LCD Projector Commercial Use

Operating Instructions

Model No.

PT-L780NTU

PT-L780U

R

Before operating this product, please read the instructions carefully and save this manual for future use.

TQBJ 0109-3

Dear Panasonic Customer:

This instruction booklet provides all the necessary operating information that you might require. We hope it will help you to get the most performance out of your new product, and that you will be pleased with your Panasonic LCD projector.

The serial number of your product may be found on its back. You should note it in the space provided below and retain this booklet in case service is required.

Model number: PT-L780NTU / PT-L780U

Serial number:

IMPORTANT SAFETY NOTICE

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Power Supply: This LCD Projector is designed to operate on 100 V – 240 V, 50 Hz/60

Hz AC, house current only.

CAUTION: The AC power cord which is supplied with the projector as an accessory can only be used for power supplies up to 125 V, 10 A. If you need to use higher voltages or currents than this, you will need to obtain a separate 250 V power cord. If you use the accessory cord in such situations, fire may result.

2

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

CAUTION: This equipment is equipped with a three-pin grounding-type power plug. Do not remove the grounding pin on the power plug. This plug will only fit a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician. Do not defeat the purpose of the grounding plug.

Do not remove

WARNING:

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

FCC CAUTION: To assure continued compliance, use only shielded interface cables when connecting to computer or peripheral devices. Any unauthorized changes or modifications to this equipment will void the users authority to operate.

Model Number:

Trade Name:

Declaration of Conformity

PT-L780NTU / PT-L780U

Panasonic

Responsible party: Matsushita Electric Corporation of America.

Address: One Panasonic Way Secaucus New Jersey 07094

Telephone number: 1-800-528-8601 or 1-800-222-0741

Email: [email protected]

This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

3

Contents

Preparation

IMPORTANT SAFETY NOTICE..........2

Precautions with regard to safety ....5

Accessories........................................9

Precautions on handling .................10

Location and function of each part ...12

Using the remote control unit.........18

Laser beam pointer.........................18

Wireless mouse ..............................19

Inserting the batteries .....................20

Operating range..............................20

Setting the projector IDs number for remote control unit ...21

Connections .....................................22

Notes on connections .....................22

Example of connecting to video equipment ...................................24

Example of connecting to computer ..25

Setting-up .........................................26

Projection methods.........................26

Projector position............................26

Projection distances .......................27

Basic Operation

Starting to use..................................28

Turning on the power......................28

Turning off the power......................29

On-screen menus.............................30

Menu screens .................................30

Menu operation guide.....................33

Returning to the previous screen....33

Returning a setting to the factory default ...34

Using the freeze function ................34

Using the D.ZOOM (digital zoom) function...35

Adjusting the picture .......................36

PICTURE MODE ............................36

Color Hue Setting ...........................37

COLOR...........................................37

TINT................................................37

BRIGHT ..........................................37

4

CONTRAST....................................37

SHARPNESS .................................37

Noise Reduction(NR)......................37

TV SYSTEM ...................................37

WHITE BALANCE R/G/B ...............38

Projecting sRGB-compatible pictures ...38

Adjusting the position .....................39

POSITION ......................................40

DOT CLOCK...................................40

CLOCK PHASE ..............................40

KEYSTONE ....................................40

OSD POSITION..............................41

ASPECT .........................................41

RESIZING.......................................42

AUTO SETUP.................................42

FRAME LOCK ................................42

Audio adjustment.............................43

VOLUME ........................................43

MUTE .............................................43

Changing the display language......43

Advanced Operation

Option settings.................................44

SHUTTER.......................................44

OSD................................................44

AUTO KEYSTONE .........................44

RGB/YPbPr ....................................44

RGB2 SELECT...............................44

BACK COLOR ................................45

FRONT/REAR ................................45

DESK/CEILING ..............................45

LAMP POWER ...............................45

LAMP RUN TIME ...........................45

FAN CONTROL..............................45

WEB CONTROL.............................45

WEB STANDBY .............................45

WEB PASSWORD .........................46

CONTROL KEY..............................46

FUNC 1...........................................46

SET ID ............................................46

AUTO POWER OFF.......................46

NETWORK SETUP ...........................47

SD CARD SETUP..............................47

Lens adjustment ..............................48

Projection lens replacement ...........49

Projection distance for each projection lens (sold separately) ..50

Slot cover replacement ...................52

Putting the power cord and remote control unit away .............53

Using the cable cover......................54

Using the remote terminal...............55

Using the SERIAL connector ..........56

Others

Indicators..........................................58

About the automatic setup function......60

List of compatible signals...............61

Cleaning and replacing the air filter...62

Replacing the lamp unit ..................63

Before calling for service ................66

Specifications...................................68

Dimensions.......................................70

Trademark acknowledgements ......71

NOTES IMPORTANTES

CONCERNANT LA SÉCURITÉ...72

Précautions de sécurité ..............73

Précautions de manipulation.............77

Remplacement du bloc de lampe...79

Precautions with regard to safety

WARNING

If a problem occurs (such as no image or no sound) or if you notice smoke or a strange smell coming from the projector, turn off the power and disconnect the power cord from the wall outlet.

B Do not continue to use the projector in such cases, otherwise fire or electric shocks could result.

B Check that no more smoke is coming out, and then contact an Authorised

Service Center for repairs.

B Do not attempt to repair the projector yourself, as this can be dangerous.

Do not install this projector in a place which is not strong enough to take the full weight of the projector.

B If the installation location is not strong enough, it may fall down or tip over, and severe injury or damage could result.

Installation work (such as ceiling suspension) should only be carried out by a qualified technician.

B If installation is not carried out correctly, there is the danger that injury or electric shocks may occur.

If foreign objects or water get inside the projector, or if the projector is dropped or the cabinet is broken, turn off the power and disconnect the power cord from the wall outlet.

B Continued use of the projector in this condition may result in fire or electric shocks.

B Contact an Authorised Service Center for repairs.

Do not overload the wall outlet.

B If the power supply is overloaded (for example, by using too many adapters), overheating may occur and fire may result.

Do not remove the cover or modify it in any way.

B High voltages which can cause fire or electric shocks are present inside the projector.

B For any inspection, adjustment and repair work, please contact an

Authorised Service Center.

Clean the power cord plug regularly to prevent it from becoming covered in dust.

B If dust builds up on the power cord plug, the resulting humidity can damage the insulation, which could result in fire. Pull the power cord out from the wall outlet and wipe it with a dry cloth.

B If not using the projector for an extended period of time, pull the power cord plug out from the wall outlet.

5

6

Do not do anything that might damage the power cord or the power cord plug.

B Do not damage the power cord, make any modifications to it, place it near any hot objects, bend it excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.

B If the power cord is used while damaged, electric shocks, short-circuits or fire may result.

B Ask an Authorised Service Center to carry out any repairs to the power cord that might be necessary.

Do not handle the power cord plug with wet hands.

B Failure to observe this may result in electric shocks.

Insert the power cord plug securely into the wall outlet.

B If the plug is not inserted correctly, electric shocks or overheating could result.

B Do not use plugs which are damaged or wall outlets which are coming loose from the wall.

Do not place the projector on top of surfaces which are unstable.

B If the projector is placed on top of a surface which is sloped or unstable, it may fall down or tip over, and injury or damage could result.

Do not place the projector into water or let it become wet.

B Failure to observe this may result in fire or electric shocks.

Do not place liquid containers on top of the projector.

B If water spills onto the projector or gets inside it, fire or electric shocks could result.

B If any water gets inside the projector, contact an Authorised Service

Center.

Do not insert any foreign objects into the projector.

B Do not insert any metal objects or flammable objects into the projector or drop them onto the projector, as doing so can result in fire or electric shocks.

Keep the remote control unit out of the reach of children, and do not look into the laser beam or point it towards other people.

B If the laser beam which is emitted by the remote control unit transmitter is pointed directly into the eyes, it may cause visual ability to be impaired.

Do not allow the + and - terminals of the batteries to come into contact with metallic objects such as necklaces or hairpins.

B Failure to observe this may cause the batteries to leak, overheat, explode or catch fire.

B Store the batteries in a plastic bag and keep them away from metallic objects.

During a thunderstorm, do not touch the projector or the cable.

B Electric shocks can result.

Do not use the projector in a bath or shower.

B Fire or electric shocks can result.

Do not look into the lens while the projector is being used.

B Strong light is emitted from the projector’s lens. If you look directly into this light, it can hurt and damage your eyes.

Do not bring your hands or other objects close to the air outlet port.

B Heated air comes out of the air outlet port. Do not bring your hands or face, or objects which cannot withstand heat close to this port, otherwise burns or damage could result.

When replacing the lamp, allow it to cool for at least one hour before handling it.

B The lamp cover gets very hot, and contact with it can cause burns.

Before replacing the lamp, be sure to unplug the power cord from the power outlet.

B Electric shocks or explosions can result if this is not done.

Keep the SD memory card out of the reach of infants. (PT-L780NTU only)

B If the memory card is swallowed, death by suffocation may result. If you believe that the memory card may have been swallowed, seek medical advice immediately.

Caution

Do not cover the air inlet or the air outlet.

B Doing so may cause the projector to overheat, which can cause fire or damage to the projector.

Do not set up the projector in humid or dusty places or in places where the projector may come into contact with smoke or steam.

B Using the projector under such conditions may result in fire or electric shocks.

When disconnecting the power cord, hold the plug, not the cord.

B If the power cord itself is pulled, the cord will become damaged, and fire, short-circuits or serious electric shocks may result.

Always disconnect all cables before moving the projector.

B Moving the projector with cables still attached can damage the cables, which could cause fire or electric shocks to occur.

Do not place any heavy objects on top of the projector.

B Failure to observe this may cause the projector to become unbalanced and fall, which could result in damage or injury.

Do not short-circuit, heat or disassemble the batteries or place them into water or fire.

B Failure to observe this may cause the batteries to overheat, leak, explode or catch fire, and burns or other injury may result.

When inserting the batteries, make sure the polarities (+ and -) are correct.

B If the batteries are inserted incorrectly, they may explode or leak, and fire, injury or contamination of the battery compartment and surrounding area may result.

7

8

Use only the specified batteries.

B If incorrect batteries are used, they may explode or leak, and fire, injury or contamination of the battery compartment and surrounding area may result.

Do not mix old and new batteries.

B If the batteries are inserted incorrectly, they may explode or leak, and fire, injury or contamination of the battery compartment and surrounding area may result.

Do not put your weight on this projector.

B You could fall or the projector could break, and injury may result.

B Be especially careful not to let young children climb onto the projector.

Disconnect the power cord plug from the wall outlet as a safety precaution before carrying out any cleaning.

B Electric shocks can result if this is not done.

Ask an Authorised Service Center to clean inside the projector at least once a year.

B If dust is left to build up inside the projector without being cleaned out, it can result in fire or problems with operation.

B It is a good idea to clean the inside of the projector before the season for humid weather arrives. Ask your nearest Authorised Service Center to clean the projector when required. Please discuss with the Authorised

Service Center regarding cleaning costs.

We are constantly making efforts to preserve and maintain a clean environment. Please take non repairable units back to your dealer or a recycling company.

NOTICE:

B This product has a High Intensity Discharge (HID) lamp that contains a small amount of mercury. It also contains lead in some components.

Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information please contact your local authorities, or the Electronics Industries

Alliance: <http://www.eiae.org.>

Accessories

Check that all of the accessories shown below have been included with your projector.

Remote control unit

(N2QAEA000011 x1)

AAA batteries for remote control unit (x2)

RGB signal cable [3.0 m

(9´10˝), K1HB15FA0001 x1]

Cable cover

(TXFKR01VJN1 x1)

Video/Audio cable [3.0

m (9´10˝),

K2KA2FA00001 x 1]

Power coed

(K2CG3FZ00008 x 1)

USB cable

(3.0 m, K1HB04FD0002 x 1)

CD-ROM (TQBH9003x1)

(PT-L780NTU only)

SD memory card (8 MB,

RP-SD008BEZ0 x1)

(PT-L780NTU only)

Protective case for SD memory card

(RP-SDCC0 x1)

(PT-L780NTU only)

Slot cover (for projector LAN card)

(TKKL5243 x1)

(PT-L780NTU only)

9

Precautions on handling

Cautions when moving the projector

Be sure to attach the lens cover before moving the projector.

The projection lens is extremely susceptible to vibration and shocks. Be careful not to subject it to excessive vibration and shock when moving the projector.

Cautions regarding setting-up

Observe the following at all times when setting up the projector.

Avoid setting up in places which are subject to vibration or shocks.

If the projector is set up in locations with strong vibration, such as near a motor, or if it is installed inside a vehicle or on board a ship, the projector may be subjected to vibration or shocks which can damage the internal parts and cause malfunctions or accidents. Accordingly, set up the projector in a place which is free from such vibrations and shocks.

Do not set up the projector near high-voltage power lines or near motors.

The projector may be subject to electromagnetic interference if it is set up near high-voltage power lines or motors.

If installing the projector to the ceiling, ask a qualified technician to carry out all installation work.

If the projector is to be suspended from the ceiling, you will need to purchase the separate installation kit (Model No.: ET-PK780). Furthermore, all installation work should only be carried out by a qualified technician.

If using this projector at high elevations (above 1 400 m), set the FAN

CONTROL to HIGH. (Refer to page 45.)

Failure to observe this may result in malfunctions.

Notes on use

In order to get the best picture quality

If outside light or light from indoor lamps is shining onto the screen, the images projected will not have good contrast. Draw curtains or blinds over any windows and turn off any fluorescent lights near the screen to prevent reflection.

Do not touch the surfaces of the lens with your bare hands.

If the surface of the lens becomes dirty from fingerprints or anything else, this will be magnified and projected onto the screen. Moreover, when not using the projector, retract the lens and then cover it with the accessory lens cover.

10

About the screen

If the screen you are using is dirty, damaged or discolored, attractive projections cannot be obtained. Do not apply any volatile substances to the screen, and do not let it become dirty or damaged.

About the lamp

The lamp may need to be replaced earlier due to variables such as individual lamp characteristics, usage conditions and the installation environment, especially when the projector is subjected to continuous use for more than

10 hours or the power is frequently turned on and off, as the operations that prevent blackening of the bulb (the action of the halogen cycle) do not work enough during short periods of time.

About the SD memory card (PT-L780NTU only)

Static electricity from the human body can damage the SD memory card. To prevent this, you should touch a nearby metallic object such as an aluminium sash or a door knob to dissipate the static charge from your body.

About the card slot (PT-L780NTU only)

Make sure that there are no foreign objects inside the slot when inserting the

SD memory card or an optional wireless card. Failure to observe it may damage the card and the slot.

Before carrying out cleaning and maintenance, be sure to disconnect the power cord plug from the wall outlet.

Wipe the cabinet with a soft, dry cloth.

If the cabinet is particularly dirty, soak the cloth in water with a small amount of neutral detergent in it, squeeze the cloth very well, and then wipe the cabinet. After cleaning, wipe the cabinet dry with a dry cloth.

If using a chemically-treated cloth, read the instructions supplied with the cloth before use.

Do not wipe the lens with a cloth that is dusty or which produces lint.

If any dust or lint gets onto the lens, such dust or lint will be magnified and projected onto the screen. Use a blower to clean any dust and lint from the lens surface, or use a soft cloth to wipe off any dust or lint.

11

Location and function of each part

Projector <Top, right and front>

$ #

0

%

%

&

'

(

)

* +

&

'

,

-

.

/

# Projector control panel

(page 14)

$ Focus ring

(pages 29 and 48)

% Air inlet ports

Do not cover these ports.

& Leg adjuster buttons(L/R)

(page 28)

These buttons are used to unlock the front adjustable legs. Press to adjust the angle of tilt of the projector.

' Front adjustable legs(L/R)

(page 28)

( Lens release button

(page 49)

This button is used when using a projection lens that is sold separately.

) Projection lens

* Lens cover

+ Remote control signal receptor

(page 20)

, Air filter

(page 62)

- Connector panel

(page 16)

. Power input socket (AC IN)

(page 28)

The accessory power cord is connected here.

Do not use any power cord other than the accessory power cord.

/ MAIN POWER switch

(pages 28 and 29)

0 Speaker

12

Projector <Back and bottom>

# ' & %

$

# Remote control signal receptor

(page 20)

$ Security lock

This can be used to connect a commercially-available theftprevention cable (manufactured by Kensington). This security lock is compatible with the Microsaver

Security System from

Kensington. Contact details for this company are given below.

Kensington Technology Group

ACCO Brands Inc.

2855 Campus Drive

San Mateo, CA 94403 USA

Tel (650)572-2700

Fax (650)572-9675 http://www.kensington.com/ http://www.gravis.com/

NOTE:

B Information given above may be changed in future.

% Carrying handle

& Lamp unit holder

(page 63)

' Air outlet port

Do not cover this port.

WARNING

Do not bring your hands or other objects close to the air outlet port.

B Heated air comes out of the air outlet port. Do not bring your hands or face, or objects which cannot withstand heat close to this port, otherwise burns or damage could result.

NOTE:

B During projection of an image, the cooling fan will operate, emitting a small noise as it operates.

Turning the lamp on or off will cause this noise to increase a little.

B By using the OPTION menu to set “LAMP POWER” to “LOW”, the operating sound of the fan can be reduced. (Refer to page

45.)

13

Remote control unit

4

(

&

3

POWER

AUTO

SETUP

RGB LASER

VIDEO MENU

PAGE

)

5

+

0 1 2

Projector control panel

# $ % & '

(

POWER

RGB INPUT LAMP TEMP

AUTO SETUP

INPUT

VIDEO RGB SHUTTER

*

)

.

STANDBY(R)

ON(G)

FOCUS

+

MENU

ZOOM

+ ENTER

/

+ , -

# Power indicator

(pages 28, 29 and 45)

This indicator illuminates red when the MAIN POWER switch is turned on (standby mode), and illuminates green when the power is turned on and a picture starts to be projected.

(PT-L780NTU only)

When the WEB STANDBY is set to "ON", the cooling fan operates and the power indicator on the projector flashes slowly in red.

$ RGB INPUT indicator

This indicator illuminates when a signal is input into the connector that is selected with the input select buttons.

% LAMP indicator (page 59)

This indicator illuminates when it is time to replace the lamp unit. It flashes if a circuit abnormality is detected.

& Input select (RGB, VIDEO)

buttons (page 28)

' TEMP indicator (page 58)

This indicator illuminates if an abnormally high temperature is detected inside the projector or

14

,

-

6

7

8

9

R-CLICK ENTER

FREEZE SHUTTER

FUNC1

Computer Pro jector

*

:

; around it. If the temperature rises above a certain level, the power supply will be turned off automatically and the indicator will illuminate or flash.

( POWER button

(pages 28 and 29)

) AUTO SETUP button

(pages 28 and 60)

If this button is pressed while a picture is being projected, the projection settings will be adjusted automatically in accordance with the signal being input. In addition, the angle of tilt of the projector will be automatically detected and adjusted in order to correct any keystone distortion. (“AUTO

SETUP” will appear on the screen during adjustment.) Set

“AUTO KEYSTONE” in the

OPTION menu to “OFF” to prevent any deterioration of the picture as a result of keystone correction. However, keystone distortion may not be corrected properly when using a lens that is sold separately. Refer to page 40 for details on correcting keystone distortion manually.

* SHUTTER button (page 44)

This button is used to momentarily turn off the picture and sound. However, keystone distortion may not be corrected properly when using a lens that is sold separately. Refer to page 40 for details on correcting keystone distortion manually.

+ MENU button (pages 30 and 33)

This button is used to display the menu screens. When a menu screen is being displayed, this button can be used to return to a previous screen or to clear the screen.

, Arrow (F GI

(page 33)

These buttons are used to select and adjust items in the menu screens.

*When in computer operating mode, these buttons on the remote control unit function differently. (page 19)

- ENTER button (page 33)

This button is used to accept and to activate items selected in the on-screen menus.

*When in computer operating mode, this button on the remote control unit operates differently.

(page 19)

. FOCUS +/- buttons (page 29)

These buttons are used to adjust the projected image focus.

/ Zoom +/- buttons (page 29)

These buttons are used to adjust the projected image size.

0 Laser emitter (page 18)

1 Infrared emitter (page 20)

2 Click button (page 19)

This button can be used when the operating mode select switch is moved to the left (Computer).

3 PAGE button (page 19)

This button can be used when the operating mode select switch is moved to the left (Computer).

4 Operation indicator (page 18)

This indicator illuminates while a laser beam is being emitted

(while the LASER button is being pressed). It flashes when any other buttons are being pressed.

5 LASER button (page 18)

A beam of laser light is emitted while this button is being pressed. This laser beam can be used as a pointer to point to something on the screen.

6 FREEZE button (page 34)

This button is used to momentarily freeze projection so that a still picture is displayed.

7 D.ZOOM +/- buttons (page 35)

These buttons are used to enlarge the projected image.

8 VOLUME +/- buttons

These buttons are used to adjust the volume of the sound output from the projector’s built-in speakers. Refer to page 43 for details on how to adjust the volume using the buttons on the projector control panel.

9 FUNCTION (FUNC1) button

(pages 40, 43 and 46)

This button can be used for 1) switching on and off the sound volume and 2) entering into the keystone distortion correction mode.

Use the FUNC1 item in the OPTION menu to select which you wish to use.

: ID SET button (page 21)

This button is used to set the IDs into the remote control unit when using multiple projectors with a single remote control unit.

; Operating mode (Computer,

Projector) select switch

(page 19)

Move this switch to the left side to use the remote control unit to operate a computer, and move it to the right side to operate the projector.

15

<Connector panel>

#

USB

REMOTE

+

$

SERIAL

% & ' ( )

RGB1 IN RGB2 IN/RGB OUT

R/R-Y/P

R

G/Y B/B-Y/P

B

RGB3 IN

SYNC/HD VD

DVI-D IN

S-VIDEO IN

L

AUDIO OUT

RGB AUDIO IN VIDEO IN

R

AUDIO IN

, .

*

# USB port

(page 19)

The remote control unit can be used as a personal computer mouse by connecting the projector to a personal computer with the supplied USB cable.

(4-pin square connector)

$ SERIAL connector

(pages 24, 25 and 56)

This connector is used to connect a personal computer to the projector in order to externally control the projector. (RS-232C compatible)

% RGB1 IN connector

(pages 24 and 25)

This connector is used to input

RGB signals and YP

B

P

R signals.

& RGB2 IN/RGB OUT connector

(pages 24 and 25)

This connector is used to input or output RGB signals and YP

B

P

R signals. Use the RGB2 SELECT item in the OPTION menu to select whether you want input or output with this connector.

' DVI-D IN connector

(page 25)

This connector is used to input

DVI-D signals.

( AUDIO OUT jack

16

(pages 24 and 25)

This jack is used to output the audio signals which are input to the projector. If audio equipment is connected to this jack, no sound will be output from the built-in speakers.

) S-VIDEO IN connector

(pages 24 and 42)

This connector is used to input signals from a S-VIDEOcompatible equipment such as a video deck. The connector is S1 signal compatible, and it automatically switches between

16:9 and 4:3 aspect ratios in accordance with the type of signal being input.

* AUDIO IN L-R (for VIDEO/S-

VIDEO) jacks

(page 24)

Only one system is provided, so connect the appropriate connector when using VIDEO or

S-VIDEO.

+ Remote control connector

(page 55)

This connector is used to control the projector from the Remote

Control set up in Wired mode.

, RGB3 (YP

B

P

R

) IN connector

(pages 24 and 25)

This connector is used to input

RGB signals and YP

B

P

R signals.

- RGB AUDIO IN jack

(pages 24 and 25)

Only one system is provided, so connect the appropriate connector when using RGB1,

(PT-L780NTU only)

<Card slot>

#

RGB2 or RGB3.

. VIDEO IN jack

(page 24)

This jack is used to input video signals from a video equipment such as a video deck.

<SD memory card>

Front Back

$

(

)

% ' &

# Slot cover

Covers the card slots. When using an optional projector LAN card, replace the slot cover (refer to page 52).

$ Card slot

Insert an optional wireless card or a projector LAN card into here.

% Eject switch

Use to remove an optional wireless card or projector LAN card from the card slot.

& Access lamp

Flashes while the projector is being accessed for reading or writing the data in the SD memory card.

' SD memory card slot

Insert the SD memory card into here.

( Metal terminals

These terminals are for connecting the SD memory card to the projector’s card slot. Do not touch the metal terminals with hands or metal objects, attach stickers to them, or allow them to become contaminated in any way.

) Write-protect switch

If the write-protect switch on the

SD memory card is moved to the

LOCK position, it will not be possible to use any file editing functions such as deleting or moving image files.

17

Using the remote control unit

Laser beam pointer

The laser beam emitted from the remote control can be used as a pointer by pointing forward to the screen.

While the LASER button is being pressed, the laser beam is being emitted and the operating indicator illuminates.

Do not look into the laser emitter of the remote control unit or point the laser beam towards other people, otherwise damage to eyes may occur.

PUSH

N2QAEA000011

18

Caution

B Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous radiation exposure.

B This remote control unit cannot be repaired.

Wireless mouse

You can use the remote control as a personal computer mouse. Set the Mode

(Projector/Computer) switch on the remote control unit to “Computer” and connect the projector’s USB port to a personal computer counterpart with the accessory USB cable.

Projector

Accessory USB cable

USB

SERIAL

RGB1 IN RGB2 IN/RGB

Computer equipped with a USB port REMOTE

R/R-Y/P

R

G/Y B/B-Y/P

B

RGB3 IN

SYN

BFor Windows (Versions 98SE, Me, 2000 and XP), you can use the standard mouse driver which comes bundled with the operating system.

AUTO

POWER SETUP

RGB LASER

VIDEO MENU

PAGE

R-CLICK ENTER

FREEZE SHUTTER

Page buttons Click button

FGIH button

R-CLICK button

FUNC1

Computer Pro jector

Mode switch

(Computer/Projector)

Mode switch (Computer/Projector)

Move the mode switch to the

“Computer” position.

B Page buttons

^: Functions as the Page Up button on a personal computer keyboard.

v: Functions as the Page Down button on a personal computer keyboard.

B Arrow (F H) buttons

These buttons can move the cursor on a personal computer’s screen as the personal computer mouse.

B R-CLICK button

This button functions as the right button on a personal computer mouse.

B Click button

This button functions as the left button on a personal computer mouse.

NOTE:

B The optional wireless receiver

(ET-RMRC1) is needed for a personal computer not equipped with a USB port.

19

Inserting the batteries

# Open the cover.

$ Insert the batteries so that the

polarities are correct, and then close the cover.

NOTE:

AAA batteries

(two)

Operating range

If the remote control unit is held so that it is facing directly in front of the remote control signal receptors on the front or rear of the projector, the operating range is within approximately 7 m (23´) from the surfaces of the receptors.

Furthermore, the remote control unit can be operated from an angle of

±30° to the left or right and ±15° above or below the receptors.

NOTE:

20

Setting the projector IDs number for remote control unit

When controlling multiple projectors individually or simultaneously with a single remote control unit, projector IDs must be set into the remote control unit as described in the following steps.

#Press the ID SET button on the remote control unit.

ID number “ALL” will be displayed on the screen.

$Press and hold the ID SET button for more than 2 seconds.

The ID number will change into “1”. The ID SET button will now toggle through ID numbers “2”, “3”, “ALL” and “1” each time it is subsequently pressed.

%Select the ID number you wish and then press the ENTER button.

When the projector ID coincides with the remote control unit

<If the MAIN POWER is ON>

The ID number will be displayed in white on the screen.

If the projector ID and ID for the remote control unit are not the same, the projector ID is displayed in green.

<If the projector is in standby mode>

The Power indicator on the projector will flash for 5 seconds.

If the projector ID and ID for the remote control unit are not the same, the

Power indicator will stay illuminated red.

NOTE:

B The projector ID number in the remote control unit is set to “ALL” by default. It is therefore not necessary to set a projector ID number when only one projector is used.

B The projector can be turned ON/OFF from the remote control unit only if the projector ID is set in the remote control unit. For more details on projector ID setting, see page 46.

21

Connections

Notes on connections

B Read the instruction manual for each system component carefully before connecting it.

B Turn off the power supply for all components before making any connections.

B If the cables necessary for connecting a component to the system are not included with the component or available as an option, you may need to fashion a cable to suit the component concerned.

B If there is a lot of jitter in the video signal which is input from the video source, the picture on the screen may flicker. In such cases, it will be necessary to connect a TBC (time base corrector).

B The projector has built-in speakers. However, you will need to connect a separate audio system to the AUDIO OUT jack if your needs specify high sound volumes. No sound will come out of the projector’s built-in speakers while the AUDIO OUT jack is being used.

B It may not be possible to connect some types of computer. Refer to the list of compatible signals on page 61.

B The pin layout and signal names for the S-VIDEO IN connector are shown below.

#

&

$

%

Pin No.

#

$

%

&

Signal

Earth (Luminance signal)

Earth (Color signal)

Luminance signal

Color signal

External view

B The pin layout and signal names for the RGB/YP

B

P

R

(RGB1 IN/RGB2 IN) connector are shown below.

(

-

#

1

'

External view

,

Pin No.

#

$

%

.

/

0

1

R/P

R

G/G·SYNC/Y

B/P

B

SDA

HD/SYNC

VD

SCL

Signal

Pin + is spare.

Pins &–*, , and - are for earth.

Pins . and 1 functions are only valid when supported by the computer.

22

B The pin assignments on the DVI-D input connector are as follows

(interface with TMDS connector on a personal computer)

: 3

2

* #

View from mating side

+

Pin No.

Signal

#

T.M.D.S data 2-

$ T.M.D.S data 2+

% T.M.D.S data 2/4 shield

& T.M.D.S data 4-

'

T.M.D.S data 4+

( DDC clock

) DDC data

*

-

+

T.M.D.S data 1-

, T.M.D.S data 1+

T.M.D.S data1/3 shield

.

T.M.D.S data 3-

Pin No.

Signal

/

T.M.D.S data 3+

0 +5 V

1 Ground

2 Hot plug sense

3

T.M.D.S data 0-

4 T.M.D.S data 0+

5 T.M.D.S data 0/5 shield

6

T.M.D.S data 5-

7

T.M.D.S data 5+

8 T.M.D.S clock shield

9 T.M.D.S clock+

:

T.M.D.S clock-

23

Example of connecting to video equipments

Computer for control use

D-sub 15 (male) - BNC5 (female) adapter cable (sold separately)

Red (connect to P

R signal connector)

Blue (connect to P

B signal connector)

Green (connect to Y signal connector)

Digital broadcast tuner or DVD player

DVD player

D-sub 9-pin

(male)

USB SERIAL

REMOTE

RGB1 IN RGB2 IN/RGB OUT

R/R-Y/P

R

G/Y B/B-Y/P

B

RGB3 IN

SYNC/HD VD

DVI-D IN

S-VIDEO IN

L

AUDIO OUT

RGB AUDIO IN VIDEO IN

R

AUDIO IN

Video deck

DVD player Audio system

Red (connect to P

R signal connector)

Blue (connect to P

B signal connector)

Green (connect to Y signal connector)

NOTE:

B Only one audio system circuit is available for the AUDIO IN L-R jacks for

S-VIDEO/VIDEO signals, so if you wish to change the audio input source, you will need to remove and insert the appropriate plugs.

B Only one audio system circuit is available for the RGB AUDIO IN jacks, so if you wish to change the audio input source, you will need to remove and insert the appropriate plugs.

B If an audio system is connected to the AUDIO OUT jack, the sound volume balance can be controlled by the remote control unit which is supplied with the projector.

B If the video signal source is connected using a cable with a BNC connector plug, use a BNC/RCA adapter (sold separately) to convert the cable end to an RCA plug-type jack.

B Refer to page 61 for a list of compatible YP

B

P

R signals which can be input to the projector.

B If the signal cables are disconnected or if the power supply for the computer or video deck is turned off while the digital zoom function is being used, this function will be cancelled.

24

Example of connecting to computer

Computer

Computer for control use

ON DIP

Monitor

D-sub 9-pin

(male)

USB

SERIAL

REMOTE

RGB1 IN RGB2 IN/RGB OUT

R/R-Y/P

R

G/Y B/B-Y/P

B

RGB3 IN

SYNC/HD VD

DVI-D IN

S-VIDEO IN

L

AUDIO OUT

RGB AUDIO IN

VIDEO IN

R

AUDIO IN

Computer

Audio system

DVI cable (Option)

(ET-SCDV03)

Computer with

DVI-D OUT connector

NOTE:

B It is better to shut down the computer before turning off the MAIN POWER switch of the projector.

B Refer to the list of compatible signals on page 61 for the types of RGB signals which can be input to the projector by connecting a computer.

B Do not input the signal to the RGB2 IN/RGB OUT connector when the

RGB2 SELECT item in the OPTION menu is set to OUTPUT. (Refer to page 44.)

Refer to the accessory CD-ROM for details on connecting the projector to a personal computer by means of a wireless or wired network using an optional wireless card or projector LAN card.

(PT-L780NTU only)

25

Setting-up

Projection methods

In way of installing projector, any one of the following four projection methods are used. Select whichever projection method matches the setting-up method. (The projection method can be set from the OPTION menu. Refer to page 45 for details.)

DESK

DESK/CEILING

CEILING

FRONT

(Factory default setting)

FRONT/REAR

REAR

NOTE:

B You will need to purchase the separate ceiling bracket (ET-PK780) when using the ceiling installation method.

Projector position

Top edge of screen

<Units: mm (inch)>

L: Projection distance

SH: Image height

SW: Image width

Screen

L

Bottom edge of screen

26

Screen

L

Projection distances

Screen size (4:3) Projection distance (L)

Diagonal length

Height

(SH)

Width

(SW)

Wide

(LW)

Telephoto

(LT)

1.01 m(40˝) 0.61 m(2´) 0.81 m(2´8˝)

1.27 m(50˝) 0.76 m(2´6˝) 1.02 m(3´4˝)

1.52 m(60˝) 0.91 m(3´) 1.22 m(4´)

1.77 m(70˝) 1.07 m(3´6˝) 1.42 m(4´8˝)

2.03 m(80˝) 1.22 m(4´) 1.63 m(5´4˝)

2.28 m(90˝) 1.37 m(4´6˝) 1.83 m(6´)

2.54 m(100˝) 1.52 m(5´) 2.03 m(6´8˝)

3.81 m(150˝) 2.29 m(7´6˝) 3.05 m(10´)

1.6 m(5´2˝)

2.0 m(6´6˝)

2.4 m(7´10˝)

2.8 m(9´2˝)

2.0 m(6´6˝)

2.6 m(8´6˝)

3.1 m(10´2˝)

3.6 m(11´9˝)

3.2 m(10´5˝) 4.2 m(13´9˝)

3.6 m(11´9˝) 4.7 m(15´5˝)

4.0 m(13´1˝) 5.3 m(17´4˝)

6.1 m(20´) 7.9 m(25´11˝)

5.08 m(200˝) 3.05 m(10´) 4.06 m(13´4˝) 8.1 m(26´6˝) 10.6 m(34´9˝)

6.35 m(250˝) 3.81 m(12´6˝) 5.08 m(16´8˝) 10.1 m(33´1˝) 13.3 m(43´7˝)

7.62 m(300˝) 4.57 m(15´) 6.10 m(20´) 12.2 m(40´) 16.0 m(52´5˝)

Setting-up dimensions which are not given in the above table can be calculated using the formulas below.

If the screen size (diagonal) is SD (m), then the following formula is used to calculate the projection distance for the wide lens position (LW) and the projection distance for the telephoto lens position (LT).

LW=0.0407xSD/0.0254-0.080

LT=0.0538xSD/0.0254-0.0774

For 16:9 aspect ratios, the following formula can be used to calculate the projection distance.

LW=0.0443xSD/0.0254-0.080

LT=0.0586xSD/0.0254-0.0774

NOTE:

B The dimensions in the table above and the values obtained from the above formulas may contain slight errors.

B If you use the projection distance for the 16:9 screen, the

4:3 projection image overflows the screen at the top and bottom.

B If you set up the projector vertically, it may cause to damage the projector.

B It is recommended that you set up the projector in a place that is tilted at less than ±35°. Setting up the projector in places that are tilted at more than

±35° may cause malfunctions.

Make sure that enough space is kept for the air outlet port.

27

Starting to use

Turning on the power

Please ensure that all preparations have been completed before turning on the power. (Refer to pages 22 – 27.)

# Remove the lens cover.

$ Connect the accessory power cord.

% Press the MAIN POWER switch to

the “l” side to turn on the power.

The power indicator on the projector will illuminate red.

& Press the POWER button.

The power indicator on the projector will flash green. After a short period, the indicator will illuminate green, and a picture will be projected.

' Press the input select (RGB, VIDEO)

button to select the input signal.

The input signal selected will change as shown at below each time an input select button is pressed.

VIDEO

VIDEO RGB

RGB

S-VIDEO

VIDEO

$

POWER

RGB INPUT LAMP TEMP

AUTO SETUP

INPUT

VIDEO RGB SHUTTER

FOCUS

+

ZOOM

+ MENU

POWER

RGB INPUT LAMP TEMP

AUTO SETUP VIDEO

INPUT

RGB SHUTTER

STANDBY(R)

ON(G)

+

ZOOM

+ MENU ENTER

RGB2

SD CARD

NETWORK

RGB3

DVI

RGB1

ENTER

POWER

AUTO

SETUP

RGB LASER

VIDEO MENU

PAGE

POWER

AUTO

SETUP

RGB LASER

VIDEO MENU

PAGE

%

( While pressing the adjuster buttons,

adjust the forward/back angle of tilt of the projector.

To make fine adjustments to the angle of tilt of the projector, turn the front adjustable legs. (The front adjustable legs will be locked if they are fully extended and then turned anticlockwise. Turn them back clockwise to release the lock.)

) Press the AUTO SETUP button to

initiate automatic positioning.

The automatic positioning is only for vertical keystone distor tion. To correct the horizontal keystone distortion or when keystone distortion has not been corrected to the optimum level, carry out the keystone correction as described on page 40.

28

POWER

RGB INPUT LAMP TEMP

AUTO SETUP

INPUT

VIDEO RGB SHUTTER

STANDBY(R)

ON(G)

FOCUS

+

ZOOM

+ MENU ENTER

POWER

AUTO

SETUP

RGB LASER

VIDEO MENU

PAGE

*Press the FOCUS +/- or ZOOM +/-

buttons to adjust the projected image focus and size.

The projected image focus can also be adjusted by turning the focus ring. To make fine adjustments to the projected image focus, use the FOCUS +/- buttons.

POWER

RGB INPUT LAMP TEMP

AUTO SETUP VIDEO

INPUT

RGB SHUTTER

STANDBY(R)

ON(G)

FOCUS

+

ZOOM

+ MENU ENTER

Focus

Turning off the power

#

Press the POWER button. “Power

OFF” is displayed on the screen.

Power OFF

OK CANCEL

$

buttons and press the ENTER button.

The lamp unit will switch off and the picture will stop being projected. (The power indicator on the projector will illuminate orange.)

% Wait until the power indicator on the projector illuminates red (until

the cooling fan stops).

Do not in any way cut power to the projector while the cooling fan is still operating. Be careful not to switch off the MAIN POWER switch of the projector, unplug the power cord from the electrical outlet or turn off in-line switches such as tabletop power switches.

& Press the MAIN POWER switch to the “O” side to turn off the power.

NOTE:

B After the power is turned off, the lamp unit will take some time to cool down. If you turn the power back on again before the lamp unit has cooled down, the lamp unit may not turn on straight away, but it will turn on automatically after a short period. (During this time, the power indicator on the projector will flash orange.)

B When the projector is in standby mode (the power indicator on the projector is illuminated red), the projector will still draw a maximum 3.5 W of power, even when the cooling fan has stopped.

B If the MAIN POWER switch is accidentally turned off while the projector is being used, the lamp unit may not turn on straight away after the power is turned back on. In such cases, the lamp unit will turn back on automatically after a short period. (During this time, the power indicator on the projector will flash green.)

B A tinkling sound may be heard while the power indicator is turned off, but this is not a sign of a malfunction.

B You can also turn off the power by pressing the POWER button twice.

B When the WEB STANDBY is set to “ON”, the cooling fan operates and the power indicator on the projector flashes slowly in red and the projector draw a maximum 43 W of power. (page 45) (PT-L780NTU only)

B Do not turn off the power while the SD card is being accessed and “SD card is in use ” is displayed on the screen. (PT-L780NTU only)

29

On-screen menus

Menu screens

The various settings and adjustments for this projector can be carried out by selecting the operations from on-screen menus.

The general arrangement of these menus is shown below.

PICTURE menu (page 36)

When an RGB/DVI signal is being input

When a YP

B

P

R signal is being input


PICTURE MODE

COLOR TEMP.

BRIGHT

CONTRAST

SHARPNESS

WHITE BALANCE R

WHITE BALANCE G

WHITE BALANCE B

STANDARD

32

32

6

32

32

32

STANDARD

STANDARD


PICTURE MODE

COLOR TEMP.

COLOR

TINT

BRIGHT

CONTRAST

SHARPNESS

NR

STANDARD

32

32

32

32

2

1

STANDARD

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

When an S-VIDEO/VIDEO signal is being input


PICTURE MODE

COLOR TEMP.

COLOR

TINT

BRIGHT

CONTRAST

SHARPNESS

NR

TV-SYSTEM

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

32

32

32

32

2

1

STANDARD

STANDARD

AUTO1

ENTER:[ENTER]

ESC:[MENU]

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

When the NETWORK/SD CARD is selected (PT-L780NTU only)


PICTURE MODE

COLOR TEMP.

BRIGHT

CONTRAST

STANDARD

32

32

STANDARD

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

NOTE:

B Keystone distortion of the on-screen display will not be corrected.

30

POSITION menu (page 39)

When an RGB/DVI signal is being input

POSITION

POSITION

DOT CLOCK

CLOCK PHASE

KEYSTONE

OSD POSITION

RESIZING

AUTO SETUP

FRAME LOCK

STANDARD

H: 128 V: 32

32

16

H: 0 V: 0

TOP LEFT

OFF ON

OFF ON

When a YP

B

P

R signal is being input

POSITION

POSITION

KEYSTONE

OSD POSITION

ASPECT

RESIZING

AUTO SETUP

STANDARD

H: 32 V: 32

H: 0 V: 0

TOP LEFT

4:3

OFF ON

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

“POSITION”, “DOT CLOCK” and

“CLOCK PHASE” are not displayed when a DVI signal is being input.

When an S-VIDEO/VIDEO signal is being input

POSITION

POSITION

KEYSTONE

OSD POSITION

ASPECT

RESIZING

AUTO SETUP

STANDARD

H: 32 V: 16

H: 0 V: 0

TOP LEFT

AUTO

OFF ON

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

When the NETWORK/SD CARD is selected (PT-L780NTU only)

POSITION

KEYSTONE

OSD POSITION

AUTO SETUP

STANDARD

H: 0 V: 0

TOP LEFT

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

AUDIO menu (page 43)

AUDIO

VOLUME

MUTE

20

OFF ON

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

LANGUAGE menu (page 43)

LANGUAGE

ENGLISH

DEUTSCH

FRANÇAIS

ESPAÑOL

ITALIANO

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

SELECT:[^][@] [{][}]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

31

OPTION menu (page 44)

OPTION

SHUTTER

OSD

AUTO KEYSTONE

RGB/YPbPr

RGB2 SELECT

BACK COLOR

FRONT/REAR

DESK/CEILING

LAMP POWER

LAMP RUN TIME

NEXT PAGE @

OFF

OFF

RGB

INPUT

BLUE

FRONT

DESK

LOW

ON

ON

YPbPr

OUTPUT

BLACK

REAR

CEILING

HIGH

10 H

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

The RGB/YPbPr item is displayed when an RGB/YP

B

P

R signal is being input.

NETWORK menu (page 47)

(PT-L780NTU only)

NETWORK

STATUS

WEP

LAN1

KEY1

OPTION

PREVIOUS PAGE ^

FAN CONTROL

WEB CONTROL

STANDARD

OFF

OFF WEB STANDBY

WEB PASSWORD

CONTROL KEY

FUNC1

OFF

MUTE

SET ID ALL

AUTO POWER OFF DISABLE

HIGH

ON

ON

ON

KEYSTONE

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

“WEB CONTROL”, “WEB STANDBY” and “WEB PASSWORD” are only displayed for the PT-L780NTU.

SD CARD menu (page 47)

(PT-L780NTU only)

SD CARD

AUTOPLAY

REPEAT

INTERVAL

OFF ON

1

5 sec

SELECT:[^][@]

調整:[←][→]

ENTER:[ENTER]

ESC:[MENU]

LENS menu (page 48)

LENS

ZOOM/FOCUS

LENS SELECT

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

32

SELECT:[^][@] ENTER:[ENTER]

実行:[ENTER]

ESC:[MENU]

Menu operation guide

# Press the MENU button.

The menu screen will be displayed.


PICTURE MODE

COLOR TEMP.

BRIGHT

CONTRAST

SHARPNESS

WHITE BALANCE R

WHITE BALANCE G

WHITE BALANCE B

STANDARD

32

32

6

32

32

32

STANDARD

STANDARD

POSITION

POSITION

DOT CLOCK

CLOCK PHASE

KEYSTONE

OSD POSITION

RESIZING

AUTO SETUP

FRAME LOCK

STANDARD

H: 128 V: 32

32

16

H: 0 V: 0

TOP LEFT

OFF ON

OFF ON

SELECT:[{][}]

ADJUST:[{][}]

buttons to select a menu.

The selected menu screen will then be displayed.

(Example: POSITION menu)

POSITION

POSITION

DOT CLOCK

CLOCK PHASE

KEYSTONE

OSD POSITION

RESIZING

AUTO SETUP

FRAME LOCK

STANDARD

ENTER:[ENTER]

ESC:[MENU]

H: 128 V: 32

32

16

H: 0 V: 0

TOP LEFT

OFF ON

OFF ON

SELECT:[{][}] ADJUST:[{][}]

ESC:[MENU]

%Press the ENTER button to

accept the selection.

You can select an item here. The selected item is shown in yellow.

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

A

B

A For the value adjusting items

Press the ENTER button to display an individual adjustment screen.

C

POSITION

H:

V:

128

32

32

DOT CLOCK

Press the I or H buttons to adjust the setting.

You can also adjust the bar-scale items pressing the I or H buttons in the menu screen.

Some items can be adjusted by pressing the F or G buttons.

B For the selective items

RESIZING OFF ON

Select the setting by pressing the

I or H buttons.

C For the fixed items

Press the ENTER button, and the function will work.

Returning to the previous screen

Press the MENU button to return to the previous screen.

33

Returning a setting to the factory default

Select the STANDARD from the menu screen by pressing the F or

G buttons and then press the

ENTER button to return all items displayed on the screen to their factory default settings.

B When a menu screen is being displayed

POSITION

POSITION

DOT CLOCK

CLOCK PHASE

KEYSTONE

OSD POSITION

RESIZING

AUTO SETUP

FRAME LOCK

STANDARD

H: 128 V: 32

32

16

H: 0 V: 0

TOP LEFT

OFF ON

OFF ON

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

Using the freeze function

The picture will alternate between a still picture and a moving picture each time the FREEZE button on the remote control unit is pressed.

Still picture Moving picture

Using the D.ZOOM (digital zoom) function

This function lets you enlarge the picture.

# Press a D.ZOOM +/- button

& Press the MENU button to

return to the normal screen.

NOTE:

B This function can only be used when using the remote control unit.

B If the type of signal being input changes while the digital zoom function is being used, the digital zoom function will be cancelled.

[

The picture will then be enlarged to 1.5 times the normal size.

$Use the F, G, I and H buttons

to move the enlarged area which you want to project.

% Use the D.ZOOM +/- buttons to

change the enlargement ratio.

The enlargement ratio can be changed within the range of x1 to x4, by 30 steps.

34 35

Adjusting the picture

Select the item pressing the F or G buttons on the remote control unit or the projector.

Press the I or H buttons to set the selective items. For the value adjusting items, press the ENTER button to display an individual screen, and press the I or H buttons to adjust the setting.

When an S-VIDEO/VIDEO signal is being input


PICTURE MODE

COLOR TEMP.

COLOR

TINT

BRIGHT

CONTRAST

SHARPNESS

NR

TV-SYSTEM

STANDARD

32

32

32

32

2

1

STANDARD

STANDARD

AUTO1

When an RGB/DVI signal is being input

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]


PICTURE MODE

COLOR TEMP.

BRIGHT

CONTRAST

SHARPNESS

WHITE BALANCE R

WHITE BALANCE G

WHITE BALANCE B

STANDARD

32

32

6

32

32

32

STANDARD

STANDARD

When the NETWORK/SD CARD is selected (PT-L780NTU only)


PICTURE MODE

COLOR TEMP.

BRIGHT

CONTRAST

STANDARD

32

32

STANDARD

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

When a YP

B

P

R signal is being input

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]


PICTURE MODE

COLOR TEMP.

COLOR

TINT

BRIGHT

CONTRAST

SHARPNESS

NR

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

32

32

32

32

2

1

STANDARD

STANDARD

ENTER:[ENTER]

ESC:[MENU]

PICTURE MODE

STANDARD

DYNAMIC

NATURAL

Select the picture mode that best matches the image source and room conditions.

The mode best used in dark rooms is NATURAL. For rooms having regular lighting conditions in use, select STANDARD. For exceptionally bright rooms, use

DYNAMIC.

36

Color Hue Setting (color temperature)

This is used to adjust the white areas of the picture if they appear bluish or reddish.

COLOR

(S-VIDEO/VIDEO/YP

B

P

R only)

Press the H button to make the color more vivid in tone, and press the I button to make the color more pastel in tone.

TINT

(NTSC/NTSC 4.43/YP

B

P

R only)

This adjusts the flesh tones in the picture. Press the H button to make flesh tones more greenish, and press the I button to make the flesh tones more reddish.

BRIGHT

This adjusts the darker areas (black areas) in the picture. Press the H button if dark areas are too solid (for example, if hair is difficult to see), and press the I button if black areas are too light (grey rather than black).

CONTRAST

This adjusts the contrast of the picture. Press the H button to make the picture brighter, and press the

I button to make the picture darker. (Adjust the BRIGHT setting first if required before adjusting the

CONTRAST setting.)

SHARPNESS

Press the H button to make the picture details sharper, and press the I button to make the picture details softer.

Noise Reduction (NR)

(When S-VIDEO/VIDEO/YP

B

P

R signals are being input)

If the signal is of such poor quality that picture interference appears, you can suppress this interference by adjusting the NR (Noise Reduction), except for 750p (720p), HDTV60

(1080i/60) and HDTV50 (1080i/50) signals. To strengthen the effect, press the H button. To turn it off , set to “0” by pressing the I button.

TV SYSTEM

(S-VIDEO/VIDEO only)

AUTO1

AUTO2

NTSC

NTSC4.43

PAL

PAL-M

PAL-N

SECAM

AUTO1 The projector automatically distinguishes between NTSC/NTSC

4.43/PAL/PAL60/SECAM signals.

AUTO2 The projector automatically distinguishes between NTSC/PAL-

M/PAL-N signals.

NOTE:

B This should normally be set to

“AUTO1” or “AUTO2”. If the signal is of such poor quality that the correct format cannot be automatically distinguished, change the setting manually to the required TV system.

37

WHITE BALANCE R/G/B

(RGB only)

This is used to adjust the white areas of the picture if they appear colorised. Press the I button to make the selected color lighter.

Press the H button to make the selected color stronger.

Projecting sRGBcompatible pictures

sRGB is an international color reproduction standard (IEC61966-2-

1) established by the International

Electrotechnical Commission (IEC).

If you would like the colors in sRGBcompatible pictures to be reproduced more faithfully, make the following settings.

# Press the F or G

select “PICTURE MODE”, and

then use the I

or H

select “NATURAL”.

$ Press the F or G

select “COLOR TEMP.”, and

then use the I

H

select “STANDARD”.

% Select the STANDARD from the

menu screen by pressing the the ENTER button.

& Select the LAMP POWER item

in the OPTION menu by and set to “HIGH” by pressing

and 45)

NOTE:

B sRGB is only enabled when RGB signals are being input .

38

Adjusting the position

When the input signal is RGB, first press the AUTO SETUP button to initiate automatic positioning.

If the optimum setting is not obtained when AUTO SETUP is carried out, adjust by the following procedure.

Select the item pressing the F or G buttons on the remote control unit or the projector.

Press the I or H buttons, to adjust the alternative items. For the numerically adjustable items, press the ENTER button to display an individual screen, and press the I or H buttons to adjust the setting.

Some items can be adjusted pressing the F or G buttons.

When an RGB/DVI signal is being input

When an S-VIDEO/VIDEO signal is being input

POSITION

POSITION

KEYSTONE

OSD POSITION

ASPECT

RESIZING

AUTO SETUP

STANDARD

SELECT:[^][@]

ADJUST:[{][}]

POSITION

POSITION

KEYSTONE

OSD POSITION

ASPECT

RESIZING

AUTO SETUP

STANDARD

H: 32 V: 16

H: 0 V: 0

TOP LEFT

AUTO

OFF ON

ENTER:[ENTER]

ESC:[MENU]

When a YP

B

P

R signal is being input.

H: 32 V: 32

H: 0 V: 0

TOP LEFT

4:3

OFF ON

POSITION

POSITION

DOT CLOCK

CLOCK PHASE

KEYSTONE

OSD POSITION

RESIZING

AUTO SETUP

FRAME LOCK

STANDARD

H: 128 V: 32

32

16

H: 0 V: 0

TOP LEFT

OFF ON

OFF ON

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

“POSITION”, “DOT CLOCK” and

“CLOCK PHASE” are not displayed when a DVI signal is being input.

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

When the NETWORK/SD CARD is selected (PT-L780NTU only)

POSITION

KEYSTONE

OSD POSITION

AUTO SETUP

STANDARD

H: 0 V: 0

TOP LEFT

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

39

POSITION

POSITION

H:

V:

128

32

Moves the picture position.

Press the I or H buttons to move the picture horizontally.

Press the F or G buttons to move the picture vertically.

DOT CLOCK

(RGB only)

Periodic striped pattern interference

(noise) may occur when a striped pattern such as the one below is projected. If this happens, use the

I and H buttons to adjust so that any such noise is minimised.

when using the standard lens.

However the horizontal distortion or adjustment of the tilted screen needs to be corrected manually by following any of the procedures below.

KEYSTONE

H:

V:

0

0

Picture condition

Operation

button.

button.

CLOCK PHASE

(RGB only)

Adjust the DOT CLOCK setting first before carrying out this adjustment.

Use the I and H buttons to adjust so that the noise level is least noticeable.

NOTE:

B If signals with a dot clock frequency of 140 MHz or higher are being input, interference may not be completely eliminated when the DOT CLOCK and CLOCK PHASE adjustments are carried out.

KEYSTONE

Before carrying out keystone correction,

1) adjust the forward/back angle of tilt of the projector by pressing the adjuster buttons and 2) press the AUTO SETUP buttons to correct vertical keystone distortion. (pages 28 and 29)

The vertical keystone distortion will be automatically corrected by the projector's automatic setup function

40

button.

button.

NOTE:

B If you press the AUTO SETUP button after correcting the keystone distortion manually, the automatic keystone correction function will operate and the corrected picture will return to its previous incorrect condition. In addition, if you change the input signal and press the AUTO SETUP button, the keystone correction may be cancelled depending on the type of signal and the angle of tilt of the projector. To prevent them from happening, you can set “AUTO

KEYSTONE” in the OPTION menu to “OFF”

B The greater the correction of keystone distortion amount, the more the picture quality will deteriorate, and the harder it will become to achieve a good level of focus. To obtain the best picture quality, set up the projector and screen in such a way that the amount of keystone correction required is as minimal as possible.

B The picture size will also change when correction of keystone distortion is carried out.

B The range of keystone correction varies depending on the type of signal being input. If you make an adjustment that is outside the allowable range, the setting will not be changed. In addition, if the input signal changes after keystone correction has been carried out, the correction setting may be cancelled.

This indicates that the current correction setting exceeds the allowable range for the new input signal.

B If you correct both vertical and horizontal keystone distortion at the same time, the allowable range of keystone correction becomes smaller. If you make an adjustment that is outside the allowable range, the setting will not be changed.

OSD POSITION

Press the I or H buttons to move the OSD position.

ASPECT

This setting is only valid for an S-

VIDEO/VIDEO signal and a YP

B

P

R signal in 525i (480i), 525p (480p) and 625i format.

AUTO

4:3

16:9

S4:3

AUTO

(S-VIDEO only)

When an S1 video signal is input to the S-VIDEO terminal, the aspect ratio is changed automatically to project a 16:9 picture.

4:3

The input signal is projected without change.

16:9

The picture is compressed to a ratio of 16:9 and projected.

[

When a squeezed signal is being input. (The projected image is contracted vertically)

S4:3

The size of the input signal is compressed to 75% and projected.

(This is useful for projecting a picture with a 4:3 aspect ratio onto a

16:9 screen.)

[

When a 4:3 signal is being input

41

NOTE:

B S1 video signals

S1 video signals are a type of video signal with an aspect ratio of 16:9 which include a detector signal. This detector signal is output by some sources such as wide-vision video decks. If the AUTO setting above is selected, this projector will recognise the detector signal and automatically switch the aspect ratio to 16:9 in order to project the picture.

B This projector is equipped with an aspect ratio selection function.

However, if a mode which does not match the aspect ratio of the input signal is selected, it may affect the quality of viewing of the original picture. Keep this in mind when selecting the aspect ratio.

B If using this projector in places such as cafes or hotels with the aim of displaying programmes for viewing for a commercial purpose or for public presentation, note that if the aspect ratio (16:9) selection function is used to change the aspect ratio of the screen picture, you may be infringing the rights of the original copyright owner for that programme under copyright protection laws.

B If a normal (4:3) picture which was not originally intended for wide-screen viewing is projected onto a wide screen, distortion may occur around the edges of the picture so that part of the picture is no longer visible. Such programmes should be viewed in

4:3 mode to give proper consideration to the aims and intentions of the original programme’s creator.

42

BWhen a VGA60 or 525p RGB signal is being input, select the signal in accordance with the input signal.

RESIZING

This should normally be set to “ON”.

(This setting is only for signals which have lower resolutions than the LCD panels. Refer to page 61 for details.)

ON

The pixel resolution of the input signal is converted to the same resolution as the LCD panels before being projected. For signals with lower resolutions, gaps in the pixels are automatically interpolated into the picture before it is projected.

This may sometimes cause problems with the quality of the picture.

OFF

The picture signal is projected at its original resolution, with no pixel conversion. The projected picture will be smaller than normal, so adjust the zoom setting or move the projector forwards or backwards to adjust the picture size if necessary.

If set to “OFF”, some features, such as D.ZOOM (digital zoom) or keystone distortion correction will not function.

AUTO SETUP

This item functions in the same way as the AUTO SETUP button on the remote control unit. (page 14)

FRAME LOCK

If the picture’s condition is bad while a RGB moving picture signal is projected, set the FRAME LOCK to

“ON”. Refer to page 61 on compatible RGB signals.

Audio adjustment

Select the items by pressing the F or G buttons on the remote control unit or the projector.

AUDIO

VOLUME

MUTE

20

OFF ON

VOLUME

Press the I or H buttons to adjust the volume of the sound output by the projector’s built-in speakers.

MUTE

Set the MUTE to “ON” pressing the

I or H buttons to turn off the volume of the sound output.

To release muting, set to “OFF” pressing the I or H buttons.

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

Changing the display language

Use the F and G buttons on the projector or remote control unit to select a language, then press the MENU button to accept the setting.

LANGUAGE

ENGLISH

DEUTSCH

FRANÇAIS

ESPAÑOL

ITALIANO

SELECT:[^][@] [{][}]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

43

Option settings

Select the item pressing the F or G buttons on the remote control unit or the projector.

Press the I or H buttons to adjust the selective items. To make the

SHUTTER or WEB PASSWORD

(PT-L780NTU only) functions work, press the ENTER button.

OPTION

SHUTTER

OSD

AUTO KEYSTONE

RGB/YPbPr

RGB2 SELECT

BACK COLOR

FRONT/REAR

DESK/CEILING

LAMP POWER

LAMP RUN TIME

NEXT PAGE @

SELECT:[^][@]

ADJUST:[{][}]

OFF

OFF

RGB

INPUT

BLUE

FRONT

DESK

LOW

ON

ON

YPbPr

OUTPUT

BLACK

REAR

CEILING

HIGH

10 H

ENTER:[ENTER]

ESC:[MENU]

OPTION

PREVIOUS PAGE ^

FAN CONTROL

WEB CONTROL

WEB STANDBY

STANDARD

OFF

OFF

WEB PASSWORD

CONTROL KEY OFF

FUNC1 MUTE

SET ID ALL

AUTO POWER OFF DISABLE

HIGH

ON

ON

ON

KEYSTONE

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

SHUTTER

The shutter function can be used to momentarily turn off the picture and sound from the projector when the projector is not being used for short periods of time, such as during breaks in meetings or when carrying out preparation. The projector uses less power in shutter mode than it does in normal projection mode.

44

OSD

ON

The current input name is displayed in the top-right corner of the screen when the input signal is changed.

OFF

Use this setting when you do not want the current input name to be displayed.

AUTO KEYSTONE

This should normally be set to ON.

ON

During automatic setup, the angle of tilt of the projector is detected and vertical keystone distortion is corrected automatically.

OFF

Use this setting when you do not want automatic keystone correction to be carried out during automatic setup, such as when the screen itself is at an angle.

RGB/YPbPr

This setting is valid when 750p,

HDTV60, HDTV50, 525p, 625i and

525i signals are being input. Select the setting in accordance with the input signal.

The RGB/YPbPr item is displayed when an RGB1 IN, RGB2 IN or

RGB 3 IN connectors has a signal being input.

RGB2 SELECT

This setting is used to select the function of the RGB2 IN/RGB OUT connector.

The selected input source (RGB1 or

RGB3) is output when RGB OUT is selected.

BACK COLOR

This sets the colour which is projected onto the screen when no signal is being input to the projector.

FRONT/REAR

This setting should be changed in accordance with the projector setting-up method.

Set to “FRONT” when using a normal reflective screen with the projector positioned in front of the screen, and set to “REAR” when using a translucent screen with the projector positioned behind the screen.

DESK/CEILING

This setting should be changed in accordance with the projector setting-up method.

Set to “DESK” when setting up the projector on a desk or similar, and set to “CEILING” when suspending the projector from the ceiling using the ceiling bracket which is sold separately.

LAMP POWER

This setting changes the lamp brightness. When set to “LOW”, the luminance of the lamp is reduced, but the projector uses less power, and the operating noise is also reduced.

This can help to extend the lamp’s operating life. If using the projector in small rooms where high luminance is not required, it is recommended that you set the LAMP POWER to “LOW”.

LAMP RUN TIME

This setting displays the usage time for the lamp unit which is currently being used. If the lamp unit is replaced in the way described on page 64, the cumulative usage time for the lamp unit will be reset to zero.

NOTE:

B The lamp’s operating life varies depending on the usage conditions

(such as the LAMP POWER setting and the number of times the power is turned on and off).

FAN CONTROL

If using of this projector at high elevations (above 1 400 m), set the

FAN CONTROL to “HIGH”.

WEB CONTROL

(PT-L780NTU only)

To control the projector with a personal computer by means of a wireless or wired network using an optional wireless or projector LAN card, set WEB CONTROL to “ON”.

To prevent it, set to “OFF”.

WEB STANDBY

(PT-L780NTU only)

To turn on and off the power with a personal computer by means of a wireless or wired network using an optional wireless or projector LAN card, set the WEB STANDBY to

“ON”.

When the WEB STANDBY is set to

“ON”, the cooling fan operates and the power indicator on the projector flashes slowly in red.

45

WEB PASSWORD

(PT-L780NTU only)

You can set the password for controlling the projector with a personal computer by means of a wireless or wired network using an optional wireless or projector LAN card. Use the F or G buttons to change the characters, and use the

I or H buttons to change the character position. When finished, press the ENTER button. The projector comes from the factory without any password.

If password setting is complete, the password will not be displayed on the WEB PASSWORD screen.

When you forget it, set it again from the beginning.

CONTROL KEY

To make the buttons on the projector not function, set the

CONTROL KEY to “OFF”.

To use the buttons on the projector, set to ON. (page 14)

FUNC 1

This assigns a function to the FUNC1 button of the remote control unit .

MUTE

B Functions in the same way as the

MUTE function. (page 43)

KEYSTONE

B Functions in the same way as when “KEYSTONE” is selected from the POSITION menu screen. (page 40)

SET ID

SET ID is used to set projector IDs to control two or more projectors either simultaneously or separately.

46

“ALL”: The projectors can be simultaneously controlled from any remote control unit regardless of their ID settings.

“1”: The projector can be controlled from the remote control unit with its projector ID set to “1”.

“2”: The projector can be controlled from the remote control unit with its projector ID set to “2”.

“3”: The projector can be controlled from the remote control unit with its projector ID set to “3”.

S E T I D

A L L

   

        [

                

1

   

[

                 2    

[

                 3       

NOTE:

SET ID is set to “ALL “ by default.

Hence ID number need not be set when only one projector is used.

If the projectors are given ID numbers, their remote control units must be assigned the same ID numbers, respectively.

If the SET ID s of two or more projectors are set to “ALL”, the user will not be able to control them separately.

The projector can be turned ON/OFF from the remote control unit only if the projector ID is set in the remote control unit. For the details of projector ID setting, see page 21.

AUTO POWER OFF

If any signal is not input into the projector during the time that you set up, the projector will return to standby mode. The auto power off time can be set to, from 15 minutes to 60 minutes, by 5 minutes. If you don't use this feature, set it to “OFF”.

This feature will not function under the following situation.

1) When the NETWORK or SD

CARD is selected (PT-L780NTU only).

2) When using the freeze function.

3) When writing the data in the SD memory card (PT-L780NTU only).

NOTE:

While projector is connected to a personal computer by means of a wireless or wired network using an optional wireless card or projector

LAN card with the WEB STANDBY set to “ON”, the cooling fan operates and the power indicator on the projector flashes slowly in red.

(Refer to page 45)

NETWORK SETUP

(PT-L780NTU only)

You need make adjustment on some items when controlling the projector with a personal computer by means of the wireless or wired network, using an optional wireless card or projector LAN card. Refer to the accessory CD-

ROM for details.

NETWORK

STATUS

WEP

LAN1

KEY1

SELECT:[^][@] 調整:[←][→] ENTER:[ENTER]

ESC:[MENU]

STATUS

This setting is used to adjust the

LAN to control the projector by means of the wireless or wired network.

WEP

This setting is for encrypting data transmitted by means of the wireless network. (This item will not be displayed when an optional projector LAN card is used.)

SD CARD SETUP

(PT-L780NTU only)

The following settings are used when projecting the pictures recorded in the

SD memory card. Refer to the accessory CD-ROM for details.

SD CARD

AUTOPLAY

REPEAT

INTERVAL

OFF ON

1

5 sec

AUTO PLAY

Plays the pictures recorded in the

SD memory card automatically.

REPEAT

This setting is for adjusting the times of the auto play.

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

INTERVAL

This setting is adjusting the interval of the auto play.

47

Lens adjustment

Select an item by pressing the F or G buttons on the remote control unit or the projector.

LENS

ZOOM/FOCUS

LENS SELECT

STANDARD

LENS SELECT

Change the setting in accordance with the type of projection lens (sold separately) by pressing the I or H buttons.

SELECT:[^][@] ENTER:[ENTER]

実行:[ENTER]

ESC:[MENU]

Zoom/Focus adjustment

Press the ENTER button to display the individual adjustment screen.

STANDARD

For standard projection

LONG FOCUS

For long-distance projection

(ET-LE30)

MIDDLE FOCUS

For medium-distance projection

(ET-LE20)

SHORT FOCUS

For short-distance projection

(ET-LE10)

←→ ZOOM

↑↓ FOCUS

Press the I or H buttons to adjust the projected image size.

Press the F or G buttons to adjust the projected image focus.

The projected image focus or zoom can also be adjusted by pressing the FOCUS +/- or ZOOM +/- buttons on the projector. To make fine adjustments to the projected image focus, use the FOCUS +/- buttons.

Projection lens replacement

By replacing the projection lens with a lens that is sold separately, you can change the projection distance.

Removing the lens

#Turn the projection lens anticlockwise until it is in position.

$While pressing the lens release button, turn the projection lens anticlockwise again.

%Remove the projection lens.

Installing the lens

Signal connection Projection

Groove

#Insert the other projection lens (sold separately) as far as it will go, while matching the projection to the groove.

$Turn the projection lens clockwise until a click is heard.

NOTE:

B When replacing a projection lens, make sure that the power is off (the

Power indicator illuminates green).

B Do not touch the signal connection. If any dust or lint gets onto the signal connection, the electrical contact may become poor.

B Do not touch the surface of the lens with your bare hands.

B Store the replaced projection lens away carefully to avoid subjecting it to excessive vibration or shock.

48 49

Projection distance for each projection lens

(sold separately)

Projector position

Top edge of screen

<Units: mm (inch)>

L: Projection distance

SH: Image height

SW: Image width

Screen

L

Bottom edge of screen

ET-LE20 (for medium-distance projection)

Screen size (4:3) Projection distance (L)

Diagonal length

Height (SH)

Width

(SW)

Wide

(LW)

Telephoto

(LT)

1.01 m(40˝) 0.61 m(2´) 0.81 m(2´8˝)

1.27 m(50˝) 0.76 m(2´6˝) 1.02 m(3´4˝)

1.52 m(60˝) 0.91 m(3´) 1.22 m(4´)

1.77 m(70˝) 1.07 m(3´6˝) 1.42 m(4´8˝)

2.03 m(80˝) 1.22 m(4´) 1.63 m(5´4˝)

2.28 m(90˝) 1.37 m(4´6˝) 1.83 m(6´)

2.54 m(100˝) 1.52 m(5´) 2.03 m(6´8˝)

3.81 m(150˝) 2.29 m(7´6˝) 3.05 m(10´)

2.1 m(6´10˝)

2.7 m(8´10˝)

3.2 m(10´5˝)

3.8 m(12´5˝)

4.3 m(14´1˝)

4.9 m(16´)

3.3 m(10´9˝)

4.2 m(13´9˝)

5.0 m(16´4˝)

5.9 m(19´4˝)

6.8 m(22´3˝)

7.7 m(25´3˝)

5.4 m(17´8˝) 8.5 m(27´10˝)

8.2 m(26´10˝) 12.9 m(42´3˝)

5.08 m(200˝) 3.05 m(10´) 4.06 m(13´4˝) 11.0 m(36´10˝) 17.2 m(56´5˝)

6.35 m(250˝) 3.81 m(12´6˝) 5.08 m(16´8˝) 13.8 m(45´3˝) 21.6 m(70´10˝)

7.62 m(300˝) 4.57 m(15´) 6.10 m(20´) 16.5 m(54´1˝) 26.0 m(85´3˝)

ET-LE30 (for long-distance projection)

Screen size (4:3) Projection distance (L)

Diagonal length

Height (SH)

Width

(SW)

Wide

(LW)

Telephoto

(LT)

1.01 m(40˝) 0.61 m(2´) 0.81 m(2´8˝)

1.27 m(50˝) 0.76 m(2´6˝) 1.02 m(3´4˝)

1.52 m(60˝) 0.91 m(3´) 1.22 m(4´)

1.77 m(70˝) 1.07 m(3´6˝) 1.42 m(4´8˝)

2.03 m(80˝) 1.22 m(4´) 1.63 m(5´4˝)

2.28 m(90˝) 1.37 m(4´6˝) 1.83 m(6´)

2.54 m(100˝) 1.52 m(5´) 2.03 m(6´8˝)

3.81 m(150˝) 2.29 m(7´6˝) 3.05 m(10´)

3.4 m(11´1˝)

4.2 m(13´9˝)

5.0 m(16´4˝)

5.8 m(19´)

4.6 m(15´1˝)

5.8 m(19´)

6.9 m(22´7˝)

8.1 m(26´6˝)

6.6 m(21´7˝) 9.2 m(30´2˝)

7.4 m(24´3˝) 10.4 m(34´1˝)

8.2 m(26´10˝) 11.5 m(37´8˝)

12.2 m(40´) 17.3 m(56´9˝)

5.08 m(200˝) 3.05 m(10´) 4.06 m(13´4˝) 16.3 m(53´5˝) 23.0 m(75´5˝)

6.35 m(250˝) 3.81 m(12´6˝) 5.08 m(16´8˝) 20.4 m(66´11˝) 28.7 m(94´1˝)

7.62 m(300˝) 4.57 m(15´) 6.10 m(20´) 24.4 m(80´) 34.5 m(113´2˝)

50

L

Screen

ET-LE10 (for short-distance projection)

Screen size (4:3) Projection distance (L)

Diagonal length

Height (SH)

Width

(SW)

Wide

(LW)

Telephoto

(LT)

1.01 m(40˝) 0.61 m(2´) 0.81 m(2´8˝)

1.27 m(50˝) 0.76 m(2´6˝) 1.02 m(3´4˝)

1.52 m(60˝) 0.91 m(3´) 1.22 m(4´)

1.77 m(70˝) 1.07 m(3´6˝) 1.42 m(4´8˝)

2.03 m(80˝) 1.22 m(4´) 1.63 m(5´4˝)

2.28 m(90˝) 1.37 m(4´6˝) 1.83 m(6´)

2.54 m(100˝) 1.52 m(5´) 2.03 m(6´8˝)

3.81 m(150˝) 2.29 m(7´6˝) 3.05 m(10´)

1.1 m(3´7˝)

1.3 m(4´3˝)

1.6 m(5´2˝)

1.9 m(6´2˝)

2.2 m(7´2˝)

2.4 m(7´10˝)

2.7 m(8´10˝)

4.0 m(13´1˝)

1.3 m(4´3˝)

1.7 m(5´6˝)

2.0 m(6´6˝)

2.4 m(7´10˝)

2.7 m(8´10˝)

3.1 m(10´2˝)

3.5 m(11´5˝)

5.3 m(17´4˝)

5.08 m(200˝) 3.05 m(10´) 4.06 m(13´4˝) 5.4 m(17´8˝) 7.0 m(22´11˝)

6.35 m(250˝) 3.81 m(12´6˝) 5.08 m(16´8˝) 6.7 m(21´11˝) 8.8 m(28´10˝)

7.62 m(300˝) 4.57 m(15´) 6.10 m(20´) 8.1 m(26´6˝) 10.6 m(34´9˝)

51

Setting-up dimensions which are not given in the table can be calculated using the formulas below.

If the screen size (diagonal) is SD (m), then the following formula is used to calculate the projection distance for the wide lens position (LW) and the projection distance for the telephoto lens position (LT).

Model No. of projection lens Aspect ratio Methods of calculation of Projection distance (L) Unit: mm

ET-LE10

(1.3-1.7:1)

4:3

LW=0.027xSD/0.0254-0.0523

LT=0.0355xSD/0.0254-0.0509

16:9

LW

=0.0294xSD/0.254-0.0523

LT

=0.0387xSD/0.0254-0.0509

ET-LE20

(2.6-4.2:1)

4:3

LW=0.0554xSD/0.0254-0.134

LT=0.0871xSD/0.0254-0.136

ET-LE30

(4.0-5.6:1)

16:9

4:3

LW

=0.0604xSD

/0.0254

−0.134

LT

=0.0949xSD

/0.0254

−0.136

LW=0.0809xSD/0.0254+0.104

LT=0.1147xSD/0.0254+0.096

16:9

LW

=0.0881xSD

/0.0254

+0.104

LT

=0.1250xSD

/0.0254

+0.096

Slot cover replacement

When connecting the projector to a personal computer using an optional projector LAN card, replace the slot cover with the accessory projector LAN card slot cover.

Removing the slot cover

$

#

#Remove the hooks from the holes of the projector.

$Lift up the slot cover to remove it.

Installing the slot cover

#Insert one of the hooks of the slot cover (for projector LAN card) into the mounting hole in the projector.

$Insert the other hook of the slot cover into the other mounting hole in the projector.

52

Putting the power cord and remote control unit away

Installing the cable cover

#

Hook1

Remote control unit

(Infrared emitter)

Hook2

#Put the remote control unit into the cable cover with the buttons facing downward to prevent them from being pressed.

$ $Put the power cords and other cords into the cable cover.

%

Velcro

%Put the Velcro through the hole, and tape it to prevent the cords from dropping out.

'

'

(

&Insert the hook 1 of the cable cover into the mounting hole in the projector.

'Push in the hook 2 until it locks into place.

(Tighten the screw by turning it clockwise.

&

Removing the cable cover

$

$

#

%

#Loosen the screw by turning it anticlockwise.

$Release the two hooks at the top of the cable cover.

%Pull the cable cover to the rear to remove it from the projector.

NOTE:

Do not lift up the projector by holding the cable, otherwise the cable cover might come off.

53

Using the cable cover

When installing the projector to the ceiling, the accessory cable cover can be used to cover the terminals or cords after removing the cut-away parts.

#

Use pliers or similar to break the perforated sections of the cutaway parts.

'Tighten the screw by turning it clockwise.

Screw

Perforated sections

$Work the cut-away parts back and forth several times to break the fixing tabs. Smooth off any jagged edges if necessary.

Hook2

Hook1

Fixing tabs Fixing tabs

%Pass the power cord through cutaway part S, and pass the other cables through cut-away part L, and then insert the tabs of the cable cover into the mounting holes in the projector.

&Push hook 2 until it locks into place.

Cut-away part S

Cut-away part L

Refer to page 53 for details on removing the cable cover.

NOTE:

Do not cover the air inlet ports when using the cable cover as stated above.

Do not place any heavy objects on the cable cover to prevent it from being removed.

Do not bend the cables greatly, otherwise it will be difficult to attach the cable cover.

Remove the cable cover when cleaning or replacing the air filter.

54

Using the remote terminal

Using the remote terminal built into this projector, it is possible to operate the projector from an external location from where infrared remote control signals cannot be received, by using a remote control panel.

Pin assignment and control

1

6 9

5

D-Sub 9-pin (female) external appearance

Pin

#

$

%

&

'

(

)

*

+

Signal Name

GND

POWER

INPUT SEL3

INPUT SEL1

INPUT SEL2

ENABLE

Short pin 1 and pin 9 when controlling.

#Power ON/OFF

Pin No.

$

-

#

Lamp

Short

ON

Setting

Open

OFF (standby)

Description

Ground

Power ON

Input signal select3

NC

Input signal select1

Input signal select2

NC

NC

Enables remote terminal control

$Switching the input mode

Pin No.

%

-

#

'

-

#

(

-

#

Input Signal

Open

Open

Open

RGB1

Open

Short

Open

RGB2

Setting

Short

Open

Short

Open

Short

Short

Open

Open

Short Open Open Short

RGB3 VIDEO S-VIDEO DVI

NOTE:

B The POWER, RGB and VIDEO buttons on the remote control unit and projector will not operate when pins 1 and 9 are shorted. RS-232C commands will also be ignored. If the projector is connecting a personal computer using an optional wireless card or LAN card, the “POWER” or

“SWITCH INPUT MODE” will not function.

B Do not short pins. 1, 2, 3, 5, or 6 when pin 9 is open. If this is done, the projector will ignore signals from the remote control unit.

55

Using the SERIAL connector

The serial connector which is on the side connector panel of the projector conforms to the RS-232C interface specification, so that the projector can be controlled by a personal computer which is connected to this connector.

Connection

SERIAL(female)

D-Sub9p (male)

Communication cable

Computer

NOTE:

B Use a proper communication cable which is suitable for the personal computer to connect the serial connector and the personal computer.

Pin layout and signal names for SERIAL connector

Communications settings

Signal level RS-232C

Sync. method

Baud rate

Asynchronous

9600 bps

Parity None

Character length 8 bits

Stop bit

X parameter

S parameter

1 bit

None

None

Basic format

The data sent from the computer to the projector is transmitted in the format shown below.

STX Command : Parameter ETX

Start byte

(02h)

3 bytes

1 byte End byte

1 byte–5 bytes

(03h)

6 9

1 5

D-SUB 9-pin connector seen from outside

56

Pin

No.

Signal name

Contents

#

NC

$

TXD Transmitted data

%

RXD Received data

&

NC

'

GND

(

DSR

)

CTS

Connected internally

*

RTS

+

NC

NOTE:

B The projector can not receive the command for 10 seconds after the lamp is switched on. Wait 10 seconds before sending the command.

B If sending multiple commands, check that a response has been received from the projector for one command before sending the next command.

B When a command which does not require parameters is sent, the colon (:) is not required.

B If an incorrect command is sent from the personal computer, the

“ER401” command will be sent from the projector to the personal computer.

Control commands

The commands which the personal computer can use to control the projector are shown in the following table.

Command

Control

Contents

Remarks

PON

POF

AVL

IIS

Q$S

Power ON

Power OFF

Volume

Input signal selection

Lamp ON condition query

In standby mode, all commands other than the PON command are ignored.

B The PON command is ignored during lamp ON control.

B If a PON command is received while the cooling fan is operating after the lamp has switched off, the lamp is not turned back on again straight away, in order to protect the lamp.

Parameter

000–063(Adjustment value 0–63)

Parameter

VID=VIDEO SVD=S-VIDEO

RG1=RGB1(YP

B

P

R

1) RG2=RGB2(YP

B

P

R

2)

RG3=RGB3 DVI=DVI

NWP=NETWORK (PT-L780NTU only)

SDC=SD CARD (PT-L780NTU only)

Parameter

0 = Standby

1 = Lamp ON control active

2 = Lamp ON

3 = Lamp OFF control active

Cable specifications

(When connected to a personal computer)

At the projector

6

7

4

5

8

9

1

2

3

NC

NC

NC

NC

At the computer

(DTE specifications)

NC

NC

NC

NC

6

7

4

5

8

9

1

2

3

57

Indicators

There are two indicators on the control panel of the projector which give information about the operating condition of the projector. These indicators illuminate or flash to warn you about problems that have occurred inside the projector, so if you notice that one of the indicators is on, turn off the power and check the table below for the cause of the problem.

Indicator display

Problem

Illuminated (red)

(Lamp unit on)

The surrounding temperature or the temperature inside the projector has become unusually high.

TEMP indicator

Flashing (red)

(Lamp unit on)

The temperature inside the projector has become dangerously high, or the temperature has suddenly changed.

Flashing (red)

(Lamp unit off)

The surrounding temperature or the temperature inside the projector has become dangerously high, causing the lamp unit to be automatically shut off.

Possible cause

B The ventilation holes may be covered.

B The ambient temperature in the place of use may be too high.

B The air filter may be blocked.

Remedy

B Uncover the ventilation holes.

B Set up the projector in a place where the temperature is between 0 °C (32 °F) and 40 °C (104 °F) and the humidity is between 20% and 80% (with no condensation). [If you set the

FAN CONTROL to “HIGH” (page 45), set up the projector in a place where the temperature is between 0 °C (32 °F) and 35 °C

(95 °F) and the humidity is between 20% and 80% (with no condensation).]

B Turn off the MAIN POWER switch by following the procedure on page 29, and then clean the air filter (refer to page 62).

LAMP indicator

Indicator display

Illuminated (red)

Problem

It is nearly time to replace the lamp unit.

Possible cause

B Does “REPLACE

LAMP” appear on the screen after the projector is turned on?

Flashing (red)

An abnormality has been detected in the lamp circuit.

B The power may have been turned on straight away after it was turned off.

B There may be an abnormality in the lamp circuit.

Remedy

B This occurs when the operation time for the lamp unit is nearing 1 300 hours. (when

LAMP POWER has been set to

“HIGH”) Ask your dealer or an

Authorised

Service Center to replace the lamp unit.

B Wait for a while until the lamp unit cools down before turning the power back on again.

B Turn off the MAIN

POWER switch by following the procedure given on page 29, and then contact an

Authorised

Service Center.

NOTE:

B Be sure to turn off the MAIN POWER switch by following the procedure given in “Turning off the power” on page 29 before carrying out any of the procedures in the “Remedy” column.

B If the main power turns off after the TEMP indicator starts flashing, it means that an abnormality has occurred. Please contact an Authorised

Service Center so that the necessary repairs can be made.

58 59

About the automatic setup function

If you press the AUTO SETUP button, the items given in the table below will be set automatically. The setting details change according to the signal which is being input. Refer to the table below for details.

Horizontal/ vertical position

Dot clock/ clock phase

Automatic vertical keystone correction

VIDEO/S-VIDEO/

NETWORK/SD CARD

YP

B

P

R

DVI

Dot Clock frequency is 140 MHz or higher

Signal other than above

Yes No

Yes

Yes

Yes

Yes

Yes

NOTE:

B If the edges of the projected picture are indistinct, or if a dark picture is being projected, the automatic setup processing may stop automatically before it is complete. If this happens, project a different picture and then press the AUTO

SETUP button once more, or make the above adjustments manually.

B If you would like to make further adjustments to the picture, use the menu commands which are listed on page 30 and subsequent pages.

60

List of compatible signals

Mode

Display resolution

(dots)* 1

Scanning frequency

H

(kHz)

V

(Hz)

15.734

59.940

Dot clock frequency

(MHz)

NTSC/NTSC4.43/

PAL-M/PAL60

PAL/PAL-N/SECAM

525i

625i

525p

HDTV60

HDTV50

750P

VESA70

VESA85

VGA60

VGA65

VGA72

VGA75

*4

VGA85

SVGA55

SVGA60

SVGA70

SVGA75

SVGA85

MAC16

XGA60

SXGA75

SXGA85

SXGA60+

UXGA60

*4

*4

XGA70

XGA75

XGA85

XGA85i

MXGA70

MXGA75

MXGA85

MAC21

MSXGA60

SXGA60

*4

*4

*4

*4

720 x 480i

720 x 576i

720 x 480i

720 x 576i

640 x 400

640 x 400

640 x 480

640 x 480

640 x 480

640 x 480

640 x 480

800 x 600

800 x 600

800 x 600

800 x 600

800 x 600

832 x 624

1 024 x 768

1 024 x 768

1 024 x 768

1 024 x 768

1 024 x 768i

1 152 x 864

1 152 x 864

15.625

50.000

15.734

59.940

15.625

50.000

720 x 483 31.469

59.940

1 920 x 1 080i 33.750

60.000

1 920 x 1 080i

1 280 x 720

28.125

45.000

31.469

35.000

37.861

72.809

37.500

75.000

43.269

35.156

46.875

53.674

49.725

74.550

48.363

60.004

56.476

60.023

50.000

60.000

31.469

70.086

37.861

85.081

59.940

66.667

85.008

56.250

37.879

60.317

48.077

72.188

75.000

85.061

70.069

75.029

68.678

84.997

35.520

86.952

13.500

13.500

27.000

74.250

74.250

74.250

25.175

31.500

25.175

30.240

31.500

31.500

36.000

36.000

40.000

50.000

49.500

56.250

57.283

65.000

75.000

78.750

94.500

44.897

63.995

71.184

94.200

67.500

74.917

108.000

1 152 x 864

1 152 x 870

76.705

85.038

121.500

68.681

75.062

100.000

1 280 x 960 60.000

60.000

108.000

1 280 x 1 024 63.981

60.020

108.000

1 280 x 1 024 79.977

75.025

135.001

1 280 x 1 024 91.146

85.024

157.500

1 400 x 1 050 63.981

60.020

108.000

1 600 x 1 200 75.000

60.000

162.000

Picture quality* 2

Resizing* 3

A

Format

OK Video/S-Video

OK

OK

OK

OK

OK

OK Video/S-Video

OK

OK

OK

YP

YP

YP

B

B

B

P

P

P

R

R

R

/RGB

/RGB

/RGB

YP

B

P

R

/RGB

OK

OK

OK

OK

OK

OK

OK

OK

YP

B

P

R

/RGB

YP

B

P

R

/RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

RGB

A

A

A

A

AA

AA

A

A

A

B

A

B

A

AA

AA

AA

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

*1 The “i” appearing after the resolution indicates an interlaced signal.

*2 The following symbols are used to indicate picture quality.

AA Maximum picture quality can be obtained.

A Signals are converted by the image processing circuit before picture is projected

B Some loss of data occurs to make projection easier.

*3 Signals with “OK” in the Resizing column can be set using the RESIZING command in the PICTURE menu. (Refer to page 42.)

*4 Signals that are compatible with the FRAME LOCK function. (page 42.)

DVI signal is compatible only with VGA60, SVGA60, XGA60 and SXGA60.

61

Cleaning and replacing the air filter

If the air filter becomes clogged with dust, the internal temperature of the projector will rise, the TEMP indicator will flash and the projector power will turn off. The air filter should be cleaned every 100 hours of use, depending on the location where the projector is being used.

& Clean the air filter.

Use a vacuum cleaner to clean off any accumulated dust.

Cleaning procedure

# Turn off the MAIN POWER

switch and disconnect the power cord plug from the mains socket.

Turn off the MAIN POWER switch according to the procedure given in “Turning off the power” on page 29 before disconnecting the plug from the mains socket.

$ Gently turn the projector

upside down.

NOTE:

B Place the projector on top of a soft cloth so that it will not become scratched.

% Remove the air filter.

Put your fingernails under the air filter and pull the air filter out of the projector.

NOTE:

B Be careful not to let the air filter get sucked into the vacuum cleaner.

' Install the air filter.

NOTE:

B Be sure to install the air filter cover before using the projector.

If the projector is used without the air filter cover installed, dust and other foreign particles will be drawn into the projector, and malfunctions will result.

B If the dust cannot be removed by cleaning, it is time to replace the air filter. Please consult your dealer. Furthermore, if the lamp unit is being replaced, replace the air filter at this time also.

62

Air filter

Replacing the lamp unit

Warning

When replacing the lamp, allow it to cool for at least one hour before handling it.

B The lamp cover gets very hot, and contact with it can cause burns.

Notes on replacing the lamp unit

B The light generating lamp is made of glass, so dropping it or allowing it to hit hard objects may cause it to burst. Be careful when handling the lamp.

B After having removed the old lamp, carelessly discarding it can cause the lamp to burst. Dispose of the lamp with the same care that would be taken with a fluorescent light.

B A Phillips screwdriver is necessary for removing the lamp unit. Make sure that your hands are not slippery when using the screwdriver.

NOTE:

B The projector is not supplied with a replacement lamp unit. Please ask your dealer for details. Lamp unit product no.: ET-LA780

CAUTION:

B Do not use any lamp unit other than the one with the product number indicated above.

Lamp unit replacement period

The lamp is a consumable product.

Even when the full life of the bulb has not been exhausted, the brightness of the light will gradually decline. Therefore periodic replacement of the lamp is necessary.

The intended lamp replacement interval is 1 500 hours, but it is possible that the lamp may need to be replaced earlier due to variables such as a particular lamp's characteristics, usage conditions and the installation environment.

Early preparation for lamp replacement is encouraged.

A lamp that has exceeded 1 500 hours of use has a much greater chance of exploding. In order to prevent the lamp from exploding, the lamp will be automatically shut off when 1 500 hours of use have been reached.

NOTE:

B The usage hours explained above are for use when the HIGH setting has been selected for

LAMP POWER in the OPTION menu. If the LOW setting is selected, the brightness of the lamp will be less and life of the lamp can be extended.

B While 1 500 hours is the intended replacement interval, it is not a period of time covered by warranty.

63

On-screen display Lamp indicator warning light

More than 1 300 hours

More than 1 500 hours

Displayed for 30 seconds. Pressing any button will clear the display.

This display cannot be cleared at all, no matter which button is pressed.

The projector will enter

Standby Mode and the red indicator lamp will illuminate.

Lamp unit replacement procedure

NOTE:

B If the lamp usage time has passed 1 500 hours (when LAMP POWER has been set to “HIGH”), the projector will switch to standby mode after approximately 10 minutes of operation. The steps ) to

.

on the next page should thus be completed within 10 minutes.

# Turn off the MAIN POWER

switch according to the procedure given in “Turning off the power” on page 29, and then disconnect the power cord plug from the mains socket and check that the area around the lamp unit has cooled down.

$ Use a Phillips screwdriver to

turn the air outlet port fixing screws at the back of the projector, and then open the air outlet port.

Air outlet port

% Use a Phillips screwdriver to loosen

the two lamp unit fixing screws until the screws turn freely. Then hold the handle of the lamp unit and gently pull it out from the projector.

Lamp unit fixing screws

Handle

& Insert the new lamp unit while

making sure that the direction of insertion is correct, and then use a Phillips screwdriver to securely tighten the lamp unit fixing screws.

Air outlet port fixing screws

64

' Close the air outlet port, and

then use a Phillips screwdriver to securely tighten the air outlet port fixing screws.

NOTE:

B Be sure to install the lamp unit and the air outlet port securely. If they are not securely installed, it may cause the protection circuit to operate so that the power cannot be turned on.

( Insert the power cord plug into

the wall outlet and then press the MAIN POWER switch.

NOTE:

B If the POWER indicator on the projector does not illuminate red when the MAIN POWER switch is turned on, turn the MAIN POWER switch off again and check that the lamp unit and the air outlet port are securely installed. Then turn the MAIN POWER switch back on.

) Press the POWER button so

that a picture is projected onto the screen.

* Press the MENU button to

display the MENU screen, and select “OPTION” by pressing

OPTION

SHUTTER

OSD

AUTO KEYSTONE

RGB/YPbPr

RGB2 SELECT

BACK COLOR

FRONT/REAR

DESK/CEILING

LAMP POWER

LAMP RUN TIME

NEXT PAGE @

SELECT:[{][}]

ADJUST:[{][}]

OFF

OFF

RGB

INPUT

BLUE

FRONT

DESK

LOW

ON

ON

YPbPr

OUTPUT

BLACK

REAR

CEILING

HIGH

1820 H

ENTER:[ENTER]

ESC:[MENU]

+ Press the ENTER button and

select the “LAMP RUN TIME” by

pressing the F or G buttons.

OPTION

SHUTTER

OSD

AUTO KEYSTONE

RGB/YPbPr

RGB2 SELECT

BACK COLOR

FRONT/REAR

DESK/CEILING

LAMP POWER

LAMP RUN TIME

NEXT PAGE @

OFF

OFF

RGB

INPUT

BLUE

FRONT

DESK

LOW

ON

ON

YPbPr

OUTPUT

BLACK

REAR

CEILING

HIGH

1820 H

SELECT:[^][@]

ADJUST:[{][}]

ENTER:[ENTER]

ESC:[MENU]

, Press and hold the ENTER

button for approximately 3 seconds.

Lamp Time Reset

OK

Power OFF

CANCEL

The “Lamp Time Reset” will be displayed.

-

Select “OK” by pressing the

ENTER button.

NOTE:

B If “CANCEL” is selected in step

-

, the operation for resetting the lamp time will be cancelled.

.

Turn off the power.

This will reset the cumulative usage time for the lamp unit to zero.

Refer to steps % and & on page

29 for details on how to turn off the power.

65

Before calling for service

Before calling for service, check the following points.

Problem

Power does not turn on.

No picture appears.

The picture is fuzzy.

COLOR is too light or

TINT is poor.

No sound can be heard.

Possible cause

B The power cord may not be connected.

B The MAIN POWER switch is turned off.

B The main power supply is not being supplied to the wall outlet.

B TEMP indicator is illuminated or flashing. (Refer to page

58.)

B LAMP indicator is illuminated or flashing. (Refer to page

59.)

B The lamp unit cover has not been securely installed.

B The video signal input source may not be connected properly.

B The input selection setting may not be correct. (Refer to page 28.)

B The BRIGHT adjustment setting may be at the minimum possible setting. (Refer to page 37.)

B The shutter function may be in use. (Refer to page 44.)

B The lens cover may still be attached to the lens.

B The lens focus may not have been set correctly. (Refer to pages 29 and 48.)

B The projector may not be at the correct distance from the screen. (Refer to pages 27 and 50.)

B The lens may be dirty.

B The projector may be tilted too much. (Refer to page 26.)

B COLOR or TINT adjustment may be incorrect. (Refer to page 37.)

B The input source which is connected to the projector may not be adjusted correctly.

B The audio signal source may not be connected properly.

B The volume adjustment may be at the lowest possible setting. (Refer to pages 15 and 43.)

B A cable may be connected to the AUDIO OUT jack.

B The MUTE function may be active (page 43.)

66

Problem

The remote control unit does not operate.

The buttons on the projector do not function.

The picture does not display correctly.

Picture from computer does not appear.

Possible cause

B The batteries may be weak.

B The batteries may not be inserted correctly. (Refer to page 20.)

B The remote control signal receptor on the projector may be obstructed. (Refer to page 20.)

B The remote control unit may be out of the operation range. (Refer to page 20.)

B Press and hold the Power button on the remote control unit or the projector for more than 5 seconds to turn the power off and back on again. At this time, the projector will turn on and go to the standby condition.

B The CONTROL KEY may be set to “OFF”. (Refer to page 46.)

In order to set the CONTROL KEY to “ON” without using the remote control unit, keep holding down the ENTER button on the projector and press the MENU button for more than 2 seconds. It will then be turned ON.

B Press and hold the Power button on the remote control unit or the projector for more than 5 seconds to turn the power off and back on again. At this time, the projector will turn on and go to the standby condition.

B The signal format (TV system) may not be set correctly.

(Refer to page 37.)

B There may be a problem with the video tape or other signal source.

B A signal which is not compatible with the projector may be being input. (Refer to page 61.)

B If you select SXGA60 or SXGA60+ type RGB signals, the pictures may not be projected correctly. If this happens, press the AUTO SETUP button.

B The cable may be too long.

B The external video output for the laptop computer may not be set correctly.

(You may be able to change the external output settings by pressing the [Fn]+[F3] or [Fn]+[F10] keys simultaneously. The actual method varies depending on the type of computer, so refer to the documentation provided with your computer for further details.)

B If an RGB input indicator (Refer to page 14) is turned off, the video signals may not be output from the computer.

B RGB2 SELECT in the OPTION menu is set to OUTPUT when the signals are input to RGB2 IN / RGB OUT connector. (Refer to page 44.)

67

Specifications

Power supply:

Power consumption:

Lamp:

Luminosity:

Scanning frequency(for RGB signals):

Horizontal scanning frequency:

100 V–240 V ~, 50 Hz/60 Hz

380 W (During standby (when fan is stopped):

Approx. 3.5 W)

[When the WEB STANDBY is set to “ON”:

Approx. 43 W (page 45)]

4.5 A–2.0 A Amps:

LCD panel:

Panel size (diagonal):

Aspect ratio:

Micro lens array:

Display method:

Drive method:

Pixels:

1.0 type (25.4 mm)

4:3 (16:9 compatible)

Available

3 transparent LCD panels (RGB)

Active matrix method

786 432 (1 024 x 768) x 3 panels

Lens: Manual zoom (1 - 1.3) / focus lens

F 1.7 - 2.1, f 40.7 mm - 52.8 mm

UHM lamp (270 W)

3 200 lm/ANSI

Vertical scanning frequency:

Dot clock frequency:

YP

B

P

R signals:

15 kHz–91 kHz

50 Hz–87 Hz

Less than 140 MHz

Color system:

525i (480i), 625i, 525p (480p), 750p (720p),

HDTV60 (1 080i/60), HDTV50 (1 080i/50)

7 (NTSC/NTSC 4.43/PAL/PAL-M/PAL-

N/PAL60/SECAM)

Projection size:

Throw distance:

Optical axis shift:

Screen aspect ratio:

Installation:

Speaker:

Max. usable volume output:

Connectors

DVI-D IN connector:

RGB IN/OUT:

1 016 mm - 7 620 mm (40˝ - 300˝)

1.6 m - 16.0 m (5´2˝ - 52´5˝)

10:0 (fixed)

4:3

Front/Rear/Ceiling/Desk (Menu selection method)

4 cm x 3 cm oval x 2

2 W

Single-line DVI-D 24 pin

Dual-line D-SUB HD 15-pin (female)

(One-line is available for input and output)

Single-line BNCX5

During YP

B

P

R input/output:

Y:

P

B

,P

R

:

During RGB input/output:

R.G.B.:

G.SYNC:

HD/SYNC:

VD:

1.0 V [p-p], 75

0.7 V [p-p], 75

0.7 V [p-p], 75

1.0 V [p-p], 75

TTL high impedance, automatic plus/minus polarity compatible

TTL high impedance, automatic plus/minus polarity compatible

68

AUDIO IN (for RGB):

VIDEO IN:

S-VIDEO IN:

AUDIO IN (for S-VIDEO/VIDEO):

AUDIO OUT:

Serial connector:

Cabinet:Moulded plastic (ABS/PC)

Dimensions:

Width:

Height:

Length:

Weight:

Operating environment:

Temperature:

Humidity:

Certifications:

<Remote control unit>

Power supply:

Operating range:

Weight:

Dimensions:

Width:

Length:

Height:

<Options>

Ceiling bracket

Ceiling mount bracket

(for low ceilings)

Wireless mouse receiver

Wide conversion lens

Wireless card

LAN card

Projection lens

Single-line 0.5 V [rms] M3 jack (Stereo MINI)

Single-line, RCA pin jack

1.0 V [p-p], 75

Single-line, Mini DIN 4-pin

Y 1.0 V [p-p], C 0.286 V [p-p], 75

0.5 V [rms] RCA pin jack x 2 (L-R)

Single-line 0.5 V [rms] M3 jack (Stereo MINI)

(Monitor output/stereo compatible) 0 V [rms] -

1.0 V [rms] (variable)

D-sub 9p (female) RS-232C compatible

290 mm (11-13/32˝)

137 mm (5-3/8˝)

406 mm (15-31/32˝) (without lens cover)

5.9 kg (13.0 lbs)

0 °C–40 °C (32 °F–104 °F)

[When the FAN CONTROL is set to “HIGH”

(page 45); 0 °C–35 °C (32 °F–95 °F)]

20%–80% (no condensation)

UL60950

FCC class B

3 V DC (AAA battery x2)

Approx. 7 m (23´) (when operated directly in front of signal receptor)

108 g (3.8 ozs.) (including batteries)

33 mm (1-9/32˝)

168 mm (6-19/32˝)

40 mm (1-9/16˝)

ET-PK780

ET-PK780S

ET-RMRC1

ET-LEC701

ET-CDWL1U

ET-CDLAN1

ET-LE10 (for a short-distance projection)

ET-LE20 (for a medium-distance projection)

ET-LE30 (for a long-distance projection)

69

Dimensions

<Units: mm (inch)>

Trademark acknowledgements

B The SD logo is a trademark.

B Windows is a trademark or registered trademark of Microsoft Corporation in the United States of America and other countries.

B VGA and XGA are trademarks of International Business Machines

Corporation.

B Macintosh is a registered trademark of Apple Computer, Inc.

B S-VGA is a registered trademark of the Video Electronics Standards

Association.

B Windows is a registered trademark of Microsoft Corporation.

All other trademarks are the property of the various trademark owners.

25(31/32)

290(11-13/32)

70 71

NOTES IMPORTANTES

CONCERNANT LA SÉCURITÉ

AVERTISSEMENT:

POUR REDUIRE LES RISQUES DE FEU OU DE CHOC

ÉLECTRIQUE, NE PAS EXPOSER CE PRODUIT À L’EAU

OU À L’HUMIDITÉ

Alimentation: Ce projecteur LCD est conçu pour fonctionner sur secteur de 100 V - 240 V, 50 Hz/60 Hz seulement.

ATTENTION: Le cordon d’alimentation secteur fourni avec le projecteur peut être utilisé uniquement pour une alimentation électrique de 125 V, 10 A maximum. Si on veut l’utiliser avec une tension ou un courant plus forts, on doit se procurer un autre cordon d’alimentation de 250 V. Si on utilise le cordon fourni sous ces conditions, risque de provoquer un incendie.

Le symbole de la flèche en forme d’éclair, dans un triangle, avertit l’usager de la présence de “tensions dangereuses” à l’intérieur du produit qui peuvent être de force suffisante pour constituer un risque de choc électrique aux personnes.

Le point d’exclamation dans un triangle avertit l’usager de la présence d’instructions importantes concernant l’utilisation et l’entretien (réparation) dans la littérature accompagnant le produit.

72

ATTENTION: Cet appareil est équipé d’une fiche de courant à trois broches avec mise à la terre. Ne pas retirer la broche de mise à la masse de la fiche.

Ne pas retirer

Cette fiche ne pourra être utilisée que dans une prise avec mise à la terre. Ceci est une précaution sécuritaire. S’il est impossible d’insérer la fiche dans la prise, s’adresser à un

électricien. Ne pas annuler la protection de la fiche à mise à la terre.

Précautions de sécurité

AVERTISSEMENT

En cas de problème (pas d’image ou de son), ou si le projecteur dégage de la fumée ou une odeur étrange, éteindre l’appareil et débrancher immédiatement la fiche d’alimentation de la prise de courant.

B Ne pas continuer d’utiliser le projecteur dans ces cas, autrement cela peut entraîner un incendie ou des chocs électriques.

B Après s’être assuré que de la fumée ne se dégage plus, s’adresser à un centre technique agréé et demander que les réparations nécessaires soient faites.

B Le fait de réparer le projecteur soi-même est très dangereux, et ne doit jamais être fait.

Ne pas installer ce projecteur dans un endroit qui n’est pas assez résistant pour supporter le poids du projecteur.

B Si l’emplacement d’installation n’est pas assez résistant, le projecteur risque de tomber et causer de graves blessures et (ou) des dommages.

Demander à un technicien qualifié d’installer le projecteur par exemple s’il est installé au plafond.

B Si l’installation n’est pas faite correctement, cela peut entraîner des blessures ou des chocs électriques.

Si de l’eau ou des objets étrangers entrent dans le projecteur, si le projecteur tombe, ou si le boîtier est endommagé, éteindre l’appareil et débrancher immédiatement la fiche d’alimentation de la prise de courant.

B Si l’on continue d’utiliser le projecteur dans cette condition, cela peut entraîner un incendie ou des chocs électriques.

B S’adresser à un centre technique agréé pour que les réparations nécessaires puissent être faites.

Ne pas surcharger la prise de courant.

B Si l’alimentation est surchargée (par exemple, par l’utilisation de trop d’adaptateurs), cela risque de faire surchauffer le projecteur et peut entraîner un incendie.

Ne pas retirer le capot ou le modifier.

B Des hautes tensions qui peuvent causer de graves blessures sont présentes à l’intérieur du projecteur.

B Pour toute inspection, réglage ou réparation, s’adresser à un centre technique agréé.

73

Nettoyer la fiche du cordon d’alimentation régulièrement afin d’éviter toute accumulation de poussière.

B Si de la poussière s’accumule sur la fiche du cordon d’alimentation, l’humidité peut endommager l’isolant et entraîner un incendie. Débrancher le cordon d’alimentation de la prise de courant et l’essuyer avec un chiffon sec.

B Si le projecteur n’est pas utilisé pendant une période prolongée, débrancher le cordon d’alimentation de la prise de courant.

Faire attention à ne pas endommager le cordon d’alimentation.

B Ne pas endommager le cordon d’alimentation, ne pas le modifier, ne pas placer sous des objets lourds, ne pas le chauffer, ne pas le placer près d’objets chauffants, ne pas le tordre, ne pas le plier ou le tirer excessivement et ne pas le rouler en boule.

B Si le cordon d’alimentation est endommagé, cela peut entraîner un incendie et des chocs électriques.

B Si le cordon d’alimentation est endommagé, le faire réparer par un centre technique agréé.

Ne pas manipuler le cordon d’alimentation avec les mains mouillées.

B Cela peut entraîner des chocs électriques.

Brancher la fiche du cordon d’alimentation fermement dans la prise de courant.

B Si la fiche n’est pas complètement insérée, cela peut entraîner des chocs

électriques ou la faire surchauffer.

B Si la fiche est endommagée ou la plaque de la prise est desserrée, elles ne devraient pas être utilisées.

Ne pas placer le projecteur sur des surfaces instables.

B Si le projecteur est placé sur une surface qui est inclinée ou instable, il risque de tomber ou de se renverser et cela peut causer des blessures ou des dommages.

Ne pas placer le projecteur dans l’eau ou ne pas le laisser se mouiller.

B Sinon cela peut causer un incendie ou des chocs électriques.

Ne pas placer des récipients de liquide sur le projecteur.

B Si de l’eau se renverse sur le projecteur, s’adresser à un centre technique agréé.

B Si de l’eau entre à l’intérieur du projecteur, entrer en contact avec un centre technique agréé.

Ne pas mettre d’objets étrangers dans le projecteur.

B Ne pas insérer d’objets métalliques ou inflammables dans les orifices de ventilation ou les faire tomber sur le projecteur, car cela peut causer un incendie ou des chocs électriques.

74

Garder la télécommande hors de portée des enfants, et ne pas regarder directement dans le rayon laser; ne pas pointer le rayon vers d’autres personnes.

B Si l’on pointe directement vers les yeux le rayon laser émis par la télécommande, ceci risque d’endommager les yeux.

Veiller à ce que les bornes + et - des piles n’entrent pas en contact avec des objets métalliques tels que des colliers ou des épingles à cheveux.

B Sinon, les piles risqueront de fuir, de surchauffer, d’exploser ou de prendre feu.

B Ranger les piles dans un sac en plastique, et ne pas les ranger à proximité d’objets métalliques.

Pendant un orage, ne pas toucher le projecteur ou le câble.

B Il y a risque d’électrocution.

Ne pas utiliser l’appareil dans un bain ou une douche.

BIl y a risque d’incendie ou d’électrocution.

Ne pas regarder directement dans la lentille pendant que le projecteur fonctionne.

B Une lumière intense est émise par la lentille du projecteur. Si l’on regarde directement dans cette lumière, elle risque de causer des blessures et de graves lésions aux yeux.

Ne pas placer ses mains ou autres objets près de la sortie d’air.

B De l’air chaud sort par l’ouverture de sortie d’air. Ne pas placer les mains ou la figure, ou d’autres objets qui ne peuvent résister à la chaleur près de cette sortie d’air, sinon cela peut causer des blessures ou des dommages.

Lors du remplacement de la lampe, la laisser refroidir pendant au moins une heure avant de la manipuler.

B Le couvercle de la lampe devient très chaud, et on risque de se brûler si on le touche.

Avant de remplacer la lampe, veiller à débrancher le cordon d’alimentation de la prise de courant.

B Il y a risque d’électrocution ou d’explosion.

Garder la carte mémoire SD hors de portée des enfants. (PT-L780NTU seulement)

B En cas d’absorption de la carte SD, consulter immédiatement un médecin.

Attention

Ne pas obstruer les orifices d’entrée et de sortie d’air.

B Cela risque de faire surchauffer le projecteur, et causer un incendie ou endommager le projecteur.

Ne pas installer le projecteur dans des endroits humides ou poussiéreux ou dans des endroits où le projecteur peut entrer en contact avec de la fumée ou la vapeur.

B L’utilisation du projecteur dans de telles conditions peut causer un incendie ou des chocs électriques.

75

Pour débrancher le cordon d’alimentation, tenir la fiche et non pas le cordon.

B Si le cordon d’alimentation est tiré, le cordon sera endommagé et cela peut causer un incendie, des courts-circuits ou des chocs électriques sérieux.

Débrancher toujours tous les câbles avant de déplacer le projecteur.

B Le fait de déplacer le projecteur avec des câbles branchés peut endommager les câbles, ce qui pourraient causer un incendie ou des chocs électriques.

Ne pas placer d’objets lourds sur le projecteur.

B Cela peut déséquilibrer le projecteur et le faire tomber, ce qui peut entraîner des dommages ou des blessures.

Ne pas court-circuiter, chauffer ou démonter les piles, et ne pas les mettre dans l’eau ou dans le feu.

B Sinon, les piles risqueront de surchauffer, de fuir, d’exploser ou de prendre feu, et donc de causer des brûlures ou d’autres blessures.

Lorsqu’on insère les piles, veiller à ce que les polarités (+ et -) soient bien respectées.

B Si l’on insère les piles incorrectement, elles risqueront d’exploser ou de fuir, ce qui peut causer un incendie, des blessures ou une contamination du logement des piles et de la zone environnante.

Utiliser uniquement les piles spécifiées.

B Si l’on utilise des piles incorrectes, elles risqueront d’exploser ou de fuir, ce qui peut causer un incendie, des blessures ou une contamination du logement des piles et de la zone environnante.

Ne pas mélanger des piles usées et des piles neuves.

B Si l’on insère les piles incorrectement, elles risqueront d’exploser ou de fuir, ce qui peut causer un incendie, des blessures ou une contamination du logement des piles et de la zone environnante.

Ne pas peser de tout son poids sur ce projecteur.

B On risque de tomber ou de casser l’appareil, ce qui peut causer des blessures.

B Veiller tout particulièrement à ce que des enfants ne montent pas sur l’appareil.

Débrancher la fiche du cordon d’alimentation de la prise de courant comme mesure de sécurité avant d’effectuer tout nettoyage.

B Sinon cela peut causer des chocs électriques.

Demander à un centre technique agréé de nettoyer l’intérieur du projecteur au moins une fois par an.

B S’il n’est pas nettoyé et que la poussière s’accumule à l’intérieur du projecteur, cela peut causer un incendie ou des problèmes de fonctionnement.

B Il est recommandé de nettoyer l’intérieur du projecteur avant que la saison humide n’arrive. Demander au centre technique agréé plus proche de nettoyer le projecteur lorsque cela est requis. Se renseigner auprès du centre technique agréé pour le coût du nettoyage.

76

Nous faisons tous les efforts possibles afin de préserver l’environnement. Prière d’apporter l’appareil, s’il n’est pas réparable, à votre revendeur ou à un centre de recyclage.

Précautions de manipulation

Précautions à prendre lors du déplacement du projecteur

Veiller à bien mettre le capuchon d’objectif en place avant de déplacer le projecteur.

La lentille de projection est extrêmement sensible aux vibrations et aux chocs.

Veiller à ne pas la soumettre à des vibrations ou à des chocs excessifs lors du déplacement du projecteur.

Avertissements concernant l’installation

Toujours observer les points suivants lors de l’installation du projecteur.

Éviter de l’installer dans les endroits sujets à des vibrations ou à des chocs.

Si le projecteur est installé dans les endroits sujets à de fortes vibrations, comme près d’un moteur, ou s’il est installé à l’intérieur d’un véhicule ou à bord d’un bateau, le projecteur peut être soumis à une vibration ou à des chocs qui peuvent endommager les pièces internes et causer des mauvais fonctionnements ou des accidents. Dès lors, installer le projecteur dans un endroit qui n’est pas soumis à des vibrations ou des chocs.

Ne pas installer le projecteur près de lignes d’alimentation électrique à haute tension ou de moteurs.

Le projecteur peut être sujet à une interférence électromagnétique s’il est installé près de lignes d’alimentation électrique à haute tension ou de moteurs.

Si le projecteur est installé au plafond, demander à un technicien qualifié de faire tous les travaux d’installation.

Si le projecteur doit être suspendu au plafond, il faut acheter le kit d’installation séparé (numéro de modèle: ET-PK780). De plus, tous les travaux d’installation ne devraient être faits que par un technicien qualifié.

Si l’on utilise ce projecteur à un endroit élevé (au-dessus de 1 400 m),

régler le VENTILATEUR à HAUTE. (Se référer à la page 45.)

Sinon, des anomalies pourront se produire.

Notes sur l’utilisation

Afin d’obtenir la meilleure qualité d’image

Si la lumière extérieure ou la lumière des lampes intérieures brille sur l’écran, les images projetées n’auront pas un bon contraste. Tirer les rideaux ou les stores de toutes les fenêtres et éteindre toutes les lumières fluorescentes près de l’écran pour empêcher la réflexion.

Ne pas toucher aux surfaces de la lentille avec les mains nues.

77

Si la surface de la lentille est salie par des empreintes digitales ou autre, ceci sera agrandi et projeté sur l’écran. D’ailleurs, lorsque le projecteur n’est pas utilisé, rétracter la lentille, puis la couvrir à l’aide du capuchon d’objectif fourni.

À propos de l’écran

Si l’écran utilisé est sale, endommagé ou décoloré, des projections de bonne qualité ne peuvent pas être obtenues. N’appliquer aucune substance volatile à l’écran et ne pas le laisser se salir ou s’endommager.

A propos de la lampe

Il est possible qu’il faille remplacer la lampe plus tôt en raison de facteurs variables tels que des caractéristiques de la lampe, des conditions d’utilisation et un environnement d’installation particuliers, en particulier si elle est utilisée de façon continue pendant plus de 10 heures.

A propos de la carte mémoire SD (PT-L780NTU seulement)

L’électricité statique dégagée par le corps humain peut endommager la carte mémoire SD. Afin d’empêcher cela, toucher un objet métallique proche comme un châssis de fenêtre en aluminium ou une poignée de porte pour décharger l’électricité statique du corps.

A propos de la fente à carte (PT-L780NTU seulement)

S’assurer qu’aucun corps étranger ne se trouve à l’intérieur de la fente lors de l’insertion de la carte mémoire SD ou d’une carte sans fil en option, sinon, cela peut endommager la carte et la fente.

Avant de faire le nettoyage et l’entretien, s’assurer de débrancher la fiche du cordon d’alimentation de la prise de courant.

Essuyer le boîtier avec un tissu doux et sec.

Si le boîtier est très sale, imbiber le chiffon dans de l’eau avec un peu de détergent neutre, bien essorer le chiffon, puis essuyer le boîtier. Après le nettoyage, sécher le boîtier à l’aide d’un chiffon sec.

Si un chiffon traité chimiquement est utilisé, lire les directives fournies avec le chiffon avant de l’utiliser.

Ne pas essuyer la lentille avec un chiffon poussiéreux ou pelucheux.

Si de la poussière ou de la peluche se dépose sur la lentille, elle sera agrandie et projetée sur l’écran. Utiliser une poire à air pour nettoyer toute poussière et peluche de sur la surface de la lentille, ou utiliser un chiffon doux pour retirer toute poussière ou peluche.

78

Remplacement du bloc de lampe

AVERTISSEMENT

Lors du remplacement de la lampe, la laisser refroidir pendant au moins une heure avant de la manipuler.

B Le couvercle de la lampe devient très chaud, et on risque de se brûler si on le touche.

Notes sur le remplacement du bloc de lampe

B Faire très attention en manipulant le bloc de lampe retiré, car il contient du gaz sous haute pression et peut facilement s’endommager s’il est cogné contre des objets durs ou s’il tombe.

B La lampe produisant la lumière est en verre; elle risque donc d’éclater si on la laisse tomber ou si elle heurte des objets durs. Faire bien attention en manipulant la lampe.

B La lampe usagée qu’on a retirée risque d’éclater si on la jette sans prendre de précautions. Jeter la lampe de la même manière qu’une lampe fluorescente.

REMARQUE:

B Le projecteur n’est pas fourni avec un bloc de lampe de rechange. Demander les détails au revendeur.Numéro de produit du bloc de lampe: ET-LA780

ATTENTION:

B Ne pas utiliser un bloc de lampe avec un numéro de pièce autre que celui indiqué ci-dessus.

Période de remplacement du bloc de lampe

La lampe est un produit qui doit être remplacé. Même si la durée de vie complète de l’ampoule n’est pas encore épuisée, la luminosité de la lampe diminuera progressivement. Il faut donc remplacer périodiquement la lampe.

L’intervalle de remplacement de la lampe prévu est de 1 500 heures; il est toutefois possible qu’il faille remplacer la lampe avant ce délai en raison d’éléments variables tels que les caractéristiques particulières de la lampe, les conditions d’utilisation et l’environnement d’installation. Il est recommandé de toujours avoir un bloc de lampe de rechange prêt à l’emploi. Une lampe qui a dépassé la limite de 1 500 heures d’utilisation risque beaucoup plus d’exploser.

Afin d’éviter que la lampe explose, celle-ci est éteinte automatiquement lorsque la limite de 1 500 heures d’utilisation est atteinte.

REMARQUE:

B Les heures d’utilisation expliquées ci-dessus concernent l’utilisation lorsque le réglage HAUTE a été sélectionné pour PUIS LAMPE dans le menu OPTION. Si le réglage FROIDE est sélectionné, la luminosité de la lampe sera moindre et la durée de vie de la lampe sera allongée.

B Bien que le délai de 1 500 heures soit l’intervalle de remplacement prévu, l’obtention de cette durée n’est pas couverte par la garantie.

79

Affichage à l’écran Témoin d’alarme de l’indicateur de la lampe

Plus de 1 300 heures

Plus de 1 500 heures

Affiché pendant 30 secondes. L’affichage disparaît si l’on appuie sur n’importe quelle touche.

L’affichage ne peut pas

être effacé, quelle que soit la touche sur laquelle on appuie.

Le projecteur passe en mode d’attente et l’indicateur rouge s’allume.

Méthode de remplacement du bloc de lampe

REMARQUE:

B Si le temps d’utilisation de la lampe a dépassé 1 500 heures (lorsque

PUIS LAMPE a été mis sur “HAUTE”), le projecteur passe en mode d’attente après environ dix minutes de fonctionnement. Dès lors, faire les

étapes ) à . à la page suivante dans les 10 minutes.

# Mettre hors circuit

l’interrupteur d’alimentation principale (MAIN POWER) suivant la méthode donnée dans “Mise hors circuit de l’alimentation” à la page 29, puis débrancher la fiche du cordon d’alimentation de la prise de courant et vérifier que les pièces autour du bloc de lampe se sont refroidies.

% Utiliser un tournevis Phillips

pour desserrer les deux vis de fixation du bloc de lampe jusqu’à ce que les vis tournent librement.

Tenir la poignée du bloc de lampe et tirer doucement pour le sortir du projecteur.

Vis de fixation du bloc de lampe

$ Utiliser un tournevis pour faire

tourner les vis de fixation de la sortie d’air à l’arrière du projecteur et ouvrir la sortie d’air.

Sortie d’air

Poignée

& Insérer le nouveau bloc de

lampe tout en s’assurant que la direction de l’insertion est correcte, puis utiliser un tournevis Phillips pour resserrer fermement les vis de fixation du bloc de lampe.

Vis de fixation de la sortie d’air

80

' Refermer la sortie d’air, puis

utiliser un tournevis Phillips pour bien resserrer les vis de fixation de la sortie d’air.

REMARQUE:

B Veiller à bien installer le bloc de lampe et la sortie d’air. S’ils ne sont pas bien installés, ils peuvent déclencher le circuit de protection, empêchant la mise en circuit de l’alimentation.

( Insérer la fiche du cordon

d’alimentation dans la prise de courant, puis appuyer sur l’interrupteur d’alimentation principale (MAIN POWER).

REMARQUE:

B Si l’indicateur POWER ne s’allume pas en rouge sur le projecteur lorsque l’interrupteur MAIN POWER est mis en circuit, remettre l’interrupteur MAIN POWER hors circuit et s’assurer que le bloc de lampe et la sortie d’air sont bien installés, puis remettre l’interrupteur

MAIN POWER en circuit.

) Appuyer sur la touche

d’alimentation (POWER) pour projeter une image sur l’écran.

* Appuyer sur la touche de menu

(MENU) pour faire apparaître l’écran de menu, et sélectionner

“OPTION” en appuyant sur les

touches I ou H.

OPTION

OBTURATEUR

INFO ÉCRAN

COR TRAP AUT

RGB/YPbPr

SELECTION RGB2

COULEUR FOND

INSTALLATION

SOL/PLAFOND

PUIS LAMPE

DURÉE LAMPE

PAGE SUIVANTE @

SÉL.:[^][@]

AJT:[{][}]

NON

NON

RGB

ENTRÉE

BLEU

FAÇADE

SOL

FROIDE

OUI

OUI

YPbPr

SORTIE

NOIR

ARRIÈRE

PLAFOND

HAUTE

1820 H

VALID:[ENTER]

ESC:[MENU]

+ Appuyer sur la touche d’entrée

(ENTER) et sélectionner le

“DURÉE LAMPE” (temps de fonctionnement de la lampe) en

appuyant sur les touches I ou H.

OPTION

OBTURATEUR

INFO ÉCRAN

COR TRAP AUT

RGB/YPbPr

SELECTION RGB2

COULEUR FOND

INSTALLATION

SOL/PLAFOND

PUIS LAMPE

DURÉE LAMPE

PAGE SUIVANTE @

SÉL.:[^][@]

AJT:[{][}]

NON

NON

RGB

ENTRÉE

BLEU

FAÇADE

SOL

FROIDE

OUI

OUI

YPbPr

SORTIE

NOIR

ARRIÈRE

PLAFOND

HAUTE

1820 H

VALID:[ENTER]

ESC:[MENU]

, Maintenir la touche d’entrée

(ENTER) enfoncée pendant environ 3 secondes.

TIME RESET

Coupe l,alimentation

OUI NON

Le “TIME RESET Coupe

I’alimentation” (réinitialisation du temps [mise hors tension]) s’affiche.

- Sélectionner “OUI” en

d'entrée (ENTER).

REMARQUE:

B Si “NON” est sélectionné à l’étape -, l’opération pour remettre le temps de la lampe à zéro sera annulée.

. Couper l’alimentation

électrique.

Le temps d’utilisation total du bloc de lampe est alors remis à zéro.

Pour plus de détails concernant la manière de couper le courant, se reporter aux étapes % et & de la page 29.

81

These Operating Instructions are printed on recycled paper.

R

Professional/Industrial Video

Panasonic Broadcast & Television Systems Company

Division of Matsushita Electric Corporation of America

3330 Cahuenga Blvd West Los Angels, CA 90068 (323) 436-3500

Technical Support:

(800) 222 - 0741

E-Mail: [email protected]

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario L4W 2T3 (905) 624-5010

Printed in Japan

S0702-4063F

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
