CLP-775 Series
Color Laser Printer
User’s Guide
imagine the possibilities
Thank you for purchasing a Samsung product.
copyright
© 2011 Samsung Electronics Co., Ltd. All rights reserved.
This user’s guide is provided for information purposes only. All information included herein is subject to change without notice.
Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this user’s guide.
•
•
•
•
•
•
•
•
Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
PCL and PCL 6 are trademarks of Hewlett-Packard Company.
Microsoft, Windows, Windows Vista, Windows 7 and Windows 2008 Server R2 are either registered trademarks or trademarks of Microsoft Corporation.
PostScript 3 is a trademark of Adobe System, Inc.
UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc.
TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc.
All other brand or product names are trademarks of their respective companies or organizations.
Refer to the 'LICENSE.txt' file in the provided CD-ROM for the open source license information.
REV 1.04
Copyright_ 2
safety information
These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to
your machine. Be sure to read and understand all of these instructions before using the machine.
Use common sense for operating any electrical appliance and whenever using your machine. Also, follow all warnings and
instructions marked on the machine and in the accompanying literature. After reading this section, keep it in a safe place
for future reference.
Important safety symbols
This section explains the meanings of all icons and signs in the user's guide. These safety symbols are in order, according to the degree of
danger.
Explanation of all icons and signs used in the user’s guide:
Warning
Hazards or unsafe practices that may result in severe personal injury or death.
Caution
Hazards or unsafe practices that may result in minor personal injury or property damage.
Do not attempt.
Do not disassemble.
Do not touch.
Unplug the power cord from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Follow directions explicitly.
Operating environment
Warning
Do not use if the power cord is damaged or if the
electrical outlet is not grounded.
► This could result in electric shock or fire.
Do not bend, or place heavy objects on the power
cord.
► Stepping on or allowing the power cord to be
crushed by a heavy object could result in electric
shock or fire.
Do not place anything on top of the machine (water,
small metal or heavy objects, candles, lit cigarettes,
etc.).
► This could result in electric shock or fire.
Do not remove the plug by pulling on the cord; do not
handle the plug with wet hands.
► This could result in electric shock or fire.
Safety information_ 3
•If the machine gets overheated, it releases smoke,
makes strange noises, or generates an odd odor,
immediately turn off the power switch and unplug the
machine.
•The user should be able to access the power outlet
in case of emergencies that might require the user to
pull the plug out.
► This could result in electric shock or fire.
Caution
During an electrical storm or for a period of
non-operation, remove the power plug from the
electrical outlet.
► This could result in electric shock or fire.
If the plug does not easily enter the electrical outlet, do not
attempt to force it in.
► Call an electrician to change the electrical outlet, or this
could result in electric shock.
Be careful, the paper output area is hot.
► Burns could occur.
Do not allow pets to chew on the AC power, telephone or PC
interface cords.
► This could result in electric shock or fire and/or injury to your
pet.
If the machine has been dropped, or if the cabinet appears
damaged, unplug the machine from all interface connections
and request assistance from qualified service personnel.
► Otherwise, this could result in electric shock or fire.
If the machine does not operate properly after these
instructions have been followed, unplug the machine from all
interface connections and request assistance from qualified
service personnel.
► Otherwise, this could result in electric shock or fire.
If the machine exhibits a sudden and distinct change in
performance, unplug the machine from all interface
connections and request assistance from qualified service
personnel.
► Otherwise, this could result in electric shock or fire.
Operating method
Caution
Do not forcefully pull the paper out during printing.
► It can cause damage to the machine.
When printing large quantities, the bottom part of the
paper output area may get hot. Do not allow children
to touch.
► Burns can occur.
Be careful not to put your hand between the machine
and paper tray.
► You may get injured.
When removing jammed paper, do not use tweezers
or sharp metal objects.
► It can damage the machine.
Do not block or push objects into the ventilation opening.
► This could result in elevated component temperatures which
can cause damage or fire.
Safety information_ 4
Do not allow too many papers to stack up in the paper output
tray.
► It can damage the machine.
Be care when replacing paper or removing jammed paper.
► New paper has sharp edges and can cause painful cuts.
This machine's power interception device is the power cord.
► To switch off the power supply, remove the power cord from
the electrical outlet.
Installation / Moving
Warning
Do not place the machine in an area with dust,
humidity or water leaks.
► This could result in electric shock or fire.
Caution
Before moving the machine, turn the power off and
disconnect all cords.
Then lift the machine:
• If the machine weighs under 20 kg (44.09lbs), lift
with 1 person.
• If the machine weighs 20 kg (44.09lbs) - 40kg
(88.18lbslbs), lift with 2 people.
• If the machine weighs more than 40 kg (88.18lbs),
lift with 4 or more people.
► The machine could fall, causing injury or machine damage.
Do not put a cover over the machine or place it in an airtight
location, such as a closet.
► If the machine is not well-ventilated, this could result in fire.
Do not place the machine on an unstable surface.
► The machine could fall, causing injury or machine damage.
Make sure you plug the power cord into a grounded electrical
outlet.
► Otherwise, this could result in electric shock or fire.
The machine should be connected to
the power level which is specified on the label.
► If you are unsure and want to check the power level you are
using, contact the electrical utility company.
Do not overload wall outlets and extension cords.
► This can diminish performance, and could result in electric
shock or fire.
Use only No.26 AWGa or larger, telephone line cord, if
necessary.
► Otherwise, it can cause damage to the machine.
Use the power cord supplied with your machine for safe
operation. If you are using a cord which is longer than 2 meters
(6 feet) with a 140V machine, then the gauge should be 16
AWG or larger.
► Otherwise, it can cause damage to the machine, and could
result in electric shock or fire.
a. AWG: American Wire Gauge
Safety information_ 5
Maintenance / Checking
Caution
Unplug this product from the wall outlet before
cleaning the inside of the machine. Do not clean the
machine with benzene, paint thinner or alcohol; do
not spray water directly into the machine.
► This could result in electric shock or fire.
Keep cleaning supplies away from children.
► Children could get hurt.
When you are working inside the machine replacing
supplies or cleaning the inside, do not operate the
machine.
► You could get injured.
Do not disassemble, repair or rebuild the machine by
yourself.
► It can damage the machine. Call a certified
technician when the machine needs repair.
Keep the power cable and the contact surface of the plug clean
from dust or water.
► Otherwise, this could result in electric shock or fire.
To clean and operate the machine, strictly follow the user's
guide provided with the machine.
► Otherwise, you could damage the machine.
Do not remove any covers or guards that are fastened with
screws.
•Do not remove any covers or guards that are fastened with
screws.
•Fuser units should only be repaired by a certified service
technician. Repair by non-certified technicians could result in
fire or electric shock.
► The machine should only be repaired by a Samsung service
technician.
Supply usage
Caution
Do not disassemble the toner cartridge.
► Toner dust can be dangerous if inhaled or
ingested.
Do not burn any of the supplies such as toner
cartridge or fuser unit.
► This could cause an explosion or uncontrollable
fire.
When changing the toner cartridge or removing jammed paper,
be careful not to let toner dust touch your body or clothes.
► Toner dust can be dangerous if inhaled or ingested.
Safety information_ 6
When storing supplies such as toner cartridges, keep
them away from children.
► Toner dust can be dangerous if inhaled or
ingested.
Using recycled supplies, such as toner, can cause damage to
the machine.
► In case of damage due to the use of recycled supplies, a
service fee will be charged.
When toner gets on your clothing, do not use hot water to wash
it.
► Hot water sets toner into fabric. Use cold water.
regulatory information
This machine is designed for our sound environment and certified with several regulatory statements.
Laser safety statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and
elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1 : 2007.
Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to
laser radiation above a Class I level during normal operation, user maintenance or prescribed service condition.
Warning
Never operate or service the printer with the protective cover removed from laser/scanner assembly. The reflected beam, although invisible,
can damage your eyes.
When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to persons:
Ozone safety
This product's ozone emission rate is under 0.1 ppm. Because ozone is heavier than air, keep the product in a place with good ventilation.
Regulatory information_ 7
Power saver
This printer contains advanced energy conservation technology that reduces power consumption when it is not in
active use.
When the printer does not receive data for an extended period of time, power consumption is automatically lowered.
ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.
For more information on the ENERGY STAR program see http://www.energystar.gov
Recycling
Recycle or dispose of the packaging material for this product in an environmentally responsible manner.
China only
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for disposal.
The United States of America only
Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our
website:www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
Regulatory information_ 8
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed with other household
waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium
or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to
human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your
local, free battery return system.
Radio Frequency Emissions
FCC Information to the User
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or experienced radio TV technician for help.
Change or modifications not expressly approved by the manufacturer responsible for compliance could void the user's authority to
operate the equipment.
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la
norme sur le matériel brouilleur: “Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
RFID (Radio Frequenty Interface Device)
RFID operation is subject to the following two conditions:(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device. (U.S.A., France, Taiwan only)
Regulatory information_ 9
Taiwan only
Russia only
Turkey only
Replacing the Fitted Plug (for UK Only)
Important
The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the
fuse, you must re-fit the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do not use the plug until
you have another fuse cover.
The 13 amp plug is the most widely used type in the UK and should be suitable. However, some buildings (mainly old ones) do not have normal
13 amp plug sockets. You need to buy a suitable plug adaptor. Do not remove the moulded plug.
If you cut off the moulded plug, get rid of it straight away.
You cannot rewire the plug and you may receive an electric shock if you plug it into a socket.
Regulatory information_ 10
Important warning:
You must earth this machine.
The wires in the mains lead have the following color code:
• Green and Yellow: Earth
• Blue: Neutral
• Brown: Live
If the wires in the mains lead do not match the colors marked in your plug, do the following:
You must connect the green and yellow wire to the pin marked by the letter “E” or by the safety ‘Earth symbol’ or colored green and yellow or
green.
You must connect the blue wire to the pin which is marked with the letter “N” or colored black.
You must connect the brown wire to the pin which is marked with the letter “L” or colored red.
You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.
Declaration of Conformity (European Countries)
Approvals and Certifications
Hereby, Samsung Electronics, declares that this [CLP-775 Series] is in compliance with the essential requirements and other relevant
provisions of R&TTE Directive (1999/5/EC).
The declaration of conformity may be consulted at www.samsung.com/printer, go to Support > Download center and enter your printer (MFP)
name to browse the EuDoC.
January 1, 1995: Council Directive 2006/95/EC Approximation of the laws of the member states related to low voltage equipment.
January 1, 1996: Council Directive 2004/108/EC, approximation of the laws of the Member States related to electromagnetic compatibility.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and telecommunications terminal equipment and the mutual recognition of
their conformity. A full declaration, defining the relevant Directives and referenced standards can be obtained from your Samsung Electronics
Co., Ltd. representative.
European radio approval information (for products fitted with EU-approved radio devices)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz/5 GHz band, may be
present (embedded) in your printer system which is intended for home or office use. This section is only applicable if these devices are present.
Refer to the system label to verify the presence of wireless devices.
Wireless devices that may be in your system are only qualified for use in the European Union or associated areas if a CE mark with
a Notified Body Registration Number and the Alert Symbol is on the system label.
The power output of the wireless device or devices that may be embedded in you printer is well below the RF exposure limits as set by the
European Commission through the R&TTE directive.
European states qualified under wireless approvals:
EU countries
European states with restrictions on use:
EU
In France, the frequency range is restricted to 2454-2483.5 MHz for devices above 10 mW transmitting power such as wireless
EEA/EFTA countries
No limitations at this time
Regulatory information_ 11
Regulatory Compliance Statements
Wireless Guidance
Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz/5 GHz Band, may be
present (embedded) in your printer system. The following section is a general overview of considerations while operating a wireless device.
Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections). The
wireless devices in your system are only qualified for use in the countries identified by the Radio Approval Marks on the system rating label. If
the country you will be using the wireless device in, is not listed, contact your local Radio Approval agency for requirements. Wireless devices
are closely regulated and use may not be allowed.
The power output of the wireless device or devices that may be embedded in your printer is well below the RF exposure limits as known at this
time. Because the wireless devices (which may be embedded into your printer) emit less energy than is allowed in radio frequency safety
standards and recommendations, manufacturer believes these devices are safe for use. Regardless of the power levels, care should be taken
to minimize human contact during normal operation.
As a general guideline, a separation of 20 cm (8 inches) between the wireless device and the body, for use of a wireless device near the body
(this does not include extremities) is typical. This device should be used more than 20 cm (8 inches) from the body when wireless devices are
on and transmitting.
This transmitter must not be collocated or operation in conjunction with any other antenna or transmitter.
Some circumstances require restrictions on wireless devices. Examples of common restrictions are listed below:
Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations
require wireless devices to be turned off while traveling in an airplane. IEEE 802.11 (also known as wireless Ethernet) and
Bluetooth communication devices are examples of devices that provide wireless communication.
In environments where the risk of interference to other devices or services is harmful or perceived as harmful, the option to use a
wireless device may be restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas laden atmospheres are limited
examples where use of wireless devices may be restricted or eliminated. When in environments where you are uncertain of the
sanction to use wireless devices, ask the applicable authority for authorization prior to use or turning on the wireless device.
Every country has different restrictions on the use of wireless devices. Since your system is equipped with a wireless device,
when traveling between countries with your system, check with the local Radio Approval authorities prior to any move or trip for
any restrictions on the use of a wireless device in the destination country.
If your system came equipped with an internal embedded wireless device, do not operate the wireless device unless all covers
and shields are in place and the system is fully assembled.
Wireless devices are not user serviceable. Do not modify them in any way. Modification to a wireless device will void the
authorization to use it. Contact manufacturer for service.
Only use drivers approved for the country in which the device will be used. See the manufacturer System Restoration Kit, or
contact manufacturer Technical Support for additional information.
Israel only
Regulatory information_ 12
China only
Regulatory information_ 13
about this user’s guide
This user’s guide provides information about basic understanding of the machine as well as detailed explanation on each
step during actual usage. Valuable for both novice and professional users can refer to this as a guide for installing and
using the machine.
•
•
•
•
•
•
Read the safety information before using the machine.
If you have a problem using the machine, refer to the troubleshooting chapter. (See "Troubleshooting" on page 68.)
Terms used in this user’s guide are explained in the glossary chapter. (See "Glossary" on page 96.)
Use Index to find information.
All illustrations in this user’s guide may differ from your machine depending on its options or models.
The procedures in this user’s guide are mainly based on Windows 7.
Convention
Some terms in this guide are used interchangeably, as below:
• Document is synonymous with original.
• Paper is synonymous with media, or print media.
• Machine refers to printer or MFP.
The following table offers the conventions of this guide:
Convention
Description
Example
Bold
For texts on the display or button names on the machine.
Note
Provides additional information or detailed specification of the machine function
and feature.
The date format may differ from country
to country.
Caution
Gives users information to protect the machine from possible mechanical
damage or malfunction.
Do not touch the green underside of the
toner cartridge.
Footnote
Provides additional more detailed information on certain words or a phrase.
a. pages per minute
(“Cross-reference”)
Guides users to a reference page for the additional detailed information.
(See "Finding more information" on
page 15.)
About this user’s guide_ 14
Start
Finding more information
You can find information for setting up and using your machine from the following resources, either as a print-out or on screen.
Material name
Description
Quick Installation
Guide
This guide provides information on setting up your machine and this requires that you follow the instructions in the guide to prepare the
machine.
Online User’s Guide
This guide provides you with step-by-step instructions for using your machine’s full features, and contains information for maintaining
your machine, troubleshooting, and installing accessories.
Network Website
You can set the network environment from your computer using network-managing programs, such as SetIP, SyncThru™ Web Admin
Service, Samsung AnyWeb Print etc. SyncThru™ Web Admin Service will be convenient for network administrators who need to
manage many machines simultaneously. Samsung AnyWeb Print helps personal users to screen-capture the website screen in
Windows Internet Explorer easily. You can download the SyncThruTM Web Admin Service or Samsung AnyWeb Print on
http://solution.samsungprinter.com. SetIP program is provided in the software CD.
Machine Driver Help
This help provides you with help information on printer driver and instructions for setting up the options for printing. (See "Using help"
on page 53.)
Samsung website
If you have Internet access, you can get help, support, machine drivers, manuals, and order information from the Samsung website,
www.samsungprinter.com.
About this user’s guide_ 15
features of your new product
Your new machine is equipped with a number of special features that improve the quality of the documents you print.
Special Features
Print with excellent quality and speed
Print in various environments
•
•
•
•
You can print with a resolution of up to 9600x600 dpi
effective output.
Your machine prints A4-sized paper at up to 33 ppm and
letter-sized paper at up to 35 ppm.
For duplex printing, your machine prints A4-sized paper at
up to 15 ipm and letter-sized paper at up to 16 ipm.
•
Handle many different types of printable material
•
•
The multi-purpose tray supports letterhead, envelopes,
labels, custom-sized media, postcards, and heavy paper.
The multi-purpose tray holds up to 100 sheets of plain paper.
The 500-sheet tray 1 and 500-sheet optional trays support
plain paper in various sizes. You can install up to 2 additional
trays.
Create professional documents (See "Using advanced print
features" on page 49.)
•
•
•
Print Watermarks. You can customize your documents with
words, such as “Confidential”.
Print Posters. The text and pictures of each page of your
document are magnified and printed across the sheet of
paper and can then be taped together to form a poster.
You can use preprinted forms and letterhead with plain
paper.
Save time and money (See "Using advanced print features"
on page 49.)
•
•
•
To save paper, you can print multiple pages on one single
sheet of paper.
This machine automatically conserves electricity by
substantially reducing power consumption when not in use.
To save paper, you can print on both sides of the paper
(double-sided printing).
Expand your machine’s capacity
•
This machine has an extra memory slot for adding more
memory. (See "Available supplies" on page 83.)
Features of your new product_ 16
You can print with Windows operating systems as well as
Linux, Macintosh and UNIX systems.
Your machine is equipped with a USB interface and a
network interface.
Features by Model
The machine is designed to support all of your document needs from printing to more advanced networking solutions for your business.
Features by model include:
Features
CLP-775 Series
USB 2.0
●
Hard Disk
Network Interface 802.11 b/g/n wireless LAN
○
○
a
Network Interface Ethernet 10/100/1000 Base TX wired LAN
●
Duplex (2-sided) printing
●
IEEE1284 Parallel Connectorb
○
Memory module
○
a. Depending on your country, wireless LAN cards may not be available. Contact your local Samsung dealer or the retailer where you
bought your printer
b. If you use the parallel port, you cannot use the USB cable.
( ●: Included, ○: Optional)
Features of your new product_ 17
introduction
1.
These are the main components of your machine:
This chapter includes:
•
•
Machine overview
Control panel overview
•
•
Understanding the control panel
Turning on the machine
Machine overview
Front view
1
Output tray
8
Front cover handle
2
Output support
9
Front cover
3
Paper level indicator
10
Control panel
4
Optional traya
11
Paper width guides on a
multi-purpose tray
5
Tray 1
12
Toner cartridge
6
Multi-purpose tray
13
Paper transfer belt
7
Multi-purpose tray handle
a. This is an optional feature.
Introduction_ 18
Rear view
1
Control board cover
6
Network port
2
Power receptacle
7
USB port
3
Power-switch
8
External device interface (EDI)a
4
Handle
9
IEEE 802.11 b/g/n Wireless
LANb
5
IEEE1284 Parallel
Connectorb
a. External device interface for Samsung and third party solutions.
b. This is an optional feature.
Introduction_ 19
Control panel overview
1
Display
Shows the current status and prompts during an operation.
2
Toner colors
Show the status of each toner cartridge. (See "Understanding the control panel" on page 21.)
3
(Menu)
Enters menu mode and scrolls through the available menus. (See "Accessing the Menu" on page 56.)
4
(Back)
Sends you back to the upper menu level.
5
Arrow
Scroll through the options available in the selected menu, and increase or decrease values.
6
OK
Confirms the selection on the screen.
7
(Stop)
Stops an operation at any time. The pop-up window appears on the screen showing the current job that the user can stop or
resume.
8
(Power)
You can also turn the power on and off with this button. (See "Buttons" on page 21.)
9
(Status LED)
Shows the status of your machine. (See "Understanding the control panel" on page 21.)
Introduction_ 20
Understanding the control panel
Buttons
(Menu button)
Status LED
When you want to know the machine status and set your machine to use an
advanced feature press
(menu button). (See "Accessing the Menu" on
page 56.)
The color of the status LED indicates the machine's current status.
Status
Off
Green
Blinking
Description
•
•
The machine is off-line.
The machine is in power saver mode. When
data is received, or any button is pressed, it
switches to on-line automatically.
•
When the LED blinks slowly, the machine is
receiving data from the computer.
When the LED blinks rapidly, the machine is
printing data.
•
Red
On
The machine is on-line and can be used.
Blinking
•
•
On
•
•
•
•
•
A minor error has occurred and the machine is
waiting for the error to be cleared. Check the
display message. When the problem is
cleared, the machine resumes.
Small amount of toner is left in the cartridge.
The estimated cartridge lifea of toner is close.
Prepare a new cartridge for replacement. You
may temporarily increase the printing quality
by redistributing the toner. (See
"Redistributing toner" on page 68.)
A toner cartridge has almost reached its
estimated cartridge lifea. It is recommended to
replace the toner cartridge. (See "Replacing
the toner cartridge" on page 84.)
A paper jam has occurred. (See "Clearing
paper jams" on page 69.)
The cover is opened. Close the cover.
There is no paper in the tray. Load paper in
the tray.
The machine has stopped due to a major
error. Check the display message. (See
"Understanding display messages" on
page 73.)
(Stop button)
By pressing the
(stop button), you can:
Function
Cancel print job
Description
Press
(stop button) during printing.
(Power button)
When you want to turn the power off, press this button until to turn the
power off. This button can also be used to turn the machine on.
Status
Description
Off
•
•
The machine is in ready mode.
The machine’s power is off.
On
The machine is in power save mode.
Turning on the machine
1. Plug in the power cord.
2. Turn the power-switch on.
a. Estimated cartridge life means the expected or estimated toner
cartridge life, which indicates the average capacity of print-outs and is
designed pursuant to ISO/IEC 19798. The number of pages may be
affected by operating environment, printing interval, media type, and
media size. Some amount of toner may remain in the cartridge even
when red LED is on and the printer stops printing.
Check the message on the display. Follow the instructions in the
message or refer to troubleshooting part. (See "Understanding display
messages" on page 73.). If the problem persists, call for service.
Introduction_ 21
If you want to turn the power off, press this button until to turn the
power off.
getting started
2.
This chapter gives you step-by-step instructions for setting up the USB connected machine and software.
This chapter includes:
•
•
Setting up the hardware
Supplied software
•
•
System requirements
Installing the driver locally
Setting up the hardware
This equipment will be inoperable when mains power fails.
This section shows the steps to set up the hardware, as is explained in the
Quick Install Guide. Make sure you read the Quick Install Guide first and
follow the steps below:
1. Select a stable location.
Select a level, stable place with adequate space for air circulation. Allow
extra space to open covers and trays.
The area should be well ventilated and away from direct sunlight or
sources of heat, cold, and humidity. Do not set the machine close to the
edge of your desk or table.
Supplied software
After you have set up your machine and connected it to your computer, you
must install the printer software. If you are a Windows or Macintosh OS,
install the software from the supplied CD and if you are a Linux OS user or
UNIX OS user, download the software from the Samsung website
(www.samsung.com/printer) and install.
Machine software are occasionally updated due to release of new
operating system and etc. If needed, download the latest version from
the Samsung website. (www.samsung.com/printer)
OS
Windows
Contents
•
•
•
Printer Manager combines device settings as well as
printing environments, settings/actions and
launching. All of these features provide a gateway to
conveniently use your Samsung machine.
Printing is suitable for altitudes under 1,000 m (3,281 ft). Refer to the
altitude setting to optimize your printing. (See "Altitude adjustment" on
page 40.)
Place the machine on a flat, stable surface so that there is no incline
greater than 2 mm (0.08 inch). Otherwise, printing quality may be
affected.
•
•
•
Macintosh
2.
3.
4.
5.
6.
7.
Printer driver: Use this driver to take full advantage
of your machine’s features.
PostScript printer driver: Use the PostScript driver
to print documents with complex fonts and graphics
in the PS language. (PostScript printer description
file is included.)
Samsung Easy Printer Manager: Samsung Easy
•
•
Unpack the machine and check all the enclosed items.
Remove tape holding the machine securely.
Install the toner cartridge.
Load paper. (See "Loading paper in the tray" on page 43.)
Make sure that all cables are connected to the machine.
Turn the machine on.
•
Getting started_ 22
Samsung Printing Status: This program allows
you to monitor the machine’s status and alerts you
when an error occurs during printing.
Direct Printing Utility: This program allows you to
print PDF files directly.
SetIP: Use this program to set your machine’s
TCP/IP addresses.
PostScript printer driver: Use this driver to run
your machine from a Macintosh computer and print
documents. (PostScript printer description file is
included.)
Smart Panel: This program allows you to monitor
the machine’s status and alerts you when an error
occurs during printing.
SetIP: Use this program to set your machine’s
TCP/IP addresses.
OS
Linux
•
•
•
•
UNIX
Macintosh
Contents
•
Unified Linux Driver: Use this driver to take full
advantage of your machine’s features.
Printer Description (PPD) file: Use this file to run
your machine from a Linux computer and print
documents.
Smart Panel: This program allows you to monitor
the machine’s status and alerts you when an error
occurs during printing.
SetIP: Use this program to set your machine’s
TCP/IP addresses.
UNIX PrinterDriver: Use this driver to print
documents from the UNIX system.
Requirements (Recommended)
Operating
system
Mac OS X 10.3 ~ •
10.4
•
CPU
RAM
free HDD
space
Windows®
2000
Intel® Pentium® II 400 MHz 64 MB (128
MB)
(Pentium III 933 MHz)
Windows® XP
Intel® Pentium® III 933
MHz (Pentium IV 1 GHz)
128 MB (256
MB)
1.5 GB
Windows
Server® 2003
Intel® Pentium® III 933
MHz (Pentium IV 1 GHz)
128 MB (512
MB)
1.25 GB to
2 GB
Windows
Server® 2008
Intel® Pentium® IV 1 GHz
(Pentium IV 2 GHz)
512 MB (2
GB)
10 GB
Windows
Vista®
Intel®
512 MB (1
GB)
15 GB
Windows® 7
Intel® Pentium® IV 1 GHz
32-bit or 64-bit processor
or higher
1 GB (2 GB)
16 GB
•
•
Windows
Server® 2008
R2
•
•
•
•
Pentium®
IV 3 GHz
600 MB
128 MB for a
powerPC based
Mac (512 MB)
512 MB for an
Intel-based Mac (1
GB)
1 GB
Mac OS X 10.5
•
•
Intel® processors 512 MB (1 GB)
867 MHz or faster
Power PC G4/ G5
1 GB
Mac OS X 10.6
•
Intel® processors 1 GB (2 GB)
1 GB
Items
Requirements
Operating
system
RedHat® Enterprise Linux WS 4, 5 (32/64 bit)
Fedora 5, 6, 7, 8, 9, 10, 11, 12, 13 (32/ 64 bit)
SuSE Linux 10.1 (32 bit)
OpenSuSE® 10.2, 10.3, 11.0, 11.1, 11.2 (32/64 bit)
Mandriva 2007, 2008, 2009, 2009.1, 2010 (32/64 bit)
Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10,
10.04 (32/64 bit)
SuSE Linux Enterprise Desktop 10, 11 (32/64 bit)
Debian 4.0, 5.0 (32/64 bit)
CPU
Pentium IV 2.4GHz (Intel Core™2)
RAM
512 MB (1 GB)
Free HDD space
1 GB (2 GB)
Unix
Support for DirectX® 9 graphics with 128 MB memory
(to enable the Aero theme).
DVD-R/W Drive
Intel® Pentium® IV 1 GHz
(x86) or 1.4 GHz (x64)
processors (2 GHz or
faster)
Intel® processors •
PowerPC G4/ G5
Linux
Requirement (recommended)
Operating
system
Free
HDD
space
RAM
•
System requirements
Microsoft® Windows®
CPU
512 MB (2
GB)
10 GB
Internet Explorer 6.0 or higher is the minimum requirement for all
Windows operating systems.
Users who have administrator rights can install the software.
Windows Terminal Services is compatible with your machine.
For Windows 2000, Services Pack 4 or higher is required.
Items
Requirements
Operating
system
Sun Solaris 9, 10 (x86, SPARC)
HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC,
Itanium)
IBM AIX 5.1, 5.2, 5,3, 5.4
Free HDD space
Up to 100 MB
Installing the driver locally
A locally connected machine is a machine directly attached to your
computer using the cable. If your machine is attached to a network, skip the
following steps below and go on to installing a network connected machine’s
driver. (See "Installing wired network connected machine’s driver" on
page 28.)
•
•
Getting started_ 23
If you are a Macintosh, Linux, or Unix OS user, refer to the
Advanced guide.
Selecting Advanced Installation > Custom Installation allows
•
you to choose which programs to install.
Only use a USB cable no longer than 3 meters (118 inches ).
install.
11. When the message which warns that all applications will close on your
computer appears, click Continue.
12. Select Typical installation for a local printer and then click OK.
Windows
1. Make sure that the machine is connected to your computer and powered
on.
If you select Typical installation for a network printer during the
machine driver installation, the SetIP program automatically runs.
If the machine has already configured network information, close
the SetIP program. Go to the next step.
If the “Found New Hardware Wizard” appears during the
installation procedure, click Cancel to close the window.
2. Insert the supplied software CD into your CD-ROM drive.
The software CD should automatically run and an installation window
will appear.
3. Select Install Now.
4. Read License Agreement and select I accept the terms of License
Agreement Then, click Next
5. Follow the instructions in the installation window.
13. After the installation is finished, click Quit.
14. Open the Applications folder > Utilities > Print Setup Utility.
• For Mac OS X 10.5~10.6, open the Applications folder > System
Preferences and click Print & Fax.
15. Click Add on the Printer List.
• For Mac OS X 10.5~10.6, click the “+” icon; a display window will pop
up.
16. For Mac OS X 10.3, select the USB tab.
• For Mac OS X10.4, click Default Browser and find the USB
connection.
• For Mac OS X 10.5~10.6, click Default and find the USB connection.
17. For Mac OS X 10.3, if Auto Select does not work properly, select
Samsung in Printer Model and your machine name in Model Name.
• For Mac OS X 10.4, if Auto Select does not work properly, select
Samsung in Print Using and your machine name in Model.
• For Mac OS X 10.5~10.6, if Auto Select does not work properly,
select Select a driver to use... and your machine name in Print
Using.
Your machine appears on the Printer List, and is set as the default
machine.
18. Click Add.
If the printer driver does not work properly, uninstall the driver and
reinstall it.
Follow steps below to uninstall the driver for Macintosh.
a) Make sure that the machine is connected to your computer and
powered on.
b) Insert the supplied software CD into your CD-ROM drive.
c) Double-click CD-ROM icon that appears on your Macintosh
desktop.
d) Double-click the MAC_Installer folder.
e) Double-click the Installer OS X icon.
f) Enter the password and click OK.
g) The Samsung Installer window opens. Click Continue.
h) Select Uninstall and click Uninstall.
i) When the message which warns that all applications will close on
your computer appears, Click Continue.
j) When the uninstall is done, click Quit.
If the printer driver does not work properly, follow the steps below to
uninstall and reinstall the driver.
a) Make sure that the machine is connected to your computer and
powered on.
b) From the Start menu, select Programs or All Programs >
Samsung Printers > your printer driver name > Uninstall.
c) Select the necessary option and follow the instructions in the
window.
d) After uninstalling the printer driver, reinstall it (see "Installing the
driver locally" on page 23, "Installing wired network connected
machine’s driver" on page 28).
Macintosh
1. Make sure that the machine is connected to your computer and powered
on.
2. Insert the supplied software CD into your CD-ROM drive.
3. Double-click the CD-ROM icon that appears on your Macintosh desktop.
4. Double-click the MAC_Installer folder.
5. Double-click the Installer OS X icon.
6. Enter the password and click OK.
7. The Samsung Installer window opens. Click Continue.
8. Read the license agreement and click Continue.
9. Click Agree to agree to the license agreement.
10. Select Easy Install and click Install. Easy Install is recommended for
most users. All components necessary for machine operations will be
installed.
If you select Custom Install, you can choose individual components to
Linux
You need to download the Linux software package from the Samsung
website to install the printer software.
Follow the steps below to install the software.
Installing the Linux Unified Driver
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type in root in the
Login field and enter the system password.
Getting started_ 24
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Unified Linux Driver
package to your computer.
4. Right click the Unified Linux Driver package and extract the
package.
5. Double click cdroot > autorun.
6. When the welcome screen appears, click Next.
7. When the installation is complete, click Finish.
The installation program has added the Unified Driver Configurator
desktop icon and the Unified Driver group to the system menu for your
convenience. If you have any difficulties, consult the on screen help that
is available through your system menu or can otherwise be called from
the driver package Windows applications, such as Unified Driver
Configurator or Image Manager.
Installing the SmartPanel
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type in root in the
Login field and enter the system password.
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Smart Panel package to
your computer.
4. Right click the Smart Panel package and extract the package.
5. Double click cdroot > Linux > smartpanel > install.sh.
Installing the Printer Settings Utility
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type in root in the
Login field and enter the system password.
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Printer Setting Utility
package to your computer.
4. Right click the Printer Settings Utility package and extract the
package.
5. Double click cdroot > Linux > psu > install.sh.
Getting started_ 25
If the printer driver does not work properly, uninstall the driver and
reinstall it again.
Follow the steps below to uninstall the driver for Linux.
a) Make sure that the machine is connected to your computer and
powered on.
b) When the Administrator Login window appears, type in “root”
in the Login field and enter the system password.
You must log in as a super user (root) to uninstall the printer
driver. If you are not a super user, ask your system
administrator.
c) Click the icon at the bottom of the desktop. When the Terminal
screen appears, type in:
[[email protected]lhost root]#cd /opt/Samsung/mfp/uninstall/
[[email protected] uninstall]#./uninstall.sh
d) Click Uninstall.
e) Click Next.
f) Click Finish.
network setup
3.
This chapter gives you step-by-step instructions for setting up the network connected machine and software.
This chapter includes:
•
•
•
•
•
Network environment
Introducing useful network programs
Using a wired network
•
•
If you are using wired network environment, see "Using a wired
network" on page 26.
If you are using wireless network environment, see "Wireless
network setup" on page 32.
Wireless network setup
IPv6 configuration
Introducing useful network programs
There are several programs available to setup the network settings easily in
network environment. For the network administrator especially, managing
several machines on the network is possible.
Before using the programs below, set the IP adress first.
Network environment
You need to set up the network protocols on the machine to use it as your
network machine. You can set up the basic network settings through the
machine's control panel.
The following table shows the network environments supported by the
machine:
Item
Network interface
Requirements
•
•
Network operating system •
•
•
•
Network protocols
•
•
•
•
•
•
Wireless Security
•
•
Ethernet 10/100/1000 Base-TX
802.11 b/g/n Wireless LAN (Optional)
Windows
2000/XP/2003/2008/Vista/7/2008
Server R2
Various Linux OS
Mac OS X 10.3 ~ 10.6
UNIX
SyncThru™ Web Service
Web server embedded on your network machine, which allows you to:
• Configure the network parameters necessary for the machine to connect
to various network environments.
• Customize machine settings.
(See "Using SyncThru™ Web Service" on page 60.)
SyncThru™ Web Admin Service
Web-based machine management solution for network administrators.
SyncThru™ Web Admin Service provides you with an efficient way of
managing network devices and lets you remotely monitor and troubleshoot
network machines from any site with corporate internet access. Download
this program from http://solution.samsungprinter.com.
SetIP
TCP/IPv4
DHCP, BOOTP
DNS, WINS, Bonjour, SLP, UPnP
Standard TCP/IP Printing(RAW), LPR,
IPP
SNMPv 1/2/3, HTTP(S), Telnet, SMTP,
IPSec
TCP/IPv6 (DHCP, DNS, RAW, LPR,
SNMPv 1/2/3, HTTP(S), IPSec
(See "IPv6 configuration" on page 39.)
This utility program allows you to select a network interface and manually
configure the IP addresses for use with the TCP/IP protocol. (See "Setting
IP address" on page 27)
TCP/IPv6 is not supported by this program.
Using a wired network
You must set up the network protocols on your machine to use it on your
network. This chapter will show you how this is easily accomplished.
You can use network after connecting network cable to a corresponding
port on your machine.
Authentication : Open System, Shared
Key, WPA Personal, WPA2 Personal
(PSK), WPA Enterprise, WPA2
Enterprise
Encryption : WEP64, WEP128, TKIP,
AES
Printing Network Configuration report
You can print a Network Configuration Report from the machine’s control
panel that will show the current machine’s network settings. This will help
you to set up a network and troubleshooting problems.
Network setup_ 26
1. Press
on the control panel.
2. Press up/down arrow to highlight Network and press OK.
3. Press up/down arrow to highlight Network Configuration and press
OK.
Using this Network Configuration Report, you can find your machine MAC
address and IP address.
For example:
• MAC Address : 00:15:99:41:A2:78
• IP Address : 192.0.0.192
7. Enter the machine’s new information into the configuration window
as follows. In a corporate intranet, you may need to have this
information assigned by a network manager before proceeding.
Setting IP address
First, you have to set up an IP address for network printing and
managements. In most cases a new IP address will be automatically
assigned by a DHCP (Dynamic Host Configuration Protocol) server located
on the network.
IP setting using control panel
1. Connect your machine to the network with a network cable.
2. Turned on the machine.
3. Press
Find the machine’s MAC address from the Network
Configuration Report (see "Printing Network Configuration
report" on page 26) and enter it without the colons. For
example, 00:15:99:29:51:A8 becomes 0015992951A8.
on the control panel.
4.
5.
6.
7.
8.
Press up/down arrow to highlight Network and press OK.
Press up/down arrow to highlight TCP/IP (IPv4) and press OK.
Press up/down arrow to highlight Set IP Address and press OK.
Press up/down arrow to highlight Manual and press OK.
The first available menu item, IP Address displays.
• Enter a number between 0 and 255.
9. Use the up/down arrow to enter digits and use the left/right arrow to
move between digits. When you finish entering the IP address, press
OK.
10. Enter other parameters, such as the Subnet Mask or Gateway, and
press OK.
11. After entering all parameters, press
to return to ready mode.
Now go to "Installing wired network connected machine’s driver" on
page 28.
IPv4 configuration using SetIP (Windows)
Before using the SetIP program, disable the computer firewall from
Control Panel > Security Center > Windows Firewall.
1. Install this program from the supplied CD-ROM by double-click
Application > SetIP > Setup.exe.
2. Follow the instructions in the installation window.
3. Connect your machine to the network with a network cable.
4. Turn on the machine.
5. From the Windows Start menu, select All Programs > Samsung
Printers > SetIP > SetIP.
6. Click the
icon (third from left) in the SetIP window to open the
TCP/IP configuration window.
8. Click Apply, and then click OK. The machine will automatically print
the Network Configuration Report. Confirm that all the settings are
correct.
IPv4 configuration using SetIP (Macintosh)
Before using the SetIP program, disable the computer firewall from
System Preferences > Security > Firewall.
The following instructions may vary from your model.
1. Connect your machine to the network with a network cable.
2. Insert the Installation CD-ROM, and open the disk window, select
MAC_Installer > MAC_Printer > SetIP > SetIPapplet.html.
3. Double-click the file and Safari will automatically open, then select
Trust. The browser will open the SetIPapplet.html page that shows
the printer’s name and IP address information.
4. Click the
icon (third from left) in the SetIP window to open the
TCP/IP configuration window.
5. Enter the machine’s new information into the configuration window.
In a corporate intranet, you may need to have this information
assigned by a network manager before proceeding.
Find the machine’s MAC address from the Network
Configuration Report (see "Printing Network Configuration
report" on page 26) and enter it without the colons. For
example, 00:15:99:29:51:A8 becomes 0015992951A8.
6. Select Apply, then OK, and OK again.
7. Quit Safari.
IPv4 configuation using SetIP (Linux)
Before using the SetIP program, disable the computer firewall from
System Preferences or Administrator.
The following instructions may vary from your model or operating
systems.
Network setup_ 27
1.
2.
3.
4.
Open /opt/Samsung/mfp/share/utils/.
Double-click the SetIPApplet.html file.
Click to open the TCP/IP configuration window.
Enter the machine’s new information into the configuration window.
In a corporate intranet, you may need to have this information
assigned by a network manager before proceeding.
Find the machine’s MAC address from the Network
Configuration Report (see "Printing Network Configuration
report" on page 26) and enter it without the colons. For
example, 00:15:99:29:51:A8 becomes 0015992951A8.
Windows
1. Make sure that the machine is connected to the network and
powered on. Also, your machine’s IP address should have been set.
If the “Found New Hardware Wizard” appears during the
installation procedure, click Cancel to close the window.
2. Insert the supplied software CD into your CD-ROM drive.
The software CD should automatically run and an installation window
will appear.
3. Select Install Now.
When you click the Advanced Installation, you can use the
Custom Installation option. The Custom Installation allows
you to select the machine’s connection and choose individual
components to install. Follow the instructions on the window.
5. The machine will automatically print the Network Configuration
Report.
Network parameter setting
You can also set up the various network settings through the network
administration programs such as SyncThru™ Web Admin Service and
SyncThru™ Web Service.
4. Read License Agreement, and select I accept the terms of the
License Agreement. Then, click Next.
The program searches for the machine.
Restoring factory default settings
If your machine is not found on the network or locally, an error
message appears.
• Check if you want to install the software without
connection of the printer.
- Check this option to install this program without a
machine connected. In this case, the print a test page
window will be skipped, and completes the installation.
• Search again
When you press this button, the firewall notice window
appears.
- Turn off the firewall and Search again. For Windows
operating system, click Start > Control Panel >
Windows Firewall, and inactivate this option.
- Turn off the firewall from the third party's program
beside the operating system. Refer to the manual
provided by individual programs.
• Direct Input
The Direct Input allows you to search for a specific
machine on the network.
- Search by IP address: Enter the IP address or the host
name. Then click Next.
To verify your machine’s IP address, print a network
configuration report (see "Printing Network
Configuration report" on page 26).
- Search by network path: To find a shared machine
(UNC Path), enter the shared name manually or find a
shared printer by clicking the Browse button. Then click
Next.
• Help
If your machine is not connected to the computer or
network, this help button gives detailed information about
how to connect the machine.
• SNMP Community Name
If your system administrator set the new SNMP
Community Name on the machine, you can find the
machine in the network. Contact your system administrator
for new SNMP Community Name.
5. The searched machines will be shown on the screen. Select the one
you wish to use and click OK.
You may need to reset the machine to the factory default settings when
machine that you are using is connected to new network environment.
Restoring factory default settings using control panel
1. Press
on the control panel.
2. Press up/down arrow to highlight Network and press OK.
3. Press up/down arrow to highlight Clear Settings and press OK.
4. Turn off and restart machine to apply settings.
Restoring factory default settings using SyncThru™
Web Service
1. Start a web browser such as Internet Explorer, Safari or Firefox and
enter your machine’s new IP address in the browser window.
For example,
2. Click Go to access the SyncThru™ Web Service.
3. Click Login on the upper right of the SyncThru™ Web Service
website.
A log-in page appears.
4. Type in the ID and Password then click Login .
If it’s your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
• ID: admin
• Password: sec00000
5. When the SyncThru™ Web Service window opens, click Settings
> Network Settings > Restore Default.
6. Click Clear for network.
7. Turn off and restart machine to apply settings.
Installing wired network connected machine’s driver
You must install the printer driver software for printing. The software
includes drivers, applications, and other user friendly programs.
Make sure that the network setup for your machine is completed. All
applications should be closed on your computer before beginning
installation.
If the driver searched only one machine, the confirmation
Network setup_ 28
window appears.
Commandline
6. Follow the instructions in the installation window.
Silent installation Mode
Silent installation mode is an installation method that does not require
any user intervention. Once you start the installation, the machine driver
and software are automatically installed on you computer. You can start
the silent installation by typing /s or /S in the command window.
/i”<script
filename>” or
/I”<script
filename>”
Command-line Parameters
Definition
Description
Specifies customized
install script file for custom
operation.
Customized script file can
be assigned for
customized silent
installation. This script file
can be created or modified
through provided installer
customizing utility or by
text editor.
The script filename
should be a fully
qualified filename.
Following table shows commands that can be used in the command
window.
This customized
script file is prior than
default installer
setting in setup
package but not prior
than command-line
parameters.
Following command-line are effective and operated when
command is used with /s or /S. But /h, /H or /? are exceptional
commands that can be operated solely.
Commandline
Definition
Description
/s or
/S
Starts silent installation.
Installs machine drivers
without prompting any UIs
or user intervention.
/p”<port
name>” or
/P”<port
name>”
Specifies printer port.
Printer port name can be
specified as IP address,
hostname, USB local port
name or IEEE1284 port
name.
For example:
•
/p”xxx.xxx.xxx.xxx” in
where,
“xxx.xxx.xxx.xxx”
means IP address for
network printer.
/p”USB001”,
/P”LPT1:”,
/p”hostname”
• When installing the
driver silently in
Korean, type
in-Setup.exe /s
/L"0x0012” or
Setup.exe /s /L"18” .
/a”<dest_path
>” or
/A”<dest_path
>”
Network Port will be
created by use of
Standard TCP/IP
Port monitor. For
local port, this port
must exist on
system before being
specified by
command.
Specifies destination path
for installation.
The destination path
should be a fully
qualified path.
Since machine drivers
should be installed on the
OS specific location, this
command applies to only
application software.
/n”<Printer
name>” or
/N”<Printer
name>”
Specifies printer name.
Printer instance shall be
created as specified
printer name.
With this parameter, you
can add printer instances
as your wishes.
/nd or
/ND
Commands not to set the
installed driver as a
default machine driver.
It indicates installed
machine driver will not be
the default machine driver
on your system if there are
one or more printer drivers
installed. If there is no
installed machine driver on
your system, then this
option won’t be applied
because Windows OS will
set installed printer driver
as a default machine
driver.
/x or
/X
Uses existing machine
driver files to create
printer instance if it is
already installed.
This command provides a
way to install a printer
instance that uses
installed printer driver files
without installing an
additional driver.
/up”<printer
name>” or
/UP”<printer
name>”
Removes only specified
printer instance and not
the driver files.
This command provides a
way to remove only
specified printer instance
from your system without
effecting other printer
drivers. It will not remove
printer driver files from
your system.
/d or
/D
Uninstalls all device
drivers and applications
from your system.
This command will remove
all installed device drivers
and application software
from your system.
/v”<share
name>” or
/V”<share
name>”
Shares installed machine
and add other available
platform drivers for Point
& Print.
It will install all supported
Windows OS platform’s
machine drivers to system
and share it with specified
<share name> for point
and print.
Network setup_ 29
Commandline
/o or
/O
Definition
Code
Description
Opens Printers and
Faxes folder after
installation.
This command will open
Printers and Faxes folder
after the silent installation.
/f”<log
filename>” or
/F”<log
filename>”
Specifies log filename.
The default log file is
created in the system
temp folder if not
specified.
It will create a log file to a
specified folder.
/h, /H or /?
Shows Command-line
Usage.
Ukraine
0X041B
Slovakia
0X0421
Indonesian
0x041E
Thai
0X0429
Farsi
Macintosh
Language code
Code
0X0422
Language
Language
0X0009
English
0X0012
Korean
0X0804
Simplified Chinese
0X0404
Traditional Chinese
0x040c
French
0X0007
German
0X0010
Italian
0X000a
Spanish
0X0013
Dutch
0X001D
Swedish
0X0006
Danish
0X000b
Finnish
0X0014
Norwegian
0X0019
Russian
0X0005
Czech
0X000e
Hungarian
0X0008
Greek
0X0816
Standard Portuguese
0X0416
Brazilian Portuguese
0X0015
Polish
0X001F
Turkish
0X0001
Arabic
0X000D
Hebrew
0x0424
Slovenian
0X0418
Romanian
0X0402
Bulgarian
0X041A
Croatian
0X081A
Serbian
1. Make sure that the machine is connected to your network and
powered on. Also, your machine’s IP address should have been set.
2. Insert the supplied software CD into your CD-ROM drive.
3. Double-click the CD-ROM icon that appears on your Macintosh
desktop.
4. Double-click the MAC_Installer folder.
5. Double-click the Installer icon.
6. Enter the network key and click OK.
7. The Samsung Installer window opens. Click Continue.
8. Select Easy Install and click Install. Easy Install is recommended
for most users. All components necessary for machine operations
will be installed.
If you select Custom Install, you can choose individual components
to install.
9. When the message which warns that all applications will close on
your computer appears, click Continue.
10. Select Typical installation for a network print and click OK.
The certificate window appears, click Trust. See "Setting IP
address" on page 27 to use SetIP program.
11. After the installation is finished, click Quit.
12. Open the Applications folder > Utilities > Print Setup Utility.
• For Mac OS X 10.5~ 10.6, open the Applications folder >
System Preferences and click Print & Fax.
13. Click Add on the Printer List.
• For Mac OS X 10.5~ 10.6, press the “+” icon; a display window
will pop up.
14. For Mac OS X 10.3, select the IP Printing tab.
• For Mac OS X 10.4, click IP Printer.
• For Mac OS X 10.5~ 10.6, click IP.
15. Select Socket/HP Jet Direct in Printer Type.
When printing a document containing many pages, printing
performance may be enhanced by choosing Socket for Printer Type
option.
16. Enter the machine’s IP address in the Printer Address field.
17. Enter the queue name in the Queue Name field. If you cannot
determine the queue name for your machine server, try using the
default queue first.
18. For Mac OS X 10.3, if Auto Select does not work properly, select
Samsung in Printer Model and your machine name in Model
Name.
• For Mac OS X 10.4, if Auto Select does not work properly, select
Samsung in Print Using and your machine name in Model.
• For Mac OS X 10.5~ 10.6, if Auto Select does not work properly,
choose Select a driver to use... and your machine name in
Print Using.
Your machine’s IP address appears on the Printer List, and is set
Network setup_ 30
as the default machine.
19. Click Add.
If the printer driver does not work properly, uninstall the driver and
reinstall it.
Follow steps below to uninstall the driver for Macintosh.
a) Make sure that the machine is connected to your computer and
powered on.
b) Insert the supplied software CD into your CD-ROM drive.
c) Double-click CD-ROM icon that appears on your Macintosh
desktop.
d) Double-click the MAC_Installer folder.
e) Double-click the Installer icon.
f) Enter the network key and click OK.
g) The Samsung Installer window opens. Click Continue.
h) Select Uninstall and click Uninstall.
i) When the message which warns that all applications will close
on your computer appears, click Continue.
j) When the uninstall is done, click Quit.
Linux
Install Linux Driver
1. Make sure that the machine is connected to your network and
powered on. Also, your machine’s IP address should have been set.
2. From the Samsung website, download the Unified Linux Driver
package to your computer.
3. Right click the Unified Linux Driver package and extract the
package.
4. Double click cdroot > autorun.
5. The Samsung Installer window opens. Click Continue.
6. The Add printer wizard window opens. Click Next.
7. Select Network printer and click Search button.
8. The Printer’s IP address and model name appears on list field.
9. Select your machine and click Next.
10. Input the printer description and Next
11. When the add printer is done, click Finish
12. When the install is done, click Finish
Add network Printer
1.
2.
3.
4.
5.
6.
7.
8.
Double-click the Unified Driver Configurator.
Click Add Printer…
The Add printer wizard window opens. Click Next.
Select Network printer and click the Search button.
The printer’s IP address and model name appears on list field.
Select your machine and click Next.
Input the printer description and Next
When the add printer is done, click Finish.
1. From the Samsung website, download and unpack the UNIX Printer
Driver package to your computer.
2. Acquire root privileges.
su 3. Copy appropriate driver archive to the target UNIX computer.
See administration guide of your UNIX OS for details.
4. Unpack the UNIX printer driver package.
For example, on IBM AIX use the following command(without “).
cd /tmp
gzip -d < "package name" | tar xf The “binaries” folder consists of binz, install, share files and
folders.
5. Copy the “binaries” folder to any local folder.
6. Change to the driver’s “binaries” directory.
cd aix_power/binaries
7. Run the install script.
./install
install is the installer script file which is used to install or uninstall the
UNIX Printer Driver package.
Use “chmod 755 install” command to give the permission to the
installer script.
8. Execute the “. /install –c” command to verify install results.
9. Run ‘installprinter’ from the command line. This will bring up the
Add Printer Wizard window. Setup the printer in this window
referring the procedure next.
On some UNIX OS, for example on Solaris 10 just added
printer may not be enabled and/or may not accept jobs. In this
case run the following two commands on the root terminal:
accept <printer_name>
enable <printer_name>
Uninstalling the printer driver package
The uninstalling printer utility should be used to delete the printer
installed in the system.
a) Run “uninstallprinter” command from the terminal.
It will open the Uninstall Printer Wizard
The installed printers are listed in the drop-down list
b) Select the printer to be deleted.
c) Click Delete to delete the printer from the system.
d) Execute the “. /install –d” command to uninstall the whole
package.
e) To verify uninstall results, execute the “. /install –c” command.
To reinstall it again, use the command “. /install” to reinstall the binaries.
Setting up the printer
UNIX
To use UNIX Printer Driver, you have to install the UNIX printer driver
package first, then setup the printer. You can download the UNIX Printer
Driver package from the Samsung website.
Installing the UNIX printer driver package
Installation procedure is common for all variants of UNIX OS mentioned.
To add the printer to your UNIX system, run ‘installprinter’ from the
command line. This will bring up the Add Printer Wizard window. Setup
the printer in this window according to the following steps:
1. Type the name of the printer.
2. Select appropriate printer model from model list.
3. Enter any decsription corresponding to the type of the printer in the
Type field. This is optional.
4. Specify any printer description in the Description field. This is
optional.
5. Specify printer location in the Location field.
Network setup_ 31
6. Type the IP address or DNS name of the printer in the Device
textbox for network-connected printers. On IBM AIX with jetdirect
Queue type only DNS name is possible, numeric IP address is not
allowed.
7. Queue type shows the connection as lpd or jetdirect in the
corresponding list box. Additionally usb type is available on Sun
Solaris OS.
8. Select Copies to set the number of copies.
9. Check the Collate option to receive copies already sorted.
10. Check the Reverse Order option to receive copies in the reverse
order.
11. Check the Make Default option to set this printer as default.
12. Click OK to add the printer.
Macintosh operating systems are supported (see "Setup using
Windows" on page 32 or "Setup using Macintosh" on page 35).
You can also install a wireless network in Samsung Easy
Printer Manager (Device Settings) or Printer Settings Utility
with a USB cable after installing the driver (Windows and
Macintosh operating systems are supported).
•
With a network cable: You can set up a wireless network using the
SyncThru™ Web Service program (see "Using a network cable" on
page 37).
Using the WLAN
Some models may not support this feature.
Before starting, you will need to know the network name (SSID) of your
wireless network and the network key if it is encrypted. This information was
set when the access point (or wireless router) was installed. If you do not
know about your wireless environment, please ask the person who set up
your network.
Wireless network setup
Make sure your machine supports a wireless network. Wireless
network may not be available depending on the model.
After completing the wireless network connection, you need to install a
machine driver to print from an application (see "Installing wired
network connected machine’s driver" on page 28).
Getting started
Understanding your network type
Typically, you can only have one connection between your computer
and the machine at a time.
Infrastructure mode
This is an environment generally used for homes
and SOHOs (Small Office/ Home Office). This
mode uses an access point to communicate with
the wireless machine.
1. Press the Press
on on the control panel.
2. Press Network > Wireless > WLAN Settings.
3. Press the OK to select the setup method you want.
• Wizard (recommended): In this mode the setup is automatic.
Machine will display a list of available network to choose. After a
network is chosen then printer will prompt for the corresponding
security Key.
• Custom: In this mode users can give their own SSID or edit SSID,
choose the security manually and apply the settings.
Setup using Windows
Ad hoc mode
This mode does not use an access point. The
wireless computer and wireless machine
communicates directly.
Shortcut to Wireless Setting program without CD: If you have
installed the printer driver once, you can access the Wireless Setting
program without CD. From the Start menu, select Programs or All
Programs > Samsung Printers > your printer driver name >
Wireless Setting Program.
Wireless network name and network key
Access point via USB cable
Wireless networks require higher security, so when an access point is
first set up, a network name (SSID), the type of security used, and a
Network Key are created for the network. Locate this information before
proceeding with the machine installation.
Items to prepare
Choosing the installation type
You can install a wireless network from the machine’s control panel or the
computer.
•
•
•
•
•
Access point
Network-connected computer
Software CD that was provided with your machine
The machine installed with a wireless network interface
USB cable
Creating the infrastructure network
1. Check whether the USB cable is connected to the machine.
2. Turn on your computer, access point, and machine.
3. Insert the supplied software CD into your CD-ROM drive.
From the control panel
You can configure wireless parameters with the control panel.
• See "Using the WLAN" on page 32.
From the computer
From the computer, we recommend using a USB cable with the
program provided in the supplied software CD.
See "Setup using Windows" on page 32.
• With a USB cable: You can simply set up a wireless network using
the program on the supplied software CD. Only Windows and
Network setup_ 32
4. Select the Wireless Setting and Installation option.
•
Install Now: If you have already set up the wireless network,
click this button to install the machine’s driver to use the wireless
network machine. If you have not set up the wireless network,
click the Wireless Setting and Installation button to set up the
wireless network before you click this button.
• Wireless Setting and Installation: Configure the wireless
network settings of your machine with a USB cable then install
the machine driver. This is only for users who have not set up the
wireless connection before.
5. Read the License Agreement, and select I accept the terms of the
License Agreement. Then, click Next.
6. The software searches the wireless network.
If the search has failed, you may check if the USB cable is
properly connected between the computer and machine, and
follow the instructions on the window.
7. After searching, the window shows the wireless network devices.
Select the name (SSID) of the access point you are using and click
Next.
If you cannot find the network name you want to choose, or if
you want to set the wireless configuration manually, click
Advanced Setting.
• Enter the wireless Network Name: Enter the SSID of
access point you want (SSID is case-sensitive).
• Operation Mode: Select Infrastructure.
• Authentication: Select an authentication type.
Open System: Authentication is not used, and encryption
may or may not be used, depending on the need for data
security.
Shared Key: Authentication is used. A device that has a
proper WEP key can access the network.
WPA Personal or WPA2 Personal: Select this option to
authenticate the print server based on WPA Pre-Shared
Key. This uses a shared secret key (generally called PreShared Key pass phrase) which is manually configured on
the access point and each of its clients.
• Encryption: Select the encryption (None, WEP64,
WEP128, TKIP, AES, TKIP AES).
• Network Key: Enter the encryption network key value.
• Confirm Network Key: Confirm the encryption network
key value.
• WEP Key Index: If you are using WEP Encryption, select
the appropriate WEP Key Index.
The wireless network security window appears when the
access point has security settings.
The wireless network security window appears. The window
may differ according to its security mode: WEP, or WPA.
• WEP
Select Open System or Shared Key for the authentication
and enter the WEP security key. Click Next.
WEP (Wired Equivalent Privacy) is a security protocol
preventing unauthorized access to your wireless network.
WEP encrypts the data portion of each packet exchanged
on a wireless network using a 64-bit or 128-bit WEP
encryption key.
• WPA
Enter the WPA shared key and click Next.
WPA authorizes and identifies users based on a secret key
that changes automatically at regular intervals. WPA also
uses TKIP (Temporal Key Integrity Protocol) and AES
(Advanced Encryption Standard) for data encryption.
8. The window shows the wireless network settings and checks if the
settings are correct. Click Next.
• For the DHCP method
If the IP address assignment method is DHCP, check if DHCP is
shown in the window. If it shows Static, click Change TCP/IP to
change the assignment method to DHCP.
• For the Static method
If the IP address assignment method is Static, check if Static is
shown in the window. If it shows DHCP, click Change TCP/IP to
enter the IP address and other network configuration values for
the machine. Before entering the IP address for the machine, you
must know the computer’s network configuration information. If
the computer is set to DHCP, you must contact the network
administrator to get the static IP address.
For example:
If the computer’s network information is as shown below:
- IP address: 169.254.133.42
- Subnet Mask: 255.255.0.0
Then, the machine’s network information should be as follows:
- IP address: 169.254.133.43
- Subnet Mask: 255.255.0.0 (Use the computer’s subnet
mask.)
- Gateway: 169.254.133.1
9. When the wireless network setting is completed, disconnect the USB
cable between the computer and machine. Click Next.
10. The Wireless Network Setting Complete window appears.
Select Yes if you accept the current settings and continue the setup
procedure.
Select No if you want to return to the beginning screen.
Then, click Next.
11. Click Next when the Confirm Printer Connection window appears.
12. Select the components to be installed. Click Next.
13. After selecting the components, you can also change the machine
name, set the machine to be shared on the network, set the machine
as the default machine, and change the port name of each machine.
Click Next.
14. After the installation is finished, a window asking you to print a test
page appears. If you want to print a test page, click Print a test
page.
Otherwise, just click Next and go to step 16.
Network setup_ 33
15. If the test page prints out correctly, click Yes.
If not, click No to reprint it.
16. To register as a user of the machine in order to receive information
from Samsung, click On-line Registration.
17. Click Finish.
network from the list.
If you want to change ad hoc settings click the Advanced
Setting button.
• Enter the wireless Network Name: Enter the SSID name
you want (SSID is case-sensitive).
• Operation Mode: Select ad hoc.
• Channel: Select the channel. (Auto Setting or 2412 MHz
to 2467 MHz).
• Authentication: Select an authentication type.
Open System: Authentication is not used, and encryption
may or may not be used, depending on the need for data
security.
Shared Key: Authentication is used. A device that has a
proper WEP key can access the network.
• Encryption: Select the encryption (None, WEP64,
WEP128).
• Network Key: Enter the encryption network key value.
• Confirm Network Key: Confirm the encryption network
key value.
• WEP Key Index: If you are using WEP Encryption, select
the appropriate WEP Key Index.
The wireless network security window appears when the ad
hoc network has security setting.
The wireless network security window appears. Select Open
System or Shared Key for the authentication and click Next.
• WEP (Wired Equivalent Privacy) is a security protocol
preventing unauthorized access to your wireless network.
WEP encrypts the data portion of each packet exchanged
on a wireless network using a 64-bit or 128-bit WEP
encryption key.
Ad hoc via USB cable
If you do not have an access point (AP), you may still connect the
machine wirelessly to your computer by setting up an ad-hoc wireless
network by following the simple steps below.
Items to prepare
•
•
•
•
Network-connected computer
Software CD that was provided with your machine
The machine installed with a wireless network interface
USB cable
Creating the ad hoc network in Windows
1.
2.
3.
4.
Check whether the USB cable is connected to the machine.
Turn on your computer and the wireless network machine.
Insert the supplied software CD into your CD-ROM drive.
Select the Wireless Setting and Installation option.
8. The window showing the wireless network setting appears. Check
the settings and click Next.
•
Install Now: If you have already set up the wireless network,
click this button to install the machine’s driver to use the wireless
network machine. If you have not set up the wireless network,
click the Wireless Setting and Installation button to set up the
wireless network before you click this button.
• Wireless Setting and Installation: Configure the wireless
network settings of your machine with a USB cable then install
the machine driver. This is only for users who have not set up the
wireless connection before.
5. Read the License Agreement, and select I accept the terms of the
License Agreement. Then, click Next.
6. The software searches the wireless network.
If the software has failed to search the network, check if the
USB cable is connected properly between the computer and
machine, and follow the instruction in the window.
7. After searching the wireless networks, a list of wireless networks
your machine has searched appears.
If you want to use the Samsung default ad hoc setting, select the last
wireless network on the list, Network Name(SSID) is portthru and
Signal is Printer Self Network.
Then, click Next.
If you want to use other ad hoc settings, select another wireless
Network setup_ 34
Before entering the IP address for the machine, you must know
the computer’s network configuration information. If the
computer’s network configuration is set to DHCP, the wireless
network setting should also be DHCP. Likewise, if the
computer’s network configuration is set to Static, the wireless
network setting should also be Static.
If your computer is set to DHCP and you want to use the Static
wireless network setting, you must contact the network
administrator to get the static IP address.
• For the DHCP method
If the IP address assignment method is DHCP, check if
DHCP is shown in the Wireless Network Setting Confirm
window. If it shows Static, click Change TCP/IP to change
the assignment method to Receive IP address
automatically (DHCP).
• For the Static method
If the IP address assignment method is Static, check if
Static is shown in the Wireless Network Setting Confirm
window. If it shows DHCP, click Change TCP/IP to enter
the IP address and other network configuration values for
the machine.
For example:
If the computer’s network information is as shown follows:
- IP address: 169.254.133.42
- Subnet Mask: 255.255.0.0
Then, the machine’s network information should be as
below:
- IP address: 169.254.133.43
- Subnet Mask: 255.255.0.0 (Use the computer’s subnet
mask.)
- Gateway: 169.254.133.1
9. When the wireless network settings are completed, disconnect the
USB cable between the computer and machine. Click Next.
12. Select Easy Install and click Install. Easy Install is recommended
for most users. All components necessary for machine operations
will be installed.
If you select Custom Install, you can choose which individual
operations will be installed.
13. Select the Wireless Setting and Installation option.
14. The software searches the wireless network.
If the Change PC Network Setting window appears, follow
the steps in the window.
Click Next if you are finished with the computer’s wireless
network settings.
If you set the computer’s wireless network on DHCP, it will take
several minutes to receive the IP address.
10. The Wireless Network Setting Complete window appears.
Select Yes if you accept the current settings and continue the setup
procedure.
Select No if you want to return to the beginning screen.
Then, click Next.
11. Click Next when the Confirm Printer Connection window appears.
12. Select the components to be installed. Click Next.
13. After selecting the components, you can also change the machine
name, set the machine to be shared on the network, set the machine
as the default machine, and change the port name of each machine.
Click Next.
14. After the installation is finished, a window asking you to print a test
page appears. If you want to print a test page, click Print a test
page.
Otherwise, just click Next and go to step 16.
15. If the test page prints out correctly, click Yes.
If not, click No to reprint it.
16. To register as a user of the machine in order to receive information
from Samsung, click On-line Registration.
17. Click Finish.
If the search has failed, you may check if the USB cable is
connected between the computer and machine properly, and
follow the instructions in the window.
Setup using Macintosh
Items to prepare
•
•
•
•
•
Access point
Network-connected computer
Software CD that was provided with your machine
The machine installed with a wireless network interface
USB cable
Access point via USB cable
1.
2.
3.
4.
Check whether the USB cable is connected to the machine.
Turn on your computer, access point, and machine.
Insert the supplied software CD into your CD-ROM drive.
Double-click the CD-ROM icon that appears on your Macintosh
desktop.
5. Double-click the MAC_Installer folder.
6. Double-click the Installer OS X icon.
7. Enter the password and click OK.
8. Click Continue.
9. Read the license agreement and click Continue.
10. Click Agree to agree to the license agreement.
11. Click Continue.
15. After searching, the window shows the wireless network devices.
Select the name (SSID) of the access point you are using and click
Next.
When you set the wireless configuration manually, click
Advanced Setting.
• Enter the wireless Network Name: Enter the SSID of the
access point you want with (SSID is case-sensitive).
• Operation Mode: Select Infrastructure.
• Authentication: Select an authentication type.
Open System: Authentication is not used, and encryption
may or may not be used, depending on the need for data
security.
Shared Key: Authentication is used. A device that has a
proper WEP key can access the network.
WPA Personal or WPA2 Personal: Select this option to
authenticate the print server based on WPA Pre-Shared
Key. This uses a shared secret key (generally called PreShared Key pass phrase) that is manually configured on
the access point and each of its clients.
• Encryption: Select the encryption. (None, WEP64,
WEP128, TKIP, AES, TKIP, AES)
• Network Key: Enter the encryption network key value.
• Confirm Network Key: Confirm the encryption network
key value.
• WEP Key Index: If you are using WEP Encryption, select
the appropriate WEP Key Index.
The wireless network security window appears when the
access point has security setting.
The wireless network security window appears. The window
may differ according to its security mode: WEP or WPA.
• WEP
Select Open System or Shared Key for the authentication
and enter the WEP security key. Click Next.
WEP (Wired Equivalent Privacy) is a security protocol
preventing unauthorized access to your wireless network.
WEP encrypts the data portion of each packet exchanged
on a wireless network using a 64-bit or 128-bit WEP
encryption key.
• WPA
Enter the WPA shared key and click Next.
WPA authorizes and identifies users based on a secret key
that changes automatically at regular intervals. WPA also
uses TKIP (Temporal Key Integrity Protocol) and AES
(Advanced Encryption Standard) for data encryption.
16. The window shows the wireless network settings and check if
settings are right. Click Next.
• For the DHCP method
Network setup_ 35
If the IP address assignment method is DHCP, check if DHCP is
shown in the window. If it shows Static, click Change TCP/IP to
change the assignment method to DHCP.
• For the Static method
If the IP address assignment method is Static, check if Static is
shown in the window. If it shows DHCP, click Change TCP/IP to
enter the IP address and other network configuration values for
the machine. Before entering the IP address for the machine, you
must know the computer’s network configuration information. If
the computer is set to DHCP, you must contact the network
administrator to get the static IP address.
For example:
If the computer’s network information is as shown follows:
- IP address: 169.254.133.42
- Subnet Mask: 255.255.0.0
Then, the machine’s network information should be as follows:
- IP address: 169.254.133.43
- Subnet Mask: 255.255.0.0 (Use the computer’s subnet
mask.)
- Gateway: 169.254.133.1
17. The wireless network connects according to the network
configuration.
18. When the wireless network settings are completed, disconnect the
USB cable between the computer and machine.
19. Follow the instructions on the screen to complete the installation.
After the installation is finished, click Quit or Restart.
If the search has failed, check if the USB cable is connected
between the computer and machine properly, and follow the
instructions in the window.
14. After searching the wireless networks, a list of wireless networks
your machine has searched appears.
If you want to use the Samsung default ad hoc setting, select the last
wireless network on the list, which Network Name(SSID) is portthru
and Signal is Printer Self Network.
Then, click Next.
If you want to use other ad hoc settings, select another wireless
network from the list.
If you want to change ad hoc settings click the Advanced
Setting button.
• Enter the wireless Network Name: Enter the SSID name
you want (SSID is case-sensitive).
• Operation Mode: Select ad hoc.
• Channel: Select the channel (Auto Setting or 2412 MHz
to 2467 MHz).
• Authentication: Select an authentication type.
Open System: Authentication is not used, and encryption
may or may not be used, depending on the need for data
security.
Shared Key: Authentication is used. A device that has a
proper WEP key can access the network.
• Encryption: Select the encryption (None, WEP64,
WEP128).
• Network Key: Enter the encryption network key value.
• Confirm Network Key: Confirm the encryption network
key value.
• WEP Key Index: If you are using WEP Encryption, select
the appropriate WEP Key Index.
Ad hoc via USB cable
If you do not have an access point (AP), you may still connect the
machine wirelessly to your computer by setting up an ad hoc wireless
network by following these simple directions.
Items to prepare
•
•
•
•
The wireless network security window appears when the ad
hoc network has security setting.
The wireless network security window appears. Select Open
System or Shared Key for the authentication and click Next.
• WEP (Wired Equivalent Privacy) is a security protocol
preventing unauthorized access to your wireless network.
WEP encrypts the data portion of each packet exchanged
on a wireless network using a 64-bit or 128-bit WEP
encryption key.
Network-connected computer
Software CD that provided with your machine
The machine installed with a wireless network interface
USB cable
Creating the ad hoc network in Macintosh
1.
2.
3.
4.
Check whether the USB cable is connected to the machine.
Turn on your computer and machine.
Insert the supplied software CD into your CD-ROM drive.
Double-click the CD-ROM icon that appears on your Macintosh
desktop.
5. Double-click the MAC_Installer folder.
6. Double-click the Installer OS X icon.
7. Enter the password and click OK.
8. Click Continue.
9. Read the license agreement and click Continue.
10. Click Agree to agree to the license agreement.
11. Select Easy Install and click Install. Easy Install is recommended
for most users. All components necessary for machine operations
will be installed.
If you select Custom Install, you can choose individual operations
will be installed.
12. Click Wireless Setting and Installation.
13. The software searches the wireless network devices.
15. The window showing the wireless network settings appears. Check
the settings and click Next.
Network setup_ 36
Before entering the IP address for the machine, you must know
the computer’s network configuration information. If the
computer’s network configuration is set to DHCP, the wireless
network setting should also be DHCP. Likewise, if the
computer’s network configuration is set to Static, the wireless
network setting should also be Static.
If your computer is set to DHCP and you want to use Static
wireless network setting, you must contact the network
administrator to get the static IP address.
• For the DHCP method
If the IP address assignment method is DHCP, check if
DHCP is shown in the Wireless Network Setting Confirm
window. If it shows Static, click Change TCP/IP to change
the assignment method to Receive IP address
automatically (DHCP).
•
For the Static method
If the IP address assignment method is Static, check if
Static is shown in the Wireless Network Setting Confirm
window. If it shows DHCP, click Change TCP/IP to enter
the IP address and other network configuration values for
the machine.
For example:
If the computer’s network information is as shown follows:
- IP address: 169.254.133.42
- Subnet Mask: 255.255.0.0
Then, the machine’s network information should be as
below:
- IP address: 169.254.133.43
- Subnet Mask: 255.255.0.0 (Use the computer’s subnet
mask.)
- Gateway: 169.254.133.1
16. The wireless network connects according to the network
configuration.
17. When the wireless network setting is completed, disconnect the USB
cable between the computer and machine.
18. Follow the instructions on the screen to complete the installation.
After the installation is finished, click Quit or Restart.
To configure wireless parameters, you can use SyncThru™ Web
Service.
Using SyncThru™ Web Service
Before starting wireless parameter configuration, check the cable
connection status.
1. Check whether or not the network cable is connected to the
machine. If not, connect the machine with a standard network cable.
2. Start a web browser such as Internet Explorer, Safari or Firefox and
enter your machine’s new IP address in the browser window.
For example,
3. Click Login on the upper right of the SyncThru™ Web Service
website.
4. Type in the ID and Password then click Login.
• ID: admin
• Password: sec00000
5. When the SyncThru™ Web Service window opens, click Network
Settings.
6. Click Wireless > Wizard.
Wizard will help you setup the wireless network configuration.
However, if you want to set the wireless network directly, select
Custom.
Using a network cable
Your machine is a network compatible machine. To enable your machine to
work with your network, you will need to perform some configuration
procedures.
•
•
After completing the wireless network connection, you need to
install a machine driver to print from an application (See "Installing
wired network connected machine’s driver" on page 28).
See your network administrator, or the person that set up your
wireless network, for information about your network configuration.
Items to prepare
•
•
•
•
•
Access point
Network-connected computer
Software CD that was provided with your machine
The machine installed with a wireless network interface
Network cable
7. Select the one Network Name(SSID) in the list.
• SSID: SSID (Service Set Identifier) is a name that identifies a
wireless network, access points, and wireless devices attempting
to connect to a specific wireless network must use the same
SSID. The SSID is case-sensitive.
• Operation Mode: Operation Mode refers to the type of wireless
connections (See "Wireless network name and network key" on
page 32).
- Ad-hoc: Allows wireless devices to communicate directly with
each other in a peer-to-peer environment.
- Infrastructure: Allows wireless devices to communicate with
each other through an access point.
If your network’s Operation Mode is Infrastructure, select the
SSID of the access point. If the Operation Mode is Ad-hoc,
select the machine’s SSID. Note that “portthru” is the default
SSID of your machine.
Printing a network configuration report
You can identify the network settings of your machine by printing a
network configuration report.
See "Printing Network Configuration report" on page 26.
IP setting using SetIP Program (Windows)
This program is used to manually set the network IP address of your
machine using its MAC address to communicate with the machine. The
MAC address is the hardware serial number of the network interface and
can be found in the Network Configuration Report.
See "Setting IP address" on page 27.
8. Click Next.
If the wireless security setting window appears, enter the registered
password (network key) and click Next.
9. The confirmation window appears, please check your wireless setup.
If the setup is right, click Apply.
Disconnect the network cable (standard or network). Your
machine should then start communicating wirelessly with the
network. In case of Ad-hoc mode, you can use a wireless LAN
and wired LAN simultaneously.
Configuring the machine’s wireless network
Turning the Wi-Fi network on/off
Before starting you will need to know the network name (SSID) of your
wireless network and the network key if it is encrypted. This information
was set when the access point (or wireless router) was installed. If you
do not know about your wireless environment, please ask the person
who set up your network.
1. Check whether the network cable is connected to the machine. If not,
connect the machine with a standard network cable.
2. Start a web browser such as Internet Explorer, Safari or Firefox and
enter your machine’s new IP address in the browser window.
Network setup_ 37
-
For example,
Gateway: 169.254.133.1
Other problems
3. Click Login on the upper right of the SyncThru™ Web Service website.
4. Type in the ID and Password then click Login.
• ID: admin
• Password: sec00000
5. When the SyncThru™ Web Service window opens, click Network
Settings.
6. Click Wireless > Custom.
You can also turn the Wi-Fi network on/off.
Problems during setup or driver installation
•
Your machine may not be turned on. Turn on your computer and the
machine.
USB cable is not connected between your computer and machine.
Connect machine to your computer using the USB cable.
The machine does not support a wireless network. Check the
machine's user's guide included on the software CD supplied with
your machine and prepare a wireless network machine.
•
•
•
•
Connecting Failure - Not Found SSID
•
•
•
Printers Not Found
•
For information on the access point (or wireless router), refer to its
own user's guide.
•
Troubleshooting
•
If problems occur while using the machine on a network, check the
following:
The machine is unable to search the network name (SSID) you have
selected or entered. Check the network name (SSID) on your access
point and try connecting again.
Your access point is not turned on. Turn on your access point.
•
Connecting Failure - Invalid Security
•
You configured security incorrectly. Check the configured security on
your access point and machine.
•
Connecting Failure - General Connection Error
•
Your computer is not receiving a signal from your machine. Check
the USB cable and your machine’s power.
Connecting Failure - Connected Wired Network
•
Your machine is connected with a wired network cable. Remove the
wired network cable from your machine.
•
•
PC Connection Error
•
•
The configured network address is unable to connect between your
computer and machine.
- For a DHCP network environment
The receives the IP address automatically (DHCP) when
computer is configured to DHCP.
- For a Static network environment
The machine uses the static address when the computer is
configured to static address.
For example:
If the computer’s network information is as shown below:
- IP address: 169.254.133.42
- Subnet Mask: 255.255.0.0
Then, the machine’s network information should be as below:
- IP address: 169.254.133.43
- Subnet Mask: 255.255.0.0 (Use the computer’s subnet
mask.)
•
•
•
Network setup_ 38
Your computer, access point (or wireless router), or machine may
not be turned on.
Check the wireless reception around the machine. If the router is far
from the machine or there is an obstacle, you might have difficulty
receiving the signal.
Cycle the power for the access point (or wireless router), machine,
and computer. Sometimes cycling the power can recover network
communication.
Check whether firewall software (V3 or Norton) is blocking the
communication.
If the computer and the machine are connected on the same network
and it cannot be found when searching, firewall software might be
blocking the communication. Refer to the user's guide for the
software to turn it off and try searching for the machine again.
Check whether the machine's IP address is allocated correctly. You
can check the IP address by printing the network configuration
report.
Check whether the access point (or wireless router) has a configured
security (password). If it has a password, refer to the access point (or
wireless router) administrator.
Check the machine's IP address. Reinstall the machine driver and
change the settings to connect to the machine on the network. Due
to the characteristics of DHCP, the allocated IP address could
change if the machine is not used for a long time or if the access
point has been reset.
Check the wireless environment. You might not be able to connect to
the network in the infrastructure environment where you need to type
in a user's information before connecting to access point (or wireless
router).
This machine only supports IEEE 802.11 b/g/n and Wi-Fi. Other
wireless communication types (e.g., Bluetooth) are not supported.
When using the ad hoc mode, in operating systems such as
Windows Vista, you might need to set the wireless connection
setting every time you use the wireless machine.
You cannot use Infrastructure mode and Ad hoc mode at the same
time for Samsung wireless network machines.
The machine is within the range of the wireless network.
The machine is located away from obstacles that could block the
wireless signal.
Remove any large metal objects between the access point (or
wireless router) and the machine.
Make sure the machine and wireless access point (or wireless
router) are not separated by poles, walls, or support columns
containing metal or concrete.
The machine is located away from other electronic devices that may
interfere with the wireless signal.
Many devices can interfere with the wireless signal, including a
microwave oven and some Bluetooth devices.
IPv6 configuration
•
DHCPv6 Addresses: Always use DHCPv6 regardless of router
request.
• DHCPv6 Off: Never use DHCPv6 regardless of router request.
6. Press OK.
IPv6 is supported properly only in Windows Vista or higher.
Activating IPv6
Manual address configuration
1. Connect your machine to the network with a network cable.
2. Turned on the machine.
3. Press
4.
5.
6.
7.
8.
9.
1. Start a web browser such as Internet Explorer that supports IPv6
addressing as a URL (See "Connecting SyncThru™ Web Service"
on page 39).
on the control panel.
Press up/down arrow to highlight Network and press OK.
Press up/down arrow to highlight TCP/IP (IPv6) and press OK.
Press up/down arrow to highlight IPv6 Activate and press OK.
Press up/down arrow to highlight On and press OK.
Turn the machine off and turn it on again.
Print a Network Configuration Report from the machine’s control
panel that will check IPv6 addresses.
1. Press
For IPv4, enter the IPv4 address (http://xxx.xxx.xxx.xxx) in the
address field and press the Enter key or click Go.
on the control panel.
2. Press up/down arrow to highlight Network and press OK.
3. Press up/down arrow to highlight Network Configuration and
press OK.
Using IPv6
In the IPv6 network environment, follow the next procedure to use the IPv6
address.
1. Connect your machine to the network with a network cable.
2. Turn on the machine.
3. Print a Network Configuration Report that will check IPv6 addresses.
4. Select Start > Control Panel > Printers and Faxes.
5. Click Add a printer in the left pane of the Printers and Faxes windows.
6. Click Add a network, wireless or Bluetooth printer in the Add Printer
windows.
7. The Add Printer Wizard window appears. Follow the instructions in the
window.
If the machine does not work in the network environment, activate
IPv6.
Setting IPv6 addresses
The machine supports the following IPv6 addresses for network printing and
managements.
• Link-local Address: Self-configured local IPv6 address (Address starts
with FE80).
• Stateless Address: Automatically configured IPv6 address by a
network router.
• Stateful Address: IPv6 address configured by a DHCPv6 server.
• Manual Address: Manually configured IPv6 address by a user.
DHCPv6 address configuration (Stateful)
2. Click Login on the upper right of the SyncThru™ Web Service
website.
A log-in page appears.
3. Type in the ID and Password then click Login .
If it’s your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
• ID: admin
• Password: sec00000
4. When the SyncThru™ Web Service window opens, click Settings
> Network Settings.
5. Click TCP/IPv6.
6. Enable the Manual Address In the TCP/IPv6 section.
IPv6 Protocol should enable.
7. Select the Address / Prefix and click the Add button, then the router
prefix will automatically be entered into the address field.
Enter the rest of address. (ex: 3FFE:10:88:194::AAAA. “A” is the
hexadecimal 0 through 9, A through F.)
8. Click the Apply button.
Connecting SyncThru™ Web Service
1. Start a web browser such as Internet Explorer that supports IPv6
addressing as a URL .
2. Click Go to access the SyncThru™ Web Service.
3. Click Login on the upper right of the SyncThru™ Web Service website.
A log-in page appears.
4. Type in the ID and Password then click Login .
If it’s your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
• ID: admin
• Password: sec00000
5. Select one of the IPv6 addresses (Link-local Address, Stateless
Address, Stateful Address, Manual Address) from Network
Configuration Report.
6. Enter the IPv6 addresses. (ex: http://[FE80::215:99FF:FE66:7701])
If you have a DHCPv6 server on your network, you can set one of the
following options for default dynamic host configuration.
1. Press
2.
3.
4.
5.
on the control panel.
Press up/down arrow to highlight Network and press OK.
Press up/down arrow to highlight TCP/IP (IPv6) and press OK.
Press up/down arrow to highlight DHCPv6 Config and press OK.
Press up/down arrow to access the required value.
• Routers: Use DHCPv6 only when requested by a router.
Network setup_ 39
Address must be enclosed in '[]' brackets.
basic setup
4.
After installation is complete, you may want to set the machine’s default settings. Refer to the next section if you would like
to set or change values. This chapter gives you step-by-step instructions for setting up the machine.
This chapter includes:
•
•
•
•
•
•
•
•
Altitude adjustment
Setting the date and time
Changing the clock mode
Changing the display language
Altitude adjustment
Setting job timeout
Using power saving feature
Setting the default tray and paper
Changing font setting
6. Press
The print quality is affected by atmospheric pressure, which is determined
by the height of the machine above sea level. The following information will
guide you on how to set your machine to the best print quality or best quality
of print.
Before you set the altitude value, find the altitude where you are using the
machine.
to return to ready mode.
This menu item is available when the optional hard disk is installed.
Changing the clock mode
You can set your machine to display the current time using either a 12-hour
or 24-hour format.
1. Press
on the control panel.
2. Press the up/down arrow to highlight System Setup and press OK.
3. Press the up/down arrow to highlight Clock Mode and press OK.
4. Press the up/down arrow to select the other mode and press OK.
5. Press
1
2
3
4
0
•
•
This menu item is available when the optional hard disk is installed.
High 3
High 2
High 1
Normal
Changing the display language
To change the language that appears on the display, follow the steps below:
1. Press
For Windows user, see "Device Settings" on page 62.
For Macintosh, Linux, or Unix OS user, see "Using Smart Panel
(Macintosh and Linux only)" on page 62.
•
•
to return to ready mode.
2.
3.
4.
5.
If your machine is connected to the network, you can set the
altitude via SyncThru™ Web Service.
You can also set the altitude in System Setup option on the
machine’s display.
on the control panel.
Press up/down arrow to highlight System Setup and press OK.
Press up/down arrow to highlight Language and press OK.
Press up/down arrow to display the language you want.
press OK to save the selection.
6. Press
to return to ready mode.
Setting the date and time
Setting job timeout
When you set the time and date, they are used in delay print. They are
printed on reports. If, however, they are not correct, you need to change it
for the correct time being.
When there is no input for a certain period of time, the machine exits the
current menu and goes in to the default settings. You can set the amount of
time the machine will wait.
If the machine’s power is cut off, you need to reset the correct time
and date once the power has been restored.
1. Press
2.
3.
4.
5.
on the control panel.
Press up/down arrow to highlight System Setup and press OK.
Press up/down arrow to highlight Date & Time and press OK.
Press up/down arrow to select the date and time you want.
press OK to save the selection.
1. Press
2.
3.
4.
5.
on the control panel.
Press up/down arrow to highlight System Setup and press OK.
Press up/down arrow to highlight Job Timeout and press OK.
Press up/down arrow to select the time you want.
press OK to save the selection.
6. Press
Basic setup_ 40
to return to ready mode.
Using power saving feature
When you are not using the machine for a while, use this feature to save
power.
1. Press
2.
3.
4.
5.
on the control panel.
to return to ready mode.
When printing continuously (over 200 pages), power save mode is
extended to about 30 minutes to adjust image.
Setting the default tray and paper
You can select the tray and paper you would like to keep using for printing
job. (See "Paper" on page 57.)
2.
3.
4.
5.
6.
7.
8.
9.
on the control panel.
Press up/down arrow to highlight Paper and press OK.
Press up/down arrow to select the paper tray you want press OK.
Press up/down arrow to highlight Paper Size and press OK.
Press up/down arrow to select the paper size you want.
Press OK to save the selection.
Press up/down arrow to highlight Paper Type and press OK.
Press up/down arrow to select the paper type you want.
Press OK to save the selection.
10. Press
Changing font setting
Your machine has preset the font for your region or country.
If you want to change the font or set the font for special condition, such as
the DOS environment, you can change the font setting from Device
Settings or Emulation section.
• For Windows user, see "Device Settings" on page 62.
• For Macintosh, Linux, or Unix OS user, see "Using Smart Panel
(Macintosh and Linux only)" on page 62.
In the control panel
1. Press
Macintosh
Macintosh does not support this function. Macintosh users need to
change the default setting manually each time they want to print using
other settings.
1. Open a Macintosh application and select the file you want to print.
2. Open the File menu and click Print.
3. Go to Paper Feed pane.
4. Set appropriate tray from which you want to print.
5. Go to Paper pane.
6. Set paper type to correspond to the paper loaded in the tray from
which you want to print.
7. Click Print to print.
Press up/down arrow to highlight System Setup and press OK.
Press up/down arrow to highlight Power Save and press OK.
Press up/down arrow to select the time you want.
press OK to save the selection.
6. Press
5. Click Paper tab.
6. Select tray and its options, such as paper size and type.
7. Press OK.
Following information shows the proper font list for corresponding
languages.
• Russian: CP866, ISO 8859/5 Latin Cyrillic
• Hebrew: Hebrew 15Q, Hebrew-8, Hebrew-7 (Israel only)
• Greek: ISO 8859/7 Latin Greek, PC-8 Latin/Greek
• Arabic & Farsi: HP Arabic-8, Windows Arabic, Code Page 864,
Farsi, ISO 8859/6 Latin Arabic
• OCR: OCR-A, OCR-B
.
11. Press up/down arrow to highlight Paper Source and press OK.
12. Press up/down arrow to select the paper tray you want.
13. press OK to save the selection.
14. Press
to return to ready mode.
In the computer
Windows
1. Click the Windows Start menu.
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware
> Devices and Printers.
3. Right-click your machine.
4. For Windows XP/2003/2008/Vista, press Printing Preferences.
For Windows 7 and Windows Server 2008 R2, from context menus,
select the Printing Preferences.
If Printing Preferences item has ► mark, you can select other
printer drivers connected with selected printer.
Basic setup_ 41
media and tray
5.
This chapter provides information on how to load print media into your machine.
This chapter includes:
•
•
•
•
•
•
Selecting print media
Changing the tray size
Loading paper in the tray
Selecting print media
Printing on special media
Setting the paper size and type
Using the output support
Media sizes supported in duplex mode
You can print on a variety of print media, such as plain paper, envelopes,
labels, and transparencies. Always use print media that meet the guidelines
for use with your machine.
Mode
Size
Duplex
printinga
Letter, A4,
Legal, US Folio,
Oficio
Guidelines to select the print media
Print media that does not meet the guidelines outlined in this user’s guide
may cause the following problems:
• Poor print quality
• Increased paper jams
• Premature wear on the machine.
Properties, such as weight, composition, grain, and moisture content, are
important factors that affect the machine’s performance and the output
quality. When you choose print materials, consider the following:
• The type, size and weight of the print media for your machine are
described in print media specifications. (See "Print media specifications"
on page 92.)
• Desired outcome: The print media you choose should be appropriate for
your project.
• Brightness: Some print media are whiter than others and produce
sharper, more vibrant images.
• Surface smoothness: The smoothness of the print media affects how
crisp the printing looks on the paper.
•
•
•
•
•
Type
Plain, Color,
Preprinted,
Recycled,
Thickb, Thinc
Source
•
•
•
tray 1
optional trays
multi-purpose tray
a. 60 to 120 g/m2 (16~32 lb bond) only.
b. If media weight is 120 g/m2 (32 lb bond), load a paper into the
multi-purpose tray one by one.
c. If media weight is 60 g/m2 (16 lb bond), select the Thin type.
Changing the tray size
The tray is preset to Letter or A4 size, depending on your country. To
change the size, you need to adjust the paper guides.
1. Push the back plate of the tray outwards completely so that it can extend
the length of the tray.
Some print media may meet all of the guidelines in this section and
still not produce satisfactory results. This may be the result of
improper handling, unacceptable temperature and humidity levels,
or other variables over which cannot be controlled.
Before purchasing large quantities of print media, ensure that it
meets the requirements specifications in this user’s guide and
meets your output requirements.
Using print media that does not meet these specifications may
cause problems, requiring repairs. Such repairs are not covered by
the warranty or service agreements.
Using inflammable print media can cause a fire.
Use designated print media (See "Print media specifications" on
page 92).
2. Squeeze the paper length guide and slide it to the correct position for the
paper size you are loading, which is marked at the bottom of the tray.
The use of inflammable media or foreign materials left in the printer
may lead to overheating of the unit and, in rare cases may cause a
fire.
The amount of paper put into the tray may differ according to media type
used. (See "Print media specifications" on page 92.)
Media and tray_ 42
1 Paper length guide
3. Flex or fan the edge of the paper stack to separate the pages before
loading papers.
machine.
3. Place paper with the side you want to print facing up.
To keep paper with perforated lines from sticking together when
printing, you must fan the sheets before feeding them into the
machine.
4. After inserting paper into the tray, squeeze the paper width guides and
slide them to the desired paper size marked at the bottom of the tray.
1 Paper limit mark
2 Paper level
indicator
Paper quantity indicator shows the amount of paper in the tray.
1 Paper width guide
•
•
Do not push the paper width guide too far causing the media to
warp.
If you do not adjust the paper width guide, it may cause paper
jams.
Loading paper in the tray
Tray 1 / optional trays
Load the print media you use for the majority of your print jobs into tray 1.
Tray 1 can hold a maximum of 500 sheets of plain paper.
You can purchase an optional tray and attach it below the standard tray to
load an additional 500 sheets of plain paper. (See "Available supplies" on
page 83.)
1 Full
2 Empty
4. When you print a document, set the paper type and size for the tray.
For information about setting the paper type and size on the control
panel. (See "Setting the paper size and type" on page 47.)
Using photographic paper or coated paper may cause problems,
requiring repairs. Such repairs are not covered by the warranty or
service agreements.
1. Pull out tray. And adjust the tray size to the media size you are loading.
(See "Changing the tray size" on page 42.)
2. Flex or fan the edge of the paper stack to separate the pages before
loading papers.
•
•
a)
b)
c)
To keep paper with perforated lines from sticking together when
printing, you must fan the sheets before feeding them into the
Media and tray_ 43
d)
e)
If you experience problems with paper feeding, check whether
the paper meets the media specification. Then, try placing one
sheet at a time in the multi-purpose tray.(See "Print media
specifications" on page 92.)
The settings made from the machine driver override the
settings on the control panel.
To print in application, open an application and start the print
menu.
Open Printing Preferences. (See "Opening printing
preferences" on page 48.)
Press the Paper tab in Printing Preferences, and select an
appropriate paper type.
For example, if you want to use a label, set the paper type to
Label.
Select tray in paper source, then press OK.
Start printing in application.
Multi-purpose tray
3. Load the paper.
The multi-purpose tray can hold special sizes and types of print material,
such as postcards, note cards, and envelopes. It is useful for single page
printing on letterhead or colored paper.
Print media should be loaded face down with the top edge going into
the multi-purpose tray first and be placed in the center of the tray.
Tips on using the multi-purpose tray
•
Load only one type, size and weight of print media at a time in the
multi-purpose tray.
• To prevent paper jams, do not add paper while printing when there is
still paper in the multi-purpose tray. This also applies to other types
of print media.
• Always load the specified print media only to avoid paper jams and
print quality problems. (See "Print media specifications" on page 92.)
• Flatten any curl on postcards, envelopes, and labels before loading
them into the multi-purpose tray.
1. Hold the handle of multi-purpose tray and pull it down to open.
4. Squeeze the multi-purpose tray paper width guides and adjust them
to the width of the paper. Do not force them too much, or the paper
will bent resulting in a paper jam or skew.
2. Flex or fan the edge of the paper stack to separate the pages before
loading papers.
•
To keep paper with perforated lines from sticking together
when printing, you must fan the sheets before feeding them
into the machine.
When printing the special media, you must follow the
loading guideline. (See "Printing on special media" on
page 45.)
• When papers overlap when printing using Multi-purpose
tray, open tray 1 and remove overlapping papers then try
printing again.
• When paper does not feed well while printing, push the
paper in manually until it starts feeding automatically.
5. When you print a document, set the paper type and size for the
multi-purpose tray.
For information about setting the paper type and size on the control
panel. (See "Setting the paper size and type" on page 47.)
The settings made from the machine driver override the
settings on the control panel.
a) To print in application, open an application and start the
print menu.
b) Open Printing Preferences. (See "Opening printing
preferences" on page 48.)
c) Press the Paper tab in Printing Preferences, and select
an appropriate paper type.
Media and tray_ 44
For example, if you want to use a label, set the paper type
to Label.
d) Select MP Tray in paper source, then press OK.
e) Start printing in application.
f) After printing, close the multi-purpose tray.
Printing on special media
The table below shows the available special media for each tray.
When using special media, we recommend you feed one paper at a
time. Check the maximum input number of media for each tray. (See
"Print media specifications" on page 92.)
Tray 1
Optional
trays
Multi-purpose
tray
Plain
●
●
●
Thick
●
●
●
Thicker
●
●
●
Extra Thicker
●
●
●
Thin
●
●
●
Cotton
●
●
●
Color
●
●
●
Preprinted
●
●
●
Recycled
●
●
●
Types
Envelope
●
Transparency
●
Labels
●
CardStock
●
Bond
●
Archive
●
•
•
•
•
•
•
•
•
90 g/m2 otherwise, jam may occur.
- Construction: Prior to printing, envelopes should lie flat with less
than 6 mm curl, and should not contain air.
- Condition: Envelopes should not be wrinkled, nicked, nor
damaged.
- Temperature: Use envelopes that are compatible with the heat and
pressure of the machine during operation.
Use only well-constructed envelopes with sharp-and well-creased folds.
Do not use stamped envelopes.
Do not use envelopes with clasps, snaps, windows, coated lining,
self-adhesive seals, or other synthetic materials.
Do not use damaged or poorly made envelopes.
Be sure the seam at both ends of the envelope extends all the way to
the corner of the envelope.
1 Acceptable
2 Unacceptable
Envelopes with a peel-off adhesive strip or with more than one flap that
folds over to seal must use adhesives compatible with the machine’s
fusing temperature for 0.1 second. To view the fusing temperature,
check your machine’s specification. (See "General specifications" on
page 91.) The extra flaps and strips might cause wrinkling, creasing, or
jams, and may even damage the fuser.
For the best print quality, position margins no closer than 15 mm from
the edges of the envelope.
Avoid printing over the area where the envelope’s seams meet.
Transparency
To avoid damaging the machine, use only transparencies designed for use
in laser printers.
In case of color printing using transparencies, the picture quality would
be lower than mono printing when the printouts are used on the
overhead projector.
( ●: Included, Blank: Not available)
Envelope
Successful printing on envelopes depends upon the quality of the
envelopes.
To print an envelope, place it flap side up with the stamp area bottom the
top right side.
•
•
•
•
•
•
When selecting envelopes, consider the following factors:
- Weight: The weight of the envelope paper should not exceed
•
•
Transparencies used in the machine must be able to withstand
machine’s fusing temperature.
Place them on a flat surface after removing them from the machine.
Do not leave unused transparencies in the paper tray for long periods of
time. Dust and dirt may accumulate on them, resulting in spotty printing.
To avoid smudging caused by fingerprints, handle them carefully.
To avoid fading, do not expose printed transparencies to prolonged
sunlight.
Ensure that transparencies are not wrinkled, curled, or have any torn
edges.
Do not use transparencies that separates from the backing sheet.
Media and tray_ 45
•
•
To prevent transparencies from sticking to each other, do not let the
printed sheets stack up as they are begin printed out.
Recommended media: Transparency for color laser printers produced
by Xerox, such as 3R 91331(A4) and 3R 2780(Letter), are
recommended.
Base type transparency (ex. Xerox 3R3117) results in better image and
paper handling quality than paper backed (ex. Xerox 3R3028) or
removable stripe (3R3108) ones.
•
•
•
•
Do not print on media smaller than 76 mm (3 inches) wide or 127 mm (5
inches) long.
In the software application, set margins at least 6.4 mm (0.25 inches)
away from the edges of the material.
Letterhead / Preprinted paper
Single-sided
Transparency with static electricity can cause image quality
problems.
Depending on the selection or storage conditions of the
transparency, jam or image scratch might occur.
double-sided
Tray1/Optio
nal trays
Face up
Face down
Multi-purpo
se tray
Face down
Face up
Labels
To avoid damaging the machine, use only labels designed for use in laser
machines.
•
•
•
•
When selecting labels, consider the following factors:
- Adhesives: The adhesive material should be stable at your
machine’s fusing temperature. Check your machine’s specification to
view the fusing temperature. (See "General specifications" on
page 91.)
- Arrangement: Only use labels with no exposed backing between
them. Labels can peel off sheets that have spaces between the
labels, causing serious jams.
- Curl: Prior to printing, labels must lie flat with no more than 13 mm
of curl in any direction.
- Condition: Do not use labels with wrinkles, bubbles, or other
indications of separation.
Make sure that there is no exposed adhesive material between labels.
Exposed areas can cause labels to peel off during printing, which can
cause paper jams. Exposed adhesive can also cause damage to
machine components.
Do not run a sheet of labels through the machine more than once. The
adhesive backing is designed for only a single pass through the
machine.
Do not use labels that are separating from the backing sheet or are
wrinkled, bubbled, or otherwise damaged.
•
•
•
•
Letterhead/ Preprinted paper must be printed with heat-resistant ink that
will not melt, vaporize, or release hazardous emissions when subjected
to the machine’s fusing temperature for 0.1 second. Check your
machine’s specification to view the fusing temperature. (See "General
specifications" on page 91.)
Letterhead/ Preprinted paper ink must be non-flammable and should not
adversely affect machine rollers.
Forms and letterhead should be sealed in a moisture-proof wrapping to
prevent changes during storage.
Before you load letterhead/preprinted paper, verify that the ink on the
paper is dry. During the fusing process, wet ink can come off preprinted
paper, reducing print quality.
Used paper
When loading used paper, printed side should be facing up with an uncurled
edge at the front. If you experience problems with paper feed, turn the paper
around. Note that print quality is not guaranteed.
Card stock/ Custom-sized paper
•
Used paper must be printed with heat-resistant ink that will not melt,
vaporize, or release hazardous emissions when subjected to the
machine’s fusing temperature for 0.1 second. Check your machine’s
specification to view the fusing temperature. (See "General
specifications" on page 91.)
Media and tray_ 46
•
•
Used paper ink must be non-flammable and should not adversely affect
machine rollers.
Before you load used paper, verify that the ink on the paper is dry.
During the fusing process, wet ink can come off used paper, reducing
print quality.
The printed pages stack on the output support, and the output support will
help the printed pages to align. Unfold the output support.
•
Make sure not to use the inkjet photo paper with this machine. It could
cause damage to the machine.
Glossy
Load one paper to the multi-purpose tray at a time, glossy side facing
down.
•
•
Recommended media: Glossy paper (Letter) for this machine by HP
Brochure Paper (Product: Q6611A) only.
Recommended media: Glossy paper (A4) for this machine by HP
Superior Paper 160 glossy (Product: Q6616A).
Setting the paper size and type
After loading paper in the paper tray, set the paper size and type using the
control panel. For computer printing, select the paper size and type in the
application program, select the Paper tab in the Printing Preferences.
(See "Opening printing preferences" on page 48.)
The settings made from the machine driver override the settings on
the control panel.
1. Press
2.
3.
4.
5.
6.
7.
8.
9.
on the control panel.
Press up/down arrow to highlight Paper and press OK.
Press up/down arrow to select the paper tray you want press OK.
Press up/down arrow to highlight Paper Size and press OK.
Press up/down arrow to select the paper size you want.
Press OK to save the selection.
Press up/down arrow to highlight Paper Type and press OK.
Press up/down arrow to select the paper type you want.
Press OK to save the selection.
10. Press
.
11. Press up/down arrow to highlight Paper Source and press OK.
12. Press up/down arrow to select the paper tray you want.
13. press OK to save the selection.
14. Press
to return to ready mode.
If you want to use special-sized paper-such as a billing paper, select
Custom in the Paper tab in the Printing Preferences. (See "Opening
printing preferences" on page 48.)
Using the output support
The surface of the output tray may become hot if you print a large
number of pages at once. Make sure that you do not touch the
surface, and do not allow children near it.
Media and tray_ 47
printing
6.
This chapter explains common printing tasks.
This chapter includes:
•
•
•
•
•
•
•
•
Basic printing
Changing the default print settings
Setting your machine as a default machine
Using advanced print features
Using Direct Printing Utility (Windows only)
Macintosh printing
Linux printing
Unix printing
Opening printing preferences
The procedures in this chapter are mainly based on Windows 7.
•
Basic printing
Printing
•
The following Printing Preferences window is for Notepad in Windows 7.
1. Open the document you want to print.
2. Select Print from the File menu.
3. Select your machine from the Select Printer list.
1.
2.
3.
4.
The Printing Preferences window that appears in this user’s
guide may differ depending on the machine in use. However, the
composition of the Printing Preferences window is similar.
When you select an option in Printing Preferences, you may see
a warning mark,
, or
. An exclamation mark ( ) means you
can select that certain option but it is not recommended, and ( )
mark means you cannot select that option due to the machine’s
setting or environment.
Open the document you want to print.
Select Print from the file menu.
Select your machine from the Select Printer.
Click Properties or Preferences.
4. The basic print settings including the number of copies and print range
are selected within the Print window.
To take advantage of the advanced printing features, click
Properties or Preferences from the Print window (see "Opening
printing preferences" on page 48).
5. To start the print job, click OK or Print in the Print window.
Canceling a print job
If the print job is waiting in the print queue or print spooler, cancel the job as
follows:
• You can access this window by simply double-clicking the machine icon
(
•
Using a favorite setting
) in the Windows task bar.
You can also cancel the current job by pressing
panel.
You can check the machine's current status using the Printer
Status button.
The Presets option, which is visible on each preferences tab except for
the Samsung tab, allows you to save the current preferences for future
use.
To save a Presets item, follow these steps:
on the control
Printing_ 48
•
•
For Windows XP/Server 2003, select Printer and Faxes.
For Windows Server 2008/Vista, select Control Panel > Hardware
and Sound > Printers.
• For Windows 7, select Control Panel > Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
2. Select your machine.
3. Right-click your machine and select Set as Default Printer.
1. Change the settings as needed on each tab.
2. Enter a name for the item in the Presets input box.
For Windows 7 or Windows Server 2008 R2, if Set as default
printer has a ►, you can select other printer drivers connected to
the selected printer.
Using advanced print features
XPS printer driver: used to print XPS file format.
• The XPS printer driver can be installed only on Windows Vista OS
or higher.
• You can install the XPS printer driver when you insert the software
CD into your CD-ROM drive. When the installation window
appears, select Advanced Installation > Custom Installation.
You can select the XPS printer driver in the Select Software and
Utilities to Install window.
• Install optional memory when an XPS job does not print because
the printer is out of memory.
3. Click
(Add). When you save Presets, all current driver settings
are saved.
Select more options and click
(Update), settings will be added
to the Presets you made. To use a saved setting, select it from the
Presets drop-down list. The machine is now set to print according
to the settings you have selected. To delete saved settings, select
it from the Presets drop-down list and click
(Delete).
You can also restore the printer driver’s default settings by
selecting Default Preset from the Presets drop-down list.
Using help
Click the option you want to know on the Printing Preferences window and
press F1 on your keyboard.
Printing to a file (PRN)
You will sometimes need to save the print data as a file.
1. Check the Print to file box in the Print window.
Changing the default print settings
1. Click the Windows Start menu.
• For Windows Server 2000, select Settings > Printers.
• For Windows XP/Server 2003, select Printer and Faxes.
• For Windows Server 2008/Vista, select Control Panel > Hardware
and Sound > Printers.
• For Windows 7, select Control Panel > Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
2. Right-click on your machine.
3. For Windows XP/Server 2003/Server 2008/Vista, select Printing
Preferences.
For Windows 7 or Windows Server 2008 R2, from context menus, select
Printing preferences.
If Printing preferences has a ►, you can select other printer
drivers connected to the selected printer.
4. Change the settings on each tab.
5. Click OK.
2. Click Print.
3. Type in the destination path and the file name, and then click OK.
For example, c:\Temp\file name.
If you type in only the file name, the file is automatically saved in
My Documents, Documents and Settings, or Users. The saved
folder may differ, depending on your operating system or the
application you are using.
If you want to change the settings for each print job, change it in
Printing Preferences.
Setting your machine as a default machine
1. Click the Windows Start menu.
• For Windows Server 2000, select Settings > Printers.
Printing_ 49
Understanding special printer features
You can use advanced printing features when using your machine.
To take advantage of the printer features provided by your printer driver,
click Properties or Preferences in the application’s Print window to change
the print settings. The machine name, that appears in the printer properties
window may differ depending on the machine in use.
Item
Double-sided Printing
Description
Print on both sides of a sheet of paper
(duplex). Before printing, decide how you
want your document oriented.
•
Some menus may not appear on the display depending on options or
models. If so, it is not applicable to your machine.
Item
Description
Multiple Pages per Side
Selects the number of pages to print on a
single sheet of paper. To print more than one
page per sheet, the pages will be reduced in
size and arranged in the order you specify.
You can print up to 16 pages on one sheet.
Poster Printing
Booklet Printing
8
9
•
•
Double-sided Printing
(Option)
Prints a single-page document onto 4
(Poster 2x2), 9 (Poster 3x3), or 16 (Poster
4x4) sheets of paper, for the purpose of
pasting the sheets together to form one
poster-size document.
Select the Poster Overlap value. Specify
Poster Overlap in millimeters or inches by
selecting the radio button on the upper right
of Basic tab to make it easier to paste the
sheets together.
•
•
•
Prints your document on both sides of a
sheet of paper and arranges the pages so
that the paper can be folded in half after
printing to produce a booklet.
If you want to make a booklet, you need to
print on Letter, Legal, A4, US Folio, or Oficio
sized print media.
The Booklet Printing option is not
available for all paper sizes. Select the
available paper Size option under the
Paper tab to see what paper sizes are
available.
If you select an unavailable paper size,
this option can be automatically
canceled. Select only available paper
(paper without
or
mark).
Printing_ 50
You can use this feature with
Letter, Legal, A4, US Folio or Oficio
sized paper
If your machine does not have a
duplex unit, you should complete
the printing job manually. The
machine prints every other page of
the document first. After that, a
message appears on your
computer.
Skip Blank Pages feature does
not work when you select the
duplex option.
Printer Default: If you select this option,
this feature is determined by the settings
you have selected on the control panel of
the machine. This option is available only
when you use the PCL/XPS printer driver.
None: Disables this feature.
Long Edge: This option is the
conventional layout used in bookbinding.
•
Short Edge: This option is the
conventional layout used in calendars.
•
Reverse Double-Sided Printing: Check
this option to reverse the print order when
duplex printing.
Paper Options
Changes the size of a document to appear
larger or smaller on the printed page by
entering in a percentage by which to enlarge
or decrease the document.
Watermark
The watermark option allows you to print text
over an existing document. For example, you
use it when you want to have large gray
letters reading “DRAFT” or
“CONFIDENTIAL” printed diagonally across
the first page or all pages of a document.
Item
Description
Watermark
(Creating a watermark)
1 To change the print settings from your
software application, access Printing
Preferences.
2 Click the Advanced tab, select Edit from
the Watermark drop-down list. The Edit
Watermarks window appears.
3 Enter a text message in the Watermark
Message box. You can enter up to 256
characters. The message displays in
the preview window.
Watermark
(Editing a watermark)
1 To change the print settings from your
software application, access Printing
Preferences.
2 Click the Advanced tab, select Edit from
the Watermark drop-down list. The Edit
Watermarks window appears.
3 Select the watermark you want to edit
from the Current Watermarks list and
change the watermark message and
options.
4 Click Update to save the changes.
5 Click OK or Print until you exit the Print
window.
Watermark
(Deleting a watermark)
Item
1 To change the print settings from your
software application, access Printing
Preferences.
2 Click the Advanced tab, select Edit from
the Watermark drop-down list. The Edit
Watermarks window appears.
3 Select the watermark you want to
delete from the Current Watermarks list
and click Delete.
4 Click OK or Print until you exit the Print
window.
Printing_ 51
Overlay
Description
This option is available only when you use
the PCL printer driver.
An overlay is text and/or images stored in the
computer hard disk drive (HDD) as a special
file format that can be printed on any
document. Overlays are often used to take
the place of letterhead paper. Rather than
using preprinted letterhead, you can create
an overlay containing exactly the same
information that is currently on your
letterhead. To print a letter with your
company’s letterhead, you do not need to
load preprinted letterhead paper in the
machine: just print the letterhead overlay on
your document.
To use a page overlay, you must create a
new page overlay containing your logo or
image.
•
•
Overlay
(Creating a new page
overlay)
The overlay document size must be
the same as the document you
print with the overlay. Do not create
an overlay with a watermark.
The resolution of the overlay
document must be the same as
that of the document you will print
with the overlay.
1 To save the document as an overlay,
access Printing Preferences.
2 Click the Advanced tab, and select Edit
from the Text drop-down list. Edit
Overlay window appears.
3 In the Edit Overlay window, click Create.
4 In the Save As window, type a name up
to eight characters in the File name box.
Select the destination path, if
necessary (The default is
C:\Formover).
5 Click Save. The name appears on the
Overlay List.
6 Click OK or Print until you exit the Print
window.
The file is not printed. Instead, it is stored
on your computer hard disk drive.
Item
Description
Overlay
(Using a page overlay)
1 Click the Advanced tab.
2 Select the desired overlay from the
Text drop-down list.
3 If the overlay file you want does not
appear in the Text drop-down list, select
Edit... from the list and click Load. Select
the overlay file you want to use.
If you have stored the overlay file you
want to use in an external source, you can
also load the file when you access the
Open window.
After you select the file, click Open. The
file appears in the Overlay List box and is
available for printing. Select the overlay
from the Overlay List box.
4 If necessary, check Confirm Page
Overlay When Printing box. If this box
is checked, a message window
appears each time you submit a
document for printing, asking you to
confirm printing an overlay on your
document.
If this box is not checked and an overlay
has been selected, the overlay
automatically prints with your document.
5 Click OK or Print until you exit the Print
window.
Overlay
(Deleting a page
overlay)
Item
Description
Print Mode
•
•
1 In the Printing Preferences window,
click the Advanced tab.
2 Select Edit in the Text drop down list.
3 Select the overlay you want to delete
from the Overlay List box.
4 Click Delete.
5 When a confirming message window
appears, click Yes.
6 Click OK or Print until you exit the Print
window. You can delete page overlays
that you no longer use.
•
•
This feature is available only if you
have installed the optional hard
disk.
• Some menus may not appear on the
display depending on options or
models. If so, it is not applicable to
your machine.
• You can see the print job list you set
in the printer driver's Print Mode in
the Job Management menu.
Print Mode: The default Print Mode is
Normal, which is for printing without
saving the printing file in the memory.
- Normal: This mode prints without
storing your document in the optional
memory.
- Proof: This mode is useful when you
print more than one copy. You can
print one copy first to check, then print
the rest of the copies later.
- Confidential: This mode is used for
printing confidential documents. You
need to enter a password to print.
- Store: Select this setting to save a
document in the hard disk without
printing.
- Store and Print: This mode is used
when printing and storing document at
the same time.
- Spool: This option can be useful
when handling large amounts of data.
If you select this setting, the printer
spools the document into the hard disk
and then prints it from the hard disk
queue, decreasing the computer’s
work load.
- Print Schedule: Select this setting to
print the document at a specified time.
User ID: This option is used when you
need to find a saved file using the control
panel.
Job Name: This option is used when you
need to find a saved file using the control
panel.
Using Direct Printing Utility (Windows only)
What is Direct Printing Utility?
Direct Printing Utility is a program that sends PDF files directly to your
machine to print without having to opening the file.
To install this program, select Advanced Installation > Custom
Installation and put a check mark in this program when you install the
printer driver.
•
•
Printing_ 52
For some models, a hard disk drive (HDD) should be installed or
memory inserted to properly run utilities. Otherwise, they should
be installed.
You cannot print PDF files that are restricted. Deactivate the
•
•
•
printing restriction feature and retry printing.
You cannot print PDF files that are restricted by a password.
Deactivate the password feature, and retry printing.
Whether or not a PDF file can be printed using the Direct Printing
Utility program depends on how the PDF file was created.
The Direct Printing Utility program supports PDF version 1.7 and
below. For higher versions, you must open the file to print it.
Printing
1. Open an application, and select Print from the File menu.
2. Select Layout from the drop-down list under Orientation. In the Pages
per Sheet drop-down list, select the number of pages you want to print
on one sheet of paper.
3. Select the other options to use.
4. Click Print.
The machine prints the selected number of pages to print on one sheet
of paper.
Printing on both sides of the paper
There are several ways you can print using the Direct Printing Utility.
1. From the Start menu select Programs or All Programs > Samsung
Printers > Direct Printing Utility > Direct Printing Utility.
The Direct Printing Utility window appears.
2. Select your machine from the Select Printer drop-down list and click
Browse.
3. Select the file you wish to print and click Open.
The file is added in the Select Files section.
4. Customize the machine settings for your needs.
5. Click Print. The selected PDF file is sent to the machine.
Some features may not be available depending on models or options.
It means that the features are not supported.
Before printing in the duplex mode, decide on which edge you will be
binding your finished document. The binding options are, as follows:
• Long-Edge Binding: This option is the conventional layout used in
book binding.
• Short-Edge Binding: This option is the type often used with calendars.
1. From your Macintosh application, select Print from the File menu.
2. Select Layout from the drop-down list under Orientation.
3. Select a binding orientation from the Two-Sided option.
4. Select the other options to use.
5. Click Print and the machine prints on both sides of the paper.
Using the right-click menu
1. Right-click on the PDF file to print and select Direct Printing.
The Direct Printing Utility window appears with the PDF file is added.
2. Select the machine to use.
3. Customize the machine settings.
4. Click Print. The selected PDF file is sent to the machine.
If you print more than 2 copies, the first copy and the second copy
might print on the same sheet of paper. Avoid printing on both sides of
paper when you are printing more than 1 copy.
Using help
Macintosh printing
Some features may not be available depending on models or options.
It means that the features are not supported.
Click the question mark on the bottom-left corner of the window and click on
the topic you want to know about. A pop-up window appears with
information about that option's feature, which is provided from the driver.
Printing a document
When you print with a Macintosh, you need to check the printer driver
settings in each application you use. Follow the steps below to print from a
Macintosh:
1. Open the document to print.
2. Open the File menu and click Page Setup (Document Setup in some
applications).
3. Choose your paper size, orientation, scaling, other options, and make
sure that your machine is selected. Click OK.
4. Open the File menu and click Print.
5. Choose the number of copies and indicate which pages to print.
6. Click Print.
Changing printer settings
You can use advanced printing features when using your machine.
Open an application and select Print from the File menu. The machine
name, which appears in the printer properties window, may differ depending
on the machine in use. Except for the name, the composition of the printer
properties window is similar to the following.
Printing multiple pages on one sheet
You can print more than one page on a single sheet of paper. This feature
provides a cost-effective way to print draft copies.
Linux printing
Some features may not be available depending on models or options.
It means that the features are not supported.
Printing from applications
There are a lot of Linux applications that allow you to print using Common
UNIX Printing System (CUPS). You can print on your machine from any
such application.
Printing_ 53
1. Open an application, and select Print from the File menu
2. Select Print directly using lpr.
3. In the LPR GUI window, select the model name of your machine from
the printer list and click Properties.
4. Change the print job properties using the following four tabs displayed at
the top of the window.
• General: Changes the paper size, the paper type, and the
orientation of the documents. It enables the duplex feature, adds
start and end banners, and changes the number of pages per sheet.
previous jobs on the job list.
Classes: Shows the class that your machine is in. Click Add to
Class to add your machine to a specific class or click Remove from
Class to remove the machine from the selected class.
4. Click OK to apply the changes and close the Printer Properties
window.
Automatic/manual duplex printing may not be available
depending on models. You can alternatively use the lpr printing
system or other applications for odd-even printing.
Some features may not be available depending on models or options.
It means that the features are not supported.
•
Text: Specifies the page margins and set the text options, such as
spacing or columns.
• Graphics: Sets image options that are used when printing image
files, such as color options, image size, or image position.
• Advanced: Sets the print resolution, paper source, and destination.
5. Click Apply to apply the changes and close the Properties window.
6. Click OK in the LPR GUI window to start printing.
7. The Printing window appears, allowing you to monitor the status of your
print job.
To abort the current job, click Cancel.
•
Unix printing
Proceeding the print job
After installing the printer, choose any of the image, text, PS or HPGL files
to print.
1. Execute “printui <file_name_to_print>” command.
For example, if you are printing “document1”
printui document1
This will open the UNIX Printer Driver Print Job Manager in which the
user can select various print options.
2. Select a printer that has been already added.
3. Select the printing options from the window such as Page Selection.
4. Select how many copies are needed in Number of Copies.
Printing files
To take advantage of the printer features provided by your printer
driver, press Properties (see "Changing printer settings" on
page 53).
You can print many different types of files on your machine using the
standard CUPS, directly from the command line interface. The CUPS lpr
utility allows you to do that, but the driver’s package replaces the standard
lpr tool by a much more user-friendly LPR GUI program.
To print any document file:
1. Enter lpr <file_name> from the Linux shell command line and press
Enter. The LPR GUI window appears.
When you type only lpr and press Enter, the Select file(s) to print
window appears first. Just select any files you want to print and click
Open.
2. In the LPR GUI window, select your machine from the list, and change
the print job properties.
3. Click OK to start printing.
5. Press OK to start the print job.
Changing the machine settings
The UNIX printer driver Print Job Manager in which the user can select
various print options in printer Properties.
The following hot keys may also be used: “H” for Help, “O” for OK, “A” for
Apply, and “C” for Cancel.
General tab
•
•
Configuring Printer Properties
Using the Printer Properties window provided by the Printers
configuration, you can change the various properties for your machine as
a printer.
1. Open the Unified Driver Configurator.
If necessary, switch to Printers configuration.
2. Select your machine on the available printers list and click Properties.
3. The Printer Properties window appears.
The following five tabs display at the top of the window:
• General: Allows you to change the printer location and name. The
name entered in this tab displays on the printer list in Printers
configuration.
• Connection: Allows you to view or select another port. If you
change the machine port from USB to parallel or vice versa while in
use, you must re-configure the machine port in this tab.
• Driver: Allows you to view or select another machine driver. By
clicking Options, you can set the default device options.
• Jobs: Shows the list of print jobs. Click Cancel job to cancel the
selected job and select the Show completed jobs check box to see
Printing_ 54
•
•
•
Paper Size: Set the paper size as A4, Letter, or other paper sizes,
according to your requirements.
Paper Type: Choose the type of the paper. Options available in the
list box are Printer Default, Plain, and Thick.
Paper Source: Select from which tray the paper is used. By default,
it is Auto Selection.
Orientation: Select the direction in which information is printed on a
page.
Duplex: Print on both sides of paper to save paper.
Automatic/manual duplex printing may not be available
depending on models. You can alternatively use the lpr printing
system or other applications for odd-even printing.
•
•
Multiple pages: Print several pages on one side of the paper.
Page Border: Choose any of the border styles (e.g., Single-line
hairline, Double-line hairline)
Image tab
In this tab, you can change the brightness, resolution, or image position
of your document.
Text tab
Set the character margin, line space, or the columns of the actual print
output.
HPGL/2 tab
•
•
•
Use only black pen: To print all graphics in black.
Fit plot to page: Fit the entire graphic into a single page.
Pen Width: Change value to increase the thickness of pen lines. By
default, it is 1000.
Margins tab
•
•
Use Margins: Set the margins for the document. By default,
margins are not enabled. The user can change the margin settings
by changing the values in the respective fields. Set by default, these
values depend on the page size selected.
Unit: Change the units to points, inches, or centimeters.
Printer-Specific Settings tab
Select various options in the JCL and General frames to customize
various settings. These options are specific to the printer and depend on
the PPD file.
Printing_ 55
machine status and advanced features
7.
This chapter explains how to browse the current status of your machine, and the method of setting for the advanced
machine setup. Read this chapter carefully in order to use your machine's diverse features.
This chapter includes:
•
•
•
•
•
Accessing the Menu
Information
Layout
Paper
Graphic
•
•
•
•
•
Accessing the Menu
1. Press
2.
3.
4.
5.
Layout
on the control panel.
Press up/down arrow to highlight the desired setting and press OK.
If the setting item has sub menus, repeat step 2.
Press up/down arrow to access the required value.
Press OK to save the selection.
6. If you want to move to the upper level menus, press
7. Press
System Setup
Emulation
Color
Network
Job Management
Item
Orientation
This menu allows you to select the direction in
which information is printed on a page.
Common Margin
Set the margins for print materials. The margins
you set here will be applied when printing from
all trays.
• Simplex: Set the margin of print materials
for one-sided printing.
• Duplex: Set the margins for double-sided
printing.
• Binding: When printing on both sides of
paper, side A's margin closest to the binding
will be the same as side B's margin closest to
the binding. Likewise, the sides' margins
farthest from the binding will be the same.
<Tray X>
Set the margins for print materials. The margins
you set here will be applied when printing from
the tray1 and optional trays.
• Simplex: Set the margin of print materials
for one-sided printing.
• Duplex: Set the margins for double-sided
printing.
MP Tray
Set the margins for print materials. The margins
you set here will be applied when printing from
the multi-purpose tray.
• Simplex: Set the margin of print materials
for one-sided printing.
• Duplex: Set the margins for double-sided
printing.
Emulation Margin
When creating an emulation print page which
does not include margin information, the
machine uses the margin value set here.
• Top Margin: Set the top margin, from 0.0 to
250mm.
• Left Margin: Set the left margin, from 0.0 to
164mm.
.
to return to ready mode.
Information
Option
Description
Menu Map
You can print the menu map which shows the
layout and current settings of this machine.
Configuration
You can print a report on the machine's overall
configuration.
Supplies Info.
You can print the supply information page.
Demo Page
You can print the demo page whether your
machine is printing properly or not.
PCL Font
You can print the PCL font list.
PS Font
You can print the PS font list.
Stored Jobsa
You can print jobs currently stored in the hard
disk.
Completed Jobsa
You can print the list of completed print jobs.
Usage Countera
The usage page contains the total number of
pages printed by person or group.
Account
You can print a report on the number of
printouts.
Description
a. This menu item is available when the optional hard disk is installed.
Machine status and advanced features_ 56
Item
Duplex
Graphic
Description
To print on both sides of paper, choose the
binding edge.
• Off: Set this option off.
• Long Edge: This item is the conventional
layout used in bookbinding.
• Short Edge: This item is the conventional
layout used in calendars.
Option
Resolution
You can select the default resolution. If the
resolution is high, the clarity of the printouts is
sharper, but the print time may take longer.
• 600dpi-Normal: If your print jobs are mostly
text, select this option for the highest quality
output.
• 1200dpi-Best: Select this option when your
job contains bitmapped images, such as
scanned photos or certain business
graphics, that will benefit from enhanced line
screening.
Edge Enhance
It allows user to enhance sharpness of text and
graphics for improving readability.
Trapping
It reduces the white gap caused by
misalignment of color channels in color printing
mode. Also black text will be overprinted on
other colors.
Clear Text
Select this option to print texts darker than on a
normal document.
Screen
This option affect the resolution and clarity of
your color output.
• Normal: This mode will generate printouts
with smooth tone over the entire page.
• Enhanced: This mode will generate
printouts with sharp texts and smooth
graphic/photo objects in the page.
• Detailed: This mode will generate printouts
with sharp details over the entire page.
Paper
Option
Description
Copies
You can select the maximum amount of copies.
MP Tray
[Tray<x>]
•
•
Paper Source
Auto Tray Switch
Paper Size: You can select the default paper
size.
Paper Type: You can select the default
paper type for the print media.
You can select the tray to process the print job. If
you select Auto, your machine supplies the
paper from the multi-purpose tray first, than the
tray 1, and tray 2 for the last. So if any tray is
empty, then the machine try to search the paper
from the next available tray.
This is the option to set if the machine is to
continue printing or not when any tray becomes
empty. For example, if both tray 1 and tray 2 are
filled with the same size paper, the machine
automatically prints from tray 2 after the tray 1
runs out of paper.
This option does not appear if you selected
Auto for Paper Source.
Tray Confirm
Allows you to select the tray and paper for a
printing job. Tray Confirm activates the window
asking whether you set the paper size and type
for the tray that was just opened.
• With this option On and both tray1 and tray2
are filled with letter size paper, the machine
automatically prints from tray2 after tray1 is
empty.
Description
System Setup
Option
Description
Date & Timea
You can set the date and time. (See "Setting the
date and time" on page 40.)
Clock Modea
You can set your machine to display the current
time using either a 12-hour or 24-hour format.
(See "Changing the clock mode" on page 40.)
Form Menua
•
•
•
Machine status and advanced features_ 57
Off: Prints in normal mode.
Single Form: Prints all page using the first
form.
Double Form: Prints the front page using
the first form and the back page using the
second form.
Option
Select Forma
Description
Form overlay is images stored in the printer
hard disk drive (HDD) as a special file format
that can be printed in layers on any document.
(See "Form file" on page 89.)
•
•
Language
Option
Select Form is not displayed when
Form Menu is set as Off.
2nd Form is displayed when Form
Menu is set as Double Form.
Allows you to change the language that appears
on the display. (See "Changing the display
language" on page 40.)
Power Save
Reduce energy consumption by setting power
saving features. (See "Using power saving
feature" on page 41.)
Wakeup Event
You can set the condition to wake up from
power-save mode. Set the item on.
• Button Press: When you press power
button, the machine wake up from the power
save mode.
• Printer: When you open or close the paper
tray, the machine wake up from the power
save mode.
Auto Continue
Altitude Adjustment
This item determines whether or not the
machine continues printing when it detects
paper that is not matched to your paper setting.
• Off: If a paper mismatch occurs, the
message remains on the display and the
machine remains off-line until you insert the
correct paper.
• On: If the paper is mismatched, an error
message displays. The machine goes
off-line for 30 seconds then automatically
clears the message and continues printing.
Print quality is affected by atmospheric
pressure. The atmospheric pressure is
determined by the height of the machine above
sea level. This feature lets you adjust the
altitude in a height district. The higher the
altitude, the higher the adjustment, the highest
being High 3. (See "Altitude adjustment" on
page 40.)
Auto CR
This option allows you to append the required
carriage return to each line feed, which is useful
to the Unix user or DOS user.
Job Timeout
You can set the amount of time a single print job
is active before it must print. The machine
handles incoming data as a single job, if it
comes in within the specified time. When an
error occurs while processing data from the
computer and the data flow stops, the machine
waits the specified amount of time and then
cancels printing if data flow does not resume.
Maintenance
Description
Clear Settings
This menu item allows you to restore the
printer's factory default settings.
Spoolinga
To spool documents in HDD for the network
printing, select On.
a. This menu item is available when the optional hard disk is installed.
Emulation
Option
Description
Emulation Type
The machine language defines how the
computer communicates with the machine.
If you select Auto, your machine can change the
machine language automatically.
Setup
You can set the detailed settings for the
emulation type you selected.
Color
Option
Description
Custom Color
This menu allows you to adjust contrast, color by
color.
• Default: Optimizes colors automatically.
• Manual Adjust: Allows you to manually
adjust the color contrast for each cartridge.
It is recommended to use the Default setting for
best color quality.
Auto Color Reg.
You can adjust the position of color texts or
graphics to match the position of the printed
colors to those on your screen.
If you have moved the machine, it is
strongly recommended to operate this
menu manually.
Density Calibration
You can manually calibrate the toner density of
machine for the best possible color print quality.
Density Control
The machine automatically calibrates the toner
density of machine for the best possible color
print quality.
If you select Off, the machine is calibrated by
the factory default toner density.
Network
Option
Ethernet Speed
This menu allows you to maintain consumables
within the machine and check supplies' life. You
can clean fuser components.
Machine status and advanced features_ 58
Description
Configure the network transmission speed.
Option
TCP/IP (IPv4)
Description
Select appropriate protocol and configure
parameters to use the network environment.
There are lots of parameters to be set;
therefore, if you are not sure, leave as is, or
consult the network administrator.
TCP/IP (IPv6)
Selects this option to use the network environment
through IPv6. (See "IPv6 configuration" on
page 39.)
Wirelessa
Configure the wireless network environments.
(See "Wireless network setup" on page 32.)
Clear Settings
Reverts the network settings to the default values.
Network
Configuration
You can print the network configuration report.
Net. Activate
You can set to use Ethernet on or off.
Http Activate
You can set to use SyncThru™ Web Service or
not. If you set this option to “off”, users cannot
access SyncThru™ Web Service.
a. This menu only appears when an optional wireless network interface
has been installed.
Job Management
This menu item is avaidlable when the optional hard disk is installed.
(See "Printing with the optional hard disk" on page 88.)
Machine status and advanced features_ 59
management tools
8.
This chapter introduces management tools provided to help you make full use of your machine.
This chapter includes:
•
•
•
•
•
•
Samsung AnyWeb Print
Using SyncThru™ Web Service
Using Samsung Easy Printer Manager (Windows only)
Samsung AnyWeb Print
•
This tool helps you screen-capture, preview, scrap, and print Windows
Internet Explorer pages more easily, than when you use an ordinary
program. Click Start > All programs > Samsung Printers > Samsung
AnyWeb Print > Download the latest version to link to the website where
the tool is available for download.
Using SyncThru™ Web Service
•
•
•
Using Samsung Printer Status (Windows only)
Using Smart Panel (Macintosh and Linux only)
Using the Unified Linux Driver Configurator
Internet Explorer 6.0 or higher is the minimum requirement for
SyncThru™ Web Service.
SyncThru™ Web Service explanation in this user’s guide may
differ from your machine depending on its options or models.
Network model only.
Accessing SyncThru™ Web Service
1. Access a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address of your printer (http://xxx.xxx.xxx.xxx) in
the address field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
•
•
left in the cartridge.
Usage Counters: Shows the usage count by print types: simplex
and duplex.
Current Settings: Shows the machine’s and network’s information.
Print information: Prints reports such as system related reports
and font reports.
Settings tab
This tab allows you to set configurations provided by your machine and
network. You need to log-in as an administrator to view this tab.
• Machine Settings tab: Sets options provided by your machine.
• Network Settings tab: Shows options for the network environment.
Sets options such as TCP/IP and network protocols.
Security tab
This tab allows you to set system and network security information. You
need to log-in as an administrator to view this tab.
• System Security: Sets the system administrator’s information and
also enables or disables machine features.
• Network Security: Sets settings for HTTPs, IPSec, IPv4/IPv6
filtering, and 802.1x.
Maintenance tab
Logging into SyncThru™ Web Service
Before configuring options in SyncThru™ Web Service, you need to
log-in as an administrator. You can still use SyncThru™ Web Service
without logging in but you won’t have access to Settings tab and
Security tab.
1. Click Login on the upper right of the SyncThru™ Web Service
website.
2. Type in the ID and Password then click Login.
• ID: admin
• Password: sec00000
SyncThru™ Web Service overview
Some tabs may not appear depending on your model.
Information tab
This tab gives you general information about your machine. You can
check things, such as remaining amount of toner. You can also print
reports, such as an error report.
• Active Alerts: Shows the alerts that have occurred in the machine
and their severity.
• Supplies: Shows how many pages are printed and amount of toner
This tab allows you to maintain your machine by upgrading firmware and
setting contact information for sending emails. You can also connect to
Samsung website or download drivers by selecting the Link menu.
• Firmware Upgrade: Upgrade your machine’s firmware.
• Contact Information: Shows the contact information.
• Link: Shows links to useful sites where you can download or check
information.
E-mail notification setup
You can receive emails about your machine’s status by setting this option.
By setting information such as IP address, host name, e-mail address and
SMTP server information, the machine status (toner cartridge shortage or
machine error) will be sent to a certain person's e-mail automatically. This
option may be used more frequently by a machine administrator.
1. Start a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address
field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
3. From the Settings tab, select Machine Settings > E-mail Notification.
Management tools_ 60
If you have not configured outgoing server environment, go to
Settings > Network Settings > Outgoing Mail Server(SMTP) to
configure network environment before setting e-mail notification.
4. Select Enable check box to use the E-mail Notification.
5. Click Add button to add e-mail notification user.
Set the recipient name and e-mail address(es) with notification items
you want to receive an alert for.
6. Click Apply.
If the firewall is activated, the e-mail may not be sent successfully. In
that case, contact the a network administrator.
Understanding Samsung Easy Printer Manager
To open the program:
Select Start > Programs or All Programs > Samsung Printers >
Samsung Easy Printer Manager > Samsung Easy Printer Manager.
The Samsung Easy Printer Manager interface is comprised of various basic
sections as described in the table that follows:
Setting the system administrator’s information
This setting is necessary for using the e-mail notification option.
1. Start a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address
field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
3. From the Security tab, select System Security > System
Administrator
4. Enter the name of the administrator, phone number, location, and email
address.
5. Click Apply.
Using Samsung Easy Printer Manager (Windows
only)
Samsung Easy Printer Manager is a Windows-based application that
combines Samsung machine settings into one location. Samsung Easy
Printer Manager combines device settings as well as printing environments,
settings/actions and launching. All of these features provide a gateway to
conveniently use your Samsung machine. Samsung Easy Printer Manager
provides two different user interfaces for the user to choose from: the basic
user interface and the advanced user interface. Switching between the two
interfaces is easy: just click a button.
1
Internet Explorer 6.0 or higher is the minimum requirement for
Samsung Easy Printer Manager.
Printer List
The printer list displays the installed printer icons
on your computer.
Printer
Information
This area gives you general information about
your machine. You can check information, such as
the machine’s model name, IP address (or Port
name), and machine status.
2
User’s Guide button: This button opens
Troubleshooting Guide when an error
occurs. You can directly open the necessary
section in the user’s guide.
Application
information
3
The
button is used to change the user
interface to the advanced settings user
interface.
Quick links
Displays Quick links to machine specific
functions. This section also includes links to
applications in the advanced settings.
Contents
Area
Displays information about the selected machine,
remaining toner level, and paper. The information
will vary based on the machine selected. Some
machines do not have this feature.
Order
Supplies
Click on the Order button from the supply ordering
window. You can order replacement toner
cartridge(s) from online.
4
5
6
Includes links for changing to the advanced
settings, preference, help, and about.
Click the Help (
Management tools_ 61
) button from the upper-right corner of the window
and click on any option you want to know about.
Icon
Advanced settings user interface overview
The advanced user interface is intended to be used by the person
responsible for managing the network and machines.
Device Settings
Mean
Normal
The machine is in ready mode and experiencing
no errors or warnings.
Warning
The machine is in a state where an error might
occur in the future. For example, it might be in
toner low status, which may lead to toner empty
status.
Error
The machine has at least one error.
You can configure various machine settings such as machine setup,
paper, layout, emulation, network, and print information.
Alert Settings
Description
This is menu includes settings related to error alerting.
• Printer Alert: Provides settings related to when alerts will be
received.
• Email Alert: Povides options relating to receiving alerts via email.
• History Alert: Provides a history of device and toner related alerts.
Job Accounting
Provides querying of quota information of the specified job accounting
user. This quota information can be created and applied to devices by
job accounting software such as SyncThru™ or CounThru™ admin
software.
Using Samsung Printer Status (Windows only)
The Samsung Printer Status is a program that monitors and informs you of
the machine status.
•
•
The Samsung Printer Status window and its contents shown in this
user’s guide may differ depending on the machine or operating
system in use.
Check the operating system(s) that are compatible with your
machine.
Samsung Printer Status overview
If an error occurs while operating, you can check the error from the
Samsung Printer Status. Samsung Printer Status is installed automatically
when you install the machine software.
You can also launch Samsung Printer Status manually. Go to the Printing
Preferences , click the Basic tab > Printer Status button.
These icons appear on the Windows task bar:
Toner Level
You can view the level of toner remaining in
each toner cartridge. The machine and the
number of toner cartridge(s) shown in the
above window may differ depending on the
machine in use. Some machines do not have
this feature.
Alert Settings
Select the settings you want from the options
window.
Order Supplies
You can order replacement toner
cartridge(s) from online.
Troubleshooting
You can directly open the troubleshooting
section in the user’s guide.
Close
Close the window.
1
2
3
4
5
Using Smart Panel (Macintosh and Linux only)
Smart Panel is a program that monitors and informs you of the machine’s
status, and allows you to customize the machine’s settings. For Macintosh,
Smart Panel is installed automatically when you install the machine
software. For Linux, you can download Smart Panel from the Samsung
website.
•
•
Management tools_ 62
The Smart Panel window and its contents shown in this user’s
guide may differ depending on the machine or operating system in
use.
Check the operating system(s) that are compatible with your
machine.
Smart Panel overview
If an error occurs while operating, you can check the error from the Smart
Panel. You can also launch Smart Panel manually.
Macintosh
Click this icon the Smart Panel icon on the
menu bar.
Linux
Double-click the Smart Panel icon in the
Notification Area.
Driver > Unified Driver Configurator.
2. Click each button on the left to switch to the corresponding configuration
window.
2
3
4
1
Toner Level
1
2
You can view the level of toner remaining in each
toner cartridge. The machine and the number of
toner cartridge(s) shown in the above window
may differ depending on the machine in use.
Some machines do not have this feature.
Buy Now
You can order replacement toner cartridge(s)
from online.
User’s Guide
You can view the online User’s Guide.
To use the on screen help, click Help.
3. After changing the configurations, click Exit to close the Unified Driver
Configurator.
Printers configuration
Printers configuration has the two tabs: Printers and Classes.
Printers Tab
This button opens the Troubleshooting
Guide when an error occurs. You can
directly open the troubleshooting section in
the user’s guide.
3
Printer Setting
4
1 Printers
configuration
2 Ports
configuration
View the current system’s printer configuration by clicking on the
machine icon button on the left side of the Unified Driver Configurator
window.
You can configure various machine settings in
the Printer Settings Utility window. Some
machines do not have this feature.
If you connect your machine to a network,
the SyncThru™ Web Service window
appears instead of the Printer Settings
Utility.
Changing Smart Panel ‘s settings
Right-click in Linux or in Mac OS X click on the Smart Panel icon and select
Options. Select the settings you want from the Options window.
Using the Unified Linux Driver Configurator
Unified Driver Configurator is a tool primarily intended for configuring
machine devices. You need to install Unified Linux Driver to use Unified
Driver Configurator (See "Linux" on page 23).
After the driver is installed on your Linux system, the Unified Driver
Configurator icon will automatically be created on your desktop.
Opening the Unified Driver Configurator
1
Switches to Printers configuration.
1. Double-click the Unified Driver Configurator on the desktop.
You can also click the startup menu icon and select Samsung Unified
2
Shows all of the installed machine.
Management tools_ 63
Ports configuration
Shows the status, model name and URI of your machine.
3
The printer control buttons are, as follows:
• Refresh: Renews the available machines list.
• Add Printer: Allows you to add a new machines.
• Remove Printer: Removes the selected machine.
• Set as Default: Sets the current selected machine as a default
machine.
• Stop/Start: Stops/starts the machine.
• Test: Allows you to print a test page to ensure the machine is
working properly.
• Properties: Allows you to view and change the printer properties.
In this window, you can view the list of available ports, check the status of
each port and release a port that is stalled in a busy state when its owner
has terminated the job for any reason.
Classes Tab
The Classes tab shows a list of available machine classes.
•
•
1
Shows all of the machine classes.
2
Shows the status of the class and the number of machines in the
class.
•
•
•
1
Switches to Ports configuration.
2
Shows all of the available ports.
3
Shows the port type, device connected to the port, and status
Refresh: Renews the available ports list.
Release port: Releases the selected port.
Refresh: Renews the classes list.
Add Class: Allows you to add a new machine class.
Remove Class: Removes the selected machine class.
Management tools_ 64
maintenance
9.
This chapter provides information for maintaining your machine and the toner cartridge.
This chapter includes:
•
•
•
•
•
•
•
Printing a machine report
Monitoring the supplies life
Cleaning a fuser belt
Using Toner Low Alert
Cleaning a machine
Storing the Toner cartridge
Tips for Moving & storing your machine
Printing a machine report
Cleaning a machine
You can print the machine's information.
If printing quality problems occur or if you use your machine in a dusty
environment, you need to clean your machine regularly to keep the best
printing condition and use your machine longer.
1. Press
on the control panel.
2. Press up/down arrow to highlight Information and press OK.
3. Press up/down arrow to highlight Configuration and press OK.
4. The display shows Print?, then press OK to print the configuration
report.
•
•
Monitoring the supplies life
To view the supply life indicators, follow the steps below:
1. Press
2.
3.
4.
5.
Cleaning the outside
on the control panel.
Clean the machine cabinet with a soft, lint-free cloth. Dampen the cloth
slightly with water, but be careful not to let any water drip onto or into the
machine.
Press up/down arrow to highlight System Setup and press OK.
Press up/down arrow to highlight Maintenance and press OK.
Press up/down arrow to highlight Supplies Info. and press OK.
The display shows options as you press up/down arrow.
Cleaning the inside
Cleaning a fuser belt
If you are experiencing blurred, faded, or smeared printouts, you can clear
the problem by printing a cleaning sheet, provided by your printer.
You can Print:
1. Press
Cleaning the cabinet of the machine with cleaning materials
containing large amounts of alcohol, solvent, or other strong
substances can discolor or distort the cabinet.
If your machine or the surrounding area is contaminated with
toner, we recommend you use cloth or tissue dampened with
water to clean it. If you use a vacuum cleaner, toner blows in the
air and might be harmful to you.
During the printing process, paper, toner, and dust particles can accumulate
inside the machine. This buildup can cause print quality problems, such as
toner specks or smearing. Cleaning the inside of the machine clears and
reduces these problems.
1. Turn the machine off and unplug the power cord. Wait for the machine to
cool down.
2. Using the handle, completely open the front cover.
on the control panel.
2. Press up/down arrow to highlight System Setup and press OK.
3. Press up/down arrow to highlight Maintenance and press OK.
4. Press up/down arrow to highlight Clean Fuser and press OK.
Your machine automatically picks up a sheet of paper from the tray and
prints out a cleaning sheet with dust or toner particles on it.
Using Toner Low Alert
If toner in the cartridge has run out, a message informing user to change the
toner cartridge appears. You can set the option for this message to appear
or not.
1. Press
on the control panel.
2. Press up/down arrow to highlight System Setup and press OK.
3. Press up/down arrow to highlight Maintenance and press OK.
4. Press up/down arrow to highlight Toner Low Alert and press OK.
•
•
•
Maintenance_ 65
Do not touch the green surface, the OPC drum or the front of
the print cartridge, with your hands or any other material. Use
the handle on each cartridge in order to avoid touching this
area.
Be careful not to scratch the surface of the paper transfer belt.
If you leave the front cover open for more than a few minutes,
the OPC drum can be exposed to light. This will cause damage
to the OPC drum. Cover the OPC drum of the print cartridge
with the clean paper to avoid damaging it from the light while
you clean the inside.
3. Press the green release handle to release the paper transfer belt.
Holding the handle on the paper transfer belt, lift it out of the machine.
belt.
5. With a dry, lint-free cloth, wipe away any dust and spilled toner from the
toner cartridge area.
If toner gets on your clothing, wipe it off with a dry cloth and wash it
in cold water. Hot water sets toner into fabric.
4. Grasp the handles on the print cartridge and pull to remove all the
cartridge from the machine.
6. Locate the long strip of glass (LSU) inside the top of the cartridge
compartment and gently swab the glass to see if dirt turns the white
cotton black.
If you open the front cover, be careful not to touch the underneath
the control panel (the lower part of the fuser unit). The temperature
of the fuser unit might be high and could damage your skin.
7. Slide the toner cartridge back into the machine.
8. Holding the handle on the paper transfer belt, align it with the slots on
the inside of the front cover.
When you open the front cover and work inside the machine, it is
highly recommend that you remove the paper transfer belt first.
Because the work you do could contaminate the paper transfer
Maintenance_ 66
9. Lower the paper transfer belt until it is parallel with the front cover and
firmly seated.
Use of non-Samsung and refilled toner cartridge
Samsung Electronics does not recommend or approve the use of
non-Samsung brand toner cartridges in your printer including generic, store
brand, refilled, or remanufactured toner cartridges.
Samsung’s printer warranty does not cover damage to the machine
caused by the use of a refilled, remanufactured, or non-Samsung
brand toner cartridge.
Estimated cartridge life
Estimated cartridge life (the life of the toner cartridge yield) depends on the
amount of toner that print jobs require. The actual print-out number may
vary depending on the print density of the pages you print on, operating
environment, printing interval, media type, and/or media size. For example,
if you print a lot of graphics, the consumption of the toner is high and you
may need to change the cartridge more often.
Tips for Moving & storing your machine
10. Close the front cover. Ensure that the cover is securely closed.
If the front cover is not completely closed, the machine will not
operate.
11. Plug in the power cord and turn the machine on.
•
•
When moving the machine, do not tilt or turn it upside down. Otherwise,
the inside of the machine may be contaminated by toner, which can
cause damage to the machine or bad print quality.
When moving the machine, make sure at least two people are holding
the machine securely.
Storing the Toner cartridge
Toner cartridges contain components that are sensitive to light,
temperature, and humidity. Samsung suggests users follow the
recommendations to ensure the optimum performance, highest quality, and
longest life from your new Samsung toner cartridge.
Store this cartridge in the same environment as the printer it will be used in;
this should be in controlled office temperature and humidity conditions. The
toner cartridge should remain in its original, unopened package until
installation – If original packaging is not available, cover the top opening of
the cartridge with paper and store in a dark cabinet.
Opening the cartridge package prior to use dramatically shortens its useful
shelf and operating life. Do not store on the floor. If the toner cartridge is
removed from the printer, always store the cartridge:
• Inside the protective bag from the original package.
• Store lying flat (not standing on end) with the same side facing up as if
they were installed in the machine.
• Do not store consumables in;
- Temperature greater than 40°C (104°F).
- Humidity range less than 20% or greater than 80%.
- An environment with extreme changes in humidity or temperature.
- Direct sunlight or room light.
- Dusty places.
- A car for a long period of time.
- An environment where corrosive gases are present.
- An environment with salty air.
Handling instructions
•
•
•
Do not touch the surface of the photosensitive drum in the cartridge.
Do not expose the cartridge to unnecessary vibrations or shock.
Never manually rotate the drum, especially in the reverse direction; this
can cause internal damage and toner spillage.
Maintenance_ 67
troubleshooting
10.
This chapter gives helpful information for what to do if you encounter an error. If your machine has a display screen, check
the message on the display screen first to solve the error. If you cannot find a solution in this User's Guide or the problem
consists, call for service.
This chapter includes:
•
•
•
•
•
Redistributing toner
Tips for avoiding paper jams
Clearing paper jams
Redistributing toner
Understanding display messages
Solving other problems
2. Press the green release handle to release the paper transfer belt.
Holding the handle on the paper transfer belt, lift it out of the machine.
When a toner is low, faded or light areas may appear. It is possible that
colored images may be printed with incorrect colors due to flawed mixing of
toner colors when the toner level of the colored toner cartridge is low. You
can temporarily improve print quality by redistributing the toner.
• The toner-related message saying that the toner is low may appear on
the display.
1. Using the handle, completely open the front cover.
3. Grasp the handles on the toner cartridge and pull the cartridge out.
•
•
•
Do not touch the green surface, the OPC drum or the front of
the toner cartridge, with your hands or any other material. Use
the handle on each cartridge in order to avoid touching this
area.
Be careful not to scratch the surface of the paper transfer belt.
If you leave the front cover open for more than a few minutes,
the OPC drum can be exposed to light. This will cause damage
to the OPC drum. Close the front cover when the installation
need to be halted for any reason.
If you open the front cover, be careful not to touch the underneath
the control panel (the lower part of the fuser unit). The temperature
Troubleshooting_ 68
of the fuser unit might be high and could damage your skin.
7. Lower the paper transfer belt until it is parallel with the front cover and
firmly seated.
When you open the front cover and work inside the machine, it is
highly recommend that you remove the paper transfer belt first.
Because the work you do could contaminate the paper transfer
belt.
4. Holding both handles on the toner cartridge, thoroughly rock it from side
to side to redistribute the toner.
If toner gets on your clothing, wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets toner into fabric.
5. Slide the toner cartridge back into the machine.
6. Holding the handle on the paper transfer belt, align it with the slots on
the inside of the front cover.
8. Close the front cover. Ensure that the cover is securely closed.
If the front cover is not completely closed, the machine will not
operate.
Tips for avoiding paper jams
By selecting the correct media types, most paper jams can be avoided.
When a paper jam occurs, refer to the next guidelines.
• Ensure that the adjustable guides are positioned correctly. (See
"Loading paper in the tray" on page 43.)
Do not overload the tray. Ensure that the paper level is below the paper
capacity mark on the inside of the tray.
• Do not remove paper from the tray while your machine is printing.
• Flex, fan, and straighten paper before loading.
• Do not use creased, damp, or highly curled paper.
• Do not mix paper types in a tray.
• Use only recommended print media. (See "Setting the paper size and
type" on page 47.)
• Ensure that the recommended side of the print media is facing up in the
tray, or facing down in the multi-purpose tray.
• If paper jams occur frequently when you print on A5/B5-sized paper:
Load the paper into the tray with the long edge facing the front of the
tray.
If load the paper this way, printing both sides of the paper (duplex) is not
supported.
In the Printing Preferences window, set the page orientation to be
rotated 180 degrees. (See "Opening printing preferences" on page 48.)
Clearing paper jams
When a paper jam occurs, a warning message appears on the display.
Troubleshooting_ 69
To avoid tearing the paper, pull the jammed paper out slowly and
gently. Follow the instructions in the following sections to clear the
jam.
5. Remove the jammed paper by gently pulling it straight out as shown
below.
In tray 1
Click this link to open an animation about clearing a jam.
If paper is jammed in the paper feed area, follow the next steps to release
the jammed paper.
1. Using the handle, completely open the front cover.
6. Insert tray 1 back into the machine until it snaps into place. Printing
automatically resumes.
In optional trays
Click this link to open an animation about clearing a jam.
2. Carefully remove the paper by pulling in the direction as shown below.
This part explains the method of removing the jammed paper in the
optional tray 2. Please refer to the next method for other optional
trays, since the method is same as the optional tray 3.
1. Pull out optional tray 2 open.
2. Remove the jammed paper from the machine.
3. Close the front cover.
If the front cover is not completely closed, the machine will not
operate.
4. Pull out tray 1.
If the paper does not move when you pull or if you do not see the paper
in this area, stop and go to the next step.
3. Open the front cover.
Troubleshooting_ 70
4. Pull the jammed paper out in the direction shown. To avoid tearing the
paper, pull it out gently and slowly.
5. Close the front cover and insert the trays back into the machine. Printing
automatically resumes.
If the front cover is not completely closed, the machine will not
operate.
In the multi-purpose tray
Click this link to open an animation about clearing a jam.
When you print using the multi-purpose tray and the machine detects
that there is either no paper or that the paper has been improperly
loaded, follow the next steps to release the jammed paper.
4. Remove the jammed paper by pulling in the direction shown. To avoid
tearing the paper, pull it out gently and slowly.
•
Do not touch the green surface, the OPC drum or the front of
the toner cartridge, with your hands or any other material. Use
the handle on each cartridge in order to avoid touching this
area.
• Be careful not to scratch the surface of the paper transfer belt.
• If you leave the front cover open for more than a few minutes,
the OPC drum can be exposed to light. This will cause damage
to the OPC drum. Close the front cover when the installation
need to be halted for any reason.
5. Close the front cover to resume printing.
If the front cover is not completely closed, the machine will not
operate.
1. If the paper is not feeding properly, pull the paper out of the machine.
In the fuser unit area
Click this link to open an animation about clearing a jam.
The fuser area is hot. Take care when removing paper from the
machine.
1. Open the top cover.
If you do not see the jammed paper or if there is any resistance when
you pull, stop and go to step 3.
2. Open and close the front cover to resume printing.
If the front cover is not completely closed, the machine will not
operate.
3. Using the handle, completely open the front cover.
Troubleshooting_ 71
2. Open the inner cover using the handle on it.
1. Open and close the front cover. The jammed paper is automatically
ejected from the machine.
2. Gently pull the paper out of the output tray.
Do not touch the fuser inside the inner cover. It is hot and could
cause burns! The fuser's operating temperature is 180°C (356°F).
Take care when removing paper from the machine.
If you do not see the jammed paper or if there is any resistance when
you pull, stop and see "In the fuser unit area" on page 71.
3. Open and close the front cover to resume printing.
If the front cover is not completely closed, the machine will not
operate.
3. Pull up the paper jam lever to loose the fusing part of the fuser unit and
carefully take the jammed paper out of the machine.
In the duplex unit area
Click this link to open an animation about clearing a jam.
1. Using the handle, completely open the front cover.
4. Press down the paper jam lever to fasten the fusing part.
5. Close the inner cover.
6. After removing the jammed paper, check for paper which may be
jammed in other parts of the machine.
7. Close the top cover. Ensure that the cover is securely closed.
Be careful not to scratch the surface of the paper transfer belt.
2. Press the green release handle to release the paper transfer belt.
Holding the handle on the paper transfer belt, lift it out of the machine.
If the top cover is not completely closed, the machine will not
operate.
In exit area
Click this link to open an animation about clearing a jam.
Troubleshooting_ 72
3. Remove the jammed paper by pulling in the direction shown. To avoid
tearing the paper, pull it out gently and slowly.
Understanding display messages
Messages appear on the control panel display to indicate the machine’s
status or errors. Some error messages are shown with graphics to help you
troubleshoot problem.
Checking display messages
1. When errors occur, Check Status appears on the display and press
OK.
2. Check the display message to see what kind of error has occured.
If several messages appear, press the up/down arrow to highlight the
message you want solve.
3. Press OK on the control panel.
Refer to the tables below to understand the messages’ and their
meaning, and solve the problem, if necessary.
4. Holding the handle on the paper transfer belt, align it with the slots on
the inside of the front cover.
•
•
•
•
•
•
•
•
•
5. Lower the paper transfer belt until it is parallel with the front cover and
firmly seated.
6. Close the front cover to resume printing.
If the front cover is not completely closed, the machine will not
operate.
Troubleshooting_ 73
If Check Status still appears, repeat above steps.
If a message is not in the table, reboot the power and try the
printing job again. If the problem persists, call for service.
When you call for service, provide the service representative with
the contents of display message.
Some messages may not appear in the display depending on
options or models.
[aaa] indicates the error code. When you contact the service
center, this error code help to handle the problem.
[ccc] indicates the part of the each toner cartridge.
[xxx] indicates the media type.
[yyy] indicates the tray.
[zzz] indicates the paper size.
Message
Meaning
Suggested solutions
[ccc] toner cart.
error
Error: [aaa]
Open/close door
The toner cartridge is
wrong installed.
Open and close the front
cover. If the problem
persists, call for service.
Prepare new [ccc]
toner
Prepare new [ccc]
toner cartridge
Small amount of toner
is left in the cartridge.
The estimated
cartridge life of toner
is close.
Prepare a new cartridge
for replacement. You
may temporarily increase
the printing quality by
redistributing the toner.
(See "Redistributing
toner" on page 68.)
Replace new [ccc]
toner
Replace with new
[ccc] toner
cartridge
A toner cartridge has
almost reached its
estimated cartridge
life.
You can choose Stop or
Continue as shown on
the control panel. If you
select Stop, the printer
stops printing and you
cannot print any more
without changing the
cartridge. If you select
Continue, the printer
keeps printing but the
printing quality cannot be
guaranteed.
Replace the toner
cartridge for the best print
quality when this
message appears. Using
a cartridge beyond this
stage can result in
printing quality issues.
(See "Replacing the toner
cartridge" on page 84.)
Samsung does not
recommend using
non-genuine
Samsung toner
cartridge such as
refilled or
remanufactured.
Samsung cannot
guarantee
non-genuine
Samsung toner
cartridge's quality.
Service or repair
required as a result
of using
non-genuine
Samsung toner
cartridges will not
be covered under
the machine
warranty.
Message
Meaning
Replace new [ccc]
toner
End of life. Replace
with new [ccc]
toner cartridge
A toner cartridge has
reached its estimated
cartridge life. The
printer stops printing.
[ccc] toner Not
Compatible
[ccc] toner
cartridge is not
compatible.
Check guide
The toner cartridge
you have installed is
not for your machine.
Install a
Samsung-genuine toner
cartridge, designed for
your machine.
[ccc] toner not
Installed
[ccc] toner
cartridge is not
installed.
Install toner
The toner cartridge is
not installed or the
CRUM (Consumer
Replaceable Unit
Monitor) in the
cartridge is not
properly connected.
Reinstall the toner
cartridge two or three
times. If the problem
persists, the toner
cartridge is not being
detected. Call for service.
Door is open or
Check Transfer
belt
The front cover or the
top cover is not
securely latched.
Close the cover until it
locks into place.
Fan error
Error: [aaa]
Turn off then on
There is a problem in
the machine.
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
Fuser error
Error: [aaa]
Turn off then on
There is a problem in
the machine.
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
Troubleshooting_ 74
Suggested solutions
Replace the toner
cartridge. (See
"Replacing the toner
cartridge" on page 84.)
Estimated
cartridge life
means the
expected or
estimated toner
cartridge life,
which indicates
the average
capacity of
print-outs and is
designed
pursuant to
ISO/IEC 19798.
The number of
pages may be
affected by
operating
environment,
printing interval,
media type, and
media size.
Some amount of
toner may
remain in the
cartridge even
when Replace
new [ccc] toner
appears and the
printer stops
printing.
Message
Meaning
Prepare Fuser unit
Prepare new fuser
unit
The life of the fuser
unit will expired soon.
Replace Fuser unit
Replace with new
fuser unit
Message
Meaning
Call for service.
Paper Jam in tray 2
Paper has jammed in
the tray2 area.
Clear the jam. (See "In
optional trays" on
page 70.)
The life of the fuser
unit has expired.
Call for service.
Paper Jam in tray 3
Paper has jammed in
the tray3 area.
Clear the jam. (See "In
optional trays" on
page 70.)
Fuser unit Not
Installed
Fuser unit is not
installed.
Install it
The fuser unit is not
installed.
Call for service.
Paper mismatch
MPT
Load [zzz] [xxx]
Continue Cancel
There is no
corresponding paper
in the corresponding
multi-purpose tray.
Jam bottom of
duplex
Paper has jammed
during duplex printing.
Clear the jam. (See "In
the duplex unit area" on
page 72.)
Load corresponding
paper in the
corresponding
multi-purpose tray. (See
"Multi-purpose tray" on
page 44.)
Jam inside
machine
Paper has jammed in
cartridge area.
Clear the jam. (See "In
the fuser unit area" on
page 71.)
Paper mismatch
tray[yyy]
Load [zzz] [xxx]
Continue Cancel
There is no
corresponding paper
in the corresponding
tray.
Load corresponding
paper in the
corresponding tray. (See
"Tray 1 / optional trays"
on page 43.)
Paper has jammed in
exit area.
Clear the jam. (See "In
exit area" on page 72.)
The life of the tray
Retard roller has
expired.
Error: [aaa]
LSU Unit Failure:
[aaa]
Turn off then on
There is a problem in
the machine.
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
Replace retard
roller
Replace with new
Tray[yyy] retard
roller
Call for service.
Jam in exit area
The machine is in a
room with improper
room temperature.
Move the machine to a
room with proper room
temperature. (See
"General specifications"
on page 91.)
The life of the Dust
Cleaning Kit has
expired.
Call for service.
Not proper room
temp
Not proper room
temperature.
Change room
temperature
Replace dust
cleaning
Replace with new
dust cleaning kit
Replace [ccc] toner
Replace with New
[ccc] Toner
The toner cartridge
has reached the end
of its lifespan.
Error: [aaa]
Actuator Motor
Failure: [aaa]
Call for service
There is a problem in
the machine.
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
Replace the toner
cartridge with a
Samsung-genuine toner
cartridge. (See
"Replacing the toner
cartridge" on page 84.)
Self Diagnostics
mode...
Please wait a few
minutes.
Output bin Full
Output bin Full.
Remove printed
paper
The document output
tray is full.
Once the paper is
removed from the
document output tray, the
printer resumes printing.
The engine in your
printer is checking
some problems
detected.
Sensor Failure
[aaa]
Turn off then on
There is a problem in
the sensor signal.
Paper Empty in MP
Paper is empty in
MP tray.
Load paper
There is no paper in
the multi-purpose tray.
Load paper in the
multi-purpose tray. (See
"Multi-purpose tray" on
page 44.)
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
System error
Error: [aaa]
Turn off then on
There is a problem in
the machine.
Paper Empty in
tray[yyy]
Paper is empty in
tray[yyy].
Load paper
There is no paper in
the tray.
Load paper in the tray.
(See "Tray 1 / optional
trays" on page 43.)
Turn the machine off and
turn it on again. If the
problem persists, call for
service.
Prepare TR. belt
Prepare new Paper
transfer belt unit
The life of the transfer
belt will expired soon.
Order the transfer belt
with a new one.
Paper Jam in MPT
Paper has jammed in
the multi-purpose tray
area.
Clear the jam. (See "In
the multi-purpose tray" on
page 71.)
Paper Jam in tray 1
Paper has jammed in
the tray1 area.
Clear the jam. (See "In
tray 1" on page 70.)
Jam top of duplex
Suggested solutions
Troubleshooting_ 75
Suggested solutions
Message
Meaning
Replace TR. belt
End of life, Replace
with new Paper
transfer belt unit
The life of the transfer
belt has expired.
Tray[yyy] cassette
Out
Tray[yyy] cassette
is pulled out.
Insert it properly
The tray is not
properly closed.
Tray[yyy] has a
problem
Communication
problem occurred
with tray[yyy]
The machine cannot
communicate the
optional trays.
Tray[yyy] Not
Installed
Tray[yyy] is not
installed
The optional trays is
not installed.
TR. belt Not
compatible
Paper transfer belt
unit is not
compatible.
Check guide
The transfer belt of
the machine is not for
your machine.
Error: [aaa]
PTB Unit Failure:
[aaa]
Install paper
transfer belt unit.
The transfer belt is not
installed.
Suggested solutions
Replace the paper
transfer belt with a new
one.
Install a
Samsung-genuine
transfer belt. (See
"Replacing the paper
transfer belt" on
page 85.)
Paper feeding problems
Condition
Paper jams during
printing.
Clear the paper jam. (See "Clearing paper jams"
on page 69.)
Paper sticks
together.
•
•
To close the tray, lower
the rear edge, align it with
the slot, and slide it into
the printer.
Reinstall the optional
trays. If the problem
persists, call for service.
Suggested solutions
•
•
Multiple sheets of
paper do not feed.
Different types of paper may be stacked in the
tray. Load paper of only one type, size, and
weight.
Paper does not feed
into the machine.
•
Reinstall the optional
trays. If the problem
persists, call for service.
•
Install the a
Samsung-genuine part
designed for your
machine. (See
"Replacing the paper
transfer belt" on
page 85.)
•
•
The paper keeps
jamming.
Install a
Samsung-genuine
transfer belt. (See
"Replacing the paper
transfer belt" on
page 85.)
Solving other problems
The following chart lists some conditions that may occur and the
recommended solutions. Follow the suggested solutions until the problem is
corrected. If the problem persists, call for service.
Check the maximum paper capacity of the
tray. (See "Print media specifications" on
page 92.)
Make sure that you are using the correct type
of paper. (See "Print media specifications" on
page 92.)
Remove paper from the tray and flex or fan
the paper.
Humid conditions may cause some paper to
stick together.
•
•
•
Remove any obstructions from inside the
machine.
Paper has not been loaded correctly. Remove
paper from the tray and reload it correctly.
There is too much paper in the tray. Remove
excess paper from the tray.
The paper is too thick. Use only paper that
meets the specifications required by the
machine. (See "Print media specifications" on
page 92.)
There is too much paper in the tray. Remove
excess paper from the tray. If you are printing
on special materials, use the multi-purpose
tray.
An incorrect type of paper is being used. Use
only paper that meets the specifications
required by the machine. (See "Print media
specifications" on page 92.)
There may be debris inside the machine.
Open the front cover and remove any debris.
Transparencies stick
together in the paper
exit.
Use only transparencies specifically designed
for laser printers. Remove each transparency as
it exits from the machine.
Envelopes skew or
fail to feed correctly.
Ensure that the paper guides are against both
sides of the envelopes.
Troubleshooting_ 76
Printing problems
Condition
The machine
does not print.
Possible cause
Suggested solutions
The machine is not
receiving power.
Check the power cord
connections. Check the
power switch and the power
source.
The machine is not
selected as the
default machine.
Select your machine as your
default machine in your
Windows.
Check the machine for the following:
• The front cover is not closed. Close the front
cover.
• Paper is jammed. Clear the paper jam. (See
"Clearing paper jams" on page 69.)
• No paper is loaded. Load paper. (See "Loading
paper in the tray" on page 43.)
• The toner cartridge is not installed. Install the
toner cartridge.
• Remove the protection sheet on the paper
transfer belt. Refer to Quick Install Guide.
• Remove the sealing tape from the toner
cartridge. Refer to Quick Install Guide.
If a system error occurs, contact your service
representative.
The connection
cable between the
computer and the
machine is not
connected properly.
Disconnect the machine
cable and reconnect it.
The connection
cable between the
computer and the
machine is
defective.
If possible, attach the cable
to another computer that is
working properly and print a
job. You can also try using a
different machine cable.
The port setting is
incorrect.
Check the Windows printer
setting to make sure that the
print job is sent to the correct
port. If the computer has
more than one port, make
sure that the machine is
attached to the correct one.
The machine may
be configured
incorrectly.
Check the Printing
Preferences to ensure that
all of the print settings are
correct. (See "Opening
printing preferences" on
page 48.)
The printer driver
may be incorrectly
installed.
Repair the machine
software. (See "Installing the
driver locally" on page 23.)
The machine is
malfunctioning.
Check the display message
on the control panel to see if
the machine is indicating a
system error. Contact a
service representative.
Condition
Possible cause
(Continued) The
machine does not
print.
The document size
is so big that the
hard disk space of
the computer is
insufficient to
access the print job.
Get more hard disk space
and print the document
again.
The machine
selects print
materials from
the wrong paper
source.
The paper option
that was selected in
the Printing
Preferences may
be incorrect.
For many software
applications, the paper
source selection is found
under the Paper tab within
the Printing Preferences.
Select the correct paper
source. See the printer
driver help screen. (See
"Opening printing
preferences" on page 48.)
A print job is
extremely slow.
The job may be
very complex.
Reduce the complexity of
the page or try adjusting the
print quality settings.
Half the page is
blank.
The page
orientation setting
may be incorrect.
Change the page orientation
in your application. See the
printer driver help screen.
The paper size and
the paper size
settings do not
match.
Ensure that the paper size in
the printer driver settings
matches the paper in the
tray.
Or, ensure that the paper
size in the printer driver
settings matches the paper
selection in the software
application settings you use.
The machine cable
is loose or
defective.
Disconnect the machine
cable and reconnect. Try a
print job that you have
already printed successfully.
If possible, attach the cable
and the machine to another
computer that you know
works and try a print job.
Finally, try a new machine
cable.
The wrong printer
driver was selected.
Check the application’s
printer selection menu to
ensure that your machine is
selected.
The software
application is
malfunctioning.
Try printing a job from
another application.
The operating
system is
malfunctioning.
Exit Windows and reboot the
computer. Turn the machine
off and back on again.
If you are in a DOS
environment, the
font setting for your
machine may be
set incorrectly.
Change the language
setting. (See "Changing font
setting" on page 41.)
The machine
prints, but the
text is wrong,
garbled, or
incomplete.
Troubleshooting_ 77
Suggested solutions
Condition
Pages print, but
they are blank.
Possible cause
Suggested solutions
The toner cartridge
is defective or out of
toner.
Redistribute the toner, if
necessary.
If necessary, replace the
toner cartridge.
The file may have
blank pages.
Check the file to ensure that
it does not contain blank
pages.
Some parts, such
as the controller or
the board, may be
defective.
Contact a service
representative.
The machine
does not print
PDF file correctly.
Some parts of
graphics, text, or
illustrations are
missing.
Incompatibility
between the PDF
file and the Acrobat
products.
Printing the PDF file as an
image may enable the file to
print. Turn on Print As
Image from the Acrobat
printing options.
The print quality
of photos is not
good. Images are
not clear.
The resolution of
the photo is very
low.
Reduce the photo size. If
you increase the photo size
in the software application,
the resolution will be
reduced.
Before printing,
the machine
emits vapor near
the output tray.
Using damp paper
can cause vapor
during printing.
This is not a problem. Just
keep printing.
The machine
does not print
special- sized
paper, such as
billing paper.
Paper size and
paper size setting
do not match.
Go to the printer properties
and click the paper tab.
Correct the paper size in the
custom option. (See
"Opening printing
preferences" on page 48.)
Condition
Suggested Solutions
Light or faded print •
•
•
•
It will take longer to
print when you print a
PDF file as an image.
Printing quality problems
If the inside of the machine is dirty or paper has been loaded improperly,
there might be a reduction in print quality. See the table below to clear the
problem.
•
If a vertical white streak or faded area appears
on the page, the toner supply is low. You may
be able to temporarily extend the toner
cartridge life. (See "Redistributing toner" on
page 68.) If this does not improve the print
quality, install a new toner cartridge.
The paper may not meet paper specifications;
for example, the paper may be too moist or
rough. (See "Print media specifications" on
page 92.)
If the entire page is light, the print resolution
setting is too low or the toner save mode is on.
Adjust the print resolution and turn the toner
save mode off. See the help screen of the
printer driver.
A combination of faded or smeared defects
may indicate that the toner cartridge needs
cleaning. (See "Cleaning the inside" on
page 65.)
The surface of the LSU part inside the machine
may be dirty. (See "Cleaning the inside" on
page 65.)
The top half of the
paper is printed
lighter than the
rest of the paper
The toner might not adhere properly to this type of
paper.
• Change the printer option and try again.
Go to the Printing Preferences, click the
Paper tab, and set the paper type to
Recycled.
Toner specks
•
A aB bC c
A aB bC c
A aB bC c
A aB bC c
A aB bC c
Troubleshooting_ 78
•
•
The paper may not meet specifications; for
example, the paper may be too moist or rough.
(See "Print media specifications" on page 92.)
The transfer roller may be dirty. Clean the
inside of your machine. Contact a service
representative.
The paper path may need cleaning. Contact a
service representative.
Condition
Dropouts
A aBb C
A aBb C
A aBb C
A aBb C
A aBb C
White Spots
Suggested Solutions
Condition
If faded areas, generally rounded, occur randomly
on the page:
• A single sheet of paper may be defective. Try
reprinting the job.
• The moisture content of the paper is uneven or
the paper has moist spots on its surface. Try a
different brand of paper. (See "Print media
specifications" on page 92.)
• The paper lot is bad. The manufacturing
processes can cause some areas to reject
toner. Try a different kind or brand of paper.
• Change the printer option and try again. Go to
Printing Preferences, click Paper tab, and
set type to Thick. (See "Opening printing
preferences" on page 48.)
• If these steps do not correct the problem,
contact a service representative.
If white spots appear on the page:
• The paper is too rough and a lot of dirt from a
paper falls to the inner devices within the
machine, so the transfer roller may be dirty.
Clean the inside of your machine. (See
"Cleaning the inside" on page 65.).
• The paper path may need cleaning. (See
"Cleaning the inside" on page 65.)
Vertical lines
If black vertical streaks appear on the page:
• The surface (drum part) of the toner cartridge
inside the machine has probably been
scratched. Remove the toner cartridge and
install a new one. (See "Replacing the toner
cartridge" on page 84.)
If white vertical streaks appear on the page:
• The surface of the LSU part inside the
machine may be dirty. (See "Cleaning the
inside" on page 65.)
Color or Black
background
If the amount of background shading becomes
unacceptable:
• Change to a lighter weight paper. (See "Print
media specifications" on page 92.)
• Check the environmental conditions: very dry
conditions (low humidity) or a high level of
humidity (higher than 80% RH) can increase
the amount of background shading.
• Remove the old toner cartridge and, install a
new one. (See "Replacing the toner cartridge"
on page 84.)
Suggested Solutions
Toner smear
If toner smears on the page:
• Clean the inside of the machine. (See
"Cleaning the inside" on page 65.)
• Check the paper type and quality. (See "Print
media specifications" on page 92.)
• Remove the toner cartridge and then, install a
new one. (See "Replacing the toner cartridge"
on page 84.)
Vertical repetitive
defects
If marks repeatedly appear on the printed side of
the page at even intervals:
• The toner cartridge may be damaged. If you
still have the same problem, remove the toner
cartridge and, install a new one. (See
"Replacing the toner cartridge" on page 84.)
• Parts of the machine may have toner on them.
If the defects occur on the back of the page,
the problem will likely correct itself after a few
more pages.
• The fusing assembly may be damaged.
Contact a service representative.
Background
scatter
Background scatter results from bits of toner
randomly distributed on the printed page.
• The paper may be too damp. Try printing with
a different batch of paper. Do not open
packages of paper until necessary so that the
paper does not absorb too much moisture.
• If background scatter occurs on an envelope,
change the printing layout to avoid printing
over areas that have overlapping seams on
the reverse side. Printing on seams can cause
problems.
• If background scatter covers the entire surface
area of a printed page, adjust the print
resolution through your software application or
in Printing Preferences. (See "Opening
printing preferences" on page 48.)
A
Toner particles are
around bold
characters or
pictures
Troubleshooting_ 79
The toner might not adhere properly to this type of
paper.
• Change the printer option and try again.
Go to the Printing Preferences, click the
Paper tab, and set the paper type to
Recycled.
Condition
Misformed
characters
Suggested Solutions
•
•
Page skew
A aBb
A aBb C
A aBb C
A aBb C
A aBb C
Cc
Curl or wave
•
•
•
•
•
•
•
•
Back of printouts
are dirty
If characters are improperly formed and
producing hollow images, the paper stock may
be too slick. Try different paper. (See "Print
media specifications" on page 92.)
If characters are improperly formed and
producing a wavy effect, the scanner unit may
need service. Contact a service representative.
Solid Color or
Black pages
Ensure that the paper is loaded properly.
Check the paper type and quality. (See "Print
media specifications" on page 92.)
Ensure that the guides are not too tight or too
loose against the paper stack.
Loose toner
Suggested Solutions
•
•
A
•
•
•
•
•
•
Wrinkles or
creases
Condition
•
•
•
Ensure that the paper is loaded properly.
Check the paper type and quality. Both high
temperature and humidity can cause paper
curl. (See "Print media specifications" on
page 92.)
Turn the stack of paper over in the tray. Also try
rotating the paper 180° in the tray.
Ensure that the paper is loaded properly.
Check the paper type and quality. (See "Print
media specifications" on page 92.)
Turn the stack of paper over in the tray. Also try
rotating the paper 180° in the tray.
Check for leaking toner. Clean the inside of the
machine. (See "Cleaning the inside" on
page 65.)
Clean the fuser belt. (See "Cleaning a fuser
belt" on page 65.)
The toner cartridge is almost empty.
Character Voids
A
Horizontal stripes
A aBb C
A aBb C
A aBb C
A aBb C
A aBb C
Curl
Troubleshooting_ 80
The toner cartridge may not be installed
properly. Remove the cartridge and reinsert it.
The toner cartridge may be defective. Remove
the toner cartridge and install a new one. (See
"Replacing the toner cartridge" on page 84.)
The machine may require repair. Contact a
service representative.
Clean the inside of the machine. (See
"Cleaning the inside" on page 65.)
Check the paper type and quality. (See "Print
media specifications" on page 92.)
Remove the toner cartridge and then, install a
new one. (See "Replacing the toner cartridge"
on page 84.)
If the problem persists, the machine may
require repair. Contact a service representative.
Character voids are white areas within parts of
characters that should be solid black:
• If you are using transparencies, try another
type of transparency. Because of the
composition of transparencies, some
character voids are normal.
• You may be printing on the wrong surface of
the paper. Remove the paper and turn it
around.
• The paper may not meet paper specifications.
(See "Print media specifications" on page 92.)
If horizontally aligned black streaks or smears
appear:
• The toner cartridge may be installed
improperly. Remove the cartridge and reinsert
it.
• The toner cartridge may be defective. Remove
the toner cartridge and install a new one. (See
"Replacing the toner cartridge" on page 84.)
• If the problem persists, the machine may
require repair. Contact a service
representative.
If the printed paper is curled or paper does not
feed into the machine:
• Turn the stack of paper over in the tray. Also
try rotating the paper 180° in the tray.
• Change the printer option and try again. Go to
Printing Preferences, click Paper tab, and
set type to Thin. (See "Opening printing
preferences" on page 48.)
Common Windows problems
Condition
Suggested Solutions
An unknown image
repetitively
appears on a few
sheets or loose
toner, light print, or
contamination
occurs.
Your machine is probably being used at an
altitude of 1,000 m (3,281 ft) or above.
The high altitude may affect the print quality, such
as loose toner or light imaging. Change the
correct altitude setting to your machine. (See
"Altitude adjustment" on page 40.)
Common PostScript problems
The following situations are PS language specific and may occur when
several printer languages are used.
Problem
PostScript file
cannot be printed.
Possible cause
The PostScript
driver may not be
installed correctly.
Solution
•
•
•
Install the PostScript
driver. (See "Installing
the driver locally" on
page 23.)
Print a configuration
page and verify that
the PS version is
available for printing.
If the problem persists,
contact a service
representative.
“Limit Check Error”
report prints.
The print job was
too complex.
You might need to
reduce the complexity of
the page or install more
memory. (See "Installing
a memory module" on
page 87.)
A PostScript error
page prints.
The print job may
not be PostScript.
Make sure that the print
job is a PostScript job.
Check to see whether
the software application
expected a setup or
PostScript header file to
be sent to the machine.
The optional tray is
not selected in the
driver.
The printer driver
has not been
configured to
recognize the
optional tray.
Open the PostScript
driver properties, select
the Device Options tab,
and set the tray option.
When printing a
document in
Macintosh with
Acrobat Reader 6.0
or higher, colors
print incorrectly.
The resolution
setting in the printer
driver may not be
matched with the
one in Acrobat
Reader.
Make sure that the
resolution setting in your
printer driver matches
the one in Acrobat
Reader.
Condition
Suggested solutions
“File in Use”
message appears
during installation.
Exit all software applications. Remove all
software from the printer’s startup group, then
restart Windows. Reinstall the printer driver.
“General Protection
Fault”, “Exception
OE”, “Spool 32”, or
“Illegal Operation”
messages appear.
Close all other applications, reboot Windows
and try printing again.
“Fail To Print”, “A
printer timeout error
occurred” messages
appear.
These messages may appear during printing.
Just keep waiting until the machine finishes
printing. If the message appears in standby
mode or after printing has been completed,
check the connection and/or whether an error
has occurred.
Refer to Microsoft Windows User’s Guide that came with your
computer for further information on Windows error messages.
Common Linux problems
condition
The machine does
not print.
Suggested solutions
•
•
•
Some color images
come out all black.
Troubleshooting_ 81
Check if the printer driver is installed in your
system. Open Unified Driver Configurator and
switch to the Printers tab in Printers
configuration window to look at the list of
available machines. Make sure that your
machine is displayed on the list. If not, open
Add new printer wizard to set up your
device.
Check if the machine is started. Open
Printers configuration and select your
machine on the printers list. Look at the
description in the Selected printer pane. If its
status contains Stopped string, press the
Start button. After that normal operation of
the machine should be restored. The
“stopped” status might be activated when
some problems in printing occurred.
Check if your application has special print
option such as “-oraw”. If “-oraw” is specified
in the command line parameter, then remove
it to print properly. For Gimp front-end, select
“print” -> “Setup printer” and edit command
line parameter in the command item.
This is a known bug in Ghostscript (until GNU
Ghostscript version 7.05) when the base color
space of the document is indexed color space
and is converted through CIE color space.
Because Postscript uses CIE color space for
Color Matching System, you should upgrade
Ghostscript on your system to at least GNU
Ghostscript version 7.06 or later. You can find
recent Ghostscript versions at
www.ghostscript.com.
condition
Some color images
come out in
unexpected colors.
Common Macintosh problems
Suggested solutions
This is a known bug in Ghostscript (until GNU
Ghostscript version 7.xx) when the base color
space of the document is indexed RGB color
space and it is converted through CIE color
space. Because Postscript uses CIE color space
for Color Matching System, you should upgrade
Ghostscript on your system to at least GNU
Ghostscript version 8.xx or later. You can find
recent Ghostscript versions at
www.ghostscript.com.
The machine does
not print whole
pages, and output is
printed on half the
page.
It is a known problem that occurs when a color
machine is used on version 8.51 or earlier of
Ghostscript, 64-bit Linux OS, and has been
reported to bugs.ghostscript.com as Ghostscript
Bug 688252.The problem is solved in AFPL
Ghostscript v. 8.52 or above. Download the
latest version of AFPL Ghostscript from
http://sourceforge.net/projects/ghostscript/ and
install it to solve this problem.
I encounter error
“Cannot open port
device file” when
printing a document.
Avoid changing print job parameters (via LPR
GUI, for example) while a print job is in progress.
Known versions of CUPS (Common Unix
Printing System) server break the print job
whenever print options are changed and then try
to restart the job from the beginning. Since
Unified Linux Driver locks the port while printing,
the abrupt termination of the driver keeps the
port locked and unavailable for subsequent print
jobs. If this situation occurs, try to release the
port by selecting Release port in Port
configuration window.
When printing a
document over the
network in SuSE 9.2,
the printer does not
print.
condition
Suggested solutions
The machine does
not print PDF files
correctly. Some
parts of graphics,
text, or illustrations
are missing.
Printing the PDF file as an image may enable
the file to print. Turn on Print As Image from the
Acrobat printing options.
The document has
printed, but the print
job has not
disappeared from
the spooler in Mac
OS X10.3.2.
Update your MAC OS to MAC OS X 10.3.3. or
higher.
Some letters are not
displayed normally
during the cover
page printing.
Mac OS cannot create the font during the cover
page printing. The English alphabet and
numbers are displayed normally on the cover
page.
When printing a
document in
Macintosh with
Acrobat Reader 6.0
or higher, colors
print incorrectly.
Make sure that the resolution setting in your
machine driver matches the one in Acrobat
Reader.
It will take longer to print when you print a
PDF file as an image.
Refer to Macintosh User’s Guide that came with your computer for
further information on Macintosh error messages.
The CUPS (Common Unix Printing System)
version distributed with SuSE Linux 9.2
(cups-1.1.21) has a problem with ipp (Internet
Printing Protocol) printing. Use the socket
printing instead of ipp or install later version of
CUPS (Common Unix Printing System)
(cups-1.1.22 or higher).
Refer to Linux User’s Guide that came with your computer for further
information on Linux error messages.
Troubleshooting_ 82
supplies and accessories
11.
This chapter provides information on purchasing supplies, accessories and maintenance parts available for your machine.
This chapter includes:
•
•
•
•
•
•
•
•
•
•
•
How to purchase
Available supplies
Available accessories
Available maintenance parts
Replacing the toner cartridge
Replacing the paper transfer belt
Available accessories may differ from country to country. Contact your
sales representatives to obtain the list of available accessories.
How to purchase
Necessary Precautions to take when installing accessories
Activating the added accessories in printer properties
Upgrading a memory module
Installing a wireless network interface card
Installing a hard disk
country where you purchased your machine. Otherwise, supplies will
be incompatible with your machine since the system configuration of
these vary from country to country.
Available accessories
To order Samsung-authorized supplies, accessories and, maintenance
parts, contact your local Samsung dealer or the retailer where you
purchased your machine. You can also visit www.samsung.com/supplies,
select your country/region, and obtain information on calling for service.
You can purchase and install accessories to enhance your machine’s
performance and capacity.
Accessory
function
Part name
Available supplies
Memory module
When supplies reach their lifespan, you can order the following types of
supplies for your machine:
Extends your machine’s
memory capacity.
ML-MEM170:
512 MB
Optional tray 2/3
If you are experiencing
frequent paper supply
problems, you can attach up
to two additional 500 sheet
trays. You can print
documents in various sizes
and types of print materials in
each tray.
CLP-S775A
Hard Disk
Allows you to enhance the
printer’s capability and print in
various ways.
ML-HDK425
IEEE 802.11 b/g/n
Wireless LANa
Allows you to connect your
printer to a wireless network.
ML-NWA65L
Type
Standard yielda
toner cartridge
Average yield
Average continuous
cartridge yield: 7,000
standard pages.
Part name
CLT-C609S (Cyan)
CLT-M609S (Magenta)
CLT-Y609S (Yellow)
CLT-K609S (Black)
Region Ab:
CLT-C6092S (Cyan)
CLT-M6092S (Magenta)
CLT-Y6092S (Yellow)
CLT-K6092S (Black)
Paper transfer
belt
Approx. 50,000 pages
CLT-T508
a. Declared yield value in accordance with ISO/IEC 19798.
b. Region A: Albania, Austria, Belgium, Bosnia, Bulgaria, Croatia, Cyprus,
Czech Republic, Denmark, Finland, France, Germany, Greece,
Hungary, Italy, Macedonia, Netherlands, Norway, Poland, Portugal,
Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
UK.
To replace a toner cartridge. (See "Replacing the toner cartridge" on
page 84.)
Depending on the options and job mode used, the toner cartridge’s
lifespan may differ.
You must purchase supplies, including toner cartridges, in the same
Supplies and accessories_ 83
Accessory
IEEE1284 Parallel
Connector
function
Allows you to use various
interface.
•
•
•
Part name
ML-PAR100
When installing the
printer driver with an
IEEE1284 parallel
connector, the
machine might not
be found and after
installing the printer
driver, only basic
printing features are
available.
If you want to check
the machine's status
or set the settings,
connect the machine
to a computer with a
USB cable or a
network.
If you use the IEEE
1284 parallel
connector, you can
not use the USB
cable.
Replacing the toner cartridge
Click this link to open an animation about replacing a toner cartridge.
The machine uses four colors and has a different print cartridge for each
one: yellow (Y), magenta (M), cyan (C), and black (K).
• The status LED and the toner-related message on the display indicate
when each individual print cartridge should be replaced.
At this stage, the toner cartridge needs to be replaced. Check the type of the
toner cartridge for your machine. (See "Available supplies" on page 83.)
1. Using the handle, completely open the front cover.
a. Depending on your country, wireless LAN cards may not be available.
Contact your local Samsung dealer or the retailer where you bought
your printer.
Available maintenance parts
To avoid print quality and paper feed problems resulting from worn parts
and to maintain your machine in top working condition, the following parts
will need to be replaced after printing the specified number of pages or
when the life span of each item has expired.
Parts
Average yielda
Fuser unit
Approx. 100,000 pages
Pickup roller (FCF)
B4 Approx. 100,000 pages
Pickup roller (MP)
Approx. 100,000 pages
Pickup roller (SCF)
Approx. 200,000 pages
Forward (SCF)
Approx. 200,000 pages
Retard (FCF)
B4 Approx. 100,000 pages
Friction (MP)
Approx. 100,000 pages
Retard (SCF)
Approx. 100,000 pages
Dust cleaning kit
Approx. 100,000 pages
Replacing maintenance parts can be performed only by an authorized
service provider, dealer, or the retailer where you bought the machine. The
warranty does not cover the replacement of any maintenance parts after
their lifespan.
•
Do not touch the green surface, the OPC drum or the front of
the print cartridge, with your hands or any other material. Use
the handle on each cartridge in order to avoid touching this
area.
• Be careful not to scratch the surface of the paper transfer belt.
• If you leave the front cover open for more than a few minutes,
the OPC drum can be exposed to light. This will cause damage
to the OPC drum. Close the front cover when the installation
need to be halted for any reason.
2. Press the green release handle to release the paper transfer belt.
Holding the handle on the paper transfer belt, lift it out of the machine.
a. It will be affected by operating system used, computing performance,
application software, connecting method, media type, media size and
job complexity.
To purchase maintenance parts, contact the source where you bought the
machine.
Supplies and accessories_ 84
3. Grasp the handles on the empty print cartridge and pull to remove the
cartridge from the machine.
6. Place the print cartridge on a flat surface, as shown, and remove the
paper covering the print cartridge by removing the tape.
If toner gets on your clothing, wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets toner into fabric.
Do not touch the green surface, the OPC drum of the cartridge.
Use the handle on the cartridge to avoid touching this area.
If you open the front cover, be careful not to touch the underneath
the control panel (the lower part of the fuser unit). The temperature
of the fuser unit might be high and could damage your skin.
7. Make sure that the color of the print cartridge matches the color slot and
then grasp the handles on the print cartridge. Insert the cartridge until it
clicks into place.
8. Holding the handle on the paper transfer belt, align it with the slots on
the inside of the front cover.
9. Lower the paper transfer belt until it is parallel with the front cover and
firmly seated.
When you open the front cover and work inside the machine, it is
highly recommend that you remove the paper transfer belt first.
Because the work you do could contaminate the paper transfer
belt.
4. Remove the new toner cartridge from its bag.
•
Don't use sharp objects, such as a knife or scissors, to open
the print cartridge package. You could damage the surface of
the print cartridge.
• To prevent damage, do not expose the print cartridge to light
for more than a few minutes. Cover it with a piece of paper to
protect it if necessary.
5. Slowly shake the cartridge five or six times to distribute the toner evenly
inside the cartridge. It will assure maximum copies per cartridge.
10. Close the front cover. Make sure that the cover is securely closed.
If the front cover is not completely closed, the machine will not
operate.
Replacing the paper transfer belt
Click this link to open an animation about replacing a paper transfer
Supplies and accessories_ 85
belt.
After the life span of the paper transfer belt is complete, you have to replace
it.
• The transfer belt-related message appears on the display, telling it's
time for a replacement.
5. Holding the handle on the new paper transfer belt, align it with the slots
on the inside of the front cover.
The life span of the paper transfer belt may be affected by operating
environment, printing interval, media type, and media size.
1. Using the handle, completely open the front cover.
6. Lower the paper transfer belt until it is parallel with the front cover and
firmly seated.
•
Do not touch the green surface, the OPC drum or the front of
the print cartridge, with your hands or any other material. Use
the handle on each cartridge in order to avoid touching this
area.
• Be careful not to scratch the surface of the paper transfer belt.
• If you leave the front cover open for more than a few minutes,
the OPC drum can be exposed to light. This will cause damage
to the OPC drum. Close the front cover should the installation
need to be halted for any reason.
2. Press the green release handle to release the paper transfer belt.
Holding the handle on the paper transfer belt, lift it out of the machine.
7. Close the front cover to resume printing.
If the front cover is not completely closed, the machine will not
operate.
Necessary Precautions to take when installing
accessories
•
•
3. Remove a new paper transfer belt from its bag.
4. Remove the paper covering the paper transfer belt.
•
•
Do not use sharp objects, such as a knife or scissors, to open
the paper transfer belt package. You could damage the surface
of the paper transfer belt.
Be careful not to scratch the surface of the paper transfer belt.
•
Disconnect the power cord.
Never remove the control board cover while the power is turned on.
To avoid the possibility of an electrical shock, always disconnect the
power cord when installing or removing ANY internal or external
accessories.
Discharge static electricity.
The control board and internal accessories (network interface card or
memory module) are sensitive to static electricity. Before installing or
removing any internal accessories, discharge static electricity from your
body by touching something metal, such as the metal back plate on any
device plugged into a grounded power source. If you walk around before
finishing the installation, repeat this procedure to discharge any static
electricity again.
Activating the added accessories in the PS driver properties.
After installing an accessory such as an optional tray, PS driver users
must do the additional setting. Go to the PS printer properties and set
the added accessory activated.
Supplies and accessories_ 86
When installing accessories, the battery inside the machine is a
service component. Do not change it by yourself.
There is a risk of an explosion if battery is replaced by an incorrect
type. Dispose used batteries according to the instructions.
4. Holding the memory module by the edges, align the memory module on
the slot at about a 30-degree tilt. Make sure that the notches of the
module and the grooves on the slot fit each other.
Activating the added accessories in printer
properties
After installing added accessories, you need to select it in the printer
properties of the printer driver in order to use it.
1. Install the driver. (See "Installing the driver locally" on page 23 or
"Installing wired network connected machine’s driver" on page 28.)
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. For Windows 2000, XP, 2003, 2008 and Vista, double-click your
machine.
For Windows 7 and Windows Server 2008 R2, right click your printer
icon > context menus > See what’ s printing.
4. Select the your machine’s driver and right-click to open Properties.
5. In printer driver properties, select Device Options.
6. In printer driver properties, set the necessary options.
7. Click OK.
Upgrading a memory module
The notches and grooves illustrated above may not match those
on an actual memory module and its slot.
5. Press the memory module into the slot with care until you hear a 'click'.
Do not press the memory module strongly or the module may be
damaged. If the module does not seem to fit into the slot properly,
carefully try the previous procedure again.
6. Replace the control board cover and fasten the cover with the screw.
7. Reconnect the power cord and machine cable. Turn on the machine.
Your machine has a dual in-line memory module (DIMM). Use this memory
module slot to install additional memory. (See "Available accessories" on
page 83.)
Installing a memory module
1. Turn the machine off and unplug all cables from the machine.
2. Open the control board cover. Release the screw, then lift up the cover
slightly and pull the cover to the right.
Installing a wireless network interface card
The machine is equipped with a network interface which allows you to use
your printer on a network. You can also purchase a wireless network
interface card to enable the use of the printer in wireless network
environments.
The order information is provided for optional wireless network interface
card. (See "Available accessories" on page 83.)
Installing a wireless network interface card
1. Turn the machine off and unplug all cables from the machine.
2. Open the control board cover. Release the screw, then lift up the cover
slightly and pull the cover to the right.
3. Take out a new memory module from its plastic bag.
Supplies and accessories_ 87
3. Detach the dummy panel on your machine using a strong stick-like tool,
such as a screwdriver.
4. Take out a new wireless interface card from its plastic bag.
5. Align the wireless network interface card into the guide, and align the
connector on the card with the connector on the control board. Push the
card firmly into the connector until it is completely and securely in place.
Installing a hard disk
1. Turn the machine off and unplug all cables from the machine.
2. Open the control board cover. Release the screw, then lift up the cover
slightly and pull the cover to the right.
3. Take out a new hard disk from its plastic bag.
4. Align the connector on the hard disk with the connector on the control
board. Push the hard disk in until it is latched into place.
1 wireless network
interface card
connector
2 wireless network
interface card
3 wireless network
interface card guide
6. Replace the control board cover and fasten the cover with the screw.
5. Fasten the screws supplied with your new hard disk.
7. Reconnect the power cord and machine cable. Turn on the machine.
8. Set the wireless network environment. (See "Wireless network setup" on
page 32.)
6. Reconnect the power cord and machine cable. Turn on the machine.
7. You must activate the added hard disk in the driver properties.
(See "Activating the added accessories in printer properties" on
page 87.)
Installing a hard disk
Printing with the optional hard disk
Installing the hard disk allows the data from your computer to be sent to the
print queue of the printer hard disk. This decreases the workload of the
computer. You can also use various print features, such as storing a job in
the hard disk, proofing a job, and printing private documents.
The order information is provided for optional hard disk. (See "Available
accessories" on page 83.)
After installing the optional hard disk, you can use advanced printing
features, such as storing or spooling a print job to the hard disk,
proofing a job, and specifying of printing a private job in the printer
properties window.
Once you have stored files in the hard disk, you can easily print or
delete the stored files using the control panel of your printer.
Storing a job
You can store jobs in the installed hard disk.
1. Open the document you want to print.
2. Select Print from the file menu. The Print window appears.
Supplies and accessories_ 88
3.
4.
5.
6.
Select your machine from Select Printer.
Click Properties or Preferences.
Click the Advanced tab and click Job Setting.
Select the print mode you want from the drop-down list.
(See "Using help" on page 53.)
7. Enter the user’s name and file name.
8. Click OK until the Print window is displayed.
9. Click OK or Print to start printing.
Release option appears only when you select a Print
Schedule print job.
6. When Yes appears, press OK.
Form file
Form overlay is images stored in the printer hard disk drive (HDD) as a
special file format that can be printed in layers on any document.
Creating new form files
Printing or deleting a stored job
You can print or delete jobs currently stored in the hard disk.
1. Press
on the control panel.
2. Press the up/down arrow to highlight Job Management and press
OK.
3. Press the up/down arrow to highlight Stored Job and press OK.
4. Press the up/down arrow to highlight the user’s name and file name
you want use and press OK.
If the select file is a confidential print job, enter the specified
4-digit password.
Use the up/down arrow to enter digits and use the left/right
arrow to move between digits. When you finnish entering the
password, press OK.
If you enter the incorrect password, Invalid Password
appears. Reenter the correct password.
5. Press the up/down arrow to highlight the desired setting and press
OK.
• Print: You can print a stored job.
• Delete: You can delete a stored job.
6. When Yes appears, press OK.
Controlling the active job queue
All of the print jobs waiting to be printed are listed in the active job queue
in the order you sent them to the printer. You can delete a job from the
queue before printing, or promote a job to print sooner.
1. Press
on the control panel.
2. Press the up/down arrow to highlight Job Management and press
OK.
3. Press the up/down arrow to highlight Active Job and press OK.
4. Press the up/down arrow to highlight the user’s name and file name
you want use and press OK.
If the select file is a confidential print job, enter the specified
4-digit password.
Use the up/down arrow to enter digits and use the left/right
arrow to move between digits. When you finnish entering the
password, press OK.
If you enter the incorrect password, Invalid Password
appears. Reenter the correct password.
5. Press the up/down arrow to highlight the desired setting and press
OK.
• Cancel: You can delete a file from the queue.
• Promote: You can select a job waiting in the active job queue
and change its print order so that it can be printed sooner.
• Release: You can print a job scheduled to be printed at a
specified time immediately. In this case, the job currently printing
is stopped and the selected job will be printed. This function is
available when the job is scheduled for later printing.
1. Create or open a document containing text or an image for use in a
new form file.
2. To save the document as a form file, access Printing Preferences.
(See "Opening printing preferences" on page 48.)
3. Click the Advanced tab, and select Advanced.
4. In the Advanced Output Options window, check Save as Form for
Overlay.
5. Click Search.
6. Type a file name of up to eight characters in the File name box.
Select the destination path and click Save.
7. Click OK or Print until you exit the Print window.
8. A confirm message appears, click Yes to save.
The file is not printed. Instead, it is stored on your computer hard disk
drive.
If you click NO, the machine prints your form without saving.
9. A confirm message appears, click Yes to save.
The form file size must be the same as the document you print with
the form file.
File Policy
You can choose the file policy for generating file name before you
proceed with the job through HDD. If the HDD memory already has the
same name when you entered a new file name, you can rename or
overwrite it.
1. Press
on the control panel.
2. Press the up/down arrow to highlight Job Management and press
OK.
3. Press the up/down arrow to highlight File Policy and press OK.
4. Press the up/down arrow to highlight the desired setting and press
OK.
• Rename : If the HDD memory already has the same name when
you enter a new file name, the file will be saved as a different
name that is automatically programmed.
• Overwrite : You can set the machine to delete previous job
information on HDD as you store new job information.
5. Press OK.
Deleting residual image data
ImageOverwrite is a security measure for customers who are concerned
about unauthorized access and duplication of classified or private
document.
1. Press
on the control panel.
2. Press the up/down arrow to highlight Job Management and press
OK.
3. Press the up/down arrow to highlight ImageOverwrite and press
OK.
Supplies and accessories_ 89
4. Press the up/down arrow to highlight the desired setting and press
OK.
• Automatic : All residual image data from the machine will be
erased immediately after each job has been processed.
• Manual : This option provides an on-demand facility for a
system administrator to erase all the real image data remained in
HDD after this option enabled. All existing jobs will be deleted
regardless of their status and all job submissions will be
prohibited for the duration of the overwrite.
5. Press the up/down arrow to move to On or Off for Automatic.
Press the up/down arrow to move to Enable or Disable for Manual.
If you selected Manual enabled, the machine confirms if the
overwrite feature starts now. Press the up/down arrow to select
Yes or No. If you select Yes, Manual overwrite starts as soon
as you select Yes. If you select No, this feature will be enabled.
6. Press OK.
Supplies and accessories_ 90
specifications
12.
This chapter guides you about this machine’s specifications such as various features.
This chapter include:
•
•
General specifications
Print media specifications
General specifications
The specification values listed below are subject to change without notice. See www.samsung.com/printer for possible changes in information.
Items
Description
Dimension
Width x Length x Height
446 x 481 x 464 mm
(17.6 x 18.9 x 18.3 inches) without optional tray
Weight
Machine with consumables
30.4 Kg (67.02 lbs)
Noise Levela
Ready mode
35 dB (A)
Print mode
54 dB (A)
Operation
10 to 32.5 °C (50 to 90.5 °F)
Storage (packed)
-20 to 40°C (-4 to 104°F)
Operation
20 to 80% RH
Storage (packed)
0 to 95% RH
110 volt models
AC 110 - 127 V
220 volt models
AC 220 - 240 V
Average operating mode
Less than 750 Wh
Ready mode
Less than 60 Wh
Power save mode
Less than 8 Wh
Power off mode
Less than 1 Wh
Module
ML-NWA65L
Temperature
Humidity
Power ratingb
Power consumption
Wireless c
a. Sound Pressure Level, ISO 7779. Configuration tested: basic machine installation, A4 paper, simplex printing.
b. See the rating label on the machine for the correct voltage (V), frequency (hertz) and type of current (A) for your machine.
c. Optional device
Specifications_ 91
Print media specifications
Type
Size
print media weighta/Capacityb
Dimensions
tray1 / optional trays
Plain paper
Envelope
Letter
216 x 279 mm (8.5 x 11 inches)
Legal
216 x 356 mm (8.5 x 14 inches)
US Folio
216 x 330 mm (8.5 x 13 inches)
A4
210 x 297 mm (8.27 x 11.69 inches)
Oficio
216 x 343 mm (8.5 x 13.5 inches)
JIS B5
182 x 257 mm (7.17 x 10.12 inches)
ISO B5
176 x 250 mm (6.93 x 9.84 inches)
Executive
184 x 267 mm (7.25 x 10.5 inches)
A5
148 x 210 mm (5.83 x 8.27 inches)
Statement
140 x 216 mm (5.5 x 8.5 inches)
A6
105 x 148 mm (4.13 x 5.83 inches)
Envelope Monarch
98 x 191 mm (3.87 x 7.5 inches)
66 to 90 g/m2 (17.3 to 24 lb bond)
•
2
500 sheets of 80 g/m (20 lb bond)
66 to 90 g/m2 (17.3 to 24 lb bond)
•
2
250 sheets of 80 g/m (20 lb bond)
multi-purpose tray
66 to 90 g/m2 (17.3 to 24 lb bond)
•
100 sheets of 80 g/m2(20 lb
bond)
66 to 90 g/m2 (17.3 to 24 lb bond)
•
50 sheets of 80 g/m2(20 lb
bond)
Not available in tray1 / optional trays.
Not available in tray1 / optional trays.
75 to 90 g/m2 (20 to 24 lb bond)
• 10 sheets
Envelope No. 10
105 x 241 mm (4.12 x 9.5 inches)
Envelope DL
110 x 220 mm (4.33 x 8.66 inches)
Envelope C5
162 x 229 mm (6.38 x 9.02 inches)
Envelope C6
114 x 162 mm (4.49 x 6.38 inches)
Envelope No. 9
98 x 225 mm (3.87 x 8.87 inches)
Envelope 6 3/4
92 x 165 mm (3.62 x 6.5 inches)
Thin paper
Refer to the Plain
paper section
Refer to the Plain paper section
60 to 65 g/m2 (16 to 17.2 lb bond)
• 500 sheets
60 to 65 g/m2 (16 to 17.2 lb bond)
• 100 sheets
Thick paper
Refer to the Plain
paper section
Refer to the Plain paper section
91 to 105 g/m2 (24.1 to 28 lb bond)
• 350 sheets
91 to 105 g/m2 (24.1 to 28 lb bond)
• 40 sheets
Thicker paper
Refer to the Plain
paper section
Refer to the Plain paper section
106 to 120 g/m2 (28 to 32lb bond)
• 350 sheets
106 to 120 g/m2 (28 to 32lb bond)
• 40 sheets
Extra Thick
Refer to the Plain
paper section
Refer to the Plain paper section
121 to 163 g/m2 (32.1 to 43 lb bond)
• 100 sheets
121 to 163 g/m2 (32.1 to 43 lb bond)
• 10 sheets
Transparency
Refer to the Plain
paper section
Refer to the Plain paper section
Not available in tray1 / optional trays.
138 to 146 g/m2 (37 to 39 lb bond)
• 10 sheets
Labelsc
Refer to the Plain
paper section
Refer to the Plain paper section
120 to 150 g/m2 (32 to 40 lb bond)
• 10 sheets
Card stock
A6
105 x 148 mm (3 x 5 inches)
171 to 220 g/m2 (46 to 59 lb bond)
• 1 sheets
Minimum size (custom)
76 x 127 mm (3 x 5 inches)
Maximum size (custom)
216 x 356 mm (8.5 x 14 inches)
60 to 163 g/m2 (16 to 43 lb bond)
a. If media weight is over 163 g/m2 (28 lb bond), load a paper into the multi-purpose tray one by one.
b. Maximum capacity may differ depending on media weight, thickness, and environmental conditions.
c. Smoothness: 100 to 250 (sheffield)
Specifications_ 92
contact samsung worldwide
If you have any comments or questions regarding Samsung products, contact the Samsung customer care center.
Country/Region
Customer Care Center
Web Site
ALBANIA
42 27 5755
ARGENTINE
0800-333-3733
ARMENIA
0-800-05-555
AUSTRALIA
1300 362 603
www.samsung.com
AUSTRIA
0810-SAMSUNG (7267864, € 0.07/min)
www.samsung.com
AZERBAIJAN
088-55-55-555
BAHRAIN
8000-4726
BELARUS
810-800-500-55-500
BELGIUM
02-201-24-18
BOSNIA
05 133 1999
BRAZIL
0800-124-421
4004-0000
www.samsung.com
BULGARIA
07001 33 11
www.samsung.com
CANADA
1-800-SAMSUNG (726-7864)
www.samsung.com
CHILE
800-SAMSUNG (726-7864)
www.samsung.com
CHINA
400-810-5858
www.samsung.com
COLOMBIA
01-8000112112
www.samsung.com
COSTA RICA
0-800-507-7267
www.samsung.com
CROATIA
062 SAMSUNG (062 726 7864)
www.samsung.com
CZECH REPUBLIC
800-SAMSUNG (800-726786)
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com/be (Dutch)
www.samsung.com/be_fr (French)
Samsung Zrt., česká organizační složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8
DENMARK
70 70 19 70
www.samsung.com
DOMINICA
1-800-751-2676
www.samsung.com
ECUADOR
1-800-10-7267
www.samsung.com
EGYPT
0800-726786
www.samsung.com
EIRE
0818 717100
www.samsung.com
EL SALVADOR
800-6225
www.samsung.com
ESTONIA
800-7267
www.samsung.com
FINLAND
030-6227 515
www.samsung.com
FRANCE
01 48 63 00 00
www.samsung.com
GERMANY
01805 - SAMSUNG (726-7864 € 0,14/min)
www.samsung.com
GEORGIA
8-800-555-555
Contact SAMSUNG worldwide_ 93
Country/Region
Customer Care Center
Web Site
GREECE
IT and Mobile : 80111-SAMSUNG (80111 7267864) from land line, local
charge/ from mobile, 210 6897691
Cameras, Camcorders, Televisions and Household Appliances
From mobile and fixed 2106293100
www.samsung.com
GUATEMALA
1-800-299-0013
www.samsung.com
HONDURAS
800-27919267
www.samsung.com
HONG KONG
(852) 3698-4698
www.samsung.com/hk
www.samsung.com/hk_en/
HUNGARY
06-80-SAMSUNG (726-7864)
www.samsung.com
INDIA
3030 8282
1800 3000 8282
www.samsung.com
INDONESIA
0800-112-8888
021-5699-7777
www.samsung.com
IRAN
021-8255
www.samsung.com
ITALY
800-SAMSUNG (726-7864)
www.samsung.com
JAMAICA
1-800-234-7267
www.samsung.com
JAPAN
0120-327-527
www.samsung.com
JORDAN
800-22273
www.samsung.com
KAZAKHSTAN
8-10-800-500-55-500 (GSM:7799)
www.samsung.com
KOSOVO
+381 0113216899
KUWAIT
183-2255
www.samsung.com
KYRGYZSTAN
00-800-500-55-500
www.samsung.com
LATVIA
8000-7267
www.samsung.com
LITHUANIA
8-800-77777
www.samsung.com
LUXEMBURG
261 03 710
www.samsung.com
MALAYSIA
1800-88-9999
www.samsung.com
MACEDONIA
023 207 777
MEXICO
01-800-SAMSUNG (726-7864)
MOLDOVA
00-800-500-55-500
MONTENEGRO
020 405 888
MOROCCO
080 100 2255
www.samsung.com
NIGERIA
080-SAMSUNG(726-7864)
www.samsung.com
NETHERLANDS
0900-SAMSUNG (0900-7267864) (€ 0,10/min)
www.samsung.com
NEW ZEALAND
0800 SAMSUNG (0800 726 786)
www.samsung.com
NICARAGUA
00-1800-5077267
www.samsung.com
NORWAY
815-56 480
www.samsung.com
OMAN
800-SAMSUNG (726-7864)
www.samsung.com
PANAMA
800-7267
www.samsung.com
PERU
0-800-777-08
www.samsung.com
Contact SAMSUNG worldwide_ 94
www.samsung.com
Country/Region
Customer Care Center
Web Site
PHILIPPINES
1800-10-SAMSUNG (726-7864)
1-800-3-SAMSUNG (726-7864)
1-800-8-SAMSUNG (726-7864)
02-5805777
www.samsung.com
POLAND
0 801 1SAMSUNG (172678)
022-607-93-33
www.samsung.com
PORTUGAL
80820-SAMSUNG (726-7864)
www.samsung.com
PUERTO RICO
1-800-682-3180
www.samsung.com
RUMANIA
08010 SAMSUNG (08010 726 7864) only from landline, local network
Romtelecom - local tariff /
021 206 01 10 for landline and mobile, normal tariff.
www.samsung.com
RUSSIA
8-800-555-55-55
www.samsung.com
SAUDI ARABIA
9200-21230
www.samsung.com
SERBIA
0700 SAMSUNG (0700 726 7864)
www.samsung.com
SINGAPORE
1800-SAMSUNG (726-7864)
www.samsung.com
SLOVAKIA
0800-SAMSUNG (726-7864)
www.samsung.com
SOUTH AFRICA
0860 SAMSUNG (726-7864)
www.samsung.com
SPAIN
902-1-SAMSUNG(902 172 678)
www.samsung.com
SWEDEN
0771 726 7864 (SAMSUNG)
www.samsung.com
SWITZERLAND
0848-SAMSUNG (7267864, CHF 0.08/min)
www.samsung.com/ch
www.samsung.com/ch_fr/
TADJIKISTAN
8-10-800-500-55-500
www.samsung.com
TAIWAN
0800-329-999
www.samsung.com
THAILAND
1800-29-3232
02-689-3232
www.samsung.com
TRINIDAD & TOBAGO
1-800-SAMSUNG (726-7864)
www.samsung.com
TURKEY
444 77 11
www.samsung.com
U.A.E
800-SAMSUNG (726-7864)
www.samsung.com
U.K
0330 SAMSUNG (726-7864)
www.samsung.com
U.S.A
1-800-SAMSUNG (726-7864)
www.samsung.com
UKRAINE
0-800-502-000
www.samsung.com/ua
www.samsung.com/ua_ru
UZBEKISTAN
8-10-800-500-55-500
www.samsung.com
VENEZUELA
0-800-100-5303
www.samsung.com
VIETNAM
1 800 588 889
www.samsung.com
Contact SAMSUNG worldwide_ 95
glossary
The following glossary helps you get familiar with the product by
understanding the terminologies commonly used with printing as well
as mentioned in this user’s guide.
client. BOOTP enables 'diskless workstation' computers to obtain an IP
address prior to loading any advanced operating system.
CCD
802.11
Charge Coupled Device (CCD) is a hardware which enables the scan
job. CCD Locking mechanism is also used to hold the CCD module to
prevent any damage when you move the machine.
802.11 is a set of standards for wireless local area network (WLAN)
communication, developed by the IEEE LAN/MAN Standards
Committee (IEEE 802).
Collation
802.11b/g/n
802.11b/g/n can share same hardware and use the 2.4 GHz band.
802.11b supports bandwidth up to 11 Mbps, 802.11n supports
bandwidth up to 150 Mbps. 802.11b/g/n devices may occasionally suffer
interference from microwave ovens, cordless telephones, and Bluetooth
devices.
Access point
Access Point or Wireless Access Point (AP or WAP) is a device that
connects wireless communication devices together on wireless local
area networks (WLAN), and acts as a central transmitter and receiver of
WLAN radio signals.
ADF
An Automatic Document Feeder (ADF) is a scanning unit that will
automatically feed an original sheet of paper so that the machine can
scan some amount of the paper at once.
Collation is a process of printing a multiple-copy job in sets. When
collation is selected, the device prints an entire set before printing
additional copies.
Control Panel
A control panel is a flat, typically vertical, area where control or
monitoring instruments are displayed. They are typically found in front of
the machine.
Coverage
It is the printing term used for a toner usage measurement on printing.
For example, 5% coverage means that an A4 sided paper has about 5%
image or text on it. So, if the paper or original has complicated images or
lots of text on it, the coverage will be higher and at the same time, a
toner usage will be as much as the coverage.
CSV
AppleTalk
AppleTalk is a proprietary suite of protocols developed by Apple, Inc for
computer networking. It was included in the original Macintosh (1984)
and is now deprecated by Apple in favor of TCP/IP networking.
Comma Separated Values (CSV). A type of file format, CSV is used to
exchange data between disparate applications. The file format, as it is
used in Microsoft Excel, has become a de facto standard throughout the
industry, even among non-Microsoft platforms.
DADF
BIT Depth
A computer graphics term describing the number of bits used to
represent the color of a single pixel in a bitmapped image. Higher color
depth gives a broader range of distinct colors. As the number of bits
increases, the number of possible colors becomes impractically large for
a color map. 1-bit color is commonly called as monochrome or black and
white.
BMP
A bitmapped graphics format used internally by the Microsoft Windows
graphics subsystem (GDI), and used commonly as a simple graphics file
format on that platform.
BOOTP
Bootstrap Protocol. A network protocol used by a network client to
obtain its IP address automatically. This is usually done in the bootstrap
process of computers or operating systems running on them. The
BOOTP servers assign the IP address from a pool of addresses to each
Glossary_ 96
A Duplex Automatic Document Feeder (DADF) is a scanning unit that
will automatically feed and turn over an original sheet of paper so that
the machine can scan on both sides of the paper.
Default
The value or setting that is in effect when taking a printer out of its box
state, reset, or initialized.
DHCP
A Dynamic Host Configuration Protocol (DHCP) is a client-server
networking protocol. A DHCP server provides configuration parameters
specific to the DHCP client host requesting, generally, information
required by the client host to participate on an IP network. DHCP also
provides a mechanism for allocation of IP addresses to client hosts.
DIMM
Emulation
Dual Inline Memory Module (DIMM), a small circuit board that holds
memory. DIMM stores all the data within the machine like printing data,
received fax data.
Emulation is a technique of one machine obtaining the same results as
another.
An emulator duplicates the functions of one system with a different
system, so that the second system behaves like the first system.
Emulation focuses on exact reproduction of external behavior, which is
in contrast to simulation, which concerns an abstract model of the
system being simulated, often considering its internal state.
DLNA
The Digital Living Network Alliance (DLNA) is a standard that allows
devices on a home network to share information with each other across
the network.
DMPr
The Digital Media Printer (DMPr) is a device that allows printing in DLNA
home network. The DMPr prints a page by combining images with an
Extensible HyperText Markup Language (XHTML) template.
Ethernet
Ethernet is a frame-based computer networking technology for local
area networks (LANs). It defines wiring and signaling for the physical
layer, and frame formats and protocols for the media access control
(MAC)/data link layer of the OSI model. Ethernet is mostly standardized
as IEEE 802.3. It has become the most widespread LAN technology in
use during the 1990s to the present.
DNS
EtherTalk
The Domain Name Server (DNS) is a system that stores information
associated with domain names in a distributed database on networks,
such as the Internet.
A suite of protocols developed by Apple Computer for computer
networking. It was included in the original Macintosh (1984) and is now
deprecated by Apple in favor of TCP/IP networking.
Dot Matrix Printer
A dot matrix printer refers to a type of computer printer with a print head
that runs back and forth on the page and prints by impact, striking an
ink-soaked cloth ribbon against the paper, much like a typewriter.
FDI
Foreign Device Interface (FDI) is a card installed inside the machine to
allow a third party device such as a coin operated device or a card
reader. Those devices allow the pay-for-print service on your machine.
DPI
FTP
Dots Per Inch (DPI) is a measurement of resolution that is used for
scanning and printing. Generally, higher DPI results in a higher
resolution, more visible detail in the image, and a larger file size.
A File Transfer Protocol (FTP) is a commonly used protocol for
exchanging files over any network that supports the TCP/IP protocol
(such as the Internet or an intranet).
DRPD
Distinctive Ring Pattern Detection. Distinctive Ring is a telephone
company service which enables a user to use a single telephone line to
answer several different telephone numbers.
Duplex
A mechanism that will automatically turn over a sheet of paper so that
the machine can print (or scan) on both sides of the paper. A printer
equipped with a Duplex Unit can print on both sides of paper during one
print cycle.
Duty Cycle
Duty cycle is the page quantity which does not affect printer
performance for a month. Generally the printer has the lifespan limitation
such as pages per year. The lifespan means the average capacity of
print-outs, usually within the warranty period. For example, if the duty
cycle is 48,000 pages per month assuming 20 working days, a printer
limits 2,400 pages a day.
Fuser Unit
The part of a laser printer that fuses the toner onto the print media. It
consists of a heat roller and a pressure roller. After toner is transferred
onto the paper, the fuser unit applies heat and pressure to ensure that
the toner stays on the paper permanently, which is why paper is warm
when it comes out of a laser printer.
Gateway
A connection between computer networks, or between a computer
network and a telephone line. It is very popular, as it is a computer or a
network that allows access to another computer or network.
Grayscale
A shades of gray that represent light and dark portions of an image
when color images are converted to grayscale; colors are represented
by various shades of gray.
Halftone
ECM
Error Correction Mode (ECM) is an optional transmission mode built into
Class 1 fax machines or fax modems. It automatically detects and
corrects errors in the fax transmission process that are sometimes
caused by telephone line noise.
Glossary_ 97
An image type that simulates grayscale by varying the number of dots.
Highly colored areas consist of a large number of dots, while lighter
areas consist of a smaller number of dots.
HDD
ITU-T
Hard Disk Drive (HDD), commonly referred to as a hard drive or hard
disk, is a non-volatile storage device which stores digitally-encoded data
on rapidly rotating platters with magnetic surfaces.
The International Telecommunication Union is an international
organization established to standardize and regulate international radio
and telecommunications. Its main tasks include standardization,
allocation of the radio spectrum, and organizing interconnection
arrangements between different countries to allow international phone
calls. A -T out of ITU-T indicates telecommunication.
IEEE
The Institute of Electrical and Electronics Engineers (IEEE) is an
international non-profit, professional organization for the advancement
of technology related to electricity.
IEEE 1284
The 1284 parallel port standard was developed by the Institute of
Electrical and Electronics Engineers (IEEE). The term "1284-B" refers to
a specific connector type on the end of the parallel cable that attaches to
the peripheral (for example, a printer).
Intranet
A private network that uses Internet Protocols, network connectivity, and
possibly the public telecommunication system to securely share part of
an organization's information or operations with its employees.
Sometimes the term refers only to the most visible service, the internal
website.
IP address
An Internet Protocol (IP) address is a unique number that devices use in
order to identify and communicate with each other on a network utilizing
the Internet Protocol standard.
IPM
ITU-T No. 1 chart
Standardized test chart published by ITU-T for document facsimile
transmissions.
JBIG
Joint Bi-level Image Experts Group (JBIG) is an image compression
standard with no loss of accuracy or quality, which was designed for
compression of binary images, particularly for faxes, but can also be
used on other images.
JPEG
Joint Photographic Experts Group (JPEG) is a most commonly used
standard method of lossy compression for photographic images. It is the
format used for storing and transmitting photographs on the World Wide
Web.
LDAP
The Lightweight Directory Access Protocol (LDAP) is a networking
protocol for querying and modifying directory services running over
TCP/IP.
The Images Per Minute (IPM) is a way of measuring the speed of a
printer. An IPM rate indicates the number of single-sided sheets a printer
can complete within one minute.
LED
IPP
MAC address
The Internet Printing Protocol (IPP) defines a standard protocol for
printing as well as managing print jobs, media size, resolution, and so
forth. IPP can be used locally or over the Internet to hundreds of
printers, and also supports access control, authentication, and
encryption, making it a much more capable and secure printing solution
than older ones.
Media Access Control (MAC) address is a unique identifier associated
with a network adapter. MAC address is a unique 48-bit identifier usually
written as 12 hexadecimal characters grouped in pairs (e. g.,
00-00-0c-34-11-4e). This address is usually hard-coded into a Network
Interface Card (NIC) by its manufacturer, and used as an aid for routers
trying to locate machines on large networks.
IPX/SPX
MFP
IPX/SPX stands for Internet Packet Exchange/Sequenced Packet
Exchange. It is a networking protocol used by the Novell NetWare
operating systems. IPX and SPX both provide connection services
similar to TCP/IP, with the IPX protocol having similarities to IP, and
SPX having similarities to TCP. IPX/SPX was primarily designed for
local area networks (LANs), and is a very efficient protocol for this
purpose (typically its performance exceeds that of TCP/IP on a LAN).
Multi Function Peripheral (MFP) is an office machine that includes the
following functionality in one physical body, so as to have a printer, a
copier, a fax, a scanner and etc.
A Light-Emitting Diode (LED) is a semiconductor device that indicates
the status of a machine.
MH
Modified Huffman (MH) is a compression method for decreasing the
amount of data that needs to be transmitted between the fax machines
to transfer the image recommended by ITU-T T.4. MH is a
codebook-based run-length encoding scheme optimized to efficiently
compress white space. As most faxes consist mostly of white space, this
minimizes the transmission time of most faxes.
ISO
The International Organization for Standardization (ISO) is an
international standard-setting body composed of representatives from
national standards bodies. It produces world-wide industrial and
commercial standards.
Glossary_ 98
MMR
PDF
Modified Modified READ (MMR) is a compression method
recommended by ITU-T T.6.
Portable Document Format (PDF) is a proprietary file format developed
by Adobe Systems for representing two dimensional documents in a
device independent and resolution independent format.
Modem
PostScript
A device that modulates a carrier signal to encode digital information,
and also demodulates such a carrier signal to decode transmitted
information.
PostScript (PS) is a page description language and programming
language used primarily in the electronic and desktop publishing areas. that is run in an interpreter to generate an image.
MR
Modified Read (MR) is a compression method recommended by ITU-T
T.4. MR encodes the first scanned line using MH. The next line is
compared to the first, the differences determined, and then the
differences are encoded and transmitted.
Printer Driver
A program used to send commands and transfer data from the computer
to the printer.
Print Media
NetWare
The media like paper, envelopes, labels, and transparencies which can
be used in a printer, a scanner, a fax or, a copier.
A network operating system developed by Novell, Inc. It initially used
cooperative multitasking to run various services on a PC, and the
network protocols were based on the archetypal Xerox XNS stack.
Today NetWare supports TCP/IP as well as IPX/SPX.
PPM
OPC
Organic Photo Conductor (OPC) is a mechanism that makes a virtual
image for print using a laser beam emitted from a laser printer, and it is
usually green or rust colored and has a cylinder shape.
An imaging unit containing a drum slowly wears the drum surface by its
usage in the printer, and it should be replaced appropriately since it gets
worn from contact with the cartridge development brush, cleaning
mechanism, and paper.
Pages Per Minute (PPM) is a method of measurement for determining
how fast a printer works, meaning the number of pages a printer can
produce in one minute.
PRN file
An interface for a device driver, this allows software to interact with the
device driver using standard input/output system calls, which simplifies
many tasks.
Protocol
Originals
The first example of something, such as a document, photograph or text,
etc, which is copied, reproduced or translated to produce others, but
which is not itself copied or derived from something else.
A convention or standard that controls or enables the connection,
communication, and data transfer between two computing endpoints.
PS
See PostScript.
OSI
Open Systems Interconnection (OSI) is a model developed by the
International Organization for Standardization (ISO) for communications.
OSI offers a standard, modular approach to network design that divides
the required set of complex functions into manageable, self-contained,
functional layers. The layers are, from top to bottom, Application,
Presentation, Session, Transport, Network, Data Link and Physical.
PSTN
The Public-Switched Telephone Network (PSTN) is the network of the
world's public circuit-switched telephone networks which, on industrial
premises, is usually routed through the switchboard.
RADIUS
PABX
A private automatic branch exchange (PABX) is an automatic telephone
switching system within a private enterprise.
PCL
Printer Command Language (PCL) is a Page Description Language
(PDL) developed by HP as a printer protocol and has become an
industry standard. Originally developed for early inkjet printers, PCL has
been released in varying levels for thermal, dot matrix printer, and laser
printers.
Remote Authentication Dial In User Service (RADIUS) is a protocol for
remote user authentication and accounting. RADIUS enables
centralized management of authentication data such as usernames and
passwords using an AAA (authentication, authorization, and accounting)
concept to manage network access.
Resolution
The sharpness of an image, measured in Dots Per Inch (DPI). The
higher the dpi, the greater the resolution.
SMB
Server Message Block (SMB) is a network protocol mainly applied to
share files, printers, serial ports, and miscellaneous communications
Glossary_ 99
UNC Path
between nodes on a network. It also provides an authenticated
Inter-process communication mechanism.
Uniform Naming Convention (UNC) is a standard way to access network
shares in Window NT and other Microsoft products. The format of a
UNC path is: \\<servername>\<sharename>\<Additional directory>
SMTP
Simple Mail Transfer Protocol (SMTP) is the standard for e-mail
transmissions across the Internet. SMTP is a relatively simple,
text-based protocol, where one or more recipients of a message are
specified, and then the message text is transferred. It is a client-server
protocol, where the client transmits an email message to the server.
URL
Uniform Resource Locator (URL) is the global address of documents
and resources on the Internet. The first part of the address indicates
what protocol to use, the second part specifies the IP address or the
domain name where the resource is located.
SSID
Service Set Identifier (SSID) is a name of a wireless local area network
(WLAN). All wireless devices in a WLAN use the same SSID in order to
communicate with each other. The SSIDs are case-sensitive and have a
maximum length of 32 characters.
USB
Universal Serial Bus (USB) is a standard that was developed by the
USB Implementers Forum, Inc., to connect computers and peripherals.
Unlike the parallel port, USB is designed to concurrently connect a
single computer USB port to multiple peripherals.
Subnet Mask
The subnet mask is used in conjunction with the network address to
determine which part of the address is the network address and which
part is the host address.
TCP/IP
The Transmission Control Protocol (TCP) and the Internet Protocol (IP);
the set of communications protocols that implement the protocol stack
on which the Internet and most commercial networks run.
Watermark
A watermark is a recognizable image or pattern in paper that appears
lighter when viewed by transmitted light. Watermarks were first
introduced in Bologna, Italy in 1282; they have been used by
papermakers to identify their product, and also on postage stamps,
currency, and other government documents to discourage
counterfeiting.
WEP
Wired Equivalent Privacy (WEP) is a security protocol specified in IEEE
802.11 to provide the same level of security as that of a wired LAN. WEP
provides security by encrypting data over radio so that it is protected as
it is transmitted from one end point to another.
TCR
Transmission Confirmation Report (TCR) provides details of each
transmission such as job status, transmission result and number of
pages sent. This report can be set to print after each job or only after
failed transmissions.
WIA
TIFF
Tagged Image File Format (TIFF) is a variable-resolution bitmapped
image format. TIFF describes image data that typically come from
scanners. TIFF images make use of tags, keywords defining the
characteristics of the image that is included in the file. This flexible and
platform-independent format can be used for pictures that have been
made by various image processing applications.
Toner Cartridge
A kind of bottle or container used in a machine like a printer which
contains toner. Toner is a powder used in laser printers and
photocopiers, which forms the text and images on the printed paper.
Toner can be fused by by a combination of heat/pressure from the fuser,
causing it to bind to the fibers in the paper.
TWAIN
An industry standard for scanners and software. By using a
TWAIN-compliant scanner with a TWAIN-compliant program, a scan can
be initiated from within the program. It is an image capture API for
Microsoft Windows and Apple Macintosh operating systems.
Glossary_ 100
Windows Imaging Architecture (WIA) is an imaging architecture that is
originally introduced in Windows Me and Windows XP. A scan can be
initiated from within these operating systems by using a WIA-compliant
scanner.
WPA
Wi-Fi Protected Access (WPA) is a class of systems to secure wireless
(Wi-Fi) computer networks, which was created to improve upon the
security features of WEP.
WPA-PSK
WPA-PSK (WPA Pre-Shared Key) is special mode of WPA for small
business or home users. A shared key, or password, is configured in the
wireless access point (WAP) and any wireless laptop or desktop
devices. WPA-PSK generates a unique key for each session between a
wireless client and the associated WAP for more advanced security.
WPS
The Wi-Fi Protected Setup (WPS) is a standard for establishing a
wireless home network. If your wireless access point supports WPS, you
can configure the wireless network connection easily without a
computer.
XPS
XML Paper Specification (XPS) is a specification for a Page Description
Language (PDL) and a new document format, which has benefits for
portable document and electronic document, developed by Microsoft. It
is an XML-based specification, based on a new print path and a
vector-based device-independent document format.
Glossary_ 101
