SUPER
®
SUPERSERVER 7045B-T
USER’S MANUAL
1.0a
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
Manual Revision 1.0a
Release Date: March 27, 2007
Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2007 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer 7045B-T. Installation and maintainance should be performed by experienced technicians only.
The SuperServer 7045B-T is a high-end server based on the SC743TQ-650 tower/
4U rackmount chassis and the X7DBE, a dual processor serverboard that supports
Intel® XeonTM processors at a Front Side (System) Bus speed of 1333 MHz and up
to 32 GB of FBD ECC DDR2-667/533 SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the X7DBE serverboard and the
SC743TQ-650 chassis, which comprise the SuperServer 7045B-T.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 7045B-T into
a rack and check out the server configuration prior to powering up the system. If
your server was ordered without processor and memory components, this chapter
will refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
iii
SUPERSERVER 7045B-T User's Manual
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 7045B-T.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X7DBE serverboard, including the
locations and functions of connections, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfiguring the
serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC743TQ-650 server chassis.
You should follow the procedures given in this chapter when installing, removing or
reconfiguring SATA or peripheral drives and when replacing system power supply
units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed information on running the CMOS Setup Utility.
Appendix A: BIOS POST Messages
Appendix B: BIOS POST Codes
Appendix C: Software Installation
Appendix D: System Specifications
iv
Preface
Notes
v
SUPERSERVER 7045B-T User's Manual
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1
Overview ......................................................................................................... 1-1
1-2
Serverboard Features ..................................................................................... 1-2
1-3
Server Chassis Features ................................................................................ 1-3
1-4
Contacting Supermicro ................................................................................... 1-6
Chapter 2: Server Installation
2-1
Overview .......................................................................................................... 2-1
2-2
Unpacking the System ................................................................................... 2-1
2-3
Preparing for Setup ......................................................................................... 2-1
2-4
Installing the System into a Rack .................................................................... 2-4
2-5
Checking the Serverboard Setup .................................................................... 2-8
2-6
Checking the Drive Bay Setup ........................................................................ 2-9
Chapter 3: System Interface
3-1
Overview ......................................................................................................... 3-1
3-2
Control Panel Buttons .................................................................................... 3-1
Power ...................................................................................................... 3-1
Reset ....................................................................................................... 3-1
3-3
Control Panel LEDs ........................................................................................ 3-2
Power ....................................................................................................... 3-2
HDD ........................................................................................................ 3-2
NIC1 ........................................................................................................ 3-2
NIC2 ........................................................................................................ 3-2
Overheat/Fan Fail ................................................................................... 3-2
Power Fail ................................................................................................ 3-3
3-4
SATA Drive Carrier LEDs................................................................................. 3-3
Chapter 4: System Safety
4-1
Electrical Safety Precautions ........................................................................... 4-1
4-2
General Safety Precautions ............................................................................. 4-2
4-3
ESD Safety Precautions ................................................................................. 4-3
4-4
Operating Precautions .................................................................................... 4-4
vi
Table of Contents
Chapter 5: Advanced Serverboard Setup
5-1
Handling the Serverboard ................................................................................ 5-1
5-2
Processor and Heatsink Installation ................................................................ 5-2
5-3
Connecting Cables .......................................................................................... 5-5
Connecting Data Cables ........................................................................... 5-5
Connecting Power Cables ......................................................................... 5-5
Connecting the Control Panel ................................................................... 5-6
5-4
I/O Ports ......................................................................................................... 5-7
5-5
Installing Memory............................................................................................. 5-7
5-6
Adding PCI Cards ............................................................................................ 5-9
5-7
Serverboard Details ...................................................................................... 5-10
X7DBE Layout ......................................................................................... 5-10
X7DBE Quick Reference ......................................................................... 5-11
5-8
Connector Definitions .................................................................................... 5-12
ATX Power Connector .......................................................................... 5-12
Auxiliary Power Connector ...................................................................... 5-12
Processor Power Connector ................................................................... 5-12
NMI Button ............................................................................................ 5-12
Power LED .............................................................................................. 5-12
HDD LED .............................................................................................. 5-13
NIC1 LED .............................................................................................. 5-13
NIC2 LED .............................................................................................. 5-13
Overheat/Fan Fail LED .......................................................................... 5-13
Power Fail LED ...................................................................................... 5-13
Reset Button ......................................................................................... 5-14
Power Button ........................................................................................ 5-14
Universal Serial Bus (USB0/1) ................................................................ 5-14
Chassis Intrusion ..................................................................................... 5-14
Serial Ports .............................................................................................. 5-15
Power Fail Header .................................................................................. 5-15
Fan Headers............................................................................................ 5-15
Extra Universal Serial Bus Headers ....................................................... 5-16
Power LED/Speaker ................................................................................ 5-16
ATX PS/2 Keyboard and Mouse Ports.................................................... 5-16
Overheat LED.......................................................................................... 5-16
Wake-On-LAN ......................................................................................... 5-17
Wake-On-Ring ........................................................................................ 5-17
SMB ......................................................................................................... 5-17
SMB Power ............................................................................................. 5-17
vii
SUPERSERVER 7045B-T User's Manual
SGPIO .................................................................................................... 5-18
JLAN1/2 .................................................................................................. 5-18
Alarm Reset ........................................................................................... 5-18
Keylock ................................................................................................... 5-18
5-9
Jumper Settings ............................................................................................. 5-19
Explanation of Jumpers ........................................................................... 5-19
CMOS Clear ............................................................................................ 5-19
VGA Enable/Disable ................................................................................ 5-19
3rd Power Supply Alarm Enable/Disable ................................................ 5-20
Watch Dog Enable/Disable ..................................................................... 5-20
JLAN Enable/Disable ............................................................................. 5-21
Compact Flash Master/Slave ................................................................. 5-21
5-10 Onboard Indicators ........................................................................................ 5-21
JLAN1/JLAN2 LEDs ................................................................................ 5-21
5-11 Parallel Port, Floppy, IDE and SATA Drive Connections ............................... 5-22
Parallel Port Connector ........................................................................... 5-22
Floppy Connector .................................................................................... 5-23
IDE Connectors ....................................................................................... 5-24
SATA Ports ............................................................................................. 5-24
Chapter 6: Advanced Chassis Setup
6-1
Static-Sensitive Devices .................................................................................. 6-1
6-2
Front Control Panel ......................................................................................... 6-3
6-3
System Fans .................................................................................................... 6-4
System Fan Failure ................................................................................... 6-4
Replacing Fans ......................................................................................... 6-4
6-4
Drive Bay Installation/Removal ........................................................................ 6-6
SATA Drives ............................................................................................. 6-6
Installing a Component in the 5.25" Drive Bay ......................................... 6-8
6-5
Power Supply................................................................................................... 6-9
Power Supply Failure ................................................................................ 6-9
Replacing the Power Supply ..................................................................... 6-9
Chapter 7: BIOS
7-1
Introduction ...................................................................................................... 7-1
7-2
Running Setup ................................................................................................ 7-2
7-3
Main BIOS Setup ............................................................................................ 7-2
7-4
Advanced Setup ............................................................................................. 7-7
7-5
Security ......................................................................................................... 7-19
7-6
Boot .............................................................................................................. 7-20
viii
Table of Contents
7-7
Exit ................................................................................................................ 7-21
Appendices:
Appendix A: BIOS POST Messages ........................................................................ A-1
Appendix B: BIOS POST Codes .............................................................................. B-1
Appendix C: Software Installation ............................................................................ C-1
Appendix D: System Specifications ......................................................................... D-1
ix
SUPERSERVER 7045B-T User's Manual
Notes
x
Chapter 1: Introduction
Chapter 1
Introduction
1-1
Overview
The Supermicro SuperServer 7045B-T is a high-end server that is comprised of two
main subsystems: the SC743TQ-650 tower/4U server chassis and the X7DBE Intel
Xeon dual processor serverboard. Please refer to our web site for information on
operating systems that have been certified for use with the SuperServer 7045B-T
(www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the SuperServer 7045B-T, as listed below:
Four (4) 8-cm hot-swap chassis fans (FAN-0072)
Two (2) 8-cm hot-swap rear exhaust fans (FAN-0081)
One (1) air shroud (CSE-PT0123)
One (1) 3.5" floppy drive [FPD-PNSC-02(01)]
Two (2) 5.25" dummy drive trays
One (1) front control panel cable (CBL-0087)
One (1) I/O shield (CSE-PT55)
Serial ATA Accessories
One (1) Serial ATA backplane (CSE-SAS-743TQ)
Four (4) Serial ATA data cables (CBL-0061L)
Two (2) Serial ATA LED cables (CBL-0157L)
Eight (8) Serial ATA hot-swap drive carriers [CSE-PT17(B)]
Optional:
Two (2) CPU passive heatsinks (SNK-P0018)
One (1) rackmount kit [CSE-PT026(B)]
1-1
SUPERSERVER 7045B-T User's Manual
1-2
Serverboard Features
At the heart of the SuperServer 7045B-T lies the X7DBE, a dual processor
serverboard based on the Intel 5000P chipset and designed to provide maximum
performance. Below are the main features of the X7DBE. (See Figure 1-1 for a
block diagram of the Intel 5000P chipset).
Processors
The X7DBE supports single or dual Intel dual-core Xeon processors 5300/5100/5000
series. Please refer to the serverboard description pages on our web site for a
complete listing of supported processors (www.supermicro.com) and for details on
board revisions needed to support 5300/5100 series CPUs.
Memory
The X7DBE has eight 240-pin DIMM slots that can support up to 32 GB of ECC
FBD (Fully Buffered DIMM) DDR2-666 or 533 SDRAM. The memory is an interleaved configuration, which requires modules of the same size and speed to be
installed in pairs.
Serial ATA
A SATA controller is integrated into the South Bridge of the 5000P chipset to provide a six-port Serial ATA subsystem, which is RAID 0, 1, 10 and 5 supported. The
Serial ATA drives are hot-swappable units. Note: The operating system you use
must have RAID support to enable the hot-swap capability and RAID function of
the Serial ATA drives.
PCI Expansion Slots
The X7DBE has six PCI expansion slots, which includes two x8 PCI-Express slots,
one x4 PCI-Express slot, two PCI-X 133 MHz slots and one PCI-X 100 MHz slot.
Onboard Controllers/Ports
One floppy drive controller and one onboard ATA/100 controller are provided to
support up to two IDE hard drives or ATAPI devices. The color-coded I/O ports
include one COM port (an additional COM header is located on the serverboard), a
VGA (monitor) port, a parallel port, two USB 2.0 ports, PS/2 mouse and keyboard
ports and two gigabit Ethernet ports. Two front side USB ports are also included
on the front of the chassis.
1-2
Chapter 1: Introduction
ATI Graphics Controller
The X7DBE features an integrated ATI video controller based on the ES1000 graphics chip. The ES1000 was designed specifically for servers, featuring low power
consumption, high reliability and superior longevity.
Other Features
Other onboard features that promote system health include onboard voltage monitors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.
1-3
Server Chassis Features
The following is a general outline of the main features of the SC743TQ-650 server
chassis.
System Power
The SC743TQ-650 features a single 650W power supply. The system must be shut
down and the AC power cord removed before replacing or performing any service
on the power supply unit.
Serial ATA Subsystem
The Serial ATA subsystem supports up to six Serial ATA drives. The Serial ATA
drives are hot-swappable units and are connected to a backplane that provides
power and control.
Note: The operating system you use must have RAID support to enable the hotswap capability of the Serial ATA drives.
Front Control Panel
The SuperServer 7045B-T's control panel provides you with system monitoring
and control. LEDs indicate system power, HDD activity, network activity, system
overheat and power supply failure. A main power button and a system reset button
are also included.
1-3
SUPERSERVER 7045B-T User's Manual
I/O Backplane
The SC743TQ-650 is an ATX form factor chassis that may be used in either a tower
or a 4U rackmount configuration. The I/O backplane provides six PCI expansion
slots, one COM port, a parallel port, a VGA port, two USB 2.0 ports, PS/2 mouse
and keyboard ports and two gigabit Ethernet ports.
Cooling System
The SC743TQ-650 chassis has an innovative cooling design that includes four 8-cm
hot-plug system cooling fans located in the middle section of the chassis as well as
two 8-cm hot-plug exhaust fans located at the rear of the chassis. An air shroud
channels the airflow from the system fans to efficiently cool the processor area of
the system. The power supply module also includes a cooling fan.
1-4
Chapter 1: Introduction
Figure 1-1. Intel 5000P Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
CPU1
CPU2
1067/1333 MT/s
PCI-Exp
5000P
MCH
FBD CH2
x8
Slot 5: PCI-Express x8
FBD DIMM Bank4
FBD CH1
FBD DIMM Bank3
Slot 6: PCI-Exp x8/SEPC
FBD DIMM Bank2
x8
FBD DIMM Bank1
FBD CH0
PCI-Exp
PCI-E x4
PCI-Exp
PCI-E x8
FBD CH3
DDR2
x4
Slot 4: PCI-Express x8
3.0 Gb/s
SATA Ports (6)
PCI-Exp
Slot 2: PCI-X
x8
PXH
ATA 100
ESB2
IDE Ports (2)
Slot 1: PCI-X
Slot 3: PCI-X
USB 2.0
PCI-X 133
PCI 32
LAN Ports (2)
82563
Kumeran
ES
1000
Kybd/
Mouse
1-5
USB Ports (5)
LPC
S I/O
Floppy
BIOS
COM
Ports (2)
Parallel
Port
SUPERSERVER 7045B-T User's Manual
1-4
Contacting Supermicro
Headquarters
Address:
Tel:
Fax:
Email:
Web Site:
SuperMicro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
+1 (408) 503-8000
+1 (408) 503-8008
[email protected] (General Information)
[email protected] (Technical Support)
www.supermicro.com
Europe
Address:
Tel:
Fax:
Email:
SuperMicro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
+31 (0) 73-6400390
+31 (0) 73-6416525
[email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address:
SuperMicro, Taiwan
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei, Taiwan, R.O.C.
Tel:
+886-(2) 8226-3990
Fax:
+886-(2) 8226-3991
Web Site:
www.supermicro.com.tw
Technical Support:
Email:
[email protected]
Tel:
886-2-8228-1366, ext.132 or 139
1-6
Chapter 2: Server Installation
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperServer 7045B-T up
and running. Following these steps in the order given should enable you to have
the system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory preinstalled. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details
on installing specific components.
The 7045B-T may be employed either as a tower or mounted in a rack as a 4U
rackmount chassis. If using it as a tower unit, please read the Server Precautions
in the next section and then skip ahead to Section 2-5.
2-2
Unpacking the System
You should inspect the box the system was shipped in and note if it was damaged
in any way. If the server itself shows damage you should file a damage claim with
the carrier who delivered it.
Decide on a suitable location for the SuperServer 7045B-T. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical
noise and electromagnetic fields are generated. You will also need it placed near
a grounded power outlet. Be sure to read the Rack and Server Precautions in the
next section.
2-3
Preparing for Setup
The box the system was shipped in may include two sets of rail assemblies, two
rail mounting brackets and mounting screws needed for installing the system into a
rack (optional kit). Follow the steps in the order given to complete the installation
process in a minimum amount of time. Please read this section in its entirety before
you begin the installation procedure outlined in the sections that follow.
2-1
SUPERSERVER 7045B-T User's Manual
Choosing a Setup Location
- Leave enough clearance in front of the system to enable you to open the front
door completely (~25 inches).
- Leave approximately 30 inches of clearance in the back of the system to allow for
sufficient airflow and ease in servicing.
- This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
- This product is not suitable for use with visual display work place devices according
to §2 of the the German Ordinance for Work with Visual Display Units.
!
Warnings and Precautions!
!
Rack Precautions
- Ensure that the leveling jacks on the bottom of the rack are fully extended to the
floor with the full weight of the rack resting on them.
- In single rack installation, stabilizers should be attached to the rack.
- In multiple rack installations, the racks should be coupled together.
- Always make sure the rack is stable before extending a component from the
rack.
- You should extend only one component at a time - extending two or more simultaneously may cause the rack to become unstable.
Server Precautions
- Review the electrical and general safety precautions in Chapter 4.
- Determine the placement of each component in the rack before you install the
rails.
- Install the heaviest server components on the bottom of the rack first, and then
work up.
- Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a power
failure.
- Allow the hot plug SATA drives and power supply units to cool before touching
them.
- Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
2-2
Chapter 2: Server Installation
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).
2-3
SUPERSERVER 7045B-T User's Manual
2-4
Installing the System into a Rack
This section provides information on installing the system into a rack unit. Rack
installation requires the use of the optional rackmount kit [CSE-PT26(B)]. If the
system has already been mounted into a rack or if you are using it as a tower, you
can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the
market, which may mean the assembly procedure will differ slightly. The following
is a guideline for installing the server into a rack with the rack rails provided in the
rackmount kit. You should also refer to the installation instructions that came with
the rack unit you are using.
Identifying the Sections of the Rack Rails
The optional rackmount kit (CSE-PT26 or CSE-PT26B - black) includes two rack
rail assemblies. Each of these assemblies consist of three sections: an inner fixed
chassis rail that secures to the chassis, an outer rack rail that secures directly to
the rack itself and two rail brackets, which also attack to the rack (see Figure 2-1.)
The inner and outer rails must be detached from each other to install.
To remove the inner chassis rail, pull it out as far as possible - you should hear a
"click" sound as a locking tab emerges from inside the rail assembly and locks the
inner rail. Depress the locking tab to pull the inner rail completely out. Do this for
both assemblies (one for each side).
Figure 2-1. Identifying the Sections of the Rack Rails
Outer rail
Inner rail
Rail brackets
2-4
Chapter 2: Server Installation
Installing the Chassis Rails
You will need to remove the top cover and the feet to add rack rails to the chassis.
First, remove the top and right covers (top and left covers when standing as a tower
chassis) by first removing the screws that secure them to the chassis. Depress
the button on the top (side if tower) of the chassis to release the cover and then
pull the cover off. Then unscrew the four feet and remove them from the chassis
(see Figure 2-2).
You can now attach rack rails to the top and bottom (now the sides) of the chassis.
First add the rack handles. Then position the inner chassis rail sections you just
removed along the side of the chassis making sure the screw holes line up. Note
that these two rails are left/right specific. Screw the rail securely to the side of the
chassis (see Figure 2-3). Repeat this procedure for the other rail on the other side
of the chassis. You will also need to attach the rail brackets when installing into a
telco rack.
Locking Tabs: As mentioned, the chassis rails have a locking tab, which serves
two functions. The first is to lock the server into place when installed and pushed
fully into the rack, which is its normal position. Secondly, these tabs also lock the
server in place when fully extended from the rack. This prevents the server from
coming completely out of the rack when you pull it out for servicing.
Figure 2-2. Preparing to Install the Chassis Rails
2-5
SUPERSERVER 7045B-T User's Manual
Figure 2-3. Installing the Rails to the Chassis
Installing the Rack Rails
Determine where you want to place the SuperServer 7045B-T in the rack. (See
Rack and Server Precautions in Section 2-3.) Position the fixed rack rail/sliding rail
guide assemblies at the desired location in the rack, keeping the sliding rail guide
facing the inside of the rack. Screw the assembly securely to the rack using the
brackets provided. Attach the other assembly to the other side of the rack, making
sure both are at the exact same height and with the rail guides facing inward.
2-6
Chapter 2: Server Installation
Installing the Server into the Rack
You should now have rails attached to both the chassis and the rack unit. The next
step is to install the server into the rack. You should have two brackets in the rack
mount kit. Install these first keeping in mind that they are left/right specific (marked
with "L" and "R"). Then, line up the rear of the chassis rails with the front of the
rack rails. Slide the chassis rails into the rack rails, keeping the pressure even on
both sides (you may have to depress the locking tabs when inserting).
When the server has been pushed completely into the rack, you should hear the
locking tabs "click". Finish by inserting and tightening the thumbscrews that hold
the front of the server to the rack (see Figure 2-4).
Figure 2-4.
Installing the Server into a Rack
2-7
SUPERSERVER 7045B-T User's Manual
2-5
Checking the Serverboard Setup
After setting up the the system, you will need to open the unit to make sure the
serverboard is properly installed and all the connections have been made.
1. Accessing the inside of the system (see Figure 2-5)
[If rack mounted, first grasp the two handles on either side and pull the unit
straight out until it locks (you will hear a "click").] There are two screws that
secure the cover to the chassis - remove these first. Depress the button on the
top (side if tower) of the chassis to release the cover. You can then lift the cover
from the chassis to gain full access to the inside of the server.
2. Check the CPUs (processors)
You may have one or two processors already installed into the serverboard. Each
processor should have its own heatsink attached. See Chapter 5 for instructions
on processor installation.
3. CPU clock ratio setting
The CPU speed should be automatically detected. No jumper or BIOS settings
need to be made.
4. Check the system memory
Your server may have come with system memory already installed. Make sure
all DIMMs are fully seated in their slots. For details on adding system memory,
refer to Chapter 5.
5. Installing add-on cards
If desired, you can install add-on cards to the system. See Chapter 5 for details
on installing PCI add-on cards.
6. Check all cable connections and airflow
Make sure all power and data cables are properly connected and not blocking
the chassis airflow. See Chapter 5 for details on cable connections.
2-8
Chapter 2: Server Installation
Figure 2-5. Accessing the Inside of the System
(Rack Configuration shown)
2-6
Checking the Drive Bay Setup
Next, you should check to make sure the peripheral drives and the SATA drives
and SATA backplane have been properly installed and all connections have been
made.
1. Accessing the drive bays
All drives can be accessed from the front of the server. For servicing the CDROM, IDE hard drives and floppy drives, you will need to remove the top/left
chassis cover. The SATA disk drives can be installed and removed from the
front of the chassis without removing any chassis covers.
2. Installing components into the 5.25" drive bays
To install components into the 5.25" drive bays, you must first remove the top/
left chassis cover as described in the previous section. Refer to Chapter 6 for
details.
3. Installing CD-ROM and floppy disk drives
Refer to Chapter 6 if you need to reinstall a CD-ROM and/or floppy disk drive
to the system.
2-9
SUPERSERVER 7045B-T User's Manual
4. Check the SATA disk drives
Depending upon your system's configuration, your system may have one or
more drives already installed. If you need to install SATA drives, please refer to
Chapter 6.
5. Check the airflow
Airflow is provided by four hot-swap 8-cm chassis fans working in conjunction
with an air shroud. Two 8-cm exhaust fans are also mounted at the rear of the
chassis. The system component layout was carefully designed to promote sufficient airflow through the chassis. Also note that all power and data cables have
been routed in such a way that they do not block the airflow generated by the
fans. Keep this in mind when you reroute them after working on the system.
6. Supplying power to the system
The last thing you must do is to provide input power to the system. Plug the
power cord from the power supply unit into a high-quality power strip that offers
protection from electrical noise and power surges. It is recommended that you
use an uninterruptible power supply (UPS). Finally, depress the power on button
on the front of the chassis.
2-10
Chapter 3: System Interface
Chapter 3
System Interface
3-1
Overview
The control panel on the 7045B-T has several LEDs and two buttons. There is
also an LED on each SATA drive carrier. These LEDs keep you constantly informed of the overall status of the system and the activity and health of specific
components.
3-2
Control Panel Buttons
There are two push-buttons located on the front of the chassis. These are (in order
from left to right) a power on/off button and a reset button.
POWER: This is the main power button, which is used to apply or turn off
the main system power. Turning off system power with this button removes the
main power but keeps standby power supplied to the system.
RESET: Use the reset button to reboot the system.
3-1
SUPERSERVER 7045B-T User's Manual
3-3
Control Panel LEDs
The control panel located on the front of the SC743TQ-650 chassis has six LEDs
that provide you with critical information related to different parts of the system.
This section explains what each LED indicates when illuminated and any corrective
action you may need to take.
Power: Indicates power is being supplied to the system's power supply. This
LED should normally be on when the system is operating.
HDD: Indicates IDE channel activity. On the SC743TQ-650, this LED indicates SATA/CD-ROM drive activity when flashing.
1
NIC1: Indicates network activity on LAN1 when flashing.
2
NIC2: Indicates network activity on LAN2 when flashing.
Overheat/Fan Fail: When this LED flashes, it indicates a fan failure. When
on continuously it indicates an overheat condition, which may be caused by cables
obstructing the airflow in the system or the ambient room temperature being too
warm. Check the routing of the cables and make sure all fans are present and
operating normally. You should also check to make sure that the chassis covers
are installed. Finally, verify that the heatsinks are installed properly (see Chapter
5). This LED will remain flashing or on as long as the indicated condition exists.
3-2
Chapter 3: System Interface
Power Fail: Indicates a power supply fan has failed. The LED will illumi-
nate and an alarm will sound to notify you of the situation. Both can be turned off
with the resset switch on the back of the power supply. Since the power supply
has redundant cooling fans, the backup fan will activate to cool the power supply.
However, if the backup fan fails the system will shut down as the power supply will
quickly oveheat. For this reason, it is recommended that you replace the power
supply soon after the primary fan fails.
3-4
SATA Drive Carrier LEDs
Each Serial ATA drive carrier has two LEDs.
Green: When illuminated, the green LED on the front of the SATA drive carrier indicates drive activity. A connection to the SATA backplane enables this LED
to blink on and off when that particular drive is being accessed.
Red: The red LED indicates two states. When blinking, it indicates the drive
is rebuilding. When solid, it indicates a drive failure. If a SATA drive fails, you
should be notified by your system management software. Please refer to Chapter
6 for instructions on replacing failed SATA drives.
3-3
SUPERSERVER 7045B-T User's Manual
Notes
3-4
Chapter 4: System Safety
Chapter 4
System Safety
4-1
Electrical Safety Precautions
!
Basic electrical safety precautions should be followed to protect yourself from
harm and the SuperServer 7045B-T from damage:
Be aware of the locations of the power on/off switch on the chassis as well as
the room's emergency power-off switch, disconnection switch or electrical
outlet. If an electrical accident occurs, you can then quickly remove power
from the system.
Do not work alone when working with high voltage components.
Power should always be disconnected from the system when removing or
installing main system components, such as the serverboard, memory
modules and the CD-ROM and floppy drives. When disconnecting power,
you should first power down the system with the operating system and then
unplug the power cords of all the power supply units in the system.
When working around exposed electrical circuits, another person who is
familiar with the power-off controls should be nearby to switch off the power
if necessary.
Use only one hand when working with powered-on electrical equipment. This
is to avoid making a complete circuit, which will cause electrical shock.
Use extreme caution when using metal tools, which can easily damage any
electrical components or circuit boards they come into contact with.
Do not use mats designed to decrease electrostatic discharge as protection
from electrical shock. Instead, use rubber mats that have been specifically
designed as electrical insulators.
4-1
SUPERSERVER 7045B-T User's Manual
The power supply power cord must include a grounding plug and must be
plugged into grounded electrical outlets.
Serverboard Battery: CAUTION - There is a danger of explosion if the onboard
battery is installed upside down, which will reverse its polarities (see Figure
4-1). This battery must be replaced only with the same or an equivalent type
recommended by the manufacturer. Dispose of used batteries according to
the manufacturer's instructions.
CD-ROM Laser: CAUTION - this server may have come equipped with a CDROM drive. To prevent direct exposure to the laser beam and hazardous
radiation exposure, do not open the enclosure or use the unit in any
unconventional way.
4-2
General Safety Precautions
!
Follow these rules to ensure general safety:
Keep the area around the SuperServer 7045B-T clean and free of clutter.
The 7045B-T weighs approximately 64 lbs (29.1 kg.) when fully loaded. When
lifting the system, two people at either end should lift slowly with their feet
spread out to distribute the weight. Always keep your back straight and lift
with your legs. Don't use the handles (if installed) to lift the chassis; the
handles should only be used to pull the server out of the rack.
Place the chassis top cover and any system components that have been
removed away from the system or on a table so that they won't accidentally
be stepped on.
While working on the system, do not wear loose clothing such as neckties and
unbuttoned shirt sleeves, which can come into contact with electrical circuits
or be pulled into a cooling fan.
Remove any jewelry or metal objects from your body, which are excellent metal
conductors that can create short circuits and harm you if they come into
contact with printed circuit boards or areas where power is present.
4-2
Chapter 4: System Safety
After accessing the inside of the system, close the system back up and secure
it to the rack unit with the retention screws after ensuring that all connections
have been made.
4-3
ESD Precautions
!
Electrostatic discharge (ESD) is generated by two objects with different electrical
charges coming into contact with each other. An electrical discharge is created to
neutralize this difference, which can damage electronic components and printed
circuit boards. The following measures are generally sufficient to neutralize this
difference before contact is made to protect your equipment from ESD:
Use a grounded wrist strap designed to prevent static discharge.
Keep all components and printed circuit boards (PCBs) in their antistatic
bags until ready for use.
Touch a grounded metal object before removing the board from the antistatic
bag.
Do not let components or PCBs come into contact with your clothing, which
may retain a charge even if you are wearing a wrist strap.
Handle a board by its edges only; do not touch its components, peripheral
chips, memory modules or contacts.
When handling chips or modules, avoid touching their pins.
Put the serverboard and peripherals back into their antistatic bags when
not in use.
For grounding purposes, make sure your computer chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.
4-3
SUPERSERVER 7045B-T User's Manual
4-4
Operating Precautions
!
Care must be taken to assure that the chassis cover is in place when the 7045B-T
is operating to assure proper cooling. Out of warranty damage to the 7045B-T
system can occur if this practice is not strictly followed.
Figure 4-1. Installing the Onboard Battery
LITHIUM BATTERY
LITHIUM BATTERY
OR
BATTERY HOLDER
BATTERY HOLDER
4-4
Chapter 5: Advanced Serverboard Setup
Chapter 5
Advanced Serverboard Setup
This chapter covers the steps required to install processors and heatsinks to
the X7DBE serverboard, connect the data and power cables and install add-on
cards. All serverboard jumpers and connections are described and a layout and
quick reference chart are included in this chapter. Remember to close the chassis completely when you have finished working on the serverboard to protect and
cool the system sufficiently.
5-1
Handling the Serverboard
Static electrical discharge can damage electronic components. To prevent damage to printed circuit boards, it is important to handle them very carefully (see
Chapter 4). Also note that the size and weight of the serverboard can cause
it to bend if handled improperly, which may result in damage. To prevent the
serverboard from bending, keep one hand under the center of the board to support it when handling. The following measures are generally sufficient to protect
your equipment from static discharge.
Precautions
•
Use a grounded wrist strap designed to prevent static discharge.
•
Touch a grounded metal object before removing any board from its antistatic
bag.
•
Handle a board by its edges only; do not touch its components, peripheral chips,
memory modules or gold contacts.
•
When handling chips or modules, avoid touching their pins.
•
Put the serverboard, add-on cards and peripherals back into their antistatic
bags when not in use.
Unpacking
The serverboard is shipped in antistatic packaging to avoid static damage. When
unpacking the board, make sure the person handling it is static protected.
5-1
SUPERSERVER 7045B-T User's Manual
5-2
Processor and Heatsink Installation
When handling the processor, avoid placing direct pressure on the label
!
area of the fan. Also, do not place the serverboard on a conductive
surface, which can damage the BIOS battery and prevent the system
from booting up.
IMPORTANT! Always connect the power cord last and remove it first before adding, removing or changing any hardware components. Make sure that you install
the processor into the CPU socket before you install the heatsink and fan. The
X7DBE can support either one or two dual-core Xeon processors 5300/5100/5000
series. If installing one processor only, install it into CPU socket #1.
Notes:
1. Intel's boxed Xeon CPU package contains a CPU fan and heatsink assembly. If
you buy a CPU separately, make sure that you use only Intel-certified multi-directional heatsinks and fans.
2. When purchasing a Xeon 5300/5100/5000 series processor or when receiving a
serverboard with one pre-installed, make sure that the CPU plastic cap is in place
and none of the CPU pins are bent; otherwise, contact the retailer immediately.
3. Check the Supermicro web site for details on board revisions needed to support
5300/5100 series CPUs.
Installing the Processor
1. A black PnP cap is attached to the
load plate to protect the CPU socket.
Press the load lever down and away
from the retention clasp to release the
load plate from its locked position.
Load lever
PnP cap
2. Gently lift the load lever to open the
load plate.
Load plate released
5-2
Chapter 5: Advanced Serverboard Setup
3. Use your thumb and your index
finger to hold the CPU at opposite
sides.
4. Align pin1 of the CPU (the corner
marked with a triangle) with the
notched corner of the CPU socket.
5. Find the corner of the CPU that
Gold dot
has a semi-circle cutout below a gold
Socket key
dot (CPU key). This corner should be
aligned with the cutout on the socket
(socket key).
CPU key
6. Once aligned, carefully lower the
CPU straight down into the socket.
Do not drop the CPU on the socket,
do not move the CPU horizontally
or vertically and do not rub the CPU
against any surface or any of the
contacts, which may damage the
CPU and/or contacts.
Notched corner
CPU pin 1
7. With the CPU in the socket, inspect
the four corners of the CPU to make
sure that it is properly installed.
Load lever
8. Use your thumb to gently push the
load lever down until it snaps into the
retention clasp.
CPU installed in socket
9. If the CPU is properly installed
into the socket, the PnP cap will be
automatically released from the load
plate when the lever locks. Remove
the cap. Repeat steps to install a
second CPU if desired.
Warning! Keep the plastic PnP cap.
The serverboard must be shipped
with the PnP cap properly installed
to protect the CPU socket. Shipment without the PnP cap properly
installed will void the warranty.
PnP cap released
from load plate
5-3
SUPERSERVER 7045B-T User's Manual
Installing the Heatsink
1. Do not apply any thermal grease
to the heatsink or the CPU die; the
CEK Passive Heatsink
required amount has already been
applied.
2. Place the heatsink on top of the CPU
so that the four mounting holes are
aligned with those on the (preinstalled)
heatsink retention mechanism.
3. Screw in two diagonal screws (i.e.
the #1 and the #2 screws) until just
snug. Do not fully tighten the screws
or you may damage the CPU.)
4. Add the two remaining screws then
finish the installation by fully tightening
all four screws.
Removing the Heatsink
Warning!
!
We do not recommend that the CPU or the heatsink be
removed. However, if you do need to uninstall the heatsink, please
follow the instructions below to prevent damage to the CPU or the
CPU socket.
1. Unscrew and remove the heatsink screws from the motherboard in the sequence as
show in the picture on the right.
2. Hold the heatsink as show in the picture on the right and gently wriggle the heatsink
to loosen it from the CPU. (Do not use excessive force when wriggling the heatsink!!)
3. Once the CPU is loosened, remove the heatsink from the CPU socket.
4. Clean the surface of the CPU and the heatsink to get rid of the old thermal grease.
Reapply the proper amount of thermal grease on the surface before you re-install the
CPU and the heatsink.
5-4
Chapter 5: Advanced Serverboard Setup
5-3
Connecting Cables
Now that the processors are installed, the next step is to connect the cables to
the serverboard. These include the data (ribbon) cables for the peripherals and
control panel and the power cables.
Connecting Data Cables
The ribbon cables used to transfer data from the peripheral devices have been
carefully routed in preconfigured systems to prevent them from blocking the flow
of cooling air that moves through the system from front to back. If you need to
disconnect any of these cables, you should take care to reroute them as they
were originally after reconnecting them (make sure the red wires connect to the
pin 1 locations). If you are configuring the system, keep the airflow in mind when
routing the cables. The following data cables (with their serverboard connector
locations noted) should be connected. See the serverboard layout diagram in this
chapter for connector locations.
Floppy Drive cable (J22)
Control Panel cable (JF1, see next page)
Serial ATA cables (SATA0 - SATA5)
Serial Enclosure Management LED cables (SGPIO1, SGPIO2)
Connecting Power Cables
The X7DBE has a 24-pin primary power supply connector designated "JPW1" for
connection to the ATX power supply. Connect the appropriate connector from the
power supply to JPW1 to supply power to the serverboard. See the Connector
Definitions section in this chapter for power connector pin definitions.
In addition, your power supply must be connected to the 4-pin Auxiliary ATX Power
connection at JPW2 and the 8-pin Processor Power connector at JPW3.
5-5
SUPERSERVER 7045B-T User's Manual
Connecting the Control Panel
JF1 contains header pins for various front control panel connectors. See Figure
5-1 for the pin locations of the various front control panel buttons and LED indicators. Please note that even and odd numbered pins are on opposite sides of
each header.
All JF1 wires have been bundled into single keyed ribbon cable to simplify their
connection. The red wire in the ribbon cable plugs into pin 1 of JF1. Connect
the other end of the cable to the Control Panel printed circuit board, located just
behind the system status LEDs in the chassis.
See the Connector Definitions section in this chapter for details and pin descriptions of JF1.
Figure 5-1. Front Control Panel Header Pins (JF1)
20
19
Ground
NMI
x (key)
x (key)
Power LED
Vcc
HDD LED
Vcc
NIC1
Vcc
NIC2
Vcc
OH/Fan Fail LED
Vcc
Power Fail LED
Vcc
Ground
Reset
Ground
Power
2
5-6
1
Chapter 5: Advanced Serverboard Setup
5-4
I/O Ports
The I/O ports are color coded in conformance with the PC 99 specification. See
Figure 5-2 below for the colors and locations of the various I/O ports.
Figure 5-2. Rear Panel I/O Ports
5-5
Installing Memory
Note: Check the Supermicro web site for recommended memory modules.
CAUTION
Exercise extreme care when installing or removing DIMMs to prevent any possible damage. Also note that the memory is interleaved
to improve performance (see step 1).
DIMM Installation (See Figure 5-5)
1. Insert the desired number of DIMMs into the memory slots, starting with DIMM
#1A and DIMM#2A. The memory scheme is interleaved so you must install two
modules at a time. See the table on the following page.
2. Insert each DIMM module vertically into its slot. Pay attention to the notch along
the bottom of the module to prevent inserting the DIMM module incorrectly.
3. Gently press down on the DIMM module until it snaps into place in the slot.
Repeat for all modules (see step 1 above).
5-7
SUPERSERVER 7045B-T User's Manual
Memory Support
The X7DBE supports up to 32 GB of ECC FBD (Fully Buffered DIMM) DDR2-667 or
ECC FBD DDR2-533 SDRAM. The memory is an interleaved configuration, which
requires modules of the same size and speed to be installed in pairs. You should
not mix DIMMs of different sizes and speeds. See Figure 5-3 for installing and
removing memory modules.
Note: Due to OS limitations, some operating systems may not show more than 4
GB of memory.
Figure 5-3a. Installing DIMM into Slot
To Install: Insert module vertically and press
down until it snaps into
place. Pay attention to
the bottom notch.
Notch
Notch
Release
Tab
Release
Tab
Note: Notches
should align
with their
receptive points
on the slot
To Remove: Use your
thumbs to gently push
each release tab outward
to free the DIMM from the
slot.
Figure 5-3b. Top View of DDR Slot
Optimized DIMM Population Configurations
Branch0
Branch1
Number of
DIMMs
2 DIMMs
4 DIMMs
6 DIMMs
8 DIMMs
Bank 1
(Channel 0)
1A
1A
1A
1A
----------1B
1B
Bank 2
(Channel 1)
2A
2A
2A
2A
----------2B
2B
Bank 3
(Channel 2)
-----3A
3A
3A
---------------3B
Bank 4
(Channel 3)
-----4A
4A
4A
---------------4B
(*Notes: i. DIMM slot# specified: DIMM slot to be populated; “---“: DIMM slot not to
be populated. ii. Both FBD 533 MHz and 667MHz DIMMs are supported; however,
you need to use the memory modules of the same speed and of the same type on a
motherboard. iii. Interleaved memory is supported when pairs of DIMM modules are
installed. To optimize memory performance, please install pairs of DIMMs in both
Branch 0 and Branch 1. iv. For memory to work properly, you need to follow the
restrictions listed above. )
5-8
Chapter 5: Advanced Serverboard Setup
Note: Due to memory allocation to system devices, memory remaining available
for operational use will be reduced when 4 GB of SDRAM is used. The reduction
in memory availability is disproportional. (Refer to the following Memory Availability
Table for details.
Possible System Memory Allocation & Availability
(with 4 GB total system memory)
System Device
Size
Physical Memory Remaining
(-Available)
Firmware Hub flash memory (System BIOS)
1 MB
3.99
Local APIC
4 KB
3.99
Area reserved for chipset
2 MB
3.99
I/O APIC (4 Kbytes)
4 KB
3.99
PCI Enumeration Area 1
256 MB
3.76
PCI Express (256 MB)
256 MB
3.51
PCI Enumeration Area 2 (if needed) Aligned on 256-MB boundary
512 MB
3.01
VGA Memory
16 MB
2.85
TSEG
1 MB
2.84
Memory available to OS and other applications
5-6
2.84
Adding PCI Cards
1. PCI Expansion Slots
The X7DBE has six PCI expansion slots, which includes two x8 PCI-Express slots,
one x4 PCI-Express slot, two PCI-X 133 MHz slots and one PCI-X 100 MHz slot.
The SC743TQ-650 chassis can accommodate up to six standard size PCI expansion cards. PCI cards are installed directly to the serverboard (riser cards are not
needed).
2. PCI Card Installation
Before installing a PCI add-on card, make sure you install it into a slot that supports
the speed of the card (see step 1, above). Begin by removing the screw from the
PCI slot shield that corresponds to the slot you wish to populate. Insert the expansion card into the correct slot on the serverboard, pushing down with your thumbs
evenly on both sides of the card. Finish by securing the card to the chassis with
the same screw you removed from the PCI slot shield. Follow this procedure when
adding a card to other slots.
5-9
SUPERSERVER 7045B-T User's Manual
5-7
Serverboard Details
Figure 5-4. SUPER X7DBE Layout
(not drawn to scale)
Kybd/
Mouse
BANK4
VGA
DIMM 4B
BANK3
Parallel
Port
CPU1/
FAN7
Speaker
DIMM 3B
BANK2
COM1
JPW2
DIMM 2B
BANK1
USB0/1
J17
JPW1
FAN6 FAN5
DIMM 1B
JAR
PSF
J3P
JPW3
FAN1
DIMM 4A
JF1
CPU 1
DIMM 3A
FAN2
DIMM 2A
JD1
DIMM 1A
LE1
JOH1
JLAN1
SGPIO2
SGPIO1
CPU 2
North
JLAN2
IDE#1
X7DBE
Bridge
JCF1
JWF1
IDE#2
South
Slot #5: x8 PCI Express
Floppy
JBT1
Battery
IDE #1
J22
Slot #6: x8 PCI Express
ATI
ES 1000
Compact Flash
Slot #7: LP IPMI
JPG1
FAN8
CPU1/FAN3
Bridge
Slot #4: x4 PCI Express
BIOS
JWD
SUPER
Slot #3: 133 MHz PCI-X
USB4
JPL1
JPL2
PXH
Slot #2: 133 MHz PCI-X
JWOL
JWOR
DA2
USB2/3
Slot #1: 100 MHz PCI-X (ZCR)
JK1
COM2
JL1 SATA4 SATA5
J18
SATA0 SATA1 SATA2 SATA3
DA1
FAN4
Notes:
Jumpers not noted are for test purposes only.
IDE#2 is for Compact Flash card use only. To use, close jumper JCF1 and connect the compact flash
power to JWF1.
5-10
Chapter 5: Advanced Serverboard Setup
X7DBE Quick Reference
Jumper
Description
Default Setting
J3P
3rd Power Fail Detect
Open (Disabled)
JBT1
CMOS Clear
(See Section 5-9)
JCF1
JPG1
Compact Flash Master/Slave Select
VGA Enable/Disable
Closed (Master)
Pins 1-2 (Enabled)
JPL1/ JPL2
JLAN1/JLAN2 Enable/Disable
Pins 1-2 (Enabled)
JWD
Watch Dog
Pins 1-2 (Reset)
Connector
Description
COM1/COM2
FAN 1-8
IDE#1
IDE#2*
J7
J17
COM1/COM2 Serial Port Connector/Header
Fan Headers 1-8
IDE Hard Drive Connector
Compact Flash Card Connector
BIOS Recovery
System Management (I2C) Power Header
J18
J22
JAR
JD1
JF1
JK1
JL1
JLAN1/2
JOH1
System Management Bus Header
Floppy Disk Drive Connector
Alarm Reset
Power LED (pins1-3)/Speaker Header (pins 4-7)
Front Control Panel Connector
Keylock Header
Chassis Intrusion Header
G-bit Ethernet Ports
Overheat LED
JPW1
Primary 24-Pin ATX Power Connector
JPW2
Auxiliary Power Connector
JPW3
Processor Power Connector
JWF1
Compact Flash Card Power Connector
JWOL
Wake-on-LAN Header
JWOR
Wake-on-Ring Header
LP IPMI (Slot 7)
Low Profile IPMI Connector
PSF
Power Supply Fail Header
Parallel
Parallel (Printer) Port
SATA0-SATA5
Intel Serial ATA Connectors
SGPIO1/SGPIO2
SGPIO Headers
USB0/1
USB Ports
USB2/3, USB4
USB Headers
*The IDE#2 slot is for use with a Compact Flash card only.
5-11
SUPERSERVER 7045B-T User's Manual
5-8
Connector Definitions
ATX Power 24-pin Connector
Pin Definitions (JPW1)
ATX Power Connector
Pin#
Definition
13
+3.3V
1
+3.3V
The primary ATX power supply con-
14
-12V
2
+3.3V
nector meets the SSI (Superset ATX)
15
COM
3
COM
24-pin specification. Make sure that
the orientation of the connector is
16
PS_ON
4
+5V
17
COM
5
COM
correct. See the table on the right for
18
COM
6
+5V
pin definitions.
19
COM
7
COM
20
Res (NC)
8
PWR_OK
21
+5V
9
5VSB
22
+5V
10
+12V
23
+5V
11
+12V
24
COM
12
+3.3V
Auxiliary Power Connector
In addition to the Primary ATX power
connector (above), the Auxiliary 4-pin
connector at JPW2 must also be connected to your power supply. See the
table on the right for pin definitions.
Pin #
Definition
+12V 4-pin Aux. Power
Pin Definitions (JPW2)
Pins
Definition
1&2
Ground
3&4
+12V
Processor Power Connector
Processor Power
Pin Definitions (JPW3)
JPW3 must also be connected to the
power supply to provide power for the
processor(s). See the table on the
right for pin definitions.
Pins
Definition
1 through 4
Ground
5 through 8
+12V
NMI Button
NMI Button
Pin Definitions (JF1)
The non-maskable interrupt button
header is located on pins 19 and 20
of JF1. Refer to the table on the right
for pin definitions.
Power LED
Pin#
Definition
19
Control
20
Ground
Power LED
Pin Definitions (JF1)
The Power LED connection is located
on pins 15 and 16 of JF1. Refer to the
table on the right for pin definitions.
5-12
Pin#
Definition
15
Vcc
16
Control
Chapter 5: Advanced Serverboard Setup
HDD LED
The HDD (IDE Hard Disk Drive) LED
connection is located on pins 13 and
14 of JF1. Attach the IDE hard drive
LED cable to display disk activity.
HDD LED
Pin Definitions (JF1)
Pin#
Definition
13
Vcc
14
HD Active
Refer to the table on the right for pin
definitions.
NIC1 LED
The NIC1 (Network Interface Controller) LED connection is located on pins
11 and 12 of JF1. Attach the NIC1
LED cable to display network activity.
Refer to the table on the right for pin
definitions.
NIC1 LED
Pin Definitions (JF1)
Pin#
Definition
11
Vcc
12
Ground
NIC2 LED
The NIC2 (Network Interface Controller) LED connection is located on pins
9 and 10 of JF1. Attach the NIC2
LED cable to display network activity.
Refer to the table on the right for pin
definitions.
NIC2 LED
Pin Definitions (JF1)
Pin#
Definition
9
Vcc
10
Ground
Overheat/Fan Fail LED (OH)
Connect an LED to the OH connection
on pins 7 and 8 of JF1 to provide advanced warning of chassis overheating or fan fail. Refer to the table on
the right for pin definitions.
OH/Fan Fail LED
Pin Definitions (JF1)
Pin#
Definition
7
Vcc
8
Ground
Power Fail LED
The Power Fail LED connection is
located on pins 5 and 6 of JF1. Refer to the table on the right for pin
definitions.
5-13
Power Fail LED
Pin Definitions (JF1)
Pin#
Definition
5
Vcc
6
Ground
SUPERSERVER 7045B-T User's Manual
Reset Button
Reset Button
Pin Definitions (JF1)
The Reset Button connection is located on pins 3 and 4 of JF1. Attach
Pin#
Definition
it to the hardware reset switch on the
computer case. Refer to the table on
3
Reset
4
Ground
the right for pin definitions.
Power Button
The Power Button connection is
located on pins 1 and 2 of JF1. Momentarily contacting both pins will
power on/off the system. This button
can also be configured to function
as a suspend button (see the Power
Button Mode setting in BIOS). To turn
off the power when set to suspend
mode, depress the button for at least
4 seconds. Refer to the table on the
right for pin definitions.
Power Button
Pin Definitions (JF1)
Universal Serial Bus
(USB0/1)
Pin#
Definition
1
PW_ON
2
Ground
Universal Serial Bus
Pin Definitions (USB0/1)
Two Universal Serial Bus ports are
located beside the PS/2 keyboard/
mouse ports. USB0 is the bottom
connector and USB1 is the top connector. See the table on the right for
pin definitions.
Chassis Intrusion
USB0
Pin #
Definition
USB1
Pin #
Definition
1
+5V
1
+5V
2
PO-
2
PO-
3
PO+
3
PO+
4
Ground
4
Ground
5
N/A
5
Key
Chassis Intrusion
Pin Definitions (JL1)
A Chassis Intrusion header is located
at JL1. Attach the appropriate cable
to inform you of a chassis intrusion.
5-14
Pin#
Definition
1
Intrusion Input
2
Ground
Chapter 5: Advanced Serverboard Setup
Serial Ports
Serial Port Pin Definitions
(COM1/COM2)
The COM1 serial port is located beside
Pin #
Definition
Pin #
Definition
the mouse port. COM2 is a header on
1
DCD
6
DSR
the serverboard (see serverboard
layout for location). See the table on
2
RXD
7
RTS
3
TXD
8
CTS
the right for pin definitions.
4
DTR
9
RI
5
Ground
10
NC
Note: Pin 10 is included on the header but not on
the port. NC indicates no connection.
Power Fail Header
Connect a cable from your power supply to the Power Fail header to provide
you with warning of a power supply
failure. The warning signal is passed
through the PWR_LED pin to indicate
a power failure. See the table on the
right for pin definitions.
Power Fail Header
Pin Definitions (PSF)
Pin#
Definition
1
P/S 1 Fail Signal
2
P/S 2 Fail Signal
3
P/S 3 Fail Signal
4
Alarm Reset
Note: This feature is only available when using
redundant Supermicro power supplies.
Fan Headers
The X7DBE has eight fan headers,
designated Fan1 through Fan8. Fan
speed is controlled via Thermal Management with a BIOS setting. See the
table on the right for pin definitions.
Note: Fans 5-8 are 4-pin fans. Pins
1-3 of the fan headers are backward
compatible with traditional 3-pin fans.
The onboard fan speed is controlled
by a BIOS setting. When using a
Thermal Management setting, use all
3-pin fans or all 4-pin fans (do not use
3-pin fans and 4-pin fans together).
5-15
Fan Header
Pin Definitions
(Fan1-8)
Pin#
Definition
1
Ground (Black)
2
+12V (Red)
3
Tachometer
4
PWM Control
SUPERSERVER 7045B-T User's Manual
Extra Universal Serial Bus
Headers
Front Panel Universal Serial Bus
Pin Definitions (JD2)
Three additional USB headers
(USB2/3 and USB4) are included on
the serverboard. These may be used
for front side access. A USB cable
(not included) is needed for the connection. See the table on the right for
pin definitions.
USB2
Pin #
Definition
USB3, USB4
Pin #
Definition
1
+5V
1
+5V
2
PO-
2
PO-
3
PO+
3
PO+
4
Ground
4
Ground
5
Key
5
NC
Power LED/Speaker
On the JDI header, pins 1-3 are for
a power LED, pins 4-7 are for the
speaker. See the table on the right
for speaker pin definitions. Note:
The speaker connector pins are for
use with an external speaker. If you
wish to use the onboard speaker, you
should close pins 6-7 with a jumper.
Speaker Connector
Pin Definitions (JD1)
Pin #
Function
Definition
4
+
Speaker data (red wire)
5
Key
No connection
6
Key
7
Speaker data
PS/2 Keyboard and
Mouse Ports
Pin Definitions
ATX PS/2 Keyboard and
PS/2 Mouse Ports
The ATX PS/2 keyboard and the PS/2
mouse ports are located beside the
USB ports. See the table on the right
for pin definitions.
Pin#
Definition
1
Data
2
NC
3
Ground
4
VCC
5
Clock
6
NC
Overheat LED
Connect an LED to the JOH1 header
to provide warning of a chassis overheating condition. See the table on the
right for pin definitions.
5-16
Overheat LED
Pin Definitions
(JOH1)
Pin#
Definition
1
+5V
2
OH Active
Chapter 5: Advanced Serverboard Setup
Wake-On-LAN
Wake-On-LAN
Pin Definitions
(JWOL)
The Wake-On-LAN header is designated JWOL. See the table on the
Pin#
Definition
1
+5V Standby
BIOS to use this feature. You must
2
Ground
also have a LAN card with a Wake-
3
Wake-up
right for pin definitions. You must
enable the LAN Wake-Up setting in
on-LAN connector and cable.
Wake-On-Ring
The Wake-On-Ring header is designated JWOR. This function allows
your computer to receive and "wakeup" by an incoming call to the modem
when in suspend state. See the table
on the right for pin definitions. You
must have a WOR card and cable to
use this feature.
Wake-On-Ring
Pin Definitions
(JWOR)
Pin#
Definition
1
Ground (Black)
2
Wake-up
SMB
SMB Header
Pin Definitions (J17)
The System Management Bus header
(for the PCI bus) designated J17 is
located near the battery. Connect the
appropriate cable here to utilize SMB
on your system. See the table on the
right for pin definitions.
Pin#
Definition
1
Data
2
Ground
3
Clock
4
No Connection
SMB Power (I2C)
Pin Definitions (J18)
2
SMB Power (I C)
The header at J18 is for I2C, which
may be used to monitor the status of
the power supply. See the table on the
right for pin definitions.
5-17
Pin#
Definition
1
Clock
2
SMB Data
3
N/A
4
N/A
5
N/A
SUPERSERVER 7045B-T User's Manual
SGPIO
The two headers labeled SGPIO1
and SGPIO2 are for SGPIO (Serial General Purpose Input/Output).
SGPIO provides a bus between the
SATA controller and the SATA drive
backplane to provide SATA enclosure
management functions. Connect the
appropriate cables from the backplane to the SGPIO1 and SGPIO2
headers to utilize SATA management
functions on your system.
JLAN1/2 (Ethernet Ports)
Two Ethernet ports (designated JLAN1
and JLAN2) are located beside the
VGA port on the I/O backplane. These
ports accept RJ45 type cables.
Alarm Reset (JAR)
The system will notify you in the event
of a power supply failure. This feature
assumes that Supermicro redundant
power supply units are installed in the
chassis. Connect a microswitch to the
JAR header to disable the power supply
fail alarm. Note: the 7045B-T has only
a single power supply so this header
is unused
Keylock
The keyboard lock connector is designated JK1. Utilizing this header allows
you to inhibit any actions made on the
keyboard, effectively "locking" it.
5-18
Alarm Reset
Pin Definitions (JAR)
Pin#
Definition
2
+5V
1
Ground
Chapter 5: Advanced Serverboard Setup
5-9
Jumper Settings
Explanation of
Jumpers
To modify the operation of the
serverboard, jumpers can be used to
3
2
1
3
2
1
Connector
Pins
choose between optional settings.
Jumpers create shorts between two
Jumper
pins to change the function of the
connector. Pin 1 is identified with
a square solder pad on the printed
Setting
circuit board. See the diagram at
right for an example of jumping pins
1 and 2. Refer to the serverboard
layout page for jumper locations.
Note: On two-pin jumpers, "Closed"
means the jumper is on and "Open"
means the jumper is off the pins.
CMOS Clear
JBT1 is used to clear CMOS and will also clear any passwords. Instead of pins,
this jumper consists of contact pads to prevent accidentally clearing the contents
of CMOS.
To clear CMOS,
1) First power down the system and unplug the power cord(s)
2) With the power disconnected, short the CMOS pads with a metal object such as
a small screwdriver
3) Remove the screwdriver (or shorting device)
4) Reconnect the power cord(s) and power on the system.
Note: Do not use the PW_ON connector to clear CMOS.
VGA Enable/Disable
JPG1 allows you to enable or disable
the VGA port. The default position is
on pins 1 and 2 to enable VGA. See
the table on the right for jumper settings.
5-19
VGA Enable/Disable
Jumper Settings (JPG1)
Jumper Setting
Definition
Pins 1-2
Enabled
Pins 2-3
Disabled
SUPERSERVER 7045B-T User's Manual
3rd Power Supply Fail Detect
Enable/Disable
3rd Power Supply Fail
Detect Enable/Disable
Jumper Settings (JP10)
The system can notify you in the event
Jumper Setting
of a power supply failure. This feature
Open
Disabled
Closed
Enabled
assumes that three power supply units
are installed in the chassis with one act-
Definition
ing as a backup. If you only have one
or two power supply units installed, you
should disable this (the default setting)
with JP13 to prevent false alarms. See
the table on right for pin definitions.
Note: JP10 should be disabled on the
7045B-T, which has only a single power supply.
Watch Dog Enable/Disable
JWD controls the Watch Dog function. Watch Dog is a system monitor
that can reboot the system when a
software application is “hung up”. Pins
1-2 will cause WD to reset the system
if an application is hung up. Pins 2-3
will generate a non-maskable interrupt
signal for the application that is hung
up. See the table on the right for jumper settings. Watch Dog must also be
enabled in BIOS.
Note: When enabled, the user needs
to write their own application software
to disable the Watch Dog Timer.
5-20
Watch Dog
Jumper Settings (JWD)
Jumper Setting
Definition
Pins 1-2
Reset
Pins 2-3
NMI
Open
Disabled
Chapter 5: Advanced Serverboard Setup
JLAN Enable/Disable
JLAN Enable/Disable
Jumper Settings (JPL1, JPL2)
Change the setting of jumper JPL1 or
Jumper Setting
JPL2 to enable or disable the onboard
Pins 1-2
Enabled
LAN ports JLAN1 and JLAN2, respectively. See the table on the right for
Pins 2-3
Disabled
Definition
jumper settings. The default setting
is enabled
Compact Flash Master/
Slave
Compact Flash
Master/Slave
Jumper Settings (JCF1)
The JCF1 jumper allows you to assign
either master or slave status to the
compact flash card. See the table on
the right for jumper settings.
Jumper Setting
Definition
Closed
Master
Open
Slave
5-10 Onboard Indicators
JLAN Right LED
(Connection Speed Indicator
JLAN1/JLAN2 LEDs
The Ethernet ports (located beside the
VGA port) have two LEDs. On each
Gigabit LAN port, the yellow (right)
LED indicates activity while the left
LED may be green, orange or off to
indicate the speed of the connection.
See the table on the right for the functions associated with the left (activity
speed) LED.
5-21
LED Color
Definition
Off
10 MHz
Green
100 MHz
Amber
1 GHz
SUPERSERVER 7045B-T User's Manual
5-11 Parallel Port, Floppy, IDE and SATA Drive
Connections
Note the following when connecting the floppy and hard disk drive cables:
•
The floppy disk drive cable has seven twisted wires.
•
A red mark on a wire typically designates the location of pin 1.
• A single floppy disk drive ribbon cable has 34 wires and two connectors to provide
for two floppy disk drives. The connector with twisted wires always connects to
drive A, and the connector that does not have twisted wires always connects to
drive B.
Parallel Port Connector
The parallel (printer) port is located
at J35. See the table below for pin
definitions.
Parallel (Printer) Port Connector
Pin Definitions (J35)
Pin#
Definition
1
Strobe-
2
Auto Feed-
3
Data Bit 0
4
Error-
5
Data Bit 1
6
Init-
7
Data Bit 2
8
SLCT IN-
9
Data Bit 3
10
GND
11
Data Bit 4
12
GND
13
Data Bit 5
14
GND
15
Data Bit 6
16
GND
17
Data Bit 7
18
GND
19
ACK
20
GND
21
BUSY
22
Write Data
23
PE
24
Write Gate
25
SLCT
26
NC
5-22
Pin #
Definition
Chapter 5: Advanced Serverboard Setup
Floppy Connector
The floppy connector is located on
J12.
See the table below for pin
definitions.
Floppy Drive Connector
Pin Definitions (J12)
Pin#
Definition
1
Ground
2
FDHDIN
3
Ground
4
Reserved
5
Key
6
FDEDIN
7
Ground
8
Index
9
Ground
10
Motor Enable
11
Ground
12
Drive Select B
13
Ground
14
Drive Select B
15
Ground
16
Motor Enable
17
Ground
18
DIR
19
Ground
20
STEP
21
Ground
22
Write Data
23
Ground
24
Write Gate
25
Ground
26
Track 00
27
Ground
28
Write Protect
29
Ground
30
Read Data
31
Ground
32
Side 1 Select
33
Ground
34
Diskette
5-23
Pin #
Definition
SUPERSERVER 7045B-T User's Manual
IDE Connectors
IDE Drive Connectors
Pin Definitions (J5, J6)
There are no jumpers to config-
Pin#
Definition
Pin #
Definition
ure the onboard IDE#1 and #2
1
Reset IDE
2
Ground
connectors. See the table on
the right for pin definitions.
3
Host Data 7
4
Host Data 8
5
Host Data 6
6
Host Data 9
7
Host Data 5
8
Host Data 10
9
Host Data 4
10
Host Data 11
11
Host Data 3
12
Host Data 12
13
Host Data 2
14
Host Data 13
15
Host Data 1
16
Host Data 14
17
Host Data 0
18
Host Data 15
19
Ground
20
Key
21
DRQ3
22
Ground
23
I/O Write
24
Ground
25
I/O Read
26
Ground
27
IOCHRDY
28
BALE
29
DACK3
30
Ground
31
IRQ14
32
IOCS16
33
Addr1
34
Ground
35
Addr0
36
Addr2
37
Chip Select 0
38
Chip Select 1
39
Activity
40
Ground
SATA Connector Pin Definitions
(SATA0 - SATA5)
SATA Ports
There are no jumpers to configure the onboard SATA connectors. See the table on the
right for pin definitions.
5-24
Pin #
Definition
1
Ground
2
TXP
3
TXN
4
Ground
5
RXN
6
RXP
7
Ground
Chapter 6: Advanced Chassis Setup
Chapter 6
Advanced Chassis Setup
This chapter covers the steps required to install components and perform simple
maintenance on the SC743TQ-650 chassis. Following the component installation
steps in the order given will eliminate most common problems. If some steps are
unnecessary, skip ahead to the step that follows. Refer to Chapter 2 for instructions
on installing the system as a 4U rackmount.
Tools Required
The only tool you will need is a Philips screwdriver.
6-1
Static-Sensitive Devices
Static electrical discharge can damage electronic components. To prevent damage
to any printed circuit boards (PCBs), it is important to handle them very carefully.
The following measures are generally sufficient to protect your equipment from
static discharge.
Precautions
•
Use a grounded wrist strap designed to prevent static discharge.
•
Touch a grounded metal object before removing any board from its antistatic
bag.
•
Handle a board by its edges only; do not touch its components, peripheral chips,
memory modules or gold contacts.
•
When handling chips or modules, avoid touching their pins.
•
Put the serverboard, add-on cards and peripherals back into their antistatic bags
when not in use.
•
For grounding purposes, make sure your computer chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.
Unpacking
The serverboard is shipped in antistatic packaging. When unpacking the board,
make sure the person handling it is static protected.
6-1
SUPERSERVER 7045B-T User's Manual
Figure 6-1. Chassis Front View
Main Power
System Reset
System LEDs
USB Ports
5.25" Drive Bays (2)
Floppy Drive
Six SATA Drive Bays (behind
locking bezel)
6-2
Chapter 6: Advanced Chassis Setup
6-2
Front Control Panel
The front control panel must be connected to the JF1 connector on the serverboard
to provide you with system status and alarm indications. A ribbon cable has bundled
these wires together to simplify this connection. Connect the cable from JF1 on the
serverboard (making sure the red wire plugs into pin 1) to the appropriate comnnector on the front control panel PCB (printed circuit board). Pull all excess cabling over
to the control panel side of the chassis. The LEDs on the control panel inform you
of system status - see Figure 6-2 for details. See Chapter 5 for details on JF1.
Figure 6-2. Front Control Panel LEDs
Indicates power is being supplied to the system.
Power
HDD
Indicates IDE device and hard drive activity. On the
SC743TQ-650, this LED indicates SATA drive activity
when flashing.
NIC1
1
Indicates network activity on JLAN1.
NIC2
2
Indicates network activity on JLAN2
Overheat/
Fan Fail
Power Fail
When this LED flashes, it indicates a fan failure. When
on continuously it indicates an overheat condition (see
Chapter 3 for details).
Indicates a power supply fan failure. An alarm will also
sound - both can be turned off with the reset switch on the
back of the power supply.
6-3
SUPERSERVER 7045B-T User's Manual
6-3
System Fans
Four 8-cm chassis cooling fans (located in the center of the chassis) provide cooling
airflow while two 8-cm exhaust fans expel hot air from the chassis. The chassis is
also fitted with an air shroud to concentrate the flow of cooling air over the areas
of highest generated heat. The fans should all be connected to headers on the
serverboard (see Chapter 5). The power supply module also has a cooling fan.
Fan Failure
Under normal operation, all four chassis fans, both exhaust fans and the power
supply fan run continuously. The four chassis fans and the two exhaust fans are
hot-swappable and can be replaced without powering down the system.
Replacing Fans
1. Identifying the failed fan
To locate and replace a failed chassis fan, begin by removing the top/left chassis
cover (see Chapter 2 for details on removing the cover).
2. Removing a hot-plug fan housing
Depress the locking tab on a chassis cooling fan and pull the unit straight out by
the handle (see Figure 6-3). The fan wiring for these fans has been designed to
detach automatically.
3. Installing a new system fan
Replace the failed fan with an identical one (Supermicro p/n FAN-0072). Install it
in (and then reassemble) the fan housing, then plug the housing back into its slot;
it should click into place when fully inserted. Check that the fan is working then
replace the top/left side chassis panel.
Removing the air shroud
Under most circumstances you will not need to remove the air shroud to perform
any service on the system. However, if you wish to temporarily remove it (the air
shroud sould always be in place when the system is operating), please follow this
procedure.
Begin by depressing the tabs at the front and rear of the shroud to unlock it, then
lift it up and out of the chassis (see Figure 6-4). To reinstall, simply position the
air shroud in its proper place and push it in until you hear it click.
6-4
Chapter 6: Advanced Chassis Setup
Figure 6-3. Removing a Chassis Fan
Figure 6-4. Removing the Air Shroud
6-5
SUPERSERVER 7045B-T User's Manual
6-4
Drive Bay Installation
SATA Drives
A total of six SATA drives may be housed in the SC743TQ-650 chassis. The drive
IDs are preconfigured as 0 through 5 in order from bottom to top (or from left to right
if rackmounted). A bezel covers the drive area but does not need to be removed
to access the drives; simply swing open the bezel. If you wish to remove the bezel
piece, push on the three tabs on the inside of the left lip of the front chassis cover.
Then slightly swing out the same (left) side of the cover - about ½ inch only. Remove by pushing on the open side of the cover to remove it from the chassis (do
not try to swing or pull it straight out after opening the left side).
!
Regardless of how many SATA hard drives are installed, all SATA
drive carriers must remain in the drive bays to promote proper
airflow.
1. Installing/removing hot-swap SATA drives
The six SATA drive carriers are all easily accessible at the front of the chassis.
These drives are hot-swappable, meaning they can be removed and installed without powering down the system. To remove a carrier, first open the front bezel then
push the release button located beside the drive LEDs. Swing the handle fully out
and then use it to pull the unit straight out.
Note: Your operating system must have RAID support to enable the hot-swap
capability of the SATA drives.
2. Mounting a SATA drive in a drive carrier
The SATA drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also work to promote proper airflow for the
system. For this reason, even carriers without drives must remain in the server. If
you need to add a new drive, insert the drive into the carrier with the printed circuit
board side facing down so that the mounting holes align with those in the carrier.
Secure the drive to the carrier with four screws (see Figure 6-6).
6-6
Chapter 6: Advanced Chassis Setup
Figure 6-5. Removing a Serial ATA Drive Carrier
Figure 6-6. Mounting a Serial ATA Drive in a Carrier
!
Important! Use extreme caution when working around the SATA
backplane. Do not touch the backplane with any metal objects
and make sure no ribbon cables touch the backplane or obstruct
the airflow holes.
6-7
SUPERSERVER 7045B-T User's Manual
Installing Components in the 5.25" Drive Bays
1. Drive bay configuration
The 7045B-T has two 5.25" drive bays. Components such as an extra floppy drive,
IDE hard drives or CD-ROM drives can be installed into these 5.25" drive bays.
2. Mounting components in the drive bays
First power down the system and then remove the top/left chassis cover to access
the drive components. With the cover off, remove the two or four screws that
secure the drive carrier to the chassis (one side only) then push the entire empty
drive carrier out from the back.
Adding a CD-ROM drive: remove the guide plates (one on each side) from the empty
drive carrier and screw them into both sides of the CD-ROM drive using the holes
provided. Then slide the CD-ROM into the bay and secure it to the chassis with
the drive carrier screws you first removed. Attach the power and data cables to the
drive. Replace the top/left chassis cover before restoring power to the system.
Adding an IDE or floppy drive: to add one of these drives, install it into one of the
removed empty drive carriers with the printed circuit board side toward the carrier
so that the drive's mounting holes align with those in the carrier. Secure the drive
to the carrier with four screws then slide the assembly into the bay and secure it to
the chassis with the drive carrier screws you first removed. Attach the power and
data cables to the drive. Replace the top/left chassis cover before restoring power
to the system.
Note: A red wire typically designates the location of pin 1. You should keep the
drive carriers inserted in any unused drive bays to reduce EMI and noise and to
facilitate the airflow inside the chassis.
6-8
Chapter 6: Advanced Chassis Setup
6-5
Power Supply
The SuperServer 7045B-T has a single 650 watt power supply. This power supply
has an auto-switching capability, which enables it to automatically sense and operate at a 100V or 240V input voltage.
Power Supply Failure
If the power supply unit fails, the system will shut down and you will need to replace
the power supply unit. Replace with the same model - SP650-RP (p/n PWS-0056),
which can be ordered directly from Supermicro (see Contact Information in the
Preface). As there is only one power supply unit in the 7045B-T, the server must
be powered down before removing and/or replacing the power supply for whatever
reason.
Replacing the Power Supply
1. Removing the power supply
First power down the server. Then, unplug the power cord from the power supply
module. Remove the screws that secure the module to the chassis then pull it
completely out.
2. Installing a new power supply
Replace the failed unit with another unit having the exact same part number (PWS0056). Gently but firmly push the new unit all the way into the open bay. Secure it
to the chassis using the screws you previously removed. Finish by replacing the
chassis left/top cover and then plugging the power cord back into the new module
you just added.
6-9
SUPERSERVER 7045B-T User's Manual
Notes
6-10
Chapter 7: BIOS
Chapter 7
BIOS
7-1
Introduction
This chapter describes the Phoenix BIOS™ Setup utility for the X7DBE. The
Phoenix ROM BIOS is stored in a flash chip and can be easily upgraded using a
floppy disk-based program.
Note: Due to periodic changes to the BIOS, some settings may have been added or
deleted and might not yet be recorded in this manual. Please refer to the Manual
Download area of the Supermicro web site <http://www.supermicro.com> for any
changes to the BIOS that may not be reflected in this manual.
System BIOS
The BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and
PS/2® compatible computers. The Phoenix BIOS flash chip stores the system
parameters, types of disk drives, video displays, etc. in the CMOS. The CMOS
memory requires very little electrical power. When the computer is turned off, a
backup battery provides power to the BIOS flash chip, enabling it to retain system
parameters. Each time the computer is powered on the computer is configured
with the values stored in the BIOS ROM by the system BIOS, which gains control
at boot up.
How To Change the Configuration Data
The CMOS information that determines the system parameters may be changed by
entering the BIOS Setup utility. This Setup utility can be accessed by pressing the
<Delete> key at the appropriate time during system boot. (See below.)
Starting the Setup Utility
Normally, the only visible POST (Power On Self Test) routine is the memory test. As
the memory is being tested, press the <Delete> key to enter the main menu of the
BIOS Setup utility. From the main menu, you can access the other setup screens,
such as the Security and Power menus. Beginning with Section 7-3, detailed descriptions are given for each parameter setting in the Setup utility.
!
Warning: Do not shut down or reset the system while updating
BIOS to prevent possible boot failure.
7-1
SUPERSERVER 7045B-T User's Manual
7-2
Running Setup
Default settings are in bold text unless otherwise noted.
The BIOS setup options described in this section are selected by choosing the appropriate text from the main BIOS Setup screen. All displayed text is described in
this section, although the screen display is often all you need to understand how
to set the options (see next page).
When you first power on the computer, the Phoenix BIOS™ is immediately activated.
While the BIOS is in control, the Setup program can be activated in one of two
ways:
1. By pressing <Delete> immediately after turning the system on, or
2. When the message shown below appears briefly at the bottom of the screen
during the POST (Power On Self-Test), press the <Delete> key to activate the
main Setup menu:
Press the <Delete> key to enter Setup
7-3
Main BIOS Setup
All main Setup options are described in this section. The main BIOS Setup screen
is displayed below.
Use the Up/Down arrow keys to move among the different settings in each menu.
Use the Left/Right arrow keys to change the options for each setting.
Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in
detail how to navigate through the menus.
Items that use submenus are indicated with the icon. With the item highlighted,
press the <Enter> key to access the submenu.
7-2
Chapter 7: BIOS
Main BIOS Setup Menu
Main Setup Features
System Time
To set the system date and time, key in the correct information in the appropriate
fields. Then press the <Enter> key to save the data.
System Date
Using the arrow keys, highlight the month, day and year fields, and enter the correct
data. Press the <Enter> key to save the data.
BIOS Date
This field displays the date when this version of BIOS was built.
Legacy Diskette A
This setting allows the user to set the type of floppy disk drive installed as diskette A.
The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB,
3.5 in and 2.88MB 3.5 in.
7-3
SUPERSERVER 7045B-T User's Manual
IDE Channel 0 Master/Slave, SATA Port0, SATA Port1, SATA Port2
and SATA Port3
These settings allow the user to set the parameters of IDE Channel 0 Master/
Slave, IDE Channel 1 Master/Slave, IDE Channel 2 Master, IDE Channel 3 Master
slots. Hit <Enter> to activate the following sub-menu screen for detailed options
of these items. Set the correct configurations accordingly. The items included in
the sub-menu are:
Type
Selects the type of IDE hard drive. The options are Auto, (which allows the BIOS
to automatically determine the hard drive's capacity, number of heads, etc.), a
number from 1-39 to select a predetermined type of hard drive, CDROM and
ATAPI Removable. The option "User" will allow the user to enter the parameters
of the HDD installed at this connection. The option "Auto" will allow the BIOS to
automatically configure the parameters of the HDD installed at the connection.
Choose the option 1-39 to select a predetermined HDD type. Select CDROM if a
CDROM drive is installed. Select ATAPI if a removable disk drive is installed.
7-4
Chapter 7: BIOS
CHS Format
The following items will be displayed by the BIOS:
TYPE: This item displays the type of CPU.
Cylinders: This item indicates the status of Cylinders.
Headers: This item indicates the number of headers.
Sectors: This item displays the number of sectors.
Maximum Capacity: This item displays the maximum storage capacity of the
system.
LBA Format
The following items will be displayed by the BIOS:
Total Sectors: This item displays the number of total sectors available in the
LBA Format.
Maximum Capacity: This item displays the maximum capacity in the LBA
Format.
Multi-Sector Transfer
This item allows the user to specify the number of sectors per block to be used
in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors, and 16
Sectors.
LBA Mode Control
This item determines whether the Phoenix BIOS will access the IDE Channel 0
Master Device via the LBA mode. The options are Enabled and Disabled.
32 Bit I/O
This option allows the user to enable or disable the function of 32-bit data transfer.
The options are Enabled and Disabled.
Transfer Mode
This option allows the user to set the transfer mode. The options are Standard,
Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.
Ultra DMA Mode
This option allows the user to select Ultra DMA Mode. The options are Disabled,
Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.
7-5
SUPERSERVER 7045B-T User's Manual
Parallel ATA
This setting allows the user to enable or disable the function of Parallel ATA. The
options are Disabled, Channel 0, Channel 1, and Both.
Serial ATA
This setting allows the user to enable or disable the function of Serial ATA. The
options are Disabled and Enabled.
Native Mode Operation
Select the native mode for ATA. The options are: Parallel ATA, Serial ATA, Both,
and Auto.
SATA Controller Mode
Select Compatible to allow the SATA and PATA drives to be automatically-detected
and be placed in the Legacy Mode by the BIOS. Select Enhanced to allow the SATA
and PATA drives to be to be automatically-detected and be placed in the Native
IDE Mode.
Note: The Enhanced mode is supported by the Windows 2000 OS or a later
version.
When the SATA Controller Mode is set to "Enhanced", the following items will
display:
Serial ATA (SATA) RAID Enable
Select Enable to enable Serial ATA RAID Functions. (*For the Windows OS
environment, use the RAID driver if this feature is set to Enabled. When this
item is set to Enabled, the item: "ICH RAID Code Base" will be available for you
to select Intel or Adaptec Host RAID Controller. If this item is set to Disabled,
the item: SATA AHCI Enable will be available. ) The options are Enabled and
Disabled.
SATA AHCI
Select Enable to enable the function of Serial ATA Advanced Host Interface.
(*Take caution when using this function. This feature is for advanced programmers
only.) The options are Enabled and Disabled.)
ICH RAID Code Base
Select Intel to enable Intel's ICH HostRAID Controller. Select Adaptec to use
Adaptec's HostRAID Driver. The options are Intel and Adaptec.
7-6
Chapter 7: BIOS
System Memory
This display informs you how much system memory is recognized as being present
in the system.
Extended Memory
This display informs you how much extended memory is recognized as being
present in the system.
7-4
Advanced Setup
Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow
keys. You should see the following display. The items with a triangle beside them
have sub menus that can be accessed by highlighting the item and pressing <Enter>.
Options for PIR settings are displayed by highlighting the setting option using the
arrow keys and pressing <Enter>. All Advanced BIOS Setup options are described
in this section.
7-7
SUPERSERVER 7045B-T User's Manual
Boot Features
Access the submenu to make changes to the following settings.
Quick Boot Mode
If enabled, this feature will speed up the POST (Power On Self Test) routine by
skipping certain tests after the computer is turned on. The settings are Enabled
and Disabled. If Disabled, the POST routine will run at normal speed.
Quiet Boot
This setting allows you to Enable or Disable the diagnostic screen during
boot-up.
ACPI Mode
Use the setting to determine if you want to employ ACPI (Advanced Configuration
and Power Interface) power management on your system. The options are
Yes and No.
Power Button Behavior
If set to Instant-Off, the system will power off immediately as soon as the user
hits the power button. If set to 4-sec., the system will power off when the user
presses the power button for 4 seconds or longer. The options are instant-off
and 4-sec override.
Resume On Modem Ring
Select On to “wake your system up” when an incoming call is received by
your modem. The options are On and Off.
Power Loss Control
This setting allows you to choose how the system will react when power returns
after an unexpected loss of power. The options are Stay Off, Power On, and
Last State.
Watch Dog
If enabled, this option will automatically reset the system if the system is not
active for more than 5 minutes. The options are Enabled and Disabled.
Summary Screen
This setting allows you to Enable or Disable the summary screen which displays
the system configuration during bootup.
7-8
Chapter 7: BIOS
Memory Cache
Cache System BIOS Area
This setting allows you to designate a reserve area in the system memory to be
used as a System BIOS buffer to allow the BIOS write (cache) its data into this
reserved memory area. Select "Write Protect" to enable this function, and this
area will be reserved for BIOS ROM access only. Select "Uncached" to disable this
function and make this area available for other devices.
Cache Video BIOS Area
This setting allows you to designate a reserve area in the system memory to be
used as a Video BIOS buffer to allow the BIOS write (cache) its data into this
reserved memory area. Select "Write Protect" to enable the function and this area
will be reserved for Video BIOS ROM access only. Select "Uncached" to disable
this function and make this area available for other devices.
Cache Base 0-512K
If enabled, this feature will allow the data stored in the base memory area: block
0-512K to be cached (written) into a buffer, a storage area in the Static DROM
(SDROM) or to be written into L1, L2 cache inside the CPU to speed up CPU
operations. Select "Uncached" to disable this function. Select "Write Through" to
allow data to be cached into the buffer and written into the system memory at
the same time. Select "Write Protect" to prevent data from being written into the
base memory area of Block 0-512K. Select "Write Back" to allow CPU to write data
back directly from the buffer without writing data to the System Memory for fast
CPU data processing and operation. The options are Uncached, Write Through,
Write Protect and Write Back.
Cache Base 512K-640K
If enabled, this feature will allow the data stored in the memory area: 512K-640K
to be cached (written) into a buffer, a storage area in the Static DROM (SDROM)
or written into L1, L2, L3 cache inside the CPU to speed up CPU operations .
Select "Uncached" to disable this function. Select "Write Through" to allow data
to be cached into the buffer and written into the system memory at the same
time. Select "Write Protect" to prevent data from being written into the base
memory area of Block 0-512K. Select "Write Back" to allow CPU to write data back
directly from the buffer without writing data to the System Memory for fast CPU
data processing and operation. The options are Uncached, Write Through, Write
Protect, and Write Back.
Cache Extended Memory
If enabled, this feature will allow the data stored in the extended memory area to
be cached (written) into a buffer, a storage area in the Static DROM (SDROM)
7-9
SUPERSERVER 7045B-T User's Manual
or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.
Select "Uncached" to disable this function. Select "Write Through" to allow data
to be cached into the buffer and written into the system memory at the same
time. Select "Write Protect" to prevent data from being written into the base
memory area of Block 0-512K. Select "Write Back" to allow CPU to write data back
directly from the buffer without writing data to the System Memory for fast CPU
data processing and operation. The options are Uncached, Write Through, Write
Protect, and Write Back.
Discrete MTRR Allocation
If enabled, MTRRs (-Memory Type Range Registers) are configured as distinct,
separate units and cannot be overlapped. If enabled, the user can achieve better
graphic effects when using a Linux graphic driver that requires the write-combining
configuration with 4GB or more memory. The options are Enabled and Disabled.
PCI Configuration
Access the submenu to make changes to the following settings for PCI devices.
Onboard GLAN1/Onboard GLAN2 (Gigabit- LAN) OPROM Configure
Enabling this option provides the capability to boot from GLAN. The options are
Disabled and Enabled.
Onboard SCSI OPROM Configure
Enabling this option provides the capitally to boot from SCSI HDD. The options
are Disabled and Enabled.
Reset Configuration Data
If set to Yes, this setting clears the Extended System Configuration Data- (ESCD)
area. The options are Yes and No.
Frequency for PCI-X#1, PCI-X#2, PCI-X#3
This option allows the user to change the bus frequency for the devices installed
in the slot indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X 66
MHz, PCI-X 100 MHz, and PCI-X 133 MHz.
Frequency for PCI-X#1 On Riser, Frequency for PCI-X#2-#3 On Riser
(Available when an Active Riser Card is present)
This option allows the user to change the bus frequency of the devices installed
in the slot indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X 66
MHz, PCI-X 100 MHz, and PCI-X 133 MHz.
7-10
Chapter 7: BIOS
Slot#1 PCI 100 MHz ZCR, Slot#2 PCI-X 133MHz, Slot#3 PCI-X 133MHz,
Slot#4 PCI-Exp x8, Slot#5 PCI-Exp x8, and Slot#6 PCI-Exp x4
Access the submenu for each of the settings above to make changes to the
following:
Option ROM Scan
When enabled, this setting will initialize the device expansion ROM. The options
are Enabled and Disabled.
Enable Master
This setting allows you to enable the selected device as the PCI bus master.
The options are Enabled and Disabled.
Latency Timer
This setting allows you to set the clock rate for Bus Master. A high-priority, highthroughout device may benefit from a greater clock rate. The options are Default,
0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix, Novell and
other Operating Systems, please select the option: other. If a drive fails after
the installation of a new software, you might want to change this setting and
try again. A different OS requires a different Bus Master clock rate.
Large Disk Access Mode
This setting determines how large hard drives are to be accessed. The options are
DOS or Other (for Unix, Novelle NetWare and other operating systems).
Advanced Chipset Control
Access the submenu to make changes to the following settings.
Warning: Take Caution when changing the Advanced settings. Incorrect
!
values entered may cause system malfunction. Also, a very high DRAM
frequency or incorrect DRAM timing may cause system instability. When
this occurs, revert to the default setting.
SERR Signal Condition
This setting specifies the ECC Error conditions that an SERR# is to be asserted.
The options are None, Single Bit, Multiple Bit, and Both.
4GB PCI Hole Granularity
This feature allows you to select the granularity of PCI hole for PCI slots. If MTRRs
are not enough, this option may be used to reduce MTRR occupation. The options
are: 256 MB, 512 MB, 1GB and 2GB.
7-11
SUPERSERVER 7045B-T User's Manual
Memory Branch Mode
This option allows the BIOS to enumerate Host Mode for Device 16, Function
1, Reg. 40h bit 16 and Reg. 58h [14]. The options are Interleave, Sequential,
Mirroring, and Single Channel 0.
Branch 0 Rank Sparing
Select enable to enable the sparing feature for Branch 0 Rank. The options are
Enabled and Disabled.
Branch 1 Rank Sparing
Select enable to enable the sparing feature for Branch 0 Rank. The options are
Enabled and Disabled.
Enhanced x8 Detection
Select Enabled to enable Enhanced x8 DRAM UC Error Detection . The options
are Disabled and Enabled.
Route Port 80h Cycles to
This feature allows the user to decide which bus to send debug information to. The
options are Disabled, PCI and LPC.
Clock Spectrum Feature
If Enabled, the BIOS will monitor the level of Electromagnetic Interference caused
by the components and will attempt to decrease the interference whenever needed.
The options are Enabled and Disabled.
Enabling Multi-Media Timer
Select Yes to activate a set of timers that are alternative to the traditional 8254
timers for the OS use. The options are Yes and No.
USB Function
Select Enabled to enable the function of USB devices specified. The settings are
Enabled and Disabled.
USB Device 29 F3 Only
Select Enabled to enable the function of USB device as specified. The settings
are Enabled and Disabled.
Legacy USB Support
This setting allows you to enable support for Legacy USB devices. The settings
are Enabled and Disabled.
7-12
Chapter 7: BIOS
Advanced Processor Options
Access the submenu to make changes to the following settings.
CPU Speed
This is a display that indicates the speed of the installed processor.
Hyper-threading (Available when supported by the CPU)
Set to Enabled to use the Hyper-Threading Technology, which will result in increased
CPU performance. The options are Disabled and Enabled.
Machine Checking (Available when supported by the CPU)
Set to Enabled to activate the function of Machine Checking and allow the CPU to
detect and report hardware (machine) errors via a set of model-specific registers
(MSRs). The options are Disabled and Enabled.
Thermal Management 2 (Available when supported by the CPU)
Set to Enabled to use Thermal Management 2 (TM2) which will lower CPU voltage
and frequency when the CPU temperature reaches a predefined overheat threshold.
Set to Disabled to use Thermal Manager 1 (TM1), allowing CPU clocking to be
regulated via CPU Internal Clock modulation when the CPU temperature reaches
the overheat threshold.
C1 Enhanced Mode (Available when supported by the CPU)
Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency to
prevent overheat. The options are Enabled and Disabled. (*Note: please refer
to Intel’s web site for detailed information.)
No Execute Mode Memory Protection (Available when supported by the
CPU and the OS)
Set to Enabled to enable Execute Disable Bit and allow the processor to classify
areas in memory where an application code can execute and where it cannot, and
thus preventing a worm or a virus from inserting and creating a flood of codes to
overwhelm the processor or damage the system during an attack.
Note: this feature is available when your OS and your CPU support the function of
Execute Disable Bit. The options are Disabled and Enabled. (For more information
regarding hardware/software support for this function, please refer to Intel's and
Microsoft's web sites.)
Adjacent Cache Line Prefetch (Available when supported by the CPU)
The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The
CPU fetches both cache lines for 128 bytes as comprised if Enabled. The options
are Disabled and Enabled.
7-13
SUPERSERVER 7045B-T User's Manual
Set Maximum Extended CPUID=3
Select Enabled to set the Maximum Extended CPUID value to 3. The options are
Enabled and Disabled.
Intel <R> Virtualization Technology
Select Enabled to use the feature of Virtualization Technology. The options are
Enabled and Disabled.
I/O Device Configuration
Access the submenu to make changes to the following settings.
KBC Clock Input
This setting allows you to select clock frequency for KBC. The options are 6MHz,
8MHz, 12MHz, and 16MHz.
Serial Port A
This setting allows you to assign control of serial port A. The options are Enabled
(user defined), Disabled, and Auto (BIOS or OS controlled).
Base I/O Address
This setting allows you to select the base I/O address for serial port A. The
options are 3F8, 2F8, 3E8, and 2E8.
Interrupt
This setting allows you to select the IRQ (interrupt request) for serial port A.
The options are IRQ3 and IRQ4.
Serial Port B
This setting allows you to assign control of serial port B. The options are Enabled
(user defined), Disabled, Auto (BIOS controlled) and OS Controlled.
Mode
This setting allows you to set the type of device that will be connected to serial
port B. The options are Normal and IR (for an infrared device).
Base I/O Address
This setting allows you to select the base I/O address for serial port B. The
options are 3F8, 2F8, 3E8 and 2E8.
Interrupt
This setting allows you to select the IRQ (interrupt request) for serial port B.
The options are IRQ3 and IRQ4.
7-14
Chapter 7: BIOS
Parallel Port
This setting allows you to assign control of the parallel port. The options are
Enabled (user defined), Disabled and Auto (BIOS-or OS- controlled).
Base I/O Address
Select the base I/O address for the parallel port. The options are 378, 278
and 3BC.
Interrupt
This setting allows you to select the IRQ (interrupt request) for the parallel port.
The options are IRQ5 and IRQ7.
Mode
This feature allows you to specify the parallel port mode. The options are Output
only, Bi-Directional, EPP and ECP.
DMA Channel
This item allows you to specify the DMA channel for the parallel port. The
options are DMA1 and DMA3.
Floppy Disk Controller
This setting allows you to assign control of the floppy disk controller. The options
are Enabled (user defined), Disabled, and Auto (BIOS or OS controlled).
Base I/O Address
This setting allows you to select the base I/O address for the Floppy port. The
options are Primary and Secondary.
7-15
SUPERSERVER 7045B-T User's Manual
DMI Event Logging
Access the submenu to make changes to the following settings.
Event Log Validity
This is a display to inform you of the event log validity. It is not a setting.
Event Log Capacity
This is a display to inform you of the event log capacity. It is not a setting.
View DMI Event Log
Highlight this item and press <Enter> to view the contents of the event log.
Event Logging
This setting allows you to Enable or Disable event logging.
ECC Event Logging
This setting allows you to Enable or Disable ECC event logging.
Mark DMI Events as Read
Highlight this item and press <Enter> to mark the DMI events as read.
Clear All DMI Event Logs
Select Yes and press <Enter> to clear all DMI event logs. The options are Yes
and No.
7-16
Chapter 7: BIOS
Console Redirection
Access the submenu to make changes to the following settings.
COM Port Address
This item allows you to specify to redirect the console to Onboard COM A or
Onboard COM B. This setting can also be Disabled.
BAUD Rate
This item allows you to select the BAUD rate for console redirection. The options
are 300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.
Console Type
This item allows you to choose from the available options to select the console
type for console redirection. The options are VT100, VT100,8bit, PC-ANSI, 7bit,
PC ANSI, VT100+, and VT-UTF8.
Flow Control
This item allows you to choose from the available options to select the flow control
for console redirection. The options are: None, XON/XOFF, and CTS/RTS.
Console Connection
This item allows you to choose select the console connection: either Direct or
Via Modem.
Continue CR after POST
Choose whether to continue with console redirection after the POST routine.
The options are On and Off.
7-17
SUPERSERVER 7045B-T User's Manual
Hardware Monitor Logic
CPU Temperature Threshold
This option allows the user to set a CPU temperature threshold that will activate
the alarm system when the CPU temperature reaches this pre-set temperature
threshold. The options are 70oC, 75oC, 80oC and 85oC.
Highlight this and hit <Enter> to see monitor data for the following items:
CPU1 Temperature: This item displays CPU1 Temperature.
CPU2 Temperature: This item displays CPU2 Temperature.
LM93 Temperature: This item displays LM93 Temperature.
Fan 1-FAN8: If the feature of Auto Fan Control is enabled, the BIOS will automatically
display the status of the fans indicated in this item.
Fan Speed Control Modes
This feature allows the user to decide how the system controls the speeds of the
onboard fans. The CPU temperature and the fan speed are correlative. When the
CPU on-die temperature increases, the fan speed will also increase, and vise versa.
If the option is set to “3-pin fan”, the fan speed is controlled by voltage. If the
option is set to “4-pin”, the fan speed will be controlled by Pulse Width Modulation
(PWM). Select “3-pin” if your chassis came with 3-pin fan headers. Select “4-pin” if
your chassis came with 4-pin fan headers. Select “Workstation” if your system is
used as a Workstation. Select “Server” if your system is used as a Server. Select
“Disable” to disable the fan speed control function to allow the onboard fans to
run at the full speed (12V) at all the time. The Options are: 1. Disable, 2. 3-pin
(Server), 3. 3-pin (Workstation), 4. 4-pin (Server) and 5. 4-pin (Workstation).
Voltage Monitoring
The following items will be monitored and displayed:
P12V_VR0
P12V_VR1
FSB VTT
PXH Vcore
ES2B Vcore
CPU1Vcore
CPU2Vcore
P3V3
7-18
Chapter 7: BIOS
7-5
Security
Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow
keys. You should see the following display. Security setting options are displayed
by highlighting the setting using the arrow keys and pressing <Enter>. All Security
BIOS settings are described in this section.
Supervisor Password Is:
This displays whether a supervisor password has been entered for the system.
Clear means such a password has not been used and Set means a supervisor
password has been entered for the system.
User Password Is:
This displays whether a user password has been entered for the system. Clear
means such a password has not been used and Set means a user password has
been entered for the system.
Set Supervisor Password
When the item "Set Supervisor Password" is highlighted, hit the <Enter> key. When
prompted, type the Supervisor's password in the dialogue box to set or to change
supervisor's password, which allows access to the BIOS.
7-19
SUPERSERVER 7045B-T User's Manual
Set User Password
When the item "Set User Password" is highlighted, hit the <Enter> key. When
prompted, type the user's password in the dialogue box to set or to change the
user's password, which allows access to the system at boot-up.
Password on Boot
This setting allows you to require a password to be entered when the system
boots up. The options are Enabled (password required) and Disabled (password
not required).
7-6
Boot
Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.
You should see the following display. Highlighting a setting with a + or - will expand
or collapse that entry. See details on how to change the order and specs of boot
devices in the Item Specific Help window. All Boot BIOS settings are described in
this section.
7-20
Chapter 7: BIOS
Boot Priority Order/Excluded from Boot Order.
Use the Up and Down Arrow Keys to select a device. Use a <+> key or a <-> key to
move the device up or down. Use the <f> key or the <r> key to specify the devices.
You can also use the keys indicated above to specify the priority of boot order of
a device or to move items from the category of "Excluded from Boot Order" to the
category of "Boot Priority Order" and vise versa. See details on how to change the
priority of boot order of devices in the "Item Specific Help" window.
7-7
Exit
Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys.
You should see the following display. All Exit BIOS settings are described in this
section.
7-21
SUPERSERVER 7045B-T User's Manual
Exit Saving Changes
Highlight this item and hit <Enter> to save any changes you made and to exit the
BIOS Setup utility.
Exit Discarding Changes
Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any
changes you may have made.
Load Setup Defaults
Highlight this item and hit <Enter> to load the default settings for all items in the
BIOS Setup. These are the safest settings to use.
Discard Changes
Highlight this item and hit <Enter> to discard (cancel) any changes you made.
You will remain in the Setup utility.
Save Changes
Highlight this item and hit <Enter> to save any changes you made. You will remain
in the Setup utility.
7-22
Appendix A: BIOS POST Messages
Appendix A
BIOS POST Messages
During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is
a list of such BIOS messages.
Failure Fixed Disk
Fixed disk is not working or not configured properly. Check to see if fixed disk is attached properly. Run Setup. Find out if the fixed-disk type is correctly identified.
Stuck key
Stuck key on keyboard.
Keyboard error
Keyboard not working.
Keyboard Controller Failed
Keyboard controller failed test. May require replacing keyboard controller.
Keyboard locked - Unlock key switch
Unlock the system to proceed.
Monitor type does not match CMOS - Run SETUP
Monitor type not correctly identified in Setup
Shadow Ram Failed at offset: nnnn
Shadow RAM failed at offset nnnn of the 64k block at which the error was detected.
System RAM Failed at offset: nnnn
System RAM failed at offset nnnn of in the 64k block at which the error was detected.
Extended RAM Failed at offset: nnnn
Extended memory not working or not configured properly at offset nnnn.
System battery is dead - Replace and run SETUP
The CMOS clock battery indicator shows the battery is dead. Replace the battery and
run Setup to reconfigure the system.
A-1
SUPERSERVER 7045B-T User's Manual
System CMOS checksum bad - Default configuration used
System CMOS has been corrupted or modified incorrectly, perhaps by an application
program that changes data stored in CMOS. The BIOS installed Default Setup Values.
If you do not want these values, enter Setup and enter your own values. If the error
persists, check the system battery or contact your dealer.
System timer error
The timer test failed. Requires repair of system board.
Real time clock error
Real-Time Clock fails BIOS hardware test. May require board repair.
Check date and time settings
BIOS found date or time out of range and reset the Real-Time Clock. May require
setting legal date (1991-2099).
Previous boot incomplete - Default configuration used
Previous POST did not complete successfully. POST loads default values and offers
to run Setup. If the failure was caused by incorrect values and they are not corrected,
the next boot will likely fail. On systems with control of wait states, improper Setup
settings can also terminate POST and cause this error on the next boot. Run Setup
and verify that the waitstate configuration is correct. This error is cleared the next
time the system is booted.
Memory Size found by POST differed from CMOS
Memory size found by POST differed from CMOS.
Diskette drive A error
Diskette drive B error
Drive A: or B: is present but fails the BIOS POST diskette tests. Check to see that
the drive is defined with the proper diskette type in Setup and that the diskette drive
is attached correctly.
Incorrect Drive A type - run SETUP
Type of floppy drive A: not correctly identified in Setup.
Incorrect Drive B type - run SETUP
Type of floppy drive B: not correctly identified in Setup.
A-2
Appendix A: BIOS POST Messages
System cache error - Cache disabled
RAM cache failed and BIOS disabled the cache. On older boards, check the cache
jumpers. You may have to replace the cache. See your dealer. A disabled cache slows
system performance considerably.
CPU ID:
CPU socket number for Multi-Processor error.
EISA CMOS not writeable
ServerBIOS2 test error: Cannot write to EISA CMOS.
DMA Test Failed
ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access)
registers.
Software NMI Failed
ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).
Fail-Safe Timer NMI Failed
ServerBIOS2 test error: Fail-Safe Timer takes too long.
device Address Conflict
Address conflict for specified device.
Allocation Error for: device
Run ISA or EISA Configuration Utility to resolve resource conflict for the specified
device.
CD ROM Drive
CD ROM Drive identified.
Entering SETUP ...
Starting Setup program
Failing Bits: nnnn
The hex number nnnn is a map of the bits at the RAM address which failed the memory
test. Each 1 (one) in the map indicates a failed bit. See errors 230, 231, or 232 above
for offset address of the failure in System, Extended, or Shadow memory.
Fixed Disk n
Fixed disk n (0-3) identified.
A-3
SUPERSERVER 7045B-T User's Manual
Invalid System Configuration Data
Problem with NVRAM (CMOS) data.
I/O device IRQ conflict
I/O device IRQ conflict error.
PS/2 Mouse Boot Summary Screen:
PS/2 Mouse installed.
nnnn kB Extended RAM Passed
Where nnnn is the amount of RAM in kilobytes successfully tested.
nnnn Cache SRAM Passed
Where nnnn is the amount of system cache in kilobytes successfully tested.
nnnn kB Shadow RAM Passed
Where nnnn is the amount of shadow RAM in kilobytes successfully tested.
nnnn kB System RAM Passed
Where nnnn is the amount of system RAM in kilobytes successfully tested.
One or more I2O Block Storage Devices were excluded from the Setup Boot
Menu
There was not enough room in the IPL table to display all installed I2O block-storage
devices.
Operating system not found
Operating system cannot be located on either drive A: or drive C:. Enter Setup and
see if fixed disk and drive A: are properly identified.
Parity Check 1 nnnn
Parity error found in the system bus. BIOS attempts to locate the address and display
it on the screen. If it cannot locate the address, it displays ????. Parity is a method
for checking errors in binary data. A parity error indicates that some data has been
corrupted.
Parity Check 2 nnnn
Parity error found in the I/O bus. BIOS attempts to locate the address and display it
on the screen. If it cannot locate the address, it displays ????.
A-4
Appendix A: BIOS POST Messages
Press <F1> to resume, <F2> to Setup, <F3> for previous
Displayed after any recoverable error message. Press <F1> to start the boot process
or <F2> to enter Setup and change the settings. Press <F3> to display the previous
screen (usually an initialization error of an Option ROM, i.e., an add-on card). Write
down and follow the information shown on the screen.
Press <F2> to enter Setup
Optional message displayed during POST. Can be turned off in Setup.
PS/2 Mouse:
PS/2 mouse identified.
Run the I2O Configuration Utility
One or more unclaimed block storage devices have the Configuration Request bit set
in the LCT. Run an I2O Configuration Utility (e.g. the SAC utility).
System BIOS shadowed
System BIOS copied to shadow RAM.
UMB upper limit segment address: nnnn
Displays the address nnnn of the upper limit of Upper Memory Blocks, indicating
released segments of the BIOS which can be reclaimed by a virtual memory manager.
Video BIOS shadowed
Video BIOS successfully copied to shadow RAM.
A-5
SUPERSERVER 7045B-T User's Manual
Notes
A-6
Appendix B: BIOS POST Codes
Appendix B
BIOS POST Codes
This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST
codes are divided into two categories: recoverable and terminal.
Recoverable POST Errors
When a recoverable type of error occurs during POST, BIOS will display a POST
code that describes the problem. BIOS may also issue one of the following beep
codes:
1 long and two short beeps - video configuration error
1 continuous long beep - no memory detected
Terminal POST Errors
If a terminal type of error occurs, BIOS will shut down the system. Before doing
so, BIOS will write the error to port 80h, attempt to initialize video and write the
error in the top left corner of the screen. The following is a list of codes that may
be written to port 80h.
POST Code Description
02h
03h
04h
06h
07h
08h
09h
0Ah
0Bh
0Ch
0Eh
0Fh
10h
11h
12h
13h
14h
16h
17h
Verify Real Mode
Disable Non-Maskable Interrupt (NMI)
Get CPU type
Initialize system hardware
Disable shadow and execute code from the ROM.
Initialize chipset with initial POST values
Set IN POST flag
Initialize CPU registers
Enable CPU cache
Initialize caches to initial POST values
Initialize I/O component
Initialize the local bus IDE
Initialize Power Management
Load alternate registers with initial POST values
Restore CPU control word during warm boot
Initialize PCI Bus Mastering devices
Initialize keyboard controller
1-2-2-3 BIOS ROM checksum
Initialize cache before memory Auto size
B-1
SUPERSERVER 7045B-T User's Manual
POST Code Description
18h
8254 timer initialization
1Ah
8237 DMA controller initialization
1Ch
20h
Reset Programmable Interrupt Controller
1-3-1-1 Test DRAM refresh
22h
1-3-1-3 Test 8742 Keyboard Controller
24h
Set ES segment register to 4 GB
28h
29h
Auto size DRAM
Initialize POST Memory Manager
2Ah
Clear 512 kB base RAM
2Ch
1-3-4-1 RAM failure on address line xxxx*
2Eh
1-3-4-3 RAM failure on data bits xxxx* of low byte of
memory bus
Enable cache before system BIOS shadow
Test CPU bus-clock frequency
Initialize Phoenix Dispatch Manager
Warm start shut down
Shadow system BIOS ROM
Auto size cache
Advanced configuration of chipset registers
Load alternate registers with CMOS values
Initialize extended memory for RomPilot
Initialize interrupt vectors
POST device initialization
2-1-2-3 Check ROM copyright notice
Initialize I20 support
Check video configuration against CMOS
Initialize PCI bus and devices
Initialize all video adapters in system
QuietBoot start (optional)
Shadow video BIOS ROM
Display BIOS copyright notice
Initialize MultiBoot
Display CPU type and speed
Initialize EISA board
Test keyboard
Set key click if enabled
Enable USB devices
2-2-3-1 Test for unexpected interrupts
Initialize POST display service
Display prompt “Press F2 to enter SETUP”
Disable CPU cache
2Fh
32h
33h
36h
38h
3Ah
3Ch
3Dh
41h
42h
45h
46h
47h
48h
49h
4Ah
4Bh
4Ch
4Eh
4Fh
50h
51h
52h
54h
55h
58h
59h
5Ah
5Bh
B-2
Appendix B: BIOS POST Codes
POST Code Description
5Ch
Test RAM between 512 and 640 kB
60h
Test extended memory
62h
64h
Test extended memory address lines
Jump to UserPatch1
66h
Configure advanced cache registers
67h
Initialize Multi Processor APIC
68h
69h
Enable external and CPU caches
Setup System Management Mode (SMM) area
6Ah
Display external L2 cache size
6Bh
Load custom defaults (optional)
6Ch
6Eh
70h
72h
76h
7Ch
7Dh
7Eh
80h
81h
82h
83h
84h
85h
86h
87h
Display shadow-area message
Display possible high address for UMB recovery
Display error messages
Check for configuration errors
Check for keyboard errors
Set up hardware interrupt vectors
Initialize Intelligent System Monitoring
Initialize coprocessor if present
Disable onboard Super I/O ports and IRQs
Late POST device initialization
Detect and install external RS232 ports
Configure non-MCD IDE controllers
Detect and install external parallel ports
Initialize PC-compatible PnP ISA devices
Re-initialize onboard I/O ports.
Configure Motherboard Configurable Devices
(optional)
Initialize BIOS Data Area
Enable Non-Maskable Interrupts (NMIs)
Initialize Extended BIOS Data Area
Test and initialize PS/2 mouse
Initialize floppy controller
Determine number of ATA drives (optional)
Initialize hard-disk controllers
Initialize local-bus hard-disk controllers
Jump to UserPatch2
Build MPTABLE for multi-processor boards
Install CD ROM for boot
Clear huge ES segment register
Fix up Multi Processor table
1-2 Search for option ROMs. One long, two short
beeps on checksum failure
88h
89h
8Ah
8Bh
8Ch
8Fh
90h
91h
92h
93h
95h
96h
97h
98h
B-3
SUPERSERVER 7045B-T User's Manual
POST Code Description
99h
Check for SMART Drive (optional)
9Ah
Shadow option ROMs
9Ch
9Dh
Set up Power Management
Initialize security engine (optional)
9Eh
Enable hardware interrupts
9Fh
Determine number of ATA and SCSI drives
A0h
A2h
Set time of day
Check key lock
A4h
Initialize typematic rate
A8h
Erase F2 prompt
AAh
ACh
AEh
B0h
B1h
B2h
B4h
B5h
B6h
B7h
B9h
BAh
BBh
BCh
BDh
BEh
BFh
C0h
C1h
C2h
C3h
C4h
C5h
C6h
C7h
C8h
C9h
CAh
CBh
Scan for F2 key stroke
Enter SETUP
Clear Boot flag
Check for errors
Inform RomPilot about the end of POST.
POST done - prepare to boot operating system
1 One short beep before boot
Terminate QuietBoot (optional)
Check password (optional)
Initialize ACPI BIOS
Prepare Boot
Initialize SMBIOS
Initialize PnP Option ROMs
Clear parity checkers
Display MultiBoot menu
Clear screen (optional)
Check virus and backup reminders
Try to boot with INT 19
Initialize POST Error Manager (PEM)
Initialize error logging
Initialize error display function
Initialize system error handler
PnPnd dual CMOS (optional)
Initialize note dock (optional)
Initialize note dock late
Force check (optional)
Extended checksum (optional)
Redirect Int 15h to enable remote keyboard
Redirect Int 13h to Memory Technologies
Devices such as ROM, RAM, PCMCIA, and
serial disk
Redirect Int 10h to enable remote serial video
CCh
B-4
Appendix B: BIOS POST Codes
POST Code Description
CDh
Re-map I/O and memory for PCMCIA
CEh
Initialize digitizer and display message
D2h
Unknown interrupt
The following are for the boot block in the Flash ROM
POST Code Description
E0h
Initialize the chipset
E1h
Initialize the bridge
E2h
E3h
Initialize the CPU
Initialize system timer
E4h
E5h
E6h
E7h
E8h
E9h
EAh
EBh
ECh
EDh
EEh
EFh
F0h
F1h
F2h
F3h
F4h
F5h
F6h
F7h
Initialize system I/O
Check force recovery boot
Checksum BIOS ROM
Go to BIOS
Set Huge Segment
Initialize Multi Processor
Initialize OEM special code
Initialize PIC and DMA
Initialize Memory type
Initialize Memory size
Shadow Boot Block
System memory test
Initialize interrupt vectors
Initialize Run Time Clock
Initialize video
Initialize System Management Manager
Output one beep
Clear Huge Segment
Boot to Mini DOS
Boot to Full DOS
If the BIOS detects error 2C, 2E, or 30 (base 512K RAM error), it displays an additional
word-bitmap (xxxx) indicating the address line or bits that failed. For example, “2C
0002” means address line 1 (bit one set) has failed. “2E 1020" means data bits 12
and 5 (bits 12 and 5 set) have failed in the lower 16 bits. The BIOS also sends the
bitmap to the port-80 LED display. It first displays the checkpoint code, followed by
a delay, the high-order byte, another delay, and then the loworder byte of the error.
It repeats this sequence continuously.
B-5
SUPERSERVER 7045B-T User's Manual
Notes
B-6
Appendix C: Software Installation
Appendix C
Software Installation
After all the hardware has been installed, you must first configure Intel's ESB2
SATA RAID* before you install the Windows Operating System and other software
drivers.
Important Notes to the User:
If you do not wish to configure onboard SATA RAID functions, you may proceed
to Section C-3.
This chapter describes RAID Configuration Instructions for the Intel ESB2 RAID
Controller designed for the Windows OS.
C-1 Introduction to Serial ATA and Parallel ATA
To configure the SATA RAID functions, you must first use the Intel ESB2 SATA
RAID Utility program to configure the RAID Level that you desire before installing
the Windows XP/2000/2003 operating system and other software drivers. (The
necessary drivers are all included on the Supermicro CD that came packaged with
your motherboard.) Note that the current version of the ESB2 SATA RAID Utility
can only support Windows XP/2000/2003 Operating Systems.
Serial ATA (SATA)
Serial ATA (SATA) is a physical storage interface that uses a single cable with a
minimum of four wires to create a point-to-point connection between devices. It is
a serial link, which supports transfer rates up to 3Gbps. Because the serial cables
used in SATA are thinner than the traditional cables used in Parallel ATA (PATA),
SATA systems have better airflow and can be installed in smaller chassis than
Parallel ATA. In addition, the cables used in PATA are limited to a length of 40cm,
while Serial ATA cables can be up to one meter in length. Overall, SATA provides
better functionality than PATA.
Introduction to Intel ESB2 Serial RAID
Located in the South Bridge of the Blackford Mukilteo chipset, the I/O Controller
Hub (ESB2) provides the I/O subsystem with access to the rest of the system. It
supports an 1-channel UltraATA/100 Bus Master IDE controller (PATA) and six Serial ATA (SATA) ports. The ESB2 supports the following PATA and SATA device
configurations: Legacy mode and Native mode.
C-1
SUPERSERVER 7045B-T User's Manual
RAID Configurations
The following types of RAID configurations are supported:
RAID 0 (Data Striping): this writes data in parallel, interleaved ("striped") sections
of two hard drives. Data transfer rate is doubled over using a single disk.
RAID1 (Data Mirroring): an identical data image from one drive is copied to another
drive. The second drive must be the same size or larger than the first drive.
RAID 10 (Striping & Mirroring): RAID 0 and 1 schemes are combined (without parity
information) to get the benefits of both.
RAID 5: both data and parity information are striped and mirrored across three or
more hard drives.
Intel Matrix Storage
The Intel Matrix Storage, supported by the ESB2, allows the user to create RAID
0, RAID 1, RAID 10 and RAID 5 sets by using only six identical hard disk drives.
The Intel Matrix Storage Technology creates two partitions on each hard disk
drive and generate a virtual RAID 0, RAID 1, RAID 10 and RAID 5 sets. It also
allows you the change the HDD partition size without any data.
Configuring BIOS settings for SATA RAID Functions (Native Mode)
1. Press the <Del> key during system bootup to enter the BIOS Setup Utility.
Note: If it is the first time powering on the system, we recommend you load the
Optimized Default Settings. If you have already done so, please skip to Step 3.
2. Use the arrow keys to select the "Exit" Settings. Once in the "Exit" settings,
Scroll down to select "Load Optimized Default Settings" and press the <Enter>
key. Select "OK" to confirm the selection. Press the <Enter> key to load the default
settings for the BIOS.
3. Use the arrow keys to select the "Main" section in BIOS.
4. Scroll down to "SATA Control Mode" and press the <Enter> key to select "Enhanced"
5. Scroll down to "SATA RAID Enabled" and press <Enter>. Then, select "Enabled."
6. Scroll down to "Exit". Select "Save and Exit" from the "Exit" menu. Press the
<Enter> key to save the changes and exit the BIOS.
7. Once you've exited the BIOS Utility, the system will re-boot.
8. During the system boot-up, press the <Ctrl> and <I> keys simultaneously to run
the Intel RAID Configuration Utility when prompted by the following message: Press
<Ctrl> <I> for Intel RAID Configuration Utility.
C-2
Appendix C: Software Installation
Using the Intel ESB2 SATA RAID Utility Program
1. Creating, Deleting and Resetting RAID Volumes:
a. After the system exits from the BIOS Setup Utility, the system will automatically
reboot. The following screen appears after Power-On Self Test.
b. When you see the above screen, press the <Ctrl> and the <I> keys simultaneously to have the main menu of the SATA RAID Utility appear:
Note: All graphics and screen shots shown in the manual are for reference only. The
screen shots shown in the manual do not imply Supernicro's endorsement or nonendorsement on any 3rd party's product. Your screens may or many not look exactly
the same as the graphics shown in this manual.
C-3
SUPERSERVER 7045B-T User's Manual
Creating a RAID 0 Volume
1. Select "Create RAID Volume" from the main menu and press the <Enter> key.
The following screen will appear:
2. Specify a name for the RAID 0 set and press the <Tab> key or the <Enter> key
to go to the next field. (You can use the <Esc> key to select the previous menu.)
3. When RAID Level item is highlighted, press the <Up Arrow>, <Down Arrow> keys
to select RAID 0 (Stripe) and hit <Enter>.
4. When the Disks item is highlighted, press <Enter> to select the HDD to configure
as RAID. The following pop-up screen (*See Note on Page C-3) displays:
5. Use the <Up Arrow>, <Down Arrow> keys to highlight a drive and press <Space>
to select it. A triangle appears to confirm the selection of the drive.
6. Use the <Up Arrow>, <Down Arrow> keys to select the stripe size, ranged from
4 KB to 128 KB for the RAID 0 array, and hit <Enter>. (*Note: For a server, please
use a lower stripe size, and for a multimedia system, use a higher stripe size. The
default stripe size is 128 KB.)
7. Press <Enter> when the Create Volume item is highlighted. A warning message
displays.
8. When asked "Are you sure you want to create this volume (Y/N), press "Y" to
create the RAID volume, or type "N" to go back to the Create Volume menu.
C-4
Appendix C: Software Installation
Creating a RAID 1 Volume
1. Select "Create RAID Volume" from the main menu and press the <Enter> key.
The following screen will appear:
2. Specify a name for the RAID 1 set and press the <Tab> key or the <Enter> key
to go to the next field. (You can use the <Esc> key to select the previous menu.)
3. When RAID Level item is highlighted, press the <Up Arrow>, <Down Arrow> keys
to select RAID 1 (Mirror) and hit <Enter>.
4. When the Capacity item is highlighted, enter your RAID volume capacity and hit
<Enter>. The default setting is the maximum capacity allowed.
5. Press <Enter> when the Create Volume item is highlighted. A warning message
displays.
6. When asked "Are you sure you want to create this volume (Y/N), press "Y" to
create the RAID volume, or type "N" to go back to the Create Volume menu.
C-5
SUPERSERVER 7045B-T User's Manual
Creating a RAID 10 (RAID 1+ RAID 0)
1. Select "Create RAID Volume" from the main menu and press the <Enter> key.
The following screen will appear:
2. Specify a name for the RAID 10 set and press <Enter>.
3. When RAID Level item is highlighted, use the <Up Arrow>, <Down Arrow> keys
to select RAID 10 (RAID1 + RAID0) and hit <Enter>.
4. When the Stripe Size is highlighted, use the <Up Arrow>, <Down Arrow> keys to
select the stripe size from 4 KB to 128 KB for your RAID 10 and hit <Enter>. The
default setting is 6 4KB. (*Note: For a server, please use a lower stripe size, and
for a multimedia system, use a higher stripe size.)
5. When the RAID Volume Capacity item is highlighted, enter your RAID volume
capacity and hit <Enter>. The default setting is the maximum capacity allowed.
6. Press <Enter> when the Create Volume item is highlighted. A warning message
displays.
7. When asked "Are you sure you want to create this volume (Y/N), press "Y" to
create the RAID volume, or type "N" to go back to the Create Volume menu.
C-6
Appendix C: Software Installation
Creating a RAID 5 Set (Parity)
1. Select "Create RAID Volume" from the main menu and press the <Enter> key.
The following screen will appear:
2. Specify a name for the RAID 5 set and press <Enter>.
3. When the Raid Level is highlighted, use the <Up Arrow>, <Down Arrow> keys to
select RAID 5 (Parity) and hit <Enter>.
4. When the Disk item is highlighted, press <Enter> to select the HDD to configure
as RAID. The following pop-up screen (*See Note on Page C-3) displays:
5. Use the <Up Arrow>, <Down Arrow> keys to highlight a drive and press <Space>
to select it. A triangle appears to confirm the selection of the drive.
6. Use the <Up Arrow>, <Down Arrow> keys to select the stripe size, ranged from
4 KB to 128 KB for the RAID 5 array, and hit <Enter>. (*Note: For a server, please
use a lower stripe size, and for a multimedia system, use a higher stripe size. The
default stripe size is 128 KB.)
7. Enter your desired RAID volume capacity and press <Enter> when the capacity
item is highlighted. The default setting is the maximum capacity allowed.
8. Press Enter when the Create Volume item is highlighted. A warning message
displays.
9. When asked "Are you sure you want to create this volume (Y/N), press "Y" to
create the RAID volume, or type "N" to go back to the Create Volume menu.
C-7
SUPERSERVER 7045B-T User's Manual
Deleting a RAID Volume
!
Warning: Be sure to back up your data before deleting a RAID set. You will lose
all data on the disk drives when deleting a RAID set.
1. From the main menu, select item2-Delete RAID Volume, and press <Enter>.
2. Use the <Up Arrow>, <Down Arrow> keys to select the RAID set you want to
delete and press <Del>. A Warning message displays.
3. When asked "Are you sure you want to delete this volume (Y/N), press "Y" to
delete the RAID volume, or type "N" to go back to the Delete Volume menu.
C-8
Appendix C: Software Installation
Resetting to Non-RAID and Resetting a RAID HDD
Warning: Be cautious when you reset a RAID volume HDD to non-
!
RAID or Resetting a RAID HDD. Resetting a RAID volume HDD or
Resetting a RAID HDD will reformat the HDD and delete the internal
RAID structure on the drive.
1. From the main menu, select item3-Reset Disks to Non- RAID, and press <Enter>.
The following screen will appear:
2. Use the <Up Arrow>, <Down Arrow> keys to highlight the RAID set drive to reset
and press <Space> to select.
3. Press <Enter> to reset the RAID set drive. A Warning message displays.
4. Press "Y" to reset the drive, or type "N" to go back to the main menu.
Exiting the Intel Matrix Storage Manager Utility
1. From the main menu, select item4-Exit, and press <Enter>. A warning message
will appear.
2. Press "Y" to reset the drive, or type "N" to go back to the main menu.
C-9
SUPERSERVER 7045B-T User's Manual
C-2 Installing Windows XP/2000/2003 on RAID Systems
New Operating System: Windows XP/2000/2003 Installation
1. Insert the Microsoft Windows XP/2000/2003 Setup CD in the CD drive, and the
system will start booting up from the CD.
2. Press the <F6> key when the message-" Press F6 if you need to install a third
party SCSI or RAID driver" displays.
3. When the Windows XP/2000/2003 Setup screen appears, press "S" to specify
additional device(s).
4. Insert the driver diskette-"Intel AA RAID XP/2000/2003 Driver for ESB2 into Drive
A: and press the <Enter> key.
5. Choose Intel(R) ESB2 SATA RAID Controller from the list indicated in the
XP/2000/2003 Setup Screen and press the <Enter> key.
6. Press the <Enter> key to continue the installation process. (If you need to specify
any additional devices to be installed, do it at this time.) Once all devices have
been specified, press the <Enter> key to continue with the installation.
7. From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The
XP/2000/2003 Setup will automatically load all device files and then continue with
the installation.
8. After the Windows XP/2000/2003 installation is completed, the system will automatically reboot.
9. Insert the Supermicro CD that came with the package into the CD drive during
system reboot, and the following screen will appear (next page):
Note: the current version of the ESB2 SATA RAID Utility can only support Windows
XP/2000/2003 Operating System.
C-10
Appendix C: Software Installation
C-3 Installing the Operating System and other Software
After all the hardware has been installed, you must first install the operating system
and then other software drivers. The necessary drivers are all included on the
Supermicro CDs that came packaged with your motherboard.
Driver/Tool Installation Display Screen
Note: Click the icons showing a hand writing on paper to view the readme files
for each item. Click the computer icons to the right of these items to install each
item (from top to the bottom) one at a time. After installing each item, you must
re-boot the system before moving on to the next item on the list. You should
install everything here except for the SUPER Doctor utility and the LAN/SCSI driver
diskettes, which are optional. The bottom icon with a CD on it allows you to view
the entire contents of the CD.
C-11
SUPERSERVER 7045B-T User's Manual
Supero Doctor III
The Supero Doctor III program is a Web base management tool that supports remote
management capability. It includes Remote and Local Management tools. The local
management is called SD III Client. The Supero Doctor III program included on the
CDROM that came with your motherboard allows you to monitor the environment
and operations of your system. Supero Doctor III displays crucial system information
such as CPU temperature, system voltages and fan status. See the Figure below
for a display of the Supero Doctor III interface.
Note: The default User Name/Password for SuperDoctor III is ADMIN / ADMIN.
Supero Doctor III: Health Information Screen
C-12
Appendix C: Software Installation
Supero Doctor III: Remote Control Screen
Note: SD III Software Revision 1.0 can be downloaded from our Web Site at: ftp://
ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's
Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf. For
Linux, we will still recommend Supero Doctor II.
C-13
SUPERSERVER 7045B-T User's Manual
Notes
C-14
Appendix D: System Specifications
Appendix D
System Specifications
Processors
Single or dual Intel® dual-core Xeon™ dual-core processors 5300/5100/5000
series
.
Note: Please refer to our web site for a complete listing of supported processors.
Chipset
Intel 5000P/ESB2 chipset
BIOS
8 Mb Phoenix® Flash ROM
Memory Capacity
Eight 240-pin DIMM sockets supporting up to 32 GB of DDR2-533 FBD or
DDR2-667 FBD SDRAM
Note: Dual channel memory - requires memory to be installed two modules at a time. See the
memory section in Chapter 5 for details.
Serial ATA Controller
• Intel ESB2 on-chip controller for 6-port Serial ATA (RAID 0, 1 10 and 5
supported)
Serial ATA Drive Bays
Six (6) hot-swap drive bays to house six (6) standard SATA drives
Peripheral Drive Bays
One (1) 3.5" floppy drive
Two (2) 5.25" drive bays
D-1
SUPERSERVER 7045B-T User's Manual
Expansion Slots
Two x8 PCI-Express slots, one x4 PCI-Express slot, two PCI-X 133 MHz slots
and one PCI-X 100 MHz slot
Serverboard
X7DBE (Extended ATX form factor)
Dimensions: 12 x 13 in (305 x 330 mm)
Chassis
SC743TQ-650 Form Factor: tower/4U rackmount
Dimensions (as tower): (WxHxD) 7 x 17.1 x 25.5 in. (178 x 434 x 648 mm)
Weight
Gross (Bare Bone): 64 lbs. (29.1 kg.)
System Cooling
Four (4) 8-cm system cooling fans
Two (2) 8-cm rear exhaust fans
One (1) air shroud for tower/4U chassis
System Input Requirements
AC Input Voltage: 100-240V AC auto-range
Rated Input Current: 100 (11A) - 240V (5A)
Rated Input Frequency: 50 to 60 Hz
PFC Power Supply
Rated Output Power: 650W (Model# SP650-RP, Part# PWS-0056)
Rated Output Voltages: +3.3V (30A), +5V (30A), +12V (46A), +5Vsb (4A),
-12V (0.6A)
BTU Rating
3431 BTUs/hr (for rated output power of 650W)
Operating Environment
Operating Temperature: 10º to 35º C (50º to 95º F)
Non-operating Temperature: -40º to 70º C (-40º to 158º F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5 to 95% (non-condensing)
D-2
Appendix D: System Specifications
Regulatory Compliance
Electromagnetic Emissions:
FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A
Electromagnetic Immunity:
EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)
Safety:
EN 60950/IEC 60950-Compliant, UL Listed (USA), CUL Listed (Canada), TUV
Certified (Germany), CE Marking (Europe)
D-3
SUPERSERVER 7045B-T User's Manual
Notes
D-4
