Introduction

This manual is intended to assist manufacturers in producing first quality merchandise for our Haband customers. The guidelines following cannot only help spot and reject defective items, but more importantly they can be used to identify production operations that require special attention to reduce the number of defects in future production.

Haband requires that all items manufactured for Haband be first quality, whether they’re expensive top-of-the-line, mid-priced, or budget-priced merchandise. To Haband, price difference is based on cost of materials and labor to produce the merchandise.

Haband will work with our suppliers to help ensure that our customers receive first quality products.

If we can help you in any way with the procedures described in this manual, please contact our Quality Control Department at (973) 942-2600.

How To Measure

1. All measurements are to be taken as specified in this manual.

2. Non-stretch fiberglass or metal tape measures are to be used.

3. All measurements will have a code. Measurements with code numbers beginning with the letter “S” are taken on the single. (Measurement is what the tape reads.)

Measurements beginning with the letter “D” are to be doubled.

4. Garments are to be laid on a flat surface when measurements are taken, with buttons, snaps, zippers and all other closures fully closed.

5. You must receive written authorization from Haband to change any Haband policy.

home

– 1 –

previous

next

Fit Samples

Samples are to be submitted in the following specified sizes only. If samples are submitted in the wrong size, they will not be evaluated and the correct size will be requested. Your cooperation in this matter will help speed up the development of production. These are the sizes required:

Size

Misses

Women’s

Men’s Tops

Men’s Woven Shirts

Men’s Pants

Big Men’s Tops

Big Men’s Pants

Range

4–18

34W–42W

S–XL

14

1

2

–20

28–43

XL–4XL

44–60

Sample Size

12 or Medium

34W or XL

M & XL

15

1

2

& 17

1

2

34W/30L

2XL

42W/30L

home

– 2 –

previous

next

Contents

Item P age

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

How to Measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Fit Samples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–7

Hoods, Necklines, Collars, Rib Bands

S-000 Hood Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

S-005 Hood Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

D-010 Neck Opening — Extended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

S-015 Neck Rib/Band Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

S-020 Neck Width — Seam to Seam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

S-024 Neck Opening — Circumference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

S-025 Front Neck Drop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

D-030 Neck Opening — Circumference (Rib/Collars) . . . . . . . . . . . . . . . . . . 8-9

S-035 Back Neck Drop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

D-040 Neck Opening — Extended (Rib/Binding) . . . . . . . . . . . . . . . . . . . . . 8-9

Turtlenecks, Neckbands, Collars, Plackets

S-045 Collar Point Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-050 Neck Width (Turtlenecks and Mock Turtlenecks) . . . . . . . . . . . . . . . . 10-11

S-055 Back Collar Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

D-060 Collar Length (Pullover Garments) . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-065 Neckband Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-070 Neck Opening — Flat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-080 Collar Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-084 Collar Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-088 Collar Spread . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-090 Placket Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

S-095 Placket Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

Armholes, Sleeves

D-100 Upper Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-104 Elbow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-105 Armhole — Set-In, Sleeveless, Drop Shoulder

with the Same Front to Back Contour . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-108 Forearm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-112 Sleeve Opening — Hemmed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

home

– 3 –

previous

next

Contents

(cont’d)

Item P age

S-115 Armhole — Set-In, Sleeveless with Different Front to Back Contour . . 12-13

S-125 Front Armhole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

S-127 Back Armhole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-131 Armhole — Saddle Shoulder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

D-133 Armhole — Straight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

Shoulders, Sleeves, Cuffs, Sleeve Plackets

S-140 Shoulder Slope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-144 Sleeve Length — Raglan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-148 Center Back Sleeve Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-150 Sleeve Length — Shoulder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-154 Sleeve Length — Underarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

D-160 Sleeve Opening — Knit Cuffs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

D-164 Sleeve Opening — Elastic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

D-168 Sleeve Opening — Extended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-170 Sleeve Placket Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-175 Sleeve Placket Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-180 Cuff Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-185 Cuff/Rib Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

S-190 Cuff Opening — Cuff Unbuttoned — Total Length . . . . . . . . . . . . . . . 14-15

S-194 Cuff Opening — Cuff Unbuttoned . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

Yokes, Waists, Center Front/Back, Chest Measurements

S-205 Yoke Height from High Point of Shoulder . . . . . . . . . . . . . . . . . . . . . . 16-17

S-210 Shoulder Width/Shoulder Seam Length . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-214 Across Shoulder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-215 Yoke Height from Center Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-218 Across Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

D-290 Chest/Bust Circumference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

D-300 Front Waist (Tops and Dresses) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-305 Side Seam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-315 High Point Length — Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-325 Center Back Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-335 Back Waist Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

S-345 Half Waist (Sportcoats) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

home

previous

next

– 4 –

Contents

(cont’d)

Item P age

Robes, Skirts, Shorts, Pants

S-400 Chest/Bust (Robes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-405 Side Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-410 Yoke Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-413 Center Front Length (Skirts) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-417 Center Back Length (Skirts) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

D-420 High Hip (Women’s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-421 Fly Stitching Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

S-423 Fly Opening — Functional (Bottoms) . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

D-424 Low Hip (Women’s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

D-428 Seat/Hip (Men’s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

Pants

D-430 Relaxed Waist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-435 Waistband Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

D-440 Extended Waist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-443 Front Rise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-447 Back Rise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-500 Total Inseam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

D-510 Thigh Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

D-514 Knee Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

D-518 Calf Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

D-522 Bottom Opening — Hemmed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-530 Outseam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

S-534 Inseam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

Cuffs, Stirrups, Sweeps

D-600 Bottom Opening — Knit Cuffs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

D-610 Bottom Opening — Elastic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

D-620 Bottom Opening — Extended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

D-630 Sweep (Skirts and Dresses) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

S-640 Sweep (Robes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

D-700 Leg Opening (Stirrup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

S-710 Stirrup Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

S-715 Stirrup Arch Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

S-720 Stirrup Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

home

– 5 –

previous

next

Contents

(cont’d)

Item P age

Sweeps, Socks

D-650 Sweep — Vents or Tails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

D-660 Sweep — Extended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

D-670 Sweep — Elastic Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

D-680 Sweep — Rib Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

D-690 Sweep — Straight Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

S-725 Sole/Foot Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

S-730 Sole/Foot Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

S-735 Foot Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

S-745 Toe Cap Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

Bras

S-800 Shoulder Strap Relaxed (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-804 Front Bottom Band Length (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-805 Center Front Length (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-808 Total Bottom Band Length (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-810 Criss-Cross Binding (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-815 Cup Length (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-818 Cup Width (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-820 Bust Point to Bust Point Length (Bras) . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-830 Back Frame Width (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-835 Back Frame Height (Bras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

S-842 Top Frame Binding — Total Length Relaxed (Bras) . . . . . . . . . . . . . . 26-27

S-848 Top Frame Binding — Side Front Length Relaxed (Bras) . . . . . . . . . . 26-27

S-844 Top Frame Binding — Center Front Length Relaxed (Bras) . . . . . . . . 26-27

Swimsuits, Panties, Girdles, Men’s Underwear

S-854 Chest — Top of Bandeau . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-856 Chest — Bottom of Bandeau . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-858 Under Bra Elastic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-860 Crotch Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-863 Crotch Length — Contour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-867 Crotch Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

D-870 Seat/Hip (Swimwear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-873 Front Rise (Panties) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

home

– 6 –

previous

next

Contents

(cont’d)

Item P age

S-875 Total Rise (Panties) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-877 Back Rise (Panties) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

D-880 Leg Opening — Straight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

D-884 Leg Opening (Underwear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-885 Fly Opening (Underwear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

D-888 Leg Opening — Extended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

S-895 Total Length (Girdles) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

Pockets, Pocket Placement

S-905 Set-In Pocket Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-910 Pocket Bag Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-915 Pocket Bag Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-920 Patch Pocket Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-924 Patch Pocket Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-931 Patch Pocket Length (Contour Bottom) . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-935 Patch Pocket Height (Straight Bottom) . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-940 Pocket Placement from Center Front . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

S-945 Pocket Placement from High Point of Shoulder . . . . . . . . . . . . . . . . . . 30-31

Belt Loops, Belt Loop Placement, Belts & Sashes

S-950 Belt Loop Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-955 Belt Loop Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-965 Belt Loop Placement (Dresses) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-970 Belt Length (Standard Buckles) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-975 Belt Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-980 Belt Length (Fixed Hook Buckles) . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

S-990 Belt Length (Sash/Tie Belt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

home

– 7 –

previous

next

Hoods, Necklines, Collars, Rib Bands

D-010 Neck Extended

S-000 Hood Width

S-020 Neck Width — Seam to Seam

S-015 Neck Rib/Band Height

S-025 Front Neck Drop

S-024 Neck Opening — Circumference

D-030 Neck Opening — Circumference

(Rib/Collars)

home

S-035 Back Neck Drop

D-040 Neck Extended

(Rib/Binding)

– 8 –

previous

next

Hoods, Necklines, Collars, Rib Bands

S-000 Hood Width

Fold hood in half and lay flat. Measure from the front to the back fold of the hood, “X” inches down from the hood opening. (Usually at the widest point of the hood.)

S-005 Hood Height

Fold hood in half and lay flat. Measure up from the center front of the hood at neckline seam to the fold at the top of the hood.

D-010 Neck Opening — Extended

Open garment if applicable. Extend the garment’s neck as far as possible without seam breakage. Measure outside from seam to seam or edge to edge if no seam is present.

S-015 Neck Rib/Band Height

Measure the distance from the neckline seam to the rib/band edge at the center back.

S-020 Neck Width — Seam to Seam

Measure across neckline or collar from high point of shoulder (high point of shoulder being the point of intersection of the neckline seam and shoulder seam, or the neckline seam and the natural fold of the shoulder) to high point of shoulder (seam to seam). Include binding or rib if present.

S-024 Neck Opening — Circumference

Button garment if applicable. Match shoulder seams and align neck seam.

Measure outside from side to side, following the collar/neck seam.

S-025 Front Neck Drop

Adjust the garment so the high points of shoulder are level. (High point of shoulder being the point of intersection of the neckline seam and shoulder seam, or the neckline seam and the natural fold of shoulder.) Place a straight edge across, connecting the two points to form the imaginary line. Measure from the imaginary line to the center front seam or edge if no stitching is present. On “V” neck cardigans, measure to the center of the top button.

D-030 Neck Opening — Circumference (Rib/Collars)

Button garment if applicable. Match shoulder seams and align neck seam.

Measure inside from side to side, following the collar/neck seam.

S-035 Back Neck Drop

Adjust the garment so the high points of shoulder are level. (High point of shoulder being the point of intersection of the neckline seam and the shoulder seam, or the neckline seam and the natural fold of the shoulder.) Place a straight edge across, connecting the two points to form the imaginary line to the center back neck seam or edge if no stitching is present.

D-040 Neck Opening — Extended (Rib/Binding)

Extend the garment’s neck as far as possible without seam breakage. Measure inside from seam to seam or edge to edge if no seam is present.

home

– 9 –

previous

next

S-045

Collar

Point

Length

Turtlenecks, Neckbands, Collars, Plackets

S-080 Collar Length

S-050 Neck Width

(Turtlenecks and

Mock Turtlenecks)

S-055 Back Collar Height

S-065 Neckband Height

D-060 Collar Length

(Pullover Garments)

S-070 Neck Opening — Flat

S-095

Placket

Length

S-084

Collar

Gap

home

S-088 Collar Spread

– 10 –

S-090 Placket Width

previous

next

Turtlenecks, Neckbands, Collars, Plackets

S-045 Collar Point Length

Measure from collar point to set seam/collar join along edge of collar.

S-050 Neck Width (Turtlenecks and Mock Turtlenecks)

Align neck edges. Measure across the top of the neck or rib trim inside from seam to seam or edge to edge if no seam is present.

S-055 Back Collar Height

At center back, measure from edge of collar to set seam.

D-060 Collar Length (Pullover Garments)

Match collar points by folding collar in equal halves. Measure from the fold to the collar point along top of the edge.

S-065 Neckband Height

At center back, measure from collar/neckband seam to neckline seam.

S-070 Neck Opening — Flat

Measure along the center of the unbuttoned collar band, from the inside of the button tack/center of button to the outside edge of the buttonhole. (Excluding buttonhole bar tack)

S-080 Collar Length

Open garment and lay collar flat. Measure the distance from one collar point to the other collar point along the top edge.

S-084 Collar Gap

Button neckband and collar points if applicable. Measure the distance one edge of the collar set seam/collar join to the other edge of the collar set seam/collar join.

S-088 Collar Spread

Button neckband and collar points if applicable. Measure the distance from collar point to collar point.

S-090 Placket Width

Measure straight across the placket at the widest point, from the opening edge to edge/seam.

S-095 Placket Length

Measure from the neckline seam or edge to the bottom edge of the placket.

Include top stitching if present.

home

– 11 –

previous

next

D-112

Sleeve Opening

— Hemmed

D-108

Forearm

Armholes, Sleeves

D-100

Upper Arm

D-104

Elbow

D-105 Armhole —

Set-In, Sleeveless, Drop Shoulder, with the Same Front to Back Contour

S-125

Front Armhole

S-127

Back Armhole

S-115 Armhole —

Set-In, Sleeveless, with Different Front to Back Contour

home

D-131 Armhole —

Saddle Shoulder

– 12 –

D-133

Armhole —

Straight

previous

next

Armholes, Sleeves

D-100 Upper Arm

Measure at armhole, or “X” inches below the armhole, straight across the sleeve, perpendicular to the sleeve edge.

D-104 Elbow

Measure “X” inches down the underarm seam. Measure straight across the sleeve, parallel to the sleeve hem.

D-105 Armhole — Set-In, Sleeveless, Drop Shoulder with the Same Front to Back Contour

Measure from the bottom of the armhole to the top of the armhole, following the seam contour.

D-108 Forearm

Measure “X” inches down from the armhole along the seam. Measure across, edge to edge, parallel to the sleeve hem.

D-112 Sleeve Opening — Hemmed

Measure straight across the bottom of the sleeve opening, edge to edge.

S-115 Armhole — Set-In, Sleeveless with Different Front to Back Contour

Measure from the bottom of the armhole to the top of the armhole, following the seam contour for front and back. Add front and back measurements together for armhole circumference.

S-125 Front Armhole

Measure from the top to the bottom of the armhole following the seam.

S-127 Back Armhole

Measure from the top to the bottom of the armhole following the seam.

D-131 Armhole — Saddle Shoulder

Measure the distance between the bottom of the armhole to the neck at the natural fold of the shoulder.

D-133 Armhole — Straight

Measure a straight line from the armhole/shoulder seam intersection

(or armhole/natural fold of shoulder intersection) to the armhole/side seam intersection.

home

– 13 –

previous

next

Shoulders, Sleeves, Cuffs, Sleeve Plackets

S-140 Shoulder Slope S-144 Sleeve Length —

Raglan

S-148

Center Back

Sleeve Length

S-150 Sleeve Length —

Shoulder

S-154 Sleeve Length —

Underarm

D-160 Sleeve Opening —

Knit Cuffs

D-164 Sleeve Opening —

Elastic

D-168 Sleeve Opening —

Extended

S-185 Cuff/Rib

Height

S-170

Sleeve

Placket

Width

S-180 Cuff Length

S-194 Cuff Opening —

Unbuttoned

S-175 Sleeve Placket

Length

home

– 14 –

S-190 Cuff Opening —

Unbuttoned

Total Length

previous

next

Shoulders, Sleeves, Cuffs, Sleeve Plackets

S-140 Shoulder Slope

Adjust garment so the high points of shoulder are level. Place a straight edge across, connecting the two points to form the imaginary line, and extend it beyond the shoulder point. Measure from the imaginary line to the shoulder point.

S-144 Sleeve Length — Raglan

Measure from the high point of shoulder to the bottom edge of sleeve. Include rib trim if applicable.

S-148 Center Back Sleeve Length

Measure from the center back neck to the shoulder point. Continue down the outer edge of the sleeve opening. Include rib trim if applicable.

S-150 Sleeve Length — Shoulder

Measure from the armhole/shoulder point, along the outside edge, to the bottom edge of the sleeve opening.

S-154 Sleeve Length — Underarm

Measure from the bottom of the armhole seam to the inside edge of the sleeve opening.

D-160 Sleeve Opening — Knit Cuffs

Measure inside following the edge of the cuff.

D-164 Sleeve Opening — Elastic

At the bottom of the sleeve opening, measure inside from edge to edge following the elastic.

D-168 Sleeve Opening — Extended

Follow the procedure for the sleeve opening, measuring inside while extending the elastic or rib fully without seam breakage.

S-170 Sleeve Placket Width

Measure across the sleeve placket, from opening edge to seam/edge.

S-175 Sleeve Placket Length

Measure from the cuff seam to the end of the placket including point (doghouse) if applicable.

S-180 Cuff Length

Unbutton cuff. Measure along the center, from edge to edge.

S-185 Cuff/Rib Height

Measure the rib or the armband, from the bottom edge to the cuff join seam.

S-190 Cuff Opening — Cuff Unbuttoned — Total Length

Measure the cuff from edge to edge at the bottom of the sleeve.

S-194 Cuff Opening — Cuff Unbuttoned

Measure along the center of the cuff, from the button tack closest to the outer edge, to the outside end of the buttonhole (last button). Do not include buttonhole bartack.

home

– 15 –

previous

next

Yokes, Waists, Center Front/Back,

Chest Measurements

S-210 Shoulder

Width/Shoulder

Seam Length

S-205 Yoke Height from High Point of Shoulder

S-214 Across Shoulder

S-218 Across Back

S-215 Yoke Height from Center Back

S-315 High Point Length — Front

D-300 Front Waist

(Tops and Dresses)

home

S-345 Half Waist

(Sportcoats)

– 16 –

D-290 Chest/Bust

Circumference

previous

next

Yokes, Waists, Center Front/Back,

Chest Measurements

S-205 Yoke Height from High Point of Shoulder

Measure from the high point of the shoulder to the bottom edge of the yoke.

S-210 Shoulder Width/Shoulder Seam Length

Measure from the neck seam to the armhole along the shoulder seam or the natural fold of the shoulder.

S-214 Across Shoulder

Align the garment so the shoulder/armhole points are level. (Or the natural fold of the shoulder/armhole points are level.) Measure across the garment, from one shoulder point to the other.

For sleeveless garments with bindings or rib trim: Measure from edge to edge of garment including the rib or binding.

S-215 Yoke Height from Center Back

Measure from the center back neck seam to the bottom edge of the yoke.

S-218 Across Back

Measure “X” amount of inches down from the center back neck. From this point, measure straight across the back from armhole to armhole.

D-290 Chest/Bust Circumference

Measure at the armhole, or “X” inches below the armhole, straight across with all pleats and fullness opened.

D-300 Front Waist (Tops and Dresses)

At either the narrowest point of the garment, or the specified distance from the high point of shoulder, measure straight across at the front of the garment, side to side, or fold to fold if no side seam is present.

S-305 Side Seam

Excluding vents or tails, measure from the armhole/side seam intersection to the bottom of the side seam or edge.

S-315 High Point Length — Front

Measure from the shoulder/neckline seam intersection, or the natural shoulder fold of the garment at the neckline, straight down to the edge of garment. Include rib trim, bands, or bottom of toe if applicable.

S-325 Center Back Length

Measure from the center back neck to the bottom edge of the garment.

S-335 Back Waist Length

Measure from the center back neck to the waistline seam or bottom edge of the waistband.

S-345 Half Waist (Sportcoats)

home

Open jacket and lay flat, face up. Measure at the waist from the center back straight across to the button front edge. To locate waist: Waist is positioned in line with the top button on a one or two button coat, and the center button on a three button coat.

– 17 –

previous

next

Robes, Skirts, Shorts, Pants

S-400 Chest/Bust (Robes)

S-405 Side Opening

Front Panel Back Panel Front Panel

S-410

Yoke

Height

S-423

Fly

Opening —

Functional

(Bottoms)

S-421

Fly

Stitching

Length

D-420

High Hip

(Women’s)

D-424

Low Hip

(Women’s)

home

– 18 –

D-428

Seat/Hip

(Men’s)

previous

next

Robes, Skirts, Shorts, Pants

S-400 Chest/Bust (Robes)

Front panel: Open garment. Measure across, “X” inches below the armhole from side seam to outer edge for each panel.

Back panel: Open garment. Measure across “X” inches below the armhole from side seam to side seam.

Add back and both front panel measurements together.

S-405 Side Opening

Close garment. Measure from the top edge of the waist to the bottom of the opening.

S-410 Yoke Height

Measure from the bottom of the waistband, (or bottom row of stitching on elastic waist garments) to the bottom of the yoke at the longest point (unless otherwise specified).

S-413 Center Front Length (Skirts)

Measure from the top of the waistband, (or the top row of the stitching in elastic waist garments) down the center front to the bottom of the garment.

For garments without a waistband, measure from the top edge of the waist.

S-417 Center Back Length (Skirts)

Measure from the top of the waistband, (or the top row of stitching in elastic waist garments) down the center back to the bottom of the garment. For garments without a waistband, measure from the top edge of the waist.

D-420 High Hip (Women’s)

Close pleats and smooth body fullness out if applicable. Measure down the center front and side seams “X” inches from the waistband seam, (or the bottom row of stitching on garments with an elastic waist). Measure from side seam to center to side seam.

S-421 Fly Stitching Length

Measure from the top of the fly stitch to the bottom along the center front edge.

S-423 Fly Opening — Functional (Bottoms)

Unzip fly. Measure from top of zipper pull to the bottom of the waistband or top edge if no waistband is present.

D-424 Low Hip (Women’s)

Measure down the center front and side seams “X” inches from the waistband seam (or bottom row of stitching on garments with an elastic waist). Measure from side seam to center to side seam.

D-428 Seat/Hip (Men’s)

Measure “X” inches up from the crotch seam or natural fold. From this point, measure straight across the garment, from side to side.

home

– 19 –

previous

next

D-430 Relaxed Waist

Pants

S-435 Waistband

Width

D-440 Extended Waist

S-447

Back

Rise

D-510

Thigh Width

home

D-514

Knee Width

D-518

Calf Width

D-522

Bottom

Opening —

Hemmed

S-500

Total Inseam

– 20 –

previous

next

Pants

D-430 Relaxed Waist

Close the garment if necessary. Measure from seam to seam or edge to edge inside the garment, straight across the top of waist. For contoured waists, follow the curve along the outer edge of the waistband or top edge.

S-435 Waistband Width

Measure from top edge of the waistband to the bottom edge or last row of stitching.

D-440 Extended Waist

Close the garment if necessary. Measure from seam to seam or edge to edge inside the garment, straight across the top of the fully extended elastic.

(“Fully extended” is stretched as far as possible without seam breakage.)

S-443 Front Rise

Measure from the crotch point (the point of intersection where the crotch seam meets the inseam), following the contour of the front rise seam, to the top edge of the waistband. On elastic waist garments, measure to the top row of stitching.

On garments without a waistband, measure to the top edge.

S-447 Back Rise

Measure from the crotch point, following the contour of the back rise seam, to the top edge of the waistband. On elastic waist garments, measure to the top row of stitching. On garments without a waistband, measure to the top edge.

S-500 Total Inseam

Measure from the bottom of the left leg opening to the bottom of the right leg opening following the curve of the seam.

D-510 Thigh Width

Measure at the crotchpoint, or “X” number of inches below the crotchpoint, straight across to the outer edge of the leg. Tape should be parallel to the hem of the garment.

D-514 Knee Width

Measure “X” inches down from the inseam. From this point, measure across the leg from side to side, parallel to the hem.

D-518 Calf Width

Measure “X” inches down from the crotch. Measure straight across edge to edge, parallel to the hem.

D-522 Bottom Opening — Hemmed

Measure at the bottom of the leg opening, straight across from outside edge to outside edge.

S-530 Outseam

Measure from the top edge of waistband, (or the top row of stitching on elastic waist garments) following the contour of the outseam to the bottom of the leg opening. Include rib if applicable.

S-534 Inseam

Measure from the crotchpoint, following seam, to the bottom of the leg, including cuff or rib if applicable.

home

– 21 –

previous

next

Cuffs, Stirrups, Sweeps

D-600

Bottom Opening —

Knit Cuffs

D-610

Bottom Opening —

Elastic

D-620

Bottom Opening —

Extended

D-700

Leg Opening

(Stirrup)

D-630 Sweep

(Skirts and Dresses)

S-710

Stirrup Length

S-715

Stirrup

Arch

Height

S-720

Stirrup

Width

home

Front Panel Back Panel Front Panel

– 22 –

S-640 Sweep (Robes)

previous

next

Cuffs, Stirrups, Sweeps

D-600 Bottom Opening — Knit Cuffs

Take the measurement inside, following the edge of the cuff from seam to seam or edge to edge if no seam is present.

D-610 Bottom Opening — Elastic

Measure inside following the edge of the bottom opening from seam to seam or edge to edge if no seam is present.

D-620 Bottom Opening — Extended

Extend elastic or rib as far as possible without seam breakage. Measure inside from seam to seam or edge to edge if no seam is present.

D-630 Sweep (Skirts and Dresses)

Open all fullness. Measure the bottom opening following the edge.

S-640 Sweep (Robes)

Front Panel: Open garment, measure the distance from the side seam to the edge along the hem for each panel.

Back Panel: Open garment, measure the distance from side seam to side seam along the hem.

Add back and both front panel measurements together.

D-700 Leg Opening (Stirrup)

Lay outseam to inseam. Measure inside, straight across the top of the arch.

S-710 Stirrup Length

Measure along the center from ankle/stirrup seam to ankle/stirrup seam.

S-715 Stirrup Arch Height

Match inseam and outseam. Use natural fold of stirrup as the imaginary line.

Measure from the imaginary line to the highest point of arch.

S-720 Stirrup Width

Measure straight across from edge to edge at narrowest point.

home

– 23 –

previous

next

Sweeps, Socks

D-650 Sweep —

Vents or Tails

D-660 Sweep — Extended

D-670 Sweep —

Elastic Bottom

D-680 Sweep —

Rib Trim

S-695

Bottom Rib/Band

Height

D-690 Sweep — Straight Bottom

home

S-730

Sole/Foot

Width

S-725

Sole/Foot

Length

S-735

Foot Height

– 24 –

S-745

Toe Cap

Length

previous

next

Sweeps, Socks

D-650 Sweep — Vents or Tails

Measure straight across from side to side at the top of the side vent.

D-660 Sweep — Extended

Extend sweep the full distance without seam breakage. Measure the bottom of the garment from inside edge to inside edge.

D-670 Sweep — Elastic Bottom

Measure the garment inside from edge to edge, following the bottom edge of the elastic.

D-680 Sweep — Rib Trim

Measure inside along the bottom, following the edge of the rib trim.

D-690 Sweep — Straight Bottom

Measure straight across from side to side at bottom of the garment.

S-725 Sole/Foot Length

At center of the foot, measure from the toe seam to the heal seam.

S-730 Sole/Foot Width

Measure from side to side at the center of the foot.

S-735 Foot Height

Measure at the outseam from bottom row of ankle stitching to sole seam/level.

S-745 Toe Cap Length

Measure from the toe seam to the fold or cap seam at the center.

home

– 25 –

previous

next

Bras

S-800

Shoulder Strap

Relaxed

S-804 Front Bottom Band Length

S-808 Total Bottom Band Length

S-810

Criss-Cross

Binding

S-818

Cup

Width

S-815 Cup Length

S-835

Back

Frame

Height

S-842

Top Frame Binding —

Total Length

Relaxed

S-830 Back Frame Width

S-844

Top Frame Binding —

Center Front Length

Relaxed

S-820

Bust Point to Bust Point

Length

S-848

Top Frame Binding —

Side Front Length

Relaxed

home

– 26 –

previous

next

Bras

S-800 Shoulder Strap Relaxed (Bras)

Measure the center of the entire strap, from top of the cup in front to the strap/back frame intersection in the back.

S-804 Front Bottom Band Length (Bras)

Measure center of band from side seam to side seam.

S-805 Center Front Length (Bras)

Measure from the top to the bottom of the bra at center front.

S-808 Total Bottom Band Length (Bras)

Measure the bottom edge of the bra from the hooks to the middle or second set of eyes (set closest to center back).

S-810 Criss-Cross Binding (Bras)

Measure from start of the binding at the strap to the bottom of the binding at the band.

S-815 Cup Length (Bras)

Measure from the top of the cup at the strap/cup seam, following the seamline across the bust point to the cup/band seam. If the cup is seamless, follow the deepest curve as shown in the diagram.

S-818 Cup Width (Bras)

Measure from the cup/frame side seam following the seamline across the bust point to the center front seaming. If the cup is seamless, follow the deepest curve as shown in the diagram.

S-820 Bust Point to Bust Point Length (Bras)

Measure from bust point to bust point across the chest on figure.

S-830 Back Frame Width (Bras)

Fold garment in half to locate center back. Measure the bottom edge of the frame from center back to side seam.

S-835 Back Frame Height (Bras)

Measure the frame at the side seam from the top to the bottom.

S-842 Top Frame Binding — Total Length Relaxed (Bras)

Measure from the highest point of the cup to the center back along the top edge.

S-848 Top Frame Binding — Side Front Length Relaxed (Bras)

Measure from the highest point of the cup to the side seam following the top edge.

S-844 Top Frame Binding — Center Front Length Relaxed (Bras)

Measure from the highest point of the cup to the center front following the top edge.

home

– 27 –

previous

next

Swimsuits, Panties, Girdles, Men’s Underwear

S-854 Chest —

Top of Bandeau

S-856

Chest —

Bottom of Bandeau

S-858 Under Bra Elastic

S-863

Crotch

Length —

Contour

S-867

Crotch Length

S-860

Crotch

Width

D-870 Seat/Hip

(Swimwear)

S-873

Front

Rise

(Panties)

S-877

Back

Rise

(Panties)

S-875 Total Rise (Panties)

S-885

Fly Opening

(Underwear)

D-880

Leg Opening —

Straight

S-895

Total

Length

(Girdles)

home

– 28 –

D-884

Leg Opening

(Underwear)

D-888

Leg Opening —

Extended

previous

next

Swimsuits, Panties, Girdles, Men’s Underwear

S-854 Chest — Top of Bandeau

Measure from end to end using a fixed tape and following the curve of the garment. (Excluding closures)

S-856 Chest — Bottom of Bandeau

Measure from end to end using a fixed tape and following the curve of the garment. (Excluding closures)

S-858 Under Bra Elastic

Measure center of relaxed elastic, from seam to seam.

S-860 Crotch Width

Measure from leg opening to leg opening at seam or narrowest point including trim if applicable.

S-863 Crotch Length — Contour

Fold garment so side seams meet and lay flat. Measure at the center of the crotch panel, following contour from seam to seam.

S-867 Crotch Length

Measure at the center of the crotch panel, seam to seam.

D-870 Seat/Hip (Swimwear)

Measure straight across at the top of the leg opening, seam to seam, or fold to fold.

S-873 Front Rise (Panties)

Fold the garment so the side seams meet and lay flat. Measure the rise following the contour from the center front waist to the front crotch seam.

S-875 Total Rise (Panties)

Fold the garment so the side seams meet and lay flat. Measure the rise following the contour from the center front waist to the center back waist.

S-877 Back Rise (Panties)

Fold the garment so the side seams meet and lay flat. Measure the rise following the contour from the center back waist to the back crotch seam.

D-880 Leg Opening — Straight

Lay the garment flat. Measure a straight line from the top of the leg opening to the bottom at crotch.

D-884 Leg Opening (Underwear)

Match side seam and crotch seam. Measure the leg opening following the curve.

S-885 Fly Opening (Underwear)

Measure from the top of the opening to the bottom of the opening, along the edge, following the curve.

D-888 Leg Opening — Extended

Stretch elastic as far as possible without seam breakage. Measure the distance of extended elastic inside from edge to edge.

S-895 Total Length (Girdles)

On the back of the garment, measure from the top edge of the waistline to the bottom edge of the leg opening (excluding garter).

home

– 29 –

previous

next

Pockets, Pocket Placement

S-905

Set-In Pocket

Opening

S-910

Pocket Bag

Width

home

S-920

Patch Pocket Opening

S-924

Patch Pocket Width

S-931 Patch Pocket Length

S-945

Pocket Placement from High Point of Shoulder

S-940

Pocket

Placement from

Center Front

– 30 –

previous

next

Pockets, Pocket Placement

S-905 Set-In Pocket Opening

Measure the inside opening from edge to edge or bar tack to bar tack following curve, where applicable.

S-910 Pocket Bag Width

Measure at the widest part of the pocket, seam to seam.

S-915 Pocket Bag Length

Measure at the longest point, from the top of the pocket to the seam at bottom.

S-920 Patch Pocket Opening

Measure the opening of the pocket inside from seam to seam or tack to tack if present.

S-924 Patch Pocket Width

Measure from edge to edge at the widest point of the pocket.

S-931 Patch Pocket Length (Contour Bottom)

Measure from the center of the top of the pocket to the center of the bottom of the pocket.

S-935 Patch Pocket Height (Straight Bottom)

Measure from the top to the bottom of the pocket at the stitching.

S-940 Pocket Placement from Center Front

Measure straight across from center front (for shirts measure from center of buttonhole) to the top edge of the pocket opening.

S-945 Pocket Placement from High Point of Shoulder

Measure straight down from the high point of shoulder (high point of shoulder being the point of intersection of the neckline seam and shoulder seam, or the neckline seam and natural fold of shoulder) to the top edge of the pocket. If pocket has a flap, measure to flap edge.

home

– 31 –

previous

next

Belt Loops, Belt Loop Placement, Belts & Sashes

S-965

Belt Loop

Placement

(Dresses)

S-950

Belt

Loop

Width

S-975 Belt Width

S-970 Belt Length (Standard Buckles)

S-980 Belt Length (Fixed Hook Buckles)

home

S-990 Belt Length (Sash/Tie Belt)

– 32 –

previous

next

Belt Loops, Belt Loop Placement, Belts & Sashes

S-950 Belt Loop Width

Measure across the belt loop from edge to edge.

S-955 Belt Loop Length

Measure inside from loop set to loop set.

S-965 Belt Loop Placement (Dresses)

Measure from the center back straight down to the top level of the loop attachment.

S-970 Belt Length (Standard Buckles)

Measure from the inside edge of the buckle to the center of middle hole. If there are no more holes, measure to the tip of the belt.

S-975 Belt Width

Measure across belt from edge to edge.

S-980 Belt Length (Fixed Hook Buckles)

Measure from the inside edge, at the base of the hook to the center of the middle hole. If there are no holes, measure to the tip of the belt.

S-990 Belt Length (Sash/Tie Belt)

Measure from edge to edge.

home

– 33 –

previous

next

home

110 Bauer Drive • Oakland • New Jersey • 07436

4/04

previous

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
