INSTALLATION INSTRUCTIONS
RSA Projector Mounts
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RSA
RSA Projector Mounts
Installation Instructions
DISCLAIMER
Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to the RSA does not exceed 25 lbs
(11.37 kg).
•
The weight capacity of the RSA may be LIMITED to the
lowest weight capacity of any other components
located between the RSA and the supporting structure!
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
IMPORTANT SAFETY INSTRUCTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
damaged. Return the mounting system to a service center for
examination and repair.
WARNING: Do not use this product outdoors.
IMPORTANT ! : The RSA mounts are designed to be:
•
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
•
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
•
•
mounted to a 1-1/2" NPT or NPSM following ANSI/
ASME B1.20.1 (Schedule 40, 0.154" minimum
thickness aluminum - ASTM B221) threaded extension
column;
mounted to double 2" x 4" wood stud cross bracing
(1-1/2" on center) between two 2" x 4" ceiling joists;
mounted to a concrete ceiling with a minimum
thickness of 8" and a maximum drywall covering of
5/8"; or
suspended from four 1/4" diameter (minimum) Grade 2
or better threaded rods (not included) which are
secured to unistrut, angle or channel assembly
overhead structural members (trusses or I-beams) by
Grade 2 or better 1/4" channel nuts (not included).
NOTE: RSA Series may be used with Listed Chief models
WM110S, WM120S, WM130S, WM210S, WM220S,
WM230S, WM240S, WM210SI, WM220SI, WM230SI,
WM240SI, and SL220 (not included).
--SAVE THESE INSTRUCTIONS--
DIMENSIONS
5.6
.22
111.1
4.38
73
2.88
BOLT CIRCLE
THREADS ONTO 1-1/2' NPT
78.8
3.10
4°
ROLL ADJUSTMENT
36.5
1.44
111.6
4.39
2
25°
PITCH ADJUSTMENT
Installation Instructions
RSA Projector Mounts
LEGEND
Tighten Fastener
Pencil Mark
Serrez les fixations
Marquage au crayon
Serrare il fissaggio
Segno a matita
Befestigungsteil festziehen
Stiftmarkierung
Apretar elemento de fijación
Marcar con lápiz
Bevestiging vastdraaien
Potloodmerkteken
Apertar fixador
Marcar com lápis
Loosen Fastener
Drill Hole
Desserrez les fixations
Percez un trou
Allentare il fissaggio
Praticare un foro
Befestigungsteil lösen
Bohrloch
Aflojar elemento de fijación
Perforar
Bevestiging losdraaien
Gat boren
Desapertar fixador
Fazer furo
Phillips Screwdriver
Adjust
Tournevis à pointe cruciforme
Ajuster
Cacciavite a stella
Regolare
Kreuzschlitzschraubendreher
Einstellen
Destornillador Phillips
Ajustar
Kruiskopschroevendraaier
Afstellen
Chave de fendas Phillips
Ajustar
Hex-Head Wrench
Remove
Clé à tête hexagonale
Retirez
Chiave esagonale
Rimuovere
Sechskantschlüssel
Entfernen
Llave de cabeza hexagonal
Quitar
Zeskantsleutel
Verwijderen
Chave de cabeça sextavada
Remover
Open-Ended Wrench
Optional
Clé à fourche
En option
Chiave a punte aperte
Opzionale
Gabelschlüssel
Optional
Llave de boca
Opcional
Steeksleutel
Optie
Chave de bocas
Opcional
By Hand
Security Wrench
À la main
Clé de sécurité
A mano
Chiave di sicurezza
Von Hand
Sicherheitsschlüssel
A mano
Llave de seguridad
Met de hand
Veiligheidssleutel
Com a mão
Chave de segurança
3
RSA Projector Mounts
Installation Instructions
Hammer
Target of Projector
Martillo
Punto de enfoque del proyector
Hammer
Ziel des Projektors
Martelo
Mira do projector
Martello
Punto di proiezione
Hamer
Doel van de projector
Marteau
Cible du projecteur
TOOLS REQUIRED FOR INSTALLATION
7/16"
#2
7/32" (6mm) dia.
5/32"
PARTS
A (1)
B (1)
Example Only
(Interface bracket
varies dependent
on projector model)
4
All-Points
Security
Kit
(Optional)
Installation Instructions
RSA Projector Mounts
1
(not included)
RSA INSTALLATION
Threaded Pipe Installation
1.
IMPORTANT ! : This will require knowing the
lens to screen distance. See projector
specifications for details on determining this
distance.
2
(not included)
2.
4
Carefully determine required mounting location.
3
Using a pipe wrench, install 1-1/2" NPT or NPSM
following ANSI/ASME B1.20.1 (Schedule 40,
0.154" minimum thickness steel or aluminum ASTM B221) threaded extension column (not
included) into threaded collar until tight, with a
minimum of four threads engaged.
WARNING: IMPROPER INSTALLATION CAN
RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Structural members
MUST be capable of supporting five times the
combined weight of all equipment being mounted.
3.
Align RSA with end of NPT pipe.
4.
Thread RSA up onto pipe by turning counterclockwise until hand tight.
(A)
Rough Alignment of RSA
1.
2
Turn RSA clockwise or counter-clockwise until front
of mount is facing target.
IMPORTANT ! : When RSA is properly
positioned, the set screw access hole should be
pointing directly at target.
(see bottom detail in figure at left)
1
(A)
2.
Secure RSA to pipe by turning set screw with a
5/32" hex key until tight.
CAUTION: DO NOT OVERTIGHTEN! Over
tightening of set screw can damage threads on pipe.
1
5
RSA Projector Mounts
Installation Instructions
INSTALLATION
Wood Stud Installation
1a
1.
Carefully determine required mounting location.
IMPORTANT ! : This will require knowing the lens
to screen distance. See projector specifications for
details on determining this distance.
1
WARNING: IMPROPER INSTALLATION CAN
RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Structural members
MUST be capable of supporting five times the
combined weight of all equipment being mounted.
IMPORTANT ! : The RSA mounts are designed to be
mounted to double 2" x 4" wood stud cross bracing
(1-1/2" on center) between two ceiling joists.
X4
2
Ø 2.5mm
(Ø 3/32”)
X4
2.
Using the RSA as a guide, mark four mounting hole
locations with a pencil or similar tool. Hole locations
must be centered on 2" x 4" cross braces.
3.
Drill four 3/32" (2.5mm) dia. pilot holes to a depth of
1-3/4" (45mm) deep.
4.
Align four mounting holes in RSA with four pilot
holes.
45mm
(1-3/4”)
3
IMPORTANT ! : Make sure mount is properly
oriented towards target before securing to
structure.
5.
4
(A)
x4
5
6
Secure RSA to structure using four #10 flat washers
and four #10 x 3" Phillips head wood screws (not
included).
Installation Instructions
RSA Projector Mounts
Solid Concrete Installation
1b
1.
Determine mounting location.
WARNING: The RSA is designed to be mounted to
a concrete ceiling with a minimum thickness of 8" and
a maximum drywall covering of 5/8".
1
WARNING: IMPROPER INSTALLATION CAN
RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Structural members
MUST be capable of supporting five times the
combined weight of all equipment being mounted.
X4
2
2.
Using the RSA as a guide, mark four mounting hole
locations on ceiling using a pencil or similar tool.
3.
Drill four 1/4" (6.3mm) diameter pilot holes to a
depth of 2-1/2" (64mm) deep.
4.
Align four mounting holes in RSA with four pilot
holes.
Ø 6.3mm
(Ø 1/4”)
X4
3
64mm
(2-1/2”)
IMPORTANT ! : Make sure mount is properly
oriented towards target before securing to
structure.
WARNING: Anchors (not provided) must be
installed into structurally sound solid concrete.
Installation into hollow concrete block, mortar, or
concrete that exhibits cracking, spalling, or other
defects may result in failure of anchor and serious
personal injury or damage to equipment.
X (4)
5
5.
Install four 3/8" x 2-1/4" Grade 2 concrete anchors
(not included) by inserting into pilot holes and
pounding in until flush with mounting surface.
6.
Secure RSA to structure using four #10 flat washers
and four #10 x 3" Phillips head wood screws. (not
included)
(A)
X4
6
7
RSA Projector Mounts
1c
Installation Instructions
1
Threaded Rod Installation
2
The RSA must be suspended from four 1/4" diameter
(minimum) Grade 2 or better threaded rods (not
included) which are secured to unistrut, angle or
channel assembly overhead structural members
(trusses or I-beams) by Grade 2 or better 1/4" channel
nuts (not included).
WARNING: IMPROPER INSTALLATION CAN
4
RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Structural members
MUST be capable of supporting five times the
combined weight of all equipment being mounted.
Ø 2.5mm
(Ø 3/32”)
1.
Carefully determine required mount position.
IMPORTANT ! : This will require knowing the lens
to screen distance. See projector specifications
for determining this distance.
NOTE: Threaded rod and installation hardware not
(A)
included.
2.
Secure one end of the threaded rod to the structural
member.
3.
Install four #10-24 jam nuts on each threaded rod.
4.
Install the RSA on the threaded rod.
5
X4
NOTE: Hole in the RSA allows socket wrench access
without unit disassembly.
2
2
45mm
(1-3/4”)
5.
Secure the RSA to the threaded rod using four 1/4"
channel nuts.
PROJECTOR INSTALLATION
IMPORTANT ! : Model RSA uses optional Chief
"SSB" Series interface brackets. (See Parts
drawing.)
Install Interface Bracket
1.
Partially thread thumb nuts onto Phillips screws until
screw end is visible in top of thumb screw.
IMPORTANT ! : DO NOT fully tighten thumb
screws at this time.
Example Only
(Interface bracket
varies dependent
on projector model)
8
Installation Instructions
RSA Projector Mounts
Example Only
(Interface bracket
varies dependent
on projector model)
2a
WARNING: IMPROPER INSTALLATION CAN
LEAD TO PROJECTOR FALLING RESULTING IN
SERIOUS PERSONAL INJURY OR DAMAGE TO
EQUIPMENT. DO NOT substitute hardware. Use only
the hardware provided by the manufacturer.
1
1.
Secure interface bracket to mount using installation
instructions and hardware provided with interface
bracket.
NOTE: Interface brackets can be installed using the
optional All-Points Security Kit included with
the SSB mounting solutions.
2b
Example Only
(Interface bracket
varies dependent
on projector model)
Install Projector With Interface Bracket
1.
Orient projector with interface bracket as shown in
figure 2b at left.
2.
Lift projector so that screws with thumb nuts are
aligned with mounting slots in mount base.
3.
Slide projector with mounting bracket onto mounting
slots in mount base until screws are seated against
the back of mounting slots. See figure 2b and 2c.
(A)
1
WARNING: IMPROPER INSTALLATION CAN
LEAD TO PROJECTOR FALLING RESULTING IN
SERIOUS PERSONAL INJURY OR DAMAGE TO
EQUIPMENT. Make certain mounting slots in mount
base slide under thumb screws and that screws are
seated in the back of slots.
9
RSA Projector Mounts
Installation Instructions
Example Only
(Interface bracket
varies dependent
on projector model)
2c
Securing Projector with Interface Bracket
to Model RSA Mount.
WARNING: IMPROPER INSTALLATION CAN
LEAD TO PROJECTOR FALLING RESULTING IN
SERIOUS PERSONAL INJURY OR DAMAGE TO
EQUIPMENT. Make certain mounting slots in mount
base slide under thumb screws and that screws are
seated in the back of slots.
1.
1
10
X4
Turn thumb nuts until tight to secure projector to
mount.
Installation Instructions
RSA Projector Mounts
3
Example Only
(Interface bracket
varies dependent
on projector model)
ADJUSTMENTS
YAW Adjustment
1.
Loosen yaw adjustment screw using a 5/32" hex
key.
NOTE: Yaw is only adjustable when attached to a
threaded pipe.
WARNING: Do not turn the projector to the end of
the pipe threads. The projector, interface plate and
projector will fall from the pipe if it is unthreaded too
far! A minimum of four threads must be engaged in
order to ensure a secure connection!
2.
Adjust projector by turning the projector on the pipe
to the desired yaw position.
3.
Tighten yaw adjustment locking screw using a 5/32"
hex key.
2
3
1
3a
Pitch Adjustment
Example Only
(Interface bracket
varies dependent
on projector model)
1.
Loosen pitch adjustment locking screw on each end
of the RSA projector mount using a #2 Phillips
screwdriver.
2.
Adjust projector angle to desired pitch.
3.
Tighten pitch adjustment locking screw on each end
of the RSA projector mount using a #2 Phillips
screwdriver.
2
1
3
11
RSA Projector Mounts
Installation Instructions
3b
1
Roll Adjustment
1.
Loosen roll adjustment locking screw on each side
of the RSA projector mount using a #2 Phillips
screwdriver.
2.
Adjust projector to desired roll position.
3.
Tighten roll adjustment locking screw on each side
of the RSA projector mount using a #2 Phillips
screwdriver.
3
Example Only
(Interface bracket
varies dependent
on projector model)
2
12
Installation Instructions
RSA Projector Mounts
13
RSA Projector Mounts
14
Installation Instructions
Installation Instructions
RSA Projector Mounts
15
RSA Projector Mounts
Installation Instructions
USA/International
Europe
Chief, a products division of
Milestone AV Technologies
8800-002643 Rev00
2014 Milestone AV Technologies
www.chiefmfg.com
09/14
Asia Pacific
A
P
F
A
P
F
A
6436 City West Parkway, Eden Prairie, MN 55344
800.582.6480 / 952.225.6000
877.894.6918 / 952.894.6918
Franklinstraat 14, 6003 DK Weert, Netherlands
+31 (0) 495 580 852
+31 (0) 495 580 845
Office No. 918 on 9/F, Shatin Galleria
18-24 Shan Mei Street
Fotan, Shatin, Hong Kong
P 852 2145 4099
F 852 2145 4477
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
