Sony FWD-32LX1, FWD-42LX1 Datasheet

Sony FWD-32LX1, FWD-42LX1 Datasheet
OPTIONAL ACCESSORIES
HE
BKM-FW10
VIDEO INPUT/OUTPUT ADAPTOR
- Composite Video In/Out (BNC x2)
- S Video In/Out (Mini DIN 4-pin x2)
- Audio In L/R {Pin jack x2)
BKM-FW12
RGB/COMPONENT ACTIVE THROUGH ADAPTOR
- RGB/Component In (D-sub15pin x1)
- RGB/Component Out (D-sub15pin x1)
- Audio In (Stereo mini jack x1)
Computer Input
Video Input
COMPONENT/RGB INPUT ADAPTOR
- Component RGB In (BNC x5)
- Audio In (Stereo mini jacket x1)
BKM-FW31
NETWORK MANAGEMENT ADAPTOR
SU-42FW/32FW
TABLE-TOP STAND
fH(kHz) {Active lines)
TERMINALS
OTHERS
fH(kHz) (Active lines)
WM-PFM01
WALL-MOUNT BRACKET
BRIS Rig Epi
SPEAKER SYSTEM
INTRODUCING THE LATEST SONY LCD DISPLAYS
— FWD-42LX1 AND FWD-32LX1
BRILLIANT, ULTRA LARGE DISPLAY
The FWD-42LX1 and FWD-32LX1 advanced WXGA screens offer exceptional brightness and superb contrast — ideal for enhancing
the colour and richness of your images. The ultra-large screens offer a high resolution of 1366 x 768 pixels which is optimum for
moving images and videos.
WEGA ENGINE
Experience beautiful and true-to-life picture quality with
sophisticated engineering from Sony. The proprietary Sony WEGA
Engine is an advanced picture quality system that integrates a
host of unique technologies and circuitry to enable full precise
digital image processing. The result is a stunning display of highly
realistic images, amazing detail and sharpness, reduced noise
and enhanced clarity, with improved depth and contrast.
BENEFITS OF WEGA ENGINE
BETTER RESOLUTION
Provides more detail and enhanced sharpness especially
on picture edges.
SEAS
Without WEGA Engine With WEGA Engine
MORE REALITY
Enhances reality and depth in picture dimension.
With WEGA Engine
WEGA ENGINE
Integrated Digital Processing System
Û,
a Panel J
й | y m
f Picture y Driver
Ш
/ Reality J
el
/]
Processor |
el
ua
fl Multi Input Y
| )
| Conversion
el
Y Creation
Converts various Creates a high- Fine-tunes and Maximises the
types of signals into density picture from scales all picture strength of each
high-quality digital the original source parameters to High display device with
signals. with Digital Reality Definition picture natural colours and
Creation. quality. smooth gradation.
LESS NOISE
Minimises noise level for a finer image.
Without WEGA Engine
With WEGA Engine
HIGHER CONTRAST
Improves contrast between black and white images.
With WEGA Engine
Without WEGA Engine
|
|
HISH PERFORMANCE
With low power consumption and no burn-ins, these models deliver a more efficient performance.
DURABLE CRYSTAL DESIGN IN SLEEK, MODERN DISPLAYS
A first for modern displays, the LCD Displays FWD-42LX1 and FWD-32LX1 utilise a unique dual layer bezel design. The scratch-
resistant crystal layer offers more durability and better damage protection for your display. Coupled with its clean rear view, smart
cable management and choice of colours, these make the models exceptionally attractive for any environment.
PICTURE AND PICTURE (PAP) & PICTURE IN PICTURE (PIP)
Designed to give you maximum enjoyment and flexibility, the LCD Display allows you to view images from two separate signals at
the same time. You can even change the position and size of the images being displayed, giving you more control over your total
viewing experience.
Picture And Picture (PAP) == = Picture In Picture (PIP) с E
* Users can select and access other TV programmes
directly through a sub-screen while the current
programme is displayed on the main screen.
* Two separate signals can be used to display two images simultaneously
* Each image can be adjusted to seven sizes (for a total of 14 steps)
* The position of each picture can be swapped if desired
WIDE RANGE OF ACCEPTABLE SIGNAL
The FWD-42LX1 and FWD-32LX1 offer versatile compatibility for a wide range of devices and formats, from VGA to UXGA signals
from your PCs and TVs, NTSC, PAL, SECAM and their variations as well as most of the DTV formats.
AUTO WIDE FUNCTION
Video images are automatically enlarged to fill the 16:9 aspect ratio screen for a greater viewing pleasure.
NETWORK MANAGEMENT ADAPTOR
BKM-FW31
This device allows you to access, control and monitor a network
of LCD displays from a central PC that's connected to LAN, WAN
or the Internet.
Lo
©
В
=]
©
+o
“ча
Ко
=]
о
