Model# TM-BT003S-2016C
Rugged Waterproof Bluetooth Speaker
User Manual
WHAT’S IN THE BOX ?
X1
X1
2
X1
X1
CONTROLS
Press and hold turns Corbett I S ON/OFF.
Corbett I S turns itself off after 20min inactive.
Decrease or Increase Volume
Skip to Previous or Next song
Single Press:Toggle among four Modes
Press and Hold: Seeking Stereo Pair
Play/Pause: Play or pause audio being played.
Phone: Pick up or hang up when calls coming in.
: Press and hold to exit Stereo Mode.
3
CONNECTION
Available Devices
TimoLabs Corbett I S
4
TIMOLABS STEREO MODE
Step 1
Bluetooth connect your mobile device to FIRST speaker.
1
Step 2
Turn on SECOND speaker, press and hold “M” on
FIRST speaker to establish wireless connection
between the two speakers.
1
L
2
R
M
Step 3
Place two speakers apart, enjoy music in stereo.
max 30ft
1
L
2
R
max 120ft
5
OPENING BACK CAP
Step 1: Unlocking the Cap
Turn the cap counter clockwise as shown. The triangle
tip on the Cap must indicate
the open triangle on the
back panel.
Step 2: Opening the Cap
Lift the Cap as shown.
6
LOCKING BACK CAP
Step 1: Fitting the Cap
Cover the Back Panel Electronics Connections with
the Cap as shown.The Cap
must fit snugly into the Back
panel.
Step 2: Closing the Cap
Turn the cap clockwise as
shown. The triangle tip on
the Cap must indicate the
close triangle on the back
panel.
7
8
Bluetooth Stereo Mode - Searching for stereo pair
Bluetooth Stereo Mode - Stereo paired
Flash Fast
Flash Slow
Red
Green
Red
Blue
Playing audio from microUSB input
Solid
Blue
Solid
Stereo Mode
microSD Stereo Mode - Stereo paired
microSD Stereo Mode - Searching for stereo pair
Flash Fast
Flash Slow
Stereo Mode
Solid
Playing audio from auxiliary input
Solid
Green
Bluetooth Mode - Connected
Flash Slow
Playing songs from microSD card
Bluetooth Mode - Searching for connection
Flash Fast
Flash Slow
Indication
Status
Green
Blue
Color
LED INDICATION
SPECIFICATION
Model No.
TM-BT003S-2016C
Dimension
Length x Width x Height
7.28” x 2.75” x 3.15”
185mm x 70mm x 80mm
Weight1.3 lbs
Full-range Driver
2”x 2, 4 Ohm
Passive Radior
1.78” x 2.36”
45mm x 60mm
Output Power
20 Watt (10W x 2)
Frequency Response
90 Hz ~ 20 kHz
Battery Capacity
Internal Li-ion Battery
3.7V, 3000mAh
Audio Inputs
Bluetooth
MicroSD Card
AUX
USB Audio Decode
Internal Microphone
Mounting Options
Integrated Carabiner
1/4”-20 bottom thread
9
CARE AND SAFETY
Important Safety Instructions
Please read following safety warnings carefully. TimoLabs is not
liable for any cause of death, severe human injurey or property
damage, if you did not read, comprehend and comply with safety
warnings and instructions:
1. Check related regulations and restrictions for bluetooth devices
in your area before using this product.
2. Do NOT replace Corbett internal battery. It is internal and irreplaceable.
3. Do NOT try to repair, modify or disassemble Corbett speaker
drivers. There are no user maintainable parts inside.
4. Keep the device in dry, dust free, regular constant temperature
environment if planning not to use for a long time.
5. Wireless signal interferes with automotive electronics devices,
please use with caution.
6. Do NOT install near any heat sources such as radiators, heat
registers, stoves or other apparatus (including amplifiers) that
produce heat
7. Do NOT use this device close to any medical apparatus.
8. Do NOT use this device on aircraft.
9. Do NOT use this device in any flammable or combustible places.
10. Do NOT allow children use this device.
11. Do NOT expose battery in extremely hot environment to avoid
explosion, or freezing environment to avoid short battery life.
ATTENTION: Do NOT use this device for emergency communication. Wireless bluetooth signal is not the most reliable method
under all circumstances.
10
CARE AND SAFETY
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate audio frequency energy and if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, you are encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to an outlet on a different circuit than the
one to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
11
CARE AND SAFETY
Please read this guide
Corbett Rugged Waterproof Bluetooth speaker is
intended to be used both indoors and outdoors. The
speaker has been tested to IPX7 waterproofing standards. IPX7 standard allows Corbett to be submerged
in water up to 1 metre water for 30 minutes without
any damage. However, Corbett is not intended for
constant underwater use. Close the Cap properly
before use (see Locking Back Panel Cap). If Corbett
is placed in water without the cap properly closed,
water may enter into Corbett and void warranty.
Always make sure the back panel cap is clean, free
of any debris and correctly fitted. The speaker will
only meet IPX7 ratings if all rubber seals and cap are
properly locked & sealed. Corbett when incorrectly
fitted and the USB cables are NOT waterproof.
If you notice a muffling of audio after submersion,
gently shake speaker to clear excess water. If your
speaker is exposed to salt water, clean it thoroughly
after use with fresh water. Do not apply excessive
force to any surface when wet or in a wet environment.
12
CARE AND SAFETY
WARNING:
This product contains magnets which can be harmful to pacemaker wearers.
WARNING:
Avoid prolonged exposure to ultraviolet radiation (UV) sunlight or
magnetic fields. Check the rubber seal periodically for premature
wear and clean Corbett I with a soft moist cloth and ensure no
objects such as dirt, hair, sand are on the rubber seal ring. Do not
use any oily solvent or chemicals for cleaning.
WARNING:
Do not use Corbett when you are charging the battery. Do not use
Corbett I near any open fire, heat source or excessive heat.reach
equipment or its controls.
WARNING:
Sound levels should be appropriate to your environment and
comply with all local regulations. Ensure that you can hear and are
aware of any potential hazards around you when you are enjoying
your Corbett.
13
WARRANTY
For TM-BT003S
Including those Sold within North America
TimoLabs warrants this product to be free from
defects in material and workmanship for a period of
TWELVE MONTHS after the original date of consumer purchase. During this period, TimoLabs will, at its
option, either repair the defective product with new
or rebuilt parts, or replace it with a new or rebuilt
product at no charge except as *stated below. The
parts or products that are replaced become the property of TimoLabs. In the USA to obtain service under
