OPERATING INSTRUCTIONS

OPERATING INSTRUCTIONS

OPERATING INSTRUCTIONS

Personal Computer

Model No.

CF-31

series

Contents

Getting Started

Introduction .................................................................

Read Me First ............................................................

(Precautions)

Description of Parts ..................................................

First-time Operation ..................................................

11

14

2

3

Useful Information

On-screen Manual ....................................................

Handling and Maintenance .......................................

Reinstalling Software ................................................

18

19

21

Troubleshooting

Troubleshooting (Basic) ............................................

23

For further information about the computer, you can refer to the on-screen manual.

To access the on-screen manual

è

page 18 “On-screen Manual”

Appendix

LIMITED USE LICENSE AGREEMENT ...................

Specifications ...........................................................

LIMITED WARRANTY ..............................................

27

29

33

Please read these instructions carefully before using this product, and save this manual for future use.

DFQW5649XAT_CF-31mk3_EN.indb 1 2013/06/21 14:53:23

Introduction

Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully.

n

Terms and illustrations in these instructions

CAUTION

NOTE

:

: Conditions that may result in minor or moderate injury.

Useful and helpful information.

Enter :

Fn + F5 :

Press [Enter] key.

Press and hold [Fn] key, and then press [F5] key.

(Start) - [All Programs] : Click (Start), and then click [All Programs]. You may need to double-click in some cases.

è

:

:

Page in these Operating Instructions or in the Reference Manual.

Reference to the on-screen manuals.

l

Some illustrations are simplified to help your understanding and may look different from the actual unit.

l

If you do not log on as an administrator, you cannot use some functions or cannot display some screens.

l

Refer for the latest information about optional products to the catalogs, etc.

l

In these instructions, the names and terms are referred as follows.

7 Professional 32-bit Service Pack 1” and “Genuine Windows

®

7 Professional 64-bit Service

Ÿ

“Genuine Windows

®

Pack 1” as “Windows” or “Windows 7”

Ÿ

DVD MULTI drive as “CD/DVD drive”

Ÿ

Circular media including DVD-ROM and CD-ROM as “discs” n

Disclaimer

Computer specifications and manuals are subject to change without notice. Panasonic Corporation assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.

n

Trademarks

Microsoft

®

, Windows

®

, the Windows logo, and IntelliMouse are registered trademarks of Microsoft Corporation of the

United States and/or other countries.

Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.

SDXC Logo is a trademark of SD-3C, LLC.

Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Bluetooth

®

is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other countries.

Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective own companies.

2

DFQW5649XAT_CF-31mk3_EN.indb 2 2013/06/21 14:53:23

Read Me First

Important Safety Instructions / Importantes Mesures De Sécurité

<Only for model with modem>

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode.

Check with local codes for possible special disposal instructions.

SAVE THESE INSTRUCTIONS

19-E-1

<Pour modèles avec modem uniquement>

Certaines mesures de sécurité doivent être prises pendant l’utilisation de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes:

1. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol humide ou près d’une piscine.

2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant un orage électrique. Ceci peut présenter un risque de choc électrique causé par la foudre.

3. Ne pas utiliser l’appareil téléphonique pour signaler une fuite de gaz s’il est situé près de la fuite.

4. Utiliser seulement le cordon d’alimentation et le type de piles indiqués dans ce manual. Ne pas jeter les piles dans le feu: elles peuvent exploser. Se conformer aux règlements pertinents quant à l’élimination des piles.

CONSERVER CES INSTRUCTIONS

19-F-1

Information to the User

<Only for model with wireless LAN/Bluetooth>

This product and your Health

This product, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by this product however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because this product operates within the guidelines found in radio frequency safety standards and recommendations, we believe this product is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of this product may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include: l

Using this product on board of airplanes, or l

In any other environment where the risk of interference to other devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use this product prior to turning on the product.

Regulatory Information

We are not responsible for any radio or television interference caused by unauthorized modification of this product. The correction of interference caused by such unauthorized modification will be the responsibility of the user. We and its authorized resellers or distributors are not liable for damage or violation of government regulations that may arise from failing to comply with these guidelines.

26-M-1

Informations destinées aux utilisateurs

<Uniquement les modèles avec réseau local sans fil et/ou Bluetooth>

Ce produit et votre santé

Ce produit, comme tout autre appareil radio, émet de l’énergie radioélectrique. Toutefois, la quantité d’énergie émise par ce produit est beaucoup moins importante que l’énergie radioélectrique émise par des appareils sans fil tels que les téléphones portables. L’utilisation de ce produit ne comporte aucun risque pour le consommateur du fait que cet appareil opère dans les limites des directives concernant les normes et les recommendations de sécurité sur les fréquences radio. Ces normes et recommandations reflètent le consensus de la communauté scientifique et résultent de délibérations de jurys et comités de scientifiques qui examinent et interprètent continuellement les nouveautés de la vaste littérature sur les recherches effectuées.

Dans certaines situations ou environnements, l’utilisation de ce produit peut être restreinte par le propriétaire du bâtiment ou par les représentants responsables de l’organisation. Ces situations peuvent être les suivantes par exemple : l

A bord d’un avion, ou l

Dans tout autre environnement où les risques d’interférence sur d’autres appareils ou services sont perçus ou identifiables comme dangereux.

Si vous n’êtes pas sûr de la réglementation applicable à l’utilisation d’appareils sans fil dans une organization ou un environnement spécifique, (par exemple dans un aéroport) nous vous invitons à demander l’autorisation d’utiliser ce produit avant sa mise en marche.

Informations concernant la réglementation

Nous déclinons toute responsabilité pour toute interférence radio ou télévision causée par des modifications non autorisées apportées à ce produit. La correction d’interférences causées par de telles modifications non autorisées sera la seule responsabilité de son utilisateur. Nousmêmes, les revendeurs officiels et les distributeurs ne sommes pas responsable de tout dégât ou de toute violation des règlements de l’État pouvant découler du non-respect de ces directives.

26-F-1

3

2013/06/21 14:53:23 DFQW5649XAT_CF-31mk3_EN.indb 3

Read Me First

Lithium Battery / Pile au lithium

Lithium Battery!

This computer contains a lithium battery to enable the date, time, and other data to be stored. The battery should only be exchanged by authorized service personnel.

Warning!

A risk of explosion from incorrect installation or misapplication may possibly occur.

15-E-1

Pile au lithium!

Le micro-ordinateur renferme une pile au lithium qui permet de sauvegarder certaines données, notamment la date et l’heure.

La pile ne doit être remplacée que par un technicien qualifié.

Danger ! Risque d’explosion en cas de non respect de cette mise en garde!

15-F-1

CD/DVD Drive Caution

CAUTION!

THIS PRODUCT UTILIZES A LASER.

USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE

OF PROCEDURES OTHER THAN THOSE SPECIFIED HERE-

IN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.

REFER SERVICING TO QUALIFIED PERSONNEL.

12-E-1

Laser safety information is appropriate only when drive with laser is installed.

12-M-2-1

AVERTISSEMENT!

CET APPAREIL UTILISE UN LASER.

L’UTILISATION DE COMMANDES OU DE RÉGLAGES OU

L’EXÉCUTION DE PROCÉDURES AUTRES QUE CELLES

SPÉCIFIÉES ICI PEUVENT PROVOQUER UNE EXPOSITION

À DES RADIATIONS DANGEREUSES.

NE PAS OUVRIR LES COUVERCLES NI ESSAYER DE

RÉPARER SOIMÊME.

CONFIER TOUT TRAVAIL D’ENTRETIEN À UN PERSONNEL

QUALIFIÉ.

12-F-1

Les mesures de sécurité relatives au laser ne s’appliquent que lors de l’installation d’une unité avec laser.

12-F-2-1

Information for Users on Collection and Disposal of Old Equipment and used

Batteries

These symbols are only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

53-M-1

Safety Precautions

<Only for model with wireless WAN>

The following safety precautions must be observed during all phases of the operation, usage, service or repair of any Personal

Computer or Handheld Computer incorporating wireless WAN modem. Manufacturers of the cellular terminal are advised to convey the following safety information to users and operating personnel and to incorporate these guidelines into all manuals supplied with the product. Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions.

When in a hospital or other health care facility, observe the restrictions on the use of mobiles. Switch Personal Computer or Handheld Computer incorporating wireless WAN modem off, if instructed to do so by the guidelines posted in sensitive areas. Medical equipment may be sensitive to RF energy.

The operation of cardiac pacemakers, other implanted medical equipment and hearing aids can be affected by interference from Personal Computer or Handheld Computer incorporating wireless WAN modem placed close to the device.

If in doubt about potential danger, contact the physician or the manufacturer of the device to verify that the equipment is properly shielded. Pacemaker patients are advised to keep their Personal Computer or Handheld Computer incorporating wireless WAN modem away from the pacemaker, while it is on.

Switch off Personal Computer or Handheld Computer incorporating wireless WAN modem before boarding an aircraft.

Make sure it cannot be switched on inadvertently. The operation of wireless appliances in an aircraft is forbidden to prevent interference with communications systems. Failure to observe these instructions may lead to the suspension or denial of cellular services to the offender, legal action, or both.

Do not operate Personal Computer or Handheld Computer incorporating wireless WAN modem in the presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel depots, chemical plants or where blasting operations are in progress. Operation of any electrical equipment in potentially explosive atmospheres can constitute a safety hazard.

Your Personal Computer or Handheld Computer incorporating wireless WAN modem receives and transmits radio frequency energy while switched on. Remember that interference can occur if it is used close to TV sets, radios, computers or inadequately shielded equipment. Follow any special regulations and always switch off Personal Computer or Handheld Computer incorporating wireless WAN modem wherever forbidden, or when you suspect that it may cause interference or danger.

4

DFQW5649XAT_CF-31mk3_EN.indb 4 2013/06/21 14:53:24

Road safety comes first! Do not use a Personal Computer or Handheld Computer incorporating wireless WAN modem while driving a vehicle. Do not place the computer with wireless WAN modem in an area where it could cause personal injury to the driver or passengers. It is recommended to stow the unit in the boot or secure stowage area while driving.

Do not place the computer with wireless WAN modem in an area over an air bag or in the vicinity where an air bag may deploy.

Air bags inflate with great force and if the computer with wireless WAN modem is placed in the air bag deployment area may be propelled with great force and cause serious injury to occupants of the vehicle.

IMPORTANT!

Personal Computer or Handheld Computer incorporating wireless WAN modem operate using radio signals and cellular networks cannot be guaranteed to connect in all conditions. Therefore, you should never rely solely upon any wireless device for essential communications, for example emergency calls.

Remember, in order to make or receive calls, Personal Computer or Handheld Computer incorporating wireless WAN modem must be switched on and in a service area with adequate cellular signal strength.

Some networks do not allow for emergency calls if certain network services or phone features are in use (e.g. lock functions, fixed dialing etc.). You may need to deactivate those features before you can make an emergency call.

Some networks require that a valid SIM card be properly inserted in Personal Computer or Handheld Computer incorporating wireless WAN modem.

27-1-2

Models for U.S.A.

Federal Communications Commission Radio Frequency

Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l

Reorient or relocate the receiving antenna.

l

Increase the separation between the equipment and receiver.

l

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

l

Consult the Panasonic Service Center or an experienced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

FCC RF Exposure Warning: l

This equipment is provided with PC Card slot that could be used with wireless transmitters, which will be specifically recommended when they become available.

Other third-party wireless transmitters have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.

<Only for model with wireless LAN/wireless WAN/Bluetooth> l

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

l

This equipment has been approved for portable operation, and does not require any minimum spacing be provided between antennas and all person’s body.

l

This equipment may not be co-located or operated with any other antenna or transmitter.

25-M-3

<Only for model with wireless WAN> l

This PC with WWAN transmitter installed, has been approved for mobile operation and to assure compliance with

RF exposure requirements, a minimum of 20 cm (8 inches) must be maintained between the WWAN antenna located in top of LCD and all person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation.

<Optional Car Mounter / Port Replicator> l

This equipment is provided with external antenna connector(s) for connection to optional Car Mounter or Port

Replicator for mobile external mounted antenna(s).

External antenna(s) must be professionally installed and cannot exceed recommended maximum antenna gain as described in individual provided supplement instructions for wireless transmitters.

For WLAN, the Car Mounter should be used with Radiall/Larsen WLAN whip antenna, type NMO5E2400BKTNC with 5dBi antenna gain or less. Also, user must maintain minimum 20 cm spacing between external antenna(s) and all person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation.

25-M-5

<Only for model with wireless LAN>

This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range.

FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this product.

25-M-W-5

Responsible Party: Panasonic Corporation of North America

Two Riverfront Plaza

Newark, NJ 07102

Tel No:1-800-LAPTOP5 (1-800-527-8675)

6-M-1

<Only for model with modem>

FCC Regulation Notice for modem

This equipment contains a FCC approved modem.

1. This equipment complies with CFR47 Part 68 rules.

On the computer is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If required, this information must be provided to the telephone company.

DFQW5649XAT_CF-31mk3_EN.indb 5

5

2013/06/21 14:53:24

Read Me First

2. An FCC compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected to the telephone network or premises wiring using a compatible modular jack which is Part 68 compliant.

See Installation Instructions for details.

3. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all area, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company.

4. If your telephone equipment cause harm to the telephone network, the telephone company will notify you in advice that temporary discontinuance of service may be required. But if advice notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

5. The telephone company may take changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service.

6. If trouble is experienced with this equipment, for repair or warranty information, please contact Panasonic Corporation of North America at DIAL TOLL FREE 1-800-LAPTOP5

(1-800-527-8675). If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

7. There are no user serviceable parts contained in this equipment.

8. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.

9. The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone fax machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entry, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. In order to program this information into your fax software, you should refer to the manual of the Fax software being used.

10. According to the FCC’s electrical safety advisory, we recommend that you may install an AC surge arrestor in the

AC outlet to which this equipment is connected. Telephone companies report that electrical surges, typically lightning transients, are very destructive to customer terminal equipment connected to AC power sources and that this is a major nationwide problem.

“Caution : To reduce the risk of fire, use only No.26 AWG or larger (e.g., 24 AWG) UL listed or CSA certified telecommunication line cord.”

“ATTENTION : Pour réduire le risque d’incendie, utiliser uniquement des conducteurs de télécommunications 26 AWG ou de section supérieure (p.ex. 24 AWG) UL énumérés ou CSA certifié.”

16-M-1

UL1604-conforming model. (The model which has description of

“UL1604” in the bottom of the computer.)

THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DI-

VISION2, GROUPS A, B, C, AND D OR NON-HAZARDOUS

LOCATIONS ONLY.

WARNING-EXPLOSION HAZARD-SUBSTITUTION OF COM-

PONENTS MAY IMPAIR SUITABILITY FOR CLASSI, DIVI-

SION2.

When connecting and using a device manufactured by a third party, enquire to the manufacturer as to whether the device suits CLASS1, DIVISION2.

33-M-1-1

USA Only: Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please visit Panasonic website: http://www.panasonic.com/environmental or call

1-888-769-0149

65-M-2

<For USA-California Only>

This product contains a Coin Cell Lithium Battery which contains Perchlorate Material - special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate/

38-M-1

For Used in Motor Vehicle /Pour L’utilisation Dans Un Véhicule Motorisé

Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to support vehicle related functions such as vehicle information, system control, rear or side observation and navigation. If used for entertainment purpose, such as television reception or video play, it must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle. Check with individual state/provincial laws to determine lawful use of this product while operating within a motor vehicle.

Avertissement : L’ordinateur bloc-notes peut être installé dans un véhicule motorisé et dans le champ de vision du conducteur uniquement en tant que dispositif d’aide aux fonctions du véhicule, comme par exemple pour fournir des informations sur le véhicule, comme dispositif de contrôle de système, pour l’observation à l’arrière ou sur les côtés du véhicule, ainsi que pour fournir de l’information routière. Pour toute utilisation à fin de divertissement, comme par exemple pour regarder la télévision ou jouer à des jeux vidéo, il doit être installé à l’arrière du siège du conducteur, en un emplacement où il ne sera pas visible, ni directement ni indirectement, pour le conducteur du véhicule motorisé. Vérifiez les lois fédérales et nationales qui régissent l’utilisation légale de cet appareil à l’intérieur d’un véhicule motorisé.

35-M-1

External Antenna

FCC RF Exposure Warning:

Ÿ

This equipment is provided with external antenna connector(s) for connection to optional Car Mounter or Port

Replicator for mobile external mounted antenna(s). External antenna(s) must be professionally installed and cannot exceed recommended maximum antenna gain as described in individual provided supplement instructions for wireless transmitters.

The maximum allowable antenna gain for the external WWAN base whip antenna for the cellular band is 7.0 dBi and PCS band is 3.5 dBi. Also, user must maintain minimum 20 cm spacing between external antenna(s) and all person’s body

(excluding extremities of hands, wrist and feet) during wireless modes of operation.

32-M-1-1

6

DFQW5649XAT_CF-31mk3_EN.indb 6 2013/06/21 14:53:24

Models for Canada

<Only for model with modem>

Industry Canada (IC) Notice for modem

This equipment contains an Industry Canada approved modem unit.

The Industry Canada label is affixed on the modem unit.

EQUIPMENT ATTACHMENT LIMITATIONS

“NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment

Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.”

“NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.”

REN: See bottom of the computer

RESTRICTIONS CONCERNANT LE RACCORDEMENT DE

MATÉRIEL

“AVIS: L’étiquette d’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme aux normes de protection, d’exploitation et de sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le matériel fonctionnera à la satisfaction de l’utilisateur.

Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’entreprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée de raccordement.

L’abonné ne doit pas oublier qu’il est possible que la conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines situations.

Les réparations de matériel homologué doivent être coordonnées par un représentant désigné par le fournisseur.

L’entreprise de télécommunications peut demander à l’utilisateur de débrancher un appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de mauvais fonctionnement.

Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la terre de la source d’énergie électrique, des lignes téléphoniques et des canalisations d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette précaution est particulièrement importante dans les régions rurales. Avertissement:

L’utilisateur ne doit pas tenter de faire ces raccordements luimême; il doit avoir recours à un service d’inspection des installations électriques, ou à un électricien, selon le cas.”

“AVIS: L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui peuvent être raccordés à une interface. La terminaison d’une interface téléphonique peut consister en une combinaison de quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de touts les dispositifs n’excède pas 5.”

IES: Voir sous le fond de l’ordinateur

17-Ca-1

Canadian ICES-003

This Class B digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe B est conforme à la norme

NMB-003 du Canada.

7-M-2

<Only for model with wireless LAN/Bluetooth>

Industry Canada

This product complies with RSS210 Industry Canada.

Operation is subject to the following two conditions;

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of the device.

<Ne s’applique qu’aux modèes avec technologie Bluetooth/LAN sans fil/WAN sans fil>

Industrie Canada

Cet équipement est conforme à la norme CNR-210 d’ndustrie

Canada. Son fonctionnement est soumis aux deux conditions suivantes :

(1) ce dispositif ne peut produire de brouillage, et

(2) ce dispositif doit accepter le brouillage, y compris le brouillage pouvant entraîner le fonctionnement non désiré de l’appareil.

30-Ca-1-1

<Only for model with wireless LAN>

This product (local network devices) for the band

5150-5250 MHz is only indoor usage to reduce potential for harmful interference to co-channel Mobile Satellite systems.

High power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to LE-

LAN devices.

<Ne s’applique qu’aux modèes avec technologie LAN sans fil>

Cet appareil (pour réseaux locaux radioélectriques) dans les bandes de fréquences 5150-5250 MHz est réervéàune utilisation àl’intéieur afin de réuire le risque d’interféence avec les systèmes satellites mobiles bicanaux.

Les radars forte puissance sont désignés comme étant les premiers utilisateurs (c’st-à-dire qu’ls ont la priorité) des bandes de fréquences 5250-5350 MHz et 5650-5850 MHz. Ces stations radars peuvent provoquer des interférences et/ou des dommages à ce périphérique.

30-Ca-2-1

This device has been designed to operate with the Radiall/

Larsen whip antenna, type NMO5E2400BKTNC WLAN antenna having a maximum gain of 5dB. A WLAN Antenna having a higher gain is strictly prohibited per regulations of Industry

Canada. The Required antenna impedance is 50 ohms.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.

Cet appareil est conçu pour opérer avec l’antenne-fouet Radiall/Larsen, type WLAN NMO5E2400BKTNC, ayant un gain maximum de 5 dB. Les règlements d’Industrie Canada interdisent l’utilisation d’une antenne WLAN dont le gain serait supérieur à cette limite. L’antenne doit avoir une impédance de 50 ohms.

DFQW5649XAT_CF-31mk3_EN.indb 7

7

2013/06/21 14:53:24

Read Me First

Afin de réduire le risque d’interférence radioélectrique aux autres utilisateurs des bandes de fréquences, le type d’antenne et son gain doivent être tels que la puissance isotrope rayonnée

équivalente (PIRE) n’est pas plus élevée que le niveau requis pour assurer la communication.

25-Ca-1-1

<Only for model with wireless LAN/wireless WAN/Bluetooth> l

This computer complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment.

l

This PC with WLAN and/or Bluetooth transmitters installed, has been approved for portable operation and does not require any minimum spacing be provided between antennas and all person’s body.

<Ne s’applique qu’aux modèles avec technologie Bluetooth/LAN sans fil/WAN sans fil> l

Cet équipement est conforme aux limites d’exposition aux rayonnements d’Industrie Canada établies pour un environnement non contrôlé.

l

Ce PC avec émetteurs WLAN et/ou Bluetooth a été approuvé à des fins d’opération mobile; aucun espace minimum entre les antennes et le corps de l’utilisateur n’est requis.

FOR USE WITH MODEL NO. : CF-AA5713A

POUR UTILISER AVEC MODÈLE : CF-AA5713A

20-Ca-1

CSA C22 2 NO.213-conforming model. (The model which has description of “CSA C22 2 NO.213” in the bottom of the computer.)

THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DI-

VISION2, GROUPS A, B, C, AND D OR NON-HAZARDOUS

LOCATIONS ONLY.

WARNING-EXPLOSION HAZARD-SUBSTITUTION OF COM-

PONENTS MAY IMPAIR SUITABILITY FOR CLASSI, DIVI-

SION2.

When connecting and using a device manufactured by a third party, enquire to the manufacturer as to whether the device suits

CLASS1, DIVISION2.

33-Ca-1

External Antenna

<For Canada>

This device has been designed to operate with the WWAN antenna having a maximum gain of 7.0 dB for the cellular band and 3.5 dB for the PCS band. WWAN Antenna having a higher gain is strictly prohibited per regulations of Industry Canada.

The Required antenna impedance is 50 ohms.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.

<Utilisation au Canada>

Cet appareil est conçu pour opérer avec une antenne WWAN

(réseau étendu sans fil) dont le gain maximum est fixé à 7.0 pour la bande cellulaire et à 3.5 pour la bande de service de communications personnelles (PCS). Les règlements d’Industrie Canada interdisent l’utilisation d’une antenne WWAN dont le gain serait supérieur à cette limite. L’antenne doit avoir une impédance de 50 ohms.

Afin de réduire le risque d’interférence radioélectrique aux autres utilisateurs des bandes de fréquences, le type d’antenne et son gain doivent être tels que la puissance isotrope rayonnée

équivalente (PIRE) n’est pas plus élevée que le niveau requis pour assurer la communication.

32-Ca-1-1

Models for Australia

For Used in Motor Vehicle

Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to support vehicle related functions such as vehicle information, system control, rear or side observation and navigation. If the Notebook Computer is to be used for work or entertainment purposes, such as television reception, video play or other work programs, it must be installed in a position where it will NOT:

(a) be visible, directly or indirectly, to the operator of the motor vehicle; or

(b) cause distraction to drivers of other motor vehicles.

Check with individual state laws to determine lawful use of this product while operating within a motor vehicle. If the visual display unit is, or is part of, a driver's aid, above rule is not applied. "Driver's aid" includes closed-circuit television security cameras, dispatch systems, navigational or intelligent highway and vehicle system equipment, rear view screens, ticket-issuing machines and vehicle monitoring devices.

35-A-1

Models for India

For the purpose of recycling to facilitate effective utilization of resources, please return this product to a nearby authorized collection center, registered dismantler or recycler, or Panasonic service center when disposing of this product.

Please see the Panasonic website for further information on collection centers, etc.

http://www.panasonic.co.in/wps/portal/home

8

DFQW5649XAT_CF-31mk3_EN.indb 8 2013/06/21 14:53:25

Precautions

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS

PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC

CONTROL EQUIPMENT/SYSTEMS, AIRCRAFT COCKPIT

EQUIPMENT/SYSTEMS

SORIES

*2

*1

, MEDICAL DEVICES OR ACCES-

, LIFE SUPPORT SYSTEMS OR OTHER EQUIP-

MENTS/DEVICES/SYSTEMS THAT ARE INVOLVED WITH

ENSURING HUMAN LIFE OR SAFETY. PANASONIC WILL

NOT BE RESPONSIBLE FOR ANY LIABILITY RESULTING

FROM THE USE OF THIS PRODUCT ARISING OUT OF THE

FOREGOING USES.

*1

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2

Electrical Flight Bag (EFB) Systems and Class1 EFB Systems when used during critical phases of flight (e.g., during takeoff and landing) and/or mounted on to the aircraft. Class1 EFB

Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance

Leaflets) No.36.

*2

As defined by the European Medical Device Directive (MDD)

93/42/EEC.

Panasonic cannot guarantee any specifications, technologies, reliability, safety (e.g. Flammability/Smoke/Toxicity/Radio

Frequency Emission, etc) requirements related to aviation standards and medical equipment standards that differ from the specifications of our COTS (Commercial-Off-The-Shelf) products.

Panasonic cannot guarantee any specifications, technologies, reliability, safety (e.g. Flammability/Smoke/Toxicity/Radio

Frequency Emission, etc) requirements related to aviation standards that exceed the specifications of our COTS (Commercial-Off-The-Shelf) products.

This computer is not inten ded for use in medical equipment including life-support systems, air traffic control systems, or other equipment, devices or systems that are involved with ensuring human life or safety. Panasonic cannot be held responsible in any way for any damages or loss resulting from the use of this unit in these types of equipment, devices or systems, etc.

The CF-31 was developed based on thorough research into the real-world portable computing environments. Exhaustive pursuit of usability and reliability under harsh conditions led to innovations such has the magnesium alloy exterior, vibration damped hard disk drive and floppy disk drive, flexible internal connections. The CF-31’s outstanding engineering has been tested using the strict MIL-STD- 810F (for vibration and shock) and IP

(for dust and water) based procedures.

As with any portable computer device precautions should be taken to avoid any damage. The following usage and handling procedures are recommended.

Before putting the computer away, be sure to wipe off any moisture.

If a Malfunction or Trouble Occurs, Immediately Stop Use

If a Malfunction Occurs, Immediately Unplug the AC Plug and the Battery Pack

Ÿ

This product is damaged

Ÿ

Foreign object inside this product

Ÿ

Smoke emitted

Ÿ

Unusual smell emitted

Ÿ

Unusually hot

Continuing to use this product while any of the above conditions are present may result in fire or electric shock.

Ÿ

If a malfunction or trouble occurs, immediately unplug the

AC plug and remove the unit from this product. Then, contact your technical support office for repair.

Do Not Touch This Product In a Thunderstorm If Connected with the AC Cable or Any Other Cables

Electric shock may result.

Do Not Connect the AC Adaptor to a Power Source Other

Than a Standard Household AC Outlet

Otherwise, a fire due to overheating may result. Connecting to a

DFQW5649XAT_CF-31mk3_EN.indb 9

DC/AC converter (inverter) may damage the AC adaptor. On an airplane, only connect the AC adaptor/charger to an AC outlet specifically approved for such use.

Do Not Do Anything That May Damage the AC Cord, the AC

Plug, or the AC Adaptor

Do not damage or modify the cord, place it near hot tools, bend, twist, or pull it forcefully, place heavy objects on it, or bundle it tightly.

Continuing to use a damaged cord may result in fire, short circuit, or electric shock.

Do Not Pull or Insert the AC Plug If Your Hands Are Wet

Electric shock may result.

Clean Dust and Other Debris of the AC Plug Regularly

If dust or other debris accumulates on the plug, humidity, etc. may cause a defect in the insulation, which may result in a fire.

Ÿ

Pull the plug, and wipe it with a dry cloth.

Pull the plug if the computer is not being used for a long period of time.

Insert the AC Plug Completely

If the plug is not inserted completely, fire due to overheating or electric shock may result.

Ÿ

Do not use a damaged plug or loose AC outlet.

Close the Connector Cover Tightly When Using This Product Where Is a Lot of Water, Moisture, Steam, Dust, Oily

Vapors, etc.

The entry of foreign matter may cause a fire or electric shocks.

Ÿ

If foreign matter has found its way inside, immediately turn the power off and unplug the AC cord, and then remove the battery pack. Then contact your technical support office.

Do Not Disassemble This Product

The high-voltage areas inside may give you an electric shock, or foreign matter may enter and result in a fire.

Keep SD Memory Cards Away from Infants and Small Children

Accidental swallowing will result in bodily injury.

Ÿ

In the event of accidental swallowing, see a doctor immediately.

Do Not Place This Product on Unstable Surface

If balance is lost, this product may fall over or drop, resulting in an injury.

Avoid Stacking

If balance is lost, this product may fall over or drop, resulting in an injury.

Do Not Leave This Product in High Temperature Environment for a Long Period of Time

Leaving this product where it will be exposed to extremely high temperatures such as near fire or in direct sunlight may deform the cabinet and/or cause trouble in the internal parts. Continued use in such a resulting condition may lead to short-circuiting or insulation defects, etc. which may in turn lead to a fire or electric shocks.

Do Not Block the Ventilation Hole (Exhaust)

Using this product wrapped in cloth or on top of bedding or a blanket can block the ventilation hole and cause heat to build up inside. Possibly resulting in a fire.

Hold the Plug When Unplugging the AC Plug

Pulling on the cord may damage the cord, resulting in a fire or electric shock.

Do Not Move This Product While the AC Plug Is Connected

The AC cord may be damaged, resulting in fire or electric shock.

Ÿ

If the AC cord is damaged, unplug the AC plug immediately.

Use Only the Specified AC Adaptor With This Product

Using an AC adaptor other than the one supplied (supplied with the unit or one sold separately as an accessory) may result in a fire.

Do Not Subject the AC Adaptor to Any Strong Impact

Using the AC adaptor after a strong impact such as being dropped may result in electric shock, short circuit, or fire.

9

2013/06/21 14:53:25

Read Me First

Take a Break of 10-15 Minutes Every Hour

Using.this.product.for.long.periods.of.time.may.have.detrimental.

health.effects.on.the.eyes.or.hands.

Do Not Turn the Volume Up To Loud When Using Headphones

Listening.at.high.volumes.that.overstimulate.the.ear.for.long.

periods.of.time.may.result.in.loss.of.hearing.

Do Not Connect a Telephone Line, or a Network Cable

Other Than the One Specified, into the LAN Port

If.the.LAN.port.is.connected.to.a.network.such.as.the.ones.

listed.right,.a.fire.or.electric.shock.may.result.

Ÿ

. Networks.other.than.1000BASE-T,.100BASE-TX.or..

10BASE-T

Ÿ

. Phone.lines.(IP.phone.(Internet.Protocol.Telephone),.Telephone.lines,.internal.phone.lines.(on-premise.switches),.

digital.public.phones,.etc.)

Do Not Use This Product in Close Contact With Your Body

For a Long Period of Time

Do.not.use.this.product.with.its.heat-emitting.parts.in.close.contact.with.your.body.for.long.periods.of.time.

Ÿ

. Low-temperature.burns.may.result.

Do Not Touch The Surface of The AC Adaptor Continuously

While Using/Charging

Burns.may.result.

Do Not Expose Yourself or Other Persons to the Hot Wind from the Ventilation Hole (Exhaust) for a Long Period of Time

Low-temperature.burns.may.result.

Covering.the.ventilation.hole.(exhaust).with.your.hand.or.other.object.can.cause.heat.to.build.up.inside,.possibly.resulting.in.burns.

Do Not Expose the Skin to This Product When Using the

Product In a Hot or Cold Environment

Burns,.low-temperature.burns.or.frostbite.may.result.

Ÿ

.

Whe n.it.is.necessary.to.expose.the.skin.to.this.product.such.as.to.

a.fingerprint,.perform.the.operation.in.the.

shortest.time.possible.

scan.

<Only.for.model.with.modem>

Use the Modem with a Regular Telephone Line

Connection.to.an.internal.phone.line.(on-premise.switches).of.

a.company.or.business.office,.etc..or.to.a.digital.public.phone.

or.use.in.a.country.or.area.not.supported.by.the.computer.may.

result.in.a.fire.or.electric.shocks.

l

. Do.not.place.the.computer.near.a.television.or.radio.receiver.

l

. Keep.the.computer.away.from.magnets..Data.stored.on.the.

hard.disk.may.be.lost.

Precautions (Battery Pack)

10

Do Not Use With Any Other Product

The.battery.pack.is.rechargeable.and.was.intended.for.the.

specified.product..If.it.is.used.with.a.product.other.than.the.one.

for.which.it.was.designed,.electrolyte.leakage,.generation.of.

heat,.ignition.or.rupture.may.result.

Do Not Charge the Battery Using Methods Other Than

Those Specified

If.the.battery.is.not.charged.using.one.of.the.specified.methods,.

electrolyte.leakage,.generation.of.heat,.ignition.or.rupture.may.result.

Do Not Throw the Battery Pack Into a Fire or Expose It to

Excessive Heat

Generation.of.heat,.ignition.or.rupture.may.result.

Avoid Extreme Heat (Near the Fire, In Direct Sunlight, for Example)

Electrolyte.leakage,.generation.of.heat,.ignition.or.rupture.may.result.

Do Not Insert Sharp Objects Into the Battery Pack, Expose

It to Bumps or Shocks, Disassemble, or Modify It

Electrolyte.leakage,.generation.of.heat,.ignition.or.rupture.may.result.

Ÿ

. If.this.product.is.subjected.to.a.strong.impact,.stop.using.it.immediately.

Do Not Short the Positive (+) and Negative (-) Contacts

Generation.of.heat,.ignition.or.rupture.may.result..

Ÿ

.

Do.not.place.the.battery.pack.together.with.articles.such.

as.necklaces.or.hairpins.when.carrying.or.storing.

Do Not Use This Product with a Battery Pack Other Than the One Specified

Use.only.the.specified.battery.pack.(è.page.11).with.your.product..Use.of.battery.packs.other.than.those.manufactured.and.

supplied.by.Panasonic.may.present.a.safety.hazard.(generation.

of.heat,.ignition.or.rupture).

When the battery pack has become degraded, replace it with a new one

Continued.use.of.a.damaged.battery.pack.may.result.in.heat.

generation,.ignition.or.battery.rupture.

l

. Do.not.touch.the.terminals.on.the.battery.pack..The.battery.pack.may.

no.longer.function.properly.if.the.contacts.are.dirty.or.damaged.

l

. Do.not.expose.the.battery.pack.to.water,.or.allow.it.to.become.wet.

l

. If.the.battery.pack.will.not.be.used.for.a.long.period.of.time.(a.month.

or.more),.charge.or.discharge.(use).the.battery.pack.until.the.remaining.battery.level.becomes.30%.to.40%.and.store.it.in.a.cool,.dry.place.

l

. This.computer.prevents.overcharging.of.the.battery.by.recharging.only.

when.the.remaining.power.is.less.than.approx..95%.of.capacity.

l

. The.battery.pack.is.not.charged.when.the.computer.is.first.purchased..

Be.sure.to.charge.it.before.using.it.for.the.first.time..When.the.AC.

adaptor.is.connected.to.the.computer,.charging.begins.automatically.

l

. Should.the.battery.leak.and.the.fluid.get.into.your.eyes,.do.not.rub.

your.eyes...Immediately.flush.your.eyes.with.clear.water.and.see.a.

doctor.for.medical.treatment.as.soon.as.possible.

CAUTION:

Risk.of.Explosion.if.Battery.is.replaced.by.an.Incorrect.Type..

Dispose.of.Used.Batteries.According.to.the.Instructions.

58-E-1

ATTENTION:

Il.y.a.risque.d’explosion.si.la.batterie.est.remplacée.par.une.batterie.

de.type.incorrect.

Mettre.au.rebut.les.batteries.usagées.conformément.aux.instructions.

58-F-1

NOTE

l

. The.battery.pack.may.become.warm.during.recharging.or.

normal.use...This.is.completely.normal.

l

. Recharging.will.not.commence.if.internal.temperature.of.the.

battery.pack.is.outside.of.the.allowable.temperature.range.

(0.°C.to.50.°C.{32.°F.to.122.°F})...

(è.

.Reference Manual.“Battery.Power”).Once.the.allowable.range.requirement.is.satisfied,.charging.begins.automatically...Note.that.the.recharging.time.varies.based.on.the.

usage.conditions..(Recharging.takes.longer.than.usual.when.

the.temperature.is.10.°C.{50.°F}.or.below.) l

. If.the.temperature.is.low,.the.operating.time.is.shortened...

Only.use.the.computer.within.the.allowable.temperature.

range.

l

. This.computer.has.a.high.temperature.mode.function.that.

prevents.the.degradation.of.the.battery.in.high.temperature.

environments..(è.

.Reference Manual.“Battery.Power”).A..

level.corresponding.to.a.100%.charge.for.high.temperature.

mode.is.approximately.equivalent.to.an.80%.charge.level.for.

normal.temperature.mode.

l

. The.battery.pack.is.a.consumable.item...If.the.amount.of.

time.the.computer.can.be.run.by.using.a.particular.battery.

pack.becomes.dramatically.shorter.and.repeated.recharging.

does.not.restore.its.performance,.the.battery.pack.should.be.

replaced.with.a.new.one.

l

. When.transporting.a.spare.battery.inside.a.package,.briefcase,.etc.,.it.is.recommended.that.it.be.placed.in.a.plastic.

bag.so.that.its.contacts.are.protected.

l

. Always.power.off.the.computer.when.it.is.not.in.use..Leaving.

the.computer.on.when.the.AC.adaptor.is.not.connected.will.

exhaust.the.remaining.battery.capacity.

DFQW5649XAT_CF-31mk3_EN.indb 10 2013/08/08 17:57:06

Description of Parts

E

F

A

B

C

D

Left side

G

H

I

J

K

O P Q R S T U V

L

N M

A: Wireless LAN Antenna

<Only for model with wireless LAN>

è

Reference Manual “Wireless LAN”

B: Camera

<Only for model with Camera>

C: Wireless WAN Antenna

<Only for model with wireless WAN>

è

Reference Manual “Wireless WAN”

D: GPS Antenna (Rear side)

<Only for model with GPS>

E: LCD

è

Reference Manual “Screen Input Operation”

(Only for model with touchscreen)

F: Function Key

è

Reference Manual “Key Combinations”

G: Keyboard

H: Touch Pad

I: LED Indicator

: SD Memory Card Indicator

(Blinking: During access)

è

Reference Manual “SD Memory Card”

: Wireless ready

This indicator lights when Wireless LAN, Bluetooth, and/or Wireless WAN are connected and ready. It does not necessarily indicate the On/Off condition of the wireless connection.

è

Reference Manual “Wireless LAN”, “Bluetooth”,

“Disabling/Enabling Wireless Communication”,

“Wireless WAN”

: Caps lock

: Numeric key (NumLk)

: Scroll lock (ScrLk)

: Hard disk drive status

: Multimedia pocket device status or the second battery status.

: Battery status

è

Reference Manual “Battery Power”

: Power status

(Off: Power off/Hibernation, Green: Power on,

Blinking green: Sleep, Blinking green rapidly:

Cannot power on or resume due to low temperature.)

J: Power Switch

K: Carrying Handle

L: Stylus Holder

M: Fingerprint Reader

<Only for model with Fingerprint Reader>

è Reference Manual “Fingerprint Reader”

N: Wireless LAN Antenna / Bluetooth Antenna

<Only for model with Wireless LAN>

è

Reference Manual “Wireless LAN”

<Only for model with Bluetooth>

è

Reference Manual “Bluetooth”

O: ExpressCard Slot

è

Reference Manual “PC Card / ExpressCard”

P: PC Card Slot

è

Reference Manual “PC Card / ExpressCard”

Q: Multimedia Pocket

è

Reference Manual “Multimedia Pocket”

R: Wireless Switch

è

Reference Manual “Disabling/Enabling Wireless

Communication”

S: Smart Card Slot

è

Reference Manual “Smart Card”

T: SD Memory Card Slot

è

Reference Manual “SD Memory Card”

U: Battery Pack

Specified Battery pack: CF-VZSU46AU/CF-VZSU72U

V: Ventilation Hole (Exhaust)

A lithium ion battery that is recyclable powers the product you have purchased.

Please call 1-800-8-BATTERY for information on how to recycle this battery.

L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion.

Pour des renseignements sur le recyclage de la batterie, veuillez composer le

1-800-8-BATTERY.

48-M-1

11

DFQW5649XAT_CF-31mk3_EN.indb 11 2013/06/21 14:53:26

Description of Parts

Right side

E

*1

E

*2

E

*3

Rear side

A B C D F G H

Bottom

Q

I J K L M N O P

R S

A: Hard Disk Drive

è

Reference Manual “Hard Disk Drive”

B: HDMI Port

è

Reference Manual “External Display”

C: SIM Card Slot

<Only for model with wireless WAN>

Insert the SIM card into the SIM card slot with the contact side facing down and the cut corner facing forward.

è

Reference Manual “Wireless WAN”

D: LAN Port

è

Reference Manual “LAN”

E: 2nd LAN Port

*1

/ Modem Port

*2

/ IEEE 1394 Interface

Connector

*3

*1

<Only for model with 2nd LAN>

è

Reference Manual “LAN”

*2

<Only for model with Modem>

è

Reference Manual “Modem”

*3

<Only for model with IEEE 1394>

è

Reference Manual “IEEE 1394 Devices”

F: USB Port (2.0)

è

Reference Manual “USB Devices”

G: USB Port (2.0)

*4

(3.0)

è

Reference Manual “USB Devices”

*4

<Only for the Value Model>

H: DC-IN Jack

I: Security Lock

A Kensington cable can be connected.

For further information, read the manual that comes with the cable.

J: USB Port (2.0)

è

Reference Manual “USB Devices”

K: External Antenna Connector

L: Expansion Bus Connector

è

Reference Manual “Port Replicator / Car

Mounter”

M: External Display Port (VGA)

è

Reference Manual “External Display”

N: Headphone Jack

You can connect headphones or amplified speakers.

When they are connected, audio from the internal speakers is not heard.

O: Microphone Jack

A condenser microphone can be used. If other types of microphones are used, audio input may not be possible, or malfunctions may occur as a result.

P: Serial Port

Q: RAM Module Slot

è

Reference Manual “RAM Module”

R: Speaker

<Only for model with Camera>

Do not turn the speaker volume and/or microphone volume up too loud. Feedback noise may occur.

è

Reference Manual “Key Combinations”

S: Ventilation Hole (Intake)

12

DFQW5649XAT_CF-31mk3_EN.indb 12 2013/06/21 14:53:26

l

This computer contains a magnet and magnetic products at the locations circled in the illustration at right. Avoid leaving metallic object or magnetic media in contact with these areas.

DFQW5649XAT_CF-31mk3_EN.indb 13

13

2013/06/21 14:53:27

First-time Operation

n

Preparation

A

Check and identify the supplied accessories.

If you do not find the described accessories, contact Panasonic Technical Support (è pages 33 - 37).

• AC Adaptor . . . . . 1 • AC Cord . . . . . . . 1 • Battery Pack . . . 1

Model No: CF-AA5713A Model No: CF-VZSU46AU CF-VZSU72U

(Refer to “Specifications” (

è

page 30).)

<Only for model with touchscreen>

• Soft Cloth . . . . . . 1 • Tether . . . . . . . . . 1 • Stylus . . . . . . . . . 1

1

Reference Manual “Screen Input Operation”)

• OPERATING INSTRUCTIONS (This book) . . . . . . . . . . . . . . . . .1

B

Read the LIMITED USE LICENSE AGREEMENT before breaking the seal on the computer’s packaging

(è page 27).

4

3

2

1

5

1 Inserting the Battery Pack

A

Slide the latch (A) to the right to unlock the cover.

B

Slide the latch (A) down, and open the cover.

C

Insert the battery pack until it securely fits the connector.

D

Close the cover until it clicks.

E

Slide the latch (B) to the left to lock the cover.

CAUTION

l

Make sure the latch is securely locked. Otherwise the battery pack may fall when you carry the computer.

l

Do not touch the terminals of the battery pack and the computer. Doing so can make the terminals dirty or damaged, and may cause malfunction of the battery pack and the computer.

NOTE

l

Note that the computer consumes electricity even when the computer power is off. If the battery pack is fully charged, the battery will fully discharge in the following period of time:

• When power is off: Approx. 6 weeks (with CF-VZSU46AU) / Approx. 3 weeks

(with CF-VZSU72U)

(with • In sleep: Approx. 3 days

*1

(with CF-VZSU46AU) / Approx. 1.5 days

*1

CF-VZSU72U)

• In hibernation: Approx. 6 days

*1

(with CF-VZSU46AU) / Approx. 3 days

*1

(with

*1

CF-VZSU72U)

If “Wake Up from wired LAN” is disabled, the period of time will be longer.

14

DFQW5649XAT_CF-31mk3_EN.indb 14 2013/06/21 14:53:27

2

2 Attaching the stylus to the computer (only for model with touchscreen)

Use the tether to attach the stylus to the computer so you will not lose it. There are holes (A) to attach it.

1

3

2 4

3

1

4

CAUTION

l

Do not pull the tether with excessive force. The stylus may hit the computer, person’s body or other objects when released.

3 Opening the Display

A

Push and hold the latch (A), and lift open the display.

5

1

DFQW5649XAT_CF-31mk3_EN.indb 15

4 Connect your computer to a power outlet.

The battery charging starts automatically.

CAUTION

l

Do not disconnect the AC adaptor and do not switch the wireless switch to on until the first-time operation procedure is completed.

l

When using the computer for the first time, do not connect any peripheral device except the battery pack and AC adaptor.

l

Handling the AC adaptor

Ÿ

Problems such as sudden voltage drops may arise during periods of thunder and lightning. Since this could adversely affect your computer, an uninterruptible power source (UPS) is highly recommended unless running from the battery pack alone.

5 Turn on the computer.

A

Slide and hold the power switch until the power indicator lights.

CAUTION

l

Do not slide the power switch repeatedly.

l

The computer will forcibly be turned off if you slide and hold the power switch for

4 seconds or longer.

l

Once you turn off the computer, wait for 10 seconds or more before you turn on the computer again.

l

Do not perform the following operation until the hard disk drive indicator turns off.

Ÿ

Connecting or disconnecting the AC adaptor

Ÿ

Sliding the power switch

15

2013/06/21 14:53:29

First-time Operation

Ÿ

Touching the keyboard, touch pad or touchscreen (only for model with touchscreen)

Ÿ

Closing the display

Ÿ

Turn on/off the wireless switch l

When the CPU temperature is high, the computer may not start up to prevent overheating of the CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support (è pages 33 - 37).

l

Any changes from the default setting of the Setup Utility must not be made until the First-time Operation is completed.

6 Setup Windows.

Follow the on-screen instructions.

l

The computer restarts several times. Do not touch the keyboard or touch pad, and wait until the hard disk drive indicator has turned off.

l

After the computer is turned on, the screen remains black or unchanged for a while. This is not a malfunction. Wait for a moment until the Windows setup screen appears.

l

During setup of Windows, use the touch pad and clicking to move the cursor and to click an item.

l

Setup of Windows will take approximately 20 minutes.

Go to the next step, confirming each message on the display.

l

“Join a wireless network” screen may not appear.

You can set the Wireless Network after the setup of Windows is complete.

CAUTION

l

You can change the user name, password, image and security setting after setup of Windows.

l

Remember your password. If you forget the password, you cannot use Windows. Creating a password reset disk beforehand is recommended.

l

Do not use the following words for user name: CON, PRN, AUX, CLOCK$, NUL,

COM1 to COM9, LPT1 to LPT9, @. In particular, if you create a user name (account name) that includes the “@” mark, a password will be requested at the log-on screen, even if no password has been set. If you try to log on without entering a password, “The user name or password is incorrect.” may be displayed and you will not be able to log on to Windows (è page 24).

7 <Only for model with touchscreen>

Perform the touchscreen calibration.

Before performing the calibration, close Tablet PC Input Panel.

n

Calibration by an administrator

NOTE

l

At first, log on to Windows as an administrator and perform this calibration.

A

Click (Start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Setting].

B

Click [Calibrate].

C

Using the stylus, touch each of the “+” target marks one by one, and then click [Yes].

D

Click [OK].

n

Calibration by a standard user

NOTE

l

Perform the following calibration for each user.

A

Click (Start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Setting].

B

Click [Calibrate].

C

Using the stylus, touch each of the “+” target marks one by one, and then click [Yes].

16

DFQW5649XAT_CF-31mk3_EN.indb 16 2013/06/21 14:53:29

D

Click [OK].

l

Perform the calibration for the orientation to be used.

NOTE

l

PC Information Viewer

This computer periodically records the management information of the hard disk, etc. The maximum data volume for each record is 1024 bytes.

This information is only used for estimating the cause in the case when the hard disk goes down by any possibility. They are never sent to outside via network nor used for any other purpose except for the purpose described the above.

To disable the function, add the check mark for [Disable the automatic save function for management information history] in [Hard Disk Status] of PC Information Viewer, and click [OK].

Reference Manual “Checking the Computer’s Usage Status”) n

Precaution against Starting Up/Shutting Down

l

Do not do the following

Ÿ

Connecting or disconnecting the AC adaptor

Ÿ

Sliding the power switch

Ÿ

Touching the keyboard, touch pad, touchscreen (only for model with touchscreen), or external mouse

Ÿ

Closing the display

Ÿ

Turn on/off the wireless switch

NOTE

l

To conserve power, the following power saving methods are set at the time of purchase.

Ÿ

The screen automatically turns off after 10 minutes of inactivity.

Ÿ

The computer automatically enters sleep

*2

after 20 minutes of inactivity.

*2

Refer to Reference Manual “Sleep and Hibernation Functions” about resuming from sleep.

n

To change the partition structure

You can shrink a part of an existing partition to create unallocated disk space, from which you can create a new partition. This computer has a single partition as default setting.

A

Click (Start) and right-click [Computer], then click [Manage].

l

A standard user needs to enter an administrator password.

B

Click [Disk Management].

C

Right-click the partition for Windows (“c” drive in the default setting), and click [Shrink Volume].

l

The partition size depends on the computer specifications.

D

Input the size in [Enter the amount of space to shrink in MB] and click [Shrink].

l

You cannot input a larger number than the displayed size.

l

To select [Reinstall to the first 3 partitions.] in reinstalling Windows 7 (è page 22), 30000 MB or more is necessary for [Total size after shrink in MB].

E

Right-click [Unallocated] (the shrunk space in the step D) and click [New Simple Volume].

F

Follow the on-screen instructions to make the settings, and click [Finish].

Wait until formatting is completed.

NOTE

l

You can create an additional partition using remaining unallocated space or newly creating unallocated space.

l

To delete a partition, right-click the partition and click [Delete Volume] in step C.

DFQW5649XAT_CF-31mk3_EN.indb 17

17

2013/06/21 14:53:29

On-screen Manual

You can access the following manuals on the computer screen.

n

Reference Manual

The Reference Manual contains the practical information to help you fully enjoy the computer’s performance.

To access the Reference Manual:

Double-click on the desktop.

l

Alternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual].

n

Important Tips

The Important Tips will provide you with the battery information so that you can use the battery pack in the optimum condition to obtain longer operation time.

To access the Important Tips:

Double-click on the desktop.

l

Alternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips].

18

DFQW5649XAT_CF-31mk3_EN.indb 18 2013/06/21 14:53:29

Handling and Maintenance

Operation environment

l

Place the computer on a flat stable surface not subject to shock, vibration, and danger of dropping. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged.

l

Operating environment

Temperature: Operation : -10 °C to 50 °C {14 °F to 122 °F} (IEC60068-2-1, 2)

*1

Storage : -20 °C to 60 °C {-4 °F to 140 °F}

Humidity: Operation : 30% to 80% RH (No condensation)

Storage : 30% to 90% RH (No condensation)

Even within the above temperature/humidity ranges, operation for a long time in extreme environments, smoking nearby, or operation in places where oil is used or where there is a lot of dust will result in the product deterioration and will shorten the product life.

*1

Do not expose the skin to this product when using the product in a hot or cold environment. such temperatures.

page 10)

If the computer is wet in temperatures of 0 °C {32 °F} or below, freeze damage may occur. Make sure to dry off the computer in l

Do not place the computer in the following areas, otherwise the computer may be damaged.

Ÿ

Near electronic equipment. Image distortion or noise may occur.

Ÿ

In extremely high or low temperature.

l

As the computer can become hot during operation, keep it away from items that are sensitive to heat.

Handling cautions

This computer is designed to minimize shock to parts such as the LCD and the hard disk drive and equipped with a drip-proof keyboard, but no warranty is provided against any trouble caused by shock. Be extremely careful when handling the computer.

l

When carrying the computer:

Ÿ

Turn off the computer.

Ÿ

Remove all external devices, cables, PC Cards and other protruding objects.

Ÿ

Remove a disc in the CD/DVD drive.

Ÿ

Do not drop or hit the computer against solid objects.

Ÿ

Do not leave the display open.

Ÿ

Do not grip the display part.

l

Do not put anything (e.g., a piece of paper) between the display and keyboard.

l

When you board an airplane, take the computer with you and never put it in your checked luggage. When using the computer on airplane, follow the airline’s instructions.

l

When carrying a spare battery, put it in a plastic bag to protect its terminals.

l

The touch pad is designed to be used by finger tip. Do not place any object on its surface and do not press down strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).

l

Avoid any harmful substances such as oil from getting into the touch pad. The cursor may not work correctly.

l

Be careful not to get injured by dropping or getting hit when carrying the computer.

<Only for model with touchscreen> l

Use only the included stylus to touch the touchscreen. Do not place any object on its surface and do not press down strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).

l

Do not use the touchscreen when dust or dirt (e.g., oil) is on the screen. Otherwise foreign particles on the screen/ stylus can scratch the screen surface or obstruct the stylus operation.

l

Use the stylus only for touching the screen. Using it for any other purpose may damage the stylus and result in scratches on the screen.

n

When using peripheral devices

Follow these instructions and the Reference Manual to avoid any damage to the devices. Carefully read the instruction manuals of the peripheral devices.

l

Use the peripheral devices conforming to the computer’s specifications.

l

Connect to the connectors in the correct direction.

l

If it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of pins, etc.

l

If screws are included, fasten them securely.

l

Remove the cables when you carry the computer. Do not pull the cables forcibly.

19

2013/06/21 14:53:29 DFQW5649XAT_CF-31mk3_EN.indb 19

Handling and Maintenance

n

Preventing your computer from unauthorized use via wireless LAN/Bluetooth/wireless WAN

<Only for model with wireless LAN/Bluetooth/wireless WAN> l

Before using wireless LAN/Bluetooth/wireless WAN, make the appropriate security settings such as data encryption.

n

Battery Recalibration

l

The battery recalibration may take a long time due to the large battery capacity. This is not a malfunction.

<When performing "Battery Recalibration" after shutting down Windows>

Only for model with CF-VZSU46AU

Ÿ

Full charge: Approximately 4.5 hours (with Main Battery) / 8.0 hours (with Main Battery + Second Battery)

Ÿ

Complete discharge: Approximately 4.0 hours (with Main Battery) / 6.0 hours (with Main Battery + Second Battery)

Only for model with CF-VZSU72U

Ÿ

Full charge: Approximately 2.5 hours (with Main Battery) / 6.0 hours (with Main Battery + Second Battery)

Ÿ

Complete discharge: Approximately 3.0 hours (with Main Battery) / 6.0 hours (with Main Battery + Second Battery)

When performing "Battery Recalibration" without shutting down Windows, it may take more time to charge / discharge.

Maintenance

To clean the LCD panel

If drops of water or other stains get on the surface of the LCD panel, wipe them off immediately. Failure to do so may result in staining.

<Only for model with touchscreen>

Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD

Surface”. è Reference Manual “Screen Input Operation”)

To clean areas other than the LCD panel

Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted detergent and wring it thoroughly.

CAUTION

l

Do not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc.

Do not use commercially-available household cleaners and cosmetics, as they may contain components harmful to the surface.

l

Do not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause malfunction or damage.

20

DFQW5649XAT_CF-31mk3_EN.indb 20 2013/06/21 14:53:29

Reinstalling Software

Reinstalling software will return the computer to the default condition. When you reinstall the software, the hard disk data will be erased.

Back up important data to other media or an external hard disk before reinstallation.

n

Hard Disk Recovery

CAUTION

l

Do not delete the recovery partition on the hard disk.

The disk space in the partition is not available to store data.

Hard disk

HDD Recovery partition

Recovery partition

Area usable by Windows

Preparation

l

Remove all peripherals.

l

Connect the AC adaptor and do not remove it until reinstallation is complete.

1 Turn on the computer, and press

F2

or

Del

while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

2 Write down all of the contents of the Setup Utility and press

F9

.

At the confirmation message, select [Yes] and press Enter.

3 Press

F10

.

At the confirmation message, select [Yes] and press Enter.

Computer will restart.

4 Press

F2

or

Del

while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

5 Select the [Exit] menu, then select [Recovery Partition] and press

Enter

.

6 Click [Reinstall Windows] and click [Next].

The License Agreement screen appears.

7 Click [Yes, I agree to the provisions above and wish to continue!] and click [Next].

8 Select the settings and click [Next].

l

[Reinstall Windows to the whole Hard Disk to factory default.]

Select this option when you want to reinstall Windows to the factory default. After reinstallation, you can create a new partition. For how to create a new partition, refer to “To change the partition structure” (è page 17).

l

[Reinstall to the System and OS partitions.]

*1

Select this option when the hard disk has already been divided into several partitions. For how to create a new partition, refer to “To change the partition structure” (è page 17).

You can keep the partition structure.

*1

This does not appear if Windows cannot be reinstalled to the partition containing boot files and the area usable by Windows.

9 At the confirmation message, click [OK].

10 Select OS (32bit or 64bit) and click [OK].

11 At the confirmation message, click [OK].

Reinstallation starts according to the instructions on the screen.

l

Do not interrupt reinstallation, for example by turning off the computer. Otherwise reinstallation may become unavailable as Windows may not start up or the data may be corrupted.

12 When ending screen is displayed, click [OK] to turn off the computer.

13 Turn on the computer.

l

If the password is requested, enter the Supervisor Password.

14 Perform the “First-time Operation” (è page 15).

15 Start the Setup Utility and change the settings as necessary.

16 Perform Windows Update.

21

2013/06/21 14:53:29 DFQW5649XAT_CF-31mk3_EN.indb 21

Reinstalling Software

n

Using Recovery Disc

Use the Recovery Disc for reinstallation in the following conditions.

Ÿ

You have forgotten the administrator password.

Ÿ

Reinstallation is not complete. The recovery partition may be broken.

NOTE

Ÿ

To change OS from 32 bit to 64 bit, or vice versa, reinstall OS using the recovery partition in the hard disk.

Preparation

l

Prepare the Recovery Disc (è Reference Manual “Recovery Disc Creation Utility”) l

Remove all peripherals.

l

Connect the AC adaptor and do not remove it until reinstallation is complete.

1 Turn on the computer, and press

F2

or

Del

while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

2 Write down all of the contents of the Setup Utility and press

F9

.

At the confirmation message, select [Yes] and press Enter.

3 Press

F10

.

At the confirmation message, select [Yes] and press Enter.

Computer will restart.

4 Press

F2

or

Del

while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

5 Set the Recovery Disc into the CD/DVD drive.

6 Select the [Exit] menu, then select [TEAC DV-W28S-W] in [Boot Override].

7 Press

Enter.

The computer will restart.

8 Click [Reinstall Windows] and click [Next].

The License Agreement screen appears.

9 Click [Yes, I agree to the provisions above and wish to continue!] and click [Next].

10 Select the settings and click [Next].

l

[Reinstall Windows to the whole Hard Disk to factory default.]

Select this option when you want to reinstall Windows to the factory default. After reinstallation, you can create a new partition. For how to create a new partition, refer to “To change the partition structure” (è page 17).

l

[Reinstall to the first 3 partitions.] *2

Select this option when the hard disk has already been divided into several partitions. For how to create a new partition, refer to “To change the partition structure” (è page 17).

You can keep the partition structure.

*2

This does not appear if Windows cannot be reinstalled to the partition containing boot files and the area usable by Windows.

11 At the confirmation message, click [YES].

Reinstallation starts.

According to the screen, replace the Recovery Disc.

l

Do not interrupt reinstallation, for example by turning off the computer. Otherwise reinstallation may become unavailable as Windows may not start up or the data may be corrupted.

12 When “Ending process.” is displayed, remove the Recovery Disc, and then click [OK] to turn off the computer.

13 Turn on the computer.

l

If the password is requested, enter the Supervisor Password.

14 Perform the “First-time Operation” (è page 15).

15 Start the Setup Utility and change the settings as necessary.

16 Perform Windows Update.

22

DFQW5649XAT_CF-31mk3_EN.indb 22 2013/06/21 14:53:30

Troubleshooting (Basic)

Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the

“Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact Panasonic Technical Support (è pages 33 - 37). You can also check the computer’s status in the PC Information

Viewer (è Reference Manual “Troubleshooting (Advanced)”).

n

Starting Up

Cannot start up.

The power indicator or battery indicator is not lit.

The power is turned on but

“Warming up the system (up to 32 minutes)” appears.

Cannot turn on the computer.

The computer does not resume from sleep.

(The power indicator blinks alternately in orange and green.)

After adding or changing the RAM module, the power is turned on but nothing is displayed on the screen.

The computer does not enter sleep mode while the screen saver is running. (The screen stays black.)

You have forgotten the password.

l

Connect the AC adaptor.

l

Insert a fully charged battery.

l

Remove the battery pack and the AC adaptor, then connect them again. l

If a device is connected to the USB port, disconnect the device, or set [USB Port] or

[Legacy USB Support] to [Disable] in the [Advanced] menu of the Setup Utility.

l

If a device is connected to the ExpressCard slot, disconnect the device, or set

[ExpressCard Slot] to [Disable] in the [Advanced] menu of the Setup Utility.

l

Press Fn + F8 to turn off the concealed mode.

l

The computer is warming up before start up. Wait for the computer to start up (takes up to 32 minutes). If, “Cannot warm up the system” is displayed, the computer failed to warm up and will not start. In this case, turn off the computer, leave it in an environment of 5 °C {41 °F} or higher temperature for about an hour, and then turn on the power again.

l

Leave it in an environment of 5 °C {41 °F} or higher temperature for about an hour, then turn on the power again.

l

Turn off the computer and remove the RAM module, then confirm whether the RAM module has compliant to specification. When the RAM module has conformed to specification, install it again.

l

Slide and hold the power switch for four seconds or longer to shut down the computer forcibly. (Data not saved will be lost.) Then disable the screen saver.

“Remove disks or other media. Press any key to restart” or a similar message appears.

Windows startup and operation is slow.

The date and time are incorrect.

l

Supervisor Password or User Password: Contact Panasonic Technical Support

(è pages 33 - 37).

l

Administrator password:

Ÿ

If you have a password reset disk, you can reset the administrator password. Set the disk and enter any wrong password, then follow the on-screen instructions and set a new password.

Ÿ

If you do not have a password reset disk, reinstall (è page 21) and set up Windows, and then set a new password.

l

A floppy disk is in the drive (optional) and it does not contain system startup information.

Remove the floppy disk and press any key.

l

If a device is connected to the USB port, disconnect the device, or set [USB Port] or

[Legacy USB Support] to [Disable] in the [Advanced] menu of the Setup Utility.

l

If a device is connected to the ExpressCard slot, disconnect the device, or set

[ExpressCard Slot] to [Disable] in the [Advanced] menu of the Setup Utility.

l

If the problem persists after removing the disk, it may be a hard disk failure. Contact

Panasonic Technical Support (è pages 33 - 37).

l

Press

F9

in the Setup Utility (è Reference Manual “Setup Utility”) to return the

Setup Utility settings (excluding the passwords) to the default values. Start the Setup

Utility and make the settings again. (Note that the processing speed depends on the application software, so this procedure may not make Windows faster.) l

If you installed a resident software after purchase, turn off the residence.

l

Make the correct settings.

Click (Start) - [Control Panel] - [Clock, Language, and Region] - [Date and Time].

l

If the problem persists, the internal clock battery may need to be replaced. Contact

Panasonic Technical Support (è pages 33 - 37).

l

When the computer is connected to LAN, check the date and time of the server.

l

The 2100 A.D. or later year will not be correctly recognized on this computer.

DFQW5649XAT_CF-31mk3_EN.indb 23

23

2013/06/21 14:53:30

Troubleshooting (Basic)

n

Starting Up

[Executing Battery Recalibration] screen appears.

[Enter Password] does not appear when resuming from sleep/hibernation.

Cannot resume.

Other startup problems.

l

The Battery Recalibration was cancelled before Windows was shut down last time. To start up Windows, turn off the computer by the power switch, and then turn on.

l

Select [Enabled] in [Password On Resume] in the [Security] menu of the Setup Utility

Reference Manual “Setup Utility”).

l

The Windows password can be used instead of the password set in the Setup Utility.

A

Click

B

Click

(Start) move user accounts] and select the account, and set the password.

(Start)

- [Control Panel] - [User Accounts and Family Safety] - [Add or re-

- [Control Panel] - [System and Security] - [Power Option] - [Require a password when the computer wakes] and add a check mark for [Require a password].

l

An error may occur when the computer automatically enters the sleep or hibernation mode while the screensaver is active. In this case, turn off the screensaver or change the pattern of the screensaver.

l

Press F9 Reference Manual “Setup Utility”) to return the

Setup Utility settings (excluding the passwords) to the default values. Start the Setup

Utility and make the settings again.

l

Remove all peripheral devices.

l

Check to see if there was a disk error.

A

Remove all peripheral devices including external display.

B

Click

in the Setup Utility (è

(Start)

- [Computer] and right-click [Local Disk (C:)], and click [Properties].

C

Click [Tools] - [Check Now...].

Ÿ

A standard user needs to enter an administrator password.

D

Select the option in [Check disk options] and click [Start].

E

Click [Schedule disk check] and restart the computer.

l

Start the computer in Safe Mode and check the error details. When the [Panasonic] boot screen disappears

*1

at startup, press and hold

Menu is displayed. Select the Safe Mode and press enter the password and press

F8

until the Windows Advanced Options

Enter .

*1

When [Password on boot] is set to [Enabled] in the [Security] menu of the Setup Utility,

[Enter Password] appears after the [Panasonic] boot screen disappears. As soon as you

Enter

, press and hold

F8

.

n

Entering Password

Even after entering the password, password input screen is displayed again.

Cannot log on to Windows.

(“The user name or password is incorrect.” is displayed.) l

The computer may be in ten-key mode.

If the NumLk indicator lights, press NumLk input.

l

The computer may be in Caps Lock mode.

If the Caps Lock indicator lights, press mode, and then input.

to disable the ten-key mode, and then

Caps Lock

to disable the Caps Lock l

The user name (account name) includes the “@” mark.

- If another user account name exists:

Log on to Windows using another user account name, and delete the account name that includes “@”. Then create a new account name.

- If no other account name exists:

You need to reinstall Windows (è page 21).

n

Shutting down

Windows does not shut down.

l

Remove the USB device and the ExpressCard.

l

Wait 1 or 2 minutes. It is not a malfunction.

24

DFQW5649XAT_CF-31mk3_EN.indb 24 2013/06/21 14:53:30

n

Display

No display.

The screen is dark.

l

The external display is selected. Press

Fn

+

F3

or +

P

to switch the display. Wait until the display has been switched completely before pressing

Ctrl .

Fn

+

F3

or +

P again.

l

When using an external display,

Ÿ

Check the cable connection.

Ÿ

Turn on the display.

Ÿ

Check the settings of external display.

l

The display is turned off by the power-saving function. To resume, do not press the direct selection keys, but press any other key like l

The computer entered sleep or hibernation by the power-saving function. To resume, press the power switch.

l

The screen is darker when the AC adaptor is not connected. Press

Fn

+

F2

and adjust the brightness. As you increase the brightness, battery consumption increases.

You can separately set the brightness for when the AC adaptor is connected and when not connected.

l

Press Fn + F8 to turn off the concealed mode.

<Only for model with discrete video controller>

“The application is not currently associated with a specific graphics processor.” is displayed when quitting an application program or screen saver that uses 3D graphics.

l

Click [Configure]. The [Catalyst Control Center] screen appears. To run the program or screen saver while activating the discrete video controller, select [High Performance] for the program listed on [Recent Applications]. If you want to run the program without activating the discrete video controller, select [Power Saving] instead of [High Performance].

If you do not select either [High Performance] or [Power Saving] (the status remains “Not

Assigned”), the program will run as if you had selected [Power Saving].

Also, you can right-click the desktop and select [Configure Switchable Graphics] on the menu to display the [Catalyst Control Center] screen. This enables you to assign an application program to either [High Performance] or [Power Saving] in advance by selecting [Other Applications] - [Browse].

l

The brightness is set low to avoid malfunction where surrounding temperature is high.

Use it in an environment of between -10 °C and 50 °C {14 °F to 122 °F}.

The screen does not become bright even if pressing

Fn

+

F2.

The screen is disordered.

During Simultaneous display, one of the screens becomes disordered.

The external display does not work normally.

l

Changing the number of display colors and resolution may affect the screen. Restart the computer.

l

Connecting/disconnecting an external display may affect the screen. Restart the computer.

l

When using the Extended Desktop, use the same display colors for the external display as those used by the LCD.

l

If you continue to experience problems, try changing the display.

Click (Start) - [All Programs] - [Panasonic] - [Display Selector].

l

Simultaneous display cannot be used until Windows startup is complete (during Setup

Utility, etc.).

l

If the external display does not support the power saving function, it may not work normally when the computer enters the power saving mode. Turn off the external display.

DFQW5649XAT_CF-31mk3_EN.indb 25

25

2013/06/21 14:53:30

Troubleshooting (Basic)

n

Display

<Only for model with GPS>

The cursor cannot be controlled properly.

l

Operate the following steps.

A

Restart the computer and press played.

B

Set [GPS] to [Disabled] in the sub-menu of [Serial and Parallel Port Settings] in the

[Advanced] menu of the Setup Utility.

C

Press F10

F2 or

The computer will restart.

D

Log on to Windows as an administrator.

Del while [Panasonic] boot screen is dis-

and select [Yes] at the confirmation message, and press Enter .

E

Click (Start) and input “c:\util\drivers\gps\GPS.reg” in [Search programs and files], and press

Enter

[Advanced] menu.

I

Press

.

F

Click [Yes], click [Yes], and click [OK].

Then restart the computer.

G

Press F2 while [Panasonic] boot screen is displayed.

H

Set [GPS] to [Enabled] in the sub-menu of [Serial and Parallel Port Settings] in the

F10 and select [Yes] at the confirmation message, and press Enter .

n

Touch Pad / Touchscreen (only for model with touchscreen)

The cursor does not work.

l

When using the external mouse, connect it correctly.

l

Restart the computer using the keyboard.

Press and press è two times, and press  to select [Restart] and press l

If the computer does not respond to keyboard commands, read “No response”

(è below).

Enter

.

Cannot input using the touch pad.

l

Set [Touch Pad] to [Enable] in the [Main] menu of the Setup Utility.

l

The drivers for some mice may disable the touch pad. Check your mouse’s operating instructions.

l

Set [Touchscreen Mode] to [Auto] or [Tablet] in the [Main] menu of the Setup Utility.

<Only for model with touch screen>

Cannot input using the touchscreen.

Cannot point the correct position using the included stylus.

l

Perform the touchscreen calibration (è page 16).

n

On-screen Document

The document of PDF format is not displayed.

l

Install Adobe Reader.

A

Log on to Windows as an administrator.

B

Click

(Start) and input “c:\util\reader\AdbeRdr1001_en_US.exe” in [Search programs and files] then press Enter

.

C

Update Adobe Reader to its latest version.

If your computer is connected to the internet, start up Adobe Reader and click [Help]

- [Check for Updates...].

n

Others

No response.

l

Press

Ctrl

+

Shift

+ that is not responding.

Esc

to open Task Manager and close the software application l

An input screen (e.g., password input screen at startup) may be hidden behind another window. Press

Alt

+

Tab

to check.

l

Slide the power switch for 4 seconds or longer to shut down the computer, and then slide the power switch to turn it on. If the application program does not work normally, uninstall and reinstall the program. To uninstall, click (Start) - [Control Panel] - [Programs] - [Uninstall a program].

26

DFQW5649XAT_CF-31mk3_EN.indb 26 2013/06/21 14:53:30

LIMITED USE LICENSE AGREEMENT

THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC PRODUCT (“PRODUCT”)

ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH

THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY

DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.

Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended results, and for the installation, use and results obtained therefrom.

LICENSE

A. Panasonic Corporation hereby grants you a personal, non-transferable and non-exclusive right and license to use the Programs in accordance with the terms and conditions stated in this Agreement. You acknowledge that you are receiving only a LIMITED LICENSE TO USE the Programs and related documentation and that you shall obtain no title, ownership nor any other rights in or to the Programs and related documentation nor in or to the algorithms, concepts, designs and ideas represented by or incorporated in the Programs and related documentation, all of which title, ownership and rights shall remain with Panasonic Corporation or its suppliers.

B. You may use the Programs only on the single Product which was accompanied by the Programs.

C. You and your employees and agents are required to protect the confidentiality of the Programs. You may not distribute or otherwise make the Programs or related documentation available to any third party, by time-sharing or otherwise, without the prior written consent of Panasonic Corporation.

D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documentation for any purpose, except that you may make one (1) copy of the Programs for backup purposes only in support of your use of the Programs on the single Product which was accompanied by the Programs. You shall not modify, or attempt to modify, the Programs.

E. You may transfer the Programs and license them to another party only in connection with your transfer of the single

Product which was accompanied by the Programs to such other party. At the time of such a transfer, you must also transfer all copies, whether in printed or machine readable form, of every Program, and the related documentation, to the same party or destroy any such copies not so transferred.

F. You may not remove any copyright, trademark or other notice or product identification from the Programs and you must reproduce and include any such notice or product identification on any copy of any Program.

YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE

THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.

YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN

WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.

IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PER-

MITTED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.

TERM

This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may terminate this license at any time by destroying, at your expense, the Programs and related documentation together with all copies thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions thereof set forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon any such termination, you agree to destroy, at your expense, the Programs and related documentation together with all copies thereof in any form.

YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND

BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATE-

MENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,

ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MAT-

TER OF THIS AGREEMENT.

GOVERNMENT RESTRICTED RIGHTS.

The Software is provided with “RESTRICTED RIGHTS.” Use duplication or disclosure by the government is subject to restrictions as set forth in FAR52.227-14 and DFAR252. 227-7013 et seq. or their successors.

Use of the Software by the government constitutes acknowledgement of Intel’s proprietary rights therein.

Contractor or Manufacturer is Intel Corporation, 2200 Mission College Blvd., Santa Clara, CA 95052.

27

2013/06/21 14:53:30 DFQW5649XAT_CF-31mk3_EN.indb 27

Contrat de licence d’usage limité

Le(s) logiciel(s) (les “Logiciels”) fournis avec ce produit Panasonic (le “Produit”) sont exclusivement concédés en licence à l’utilisateur ultime (“vous”), et ils ne peuvent être utilisés que conformément aux clauses contractuelles cidessous. En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et conditions des présentes.

Panasonic Corporation a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.

Licence

A. Panasonic Corporation vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs d’utiliser les Logiciels conformément aux termes, clauses et conditions de ce contrat. Vous reconnaissez ne recevoir qu’un droit limité d’utiliser les Logiciels et la documentation les accompagnant et vous vous engagez à n’ obtenir aucun droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-à-vis des algorithmes, concepts, dessins, configurations et idées représentés par ou incorporés dans les Logiciels et la documentation les accompagnant, dont les titres, propriété et droits resteront tous à Panasonic

Corporation ou à leurs propriétaires.

B. Vous ne pouvez utiliser les Logiciels que sur le Produit unique qui est accompagné par les Logiciels.

C. Vous et vos employés ou agents êtes requis de protéger la confidentialité des Logiciels. Vous ne pouvez ni distribuer ni mettre les Logiciels et la documentation les accompagnant à la disposition d’un tiers, par partage de temps ou de quelque autre manière que ce soit, sans l’autorisation écrite préalable de Panasonic Corporation.

D. Vous ne pouvez ni copier ni reproduire ni permettre la copie ni la reproduction des Logiciels ni de la documentation les accompagnant pour quelque fin que ce soit, à l’exception d’une (1) copie des Logiciels à des fins de sauvegarde uniquement pour soutenir votre utilisation des Logiciels sur le Produit unique qui est accompagné par les

Logiciels. Vous ne pouvez ni modifier ni tenter de modifier les Logiciels.

E. Vous ne pouvez céder les Logiciels et en octroyer la licence à une autre partie qu’en rapport avec votre cession du

Produit unique qui est accompagné par les Logiciels à cette autre partie. Au moment de cette cession, vous devez céder également toutes les copies, que ce soit sous forme imprimée ou lisible par la machine, de tous les Logiciels ainsi que de la documentation les accompagnant, à la même partie ou détruire les copies non cédées.

F. Vous ne pouvez retirer aucune marque de droits d’auteur, marque de commerce ou autre ni aucune identification de produit des Logiciels et vous devez reproduire et inclure toutes ces notices ou identifications de produit sur toutes les copies des Logiciels.

Vous ne pouvez assembler en sens inverse, compiler en sens inverse ni retracer les Logiciels ni aucune de leurs copies, de façon électronique ou mécanique, en tout ou en partie.

Vous ne pouvez utiliser, copier, modifier, altérer ni céder les Logiciels ni aucune de leurs copies, en tout ou en partie, à l’exception de ce qui est expressément stipulé dans ce contrat.

Si vous cédez la possession de toute copie ou de tout Logiciel à une autre partie, à l’exception de ce qui est autorisé au paragraphe E ci-dessus, votre licence est automatiquement résiliée.

Termes, clauses et conditions

Cette licence n’est effective que pour la durée de possession ou de crédit-bail du Produit, à moins d’une résiliation antérieure. Vous pouvez résilier cette licence à tout moment en détruisant, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme que ce soit. Cette licence sera également résiliée, avec application immédiate, si les conditions de résiliation définies ailleurs dans ce contrat se sont réalisées ou si vous ne respectez pas les termes, clauses et conditions qui y sont contenues. Au moment de la résiliation, vous acceptez de détruire, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme que ce soit.

Vous reconnaissez avoir lu ce contrat, en avoir compris toute la substance et avoir accepté de respecter ses termes, clauses et conditions. Vous reconnaissez en outre qu’ils sont la description complète et exclusive du contrat conclu entre nous, contrat qui remplace et annule toute proposition ou contrat précédent, écrit ou oral, et toute autre communication entre nous, relativement à l’objet du présent contrat.

28

DFQW5649XAT_CF-31mk3_EN.indb 28 2013/06/21 14:53:30

Specifications

This page provides the specifications for the basic model.

The model number is different according to the unit configuration.

l

To check the model number:

Check the bottom of the computer or the box the computer came in at the time of purchase.

l

To check CPU speed, memory size and the hard disk drive (HDD) size:

Run the Setup Utility (è Reference Manual “Setup Utility”) and select [Information] menu.

[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Hard disk drive size n

Main Specifications

Model No.

Chip Set

CF-31UFLAXDM

CPU/Secondary cache memory i5-3360M Processor (3 MB cache, up to 3.5 GHz) with

Intel

®

*1

Turbo Boost Technology

CF-31SFLAXDM i5-3320M Processor (3 MB

*1 cache, up to 3.3 GHz) with

Intel

®

Turbo Boost Technology

Mobile Intel

®

QM77 Express Chipset

Video controller

Main Memory

*2

Video Memory

*1 *3

Hard Disk Drive

CF-31VFAAXDM i3-3110M Processor (3 MB

*1 cache, up to 2.4 GHz)

Mobile Intel

®

Chipset

HM75 Express

AMD Radeon™ HD

7750M+Built in Chip Set

4 GB

*1

, DDR3L SDRAM (8 GB

*1

(Built-in Chip Set)

Max.) 2 GB

*1

Max.)

, DDR3L SDRAM (4 GB

*1

<32 bit>

UMA (1785 MB Max.)

<64 bit>

UMA (1696 MB Max.)

<32 bit>

UMA (1419 MB Max.)

512 MB dedicated

500 GB

*4

(Serial ATA)

320 GB

*4

(Serial ATA)

Approx. 10 GB

*4

Approx. 300 MB

is used as a partition with HDD recovery tools. (Users cannot use this partition.)

*4

is used as a partition with recovery tools. (Users cannot use this partition.)

Display Method

Internal LCD

External Display

*6

Wireless LAN

*7

Bluetooth

*8

GPS

*9

Wireless WAN

*10

LAN

Modem

Sound

*12

Security Chip

Card Slots

RAM Module Slot

Interface

Keyboard / Pointing Device

Fingerprint Reader

*23

13.1 XGA type (TFT) (1024 × 768 dots)

65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots)

è

page 31

LR9101 (SirfStarIII)

*5

65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 768 dots/1280 × 1024 dots)

Intel

®

Centrino

®

Advanced - N 6235 (è page 30)

Sierra™ Wireless High-speed module

IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX,

IEEE 802.3ab 1000BASE-T

(2nd LAN

*11

: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX)

IEEE 802.3 10BASE-T,

IEEE 802.3u 100BASE-TX,

IEEE 802.3ab 1000BASE-T

Data: 56 kbps (V.92) FAX: 14.4 kbps

WAVE and MIDI playback, Intel

®

High Definition Audio subsystem support

TPM (TCG V1.2 compliant)

*13

PC Card Slot × 1, Type I or Type II, Allowable current 3.3 V: 400 mA, 5 V: 400 mA

ExpressCard Slot × 1, ExpressCard/34 or ExpressCard/54

× 1 SD Memory Card

Slot

*14

Contact Smart

Card Slot

*15

× 1

× 1, DDR3L SDRAM, 204-pin, 1.35 V, SO-DIMM, PC3L-10600

USB 2.0 ports

*16

x 3, USB 3.0 ports male) / Modem Port (RJ-11)

*16

x 1

*17

or USB 2.0 ports

*16

*12

/ LAN Port (RJ-45) × 1

*19

or × 2

x 4

*18

/ Serial Port (Dsub 9-pin

(Mini Dsub 15-pin female) / HDMI Port (Type A)

*20

*11

/ External Display Port (VGA)

/ IEEE1394a Interface Connector (4-pin)

*21 ance 32 W, Output Power 4 mW × 2, Stereo) / Expansion Bus Connector (Dedicated 100-pin female)

/

Microphone Jack (Miniature jack, 3.5 DIA) / Headphone Jack (Miniature jack, 3.5 DIA, Imped-

87 keys / Touch Pad / Touchscreen

*22

Array Size : 192 × 4 pixels, Image Size : 192 × 512 pixels, Image Resolution : 508 DPI

29

DFQW5649XAT_CF-31mk3_EN.indb 29 2013/06/21 14:53:30

Specifications

n

Main Specifications

Model No.

Web Camera

Power Supply

AC Adaptor

*25

Battery Pack

*24

Operating Time

Storage

*26

CF-31UFLAXDM

640 × 480 dots, 30 fps

CF-31SFLAXDM

AC adaptor or Battery pack

Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 7.05 A

<CF-VZSU46AU>

Li-ion 10.65 V, Typical 8550 mAh / Minimum 8100 mAh

CF-31VFAAXDM

Main Battery:

Approx. 12.0 hours

-

Main Battery:

Approx. 14.5 hours

Main Battery + Second Battery

Approx. 21.0 hours

*27

:

<CF-VZSU72U>

Li-ion 10.8 V,

Typical 4500 mAh /

Minimum 4200 mAh

Main Battery:

Approx. 8.0 hours

Main Battery + Second Battery

*27

Approx. 14.5 hours

:

Charging

Time

*28

Power on Main Battery: Approx. 4.5 hours

-

Main Battery + Second Battery

*27

Approx. 8.0 hours

:

Main Battery:

Approx. 2.5 hours

Main Battery + Second Battery

Approx. 6 hours

*27

:

Power off

Power Consumption

*29

Main Battery: Approx. 3.5 hours

-

Main Battery + Second Battery

*27

Approx. 7.0 hours

:

Approx. 55 W

*30

/

Approx. 100 W (maximum when recharging in the ON state)

302 mm × 292 mm × 73.5 mm {11.9" × 11.5" × 2.9"}

Main Battery: Approx. 2 hours

Main Battery + Second Battery

Approx. 5.5 hours

*27

Approx. 45 W

*30 in the ON state)

/ Approx. 100 W (maximum when recharging

:

Physical Dimensions (W × D × H)

(including the carrying handle)

Weight (including the hand strap) Approx. 3.72 kg {Approx. 8.2 lb.}

Operating Temperature -10 °C to 50 °C {14 °F to 122 °F} (IEC60068-2-1, 2)

*31

Humidity

Temperature

Humidity

30 % to 80 % RH (No condensation)

-20 °C to 60 °C {-4 °F to 140 °F}

30 % to 90 % RH (No condensation) n

Software

Installed OS

*32

Pre-installed Software

*32

Genuine Windows

®

7 Professional 32-bit Service Pack 1 / Genuine Windows 7 Professional

64-bit Service Pack 1

Adobe Reader, PC Information Viewer, Display Selector, Bluetooth Stack for Windows

TOSHIBA

*8

, Wireless Switch Utility, Intel

®

PROSet / Wireless Soft ware

*7

Disable Utility

*33 age

*13 *33

, Protector Suite

*23

®

by

, Wireless Connection

, Hotkey Settings, Battery Recalibration Utility, Infineon TPM Professional Pack-

Utility, Wireless Manager Mobile Edition 5.5f

*33 ity, Dashboard for Panasonic PC, GPS Viewer

Video switch Utility

*36

*33

, Aptio Setup Utility, Hard Disk Data Erase Utility

*34

*35

*9

, Camera Utility

, External Antenna Setting Utility, Wireless Antenna switch Utility, Recovery

Disc Creation Utility, Power Plan Extension Utility

, PC-Diagnostic

, Quick Boot Manager, Fan Monitoring Util-

*24

, System Interface Manager, n

Wireless LAN

*7

Data Transfer Rates

Standards Supported

Transmission method

IEEE802.11a : 54/48/36/24/18/12/9/6 Mbps (automatically switched)

IEEE802.11b : 11/5/2/1 Mbps (automatically switched)

*37

IEEE802.11g : 54/48/36/24/18/12/9/6 Mbps (automatically switched)

IEEE802.11n

*38

: (HT20) GI

*37

*37

*39

= 400ns: 144/130/115/86/72/65/57/43/39/28/21/14/7 Mbps

(automatically switched)

*37

GI

*39

(HT40) GI

*39

= 800ns: 130/117/104/78/65/58/52/39/26/19/13/6 Mbps

(automatically switched)

*37

GI

*39

= 400ns: 300/270/240/180/157/135/120/90/60/30/15 Mbps

(automatically switched)

*37

= 800ns: 270/243/216/162/135/121/108/81/54/40/27/13 Mbps

(automatically switched)

*37

IEEE802.11a / IEEE802.11b / IEEE802.11g / IEEE802.11n

OFDM system, DSSS system

30

DFQW5649XAT_CF-31mk3_EN.indb 30 2013/06/21 14:53:31

n

Wireless LAN

*7

Wireless Channels Used

RF Frequency Band

IEEE802.11a : Channels 36/40/44/48/52/56/60/64/100/104/108/112/116/120/124/128/132/136/

140/149/153/157/161/165

IEEE802.11b/IEEE802.11g : Channels 1 to 11

IEEE802.11n : Channels 1-11/36/40/44/48/52/56/60/64/100/104/108/112/116/132/136/140/149/

153/157/161/165

IEEE802.11a : 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz, 5.745 GHz - 5.825 GHz

IEEE802.11b/IEEE802.11g : 2.412 GHz - 2.462 GHz

IEEE802.11n : 2.412 GHz - 2.462 GHz, 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz, 5.745 GHz -

5.825 GHz n

Bluetooth

*8

Bluetooth Version

Transmission method

Wireless Channels Used

RF Frequency Band

4.0

Classic mode / Low Energy mode

FHSS system

Channel 1 to 79 / Channel 0 to 39

2.402 GHz - 2.480 GHz

*1

*2

You can physically expand the memory up to 8 GB, but the total amount of usable memory available will be less depending on the actual system configuration.

*3

1 MB = 1,048,576 bytes /1 GB = 1,073,741,824 bytes

Memory size of the factory default depends on the model.

*4

*5

*6

*7

*8

A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video

Memory cannot be set by the user.

1 MB = 1,000,000 bytes / 1 GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer

MB/GB.

A 16,777,216 color display is achieved by using the dithering function.

Display may be impossible using some connected external displays.

Only for model with wireless LAN.

Only for model with Bluetooth.

*9

*10

Only for model with GPS.

*11

Only for model with wireless WAN.

Only for model with 2nd LAN.

*12 Only for model with modem.

*13 Only for model with TPM

For information on TPM, refer to the Installation Manual of “Trusted Platform Module (TPM)” by the following procedure.

Click (Start) and input “c:\util\drivers\tpm\index.hta” in [Search programs and files] and press Enter .

*14

This slot is compatible with High-Speed Mode. Operation has been tested and confirmed using Panasonic SD/SDHC/SDXC

*15

Memory Cards with a capacity of up to 64 GB. Operation on other SD equipment is not guaranteed.

Only for model with Smart Card slot.

*16

Does not guarantee operation of all USB-compatible peripherals.

*17

Only for model with i5 processor

*18

Only for model with i3 processor

*19

Only for model without 2nd LAN.

*20

Does not guarantee operation of all HDMI-compatible peripherals.

*21

Only for model with IEEE 1394a interface.

*22

Only for model with Touchscreen.

*23

Only for model with Fingerprint reader.

*24

Only for model with Web Camera.

*25

<Only for North America>

The AC adaptor is compatible with power sources up to 240 V AC adaptor. This computer is supplied with a 125 V AC compat-

*26 ible AC cord.

20-M-2-1

Measured with LCD brightness : 60 cd/m

2

*27

Varies depending on the usage conditions, or when an optional device is attached.

Only for model with 2nd Battery.

*28

Varies depending on the usage conditions, CPU speed, etc.

*29

Approx. 0.5 W when the battery pack is fully charged (or not being charged) and the computer is off.

<When using with 115 V AC>

Even when the AC adaptor is not connected to the computer, power is consumed (Max. 0.2 W) simply by having the AC adaptor

*30 plugged into an AC outlet.

Rated power consumption.

23-E-1

*31

Do not expose the skin to this product when using the product in a hot or cold environment. (è page 10)

When using in hot or cold environment, some peripherals may fail to work properly. Check the operation environment of the peripherals.

Using this product continuously in a hot environment will shorten the product life. Avoid use in these types of environments.

When using in low temperature environment, startup may become slow or battery operation time may become short. The computer consumes power when the hard disk is warming up during startup. Therefore, if you are using battery power and the remaining power is low, the computer may not start up.

DFQW5649XAT_CF-31mk3_EN.indb 31

31

2013/06/21 14:53:31

Specifications

*32

When reinstalling Windows using the data of the recovery area on the hard disk, you can select the OS to be installed (either

Windows 7 (32-bit) or Windows 7 (64-bit)). An OS that has been installed at the time of purchase or an OS that has been installed using the hard disk recovery function or the recovery disc can be supported.

*33

Must be installed before use.

*34

Perform on the recovery partition. (If this software can not be performed on the recovery partition, perform from the recovery

*35 disc)

For information on Wireless Manager, refer to the “Supplementary Instructions for Wireless Manager mobile edition 5.5” by the following procedure.

Click (Start) and input “c:\util\wlprjct\Supplementary Instructions.pdf” in [Search programs and files] and press

*36

*37

Only for model with AMD Radeon™ HD 7750M.

These are speeds specified in IEEE802.11a+b+g+n standards.

Actual speeds may differ.

*38

Available when set to “WPA-PSK”, “WPA2-PSK” or “none”.

*39

Only available when HT40 enabled by the computer and access point which associated supports HT40.

Enter .

32

DFQW5649XAT_CF-31mk3_EN.indb 32 2013/06/21 14:53:31

LIMITED WARRANTY

For U.S.A.

Panasonic System Communications Company of North America (PSCNA)

Computer Products - Worldwide Warranties

Section 1: Limited Warranty - Hardware

PSCNA, referred hereafter as “Panasonic” will repair the products listed below with new or rebuilt parts, free of charge in a Global

Panasonic designated service location for the period specified below from the date of original purchase in the event of a defect in materials or workmanship. These warranties are extended solely to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty performance is rendered.

• Laptop PC (CF-##) – 3 Years

• Tablet PC (FZ-A#) – 3 Years

• Ultra-Mobile (CF-U#/CF-H# Series) – 3 Years

• PDRC - LCD & Keyboard Assembly – 3 Years

Battery Warranty

Batteries supplied with the product are covered under the warranty for one (1) year from date of purchase, except as excluded in Section 3. Batteries purchased separately are covered under the warranty for one (1) year from the date of purchase. A replacement battery furnished under the product warranty is covered for the remaining period of the one year warranty on the original or purchased battery.

Optional: Panasonic “Protection Plus” Warranty

Any unit for which the Panasonic “Protection Plus” warranty has been purchased will receive additional coverage for any failure that occurs due to accidental damage. All other terms and conditions of the standard warranty apply and this additional coverage will exist for the duration of the standard warranty period of the unit. If an extended Protection Plus warranty program is purchased, coverage is extended to the end of the last year of extended coverage purchased.

This warranty does not cover failures or defects that are caused by fire, intentional acts, loss, theft, improper maintenance, modification or service by anyone other than the Panasonic National Service Center or a Panasonic Authorized Service Provider, or damage that is attributable to acts of God. Cosmetic damage that does not affect functionality is not covered. Cosmetic damage on units with hardware failures will be repaired in accordance with the warranty terms. This warranty is extended solely to the original purchaser on the unit serial number for which it was purchased. Complete unit replacement fulfills the full obligation and is at the discretion of Panasonic and is limited to once during the coverage term. Maximum benefit is limited to one replacement per coverage year of the Motherboard, LCD, Storage Drive, and Keyboard.

Wireless Module Warranty

Panasonic approved wireless modems installed in Panasonic brand computers and integrated by Panasonic or an Authorized

Panasonic Wireless Integrator are covered under the warranty for the remaining warranty period of the device in which the modem is installed. For devices with less than three (3) months remaining on the unit warranty, the wireless modem will be covered for a period of three (3) months from the date of installation of the modem, covering only modem replacement or modem installation related issues.

All modems must be approved by the wireless carrier prior to use. Any use or attempted use of a wireless modem not approved and activated by the carrier for use on their network is strictly prohibited and is not sanctioned or warranted by Panasonic and may result in legal action. In addition, all modems must be approved by Panasonic as compatible with the device hardware before installation or use.

Panasonic’s sole responsibility for the warranty or technical support of the software required to install or operate the modem is defined in Section 2 (Limited Software Warranty). Any attempted software installation by anyone other than a Panasonic Authorized

Wireless Integrator is not covered under warranty and may result in service charges to re-image or replace the hard drive.

Installation or attempted installation by any party other than Panasonic or an Authorized Panasonic Wireless Integrator is strictly not covered under the warranty and may void the computer warranty if damage results.

Options and Accessories Warranties

The below listed Panasonic brand or supplied options and accessories are covered under this limited warranty for the period specified from the date of purchase or as specifically stated:

• AC Adaptor / Power Cord – 3 Years

• Memory Expansion Card (Panasonic Brand) – 3 Years

• Car Mount - Docking Station PCB or Vehicle Docking Station – 3 Years

• Desktop Port Replicator, I-O Box, Docking Cradle (like CF-U1) – 3 Years

• Antenna Pass-through Cable – 3 Years

• Backlit or Full-sized keyboard - 3 Years or assumes warranty of the unit in which it is installed

• Integrated Panasonic supplied options and kits including, but not limited to Wireless Modems, Media Bay Drives (Floppy,

CD, DVD, Combo), Camera, GPS, Bluetooth, Smartcard Reader, Magnetic Card Reader, Barcode Scanner, and Fingerprint

Reader - 3 Years or assumes warranty period of the unit in which it is installed provided the integration was performed by

Panasonic or an Authorized Integrator.

• Hard Drive / Solid State Drive (Internal) - 3 Years

• Separately purchased 2nd Hard Drive – 1 Year

• External USB Drives (CD / DVD / Floppy / Hard Drive) – 1 Year

• Optional Battery – 1 Year

• Battery Charger / Multi-Bay Battery Charger – 1 Year

• Stylus Pens, Digitizer & Standard - 90 Days (physical damage excluded)

33

DFQW5649XAT_CF-31mk3_EN.indb 33 2013/06/21 14:53:31

LIMITED WARRANTY (GARANTIE LIMITÉE)

Section 2 - Limited Warranty - Software

Panasonic warrants to you only that the disk(s) or other media on which the Programs are furnished will be free from defects in material and workmanship under normal use for a period of sixty (60) days from the date of delivery thereof to you, as evidenced by your purchase receipt.

This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will meet your requirements or that the operation of the Programs will be uninterrupted or error free. Panasonic shall have no obligation for any defects in the disk(s) or other media on which the Programs are furnished resulting from your storage thereof, or for defects that have been caused by operation of the disk(s) or other media

Panasonic’s entire liability and your exclusive remedy under this warranty shall be limited to the replacement, in the United States or other Panasonic designated location, of any defective disk or other media which is returned to Panasonic’s Authorized Service

Center, together with a copy of the purchase receipt, within the aforesaid warranty period.

Section 3 - Limited Warranty Exclusions - Specifically excluded from the warranty are:

• All consumable items; such as screen protection films, logo badges, labels, cleaning cloths, carry cases, manuals, cables, straps, belts, holsters, tethers, and harnesses and any other options and accessories not listed above or covered under a separate warranty.

• Failures related to the product operating system, hard drive or solid state drive image, software setup, software program, virus, other program(s) or file(s) on any drive or in any computer memory location.

• Failures due to BIOS settings or changes, as well as any cosmetic or physical damage to the unit.

• Any unit or device with a missing or altered model number or serial number label

• Cosmetic damage or any damage which occurs in shipment

• Failures which are caused by products not supplied by Panasonic

• Failures which result from alteration, accident, misuse, introduction of liquid or other foreign matter into the unit, abuse, neglect, installation, maladjustment of consumer controls, improper maintenance or modification, use not in accordance with product use instructions

• Failures due to service by anyone other than a Panasonic Authorized Service Provider

• Failures caused by improper installation of options or accessories or due to integration by any company other than Panasonic or a Panasonic Authorized Integrator

• Damage, failure, or loss due to the unit being stolen, lost, misplaced, or used by anyone other than the original purchaser

• Damage that is attributable to acts of God

This limited warranty only covers failures due to defects in materials or workmanship which occur during normal use. If a unit is sent to a Panasonic Authorized Service Center and no hardware failure is found, the customer will be billed for labor to correct a software issue or reimage the hard drive plus shipping and applicable administrative fees at the current rates set by the service provider.

THIS PRODUCT IS NOT INTENDED FOR USE AS OR PART OF NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CONTROL

EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS

*1

. PANASONIC WILL NOT BE RESPONSIBLE FOR

*

ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

1

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include class 2 Electronic Flight Bag (EFB) Systems and Class 1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted onto the aircraft. Class 1 EFB

Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance

Leaflets) No. 36.

Other Limits and Exclusions: There are no other express warranties except as listed above.

PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS

AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

For technical support or to arrange for service on your Panasonic computer product, call our toll-free hotline at 1-855-PSC-TECH

(855-772-8324).

DIAL TOLL FREE: 1-855-PSC-TECH (855-772-8324)

Web Site : www.panasonic.com/toughbook

34

DFQW5649XAT_CF-31mk3_EN.indb 34 2013/06/21 14:53:31

For Canada

PANASONIC COMPUTER AND PERIPHERALS LIMITED WARRANTY

Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the first end user customer, this computer product (excluding software media), when purchased from PCI or from a PCI authorized reseller, to be free from defects in materials and workmanship under normal use, subject to the terms set forth below, during the period of warranty coverage specified.

Scope of Coverage

Laptop Computers (except Battery) and AC Adaptor

• Factory/PCI installed options including Wireless WAN, GPS,

Bluetooth, Finger print reader, Backlit keyboard, Memory Card and Media Bay Drives (Floppy, CD/DVD)

Mobile Wireless Display

• PDRC – LCD and Keyboard Assemblies

Port Replicator

Hand-held Computers

• Battery

Battery charger

• Auto Adaptor

External USB Drives

Stylus

All consumable items including protection film, cleaning cloth, carry case, tether and harness

Period of Coverage

Three (3) Years from Date of

Original End User Customer

Purchase

One (1) Year from Date of

Original End User Customer

Purchase

Ninety (90) Days from Date of

Original End User Customer

Purchase

No Coverage

Type of Failure Coverage

Defective Materials or Workmanship

Defective Materials or Workmanship

Defective Materials or Workmanship nature of the defect claimed, at 1-800-668-8386 between 9:00 A.M. and 5:00 P.M., Eastern Time Zone, Mon. – Fri. (excluding holidays) for instructions on how to obtain service. A purchase receipt or other proof of date of original purchase is required before warranty service is performed. Defective parts covered by this Limited Warranty will be repaired or replaced with new or comparable rebuilt parts on an exchange basis. Warranty replacement or repair is subject to the terms of this Limited Warranty for the balance of the original period of warranty coverage.

No Coverage – This Limited Warranty does not cover products purchased outside Canada. Neither does it cover damage to, failure of, or defects in a product or accessory through mishandling, improper installation, abnormal use, misuse, neglect, accident, introduction of liquid or other foreign matter into the product, alteration or servicing by anyone not authorized by PCI, or act of God.

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-

TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS

*2

. PANASONIC WILL NOT BE RESPONSIBLE

FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets)

No.36

IF YOU SHIP THE PRODUCT FOR WARRANTY SERVICE

Carefully pack the product, preferably in the original carton. Include details of defect claimed and proof of date of original purchase. No liability is assumed for loss or damage to the product while in transit, if you chose your own transportation carrier.

SOFTWARE MEDIA LIMITED WARRANTY

supplied will be free from defects in materials and workmanship under normal use in Canada for a period of sixty (60) days from date of receipt as evidenced by your purchase receipt for your Panasonic Computer product.

THIS IS THE ONLY WARRANTY THAT PCI MAKES RESPECTING THE SOFTWARE MEDIA. PCI does not warrant the software.

Please refer to the software licensor’s written warranty (accompanying the copy of the software) for any software warranty claim.

Claim Procedure – In the event of a defect in material or workmanship in the media during the sixty (60) days warranty period, and you return it, transportation costs prepaid, to Panasonic Canada Inc., Computer Products Marketing, 5770 Ambler Drive, Mississauga, Ontario L4W 2T3, within the warranty period, together with a copy of your purchase receipt, and an explanation of the suspected defect, PCI will replace in Canada the defective disk(s) or other media.

Remedy – PCI’s entire liability, and your only remedy for any breach of this software media warranty is limited to replacement of the media only. It does not cover any other damages, including, but not limited to, loss of use or profit loss, or special, indirect or consequential damages, or other claims, whether or not of similar character.

No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product, or in environmental conditions other than those specified by PCI or the manufacturer, or if subjected to misuse, neglect, mishandling, modification or attempted modification of the program, or if damaged by accident or act of God. PCI is not responsible for damage to or loss of any program, data or removable storage media.

GENERAL

NO OTHER WARRANTIES – PCI DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT

NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RE-

SPECT TO THE SOFTWARE, SOFTWARE MEDIA, COMPUTER PRODUCT, OPTIONS AND ACCESSORIES.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES – IN NO EVENT SHALL PCI BE LIABLE FOR ANY SPECIAL, INDIRECT OR

CONSEQUENTIAL DAMAGES ARISING FROM ANY BREACH OF THE LIMITED WARRANTIES SET OUT IN THIS DOCUMENT,

OR FROM THE USE OF THE COMPUTER PRODUCT, INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, BUSINESS, PROF-

IT OR GOODWILL.

IN ANY EVENT, PCI’S MAXIMUM LIABILITY FOR ANY BREACH SHALL NOT EXCEED THE AMOUNT ACTUALLY PAID BY YOU

FOR THE COMPUTER PRODUCT.

NO ACTION, REGARDLESS OF ITS BASIS, MAY BE BEGUN AGAINST PCI MORE THAN TWO (2) YEARS AFTER THE CAUSE

OF ACTION AROSE.

Statutory Warranties – Some jurisdictions do not allow these limitations or exclusions, so they may not apply to you.

35

DFQW5649XAT_CF-31mk3_EN.indb 35 2013/06/21 14:53:31

LIMITED WARRANTY (GARANTIE LIMITÉE)

Pour le Canada

GARANTIE LIMITÉE – ORDINATEURS ET PÉRIPHÉRIQUES PANASONIC

Couverture – Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que ce produit informatique (à l’exclusion des supports des logiciels) est, au moment de sa vente par PCI ou d’un revendeur agréé par PCI, exempt de défauts de pièces et de fabrication dans les conditions normales d’utilisation, et ce, pendant la période de couverture de la garantie, sous réserve des modalités décrites ci-dessous.

Éléments couverts

Ordinateurs blocs-notes (sauf batteries) et adaptateur secteur

• Options installées en usine/par PCI incluant : WAN sans fil,

GPS, Bluetooth, lecteur d’empreintes digitales, clavier rétroéclairé, carte mémoire et lecteurs (disquettes, CD/DVD)

Écran mobile sans fil

• Ensembles PDRC – ACL et clavier

Duplicateur de port

Ordinateurs de poche

• Batterie

Chargeur de batterie

• Adaptateur pour voiture

Périphériques USB

Stylo pointeur standard ou pour numériseur graphique

Durée de couverture

Trois (3) ans à partir de la date d’achat original.

Un (1) an à partir de la date d’achat original.

Type de couverture

Défauts de pièces et de fabrication

Défauts de pièces et de fabrication

• Tous les articles consommables incluant les pellicules protectrices, chiffons de nettoyage, étuis de transport, longes et sangles

Quatre-vingt-dix (90) jours à partir de la date d’achat original.

Aucune couverture

Défauts de pièces et de fabrication

Recours – Pour obtenir des informations sur la marche à suivre dans le cas où une réclamation en vertu de la garantie deviendrait nécessaire, communiquez par téléphone avec un représentant de PCI au 1-800-668-8386, entre 9h00 et 17h00 (heure de l’Est) du lundi au vendredi (sauf les jours fériés), avant l’échéance de la garantie applicable, en prenant soin d’identifier la nature de la défaillance.

Un reçu ou toute autre pièce justificative de la date d’achat original sera exigé avant toute réparation. Toute pièce défectueuse couverte par la présente garantie limitée sera réparée ou remplacée par une pièce neuve ou remise à neuf. Le remplacement ou la réparation sera fait conformément aux modalités de la présente garantie limitée pendant la durée restante de la période originale de la garantie.

Produits non couverts – La présente garantie limitée ne couvre pas les produits achetés à l’extérieur du Canada. Elle ne couvre pas non plus les dommages, la défaillance ou les défauts attribuables à une manutention inadéquate, une mauvaise installation, une utilisation anormale ou abusive, de la négligence, un accident, un déversement ou la pénétration d’un objet étranger, une modification, un cas fortuit ou une réparation effectuée par une personne non agréée par PCI.

CE PRODUIT N’EST PAS DESTINÉ À ÊTRE UTILISÉ, EN TOUT OU EN PARTIE, COMME SYSTÈME/ÉQUIPEMENT NUCLÉAIRE, SYSTÈME/

ÉQUIPEMENT DE CONTRÔLE DU TRAFFIC AÉRIEN OU SYSTÈME/ÉQUIPEMENT DE POSTE DE PILOTAGE D’AVION

*3

. PANASONIC

DÉCLINE TOUTE RESPONSABILITÉ CONCERNANT L’UTILISATION DE CE PRODUIT DANS LES CAS SUSMENTIONNÉS.

Les SYSTÈMES/ÉQUIPEMENTS DE POSTE DE PILOTAGE D’AVION sont dotés de systèmes OEPP (organiseur électronique de poste de pilotage) de classe 2 et de classe 1 utilisés pendant des phases critiques de vol (par exemple, pendant le décollage et l’atterrissage) et(ou) montés sur l’avion. Les systèmes OEPP de classe 1 et de classe 2 sont définis par le circulaire d’information FAA: AC (Advisory Circular) 120-76A ou le feuilet n° 36 JAA: JAA TGL (Temporary Guidance Leaflets) No 36.

EXPÉDITION DU PRODUIT POUR SERVICE SOUS GARANTIE

Emballez soigneusement le produit, de préférence dans son emballage d’origine. Joignez une description de la défaillance de même qu’une pièce justificative de la date d’achat. Panasonic Canada Inc. ne peut être tenue responsable pour tout dommage ou perte subi pendant le transport si vous avez choisi le transporteur.

GARANTIE LIMITÉE – SUPPORTS DES LOGICIELS

36 lequel le ou les programmes sont fournis sont exempts de défauts de pièces et de fabrication dans des conditions normales d’utilisation au Canada, et ce, pour une période de soixante (60) jours suivant la date de réception indiquée sur la preuve d’achat.

LA PRÉSENTE GARANTIE EST LA SEULE OFFERTE PAR PCI COUVRANT LES SUPPORTS DE LOGICIELS. PCI ne garantit pas les logiciels. Reportez-vous à la garantie écrite du concédant de licence d’utilisation du logiciel (qui accompagne la copie du logiciel) pour toute réclamation en vertu de la garantie.

Réclamation – marche à suivre – Panasonic Canada Inc. remplacera toute disquette ou support défectueux si l’article en question est retourné, port payé, à son service de Marketing – produits informatiques, 5770 Ambler Drive, Mississauga (Ontario) L4W 2T3, dans les soixante (60) jours suivant la date d’achat original. Joignez à votre envoi une pièce justificative de votre achat et une description du problème.

Recours – La responsabilité de PCI - et votre seul recours - dans le cas de toute défaillance couverte par la garantie sur ce support de logiciel est limitée au seul remplacement du support. Elle ne couvre aucun autre dommage, y compris, mais non exclusivement, la perte d’usage ou de profits, ni aucun dommage spécial, indirect ou consécutif, ni aucune autre réclamation de nature similaire ou autre.

Produits non couverts – La présente garantie limitée ne s’applique pas si la ou les disquettes ou autre support ont été utilisés dans un produit d’une marque autre que Panasonic ou dans des conditions environnementales autres que celles spécifiées par PCI ou le fabricant, ou soumis à une mauvaise utilisation, à la négligence, à une manutention inadéquate ou encore si le programme a été modifié ou subi une tentative de modification ou des dommages attribuables à un accident ou à un cas fortuit. De plus, PCI n’assume aucune responsabilité pour toute perte de, ou tout dommage à, un programme, des données ou un support de sauvegarde amovible.

GÉNÉRALITÉS

PCI NE RECONNAÎT AUCUNE AUTRE GARANTIE, EXPLICITE OU IMPLICITE, Y COMPRIS, MAIS NON EXCLUSIVEMENT, LES

GARANTIES IMPLICITES DE VALEUR COMMERCIALE ET D’UTILITÉ À UNE FIN QUELCONQUE, À L’ÉGARD DU LOGICIEL,

SUPPORTS DE LOGICIELS, PRODUITS INFORMATIQUES, PÉRIPHÉRIQUES ET ACCESSOIRES.

SOUS AUCUNE CIRCONSTANCE PCI NE POURRA ÊTRE TENUE RESPONSABLE DES DOMMAGES SPÉCIAUX, INDIRECTS

OU CONSÉCUTIFS ATTRIBUABLES À UN MANQUEMENT AUX GARANTIES LIMITÉES DÉCRITES DANS LE PRÉSENT DOCU-

MENT OU À L’UTILISATION DU PRODUIT INFORMATIQUE, Y COMPRIS, SANS RESTRICTION, LA PERTE DE DONNÉES,

D’AFFAIRES, D’ACHALANDAGE OU DE PROFIT.

DANS TOUS LES CAS, LA RESPONSABILITÉ MAXIMALE DE PCI POUR TOUT MANQUEMENT NE POURRA EXCÉDER LE

PRIX DE VENTE DU PRODUIT INFORMATIQUE.

AUCUNE RÉCLAMATION, SANS ÉGARD À SES MOTIFS, NE POURRA ÊTRE FAITE AUPRÈS DE PCI PLUS DE DEUX (2) ANS

APRÈS LES FAITS INVOQUÉS À LA BASE D’UNE TELLE RÉCLAMATION.

Garantie statutaires – Certaines juridictions interdisent de telles limitations ou exclusions; aussi, pourraient-elles ne pas s’appliquer.

DFQW5649XAT_CF-31mk3_EN.indb 36 2013/06/21 14:53:31

For Australia

Personal / Notebook Computers - 36 Month Warranty from Date of Purchase

1. Subject to the conditions of this warranty Panasonic or it’s Authorised Service Centre will perform necessary service on the product without charge for parts or labour, if in the opinion of Panasonic, the product is found to be faulty within the warranty period.

2. This warranty only applies to Panasonic products purchased in Australia and sold by Panasonic Australia or its Authorised

Distributors or Dealers and only where the products are used and serviced within Australia or it's territories. Warranty cover only applies to service carried out by a Panasonic Authorised Service Centre and only if valid proof of purchase is presented when warranty service is requested.

3. This warranty only applies if the product has been installed and used in accordance with the manufacturer’s recommendations

(as noted in the operating instructions) under normal use and reasonable care (in the opinion of Panasonic). The warranty covers normal domestic use only and does not cover damage, malfunction or failure resulting from use of incorrect voltages, incorrect installation, accident, misuse, neglect, build-up of dirt or dust, abuse, maladjustment of customer controls, mains supply problems, thunderstorm activity, infestation by insects or vermin, tampering or repair by unauthorised persons (including unauthorised alterations), exposure to abnormally corrosive conditions or any foreign object or matter having entered the product.

4. This warranty does not cover the following items unless the fault or defect existed at the time of purchase: Software

5. Warranty on Toughbook accessories (stylus, pens, AC charger, combo drive, etc) is 12 Months from the date of purchase &

3 months for batteries.

6. To claim warranty service, when required, you should:

Check the Panasonic web site for latest warranty contact http://www.panasonic.com.au/toughbook, use the Service Centre

Locator and call the National Service Centre number indicated.

Prepare purchase receipt as proof of purchase date and system serial number which will be required by the Authorised Service

Centre.

7. The Warranty excludes 3 or less faulty pixels on screen.

8. The Warranty includes the repair or exchange of faulty parts within the product with items that are functionally equivalent to that as originally supplied or better – including new or refurbished parts or units – solely at Panasonic’s discretion.

9. It is the customer’s responsibility to backup all data from the hard disk drive before sending equipment for repair. If a problem is related to the hard disk drive, or the hard disk drive has to be replaced, Panasonic will only reload the factory pre-installed software for the product onto the replacement drive.

10. Panasonic will arrange free pick up and return for approved warranty repairs within 50 km of capital city locations. Please ensure your unit is properly packed for return to the service location.

11. The warranties hereby conferred do not extend to, and exclude, any costs associated with the installation, de-installation or re-installation of a product, including costs related to the mounting, demounting or remounting of any screen, (and any other ancillary activities), delivery, handling, freighting, transportation or insurance of the product or any part thereof or replacement of and do not extend to, and exclude, any damage or loss occurring by reason of, during, associated with, or related to such installation, de-installation, re-installation or transit.

In addition to your rights under this warranty, Panasonic products come with consumer guarantees that cannot be excluded under the Australian Consumer Law. If there is a major failure with the product, you can reject the product and elect to have a refund or to have the product replaced or if you wish you may elect to keep the goods and be compensated for the drop in value of the goods.

You are also entitled to have the product repaired or replaced if the product fails to be of acceptable quality and the failure does not amount to a major failure.

If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.

THIS PRODUCT IS NOT INTENDED FOR USE AS OR AS PART OF NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CONTROL

EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS

*4

. PANASONIC WILL NOT BE RESPONSIBLE FOR

ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

*4

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class 2 Electronic Flight Bag (EFB) Systems and Class 1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted onto the aircraft. Class 1 EFB Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets) No.36.

THIS WARRANTY CARD AND THE PURCHASE DOCKET (OR SIMILAR PROOF OF PURCHASE)

SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES

If you require assistance regarding warranty conditions or any other enquiries, please visit the

Panasonic Australia website www.panasonic.com.au/toughbook or contact by phone on 1300 132 463

PRO-031-F05 Issue: 4.0

Panasonic Australia Pty. Limited

ACN 001 592 187 ABN 83 001 592 187

1 Innovation Road, Macquarie Park NSW 2113 www.panasonic.com.au

11-11-2011

DFQW5649XAT_CF-31mk3_EN.indb 37

37

2013/06/21 14:53:31

MEMO

38

DFQW5649XAT_CF-31mk3_EN.indb 38 2013/06/21 14:53:31

DFQW5649XAT_CF-31mk3_EN.indb 39

39

2013/06/21 14:53:31

As an

E

NERGY product meets the

S

TAR

E

®

Partner, Panasonic Corporation has determined that this

NERGY

S

TAR

®

guidelines for energy efficiency. By enabling available power management settings, Panasonic computers enter a low-power sleep mode after a period of inactivity, saving the user energy.

<Only for U.S.A.>

To learn more about power management, please visit the web site: www.energystar.gov/index.cfm?c=power_mgt.pr_power_management

Outline of the International

E

NERGY

S

TAR ® Office Equipment Program

The international

E

NERGY

S

TAR

®

Office Equipment Program is an international program that promotes energy saving through the use of computers and other office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted products are office equipment such as computers, displays, printers, facsimiles, and copiers. Their standards and logos are uniform among participating nations.

<Only for U.S.A.>

For information about

E

NERGY

Web Site: www.energystar.gov

S

TAR

®

, refer to the following web site:

22-E-1

Panasonic Corporation

Osaka,.Japan

Panasonic System Communications

Company of North America

Two.Riverfront.Plaza

Newark,.NJ.07102

Panasonic Canada Inc.

5770.Ambler.Drive,.Mississauga,

Ontario.L4W.2T3

Importer’s.name.&.address.pursuant.to.the.EU.legislation

Panasonic System Communications Company Europe, Panasonic Marketing Europe GmbH

Hagenauer.Straße.43

65203.Wiesbaden

Germany

©.Panasonic.Corporation.2012.-.2013

Printed.in.Taiwan

TA0612-2083

DFQW5649XAT

DFQW5649XAT_CF-31mk3_EN.indb 40 2013/08/08 17:57:14

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
