safely and to alert you to potential dangers resulting from improper
connections and operations. The meanings of the pictographs are
explained below. It is important that you fully understand the meanings of the pictographs in order to use this manual and the system
properly.
This pictograph intends to alert you to the presence of
important operating instructions and installation
Warning instructions. Failure to heed the instructions may
result in severe injury or death.
BAND
CQ-C1115N
SEL
PWR
7
1
8
2
9
3
10
11
12
4
5
6
SQ/SCAN
CLOCK
DO
N
MUTE
REP
RA
SRC
D·M
TUNE/TRACK
APM
M
DISP
Caution
This pictograph intends to alert you to the presence of
important operating instructions and installation instructions. Failure to heed the instructions may result in
injury or material damage.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and traffic
conditions while driving.
Observe the following warnings when installing.
Warning
❑ Disconnect the lead from the negative (–) battery terminal before installation.
Observe the following warnings when using this
unit.
Wiring and installation with the negative (–) battery terminal connected may cause electrical shock and injury due to a short circuit.
Some cars equipped with the electrical safety system have specific
procedures of battery terminal disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM
RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL
INJURY OR DEATH.
❑ The driver should neither watch the display nor operate
the system while driving.
Watching the display or operating the system will distract the driver from looking ahead of the vehicle and can cause accidents.
Always stop the vehicle in a safe location and use the parking
brake before watching the display or operating the system.
❑ Use the proper power supply.
This product is designed for operation with a negative grounded
12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery system.
❑ Protect the Deck Mechanism.
Do not insert any foreign objects into the slot of this unit.
❑ Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the product yourself. If the product needs to be repaired, consult your
dealer or an authorized Panasonic Service Centre.
❑ Never use safety-related components for installation,
grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank, brake,
suspension, steering wheel, pedals, airbag, etc.) for wiring or fixing the product or its accessories.
❑ Installing the product on the air bag cover or in a location
where it interferes with airbag operation is prohibited.
❑ Check for piping, gasoline tank, electric wiring, and other
items before installing the product.
❑ Refer fuse replacement to qualified service personnel.
When the fuse burns out, eliminate the cause and have it replaced
with the fuse prescribed for this unit by a qualified service engineer. Incorrect replacement of the fuse may lead to smoke, fire,
and damage to the product.
Use the supplied or designated parts and appropriate tools to
install the product. The use of parts other than those supplied or
designated may result in internal damage to the unit. Faulty installation may lead to an accident, a malfunction or fire.
Otherwise these will raise the interior temperature of the unit, and
it may lead to smoke, fire, or other damage to the unit.
❑ Do not block the air vent or the cooling plate of the unit.
Blocking these parts will cause the interior of the unit to overheat
and will result in fire or other damage.
❑ Do not install the product where it is exposed to strong
vibrations or is unstable.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially sure that
the unit does not get wet in car washes or on rainy days.
Installation of this unit requires special skills and experience. For
maximum safety, have it installed by your dealer. Panasonic is not
liable for any problems resulting from your own installation of the
unit.
❑ Follow the instructions to install and wire the product.
Not following the instructions to properly install and wire the product could cause an accident or fire.
❑ Never install the product in a location where it interferes
with your field of vision.
❑ Never have the power cord branched to supply other
equipment with power.
❑ After installation and wiring, you should check the normal operation of other electrical equipment.
The continuation of their using in abnormal conditions may cause
fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipped car, confirm warnings and cautions of the vehicle manufacturer
before installation.
❑ Make sure the leads do not interfere with driving or getting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
Caution
Caution Label
This product utilizes a laser.
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
Do not take apart this unit or attempt to
make any changes yourself.
The product should be installed in a horizontal position with the
front end up at a convenient angle, but not more than 30˚.
The user should bear in mind that in some areas there may be
restrictions on how and where this unit must be installed. Consult
your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is completed before installation.
❑ To prevent damage to the unit, do not connect the power
connector until the whole wiring is completed.
❑ Do not connect more than one speaker to one set of
speaker leads. (except for connecting to a tweeter)
your car's ignition switch to the ACC
1 Set
or ON position.
2 Press [SRC] (PWR: Power).
ACC
ON
The 24-hour system is used for the clock.
1 Press [DISP] (CLOCK).
This unit is a very intricate device that uses a laser
pickup to retrieve information from the surface of
compact discs. The laser is carefully shielded so that
its rays remain inside the cabinet.
Therefore, never try to disassemble the player or alter
any of its parts since you may be exposed to laser
rays and dangerous voltages.
❑ Installation Angle
Observe the following cautions when installing.
❑ Refer wiring and installation to qualified service personnel.
LASER RADIATION WHEN OPEN. DO NOT STARE
INTO BEAM.
Avoid slanted or strongly curved surfaces for installation. If the
installation is not stable, the unit may fall down while driving and
this can lead to an accident or injury.
❑ Do not use the product where it is exposed to water,
moisture, or dust.
2 Hold down [DISP] (CLOCK) for more than
Deck Ass’y (in the unit,
upper side)
2 seconds.
3 Adjust the hour.
Before Reading These Instructions
If you need to open a hole in the vehicle chassis to attach or wire
the product, first check where the wire harness, gasoline tank, and
electric wiring are located. Then open the hole from outside if possible.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an abnormal
state (has foreign objects in it, is exposed to water, is smoking, or
smells), turn it off immediately and consult your dealer.
❑ Do not expose the unit to direct sunlight or excessive
heat.
CAUTION
❑ Use the designated parts and tools for installation.
❑ This unit is designed for use exclusively in automobiles.
❑ Do not operate the unit for a prolonged period with the
engine turned off.
Operating the audio system for a long period of time with the
engine turned off will drain the battery.
Operating Instructions
When wiring, take care not to damage the leads. Prevent them
from getting caught in the vehicle chassis, screws, and moving
parts such as seat rails. Do not scratch, pull, bend or twist the
leads. Do not run them near heat sources or place heavy objects
on them. If leads must be run over sharp metal edges, protect the
leads by winding them with vinyl tape or similar protection.
Observe the following cautions when using this
unit.
CLASS 1 LASER PRODUCT
Label Indications and Their Locations
❑ Take care not to damage the leads.
Caution
First Time Power On
■ This manual uses pictographs to show you how to use the product
nents of your car audio system carefully before using the system.
They contain instructions about how to use the system in a safe and
effective manner. Panasonic assumes no responsibility for any problems resulting from failure to observe the instructions given in this
manual.
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components, and
assembled by people who are proud of the reputation their work has built for our company. We know this product will bring you many hours of
enjoyment, and after you discover the quality, value and reliability we have built into it, you too will be proud to be a member of our family.
Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
[[]: sets the hour ahead.
[]]: sets the hour back.
Clock Setting
CQ-C1115N
■ Read the operating instructions for the unit and all other compo-
Laser Product
Model:
English
CD Player/Receiver
Preparation
Safety Information
4 Press [DISP] (CLOCK).
5 Adjust the minute.
[[]: sets the minute ahead.
[]]: sets the minute back.
This symbol on the products and/or accompanying documents means that used electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be
accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to your local
retailer upon the purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling. Please contact your local authority for further
details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
6 Press [DISP] (CLOCK).
Notes:
¡ “AdJ” is displayed before adjusting the clock.
¡ Hold down []] or [[] to change numbers rapidly.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union
¡Please read these instructions carefully before using this product and keep this manual for future reference.
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
For customers within the UK: 08705 357357
For customers within the Republic of Ireland: 01 289 8333
Visit our website for product information
E-mail: [email protected]
:YFM294C083CA)
Q'ty: 1
PAN EUROPEAN GUARANTEE
Q'ty: 1
Mounting Bolt
Mounting Collar
(FX0214C384ZB)
Trim Plate
(YFC054C079YA)
Q'ty: 1
Power Connector
(YEAJ02874)
Q'ty: 1
Request for use of the Removable Face Plate Case
¡ To avoid trouble and ensure safety, use the optional
Removable Face Plate Case (YFC054C061ZB)
If you use commercial CDs, they must have the label
shown at right.
Some copy-protected music CDs are not playable.
How to hold a disc
¡ Do not touch the underside of a disc.
¡ Do not scratch on a disc.
¡ Do not bend a disc.
¡ When not in use, keep the disc in a case.
Printed side
¡ In direct sunlight
¡ Near car heaters
¡ Dirty, dusty and damp areas
¡ On seats and dashboards
Labels created by a printer,
protective films or sheets
Irregularly shaped discs
Anti-Theft System
<Wrong>
Do not write on the disc label with a ballpoint pen or
other hard-point pens.
DC 12 V (11 – 16 V), test voltage 14.4 V, negative ground
Less than 2.2 A (CD mode; 0.5 W x 4 channels)
Bass: ±12 dB at 100 Hz, Treble: ±12 dB at 10 kHz
178 x 50 x 155 mm
1.3 kg
45 W x 4 channels (at 1 kHz), volume control maximum
20 W x 4 (DIN 45 324, at 4 Ω)
4–8Ω
Sampling frequency
DA converter
Pick-up type
Light source
Wave length
Frequency response
Signal to noise ratio
Wow and flutter
Channel separation
8 times oversampling
1 bit DAC System
Astigma 3 – beam
Semiconductor laser
790 nm
20 Hz – 20 kHz (±1 dB)
96 dB
Below measurable limits
75 dB
Warning
¡ Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the unit directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your nearest authorized
Panasonic Service Centre.
Disc cleaning
<Correct>
Power supply
Current consumption
Tone adjustment range
Dimensions (W x H x D)
Weight
Maximum power output
Power output
Speaker impedance
If the replaced fuse fails, contact your nearest authorized Panasonic Service Centre.
Do not leave discs in the following places:
Use a dry, soft cloth to wipe from the center outward.
Your product is designed and manufactured to ensure the minimum of maintenance. Use a dry, soft cloth for routine
exterior cleaning. Never use benzine, thinner, or other solvents.
This unit is equipped with a removable face plate. Removing this face plate makes the unit totally inoperable.
Disc with adhered
stickers or tape
Discs with cracks,
scratches or parts missing
¡ This face plate is not waterproof. Do not expose it to
water or excessive moisture.
¡ Do not remove the face plate while driving your car.
¡ Do not place the face plate on the dashboard or nearby
areas where the temperature rises high.
¡ Do not touch the contacts on the face plate and the main
unit, since this may result in poor electrical contact.
¡ If dirt or other foreign substances get on the contacts,
wipe them off with a clean and dry cloth.
Removing
Mounting
1
2 Press [ ]. The face plate will open.
3 Pull it out toward you.
1
2 Press the right end of face plate until a
Turn off the power.
Slide the left side of the face plate in place.
“click” is heard.
[
FM
Frequency Range
Usable Sensitivity
Stereo Separation
87.5 MHz – 108 MHz
6 dB/µV (S/N 30 dB)
35 dB (at 1 kHz)
AM (MW)
Radio
(Anti-Theft System)
¡ You may have trouble playing back some CD-R/RW discs
recorded using CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints,
scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and
high humidity than ordinary music CDs. Leaving them
inside a car for extended periods may damage them and
make playback impossible.
¡ Some CD-R/RWs cannot be played back successfully due
to incompatibility among writing software, a CD recorder
(CD-R/RW drive) and the discs.
¡ This player cannot play the CD-R/RW discs if the session is
not closed.
¡ This player cannot play the CD-R/RW discs which contain
other than CD-DA data.
¡ Be sure to observe the instructions of the CD-R/RW disc
for handling it.
Face Plate Removing/Mounting
Caution
Notes on
CD-Rs/RWs
¡
¡
¡
¡
(English
Notes:
¡ The number in parentheses underneath
each accessory part name is the part
Q'ty: 2
number for maintenance and service.
¡ Accessories and their part numbers are
subject to modification without prior
notice due to improvements.
Q'ty: 1
¡ Mounting Collar and Trim Plate are
mounted on the main unit at shipment.
Q'ty: 1
General
Customer Care Centre
Q'ty: 1
Installation Instructions
Installation kit (ZZBISC1021N-J)
Lock Cancel Plate
Specifications
Disc Player
For UK and Ireland customers only.
¡ Order accessories and consumable items for your product
with ease and confidence by phoning our Customer Care
Centre Monday - Thursday 9:00am - 5:30pm, Friday
9:30am - 5:30pm. (Excluding public holidays).
¡ Or go on line through our Internet Accessory ordering
application at www.panasonic.co.uk.
¡ Most major credit and debit cards accepted.
¡ All enquiries, transactions and distribution facilities are
provided directly by Panasonic UK Ltd.
¡ It couldn't be simpler!
¡ Also available through our Internet is direct shopping for a
wide range of finished products, so take a browse on our
website for further details.
:YFM284C651CA)
Cleaning the
Unit
Sales and Support Information
(English
Maintenance
Fuse
Operating Instructions
Direct Sales at Panasonic UK
Notes on Discs
Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)
Accessories
Frequency Range
Usable Sensitivity
531 kHz – 1 602 kHz
28 dB/µV (S/N 20 dB)
]
Matsushita Electric Industrial Co., Ltd.
Web Site: http://panasonic.net
YFM284C651CA PTW1206-1106
Printed in China
Notes:
¡ Specifications and design are subject to modification without notice due to improvements.
¡ Some figures and illustrations in this manual may be different from your product.
Radio (AM [MW]/FM)
PWR
3
10
11
12
4
5
6
SQ/SCAN
CLOCK
DO
REP
M
DISP
Source Selection
(ROCK) speedy and heavy sound:
exaggerates bass and treble.
1
Disc Player
9
2
10
3
11
4
12
5
CLOCK
DO
REP
[DISP] (Display)
(CLOCK)
switches the information on the display.
sets the clock time.
DISP
M
(VOCAL) clear sound:
emphasizes middle tone and slightly emphasizes treble.
Down
Mute
Note: Settings of SQ, bass and treble are influenced one
another. If such an influence causes distortion to the audio
signal, readjust bass/treble or volume.
Frequency adjustment
lights.)
Troubleshooting
Preset station selection
Press the corresponding preset button from [1] to [6] to
tune into a preset station.
D•M station calling
D•M station writing
1 Press [D•M].
1 Select a station you would like to preset.
2 Hold down [D•M] for more than 2 seconds.
Check point
No power
No sound
Noise
No sound from
left, right, front,
or rear speaker
Left and right
sounds are
reversed
● Disable the mute function.
● Verify the wiring.
● Wait until the dew disappears before
turning on the unit.
● Make sure that grounding is established
properly.
● Adjust the balance and fader.
● Verify the wiring.
● Connect the speaker lead correctly.
Disc Player
No sound, or disc
is automatically
ejected
● Load the disc correctly.
● Clean the disc.
Sound skip,
poor sound
quality
● Clean the disc.
Sound skip
due to
vibration
● The maximum permissible tilt angle is
30°.
● Secure the unit.
Disc not
ejectable
● Press [u]. If the disc is still not ejected,
contact the nearest Panasonic Service
Centre.
TUNE/TRACK
7
8
2
9
10
11
12
4
5
6
3
SQ/SCAN
CLOCK
DO
REP
M
DISP
[DISP] (Display)
exits from the audio
menu.
[▲] [▼]
selects a value in the audio menu.
Trouble
Check point
Radio
● Start the engine. (Or turn the ignition
switch to the ACC position.)
● Verify the wiring. (battery lead, power
lead, ground lead, etc.)
● Fuse blown (Contact the nearest
Panasonic Service Centre.)
● Ask a professional for fuse replacement.
● Be sure to use the same rated fuse.
MUTE
1
Frequent
noise
● Tune in to another station of high-intensity waves.
● Make sure that the antenna mounted
point is grounded properly.
Preset data
deleted
● The preset memory is cleared to return
to the original factory setting when the
power connector or battery is disconnected.
1 Press [SEL] (Select) to display the audio menu display.
Note: If no operation takes place for more than 5 seconds in the audio menu (2 seconds in Main volume adjustment), the display returns to the regular mode.
2 Press [SEL] (Select) to select a mode to
be adjusted.
(Setting Range: 0 to 40, Default: 18)
Error Display Messages
(The disc is ejected automatically.)
The disc is dirty, or is upside down.
The disc has scratches.
● Check the disc.
No operation by some cause.
● If normal operation is not restored, consult your dealer or the nearest Service
Centre to ask for repairs.
3 Press [▲] or [▼].
Volume
q : Up
w : Down
Bass
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
Audio Menu
Common
PWR
SRC
D·M
N
Trouble
CQ-C1115N
SEL
RA
Never take measures especially for those other than indicated by italic letters in “Check point” described below because
those are too dangerous for users to handle themselves.
BAND
APM
q : Increased
w : Decreased
Treble
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
q : Increased
w : Decreased
Balance
(Setting Range: 15 levels each and 0 (center),
Default 0)
q : Right enhanced
w : Left enhanced
Fader
(Setting Range: 15 levels each, Default CNT (centre))
q : Front enhanced
w : Rear enhanced
[u] (Eject)
ejects the disc.
Band/frequency
lights while receiving the D•M (Direct Memory)
station.
Clock display
(y / 5) (Pause/Play)
toggles pause/play in the
player source.
BAND
CQ-C1115N
APM
SEL
PWR
MUTE
SRC
seconds.
7
1
8
2
9
3
10
11
12
4
5
6
D·M
SQ/SCAN
CLOCK
DO
REP
M
DISP
[DISP] (Display)
switches the information on the
display.
[REP] (Repeat)
toggles on/off the repeat play.
(RANDOM)
toggles on/off the random play. (Hold down it for
more than 2 seconds.)
[1] to [6]
(7) to (12) (Hold down one of
them for more than 2 seconds.)
select a track directly.
Manual station preset
Press [DISP] (Display) to change the display.
Player mode display (Default)
Clock display
lights when a disc is in the player.
[1] to [6] for more than 2 seconds.
Repeat indicator
Random play
Caution
(blinks once)
Display change
Track
(SCAN)
toggles on/off the scan play. (Hold down it for more than 2
seconds.)
1 Tune into a station.
2 Hold down one of the preset buttons from
All the available (tracks) are played in a random sequence.
¡ Do not insert a disc when the
indicator lights.
¡ Refer to the section of “Notes on Discs”.
¡ This unit does not support 8 cm discs.
¡ If you insert an 8 cm disc and cannot eject it,turn the ignition key
to the ACC OFF position once and turn the key to the ACC ON position again, then press [u] (Eject).
¡ Do not insert foreign objects into the disc slot.
Hold down [REP] (RANDOM) for more
than 2 seconds.
1 Press [SRC] to select the Disc Player
source.
2 Select a desired portion.
Note: New stations overwrite existing saved stations.
Pause
Press [BAND] (y / 5).
Press again to cancel.
Track selection
Direct track selection
Press [6] / [7].
Press a track number button from [1] to [6].
Note: To perform fast forward/reverse, hold down either
of them.
¡ The corresponding track (1-6) starts playing.
Next track:
[7]
Previous track: [6]
Memorandum
Hold down a track number button from [1]
to [6] ((7) to (12)) for more than 2 seconds.
Scan play
The first 10 seconds of each track is played in sequence.
Hold down [SQ] (SCAN) for more than 2
seconds.
Hold down again to cancel.
Note: New stations overwrite existing saved stations.
The preset stations under best receiving conditions are
received for 5 seconds each after presetting the stations
(SCAN). To stop scanning, press one of the buttons from
[1] to [6].
Memorandum
Warning
[SEL] (Select)
selects items in the audio menu.
FM mode:
1 Select a band.
2 Hold down [BAND] (APM) for more than 2
Note: Hold down either of them for more than 0.5 seconds and release it for seek tuning.
Audio Settings
¡ Do not use the unit in an irregular condition, for example, without sound, or with smoke or a foul smell, which can cause
ignition or electric shock. Immediately stop using the unit and
consult your dealer.
¡ Never try to repair the unit by yourself because it is dangerous
to do so.
indicator
With this operation, stations with good receiving conditions can
be automatically stored in the preset memory.
If You Suspect Something Wrong
Check and take steps as described below.
If the described suggestions do not solve the problem, it is recommended to take the unit to your nearest authorized Panasonic Service
Centre. The product should be serviced only by qualified personnel.
Please refer the checking and the repair to professionals. Panasonic
shall not be liable for any accidents arising out of neglect of checking
the unit or your own repair after your checking.
Clock display
Auto Preset Memory (APM)
[TUNE ]]: Lower
[TUNE []: Higher
Press again to cancel.
Printed side
Up to 6 stations can be preset in AM (MW), FM1, FM2, and
FM3 respectively.
Preset stations can be simply called up by pressing one of the
preset buttons from [1] to [6].
Up
(Setting Range: 0 to 40, Default: 18)
UP
:Press [▲]
Down :Press [▼]
Band/frequency
[SRC] (Source)
selects a source.
3 Select a station.
(POP) wide-ranged and deep sound:
slightly emphasizes bass and treble.
Volume Adjustment
SQ/SCAN
6
1 Press [SRC] to select the radio source.
2 Press [BAND] to select a band.
Direct Memory
General Operations
Press [SRC] to change the source.
8
Operation Flow
(FLAT) flat frequency response:
does not emphasize any part. (Default)
[6] [7]
skip to the previous/next track in
the player source.
Hold down either of them for fast
reverse/fast forward.
N
SQ is a function that can call up various sound types at the
touch of button in accordance with your listening music
type.
Press [SQ] to select the sound type as follows:
Press [DISP] to change the display.
RA
Set your car's ignition switch to the ACC or ON position.
ON: Press [MUTE]. (
OFF: Press [MUTE] again.
7
Preset buttons [1] to [6]
selects a preset station in the radio
source, and presets the current
[TUNE ]] [TUNE []
station. (Hold it down for more
down/up the frequency. (Hold it down for more
than 2 seconds.)
than 0.5 seconds and release it for seek tuning.)
SQ (Sound Quality)
Power on: Press [SRC] (PWR).
Power off: Hold down [SRC] (PWR) for
more than 1 second.
MUTE
SRC
[SQ] (Sound Quality)
selects a sound type (SQ).
[MUTE]
toggles mute on/off.
Power On/Off
Radio
PWR
[SRC] (Source)
selects a source
N
[SRC] (Source)
selects a source.
(PWR) (Power)
toggles power on/off.
9
2
D·M
RA
8
1
SEL
N
7
CQ-C1115N
APM
RA
MUTE
SRC
Preset Number
Play time
Player Source Display
TUNE/TRACK
SEL
Band
Random indicator
Disc slot
takes a disc in with the printed side facing
up.
AM (MW) mode:
BAND
D·M
Frequency
Display change
Random, Repeat, Scan
CQ-C1115N
(Stereo) indicator
lights while receiving an FM stereo signal.
TUNE/TRACK
BAND
APM
[D•M] (Direct Memory)
tunes into the station memorized in D•M. (Hold
down it for more than 2 seconds to memorize
the current station.)
Radio Source Display
lights when mute is on.
[BAND]
selects a band in the radio source.
(APM) (Auto Preset Memory)
executes APM in the radio source.
(Hold it down for more than 2 seconds.)
Station Preset
[D•M] (Direct Memory)
tunes into the station memorized in D•M.
(Hold down it for more than 2 seconds to
memorize the current station.)
TUNE/TRACK
[VOLUME▲] [VOLUME▼]
adjusts the volume.
Disc Player
Operation Flow
General
Repeat play
The current (track) is repeated.
Press [REP] (REPEAT).
Press again to cancel.
¡ The corresponding track (7-12) starts playing.
Memorandum
(blinks during scanning)
Hold down again to cancel.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
