19 inch CRT Monitor
superb computainment display,
lead-free design
With LightFrame™ for the best-ever sharpness and brightness, high resolution UXGA performance, a
big screen that displays more without scrolling and lead-free design, this 109B6 CRT monitor delivers
an exciting computainment experience.
Outstanding front of screen performance
• LightFrame™ delivers best-ever sharpness and brightness
• UXGA, 1600x1200 resolution for sharper display
• Easy-on-the-eyes high-bright, high-contrast tube
• Real flat CRT for natural, distortion and glare-free display
• sRGB ensures color matching between display and printouts
Great convenience
• Compatibility with PC, Mac and workstation platforms
• Quick and easy to personalize On-Screen-Display control
• Plug and play for easy and friendly installation
• Large viewing area for seeing more images without scrolling
Green design
• Lead-free display protects your health and our environment
• The lowest power consumption than industry average
• TCO guarantees the highest safety and ergonomics standards
• Environmentally responsible Energy Star Partner
• Flame retardant case safeguards the display from fire
109B60
19 inch CRT Monitor
Commercial Specifications
Convenience
Picture/Display
•
•
•
•
Display Screen Type
Panel Size
Phosphor
Recommended Display Area
•
•
•
•
•
•
•
•
Dot Pitch
Horizontal Dot Pitch
White Chromaticity, 5500º K
White Chromaticity, 6500º K
White Chromaticity, 9300º K
Maximum Resolution
Recommended Resolution
Factory Preset Modes
•
•
•
•
•
•
Factory Preload Modes
Video Dot Rate
Horizontal Scanning Frequency
Vertical Scanning Frequency
Recommended Refresh Rate
Screen Enhancements
• LightFrame™
• sRGB
• GTF
Connectivity
• Cables
•
•
•
•
•
•
Product Highlights
LightFrame™
Real Flat Picture Tube • Convenience Enhancements Menu Languages,
On-screen Display
19"/ 46 cm
• Monitor Controls
Brightness Control,
P22
Contrast Control,
355 x 265 mm
Left/Right, Menu,
(14" x 10.4")
LightFrame Hotkey,
0.25 mm
Power On/Off,
0.21 mm
Up/Down
x = 0.332 / y = 0.347
English, French, German,
x = 0.313 / y = 0.329 • OSD Languages
Italian, Simplified Chinese,
x = 0.283 / y = 0.297
Spanish, Portuguese,
1920 x 1440 @ 64 Hz
Korean
1600 x 1200 @ 75 Hz
• Plug & Play Compatibility
DDC 2B, sRGB,
8 modes
Windows 98/ME/
640 x 480 @ 85 Hz,
2000/XP
720 x 400 @ 70 Hz,
E2000, NUTEK,
800 x 600 @ 85 Hz, • Regulatory Approvals
Energy Star, CE Mark,
1024 x 768 @ 85 Hz,
FCC-B, UL, CSA, SEMKO,
1152 x 864 @ 70 Hz,
TCO'03, TÜV/GS,
1280 x 1024 @ 75 Hz,
TÜV Ergo, FDA, BSMI,
1280 x 1024 @ 85 Hz,
GOST, C-Tick
1600 x 1200 @ 75 Hz
• Swivel
+/- 90°
24 modes
• Tilt
-5° to 25°
250 MHz
30 - 97 KHz
50 - 160 Hz
Accessories
75 Hz
• Included Accessories
AC Power Cord
Anti-glare Polarizer,
• User Manual
Yes
Anti-Reflection, Anti-Static,
High Brightness,
High Contrast
Dimensions
Yes
• Depth (with base)
449 mm
Yes
• Height (with base)
433 mm
Yes
• Width (with base)
440 mm
• Temperature Range (Operation) 0°C to 35°C
• Temperature Range (Storage)
-25°C to 65°C
• Weight
20 kg
D-sub Video Cable,
Power Cord
Sync Input Impedance (ohm) 2.2 k
Video Input Impedance (ohm) 75
Video Input Signal Levels
0.7 Vpp
Video Sync Input Signal
Composite Sync,
Separate Sync,
Sync on Green
Video Sync Polarities
Positive and Negative
Cable Connection
AC Power in
Power
•
•
•
•
Comply With
Consumption
Off Mode
Power LED Indicator
• Power Supply
E2000, Energy Star, NUTEK
70 W
1W
Off, Amber;
Operation, Green
Built-in
An intelligent and revolutionary technology for enhancing monitor's
brightness, sharpness, contrast, and color. Images enhanced by
LightFrame™ are lively, realistic, clear, attractive and colorful.
UXGA, 1600 x 1200 resolution
For graphics monitors, the screen resolution signifies the number
of dots (pixels) on the entire screen. For example, a 1600-by-1200
pixel screen is capable of displaying 1600 distinct dots on each
of 1200 lines, or about 2 million pixels. This ensures a better
display performance and accurate color display effect.
High-bright, high-contrast tube
A CRT tube designed to increase display brightness and contrast
by increasing the CRT ray gun's beam current.
Real flat CRT display
Philips advanced flat CRT technology that minimizes glare while
reducing reflection and distortion, providing display quality superior
to that of conventional CRTs.
sRGB ready
Calibrated RGB that is optimized for the vast majority of computer
peripherals, monitors, operating systems and browsers, allowing
accurate color mapping with very little data overhead.
Platform compatibility
The ability to work with a variety of platforms; Philips monitors
are compatible with PCs and workstations by employing a VGA
connection and connect with Macintoshes.
OSD On-Screen-Display control
An on-screen panel for adjusting a monitor. The OSD is used for
contrast, brightness, horizontal and vertical positioning and other
monitor adjustments.
Easy plug and play
The ability of display device to plug in a PC and operate without
requiring user intervention to adjust complicated settings.
Large viewing area
The visible portion of a monitor screen available to display data.
Lead free
Lead-free display products are designed and produced in
compliance with strict European Community Restriction of
Hazardous Substances (RoHS) standards that restrict lead and
other toxic substances that can harm health and the environment.
Energy efficiency
Reduction of the electrical power required to operate a device to
achieve real savings.
TCO compliance
A TCO (Swedish confederation of Professional Employees) standard
even more stringent than MPR-II for safety and ergonomics,
especially concerning alternating electric fields (AEF).
Energy Star Partner
Power conservation requirements set forth by the Environmental
Protection Agency of the U.S. government.
Flame retardant case
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
As an Energy Star partner, Philips has determined that
this product meets the Energy Star guidelines for
energy efficiency.
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: November 2004, v.2
www.philips.com
A system of limiting accidental fires by engineering flame retardants
into the monitor's case.
