Video Converters, Transmitters
#04201
#04200
#04199
Net Price:
71,00 EUR
Unit: set
Net Price:
71,00 EUR
Unit: set
Net Price:
390,00 EUR
Unit: set
Fiber Optic Video Transmitter, 1 positive video +
1 return data mini-type, MM (WO-1V1DM)
Fiber Optic Video Transmitter, 1 positive video +
1 return data mini-type, SM (WO-1V1DS)
Fiber Optic Video Transmitter, 16 positive video
+ 1 return data, SM (WO-16V1DS)
Video channels: 1
Data channel: 1
Video connector: BNC
Fiber optic connector: FC/PC
Wavelength: 850/1310 nm
Max. distance: 2 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power supplys
Video channels: 1
Data channel: 1
Video connector: BNC
Fiber optic connector: FC/PC
Wavelength: 1310/1550 nm
Max. distance: 20 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power supplys
Video channels: 16
Data channel: 1
Video connectors: BNC
Fiber optic connector: FC/PC
Wavelength: 1310/1550 nm
Max. distance: 20 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Enclosure: rack 1U 19"
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power cord
#04203
#04202
#04198
Net Price:
136,00 EUR
Unit: set
Net Price:
136,00 EUR
Unit: set
Net Price:
176,00 EUR
Unit: set
Fiber Optic Video Transmitter, 4 positive video +
1 return data, MM (WO-4V1DM)
Fiber Optic Video Transmitter, 4 positive video +
1 return data, SM (WO-4V1DS)
Fiber Optic Video Transmitter, 8 positive video +
1 return data, SM (WO-8V1DM)
Video channels: 4
Data channel: 1
Video connectors: BNC
Fiber optic connector: FC/PC
Wavelength: 850/1310 nm
Max. distance: 2 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power supplys
Video channels: 4
Data channel: 1
Video connectors: BNC
Fiber optic connector: FC/PC
Wavelength: 1310/1550 nm
Max. distance: 20 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power supplys
Video channels: 8
Data channel: 1
Video connectors: BNC
Fiber optic connector: FC/PC
Wavelength: 1310/1550 nm
Max. distance: 20 km
Digital encoding: 8-bit
Systems: NTSC, PAL, SECAM
Operating Temperature: -10°C do +75°C
Operating Humidity: 0 - 95%
Power : AC 230V - DC 5V/2A
Package Contents: transmitter, receiver, power supply
HDMI, DVI
#07200
#07201
#07202
Net Price:
1,17 EUR
Unit: pcs
Net Price:
1,44 EUR
Unit: pcs
Net Price:
2,12 EUR
Unit: pcs
Cable HDMI(18+1)/HDMI(18+1), HIGH SPEED, 1,5
m
Cable HDMI(18+1)/HDMI(18+1), HIGH SPEED,
Ethernet (HEC), 1,5 m
Cable HDMI(18+1)/HDMI(18+1), HIGH SPEED,
Ethernet (HEC), 3 m
Standard: 1.3, 1.4
High Speed: Yes
Length: 1.5 m
Standard: 1.3, 1.4
High Speed with Ethernet: Yes
HEC: Yes
Length: 1.5 m
Standard: 1.3, 1.4
High Speed with Ethernet: Yes
HEC: Yes
Length: 3 m
#07203
#03337
#06233
Net Price:
2,86 EUR
Unit: pcs
Net Price:
2,62 EUR
Unit: pcs
Net Price:
1,72 EUR
Unit: pcs
Cable HDMI(18+1)/HDMI(18+1), HIGH SPEED,
Ethernet (HEC), 5 m
Cable HDMI(M)/HDMI(M), HQ, 5.0 m
Coupler, HDMI female
Standard: 1.3, 1.4
High Speed with Ethernet: Yes
HEC: Yes
Length: 5 m
AV adaptors
#00615
#00623
#02030
Net Price:
0,112 EUR
Unit: pcs
Net Price:
0,181 EUR
Unit: pcs
Net Price:
0,250 EUR
Unit: pcs
Adaptor; 3.5 mm mono male to RCA female
Adaptor; 6.3 mm stereo male to 5p DIN male,
180°
1/12
Adaptor; BNC female to RCA male
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#00358
#00360
#00605
Net Price:
0,912 EUR
Unit: pcs
Net Price:
0,226 EUR
Unit: pcs
Net Price:
0,183 EUR
Unit: pcs
Adaptor; BNC female to SMA male
Adaptor; BNC male to F female
Adaptor; BNC male to RCA female
#01518
#00797
#02065
Net Price:
0,310 EUR
Unit: pcs
Net Price:
1,07 EUR
Unit: pcs
Net Price:
1,18 EUR
Unit: pcs
Adaptor; F female to RCA male
Adaptor; FME male to SMA male
Adaptor; FME male to SMB male
#00799
#02028
#02031
Net Price:
0,452 EUR
Unit: pcs
Net Price:
2,00 EUR
Unit: pcs
Net Price:
2,27 EUR
Unit: pcs
Adaptor; FME male to TNC male
Adaptor; N female to SMA female reverse pin
(RP)
Adaptor; N female to SMA male reverse pin (RP)
#02027
#02032
#00366
Net Price:
2,01 EUR
Unit: pcs
Net Price:
2,37 EUR
Unit: pcs
Net Price:
1,12 EUR
Unit: pcs
Adaptor; N male to SMA female reverse pin (RP)
Adaptor; N male to SMA male reverse pin (RP)
Adaptor; N male to UHF female
#00740
#01520
#01504
Net Price:
0,233 EUR
Unit: pcs
Net Price:
0,157 EUR
Unit: pcs
Net Price:
0,121 EUR
Unit: pcs
Adaptor; TNC female to NEC male
Adaptor; TV antenna female to F female
Adaptor; TV antenna female to RCA male
#00624
#01519
Net Price:
0,157 EUR
Unit: pcs
Net Price:
0,157 EUR
Unit: pcs
Adaptor; TV antenna male to F female
Adaptor; TV antenna male to F male
AV connections
#01234
#01235
#01250
Net Price:
0,498 EUR
Unit: pcs
Net Price:
0,556 EUR
Unit: pcs
Net Price:
0,556 EUR
Unit: pcs
DC cable 2x0.22 mm, 1.5 m + connector 1.1/3.0
male, 90°
DC cable 2x0.22 mm, 1.5 m + connector 1.1/3.5
male, 90°
DC cable 2x0.22 mm, 1.5 m + connector 1.3/3.5
male, 90°
#01236
#00291
#00292
Net Price:
0,512 EUR
Unit: pcs
Net Price:
0,537 EUR
Unit: pcs
Net Price:
0,590 EUR
Unit: pcs
DC cable 2x0.22 mm, 1.5 m + connector 1.6/5.0
male, 90°
DC cable 2x0.22 mm, 1.5 m + connector 1.7/4.0
male, 90°
2/12
DC cable 2x0.22 mm, 1.5 m + connector 2.1/5.5
male, 90°
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#00293
#01727
#02725
Net Price:
0,590 EUR
Unit: pcs
Net Price:
1,77 EUR
Unit: pcs
Net Price:
0,321 EUR
Unit: pcs
DC cable 2x0.22 mm, 1.5 m + connector 2.5/5.5
male, 90°
Mini DIN 4P male to mini DIN 4P male, gold, Satin
type, cable 5.0 m, dark blue
F male to F male, RG6/U cable 1.5 m, black
#02727
#01762
#01763
Net Price:
1,14 EUR
Unit: pcs
Net Price:
1,14 EUR
Unit: pcs
Net Price:
1,64 EUR
Unit: pcs
VIDEO cable, BNC male to BNC male, 1.5 m
SCART male + switch to 2RCA & mini DIN 4P,
gold, Satin type, cable 1.5 m, dark blue
Length: 1.5m
Cable type: RG59, stranded, 75Ω
SCART male + switch to 2RCA male & mini DIN
4P, gold, Satin type, cable 3.0 m, dark blue
#00259
#00275
#00260
Net Price:
0,402 EUR
Unit: pcs
Net Price:
0,429 EUR
Unit: pcs
Net Price:
0,481 EUR
Unit: pcs
SCART male to SCART male, 9P, standard cable
1.5 m
SCART male to SCART male, 21P, cable 1.2 m
SCART male to SCART male, 21P, cable 1.5 m
#01218
#01292
#01746
Net Price:
0,910 EUR
Unit: pcs
Net Price:
0,369 EUR
Unit: pcs
Net Price:
0,883 EUR
Unit: pcs
SCART male to SCART male, 21P, cable 3.0 m
TV-VIDEO cable, TV male to TV female, 2.0 m,
black HQ
TV-VIDEO cable, TV male to TV female, gold,
Satin type, 1.5 m, dark blue
Cables coaxial type
#08999
#07208
#07209
Net Price:
116,00 EUR
Unit: roll 100m
Net Price:
11,10 EUR
Unit: roll 100m
Net Price:
23,30 EUR
Unit: roll 100m
Coaxial cable RG213, stranded wire, black, 100 m
Internal wire: 7x0.75 copper/stranded wire
Insulation: 7.2 mm, PE
External coating: 10.3mm/PVC/black
Impedance: 50Ω
capacitance: 98 +/- 2 pF/m
attenuation: 10 MHz - 1.7 dB/100m, 50 MHz - 4.6 dB/100m,
100 MHz - 6.7 dB/100m, 230 MHz - 9.8 dB/100m, 470 MHz 15.3 dB/100m, 860 MHz - 22.3 dB/100m, 1000 MHz - 24.5
dB/100m, 1500 MHz - 31.3 dB/100m, 2000 MHz - 36.5
dB/100m
Coaxial cable Wave Cables RG58, stranded wire,
black, 100 m
Internal wire: 7x0.16 copper/stranded wire
Insulation: 1.6 mm, PE
Shield: 96x0.1 copper
External coating: 2.90mm/PVC/black
Impedance: 50Ω
capacitance: 100 +/- 2 pF/m
attenuation: 50 MHz - 18.0 dB/100m, 200 MHz - 37.2
dB/100m, 400 MHz - 53.2 dB/100m, 600 MHz - 64.3
dB/100m, 800 MHz - 79.2 dB/100m
Internal wire: 19x0.18 copper/stranded wire
Insulation: 3.0 mm, PE
Shield: 112x0.1 copper
External coating: 5.0mm/PVC/black
Impedance: 50Ω
capacitance: 100 +/- 2 pF/m
attenuation: 50 MHz - 10.9 dB/100m, 200 MHz - 23.0
dB/100m, 400 MHz - 33.8 dB/100m, 600 MHz - 42.5
dB/100m, 800 MHz - 47.8 dB/100m, 1000 MHz - 51.9
dB/100m
#00129
#07098
#07204
Net Price:
28,00 EUR
Unit: roll 100m
Net Price:
28,00 EUR
Unit: roll 100m
Net Price:
11,60 EUR
Unit: roll 100m
Coaxial cable, RG58 ALL, stranded wire, 100 m,
black
High performance, professional outdoor coaxial cable for
video instalation.
Internal wire:1.10mm/cooper (Cu)
Insulation: 2.90mm
Shield: Al-PET + 70% CuSn
External coating:5.00mm/PVC/black
Coaxial cable Wave Cables RG174, stranded
wire, black, 100 m
Coaxial cable CTF 113 Tri-shield, 100 m
Coaxial cable Wave Cables RG59 Cu, 100 m
CFT 113 Tri-shield is a high quality 75Ω coaxial cable
designed for perfect signal transmission of digital and analog
in a very difficult external environment.
center conductor: 0.81 mm / copper wire (Cu)
dielectric: 3.7 mm
screen: Al-PES foil
braid: 64x0.12 Al
outer shell: 6.0mm/PVC
impedance: 75Ω
capacitance: 52 +/- 2 pF/m
return loss: 5-30 MHz - >26dB, 30-470 MHz - >23dB,
470-1000 MHz - >20dB, 1000-3000 MHz - >20dB
acreening attenuation: 1-1000MHz - >90dB
attenuation: 5 MHz - 1.8 dB/100m, 50 MHz - 5.9 dB/100m,
200 MHz - 10.7 dB/100m, 400 MHz - 14.8 dB/100m, 800 MHz
- 22.5 dB/100m, 1000 MHz - 25.0 dB/100m, 1350 MHz - 30.5
dB/100m, 1750 MHz - 33.5 dB/100m, 2150 MHz - 37.5
dB/100m, 3000 MHz - 46.5 dB/100m
internal vein: 1.13 mm / copper wire (Cu)
dielectric: 4.8 mm
Screen: Al foil + Al-Pet
braid: 80%
outer shell: 7mm/PVC/white
Attenuation: 50 MHz - 3.9 dB/100m, 100 MHz - 5.6 dB/100m,
200 MHz - 7.8 dB/100m, 450 MHz - 12.3 dB/100m, 860 MHz 17.0 dB / 100m, 1000 MHz - 18,6,1 dB/100m, 1350 MHz 21.9 dB/100m, 1750 MHz - 25.2 dB/100m, 2150 MHz - 28.2
dB/100m, 3000 MHz - 33.8 dB/100m
3/12
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#07205
#07206
#07212
Net Price:
13,30 EUR
Unit: roll 100m
Net Price:
16,60 EUR
Unit: roll 100m
Net Price:
16,60 EUR
Unit: roll 100m
Coaxial cable Wave Cables RG59-Tri Cu, 100 m
Coaxial cable Wave Cables RG6 Cu, black, 100 m
center conductor: 0.81 mm / copper wire (Cu)
dielectric: 3.7 mm
screen: Al-PES-Al foil
braid: 96x0.12 Al
outer shell: 6.2mm/PVC
impedance: 75Ω
capacitance: 52 +/- 2 pF/m
return loss: 5-30 MHz - >26dB, 30-470 MHz - >23dB,
470-1000 MHz - >20dB, 1000-3000 MHz - >20dB
screening attenuation: 1-1000MHz - >100dB
attenuation: 5 MHz - 1.7 dB/100m, 50 MHz - 5.8 dB/100m,
200 MHz - 10.7 dB/100m, 400 MHz - 15.2 dB/100m, 800 MHz
- 22.5 dB/100m, 1000 MHz - 25.0 dB/100m, 1350 MHz - 30.5
dB/100m, 1750 MHz - 33.5 dB/100m, 2150 MHz - 37.5
dB/100m, 3000 MHz - 46.5 dB/100m
center conductor: 1.02 mm / copper wire (Cu)
dielectric: 4.7 mm
screen: Al-PES foil
braid: 64x0.12 Al
outer shell: 6.8mm/PVC
impedance: 75Ω
capacitance: 52 +/- 2 pF/m
return loss: 1-1000 MHz - >23dB, 1000-3000 MHz - >20dB
screening attenuation: 1-1000MHz - >90dB
attenuation: 5 MHz - 5 MHz - 1.7 dB/100m, 50 MHz - 5.0
dB/100m, 200 MHz - 8.7 dB/100m, 400 MHz - 12.8 dB/100m,
800 MHz - 18.0 dB/100m, 1000 MHz - 19.8 dB/100m, 1350
MHz - 23.8 dB/100m, 1750 MHz - 28.0 dB/100m, 2150 MHz 31.4 dB/100m, 3000 MHz - 38.0 dB/100m
center conductor: 1.02 mm / copper wire (Cu)
dielectric: 4.7 mm
screen: Al-PES foil
braid: 64x0.12 Al
outer shell: 6.8mm/PVC
impedance: 75Ω
capacitance: 52 +/- 2 pF/m
return loss: 1-1000 MHz - >23dB, 1000-3000 MHz - >20dB
screening attenuation: 1-1000MHz - >90dB
attenuation: 5 MHz - 5 MHz - 1.7 dB/100m, 50 MHz - 5.0
dB/100m, 200 MHz - 8.7 dB/100m, 400 MHz - 12.8 dB/100m,
800 MHz - 18.0 dB/100m, 1000 MHz - 19.8 dB/100m, 1350
MHz - 23.8 dB/100m, 1750 MHz - 28.0 dB/100m, 2150 MHz 31.4 dB/100m, 3000 MHz - 38.0 dB/100m
#07207
#08002
#08000
Net Price:
18,60 EUR
Unit: roll 100m
Net Price:
49,00 EUR
Unit: roll 100m
Net Price:
38,00 EUR
Unit: roll 100m
Coaxial cable Wave Cables RG6-Tri Cu, 100 m
center conductor: 1.02 mm / copper wire (Cu)
dielectric: 4.7 mm
screen: Al-PES-Al foil
braid: 96x0.12 Al
outer shell: 7.2mm/PVC
impedance: 75Ω
capacitance: 52 +/- 2 pF/m
return loss: 1-1000 MHz - >23dB, 1000-3000 MHz - >20dB
screening attenuation: 1-1000MHz - >100dB
attenuation: 5 MHz - 5 MHz - 1.5 dB/100m, 50 MHz - 4.6
dB/100m, 200 MHz - 8.7 dB/100m, 400 MHz - 12.8 dB/100m,
800 MHz - 18.0 dB/100m, 1000 MHz - 19.8 dB/100m, 1350
MHz - 23.8 dB/100m, 1750 MHz - 28.0 dB/100m, 2150 MHz 31.4 dB/100m, 3000 MHz - 38.5 dB/100m
Coaxial cable XAp RG59 + 2 x power cable,
white, 100m
Coaxial cable YAp RG59 + 2 x power cable,
white, 100m
XAP RG59 + 2x0, 5 is 75Ω coaxial cable with the wires
supplying integrated / octal construction controls, designed
primarily for use in CCTV installations.
YAp 75-0,59/3,7 + 2x0,5 coaxial outdoor cable for industrial tv
instalation.
The parameters of the coaxial
Inner conductor: 0.59 mm / copper wire (Cu)
Dielectric: 3.70 mm / EP
Display: braided copper (Cu) 90%
Outer sheath: PE 6mm/black
Impedance: 75 Ω +/- 3
Unit Capacity: 67 +/- 3 pF / m
Screening efficiency:> 65dB (100-900MHz)
Internal conductor resistance: 46 Ω / km
Minimum bending radius in the internal installations:> 5x
cable diameter
Damping [dB/100m]: 7.6 (50MHz), 10.9 (100MHz), 15.5
(200MHz), 23.1 (450MHz), 25.9 (500MHz), 32.6 (800MHz),
36 , 5 (1000MHz), 42.0 (1300MHz)
The parameters of the control
Vein internal: 2 x stranded copper (Cu)
Rated cross-section of living control: 0.50 mm / copper,
multipleOuter sheath: 5mm/PVC/black
The parameters of the coaxial
Inner conductor: 0.59 mm / copper wire (Cu)
Dielectric: 3.70 mm / EP
Display: braided copper (Cu) 90%
Outer sheath: 6mm/PVC/biała
Impedance: 75 Ω +/- 3
Unit Capacity: 67 +/- 3 pF / m
Screening efficiency:> 65dB (100-900MHz)
Internal conductor resistance: 46 Ω / km
Minimum bending radius in the internal installations:> 5x
cable diameter
Damping [dB/100m]: 7.6 (50MHz), 10.9 (100MHz), 15.5
(200MHz), 23.1 (450MHz), 25.9 (500MHz), 32.6 (800MHz),
36 , 5 (1000MHz), 42.0 (1300MHz)
Weight: 7.5 kg
The parameters of the control
Vein internal: 2 x stranded copper (Cu)
Rated cross-section of living control: 0.50 mm / copper,
multipleOuter sheath: 5mm/PVC/biała
#02052
#07211
#07253
Net Price:
53,90 EUR
Unit: roll 100m
Net Price:
37,10 EUR
Unit: roll 100m
Net Price:
186,00 EUR
Unit: roll 500m
H155 (RF-5) coaxial cable, 50 Ohm (PE), Draka,
100 m
High performance outdoor coaxial cable for WLAN
communication (2,4 GHz). Draka Comteq.
Internal wire:1.35mm(7x0,45)/cooper (Cu)
Insulation: 3.60mm
Shield: Al-PET-Al + 80% cooper (Cu)
External coating:5.4mm/PE/black
Coaxial cable Wave Cables RG6 Cu, white, 100 m
H155 (WC-55) coaxial cable Wave Cables, 50
Ohm (PE), 100 m
H155 (WC-55) coaxial cable Wave Cables, 50
Ohm (PE), 500 m
High performance outdoor coaxial cable for WLAN
communication (2,4 GHz).
50Ω, 5,4mm (H155) High performance outdoor coaxial cable
for WLAN communication (2,4 GHz).
Internal wire:7x0.45 / cooper (Cu)
Insulation: 3.60mm
Shield: Double Al foil, 96x0.12Cu
External coating:5.4mm/PE
Internal wire:7x0.45 / cooper (Cu)
Insulation: 3.60mm
Shield: Double Al foil, 96x0.12Cu
External coating:5.4mm/PE
Attenuation 20°C [dB/100m]
5 MHz: 1,8
50 MHz: 6,8
200 MHz: 12,5
400 MHz: 17,8
800 MHz: 26
1000 MHz: 29,6
1350 MHz: 34,7
1750 MHz: 40
2150 MHz: 44,5
3000 MHz: 53,2
Attenuation 20°C [dB/100m]
5 MHz: 1,8
50 MHz: 6,8
200 MHz: 12,5
400 MHz: 17,8
800 MHz: 26
1000 MHz: 29,6
1350 MHz: 34,7
1750 MHz: 40
2150 MHz: 44,5
3000 MHz: 53,2
Return loss [dB]
5-30 MHz: >22
30-470 MHz: >20
470-1000 MHz: >18
1000-2150 MHz: >18
Return loss [dB]
5-30 MHz: >22
30-470 MHz: >20
470-1000 MHz: >18
1000-2150 MHz: >18
4/12
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#02058
#07096
#08259
Net Price:
152,00 EUR
Unit: roll 100m
Net Price:
71,50 EUR
Unit: roll 100m
Net Price:
147,00 EUR
Unit: roll 100m
RF-10F (H1000) coaxial cable, 50 Ohm (PE), wire,
100 m
Internal wire: 2.71/Cu/solid
Insulation: 7.25/Foam-PE
Shield: 10.3 mm Cu-PET-Cu-foil+cooper braid
External coating: 5.4/PE/black
Wave loss [100/1000/2500MHz]: 1.0/3.6/20.6
MRC 240 coaxial cable, 50 Ohm, 100 m
50Ω coaxial cable. Features very good electrical
characteristics and resistance to weather conditions.
Copper core diameter: 1.42 mm+/-0.02 mm
Outer diameter: 3.81 mm +/- 0.05 mm
Shield: Al/Poliester Foil/Al Foil 12/15/12 um
Foil coverage rate: 100 %
CuSn braid: 16x7x0.12
Braid coverage rate: 93 %
Outer diameter: 4.45 mm
Sheath
Material: PE
Outer diameter: 6.10 mm +/-0.10 mm
Colour: black
Electrical parameters
Impedance: 50 Ohm +/-2
Capacitance: 83 pF/m
Wave reduction factor: 81%
Core resistance: 11.2 Ohm/km
Braid resistance: 12.4 Ohm/km
Other parameters
Minimum bending radius: 30/60 mm
Attenuation table: 30 MHz - 4,4 dB/100m, 150 MHz - 9,9
dB/100m, 220 MHz - 12,0 dB/100m, 450 MHz - 17,3
dB/100m, 900 MHz - 24,8 dB/100m, 1500 MHz - 32,4
dB/100m, 1800 MHz - 35,6 dB/100m, 2500 MHz - 42,4
dB/100m, 5800 MHz - 66,8 dB/100m
MRC 400 ECO coaxial cable, Draka, 50 Ohm (PE),
100 m
High performance, professional outdoor coaxial cable for
WLAN communication (2,4 GHz, WiMAX, 5 GHz) with a CCA
inner conductor (Copper Clad Aluminium). Draka Comteq.
Internal wire: 2.74 mm/CCA
Insulation: Ø7.24 mm
Shield: AL-PET Foil, bonded to the dielectric + Aluminium
braid
External coating:10.3 mm/PE/black
Attenuation table
30 MHz: 2.2 dB/100m
150 MHz: 5 dB/100m
220 MHz: 6.1 dB/100m
450 MHz: 8.9 dB/100m
900 MHz: 12.8 dB/100m
1800 MHz: 18.6 dB/100m
2500 MHz: 22.3 dB/100m
5200 MHz: 33.6 dB/100m
5800 MHz: 35.5 dB/100m
#05299
Net Price:
69,30 EUR
Unit: roll 100m
RF-240 coaxial cable, 50 Ohm, 100 m
Copper core diameter: 1.4 mm+/-0.02 mm
Outer diameter: 3.8 mm +/- 0.05 mm
Shield: Al/Poliester Foil/Al Foil 12/15/12 um
Foil coverage rate: 100 %
CuSn braid: 16x7x0.12
Braid coverage rate: 80 %
Outer diameter: 4.45 mm
Sheath
Material: PE
Outer diameter: 6.10 mm +/-0.10 mm
Colour: black
Electrical parameters
Impedance: 50 Ohm +/-2
Capacitance: 83 pF/m
Wave reduction factor: 81%
Screening efficiency: >90 dB
Core resistance: 11.2 Ohm/km
Braid resistance: 12.4 Ohm/km
Other parameters
Minimum bending radius: 30/60 mm
Weight: 47 kg/km
Working temperature: -40°C ÷ 70°C
Attenuation table
30 MHz: 4.2 dB/100m
50 MHz: 5.4 dB/100m
150 MHz: 9.2 dB/100m
220 MHz: 11.2 dB/100m
450 MHz: 16.2 dB/100m
900 MHz: 23.3 dB/100m
1500 MHz: 30.7 dB/100m
1800 MHz: 33.9 dB/100m
2000 MHz: 35.9 dB/100m
2500 MHz: 40.6 dB/100m
5800 MHz: 65.2 dB/100m
Connectors SMA type
#02023
#00378
#01561
Net Price:
0,571 EUR
Unit: pcs
Net Price:
0,571 EUR
Unit: pcs
Net Price:
0,571 EUR
Unit: pcs
SMA male connector, crimp type, H155
SMA male connector, crimp type, RG174
SMA male connector, crimp type, RG58
#02025
#02789
#02791
Net Price:
0,550 EUR
Unit: pcs
Net Price:
0,721 EUR
Unit: pcs
Net Price:
0,748 EUR
Unit: pcs
SMA male reverse pin connector (RP), crimp
type, H155
SMA male reverse pin connector (RP), crimp
type, RG174
5/12
SMA male reverse pin connector (RP), crimp
type, RG58
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#00374
#00372
#02024
Net Price:
0,836 EUR
Unit: pcs
Net Price:
0,786 EUR
Unit: pcs
Net Price:
0,736 EUR
Unit: pcs
Adaptor, SMA female to SMA female
SMA female connector, bulkhead
SMA female connector, crimp type, H155
#00375
#01560
#02043
Net Price:
0,688 EUR
Unit: pcs
Net Price:
0,688 EUR
Unit: pcs
Net Price:
0,976 EUR
Unit: pcs
SMA female connector, crimp type, RG174
SMA female connector, crimp type, RG58
SMA female connector, PCB, right angle
#02036
#02039
#02041
Net Price:
0,969 EUR
Unit: pcs
Net Price:
0,552 EUR
Unit: pcs
Net Price:
0,731 EUR
Unit: pcs
Adaptor, SMA female reverse pin (RP) to SMA
female rerverse pin (RP)
SMA female reverse pin connector (RP),
bulkhead receptacle, 11.6 mm
SMA female reverse pin connector (RP),
bulkhead receptacle, 13.15 mm
#02026
#02792
#02790
Net Price:
0,669 EUR
Unit: pcs
Net Price:
0,695 EUR
Unit: pcs
Net Price:
0,721 EUR
Unit: pcs
SMA female reverse pin connector (RP), crimp
type, H155
SMA female reverse pin connector (RP), crimp
type, RG174
SMA female reverse pin connector (RP), crimp
type, RG58
#02037
Net Price:
0,869 EUR
Unit: pcs
SMA female reverse pin connector (RP), PCB,
right angle, L=15 mm
Connectors N type
#00723
#02018
#02021
Net Price:
1,11 EUR
Unit: pcs
Net Price:
0,986 EUR
Unit: pcs
Net Price:
0,964 EUR
Unit: pcs
N male connector, clamp type, RG213
N male connector, crimp type, H1000
N male connector, crimp type, H155
#00347
#08147
#00342
Net Price:
0,986 EUR
Unit: pcs
Net Price:
1,70 EUR
Unit: pcs
Net Price:
0,364 EUR
Unit: pcs
N male connector, crimp type, RG58
Adapter N(F)-N(F) panel mount straight
N female connector, bulkhead crimp type, RG58
Jack-jack 4 mount straight
#00719
#02019
#02022
Net Price:
0,995 EUR
Unit: pcs
Net Price:
1,01 EUR
Unit: pcs
Net Price:
0,964 EUR
Unit: pcs
N female connector, bulkhead solder type
N female connector, crimp type, H1000
6/12
N female connector, crimp type, H155
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#00344
#02020
#00343
Net Price:
1,00 EUR
Unit: pcs
Net Price:
0,802 EUR
Unit: pcs
Net Price:
1,15 EUR
Unit: pcs
N female connector, crimp type, RG58
N female connector, receptacle chassis mount,
RG58
Adaptor, N female to N female
#00346
Net Price:
1,13 EUR
Unit: pcs
Adaptor, N male to N male
Connectors TNC type
#00752
#02483
#00386
Net Price:
0,100 EUR
Unit: pcs
Net Price:
0,312 EUR
Unit: pcs
Net Price:
0,300 EUR
Unit: pcs
TNC male connector, clamp type, RG6
TNC male connector, crimp type, H155
TNC male connector, crimp type, RG58
#04727
#04728
#00381
Net Price:
0,586 EUR
Unit: pcs
Net Price:
0,552 EUR
Unit: pcs
Net Price:
0,402 EUR
Unit: pcs
TNC male RP connector (Reverse Pin), crimp
type, H155
TNC male RP connector (Reverse Pin), crimp
type, RG58
Adaptor, TNC female to TNC female
#00380
#02482
#00750
Net Price:
0,314 EUR
Unit: pcs
Net Price:
0,360 EUR
Unit: pcs
Net Price:
0,110 EUR
Unit: pcs
TNC female connector, bulkhead receptacle
TNC female connector, crimp type, H155
TNC female connector, crimp type, RG6
Connectors FME type
#02481
#01503
#00756
Net Price:
0,362 EUR
Unit: pcs
Net Price:
0,362 EUR
Unit: pcs
Net Price:
0,357 EUR
Unit: pcs
FME male connector, crimp type, H155
FME male connector, crimp type, RG174
FME male connector, crimp type, RG58
#02480
#01502
#00755
Net Price:
0,286 EUR
Unit: pcs
Net Price:
0,231 EUR
Unit: pcs
Net Price:
0,255 EUR
Unit: pcs
FME female connector, crimp type, H155
FME female connector, crimp type, RG174
FME female connector, crimp type, RG58
MCX, MC CARD, TS9, CRC9 Connectors
#07132
#07134
#02053
Net Price:
1,24 EUR
Unit: pcs
Net Price:
1,66 EUR
Unit: pcs
Net Price:
0,714 EUR
Unit: pcs
CRC9 male connector, 90°, crimp type, RG174
CRC9 is mailny used in Huawei 3G and LTE modems.
CRC9/TS9 twix male connector, 90°, crimp type,
RG174
MC-CARD male connector; 90°, gold, crimp type,
H155
TS9 is mailny used in 3G and LTE modems manufactured by
ZTE, Sierra Wireless, Novatel and others.
CRC9 is mailny used in Huawei 3G and LTE modems.
7/12
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#02787
#03389
#07133
Net Price:
1,28 EUR
Unit: pcs
Net Price:
1,03 EUR
Unit: pcs
Net Price:
1,24 EUR
Unit: pcs
MCX male connector, 90°, crimp type, RG174
MCX male connector, straight, crimp type, RG174
TS9 male connector, 90°, crimp type, RG174
TS9 is mailny used in 3G and LTE modems manufactured by
ZTE, Sierra Wireless, Novatel and others.
Connectors BNC type
#00314
#00716
#00717
Net Price:
0,440 EUR
Unit: pcs
Net Price:
0,369 EUR
Unit: pcs
Net Price:
0,348 EUR
Unit: pcs
Adaptor, BNC(M) - BNC(M)
BNC male connector, clamp type, RG58
BNC male connector, clamp type, RG59
#00718
#00316
#01635
Net Price:
0,348 EUR
Unit: pcs
Net Price:
0,464 EUR
Unit: pcs
Net Price:
0,343 EUR
Unit: pcs
BNC male connector, clamp type, RG6
BNC male connector, crimp type, RG11
BNC male connector, crimp type, RG174
Cable core diameter up to Ø1,3mm.
#00317
#00318
#01559
Net Price:
0,245 EUR
Unit: pcs
Net Price:
0,245 EUR
Unit: pcs
Net Price:
0,245 EUR
Unit: pcs
BNC male connector, crimp type, RG58
BNC male connector, crimp type, RG59
#00311
#00310
#01634
Net Price:
0,217 EUR
Unit: pcs
Net Price:
0,231 EUR
Unit: pcs
Net Price:
0,340 EUR
Unit: pcs
Adaptor, BNC(F) - BNC(F)
BNC female connector, bulkhead receptacle nut
12.7 mm
BNC female connector, crimp type, RG174
#00312
#01633
#00714
Net Price:
0,345 EUR
Unit: pcs
Net Price:
0,343 EUR
Unit: pcs
Net Price:
0,457 EUR
Unit: pcs
BNC female connector, crimp type, RG58
BNC female connector, crimp type, RG59
BNC female connector, isolated ground
#01641
#00715
#00306
Net Price:
0,229 EUR
Unit: pcs
Net Price:
0,452 EUR
Unit: pcs
Net Price:
0,374 EUR
Unit: pcs
BNC female connector, PCB, 180°
Splitter, BNC(M) - 2x BNC(F)
BNC male connector, crimp type, RG6
BNC female connector, PCB, 90°
Splitter, BNC(F) - 2x BNC(F)
#00307
#02408
#02409
Net Price:
0,376 EUR
Unit: pcs
Net Price:
0,040 EUR
Unit: pcs
Net Price:
0,040 EUR
Unit: pcs
BNC boot, RG58
BNC boot, RG59
8/12
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
Connectors F type
#00582
#00578
#01796
Net Price:
0,107 EUR
Unit: pcs
Net Price:
0,469 EUR
Unit: pcs
Net Price:
5,71 EUR
Unit: 100pcs
F male connector with attached ring, RG59
F male connector, RG11
F male connector, TWIST-ON, RG59, brass
#02059
#01550
#01797
Net Price:
2,79 EUR
Unit: 100pcs
Net Price:
5,10 EUR
Unit: 100pcs
Net Price:
5,71 EUR
Unit: 100pcs
F male connector, TWIST-ON, RG6
F male connector, TWIST-ON, RG6, Thickness
7.2 mm
#00575
#00574
Net Price:
9,24 EUR
Unit: 100pcs
Net Price:
13,90 EUR
Unit: 100pcs
F double female connector + Nut/Washer, diecast
F male connector, TWIST-ON, RG6, brass
F female connector, bulkhead receptacle, O.D.:11
mm, brass, with Nut/Washer
Connectors UHF type
#03387
#01558
#00699
Net Price:
0,381 EUR
Unit: pcs
Net Price:
0,429 EUR
Unit: pcs
Net Price:
0,417 EUR
Unit: pcs
UHF male connector, crimp type, RG58
UHF male connector, twist type, RG11
UHF male connector, twist type, RG58
#00700
#00697
#00696
Net Price:
0,417 EUR
Unit: pcs
Net Price:
0,462 EUR
Unit: pcs
Net Price:
0,421 EUR
Unit: pcs
UHF male connector, twist type, RG59
Adaptor, UHF female to UHF female
UHF female connector, bulkhead, 16 teeth
Connectors DC type
#01594
#00559
Net Price:
0,348 EUR
Unit: pcs
Net Price:
5,10 EUR
Unit: 100pcs
DC Chassis female connector, 2.5/5.5
DC male connector with plastic handle, 2.5/5.5
Connectors RCA type
#00674
Net Price:
0,060 EUR
Unit: pcs
Splitter, RCA male to 2RCA female
Connectors PAL type
TV antenna male connector
#00544
#00539
#00534
Net Price:
1,61 EUR
Unit: 100pcs
Net Price:
1,43 EUR
Unit: 100pcs
Net Price:
1,87 EUR
Unit: 100pcs
TV antenna male connector, chassis mount
9/12
TV antenna female connector
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
#00530
#00528
#00529
Net Price:
2,40 EUR
Unit: 100pcs
Net Price:
0,060 EUR
Unit: pcs
Net Price:
1,43 EUR
Unit: 100pcs
TV antenna female connector, 90°, big
TV antenna female connector, metal, chassis
mount
TV antenna female connector, metal, PCB
#01516
#00647
#00690
Net Price:
0,100 EUR
Unit: pcs
Net Price:
0,071 EUR
Unit: pcs
Net Price:
0,126 EUR
Unit: pcs
TV antenna female connector, with attach ring,
RG6
TV single outlet box
Splitter, TV antenna male to 2xTV antenna
female, metal
Connectors phone type
#00519
Net Price:
0,069 EUR
Unit: pcs
6.3 mm stereo female connector, plastic
Microphones
#03626
Net Price:
0,095 EUR
Unit: pcs
Microphone holder T-91
Max. diameter 25 mm.
Cables power type
#01213
#01214
#01211
Net Price:
186,00 EUR
Unit: roll 100m
Net Price:
77,10 EUR
Unit: roll 100m
Net Price:
107,00 EUR
Unit: roll 100m
HC OFC power cable, 5AWG, black, O.D.: 8.5
mm
HC OFC power cable, 8AWG, black, O.D.: 6.5
mm
External diameter with isolation: 8,5 mm
Wire diameter: 0,15 mm
External diameter with isolation: 6,5 mm
Wire diameter: 0,15 mm
HC OFC power cable, 8AWG, red, O.D.: 6.5 mm
External diameter with isolation: 6,5 mm
Wire diameter: 0,15 mm
#01215
Net Price:
46,70 EUR
Unit: roll 100m
HC OFC power cable, 10AWG, black, O.D.:5.5
mm
External diameter with isolation: 5,5 mm
Wire diameter: 0,15 mm
Cables AV type, other
#00202
Net Price:
5,88 EUR
Unit: roll 100m
SCART cable, 8C+1, 100 m, CCS
Isolation: 8x0,82 PVC
Shield: Alu + Folia
External coat: Ø 5,5 PVC
Toslink optical accessories
#01676
Net Price:
0,810 EUR
Unit: pcs
Optical cable, 3.5 mini male, O.D. 4 mm, black 0.5 m
10/12
https://www.atel-electronics.eu 2017.07.25 17:10
Audio-Video Accessories
AV splitters
#00668
#00660
#02700
Net Price:
0,195 EUR
Unit: pcs
Net Price:
0,476 EUR
Unit: pcs
Net Price:
0,171 EUR
Unit: pcs
Splitter, 3.5 mm stereo male to 2xRCA female,
HQ
Splitter, 3xSCART male to 3xRCA female +
switch
Splitter, SCART 21P male to SCART 21P female +
2XRCA female
#01779
Net Price:
0,357 EUR
Unit: pcs
Splitter, SCART male to SCART female + 2xRCA
female +switch, 0.5 m
Car audio accessories
#02105
Net Price:
4,52 EUR
Unit: pcs
Fuse holder for WF (ANL), 4 AWG power cable,
water resistant
Other audio accessories
#01535
Net Price:
0,119 EUR
Unit: pcs
Auto cigarette male connector, HQ type
11/12
https://www.atel-electronics.eu 2017.07.25 17:10
Index
Video Converters, Transmitters ................................................................................................................................................................................ 1
HDMI, DVI ..................................................................................................................................................................................................................... 1
AV adaptors ................................................................................................................................................................................................................. 1
AV connections ........................................................................................................................................................................................................... 2
Cables coaxial type ..................................................................................................................................................................................................... 3
Connectors SMA type ................................................................................................................................................................................................. 5
Connectors N type ...................................................................................................................................................................................................... 6
Connectors TNC type ................................................................................................................................................................................................. 7
Connectors FME type ................................................................................................................................................................................................. 7
MCX, MC CARD, TS9, CRC9 Connectors .................................................................................................................................................................. 7
Connectors BNC type ................................................................................................................................................................................................. 8
Connectors F type ...................................................................................................................................................................................................... 9
Connectors UHF type ................................................................................................................................................................................................. 9
Connectors DC type ................................................................................................................................................................................................... 9
Connectors RCA type ................................................................................................................................................................................................. 9
Connectors PAL type ................................................................................................................................................................................................. 9
Connectors phone type ............................................................................................................................................................................................ 10
Microphones .............................................................................................................................................................................................................. 10
Cables power type .................................................................................................................................................................................................... 10
Cables AV type, other ............................................................................................................................................................................................... 10
Toslink optical accessories ..................................................................................................................................................................................... 10
AV splitters ................................................................................................................................................................................................................ 11
Car audio accessories .............................................................................................................................................................................................. 11
Other audio accessories .......................................................................................................................................................................................... 11
12/12
https://www.atel-electronics.eu 2017.07.25 17:10

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
