DSC-W70

DSC-W70
DSC-W70
Cyber-shot® Digital Still Camera
Compact design, 7.2 megapixel performance. Sony Cyber-shot® DSC-W70 offers amazing value and performance -7.2 megapixels for big prints and tight crops, Carl Zeiss® 3X Optical zoom, High Sensitivity Mode, 58 MB Internal
Memory for capturing images in-camera, 2.5”1 LCD screen with on-screen Function Guide and Stamina® Lithium Ion
battery.
Step-up
New
7.2 Megapixel Super HAD™
CCD
Higher megapixels gives you
more detail and definition for
large prints and cropping in
on your subject. Sony’s
advanced Super HAD (Hole
Accumulated Diode) CCD
design allows more light to
pass to each pixel,
increasing sensitivity and
reducing noise.
Large 2.5"1 LCD Screen
The DSC-W70 has a bright
2.5” LCD screen for setting
up and viewing images -with a one touch “ Play”
button that makes it quick
and easy to view your
photos.
Simple Controls, Function
Guide
User-friendly controls and
simple on-screen Function
Guide text/icon display help
you set up camera functions
-- and you’ll have greater
creative freedom to adjust
color mode including
“Natural” for subtle colors
and “Rich” for more intense
colors), sensitivity, brightness
and image size.
High Sensitivity Mode
A new High Sensitivity Mode
(ISO 1000) allows you to shoot
with great results in low-light
conditions -- and Sony’s
original Clear RAW NR™
(Noise Reduction) image
processing technology helps
suppress the color noise that
can accompany highsensitivity shooting.
Carl Zeiss® 3X Optical/2X
Digital Zoom/6X Total Zoom
3X Optical Zoom helps the
DSC-W70 bring distant
subjects closer and lets you
frame shots for better
composition; Sony’s precision
2X Digital Zoom provides an
additional 2X magnification
to zoom in close without
jagged edges.
Stamina® Battery Power
With its powerful Lithium Ion
rechargeable battery, the
DSC-W70 can capture up to
3602 images -- enough for a
week of shooting. The
compact BC-CSG Battery
Charger is also supplied for
battery recharging on the go.
14X Smart Zoom™ Feature3
Sony's Smart Zoom feature
lets you magnify your subject
beyond the 3x optical zoom to 3.6x (5MP), 4.5x (3MP),
even 14x (VGA). By
intelligently cropping into the
central portion of the scene,
it avoids the image distortion
of other digital zooms.
Capture Images In-Camera
With 58 MB Internal Memory,
the DSC-W70 allows you to
shoot without a flash memory
card -- then transfer your
images to optional Memory
Stick™ Duo media, upload to
your computer or make prints
on your digital printer.
Memory Stick Duo™ Media
The DSC-W70 has a built-in slot
for optional Memory Stick
Duo™ or higher-capacity
Memory Stick PRO Duo™
media -- the ultra compact
media for shooting, storing
and sharing your photo
images.
DSC-W70
Cyber-shot® Digital Still Camera
Specifications
Optics/Lens
General
Focal Length: 6.3 -18.9mm
35mm Equivalent: 38 - 114 mm
Focus: 5 Area Multi-Point AF, Center AF
Focal Distance: 4-3/4" (12 cm) (W), 193/4" (50cm) (T)
Aperture Range: f2.8-7.1(W), f5.2-13(T)
Shutter Speed: 1/8-1/2000 sec. (Auto),
1-1/2000 sec. (Program Auto)
Exposure Compensation: ±2.0 EV, 1/3
EV Step Increments
ISO: Auto, 100, 200, 400, 800, 1000
Filter Diameter: 30mm (with VAD-WB
Adapter Ring)
Smart Zoom® Technology: Up to 3.6X
(5MP), 4.5X (3MP), 5.6X (2MP), 14X
(VGA Resolution)3
Digital Zoom: 0-2.0X (Precision)
Optical Zoom: 3X
Macro Mode: Yes
Total Zoom: 6X
Minimum Focus Distance: 19.7" (50cm)
Normal, 0.74" (2cm) Macro
Megapixel: 7.2 MP
Imaging Device: 1/2.5" Super HAD™
CCD
Recording Media: 58MB1 internal Flash
Memory, optional Memory Stick™
DUO Media, optional Memory Stick
DUO PRO™ Media
Convenience
White Balance: Automatic, Cloudy,
Daylight, Fluorescent, Incandescent,
Flash
Self Timer: Yes (10 seconds, 2 seconds,
Off)
Memory Stick PRO™ Media
Compatibility: Tested to support up
to 2GB Memory Stick DUO PRO
TM
media capacity; does not support
Access Control security function.
Still Image Mode(s): Burst, JPEG
(Fine/Standard), Multi-Burst
Red-Eye Reduction: Yes (On/Off, all
modes)
Burst Mode: 4 Shot at 1.11 fps (7.2MP
JPEG fine), 100 Shot VGA at 1.25 fps
(JPEG std.)
Erase/Protect: Yes/Yes
Date/Time Stamp: No/ No
Media/Battery Indicator: Yes/Yes
Color Mode(s): Black & White, Natural,
Rich, Sepia
Convenience Features
Power
Battery Type: Lithium-Ion NP-BG1
Battery Capacity: 3.6V, 960 mAh
Software
Supplied Software: Cyber-shot® Viewer
Vers 1.0 + USB Driver, (Windows®)
Operating System Compatibility:
Microsoft® 2000 Professional, Me, XP
Home and Professional; Macintosh®
OS 9.1/9.2/OS X (10.0-10.4)
Real Imaging Processor™ Technology:
Yes
AF Illuminator Light: Yes
PictBridge Compatible: Yes
Multi-Pattern Measuring: Yes, 49segment
SteadyShot® Image Stabilization: N/A
Clear RAW NR: Yes
Scene Mode(s): Beach, High Sensitivity,
Landscape, Snow, Soft Snap,
Twilight, Twilight Portrait
Movie Mode(s): MPEG VX Fine with
Audio (640x480 at 30fps) (MPEG VX
Fine requires Memory Stick DUO
PRO™ media), MPEG VX Standard
with Audio (640x480 at 16fps), Video
Mail with Audio (160x112 at 8fps).
Power Save Mode: Yes (after approx. 3
min. of inactivity)
Dimensions
Inputs and Outputs
Optional Accessories
Weight: 4.7 oz (127 g) Body; 5.8 oz.
(157 g) including Battery and
optional Memory Stick™ DUO Media
Measurements: 3 1/2" x 2 1/4" x
7/8" (89 x 57 x 23 mm)
Service and Warranty Information
Limited Warranty Term: 1 Year Parts &
Labor
Supplied Accessories
NP-BG1 rechargeable battery
BC-CSG battery charger
A/V and USB multi-connector cables
Wrist strap
Software CD-ROM
Note: No Memory Stick® DUO media or
adaptors are included.
Accessory Kit (ACC-CLG)
Rechargeable Lithium-Ion Battery (NPBG1)
Travel Charger (BC-TRG)
AC Power adaptor (AC-LS5K)
Hardware
Soft Carrying Case (LCS-WE)
LCD: 2.5"1 (115K Pixels TFT LCD Screen)
Soft Carrying Case (LCJ-WF)
Viewfinder: Optical
Conversion Lens Adaptor Mount (VADLens Construction: 6 Elements in 5
WB)
Groups, 3 Aspheric Elements
Wide Angle Conversion Lens (VCLMicrophone/Speaker: Yes/ Yes
DH0730)
Lens Type: Carl Zeiss® Vario-Tessar®
Telephoto Conversion Lens (VCLDH1730)
Docking Station: N/A
Super Telephoto Conversion Lens (VCLOperating Conditions
1: Viewable area, measured diagonally
DH2630)
2: Under average conditions; when fully charged, actual results may vary based on camera settings
Flash Effective Range: ISO Auto: 7-7/8”
and conditions of use.
Polarizing Kit Filter (VF-30CPKS)
to 12' (0.2-3.7m)(W), ISO 1000: 6” to
3: Smart Zoom® feature will not work at highest resolution setting.
External Slave Flash w/Bracket (HVL4: Not all products with USB connectors may communicate with each other due to chip-set variations
21’ (0.2-6.5m)(W)
FSL1B)
5. A portion of the memory is used for data management purposes.
Flash Mode(s): Auto, Forced On, Forced
Sony, Cyber-shot, Handycam, Memory Stick, Memory Stick PRO, Memory Stick PRO Duo, , Super HAD,
Memory Stick Duo PRO™ (MSX-M512S)
Off, Slow Synch, Daylight Fill
Clear RAW, Smart Zoom, Stamina, Trinitron and Walkman are trademarks of Sony. All other
Memory Stick Duo PRO™ (MSX-M1GN)
trademarks are trademarks of their respective owners.
Memory Stick Duo PRO™ (MSXPlease visit the Dealer Network for more information at
M2GN/GS)
www.sony.com/dn
Memory Stick Duo PRO™ (MSX-M4GS)
Sony Electronics Inc. •16530 Via Esprillo •San
Diego,Stick
CA 92127
•1-800-222-7669
Last Updated: 03/12/2009
Memory
Duo PRO™
(MSX-M8GS)•www.sony.com
Memory Stick Duo Adaptor (MSAC-M2)
Memory Stick Duo USB Adptr (MSACAccessory Terminal: N/A
Audio/Video Output(s): Yes via MutliUse Connector
USB Port(s): Yes (Supports USB 2.04 )
