIE1 Option ROM [Enabled]
Allows you to enable or disable the PCIE1 Option ROM.
Configuration options: [Disabled] [Enabled]
4-18
Chapter 4: BIOS Setup
4.4.3
Platform Configuration
USB Configuration
Legacy USB Support [Enabled]
[Disabled]
The USB devices can be used only for the BIOS setup program. It cannot
be recognized in boot devices list.
Enables the support for USB devices on legacy operating systems (OS).
Allows the system to detect the presence of USB devices at startup. If
detected, the USB controller legacy mode is enabled. If no USB device is
detected, the legacy USB support is disabled.
[Enabled]
[Auto]
XHCI Hand-off [Disabled]
This item is set to [Disabled] by default for the EHCI (enhanced host controller interface)
support by XHCI drivers in operating systems.
[Disabled]
[Enabled]
ASUS P10S-I
Support XHCI by XHCI drivers for operating systems with XHCI support.
Support XHCI by BIOS for operating systems without XHCI support.
4-19
USB Mass Storage Driver Support [Enabled]
Allows you to enable or disable the USB Mass Storage driver support.
Configuration options: [Disabled] [Enabled]
Port 60/64 Emulation [Enabled]
This allows you to enable the I/O port 60h/64h emulation support. This should be enabled for
the complete USB keyboard legacy support for non-USB aware OSes.
Configuration options: [Disabled] [Enabled]
USB hardware delays and time-outs
USB transfer time-out [20 sec]
Allows you to select the USB transfer time-out value.
Configuration options: [1 sec] [5 sec] [10 sec] [20 sec]
Device reset time-out [20 sec]
Allows you to select the USB device reset time-out value.
Configuration options: [10 sec] [20 sec] [30 sec] [40 sec]
Device power-up delay [Auto]
This allows you to set the maximum time the device will take before it properly reports itself to
the Host Controller.
Configuration options: [Auto] [Manual]
Mass Storage Devices
Allows you to select the mass storage device emulation type for devices connected.
Configuration options: [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM]
NVMe Configuration
4-20
Chapter 4: BIOS Setup
Onboard LAN Configuration
This allows you to enable or disable the onboard LAN.
Intel LAN1 Enable [Enabled]
Allows you to enable or disable the Intel LAN.
Configuration options: [Disabled] [Enabled]
Intel LAN ROM Type [PXE]
Allows you to select the Intel LAN ROM type.
Configuration options: [Disabled] [PXE] [iSCSI]
Intel LAN2 Enable [Enabled]
Allows you to enable or disable the Intel LAN.
Configuration options: [Disabled] [Enabled]
Intel LAN ROM Type [Disabled]
Allows you to select the Intel LAN ROM type.
Configuration options: [Disabled] [PXE] [iSCSI]
Super IO Configuration
ASUS P10S-I
4-21
Serial Port 1 Configuration
Allows you to set the parameters of Serial Port 1.
Serial Port [Enabled]
Allows you to enable or disable Serial Port.
Configuration options: [Disabled] [Enabled]
Change Settings [Auto]
Allows you to choose the setting for Super IO device.
Configuration options: [Auto] [IO=3F8h; IRQ=4;] [IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11,
12;] [IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;] [IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11,
12;] [IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;]
4-22
Chapter 4: BIOS Setup
Serial Port Console Redirection
COM1 / COM2
Console Redirection [Disabled]
Allows you to enable or disable the console redirection feature.
Configuration options: [Disabled] [Enabled]
The following item appears only when you set Console Redirection to [Enabled].
Console Redirection Settings
This item becomes configurable only when you enable the Console Redirection item. The
settings specify how the host computer and the remote computer (which the user is using)
will exchange data. Both computers should have the same or compatible settings.
Terminal Type [VT-UTF8]
Allows you to set the terminal type.
[VT100]
ASCII char set.
[VT100+]
Extends VT100 to support color, function keys, etc.
[VT-UTF8]
Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
[ANSI]
Extended ASCII char set.
ASUS P10S-I
4-23
Bits per second [57600]
Selects serial port transmission speed. The speed must be matched on the other side.
Long or noisy lines may require lower speeds.
Configuration options: [9600] [19200] [38400] [57600] [115200]
Data Bits [8]
Configuration options: [7] [8]
Parity [None]
A parity bit can be sent with the data bits to detect some transmission errors. [Mark]
and [Space] parity do not allow for error detection.
[None]
None.
[Even]
parity bit is 0 if the num of 1’s in the data bits is even.
[Odd]
parity bit is 0 if num of 1’s in the data bits is odd.
[Mark]
parity bit is always 1.
[Space]
parity bit is always 0.
Stop Bits [1]
Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning.)
The standard setting is 1 stop bit. Communication with slow devices may require more
than 1 stop bit.
Configuration options: [1] [2]
Flow Control [Hardware RTS/CTS]
Flow control can prevent data loss from buffer overflow. When sending data, if the
receiving buffers are full, a “stop” signal can be sent to stop the data flow. Once the
buffers are empty, a “start” signal can be sent to re-start the flow. Hardware flow control
uses two wires to send start/stop signals.
Configuration options: [None] [Hardware RTS/CTS]
VT-UTF8 Combo Key Support [Enabled]
Allows you to enable the VT-UTF8 Combo Key Support for ANSI/VT100 terminals.
Configuration options: [Disabled] [Enabled]
Recorder Mode [Disabled]
With this mode enabled only text will be sent. This is to capture Terminal data.
Configuration options: [Disabled] [Enabled]
Legacy OS Redirection Resolution [80x24]
Allows you to set the number of rows and columns supported on the Legacy OS.
Configuration options: [80x24] [80x25]
Putty Keypad [VT100]
Allows you to select the FunctionKey and Keypad on Putty.
Configuration options: [VT100] [LINUX] [XTERMR6] [SCO] [ESCN] [VT400]
Redirection After BIOS POST [Always Enable]
Allows you to specify if Bootloader is selected than Legacy console redirection.
Configuration options: [Always Enable] [Bootloader]
4-24
Chapter 4: BIOS Setup
Legacy Console Redirection Settings
Legacy Serial Redirection Port [COM1]
Allows you to select a COM port to display redirection of Legacy OS and Legacy
OPROM Messages.
Configuration options: [COM1] [COM2]
Serial Port for Out-of-Band Management/
Windows Emergency Management Services (EMS)
Console Redirection [Disabled]
Allows you to enable or disable the console redirection feature.
Configuration options: [Disabled] [Enabled]
The following item appears only when you set Console Redirection to [Enabled].
Console Redirection Settings
Out-of-Band Mgmt Port [COM1]
Microsoft Windows Emergency Management Services (EMS) allows for remote
management of a Windows Server OS through a serial port.
Configuration options: [COM1] [COM2]
Terminal Type [VT-UTF8]
Allows you to set the terminal type for out-of-band management.
Configuration options: [VT100] [VT100+] [VT-UTF8] [ANSI]
Bits per second [115200]
Allows you to set the serial port transmission speed.
Configuration options: [9600] [19200] [57600] [115200]
Flow Control [None]
Allows you to set the flow control to prevent data loss from buffer overflow.
Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff]
ASUS P10S-I
4-25
ACPI Settings
Enable Hibernation [Enabled]
Allows you to enable or disable the ability of the system to hibernate (OS/S4 Sleep State).
Configuration options: [Disabled] [Enabled]
This option may be not be effective with some OS.
ACPI Sleep State [S3 (Suspend to RAM)]
Allows you to select the highest ACPI sleep state the system will enter when the SUSPEND
button is pressed.
Configuration options: [Suspend Disabled] [S3 (Suspend to RAM)]
APM
Allows you to configure the Advance Power Management (APM) settings.
Restore AC Power Loss [Last State]
When set to [Power Off], the system goes into off state after an AC power loss. When set
to [Power On], the system will reboot after an AC power loss. When set to [Last State], the
system goes into either off or on state, whatever the system state was before the AC power
loss.
Configuration options: [Power Off] [Power On] [Last State]
Power On By PCI [Disabled]
Allows you to enable or disable the Wake-on-LAN feature of Intel LAN.
Configuration options: [Disabled] [Enabled]
Power On By PCIE [Disabled]
[Disabled]
[Enabled]
4-26
Disables the PCIE devices to generate a wake event.
Enables the PCIE devices to generate a wake event.
Chapter 4: BIOS Setup
Power On By Ring [Disabled]
[Disabled]
[Enabled]
Disables the Ring devices to generate a wake event.
Enables the Ring devices to generate a wake event.
This item functions only if there is a serial port (COM1) connector on the motherboard.
Power On By RTC [Disabled]
[Disabled]
[Enabled]
Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and Hour/Minute/
Second will become user-configurable with set values.
SMART Settings
SMART Self Test [Enabled]
Allows you to run SMART Self Test on all HDDs during POST.
Configuration options: [Disabled] [Enabled]
WHEA Configurations
WHEA Support [Enabled]
This item allows you to enable or disable the WHEA support.
Configuration options: [Disabled] [Enabled]
ASUS P10S-I
4-27
4.4.4
CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically
detects. Some items may not appear if your CPU does not support the related functions.
Navigate to the second page of the screen to see the rest of items in this menu by pressing
the Up or Down arrow keys.
To quickly go to the last item of the second page, press the Page Down button. Press the
Page Up button to go back to the first item in the first page.
4-28
Chapter 4: BIOS Setup
Hyper-threading [Enabled]
This item allows a hyper-threading processor to appear as two logical processors, allowing
the operating system to schedule two threads or processors simultaneously.
Configuration options: [Disabled] [Enabled]
Active Processor Cores [All]
Allows you to select the number of CPU cores to activate in each processor package.
Configuration options: [All] [1] [2] [3]
Intel Virtualization Technology [Enabled]
When set to [Enabled], a VMM can utilize the additional hardware capabilities provided by
Vanderpool Technology.
Configuration options: [Disabled] [Enabled]
Hardware Prefetcher [Enabled]
Allows you to enable or disable the MLC streamer prefetcher.
Configuration options: [Disabled] [Enabled]
Adjacent Cache Line Prefetch [Enabled]
This item allows you to enable or disable prefetching of adjacent cache lines.
Configuration options: [Disabled] [Enabled]
CPU AES [Enabled]
Allows you to enable or disable the CPU Advance Encryption Standard instructions.
Configuration options: [Disabled] [Enabled]
ASUS P10S-I
4-29
Boot performance mode [Turbo Performance]
Allows you to select the CPU performance state during system boot before the operating
system takes control. The CPU runs at a selected performance ratio based on CPU
configuration.
Configuration options: [Max Non-Turbo Performance] [Turbo Performance]
HardWare P states (HWP) [Disabled]
Allows you to enable or disable HWP support.
Configuration options: [Disabled] [Enabled]
Intel(R) SpeedStep(tm) [Enabled]
Allows your system to adjust the CPU’s voltage and cores frequency, resulting in decreased
power consumption and heat production.
[Disabled]
The CPU runs at its default speed.
[Enabled]
The system controls the CPU speed.
The following item appears only when you set Intel(R) SpeedStep(tm) to [Enabled].
Turbo Mode [Enabled]
This item allows you to automatically set the CPU cores to run faster than the base
operating frequency when it is below the operating power, current and temperature
specification limit.
Configuration options: [Disabled] [Enabled]
CPU C states [Enabled]
Allows you to enable or disable the CPU C states.
Configuration options: [Disabled] [Enabled]
The following items appear only when you set the CPU C states to [Enabled].
Enhanced C-States [Enabled]
This item allows you to enable or disable C1E. When [Enabled] is selected, CPU will
switch to minimum speed when all cores enter C-State.
Configuration options: [Disabled] [Enabled]
C-State Auto Demotion [C1 and C3]
Allows you to enable or disable the demotion of the C-State.
Configuration options: [Disabled] [C1] [C3] [C1 and C3]
C-State Un-demotion [C1 and C3]
Allows you to enable or disable the un-demotion of the C-State.
Configuration options: [Disabled] [C1] [C3] [C1 and C3]
Package C state demotion [Disabled]
Allows you to enable or disable the Package C state demotion.
Configuration options: [Disabled] [Enabled]
Package C state undemotion [Disabled]
Allows you to enable or disable the Package C state undemotion.
Configuration options: [Disabled] [Enabled]
4-30
Chapter 4: BIOS Setup
CState Pre-Wake [Enabled]
Allows you to enable or disable the CState Pre-Wake. Selecting [Disabled] will set bit 30 of
POWER_CTL MSR(0x1FC) to 1 to disable the CState Pre-Wake.
Configuration options: [Disabled] [Enabled]
Package C State limit [AUTO]
Allows you set the Package C State limit.
Configuration options: [C0/C1] [C2] [C3] C6] [C7] [C7s] [C8] [AUTO]
CFG lock [Enabled]
Allows you to configure MSR 0xE2[15], CFG lock bit.
Configuration options: [Disabled] [Enabled]
Intel TXT(LT) Support [Disabled]
Allows you to enable or disable the Intel(R) TXT(LT) support.
Configuration options: [Disabled] [Enabled]
ASUS P10S-I
4-31
4.4.5
SATA Configuration
SATA Controller(s) [Enabled]
Allows you to enable or disable the SATA Device.
Configuration options: [Enabled] [Disabled]
SATA Mode Selection [AHCI]
This item allows you to set the SATA configuration.
[AHCI]
Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advanced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
[RAID]
Set to [RAID] when you want to create a RAID configuration from the SATA
hard disk drives.
4-32
Chapter 4: BIOS Setup
Software Feature Mask Configuration
RAID0 [Enabled]
Allows you to enable or disable the RAID0 feature.
Configuration options: [Disabled] [Enabled]
RAID1 [Enabled]
Allows you to enable or disable the RAID1 feature.
Configuration options: [Disabled] [Enabled]
RAID10 [Enabled]
Allows you to enable or disable the RAID10 feature.
Configuration options: [Disabled] [Enabled]
RAID5 [Enabled]
Allows you to enable or disable the RAID5 feature.
Configuration options: [Disabled] [Enabled]
Intel Rapid Recovery Technology [Enabled]
Allows you to enable or disable the Intel Rapid Recovery Technology.
Configuration options: [Disabled] [Enabled]
OROM UI and BANNER [Enabled]
[Disabled]
[Enabled]
o OROM banner or information will be displayed if all disks and
N
RAID volumes are Normal.
OROM UI is shown.
HDD Unlock [Enabled]
Selecting [Enabled] will indicate that the HDD password unlock in the OS is enabled.
Configuration options: [Disabled] [Enabled]
LED Locate [Enabled]
Selecting [Enabled] will indicate that the LED/SGPIO hardware is attached and ping to
locate feature is enabled on the OS.
Configuration options: [Disabled] [Enabled]
IRRT Only on eSATA [Enabled]
[Disabled]
[Enabled]
ASUS P10S-I
Any RAID volume can span internal and eSATA drives.
Only IRRT volumes can span internal and eSATA drives.
4-33
Smart Response Technology [Enabled]
Allows you to enable or disable the Smart Response Technology.
Configuration options: [Disabled] [Enabled]
OROM UI Normal Delay [4 sec]
Allows you to select the delay time of the OROM UI Splash Screen in a normal status.
Configuration options: [2 sec] [4 sec] [6 sec] [8 sec]
RST Force Form [Disabled]
Allows you to enable or disable Form for Intel Rapid Storage Technology.
Configuration options: [Disabled] [Enabled]
SATA Port 1 / SATA Port 2 / SATA Port 3 / SATA Port 4 / SATA Port 5 /
SATA Port 6
Port 1 / Port 2 / Port 3 / Port 4 / Port 5 / Port 6 [Enabled]
Allows you to enable or disable the SATA port.
Configuration options: [Disabled] [Enabled]
Mechanical Presence Switch [Enabled]
Allows you to control a connected Mechanical Presence Switch.
Configuration options: [Disabled] [Enabled]
Spin Up Device [Disabled]
Selecting [Enabled] will start a COMERSET initialization sequence to the device on an
edge detect from 0 to 1.
Configuration options: [Disabled] [Enabled]
SATA Device Type [Hard Disk Drive]
Allows you to set whether the SATA port is connected to Solid State Drive or Hard Disk
Drive.
Configuration options: [Hard Disk Drive] [Solid State Drive]
Device Sleep [Disabled]
Allows you to enable or disable the mSata for RTD3.
Conifguration Options: [Disabled] [Enabled]
SATA DEVSLEP Idle Timeout Config [Disabled]
Allows you to enable or disable SATA DTIO Config.
Configuration options: [Disabled] [Enabled]
4.4.6
Network Stack Configuration
Network Stack [Disabled]
Allows you to enable or disable UEFI Network Stack.
Configuration options: [Disabled] [Enabled]
The following items appear only when you set the Network Stack to [Enabled].
4-34
Chapter 4: BIOS Setup
Ipv4 PXE Support [Enabled]
Enables or disables the Ipv4 PXE Boot Support. If disabled, Ipv4 PXE boot option will
not be created.
Configuration options: [Disable] [Enable]
Ipv6 PXE Support [Enabled]
Enables or disables the Ipv6 PXE Boot Support. If disabled, Ipv6 PXE boot option will
not be created.
Configuration options: [Disable] [Enable]
PXE boot wait time [0]
Set the wait time to press ESC key to abort the PXE boot. Use the <+> or <-> to adjust
the value. The values range from 0 to 5.
Media detect count [1]
Set the number of times presence of media will be checked. Use the <+> or <-> to
adjust the value. The values range from 1 to 50.
4.4.7
CSM Configuration
CSM Support [Enabled]
This option allows you to enable or disable CSM Support.
Configuration options: [Disabled] [Enabled]
ASUS P10S-I
4-35
GateA20 Active [Upon Request]
This allows you to set the GA20 option.
[Upon Request] GA20 can be disabled using BIOS services.
[Always] Do not allow disabling GA20; this option is useful when any RT code is
executed above 1MB.
Option ROM Messages [Force BIOS]
This allows you to set the display mode for option ROM.
Configuration options: [Force BIOS] [Keep Current]
Boot Option filter [Legacy only]
This option allows you to control the Legacy/UEFI ROMs priority.
Configuration options: [UEFI and Legacy] [Legacy only] [UEFI only]
Network / Storage / Video [Legacy]
This option allows you to control the execution of UEFI and Legacy PXE/ Storage/ Video
OpROM.
Configuration options: [UEFI ] [Legacy]
Other PCI devices [Legacy]
This item determines the OpROM execution policy for devices other than Network, Storage,
or Video.
Configuration options: [UEFI ] [Legacy]
4.4.8
iSCSI Configuration
Allows you to configure the iSCSI parameters.
4-36
Chapter 4: BIOS Setup
4.5
Security Menu
This menu allows a new password to be created or a current password to be changed. The
menu also enables or disables the Secure Boot state and lets the user configure the System
Mode state.
Administrator Password
To set an administrator password:
1.
Select the Administrator Password item and press <Enter>.
2.
From the Create New Password box, key in a password, then press <Enter>.
3.
Confirm the password when prompted.
To change an administrator password:
1.
Select the Administrator Password item and press <Enter>.
2.
From the Enter Current Password box, key in the current password, then press
<Enter>.
3.
From the Create New Password box, key in a new password, then press <Enter>.
4.
Confirm the password when prompted.
To clear the administrator password, follow the same steps as in changing an administrator
password, but press <Enter> when prompted to create/confirm the password.
ASUS P10S-I
4-37
User Password
To set a user password:
1.
Select the User Password item and press <Enter>.
2.
From the Create New Password box, key in a password, then press <Enter>.
3.
Confirm the password when prompted.
To change a user password:
1.
Select the User Password item and press <Enter>.
2.
From the Enter Current Password box, key in the current password, then press
<Enter>.
3.
From the Create New Password box, key in a new password, then press <Enter>.
4.
Confirm the password when prompted.
Secure Boot Menu
This item allows you to customize the Secure Boot settings.
Secure Boot [Disabled]
This item allows you to enable or disable the Secure Boot flow control.
Configuration options: [Disabled] [Enabled]
Secure Boot Mode [Custom]
This item allows you to select the mode of the Secure boot to change Execution policy and
Secure Boot Key management.
Configuration options: [Standard] [Custom]
4-38
Chapter 4: BIOS Setup
Key Management
This item only appears when you set the Secure Boot Mode to [Custom]. This allows you to
modify Secure Boot variables and set Key Management page.
Provision Factory Default Keys [Disabled]
Configuration options: [Disabled] [Enabled]
Enroll All Factory Default Keys
This item will ask you if you want to Install Factory Default secure variables. Select Yes
if you want to load the default secure variables, otherwise select No.
Platform Key (PK)
Configuration options: [Set New Key] [Delete]
Key Exchange Keys / Authorized Signatures / Forbidden Signatures / Authorized
TimeStamps
Configuration options: [Set New Key] [Delete] [Append]
4.6
Boot Menu
The Boot menu items allow you to change the system boot options.
Bootup NumLock State [On]
Allows you to select the power-on state for the NumLock.
Configuration options: [On] [Off]
ASUS P10S-I
4-39
Boot Logo Display [Disabled]
Allows you to enable or disable the full screen logo display feature.
[Auto]
Auto adjustment for Windows requirements.
[Full Screen]
Maximize the boot logo size.
[Disabled]
Hide the logo during POST.
POST Report [5 sec]
Allows you to set the desired POST Report waiting time from 1 to 10 seconds.
Configuration options: [1 sec] – [10 sec] [Until Press ESC]
Chassis Intrusion Message [Warning]
Allows you to set an action when chassis intrusion has occured.
[Warning]
Warning beep and pause at intrusion message for 3 seconds.
[Halt]
Halt at intrusion message.
Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
•
To select the boot device during system startup, press <F8> when ASUS Logo
appears.
•
To access Windows OS in Safe Mode, please press <F8> after POST.
Set the booting order of network devices.
Boot Option #1 [IBA GE Slot 0300 v1556]
Configuration options: [IBA GE Slot 0300 v1556] [Disabled]
Network Device BBS Priorities
These items appear only when you connect SATA ODD or hard drive to the SATA ports and
allow you to set the booting order of the SATA devices.
4-40
Chapter 4: BIOS Setup
4.7
Monitor Menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
Fan Speed Control [Generic Mode]
Allows you to set the fan speed.
Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode]
4.8
Tool menu
The Tool menu items allow you to configure options for special functions. Select an item then
press <Enter> to display the submenu.
ASUS EZ Flash
Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>. Refer to 4.1.2
ASUS EZ Flash Utility for details.
ASUS P10S-I
4-41
4.9
Save & Exit menu
The Exit menu items allow you to save or discard your changes to the BIOS items.
Pressing <Esc> does not immediately exit this menu. Select one of the options from this
menu or <F10> from the legend bar to exit.
Discard Changes and Exit
Exit System setup without saving any changes.
Save Changes and Reset
Reset the system setup after saving the changes.
Restore Defaults
Restore/load default values for all the setup options.
Boot Override
These items display the available devices. The device items that appear on the screen
depends on the number of devices installed in the system. Click an item to start booting from
the selected device.
Launch EFI Shell from filesystem device
Attempts to launch EFI Shell application (Shell.efi) from one of the available filesystem
devices.
4-42
Chapter 4: BIOS Setup
4.10
Server Mgmt menu
The Server Management menu displays the server management status and allows you to
change the settings.
OS Watchdog Timer [Disabled]
This item allows you to start a BIOS timer which can only be shut off by Management
Software after the OS loads.
Configuration options: [Enabled] [Disabled]
The following items is configurable only when the OS Watchdog Timer is set to [Enabled].
OS Wtd Timer Timeout [10 minutes]
Allows you to configure the length for the OS Boot Watchdog Timer.
Configuration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes]
OS Wtd Timer Policy [Reset]
This item allows you to configure how the system should respond if the OS Boot Watchdog
Timer expires.
Configuration options: [Do Nothing] [Reset] [Power Down] [Power Cycle]
System Event Log
Allows you to change the System Event Log configuration.
ASUS P10S-I
4-43
SEL Components [Enabled]
Allows you to enable or disable all features of System Event Logging during boot.
Configuration options: [Disabled] [Enabled]
•
The following items appears only when you set SEL Components to [Enabled].
•
All values changed here do not take effect until computer is restarted.
Erase SEL [No]
Allows you to choose options for erasing SEL.
Configuration options: [No] [Yes, On next reset] [Yes, On every reset]
When SEL is Full [Do Nothing]
Allows you to choose options for reactions to a full SEL.
Configuration options: [Do Nothing] [Erase Immediately]
Log EFI Status Codes [Error code]
Disable the logging of EFI Status Codes, or log only error code, or only progress code, or
both.
Configuration options: [Disabled] [Both] [Error code] [Progress code]
BMC network configuration
The sub-items in this configuration allow you to configure the BMC network parameters.
DM_LAN1/Shared LAN
Config Address source [Previous State]
This item allows you to configure LAN channel parameters statistically or dynamically
(by BIOS or BMC). Previous State option will not modify any BMC network parameters
during BIOS phase.
Configuration options: [Previous State] [Static] [DynamicBmcDhcp]
4-44
Chapter 4: BIOS Setup
View System Event Log
This item allows you to view the System Event Log Records.
IPv6 BMC Network Configuration
This item allows you to configure the parameter settings of IPv6 BMC network.
IPv6 Display Full Field [Enable]
Displays the Full or Brief IPv6 Field.
Configuration options: [Disable] [Enable]
IPv6 Display Full Formula [Enable]
Displays the Full or Brief IPv6 Formula.
Configuration options: [Disable] [Enable]
IPv6 Display Letter Case [Upper Case]
Displays the uppercase or lowercase letters of the alphabet.
Configuration options: [Lower Case] [Upper Case]
IPv6 BMC DM_LAN1/Shared LAN
IPv6 BMC LAN IP Address source [Previous State]
Select to configure LAN channel parameters statically or dynamically (by BIOS or
BMC).
Configuration options: [Previous State] [Static] [Dynamic-Obtained by BMC running
DHCP]
ASUS P10S-I
4-45
4.11
Event Logs menu
The Event Logs menu items allow you to change the event log settings and view the system
event logs.
Change Smbios Event Log Settings
Press <Enter> to change the Smbios Event Log configuration.
All values changed here do not take effect until computer is restarted.
Enabling/Disabling Options
Smbios Event Log [Enabled]
Change this to enable or disable all features of Smbios Event Logging during boot.
Configuration options: [Disabled] [Enabled]
Erasing Settings
Erase Event Log [No]
Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation
during reset.
Configuration options: [No] [Yes, Next reset] [Yes, Every reset]
4-46
Chapter 4: BIOS Setup
When Log is Full [Do Nothing]
Allows you to choose options for reactions to a full Smbios Event Log.
Configuration options: [Do Nothing] [Erase Immediately]
Smbios Event Log Standard Settings
Log System Boot Event [Disabled]
Allows you to enable or disable logging of System Boot Event.
Configuration options: [Enabled] [Disabled]
MECI [1]
Also known as Multiple Event Count Increment, and allows you to set the value for the
number of occurrences of a duplicate event that must pass before the multiple-event counter
of log entry is updated. Use the <+> and <-> keys to adjust the value.
Configuration options: [1] - [255]
METW [60]
Also known as Multiple Time Event Window, and allows you to set the value for the number of
minutes which must pass between duplicate log entries which utilize a multiple-event counter.
Use the <+> and <-> keys to adjust the value.
Configuration options: [0] - [99]
Custom Options
Log OEM Codes [Enabled]
Allows you to enable or disable the logging of EFI Status Codes as OEM codes (if not already
converted to legacy).
Configuration options: [Disabled] [Enabled]
Convert OEM Codes [Disabled]
Allows you to enable or disable the converting of EFI Status Codes to Standard Smbios
Types (not all may be translated).
Configuration options: [Disabled] [Enabled]
View Smbios Event Log
Press <Enter> to view the Smbios Event Log.
ASUS P10S-I
4-47
4-48
Chapter 4: BIOS Setup
Chapter 5:
RAID Configuration
5.1
Setting up RAID
The motherboard comes with the Intel® C232 controller that supports Intel® Rapid Storage
Technology enterprise Option ROM Utility with RAID 0, RAID 1, RAID 10, and RAID 5
support (for both Windows® OS and Linux).
5.1.1
RAID definitions
RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in
parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a
sustained data transfer rate, double that of a single disk alone, thus improving data access
and storage. Use of two new identical hard disk drives is required for this setup.
RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to a
second drive. If one drive fails, the disk array management software directs all applications
to the surviving drive as it contains a complete copy of the data in the other drive. This RAID
configuration provides data protection and increases fault tolerance to the entire system. Use
two new drives or use an existing drive and a new drive for this setup. The new drive must be
of the same size or larger than the existing drive.
RAID 10 is data striping and data mirroring combined without parity (redundancy data) having
to be calculated and written. With the RAID 10 configuration you get all the benefits of both
RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive
and three new drives for this setup.
RAID 5 stripes both data and parity information across three or more hard disk drives. Among
the advantages of RAID 5 configuration include better HDD performance, fault tolerance, and
higher storage capacity. The RAID 5 configuration is best suited for transaction processing,
relational database applications, enterprise resource planning, and other business systems.
Use a minimum of three identical hard disk drives for this setup.
If you want to boot the system from a hard disk drive included in a created RAID set, copy
first the RAID driver from the support DVD to a floppy disk before you install an operating
system to the selected hard disk drive.
5-2
Chapter 5: RAID Configuration
5.1.2
Installing hard disk drives
The motherboard supports Serial ATA for RAID set configuration. For optimal performance,
install identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for RAID configuration:
1.
Install the SATA hard disks into the drive bays following the instructions in the system
user guide.
2.
Connect a SATA signal cable to the signal connector at the back of each drive and to
the SATA connector on the motherboard.
3.
Connect a SATA power cable to the power connector on each drive.
5.1.3
Setting the RAID mode in BIOS
You must set the RAID mode in the BIOS Setup to be able to launch the RAID utilities before
you can create a RAID set from the SATA hard disk drives attached to the SATA connectors
supported by Intel® C232 chipset.
To do this:
1.
Enter the BIOS Setup during POST.
2.
Go to the Advanced Menu > SATA Configuration, then press <Enter>.
3.Set SATA Mode to [RAID].
4.
Press <F10> to save your changes and exit the BIOS Setup.
Refer to Chapter 4 for details on entering and navigating through the BIOS Setup.
5.1.4
RAID configuration utilities
Depending on the RAID connectors that you use, you can create a RAID set using the utilities
embedded in each RAID controller. For example, use the Intel® Rapid Storage Technology
enterprise SATA Option ROM Utility if you installed Serial ATA hard disk drives on the
Serial ATA connectors supported by the Intel® C232 chipset.
ASUS P10S-I
5-3
5.2Intel® Rapid Storage Technology enterprise SATA
Option ROM Utility
The Intel® Rapid Storage Technology enterprise SATA Option ROM utility allows you to create
RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set from Serial ATA hard disk drives that
are connected to the Serial ATA connectors supported by the Southbridge.
Before you proceed, ensure that you have installed the Serial ATA hard disk drives,
and have set the correct SATA mode in the BIOS setup. You can refer to sections
5.1.2 Installing hard disk drives and 5.1.3 Setting the RAID mode in BIOS for more
information.
To launch the Intel® Rapid Storage Technology enterprise SATA Option ROM utility:
1.
Turn on the system.
2.
During POST, press <Ctrl>+<I> to display the utility main menu.
Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 4.5.0.1012
Copyright(C) 2003-15 Intel Corporation. All Rights Reserved.
1. Create RAID Volume
2. Delete RAID Volume
RAID Volumes:
None defined.
Physical Disks:
ID Drive Model
0
ST3300656SS
1
ST3300656SS
2
ST3300656SS
3
ST3300656SS
[
]-Select
[ MAIN MENU ]
3. Reset Disks to Non-RAID
4. Mark Disks as Spare
5. Exit
[ DISK/VOLUME INFORMATION]
Serial #
HWAS0000991753TR
37VN00009846RAJ1
397600009846UEDY
GWC50000991756G6
[ESC]-Exit
Size
279.3GB
279.3GB
279.3GB
279.3GB
Type/Status(Vol ID)
Non-RAID Disk
Non-RAID Disk
Non-RAID Disk
Non-RAID Disk
[ENTER]-Select Menu
The navigation keys at the bottom of the screen allow you to move through the menus
and select the menu options.
The RAID BIOS setup screens shown in this section are for reference only and may not
exactly match the items on your screen.
5-4
Chapter 5: RAID Configuration
5.2.1
Creating a RAID set
To create a RAID set:
1.
From the utility main menu, select 1. Create RAID Volume and press <Enter>.
2.
Key in a name for the RAID set and press <Enter>.
Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 4.5.0.1012
Copyright(C) 2003-15 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
Name: Volume0
RAID Level: RAID0(Strips)
Disks: Select Disks
Strip Size: 128KB
Capacity: 0.0 GB
Syne: N/A
Create Volume
[ HELP ]
Enter a unique volume name that has no special characters and is
16 characters or less.
[
]Change
[TAB]-Next
[ESC]-Previous Menu
[ENTER]-Select
3.
Press the up/down arrow keys to select a RAID Level that you wish to create then
press <Enter>.
4.
From the Disks item field, press <Enter> to select the hard disk drives that you want to
include in the RAID set.
[ SELECT DISKS ]
Port
0
1
2
3
Drive Model
ST3300656SS
ST3300656SS
ST3300656SS
ST3300656SS
Serial #
HWAS0000991753TR
37VN00009846RAJ1
397600009846UEDY
GWC50000991756G6
Size
279.3GB
279.3GB
279.3GB
279.3GB
Status
Non-RAID
Non-RAID
Non-RAID
Non-RAID
Disk
Disk
Disk
Disk
Select 2 disks to create volume.
[
5.
]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done
Use the up/down arrow keys to move the selection bar then press <Space> to select a
disk. A small triangle before the Port number marks the selected drive. Press <Enter>
when you are done.
ASUS P10S-I
5-5
6.
Use the up/down arrow keys to select the stripe size for the RAID array (for RAID 0,
10 and 5 only) then press <Enter>. The available stripe size values range from 4 KB to
128 KB. The following are typical values:
RAID 0:
128KB
RAID 10:
64KB
RAID 5:
64KB
We recommend a lower stripe size for server systems, and a higher stripe size for
multimedia computer systems used mainly for audio and video editing.
7.
In the Capacity field item, key in the RAID volume capacity that you want to use and
press <Enter>. The default value field indicates the maximum allowed capacity.
8.
Press <Enter> to start creating the RAID volume.
9. From the following warning message, press <Y> to create the RAID volume and return
to the main menu, or press <N> to go back to the CREATE VOLUME menu.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
5-6
Chapter 5: RAID Configuration
5.2.2
Deleting a RAID set
Take caution when deleting a RAID set. You will lose all data on the hard disk drives when
you delete a RAID set.
To delete a RAID set:
1.
From the utility main menu, select 2. Delete RAID Volume and press <Enter>.
2.
From the Delete Volume Menu, press the up/down arrow keys to select the RAID set
you want to delete then press <Del>.
Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 4.5.0.1012
Copyright(C) 2003-15 Intel Corporation. All Rights Reserved.
[ DELETE VOLUME MENU ]
Name
Volume0
Level
RAID0(Stripe)
Drives
2
Capacity
298.0GB
Status
Normal
Bootable
Yes
[ HELP ]
Deleting a volume will reset the disks to non-RAID
WARNING: ALL DISK DATA WILL BE DELETED.
(This does not apply to Recovery volumes)
[
3.
]-Select
[ESC]-Previous Menu
[DEL]-Delete Volume
Press <Y> to confirm deletion of the selected RAID set and return to the utility main
menu, or press <N> to return to the DELETE VOLUME menu.
[ DELETE VOLUME VERIFICATION ]
ALL DATA IN THE VOLUME WILL BE LOST!
(This does not apply to Recovery volumes)
Are you sure you want to delete volume “Volume0”? (Y/N):
ASUS P10S-I
5-7
5.2.3
Resetting disks to Non-RAID
Take caution before you reset a RAID volume hard disk drive to non-RAID. Resetting a
RAID volume hard disk drive deletes all internal RAID structure on the drive.
To reset a RAID set:
1.
From the utility main menu, select 3. Reset Disks to Non-RAID and press <Enter>.
2.
Press the up/down arrow keys to select the drive(s) or disks of the RAID set you want
to reset, then press <Space>. A small triangle before the Port number marks the
selected drive. Press <Enter> when you are done.
[ RESET RAID DATA ]
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
(This does not apply to Recovery volumes)
Port
0
1
Drive Model
ST3300656SS
ST3300656SS
Serial #
HWAS0000991753TR
37VN00009846RAJ1
Size
279.3GB
279.3GB
Status
Member Disk
Member Disk
Select the disks that should be reset.
[
3.
5-8
]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
Press <Y> in the confirmation window to reset the drive(s) or press <N> to return to the
utility main menu.
Chapter 5: RAID Configuration
5.2.4
Exiting the Intel® Rapid Storage Technology
enterprise SATA Option ROM utility
To exit the utility:
1.
From the utility main menu, select 4. Exit then press <Enter>.
2.
Press <Y> to exit or press <N> to return to the utility main menu.
[ CONFIRM EXIT ]
Are you sure you want to exit? (Y/N):
5.2.5
Rebuilding the RAID
This option is only for the RAID 1 set.
Rebuilding the RAID with other non-RAID disk
If any of the SATA hard disk drives included in the RAID 1 array failed, the system displays
the status of the RAID volume as “Degraded” during POST. You can rebuild the RAID array
with other installed non-RAID disks.
To rebuild the RAID with other non-RAID disk:
1.
During POST, press <Ctrl>+<I> at the prompt to enter the Intel Rapid Storage
Technology option ROM utility.
2.
If there is a non-RAID SATA Hard Disk available, the utility will prompt you to rebuild
the RAID. Press the up/down arrow keys to select the destination disk then Press
<Enter> to start the rebuilding process, or press <ESC> to exit.
[ DEGRADED VOLUME DETECTED ]
“Degraded” volume and disk available for rebuilding detected. Selecting
a disk initiates a rebuild. Rebuild completes in the operating system.
Select the port of destination disk for rebuilding (ESC to exit):
Port Drive Model
Serial #
Size
X
XXXXXXXXXXX
XXXXXXXX
XXX.GB
[
]-Previous/Next [ENTER]-Select [ESC]-Exit
Select a destination disk with the same size as the original hard disk.
ASUS P10S-I
5-9
3.
The utility immediately starts rebuilding after the disk is selected. When done, the
status of the degraded RAID volume is changed to “Rebuild”.
Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 4.5.0.1012
Copyright(C) 2003-15 Intel Corporation. All Rights Reserved.
1. Create RAID Volume
2. Delete RAID Volume
RAID Volumes:
ID
Name
1
Volume0
[ MAIN MENU ]
3. Reset Disks to Non-RAID
4. Mark Disks as Spare
5. Exit
[ DISK/VOLUME INFORMATION]
Level1
RAID1(Mirror)
Physical Devices:
Port Drive Model
1
ST3160812AS
2
ST3160812AS
Strip
N/A
Serial #
9LS0F4HL
3LS0JYL8
Size
149.0GB
Size
149.0GB
149.0GB
*=Data is Encrypted
Status
Bootable
Rebuild
Yes
Type/Status(Vol ID)
Member Disk(0)
Member Disk(0)
Volumes with “Rebuild” status will be rebuilt within the operating system.
[
4.
]-Select
[ESC]-Exit
[ENTER]-Select Menu
Press <Esc> to exit Intel Rapid Storage Technology and reboot the system.
5.Select Start > Programs > Intel Rapid Storage > Intel Rapid Storage Console or
click the Intel Rapid Storage Technology tray icon to load the Intel Rapid Storage
Manager utility.
6.
From the View menu, select Advanced Mode to display the details of the Intel Rapid
Storage Console.
7.
From the Volumes view option, select RAID volume to view the rebuilding status.
When finished, the status is changed to “Normal”.
Rebuilding the RAID with a new hard disk
If any of the SATA hard disk drives included in the RAID array failed, the system displays the
status of the RAID volume as “Degraded” during POST. You may replace the disk drive and
rebuild the RAID array.
To rebuild the RAID with a new hard disk:
1.
Remove the failed SATA hard disk and install a new SATA hard disk of the same
specification into the same SATA Port.
Select a destination disk with the same size as the original hard disk.
2.
5-10
Reboot the system then follow the steps in section Rebuilding the RAID with other
non-RAID disk.
Chapter 5: RAID Configuration
5.2.6
Setting the Boot array in the BIOS Setup Utility
You can set the boot priority sequence in the BIOS for your RAID arrays when creating multiRAID using the Intel® Rapid Storage Technology enterprise SATA Option ROM utility.
To set the boot array in the BIOS:
Set at least one of the arrays bootable to boot from the hard disk.
1.
Reboot the system and press <Del> to enter the BIOS setup utility during POST.
2.
Go to the Boot menu and select the boot option priority.
3.
Use up/down arrow keys to select the boot priority and press <Enter>. See the Boot
menu section of Chapter 4 for more details.
4.
From the Exit menu, select Save Changes & Exit, then press <Enter>.
5.
When the confirmation window appears, select Yes, then press <Enter>.
ASUS P10S-I
5-11
5.3Intel® Rapid Storage Technology enterprise
(Windows)
The Intel® Rapid Storage Technology enterprise allows you to create RAID 0, RAID 1, RAID
10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives that are connected to the
Serial ATA connectors supported by the Southbridge.
You need to manually install the Intel® Rapid Storage Technology enterprise utility on a
Windows® operating system. Please refer to the installation instructions in Chapter 6.
To enter the Intel® Rapid Storage Technology enterprise utility under Windows operating
system:
1.
Turn on the system to windows desktop.
2.
Click the Intel® Rapid Storage Technology enterprise icon to display the main menu.
Your storage system is configured for data protection, increased performance and optimal
data storage capacity. You can create additional volumes to further optimize your storage
system.
You can click Rescan to re-scan any attached hard disks.
5-12
Chapter 5: RAID Configuration
5.3.1
Creating a RAID set
To create a RAID set:
1.
From the utility main menu, select Create Volume then select volume type and click
Next.
2.
Key in a name for the RAID set, then select the array disks.
3.
Select the Volume Size tab then drag the bar to set the volume size.
4.Click Next.
•
If you do not want to keep the data on one of the selected disks, select NO when
prompted.
•
If you want to Enable volume write-back cache or Initialize volume, click
Advanced.
ASUS P10S-I
5-13
5.
Confirm the volume creation, then click Create Volume to continue.
This process could take a while depending on the number and size of the disks. You can
continue using other applications during this time.
6. Wait until the process is completed, then click OK when prompted.
You still need to partition your new volume using Windows Disk Management before
adding any data.
The created RAID set is displayed in the Volumes list. If you wish to change the settings, go
to Volume Properties.
5-14
Chapter 5: RAID Configuration
5.3.2
Changing a Volume Type
To change the volume type in Volume Properties:
1.
Click the SATA array items you want to change in Volumes field.
2.
From the Volume Properties field, select Type: RAID 1 Change type.
3.
You can also change the Name, Select the new volume type, and Select additional
disks to include in the new volume if needed.
4.
Select the Data stripe size for the RAID array (for RAID 0, 10 and 5 only) and click
OK. The available stripe size values range from 4 KB to 128 KB. The following are
typical values:
RAID 0:
128KB
RAID 10:
64KB
RAID 5:
64KB
We recommend a lower stripe size for server systems, and a higher stripe size for
multimedia computer systems used mainly for audio and video editing.
ASUS P10S-I
5-15
5.3.3
Deleting a volume
Be cautious when deleting a volume. You will lose all data on the hard disk drives. Before
you proceed, ensure that you back up all your important data from your hard drives.
To delete a volume:
1.
From the Volumes field in the utility main menu, select the volume that you want to
delete.
2.
From the Volume Properties field, select Delete volume.
3.Click Yes to delete the volume and return to the utility main menu, or click No to return
to the main menu.
5-16
Chapter 5: RAID Configuration
5.3.4Preferences
System Preferences
Allow you to set to show the notification area icon and show system information, warning, or
errors here.
E-mail Preferences
Allow you to set to sent e-mail of the following events:
•
Storage system information
•
Storage system warnings
•
Storage system errors
ASUS P10S-I
5-17
5-18
Chapter 5: RAID Configuration
Chapter 6:
Driver Installation
6.1
RAID driver installation
After creating the RAID sets for your server system, you are now ready to install an
operating system to the independent hard disk drive or bootable array. This part provides the
instructions on how to install the RAID controller drivers during OS installation.
6.1.1
Creating a USB flash drive with RAID driver
When installing Windows® Server OS, you can load the RAID driver from a USB flash drive.
You can create a USB flash drive with RAID driver in Windows by copying the files from the
support DVD to the USB flash drive.
To copy the RAID driver to a USB flash drive in Windows environment:
1.
Place the motherboard support DVD in the optical drive.
2.
Connect a USB flash drive to your system.
3.
Launch Windows Explorer.
4. Click on the optical drive to browse the contents of the support DVD.
5.Click Drivers > C23x INTEL RAID > Driver > Windows and then copy the SATA_RAID
driver folder to the USB flash drive.
6.1.2
Installing the RAID controller driver
During Windows® Server 2008 OS installation
To install the RAID controller driver when installing Windows® Server 2008 OS
6-2
1.
Boot the computer using the Windows® Server 2008 OS installation disc. Follow the
screen instructions to start installing Windows Server 2008.
2.
When prompted to choose a type of installation, click Custom (advanced).
Chapter 6: Driver Installation
3.Click Load Driver.
4.
A message appears reminding you to insert the installation media containing the driver of
the RAID controller driver (the installation media can be a CD, DVD, or USB flash drive).
•
If you have only one optical drive installed in your system, eject the Windows OS
installation disc and replace with the motherboard Support DVD into the optical
drive.
•
Or you may connect a USB flash drive containing the RAID controller driver.
Click Browse to continue.
5.
Locate the driver in the corresponding folder of the Support DVD or USB flash drive
and then click OK to continue.
6.
Select the RAID controller driver you need from the list and click Next.
ASUS P10S-I
6-3
7.
When the system finishes loading the RAID driver,
•
Replace the motherboard Support DVD with the Windows Server installation disc.
•
Remove the USB flash drive.
Select the drive to install Windows and click Next.
8.
6-4
Follow succeeding screen instructions to continue.
Chapter 6: Driver Installation
6.2Management applications and utilities installation
The support DVD that is bundled with your motherboard contains drivers, management
applications, and utilities that you can install to maximize the features of your motherboard.
•
The contents of the support DVD are subject to change at any time without notice. Visit
the ASUS website (www.asus.com) for the latest updates on software and utilities.
•
The support DVD is supported on Windows® Server 2008 R2 and Windows® Server 2012.
6.3
Running the Support DVD
When you place the support DVD into the optical drive, the DVD automatically displays the
main screen if Autorun is enabled in your computer. By default, the Drivers tab is displayed.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the support DVD.
The main screen of the Support DVD contains the following tabs:
1.Drivers
2.Utilities
3.Manual
4.Contact
The main screen of the Support DVD looks exactly the same on the Windows® Server 2008
R2 and on the Windows® Server 2012 Operating System (OS).
ASUS P10S-I
6-5
6.3.1
Drivers menu tab
The Drivers Menu shows the available device drivers if the system detects installed devices.
Install the necessary drivers to activate the devices.
6.3.2
Utilities menu tab
The Utilities menu displays the software applications and utilities that the motherboard
supports.
6-6
Chapter 6: Driver Installation
6.3.3
Manual menu
The Manual menu provides the link to the P10S-I user guide.
You need an internet browser installed in your OS to view the User Guide.
6.3.4
Contact information menu
The Contact menu displays the ASUS contact information, e-mail addresses, and useful links
if you need more information or technical support for your motherboard.
ASUS P10S-I
6-7
6.3.5
Installing the Intel® Chipset device Software driver
This section provides the instructions on how to install the Intel® chipset device software on
the system.
You need to manually install the Intel® chipset device software on a Windows® Operating System.
To install the Intel® chipset device software:
1.
Restart the computer.
2. Log in with Administrator privileges.
3.
Insert the Motherboard Support DVD to the optical drive.
The support DVD automatically displays the Drivers menu if Autorun is enabled in your
computer.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the support DVD.
4.Click Intel® Chipset Device Software from the Drivers menu to start the installation.
5.The Intel(R) Chipset Device Software window appears. Click Next to start
installation.
6-8
Chapter 6: Driver Installation
6.Select Yes to accept the terms of the License Agreement and continue the process.
7.
Read the Readme File Information and press Install to continue the installation.
8.Toggle Yes, I want to restart the computer now and click Finish to complete the
setup process.
ASUS P10S-I
6-9
6.4
Installing the Intel® I210 Gigabit Adapters driver
This section provides the instructions on how to install the Intel® I210 Gigabits Adapter
Driver on the system.
To install the Intel® I210 Gigabit Adapters Driver on the Windows® operating system:
1.
Restart the computer.
2. Log on with Administrator privileges.
3.
Insert the motherboard/system support DVD to the optical drive.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the support DVD.
4.Click Intel® I210 Gigabit Adapters Drivers in the Drivers menu of the main screen to
start the installation.
5.Click Install Drivers and Software option to begin installation.
6-10
Chapter 6: Driver Installation
6.Click Next when the Intel(R) Network Connections–InstallShield Wizard window
appears.
7.Tick I accept the terms in the license agreement and click Next to continue.
8.
From the Setup Options window, click Next to start the installation.
By default, Intel(R) PROSet for Windows Device Manager and Windows PowerShell
Module are ticked.
ASUS P10S-I
6-11
9.Click Install to start the installation.
10. When the installation is done, press Finish to complete the installation.
6-12
Chapter 6: Driver Installation
6.5
Installing the VGA driver
This section provides the instructions on how to install the ASPEED Video Graphics Adapter
(VGA) driver.
To install the ASPEED VGA driver:
1.
Restart the computer.
2. Log in with Administrator privileges.
3.
Insert the Motherboard Support DVD to the optical drive.
The support DVD automatically displays the Drivers menu if Autorun is enabled in your
computer.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the support DVD.
4.
From the Main Menu, click ASPEED AST1400/AST2400 Display Driver on the
Drivers tab to start the installation.
5.
From the installation window, click Next to start the installation.
ASUS P10S-I
6-13
6.Click Install to proceed with the installation.
7.Click Finish to complete the installation.
6-14
Chapter 6: Driver Installation
Appendix
P10S-I block diagram
A-2
Appendix
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone Fax Web site
4F, No. 150, Li-Te Rd., Peitou, Taipei 112, Taiwan
+886-2-2894-3447
+886-2-2890-7798
http://www.asus.com
Technical Support
Telephone +86-21-38429911
Fax +86-21-58668722 ext: 9101
Online Support
http://support.asus.com/techserv/techserv.aspx
ASUSTeK COMPUTER INC. (Taiwan)
Address
Telephone Fax Web site
4F, No. 150, Li-Te Rd., Peitou, Taipei 112, Taiwan
+886-2-2894-3447
+886-2-2890-7798
http://www.asus.com.tw
Technical Support
Telephone Online Support
+886-2-2894-3447 (0800-093-456)
http://support.asus.com/techserv/techserv.aspx
ASUSTeK COMPUTER INC. (China)
Address
Telephone Fax Web site
No. 5077 Jindu Road, Minhang District, Shanghai, China
+86-21-5442-1616
+86-21-5442-0099
http://www.asus.com.cn
Technical Support
Telephone Online Support
ASUS P10S-I
+86-20-2804-7506 (400-620-6655)
http://support.asus.com/techserv/techserv.aspx
A-3
ASUS contact information
ASUS COMPUTER INTERNATIONAL (America)
Address
Fax
Web site
800 Corporate Way, Fremont, CA 94539, USA
+1-510-608-4555
http://usa.asus.com
Technical Support
Support fax
General support
Online support
+1-812-284-0883
+1-812-282-2787
http://support.asus.com/techserv/techserv.aspx
ASUS COMPUTER GmbH (Germany and Austria)
Address
Fax
Web site
Online contact
Harkort Str. 21-23, D-40880 Ratingen, Germany
+49-2102-959911
http://www.asus.de
http://www.asus.de/sales
Technical Support
Telephone+49-1805-010923
Support Fax
+49-2102-959911
Online support
http://support.asus.com/techserv/techserv.aspx
ASUS Czech Service s.r.o. (Europe)
AddressNa Rovince 887, 720 00 Ostrava – Hrabová, Czech
Republic
Telephone+420-596766888
Web site
http://www.asus.cz
Technical Support
Telephone+420-596-766-891
Fax
+420-596-766-329
[email protected]
Online Support
http://support.asus.com/techserv/techserv.aspx
A-4
Appendix
ASUS contact information
ASUS Holland BV (The Netherlands)
Address Web site
Marconistraat 2, 7825GD EMMEN, The Netherlands
http://www.asus.com
Technical Support
Telephone Fax E-mail Online Support +31-(0)591-5-70292
+31-(0)591-666853
[email protected]
http://support.asus.com/techserv/techserv.aspx
ASUS Polska Sp. z o.o. (Poland)
Address Web site Ul. Postępu 6, 02-676 Warszawa, Poland
http://pl.asus.com
Technical Support
Telephone Online Support +48-225718033
http://support.asus.com/techserv/techserv.aspx
ASK-Service (Russia and CIS)
Address Telephone Web site г.Москва, ул. Орджоникидзе, д.10, Россия
(495) 640-32-75
http://ru.asus.com
Technical Support
Telephone Online Support ASUS P10S-I
008-800-100-ASUS (008-800-100-2787)
http://vip.asus.com/eservice/techserv.aspx?SLanguage=ru
A-5
A-6
Appendix
(510)739-3777/(510)608-4555
800 Corporate Way, Fremont, CA 94539.
Asus Computer International
Date :
Signature :
Representative Person’s Name :
Oct. 08, 2015
Steve Chang / President
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Supplementary Information:
FCC Part 15, Subpart B, Unintentional Radiators
Conforms to the following specifications:
Model Number : P10S-I
Product Name : Motherboard
hereby declares that the product
Phone/Fax No:
Address:
Responsible Party Name:
Per FCC Part 2 Section 2. 1077(a)
DECLARATION OF CONFORMITY
Ver. 140331
Manufacturer:
ASUS COMPUTER GmbH
HARKORT STR. 21-23, 40880 RATINGEN
GERMANY
Authorized representative in Europe:
Address, City:
Country:
Motherboard
P10S-I
Model name :
Regulation (EU) No. 617/2013
Year to begin affixing CE marking: 2015
Declaration Date: 08/10/2015
CE marking
Name :
Signature : __________
CEO
Jerry Shen
Position :
(EC conformity marking)
Regulation (EC) No. 278/2009
2011/65/EU-RoHS Directive
Regulation (EC) No. 642/2009
EN 60065:2002 / A12: 2011
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50566:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
Regulation (EC) No. 1275/2008
2009/125/EC-ErP Directive
EN 60950-1: 2006 / A2: 2013
EN 60950-1: 2006 / A12: 2011
2006/95/EC-LVD Directive
EN 300 328 V1.8.1(2012-06)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.7.1(2012-06)
EN 302 544-2 V1.1.1(2009-01)
EN 302 623 V1.1.1(2009-01)
EN 50360:2001
EN 62479:2010
EN 50385:2002
EN 62311:2008
1999/5/EC-R&TTE Directive
EN 55022:2010+AC:2011
EN 61000-3-2:2006+A2:2009
EN 55013:2001+A1:2003+A2:2006
2004/108/EC-EMC Directive
conform with the essential requirements of the following directives:
Product name :
declare the following apparatus:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Address:
ASUSTeK COMPUTER INC.
EC Declaration of Conformity
We, the undersigned,
Ver. 150326
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
