ORCA-4K HARDWARE MANUAL
299-433-104
Sixth Edition (January 2007)
This edition applies to the Nuera Communications, Inc. ORCA-4K gateway. The licensed
product described in this document and all licensed materials that are available for it are provided by Nuera under terms of the agreement for Nuera licensed products. Nuera periodically
makes additions, deletions, or changes to the information in this document. Before you use
this document, consult Nuera or your distributor for the most recent Nuera edition.
The author and publisher have made reasonable efforts to ensure the accuracy and timeliness
of the information in this book. However, neither the author nor the publisher shall have any
liability with respect to loss or damage caused or alleged to be caused by reliance on any information in this book.
Nuera may have patents or pending patent applications covering material in this document.
Furnishing this document does not of itself constitute a grant of any license or immunity
under any patents, patent applications, trademarks, copyrights, or other rights of Nuera, or of
any third party, or any right to refer to Nuera in any advertising or other marketing activities. Nuera assumes no responsibility for any infringement of patents or other rights of third
parties that may result from use of the material in this document or for the manufacture, use,
lease, or sale of machines or software programs described herein, outside of any responsibilities assumed in the original or subsequent purchase or lease agreements.
This document may contain information about, or make reference to, Nuera products, programming, or services that are not available in your country. This information must not be
construed to mean that Nuera intends to make available such products, programs, or services
in your country.
A form for your comments is provided at the back of this document. If the form has been
removed, address your comments to: Nuera Communications, Inc., Professional Services,
10445 Pacific Center Court, San Diego, CA 92121.
Nuera may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.
No part of this publication may be reproduced in any manner without the written permission
of Nuera, Inc. For information, write to: Nuera Communications, Inc., Legal Office, 10445
Pacific Center Court, CA 92121.
© 2007 by Nuera Communications, Inc.
All rights reserved
ORCA-4K Hardware Manual
2
Warranty
Nuera's standard warranty is one year from the date of shipment and is verified by
serial number of the system. Any defective component will be replaced or repaired at
no charge during this period. If any equipment fails within the first 90 days of shipment, an advance replacement will be sent or on-site repair performed at Nuera's discretion, at no charge. After that period, and for the reminder of the warranty,
defective modules will be repaired at Nuera and then returned to the customer.
Once the warranty has expired, the components can either be returned to Nuera for
repair, or an advance replacement can be provided. The repair and advance replacement pricing are described in the Nuera Global Pricelist and Configuration Guide.
In order to exercise your rights to repair under this warranty, you must first contact
Nuera to obtain a Repair Material Authorization (RMA) number. If you must return
the unit to Nuera for repair while the unit is under warranty, Nuera will pay the cost
of shipping it to and from Nuera.
Software License Agreement
Each software Product, including any documentation relating to or describing such
Software, provided by Nuera (hereinafter collectively called "Software") is furnished
to you under a nonexclusive, nontransferable license solely for your own use only on
the single processor on which the Software is first installed. The Software may not be
copied, in whole or in part, except for archival purposes, to replace a defective copy, or
for program error verification.
You may not reverse engineer, decompile, or disassemble the Software, except to the
extent such foregoing restriction is expressly prohibited by applicable law.
The term of each paid-up license shall expire at such time as you discontinue use of
the applicable Software on the single processor specified above but otherwise shall be
without restriction as to time.
The Software (including any images, applets, photographs, animations, video, audio,
music, and text incorporated into the Software) is owned by Nuera or its suppliers
and is protected by United States copyright laws and international treaty provisions.
ORCA-4K Hardware Manual
3
Therefore, you must treat the Software like any other copyrighted material (for
example, a book or musical recording) except that you may either (a) make one copy
of the Software solely for backup or archival purposes, or (b) transfer the Software to
a single hard disk provided you keep the original solely for backup or archival purposes. You may not copy the printed materials accompanying the Software.
ORCA User Library
All books that support the ORCA product line are provided on a compact disc (CD) in
Adobe Acrobat format. Included on the CD is the appropriate version of Adobe Acrobat Reader.
This section lists the titles of all the books in the ORCA library. To order any of these
books, contact your distributor or Nuera directly. To make comments or suggestions
regarding any of these books, direct your correspondence to [email protected]
Number
Book
299-225-4nn
ORCA SSC Softswitch User’s Guide
This guide presents conceptual information about the use and functionality of the ORCA
SSC Softswitch. It also provides information about installing and configuring SSC for use
with other equipment.
299-193-5nn
ORCA GX-Series Software Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA GX gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA GX gateway correctly configured
using network management software.
299-297-5nn
ORCA RDT-8g Software Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA RDT-8g gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA RDT-8g gateway correctly configured using network management software.
299-298-5nn
ORCA RDT-8v Software Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA RDT-8v gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA RDT-8v gateway correctly configured using network management software.
ORCA-4K Hardware Manual
4
Number
Book
299-252-5nn
ORCA BTX-Series Software Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA BTX gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA BTX gateway correctly configured using network management software.
299-335-1nn
ORCA Gateway Hardware Manual
This manual presents conceptual information about the use, functionality, and specifications of the ORCA 21-slot and 8-slot gateways, including installation steps and information.
299-433-1nn
ORCA-4K Hardware Manual
This manual presents conceptual information about the use, functionality, and specifications of the ORCA-4K gateway, including installation steps and information.
299-432-5nn
ORCA ORCA-4K Application Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA ORCA-4K gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA ORCA-4K gateway correctly configured using network management software.
299-442-5nn
ORCA UMX-4K Application Manual
This manual is designed for the system integrator/system administrator who needs to configure ORCA UMX-4K gateways at an end-user site. Its purpose is to guide this individual
through the configuration steps required to get the ORCA UMX-4K gateway correctly configured using network management software.
299-434-4nn
NetConductor User’s Guide
This guide presents conceptual information about the use, functionality, and specifications
of the NetConductor application, including installation steps and information.
Additional ORCA books are available in PDF format from Nuera’s website,
http://www.nuera.com. For information regarding pricing and availability, contact a
sales representative at:
Nuera Communications, Inc.
10445 Pacific Center Court
San Diego, CA 92121
858-625-2400
ORCA-4K Hardware Manual
5
Trademarks Used in This Manual
The following list contains trademarks that are used in this manual. In the United
States, these trademarks are registered trademarks; in World Trade countries, these
trademarks are not registered.
Trademark
Trademark Owner
ORCA-4K
Nuera Communications, Inc.
Adobe Acrobat
Adobe Systems Inc.
ANSI
American National Standards Institute
Procomm Plus
Symantec Corporation
PacketCable
Cablelabs
ORCA-4K Hardware Manual
6
TABLE
OF
CONTENTS
About This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Who Should Use This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Conventions Used in This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes, Cautions, and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
How Numbers Are Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replaceable Input Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 2. Chassis and Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chassis Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chassis Front View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chassis Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 3. Gateway Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Voice Processing Module (VPM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Redundancy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Gigabit Ethernet Transceiver and LC Style Optical Connector . . . . 20
VPM Sub-Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Media Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
DS3 Connector Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Optical Connector Module (OCM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Rear Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
BITS Clock Module (BCM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Alarm Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 4. Installing the Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installing the Chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Connecting Main Power and Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Chapter 5. Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
The Craft Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Craft Port Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Password Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
ORCA-4K Hardware Manual
7
Help Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
DS3 Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Ethernet Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
CallPro Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Ping Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SNMPCFG Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SNMP Community String Commands. . . . . . . . . . . . . . . . . . . . . . . . . 40
TDM Connection Type Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
VPMReset Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Version Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Quit Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Storage Initialization Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Chapter 6. Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Gateway Status Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
VPM LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
OCM LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Fan Tray LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Maintenance Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chassis Intake/Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Hot-Swapping a Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
VPM Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Hot Swapping a VPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Swapping a VPM Between Gateways . . . . . . . . . . . . . . . . . . . . . . . . . 47
DSP Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
OCM Card Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
OCM Card Removal (Hot Swap) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rear Module Installation and Removal (Hot Swap) . . . . . . . . . . . . . . 49
Gateway Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Software Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Capacity Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Chapter 7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
System LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
VPM Status LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
VPM/DS3 Interface LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
VPM/Optical Interface LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
VPM Ethernet Interface LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
OCM LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Fan Tray LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
System Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Alarm Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Appendix A. Parts and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
ORCA-4K Hardware Manual
8
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Replacement Modules and Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Appendix B. Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Emissions and Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Environmental and EMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
ORCA-4K Hardware Manual
9
ABOUT THIS BOOK
This book presents information on the system design and operation of the Open Reliable Communications Architecture (ORCA) telephony 4K gateway. The purpose of
this information is to help you install, use, and maintain the ORCA-4K gateway.
WHO SHOULD USE THIS BOOK
This book is for product distributors, systems integrators, systems analysts, and network administrators who design, install, configure, and maintain wide area networks
(WANs) and large-scale communications applications. It contains conceptual and
practical information about how to use the ORCA-4K gateway within your network.
CONVENTIONS USED IN THIS BOOK
This book uses specific conventions to show the following types of information:
•
Number usage
•
Replaceable input values
•
Messages
Read the following sections to learn more about how this information is shown in the
rest of the book.
Notes, Cautions, and Warnings
Notes show useful information and/or contain information requiring attention.
Cautions show information requiring extra attention.
ORCA-4K Hardware Manual
10
Warnings are information that, if not followed, could result in injury or
equipment damage.
How Numbers Are Used
When numbers are shown in this book, they can appear as descriptive values or as
data to be manipulated internally. Decimal values are used frequently; however,
alternate number bases are useful when internal data is shown.
Large Decimal Numbers
Numbers greater than 9999 display in SI metric style, where whole numbers that
contain more than four digits are broken into groups of three digits that are separated by spaces. For example, the number sixteen thousand three hundred eighty
three is shown as 16 383. This avoids confusion between American and European
punctuation conventions. However, a number that is internally manipulated by a
computer is shown without punctuation or spaces. For example, notice how the value
65 535 appears in the following instruction without a space or a thousands separator
within the number:
Specify 65535 as a maximum value
Numbers with Different Bases
All numbers shown in this book are decimal values unless the number base is binary
or hexadecimal. In these cases, an identifier precedes a binary or hexadecimal number. For example:
•
the value of binary 1010
•
the value of hex 4F
Replaceable Input Values
In some cases, you can insert user-defined values into commands or you can specify
local paths and filenames. These variable values are shown in italic typeface.
For example, you might be asked to specify the name of your server in this path:
A:\LOGIN\LOGIN servername
ORCA-4K Hardware Manual
11
The italic typeface shows that you need to replace servername with your local server
name.
When prompted for variable input represented by lower-case letters, follow these conventions:
When You See This
Substitute This Value
b
Any binary digit
h
Any hexadecimal digit
n
Any decimal digit
x
Any alphabetic value, such as:
x:\DOS
where you substitute the correct drive letter
for x
Multiple letters
A series of digits, such as:
FIRST 2 HEX BYTES: hhhh
where you substitute four hexadecimal digits for hhhh
When prompted for variable input with embedded decimal points, replace the variable digits and let the decimal points remain to separate 32-bit dotted-decimal
address segments. For example, you might be prompted to supply a 32-bit, dotteddecimal address in this format:
nnn.nnn.nnn.nnn
where nnn is a decimal value from 0 through 255. Leading zeros are not required.
GETTING HELP
If, after installing and configuring your Nuera equipment, you cannot establish communications to or from the unit, carefully review the information in this book and in
the other ORCA books prior to calling Technical Assistance Center (TAC).
Before going any further, ensure that you have checked the following:
ORCA-4K Hardware Manual
12
•
Console Port configuration. Verify that the baud rate of your terminal is set to
9600 bps.
•
Power reset. When cycling power, be sure to leave the power off for a minimum of
30 seconds before reapplying power to the unit.
•
Command review. Review the gateway commands in Chapter 5,Configuration.
•
Software version. To ensure that our customers have the latest enhancements
and product features, Nuera ships every new or factory-upgraded unit with the
latest software version. Therefore, whenever you are installing or reinistalling
units into your system check each unit to verify that all units are equipped with
identical software versions.
Checklist
If, after carefully reviewing the information in this book and in the other ORCA
books, your problem persists, contact your product representative or a service representative at Nuera’s Technical Assistance Center. So we can serve you better, make a
list of the following items before calling:
•
A detailed description of your problem.
•
A complete listing of your system components and configuration, including the
serial number of your unit and the current software version number.
•
A narrative of the actions you performed prior to the problem.
•
A list of all system messages posted by your unit.
Contacts
Address:
Nuera Communications, Inc.
10445 Pacific Center Court
San Diego, CA 92121 USA
[email protected]
www.nuera.com/support/
Telephone:
1-858-625-9220, extension 1391
1-800-966-8372, extension 1391
ORCA-4K Hardware Manual
13
1
INTRODUCTION
This chapter presents a high-level introduction to the ORCA-4K gateway hardware
platform. The ORCA-4K gateway provides high-density voice transmission that
enables high-quality, cost-efficient telecommunications VoIP service.
Overview
Nuera's ORCA-4K (Open Reliable Communications Architecture) product is designed
to bridge the gap between traditional, circuit-based Public Switched Telephone Networks (PSTNs) and the emerging packet-switched networks. The ORCA-4K provides
an excellent solution for merging digital broadband access networks with the legacy
telephone network in a seamless, reliable manner.
Design
This section presents high-level information about the design philosophy of the
ORCA-4K platform. It has been designed to serve carrier-grade environments that
require:
•
High availability with redundancy
•
High scalability
•
Hot-swap capability
•
NEBS compliance
ORCA-4K Hardware Manual
14
Introduction
High-Reliability
The ORCA-4K’s robust platform provides sufficient fault tolerance and redundancy to
guarantee high availability. Because ORCA-4K carries large amounts of revenue-producing voice traffic, hardware or software faults are contained and not permitted to
affect other system resources.
The ORCA-4K design includes full 1+1 redundancy for all control, signaling, and
voice processes in the system.
Scalability
Depending on the application, the ORCA-4K can support up to six DS3s, two STM-1,
or two OC-3 of packetized voice. Please refer to the specific application manual for the
exact number of voice channels supported.
Hot-Swap Capability
The ORCA-4K modules are hot-swapable in the event of a physical failure. These
modules require no special tools or training to perform a field replacement.
NEBS Compliance
The ORCA-4K product complies and is certified to the Network Equipment Building
System (NEBS) Level-3, Zone 4 requirements.
ORCA-4K Hardware Manual
15
2
CHASSIS
AND
COMPONENTS
This chapter presents the functional architecture of the ORCA-4K gateway. It introduces the major gateway components, their functions, and inter-activities.
The ORCA-4K chassis consists of a fault-tolerant fan tray, dual -48VDC inputs and
front and rear modules that are hot-swappable and field replaceable. The modules
are separated by a midplane which is functionally equivalent to a backplane. The
front module is the Voice Processor Module (VPM). It is active (that is, it has powered
circuitry), redundant and provides an optical Gigabit interface. When the Optical
Connector Modules (OCM) are present above the top VPM, the ORCA-4K is capable
of OC-3 (SONET) or STM-1 (SDH). The rear modules are the Bits Clock Module
(BCM), DS3 Connector Module and Alarm Module. The ORCA-4K includes a mixture
of active and passive (no active circuitry) modules. Some of these modules are redundant (such as the BCM) and others are shared by the VPM and gain redundancy
internally through the midplane (DS3 Connector and Alarm Modules). All metallic
interfaces linking the system to the network are located on the rear modules. The
OCM and DS3 Connector Modules are system-dependent and are not present in
every system.
For more information on the ORCA-4K gateway modules, see "Gateway Modules" on
page 19.
ORCA-4K Hardware Manual
16
Chassis and Components
Chassis Overview
Dimensions
The ORCA-4K chassis is three rack units (3RU) high, or 5.25 inch (13.3 cm) high x
17.5 inch (44.5 cm) wide x 22 inch (49.5 cm) deep. It can be front or center mounted on
an Electronics Industry Association (EIA) standard 19 inch relay rack or optionally,
on a 23 inch relay rack when extended mounting ears are purchased, see "Replacement Modules and Components" on page 58.
Weight
The ORCA-4K chassis weighs ~ 33 lbs. (15 kg).
Fan Tray
The ORCA-4K chassis contains a fault-tolerant fan tray with 12 high reliability tubeaxial fans. The tray is hot-swappable, located on the left side of the chassis and capable of sufficiently cooling the system modules within an operating temperature range
of 5 to 50° C (23 to 122° F).
The system is capable of monitoring the fan tray performance and in the event of a
fan or fan tray failure, will generate an alarm. Although, the system will continue to
operate within acceptable temperature limits with up to three failed fans, it is recommended the user replace the entire fan tray as soon as possible. The gateway will also
operate for up to 20 minutes (at ambient temperature) without a functioning fan tray,
but this is not recommended. A failed fan tray should be replaced immediately. Since
the fan tray is hot swappable, the new fan tray can be installed while the gateway is
running, thereby restoring full cooling capacity.
Chassis Front View
Figure 1 shows the front view of an ORCA-4K chassis gateway with the front cover
removed. The fan tray is located on the left of the chassis. The module slots are numbered from the bottom up:
•
Slot 3B: OCM Module
•
Slot 3A: OCM Module
•
Slot 2: VPM
•
Slot 1: VPM
ORCA-4K Hardware Manual
17
Chassis and Components
Figure 1. ORCA-4K Gateway Chassis, Front View (cover removed)
Chassis Rear View
Figure 2 shows the rear view of an ORCA-4K chassis.
The rear modules and components are listed below:
•
DS3 Connector module (1, 2, 3)
•
DS3 Connector module (4, 5, 6)
•
BCM (1) associated with the VPM in slot 1
•
BCM (2) associated with the VPM in slot 2
•
Alarm Module
•
-48VDC Terminal block and Circuit Breaker (A and B)
•
ESD jack
•
Ground Lug
Figure 2. ORCA-4K Gateway, Rear View
ORCA-4K Hardware Manual
18
3
GATEWAY MODULES
This chapter describes the function, features, and hardware connections of the
ORCA-4K gateway modules.
Voice Processing Module (VPM)
This section describes the VPM’s installed in the front of the chassis. The VPM acts
as the host cluster and the voice processor.
Redundancy
The ORCA-4K gateway is designed to allow for distributed execution of control and
processes to minimize service loss due to potential failures. In the event of a failure,
the VPM can be removed and replaced (hot-swapped), thereby, permitting the gateway to continue to function.
The ORCA-4K gateway design provides for two VPMs; one is a hot standby for the
other. In normal operation, the active VPM monitors the operational status of the hot
standby VPM and the hot standby VPM monitors the status of the active VPM.
In the event of a failure, the ORCA-4K gateway sends a trap alarm to the Nuera NetConductor EMS and then switches control to the standby VPM, thereby maintaining
service. The switchover process takes ~ 50 milliseconds, and there is no loss of stable
calls.
The ORCA-4K gateway then continues operation under control of the other VPM,
until a failure again initiates a switchover. This can also be activated by issuing the
appropriate command from the Nuera NetConductor EMS.
ORCA-4K Hardware Manual
19
Gateway Modules
After a switchover, the now inactive VPM can be diagnosed via the Nuera NetConductor EMS.
Gigabit Ethernet Transceiver and LC Style Optical Connector
The gigabit optical ethernet transceiver as shown in Figure 3 is located on the VPM.
The gigabit serial optical transceiver is compliant with the Fiber Channel, 100-M5/
M6-SN-I and Gigabit Ethernet 1000 Base-SX standards. This transceiver features a
high reliability, 850 nm, High Speed, Oxide VCSEL Laser coupled to a LC optical
connector. This transceiver meets Class 1 laser eye safety requirements. It has GBIC
functionality in 1/2 the width. The transceiver complies with the Small Form Factor
Plug (SFP).
You must provide the optical fiber and LC style optical connector to connect to the
VPM transceiver.
Eye Safety: The LC Series Optical Transceiver on the VPM is an international Class 1 laser product per IEC 825-1: 1993, and per CDRH, 21 CFR
1040 Laser Safety Requirements. The transceiver is an eye safe device when
operated within the limits of this specification. Operating this product in a
manner inconsistent with intended usage and specification may result in hazardous radiation exposure.
Tampering with this laser based product or operating this product outside the
limits of this specification may be considered an act of “manufacturing,” and
will require, under law, recertification of the modified product with the U.S.
Food and Drug Administration (21 CFR 1040). The use of optical instruments with this product will increase eye hazard. At the normal operating
current, optical output power with an unaided eye can be as much as 30 uW
at a wavelength of 850 nm. Approximately ten times this power level could
be collected with an eye loop. Under a failure condition, this level could
increase by a factor of two.
ORCA-4K Hardware Manual
20
Gateway Modules
Figure 3. VPM LC Series Optical Transceiver (front view)
VPM Sub-Modules
The VPM contains a number of sub-modules, each assigned a separate processing
task.
With exception of the DSP module: VPM sub-modules are not field replacable. In the event of a suspected VPM sub-module failure, the entire VPM
should be returned. Removal of sub-modules may void your warranty.
Network Processor (NP) Module
The NP module routes all packet traffic into and out of the system, as well as
between the internal boards. This module is not field serviceable.
DS3 Daughter Board (DS3DB)
This card is only installed on VPMs labeled VPM/DS3. The DS3 daughter board
handles the terminations for the DS3 interfaces and distributes traffic to the
DSPs. This module is not field serviceable.
OC3 Daughter Board (OC3DB)
This card is only installed on VPMs labeled VPM/Optical. The OC3 daughter
board handles the terminations for the optical interface (OC-3 or STM-1) and distributes traffic to the DSPs. This module is not field serviceable.
Digital Signal Processor (DSP) Modules
The DSP modules are the payload processors. They are responsible for processing,
encryption, and packetization of the traffic on the voice channels within the
ORCA-4K gateway. These modules are field serviceable and upgradeable.
ORCA-4K Hardware Manual
21
Gateway Modules
Media Interface Modules
The ORCA-4K Media Gateway can be configured for either metallic DS3 interfaces or
optical (OC-3 or STM-1) interfaces. A ORCA-4K is said to be configured as metallic
DS3 if the VPM cards are of type “DS3”, which means they have a DS3DB_MODULE
installed. An “Optical” VPM card has an OC3DB_MODULE installed and is said to
be configured as optical OC-3 or optical STM-1. NetConductor automatically
adapts to the configuration of your ORCA-4K. For example, if it detects a ORCA-4K
configured for metallic DS3 interfaces then you will see DS3 interfaces in the inventory of your Network Element (instead of OC-3 or STM-1).
DS3 Connector Module
The DS3 Connector Module, as shown in Figure 4, provides TX/RX connections for
the DS3 lines. There are two DS3 Connector Modules per gateway, each providing
three DS3s of connectivity. DS3 redundancy is achieved through internal DS3 circuitry that duplicates the signals from each incoming DS3 link and sends identical
information to each VPM.
Figure 4. DS3 Front Panel Connections
Interfaces and Specifications
The DS3 Connector Module (two per system) has the following interfaces and specifications:
•
Three RX BNC ports
•
Three TX BNC ports
•
Line Code: B3ZS only
•
Line Rate: 44.736 MB/s
•
Termination: 75 Ohm
•
Line Type (framing): M13 or C-bit Parity
•
Line Length: short (0 to 68 m), and long haul
ORCA-4K Hardware Manual
22
Gateway Modules
Optical Connector Module (OCM)
The OCM card hardware supports both OC-3 (SONET) and STM-1 (SDH) applications. Optical units are configured for OC-3 (SONET) at the factory at the time of
order/shipment. Each OCM interfaces is 1+1 redundant, unidirectional and has nonrevertive protection switching. Viewed from the front, as shown in Figure 5, the OCM
interface on the left is designated Working, while the interface on the right is Protect.
•
When configured for OC-3 (SONET) the interface enables interconnection to optical
networks as defined by GR-253-CORE from Telcordia. In this case, the system can be
configured to transport as many as 4,032 DS0s via 2 OC-3 level 1 payloads.
•
When configured for STM-1 (SDH) the interface enables interconnection to the
synchronous optical networks using the ITU-T standards. In this case, the system
can be configured to transport as many as 3,906 DS0s via 2 STM-1 (Synchronous
Transport Module, level 1) payloads.
Figure 5. OCM Card
Interfaces and Specifications
Optical Transmitter
•
Eye Pattern Pulse Shape in G.957 section 6.2.5.
•
Spectral characteristics: maximum RMS width of 7.7 nm.
•
Mean launched power: -8 dBm maximum, -15 dBm minimum.
•
Minimum extinction ratio: 8.2 dB
Optical Path
•
Attenuation range: 0-12 dB
•
Maximum dispersion: 96 ps/nm
Optical Receiver
•
Minimum sensitivity: -28 dBm
•
Minimum overload: -8 dBm
ORCA-4K Hardware Manual
23
Gateway Modules
•
Maximum optical path penalty: 1dB
Rear Modules
The rear modules, or transition cards, provide all of the metallic interfaces to equipment outside of the unit.
BITS Clock Module (BCM)
The BCM routes system reference clocking to both VPMs via the Bits Clock port (RJ
or BNC). This redundant card provides the 100 Base-T Ethernet Control and Craft
DB9 interfaces as shown in Figure 6. The 100 Base-T Ethernet port is IEEE 803.2
compliant.
Interfaces
The BITS Clock Module includes four interfaces:
•
Craft port, available for basic unit configuration through a DB9 (M) connector.
RS232 electrical levels are supported for this port.
•
100 Base-T Ethernet port for SNMP and signaling traffic that is separate from
the IP media traffic.
•
120 ohm (RJ, used for T1 or E1) BITS clock input
•
75 ohm (BNC, used for E1) BITS clock input
Figure 6. BCM Ports
Alarm Module
The Alarm module reflects the major and minor alarm state of the system with contact closures (both normally open and normally closed).
ORCA-4K Hardware Manual
24
Gateway Modules
Connection Requirements
The alarm port, as shown in Figure 7, is connected through a terminal block and provides four output closures (minor normally open, minor normally closed, major normally open, major normally closed). The alarm contacts are rated at 350 V peak, 130
mA maximum.
Figure 7. Alarm Module Port
The following table describes these pins:
Table 1:
Pin #
Label
Normal State
1
Minor Alarm
Open
2
Minor Alarm
Closed
3
Major Alarm
Open
4
Major Alarm
Closed
5
Not used
n/a
6
Common Alarm Return
n/a
ORCA-4K Hardware Manual
25
4
INSTALLING
THE
CHASSIS
The installation of the ORCA-4K gateway requires a few simple tasks.
Site Preparation
Power Input
You will need -48 VDC nominal (42 to 60 VDC), 5A minimum per gateway. Nuera recommends that a qualified professional determine the appropriate wire gauge based
on the distance from the power source and the power input requirements.
Redundant Power Feeds
Nuera recommends redundant power feeds from separate power sources to ensure
the continuous operation of the gateway. This ensures proper operation of the gateway in the event of a power loss from one of the sources.
Airflow and Thermal Cooling Requirements
The ORCA-4K gateway is equipped with a fan tray for cooling the system modules.
The air intake is located on the right side (as viewed from the front) and the exhaust
vents are located on the left and left-rear of the chassis. To prevent overheating, the
air intake must not be obstructed. After installation of the gateway, you should avoid
installing other equipment that exhausts hot air directly into the ORCA-4K air
intake.
ORCA-4K Hardware Manual
26
Installing the Chassis
The gateway produces heat at a maximum of 854 BTU/hr. The facility air conditioning system must be capable of handling the heat load to reduce the ambient air temperature to an acceptable level for proper operation.
Space Allocation Guidelines
The gateway can be installed in a 19 or 23 inch EIA standard open relay rack. Nuera
can supply a 23 inch rack adapter, if necessary. See “Replacement Modules and Components” on page 58. An enclosed cabinet is not recommended unless it can provide
sufficient cooling capacity to dissipate 854 BTU/hr per gateway.
Chassis Mounting Guidelines
The chassis can be flush or mid-mounted. A single gateway requires 5.25 inches (3RU
or 133.35 mm) of vertical rack space, 22 inches (558.8 mm) of rack depth and weighs
approximately 33 lbs (15 kg).
Redundant BITS Clock Inputs
Nuera recommends redundant BITS Clock inputs derived from a Stratum 1 timing
source to ensure a continuous clocking source and guard against timing slips on the
TDM interfaces. The BITS clock input is located on the BITS Clock Module.
100 Base-T Ethernet Connections
The ORCA-4K only supports full-duplex mode on the 100 Base-T Ethernet ports.
Autonegotiation is not supported. You must configure the remote switch to auto negotiation off, full-duplex mode.
1000 Base-SX Ethernet Connections
The ORCA-4K does not support autonegotiation on the 1000 Base-SX Ethernet ports.
You must configure the remote switch to autonegotiation off, full-duplex mode. Use
the optical cable guide lances on the front of the chassis to secure the 1000 Base-SX
Ethernet optical (fiber) cable from the VPMs.
The 100Base-Sx Ethernet optical cables can be pinched or damaged if they
are not secured to the chassis guide lances using a nylon tie-wrap when
installing the front cover.
ORCA-4K Hardware Manual
27
Installing the Chassis
Figure 8. ORCA-4K Gateway Chassis Optical Cable Guide Lances
DS3 Connections
You should be prepared with the proper length 75 ohm DS3 cables prior to connecting
to the remote DS3 equipment. If necessary, these can be purchased from Nuera. Also,
you should confirm the line type used by the DS3 equipment needed to configure the
gateway via the Nuera NetConductor EMS.
Optical Connections
You should be prepared with the proper length single mode fiber optic cable. The
cable must also be compatible with the Small Form Factor Pluggable (SFP) MultiSource Agreement (MSA) transceiver with LC connectors and support OC-3
(SONET)/STM-1 (SDH). The optical wavelength is 1300 nm and the transceiver is
intended for IR (less than 15 km) operation. Also, you should confirm the width setting used by the OC-3 (SONET) or STM-1 (SDH) equipment needed to configure the
gateway via the Nuera NetConductor EMS.
ORCA-4K Hardware Manual
28
Installing the Chassis
Installing the Chassis
The ORCA-4K is shipped in a protective carton to prevent damage during shipping.
The shipping carton contains the following items:
•
ORCA-4K gateway chassis (with modules installed)
•
Aesthetic front cover
•
Cable assemblies (optional)
•
ORCA-4K gateway documentation and software on CD
To install the chassis:
1. Remove the ORCA-4K chassis from its shipping carton.
2. The ORCA-4K chassis is shipped with its rack mount ears positioned for front
(flush) mounting. To change the mount position of the chassis, use a #2 Phillips
screwdriver to remove the three #8-32 screws affixing each rack mount ear. Reposition the rack mount ears to the desired mount position. Replace all screws.
3. Lift the chassis into the rack so that the chassis mounting ears are aligned with
the rack holes. Partially install one rack screw in the bottom corner of each side
for the keyhole cutouts. Set the chassis over the partially installed rack screws,
then install the remaining rack screws (rack screws not provided).
4. For racks with equipment shelves installed, lift the ORCA-4K chassis and position it on the shelf.
5. Snap the aesthetic cover onto the front of the chassis.
Connection to the -48 VDC power source must be made with the appropriate
wire gauge based on the power input requirements and the distance of the
wire from the power source. Nuera recommends that a qualified professional
determine the wiring and installation requirements for the site.
ORCA-4K Hardware Manual
29
Installing the Chassis
Connecting Main Power and Ground
The ORCA-4K gateway is configured for DC power. Nuera recommends that your
installer provide two independent fault current protected -48 VDC power feeds. The
DC power feeds should be fault current protected at 5A minimum.
Installation must be performed by a qualified professional who is skilled in
the installation and connection of power distribution systems, and is knowledgeable of applicable municipal electrical code requirements.
Before connecting the DC power mains, a separate ground strap (which is
connected to a centralized ground network in the installation site) must be
connected to the ground terminal at the rear of the chassis. The strap used for
this purpose must be 14 AWG or larger. A ring tongue terminal for a #10
stud must be securely crimped to the end of the wire that connects to the
ORCA-4K gateway ground terminal. Also, ensure the power cord(s) or
cable(s) are not connected to the main power source and cannot carry a voltage potential until after this procedure is complete.
To connect power to the chassis:
1. Place the #10 ring tongue terminal of the ground strap over the threaded stud of
the chassis ground terminal. Fasten the #10 star washer and a #10-24 nut on the
threaded stud. Tighten the nut to a torque of 6 ft-lb. (0.83 kg-m).
2. Remove the terminal cover to access to terminal posts. The terminals for DC
power are labeled -48VDC and BAT RTN (BATTERY RETURN) and are wire
ready, meaning the wires need to be stripped to the appropriate length prior to
being clamped down by the screws on the DC terminal block (See Figure 9).
Figure 9. ORCA-4K Gateway DC Power Terminal Posts
3. Make power connections to the rear of the chassis. Tighten each screw to a torque
of 20 in-lb. max.
4. Replace the terminal cover.
ORCA-4K Hardware Manual
30
Installing the Chassis
Applying Power
Turn on power to the chassis by switching both circuit breakers to the On (|) position. The ORCA-4K gateway will run a power-on self-test to ensure proper initialization of the gateway.
If either terminal block is not connected or both circuit breakers are not
turned on, the LED on the fan tray and a LED on the VPM will remain red.
The system will also send out a trap alarm indicating there is no redundant
power.
ORCA-4K Hardware Manual
31
5
CONFIGURATION
This chapter describes the basic configuration functions performed through the Craft
port of the ORCA-4K gateway. It also provides specific instructions for configuring a
gateway using craft port commands.
Once the basic configuration is complete through the Craft port and the system has
been power-cycled, you should complete the configuration using Nuera’s NetConductor EMS. Refer to the NetConductor User’s Guide and the ORCA-4K Application
User Guide to learn how to fully configure and monitor the gateway.
The Craft Port
The Craft port plays a small yet crucial part of bringing an ORCA-4K gateway online
in a network. Located on the BCM, this is a DB9 (M) serial port intended to connect a
computer directly into the gateway to assign basic configuration information.
Connect a null modem cable to the active BCM Craft port. The active BCM is connected to the active VPM; for example, VPM1 is connected to BCM1. The active VPM
will also have its green “active” LED illuminated on the front panel.
Once a computer has been connected to the port, use a terminal emulation program
such as Procomm PlusTM or Hyperterminal to access the gateway. Use the settings
below to correctly configure the emulation program:
•
9600 bps (ANSI ASCII format)
•
Parity: None
•
Bits: 8
ORCA-4K Hardware Manual
32
Configuration
•
Stop bits: 1
•
Flow Control: None
Craft Port Commands
This section presents a list of ORCA-4K gateway commands that can be entered
through the BCM Craft port. These commands are initially used to configure the
gateway. Once the gateway is functional, the remainder of the configuration can be
performed through the Nuera NetConductor EMS.
The default password for the ORCA-4K gateway is: nuera. You should modify the
default password prior to configuring the gateway.
Take special care with your password as there is no way to recover a lost
password.
Password Command
Changes the default access password for the ORCA-4K gateway. Specify a maximum
of 40 alphanumeric characters.
PSW <PASSWORD>
Help Command
The help or ? command displays a list of the ORCA-4K gateway console port commands.
HELP
or
?
DS3 Commands
The DS3 command allows modification of the received DS3 equalizer to compensate
for remote DS3 equipment that does not meet the standard pulse template defined in
ORCA-4K Hardware Manual
33
Configuration
GR-499-CORE or for DS3 signals that have been driven through more than 900 feet
(274.3 meters) of cable.
The default value, enable, should be fine for most network applications. If, however,
the remote equipment is known not to meet the standard pulse template, is driven
through more than 900 feet (274.3 meters) of cable AND bit errors are seen on the
received DS3 at the ORCA-4K, you should try setting the value to disable.
This setting is modified on a per DS3 basis. The current setting for individual DS3s is
displayed using show.
DS3 {1-6} EQUALIZER {ENABLE | DISABLE | SHOW}
Ethernet Commands
The ethernet command group provides LAN configuration parameters for the
ORCA-4K gateway. There are five ethernet commands:
•
ethernet control <100 Base-T Floating IP address>
•
ethernet media <1000 Base-SX Floating IP address>
•
ethernet bkcontrol <Background Control IP address>
•
ethernet bkmedia <Background Control IP address>
•
ethernet show
The ethernet control and media commands set the floating IP address, default
gateway, and subnet mask used by the active VPM, regardless of the slot. The ethernet bkcontrol and bkmedia commands set the fixed IP addresses for the control ports and media ports for both VPMs.
After the ethernet addresses are modified, the gateway must be power-cycled
for the changes to take effect.
In addition to the configuration commands above, a command for viewing a subset of
the Ethernet statistics for each port is included (ethernet control stats, ethernet
media stats, etc.). Information provided includes the current state of the port (up/
down), the MAC address associated with the port and the following statistics:
•
Number of octets received and sent;
ORCA-4K Hardware Manual
34
Configuration
•
Number of packets received and sent;
•
Number of received and sent packets that are discarded;
•
Number of received and sent packets with errors;
•
Number of unknown protocol packets received.
Ethernet statistics can also be viewed from the Nuera NetConductor EMS.
Ethernet Control
Set the floating IP address for the active 100 Base-T control port using the dotted
quad decimal IP address (xxx.xxx.xxx.xxx).
ETHERNET CONTROL IP <IPADDR>
Set the subnet mask for the 100 Base-T control ports using the dotted quad decimal
format (xxx.xxx.xxx.xxx).
ETHERNET CONTROL MASK <IPMASK>
Set the IP address of the default gateway for the 100 Base-T control ports using the
dotted quad decimal IP address (xxx.xxx.xxx.xxx).
ETHERNET CONTROL DEFAULT <IPADDR>
Display the current control port settings with the following command:
ETHERNET CONTROL SHOW
You can display port status, MAC address and a subset of Ethernet statistics for the
active control port with the following command:
ETHERNET CONTROL STATS
ORCA-4K Hardware Manual
35
Configuration
Ethernet Media
Set the desired floating IP address for the active 1000 Base-SX (GigE) media port
using the dotted quad decimal IP address (xxx.xxx.xxx.xxx).
ETHERNET MEDIA IP <IPADDR>
Set the subnet mask for the media ports using the dotted quad decimal format
(xxx.xxx.xxx.xxx).
ETHERNET MEDIA MASK <IPMASK>
Set the IP address of the default gateway for the media ports using the dotted quad
decimal IP address (xxx.xxx.xxx.xxx).
ETHERNET MEDIA DEFAULT <IPADDR>
Display the current media port settings with the following command:
ETHERNET MEDIA SHOW
Display the port status, MAC address and a subset of Ethernet statistics of the active
media port with the following command:
ETHERNET MEDIA STATS
Ethernet Bkcontrol
Set the fixed (background) IP addresses for the control ports using the dotted quad
decimal IP address (xxx.xxx.xxx.xxx). Select which control port {1|2} to assign
the IP address. 1 configures the control port on the VPM in slot 1 and 2 configures
the control port on the VPM in slot 2. The subnet mask and default gateway will be
the same as configured in the Ethernet Control section above.
ETHERNET BKCONTROL IP {1|2} <IPADDR>
ORCA-4K Hardware Manual
36
Configuration
Display the current settings by using the following command:
ETHERNET BKCONTROL SHOW
Display the port status, MAC address and a subset of Ethernet statistics of the background control port with the following command:
ETHERNET BKCONTROL STATS
Ethernet Bkmedia
Set the fixed (background) IP addresses for the media ports using the dotted quad
decimal IP address (xxx.xxx.xxx.xxx). Select which media port {1|2} to assign
the IP address. 1 will configure the media port on the VPM in slot 1 and 2 will configure the media port on the VPM in slot 2. The subnet mask and default gateway will
be the same as configured in the Ethernet Media section above.
ETHERNET BKMEDIA IP {1|2} <IPADDR>
Display the current settings by using the following command:
ETHERNET BKMEDIA SHOW
Display the port status, MAC address and a subset of Ethernet statistics of the background media port with the following command:
ETHERNET BKMEDIA STATS
Ethernet settings can be viewed from the Nuera NetConductor EMS, but can
only be changed through the Craft port on the BCM.
Ethernet Show
The ethernet show command displays the current IP settings for all the ports, the
MAC addresses and the current syslog destination.
ETHERNET SHOW
ORCA-4K Hardware Manual
37
Configuration
CallPro Commands
The CALLPRO commands are used to provision the RTP base port number and
MGC interface. There are three CALLPRO commands:
•
callpro rtpbaseport [port number]
•
callpro mgcinterface [control | media]
•
callpro show
Changing the CallPro RTPBasePort or MGCInterface will require a power
cycle of the system.
CallPro RTPBasePort
The callpro rtpbaseport command defines the starting or base RTP port to be used
by the BTX-4K for receiving and sending media (voice) packets. The ORCA-4K uses
four RTP ports per channel. For example, this means with a default callpro rtpbaseport of 11000:
•
Six DS3 capacity will result in a RTP port range of 11000 to 27128 (4032 channels
per DS3). The port number may be any even number between 7000 - 48000.
•
Two STM-1 capacity will result in a RTP port range of 11000 to 26625 (3906 channels per STM-1.) The port number may be any even number between 7000 48000.
CALLPRO RTPBASEPORT [PORT NUMBER]
RTP voice packets are sent and received on even UDP port numbers while
RTCP voice control packets are sent and received on odd UDP port numbers.
CallPro MGCInterface
The callpro mgcinterface command indicates which interface is connected to the
MGC. The MGC interface may be configured to control or media.
CALLPRO MGCINTERFACE [CONTROL | MEDIA]
ORCA-4K Hardware Manual
38
Configuration
CallPro Show
The callpro show command reports the current configuration of the RTP base port
and MGC interface settings.
CALLPRO SHOW
Ping Command
The PING command can be used to validate the connections from the gateway to the
network. Select the appropriate port from which to send the ping. Use the dotted
quad decimal IP address (xxx.xxx.xxx.xxx) of the network destination to ping.
PING {BKCONTROL | CONTROL | BKMEDIA | MEDIA} <IPADDR>
SNMPCFG Commands
This command sets certain SNMP configuration parameters in the gateway.
SNMPCFG SecLevel
Allows the user to change the security level used with SNMPv3. Selecting auth will
allow either auth only or auth/priv security to be negotiated with the SNMPv3 client. Selecting priv will allow only auth/priv (highest security level) to be negotiated
with the SNMPv3 client. The default is priv and is the recommended setting.
SNMPCFG SECLEVEL[AUTH/PRIV]
SNMPCFG Help
Displays the SNMP configuration options.
SNMPCFG HELP
ORCA-4K Hardware Manual
39
Configuration
SNMPCFG Passphrase
Sets the SNMP local interface password to the default of: authpriv
SNMPCFG PASSPHRASE RESET
SNMPCFG ProcV2
Sets the gateway to process or stop processing SNMPv2 packets. The default value is
PROCV2 OFF.
SNMPCFG [PROCV2 ON/PROCV2 OFF]
The gateway will always process SNMPv3 packets
SNMPCFG Show
Displays the current SNMP configuration options.
SNMPCFG SHOW
SNMPCFG ShowStat
Displays the SNMP statistics.
SNMPCFG SHOWSTAT
SNMPCFG TrapGen
Allows you to select the SNMP protocol format for traps.
SNMPCFG TRAPGEN [V2C/V3]
SNMP Community String Commands
SNMP community string commands are only relevant when using SNMPv2.
ORCA-4K Hardware Manual
40
Configuration
SNMP community strings allows you to set low-level security for an ORCA-4K
gateway. With a community string, you can assign a name to your ORCA-4K gateway. This name will be embedded in every header packet sent from the gateway.
When an ORCA-4K gateway and the Nuera NetConductor EMS have community
strings enabled, they will both embed the same name in their messages, verify the
name in the header and discard packets from nodes that do not contain the configured community string. The default community string is set to public. There are
two community string commands.
Manager Community Show
Display the current community string name listed for the ORCA-4K gateway with
the following command:
MANAGER COMMUNITY SHOW
Manager Community Write
The gateway supports community strings using the following parameters: <INDEX>
<PRIVILEGES> <STRING>. After entering the command below, a prompt will appear
to enter one of the following parameters:
<INDEX>
This parameter specifies one of five community strings where <INDEX> is 1,2,3, 4
or 5.
<PRIVILEGES>
This parameter grants read-only or read-write privileges to the gateway accessed
by the specified community string. Specify r or rw.
<STRING>
This parameter specifies the designation (name) for the ORCA-4K gateway. Specify a string of up to 32 alphanumeric characters.
MANAGER COMMUNITY WRITE
ORCA-4K Hardware Manual
41
Configuration
TDM Connection Type Commands
The first command displays the current TDM Connection type (STM1, OC3, DS3). If
configuring an optical ORCA-4K, please use this command to confirm the gateway is
configured for the desired optical interface (STM1 or OC3):
TDMCONNTYPE SHOW
An optical ORCA-4K gateway is initially shipped with a TDM connection
type configuration of OC3. If you are using the ORCA-4K in an STM-1
application you will have to configure it for STM1.
The following command allows you to configure the current optical connection:
TDMOPTCONNTYPE [STM1/OC3]
Changing the optical connection type will cause a storage initialization (see
“Storage Initialization Command” on page 43 to be performed by the gateway.
When a DS3 daughter card is present in your gateway, this command will display an
error message and exit. When changing the optical connection type, you must power
cycle your system for changes to take affect.
VPMReset Command
The VPMRESET command allows the VPM board to be reset from the associated
port.
VPMRESET
Version Command
The version command displays the number and date of the Nuera ORCA-4K code
release currently running on the active VPM.
VERSION
ORCA-4K Hardware Manual
42
Configuration
Quit Command
The quit command ends an ORCA-4K gateway Craft session and returns the display
to the Enter Password prompt. After a Craft session has ended, you must re-enter
the password to begin a new Craft session.
Always conclude a terminal session by executing the quit command. This prevents
accidental or unauthorized use of a command that might disrupt the operation of the
ORCA-4K gateway.
QUIT
Storage Initialization Command
The storage init command deletes all configuration settings (except the Ethernet
addresses) from the gateway and resets them to factory defaults. After entering this
command, you must confirm the action, then wait approximately 30 seconds until
another prompt appears requesting to power cycle the gateway.
STORAGE INIT
You must not power cycle the gateway until prompted. Power cycling too
soon can result in an undefined configuration, which can cause irreparable
damage to the gateway.
ORCA-4K Hardware Manual
43
6
MAINTENANCE
This chapter presents maintenance procedures and techniques for working with the
the ORCA-4K gateway and its components. The VPM, BCM, OCM, DS3 Connector
Module, Alarm Module and fan tray are hot-swappable and serviceable outside the
chassis. The DSP Modules can be installed on a VPM after it has been removed from
the chassis. The DSP Modules cannot be hot swapped.
Precautions
Nuera does not recommend any maintenance on the internal components of the chassis. If, however, you must access the internal parts of the chassis, you should take the
following precautions:
•
Always disconnect the main power and any connections to the public telephone network.
•
Electrostatic Discharge (ESD): All internal assemblies and cable ports on the
rear panels are susceptible to damage from ESD. To reduce the possibility of damage to these devices, always observe standard ESD handling precautions, including (but not limited to) the following:
•
Avoid touching circuitry or conductive components of the gateway or its subassemblies without being properly grounded.
•
Place the gateway and all subassemblies on a grounded anti-static mat whenever maintenance is performed.
•
Use an approved personal grounding device (such as a wrist strap) at all times
when handling these products. To prevent rapid dissipation of any static
charge and to protect service personnel from electric shock, a minimum of
1MΩ (Megohm) series resistance is required between service personnel and
the ground connection. Please consult Nuera for additional information.
ORCA-4K Hardware Manual
44
Maintenance
•
Use only approved anti-static containers when shipping or moving any of
these products.
•
Failure to observe these precautions could result in serious damage to the
gateway modules with either immediate or latent operational failure or performance degradation. ESD-related failures due to improper handling may
affect the coverage under your warranty.
Gateway Status Monitoring
You can monitor the gateway operation in five ways:
•
Nuera NetConductor EMS
•
SNMP trap monitoring
•
Alarm port monitoring
•
Syslog Collector
•
LED indicators
VPM LED Indicators
The VPM includes three sets of LEDs. The first set (far left) indicates the overall system health, the second set (middle) indicates the status of the TDM interfaces, and
the third set (far right) indicates the status of the ethernet (100 Base-T and 1000
Base-SX) ports. These LEDs and their associated conditions are described in Tables
2, 3 and 4.
OCM LED Indicators
The OCM card has four bi-color LEDs: two on the far left and one on each side of the
Optical interface. On the left, a green LED signifies the Working interface, while a
yellow LED shows the Protect interface. The LEDs on each side of the optical interface provide link status information for the optical interface. A green LED signifies
that the OCM is receiving a signal, while an unlit LED signifies that no signal is
being received.
Fan Tray LED Indicator
The fan tray has a bi-color LED status indicator. Normal operation is designated by a
green LED. A red LED indicates there is a fault within the fan tray. If neither LED is
lit, the fan tray may have lost connection to power and should be replaced immediately. The fan tray also monitors both power feeds. Although only one feed is necessary to power the fan tray, the LED will remain red in this case to indicate a
potential for a single point of failure. For this reason, verify there are redundant
ORCA-4K Hardware Manual
45
Maintenance
power inputs before servicing the fan tray This LED and the associated conditions
are described in Table 5.
Maintenance Procedures
Chassis Intake/Exhaust
Given the complexity of the internal circuitry of an ORCA-4K gateway, maintaining
operating temperatures within acceptable levels is critical. Cooling is provided by a
fan tray on the left side of the ORCA-4K gateway. Ensure that the air intake and
exhaust areas are not obstructed during operation.
Hot-Swapping a Fan Tray
If you receive a fan tray failure notification, either through the Nuera NetConductor
EMS or by observing the LED’s, remove the faulty fan tray after confirming the
redundant power inputs are connected, then insert a new fan tray into the chassis.
No tools are required to perform this task.
Removing an ORCA-4K gateway fan tray alters the airflow characteristics
of the chassis. Operating a gateway in this condition will cause overheating.
To avoid potential damage or loss of service, ensure the fan tray is replaced
as quickly as possible. The system should not be run (at ambient temperature) without a fan tray any longer twenty minutes.
VPM Installation
Follow the steps below to install a VPM.
To install a VPM card:
1. Ensure the black ejector tabs on the front of the VPM are in the unlocked/open
position by pushing the red tabs outward.
2. Ensure the DSP module ejector tabs on the right side of the circuit card are in the
closed (towards the center of circuit card) position.
3. Place the bottom edge of the circuit card into the card guide slot. The edge of the
module must be inserted into the channel to ensure alignment with the midplane
connectors.
4. Carefully slide the front module all the way into the chassis.
5. Close/lock the ejector handles to fully seat the module to the midplane connectors.
There will be an audible “click” when the red tabs on the handles are closed.
ORCA-4K Hardware Manual
46
Maintenance
6.
Tighten the captive screw on both ejector handles to the chassis.
Hot Swapping a VPM
Once you have received notification of a VPM failure, use the following procedure to
remove the faulty VPM and insert a new one into the chassis.
To hot-swap a VPM card:
1. Unscrew the captive screws located on either side of the ejector handles.
2. Push the red tabs outward to unlock the ejector handles; then pull the handles to
disengage the circuit card from the midplane connectors.
3. Remove the VPM from the chassis by gently pulling on the ejector handles.
4. To install the new VPM, see "VPM Installation" on page 46.
Swapping a VPM Between Gateways
Swapping VPM cards between 4K gateways can alter the gateway configuration and
cause IP conflicts in your network. To prevent potential problems, Nuera recommends that you only insert a VPM from one gateway into another gateway containing
a VPM that has already reached the active state (as detailed in Scenario 1).
Scenario 1: Gateway with Active VPM
If a VPM from one gateway is inserted into a gateway with an existing active VPM,
the new VPM will arbitrate to standby mode in the new gateway. It will receive background IP addresses and mirrored configuration from the active VPM card. In this
way, the new standby VPM will take on the configuration of its new gateway.
Scenario 2: Gateway with no Active VPM
If a VPM from one gateway is inserted into an empty chassis, it will arbitrate with
the other VPM (if inserted at the same time) to decide which card should become
active. There is no easy way to determine which VPM will decide to become active
and thus which configuration and IP addresses will be used. If the VPM arbitrates to
active mode in the new gateway, it will maintain the floating IP address it had in the
previous gateway. This may cause a problem if was the standby card in the previous
gateway because now two gateways in the network will have the same IP address. To
resolve this problem, use craft port commands to reconfigure the VPM.
ORCA-4K Hardware Manual
47
Maintenance
DSP Module Installation
To install a DSP Module:
1. Remove the VPM from the chassis as directed in the procedure “Hot Swapping a
VPM” on page 47 and place it on a firm surface.
2. Open the DSP card guide ejectors located on the VPM. Always install the DSP
module in sequential order (start with Slot 1 then Slot 2, then Slot 3 etc....); do not
skip slots.
3. Carefully place the DSP module into the connector slot and gently push down
until the ejector handles snap in place.
4. Ensure that all non-populated DSP connector ejectors are in the closed (up) position before re-installing the VPM into the chassis. Failure to confirm this may
result in a broken ejector handle during installation of the VPM into the chassis.
OCM Card Installation
Follow the steps below to install an OCM module.
To install an OCM card:
1. Place the bottom edge of the circuit card into the card guide slot. The edge of the
module must be inserted into the channel to ensure alignment with the midplane
connectors.
2. Carefully slide the module all the way into the chassis.
3. Tighten the captive screws on both sides of the module to the chassis.
OCM Card Removal (Hot Swap)
Once you have received notification of an OCM failure, use the following procedure to
remove the faulty OCM card and insert a new one into the chassis.
To hot-swap an OCM card:
1. Unscrew the captive screws located on either side of the ejector handles.
2. Remove the OCM card from the chassis by gently and evenly pulling on the handle or the captive screws.
3. See "OCM Card Installation" on page 48 to install the new OCM card.
ORCA-4K Hardware Manual
48
Maintenance
Rear Module Installation and Removal (Hot Swap)
There are no card guides for the rear modules. They are installed “blind mated” to the
appropriate card edge connector on the midplane.
To hot-swap rear modules:
1. Once the module is inserted into the midplane connector, tighten the fastener
screws on the front panel using a equal number of turns on each fastener until the
module is fully seated.
2. The rear modules can be hot swapped and replaced by equally rotating the fastener screws counterclockwise until the threads are no longer engaged with the
chassis, then the module can easily be removed and replaced.
Gateway Upgrades
Upgrading an ORCA-4K gateway requires the use of the Nuera NetConductor EMS
and the procedures located in the ORCA-4K Application Manual and release notes on
the Nuera Software CD. These items are shipped with each upgrade and can also be
downloaded from the Nuera Technical Assistance Center website.
Software Upgrade
Nuera upgrades software via the Nuera NetConductor EMS. Contact your Nuera representative to upgrade to the latest version of software.
Capacity Upgrade
Additional capacity can be added to the gateway by installing additional DSP modules on the VPMs and by entering the required authorization file. Contact your
Nuera representative to purchase capacity upgrades.
ORCA-4K Hardware Manual
49
7
TROUBLESHOOTING
This chapter contains information to help you solve problems that may occur while
installing and using your ORCA-4K gateway. For information about ORCA-4K
alarms and traps, see the appropriate Application User’s Guide for your software.
System LEDs
This section presents information about the ORCA-4K system LEDs. The ORCA-4K
gateway provides status information through the VPM LEDs and Nuera NetConductor EMS.
VPM Status LEDs
The VPM has three sets of LEDs as shown in Figure 10. The first set (far left) indicates the overall system health, the second set (middle) indicates the status of the
TDM interfaces, and the third set (far right) indicates the status of the ethernet (100
Base-T and 1000 Base-SX) ports. The LEDs can either be steady or flashing, and can
show patterns to help isolate troubleshooting information. Table 2, “VPM Status
LEDs,” on page 51, Table 3, “VPM TDM Interface LEDs,” on page 52 and Table 6,
“VPM Ethernet Interface LEDs,” on page 53 lists the LED patterns and their associated states.
ORCA-4K Hardware Manual
50
Troubleshooting
Figure 10. VPM Status LEDs
Table 2. VPM Status LEDs
State
LED Pattern
Indicates
Startup
Blue
This light is illuminated by the hardware when power
is applied. If the boot image is missing or bad, the
LED will stay blue.
Startup - RAM
Test
Blue, Flash Yellow
Boot code executes diagnostic RAM tests and loads
the CCP image from flash to RAM.
Startup - RAM
Test Failure
Blue, Flash Red
Boot RAM test or CCP image download from flash to
RAM fails.
Startup Arbitration
Blue, Yellow
Lights are on from CCP application start until arbitration is complete.
Startup Mirroring
Yellow, Green, Red (sequential
on both VPMs)
Mirroring configuration from the active VPM to the
standby.
Active
Green
Arbitrate to active state or alarm condition clears.
Active - Alarm
Green, Red
An alarm condition is detected that doesn’t cause a
fail-over because the same alarm is seen on the
standby (e.g., fan tray is missing)
Standby
Yellow
Mirroring completes and VPM is in standby protect
state.
Standby Alarm
Yellow, Red
An alarm condition is detected, but the standby is still
available for fail-over. (e.g., fan tray is missing)
Fault
Red
Arbitrated to fault state. (e.g., missing/bad daughter
card, loading NP or DSP image from flash failed, ethernet link missing, etc.)
Code Download
Yellow, Green, Red (sequential
on individual VPM)
TFTP of boot, CCP, NP, or DSP code to the VPM
and storing the downloaded code to flash.
Power Failure
Green, Red (Active) and Yellow, Red (standby) and Fan
Alarm: Red
Single Power Feed Failure. This will not cause a
switchover.
ORCA-4K Hardware Manual
51
Troubleshooting
VPM/DS3 Interface LEDs
The VPM DS3 Interface LEDs, as shown in Figure 10, are the middle set of LEDs on
the VPM. There is one LED per DS3 interface.
Table 3. VPM TDM Interface LEDs
State
LED Color
Indicates
Offline
Off
The interface is not online.
Link
Green
The DS3 link is functioning properly and there are no outstanding alarms.
Test
Yellow
The interface is first coming online and is performing a self-test, or the user
has put the link into diagnostic mode.
Alarm
Red
There is an error on the DS3 interface, or on one of the DS1s in the DS3. The
possible errors are: Rcvd LOS (loss of signal), Rcvd LOF (loss of frame),
Rcvd RAI (remote alarm indication), or Rcvd AIS (alarm indicator signal).
VPM/Optical Interface LEDs
The VPM/Optical Interface includes two sets of three LEDs, as shown in Figure 11.
Figure 11. VPM/Optical LEDs
Each interface displays status through two Sync LEDs and one Active LED.
Table 4. VPM/OPTICAL Sync LEDs
State
LED Color
Indicates
Offline
Off
The interface is not online.
Link
Green
The Optical link is functioning properly and there are no outstanding alarms.
Test
Yellow
The interface is first coming online and is performing a self-test, or the user
has put the link into diagnostic mode.
ORCA-4K Hardware Manual
52
Troubleshooting
Table 4. VPM/OPTICAL Sync LEDs
State
Alarm
LED Color
Red
Indicates
There is an error on the Optical interface. The possible errors are: Rcvd LOS
(loss of signal), Rcvd LOF (loss of frame), Rcvd RAI (remote alarm indication), or Rcvd AIS (alarm indicator signal).
The Active LED displays the line, either working or protect, from which the VPM is
currently receiving voice traffic.
Table 5. VPM/OPTICAL Active LEDs
State
LED Color
Indicates
Offline
Off
The interface is offline.
Link
Green
Voice traffic is being received on the working interface.
Link
Yellow
Voice traffic is being received on the protect interface.
VPM Ethernet Interface LEDs
The VPM Ethernet Interface LEDs are at the far right of the VPM. The LEDs, as
shown in Figure 10 and in starting from the left to right are: Control TX, Control RX/
Link, Media TX, and Media RX/Link. These are all green LEDs.
Table 6. VPM Ethernet Interface LEDs
State
LED Pattern
Indicates
Control (Media) TX Off
Off
No activity in the Tx (send) direction.
Control (Media) TX Active
Flash Green
There is activity in the Tx (send) direction.
Control (Media) RX Off
Off
No link or link offline.
Control (Media) RX Link
Green
Link is up but there is no activity in the Rx (receive) direction.
Control (Media) RX Active
Flash Green
There is activity in the Rx (receive) direction.
OCM LEDs
The OCM card has four bi-color LEDs: two on the far left and one on each side of the
Optical interface. On the left, a green LED signifies the Working interface, while a
yellow LED shows the Protect interface. The LEDs on each side of the optical interface provide link status information for the optical interface. A green LED signifies
that the OCM is receiving a signal, while an unlit LED signifies that no signal is
being received.
ORCA-4K Hardware Manual
53
Troubleshooting
Fan Tray LED
The fan tray has a bi-color LED status indicator. Normal operation is designated by a
green LED; a fault condition is indicated by a red LED and if neither LED is lit, the
fan tray may have lost connection to power. The fan tray also monitors both power
feeds. Although only one feed is necessary to power the fan tray, the LED will remain
red in this case to indicate a potential for a single point of failure. The LED and its
associated conditions are described in Table 7.
Table 7. Fan Tray LED
State
LED Pattern
Indicates
Fan Tray / Power
OK
Green
Both the fan tray and the dual power feeds are operating correctly.
Fan Failure or Dual
Power Feed not
connected
Red
One or more of the fans on the fan tray is not spinning at the proper speed or the dual power feeds are
not connected. This will not cause a switchover.
Power Failure
Fan Alarm: Red
Active VPM: Green, Red
Standby VPM: Yellow, Red
Single power feed failure.
System Alarms
If any of the modules fail, an alarm is sent to the Nuera NetConductor EMS. These
alarms are discussed in detail in the Application User’s Guide for your software.
Alarm Module
Use the “Connection Requirements” on page 25 to wire the Alarm Module. If an
alarm is generated, a signal is sent to the Alarm Module. The module has output
leads for major and minor alarms. Table 8 reflects states when a signal is driven
through the Alarm Module.
Table 8. Alarm Module Signals
VPM State
Startup - Fault
Description
•
•
•
•
•
•
•
•
ORCA-4K Hardware Manual
No Ethernet Link
Missing TDM daughter card
Missing NP daughter card
Missing DSP Cards that correspond to Authorized and Configured DS1s.
DSP daughter cards improperly placed. (e.g., not starting in the first available slot or skipping slots.)
Loading NP or DSP image from flash failed
No boot, or either card not properly seated
Single Card O.K., but Second Card Fault
54
Troubleshooting
Table 8. Alarm Module Signals
VPM State
Description
Active - Alarm
This alarm condition is seen on both the active and the standby VPMs; therefore, it does not cause a fail-over. (e.g., fan tray missing alarm).
Standby - Alarm
An alarm condition is detected but the standby is still available for fail-over.
(e.g., fan tray missing alarm).
Fan Failure
One or more of the fans on the fan tray is not spinning at the proper speed.
Power Supply Failure
A power supply failure seen on either or both VPMs.
GETTING HELP
If, after installing and configuring your Nuera equipment, you cannot establish communications to or from the unit, carefully review the information in this book and in
the other ORCA books prior to calling Technical Assistance Center (TAC).
Before going any further, ensure that you have checked the following:
•
Console Port configuration. Verify that the baud rate of your terminal is set to
9600 bps.
•
Power reset. When cycling power, be sure to leave the power off for a minimum of
30 seconds before reapplying power to the unit.
•
Command review. Review the gateway commands in Chapter 5,Configuration.
•
Software version. To ensure that you have the latest enhancements and product
features, Nuera ships every unit with the latest software version. Therefore,
when you are installing or reinistalling units into your system, verify that each
unit is equipped with identical software versions.
Checklist
If, after carefully reviewing the information in this book and in the other ORCA
books, your problem persists, contact your product representative or a service representative at Nuera’s Technical Assistance Center. So we can serve you better, make a
list of the following items before calling:
•
A detailed description of your problem.
•
A complete listing of your system components and configuration, including the
serial number of your unit and the software version number it is running.
•
A narrative of the actions you performed prior to the problem.
•
A list of all system messages posted by your unit.
ORCA-4K Hardware Manual
55
Troubleshooting
Contacts
Address:
Nuera Communications, Inc.
10445 Pacific Center Court
San Diego, CA 92121 USA
[email protected]
www.nuera.com/support/
Telephone:
1-858-625-9220, extension 1391 or 1-800-966-8372, extension 1391
ORCA-4K Hardware Manual
56
A
PARTS
AND
ACCESSORIES
ORCA-4K gateway parts and accessories can be purchased from your Nuera authorized service provider. The tables in this appendix list the part numbers for fieldreplaceable items. For the latest information (including prices) on the parts described
in this appendix, consult your Nuera representative or see the most recent edition of
the Nuera Global Price List and Configuration Guide.
Cables
Cable Description
Part Number
BCM Standard Ethernet 100 Base-T Cable RJ45 (M)-RJ45 (M)
504-172-010 (10 ft)
504-172-025 (25 ft)
BCM T1 Straight Cable RJ48 (P) to RJ48 (P)
500-937-010 (10 ft)
500-937-025 (25 ft)
BCM T1 Crossover Cable RJ48 (P) to RJ48 (P)
500-938-010 (10 ft)
500-938-025 (25 ft)
BCM Craft Port Crossover Cable DB9 (F) to DB9 (F)
500-252-010 (10 ft)
500-252-025 (25 ft)
DS3 Connector Module BNC 75 ohm Cable
504-264-010 (10 ft)
504-264-025 (25 ft)
504-264-050 (50 ft)
504-264-100 (100 ft)
You must provide the optical fiber and LC style connector to connect to the
VPM transceiver.
ORCA-4K Hardware Manual
57
Upon request, Nuera can provide the manufacturing specification data sheets
for these cables through the download section of Nuera’s website. These
specifications include the pertinent data needed to fabricate the cables.
Please contact the Nuera Technical Assistance Center at [email protected] to
gain access to the website.
Documentation
Publications
Part Number
ORCA-4K Hardware User’s Guide
299-433-1nn
BTX-4K Application Manual
299-432-5nn
UMX-4K Application Manual
299-442-5nn
NetConductor EMS User’s Guide
299-434-4nn
The User’s Guides are included on the specific application CD in Adobe
Acrobat™ PDF format.
Replacement Modules and Components
Description
Part Number
DS3 Voice Processing Module (VPM)
504-378
OCM Voice Processing Module (VPM)
504-379
DS3 Connector Module
504-288
OCM Connector Module
504-307
BITS Clock Module (BCM)
504-286
Alarm Module
504-287
Fan Tray
504-355
DSP Module
504-302
OCM Filler Plate
504-386
Front Door Assy
504-377
Relay Rack Adapter, 23 inch
504-048
ORCA-4K Chassis
504-299
ORCA-4K Hardware Manual
58
B
REGULATORY INFORMATION
This appendix presents pertinent regulatory information for the ORCA-4K product.
Safety
UL/cUL Standard 60950
CB Certification Standard IEC 60950
Emissions and Immunity
FCC Part 15, Class A
CE Marking EN55022 and EN55024
Environmental and EMI
NEBS GR-63 Zone 4
NEBS GR-1089 Level 3, Types 1 and 3
ORCA-4K Hardware Manual
59
Was this manual useful for you? yes no
Thank you for your participation!
