This document will provide instructions on how setup a UCM6100 series from an out of the box state to a fully functional state. This includes design considerations, creating user extensions, provisioning endpoints with Zero-Config, conferencing, auto attendant configuration, analog/VoIP trunks, routing inbound/outbound calls and voicemail/fax to email setup.

For detailed information in regards to parameters that are encountered in this guide, please check the

UCM6100 series User Manual

S

ETUP

G

UIDE

S

CENARIO

In this setup guide we will be using the UCM6102 which has a WAN and LAN interface. The image below shows the most typical setup where you have the UCM6100 series WAN port connected to the

Internet and the LAN side of the UCM6100 series providing DHCP.

We will use this scenario to setup a Grandstream GXP2124 which will be connected to the LAN side of the UCM6100 series. There can also be a network switch connected to the LAN port of the

UCM6100 series so that there may be more than one device connected.

Figure 1: Typical UCM Scenario

4

C

ONNECTING THE

UCM6102

Q

UICK

I

NSTALLATION

Figure 2: Quick Installation Guide for UCM6102

A

CCESS

UCM6100

SERIES

W

EB

I

NTERFACE

Accessing the UCM6100 series web interface allow users to manage users and system settings locally as well as remotely.

To access the web UI, depends on where the user’s computer is connected. If the computer is connected to the same switch/router that the UCM6100 series WAN port is connected, then browse to the IP addressed that is displayed on the UCM6100 series LCD. This address is the WAN IP. If the computer is connected to the LAN side of the UCM6100 series, then users would browse to the default IP of the

UCM6100 series which is 192.168.2.1. If successful, the UCM6100 series login page will be displayed as shown below.

Figure 3: Quick Installation Guide – Login Screen

5

C

REATE

U

SER

E

XTENSION

C

ONFIGURE

E

XTENSION

R

ANGE

First part of configuring the UCM6100 series should be about planning for expansion. Here are some questions to think about when setting up extension ranges:

• How many users are in the office?

• Will there be departments within the office?

• Is this office interconnecting with another office?

Once there’s a clear picture of how many users will be at each location, how departments are going to be segmented and what’s the expected growth of the company, a user can then configure the extension range. Navigate to PBX

 Internal Options  General.

Figure 4: Create User Extension – Extension Range

In the figure above, the user extension range is set with a starting extension of 100 and ending at 195.

This allows up to 196 extensions to assign to users. We have also created a conference extension range from 196 to 199, which gives 4 conference bridges. Users can configure any extension range as they desire. Here we’ve configured it to use three digit extensions with a leading 1.

Click “Save” at the bottom. Then remember to click on “Apply Changes” at the top so that our extension range will be ready for the next steps.

6

B

ATCH

& S

INGLE

U

SER

C

REATION

So now that there’s extension ranges configured, we can now begin creating users to prepare for the provisioning process. There are two methods of creating a user. One method would be creating a single user. The other method would be creating a batch of users.

S

TEPS ON

A

DDING

S

INGLE

U

SER

1. Navigate to PBX

Basic/Call Routes  Extensions. For first time setups users will see “No

Extension defined”.

Figure 5: Create User Extension – Extensions

2. Click on “Create New User”

3. On the “Create New User” screen, users can enter in quite a few options, but they are not required for this tutorial. Click “Save” at the bottom of the page.

Figure 6: Create User Extension – Create New User

After clicking “Save” the Extensions page will display with the single SIP extension that was just created.

at the right. Here the user has the ability to edit the extensions by clicking the

7

Figure 7: Create User Extension – Created Single User

S

TEPS ON

A

DDING

B

ATCH OF

U

SERS

1. Navigate to PBX

Basic/Call Routes  Extensions

2. Click on “Batch Add Extensions”

3. At the “Batch Add Extensions” dialog, the user can specify the “Starting Extension” and the number of extensions to generate by setting the “Create Number”. In this tutorial we will have a starting extension of 101 and have the UCM6100 series generate 5 extensions with a password randomly generated. This would create extensions 101, 102, 103, 104 and 105.

Figure 8: Create User Extension – Batch Add User

4. Click “Create Users” at the bottom to have the UCM6100 series generate the extensions

5. Next, a prompt will appear asking “Are you sure you want to create users: 101, 102, 103, 104 105”.

Click “OK”.

Figure 9: Create User Extension – Create User Prompt

8

At this point the Extensions page should look similar to this:

Figure 10: Create User Extension – Single and Batch Add Extensions Created

For more details on Extension parameters please see the UCM6100 series User Manual .

9

P

ROVISIONING

& Z

ERO

C

ONFIG

Grandstream SIP Devices can be configured via Web interface as well as via configuration file through

TFTP/HTTP/HTTPS download. All Grandstream SIP devices support a proprietary binary format configuration file and XML format configuration file. The UCM6100 provides a Plug and Play mechanism to auto-provision the Grandstream SIP devices in a zero configuration manner by generating XML config file and having the phone to download it. This allows users to finish the installation with ease and start using the SIP devices in a managed way.

To provision a phone, three steps are involved, i.e., discovery, assignment and provisioning. The

UCM6100 creates XML config file to the detected/assigned Grandstream device and accomplishes the following configurations on the device after the provisioning:

• A UCM6100 extension will be assigned and registered on the phone.

• SIP-related network settings such as "NAT traversal" and "Use Random Port" are configured on the phone.

• Call settings such as "Dial Plan" and "Auto Answer".

• LDAP client configurations will be set up automatically on the phone to use the default LDAP directory

• generated in the UCM6100 LDAP server.

This section explains how zero config works on the UCM6100. The settings for this feature can be accessed via Web GUI->PBX->Basic/Call Routes->Zero Config.

A

UTO

D

ISCOVERING

When referring back to our typical scenario in the beginning of this tutorial, we know that there is a

GXP2124 connected to the LAN side of the UCM6100 series. The UCM6100 series LAN interface has

DHCP enabled and has assigned the GXP2124 with an IP address. By default the IP assigned would be within the 192.168.2.X range. When the UCM6100 series offers an IP address to the phone it also offers

DHCP Option 66, which provides the phone with a config server path that points to the UCM6100 series.

All of Grandstream VoIP devices have Option 66 turned on by default and this is how the GXP2124 was discovered by the UCM6102.

Upon being discovered, the GXP2124 will provide details about its MAC, IP Address, Version(Firmware),

Vendor, Model, Connection Status and Create Config.

By navigating to PBX

Basic/Call RoutesZero Config, a user will be able to see the discovered device(s).

Figure 11: Provisioning with Zero Config – Auto Discovery

10

E

XTENSION

A

SSIGNMENT

In the Auto Provision settings, users have the option to enable “Automatically Assign Extension”. If enabled, an extension will be created and assigned to the new device detected. This is a great feature if specific extension assignment isn’t required, but for our setup we’ll work on manually assigning an extension to a discovered device.

Navigate to PBX

Basic/Call RoutesZero Config and click on the

for the discovered device.

The next screen provides details of the device and also allows a user to assign an extension. Since our

GXP2124 is a 4 line phone, the UCM6100 series gives us the option to assign 4 extensions to the phone.

Figure 12: Provisioning with Zero Config – Extension Assignment

Click on the Account 1 and select the desired extension, then click “Save”. Now the Zero Config page displays the device with an extension assigned to it on Account 1.

Figure 13: Provisioning with Zero Config – Manually Assigned Extension

After assigning an extension, the phone must be rebooted in order to pick up the configuration file from the UCM6100 series. During this process, the phone will bootup, request for config file,download the config file, then reboot once more in order to apply the changes.

After the phone is completely booted, Navigate to PBX

Basic/Call RoutesExtensions page to see the extension status. The SIP status will show a green circle for a successful registration.

Figure 14: Provisioning with Zero Config – Extension Status

11

C

ONFERENCE

B

RIDGE

The UCM6100 supports conference bridge allowing multiple bridges used at the same time:

• UCM6102/6104 supports up to 3 conference bridges allowing up to 25 simultaneous PSTN or IP participants.

• UCM6108/6116 supports up to 6 conference bridges allowing up to 32 simultaneous PSTN or IP participants.

The conference bridge configurations can be accessed under Web GUI->PBX->Call Features-

>Conference. In this page, users could create, edit, view, invite, manage the participants and delete conference bridges. The conference bridge status and conference call recordings (if recording is enabled) will be displayed in this web page as well.

H

OW TO

S

ETUP A

C

ONFERENCE

B

RIDGE

1. Click on “Create New Conference Room”

2. At the “Create New Conference Room” screen, the Extension is automatically populated since the extension range is in effect. Users can assign another number that is within the Conference

Extension range

3. Next, uncheck the option “Public Mode”. This will make the password options available. Enter a numeric password for an admin as well as the regular user password. In this example, the user enters 511511 as the user password and 510510 as the admin password.

Figure 15: Conference Bridge – Create New Conference Room

12

4. Click “Save” at the bottom then “Apply Changes” at the top.

We should now have a conference room created and the status page will display the following:

Figure 16: Conference Bridge – Create New Conference Room

With the phone that was registered to the UCM6100 series, dial the conference room extension. For this example we will dial 196. The user will hear a prompt for the conference password. Depending on the user, the regular password or admin password can be entered.

During a conference call, the admin can login to the UCM6100 series and view the conference room status. This provides the admin with details on which conference room is active, who the participants are and the conference call current duration.

Besides status information, the admin has a several conference management tools. By clicking the button, the admin can invite other users to the conference. Clicking will kick the selected user from the conference. When clicking or button the admin will mute/unmute the specific user.

Figure 17: Conference Bridge – Conference In Progress

For more options and features for the conference room, please see the UCM6100 series User Manual

13

IVR

C

ONFIGURE

IVR

IVR configurations can be accessed under the UCM6100 Web GUI->PBX->Call Features->IVR. Users could create, edit, view and delete an IVR.

• Click on "Create New IVR" to add a new IVR.

• Click on

to edit the IVR configuration.

• Click on

to delete the IVR.

Figure 18: IVR – Manage IVR

C

REATE

N

EW

IVR

1. Click on “Create New IVR”

2. Enter a Name for the IVR. This is used for referencing purposes. In this example the user will create “OfficeHours2”

3. “Extension” is populated automatically by the extension range that was created in the beginning of the tutorial. A user may choose another IVR extension within the range if desired.

4. Enable “Dial Other Extensions” to allow callers who reach the IVR to dial a direct internal extension without having to go through voice prompts.

5. “Welcome Prompt” is the recording that will be played when a caller reaches the IVR. Users can click on the “Prompt” link next to the dropdown box to configure a welcome prompt.

14

Figure 19: IVR – Create New IVR

6. The next section on configuring an IVR would be the Key Pressing Events. Users can direct calls based on a callers selection. For example, a caller reaches the IVR and the Welcome Prompt plays,

“Thank you for calling Grandstream Networks. For support, please dial 0. For Sales, please dial 1.”

Click on the drop down box for the first event, which is “Press 0” and select Extension. Another drop down box will appear and the user can then select an extension from the list. For this example, the user selects Extension 100.

7. For Key Pressing Event “Press 1” click on the drop down box and select Extension. User selects

Extension 101. Besides from Extension as a Key Pressing Event, the user can select Voicemail,

Conference Room, Voicemail Group, IVR, Ring Group and many more.

Figure 20: IVR – Key Pressing Events

8. Click “Save” at the bottom and then click on “Apply Changes” at the top.

To find out more options and parameter descriptions in regards to the IVR, please refer to the UCM6100 series User Manual .

15

T

RUNKS

A

NALOG

T

RUNKS

Go to Web GUI->PBX->Basic/Call Routes->Analog Trunks to add and edit analog trunks.

• Click on "Create New Analog Trunk" to add a new analog trunk.

• Click on

to edit the analog trunk.

• Click on

to delete the analog trunk.

The UCM6100 series has built in FXO ports which allows it to pull in PSTN lines and provide analog trunk service. For this example, we will configure an analog line that is connected to FXO1.

S

ETUP

A

NALOG

T

RUNK

1. Click on “Create New Analog Trunk”

2. For “Channels” select 1

3. Trunk Name is set to “Analog1”

4. “Caller ID Scheme” is set for “Bellcore/Telcordia”. Depending on the provider, users can select other schemes

5. “Tone Country” is set to “United States of America (USA)” since this tutorial is setup in the North

American region. Users can click the dropdown box to select an option more suited for their region

6. Click “Save” and then click on “Apply Changes” at the top

Figure 21: Analog Trunks – Create New Analog Trunk

16

Note: If there are reports of calls being dropped and lines are not disconnecting properly, this could mean that there are line settings mismatched. The UCM6100 series offers an auto detect feature that tests the line and provides the best possible settings. This option is called “PSTN Detection” which can be found under the Analog trunk configuration page.

V

O

IP T

RUNKS

VoIP trunks can be configured under Web GUI->PBX->Basic/Call Routes->VoIP Trunks. Once created, the VoIP trunks will be listed with Provider Name, Type, Hostname/IP, Username and Options to edit/detect the trunk.

• Click on "Create New SIP/IAX Trunk" to add a new VoIP trunk.

• Click on

to configure detailed parameters for the VoIP trunk.

• Click on

to configure Direct Outward Dialing (DOD) for the SIP Trunk

• Click on

to start LDAP Sync

• Click on

to delete the VoIP trunk.

There are 4 different type of VoIP trunks that can be configured. The types are Peered/Registered SIP trunk or Peered/Registered IAX trunk. This tutorial will demonstrate how to configure a SIP Registered

Trunk.

S

ETUP

V

O

IP T

RUNK

1. Click on “Create New SIP/IAX Trunk”

2. Click the dropdown box for Type and select “Register SIP Trunk”

3. Enter a name for “Provider Name” e.g., GSTrunk

4. Configure the IP address or URL of the VoIP providers server as the “Host Name” e.g., sip.grandstream.com

5. Input the username to authenticate with the VoIP provider as the “Username” e.g, 6266389172

6. Enter password for username to authenticate with VoIP provider server

7. Enter the AuthID. This is the SIP service subscriber’s ID used for authentication. If not configured, the CallerID will be used for authentication.

8. Enter an outbound proxy if the provider requires one

9. Click “Save” and then “Apply Changes” at the top

17

Figure 22: VoIP Trunks – Create New Register SIP Trunk

After creating the SIP trunk, users can click the on the right of the VoIP trunk for more configuration options.

Figure 23: VoIP Trunks – Edit VoIP Trunk

To verify if the SIP trunk is registered, the user may navigate to Web UI->Status.

Figure 24: Status – Trunks

18

C

ALL

R

OUTES

O

UTBOUND

R

OUTES

In the UCM6100, an outgoing calling rule pairs an extension pattern with a trunk used to dial the pattern.

This allows different patterns to be dialed through different trunks (e.g., "Local" 7-digit dials through a

FXO while "Long distance" 10-digit dials through a low-cost SIP trunk). Users can also set up a failover trunk to be used when the primary trunk fails.

Go to Web GUI->PBX->Basic/Call Routes->Outbound Routes to add and edit outbound rules.

• Click on "Create New Outbound Rule" to add a new outbound route.

• Click on

to edit the outbound route.

• Click on

to delete the outbound route.

• Click on

to move the outbound route up/down to arrange the priority of the outbound rule. The outbound rule listed on the top has higher priority. When the dialing pattern matches two or more outbound rules (for example, the same pattern is configured for 2 different trunks; or dialing out

1000 matches pattern 1xxx for trunk 1 and pattern 100x for trunk 2), the one listed on the top will be used.

H

OW TO

C

ONFIGURE AN

O

UTBOUND

R

OUTE

1. Click “Create New Outbound Rule”

2. Configure the name of the Calling Rule. For example, ‘Local’, ‘LongDistance’ and etc.

3. Create a dial Pattern. For 7 digit dialing (Local) the pattern will look like this: XXXXXXX

This means that any 7 digits will use this route. For 10 digit dialing the pattern would look like this:

NXXNXXXXXX. If a ‘1’ is required before dialing out, the dial patter can be configured in this manner: 1NXXNXXXXXX.

In this example, the dial pattern is going to be created for local 7 digit dialing so the pattern is

XXXXXX

4. Next, set a “Privilege Level”. There are 4 Privilege Levels; Internal, Local, National, International.

Internal is the lowest level of security where as international is the highest level of security.

The way that Privilege Levels are used could be thought of as door locks. Extensions are granted with “Permissions” that can be seen as keys. If an Extension is configured with an Internal permission, it CANNOT access an outbound route with a Privilege level of Local, National and

International. A user configured with National permission can access routes that have a Privilege

Level of Internal, Local, National, but not International.

5. The pattern that was configured is a 7 digit dialing pattern. For “Use Trunk” select the Analog Trunk or select the desired trunk for this particular dial pattern. For long distance calls, it may be cost effective to route the calls to SIP trunk versus going through a local PSTN line.

6. Click “Save” and then click on “Apply Changes” at the top.

19

Figure 25: Routes – Create Outbound Route

I

NBOUND

R

OUTES

In the UCM6100, an incoming calling rule allows for various inbound destinations. Users can route inbound calls by DID, to Extension, Voicemail, Conference Room, Queue, Ring Group, Page, Voicemail

Group, FAX, DISA or IVR. These inbound routes can also be triggered based on a time condition as well.

Inbound routes can be configured via Web GUI->PBX->Basic/Call Routes->Inbound Routes.

• Click on "Create New Inbound Rule" to add a new inbound route.

• Click on "DID Features" to configure DID features for the inbound route.

• Click on "Blacklist" to configure blacklist for all inbound routes.

• Click on

to edit the inbound route.

• Click on

to delete the inbound route.

This section of the tutorial will provide instructions on how to setup an inbound route for a Registered SIP

Trunk. Inbound calls into this SIP trunk will have a default destination as well as a time conditioned destination.

20

S

ETUP

I

NBOUND

R

OUTE

1. Click on “Create New Inbound Rule”

2. For “Trunks” select the SIP trunk that has been configured. (e.g. GS Trunk)

3. The DID pattern can be composed of two parts, divided by a ‘/’ character. The first part is used to specify the dialed number and the second part is used to specify the caller ID, which is optional. If caller ID section is entered it means only the extension with the specific caller ID is allowed to call into this trunk.

4. “Privilege level” can be left as Internal

5. Click the dropdown box for “Default Destination” and select IVR. Then select the IVR extension.

6. Next, click on “Click to add Time Condition”.

7. Enter a “Start Time” of 8am, “End Time” of 6pm.

8. Next select By Week for “Date” and select Monday-Friday.

9. For “Destination” select Extension and choose an extension number.

Figure 26: Routes – Create Inbound Route

When a call is received on this SIP trunk during the hours of 8am to 6pm it will be routed to extension 100.

All calls outside of this condition will be routed to the IVR extension 7004.

If there are any questions or concerns, please feel free to get in contact with Grandstream Networks support by calling (617) 566-9300 or create a support ticket by clicking this link .

21

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
