x Memory cards that you can use
Charging the battery pack
When using the camera for the first time, be sure to charge the NP-FW50
“InfoLITHIUM” battery pack (supplied).
The “InfoLITHIUM” battery pack can be charged even when it has not been
fully depleted. It can also be used when it has not been fully charged.
Interchangeable Lens Digital Camera
1
Usable memory card
Insert the battery pack onto the For the U.S.A and Canada
battery charger, and charge it.
“Memory Stick PRO Duo”
media
• The CHARGE lamp turns off when
charging is finished.
“Memory Stick PRO-HG
Duo” media
Estimated charging
time
Instruction Manual
You can use following types of memory cards with this camera. However,
proper operation cannot be guaranteed for all types of the memory cards.
250 minutes
Getting Started
CHARGE lamp
For countries/regions other
than the U.S.A. and Canada
Still
Movie
(Mark2)
SD memory card
(Class 4 or more)
SDHC memory card
(Class 4 or more)
SDXC memory card
(Class 4 or more)
Power cord (mains lead)
1
©2011 Sony Corporation
1
Turn the diopter-adjustment
dial.
Mount the lens by aligning the
white index marks on the lens
and the camera.
White index marks
1
x Removing the battery pack
Turn off the camera, make sure that the
access lamp is not lit, slide the lock lever
in the direction of the arrow, and pull out
the battery pack.
While pushing the lens lightly
toward the camera, turn the
lens clockwise until it clicks
into the locked position.
It is recommended that you attach the eyepiece cup when you intend to use the
viewfinder.
1
Align the top of the eyepiece
cup with the viewfinder, and
snap it onto the bottom of the
viewfinder.
Note
• Remove the eyepiece cup when you attach an accessory (sold separately) to the
accessory shoe.
Installing the software
To utilize images recorded with the camera, the following software is
provided:
• “Image Data Converter”
You can edit RAW images, etc.
• “PMB” (Picture Motion Browser) (Windows only)
You can import images to the computer, edit them, such as displaying them
on a calender.
Press the lens release button
all the way in and turn the lens
counterclockwise until it
stops.
Note
Lens release button
Lock lever
Access lamp
Inserting a memory card (sold separately)
1
Insert a memory card with the
direction as illustrated here.
• If “PMB” has already been installed on the computer, and the version number of
the previously installed “PMB” is lower than that of the “PMB” on the CD-ROM
(supplied), install “PMB” also from the CD-ROM (supplied).
Notes
• When changing the lens, if dust or debris gets inside the camera and adheres to the
surface of the image sensor (the part that acts as the film), it may appear as dark
spots on the image, depending on the shooting environment. The camera vibrates
slightly when it is turned off, due to the anti-dust function, to prevent dust from
adhering to the image sensor. However, attach or remove the lens quickly
somewhere away from dusty locations.
x Windows
OS (pre-installed)
Microsoft Windows XP* SP3/Windows Vista** SP2/
Windows 7 SP1
Setting up the date
“PMB”
CPU: Intel Pentium III 800 MHz or faster
(For playing/editing the HD movies: Intel Core Duo
1.66 GHz or faster, Intel Core 2 Duo 1.66 GHz or faster,
Intel Core 2 Duo 2.26 GHz or faster (HD FX/HD FH), Intel
Core 2 Duo 2.40 GHz or faster (HD PS))
Memory: 512 MB or more (For playing/editing the HD
movies: 1 GB or more)
Hard Disk: Disk space required for installation—
approximately 500 MB
Display: Screen resolution—1024 × 768 dots or more
The following computer environment is recommended when using the
supplied software and importing images via a USB connection.
When you turn on the camera for the first time, the screen to set date and time
appears.
Check on the direction of the
notched corner.
1
USB Connection: Mac OS X (v10.3 to v10.6)
“Image Data Converter Ver.4”: Mac OS X v10.5/
Mac OS X v10.6 (Snow Leopard)
“Image Data
Converter Ver.4”
CPU: Intel processors, such as Intel Core Solo/Core Duo/
Core 2 Duo
Memory: 1 GB or more is recommended.
Display: 1024 × 768 dots or more
1
Insert the CD-ROM (supplied) into the CD-ROM drive, and
double-click the CD-ROM icon.
2
Copy the [IDC_INST.pkg] file in the [MAC] folder to the
hard disk icon.
3
Double-click the [IDC_INST.pkg] file in the copy-to folder.
• Follow the instructions on the screen to complete the installation.
Remove large specks of dirt from the Cleaning Cloth before using it.
x Removing the lens
Close the cover.
OS (pre-installed)
The Cleaning Cloth
Lock lever
2
The following computer environment is recommended when using the
supplied software and importing images via a USB connection.
Precautions
• When attaching a lens, do not press the lens release button.
• Do not use force when attaching a lens.
• The Mount Adaptor (sold separately) is required to use an A-mount lens (sold
separately). For details, refer to the operating manual supplied with the Mount
Adaptor.
• Insert the memory card until it
clicks as illustrated.
Attaching the shoulder strap is
recommended not to drop the camera.
Adjusting the viewfinder (diopter
adjustment)
Attaching/removing the eyepiece cup
2
Insert the CD-ROM (supplied) into the CD-ROM drive, and
install the software following the instructions on the screen.
When you have set all items, press the center of the control
wheel.
Notes
Checking the supplied items
NEX-7K only
• E18 – 55 mm zoom lens (1)/Front lens cap (1)/Rear lens cap (1) (The caps
are attached to the lens.)
• Lens hood (1)
5
• To remove the eyepiece cup, push
on the sides and pull the eyepiece
cup off the viewfinder.
Printed in Thailand
The accessories supplied differ depending on the model. The number in
parentheses indicates the number of pieces.
• Camera (1)
• Battery charger BC-VW1 (1)
• Power cord (mains lead) (1) (not supplied in the U.S.A. and Canada)
• Rechargeable battery pack NP-FW50 (1)
• USB cable (1)
• Shoulder strap (1)
• Eyepiece cup (1)
• Body cap (1) (attached to the camera)
• Accessory shoe cap (1) (attached to the camera)
• Cleaning Cloth (1)
• CD-ROM (1)
– Application Software for α camera
– α Handbook
• Instruction Manual (Getting Started: This manual) (1)
• Instruction Manual (Operations) (1)
Press the left or right of the control wheel to select each
item, and press the top or bottom, or turn it to select the
numeric value.
Adjust the viewfinder so that you can see the screen displays clearly.
Open the cover, and insert the
battery pack.
• Insert the battery pack while
pressing the lock lever with the tip
of the battery.
4-299-175-12(1)
4
• Hold the camera’s face downward
to prevent the dust from entering
into the camera.
Inserting the charged battery pack
NEX-7
Select your area by pressing the right or left of the control
wheel and press the center.
• Midnight is indicated as 12:00 AM, and noon as 12:00 PM.
Set the power switch of the camera to OFF before you attach or remove the
lens.
1
Notes
• The charging time differs depending on the remaining capacity of the battery pack
or charging conditions. The above charging time is when charging a fully depleted
battery pack at a temperature of 25 °C (77 °F).
• We recommend charging the battery pack in an ambient temperature of between
10 °C and 30 °C (50 °F and 86 °F) to efficiently charge the battery pack.
• Connect the battery charger to the nearest wall outlet (wall socket).
• A charged battery discharges little by little even though you do not use your
camera.
Charge the battery before using the camera to avoid missing an opportunity to
shoot.
3
You cannot use MultiMediaCard.
Attaching/removing the lens
API (IMAPI) Ver. 2.0 or later is required to use the function for creating discs.
** Starter (Edition) is not supported.
x Macintosh
SD card
x Removing the memory card
* 64-bit editions and Starter (Edition) are not supported. Windows Image Mastering
1
“Memory Stick
PRO Duo” media
• When the access lamp is lit, do not remove the memory card or the battery pack, or
turn off the power. The data may be corrupted.
CHARGE lamp
Press the center of the control
wheel to confirm [OK].
Term in this
manual
Open the cover, make sure that the access lamp is not lit, and push the memory
card once.
E-mount
2
Set the power switch to ON to turn on the camera.
The screen to set date and time appears.
“Image Data
Converter Ver.4”
CPU/Memory: Pentium 4 or faster/1 GB or more
Display: 1024 × 768 dots or more
On the functions available with the camera
You may feel uncomfortable symptoms such as eyestrain, nausea, or a tired
feeling while watching 3D images recorded with the camera on 3D compatible
monitors. When you watch 3D images, we recommend that you take a break at
regular time intervals. Since the need for or frequency of break times varies
between individuals, please set your own standards. If you feel sick, stop
watching 3D images, and consult a doctor as needed. Also, refer to the
operating instructions of the connected device or the software used with the
camera. A child's vision is always vulnerable (especially for children under six
years of age). Before allowing them to watch 3D images, please consult with
an expert, such as a pediatric or ophthalmic doctor. Make sure your children
follow the precautions above.
On the LCD monitor and lens
• The LCD monitor is manufactured using extremely high-precision
technology so over 99.99 % of the pixels are operational for effective use.
However, there may be some tiny black points and/or bright points (white,
red, blue or green in color) that constantly appear on the LCD monitor. These
points are normal in the manufacturing process and do not affect the images
in any way.
• A magnet is attached to the back of the LCD monitor. Do not put objects that
are affected by magnetic fields, such as a floppy disk or a credit card,
between the LCD monitor and the camera body.
Magnet
• Images may trail across on the LCD monitor in a cold location. This is not a
malfunction. When turning on the camera in a cold location, the LCD
monitor may become temporarily dark.
• Do not expose the camera to direct sunlight. If sunlight is focused on a
nearby object, it may cause a fire. When you must place the camera under
direct sunlight, attach the front lens cap.
On using the lenses and accessories
It is recommended that you use Sony lenses/accessories designed to suit the
characteristics of this camera. Using the products of other manufacturers may
cause the camera not to operate to its capability, or result in accidents and
malfunctions of the camera.
Do not use/store the camera in the following places
• In an extremely hot, dry or humid place
In places such as in a car parked in the sun, the camera body may become
deformed and this may cause a malfunction.
• Storing under direct sunlight or near a heater
The camera body may become discolored or deformed, and this may cause a
malfunction.
• In a location subject to rocking vibration
• Near strong magnetic place
• In sandy or dusty places
Be careful not to let sand or dust get into the camera. This may cause the
camera to malfunction, and in some cases this malfunction cannot be
repaired.
On the temperature of the camera
Your camera and battery may get hot due to continuous use, but it is not a
malfunction.
On moisture condensation
If the camera is brought directly from a cold to a warm location, moisture may
condense inside or outside the camera. This moisture condensation may cause
a malfunction of the camera.
How to prevent moisture condensation
When bringing the camera from a cold place to a warm place, seal the camera
in a plastic bag and allow it to adapt to conditions at the new location over
about an hour.
If moisture condensation occurs
Turn off the camera and wait about an hour for the moisture to evaporate. Note
that if you attempt to shoot with moisture remaining inside the lens, you will
be unable to record clear images.
On the internal rechargeable battery
This camera has an internal rechargeable battery for maintaining the date and
time and other settings regardless of whether the power is on or off, or the
battery is installed or not. This rechargeable battery is continually charged as
long as you are using the camera. However, if you use the camera for only
short periods, it discharges gradually, and if you do not use the camera at all
for about 3 months it becomes completely discharged. In this case, be sure to
charge this rechargeable battery before using the camera. However, even if
this rechargeable battery is not charged, you can still use the camera as long as
you do not record the date and time. If the camera resets the settings to the
defaults each time you charge the battery, the internal rechargeable battery
may be dead. Consult your Sony dealer or local authorized Sony service
facility.
Trademarks
•
is a trademark of Sony Corporation.
• “Memory Stick,”
, “Memory Stick PRO,”
, “Memory
Stick Duo,”
, “Memory Stick PRO Duo,”
, “Memory Stick PRO-HG Duo,”
, “Memory Stick Micro,” “MagicGate,” and
are trademarks of Sony Corporation.
• “InfoLITHIUM” is a trademark of Sony Corporation.
• “PhotoTV HD” is a trademark of Sony Corporation.
• DVDirect is a trademark of Sony Corporation.
• Blu-ray Disc™ and Blu-ray™ are trademarks of the Blu-ray Disc Association.
• “AVCHD Progressive” and “AVCHD Progressive” logotype are trademarks of
Panasonic Corporation and Sony Corporation.
• Dolby and the double-D symbol are trademarks of Dolby Laboratories.
• Microsoft, Windows, and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC.
• Macintosh and Mac OS are trademarks or registered trademarks of Apple Inc.
• PowerPC is a registered trademark of IBM Corporation in the United States.
• Intel, Intel Core, and Pentium are trademarks or registered trademarks of Intel
Corporation.
• SDXC logo is trademarks of SD-3C, LLC.
• Eye-Fi is a trademark of Eye-Fi Inc.
• MultiMediaCard is a trademark of MultiMediaCard Association.
• “ ” and “PlayStation” are registered trademarks of Sony Computer
Entertainment Inc.
• Adobe is a registered trademark or a trademark of Adobe Systems Incorporated in
the United States and/or other countries.
• In addition, system and product names used in this manual are, in general,
trademarks or registered trademarks of their respective developers or
manufacturers. However, the ™ or ® marks are not used in all cases in this
manual.
On recording/playback
• When you use a memory card with this camera for the first time, it is
recommended that you format the card using the camera for stable
performance of the memory card before shooting. Note that formatting
permanently erases all data on the memory card, and is unrecoverable. Save
precious data on a computer, etc.
• If you repeatedly record/delete images, fragmentation of data may occur on
the memory card. Movies may not be able to be saved or recorded. In such a
case, save your images to a computer or other storage location, then format
the memory card.
• The recorded contents cannot be compensated for even if recording or
playback is not possible due to a malfunction of the camera or memory card,
etc.
• To avoid the potential risk of data loss, always copy (back up) data to other
medium.
• Before you record one-time events, make a trial recording to make sure that
the camera is working correctly.
• This camera is neither dust-proof, nor splash-proof, nor water-proof.
• Do not aim the camera at the sun or other bright light. It may cause the
malfunction of the camera.
• Do not look at the sun or a strong light through a removed lens. This may
cause irrecoverable damage to your eyes. Or it may cause a malfunction of
the lens.
• Do not use the camera near a location that generates strong radio waves or
emits radiation. The camera may not be able to record or play back properly.
• Using the camera in sandy or dusty locations may cause malfunctions.
• Do not shake or strike the camera. In addition to malfunctions and an
inability to record images, this may render the memory card unusable, or
cause image data breakdown, damage or loss.
• Clean the flash surface with a soft cloth. The heat of flash emission may
cause dirt to adhere on the flash surface, resulting in smoking or scorching.
• Keep the camera, supplied accessories, etc., out of the reach of children. A
memory card, etc., may be swallowed. If such problem occurs, consult a
doctor immediately.
Warning on copyright
Television programs, films, videotapes, and other materials may be
copyrighted. Unauthorized recording of such materials may be contrary to the
provisions of the copyright laws.
• Add further enjoyment with your PlayStation 3 by downloading the application
for PlayStation 3 from PlayStation Store (where available.)
• The application for PlayStation 3 requires PlayStation Network account and
application download. Accessible in areas where the PlayStation Store is
available.
Even if the CHARGE lamp is not lit, the battery charger is not disconnected from the AC
power source (mains) as long as it is connected to the wall outlet (wall socket). If some
trouble occurs while using the battery charger, immediately shut off the power by
disconnecting the plug from the wall outlet (wall socket).
The power cord (mains lead), if supplied, is designed specifically for use with this camera
only, and should not be used with other electrical equipment.
For Customers in the U.S.A. and Canada
[ RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your used
rechargeable batteries to the collection and recycling location nearest
you.
For more information regarding recycling of rechargeable batteries,
call toll free
1-800-822-8837, or visit http://www.rbrc.org/
Caution: Do not handle damaged or leaking Lithium-Ion batteries.
[ Battery pack and lens
This Class B digital apparatus complies with Canadian ICES-003.
For Customers in the U.S.A.
UL is an internationally recognized safety organization.
The UL Mark on the product means it has been UL Listed.
If you have any questions about this product, you may call:
Sony Customer Information Center
1-800-222-SONY (7669)
The number below is for the FCC related matters only.
[ Regulatory Information
Declaration of Conformity
Owner’s Record
The model and serial numbers are located on the bottom. Record the serial number in the
space provided below. Refer to these numbers whenever you call upon your Sony dealer
regarding this product.
Model No. NEX-7
Serial No. _____________________________
Trade Name: SONY
Model No.: NEX-7
Responsible Party: Sony Electronics Inc.
Address:
16530 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone No.: 858-942-2230
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
[ CAUTION
WARNING
To reduce fire or shock hazard, do not expose the unit to rain or
moisture.
IMPORTANT SAFETY INSTRUCTIONS
-SAVE THESE INSTRUCTIONS
DANGER
-TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW
THESE INSTRUCTIONS
If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the
proper configuration for the power outlet.
On the data specifications described in this manual
The data on performance and specifications is defined under the following
conditions, except as described in this manual: at an ordinary ambient
temperature of 25ºC (77°F), and using a battery pack that is charged for an
hour after the CHARGE lamp goes out.
[ Battery charger
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Charging method of the internal rechargeable battery
Insert a charged battery pack into the camera, or connect the camera to a wall
outlet (wall socket) using the AC Adaptor (sold separately), and leave the
camera for 24 hours or more with the power off.
• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a
car parked in the sun.
• Do not incinerate or dispose of in fire.
• Do not handle damaged or leaking lithium ion batteries.
• Be sure to charge the battery pack using a genuine Sony battery charger or a device that
can charge the battery pack.
• Keep the battery pack out of the reach of small children.
• Keep the battery pack dry.
• Replace only with the same or equivalent type recommended by Sony.
• Dispose of used battery packs promptly as described in the instructions.
CAUTION
[ Battery pack
If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical
burns. Observe the following cautions.
• Do not disassemble.
• Do not crush and do not expose the battery pack to any shock or force such as
hammering, dropping or stepping on it.
• Do not short circuit and do not allow metal objects to come into contact with the battery
terminals.
You are cautioned that any changes or modifications not expressly approved in this manual
could void your authority to operate this equipment.
[ Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
The supplied interface cable must be used with the equipment in order to comply with the
limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.
For Customers in Europe
[ Notice for the customers in the countries applying EU Directives
The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo,
108-0075 Japan. The Authorized Representative for EMC and product safety is Sony
Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or
guarantee matters please refer to the addresses given in separate service or guarantee
documents.
This product has been tested and found compliant with the limits set out in the EMC
Directive for using connection cables shorter than 3 meters (9.8 feet).
[ Attention
The electromagnetic fields at the specific frequencies may influence the picture and sound
of this unit.
[ Notice
If static electricity or electromagnetism causes data transfer to discontinue midway (fail),
restart the application or disconnect and connect the communication cable (USB, etc.)
again.
[ Disposal of Old Electrical & Electronic Equipment (Applicable in
the European Union and other European countries with separate
collection systems)
This symbol on the product or on its packaging indicates that this product
shall not be treated as household waste. Instead it shall be handed over to
the applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling
of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of this product,
please contact your local Civic Office, your household waste disposal service or the shop
where you purchased the product.
[ Disposal of waste batteries (applicable in the European Union
and other European countries with separate collection systems)
This symbol on the battery or on the packaging indicates that the battery
provided with this product shall not be treated as household waste.
On certain batteries this symbol might be used in combination with a
chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are
added if the battery contains more than 0.0005% mercury or 0.004% lead.
By ensuring these batteries are disposed of correctly, you will help prevent
potentially negative consequences for the environment and human health which could
otherwise be caused by inappropriate waste handling of the battery. The recycling of the
materials will help to conserve natural resources.
In case of products that for safety, performance or data integrity reasons require a
permanent connection with an incorporated battery, this battery should be replaced by
qualified service staff only. To ensure that the battery will be treated properly, hand over
the product at end-of-life to the applicable collection point for the recycling of electrical
and electronic equipment.
For all other batteries, please view the section on how to remove the battery from the
product safely.
Hand the battery over to the applicable collection point for the recycling of waste batteries.
For more detailed information about recycling of this product or battery, please contact
your local Civic Office, your household waste disposal service or the shop where you
purchased the product.
Notice for customers in the United Kingdom
A moulded plug complying with BS 1363 is fitted to this equipment for your safety and
convenience.
Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the
supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an
or
mark) must be used.
If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the
fuse cover after you change the fuse. Never use the plug without the fuse cover. If you
should lose the fuse cover, please contact your nearest Sony service station.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
