Sony DR260USBS Datasheet

Sony DR260USBS Datasheet
United Kingdom
DR-260USB
This document was created on
24-Jul-2008
http://www.sony.co.uk
Stereo PC headset with flexible boom microphone and removable audio box
with control functions and USB connection. Make the most of your Internet
conversations, music listening or gaming fun.
Features
Please be aware that the features/specifications can differ from country to country.
• Lightweight hands-free stereo headset with convenient removable USB
audio box for volume and microphone sound control
• Lightweight adjustable over-the-head headband with ear pads and silent
cap design for long lasting wear and comfort and minimal sound leakage
• High sound quality through 30 mm driver units
• Ferrite Magnet and Acoustic Twin Turbo Circuit ensure deep bass and
clear treble sound
• Noise canceling flexible boom microphone filters background noise and
microphone position can be adjusted
• 3-metre long cord for easy connection to your PC
• Gold-plated stereo mini-jack (TRS) plugs minimise transmission loss
1
Useful Links
Product support
http://www.sony.co.uk
Technical
specifications
General data - for headphone
Open Air Type
YES
Dynamic Type
YES
Capacity (W)
1
Driver unit (mm)
30
Driver unit type
Dome
Frequency (Hz)
40 - 20,000
Sensitivity (dB/mW)
100
Magnet
Ferrite
Impedance (Ohm)
24
General data - for microphone
Type of microphone
Boom microphone
Electret condenser unit
YES
Bi-directional
YES
Frequency (Hz)
300 - 20,000
Open circuit voltage level (dB)
-40
Output impedance (kOhm)
1.5
Specifications
Cord length (m)
3
Cord type
Single sided
Weight without cord (g)
110
USB Interface box
Switch type 1
Microphone mute (tact)
Switch type 2
Microphone
control (rotary)
Switch type 3
Headphone volume control
(tact)
Frequency response headphone (Hz)
20 - 20,000
Frequency response microphone (Hz)
100 - 10,000
Weight of USB box (g)
40
© 2002 - 2008 Sony- Terms and Conditions
| Privacy statement
2
