I2C Driver in Linux
Computer Science & Engineering Department
Arizona State University
Tempe, AZ 85287
Dr. Yann-Hang Lee
[email protected]
(480) 727-7507
7/23
I2C and SMBus in x86
 In general, a system can have multiple I2C
buses via different adapters and many
I2C devices
 2-wire synchronous serial buses
 0000:00:1f.3 [0x400-0x41f]
ICH8
SMBus
 Master and slave, addressable
 SMBus module in ICH8
Processor
PCI to I2c
Adapter
EEPROM
 I2C bus and the SMBus are
PCI bus
EEPROM
I2C
sensor
essentially compatible with each other.
 Differences:
 Timeout (in SMBus, reset interfaces when
clock is low forlonger than 35ms))
 Maximum clock speed: 100MHz(Smbus) but I2C bus has both 400kHz and
3.4MHz versions.
 Logic level: 1: 3V in I2C and 2.1V in SMBus
 General call and alert response.
1
I2C Drivers in Linux
 A driver for I2C bus
 adapter and algorithm drivers
 manages I2C bus transactions
 Drivers for I2C devices
 A client has the device’s I2C bus
address and a pointer to a driver
which is attached with an adapter
 When a user program issues a file
operation that needs an I2C
transaction
 i2C_transfer (i2C-core.c) to invoke
adap_algo_master_xfer
 command or data is in an msg array
 the adapter issues reads/writes to
hardware I/O addresses.
 Other operations (except I2C bus
transaction) are handler by the
drivers
(https://i2c.wiki.kernel.org/index.php/Driver_Architecture)
2
Example of Accessing I2C/SMBus Devices
i2c_smbus_xfer(adapter, addr, …., data)
user
program
device
driver
I2C
core
I2C
algorithm
I2C
adapter
read(……)
I2C
device
I2C bus signals
i801_access(adapter, addr, …. data)
user space
kernel space
// for each i2c device
struct i2c_client {
unsigned short flags;
unsigned short addr;
char name[I2C_NAME_SIZE];
struct i2c_adapter * adapter;
adapter->algo->smbus_xfer(adapter, addr, flags,
read_write, command, protocol, data);
struct i2c_driver * driver;
struct device dev;
int irq;
struct list_head list;
struct completion released;
};
3
Example of I2C Devices
 Two Wii nunchuck devices
 one is connected to ICH8 SMBus
 one is connected to I2C adapter on PCI bus
 2 instances of I2C_client
 different I2C device names
 different adapters
 Use the same device driver
 same I2C slave address 0x52
 When read from the nunchucks
 Same I2C signals on both buses, e.g. start, addr, R/W, ack …..
 Different commands are sent to the different adapters (ICH8 SMBus
module and PCI I2C adapter)
 Driver makes the same call to
i2c_smbus_xfer of i2c.core and then adapter->algo->smbus_xfer
4
User Space Access to I2C Devices
 Basically, a device driver to control I2C adapters
 Send and receive raw data to and from I2C buses
 An I2C device driver can process the raw data and present
data according to device model
 A nunchuck device driver measures the speed of joystick movement
instead of reporting joystick position.
 I2C-dev – loadable module
 Major number: 89
 Minor number: defined for each adapter
 i2c_dev represents an i2c_adapter, an I2C or SMBus master, not a
slave (i2c_client) – called /dev/i2c-0, /dev/i2c-1, /dev/i2c-2, etc.
struct i2c_dev {
struct list_head list;
struct i2c_adapter *adap;
struct device *dev;
};
5
How to Use I2C-dev
 Load i2c-dev module
 Create an i-node for the device
% mknod /dev/i2c-0 c 89 0
 Include i2c-dev.h where i2c-dev interface is defined
#define ADDRESS 0x38
int fd;
fd = open( "/dev/i2c-0", O_RDWR );
ioctl( fd, I2C_SLAVE, ADDRESS );
// open a device file
// set up the slave address
 Using read() and write) for an entire I2C transaction takes place (i.e.
start bit, address, data, stop).
 Using the wrapper functions that i2c-dev.h provides.
 SMBus commands
i2c_smbus_write_byte_data()  i2c_smbus_acces
 ioctl(file,I2C_SMBUS,&args)
 S _ Addr _ Wr _ [A] _ Comm _ [A] _ Data _ [A] _ P
6
