HD Video/Audio Decoder

HD Video/Audio Decoder

HD Video/Audio Decoder

User Manual

UD.6L0203D1174A01

DS-6400HDI–T Decoder User Manual

User Manual

COPYRIGHT ©2015 Hangzhou Hikvision Digital Technology Co., Ltd.

ALL RIGHTS RESERVED.

Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision

Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.

About this Manual

This Manual is applicable to DS-6400HDI-T Decoder.

The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the company website

( http://overseas.hikvision.com/en/ ).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS

HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,

MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-

INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES,

OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT

DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS

PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT

YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS

INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY

TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH

ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

1

DS-6400HDI–T Decoder User Manual

Regulatory information

FCC information

FCC compliance

: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the

European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info

.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the

European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info

.

2

DS-6400HDI–T Decoder User Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings Follow these safeguards to prevent serious injury or death.

Cautions Follow these precautions to prevent potential injury or material damage.

Warnings

Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.

In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.

Please refer to technical specifications for detailed information.

Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 100~240 VAC or

12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information.

Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.

Please make sure that the plug is firmly connected to the power socket.

If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.

3

DS-6400HDI–T Decoder User Manual

Preventive and Cautionary Tips

Before connecting and operating your device, be advised of the following tips:

Ensure unit is installed in a well-ventilated, dust-free environment.

Unit is designed for indoor use only.

Keep all liquids away from the device.

Ensure environmental conditions meet factory specifications.

Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it may cause damage to the sensitive electronics within the unit.

Use the device in conjunction with an UPS if possible.

Power down the unit before connecting and disconnecting accessories and peripherals.

Improper use or replacement of the battery may result in explosion. Replace with the same or equivalent type only.

Dispose of used batteries according to the instructions provided by the battery manufacturer.

4

DS-6400HDI–T Decoder User Manual

Table of Contents

CHAPTER 1 Introduction ..................................................................................................................................... 7

1.1 Description

...................................................................................................................................................... 8

1.2 Features

........................................................................................................................................................... 8

CHAPTER 2 Panels and Connections ................................................................................................................. 10

2.1 Front Panel

.................................................................................................................................................... 11

2.2 Rear Panel

..................................................................................................................................................... 12

CHAPTER 3 Initial Network Parameters Configuration ................................................................................. 14

3.1

Search Active Devices Online .................................................................................................................... 15

3.2

Modify Network Parameters ...................................................................................................................... 16

3.3

Set Admin Password for the Decoder......................................................................................................... 17

CHAPTER 4 Decoder Configuration and Operation by Web Browser ............................................................ 21

4.1 Decoder Configuration

.................................................................................................................................. 26

4.1.1 Checking Device Information

............................................................................................................... 26

4.1.2 Configuring Time Settings

.................................................................................................................... 26

4.1.3 Configuring RS485/RS232 Serial Port

.................................................................................................. 28

4.1.4 Configuring Basic Network Settings

..................................................................................................... 29

4.1.5 Configuring DDNS Settings

.................................................................................................................. 30

4.1.6 Managing User Account

........................................................................................................................ 32

4.1.7 Importing/Exporting Parameters

........................................................................................................... 33

4.1.8 Upgrading, Restoring the Default Settings,and Rebooting the Decoder

............................................. 33

4.1.9 Transparent Channel .............................................................................................................................. 34

4.2 Seting Video Wall Layout

............................................................................................................................. 37

4.3 Decoding Operation

...................................................................................................................................... 38

4.3.1

Add Encoding Device ............................................................................................................................ 38

4.3.2 Decode on the Video Wall

.................................................................................................................... 40

4.3.3 Video Wall Floating

.............................................................................................................................. 41

4.3.4

Set Scene ............................................................................................................................................... 42

CHAPTER 5 Decoder Configuration and Operation by Client Software ......................................................... 45

5.1 Adding an Encoding/Decoding Device

......................................................................................................... 46

5

DS-6400HDI–T Decoder User Manual

5.2 Linking Video Output with Video Wall

........................................................................................................ 48

5.3 Displaying Video on Video Wall

.................................................................................................................. 50

5.4.1 Decoding and Displaying Video

............................................................................................................ 51

5.4.3 Windowing and RoamingSettings

......................................................................................................... 53

5.4.4 Configuring Playback

............................................................................................................................ 55

5.4.5 Configuring Cycle Decoding

................................................................................................................. 55

5.4.6

Window Configuration .......................................................................................................................... 56

CHAPTER 6 Appendix ......................................................................................................................................... 58

Appendix A. Specifications

................................................................................................................................. 59

Appendix B. FAQ ............................................................................................................................................... 61

Appendix C. List of Third-party IP Cameras Access

.......................................................................................... 63

6

DS-6400HDI-T Decoder User Manual

CHAPTER 1

Introduction

7

DS-6400HDI-T Decoder User Manual

1.1 Description

Designed for the high-definition video monitoring system, DS-6400HDI-T Series HD Video/Audio Decoder is developed on the basis of TI platform, Linux operating system and Netra processor, ensuring high reliability and stability of system running.

DS-6400HDI-T Series HD Video/Audio Decoder is capable of decoding video at 8MP resolution and outputting decoded video via BNC, VGA, DVI or HDMI interfaces, and it also supports multiple network protocols and multiple stream transmission modes. The decoded video can be displayed on video wall or large screen.

1.2 Features

Hardware Structure

Standard rack-mount structure with carrier-level ATCA chassis system.

Pluggable modular design provides high flexibility.

Up to 8 audio/video output modules can be mounted.

Dual-power supply redundancy (optional) ensures high stability and reliability of system running.

Support decoding output via BNC and DVI (DVI-to-VGA and DVI-to-HDMI supported) interfaces.

Models

DS-6401HDI-T, DS-6404HDI-T, DS-6408HDI-T, DS-6410HDI-T, DS-6412HDI-T, DS-6416HDI-T

Decoding Video and Audio

Private H.264, standard H.264, MJPEG, MPEG2 and MPEG4 video stream formats.

PS, RTP and private customized data encapsulation formats.

PAL and NTSC image standards.

DS-6401HDI-T provides the HDMI/VGA/BNC video output, and other models provide DVI/VGA/BNC video output.

Decode video stream at resolution of 8MP, 5MP, 3MP, 1080P, 720P, SVGA, VGA, 4CIF, DCIF, 2CIF, CIF and

QCIF.

G.722, G.711A, G.711U, MPEG2-L2 and ACC audio stream formats.

Getting stream and decoding via channel zero, HiDDNS and VGA/DVI local channel (not supported by DS-

6401HDI-T).

High-definition video output via DVI/VGA/HDMI interface and standard-definition video output via BNC interface.

Window spanning for video wall display.

Windowing, roaming and window splitting is available under roaming mode.

Decoding Capacity

Refer to the following table for the decoding capacity and display modes of different models:

Resolution

Resolution

Model

8MP 5MP 1080p 720p 4CIF

Split Screen

Mode

Multi-display

Mode

DS-6401HDI-T

DS-6404HDI-T

1-ch 2-ch 4-ch

2-ch 4-ch 8-ch

8-ch 16-ch

16-ch 32-ch

1/4/9/16

1/4/9/16

DS-6408HDI-T

DS-6410HDI-T

4-ch 8-ch 16-ch 32-ch 64-ch

5-ch 10-ch 20-ch 40-ch 80-ch

1/4/9/16

1/4/9/16

--

1×2, 1×3, 1×4, 2×1, 2×2

1×2, 1×3, 1×4, 2×1, 2×2,

2×3, 3×2, 2×4, 4×2

1×2, 1×3, 1×4, 2×1, 2×2,

2×3, 2×4, 2×5, 3×2, 3×3,

8

DS-6400HDI-T Decoder User Manual

DS-6412HDI-T

DS-6416HDI-T

6-ch 12-ch 24-ch 48-ch 90-ch

8-ch 16-ch 32-ch 64-ch 100-ch

1/4/9/16

1/4/9/16

4×2, 5×2

1×2, 1×3, 1×4, 2×1, 2×2,

2×3, 2×4, 2×5, 3×2, 3×3,

4×2, 5×2, 3×4, 4×3

1×2, 1×3, 1×4, 2×1, 2×2,

2×3, 2×4, 2×5, 3×2, 3×3,

4×2, 5×2, 3×4, 4×3, 5×3,

3×5, 4×4

Decoding Mode

Dynamic decoding:

Log in the remote encoder or remote stream media server to select a channel of video source to acquire video stream, and then decode and output the video for local display.

Cycle decoding:

Set multiple remote monitoring channels on a decoding channel, and the decoder is capable of performing cycle decoding according to the configured sequence and time. The stream sources can be obtained via remote access to the encoder or stream media server and decoded for local output. A maximum of

64 channels are allowed for cycle decoding.

Obtain stream from stream media server:

The decoder can receive real-time data by accessing to stream media server, and then decode the video stream and output them on the video wall. The private RTSP is adopted as the control protocol, and the TCP/UDP is used for receiving the data stream.

Remote playback of record files:

By remote access to the encoding devices with storage capability, and directly obtain the record files from the encoder, and finally decode for local output.

Network

One 10/100/1000Mbps self-adaptive Ethernet interface.

Support TCP, UDP and Multicast network protocols.

Multiple DDNS settings: Peanut Hull, Dyndns, IPServer, NO-IP and HiDDNS.

Support SADP software to automatically search and discover the online devices in local network area.

Automatically get IP address by DHCP protocol.

Remote upgrading and maintenance can be done via Web browser or client software.

User Administration

A maximum of 32 user accounts can be created by the system, including 1 administrator and 31 normal users.

The user name of the administrator is admin, which cannot be modified, and the password is allowable to be modified by the administrator only; no deletion of the administrator is allowed, and the administrator is authorized to set the operation permissions for other users.

Transparent Channel

The decoder adopts the RS-232/RS-485 serial interface to realize transparent transmission, and the transparent channel of the decoder supports multicast transparent transmission as well. Multiple transparent channels can be established simultaneously.

Two-way Audio

The decoder is capable of realizing two-way audio with the remote client.

9

DS-6400HDI-T Decoder User Manual

CHAPTER 2

Panels and Connections

10

2.1 Front Panel

Front panel of DS-6400HDI-T

DS-6400HDI-T Decoder User Manual

1 2 3 4 5 6

Figure 2.1 Front Panel of DS-6401HDI-T

7

1

2

3

4

5

6

7

Table 2.1 Description of Front Panel

LED Indicator & Interface

POWER

LINK

Tx/Rx

HDMI Video Output

VGA Video Output

Audio Output

Video Output

Connections

Power LED indicator

Network connection LED indicator

Data transmitting/receiving status LED indicator

HDMI output of decoded video

VGA output of decoded video

Audio output, 3.5mm connector

Video output, BNC connector

Figure 2.2 Front Panel of DS-6404/6408/6410/6412/6416HDI-T

1

2

3

Table 2.2 Description of Front Panel

LED Indicator & Interface

POWER

LINK

Tx/Rx

Connections

Power LED indicator

Network connection LED indicator

Data transmitting/receiving status LED indicator

11

2.2 Rear Panel

Rear panel of DS-6401HDI-T

DS-6400HDI-T Decoder User Manual

1 2 3 4

Figure 2.3 Rear Panel of DS-6401HDI-T

5

6

3

4

1

2

5

6

Interface

LINE IN/OUT

LAN

RS-232 Serial Interface

RS-485 Serial Interface

Alarm In

Alarm Out

Power Supply

Rear Panel of DS-6416HDI-T

Table 2.3 Description of DS-6401HDI-T Rear Panel

Connections

Two-way audio input/output, 3.5mm connector.

10/100/1000 Mbps Ethernet interface

Connect to RS-232 devices, e.g., PC, etc.

Connect to RS-485 devices, e.g., keyboard, etc.

4 alarm inputs

4 alarm outputs

12 VDC power input

4 7 8 12 13

1 2 3

5 6

9 10 11

Figure 2.4 Rear Panel of DS-6416HDI-T

For DS-6404/6408/6410/6412HDI-T models, 4/8/10/12 DVI-I video output connectors are provides on the rear panel.

12

DS-6400HDI-T Decoder User Manual

Table 2.4 Description of DS-6416HDI-T Rear Panel

2

3

1

4

Interface

VGA Video Input

Connections

VGA video input

DVI-I Video Input

DVI-I Video Output

LINE IN/OUT

DVI-I video input ( support DVI-to-VGA adapter)

DVI output of decoded video

Two-way audio input/output, 3.5mm connector.

AUDIO OUT

DB15 connector for audio out, connecting to audio output device with the

DB15-to-BNC adapter.

10/100/1000 Mbps Ethernet interface LAN

USB Interface Reserved

RS-232 Serial Interface Connect to RS-232 devices, e.g., PC, etc.

5

6

7

8

9

10

VIDEO OUT

DB15 connector for video output, connecting to video output device (e.g., monitor) with the DB15-to-BNC adapter.

RS-485 Serial Interface Connect to RS-485 devices, e.g., keyboard, etc.

Alarm In

Alarm Out

4 alarm inputs

4 alarm outputs

11

GND

12

Power Supply

13

Power Switch

Grounding

Power input interface

Power On/Off Switch

1.

It is recommended to use UPS power supply to ensure the high stability and reliability of the system running.

2.

The single power supply module is provided by factory default configuration.

13

DS-6400HDI-T Decoder User Manual

CHAPTER 3

Initial Network Parameters

Configuration

14

DS-6400HDI-T Decoder User Manual

Purpose:

If you don’t know the IP address of the decoder and this is not the first time you use the decoder, you can use

SADP (IP finder) software or the Serial port tools to find out the IP address of the decoder and to configure the IP address or other network parameters of it. It is recommended to change the default IP address for the first time to use it.

This chapter aims to tell the procedures of using the SADP software to find and configure the IP address and other parameters of the device.

For the first-time user, the default user name of DS-6400HDI-T is admin, and the default IP address is

192.0.0.64.

It is highly recommended to change the default user name and password after initial use.

3.1 Searching Active Devices Online

Search online devices automatically

Click to run the SADP software and it will automatically search the online devices every 15 seconds from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. is displayed.

Figure 3.1 Search Online Device by SADP

Device can be searched and displayed in the list in 15 seconds after it went online; it will be removed from the

15

DS-6400HDI-T Decoder User Manual list in 45 seconds after it went offline.

Search online devices manually

to refresh the online device list manually. The newly searched devices will be You can also click added to the list.

You can click or on each column heading to order the information; you can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.

3.2 Modifying Network Parameters

Steps:

1.

Select the device to be modified in the device list and the network parameters of the device will be displayed in the Modify Network Parameters panel on the right side.

2.

Edit the modifiable network parameters, e.g., IP address, port number and gateway.

3.

Enter the password of the admin account of the device in the Password field and click changes.

to save the

Figure 3.2 Add Searched Online Device

16

DS-6400HDI-T Decoder User Manual

3.3 Setting Admin Password for the Decoder

You are required to activate the decoder first by setting a strong password for it before you can use the device.

Activation via Web Browser and Client Software are all supported.

Activation via Web Browser

Steps:

1.

Power on the decoder, and connect the decoder to the network.

2.

Input the IP address into the address bar of the web browser, and click Enter to enter the activation interface.

Figure 3.3 Activation Interface

3.

Create a password and input the password into the password field.

STRONG PASSWORD RECOMMENDED– We highly recommend that you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend that you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

4.

Confirm the password.

5.

Click OK to save the password and enter the live view interface.

Activation via Client Software

The client software is versatile video management software for multiple kinds of devices.

Get the client software from the supplied disk or the official website, and install the software according to the

17

DS-6400HDI-T Decoder User Manual prompts. Follow the steps to activate the camera.

Steps:

1.

Run the client software and the Video Wall interface pops up, as shown in the figure below.

Figure 3.4 Control Panel

2.

Click the Device Management icon to enter the Device Management interface, as shown in the figure below.

Figure 3.5 Control Panel

3.

Check the device status from the device list, and select an inactive device.

4.

Click the Activate button to pop up the Activation interface.

18

DS-6400HDI-T Decoder User Manual

5.

Create a password and input the password in the password field, and confirm the password.

STRONG PASSWORD RECOMMENDEDWe highly recommend that you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. We recommend that you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

Figure 3.6 Activation Interface (Client Software)

6.

Click OK button to start activation.

7.

Click the Modify Netinfo button to pop up the Network Parameter Modification interface, as shown in the figure below.

Figure 3.7 Modifying the Network Parameters

19

DS-6400HDI-T Decoder User Manual

8.

Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the DHCP checkbox.

9.

Input the password to activate your IP address modification.

20

DS-6400HDI-T Decoder User Manual

CHAPTER 4

Decoder Configuration and Operation by

Web Browser

21

DS-6400HDI-T Decoder User Manual

Purpose:

You shall acknowledge that the use of the product with the Internet access might be under network security risks.

For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, contact with your dealer or the nearest service center.

Since there is no local operation GUI provided for the decoder, you can manage and configure it by Web browser or the iVMS-4200 Video Wall Client Software. In this chapter, the operation and management of the decoder by the Web browser is provided.

The tested Web browsers include: IE 8.0+, Chrome 18.0+, Firefox 5.0+, and Safari 5.02+.

Steps:

1.

Open the Web browser and input the IP address of Decoder (e.g., http://192.168.0.0) .

2. Login to the device.

Figure 4.1 Login Interface

If the device has not been activated, you need to active the device first before login.

Figure 4.2 Activation Interface

1) Set the password for admin user account.

2) Click OK to login the device.

22

DS-6400HDI-T Decoder User Manual

STRONG PASSWORD RECOMMENDEDWe highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. We recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

If the device is already activated, enter the user name and password in the login interface, and click the

Login button.

3.

The following interface is showed after successful login.

Figure 4.3 Enter WEB Page

4.

Click Configuration > Decoding Configuration and check the checkbox of Enable Roaming

Figure 4.4 Enable Roaming

5.

Click Save to pop up the dialog box interface as following.

23

DS-6400HDI-T Decoder User Manual

6.

Click OK to enter the Video Wall interface.

Figure 4.5 Note Interface

Figure 4.6 Enter WEB Page of Decoder

If the password is not strong enough, the following message box pops up to remind you to change the weak or risky password to strong password.

Figure 4.7 Note Interface

1) Click Cancel to login the device and click OK to enter the password change interface.

Figure 4.8 Password Change Interface

24

DS-6400HDI-T Decoder User Manual

2) Input the password in Password and Confirm text fields to finish the strong password settings.

Click Cancel to login the device.

25

DS-6400HDI-T Decoder User Manual

4.1 Decoder Configuration

4.1.1 Checking Device Information

Purpose:

You can check the information of the device in the device information interface, such as the Device Type, Device

Serial No., Firmware Version, Decoding Version, Web Version, Plugin Version etc.

Step:

Click Configuration > System Settings > Basic Information to view Device Type, Device Serial No.,

Firmware Version, DSP Version, etc.

The device name can be edited.

Figure 4.9 Checking Device Information

4.1.2 Configuring Time Settings

Purpose:

You can set the time for the decoder in the Time Settings interface.

Steps:

1.

Click Configuration > System Settings > Time Settings to enter the following interface:

26

DS-6400HDI-T Decoder User Manual

Figure 4.10 Configure Time Settings

2.

Configure the time synchronization by NTP server or manually.

Configuring Time Sync by NTP Server

A Network Time Protocol (NTP) Server can be configured on your device to ensure the accuracy of system date/time.

If the device is connected to a Dynamic Host Configuration Protocol (DHCP) network that has time server properties configured, the camera will synchronize automatically with the time server.

Enable the NTP function by checking the checkbox, and configure the following settings:

NTP Server: IP address of NTP server.

NTP Port: Port of NTP server.

Figure 4.11 Configure Time by NTP

If the device is connected to a public network, you should use a NTP server that has a time synchronization function, such as the server at the National Time Center (IP Address: 210.72.145.44). If the device is set up in a more customized network, NTP software can be used to establish a NTP server used for time synchronization.

Configuring Time Synchronization Manually

Enable the Manual Correction function and then click icon to set the system time from the pop-up calendar.

27

DS-6400HDI-T Decoder User Manual

Figure 4.12 Configure Time Manually

3.

Select the time zone that is closest to the device’s location from the drop-down list.

4.

Click Save to save the settings.

4.1.3 Configuring RS485/RS232 Serial Port

Configure RS232 Parameters

Steps:

1.

Click Configuration > System Settings > RS232 to enter the following interface:

Fig ure 4.13 Configure RS-232 Settings

2.

Configure the RS232 parameters, including the baud rate, data bit, stop bit and parity type.

3.

Select the Operating Mode of RS232 as Console or Transparent Channel.

Console: use the RS232 serial port for debugging the decoder.

Transparent Channel: use the RS232 serial port as the transparent channel.

4.

Click Save to save the settings.

28

DS-6400HDI-T Decoder User Manual

Configure RS485 Parameters

Steps:

1.

Click Configuration > System Settings > RS485 to enter the following interface:

Figure 4.14 Configure RS-485 Settings

2.

Configure the RS-485 parameters, including the baud rate, data bit, stop bit and parity type.

3.

Click Save to save the settings.

4.1.4 Configuring Basic Network Settings

Purpose:

You can set the network parameters for the decoder in the parameter configuration interface.

Steps:

1.

Click Configuration > Network > TCP/IP to enter the general network settings interface.

Figure 4.15 Configure Basic Network Settings

2.

Set the network parameters, including the IP Address, Subnet Mask, Gateway, and DNS Server.

3.

Click Save to save the settings.

29

DS-6400HDI-T Decoder User Manual

4.1.5 Configuring DDNS Settings

Purpose:

If your device is set to use PPPoE as its default network connection, you may set Dynamic DNS (DDNS) to be used for network access.

Prior registration with your DDNS Provider is required before configuring the system to use DDNS.

Steps:

1.

Click Configuration > Network > DDNS to enter the DDNS Settings interface:

2. Check the Enable DDNS checkbox to enable this feature.

3. Select DDNS Type. Five different DDNS types are selectable: IPServer, DynDNS, PeanutHull,

HiDDNS and NO-IP.

DynDNS:

(1) Enter Server Address for DynDNS (e.g., members.dyndns.org).

(2) Enter the User Name and Password registered in the DynDNS website.

(3) In the Domain text field, enter the domain obtained from the DynDNS website.

(4) Click Save to save the settings.

Figure 4.16 DynDNS Settings

IPServer:

(1) Enter server address for IPServer.

(2) Click Save to save the settings.

For the IP Server, you have to apply a static IP, subnet mask, gateway and primary DNS from the ISP. The

Server Address should be entered with the static IP address of the PC that runs IP Server software.

30

DS-6400HDI-T Decoder User Manual

Figure 4.17 IPServer Settings

PeanutHull:

(1) Enter User Name and Password obtained from the PeanutHull website.

(2) Click Save to save the settings.

Figure 4.18 PeanutHull Settings

HiDDNS:

(1) Enter the Server Address of the HiDDNS server: www.hik-online.com

.

(2) Enter the Domain Name of the device. You can register the alias of the device domain name in the

HiDDNS server first and then enter the alias to the domain name in the decoder; you can also enter the domain name directly on the decoder to create a new one.

If a new alias of the device domain name is defined in the decoder, it will replace the old one registered on the server.

(3) Click Save to save the settings.

31

DS-6400HDI-T Decoder User Manual

Figure 4.19 HiDDNS Settings

After having successfully registered the device on the HiDDNS server, you can access your device via Web browser or client software with the Device Domain Name (device name).

4.1.6 Managing User Account

The user accounts can be managed in this interface.

Steps:

1.

Click Configuration > System > User Management to enter the account management interface.

2.

You can add, modify or delete the user account, as well as configure operating permissions for each user account.

Figure 4.20 Configure User Account

32

DS-6400HDI-T Decoder User Manual

For the admin user, only the password can be modified.

STRONG PASSWORD RECOMMENDEDWe highly recommend that you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. We recommend that you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

4.1.7 Importing/Exporting Parameters

Purpose:

The configuration files of the device can be imported from or exported to local device for backup, which maintains convenient parameters configuration.

Steps:

1.

Click Configuration >

Syste

m

> Maintenance to enter the parameters import/export interface:

Figure 4.21 Import/Export Config File

2. Click Browse to select the file from the local directory and then click the Import button to import a configuration file. Click Device Parameters to export parameters.

4.1.8 Upgrading, Restoring the Default Settings and

Rebooting the Decoder

Steps:

1.

Click Configuration >

Syste

m

> Maintenance to do Reboot, Upgrade, and Default configurations.

Upgrade the decoder

1) Click Browse to search the upgrading files.

2) Click Upgrade to upgrade it.

Figure 4.22 Device Management

33

DS-6400HDI-T Decoder User Manual

1.

When logging in the device for first time, please install the plug-in according to the prompt on the screen.

2.

The device will restart after completing the upgrade.

Restore the default settings of the decoder:

1) Click Default to restore the completed factory settings of the decoder.

Or

Click Restore to restore a part of the factory settings of the decoder.

Figure 4.23 Default Settings

Reboot the decoder:

1) Click Reboot if you are sure to reboot the device.

Figure 4.24 Reboot the Device

4.1.9 Transparent Channel

Purpose:

The Transparent Channel refers to the transmission channel used for forwarding data between the decoder and the encoder without operating on the data.

Steps:

1. Click

Configuration

> Decoding Configuration > Transparent Channel to enter transparent channel interface.

34

DS-6400HDI-T Decoder User Manual

Figure 4.25 Transparent Channel Interface

2.

Select a transparent channel from the list to configure.

3.

Click Modify to modify the parameters of the selected transparent channel.

Figure 4.26 Modifying Interface

4.

Select the Local Serial Port and the Remote Serial Port to RS-485 or RS-232.

Local Serial Port: the serial port used as the transparent channel by the decoder.

Remote Serial Port: the serial port used as the transparent channel by the encoding device.

5.

Click Delete to pop up the following dialog box and click OK to delete the selected channel.

35

DS-6400HDI-T Decoder User Manual

Figure 4.27 Deleting Interface

36

DS-6400HDI-T Decoder User Manual

4.2 Setting Video Wall Layout

Purpose:

To realize the display of the decoded video on the video wall, you must set the Video Wall Configuration in the first place so as to link the video output with video wall.

Steps:

1.

Click Video Wall Configuration to enter the corresponding interface.

Figure 4.28 Enter Video Wall Configuration Interface

2.

You can use the default video wall layout or click to add a new layout. Enter the number of screens in row and column and up to 16 × 20 split screen is available.

Figure 4.29 Split Screen Configuration

3.

Click OK to finish the adding of the video wall information.

4.

Click and drag the output channels from the left-side list to the display screen.

Figure 4.30 Video Wall Configuration Interface

37

DS-6400HDI-T Decoder User Manual

5.

Move the cursor to the window, and icon automatically appears in the upper-right comer of the window.

Click to close the window.

Figure 4.31 Delete the Window

4.3 Decoding Operation

Purpose:

After configuration has done according to 4.2 Setting Video Wall Layout, decoding video on the TV Wall can be

realized in this section.

Steps:

1.

Click Video Wall to enter video wall interface.

No.

1

2

3

4

Figure 4.32 Video Wall Interface

Table 4.1 Description of Video Wall

Description

Camera: the camera added in the Web

Scene: the Web supports up to 8 scenes by default, capable of independent scene configuration and fast switching

TV Wall: TV Wall operation interface

Shortcut toolbar: decoding screen layout, save the scene, delete all windows, refresh all windows, at bottom

4.3.1 Adding Encoding Device

1.

Click Add to add new encoding devices.

38

DS-6400HDI-T Decoder User Manual

Figure 4.33 Encoding Device List

2.

Input Device Name, IP Address, Port, Password, Area Name and Channel Number. Check the checkbox of Get Stream by Stream Media to lower the network load of the device.

Figure 4.34 Adding Camera Interface

3.

Select one of the areas or one channel of the encoding device, and click Modify to modify corresponding parameters.

Figure 4.35 Modifying Area

39

DS-6400HDI-T Decoder User Manual

Figure 4.36 Modifying Encoding Device

4.

Select one area or one channel of encoding device and click Delete to delete the encoding device.

Figure 4.37 Deleting Camera Interface

4.3.2 Decoding on the Video Wall

Steps

1.

Drag the channel from the left side list to realize the decoding in the selected window.

Figure 4.38 Decode the Video on the Wall

2.

Select one decoding window and click to set the decoding screen layout with 1/4/9/16 split screen available.

40

DS-6400HDI-T Decoder User Manual

Figure 4.39 Split Screen Interface

3.

Right click the selected window and the following interface shows up.

Figure 4.40 Decoding Channel Interface

4.

Click Stop Decoding to stop decoding

5.

Click Decoding Status to check the decoding status.

Figure 4.41 Decoding Channel Status

4.3.3 Video Wall Roaming

Steps:

1.

Drag one camera from the left side list to the Video Wall layout, which enables decoding in the corresponding window automatically.

2.

Drag the decoding window randomly to realize the window roaming on the Video Wall.

41

DS-6400HDI-T Decoder User Manual

Figure 4.42 Video Roaming Interface

3.

Select one of the roaming windows, and click to realize split screen in the selected roaming window with 1/4/9/16 available.

4.

Generally the selected window is at top by default. Click to place the selected window at bottom.

Figure 4.43 Set Decoding at Bottom

Roaming and fluent video cannot be realized in the window with the signal outputted via BNC interfaces.

4.3.4 Setting Scene

Purpose:

Different video wall layouts are saved as different scenes and up to 8 scenes can be added.

You can easily view the required live videos on the video wall by calling the scene.

Steps:

1.

In the Video Wall interface drag the channel from the left side list to realize the decoding in the selected window.

42

DS-6400HDI-T Decoder User Manual

Figure 4.44 Saving the Scene Interface

2.

Click Save as to pop up the following dialog box.

Figure 4.45 Save as Interface

3.

Input the Name and click OK to save the scene.

Figure 4.46 Scene List

4.

Select one of the scenes you have set. Click to call the scene.

5.

Click to rename the scene.

6.

Click to delete the scene

.

Figure 4.47 Rename the Scene

43

DS-6400HDI-T Decoder User Manual

Figure 4.48 Delete the Scene

44

DS-6400HDI-T Decoder User Manual

CHAPTER 5

Decoder Configuration and Operation by

Client Software

45

DS-6400HDI-T Decoder User Manual

Run the disk of iVMS-4200 Video Wall Client Software, and double click the icon to install it in your PC. In this chapter, the basic procedure of operating the decoder by the software is described.

Please refer to the user manual of iVMS-4200 for more detailed information.

The following figure shows the main interface after accessing to the software:

Figure 5.1 Main Interface

The software is capable of many functions for controlling and managing many devices. In this manual, only the operation related to the decoder is introduced.

5.1 Adding an Encoding/Decoding Device

Steps:

1.

Click Device Management tab to enter the Device Management interface.

Figure 5.2Device Management Interface

2.

Click the Add Device and you can add device manually by means of IP address/domain, IP segment

46

and HiDDNS.

DS-6400HDI-T Decoder User Manual

Figure 5.3 Add Device by IP/Domain

3.

You can add the device by detecting the online devices. The active online decoding devices in the same local subnet with the software are displayed on the list. Select the decoder and click Add to Client to add the decoder.

Figure 5.4 Add Device by Detecting the Online Device

Please refer to the User Manual of iVMS-4200 Video Wall Client Software for detailed instructions of adding encoding/decoding device.

The successfully added encoding/decoding device can be viewed in the list.

Figure 5.5 List of Added Decoders

47

DS-6400HDI-T Decoder User Manual

5.2 Linking Video Output with Video Wall

Steps:

1.

Click Video Wall tab to enter the Video Wall setting interface.

Figure 5.6 Video Wall Layout Settings

2.

You can use the default video wall layout or click to choose one mode to edit Video Wall layout.

Figure 5.7 Add Screen Information

Three modes are available, respectively Add Video Wall, Modify Video Wall, and Delete Video Wall.

3.

Choose Add Video Wall from the drop-down list to add a new Video Wall.

48

DS-6400HDI-T Decoder User Manual

Figure 5.8 Add Video Wall

4.

Edit the video wall name, and the number of screens in row and column.

5.

Click Add to finish video wall adding.

6.

Choose Modify Video Wall to edit current video wall’s layout, name and decoding outputs

Figure 5.9 Modify Video Wall

7.

Choose Delete Video Wall and the information dialog box pops up. Click OK to delete the selected video wall.

Figure 5.10 Delete Video Wall

49

DS-6400HDI-T Decoder User Manual

 Up to 5 video walls can be added to the client software.

 The total number of display windows of the video wall is 16 × 20.

The range of the row number is between 1 and 16, and column number between 1 and 20.

8.

Click and drag the output channels from the left-side list to the display screens.

Figure 5.11 Video Wall Layouts

9.

You can select a linked display window and click Cancel to release the linkage, or click Cancel All to release all the linked windows.

10. Click Modify to save the settings.

11. In the left-side list, you can select a device and click to edit the parameters for the device, click to add decoding devices, or click to delete the device.

For the DS-6401HDI-T models, the VGA, BNC and HDMI video output interfaces are provided; and for

DS-6404/6408/6410/6412/6416HDI-T, the VGA, DVI-I and BNC video output interfaces are provided.

5.3 Displaying Video on Video Wall

Purpose:

After the settings of the encoding device, decoding device and video wall, the video stream from the encoding devices can be decoded and displayed on the Video Wall.

After enable decoding and displaying, the captured picture of the video from the encoding device displays on the

Video Wall interface. And the real-time live view is shown on the physical video wall.

50

DS-6400HDI-T Decoder User Manual

5.3.1 Decoding and Displaying Video

Steps:

1.

Close Modify Video Wall interface to go back to the Video Wall interface.

Figure 5.12 Video Wall Operation Page

2.

Click scene to display the scene interface. Click to add a new scene, click to edit the name for the scene, and click to delete the scene.

Up to 8 scenes can be added.

Figure 5.13 Video Wall Operation Page

3.

Click and drag the camera from the left side list to the display window of video wall. The video stream from the camera will be decoded and displayed on the Video Wall. You can select a decoding window and then double click a camera to decode and display the video. You can also click and hold the Ctrl or Shift key to select multiple cameras and then drag them to the video wall.

4.

Select a playing window to get a preview of the video in the lower-left corner of the screen. Or you can directly drag a camera to the preview window for live view.

51

DS-6400HDI-T Decoder User Manual

Figure 5.14 Preview Interface

You can move the cursor to the preview window and click in the lower-left corner to stop decoding.

5.

Select a decoding window and click to set the split screen with 1/4/9/16 available.

6.

If the decoded camera supports PTZ control, you can click beside PTZ to activate the PTZ control panel.

Figure 5.15 PTZ Interface

7.

Right-click on a playing window to activate the decoding management menu, as shown below:

The menu differs depending on the devices.

Figure 5.16 Right-click Menu

Stop/Start Decoding: stop/start the decoding.

Start/Pause Successive Decoding: start/pause the cycle decoding. This function is only supported by decoder.

Enable Audio: turn on/off the audio of the decoding video.

Decoding Status: view the status of the decoding channel, like decoding status and stream type.

Stick at Bottom: generally the selected window is at top by default. Click Stick at Bottom to place the selected window at bottom.

Lock/Unlock: the locked decoding window is unable to do any operation.

52

DS-6400HDI-T Decoder User Manual

Set Alarm Window: display the video triggered by event or alarm input on Video Wall.

Figure 5.17 Video Wall Display

Icon Description

Start Decoding

Stop Decoding

Stop All Window

Enable All VCA Decoding

Disable All VCA Decoding

Open Roaming Window

Refresh

The bottom bar lists several functions, but the decoder only supports Window and Log, since the iVMS 4200

Video Client Software is not only available for decoder but also for other devices.

5.3.2 Windowing and Roaming Settings

Purpose:

Windowing is to open a new window on the screen(s). The window can be within a screen or span multiple screens. Roaming means that you can move the playing window randomly within the video wall.

Steps:

1.

Click and then click and drag on a screen which links to a video output to open a window. The window can be within a screen or span multiple screens. If you want to open a window on the opened window, click and drag and hold the Ctrl key to create one. For the locked window, you can click and drag to create a new window on it.

53

DS-6400HDI-T Decoder User Manual

Figure 5.18 Roaming Interface

2.

You can move the window when the cursor becomes , and adjust the window size when becomes directional arrow. The window will be adjusted to align with the borders if it is moved to the location near the border of the screen

3.

Double click the roaming window and it enlarges to full fill the whole screen(s) and displays in the top layer. Double click again to restore the original roaming size.

4.

Select a window or open a window and click to set the split screen with 1/4/9/16 available.

Figure 5.19 Split Screen

5.

Select a window and click to disable any operations on this window. The icon appears in the upperright corner of the window when applying this function. Click to release the lock.

 Roaming and fluent video cannot be realized in the window with the signal outputted via BNC interfaces.

Figure 5.20 Signal Output via BNC Interface

54

DS-6400HDI-T Decoder User Manual

 Audio can be outputted in the window with the signal outputted via DVI-I interface. There are up to 16 audio outputs and one to one correspondence is required.

Figure 5.21 Signal Output via DVI Interface

5.3.3 Configuring Playback

Purpose:

The record file is supported to be played back on the video wall.

Playback function is only supported by decoder.

Steps:

1.

Click and drag the camera on the left-side list to the display window of video wall, or you can open a window if supported.

2.

Click Start Playback to start searching the video files of the camera.

3.

If the record file is of current day, the video file can be played back automatically. If not, you can set the search condition on the search panel (click to show the date and click More Search Conditions to specify more conditions), and click Search to find the video file.

The following icons are available for controlling the playback

Pause/Start the playback

Delete View

Slow Forward

Fast Forward

Start/Stop Clipping

Capture

5.3.4 Configuring Cycle Decoding

Purpose:

Cycle decoding refers to you can configure multiple video streams in a video output and the interval time in switching video streams.

Steps:

1.

Click and drag the camera from the left-side list to the display window of video wall, or you can open a window if supported.

2.

Click and drag a group to the window.

3.

Click to set the switching interval for the cycle decoding and click to start decoding. You can view the cycle decoding on the physical video wall. You can click to stop cycle decoding.

55

DS-6400HDI-T Decoder User Manual

Figure 5.22 Cycle Decoding

5.3.5 Window Configuration

Purpose:

You can set the window as the alarm window to display the video triggered by event or alarm input on the video wall, you can also set the decoding delay and image parameters.

Steps:

1.

Click and drag the camera from the left-side list to the display window of the video wall, or you can open a window if supported.

2.

Click Window Configuration to pop up the configuration dialog box.

3.

Figure 5.23 Window Configuration

Configure the parameters as needed. The window status shows the current status of the selected window.

Alarm Window: display the video triggered by the event or alarm input on the selected window of the video wall.

Decoding Delay: set the delay status of the decoding according to the actual needs.

Fluent Video: check the Fluent Video checkbox to enable this function to increase the frame rate of the video for playing the video more fluently.

Enable VCA Decode: enable this function to display the smart lines set by the encoding device. This function is unsupported under Fluent Video mode.

56

DS-6400HDI-T Decoder User Manual

Functions like 3D DNR, Enable Defog, and Enable Low Illumination are not supported by DS-6400HDI-

T series.

57

CHAPTER 6

Appendix

DS-6400HDI-T Decoder User Manual

58

DS-6400HDI-T Decoder User Manual

Appendix A. Specifications

Model DS-6404HDI-T DS-6408HDI-T

59

DS-6400HDI-T Decoder User Manual

4-ch 8-ch

DVI Output

1920 × 1080 @ 60/50Hz, 1600 × 1200 @ 60Hz,

1280 × 1024 @ 60Hz, 1280 × 720 @ 50/60Hz,

1024 × 768 @ 60Hz.

Audio/

Video

Input/Output

Audio/

Video

Decoding

CVBS Output

(without audio)

Video Input

2-ch 4-ch

DB15 connector (used with the DB15-to-BNC adapter)

1-ch, VGA connector; 1-ch, DVI-I connector

XGA @ 60Hz, 720p @ 60Hz, 720p @ 50Hz, UXGA @ 60Hz,

SXGA @ 60Hz, 1080p @ 50Hz, 1080p @ 60Hz, 1080I @ 50Hz,

1080I @ 60Hz, WXGA @ 60Hz, WSXGA+ @ 60Hz

4-ch, DB15 connector 8-ch, DB15 connector

Audio Output

Video Stream Format

Supported

H.264/MJPEG/MPEG4/MPEG2/Private

Audio Stream Format

Supported

G.722/G.711A/G.711U/MPEG2-L2/AAC

Decoding Capability

Split Screen Display

8MP: 2-ch

5MP: 4-ch;

1080p: 8-ch;

720p: 16-ch;

4CIF: 32-ch

1/4/9/16

8MP: 4-ch

5MP: 8-ch;

1080p: 16-ch;

720p: 32-ch;

4CIF: 64-ch

1/4//9/16

Screen Spanning Mode

1 × 2, 1 × 3, 1 × 4, 2 × 1, 2 × 2

1 × 2, 1 × 3, 1 × 4, 2 × 1, 2 × 2, 2 ×

3, 3 × 2, 2 × 4, 4 × 2

Fluent

Decoding Decoding Capability

1/4 decoding capability contrast to the normal mode

External

Interface

General

Network Interface

Serial Interface

USB Interface (reserved)

Two-Way Audio In

Two-Way Audio Out

Alarm In

Alarm Out

Power Supply

Power Consumption

Working Temperature

Working Humidity

Dimensions

(W×D×H)

Weight

1; 10/100/1000 Mbps self-adaptive Ethernet interface

1 RS-232 (DB9), 1 RS-485

2, USB 2.0

1-ch, 3.5 mm connector (2.0 Vp-p, 1 k Ω)

1-ch, 3.5 mm connector (2.0 Vp-p, 1 k Ω)

4

4

100 to 240V AC

Max. 108 W

-10° C to 55° C

(14

º F to 131º F

)

10% to 90%

440 × 340 × 70 mm (17.32" × 13.39" × 2.76")

≤5.2 kg (11.46 lb)

DS-6410HDI-T DS-6412HDI-T DS-6416HDI-T

60

DS-6400HDI-T Decoder User Manual

10-ch 12-ch 16-ch

DVI Output

1920 × 1080 @ 60/50Hz, 1600 × 1200 @ 60Hz,

1280 × 1024 @ 60Hz, 1280 × 720 @ 50/60Hz,

1024 × 768 @ 60Hz

Audio/

Video Input/

Output

Audio/

Video

Decoding

Fluent

Decoding

CVBS Output

(without audio)

Video Input

Audio Output

Video Stream Format

Supported

5-ch 6-ch 8-ch

DB15 connector (used with the DB15-to-BNC adapter)

1-ch, VGA connector; 1-ch, DVI-I connector

[email protected], [email protected], [email protected], [email protected],

[email protected], [email protected], [email protected], [email protected],

[email protected], [email protected], [email protected]

16-ch, DB15 connector

H.264/MJPEG/MPEG4/MPEG2/Private

Audio Stream Format

Supported

G.722/G.711A/G.711U/MPEG2-L2/AAC

Decoding Capability

Split Screen

Screen Spanning Mode

8MP: 5-ch

5MP: 10-ch;

1080p: 20-ch;

720p: 40-ch;

4CIF: 80-ch

1/4/9/16

1 × 2, 1 × 3, 1 × 4, 2

× 1, 2 × 2, 2 × 3, 2 ×

4, 2 × 5, 3 × 2, 3 × 3,

4 × 2, 5 × 2

8MP: 6-ch

5MP: 12-ch;

1080p: 24-ch;

720p: 48-ch;

4CIF: 90-ch

1/4/9/16

1 × 2, 1 × 3, 1 × 4, 2

× 1, 2 × 2, 2 × 3, 2 ×

4, 2 × 5, 3 × 2, 3 × 3,

4 × 2, 5 × 2, 3 × 4, 4

× 3

8MP: 8-ch

5MP: 16-ch;

1080p: 32-ch;

720p: 64-ch;

4CIF: 100-ch

1/4/9/16

1 × 2, 1 × 3, 1 × 4, 2

× 1, 2 × 2, 2 × 3, 2 ×

4, 2 × 5, 3 × 2, 3 × 3,

4 × 2, 5 × 2, 3 × 4, 4

× 3, 5 × 3, 3 × 5, 4 ×

4

1/4 decoding capability contrast to the normal mode

External

Interface

Decoding Capability

Network Interface

Serial Interface

USB Interface (reserved)

Two-way Audio In

Two-way Audio Out

Alarm In

Alarm Out

1; 10/100/1000 Mbps self-adaptive Ethernet interface

1 RS-232 (DB9), 1 RS-485

2, USB 2.0

1-ch, 3.5 mm connector (2.0 Vp-p, 1 k Ω)

1-ch, 3.5 mm connector (2.0 Vp-p, 1 k Ω)

4

4

Power Supply

100 to 240 VAC

General

Power Consumption

Working Temperature

Working Humidity

≤ 108 W

-10° C to 55° C

(14

º F to 131º F

)

10% to 90%

Dimensions

(W × D × H)

440 × 340 × 88 mm (17.32" × 13.39" × 3.46")

Weight

≤6.4 kg (14.1 lb)

Appendix B. FAQ

Why cannot ping the decoder?

61

DS-6400HDI-T Decoder User Manual

1.

Check the cable and the switch.

2.

Please refer to Chapter 3 to configure the IP address of the decoder.

Why cannot connect the decoder with client software?

1.

Check the decoder IP address.

2.

Cable is connected.

3.

User name and password of decoder are correct.

Why cannot play back the record files in DVR with decoder?

1.

Check the DVR network connection.

2.

Check the parameters of the playback file.

3.

Check if there are files existed in the selected time duration.

Why cannot decode the stream transported by stream media server?

1.

Check the network connection between decoder and stream media server.

2.

Check if the stream media server port is connected with the port added on decoder.

62

DS-6400HDI-T Decoder User Manual

Appendix C. List of Third-party IP Cameras

Access

IP Camera

Manufacturer

Panasonic

Sony

Axis

Sanyo

SAMSUNG

Bosch

Zavio

Arecont

Pelco

Onvif

Model

SP306H

SP336H

SNC-CH220

SNC-RH124

P5532

Q7404

VCC-HD2500P

SND-5080P

NBC265P

D5110

AC1305M

IX30DN-ACFZHB3

Supported

Supported Video Format

H.264, MPEG4

63

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
