Philips AC4054/00 Datasheet

Philips AC4054/00 Datasheet
Bedroom air purifier
Smart sensor
20 m2
Healthy air always
with smart air control
The Philips air purifier comes with unique 6-stage clean air system which removes and
sterilizes harmful agents. The active oxygen constantly rejuvenates the zeolite filter,
ensuring long lasting superior performance.
• Smart air control measures and controls air quality
• Boost-power cleans quickly at high speed
Fresh air
• 6-stage Clean air system for clean and fresh air
• 3-stage Electro-clean system charges and traps all particles
• Active oxygen sterilizes pollutants and rejuvenuates filter
• 2-stage Fresh air system removes gases and odours
Bedroom air purifier
Smart sensor 20 m2
Smart air control
stage FreshAir filtration system removes gases
and odours * The active oxygen sterilizes
trapped particles and constantly rejuvenates
the zeolite filter, ensuring longlasting superiour
the Electro-Static Precipitation (ESP) filter. It
then passes through the zeolite filter, where it
oxidizes the trapped gases, rendering them
harmless. Thanks to this process, the zeolite
filter is constantly rejuvenated and its life can
be extended over many years.
3-stage Electro-clean system
2-stage Fresh air filtration
The built-in sensor measures the air quality in
the room and automatically selects the
appropriate speed setting to guarantee the
best possible air quality in your rooms. The
dual color display informs you on the actual air
quality, and will be red if the air quality is not
yet good enough, and green when the air is
fresh and healthy again.
Boost-power function
The 3-stage Electro-clean filtration system
works three ways. * First, the pre-filter blocks
larger particles, such as hairs, animal dander
and house dust allergens. * Second, the finer
particles that have passed through the prefilter, including bacteria and viruses, are
charged by the Corona field charger. * Third,
the Electro-Static Precipitation (ESP) filter
attracts these charges particles to its surface
and keeps them safely trapped.
Active oxygen
When the appliance is switched on at Boost
power, it is set at high fan speed to quickly
clean the air. After 30 minutes, it automatically
switches to Smart air control mode.
6-stage Clean air system
The advanced and innovative 6-stage Clean air
system removes and sterilizes even the finest
particles and a wide spectrum of gases and
odours. * The 3-stage Electro-clean filtration
system efficiently removes particles * The 2-
The active oxygen, which is generated by the
Corona Field Charger, sterilizes harmful germs
such as bacteria and viruses that are trapped in
The 2-stage Fresh air filtration system uses
advanced Nano-Confined Catalytic
Oxidization (NCCO) technology. Firstly, the
hi-grade zeolite filter traps a wide spectrum of
gases and odours and subsequently uses the
active oxygen that passes through to neutralize
them, constantly rejuvenating the filter.
Compared to the traditional activated carbon
filter, this hi-grade zeolite filter performs more
stably in different humidity conditions, and
because it is rejuvenated by the active oxygen,
it can last a much longer life of upto five years.
Bedroom air purifier
Smart sensor 20 m2
Design specifications
• Product dimensions (W x D x H): 281 x 216 x
490 mm
• Product weight: 5 kg
• ESP particle filter: AC4105
• Zeolite gas filter: AC4115
Frequency: 50/ 60 Hz
Voltage: 220-240 V
Noise level: < 49 (JIS compliance) dB
Effective area: up to 20 m²
Operating relative humidity: 20 - 90 %
Power consumption: 36 (at 220-240V, hi speed) W
Power cord: 1.8 m
• CADR: > 60 ft³/min
• Gas removal efficiency: > 99 (run at hi speed over
3 mins inside 1m3 box) %
• Particle removal efficiency: > 99 (particle size at
0.02 - 10 µm) %
Color - air outlet mesh/ control panel: silver blue
Color - control button: christal silver
Color - front cover/ air inlet mesh: christal silver
Color - rear housing: translucent algiers blue
Key specifications
• Operating temperature: 5 - 40 °C
Issue date 2014-04-08
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Version: 5.1.1
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
12 NC: 0000 000 00000
