Key Features Design Versatility Security Camera/Video

Key Features Design Versatility Security Camera/Video
• 5.5" Quad HD Display (4x HD Quality)
• Rear Key Placement – ambidextrous, multi-purpose use of Power/Lock
and Volume Keys with quick shortcuts to QuickMemo+ or Camera
• Smart Keyboard – customize position of the keyboard or keypad for
convenient one-handed access
• Streamlined UI – simplified user interface with consolidated apps
and modern flat iconic style
• Corning® Gorilla® Glass 3 Screen Protection
• Customizable Home Touch Buttons – includes Notifications,
QuickMemo+, QSlide Function, and Dual Window
• QuickRemote™ – control compatible TVs, audio systems, cable
provider set-top boxes, and more
• Loud and Clear Sound – 1W speaker with 1.5W booster amp produces
loud and articulate sound with deep bass and reduced clipping
• Live Zooming – zoom in/out on videos during playback
• Video Player with Touch Lock and Resume Play Function; supports
DivX,® WMV, MP4, 3GP, 3G2, AVI, MKV, ASF, WebM, and FLV formats
• Customizable Video Screen Ratio, Subtitle Settings, Playback
Speed, and Video Auto Off Function
• Edit Recorded Movies with Video Trim
• Music Player with Custom Audio Effects and Sleep Timer:
supports AAC, AAC+, eAAC+, M4A, AMR, MP3, MIDI, WAV, WMA,
and Ogg formats
• Customizable Music Library – organized by song, album, artist,
and genre
• Media Device (MTP) – transfer files or synchronize with Windows®
Media Player or Android™ File Transfer1
• USB1 and Bluetooth® Tethering – share your phone’s Internet
connection with your computer
• Accelerometer – control games by turning and tilting the phone2
Key Features
• Smart Notice – interprets a range of contextual inputs and device
usage patterns, and provides recommendations that change with
the user’s intent
• Smart Cleaning – free up space by deleting temporary files and
removing infrequently used apps
• LG Health – manage daily activities, record health information, track
weather conditions to take control of your fitness*
• QuickMemo+ – write or draw on any screen
• QSlide Function – overlay up to two windows with adjustable
sizing and transparency on the primary screen for advanced and
convenient multitasking
• Dual Window – use two apps simultaneously on a split screen
• ThinkFree Viewer – PC-like office suite app for viewing documents,
presentations, and spreadsheets
• Smart Screen – display setting keeps the screen active when phone
detects eye movement
• Notification LEDs – colored light alerts for incoming calls, missed
calls and messages, and more
• Quiet Mode – specify times to turn off all sounds except alarm
and media
• Multilanguage Support for Phone and Keyboard Input
• EasyHome – show the dialer and other frequently used features
right on the home screen for quick and easy access
5.5" Quad HD Display with 538 ppi
* This app is not intended to diagnose, treat or prevent any disease or medical
condition. Always seek the advice of a qualified medical professional before making
any changes to your exercise, sleep, or nutrition.
Long-Lasting 3,000 mAh Removable Battery
Intuitive Rear Key Placement for Ambidextrous Use
• Knock Code – create a 3-8 point tapping pattern for superior
security and direct access to the home screen with over 86,000
possible combinations
• KnockON – double tap the screen to put your phone to sleep/wake
it without picking it up or pressing the Power/Lock Key
• Content Lock – password protect certain images and videos in
Gallery; prevent files from being previewed when linked to a PC1
• Guest Mode – create a separate unlock screen pattern for guests
with pre-set access and restrictions2
• Privacy Keeper – hide caller information for incoming calls; tap
screen to reveal information
5.36 oz.
Colors: Metallic Black, Silk White
Advanced 13 MP OIS+ Laser Auto Focus Camera
Easy-Input Customizable Smart Keyboard
Secure Your Phone with Knock Code™
Qualcomm® Snapdragon™ 801 Quad-Core Processor
up to 2.5 GHz
Some owner content may still be accessible to a user that enables Content Lock.
Some owner/personal content and information may still be accessible to a user in
Guest Mode.
LG Electronics USA, Inc.
920 Sylvan Avenue
Englewood Cliffs, NJ 07632
Cust. Service: (800) 793-8896
• 13 MP OIS+ Laser Auto Focus Camera with Dual Flash
• Laser Auto Focus – adjusts focus by measuring distance to subject
using a laser, allowing faster focus speed even in low-light situations
• Soft Light – screen will illuminate a soft light around the photo
preview for well-lit selfies
• 4k Ultra HD Camcorder with 120 FPS Slow Motion Recording1
• 2.1 MP Full HD Front-Facing Camera and Full HD Camcorder
• Camera Resolutions: up to 4160 x 31201 (4160 x 2340 default)
• Shot Mode – Auto, Dual, Panorama,1 Dynamic Tone (HDR), and
Magic Focus1
• Burst Shot – hold the shutter button to take multiple shots quickly
• Gesture Shutter2 – take selfies with a simple hand gesture
• Multiple Shutter Options – tap the shutter, tap the screen, use your
voice, or press a volume key to take a photo
• Image Editor – add frames and much more to your pictures
• Video Resolutions: up to 3840 x 21601 (1920 x 1080 default)
• Dual Recording/Dual Camera – front and rear cameras take pictures
or videos with picture-in-picture technology
• Pause & Resume Recording – pause and start in record mode for
one continuous video file
• Live Shot – take still shots while recording video3
• Geotagging – include location information with photos and videos
USB cable required (included).
Only available on certain interactions with the touch screen.
• AT&T 4G LTE Network1
• Mobile Hotspot† – share a 4G LTE data connection with up to
8 compatible wireless devices2
• Bluetooth Wireless Technology Version 4.0
• Wi-Fi® Connectivity – 802.11 a/b/g/n/ac
• Miracast® – enjoy your phone’s content on a compatible larger screen
• SmartShare Beam – wirelessly receive multimedia content from
compatible LG devices
• Android Beam – share contacts, web pages, and more via
Near Field Communication (NFC)
• Media Server – allow compatible nearby devices to access your
content via DLNA®
• S-GPS For Enhanced Location Accuracy
AT&T’s 4G LTE Network not available everywhere.
Depends on network availability. Additional carrier charges may apply.
Display: 5.5" Quad HD (2560 x 1440) IPS Display with 538 ppi
Battery Capacity: 3,000 mAh
Platform: Android 4.4 (KitKat)
Technology: GSM, LTE
Processor: Qualcomm Snapdragon 801 Quad-Core up to 2.5 GHz
Network: GSM Quad Band/UMTS Tri Band/LTE
Frequencies: GSM 850/900/1800/1900 MHz, UMTS
850/1900/2100, LTE Bands 2/4/5/17/29, Roaming 1/3/7, and CA
Data Transmission: GPRS, EDGE, UMTS, HSPA+, LTE
Dimensions: 5.76" (H) x 2.94" (W) x 0.35" (D)
Weight: 5.36 oz.
Talk Time: up to 21 hours1
Standby Time: up to 28 days1
Internal Memory: 32 GB (up to 24 GB user memory);
supports microSD™ card up to 2 TB2
Available Colors: Metallic Black, Silk White
Certain features may use more power and cause actual time to vary.
microSD card sold separately.
Standard Battery*
Travel Adaptor and USB Cable*
LG Quick Circle™ Wireless Charging Folio Case
Bluetooth Mono Headset (HBM-290)
Bluetooth Stereo Headset (LG TONE ULTRA™ HBS-800,
• Miracast Certified Wireless HDMI® Adaptor (DWD-300)
• Vehicle Power Adaptor
* Included with phone.
Available only on rear-facing camera or camcorder.
Available only on front-facing camera or camcorder.
Not available in UHD camcorder setting.
AT&T Wireless service required. Product features subject to change. Features based on carrier program availability. Additional charges may apply.
All materials in this brochure including, without limitation, the design, the text, and any marks are the property of LG Electronics, Inc. Copyright © 2014 LG Electronics USA, Inc. ALL RIGHTS RESERVED. LG, LG Life’s Good, and the LG logo are registered trademarks of LG Corp. The Bluetooth word mark and
logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics USA, Inc. is under license. 4G LTE not available everywhere. LTE is a trademark of ETSI. Learn more at AT&T, the AT&T logo, and all other AT&T marks contained herein are trademarks
of AT&T Intellectual Property. Google and Android are trademarks of Google Inc. Wi-Fi is a registered trademark of Wi-Fi Alliance. Other trademarks and trade names are those of their respective owners. Unless otherwise specified herein, all accessories referenced herein are sold separately. All features,
functionality, and other product specifications are subject to change without notice. Screen shots are simulated and subject to change.
