EMC NetWorker Release 7.5 Performance Tuning Guide

EMC NetWorker Release 7.5 Performance Tuning Guide

EMC

®

NetWorker

®

Release 7.5

Performance Tuning Guide

P/N 300-008-472

REV A01

EMC Corporation

Corporate Headquarters:

Hopkinton, MA 01748

-

9103

1

-

508

-

435

-

1000 www.EMC.com

Copyright © 2008 EMC Corporation. All rights reserved.

Published December, 2008

EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.

THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS IS.” EMC CORPORATION MAKES NO

REPRESENTATIONS OR WARRANTIES OF ANY KIND WITH RESPECT TO THE INFORMATION IN THIS PUBLICATION,

AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE.

Use, copying, and distribution of any EMC software described in this publication requires an applicable software license.

For the most up-to-date listing of EMC product names, see EMC Corporation Trademarks on EMC.com.

All other trademarks used herein are the property of their respective owners.

2

EMC NetWorker Release 7.5 Performance Tuning Guide

Contents

Preface

Chapter 1

Chapter 2

Chapter 3

NetWorker Features

Introduction to NetWorker editions..................................................................... 12

Overview of hardware and software performance............................................ 12

Testing and Tuning Basics

Overview of performance testing and tuning .................................................... 16

Server hardware...................................................................................................... 17

Physical disks .................................................................................................... 17

Memory and CPU usage ................................................................................. 20

Server input/output......................................................................................... 21

NetWorker settings ................................................................................................. 22

Server parallelism ............................................................................................. 22

Client parallelism.............................................................................................. 22

Multiplexing ...................................................................................................... 22

Modifying settings for performance tuning ................................................. 23

Backup devices........................................................................................................ 26

Device write performance tuning methods .................................................. 26

Device performance tuning methods ............................................................ 29

File type device and staging.................................................................................. 29

Configuration of file type and adv_file devices........................................... 30

Network hardware ................................................................................................. 31

How to tune network hardware performance ............................................. 32

Testing and Tuning on Windows

Windows performance monitor ........................................................................... 34

Start the Windows performance monitor ..................................................... 34

Testing a NetWorker server from another computer.................................. 35

Physical disk ............................................................................................................ 36

Test disk performance...................................................................................... 36

Disk performance evaluation methods ......................................................... 36

Disk tuning methods........................................................................................ 37

Memory .................................................................................................................... 37

Test memory performance .............................................................................. 37

Memory performance evaluation methods .................................................. 38

Tuning memory performance in Windows .................................................. 38

EMC NetWorker Release 7.5 Performance Tuning Guide

3

4

Adjust the physical memory allocation ......................................................... 39

Memory-related server tuning methods........................................................ 39

CPU ........................................................................................................................... 40

Testing CPU performance................................................................................ 40

Server input/output ............................................................................................... 41

Test input/output performance...................................................................... 41

Tuning input/output performance ................................................................ 41

Devices ...................................................................................................................... 44

Test device performance .................................................................................. 44

Tuning device performance............................................................................. 44

Windows software................................................................................................... 45

Recoveries................................................................................................................. 46

Perform multiple, simultaneous recoveries .................................................. 46

Chapter 4 Testing and Tuning on UNIX and Linux

Physical disks........................................................................................................... 48

Benchmark evaluation...................................................................................... 48

Test the read speed of a single disk................................................................ 48

Test the read speed of several disks ............................................................... 49

Test the read speed of a single disk while running the software............... 49

Test the read speed of several disks while running the software.............. 49

Devices ...................................................................................................................... 51

Benchmark evaluation...................................................................................... 51

Test the write speed of a single tape drive .................................................... 51

Test the write speed of several tape drives ................................................... 51

Test the write speed of a single drive while running the software ........... 52

Test the write speed of several drives while running the software........... 52

Using the system activity reporter........................................................................ 53

Monitor buffer activity ..................................................................................... 53

Monitor block device activity.......................................................................... 53

Test CPU utilization.......................................................................................... 54

Recoveries................................................................................................................. 55

Perform multiple, simultaneous recoveries .................................................. 55

OS tuning recommendations ................................................................................. 56

OS settings.......................................................................................................... 56

Additional NetWorker related tuning parameters ...................................... 59

Chapter 5 NetWorker Configuration

NetWorker software services and programs ....................................................... 62

Services and programs on the NetWorker server ........................................ 62

How the NetWorker software backs up data ............................................... 64

How the NetWorker server recovers data .................................................... 66

NetWorker configurations ..................................................................................... 67

Immediate save and recovery ......................................................................... 67

Local backup and recovery of a client............................................................ 67

Backup and recovery of remote client ........................................................... 68

Backup and recovery to a storage node......................................................... 68

Local backup to a silo ....................................................................................... 69

Appendix A Troubleshooting

RPC error messages ................................................................................................ 72

Problem............................................................................................................... 72

Solution............................................................................................................... 72

EMC NetWorker Release 7.5 Performance Tuning Guide

Troubleshooting target sessions............................................................................ 73

Appendix B Stability settings

Tuning to increase NetWorker stability ............................................................... 76

Glossary

Index

EMC NetWorker Release 7.5 Performance Tuning Guide

5

6

EMC NetWorker Release 7.5 Performance Tuning Guide

Preface

Audience

As part of an effort to improve and enhance the performance and capabilities of its product lines, EMC periodically releases revisions of its hardware and software. Therefore, some functions described in this document may not be supported by all versions of the software or hardware currently in use. For the most up-to-date information on product features, refer to your product release notes.

If a product does not function properly or does not function as described in this document, please contact your EMC representative.

This document is part of the EMC NetWorker documentation, and is intended for use by:

System administrators responsible for installing software and maintaining the servers and clients on a network.

Operators monitoring the daily backups who may also find this manual useful.

Readers of this document are expected to be familiar with the following software:

EMC NetWorker software

Organization

Here is a list of where information is located in this guide.

Chapter 1, ”NetWorker Features,” provides brief descriptions of software features

and an overview of hardware and software performance.

Chapter 2, ”Testing and Tuning Basics,”

describes the hardware and software components that make up the data storage management environment, discusses their impact on storage management tasks, and provides general guidelines for locating problems and solutions.

Chapter 3, ”Testing and Tuning on Windows,” explains the specific performance

testing and tuning tasks that can be performed on a NetWorker server in a

Windows environment.

Chapter 4, ”Testing and Tuning on UNIX and Linux,” provides additional

performance testing and tuning information for the NetWorker server on a UNIX or Linux platform. This chapter contains information written specifically for the

UNIX and Linux environments, and provides UNIX and Linux-based examples only.

Chapter 5, ”NetWorker Configuration,” explains the configuration activities that

can be performed on the NetWorker server.

Appendix A, “Troubleshooting,” describes error messages and explains how to

correct problems with the NetWorker Server.

“Glossary”

EMC NetWorker Release 7.5 Performance Tuning Guide

7

Preface

Related documentation

Conventions used in this document

Related documents include:

EMC NetWorker Release 7.5 Multiplatform Version Administration Guide

EMC NetWorker Release 7.5 Release Notes

EMC NetWorker Release 7.5 Installation Guides

EMC Information Protection Software Compatibility Guide

EMC uses the following conventions for special notices.

Note:

A note presents information that is important, but not hazard-related.

!

CAUTION

A caution contains information essential to avoid data loss or damage to the system or equipment. The caution may apply to hardware or software.

!

IMPORTANT

An important notice contains information essential to operation of the software.

The important notice applies only to software.

Typographical conventions

EMC uses the following type style conventions in this document:

Normal Used in running (nonprocedural) text for:

• Names of interface elements (such as names of windows, dialog boxes, buttons, fields, and menus)

• Names of resources, attributes, pools, Boolean expressions, buttons, DQL statements, keywords, clauses, environment variables, filenames, functions, utilities

• URLs, pathnames, directory names, computer names, links, groups, service keys, file systems, notifications

Bold:

Used in running (nonprocedural) text for:

• Names of commands, daemons, options, programs, processes, services, applications, utilities, kernels, notifications, system call, man pages

Italic:

Courier:

Courier bold

:

Courier italic:

< >

Used in procedures for:

• Names of interface elements (such as names of windows, dialog boxes, buttons, fields, and menus)

• What user specifically selects, clicks, presses, or types

Used in all text (including procedures) for:

• Full titles of publications referenced in text

• Emphasis (for example a new term)

• Variables

Used for:

• System output, such as an error message or script

• URLs, complete paths, filenames, prompts, and syntax when shown outside of running text.

Used for:

• Specific user input (such as commands)

Used in procedures for:

• Variables on command line

• User input variables

Angle brackets enclose parameter or variable values supplied by the user

8

EMC NetWorker Release 7.5 Performance Tuning Guide

Preface

Where to get help

[ ]

|

{ }

...

Square brackets enclose optional values

Vertical bar indicates alternate selections - the bar means “or”

Braces indicate content that you must specify (that is, x or y or z)

Ellipses indicate nonessential information omitted from the example

EMC support, product, and licensing information can be obtained as follows.

Product information —

For documentation, release notes, software updates, or for information about EMC products, licensing, and service, go to the EMC Powerlink website (registration required) at: http://Powerlink.EMC.com

Technical support —

For technical support, go to EMC Customer Service on

Powerlink. To open a service request through Powerlink, you must have a valid support agreement. Please contact your EMC sales representative for details about obtaining a valid support agreement or to answer any questions about your account.

Your comments

Your suggestions will help us continue to improve the accuracy, organization, and overall quality of the user publications. Please send your opinion of this document to: [email protected]

EMC NetWorker Release 7.5 Performance Tuning Guide

9

Preface

10

EMC NetWorker Release 7.5 Performance Tuning Guide

1

NetWorker Features

The NetWorker product is a network storage management application that is optimized for high-speed backup and recovery operations of large amounts of complex data across an entire network computer. The NetWorker software is available in four editions. Brief descriptions and distinctions among these editions are covered in this chapter, as well as an overview of hardware and software performance, in the following sections:

Introduction to NetWorker editions ........................................................................... 12

Overview of hardware and software performance .................................................. 12

NetWorker Features

11

NetWorker Features

Introduction to NetWorker editions

The four editions of the NetWorker

<sp Superscript>®<sp Superscript>

software are as follows:

Workgroup Edition

The Workgroup Edition supports small networks that do not require clustering or contain large databases and/or file systems.

Business Edition

The Business Edition is similar to the Workgroup Edition as it is designed for small business needs.

Network Edition

The Network Edition supports large, distributed networks and a full range of add-on products.

Power Edition

The Power Edition addresses the storage management and data protection needs of enterprises with high-performance database servers and file servers, such as very large database (VLDB) applications, online transaction processing (OLTP) applications, data warehouses, and web servers.

12

Overview of hardware and software performance

Performance is the speed and efficiency by which a task is completed. Backup and recovery performance is dependent on several hardware and software variables, but in general, backups cannot go faster than the speed of their slowest component.

This guide provides tests to measure and maximize the various components of your computer. Change software settings or replace a hardware component by identifying the slowest component in the data path between the location of the data and the storage device.:

Factors that affect the speed of the server include:

• CPU

• Memory

• Input/output (I/O) bandwidth

• SCSI bandwidth

• Number of ports

Factors that affect the speed of the devices include:

• I/O transfer rate

• Built-in compression and initialization characteristics

Note:

Device speed is combined for all storage devices used concurrently.

If clients are backed up over a network, these factors can also affect performance:

Client speed:

• CPU

• Memory

• Disk speed

EMC NetWorker Release 7.5 Performance Tuning Guide

Note:

Client speed is combined for all clients active at a single point in time.

Network speed:

• Network I/O bandwidth

• Network path

• Network load

Factors impacting software performance include:

File-system management

Application-specific optimization

Backup application (for example, the NetWorker software)

NetWorker Features

Overview of hardware and software performance

13

NetWorker Features

14

EMC NetWorker Release 7.5 Performance Tuning Guide

2

Testing and Tuning Basics

This chapter identifies the different hardware and software components that make up the data storage management environment, discusses their impact on storage management tasks, and provides general guidelines for locating problems and solutions in the following sections:

Overview of performance testing and tuning........................................................... 16

Server hardware ............................................................................................................ 17

NetWorker settings ....................................................................................................... 22

Backup devices .............................................................................................................. 26

File type device and staging ........................................................................................ 29

Network hardware........................................................................................................ 31

Testing and Tuning Basics

15

Testing and Tuning Basics

Overview of performance testing and tuning

The benchmark tests used in the computer industry are done in controlled environments to simplify analysis and show products at their greatest advantage.

When testing the performance of the NetWorker server in your environment, determine the degree to which the test is controlled:

To run a fully-controlled test, turn off all extraneous processes to isolate the performance of the NetWorker server. The results of this test show the optimal performance of the NetWorker server with the current hardware and software configuration.

To run a less-controlled test, do not shut down other applications and network traffic. The results of this type of test show how the NetWorker server performs while the computer is running other programs and processes.

If running both a controlled test and one with a normal or simulated load, the difference between the results can determine:

• How to schedule the backups.

• Whether to run other programs on the NetWorker server.

The tests in this and the following chapters follow a basic process:

1. Measure the current performance of the NetWorker server.

2. View the results to find a blockage or limiting factor.

3. Adjust the hardware and software to correct the blockage.

4. Measure the performance of the NetWorker server.

Although there will be some blockage in a system, use this process to eliminate the greatest obstacles to fast backup performance.

!

IMPORTANT

Install sufficient computer and network hardware to support a storage application.

Failure to meet minimum system requirements, particularly for memory, free space, and CPU speed, can have an obvious and immediate negative impact on the storage management processes.

16

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

Server hardware

The following sections address different hardware components of the NetWorker server, as well as performance tests of these components.

Physical disks

The physical disks in a computer system are in constant motion, reading and writing data for storage and recovery, and maintaining the client file indexes and media database. Problems with these disks can negatively affect every performance level within a storage management environment.

The type of data backed up and how it is laid out on the disk can cause backup performance to vary. If you have large files that are fragmented, or many small files, the efficiency of the disk suffers because the disk head moves frequently from one fragment or file to another.

If the data is compressed on the disk, the operating system or application decompresses the data before transferring it for backup. The CPU spends cycles to decompress the files, and the disk can rarely go at its maximum speed.

The backup process is most efficient for large files with minimal fragmentation.

Disk read speed testing methods

Follow these guidelines to determine the read speed of disks:

Test the read speed of each individual disk while NetWorker software is not running.

Test the read speed of all disks while the NetWorker software is not running.

Test the read speed of each individual disk while NetWorker software is running.

Test the read speed of all disks while NetWorker software is running.

Use the NetWorker uasm program, which saves and recovers file-system data, to test how fast the system can read from disk.

The syntax is as follows:

uasm -s

[-benouv] [-ix] [-t

time] [-f proto] [-p ppath] path

uasm -r

[-nuv] [-i {nNyYrR}] [-m

src = dst] [-z suffix] path

uasm -c

[-nv]

path

For example, enter the following command at the system prompt:

uasm -s

filename > /dev/null where

filename

is a large file not accessed recently. If the file was recently accessed, it may be in memory and uasm will not actually read the file from disk.

The uasm program reads from the disk at the maximum speed. In this example, the data is written to a null location so the disk read is not slowed down to allow time for writing.

Server hardware

17

Testing and Tuning Basics

Table 1

In this mode

save recover compare

The uasm program has three modes: save, recover, and compare. A description of

how the uasm program performs in the three modes is provided in Table 1

.

uasm program modes

The uasm program

Scans directory trees and generates a save stream on its standard output (stdout) representing the files and organization of the directory tree. Symbolic links are not followed by application-specific modules (ASMs), except rawasm, which enables NetWorker to process data in raw disk partitions.

Reads a save stream from its standard input (stdin) and creates the corresponding directories and files.

Reads a save stream from its stdin and compares the save stream with the files on the file system.

In save mode, uasm can be controlled by directive files. Directive files control the following:

How to search descendent directories.

Which files to ignore.

How the save stream is generated.

How to process subsequent directive files.

All ASMs accept the options described in

Table 2 on page 18

. ASMs also can have additional options.

Note:

The -s (save), -r (recover), or -c (compare) mode must be specified when using the uasm program and must precede any other options. When saving, at least one path value must be specified. The path value can be either a directory or a filename.

Options valid for all modes of uasm

Table 2

lists the options that are valid with all modes of uasm.

Table 2 uasm options

Option

-n

-v

Usage

Use the -n option to perform a dry run.

When saving, scan the file system, but do not attempt to open files and produce the save stream.

When recovering or comparing, consume the input save stream and perform basic checks, but do not create directories or files when recovering or do the work of comparing the file data.

Use the -v option to turn on verbose mode. The current ASM, its specified options, and the file it is processing are displayed. When an ASM is operating in filtering mode (that is, processing the save stream of another ASM) and modifies the stream, its name, specified options, and the current file appear within square brackets.

18

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

Options for save mode

Table 3

Table 3 lists the options to be used in save mode.

Save mode options

-t

-x

-i

-f

Use this option To

-b

-o

Produce a byte count. This is similar to the -n option, but byte count estimates the amount of data to produce, instead of actually reading file data. This option is faster, but less accurate than the -n option. Byte count mode produces three numbers: records (files and directories), bytes of header information, and bytes of file data. Byte count mode does not produce a save stream, so its output cannot be used as input to another ASM in recover mode.

Produce an "old style" save stream that can be handled by older NetWorker servers.

-e Instruct uasm to not generate the final "end of save stream" boolean. Use this option only when the following applies:

• ASM invokes an external ASM.

• An optimization does not consume the generated save stream itself.

Ignore all save directives from .nsr directive files found in the directory tree.

-p

Specify the location of a .nsr directive file to interpret before processing any files. Within the directive file specified by proto, path directives must resolve to files within the directory tree being processed, otherwise their subsequent directives will be ignored.

Specify the path with ppath. When you specify -p ppath, this string is added to the beginning of each filename as it is output. This option is used internally when one ASM executes another external ASM. The path entered for ppath must be a properly formatted path that is either the current working directory, or a trailing component of it.

Specify a date with -t date to set the date after which files are modified before they are saved.

Cross file system boundaries. Normally, file-system boundaries are not crossed when walking the file-system. Symbolic links are not followed, except in the case of rawasm.

Options for recover mode

Table 4 lists the options to use in recover mode.

Table 4

Recover mode options

Use this option

-i

{nNyYrR}

m

src=dst

-z

suffix

To

Define the initial default overwrite response option. Only one overwrite response option is allowed. When the file being recovered conflicts with an existing file, the user is prompted for overwrite permission. The default response option, selected by pressing Return, is displayed within square brackets.

“The -i option” on page 19

provides additional information about the -i option.

Map the filenames to be created. Any files that start exactly with src are mapped to have the path of dst replacing the leading src component of the pathname. This option is useful when relocating the recovered files saved using absolute pathnames into an alternate directory (for example, -m c:\win32app=.).

Specify the suffix to append when renaming conflicting files. The default suffix is R.

The -i option

The -i option defines the initial default overwrite response option. Table 5 on page 20

lists the overwrite response options and their meanings.

Server hardware

19

Testing and Tuning Basics

Table 5

r

N y

Y

Overwrite response options

Option

n

R

Meaning

Do not recover the current file. This is the initial default overwrite response option. Each time a response option other than the default is specified, the new response option becomes the default.

Do not recover any files with conflicting names.

Overwrite the existing file with the recovered file.

Overwrite all files with conflicting names.

Rename the conflicting file. A dot, “.”, and a suffix (by default “R”) are appended to the recovered filename. If a conflict still exists, the NetWorker software prompts you again.

Automatically renames conflicting files by appending a dot, “.”, and a suffix. If a conflicting filename already ends in a “.” suffix, the NetWorker software prompts you to avoid potential auto-rename looping conditions.

When you specify either N, R, or Y, you are prompted only when the NetWorker server cannot auto-rename a file ending with the rename suffix. Subsequent conflict is resolved as if the corresponding lowercase letter is selected.

Disk performance tuning methods

If there is a blockage in the disk system, make the following changes to improve performance:

Defragment files to reduce the number of disk seeks.

Use larger files or fewer files to reduce the number of disk seeks.

Change to a faster SCSI adapter with synchronous I/O support and bus mastering.

Use stripe sets on multiple disks to accommodate large files and databases, so the physical disks can work in parallel to read data.

Spread disk-intensive programs onto different servers.

Purchase disks with higher transfer rates.

Memory and CPU usage

Each backup session requires CPU and memory resources on the NetWorker server. If other applications are running concurrently with the backup, they impose an additional load on the system. Heavy swapping or paging activities indicate that the server is CPU or memory-bound.

Memory usage

A NetWorker server or storage node computer can never have too much memory.

Data transfer within memory is much faster than over a network. Memory holds frequently used data so the disk does not have to be read as often. Open applications, processes in run mode, and disk cache all use memory. If the operating system is capable, disk storage space is used as simulated memory, or virtual memory.

For best results, install the maximum amount of memory that your computers will sustain, especially for the NetWorker server and storage nodes.

20

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

CPU usage

To increase CPU performance and bandwidth:

1. Upgrade to a faster CPU.

2. Add additional CPUs if the NetWorker server supports multiple processors.

3. Shut down other processes during backup time.

This may reduce the processor load and improve backup performance.

Set scheduled backups for low-traffic periods to avoid performance degradation or excessive network traffic. The default NetWorker backup start time is 3:33 A.M.

The operating system of a computer might contain various utilities for testing and tuning CPU speed. Additionally, you can check the CPU utilization of each

NetWorker function. The processes involved in a NetWorker backup are the following:

These NetWorker services:

• nsrexecd

• nsrd

• nsrmmd

• nsrmmdbd

• nsrindexd

The save program for NetWorker backups

Application-specific services, such as for a database server

Note:

To measure and record CPU speed for the NetWorker server on the Windows platform, use the Windows Performance Monitor.

“Testing CPU performance” on page 40 provides more

information.

Server input/output

Input/output backplane

On a well-configured NetWorker server, the maximum data transfer rate of the server's I/O backplane is the limiting factor for backup throughput. The theoretical backup throughput limitation is the following formula:

Backup throughput = Maximum I/O throughput/2

At a minimum, the NetWorker server requires two I/O transactions per data block:

A read from the disk to memory

A write from memory to media

SCSI I/O bandwidth

The following performance variables relate to the input/output (I/O) throughput on the NetWorker server.

SCSI bus performance depends on the technology deployed. Some specifications for different types of SCSI technology include the following:

SCSI-2 single-ended, 10 MB/s

FWD (fast-wide-differential), 20 MB/s

UltraSCSI, 40 MB/s

Server hardware

21

Testing and Tuning Basics

NetWorker settings

The NetWorker software has several attributes that control the speed and volume of data being backed up. These attribute settings can be adjusted to modify backup levels to attain the best performance on the NetWorker server.

The following sections address the various NetWorker settings in principle. Because these attributes appear in different locations in the Windows and UNIX versions, the

EMC NetWorker Release 7.4 Multiplatform Version Administration Guide provides specific instructions on how to access these settings based on the server platform.

Server parallelism

Fibre

Note the following:

The rated speeds of SCSI buses are defined as "best case."

The selection of UltraSCSI-compatible devices is limited.

The server parallelism attribute controls how many savestreams the server accepts simultaneously. The more savestreams the server can accept, the faster the devices and client disks run, up to their performance limit or the limits of the connections between them.

Client parallelism

The client parallelism attribute controls how many savestreams a client can send at the same time. To avoid disk contention, do not set a value for client parallelism that is higher than the number of physical disks on the client. The client parallelism for a

NetWorker server controls the number of index, bootstrap and local filesystem savestreams that start from the server at the same time.

Multiplexing

The target sessions attribute sets the target number of save streams to write to a device simultaneously. Because this value is not a limit, a device might receive more sessions than the attribute specifies. The larger the number of sessions specified for target sessions, the more save sets that can be multiplexed (or interleaved) onto the same volume.

Performance tests and evaluation can determine whether multiplexing is appropriate for the system. Follow these guidelines when evaluating the use of multiplexing:

Find the backup rate of each disk on the client. Use the uasm test described in

“Disk read speed testing methods” on page 17

.

Find the maximum rate of each device. Use the bigasm test described in “Test device performance with bigasm” on page 28 .

If the sum of the backup rates from all disks involved in a backup is greater than the maximum rate of the device, do not increase server parallelism. If more save groups are multiplexed in this case, backup performance will not improve, and recovery performance could slow down.

22

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

Modifying settings for performance tuning

This section describes measures to improve NetWorker server performance related to the following:

Parallelism and target sessions attribute settings

Workload balance

Multiplexing

Backups across a network

Setting the value for file descriptors

Parallelism and target sessions attribute settings

Follow these guidelines to adjust the parallelism and target sessions attributes for the best server performance:

Set the server Parallelism and Target Sessions attributes so that the total performance of the disk drives equals the total performance of the tape drives. If the Parallelism attribute is set to a higher value, there is no benefit.

To select the right values for the parallelism and target sessions attributes, use the following equation:

Parallelism = Number of Devices * Target Sessions

For example, if there are three tape drives available for backup, and you want each tape drive to accept two savestreams, set the value of server parallelism to six and the value of target sessions to two.

When a NetWorker server is saving a large number of save sets, such as 500 or more, memory consumption and file descriptor consumption can reach values that are close to operating system limitations. In this event, the parallelism may need to be lowered.

Decrease the server parallelism and target sessions attributes to unload an overworked NetWorker server. With the correct settings, the normal operation of the computer should not be interrupted by backups or other NetWorker server activities.

Add more memory to handle a higher parallelism setting.

Workload balance

The following are recommended to avoid overloading the server:

Increase CPU power by upgrading the CPU or adding additional CPUs to the server (if possible).

Reduce server load by spreading backups across multiple servers or storage nodes.

Balance the number of disks and devices, so that the backups finish at about the same time. The NetWorker Administration Guide provides instructions on how to change these settings.

Here are some methods of balancing the workload on disks and devices:

• In general, start backups for the slowest or the biggest disk volumes first, because other disks can join in later to match the maximum bandwidth of the device.

• Use pools of media to force the bigger and faster disk volumes to back up to faster devices.

NetWorker settings

23

Testing and Tuning Basics

• If there is a large and fast disk volume and many tape drives, manually divide the volume into several save sets so that each one can go to each tape drive in parallel.

• Balance data load for simultaneous sessions more evenly across available devices by adjusting the target sessions attribute. This parameter specifies the minimum number of save sessions to be established before the NetWorker server attempts to assign save sessions to another device.

Multiplexing

Refer to the following guidelines for improving server performance through multiplexing:

To fully use the bandwidth of a high-speed device when you have many slow clients or disks, multiplex the save sets on the media. You maximize the performance of the devices since they do not have to start and stop to wait for data.

To improve recovery performance, multiplex save sets to recover together onto the same tape. For example, multiplex the disks of the same computer onto the same media because it is likely that the data from all the disks will recover simultaneously.

Backups across a network

In cases where you back up data across a network, the following suggestions also can improve performance:

Increase the client parallelism attribute, especially for clients with a logical volume manager and several physical disks. The bandwidth of the network could limit the number of savestreams to transmit at a time.

To reduce server load, split backups across multiple servers.

Turn on data compression in the NetWorker client to improve effective data throughput and reduce network traffic.

Configure clients with high-transfer rate requirements to have a preference for a particular backup server on the same subnet; avoid router hops between the

NetWorker server and its clients.

Setting the value for file descriptors

You may want to increase the value for file descriptors to 2048 (or 1024 if running

Solaris 2.5). The number of file descriptors can be changed using the following command line:

# ulimit -n 2048

This sets the number of file descriptors to 2048, which is considered the soft limit.

This number cannot exceed the hard limit, which is set in the kernel. For Solaris 8, the default value is 1024.

Note:

It is possible to set the soft limit (using ulimit -n) to a number greater than the hard limit, but the maximum number of file descriptors used will be the lower number. For example, if you set the soft limit to 2048, but the hard limit is 1024, the maximum number of file descriptors will be the hard limit.

To find the hard file descriptor limit and change the value:

1. Go to the /etc/system file. If a value other than the default is used, it must be listed in /etc/system for the value to be set after a reboot.

24

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

2. Run the following:

# adb -kw /dev/ksyms

physmem 5da31

Type: rlim_fd_max/D

Result: rlim_fd_max: rlim_fd_max: 1024 man pages adb

3. To override this value: a. Tune the system parameter by adding set rlim_fd_max=2048 to the /etc/system file.

b. Shut down and run boot -r at the OpenBoot prompt.

Note:

If you are not familiar with changing kernel parameters, verify the process with your Sun documentation.

Tuning system parameters

You can view and change the values of the following system parameters:

tcp_time_wait_interval

Get the tcp_time_wait_interval by running the following:

ndd -get /dev/tcp

The default value of the parameter is 240000 milliseconds (four minutes). To change the value to one minute, set tcp_time_wait_interval to 60000, as in the following:

ndd -set /dev/tcp tcp_time_wait_interval 60000

Note:

For Solaris 2.6, the parameter is check tcp_close_wait_interval.

tcp_keepalive_interval

View the current value (in milliseconds) of tcp_keepalive_interval by running the following:

ndd -get /dev/tcp tcp_keepalive_interval

To set a new value, run:

ndd -set /dev/tcp tcp_keepalive_interval

<value> where

<value>

is a number representing the new value.

tcp_conn_hash

View the current value of the TCP parameter tcp_conn_hash by running the following:

ndd -get /dev/tcp tcp_conn_hash

NetWorker settings

25

Testing and Tuning Basics

Backup devices

NetWorker software and other storage management products use backup devices to do the following:

Write backed-up data to the storage media volume.

Read saved data from the storage media during recoveries.

Devices pass data to and from the NetWorker server itself, or from a NetWorker storage node through a SCSI connection. Backup devices can include optical disks, and, in most cases, tape drives. When a backup device has multiple drives, such as for autochangers, each drive is considered a separate device.

Device write performance tuning methods

If the disk read speed is noticeably faster than the ability of the device to write, that might indicate a problem with the write performance of the device. To perform a thorough evaluation of device performance, follow these guidelines:

Measure the write speed of each individual device while the NetWorker software is not in run mode.

Measure the write speed of all devices while the NetWorker software is not in run mode.

Measure the write speed of each individual device while the NetWorker software is in run mode.

Measure the write speed of all devices while the NetWorker software is in run mode.

First evaluate the device performance without the NetWorker software running, and then evaluate the devices again with the NetWorker software running.

To ensure consistency in the measurements, ensure you use the same tape drives for all tests.

Testing tape device performance without running NetWorker

The mt program is used to determine tape device performance when the NetWorker software is not running. Use it to evaluate the tape device without a need to consider the overhead incurred when using the NetWorker software.

The mt program allows you to operate a magnetic tape device, which includes rewinding, fast-forwarding, and ejecting tapes.

Note:

The mt program cannot be used to measure the writing data rate, but can indicate performance rates related to having tapes start loaded and rewound prior to measuring write speeds to tape.

Determine tape device performance

To determine tape device performance when NetWorker software is not running, enter the following at the command line:

mt -f

devicename command count

By default, the mt program performs the requested operation once. To perform the operation more than once, specify a value in place of

count

.

26

EMC NetWorker Release 7.5 Performance Tuning Guide

Table 6

Table 7

Testing and Tuning Basics

The mt program returns the following exit status:

0 if the operations were successful.

1 if the command was unrecognized or mt was unable to open the specified tape drive.

2 if an operation failed.

Table 6 on page 27 lists the available commands to use with the mt command.

Note:

Older UNIX systems may have different options for the mt command. Before using the

mt

command, check the mt man page on your system for the available options.

Commands to use with the mt command

fsf fsr bsf

Enter this command

eof, weof bsr nbsf asf

To

Write count end of file (EOF) marks at the current position on the tape.

Forward space over count EOF marks. The tape is positioned on the first block of the file.

Forward space count records.

Backspace over count EOF marks. The tape is positioned on the beginning-of-tape side of the EOF mark.

Backspace count records.

Backspace count files. The tape is positioned on the first block of the file. This is equivalent to count + 1 bsf followed by one fsf.

Absolute space to count file number. This is equivalent to a rewind followed by fsf count.

Table 7 on page 27 lists the available commands where count is ignored.

Available mt commands with count ignored

Enter this command:

eom rewind offline, rewoffl status retension erase format

To

Space to the end of recorded media on the tape.This is useful for appending files onto previously written tapes.

Rewind the tape.

Rewind the tape and, if appropriate, take the drive unit offline by unloading the tape.

Print status information about the tape unit.

Rewind the cartridge tape completely, and then wind it forward to the end of the reel and back to the beginning of tape to smooth out tape tension.

Erase the entire tape.

Format the tape at a low level.

Limitations

Not all tape devices support all options. Some options are hardware-dependent. For example, by entering the following command on a Windows computer:

D:\>mt -f \\.\Tape0 status the following output is displayed:

Backup devices

27

Testing and Tuning Basics

\\.\Tape0:

Media Capacity = 2.12GByte

Media Remaining = 3.06GByte

Media Block size = 0

Media Partition Count = 0

Media is not write protected default block size = 8192 maximum block size = 1040384

The maximum block-size value limits the maximum number of bytes per SCSI transfer on disk reads and volume writes.

Test the native OS driver positioning

Use the mt command to test whether the native OS driver is able to position.

To test the driver:

1. Write a file.

2. Issue the following command:

mt fsf 1

3. Write a second file.

4. Issue the following command:

mt bsf 2

If the first file cannot be read, the driver is not positioning correctly.

Test device performance with bigasm

To measure SCSI throughput and the write speed of a device while the NetWorker software is running, run the bigasm module. The bigasm module is run from a directive and generates a file of the specified size, transfers it over a SCSI connection, and writes it to a tape or optical device.

The description and options of bigasm (and all other application specific modules) are the same as for the uasm module. For a full description of the uasm module, see

“Disk read speed testing methods” on page 17 .

To set up a bigasm test:

1. Create a file, bigasm.file, that contains the following command:

bigasm

-S

size : filename

For example:

bigasm

-S100M : bigfile

2. Save the file using the NetWorker server. For example, if the directive file is called

bigasm.file and the NetWorker server is called jupiter, enter the following command:

save

-s jupiter -f /bigasm.file /tmp/

filename

The amount of time it takes for the backup to complete indicates the efficiency of the SCSI throughput and the write speed of the device.

The bigasm module also can be used in a scheduled backup by creating a directive for it.

28

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

Device performance tuning methods

The following sections address specific device-related areas to improve performance.

Input/output transfer rate

Input/output (I/O) transfer rates can affect device performance. The I/O rate is the rate at which data can be written to the device. Depending on the device and media technology, device transfer rates can range from 500 KB per second to 20 MB per second. Default block size and buffer size of a device affect its transfer rate. If I/O limitations are hampering improved performance of the NetWorker server, try upgrading the equipment to affect a better transfer rate.

Built-in compression

Turn on device compression to increase effective throughput to the device. Some devices have a built-in hardware compression feature. Depending on how compressible the backup data is, this can improve effective data throughput, from a ratio of 1.5:1 to 3:1.

Drive streaming

To obtain peak performance from most devices, stream the drive at its maximum sustained throughput. Without drive streaming, the drive must stop to wait for its buffer to refill or to reposition the media before the drive can resume writing. This can cause a delay in the cycle time of a drive, depending on the device.

Device load balancing

Balance data load for simultaneous sessions more evenly across available devices by adjusting sessions per device. This parameter specifies the minimum number of save sessions to be established before the NetWorker server attempts to assign save sessions to another device.

File type device and staging

The NetWorker software includes file type and advanced file type devices and save set staging features, which can be used to improve backup performance. Since reading and writing data to disk is generally faster than to tape or optical media, use the file type or advanced file type device feature to direct the backups to disk media instead of tape or optical media.

The advanced file type (adv_file) is designed for large disk devices. It differs from the file type device because the volume for the advanced file type device is never marked full. When an advanced file type device is out of disk space, the current backup is suspended. The following message appears: filesystem full - recover adv_file space

Immediately after the message displays, the NetWorker software begins deleting expired save sets until more space is made available. If enough space is cleared, the backup continues.

Use save set staging in conjunction with backups to the file type or adv_file device.

Save set staging lets you move save sets backed up from one medium to another according to criteria you set, such as:

Space remaining on the disk.

Age of the save set.

File type device and staging

29

Testing and Tuning Basics

With staging, you can automate transferring older backups from the file type device or adv_file device to a less expensive storage media. This frees up hard disk space for new backups.

Configuration of file type and adv_file devices

A possible configuration to maximize performance of file type or an adv_file device is:

1. Create one directory per user, preferably with a mnemonic name matching a client.

2. Create one file type or adv_file device per directory; set the volume size to 1 GB.

3. Create one client per system, setting the device that is always used to have the matching mnemonic device name.

This configuration limits the system to a maximum of 64 users with the NetWorker software, since one user equals one device, and that is how many devices Power

Edition supports. However, if you use storage nodes, you can have 64 devices per node up to a maximum of 256 devices total for the NetWorker server and all attached storage nodes.

If you back up the data to file type devices or adv_file devices, you get high-speed backups to a hard drive in near real time, but the disk tends to fill quickly with backups.

Without save set staging

Without save set staging, disk usage will have to be closely monitored to avoid running out of space for the backups. Also, you will have to either move save sets to other storage media manually or create short browse and retention policies.

With save set staging

With save set staging, the process of moving data from disk storage to tape or optical disk is automated, and the space occupied by the save set is freed to make space for new backups. The browse and retention policies for the save sets on tape or optical disk can be as long as necessary. Also use save set staging to move files from other types of media, but the space is only reclaimed on the file-type device.

If disk contention is a concern when backing up to file type or adv_file devices, use smaller drives (for example, six drives of 4 GB each and four users per drive, instead of one 23 GB drive).

You also can use a RAID array, which provides redundancy in case of a drive failure.

Microsoft Windows includes a software RAID capability that works well, but uses many CPU cycles. A hardware RAID solution is a more efficient, but more expensive solution.

30

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning Basics

Network hardware

If you back up data from remote clients, the routers, network cables, and network interface cards affect the backup and recovery operations. This section lists the performance variables in network hardware and suggests some basic tuning for networks. The following items address specific network issues:

Network input/output bandwidth

The maximum data transfer rate across a network rarely approaches the specification of the manufacturer because of network protocol overhead.

!

!

IMPORTANT

The following statement concerning overall system sizing needs to be taken into account when considering bandwidth.

Each attached tape drive (same for physical drive, VTL or AFTD device) uses part of the available I/O bandwidth of the system and also consumes CPU since data still has to be processed.

Network path

Networking components such as routers, bridges, and hubs consume some overhead bandwidth, which degrades network throughput performance.

Network load

CAUTION

Do not attach a high number of high-performance tape drives or AFTD devices directly to a backup server.

For example, there is no system which can fully sustain 8 by LTO3 (considered normal practice in many environments).

The same rule (although in smaller amounts) applies to network interfaces; that is, processing data on each high-speed network interface card and for each IP address can use a significant amount of CPU cycles available on the server.

For example, a mid-size system with 4 by 1-Gbit, NICs will use over 50 percent of its power just to process TCP data during a backup window.

Other network traffic limits the bandwidth available to the NetWorker server and degrades backup performance. As the network load reaches a saturation threshold, data packet collisions degrade performance even more.

When using a VTL or AFTD solution from any vendor which utilizes SATA drives, do not overlap staging and backup operations. The recommendation is to have enough capacity so that staging occurs outside of the main backup window.

Here, the reason is that regardless of the performance of the array, ATA technology experiences significant performance degradation on long parallel read and write streams.

Systems with a smaller number of high-performance CPUs generally outperform systems with a high number of CPUs because the majority of processing is limited to specific processes or threads inside those processes (although the overall number of NetWorker processes can be high).

Network hardware

31

Testing and Tuning Basics

How to tune network hardware performance

Employ the following measures to improve network hardware performance:

Add additional network interface cards to client systems to expand network bandwidth available to clients.

Upgrade to faster LAN media, such as 100 MB Ethernet or FDDI, to improve network bandwidth. Note, however, that TCP packet overhead can reduce the total transfer rate.

Configure clients with high-transfer rate requirements to show a preference for a particular backup server (or storage node) on the same subnet; avoid router hops between the NetWorker server and clients.

Minimize the number of network components in the data path between the client and server.

32

EMC NetWorker Release 7.5 Performance Tuning Guide

3

Testing and Tuning on

Windows

This chapter addresses specific performance testing and tuning tasks to perform on a

NetWorker server in a Windows environment.

The following topics are discussed in this chapter:

Windows performance monitor .................................................................................. 34

Physical disk .................................................................................................................. 36

Memory .......................................................................................................................... 37

CPU ................................................................................................................................. 40

Server input/output ..................................................................................................... 41

Devices............................................................................................................................ 44

Windows software ........................................................................................................ 45

Recoveries....................................................................................................................... 46

Testing and Tuning on Windows

33

Testing and Tuning on Windows

Windows performance monitor

Use the Windows performance monitor program to test system performance. In the performance monitor, choose:

Which objects to watch. For example, the processor or memory.

Which counters to test. For example, available bytes of memory.

How to display the data.

The default view of the data is a realtime line chart. However, the data also can be logged or formatted as a report, or alerts created to warn when a counter reaches a certain limit.

Note:

The following procedures have been updated for the Windows XP interface. For previous Windows OS, the interface names are in parenthesis ().

34

Start the Windows performance monitor

To start the Windows performance monitor on the NetWorker server:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

Note:

The default viewing mode of performance monitor is Graph, but the performance monitor-related tasks in this chapter use the Report mode.

4. To open the Add Counters dialog box, click the Data tab and click Add.

5. To ensure the local computer is the one being monitored, select Use Local

Computer Counters

.

6. From the Performance object (Object) list, select the NetWorker server component to be tracked by the Performance monitor.

The Performance object (Object) choice selected determines which Counter and

Instance

choices are available.

7. From the Select counters from list (Counter) box, select a counter. Click Explain to view descriptions of each counter.

8. From the Select instances from list (Instances) box, select an instance.

9. When all choices are selected, click Add.

10. Click Close.

The Performance Monitor window displays the NetWorker server and component to be monitored.

11. Repeat steps 4 through 10 for each component on the NetWorker server whose performance you want to test.

The Performance object (Object) window lists each component separately under the name of the NetWorker server:

1. Once all the NetWorker server components to be tested are added, click OK.

2. Start a backup, and view or capture the results.

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on Windows

To save the performance monitoring information in log form, select

Performance Logs and Alerts

in the Performance window.

To test the maximum performance of the NetWorker software:

1. Shut down all extraneous processes.

2. Run just the necessary software on the NetWorker server.

Testing a NetWorker server from another computer

Run the performance monitor on a different Windows computer on the network during controlled tests of the NetWorker server because the performance monitor uses system resources.

When the performance monitor is run on a different Windows system, it still uses some resources on the NetWorker system, especially adding to network traffic during remote backups. However, the performance of the processor and SCSI throughput on the NetWorker system are unaffected.

Test a NetWorker server from another Windows computer

To test the performance of one or more NetWorker servers from another Windows computer:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

Note:

The default viewing mode of performance monitor is Graph, but the performance monitor-related tasks in this chapter use the Report mode.

4. To open the Add Counters dialog box, click the Data tab and click Add.

5. Select Counters from Computer and type in the name of the NetWorker server.

6. From the Performance object (Object) list box, select an object. The Performance

object

(Object) choice determines the available Counter and Instance choices.

7. From the Select counters from list (Counters) box, select a counter. Click Explain to view descriptions of each counter.

8. From the Select instances from list (Instances) box, select an instance.

9. When all choices are selected, click Add.

10. Click Close.

The Performance Monitor window displays the NetWorker server and the component to be monitored.

11. Repeat steps 5 through 9 for each component on the NetWorker server to be tested.

The Performance Monitor window lists each component separately under the

NetWorker server.

12. Repeat steps 4 through 9 if you want to monitor the performance of any other

NetWorker servers (or any other Windows computer in general).

Windows performance monitor

35

Testing and Tuning on Windows

13. When you finish adding all the NetWorker server components to be tested, click

OK

.

14. Start a backup, and view or capture the results.

You can save, add to, and redirect the performance monitoring information that results from this procedure. The Microsoft Windows operating system documentation provides more detailed information about the performance monitor.

Physical disk

This section describes how to use performance monitor to test and evaluate physical

disk performance problems related to the NetWorker server. “Physical disks” on page 17 provides a general discussion of disk-related performance problems and

solutions.

Test disk performance

To test the disk performance of the NetWorker server in a Windows environment:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

4. To open the Add Counters dialog box, click the Data tab and click Add.

5. From the Performance object (Object) list box, select Physical Disk.

6. From the Select counters from list (Counters) box, select the following counters:

• % Disk Time

• Current Disk Queue Length

To view details on each counter, click Explain.

If the NetWorker server has more than one physical disk, select these counters for each disk:

1. When all choices are selected, click Add.

2. Click Close.

The Performance Monitor window displays the NetWorker server and the component to be monitored.

3. Click OK.

4. Start a backup, and view or capture the results.

5. If the disk performance counters do not work, open a command prompt window and enter the following command:

diskperf -y

6. Restart the NetWorker server to activate the counters.

36

Disk performance evaluation methods

To determine if the NetWorker server has a disk-related blockage, check the values gathered from the performance testing:

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on Windows

If the value for the Percent Disk Time counter exceeds 90 percent, tune the disk

performance as suggested in “Disk tuning methods” on page 37

.

This counter measures the percentage of operating time the disk is occupied with read or write requests.

If the value for the Disk Queue Length counter exceeds 2, tune the disk

performance as suggested in “Disk tuning methods” on page 37

.

This counter measures the average number of read or write requests that were waiting to be serviced during the sampling interval.

Disk tuning methods

The methods for tuning disk performance on the NetWorker server in a Windows environment are the same for tuning computer disks in general, including:

Defragment files to reduce the number of disk seeks.

Use larger files or fewer files to reduce the number of disk seeks.

Change to a faster SCSI adapter, with synchronous I/O support and bus mastering.

Use stripe sets on multiple disks to accommodate large files and databases, so the physical disks can work in parallel to read data.

Spread disk-intensive programs onto different servers.

Purchase disks with higher transfer rates.

Memory

This section describes how to use the performance monitor to test and evaluate memory-related performance problems related to the NetWorker server. For a general

discussion of memory-related performance problems and solutions, see “Memory usage” on page 20

.

Test memory performance

To test the memory-related performance of the NetWorker server in a Windows environment:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

4. To open the Add Counters dialog box, click the Data tab and click Add.

5. From the Performance object (Object) list box, select Memory.

6. From the Select counters from list (Counters) box, select the following counters:

• Available Bytes

• Commit Limit

• Committed Bytes

• Pages/sec

To view details on each counter, click Explain.

Memory

37

Testing and Tuning on Windows

1. When all choices are selected, click Add.

2. Click Close.

The Performance Monitor window displays the NetWorker server and the component to monitor.

3. Click OK.

4. Start a backup, and view or capture the results.

“Memory performance evaluation methods” on page 38

provides information on how to analyze the results of these tests.

Memory performance evaluation methods

Use the values gathered from the performance testing to determine if the NetWorker

server has a memory-related blockage. Table 8 on page 38 lists the counters and

which values indicate that tuning is required.

Table 8

Counter values

Counter

Available Bytes

Values

This counter measures how much memory is unoccupied. The smaller the value, the slower the performance. If the value is less than 4 MB, the memory performance requires tuning.

Pages/sec This counter measures virtual memory activity; that is, how often the memory writes to disk. When the computer is memory-bound, it pages to the virtual memory on disk more often. A value of 20 or greater indicates that tuning is required.

Committed Bytes This counter is the total memory of all applications in use at the moment. Applications generally reserve more memory than they use during regular operation. However, an application does not write data to memory without committing the memory first. Therefore, the value for Committed Bytes shows the amount of memory the applications currently need.

If more memory is committed than you have physical memory to accommodate, the computer pages memory contents to disk (virtual memory), and the computer works more slowly because physical memory is faster than virtual memory.

Commit Limit This counter is the size of virtual memory that can be committed without having to extend the paging file. Every time the Windows computer extends the paging file, it goes to disk and searches for more space to use for virtual memory. This process has a high performance cost, and you might run out of disk space. The Committed Bytes value should not consistently exceed the Commit Limit value.

Tuning memory performance in Windows

The following section explains how to tune memory performance on the NetWorker server.

Note:

To determine a good baseline size for the virtual memory file pagefile.sys, log the

Committed Bytes counter over a period of time, add 10 to 20 percent to the maximum value, and enter that value in the Initial Size (MB) text box in the Virtual Memory dialog box.

Adjust the virtual memory

To adjust the allocated size of virtual memory on the NetWorker server in a Windows environment:

1. From the Control Panel, select System.

2. Click the Advanced tab and click the Settings button in the Performance box.

38

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on Windows

3. In the Performance Options window, click the Advanced tab.

4. Select Change to open the Virtual Memory dialog box.

5. As needed, adjust the size and location of the disk space allocated to virtual memory.

6. Click OK when the change is completed.

Adjust the physical memory allocation

To adjust physical memory allocation on the NetWorker server in a Windows environment:

1. From the Control Panel, click the Network Connections (Network and dial-up connections) icon.

2. Right-click Local Area Connection and select Properties.

3. In the Local Area Connection Properties dialog box, select File and Printer

Sharing for Microsoft Networks

and click Properties.

4. Select one of the following options:

Minimize Memory Used: Use when the server has fewer than 10 users, such as a local backup on a NetWorker server.

Balance: Use when the server has 10 to 64 users.

Maximize Throughput for File Sharing: Allocate most of the memory to the file server module, for systems with more than 64 users.

Maximize Throughput for Network Application: Use for a client-server application server, such as a NetWorker server with remote clients.

5. Click OK.

Memory-related server tuning methods

To speed up access to and from virtual memory, you can implement the disk

recommendations in “Disk tuning methods” on page 37 . You can also defragment the

disks where pagefile.sys resides.

Do not put pagefile.sys on either of the following:

A stripe set, because virtual memory is less efficient when it is fragmented.

A mirrored drive, because every write is done twice, which slows writes to virtual memory.

Memory that the NetWorker server uses can be reduced. Suggestions to reduce memory requirements include the following:

Reduce the number of other applications that run on the NetWorker server.

Dedicate the NetWorker server to run the database server, NetWorker client,

NetWorker Module client, and NetWorker server.

Stop services you do not use. For example, if you have only SCSI devices, stop the

ATDISK service, which is for IDE devices only.

Remove communications protocols you do not use. For example, if you only use

TCP/IP, but you also have SPX installed, remove SPX.

Memory

39

Testing and Tuning on Windows

CPU

The following sections address testing and tuning issues for the NetWorker server

CPU(s). “CPU usage” on page 21 provides a general discussion of how CPU issues

affect NetWorker software performance.

40

Testing CPU performance

Total CPU utilization and CPU utilization for each individual process demonstrate the CPU performance of the NetWorker server.

Test total CPU utilization

To test total CPU utilization of the NetWorker server in a Windows environment during backup:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

4. Click the Data tab and click Add.

5. From the Performance object (Object) list box, select Processor.

6. From the Select counters from list (Counters) box, select % Processor Time. Click

Explain

to view details on this counter.

7. Select the processors to be tested from the Select instances from list (Instances) box if the NetWorker server has more than one processor.

8. When all choices are selected, click Add.

9. Click Close.

The Performance Monitor window displays the NetWorker server and the component to be monitored.

10. Click OK.

11. Start a backup, and view or capture the results.

Test CPU performance by process

You also can test CPU utilization for each process involved in the backup, to determine which processes use most of the CPU capacity.

To test total CPU utilization of the NetWorker server in a Windows environment during backup:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

4. Click the Data tab and click Add.

5. From the Performance object (Object) list box, select Processor.

6. From the Select counters from list (Counters) box, select % Processor Time. Click

Explain

to view details on this counter.

7. Select the processors to be tested from the Select instances from list (Instances) box, if the NetWorker server has more than one processor.

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on Windows

8. When all choices are selected, click Add.

9. Click Close.

The Performance Monitor window displays the NetWorker server and the component to be monitored.

10. Click OK.

11. Start a backup, and view or capture the results.

There is a CPU blockage if total CPU utilization remains above 90 percent for long periods during the backup process.

Server input/output

The following sections address testing and tuning issues for the NetWorker server input/output (I/O).

“Server input/output” on page 21

provides a general discussion of how I/O issues affect NetWorker software performance.

To test the I/O of the NetWorker server most effectively, you must start and configure the performance monitor, and then run specific NetWorker server I/O-related tests.

“Server input/output” on page 21 provides more information about these tests.

Test input/output performance

To start and configure the performance monitor to test the NetWorker server I/O in a

Windows environment:

1. From the Control Panel, select Administrative Tools > Performance.

2. Right-click anywhere in the System Monitor details pane and select Properties.

3. In the General tab, select Report.

4. Click the Data tab and click Add.

5. From the Performance object (Object) list box, select System.

6. From the Select counters from list (Counters) box, and select File Write

Bytes/sec

. Click Explain to view details on this counter.

7. Click Add.

8. Click Close.

The Performance Monitor window displays the NetWorker server and the component to be monitored.

9. Click OK.

10. Run the following tests, and view or capture the results:

• For the uasm program: “Disk read speed testing methods” on page 17 .

• For the mt program:

“Testing tape device performance without running

NetWorker” on page 26 .

• For the bigasm program: “Test device performance with bigasm” on page 28 .

Tuning input/output performance

The rate at which a SCSI device can write data to media is limited by the amount of data that transfers over the SCSI bus in a single I/O operation. To tune SCSI

Server input/output

41

Testing and Tuning on Windows

42

!

performance, change the number of memory pages the SCSI host bus adapter (HBA) can scatter and/or gather in a single direct memory access (DMA). The number of bytes that can be transferred in a single I/O with a SCSI device is limited by the number of memory pages that the SCSI host bus adapter can scatter and/or gather in a single DMA.

The SCSI driver of each vendor specifies the maximum number of pages that the

HBA can scatter and/or gather for the DMA transfer. When you multiply the page size by the number of scatter and/or gather entries, the product is the effective limit to the number of bytes that can be transmitted in a single I/O operation.

The equation is the following:

I/O operation size = Page size * (# of scatter/gather entries -1)

User memory is not necessarily page-aligned; therefore:

If MaximumSGList = 255, then the I/O transfer size is 4 KB * 254 = 1016KB.

For the drivers of some SCSI host adapters, you can change the maximum number of scatter and/or gather pages. Many tape drives and disk drives perform better with a larger I/O limit. A change in the number of scatter and/or gather pages can make a large performance difference. For example:

The Ampex DST tape drive writes only 3 MB per second with 64 KB SCSI transfers and 20 MB per second with 992 KB SCSI transfers.

The SCSI disk “CYBERNET 10XP” reads 1.7 MB per second with a 32 KB read buffer size and 17 MB per second with a 200 KB read buffer size.

To change the maximum scatter and/or gather pages setting in the Windows

Registry, add the following new Registry subkey to specify the maximum number of scatter and/or gather list elements for each device on a given bus:

HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\DriverName\

Parameters\Device number\MaximumSGList

IMPORTANT

Modifying the Registry is dangerous. Do not attempt to modify the Registry unless you have an up-to-date backup of the Registry to which you can revert and you are convinced that the modification you make is correct. Inappropriate changes to the

Registry can result in having to reinstall the Windows software.

Add a subkey entry to the Windows registry

To add the subkey entry to the Windows Registry:

1. Start the Windows Registry Editor program as follows: a. Select Start > Run.

b. Enter the following value in the Open text box:

regedt32

c. Press Enter.

You also can open this program at the following location:

%SystemRoot%\Winnt\System32\regedt32.exe

2. Select Window > HKEY_LOCAL_MACHINE to make that window active.

3. Select Edit > Add Key and enter Parameters for Key Name to create a key named

Parameters, if one does not exist.

EMC NetWorker Release 7.5 Performance Tuning Guide

Table 9

Testing and Tuning on Windows

4. To create a key named Device, open the Parameters key by selecting Edit > Add

Key

and enter Device for Key Name.

5. To create a DWORD named MaximumSGList, open the Device key by selecting

Edit > DWORD

and entering MaximumSGList for DWORD Name.

6. Open the MaximumSGList Value Name and replace the existing Value Data in

Decimal with a number at least as large as the block size you need for the device.

To calculate the value, use the following equation:

(Block_Size / 4) + 1 = Value

Table 9 on page 43 provides block size and corresponding decimal and hex values.

Block sizes

Block size

64k

96k

128k

256k

512k

Decimal value

17 decimal

25 decimal

33 decimal

65 decimal

129 decimal

Hex value

11 hex

19 hex

21 hex

41 hex

81 hex

To locate the drives and check the maximum block size:

1. Reboot the machine.

2. To locate the drives, run the inquire program:

C:\>inquire

Results similar to the following appear: [email protected]:NEC CD-ROM DRIVE:4661.06|CD-ROM [email protected]:ARCHIVE Python 06408-XXX8071|Tape, \\.\Tape0 [email protected]:HP C5173-7000 3.02|Autochanger (Jukebox) [email protected]:QUANTUM DLT7000 1732|Tape, \\.\Tape1 [email protected]:QUANTUM DLT7000 1732|Tape, \\.\Tape2 [email protected]:SEAGATE ST39204LC 0002|Disk, \\.\PHYSICALDRIVE0 [email protected]:QUANTUM ATLAS V 9 SCA 0201|Disk, \\.\PHYSICALDRIVE1 [email protected]:DELL 1x4 U2W SCSI BP 5.35|Processor

3. To check if the maximum blocksize changed, run the mt program:

C:\>mt -f \\.\Tape1 status

Results similar to the following appear:

\\.\Tape1:

Media Capacity = 15.20GByte

Media Remaining = 13.60GByte

Media Blocksize = 0

Media Partition Count = 0

Media is not write protected default blocksize = 65536 maximum blocksize = 131072 minimum blocksize = 1

MaximumPartitionCount = 0

Partition = 0

Logical block position = 44815

EOTWarningZoneSize = 0

Server input/output

43

Testing and Tuning on Windows

CompressionEnabled

Features: ...

In the previous example, the maximum block size is 128 KB (131072 divided by

1024).

Other suggestions for tuning I/O performance are:

Move the hardware configuration around; for example, move some disks off an overloaded SCSI bus.

If possible, use PCI adapters in the NetWorker server. If you must use other adapters, EISA adapters are better than ISA adapters because ISA adapters have bus contention problems that degrade system performance.

Use a dual-PCI backplane system, rather than a bridged-PCI backplane.

Use multiple SCSI buses with devices of the same type (for example, UltraSCSI) on the same bus.

Use short, high-quality cables with active terminators.

Ensure that SCSI communications are occurring synchronously, not asynchronously.

Devices

The following sections address testing and tuning issues for the NetWorker backup devices within the Windows environment.

“Backup devices” on page 26 provides a

general discussion of how device issues affect NetWorker software performance.

Test device performance

To test device input/output, see the bigasm program test described in “Test device performance with bigasm” on page 28

.

Tuning device performance

Most tape drives come with hardware data compression enabled by default. When compression is enabled, device performance and media capacity can double.

Hardware data compression is controlled by the NSR_NO_HW_COMPRESS environment variable. When you set this environment variable to Yes, data is not compressed by the hardware before it is written to media.

Note:

For data compressed before it reaches the device, additional compression might increase the size of the data. If the data is compressed on the device, you can disable compression on the storage device.

When you change the name of an existing variable, Windows NT treats it as a new variable and does not overwrite or delete original variable.

Tune device performance

To tune the hardware compression system variable:

1. From the Control Panel, select System.

2. Click the Advanced tab and click Environment Variables.

44

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on Windows

3. Review the variables and values listed in the System Variables list box.

Depending on whether the NSR_NO_HW_COMPRESS variable already exists or not, follow the appropriate step:

• If the NSR_NO_HW_COMPRESS variable is already listed, and you simply want to change its value, select it. The variable name and its value appear in the Variable and Value text boxes. a. Change its value to Yes.

b. Click OK to confirm the change.

The updated value of the NSR_NO_HW_COMPRESS variable is reflected in the System Variables list box.

• If the NSR_NO_HW_COMPRESS variable is not listed, you need to create it. a. Click New. b. Enter the variable name NSR_NO_HW_COMPRESS c. Enter the value Yes. d. Click OK.

4. When you have completed adding or modifying the NSR_NO_HW_COMPRESS variable and/or its value, click OK.

5. Restart the NetWorker server.

To see the device compression setting, enter the following on the command line:

mt -f \\.\Tape0 stat

In the output of a device with compression enabled, the following appears:

Compress Enabled

Windows software

The following variables affect the overall Windows operating system performance and the speed of backup:

File-system overhead

File-system input/output (I/O) can degrade I/O performance. If you integrate logical volume managers with the file system, you can increase disk performance and add many other features to improve manageability of large file systems. Also, depending on the level of RAID (Redundant Array of Independent Disks) you implement, RAID can improve or adversely affect backup performance.

Server memory usage setting

You can set server memory use to be optimized for the following:

• Small number of clients

• Large number of clients

• File server

• Domain controller

“Memory performance evaluation methods” on page 38 provides more

information.

Page file size

Windows software

45

Testing and Tuning on Windows

You can adjust the size and location of the virtual memory file (pagefile.sys) on the local disks.

“Memory performance evaluation methods” on page 38 provides

more information.

Recoveries

Recovery performance can fluctuate based on a variety of issues, including network traffic, bottlenecks, and file sizes. One method of recovering data efficiently is to start multiple recover commands simultaneously through the save set recovery method.

For example, you can start three different save set recover programs instead of one save set recover program with three save sets. Separate recover programs provide the maximum parallelism possible given the number of daemons and the actual volume and save set layout.

Note:

If multiple, simultaneous recover programs are run from the same tape, do not let the tape mount and start until all recoveries are ready. If the tape is used before all recoveries are ready, the tape will be read through multiple times and recovery performance will be slower, rather than faster.

Perform multiple, simultaneous recoveries

To perform multiple recoveries:

1. Open one NetWorker User program for each save set that needs to be recovered.

2. In each window, select the save set to be recovered, but do not start the recovery process.

3. Once all three save sets are selected in their respective window, execute each recovery consecutively.

4. Measure the time it takes to recover all three save sets.

5. Once the recoveries are finished, perform another recovery with all three save sets in the same recover request.

6. Compare the time needed for the multiple recover requests to the time needed for the single recover request.

The multiple recoveries should have finished before the single recovery of multiple save sets. If the single recovery completed faster, the tape may have mounted before all recoveries could start or the computer is CPU-bound rather than I/O-bound. To determine the cause of the bottlenecks, use the performance and activity monitoring tools available with the operating system.

46

EMC NetWorker Release 7.5 Performance Tuning Guide

4

Testing and Tuning on

UNIX and Linux

This chapter provides additional performance testing and tuning information for the

NetWorker server on a UNIX or Linux platform.

These topics are discussed:

Physical disks................................................................................................................. 48

Devices............................................................................................................................ 51

Using the system activity reporter.............................................................................. 53

Recoveries....................................................................................................................... 55

OS tuning recommendations ....................................................................................... 56

The multitude of platform- and network-specific variables that can impact UNIX or

Linux system performance cannot be covered comprehensively in a single chapter.

The scope of this chapter is therefore limited to the detection and analysis of processes that have an impact on how efficiently the NetWorker server can perform backups and recoveries.

While there are no simple solutions to performance issues, this chapter provides a general testing strategy for locating performance blockages. The testing strategy uses benchmarks and baselines derived from common utilities.

This chapter assumes that you are familiar with:

UNIX or Linux system infrastructure, including networking and devices.

Writing shell scripts and using Linux or UNIX utilities, such as tar.

The scripts in this chapter use standard utilities. The examples are specific to Solaris, but the scripts can be applied to most UNIX and Linux platforms with minimal changes.

The testing strategy and scripts use this scenario:

All backup processes are local (that is, not over a network).

All tape devices operate at the same speed.

Data is stored on a file system (no databases are used).

Testing and Tuning on UNIX and Linux

47

Testing and Tuning on UNIX and Linux

Physical disks

These sections provide information and suggestions on testing and evaluating the read speed performance on the physical disks of the NetWorker server. The UNIX and Linux operating systems provide several utilities for determining disk read speed. These sections detail their usage.

Apply this testing strategy to collect baselines to measure tape drive performance:

Test the read speed of each individual disk while the NetWorker software is not in run mode.

Test the read speed of all disks while the NetWorker software is not in run mode.

Test the read speed of each individual disk while the NetWorker software is in run mode.

Test the read speed of all disks while the NetWorker software is in run mode.

Benchmark evaluation

The utility /bin/time reports the amount of time required to execute a program, breaking down the total time into three components:

Real time — The time that the program takes to run as it would be measured by a user sitting at the terminal using a stopwatch.

User time — The actual time that the computer spent executing code in the user state.

System time — The time the computer spent executing UNIX or Linux system code on behalf of the user.

Note:

When running the tar or uasm command, do not specify a file or mountpoint accessed recently. The file may still be in memory and not read from the disk.

The result of running the /bin/time tar cvf - /space2 > /dev/null command on a

Solaris computer provides this result for the mount point /space2:

RESULTS: real 6:53.4

user 18.2

sys 1:48.1

Test the read speed of a single disk

To test the read speed of an individual disk:

1. Enter the df command to display a list of mounted file systems and their respective sizes.

2. Run the /bin/time utility to determine how long it takes to read each file system.

For example, on Solaris, enter:

/bin/time tar cf -

mount_point > /dev/null

To achieve a consistent result, no other disk or system activity should be running when you run this command.

48

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on UNIX and Linux

Test the read speed of several disks

After you execute the /bin/time utility for each file system, measure the read time for all file systems on each SCSI bus. If you are running the disks in parallel, develop a baseline for the number of parallel disks. For example, if there are 300 disks, and 10 are in parallel, measure the baseline for the 10 disks.

To streamline this task, create a shell script using the editor of your choice. Following is an example shell script from a Solaris computer that was created for multiple disks

(/space, /space2, and so forth):

/bin/time tar cf - /space > /dev/null &

/bin/time tar cf - /space2 > /dev/null &

/bin/time tar cf - /space3 > /dev/null &

...

Test the read speed of a single disk while running the software

To test the read speed of an individual disk using the NetWorker software:

1. Enter the df command to display a list of mounted file systems and their respective sizes.

2. Run the uasm program for each disk. For example, on Solaris, enter:

/bin/time uasm -s

mount_point > /dev/null

Depending on the configuration of the computer, you might need to specify the path for uasm in the command.

“Disk read speed testing methods” on page 17 provides more information on the

uasm

command.

Test the read speed of several disks while running the software

Test the read speed for all the disks on a SCSI channel. If you are running the disks in parallel, develop a baseline for the number of parallel disks. For example, if there are

300 disks, and 10 are in parallel, measure the baseline for the 10 disks.

To streamline this task, create a shell script using the editor of your choice. The following is an example shell script for a Solaris computer that was created for multiple disks (/space, /space2, and so forth):

/bin/time uasm -s /space > /dev/null &

/bin/time uasm -s /space2 > /dev/null &

/bin/time uasm -s /space3 > /dev/null &

...

To calculate the read speed of the disk:

1. Enter the df -k command to obtain the file size (in kilobytes) of /space2:

%

df -k

FilesystemkbytesusedcapacityMounted on /dev/dsk/c0t1d0s0

195257379793546%/space2

2. Divide the real time by the size (in kilobytes) of /space2.

For example, based on the result and size of /space2 above, the read speed of

/space2 is 1932 KB per second.

Physical disks

49

Testing and Tuning on UNIX and Linux

3. Compare the results of the benchmarks generated from:

• First, the individual disks without the NetWorker software running, as compared to the results of individual disks running the NetWorker software.

• Then, multiple disks without the NetWorker software running, as compared to the results of multiple disks running the NetWorker software.

50

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on UNIX and Linux

Devices

Apply this testing strategy to collect baselines to measure tape drive performance:

Test the write speed of each individual tape drive while the NetWorker software is not in run mode.

Test the write speed of all tape drives while the NetWorker software is not in run mode.

Test the write speed of each individual tape drive while the NetWorker software is in run mode.

Test the write speed of all tape drives while the NetWorker software is in run mode.

To ensure consistency in the measurements, test the same tape drives both when the

NetWorker software is running and when it is not.

Benchmark evaluation

Compare the results of the benchmarks generated from:

First, individual drives writing data without the NetWorker software running, as compared to the results of individual drives writing data when the NetWorker software is running.

Then, multiple drives writing data without the NetWorker software running, as compared to the results of multiple drives writing data while running the

NetWorker software.

Test the write speed of a single tape drive

A single tape drive can be tested by using the commands in this section.

Note:

Using the mt rewind command, followed by the dd command, can erase a tape. Exercise caution when using these commands.

To test the write speed of a single tape drive, enter these commands for each tape drive:

mt -f /dev/rmt/

drive_name rewind

dd if=/dev/zero of=/dev/rmt/

drive_name \

bs=

block_size count=1;\

/bin/time dd if=/dev/zero of=/dev/rmt/

drive_name \

bs=

block_size count=1000

Although the block size can vary depending on the environment, a block-size value of 32 can be used for purposes of testing and examples.

Test the write speed of several tape drives

Test the write speed of all the tape drives on the SCSI channel. To streamline this task,

create a shell script using the command demonstrated in “Test the write speed of a single tape drive” on page 51

.

Devices

51

Testing and Tuning on UNIX and Linux

This is an example shell script for a Solaris computer that was created for multiple drives (0mbn, 1mbn, 2mbn, and so forth): mt -f /dev/rmt/0mbn rewind; dd if=/dev/zero \ of=/dev/rmt/0mbn bs=32k count=1; \

/bin/time dd if=/dev/zero of=/dev/rmt/0mbn \ bs=32k count=1000 & mt -f /dev/rmt/1mbn rewind; dd if=/dev/zero \ of=/dev/rmt/1mbn bs=32k count=1; \

/bin/time dd if=/dev/zero of=/dev/rmt/1mbn \ bs=32k count=1000 & mt -f /dev/rmt/2mbn rewind; dd if=/dev/zero \ of=/dev/rmt/2mbn bs=32k count=1; \

/bin/time dd if=/dev/zero of=/dev/rmt/2mbn \ bs=32k count=1000 &

...

Test the write speed of a single drive while running the software

To test the write speed of a single drive while running the NetWorker software:

1. Set target sessions to 1.

2. Label the tape.

3. Set up bigasm: a. Create an empty directory:

mkdir /empty

b. Go to the directory empty:

cd /empty

c. Create an empty file:

touch e

d. Using a text editor, create a .nsr file.

e. Edit the .nsr file by adding this directive:

bigasm -S100M : e

f. Save the file and edit the text editor.

4. Run this script to determine the baseline:

save -s

server_name /etc/motd; /bin/time save -s server_name

/empty/e

When NetWorker encounters the .nsr file, the directive results in a 100 MB file written to tape.

The NetWorker server automatically assigns each command to a tape, since target sessions are set to 1.

Test the write speed of several drives while running the software

To test the write speed of several drives, repeat steps 1 through 4 in “Test the write speed of a single drive while running the software” on page 52 for every drive on the

SCSI channel simultaneously.

52

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on UNIX and Linux

Using the system activity reporter

The System Activity Reporter (sar) is a standard UNIX utility for most systems that monitors and reports on system performance, including buffer and block device activity, kernel memory allocation, and CPU utilization. Use this utility to evaluate and tune a UNIX system. The sar man page provides more information on this utility.

Monitor buffer activity

If the read and write buffer cache hit rates (%rcache and %wcache) are consistently low, increase the size of the buffer cache to improve disk I/O performance.

To monitor buffer read activity, enter this command:

sar -b %rcache

To monitor buffer write activity, enter this command:

sar -b %wrcache

The values of %rcache and %wrcache depend on the combination of applications that the system is running, the speed of its disk subsystems, and the amount of memory available. The ideal value for both is 100, but that value is unlikely on an average system. If either value is consistently below 50 percent, increase the size of the buffer cache.

Monitor block device activity

To monitor block device activity, enter this command:

sar -d

Results similar to this appear:

23:59:44 device %busy avquer+w/s blks/s avwait avserv

23:59:49 Sdsk-0 99.42 4.18 39.39 166.28 80.26 25.24

23:59:54 Sdsk-0 100.00 4.18 38.73 163.64 82.35 25.87

23:59:59 Sdsk-0 100.00 3.98 38.07 171.95 78.32 26.32 where:

device is the device on which the activity is measured.

%busy is the percentage of time that the system was transferring data to and from the device.

• A consistently high value for %busy indicates a heavily utilized disk.

Increasing CPU power will create a worse bottleneck because the processor produces more I/Os for a disk that is already overloaded.

avque is the average number of requests pending on the device including any on the device itself.

r+w/s is the number of read and write transfers to and from the disk.

blks/s is the number of 512-byte blocks transferred per second.

• The values for r+w/s and blks/s can be used to calculate the average size of data transfers by using this formula:

Average size of data transfer = blks/s / r+w/s

avwait is the average time in milliseconds that the request waits in the driver before being sent to the device.

Using the system activity reporter

53

Testing and Tuning on UNIX and Linux

avserv is the average time in milliseconds that it takes a request to complete.

The length of time is calculated from the time that the request is sent to the device to the moment the device signals it completed the request. The value of avserv varies depending on the type of disk and any caching on the disk controller.

Use the values generated by sar -d to determine which disks are overused and underused. To avoid bottlenecks, balance the disk load by moving some users from the busier disks to the less active disks.

Test CPU utilization

The sar -u command identifies disks to which the NetWorker software writes frequently, which could be I/O bottlenecks. To enhance performance, optimize these disks.

To test I/O-related CPU activity, enter this command:

sar -u

This information is reported:

%usr is the percentage of time the system is in user mode (that is, running user or application code).

%sys is the percentage of time system programs or system calls are run from user programs.

%wio is the percentage of time the system is waiting for I/O.

The %wio value should generally not exceed 25 percent. A higher percentage may indicate speeding up the disk throughput or add I/O bus capacity.

%idle is the percentage of time the system is completely idle.

If %idle is frequently equal to zero, the system is CPU bound. If the system throughput is too low, upgrade to a faster processor or reduce computational load on the system.

This example shows how to test CPU utilization by taking 5 samples at 60-second intervals.

To test CPU utilization, enter this command:

sar -u 60 5

These results appear:

18:22:46 %usr %sys %wio %idle

18:23:4613 9 6 73

18:24:46 25 16 13 45

18:25:46 21 9 1 68

18:26:46 22 10 1 66

18:27:46 22 11 1 66

54

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on UNIX and Linux

Recoveries

Recovery performance can fluctuate based on a variety of issues, including network traffic, bottlenecks, and file sizes. One method of recovering data efficiently is to start multiple recover commands simultaneously through the save set recovery method.

For example, you can start three different save set recover programs instead of one

recover

program with three save sets. Separate recover programs provide the maximum parallelism possible given the number of daemons and the actual volume and save set layout.

If multiple, simultaneous recover programs are run from the same tape, do not let the tape mount and start until all recoveries are ready. If the tape is used before all recoveries are ready, the tape will be read through multiple times and recovery performance will be slower, rather than faster.

Perform multiple, simultaneous recoveries

To perform multiple recoveries:

1. Open one command window for each save set to recover.

2. In each window, enter the recover command with the save set to recover, but do not press Enter.

3. Once all three recover commands are ready, execute each command consecutively.

4. Measure the time to recover all three save sets.

5. Once the recoveries finish, perform another recovery with all three save sets in the same recover request.

6. Compare the time needed for the multiple recovery requests to the time needed for the single recovery request.

The multiple recoveries should finish before the single recovery of multiple save sets.

If the single recovery completed faster:

The tape mounted before all recoveries could start.

The computer is CPU-bound rather than I/O-bound.

To determine the cause of the bottlenecks, use the performance and activity monitoring tools available with the operating system.

Recoveries

55

Testing and Tuning on UNIX and Linux

OS tuning recommendations

Starting with NetWorker Release 7.3, architectural changes were introduced into the

NetWorker application to provide key features for the following:

◆ reporting day-to-day maintenance through a Java-based interface

◆ a more reliable certificate-based authentication scheme.

In order to implement these changes in existing NetWorker environments, some

Operating System (OS) considerations need to be taken into account when tuning the

NetWorker datazone for optimization.

As a result of features that have been implemented, versions of NetWorker 7.3.x and higher rely more heavily on internal and external communications. Large, busy

NetWorker 7.2.x environments will benefit from a review of the current configuration to take into consideration a reduction in concurrent NetWorker operations which may overwhelm the underlying operating systems.

NetWorker operations which may impact operating system performance due to increased communication processes and ultimately NetWorker performance:

-Launching of a large number of NetWorker groups with a large number of clients at the same time.

-Having a large number of groups with a large number of clients which have overlapping backup windows.

- Having a large number of mount requests occurring at the same time

- Having overlapping devices requirements causing contention

If you were previously running NetWorker 7.2 and had groups starting at the same time, it may cause minor delays and no other real impact. However, with

NetWorker’s later releases, it may be more significant if the increase in internal and external communications cause a load that will be higher than the OS can handle.

If there are several local devices associated with the backup server, the OS resources can be exhausted due to excessive hardware resource usage. Consideration needs to be taken to ensure to avoid configuring a system with more devices than it can handle.

Before upgrade run the following:

◆ nsrim -x nsrck -m

◆ nsrck -L6 to ensure consistency in the NetWorker databases before upgrade.

OS settings

Starting with NetWorker release 7.3 SP4 and NetWorker release 7.4 SP1, the

NetWorker savegroup will utilize two file descriptors per each active session.

Since the maximum number of sessions on a backup server is limited to 512 sessions, setting the number of available file descriptors to 1048 is sufficient for all environments. Note that some operating systems have this value by default on 256 which is insufficient for NetWorker operations.

56

EMC NetWorker Release 7.5 Performance Tuning Guide

AIX

Solaris

HPUX

TRU64

!

!

Testing and Tuning on UNIX and Linux

For older versions of NetWorker release 7.3 and 7.4, set the number of file descriptors to a high value (4096). Refer to the OS documentation regarding changes to file descriptors with ulimit.

Issues can be encountered from TCP CRC checksuming when offloading is enabled on a network interface card. If that's expected, disable offloading.

IMPORTANT

This will increase CPU usage during high network usage.

# ethtool -K eth0 tso off

Increasing the network interface card queue length is recommended. Most new network interface cards already have this as a default.

# ifconfig eth0 txqueuelen 1000

The following settings are indicated for the specific Unix and Linux platforms that

NetWorker can operate on.

Refer to powerlink.emc.com for further details

To increase TCP buffers, modify the following parameters: tcp_sendspace tcp_recvspace to the value of 524 288

Refer to powerlink.emc.com for further details

CAUTION

It is not recommended to run NetWorker 7.3 and later on a Solaris 8 box.

On Solaris 9 and Solaris 10, tcp_conn_req_max_q 1024

(Queue depth for a number of non-processed TCP requests) tcp_conn_req_max_q0 4096

(normally, 4 x max_q param) tcp_time_wait_interval 60000

(this allows Solaris to free connections faster once they are closed)

Refer to powerlink.emc.com for further details

It is recommended to increase the max_thread_proc kernel parameter from 64 to 256 for versions prior to 7.3.4 and 7.4.2.

Refer to powerlink.emc.com for further details

Consider the following settings:

/etc/sysconfigtab

socket:

somaxconn = 65535

OS tuning recommendations

57

Testing and Tuning on UNIX and Linux

sominconn = 65535

proc:

open_max_hard = 32768

open_max_soft = 32768

ipc:

sem_mni = 1024

sem_msl = 512

sem_opm = 512

sem_ume = 512

shm_allocate_striped = 1

shm_max = 2139095040

shm_min = 1

shm_mni = 256

shm_seg = 256

inet:

tcbhashnum = 16

tcbhashsize = 8192

Linux

Linux kernel tunings:

To increase the connection backlog (hash tables) to a maximum allowed value, modify the parameters as follows: net.ipv4.tcp_max_syn_backlog = 8192 net.core.netdev_max_backlog = 8192

Note:

A common problem occurs when the above values are too low.

To increase the memory size available for TCP buffers, modify the parameters as follows: net.core.rmem_max = 16777216 net.core.wmem_max = 16777216 net.ipv4.tcp_rmem = 4096 87380 16777216 net.ipv4.tcp_wmem = 4096 65536 16777216

Note:

Increasing the above parameters helps to increase the transfer rate and reduce CPU usage.

The following keep alive values are suggested: net.ipv4.tcp_keepalive_intvl = 30 net.ipv4.tcp_keepalive_probes = 8 net.ipv4.tcp_keepalive_time = 7200

Note:

The application still needs to ask for keep alive values - they are not forced by the kernel.

The following is a timeout after improper close: net.ivp4.tcp_fin_timeout = 60

Note:

The above value should be low, not high.

The following is an RPC value: sunrpc.tcp_alot_table_entries = 64

58

EMC NetWorker Release 7.5 Performance Tuning Guide

Testing and Tuning on UNIX and Linux

Additional NetWorker related tuning parameters

Decrease nsrmmd polling interval (default: 2 minutes, recommended at least 15 minutes -- even more for large environments) since polling of unavailable

nsrmmd

(if S/Ns are down) is a blocking call.

Decrease nsrmmd restart interval (default: 2 minutes, recommended 10 minutes)

(if SN is down, blocking calls every 2 minutes is ineffectual) If these two nsrmmd values are not re-evaluated, then the server can freeze because it will get too busy polling (RPC errors, backups will hang, etc.)

Change scheduling so no savegrps start at the identical time (splitting start time for different savegroups by only 5 minutes improves stability immensely and prevents file descriptor resource exhaustion and resource exhaustion on OS level). Prior to 7.3.x a single thread was invoked during the backup, now with multi-threading in 7.3.x, there can be up to six internal threads invoked at the start of a backup.

OS tuning recommendations

59

Testing and Tuning on UNIX and Linux

60

EMC NetWorker Release 7.5 Performance Tuning Guide
