Philips M120/10 User manual

Philips M120/10 User manual
In.Sight wireless HD home
Wi-Fi and HD
Wide angle, Night vision
For iPhone, iPad
Powered by Ivideon
Watch over your home from your iPhone/iPad
With HD and night vision
Keep an eye on home with the In.Sight wireless HD home monitor via your iPhone/iPad.
With HD video and night vision, it lets you clearly see your home in daylight or darkness.
It's easy to set up and will alert you when it detects motion/sound.
Stay close to loved ones when you're on the move
• Wi-Fi enabled for placement anywhere in your home
• Unlimited live viewing via Wi-Fi/3G/4G LTE
• Extra-wide-angle lens to let you see more
• InSightHD app available on Apple Store
• Night vision mode for viewing in the dark
Alerts and notifications for ultimate peace of mind
• Phone receives notification when motion/sound is detected
• Push to talk via iPhone/iPad
• Share monitors with other iPhone/iPad users
• Optional cloud video recording when sound/motion is detected
Easy, safe and secure
• Easy setup of monitor via QR code
• Video encrypted for secure connection
• Powered by Ivideon, a leading firm in video cloud solutions
In.Sight wireless HD home monitor
Wi-Fi and HD Wide angle, Night vision, For iPhone, iPad, Powered by Ivideon
Wi-Fi enabled
vision mode switches on and off automatically,
or you can adjust it manually.
Motion/sound notifications
Extra-wide-angle lens
The In.Sight wireless monitor is a Wi-Fi
enabled monitor. It uses your home wireless
network to stream live video and audio with
monitors that you can set up anywhere you
Night vision mode
Philips In.Sight wireless HD home monitor
M120 boasts a viewing angle of 102 degrees
that shows you more of the room at once,
letting you see a lot more than other monitors.
It's impossible to predict when something
might happen. In.Sight keeps watching with
adjustable motion and sound detection. You
will be notified automatically when sound or
motion is detected.
Easy set-up via QR code
Push to talk
With the In.Sight monitor, not only can you
keep an eye on your home, but you can also
talk to your loved ones. Simply press "talk" on
your iPhone/iPad and communicate at once.
What a great way to say hello!
Infrared night vision mode allows you to watch
your home even in the dark. When it's dark,
infrared light goes on so the monitor can
capture clear black-and-white video. Night
Setup is simple with the In.Sight+ app. The app
will generate a QR code for your home Wi-Fi
settings. With the QR code, the monitor will
automatically pair with your Wi-Fi network,
easily and instantly.
In.Sight wireless HD home monitor
Wi-Fi and HD Wide angle, Night vision, For iPhone, iPad, Powered by Ivideon
Lens and Sensor
Sensor: HD 720p
Focus mode: Fixed
View angle: 102 degrees
Focus range: 0.8 M to infinity
Ambient light sensor: Yes, day/night mode
Night mode: Infra-Red
Video Quality
HD/VGA/QVGA streaming
Formats: H.264 video compression
White Balance: Automatic white balance
Exposure: Automatic exposure control
Wi-Fi: 802.11 b/ g/ n (2.4 GHz)
Motion detection
Noise detection
LED indicator
Night Vision
Base: Direction adjustable
• App name: InSightHD
Installation: via App
Automatic App update
System supported: iOS6 or above
iPad compatibility: iPad 2 and later
iPhone compatibility: iPhone 4S and later
iPod compatibility: iPod Touch 4th gen and later
Accessories included
USB power adapter: 1
USB cable: Yes, 3m
Wall mount
Screws/wall anchors: 2
Quick Start Guide
Input and Output
• Microphone: Highly sensitive, Mono
• USB: Mini-USB port
• Speaker: Built-in
• Packaging dimensions (W x H x D):
158 x 160 x 78 mm
• Product dimensions (W x H x D):
65 x 114 x 65 mm
Issue date 2014-11-28
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Version: 8.2.8
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
12 NC: 8670 001 02363
EAN: 08 71258 16852 25
