HONDA NIFTY 50
OWNER’S MANUAL
TYPE: U
All information in this publication is based on the latest product information available at the
time of approval for printing. HONDA MOTOR CO., LTD reserves the right to make
changes at any time without notice and without incurring any obligation.
No part of this publication may be reproduced without written permission.
© Honda Motor Co., Ltd. 1985
WELCOME,
The motorcycle presents you a challenge to master the machine, a challenge to adventure.
You ride through the wind, linked to the road by a vehicle that responds to your com-
mands as no other does, Unlike an automobile, there is no metal cage around you. Like
an airplane, a pe-ride inspection and regular maintenance are essential to your safety.
Your reward is freedom.
To meet the challenges safely, and to enjoy the adventure fully, you should become
thoroughly familiar with this owner’s manual BEFORE YOU RIDE THE MOTORCY-
CLE.
When service is required, remember that your Honda dealer knows your motorcycle best.
If you have the required mechanical “know-how” and tools, your dealer can supply you
with an official Honda Shop Manual to help you perform many maintenance and repair
tasks.
Pleasant riding, and thank you for choosing a Honda!
Page
MOTORCYCLE SAFETY ................ 1
Safe Riding Rules ......................... 3
Protective Apparel....................... 4
Loading and Accessories ................ 5
Tires Lecce naar a anna nee eee 6
Modifications............e_eoeceresrerpereee. 7
DESCRIPTION... can a eee 00e 8
Control Location ve... 8
Serial Numbers... 12
Color Label ...............0..... 13
Parts FUnction..........._emeeerrereeioree 14
Fuel oo a ea a sean sean s esse 21
Engine Olsen 23
OPERATION oii 24
Pre-ride Inspection .................e..... 24
Starting the Engine 25
Break-in..............recesverrererereeneer e 28
Riding the Motorcycle.................. 29
Braking.........e...eeeeevecernererteereees 31
Parking............eeeerevrrecrercerirercere. 32
CONTENTS
Page
MAINTENANCE............... .eresccumooo 33
Maintenance Schedule ................... 35
Maintenance Record ..................... 37
Spark Plug..................ee.ercerrcencae. 38
Air Cleaner ..........._m.errercercocerecce.. 39
Brakes...........eescercorcocoreroc0cmoarere. 40
Battery ......c.c.erecresrccorererrereerercar. 42
Fuse Replacement......................... 43
Transporting the Motorcycle.......... 45
CLEANING oie 46
STORAGE GUIDE ers 47
SPECIFICATIONS Lace s casa n anne n 49
NOISE EMISSION (AUSTRALIA
ONLY )-eorcccaonnoonaracananacacnonenenenenorerarecane. 52
WIRING DIAGRAM
MOTORCYCLE SAFETY
Read these WARNING LABELS before you ride!
a
REMEMBER
a PRESERVE NATURE
m ALWAYS WEAR A HELMET
m RIDE SAFELY
m READ OWNER'S MANUAL
CAREFULLY BEFORE RIDING. )
L
TYPE: U
( CAUTION
OIL : TWO STROKE “INJECTOR |
OIL IS RECOMMENDED.
COLD TIREPRESSURES
FRONT 18psi. 125kPa 1.25kg/cm:
REAR 24psi. 175kPa 1.75kg/cm*
TIRE SIZE : FRONT 12.50-10-2PR
REAR 2.50-10-2PR
VEHICLE CAPACITY LOAD: 1801bs. (82kg)
DRIVER ONLY
MAXIMUM CARGO WEIGHT
| FRONT 71bs.{3kg) REAR 11bs. (5kg)
\ J
GKB—&70
WARNING
FOR SAFE OPERATION, DO NOT
PUT ANYTHING BETWEEN THE
FRAME AND ENGINE.
pee TYPE: U
| V WARNING
* Motorcycle riding requires special efforts on your part to ensure your safety. Know
these requirements before you ride.
SAFE RIDING RULES
|.
Always make a pre-ride inspection (page
24) before you start the engine. You
may prevent an accident or equipment
damage.
. Many accidents involve inexperienced
riders. Most states require a special
riding test or license. Make sure you
are qualified before you ride. NEVER
lend your motorcycle to an inexperi-
enced rider.
. Many automobile/motorcycle acci-
dents happen because the automobile
driver does not “see” the rider, Make
yourself conspicuous to help avoid the
accident that wasn’t your fault:
e Don't ride in another motorist’s
“blind spot.”
4. Obey all national and local laws and
regulations.
e Excessive speed is a factor in many
accidents. Obey the speed limits, and
NEVER travel faster than conditions
warrant.
e Signal before you make a turn or lane
change. Your size and maneuverabili-
ty can surprise other motorists.
. Don’t let other motorists surprise you.
Use extra caution at intersections, park-
ing lot entrances and exits, and
driveways.
6. Keep both hands on the handlebars and
both feet on the floor boards while
riding.
. Moderate your speed when riding over
bumpy roads. Avoid hitting road
hazards, such as sharp bumps and
holes in the road surface. These haz-
ards can cause loss of control or struc-
tural damage to the vehicle.
PROTECTIVE APPAREL
1.
Most motorcycle accident fatalities are
due to head injuries: ALWAYS wear
a helmet. You should also wear a face
shield or goggles as well as boots,
gloves and protective clothing.
The exhaust system becomes very hot
during operation, and it remains hot
after operation. Never touch any part of
the hot exhaust system. Wear clothing
that fully covers your legs.
. Do not wear loose clothing which could
catch on the control levers or wheels.
LOADING AND ACCESSORIES
* A motorcycle is sensitive to changes in
weight distribution. Improper loading
of cargo and mounting of accessories
can impair the motorcycle's stability
and performance. To prevent an acci-
dent, use extreme care when mounting
accessories and riding with cargo,
These general guidelines may help you
decide whether or how to equip your
motorcycle, and how to load it safety.
The vehicle load limit is 82 kg (180 1bs.).
The combined weight of the rider, and
cargo must not exceed this limit,
1. Do not exceed these following weight
limits for the luggage rack.
Overloading the luggage rack will ad-
versely affect stability and handling.
Front (Basket) Rear (Corrier)
3 Кв (7 155.) 5 Кв (11 165.)
. Keep cargo weight low and close to
the center of the motorcycle. As
weight is located farther from the
motorcycle’s center of gravity, han-
dling is proportionally affected.
. All cargo and accessories must be secure
for stable handling. Recheck security
frequently.
. Do not carry items that protrude
through the rack or block the taillight.
. Do not carry children or pets on the lug-
gage rack.
. Do not install another fairing or modify
the existing one,
TIRES
Proper air pressure will provide maximum
traction, stability, riding comfort and tire
life.
Check tire pressures frequently and adjust
if necessary (see page 2).
NOTE:
* Tire pressure should be checked when
the tires are ‘‘cold’’, before you ride.
Check the tires for cuts, imbedded nails, or
other sharp objects. See your authorized
Honda motor dealer for replacement of
damaged tires or punctured inner tubes.
* Improper tire inflation will cause abnor-
mal tread wear and create a safety
hazard. Underinflation may result in the
tire slipping on, or coming off of the
rim.
* Operation with excessively worn tires is
hazardous and will adversely affect trac-
tion and handling.
* Do not attempt to patch a damaged tire
or inner tube. Wheel balance and tire
reliability may be impaired.
* Replace tires before tread depth at the
center of the tires reaches the following
limit:
Minimum tread depth
0.8 mm (1/32 in)
MODIFICATIONS
* Modification of the motorcycle or re-
moval of original equipment may
render the vehicle unsafe or illegal,
Obey all national, state and local equip-
ment regulations.
CONTROL LOCATION
DESCRIPTION
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
Starter button
Headlight switch
Throttle grip
Front brake lever
Rear view mirror
Fuel gauge
Speedometer
Oil level warning light
Rear brake lock lever
(10) Rear brake lever
(11) Dimmer switch
(12) Turn signal switch
(13) Horn button
EQUIPMENT AND CONTROLS
Control Location
TYPE: U
10
(1) Helmet holder
(2) Center stand
TYPE: U
(1) Oil tank cap
2
(2) Ignition switch
TYPE: U
11
SERIAL NUMBERS
The frame serial number (1) is stamped
on the right side of the frame body.
FRAME NO.
\\
I UE
E ID
a
(1) Frame serial number
12
The engine serial number (2) is stamped on
the back of the crankcase near the rear
wheel.
ENGINE NO.
(2) Engine serial number
COLOR LABEL
The color label (1) is attached to the fuel
tank below the seat. It is helpful when
ordering replacement parts. Record the
model, color and code here for your
reference.
MODEL
COLOR
CODE
COLOR LABEL
SOBEL
DLE
©
opr
HONDA
(1) Color label
13
PARTS FUNCTION
Instruments and Indicators
The indicators are grouped between the
handlebars.
Their functions are described in the table on
the following page.
(1) Speedometer
(2) Odometer
(3) Fuel gauge
(4) Oil level warning light
(5) Turn signal indicator (U)
14
Ref. No. Description Function
1 Speedometer Shows riding speed.
2 Odometer Shows total accumulated distance traveled.
3 Fuel gauge Shows approximate fuel supply available
(see page 16).
4 qe 5 vel warning light Lights when oil level is low (see page 16).
5 Flashes when either turn signal is operated.
Turn signal indicator (U)
15
Fuel Gauge
The fuel gauge (1) shows the approximate
fuel supply available. At F (Full) there are
2.5 liters (0.66 U.S. gal., 0.55 Imp. gal.),
including the reserve supply.
When the gauge needle enters the red band
(2), fue! will be low and you should refill the
tank as soon as possible. The amount of
fuel left in the tank when the needle
enters the red band is approximately 0.5
liters (0.13 U.S. gal., 0.11 Imp. gal.).
(2) Red band
(1) Fuel gauge
16
Oil Level Warning Light
The oil level warning light (1) lights when
the 2-stroke engine oil level is below ap-
proximately 0.2 liter (0.21 U.S. qt., 0.18
Imp. gt.).
* If the warning light comes on while
riding, stop riding and shut rhe engine
off. Fill the oil tank immediately to the
UPPER LEVEL mark with the recom-
mended oil (see page 23). Do not ride
if the oil level is low.
il level warning light
Ignition Switch
The ignition switch (1) is on the right side
below the steering stem.
(1) Ignition switch
Key Position Function Key Removal
LOCK The steering is locked. The engine and Key can be removed.
(Steering lock) lights cannot be operated.
OFF Engine and lights cannot be operated. Key can be removed.
ON The engine can be started. Key can not be removed.
17
Starter Button
When the starter button (1) is pressed,
the starter motor cranks the engine. See
page 25 for the starting procedure.
Headlight Switch (2)
=D: Headlight, taillight, meter lights on
when the engine is running.
The three controls next to the left han-
dlebar grip are:
LK
—
9 O
с
o (U)
D (pk)
Dimmer Switch (3)
Select HI for high beam, LO for low
beam.
Turn Signal Switch (4)
Move to L or “+” to signal a left turn, К
or “>” to signal a right turn. Return to
the center (off) position upon completing
the turn.
Horn Button (5)
Press the button to sound the horn.
(1) Starter button
18
(2) Headlight switch
(3) Dimmer switch
(4) Turn signal switch
(5) Horn button
Steering Lock Seat Lock
To lock the steering, turn the handlebars all The seat lock (1) is on the left side below the
the way to the left, and turn the key (1) to seat.
LOCK. Remove the key. To lift the seat, insert the ignition key (2)
and turn it clockwise to unlock.
| Y WARNING | To lock the seat, lower and push down on it
until it locks. Make sure the seat is secure
* Do not turn the key to LOCK while before riding
riding the scooter.
(1) Ignition key (A) Turn to LOCK © (1) Seat lock — (2) Ignition key
19
Helmet Holder To remove a helmet, unlock the seat. Lift
The helmet holder (1) eliminates the need the helmet off the holder and lower the
for carrying your helmet after parking. seat, making sure it is securely locked
|. Insert the ignition key into the seat lock before riding.
(2), and turn it clockwise to unlock.
2. Hang your helmet on the hook at the CTN ‚ ‚
seat hinge. The helmet holder is designed for hel-
met security while parked. Do not
operate the motorcycle with a helmet
attached to the holder.
3. Lower the seat to lock.
(1) Helmet holder (2) Seatlock
20
FUEL
Fuel Valve
OFF
At OFF, fuel will not flow from the tank
to the carburetor.
Turn the valve off whenever the motor-
cycle is not in use.
ON
At ON, fuel will flow from the tank to
the carburetor.
RES
With the fuel valve in the RES position,
fuel will flow from the reserve fuel supply
to the carburetor. Use the reserve fuel
only when the main supply is gone, Refill
the tank as soon as possible after switch-
ing to RES. The reserve fuel supply is
0.5 £ (0.13 U.S. gal., 0.11 Imp. gal.).
(1) Fuel valve
21
Fuel Tank Y WARNING]
Fuel tank ity is 2.52 (0.66 U.S. gal.
oe imp sal). Rem Sue ee D о * Gasoline is extremely flammable and is
: - gal.). explosive under certain conditions.
bv turning it counterclockwise. )
y 8 Refuel in a well-ventilated area with
NOTE: the engine stopped. Do not smoke or
* Use UNLEADED gasoline with a allow flames or sparks in the area
Research Octane number of 91 or where the motorcycle is refueled or
higher, or a Pump Octane number of 86 where gasoline is stored,
or higher. * Do not oxerfill the tank (there should
* The use of leaded gasoline will cause be no fuel in the filler neck). After
spark plug fouling. refueling, make sure the fuel cap is
closed securely,
(1) Fuel cap
22
ENGINE OIL
Oil Level
If the oil level indicator lights when the
ignition switch turns to ON position,
there is insufficient oil in the oil tank;
stop the engine and fill the oil tank. To
fill, lift the seat, remove the cap (1) from
the oil tank, and fill with the recommend-
ed oil up to the UPPER LEVEL mark (2).
Capacity:
0.62 (0.63 U.S. gt., 0.53 Imp. qt.)
(1) Oil tank cap (2) UPPER LEVEL mark
Oil Recommendation
USE HONDA 2 STROKE OIL OR ITS
EQUIVALENT.
CAUTION:
* The use of improper oils may cause
excessive and/or premature carbon
build up in the engine and exhaust
system, resulting in loss of power and
possible engine damage. Genuine
Honda 2-Stroke Oil has been specifi-
cally designed and tested in Honda
motorcycles and is a proper oil,
* If the engine has run after the oil in-
dicator light has come on, check the
tube from the oil tank to the oil pump.
If air is present in this tube, do not
start the engine. The motorcycle must
be taken to an authorized Honda
dealer for inspection and bleeding of
the oil system. Failure to do this will
result in serious engine damage.
NOTE:
* When filling, do not let dirt or other
foreign materials enter the tank.
23
PRE-RIDE INSPECTION
* If the Pre-ride Inspection is not per-
formed, serious damage or an accident
may result.
Inspect your motorcycle every day before
you start the engine. The items listed here
will only take a few minutes to check
and, in the long run, can save time, ex-
pense, and possibly your life.
1. Oil level-check the level and if necessary
add oil (page 23).
2. Fuel level-fill the fuel tank when
necessary (page 22). Check for leaks.
3. Front and rear brakes-check operation
and if necessary, adjust free play
(pages 40—41).
4. Tires-check condition and pressure
(pages 2, 6).
5. Throttle-check for smooth opening and
closing in all steering positions.
24
6. Lights and horn- check that the
headlight, tail/stoplight, turn signals, in-
dicators and horn function properly.
Correct any discrepancy before you ride.
Contact your authorized Honda dealer
for assistance if you cannot correct the
problem.
STARTING THE ENGINE
1. Place the motorcycle on its center
stand.
2. Lock the rear wheel by squeezing the
rear brake lever and setting the lock
lever (1).
NOTE:
* The electric starter will only work
when the rear brake lever (2) is operated.
* The rear wheel will spin if not restrain-
ed by the brake or contact with the
ground. Accidental contact with the
spinning rear wheel could cause per-
sonal injury.
3. Turn the fuel valve to ON.
(1) Lock lever
(2) Rear brake lever
25
4. Turn the ignition switch (3) to ON.
¥ WARNING
* Never run the engine in a closed area.
The exhaust contains poisonous carbon
monoxide gas.
5. With the throttle closed, push the
starter button (4). Release the starter
button as soon as the engine starts.
(3) Ignition switch
26
NOTE:
Do not use the electric starter for more than
5 seconds at a time. Release the starter but-
ton for approximately 10 seconds before
pressing it again.
CLOSED
(U)
(4) Starter button
NOTE:
* If the motorcycle has been left stand-
ing for a long time, or when the fuel
tank has just been refilled, you may
have to operate the starter button for
slightly longer than usual without
opening the throttle.
. Be sure to keep the throttle (5) closed
and the rear brake lever (6) locked
while starting and warming up the
engine.
Allow the engine to warm up before
riding (see RIDING THE MOTOR-
CYCLE, page 29).
(5) Throttle
(6) Rear brake lever
27
* The rear wheel will spin if not restrain-
ed by the brake or contact with the
ground.
Accidental contact with the spinning
rear wheel could cause personal injury.
Do not leave the motorcycle unattend-
ed while the engine is running.
* Do not attempt to “BLIP” the throttle
fopen and close rapidly) as the motor-
cycle will move forward suddenly,
causing possible loss of control.
28
BREAK-IN
During the first 300 km (200-miles), do
not operate the motorcycle at more than
80% of the maximum speed.
Avoid full throttle operation, and do not
operate for a long time at one speed.
During initial break-in, newly machined
surfaces will be in contact with each
other and these surfaces will wear in
quickly.
Break-in maintenance at 300 km (200
miles) is designed to compensate for this
initial minor wear. Timely performance
of the break-in maintenance will ensure
optimum service life and performance
from the engine.
RIDING THE MOTORCYCLE 1. Make sure the throttle is closed and
the rear brake is locked before moving
the motorcycle off the center stand.
* The exhaust pipe and muffler become
very hot during operation and remain * The rear wheel must be locked when
sufficiently hot to inflict burns if moving the motorcycle off the center
touched, even after shutting off the stand or loss of control may result.
engine. Wear clothing which will com-
pletely cover your legs while riding
and avoid any contact with unshielded
portions of the exhaust system,
* Do not wear loose clothing which may
catch on control levers, wheels and
tires.
* Ensure that all required equipment as
specified by local laws and regulations
are installed on the scooter and oper-
able before riding it on public streets.
* Modification of the motorcycle, or re-
moval of original equipment, may
render the vehicle unsafe or illegal.
29
2. Once off the center stand, unlock the 3. To accelerate, open the throttle (2)
rear wheel by squeezing and releasing gradually; to decelerate, close the
the rear brake lever (1). throttle.
* Do not blip the throttle (open and * The motorcycle is equipped with an
close it rapidly) as the motorcycle will automatic clutch which engages as en-
move forward suddenly, causing possi- gine speed is increased.
ble loss of control.
(1) Rear brake lever (2) Throttle
30
BRAKING
When slowing down the motorcycle, co-
ordination of the throttle (1) and front
and rear brakes (2) are most important.
* Both front and rear brakes should be
applied together, Independent use of
only the front or rear brake reduces
stopping performance.
Excessive brake application may cause
either wheel to lock, reducing control
of the motorcycle.
(1) Throttle
CAUTION:
* When descending a steep grade, close
the throttle fully and intermittently
apply both brakes to slow the motor-
cycle down. Avoid continuous use of
the brakes, which may result in over-
heating and reduction of braking effi-
ciency,
LAA GIN
* When riding in wet or rainy conditions
or on loose surfaces, the ability to
maneuver and stop will be reduced. For
your safety, exercise extreme caution
when braking, accelerating, or turning.
REAR
FRONT
Apply both the front and rear brakes. (U)
(2) Brake lever
31
PARKING
1. After stopping the motorcycle, turn
the ignition switch OFF and remove
the key.
2. Use the center stand to support the
motorcycle while parked.
CAUTION:
* Park the motorcycle on firm, level
ground to prevent overturning.
3. Lock the steering to help prevent
theft (page 19).
32
ANTI-THEFT TIPS
1.
Always lock the steering and never leave
the key in the ignition switch. This
sounds simple but people do forget.
. Be sure the registration information
for your motorcycle is accurate and
current,
. Park your motorcycle in a locked
garage whenever possible.
. Use an additional anti-theft device of
good quality.
. Put your name, address, and phone
number in this Owner’s Manual and
keep it on your motorcycle at all
times.
Many times stolen motorcycles are
identified by information in the
Owner’s Manuals which are still with
them.
NAME:
ADDRESS:
PHONE NO:
MAINTENANCE
e When service is required, remember that your authorized Honda dealer knows your
motorcycle best and is fully equipped to maintain and repair it. The scheduled mainte-
nance may be performed by a qualified service facility that normally does this kind of
work; or you may perform most of the work yourself if you are mechanically quali-
fied.
® The maintenance intervals shown in the following schedule are based upon average
riding conditions. Motorcycles subjected to severe use, or ridden in unusually muddy
or dusty areas, require more frequent servicing,
® Consult your authorized Honda dealer for recommendations applicable to you individ-
ual needs and use.
33
*
34
If your motorcycle is overturned or
involved in a collision, inspect control
levers and, cables, switches and other
vital parts for damage. Do not ride the
motorcycle if damage impairs safe
operation. Have your authorized
Honda dealer inspect the major com-
ponents including frame, suspension,
and steering parts for misalignment
and damage that you may not be able
to detect.
Stop the engine and support the mo-
torcycle securely on a level surface
before performing any maintenance.
Use new, genuine Honda motorcycle
parts or their equivalent for mainte-
nance and repair.
Parts which are not of equivalent qual-
ity may impair the safety of your
motorcycle,
MAINTENANCE SCHEDULE
Perform the Pre-ride Inspection (page 24) at each scheduled maintenance period.
I. Inspect and Clean, Adjust, Lubricate or Replace, if necessary.
C: Clean R: Replace A: Adjust L: Lubricate
FREQUENCY | WHICHEVER ODOMETER READING
COMES (NOTE 2)
FIRST
5 =
SP >)
Vas $
O
УС
ITEM EVERY N Refer to
* | FUEL LINE — 11
* | FUEL STRAINER SCREEN Тс
* | THROTTLE OPERATION — 11
** | OIL PUMP AND OIL LINE J
* | CARBURETOR CHOKE — 1]
AIR CLEANER NOTE 1 — € Page 39
SPARK PLUG NOTE 3 TOMA Page 38
** | DECARBONIZING NOTE 3 dom
* | CARBURETOR-IDLE SPEED I | I | I | I
FREQUENCY WHICHEVER ODOMETER READING
COMES (NOTE 2)
FIRST = > <=
Q Ne
SES
Q SASS
ITEM EVERY Ne N No O° Refer to
TRANSMISSION OIL — — _ R
* | FINAL DRIVE OIL 2 YEARS *R — Ш _ Ш
BRAKE SHOE WEAR — I 1 1 Page 41
BRAKE SYSTEM I I I I Pages 40-41
* | BRAKE LIGHT SWITCH _ I I I
* | SUSPENSION — I I I
* | NUT, BOLT, FASTENER I — I —
* | HEADLIGHT AIM — 1 I I
** | CLUTCH SHOE WEAR — — I —
** | WHEEL — I I I
** | STEERING HEAD BEARING I — _ I
ЖЖ
SHOULD BE SERVICED BY AN AUTHORIZED HONDA MOTORCYCLE DEALER UNLESS THE OWN-
ER HAS PROPER TOOLS AND SERVICE DATA, AND IS MECHANICALLY QUALIFIED. REFER TO
THE OFFICIAL HONDA MOTORCYCLE SHOP MANUAL.
IN THE INTEREST OF SAFETY, WE RECOMMEND THESE ITEMS BE SERVICED ONLY BY AN AU-
THORIZED HONDA MOTORCYCLE DEALER.
NOTES: (1) Service more frequently when riding in dusty areas.
2
36
For higher odometer readings, repeat at the frequency interval established here,
(3) HONDA 2 STROKE MOTORCYCLE OIL has been specifically tested in and is recommended for
this engine. The use of other oils may cause excessive carbon build-up in the engine and exhaust
system, resulting in loss of power and possible engine damage.
MAINTENANCE RECORD
Km Performed by Odometer Date
1,000
4,000
8,000
12,000
e Make sure that whoever performs the maintenance completes this record.
All scheduled maintenance including the 1,000 km (600 miles) initial inspection is
considered a normal owner operating cost and will be charged for by your authorized
Honda dealer.
e Detailed receipts verifying the performance of required maintenance should be retain-
ed.
These receipts should be transferred with the motorcycle to the new owner if the mo-
torcycle is sold.
37
SPARK PLUG
Recommended plugs:
Standard:
BP6HSA (NGK) W20FP-L (ND)
For cold climate (Below 5” C, 41 °F):
BP4HSA (NGK) W14FP-L (ND)
For extended high speed riding:
1.
WwW NI
38
BP8HSA (NGK) W24EP-L (ND)
Remove the left side cover by un-
screwing the rear bracket screw and
gently pulling the cover away, starting
from the rear edge.
. Disconnect the spark plug cap.
. Clean any dirt from around the spark
plug base. Remove and discard the
spark plug.
. Make sure the spark plug gap (1) is
0.6—0.7 mm (0.024—0.028 in) using a
wire-type feeler gauge. If adjustment is
necessary, bend the side electrode (2)
carefuliy.
. With the plug washer attached, thread
the new spark plug in by hand to pre-
vent cross-threading.
(1) Spark plug gap
6. Tighten the spark plug 1/2 turn with a
spark plug wrench to compress the
washer.
7. Connect the plug cap, and replace the
side cover.
CAUTION :
* The spark plug must be securely tight-
ened. An improperly tightened plug
can become very hot and possibly
damage the engine.
* Never use a spark plug with an im-
proper heat range,
(2) Side electrode
AIR CLEANER
The air cleaner should be serviced at regu-
lar intervals (page 35). Service more fre-
quently when riding in dusty areas.
1. Remove the rear carrier by removing
two cap nuts (1) and two flange nuts
(2).
2. Remove the side cover by removing a
bolt (3), cap nut/washer (4) and clip
(5).
3. Remove the air cleaner cover (6) by
removing the screw (7).
4. Remove the air cleaner element.
(1) Cap nuts (3)
(2) Flange nuts (4) Cap nut/washer
(5) Clip
sure to secure all nuts and bolts.
(6) Air cleaner cover
(7) Screw
5. Wash the element in non-flammable
or high flash point solvent and allow
it to dry thoroughly.
Never use gasoline or low flash point
solvents for cleaning the air cleaner
element. A fire or explosion could
result.
. Soak the air cleaner element in clean
gear oil (SAE 80 or 90) and squeeze
out the excess.
. To install the air cleaner element, re-
verse the removal procedure. Make
39
BRAKES
Adjustment:
1.
Measure the distance the front brake
lever (1) and the rear brake lever (2)
move before the brake starts to take
Make sure the cut-out on the adjusting
nut is seated on the brake arm pin (4)
after making the final free play adjust-
ment.
. Apply the brake several times and check
for free wheel rotation when released.
hold. Free play should be 10—20mm
(3/8—3/4 in) at the tip of the brake
levers.
2. Make free play adjustments by turning
the adjusting nut (3) at the brake arm.
NOTE:
x If proper adjustment cannot be obtained
by this method, see your authorized
Honda dealer.
10-20mm
— (Front) (Rear)
(3) Adjusting nut (A) Increase
(4) Arm pin (B) Decrease
(1) Front brake lever
(2) Rear brake lever
Wear Indicator:
When the brake is applied, an arrow (2) at-
tached to the brake arm (3) moves toward a
reference mark (1) on the brake panel.
If the arrow aligns with the reference mark
on full application of the brake, the brake
shoes must be replaced. See your autho-
rized Honda dealer for this service,
(FRONT)
(1) Reference mark (2) Arrow
Other Checks:
Check the brake cable for kinks or signs of
wear that could cause sticking or failure.
Lubricate the brake cable with a commer-
cially available cable lubricant to prevent
premature wear and corrosion.
Make sure the brake arm, spring and
fasteners are in good condition.
(REAR)
(3) Brake arm
BATTERY
It is not necessary to check battery elec-
trolyte level or add distilled water as the
battery is a sealed type. If any los of elec-
trolyte is experienced or if your battery
seems to be weak, causing slow starting or
other electrical troubles, see your author-
ized Honda dealer.
CAUTION:
* Do not attempt to remove the caps
from the cells.
* When the motorcycle is to be stored
for an extended period of time, re-
move the battery from the motorcycle
and charge it fully. Then store it in a
cool, dry place. If the battery is to be
left in the motorcycle, disconnect the
negative cable from the battery termi-
nal.
CIT
* Keep away from open flames or sparks
when handling a battery.
42
FUSE REPLACEMENT
The fuse holder is near the battery. The
specified fuse is 7A. When frequent fuse
failure occurs, it usually indicates a short
circuit or an overload in the electrical sys-
tem. If this happens, the electrical system
should be checked visually for damaged
insulation or other possible malfunctions.
If the problem cannot be located visually,
the motorcycle should be examined by
an authorized Honda dealer.
(1) Fuse holder
* Never use a fuse with a different rating
from that specified. Serious damage to
the electrical system or a fire may result,
causing a dangerous loss of lights or
engine power at night or in traffic.
CAUTION:
* Turn the ignition switch OFF before
checking or replacing the fuse to prevent
accidental short-circuiting.
43
* Do not pry the clips open to get a fuse
out; you could bend them and cause
poor contact with the new fuse. A loose
fuse could cause damage to the electrical
system and even start a fire.
To replace the fuse, open the fuse holder
and lift out the fuse with the clips. Slide the
old fuse out of the clips and discard it. Slide
the clips onto the ends of the new fuse, push
them back into the fuse holder, and close
the fuse holder.
44
REMOVAL
FUSE HOLDER
SLIDE 4mm
INSTALLATION
TRANSPORTING THE MOTORCYCLE
* To prevent the possibility of a fire or ex-
plosion when transporting the motor-
cycle always
— Drain the fuel tank and carburetor.
— Carry the vehicle upright in its normal
riding position to prevent oil and battery
electrolyte from leaking.
— Tie down the motorcycle at the wheels.
Draining Fuel
Perform this operation only in a well-
ventilated area.
* Gasoline is flammable and explosive
under certain conditions. Always stop
the engine, and do not smoke or allow
flames or sparks in the area when drain-
ing or refueling.
1. Stop the engine and remove the left side
cover.
2. Empty the fuel tank using a commer-
cially available hand siphon or other
equivalent way.
3. Place the free end of the carburetor
drain tube into a suitable fuel container.
4. Open the carburetor drain by turning the
drain screw counterclockwise.
When all fuel has drained, turn the
screw clockwise until tight.
(1) Drain screw
45
Clean your motorcycle regularly to pro-
tect the surface finishes and inspect if for
damage, wear, and oil seepage.
CAUTION:
x
46
Avoid spraying high pressure water
(typical in coin-operated car washes)
at the following areas:
Wheel Hubs Ignition Switch
Muffler Outlet Handlebar Switches
Under Seat
. After cleaning, rinse the motorcycle
thoroughly with plenty of clean water.
Strong detergent residue can corrode
alloy parts.
. Dry the motorcycle start the engine,
and let it run for several minutes.
3. Test the brakes before riding the
motorcycle in traffic. Several applica-
tions may be necessary to restore
normal braking performance.
CT
* Braking performance may be impaired
immediately after washing the motor-
cycle.
Storage
Extended storage, such as for winter, re-
quires that you take certain steps to
reduce the effects of deterioration from
non-use of the motorcycle. In addition,
necessary repairs should be made BE-
FORE storing the motorcycle; otherwise,
these repairs may be forgotten by the
time the motorcycle is removed from
storage.
I. Drain the fuel tank and carburetor.
Spray the inside of the tank with an
aerosol rust-inhibiting oil.
Reinstall the fuel cap on the tank.
CI
* Gasoline is flammable and is explosive
under certain conditions, Do not smoke
or allow flames or sparks near the equip-
ment while draining fuel,
STORAGE GUIDE -—-—.e—e—e—e— o—e—em—.
2. Remove the spark plug and pour a
tablespoon (15—20 cc) of clean 2-stroke
oil into the cylinder.
Operate the starter button to distrib-
ute the oil, then reinstall the spark
plug.
NOTE:
* When turning the engine over, the
Engine Stop Switch should be OFF.
3. Remove the battery. Store in an area
protected from freezing temperatures
and direct sunlight.
4, Wash and dry the motorcycle, Wax
all painted surfaces.
47
5.
48
. Cover the
Inflate the tires to their recommended
pressures. Place the motorcycle on
blocks to raise both tires off the
ground.
motorcycle (don’t use
plastic or other coated materials) and
store in an unheated area, free of
dampness with a minimum of daily
temperature variation. Do not store
the motorcycle in direct sunlight.
Removal from Storage
1.
2.
3.
Uncover and clean the motorcycle.
Check the voltage and slow charge the
battery if it is below 12.3 V.
Drain any excess aerosol rust-inhibit-
ing oil from the fuel tank. Fill the fuel
tank with fresh gasoline,
. Perform all Pre-ride Inspection checks
(page 24). Test ride the motorcycle
at low speeds in a safe riding area away
from traffic.
SPECIFICATIONS
DIMENSIONS
Overall length 1,490 mm (58.6 in)
Overall width 590 mm (23.2 in)
Overall height 915 mm (36.0 in)
Wheelbase 1,065 mm (41.9 in)
WEIGHT
Dry weight 41.8 kg (92.2 1bs)
CAPACITIES
2 stroke engine oil 0.6 liter (0.63 U.S. qt, 0.53 Imp. qt)
Transmission Oil 0.09 liter (0.095 U.S. qt, 0.079 Imp. qt)
Fuel tank 2.5 liter (0.66 U.S. gal, 0.55 Imp. gal)
Rider capacity Operator only
Vehicle capacity load 82 kg (180 1bs.)
49
ENGINE
Bore and stroke
Compression ratio
Displacement
Spark plug
Spark plug gap
41.0 x 37.4 mm (1.61 x 1.47 in)
6.8 : 1
49 cc (3.0 cu-in)
Standard: BP6HSA (NGK) or W20FP-L (ND)
For cold climate: (Below 5°C, 41°F)
BP4HSA (NGK) or W14FP-L (ND)
For extended high speed riding:
BP8HSA (NGK) or W24EP-L (ND)
0.6 — 0.7 mm (0.024—0.028 in)
Idle speed 1,800 + 200 rpm
CHASSIS AND SUSPENSION
Caster 27°
Trail 76 mm (3.0 in)
Tire size, front 2.50—10—2PR
Tire size, rear 2.50—10—2PR
50
POWER TRANSMISSION
Primary reduction V-Belt
ELECTRICAL
Battery 12V—3AH
Ignition system C.D.I.
LIGHTS U DK
Headlight (High/Low) 12V—25/25W 12V—25W
Tail/stoplight 12V—5/18W 12V—5/18W
Turn signal light 12V—32 cp 12V—10W
Turn signal indicator 12V—3.4W ——
Speedometer light 12V—3.4W 12V—3.4W
FUSE 7 Amp.
51
NOISE EMISSION (AUSTRALIA ONLY)
This motorcycle complies with the Australian Design Rule (ADR 39-2-3) requirements
for noise emission regulations. And the data below is written according to the require-
ments.
Sound Level of Stationary Test Engine Speed at Maximum Power
81 dB (A) 6,500 rpm
52
0099 - 849 -Z0£00
HO 97 CH y
O+O+0 TE | | |O+0 440 [OO |Hsne O-O |Hsn | e | {N}
O+O 'H oo! | NO | (asus 334 OOo ΠO+O1| 1
| ^уно[ю | зынм ни | ju 1H] NV] paveluve à | ai 3 | 16 Lvs] oH 13 | WH wml
A a = HOLIMS HINWIA HOLIMS NOLLINDI HOLIMS H3LUV1S HOLIMGNHOH HOLIMS SNILHDI HOLIMS IVNOIS NUNL
N334D LHD BY
эпля 1H911; 91
— ALINNILNOS HILIMS dIZEAZL
TYNDIS NHNL LNOHA 1
agn1-5
HOLYNYALTV
OSEMS 40151538 = HOLOW dalbvis
|
431411234
NHOH /HOLVIND3H
O
HOLIMS NUOH-d3AWIC-IYNDIS NN.
OH TMUY*‘H 91 TH
HOLIMS
4015 HY3H
>
!
YILIN 13nd
AY 13
TYNDIS NHNL
dOZEAZL MPEACL
AIYNDIS NUNL HY3Y 1 LH H3ILIM
9
=
AS
9 .—. >»
MS/8LAZI LHD TIVLHJOIS
MSZ/SZ AZL LHDI1OY3H
dOCEAZL
TYNDIS NHONL YV3H y
MPEAZL
HOLYIION) TYNDIS NYNL
(3AYY4) aNNOYO (O)
dOZEAZL
A ADB IVYNDIS NHNL LINOHA HE
INTA
Ti09 NOLLINDI nd MHYds
HILIMS
LINA 105
LAST dOLS LNOHA
HILIMS МОНО
HOLIMS
4
HILIMS T3A37 HO 185
OSALAIN
AYT34 YH3LHV1S
NIFTY50
FRONT STOP LIGHT OIL LEVEL
SWITCH IGNITION SWITCH
STATRTER
SWITCH
CDI UNIT
IGNITION COIL
SPARK PLUG
R. FRONT TURN SIGNAL
12V10W
O
GROUND (FRAME)
HEAD LIGHT 12V25W
R. REAR TURN SIGNAL
12V10W
gg
METER LIGHT
12V3.4W
STOP&TAIL LIGHT
12V18/5W
on !
L. REAR TURN SIGNAL
12V10W
1
iu TURN SIGNAL
METER RELAY
FUEL UNIT
O
HORN
REAR STOP
SWITCH TURN SIGNAL LIGHTING-HORN STARTER !
SWITCH MOTOR ALTERNATOR /
L. FRONT TURN SIGNAL ;
12V10W BI | BLACK Br | BROWN
| Y | YELLOW | O | ORANGE /
Bu| BLUE | Lb LIGHT BLUE í
G {GREEN | Ly LIGHT GREEN !
| В | RED P [PINK
LIGHTING SWITCH HORN SWITCH STATER SWITCH W | WHITE [Gr [GRAY
HI fal Ho | E sT | E
D | OO FREE FREE
e PUSH OO PUSH
0030Z—GK8—6300;ED
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
