2

NEW TECHNOLOGY GUIDE

CONTENTS

MATRIX SWITCHERS

FLX-64

HDBaseT Matrix Switcher

DL-HDM44-SS / DL-HDM66-SS / DL-HDM88-SS

Standard Matrix Switchers

DL-HDM44-FS / DL-HDM88-FS Fast Matrix Switchers

INT-44HDX / INT-66HDX / INT-88HDX

HDBaseT HDCP 2.2 Matrix Switchers

3

4

5

6

VIDEO OVER IP

INT-IPEX1001/1002

HDMI Over IP MJPEG Extenders

INT-IPEX2001/2002 HDMI Over IP H.264 Extenders

INT-IPEX5001/5002 HDMI Over IP JPEG2000 Extenders

INT-IPEXCB HDMI Over IP Control Box

DISTRIBUTION AMPLIFIERS

HD14S / HD18S HDMI 2.0 Distribution Amps

DL-DA12S / DL-DA14S HDMI Distribution Amps

11

12

13

DIGI-1X4B-1H HDBaseT Distribution Amp

LBC-SPH-1H3B-EIR / LBC-SPH8-1H7B-EIR

HDBaseT Distribution Amps

AUTO SWITCHERS AND EXTENDERS

DL-S41 4x1 Slim HDMI Auto Switcher

DL-AS21C 2x1 HDMI VGA Auto Switcher

DL-AS61 6x1 HDMI VGA Auto Switcher

DL-AS31-2H1V 3x1 HDMI VGA Auto Switcher

DL-AS31-2H1DP 3x1 HDMI DisplayPort Auto Switcher

DL-AS31-1H1DP1V 3x1 HDMI VGA DisplayPort Auto Switcher

14

AS-2H / AS-2H-WP Dual HDMI Auto Switcher

AS-1H1V / AS-1H1V-WP HDMI VGA Auto Switcher

AS-1H1DP / AS-1H1DP-WP HDMI Displayport Auto Switcher

EDU-KIT-001 Multi-Funtion AV Distribution for Classrooms

HDBASET EXTENDERS

DIGI-HD60-WP-S HDBaseT Wall Plate Extender

INT-HDX100-TX / INT-HDX100-RX HDBaseT 100m Extenders

26

27

INT-HDXL100-TX / INT-HDXL100-RX HDBaseT 150m Extenders

27

INT-HD70-TX / INT-HD70-RX HDBaseT 70m Extenders

RACK12 EXT / PSU12 Extender Accessories

DL-HD60-ARC HDBaseT Extender with Audio Return Channel

DIGI-BSR-4K HDBaseT 100m Scaling Receiver

DL-HDE100 Slim HDBaseT 100m Extender

DL-HD70 Slim HDBaseT 70m Extender

ADDITIONAL EXTENDERS / CONVERTERS

28

29

30

31

32

33

DL-HDCOAX HDMI IR Over Coax Extender

34

20

21

22

23

24-25

15

16

17

18

19

9

10

7

8

3G-12EQ SDI Equalizer with Dual Outputs

3G-14 1x4 SDI Distribution Amplifier

3G-SH SDI to HDMI Converter

3G-HS HDMI to SDI Converter

DL-FO-HDLC HDMI Over Fiber Extender Module

DL-HDCP-C HDCP 2.2 to 1.4 Converter

DL-SP HDMI Surge Protector

USB 3.0 EXTENSION

DL-USB3.0 Active Extension Cable

DIGI-FO-USB3.0 Fiber Extender System

USB 2.0 EXTENSION

DIGI-HDUSB HDMI and USB 2.0 Extension System

DIGI-USB2-4P USB 2.0 4-Port Extension System

AUDIO AMPLIFICATION

AUD-220 2 Input Audio Amplifier

AUD-340 3 Input Audio Amplifier

TECHNOLOGY ALLIANCE PARTNERS

BROADATA

NIVEO

SP CONTROLS

ACCESSORIES

FLEXBOX-WH AV Enclosure Box

BYOD-PUCK AV Connection Hub

DL-AR Customizable HDMI Adapter Ring

TRB-2V1AD / TSPB-2V1AD / TDPB-2V1AD Table Top AV Boxes

HDMI CABLES

HDPMM HDMI Premium 18G Cable

HDMI Cable Solutions

DL-HDM-M HDMI Premium 18G Active Optical Cable

PF-HDM-M HDMI Premium 18G Active Optical Plenum Cable

FIBER OPTIC GATEWAY (FOG) HDMI/AV Extension System

FIBER OPTIC CABLE

STRONGER, SAFER, FASTER (SSF) FIBER SOLUTIONS

STANDARD FIBER SOLUTIONS

PRODUCT HIGHLIGHTS

CATEGORY CABLE SOLUTIONS

RF COAXIAL SOLUTIONS

SERIAL DIGITAL SOLUTIONS

SPEAKER CABLE SOLUTIONS

41

41

42

43

44

45

46-49

50-53

54-55

64-67

68-70

56

57

57

58

71-73

74-75

76-77

78-79

35

36

37

38

39

40

40

59

60-61

62

62

63

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

MATRIX SWITCHERS

FLX-64

6 INPUT, 4 OUTPUT HDMI/HDBASET MATRIX SWITCHER AUDIO EMBED/DE-EMBED WITH BREAKAWAY ROUTING key features

6 × 4 MATRIX SWITCH

2 HDBASET INPUTS

AUDIO BREAKAWAY

RECEIVERS & TRANSMITTERS

The Intelix

FLX-64

was designed for use in conference rooms that have two in-room inputs extended to the rack, a few local sources at the rack, two discrete displays, a VTC codec & a recorder. The FLX-64 can be controlled via front panel buttons, front panel IR, external IR, remote IR through HDBaseT extenders, RS232 & Ethernet.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

(Inputs 1 through 4)

Four HDMI Type A receptacle

HDBaseT Inputs (Inputs 5 & 6)

Two 8P8C Port (shielded RJ45 female)

Balanced Analog Audio

Inputs (Inputs 1 & 2 only)

Two 5-Pole/3.5mm Euroblock

Two 3.5mm TRS

IR Input Tunnel

(Inputs 5 & 6 only)

IR Outputs

(Inputs 1 through 4)

Four 3.5mm TRS

HDMI Outputs

(Outputs 1 & 2 only)

HDBaseT Outputs

Two HDMI Type A receptacle

Balanced Analog

Audio Outputs

RS232 Output Tunnel

Four 8P8C Port (Shielded RJ45 female)

Four 5-Pole/3.5mm Euroblock

Four 3-Pole/3.5mm Euroblock

IR All In

IR Eye

TCP/IP

RS232

AC Power Inlet

One 3.5mm TRS

One 3.5mm TRS

One 8P8C Port (Shielded RJ45 female)

One DE9 Port female

IEC C14

SUPPORTED AUDIO, VIDEO & CONTROL

Maximum Video

Compatibility at 60m

Maximum Video

Compatibility at 35m

Deep Color 36/30/24 Bit at

1080p

Deep Color 48 Bit at 1080p % 3D

Maximum Passive

HDMI Cable Distance

5m (16.4ft)

Video Compliance

Embedded Audio

Input DDC Signal

HDMI and HDCP

Up to PCM 8 channel, Dolby

Digital TrueHD & DTS-HD

Master Audio

5.0 volts p-p (TTL)

Input Video Signal

Analog Audio Pinout

TCP/IP Speed

RS232 Baud Rate

IR Carrier

Frequency Range

0.5 to 1.0 volts p-p

Left +, Left -, Ground, Right +,

Right -

100BaseT

9600, 19200, 38400 & 115200 baud

33-55kHz at 5 volts

HDBaseT SIGNAL CHARACTERISTICS

Maximum Distance

60m

Cable Requirements

Bandwidth

Gain

Solid core shielded Cat 5e, Cat 6 or greater 568B pin out

10.2 Gbps

0 dB – 10 dB at 100 MHz

> 70 dB at 100 MHz over 100 m

Signal to Noise

Ratio (SNR)

Return Loss

Total Harmonic

Distortion (THD)

Min-Max Signal Level

< -30 dB at 5 KHz

< 0.005% at 1 KHz

< 0.3 V – 1.45 Vp-p

Differential Phase Error

±10° at 135 MHz over 100m

CHASSIS & ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions

Shipping Weight

89mm x 437mm x 332mm

(3.5 in x 17.2 in x 13.1 in) – 2 RU

6.5 kg (14.4 lbs.)

Operating Temperature

0° to +48° C (+32° to +120° F)

Operating Humidity

Storage Temperature

Storage Humidity

10% to 90%, Non-condensing

-20° to +70° C (+14° to +158° F)

10% to 85% non-condensing

POWER, ESD & REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.8A

Power Supply Output

Power Consumption

ESD Protection

Product Regulatory

24VDC / 1.25A

200 watts (max)

15kV

FCC, CE, RoHS

Power Supply Regulatory

CE, RoHS

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. Intelix specifications are based on straight-through cabling with standard-grade Cat 5e unless noted otherwise.

OTHER

Standard Warranty

Diagnostic Indicators

2 years

Power LED, System LCD

Included Accessories

Installation guide, IR remote, IR eye, rack mounting ears with screws, rubber feet, US power cable, straightthrough DE9 male to female RS232 cable, six 3.5mm TRS to 3.5mm TR IR cable

Compatible Transmitters

(AV & Control)

DIGI-P52, DIGI-P123

Compatible Transmitters

(AV & Power)

DIGI-HD60-S

Compatible Transmitters

(AV, Control & Power)

ASW-WP, DIGI-HD60C-S, DIGI-

HDX-S

Compatible Receivers

(AV & Power)

DIGI-HD60-R

Compatible Receivers

(AV, Control & Power)

DIGI-HD60C-R, DIGI-HDX-R

LIBERTY INVENTORY SERVICES

It's like having a bigger workforce for free!

WHAT'S THE BENEFIT?

Reduced Procurement Costs & Increased Revenue

Easy Scan & Checkout

Pay only when you consume the materials.

No start-up costs or maintenance fees.

Possible Savings: Tens of thousands of dollars

THE PROGRAM

Pay only when you consume the materials

On-site consigned inventory management program for day-to-day install materials. Inventory is on-site, not "virtual" with an unknown vendor warehouse.

Dedicated LIS Service Coordinator & redundant back-up.

Live webinar demonstration available.

Open to the entire catalog of Liberty's products including custom cable, install kits, assemblies, connectors, racks, devices, fiber & more!

Initial launch package includes estimated two months supply.

Automated monthly replenishment of inventory with FREE surface freight. (Racks excluded)

Liberty provides on-site training synchronized with initial delivery.

JOIN THE CROWD!

The best companies in the Pro A/V industry use

LISyou should too!

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

3

MATRIX SWITCHERS

DL-HDM44-SS / DL-HDM66-SS / DL-HDM88-SS

4X4, 6X6, 8X8 HDMI MATRIX HDMI 2.0, HDCP 2.2 COMPLIANT

DL-HDM44-SS

DL-HDM88-SS

DL-HDM66-SS

The DigitaLinx

DL-HDMxx-SS

series of matrix switchers are available in four, six or eight HDMI ouputs with HDCP 2.2 and a full-loading capability

[email protected] output for each channel. These switchers feature advanced independent DIP switch for EDID management with HDCP handling, including the ability to turn input HDCP compliance ON and OFF to ensure maximum functionality with a wide range of sources. These matrix switchers can be controlled via front panel buttons, front panel IR, external IR, remote IR, RS232, and Ethernet.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

HDMI Outputs

Four (4) HDMI Type A Receptacle

Four (4) HDMI Type A Receptacle

IR All In

TCP/IP

RS232

Power

One (1) 3.5mm TRS

One (1) 8P8C Port (Shielded RJ45 Female)

One (1) DE9 Port Female

One (1) IEC C14

SUPPORTED AUDIO, VIDEO, AND EMBEDDED CONTROL

Video Resolutions

Up to [email protected] (chroma sub-sampling 4:2:0 8-bit only) Color Depth: 1080p 48bit / 4K 24bit

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted Aluminum

Dimensions (H x W x D)

43 mm x 437 mm x 299 mm

(1.69 in x 17.20 in x 11.77 in) – 1 RU

Shipping Weight

Operating Temperature

4.22kg (9.30 lbs.)

0° to +45° C (+32° to +113° F)

Operating Humidity

Storage Temperature

Storage Humidity

10% to 90%, Non-condensing

-20° to +70° C ( -4° to +140° F)

10% to 90%, Non-condensing

Maximum Passive HDMI

Cable Distance

Video Compliance

Embedded Audio

Embedded RS232 Baud Rate

5 m (16.4 ft)

HDMI 2.0 and HDCP 2.2

Up to PCM 8 channel, Dolby Digital TrueHD, and

DTS-HD Master Audio

9600 baud

DEVICE CONTROL PARAMETERS

IR Carrier Frequency Range

33-55kHz at 5 volts

Ethernet

RS232 Baud Rate

100BaseT

9600 baud

POWER, ESD, AND REGULATORY

Power Supply

100V-240VAC / 50-60 Hz

Power Consumption

ESD Protection

Product Regulatory

35.5W (Max.)

8kV air, 4kV contact

FCC, CE, RoHS

OTHER

Standard Warranty

2 years

Diagnostic Indicators

System LCD

Included Items

Installation Guide, IR Remote, IR Receiver, Rack Mounting Ears with Screws,

US Power Cable, USB to UART Cable

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

4

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

MATRIX SWITCHERS

DL-HDM44-FS / DL-HDM88-FS

4X4, 8X8 HDMI MATRIX WITH SEAMLESS SWITCHING AND SCALING PER OUTPUT UP TO 4K

DL-HDM44-FS

The DigitaLinx

DL-HDMxx-FS

series of matrix switchers offer four by four or eight by eight outputs with seamless 4K scaling. These HDMI matrix switchers support up to [email protected] and

HDCP2.2. With a high-performance [email protected] video scaler built into each output channel, it easily scales various resolutions to match the best video and picture quality across all displays.

The DL-HDMxx-FS series matrix switchers provide each HDMI output with a de-embedded 3-pin unbalanced stereo audio out to feed an audio amplifier system. The matrix features advanced independent DIP switch for EDID management with HDCP handling, including the ability to turn input HDCP compliance ON and OFF to ensure maximum functionality with a wide range of sources.

DL-HDM88-FS

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Four (4) HDMI Type A Receptacle

HDMI Outputs

Analog Audio Outputs

IR All In

TCP/IP

RS232

Power

Four (4) HDMI Type A Receptacle

Four (4) 3-Pole/3.5mm Euroblock

One (1) 3.5mm TRS

One (1) 8P8C Port (Shielded RJ45 Female)

One (1) 3-pin Removable Terminal Block Connector

One (1) IEC C14

SUPPORTED AUDIO AND VIDEO

Video Resolutions

VESA:

[email protected],[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

SMPTE: 720x4[email protected],[email protected],

[email protected]/60Hz, [email protected]/60Hz,

[email protected]/25/30Hz

Deep Color

1080p 36bit / 4K 24bit

Maximum Passive HDMI

Cable Distance

Video Compliance

Audio Format Supported

Embedded RS232 Baud Rate

5 m (16.4 ft)

HDMI1.4 / HDCP2.2

Multi-channel digital audio, PCM2.0 and Dolby5.1.,

2-CH stereo audio de-embedded

57600 baud

DEVICE CONTROL PARAMETERS

IR Carrier Frequency Range

33-55kHz at 5 volts

Ethernet

100BaseT

RS232 Baud Rate

57600 baud

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted Aluminum

Dimensions (H x W x D)

43 mm x 437 mm x 326 mm

(1.69 in x 17.20 in x 12.83 in) – 1 RU

Shipping Weight

Operating Temperature

4.86kg (10.71 lbs.)

0° to +45° C (+32° to +113° F)

Operating Humidity

Storage Temperature

Storage Humidity

10% to 90%, Non-condensing

-20° to +70° C ( -4° to +140° F)

10% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Power Supply

100V-240VAC / 50-60 Hz

Power Consumption

ESD Protection

Product Regulatory

75W(Max.)

8kV air, 4kV contact

FCC, CE, RoHS

OTHER

Standard Warranty

2 years

Diagnostic Indicators

System LCD

Included Items

Installation Guide, IR Remote, IR Receiver, Rack Mounting Ears with Screws, US Power

Cable, USB to UART Cable, (8) 3.5mm 3pin Phoenix

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

5

MATRIX SWITCHERS

INT-44HDX / INT-66HDX / INT-88HDX

4X4, 6x6, 8x8 HDBASET MATRIX SWITCH; 100M, 4K, HDCP 2.2, POH

INT-44HDX NT-66HDX INT-88HDX

The Intelix

INT-xxHDX

series is a 4x4, 6x6 or 8x8 output HDBaseT/HDMI matrix switcher with HDCP 2.2 and UHD/30 video support. The matrices feature advanced EDID and HDCP handling, including the ability to turn input HDCP compliance ON and

OFF to ensure maximum functionality with a wide range of sources. This series provides HDBaseT twisted pair extension for each output, and simultaneous HDMI on the first two outputs, allowing the same signal to be routed to the HDMI connector and a remote destination with an HDBaseT receiver. The HDBaseT ports support up to UHD/30 HDMI video with audio, bidirectional wide-band IR, matrix control via IR, RS232 tunneling, and HDCP (1.4 and 2.2) up to 100 meters (328 feet). Each HDBaseT output port supplies power to the attached extender, eliminating the need for a power supply at the display end.

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Four (4) HDMI Type A Receptacle

IR Outputs

HDMI Outputs

(Outputs 1 and 2 only)

Four (4) 3.5mm TRS

Two (2) HDMI Type A Receptacle

HDBaseT Outputs

Digital Audio Outputs

Analog Audio Outputs

RS232 Tunnel

IR All In

IR Eye

TCP/IP

RS232

Power

Four (4) 8P8C Port (Shielded RJ45 Female)

Four (4) RCA Connectors

Four (4) 3-Pole/3.5mm Euroblock

Four (4) 3-Pole/3.5mm Euroblock

One (1) 3.5mm TRS

One (1) 3.5mm TRS

One (1) 8P8C Port (Shielded RJ45 Female)

One (1) DE9 Port Female

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

SUPPORTED AUDIO, VIDEO, AND EMBEDDED CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p,

UHD/30 (HDMI only) Color Depth: 24, 30, 36, 48bit

Maximum Video

Compatibility at 100 m

Deep Color 48 Bit at 1080p and 3D, UHD/30

Maximum Passive HDMI

Cable Distance

Video Compliance

Embedded Audio

5 m (16.4 ft)

Analog Audio Pinout

Embedded RS232 Baud Rate

IR Carrier Frequency Range

HDMI 1.4, HDCP 1.4 and HDCP 2.2

Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-

HD Master Audio

Left, Ground, Right

2400, 4800, 9600, 19200, 38400, and 115200 baud

33-55kHz at 5 volts

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

100 m (328ft)

Cable Requirements

Continuous solid core Category 5e or greater with

TIA/EIA-568B crimp pattern (no couplers in-line)

Bandwidth

HDBaseT Chipset

10.2 Gbps

VS100TX

DEVICE CONTROL PARAMETERS

IR Carrier Frequency Range

33-55kHz at 5 volts

Ethernet

RS232 Baud Rate

100BaseT

9600 baud

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted Aluminum

Dimensions (H x W x D)

Shipping Weight

Operating Temperature

44 mm x 437 mm x 235 mm (1.73 in x 17.20 in x 9.25 in) – 1 RU

3.95 kg (8.7 lbs.)

0° to +48° C (+32° to +120° F)

Operating Humidity

Storage Temperature

Storage Humidity

10% to 90%, Non-condensing

-20° to +70° C (+14° to +158° F)

10% to 85%, Non-condensing

POWER, ESD, AND REGULATORY

Power Supply

24V DC 1.25A or PoH (Power over HDBaseT)

Power over Ethernet (PoE)

Compatibility

Power Consumption

802.3af Alternative A, 15 watts per port, 48V available at remote device

48 watts (max)

ESD Protection

Product Regulatory

15kV air, 8kV contact

UL, FCC, CE, RoHS

OTHER

Standard Warranty

Diagnostic Indicators

2 years

Power LED, System LCD

Compatible Receivers (AV and Power)

DIGI-HD60-R

Compatible Receivers (AV,

Control, and Power)

DIGI-HD60C-R, DIGI-HDX-R

Included Accessories

Installation Guide, IR Remote with AAA Batteries, IR Eye, Rack Mounting Ears with

Screws, Chassis Feet with Screws, US Power Cable, Power Supply, Straight-Through DE9

Male to Female RS232 Cable, Eight (8) 3-pole Removable Terminal Blocks

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

6

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

VIDEO OVER IP

INT-IPEX1001

HDMI over IP Encoder - MJPEG

The

INT-IPEX1001

is an HDMI video to M-JPEG encoder which transmits the video via

UDP through the LAN output. Since UDP is a unidirectional protocol, the INT-IPEX1001 has a built-in EDID of 1080p/30 with 2 channel audio.

The

INT-IPEX1002

receives the UDP stream on the LAN input & decodes the M-JPEG video back to an HDMI formatted video stream.

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

LAN port

One 8P8C-F

HDMI Input

5vDC Input

One HDMI Type A Receptacle

One threaded locking barrel

(5.5mm OD; 2.6mm ID)

SUPPORTED AUDIO AND VIDEO

Maximum Video

Compatibility

24 Bit at 1080p

Video Compliance

HDMI 1.3 and HDCP 1.3

Embedded Audio

PCM 2-channel, 44.1 and 48 KHz

ETHERNET SIGNAL CHARACTERISTICS

Maximum Distance

100m

Cable Requirements

Ethernet Standards

PoE Standards

Transcoder

Compression

Solid core Cat 5e, Cat 6 or greater with 568B pin out

IEEE 802.3/802.3u/802.3x/802.

1p/802.1q

IEEE 802.3af/at (Type 1)

Motion JPEG

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Galvanized Steel

Enclosure Dimensions

(H x W x D)

Shipping Weight

21.5mm x 120mm x 60mm

(0.85 in x 4.72 in x 2.36 in)

0.18 kg (0.40 lbs)

Operating

Temperature

0° to +55° C (+32° to +131° F)

Operating Humidity

10% to 90%, Non-condensing

Storage Temperature -40° to +85° C (-40° to +185° F)

Storage Humidity

10% to 85%, non-condensing

POWER AND REGULATORY

Power Consumption

(INT-IPEX1001)

4.2 watts

Power Consumption

(INT-IPEX1002)

ESD Protection

3.5 watts

±15 kV

Product Regulatory

CE, FCC, RoHS

key features

Point-to-point and point-to-multipoint (250 Decoders)

PoE PD (powered by switch) or local power (not included)

MJPEG compression with stereo audio

100 m (328 ft) range per junction

Compatible with Ethernet switches

Uses any Cat5/5e/6/6A twisted pair cabling

OTHER

Warranty

Diagnostic Indicators

2 years

Power, Link, Data

Power Supply

(sold separately)

PS-5D-10

Included Accessories

Installation guide, rubber feet (4 ea), mounting brackets

(2 ea) with screws

INT-IPEX1002

HDMI OVER IP DECODER - MJPEG

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

LAN port

One 8P8C-F

HDMI Input

5vDC Input

One HDMI Type A Receptacle

One threaded locking barrel

(5.5mm OD; 2.6mm ID)

SUPPORTED AUDIO AND VIDEO

Maximum Video

Compatibility

24 Bit at 1080p

Video Compliance

HDMI 1.3 and HDCP 1.3

Embedded Audio

PCM 2-channel, 44.1 and 48 KHz

ETHERNET SIGNAL CHARACTERISTICS

Maximum Distance

100m

Cable Requirements

Ethernet Standards

PoE Standards

Solid core Cat 5e, Cat 6 or greater with 568B pin out

IEEE 802.3/802.3u/802.3x/802.1

p/802.1q

IEEE 802.3af/at (Type 1)

Transcoder

Compression

Motion JPEG

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Enclosure Dimensions

(H x W x D)

Shipping Weight

Galvanized Steel

21.5mm x 120mm x 60mm

(0.85 in x 4.72 in x 2.36 in)

0.18 kg (0.40 lbs)

Operating

Temperature

0° to +55° C (+32° to +131° F)

Operating Humidity

10% to 90%, Non-condensing

Storage Temperature -40° to +85° C (-40° to +185° F)

Storage Humidity

10% to 85%, Non-condensing

POWER AND REGULATORY

Power Consumption

(INT-IPEX1001)

4.2 watts

Power Consumption

(INT-IPEX1002)

ESD Protection

3.5 watts

±15 kV

Product Regulatory

CE, FCC, RoHS

OTHER

Warranty

Diagnostic Indicators

2 years

Power, Link, Data

Power Supply

(sold separately)

PS-5D-10

Included Accessories

Installation guide, rubber feet (4 ea), mounting brackets

(2 ea) with screws

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

7

VIDEO OVER IP

INT-IPEX2001 / INT-IPEX2002

HDMI OVER IP H.264 ENCODER AND DECODER

5001/5002

INT-IPEX2001

ENCODER

INT-IPEX2002

DECODER

The Intelix

INT-IPEX2001/2002

transmits HDMI video and audio over a gigabit IP network using h.264 AVC encoding with a data rate up to 30 Mbps. The INT-IPEX2001 supports video signals up to 1920x1200 at 60 Hz. The INT-IPEX2001 outputs two video streams: one large IP stream at the native content resolution and a smaller video stream at 352x288 at 5 Hz to easily view a preview of the content on PC software or an iPad. An analog audio output port de-embeds the audio from the HDMI content, while still streaming the audio with the video content. The INT-IPEX2001/2002 supports PoE and can be powered remotely by compatible power source equipment, such as a PoE Ethernet switch, eliminating the need for a nearby power outlet. Encoding control provides adjustments for encoding bit rate and quality. The RS232 port operates in a pass-through capacity to control a third party device such as a projector.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

Ethernet

Power

RS232 Port

One (1) 8P8C port (Shielded RJ45)

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

One (1) 3-pin Removable Terminal Block Connector

Audio Output

One (1) 3-pin Removable Terminal Block Connector

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480p, 576p, 720p, 1080i, 1080p VESA: Resolutions up to 1920x1200 Color Depth: 24, 30, 36 bit

Video Compliance

Embedded Audio

ARC (Audio

Return Channel)

HDMI 1.3 and HDCP 1.3

Up to PCM 6 channel, Dolby Digital, and DTS

No

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

No

Yes

Supported Baud Rates

2400, 4800, 9600, 19200, 38400, 57600, 115200

STREAMING SIGNAL CHARACTERISTICS

Maximum Distance

(point to point)

100 m (328 ft)

Cable Requirements

Category 5e or greater with TIA/EIA-568B crimp pattern

Bandwidth

End to End Latency

30 Mbps

Low Latency Mode: 79 ms High Quality Mode: 250 ms

CHASSIS AND ENVIRONMENTAL

Construction

Black Alumininum

Dimensions (H x W x D)

25 mm x 237 mm x 94.3 mm (0.98in x 9.33 in x 3.71 in)

Operating

Temperature

Operating Humidity

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

Storage Temperature

-10° to +60° C (+14° to +140° F)

Storage Humidity

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

12V DC 1A or 48V DC PoE (Power over Ethernet)

Power over Ethernet

(PoE) Compatibility

802.3af Alternative B

Power Consumption

ESD Protection

Regulatory

6 watts

8kV air, 4kV contact

FCC, CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

HDCP, Link, and Power

Included Accessories

Installation Guide, Power Supply, 3-pin Removable Screw

Terminal (2 ea), Mounting Ears (2 ea)

Optional Accessories

INT-IPEXCB

Compatible Decoder

INT-IPEX2002

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

8

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

VIDEO OVER IP

INT-IPEX5001 / INT-IPEX5002

HDMI OVER IP JPEG2000 ENCODER AND DECODER

The Intelix

INT-IPEX5001/5002

transmits

HDMI video and audio over a gigabit IP network using JPEG2000 encoding. The

INT-IPEX5001 supports video signals up to 4K at 60 Hz 4:2:0 with HDCP 2.2 and 7.1 multichannel audio. An analog audio input port embeds the audio with the video content, such as a DVI video source.

The INT-IPEX5001/5002 supports PoE and can be powered remotely by compatible power source equipment, such as a PoE

Ethernet switch, eliminating the need for a nearby power outlet. The RS232 port relays commands from the IP controller and operates in a pass-through capacity to control a third party device such as a projector. The USB connection passes keyboard and mouse signals from the

INT-IPEX5002 decoder to the INT-IPEX5001.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

HDMI Output

One (1) HDMI Type A Receptacle

LAN

Power

RS232 Port

USB Device

Audio Input

IR Input

IR Output

One (1) 8P8C port (Shielded RJ45)

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

One (1) 3-pin Removable Terminal Block Connector

One (1) USB Type B Port

One (1) 3.5 mm TRS Receptacle

One (1) 3.5 mm TRS Receptacle

One (1) 3.5 mm TRS Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

Video Compliance

SMPTE: 480p, 576p, 720p, 1080i, 1080p, VESA: Resolutions up to 1920x1200 Color Depth: 24, 30, 36 bit

HDMI 2.0 and HDCP 1.4/2.2

Embedded Audio

ARC (Audio

Return Channel)

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

Supported Baud

Rates

USB Compliance

Up to PCM 8 channel, Dolby Digital True HD, and DTS-HD

Master Audio

No

No

Yes

2400, 4800, 9600, 19200, 38400, 57600, 115200

HID only

STREAMING SIGNAL CHARACTERISTICS

Maximum Distance

(point to point)

100 m (328 ft)

Cable Requirements

Category 5e or greater with TIA/EIA-568B crimp pattern

CHASSIS AND ENVIRONMENTAL

Construction

Black Alumininum

Dimensions (H x W x D)

25 mm x 220 mm x 130.2 mm (0.98in x 8.66 in x 5.13 in)

Operating

Temperature

0° to +40° C (+32° to +104° F)

Operating Humidity 20% to 90%, Non-condensing

Storage Temperature -10° to +60° C (+14° to +140° F)

Storage Humidity

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

12V DC 1A or 48V DC PoE (Power over Ethernet)

Power over Ethernet

(PoE) Compatibility

802.3af Alternative B

Power Consumption 6 watts

ESD Protection

8kV air, 4kV contact

Regulatory

FCC, CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators HDCP, Link, and Power

Included Accessories Installation Guide, Power Supply, 3-pin Removable Screw

Terminal, Mounting Ears (2 ea), IR emitter, IR receiver

Optional Accessories INT-IPEXCB

Compatible Decoder INT-IPEX5002

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

9

VIDEO OVER IP

INT-IPEXCB

HDMI OVER IP CONTROL BOX

The Intelix

INT-IPEXCB

is an IP control box that is used as an A/V control device for controlling, configuring and managing encoders and decoders on the local area network. It integrates two Ethernet ports and two RS232 ports, offering integrationfriendly control features, including a web GUI . It also can be used with a third party controller to provide a simple, flexible control and management options. The INT-IPEXCB can automatically search and display encoders and decoders. It is designed to be compatible with the configuration file from the PC configurator software (HDMI over IP Console) and use the imported configuration file to perform operations on encoders and decoders such as matrix and video wall. The INT-IPEXCB is compatible with Intelix INT-IPEX2000 and INT-IPEX5000 series streaming IP devices.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

LAN

Two (2) 8P8C port (Shielded RJ45)

Power

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

RS232 Port

Reset Button

One (1) 6-pin Removable Terminal Block Connector

One (1) Recessed Microswitch

SUPPORTED CONTROL

Supported Baud

Rates

9600 (control) and 115200 (debug)

Ethernet

1000BaseT

LAN Maximum

Distance

LAN Cable

Requirements

100 m (328 ft)

Category 5e or greater with TIA/EIA-568B crimp pattern

CHASSIS AND ENVIRONMENTAL

Construction

Black Steel

Dimensions

(H x W x D)

Operating

Temperature

26 mm x 93.2 mm x 138.7 mm (1.02 in x 3.67 in x 5.46 in)

0° to +40° C (+32° to +104° F)

Operating Humidity 20% to 90%, Non-condensing

Storage Temperature -10° to +60° C (+14° to +140° F)

Storage Humidity

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

12V DC 1A or 48V DC PoE (Power over Ethernet)

Power Output

(RS232 port)

12V DC 0.5A

Power over Ethernet

(PoE) Compatibility

802.3af Alternative B

Power Consumption 4.5 watts (10.5 watts when using 12V on RS232 port)

ESD Protection

Regulatory

8kV air, 4kV contact

FCC, CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

Status and Power

Included Accessories Installation Guide, Power Supply, 6-pin Removable Screw

Terminal

Compatible

Encoders

INT-IPEX2001, INT-IPEX5001

Compatible

Decoders

INT-IPEX2002, INT-IPEX5002

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

10

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

DISTRIBUTION AMPLIFIERS

HD14S / HD18S

1X4, 1X8 HDMI 2.0 DISTRIBUTION AMPLIFIER

The Intelix

HD14S

(1x4) or

HD18S

(1x8) are distribution amplifiers that have an HDMI splitter with HDMI 2.0 and

HDCP 2.2. They support data rates up to

18Gbps and resolutions of [email protected]

(4:2:0). These distribution amplifies features EDID management which provides multiple EDID options for various resolutions output and HDCP encryption between all devices, ensuring the HDMI source reliably outputs the correct content for the display.

HD14S

The Intelix HD14S and HD18S include input cable equalization and signal regeneration compensation, which reduces the need for additional signal conditioning equipment by compensating for signal loss when using long input cables or cascading multiple units.

HD18S

1x4 HDMI distribution amplifier/splitter

4K, HDMI 2.0, HDCP 2.2 compliant

Adjustable EDID management

Field firmware upgradeable

Locking power supply

Includes mounting hardware

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

HDMI Outputs

Four (4) HDMI Type A

Receptacle (1 per output)

SUPPORTED AUDIO AND VIDEO

Maximum Data Rate

18 Gbps

HDTV Video Resolutions

VESA Video Resolutions

480p, 576p, 720p, 1080i, 1080p, 4Kx2K @30Hz,

4Kx2K @60Hz (4:2:0)

Up to 1920x1200

Embedded Audio

Compatibility

Maximum Passive

HDMI Distance

Compliance

Maximum Pixel Clock

Input DDC Signal

Up to PCM 5 channel, Dolby Digital TrueHD, and DTS-HD Master Audio

5m (16 ft)

HDMI 2.0, HDCP 2.2

600MHz

5V

CHASSIS AND ENVIRONMENTAL

Enclosure

Dimensions (W x H x D)

Painted aluminum

167 mm x 69 mm x 18 mm (6.57 in x 2.71 in x 0.70 in)

Shipping Weight

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0.30 kg (0.66 lbs)

0° to +45° C (+32° to +113° F)

10% to 90%, Non-condensing

-20° to +70° C (+4° to +140° F)

10% to 90%, Non-condensing

POWER, ESD AND REGULATORY

Maximum Power

Consumption

1080p: 2 W (max) / 4K: 2.5 W (max)

Power Supply Input Voltage

100-240v AC at 50/60 Hz at 0.35A

DC 12V 0.5A

Power Supply

Output Rating

ESD Protection

Device Regulatory

Power Supply

Regulatory

OTHER

Warranty

Diagnostic Indicators

8kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

2 years

Power LED, Input LED, Four (4) Output Status LEDs

Included Accessories

Installation guide, power supply, mounting “L” brackets (2 ea), mounting screws (2 ea),

3 pole RS232 connector.

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

11

DISTRIBUTION AMPLIFIERS

DL-DA12S / DL-DA14S

1 × 2 OR 1 × 4 HDMI DISTRIBUTION

AMPLIFIER/SPLITTER

The Digitalinx

DL-DA12S

one by two and

DL-DA14S

one by four HDMI distribution amplifiers support 3D and 4K video resolutions as well as multichannel audio formats. The EDID setting is defined by the highest compatible resolution of all connected displays. They feature diagnostic LEDs on the front of the product indicating the state of the connections into and out of the unit.

key features

1 ×2 or 1 x 4 HDMI distribution amplifier/splitter

3D & 4K video support

Diagnostic LEDs

Field firmware upgradeable

Ultra slim

Plug-and-play, no drivers required

Powered on port (client) end

DL-DA12S

DL-DA14S

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One HDMI Type A receptacle

HDMI Outputs

5v DC Power

Firmware Port

Two or Four HDMI Type A receptacle (1 per output)

One 2.35mm outside diameter,

0.7mm inside diameter barrel

(EIAJ-1)

One ,mini USB Type B receptacle

SUPPORTED AUDIO AND VIDEO

Maximum Data Rate

10.2 Gpbs

HDTV

Video Resolutions

480i, 480p, 576i, 576p, 720p, 1080i,

1080p, 1080p 3D, 4K × 2K (24, 25

& 30Hz)

Up to 1920

× 1200

VESA Video

Resolutions

Embedded Audio

Compatibility

Maximum Passive

HDMI Distance

Compliance

Up to PCM 5 channel,

Dolby Digital TrueHD & DTS-HD

Master Audio

5m (16ft)

HDMI 1.4, HDCP 1.1, DVI 1.0

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions

(W x H x D)

Shipping Weight

11mm × 102.4mm × 70.4mm

(0.43 in × 4.03 in × 2.77 in)

0.83 kg (1.87 lbs)

0° to +40° C (+32° to +104° F)

Operating

Temperature

Operating Humidity

20% to 90%, Non-condensing

Storage Temperature

-10° to +60°C (+14° to +140°F)

Storage Humidity

20% to 90%, non-condensing

POWER, ESD AND REGULATORY

Maximum Power

Consumption

5 watts

100-240v AC at 50/60 Hz at 0.5A

Power Supply

Input Voltage

Power Supply

Output Rating

ESD Protection

5v DC at 1 A

15kV

Device Regulatory

Power Supply

Regulatory

CE, RoHS

CE, RoHS, TUV, UL, SGS

OTHER

Warranty

2 years

Diagnostic Indicators

Power LED, Input LED, four output Status LEDs

Included Accessories

Installation guide, power supply, AC adapters (AU, EU,

UK, and US), rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

NEED HELP?

We offer technical assistance on all of our products or applications!

Call us at 800-530-8998 or email

[email protected]

12

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

DISTRIBUTION AMPLIFIERS

DIGI-1X4B-1H

DISTRIBUTION AMP - 1 HDMI INPUT TO 4 HDBASET OUTPUT PLUS 1 HDMI OUTPUT the intelix digi-

1X4B-1H

is designed with a hdmi loop out

which is intended to cascade to additional units, allowing for system expansion for larger systems. A unique control design allows the RS232 port to be addressed and cascaded, allowing control commands to be discretely directed to the RS232 port of any attached

HDBaseT receiver.

This design allows third party control systems to reduce the number of COM ports required, thus reducing hardware costs.

The Intelix DIGI-1X4B-1H is HDMI compatible and supports up to 4k × 2k resolutions, Deep Color and full 3D capabilities. The

DA features advanced EDID and HDCP handling, including EDID copy and preset modes.

HDMI DISTRIBUTION AMP WITH FOUR (4) HDBaseT

OUTPUTS AND ONE (1) HDMI LOOP OUTPUT

The Intelix DIGI-1X4B-1H features HDBaseT twisted pair extension for four (4) outputs, allowing the same signal to be routed to a remote destination with a HDBaseT receiver.

The HDBaseT ports support up to 4Kx2K HDMI video with audio, wide-band IR tunneling (for IR control of source or displays), RS232 tunneling, and HDCP up to 60 meters (196 feet). Each

HDBaseT output port supplies power to the attached extender, eliminating the need for a power supply at the display end.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

HDBASET OUTPUTS

HDMI OUTPUT

RS232 IN

RS232 LOOP

IR INPUT

IR Loop

IR OUTPUT

24V DC POWER

One

(1) 3.5

mm TRS

One

(1) 3.5

mm TRS

One

(1) 3.5

mm TRS

One

(1)

Locking Barrel (

5.5

mm OD,

2.1

mm ID)

CHASSIS AND ENVIRONMENTAL

ENCLOSURE

DIMENSIONS

SHIPPING WEIGHT

OPERATING TEMPERATURE

OPERATING HUMIDITY

Painted Aluminum

(

44 mm ×

220 mm ×

148 mm

1.73

in ×

8.66

in ×

5.83

in) – 1RU

0.67

kg (

1.48

lbs)

0

° to +

48

°C (+

32

° to +

120

°F)

10

% to

90

%, Non-condensing

STORAGE TEMPERATURE

STORAGE HUMIDITY

MIN-MAX SIGNAL LEVEL

DIFFERENTIAL PHASE ERROR

-20

° to +

70

° C (+

14

° to +

158

°F)

10

% to

85

%, Non-condensing

< 0.3

V –

1.45

V p-p

± 10

° at

135

MHz over

100 m

POWER, ESD AND REGULATORY

POWER SUPPLY INPUT

100

V-

240

VAC /

50-60

Hz /

0.8

A

POWER SUPPLY OUTPUT

POWER CONSUMPTION

ESD PROTECTION

PRODUCT REGULATORY

POWER SUPPLY REGULATORY

One

(1)

HDMI Type A Receptacle Connector

Four

(4)

Shielded RJ4

5

Female

One

(1)

HDMI Type A Receptacle Connector

One

(1) 3

-Pole /

3.5

mm Euroblock

One

(1) 3

-Pole /

3.5

mm Euroblock

24

VDC /

1.25

A

30 watts (max)

15 kV

FCC, CE, RoHS

CE, RoHS

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. Liberty Wire & Cable specifications are subject to change without notice. Contact an account representative for current product specifications. Liberty Wire & Cable continuously strives to ensure product specifications are accurate and complete. All physical specifications are nominal.

SUPPORTED AUDIO, VIDEO AND CONTROL

MAX. VIDEO COMPATIBILITY AT 60 M

Deep Color

36

/

30

/

24

Bit at

1080 p

MAX. VIDEO COMPATIBILITY AT 35 M

MAX. PASSIVE HDMI CABLE DISTANCE

VIDEO COMPLIANCE

EMBEDDED AUDIO

INPUT DDC SIGNAL

Deep Color

48

Bit at

1080 p, 3D and

4 k ×

2 k

5 m (

16.4

ft)

HDMI and HDCP

Up to PCM

8

channel, Dolby Digital TrueHD and DTS-HD Master Audio

5V p-p (TTL)

INPUT VIDEO SIGNAL

RS232 BAUD RATE

IR CARRIER FREQUENCY RANGE

0.5

to

1

V p-p

9600

,

19200

,

38400

and

115200

baud

33-55 kHz at

5

V

HDBASET SIGNAL CHARACTERISTICS

MAX. DISTANCE

CABLE REQUIREMENTS

BANDWIDTH

60 m

Solid core shielded Cat

568B pin out

5 e, Cat

6

or greater with

10.2

Gbps

GAIN

SIGNAL TO NOISE RATIO (SNR)

0 dB –

10 dB at

100

MHz

>

70 dB at

100

MHz over

100 m

RETURN LOSS

< -

30 dB at

5 kHz

TOTAL HARMONIC DISTORTION (THD)

<

0.005

% at

1 kHz

MIN-MAX SIGNAL LEVEL

DIFFERENTIAL PHASE ERROR

<

0.3

V –

1.45

Vp-p

±

10

° at

135

MHz over

100 m

OTHER

STANDARD WARRANTY

DIAGNOSTIC INDICATORS

INCLUDED ACCESSORIES

2

years

Power LED, HDMI Input LED, HDMI Output LED,

HDBaseT Link LEDs, HDBaseT HDCP LEDs

Installation Guide, Power Supply, IR Emitter, IR

Receiver, IR Loop Cable

DIGI-HD

60

-R

COMPATIBLE RECEIVERS (AV & POE)

COMPATIBLE RECEIVERS

(AV & CONTROL)

COMPATIBLE RECEIVERS

(AV, POE & CONTROL)

FLX-B

I4

DIGI-HDXL-R, DIGI-HDX-R, DIGI-HD

60

C-R

National Electric Code® is a registered trademark of the National Fire Protection Agency (NFPA).

NEC® is a registered trademark of the National Fire Protection Agency (NFPA).

HDMI® is a registered trademark of HDMI, LLC.

High Definition Multimedia Interface® is a registered trademark of HDMI, LLC.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

13

DISTRIBUTION AMPLIFIERS

LBC-SPH-1H3B-EIR / LBC-SPH8-1H7B-EIR

LINK BRIDGE 1X4, 1X7 HDMI SPLITTER TO 1 HDMI & 3, 7 CAT5E/6/7 WITH LAN/IR, POH-TX

LBC-SPH8-1H7B-EIR

LBC-SPH-1H3B-EIR

1 in 3 or 1 in 7 out HDBaseT Splitter

Video Resolutions up to Ultra HD (4K2K)@60 Hz

Supports HDCP, DDC/EDID

Video/Audio+IR+LAN, Over 1 CAT 5e/6 Cable

Supports PoH (Power over HDBT) with compatible recievers

Fully Uncompressed Video/Audio Zero Loss of Quality

LEVERAGE OUR SERVICES AS AN

EXTENSION OF YOUR WORKFORCE!

Consolidate purchases, save time, labor and improve your profitability by putting the expansive Liberty Edge services to work for you!

TECH SPECS

VIDEO/ AUDIO SPECIFICATIONS

HDMI

Version 1.4 with 3D, 4K×2K support

Video Resolution

4K2K & up to [email protected] or

[email protected]

Protocol

Video Bandwidth

Audio Operating Mode

Audio Formats

Audio Sampling Rate

HDMI/Audio Connector

DDC/EDID/HDCP Capable

340MHz / 10.2Gbps

Stereo Audio

Supports up to 7.1CH & Dolby TrueHD, DTS-HD

Master Audio

32KHz to 192KHz

HDMI Female plug

DATA

Network

Data Rate

Connector

IR Control

Data Rate

In/Out Connectors

LAN (only available in -EIR model)

100Mbps (only available in -EIR model)

RJ45 (only available in -EIR model)

Infrared

30 - 50KHz

3.5mm Stereo

PHYSICAL

Dimensions Standalone

Power Consumption

5.71” (145mm)(W) x 7.83” (199mm)(D) x

1.18”(30mm)(H)

+24VDC @ 2.7 Amps (Max.)

Operating Temperature

Humidity

0 to +40oC

20 to 90% RH, Non-Condensing

HDBT TRANSMISSION

Cable Type

Number of Cables

Connector/ Distance

OTHER

Standard Warranty

CAT 5e/6 or higher

1

3x RJ-45 / Up to 100m

2 years

14

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

DL-S41

BLACK DIGITALINX 4X1 HDMI AUTOSWITCHER

The new

DL-S41

is a small format auto-switcher with four HDMI video inputs and one HDMI output. This switcher supports HDMI video resolutions up to 4K (3840x2160) at 30 Hz, 1080p 3D, and multichannel audio. In addition to passing EDID information from the display, there are multiple built-in EDID settings to simplify an installation. The DL-S41 will de-embed digital stereo audio to allow for an existing audio system. This switcher also features audio return channel (ARC) support through the analog audio output.

When in auto-switch mode, the DL-S41 will switch to a HDMI input as soon as a new source is connected. When the active source is removed, the switcher will select the first source on the lowest numbered input. The DL-S41 may also be controlled via RS232, IR with the included remote, or from the source button on the front of the switcher.

key features

Auto-switch or manual switch between four HDMI inputs

One HDMI and one 3.5 mm (ARC & audio de-embedding) output

Front panel, IR and RS232 control

UHD, 1080p, 3D compatible; HDCP compliant

Need Help?

We offer technical assistance on all of our products or applications!

Call us at

800-530-8998 or email:

[email protected]

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Four HDMI Type A receptacle

HDMI Output

Audio Output

IR Input

RS232

EDID Selection

5v DC Power

Source/Auto Button

Firmware Port

One HDMI Type A receptacle

One 3.5mm TRS jack

One 3.5mm TRS jack

One 3.5mm TRS jack

Four position DIP switch

One 2.35mm outside diameter, 0.7mm

Inside diameter barrel (EIAJ-1)

One 3mm microswitch

One USB Type B receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Maximum Video

Compatibility

Deep Color 48/36/30/24 Bit at 1080p,

3D, and 2160p/30

Video Compatibility

HDMI, HDCP, CEC & ARC

Video Compliance

Embedded Audio

Analog Audio

Input DDC Signal

Input Video Signal

IR Carrier Frequency Range

RS232 Baud Rate

HDMI & HDCP (Selectable)

Up to PCM 8 channel, Dolby Digital

TrueHD & DTS-HD Master Audio

Analog stereo line-level

(converted to 2ch 24bit PCM 48kHz)

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

33-55kHz at 5 volts

9600

CHASSIS AND ENVIRONMENTAL

Enclosure

Black aluminum

Dimensions

(W x H x D)

Shipping Weight

193mm x 80mm x 11mm

(7.60 in × 3.15 in × 0.43 in)

0.82 kg (1.8 lbs.)

Operating Temperature

(Environment)

Operating Temperature (Chassis)

0° to +40°C (+32° to +104°F)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature (Environment)

-10° to +60°C (+14° to +140°F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

5 watts

100-240v AC at 50/60 Hz at 0.5 A

5v DC at 1 A

15kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

OTHER

Standard Warranty

2 years

Diagnostic Indicators

Power, audio mode, source mode, selected input

Included Accessories

Installation guide, power supply, AC adapters (AU, EU, UK, and US), IR receiver, rubber feet, mounting “L” brackets (4 ea), mounting screws (4 ea)

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

15

AUTO SWITCHERS AND EXTENDERS

DL-AS21C

HDMI + VGA AUTO-SWITCHER WITH CEC CONTROL

SUPPORTED AUDIO, VIDEO AND CONTROL

Supported Broadcast HDMI Input

Resolutions

480p: 59.94/60 Hz, 576p: 50 Hz, 720p:

25/29.97/30/50/59.94/60 Hz; 1080i: 50/59.94/60

Hz; 1080p: 23.98/24/25/29.97/30/50/59.94/

60 Hz; 4096x2160/3840x2160: 24/25/30 Hz;

4096x2160/3840x2160 (4:2:0): 50/60 Hz

Supported DVI-based HDMI Input

Resolutions (all at 60 Hz)

Supported VGA Input Resolutions

(all at 60 Hz)

Video Compliance

HDMI EDID

640x480, 720x576, 800x600, 1024x768,

1280x720, 1280x800, 1280x1024, 1360x768,

1366x768, 1440x900, 1400x1050, 1600x900,

1600x1200, 1680x1050, 1920x1080, 1920x1200

640x480, 720x576, 800x600, 1024x768,

1280x720, 1280x800, 1280x1024, 1360x768,

1366x768, 1440x900, 1400x1050, 1600x900,

1600x1200, 1680x1050, 1920x1080, 1920x1200

HDMI, HDCP

Pass-through from Display

The DigitaLinx

DL-AS21C

is a compact multi-format switcher with support for video resolutions up to UHD

(4096x2160). Featuring one HDMI input and one VGA input with stereo audio, the DL-AS21C automatically or manually switches either input to a single HDMI output.

The DL-AS21C features multiple methods of control. When set to AUTO, the switcher will automatically switch to the newest source device added to the DL-AS21C with

VGA taking precedence should multiple sources be live simultaneously. The DL-AS21C may be manually controlled by switching via the front panel, RS232, or contact closure.

As an added benefit, the DL-AS21C features a built-in CEC controller to power on/off the connected display by autoselecting the source device’s status.

key features

HDMI supports 1080p, 3D and 4K video and 2.0/5.1 audio

VGA supports up to 1920x1200 with audio embedding

Built-in EDID settings and EDID pass-through

HDMI output with CEC control of display

Manual, RS232, contact closure, &automatic switching

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

One (1) HDMI Type A Receptacle

VGA Input

One (1) Female HD15-F Connector

Analog Audio Input

HDMI Output

RS232

CEC On/Off Contact Closure

One (1) 3.5mm TRS Jack

One (1) HDMI Type A Receptacle

One (1) 3-Pole/3.5mm Euroblock

One (1) 3-Pole/3.5mm Euroblock

One (1) 5-Pole/3.5mm Euroblock

HDMI/VGA Select Contact

Closure with LED

Auto Mode Switch

CEC On/Off Switch

12V DC Power

Front Panel Control

One (1) Two-position Switch

One (1) Two-position Switch

One (1) Threaded Barrel

(5.5 mm OD; 2.6 mm ID)

Four (4) Pushbuttons

VGA EDID (set via RS232)

Analog Audio Output Impedance

1024x768, 1280x720, 1280x800, 1600x1200,

1920x1080 (default), 1920x1200

Embedded Audio Input/Output

PCM 2 channel; AAC 5.1

Analog Audio Frequency Response

20Hz-20KHz

Analog Audio Input Impedance

>10k ohm

50 ohm

Input DDC Signal

Input Video Signal

Maximum Passive HDMI Distance

RS232 Baud Rate

CEC

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

5 m (16 ft)

9600 baud

On and Off to display only

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted steel

Dimensions (H x W x D)

Shipping Weight

20 mm x 142 mm x 64 mm (0.78 in x 5.59 in x

2.52 in)

0.48 kg (1.06 lbs.)

Operating Temperature

(Environment)

0° to +40° C (+32° to +104° F)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature

(Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

3.8 watts

100-240v AC at 50/60 Hz at 0.45 A

5V DC at 3 A

15kV

RoHS

CE, RoHS, UL, TUV, FCC

OTHER

Standard Warranty

2 years

Diagnostic Indicators

Power, Selected Input

Included Accessories

Installation guide, power supply, AC adapter (US), three pole terminal blocks (2 ea), five pole terminal blocks ( 1 ea), mounting “L” brackets

(2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

16

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

DL-AS61

4 HDMI + 2 VGA INPUT AUTO-SWITCHER W/VGA SCALING

The DigitaLinx

DL-AS61

is a compact multi-format switcher with support for video resolutions up to UHD (3840x2160). With multiple built-in EDID settings, including an EDID pass-through option, the highest quality digital video signal will be routed directly to the display. When a VGA video signal is connected, the video signal will be scaled up to 1920x1200. The DL-AS61 supports stereo and multichannel audio on the HDMI inputs.

key features

HDMI supports 1080p, 3D and 4K video and 2.0/5.1 audio

VGA scaling up to 1920x1200 with audio embedding

Built-in EDID settings and EDID pass-through

HDMI output with analog and optical audio outputs

Manual, RS232, IR, and automatic switching

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Four (4) HDMI Type A Receptacle

VGA Inputs

Analog Audio Inputs

HDMI Output

Digital (Optical) Audio Output

Analog Audio Outputs

IR Input

Two (2) Female HD15-F Connector

Two (2) 3.5mm TRS Jack

One (1) HDMI Type A Receptacle

One (1) EIAJ Optical Connector

One (1) 3.5mm TRS Jack, One (1) 3-Pole/3.5mm

Euroblock

One (1) 3.5mm TRS Jack

RS232

5V DC Power

One (1) 3-Pole/3.5mm Euroblock

One (1) Threaded Barrel (5.5 mm OD; 2.6 mm ID)

Front Panel Control

Firmware

Four (4) Pushbuttons

One (1) USB Type A Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Supported Input Resolutions

(HDMI/DVI)

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

Supported Input Resolutions (VGA)

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

VGA Scaling Resolutions

Video Compliance

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

HDMI, HDCP

HDMI EDID

Pass-through from Display, 1080p/PCM 2ch,

1080p/PCM 6ch, 1080p3D/PCM 6ch, 1080i/PCM 2 ch, [email protected]/PCM 2ch

VGA EDID

Embedded Audio Input/Output

1360x768

Up to PCM 6 channel

Digital (Optical) Audio Output

PCM: 6 channel (5.1) at 16, 20, or 24 bit

Analog Audio Frequency Response

20Hz-20KHz

Analog Audio Input Impedance

>10k ohm

Analog Audio Output Impedance

Input DDC Signal

50 ohm

5.0 volts p-p (TTL)

Input Video Signal

0.5 to 1.0 volts p-p

Maximum Passive HDMI Distance

5 m (16 ft)

IR Carrier Frequency Range

RS232 Baud Rate

33-55kHz at 5 volts

9600 baud

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions (H x W x D)

Shipping Weight

28 mm x 350 mm x 110 mm (1.10 in x 13.78 in x

4.33 in)

0.82 kg (1.8 lbs.)

Operating Temperature (Environment)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature (Environment)

Storage Humidity (Environment)

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

3.8 watts

100-240v AC at 50/60 Hz at 0.45 A

5V DC at 3 A

15kV

CE, FCC, RoHS

CE, RoHS, UL, SGS, FCC

OTHER

Standard Warranty

Diagnostic Indicators

2 years

Power, Selected Input

Included Accessories

Installation guide, power supply, AC adapters (AU, EU, UK, and US), RS232 cable,

IR receiver, IR remote with batteries, rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

17

AUTO SWITCHERS AND EXTENDERS

DL-AS31-2H1V

3X1 AUTOSWITCHER - 2 HDMI AND 1 VGA INPUT

HDMI Video Signal Resolution

[email protected],[email protected]/25/30Hz,

[email protected]/25/30/50/60Hz,

[email protected]/60Hz, [email protected]/60Hz,

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

The

DL-AS31-2H1V

is a multiformat auto-switcher with two

HDMI inputs, one VGA with analog audio input, one HDMI output, and one balanced analog audio output. This autoswitcher supports HDMI video resolutions up to 4Kx2K at 30

Hz and multichannel audio and VGA video resolutions up to

1920x1200 at 60 Hz. In addition to passing EDID information from the display, there are multiple built-in EDID settings to simplify an installation. The DL-AS31-2H1V will de-embed the digital audio from the HDMI output signal, and output it via the balanced analog audio output port.

TECH SPECS

VGA Video Signal Resolution

HDMI Embedded Audio

[email protected]/25/30/50/60Hz,

[email protected]/60Hz, [email protected]/60Hz,

[email protected],[email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected],[email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

PCM/Dolby Digital/DTS/DTS-HD

External Audio Signal

Output Audio Signal

Input Video Signal

Stereo audio

Balanced analog audio, compatible with unbalanced analog audio

Output Audio Signal to Noise Ratio

SNR≥85dB

Output Audio Frequency Response

20 Hz to 20 kHz

Input DDC Signal

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

Maximum Passive Cable Length

RS232 Baud Rate

5 m (16 ft)

9600 baud

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Two (2) HDMI Type A Receptacle

VGA Input

One (1) HD-15 Female Receptacle

Audio Input

HDMI Output

Audio Output

Input Select Contact Closures

Manual CEC Contact Closures

RS232

DC 5V Power

One (1) 3.5mm TRS Jack

One (1) HDMI Type A Receptacle

One (1) 5-pin Removable Terminal Block

One (1) 5-pin Removable Terminal Block

One (1) 3-pin Removable Terminal Block

One (1) 3-pin Removable Terminal Block

One (1) 5.5 mm Outside Diameter, 2.1 mm Inside

Diameter Barrel

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions (H x W x D)

Shipping Weight

240 mm x 100mm x 30 mm (9.45 in x 3.94 in x

1.18 in)

0.85 kg (1.87 lbs.)

Operating Temperature (Environment)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature (Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

5 watts

100-240V AC at 50/60 Hz

DC5V at 3 A

Contact discharge: ±15kV; Air discharge: ±8kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

CEC Switch

Firmware

One (1) 3mm Microswitch

One (1) Micro-B Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Maximum Video Compatibility

Deep Color 48/36/30/24 Bit at 1080p and

2160p/30

Video Compliance

HDMI1.4, HDCP1.4, CEC (Consumer Electronics

Control)

OTHER

Standard Warranty

Diagnostic Indicators

2 years

Power, Source Mode, Selected Input.

Included Accessories

Installation guide, power supply with AC adapters (AU, EU, UK, and US), RS232 cable,

5-pin terminal blocks (2 ea), 3-pin terminal blocks (2 ea), rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

18

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

DL-AS31-2H1DP

3X1AUTO-SWITCH 2 HDMI AND 1 DISPLAYPORT INPUT

The

DL-AS31-2H1DP

two HDMI inputs, one DisplayPort with analog audio input, one HDMI output, and one balanced analog audio output.

This auto-switcher supports HDMI and DisplayPort video resolutions up to 4Kx2K at 30 Hz and multi-channel audio. In addition to passing EDID information from the display, there are multiple built-in EDID settings to simplify an installation.

The DL-AS31-2H1DP will de-embed the digital audio from the

HDMI output signal, and output it via the balanced analog audio output port.

When in auto-switch mode, the DL-AS31-2H1DP will switch to a signal input as soon as a new source is connected. When the active source is removed, the switcher will select the first source on the lowest numbered input. The DL-AS31-2H1DP may also be controlled via RS232 commands or by contact closures on the rear of the switcher.

TECH SPECS

is a multi-format auto-switcher with

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Two (2) HDMI Type A Receptacle

DisplayPort Input

Audio Input

HDMI Output

Audio Output

Input Select Contact Closures

Manual CEC Contact Closures

One (1) Full Size DisplayPort Female Receptacle

One (1) 3.5mm TRS Jack

One (1) HDMI Type A Receptacle

One (1) 5-pin Removable Terminal Block

One (1) 5-pin Removable Terminal Block

One (1) 3-pin Removable Terminal Block

RS232

DC 5V Power

CEC Switch

Firmware

One (1) 3-pin Removable Terminal Block

One (1) 5.5 mm Outside Diameter, 2.1 mm Inside

Diameter Barrel

One (1) 3mm Microswitch

One (1) Micro-B Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Maximum Video Compatibility

Deep Color 48/36/30/24 Bit at 1080p and

2160p/30

Video Compliance

HDMI1.4, HDCP1.4, CEC (Consumer Electronics

Control)

HDMI and DisplayPort Video Signal

Resolution

HDMI Embedded Audio

[email protected],[email protected]/25/30Hz,

[email protected]/25/30/50/60Hz,

[email protected]/60Hz, [email protected]/60Hz,

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

PCM/Dolby Digital/DTS/DTS-HD

External Audio Signal

Stereo audio

Output Audio Signal

Balanced analog audio, compatible with unbalanced analog audio.

Output Audio Signal to Noise Ratio

SNR≥85dB

Output Audio Frequency Response

20 Hz to 20 kHz

Input DDC Signal

5.0 volts p-p (TTL)

Input Video Signal

Maximum Passive Cable Length

RS232 Baud Rate

0.5 to 1.0 volts p-p

5 m (16 ft)

9600 baud

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions (W x H x D)

Shipping Weight

240 mm x 100mm x 30 mm (9.45 in x 3.94 in x

1.18 in)

0.85 kg (1.87 lbs.)

Operating Temperature (Environment)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature (Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

5 watts

100-240V AC at 50/60 Hz

DC5V at 3 A

Contact discharge: ±15kV; Air discharge: ±8kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

OTHER

Standard Warranty

2 years

Diagnostic Indicators

Power, Source Mode, Selected Input.

Included Accessories

Installation guide, power supply with AC adapters (AU, EU, UK, and US), RS232 cable,

5-pin terminal blocks (2 ea), 3-pin terminal blocks (2 ea), rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

19

AUTO SWITCHERS AND EXTENDERS

DL-AS31-1H1DP1V

3X1 AUTOSWITCHER - UNDER-TABLE. [1] HDMI, [1] DP, AND [1] VGA

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

DisplayPort Input

VGA Input

One (1) Full Size DisplayPort Female Receptacle

One (1) HD-15 Female Receptacle

Audio Input

HDMI Output

Audio Output

Input Select Contact Closures

Manual CEC Contact Closures

RS232

DC 5V Power

CEC Switch

Two (2) 3.5mm TRS Jack

One (1) HDMI Type A Receptacle

One (1) 5-pin Removable Terminal Block

One (1) 5-pin Removable Terminal Block

One (1) 3-pin Removable Terminal Block

One (1) 3-pin Removable Terminal Block

One (1) 5.5 mm Outside Diameter, 2.1 mm

Inside Diameter Barrel

One (1) 3mm Microswitch

Firmware

One (1) Micro-B Receptacle

SUPPORTED AUDIO AND VIDEO

Maximum Video Compatibility

Deep Color 48/36/30/24 Bit at 1080p and

2160p/30

Video Compliance

HDMI and DisplayPort Video

Signal Resolution

HDMI1.4, HDCP1.4, CEC (Consumer

Electronics Control)

[email protected],[email protected]/25/30Hz,

[email protected]/25/30/50/60Hz,

[email protected]/60Hz, [email protected]/60Hz,

[email protected], [email protected],

[email protected], [email protected],

1680x[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected]

VGA Video Signal Resolution

[email protected]/25/30/50/60Hz,

[email protected]/60Hz,

[email protected]/60Hz, [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected], [email protected],

[email protected]

HDMI Embedded Audio

External Audio Signal

PCM/Dolby Digital/DTS/DTS-HD

Stereo audio

The

DL-AS31-1H1DP1V

is a multiformat auto-switcher with one

HDMI input, one DisplayPort with analog audio input, one VGA with analog audio input, one HDMI output, and one balanced analog audio output. This auto-switcher supports HDMI and DisplayPort video resolutions up to 4Kx2K at 30 Hz and multichannel audio and VGA video resolutions up to 1920x1200 at 60 Hz. In addition to passing EDID information from the display, there are multiple built-in

EDID settings to simplify an installation.

key features

1 HDMI, 1 DisplayPort, & 1 VGA input

1 HDMI and stereo audio output

Built-in audio de-embedding

Automatic and manual switching via RS232 and contact closure

Includes under table mounting ears

Output Audio Signal

Balanced analog audio, compatible with unbalanced analog audio

Output Audio Signal to Noise Ratio

SNR≥85dB

Output Audio Frequency Response

20 Hz to 20 kHz

Input DDC Signal

Input Video Signal

Maximum Passive Cable Length

RS232 Baud Rate

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

5 m (16 ft)

9600 baud

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted aluminum

Dimensions (W x H x D)

Shipping Weight

240 mm x 100mm x 30 mm (9.45 in x 3.94 in x

1.18 in)

0.85 kg (1.87 lbs.)

0° to +40° C (+32° to +104° F)

Operating Temperature

(Environment)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity (Environment)

20% to 90%, Non-condensing

Storage Temperature

(Environment)

Storage Humidity (Environment)

POWER AND REGULATORY

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

OTHER

Standard Warranty

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

5 watts

100-240V AC at 50/60 Hz

DC5V at 3 A

Contact discharge: ±15kV; Air discharge: ±8kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

2 years

Diagnostic Indicators

Power, Source Mode, Selected Input

Included Accessories

Installation guide, power supply with AC adapters (AU, EU, UK, and US), RS232 cable, 5-pin terminal blocks (2 ea), 3-pin terminal blocks (2 ea), rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

20

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

AS-2H / AS-2H-WP-W / AS-2H-WP-B

AS-2H

The Intelix

AS-2H

and

AS-2H-WP

are under table or wall mounted auto switchers designed to be the primary

PC interface for classrooms, boardrooms & conference centers. They both feature dual HDMI inputs and utilize

HDBaseT technology to extend the digital output up to

70 meters away using solid core shielded Category 5e or greater cable. These transmitter devices are compatible with several Intelix HDBaseT receivers, but are designed to work primarily with the DIGI-HD60C-R. Units feature multiple EDID modes to eliminate user confusion, and incompatible video formats. An HDMI output is available for use to connect to a local display.

key features

Two HDMI inputs

HDMI and HDBaseT output—60m Max Distance

Automatically switches input to active video

RS232, Auto, and Dry Contact Closure for control of device

PoE (Power over Ethernet) or 12V DC local power

Display Control Software to control TV or projector with RS232 commands— automatically turns display on / off

Customizable power management system when not in use

AS-2H-WP-W

AS-2H-WP-B

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

Two HDMI Type A receptacle

HDBaseT Port

HDMI Output

Power

RS232 Port

Contact Closures

Firmware Port

One

8P8C port (shielded RJ45)

One HDMI Type A receptacle

One 5.5 mm OD, 2.6mm ID barrel

One 3-pin removable terminal block connector

One 4-pin removable terminal block connector

One USB Type B Micro receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p,

720p, 1080i, 1080p

VESA: Resolutions up to

1920 × 1200

Maximum Video

Compatibility at 60m

Deep Color 36/30/24 Bit at 1080p

Maximum Video

Compatibility at 40m

Video Compliance

Deep Color 48 Bit at 1080p,

3D (HDMI Input)

HDMI & HDCP (selectable)

Embedded Audio

Analog Audio

ARC (Audio

Return Channel)

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

Baud Rate

(Wall plate control)

Supported Baud Rates

(Display Control)

Up to PCM 8 channel, Dolby Digital

TrueHD & DTS-HD master audio

Analog stereo line-level

(converted to 2ch 24bit PCM

48kHz)

No

No

Yes

9600

9600, 19200, 57600, 115200

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

60m

Cable Requirements

Bandwidth

Solid core shielded Category 5e,

Category 6 or greater with 568B pin out

10.2 Gbps

Gain

Signal to Noise

Ratio (SNR)

Return Loss

0 dB – 10 dB at 100 MHz

> 70 dB at 100 MHz over 100m

Total Harmonic

Distortion (THD)

< -30 dB at 5 KHz

< 0.005% at 1 KHz

Min-Max Signal Level

< 0.3 V – 1.45 Vp-p

Differential Phase Error

±10° at 135 MHz over 100m

CHASSIS AND ENVIRONMENTAL

Construction

Black aluminum

Dimensions

(H x W x D)

Shipping Weight

30mm × 172mm × 84mm

(1.18 in × 6.77 in × 3.31 in)

0.68 kg (11.5 lbs.)

Operating Temperature

0° to +40°C (+32° to +104°F)

Operating Humidity

20% to 90%, Non-condensing

Storage Temperature

-10° to +60°C (+14° to +140°F)

Storage Humidity

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Supply

12V DC 1A or PoE

Power Consumption

Default Automatic

Standby Mode

ESD Protection

10 watts

30 minutes no signal

16kV

Regulatory

CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

HDCP, Link, HDMI 1, HDMI 2

& power

Included Accessories

Installation guide, power supply, mounting brackets with screws, 4-pin removable screw terminal, 3-pin removable screw terminal, RS232 cable (3-pin to de9), rubber feet

HDBaseT Receiver

(A/V, PoE, Control)

Compatibility

HDBaseT Receiver (A/V,

Control) Compatibility

HDBaseT Receiver (A/V

& PoE) Compatibility

DIGI-HD60C-R, DIGI-HDX-R,

FLX-64

FLX-BI4

DIGI-HD60-R

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

Need Help?

We offer technical assistance on all of our products or applications!

Call us at

800-530-8998 or email:

[email protected]

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

21

22

AUTO SWITCHERS AND EXTENDERS

AS-1H1V / AS-1H1V-WP-W / AS-1H1V-WP-B

AS-1H1V

The Intelix

AS-1H1V

and

AS-1H1V-WP

are under-table or wall mounted auto switchers designed to be the primary PC interface for classrooms, boardrooms & conference centers.

They both feature VGA + Audio to HDMI conversion with

VGA scaling up to 1920x1200 and an HDMI input, and utilize

HDBaseT technology to extend the digital output up to 70 meters away using solid core shielded Category 5e or greater cable. These transmitter devices are compatible with several

Intelix HDBaseT receivers, but are designed to work primarily with the DIGI-HD60C-R. Units feature multiple EDID modes to eliminate user confusion, and incompatible video formats. An

HDMI output is available for use to connect to a local display.

AS-1H1V-WP-W AS-1H1V-WP-B key features

HDMI (including audio) and VGA/3.5mm Stereo input

HDMI and HDBaseT output - 70m Max Distance

Automatically switches input to active video

VGA scaling up to 1920x1200

RS232, Auto, and Dry Contact Closure for control of device

PoH (Power over HDBaseT) or 24V DC local power

Display Control Software to control TV or projector with RS232 commands - automatically turns display on/off

Customizable power management system when not in use

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

One HDMI Type A receptacle

VGA Input

Analog Audio Inputs

HDBaseT Port

HDMI Output

Power

RS232 Port

Contact Closures

Firmware Port

One HD15-F receptacle

One 3.5mm TRS receptacle

One

8P8C port (shielded RJ45)

One HDMI Type A receptacle

One 5.5 mm OD, 2.6mm ID barrel

One 3-pin removable terminal block connector

One 4-pin removable terminal block connector

One USB Type B Micro receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p,

720p, 1080i, 1080p

VESA: Resolutions up to

1920x1200

HDMI Color Depth: 24, 30,

36, 48bit

Maximum Video

Compatibility at 60m

Deep Color 36/30/24 Bit at

1080p

Maximum Video

Compatibility at 40m

Video Compliance

Deep Color 48 Bit at 1080p,

3D (HDMI Input)

HDMI & HDCP (Selectable

Embedded Audio

Analog Audio

Up to PCM 8 channel, Dolby

Digital TrueHD & DTS-HD

Master Audio

Analog stereo line-level

(Converted to 2ch 24bit PCM

48kHz)

No

ARC (Audio

Return Channel)

HEC (HDMI

Ethernet Channel)

No

CEC (Consumer

Electronics Control)

Baud Rate

(Wall plate control)

Supported Baud Rates

(Display Control)

Yes (HDMI Pass-through Only)

9600

9600, 19200, 57600, 115200

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

60m

Cable Requirements

Bandwidth

Solid core shielded Cat 5e, Cat 6 or greater with 568B pin out

10.2 Gbps

Gain

Signal to Noise

Ratio (SNR)

Return Loss

Total Harmonic

Distortion (THD)

Min-Max Signal Level

0 dB – 10 dB at 100 MHz

> 70 dB at 100 MHz over 100m

< -30 dB at 5 KHz

< 0.005% at 1 KHz

< 0.3 V – 1.45 Vp-p

Differential Phase Error

±10° at 135 MHz over 100m

CHASSIS AND ENVIRONMENTAL

Construction

Black aluminum

Dimensions (H x W x D)

30mm × 172mm × 84mm

(1.18 in × 6.77 in × 3.31 in)

Shipping Weight

0.68 kg (11.5 lbs.)

Operating Temperature

0° to +40°C (+32° to +104°F)

Operating Humidity

Storage Temperature

Storage Humidity

20% to 90%, Non-condensing

-10° to +60°C (+14° to +140°F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Supply

12V DC 1A or PoE

(Power-Over-Ethernet)

Power Consumption

10 watts

Default Automatic

Standby Mode

ESD Protection

Regulatory

30 minutes no signal

16kV

CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

HDBaseT Receiver (A/V and PoE) Compatibility

HDCP, Link, VGA,

HDMI & Power

Included Accessories

Installation guide, power supply, mounting brackets with screws, 4-pin removable screw terminal, 3-pin removable screw terminal, rs232 cable (3-pin to de9), rubber feet

HDBaseT Receiver

(A/V, PoE, Control)

Compatibility

DIGI-HD60C-R, DIGI-HDX-R,

FLX-64

HDBaseT Receiver (A/V,

Control) Compatibility

FLX-BI4

DIGI-HD60-R

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. Intelix specifications are based on straight-through cabling with standard-grade Category 6 rating unless noted otherwise.

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

AS-1H1DP / AS-1H1DP-WP-W / AS-1H1DP-WP-B

AS-1H1DP

AS-1H1DP-B-WP AS-1H1DP-WP-B

The Intelix

AS-1H1DP

and

AS-1H1DP-WP

are under-table or wall mounted auto switchers designed to be the primary PC interface for classrooms, boardrooms & conference centers.

They both feature DisplayPort + Audio to HDMI conversion and an HDMI input. If the DisplayPort signal does not support embedded audio, the analog audio input port can be accessed via RS232. They utilize HDBaseT technology to extend the digital output up to 70 meters away using solid core shielded

Category 5e or greater cable. These transmitter devices are compatible with several Intelix HDBaseT receivers, but are designed to work primarily with the DIGI-HD60C-R. Units feature multiple EDID modes to eliminate user confusion, and incompatible video formats. An HDMI output is available for use to connect to a local display.

key features

HDMI and DisplayPort w/ 3.5mm Stereo input

HDMI and HDBaseT output - 70m Max Distance

Automatically switches input to active video

RS232, Auto, and Dry Contact Closure for control of device

PoH (Power over HDBaseT) or 24V DC local power

Display Control Software to control TV or projector with RS232 commands - automatically turns display on/off

Customizable power management system when not in use

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Inputs

One HDMI Type A receptacle

DisplayPort Input

Analog Audio Inputs

One

DisplayPort receptacle

One 3.5mm TRS receptacle

HDBaseT Port

HDMI Output

Power

RS232 Port

Contact Closures

Firmware Port

One 8P8C port (shielded RJ45)

One HDMI Type A receptacle

One 5.5 mm OD, 2.6mm ID barrel

One 3-pin removable terminal block connector

One 4-pin removable terminal block connector

One USB Type B Micro receptacle

CEC (Consumer

Electronics Control)

Baud Rate

(Wall plate control)

Supported Baud Rates

(Display Control)

Yes (HDMI Pass-through Only)

9600

9600, 19200, 57600, 115200

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

60m

Cable Requirements

Bandwidth

Gain

Solid core shielded Cat 5e, Cat 6 or greater with 568B pin out

10.2 Gbps

0 dB – 10 dB at 100 MHz

Signal to Noise

Ratio (SNR)

Return Loss

Total Harmonic

Distortion (THD)

Min-Max Signal Level

> 70 dB at 100 MHz over 100m

< -30 dB at 5 KHz

< 0.005% at 1 KHz

< 0.3 V – 1.45 Vp-p

Differential Phase Error

±10° at 135 MHz over 100m

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

Maximum Video

Compatibility at 40m

SMPTE: 480i, 480p, 576i, 576p,

720p, 1080i, 1080p

VESA: Resolutions up to

1920

× 1200

Deep Color 36/30/24 Bit at

1080p

Maximum Video

Compatibility at 60m

Deep Color 48 Bit at 1080p,

3D (HDMI Input)

Video Compliance

HDMI & HDCP (Selectable

Embedded Audio

Analog Audio

Up to PCM 8 channel, Dolby

Digital TrueHD & DTS-HD

Master Audio

Analog stereo line-level

(Converted to 2ch 24bit PCM

48kHz)

ARC (Audio Return Channel)

No

HEC (HDMI

Ethernet Channel)

No

CHASSIS AND ENVIRONMENTAL

Construction

Black aluminum

Dimensions (H x W x D)

30mm × 172mm × 84mm

(1.18 in × 6.77 in × 3.31 in)

Shipping Weight

0.68 kg (11.5 lbs.)

Operating Temperature

0° to +40°C (+32° to +104°F)

Operating Humidity

Storage Temperature

Storage Humidity

20% to 90%, non-condensing

-10° to +60°C (+14° to +140°F)

20% to 90%, non-condensing

POWER AND REGULATORY

Power Supply

12V DC 1A or PoE

Power Consumption

Default Automatic

Standby Mode

ESD Protection

Regulatory

10 watts

30 minutes no signal

16kV

CE, RoHS

OTHER

Warranty

Diagnostic Indicators

HDCP, Link, DisplayPort (DP),

HDMI & Power

Included Accessories

Installation guide, power supply, mounting brackets with screws, 4-pin removable screw terminal, 3-pin removable screw terminal, rs232 cable (3-pin to de9), rubber feet

HDBaseT Receiver

(A/V, PoE, Control)

Compatibility

HDBaseT Receiver (A/V,

Control) Compatibility

HDBaseT Receiver (A/V and PoE) Compatibility

2 years

DIGI-HD60C-R, DIGI-HDX-R,

FLX-64

FLX-BI4

DIGI-HD60-R

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. Intelix specifications are based on straight-through cabling with standard-grade Category 6 rating unless noted otherwise.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

23

AUTO SWITCHERS AND EXTENDERS

AV DISTRIBUTION SYSTEM FOR CLASSROOMS

Complete classroom solution with integrated audio and video in the same compact design. Single cable connectivity for a much easier and faster installation. The system includes a compact audio/video processor, dual HDMI wall plate with USB extension, and a control plate for source and volume control. Part# EDU-KIT-001

TPHD541R-PA

Audio

TPHD541T-WP

WP4N

USB

HDMI

HDMI

24

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUTO SWITCHERS AND EXTENDERS

DIGITALINX EDU-KIT-001

Multi-Function AV Distribution System

WP4N TPHD541T-WP

Easy to Use Web Control Interface

TPHD541R-PA

INCLUDED IN PACKAGE:

• Qty 1: TPHD541T-WP

HDMI HDBaseT auto or manual switching wall plate

• Qty 1: TPHD541R-PA

AV receiver/processor with HDBaseT

• Qty 1: WP4N

Manual control wall plate

PACKAGE FEATURES AND BENEFITS:

Double-gang wall plate with 2 HDMI inputs, USB-B connection, & source selection button. Signal extended via HDBaseT 2.0

Auto-sensing/switching or manual switching of HDMI inputs. Extend HDMI

& USB 2.0 for Smart Board control (or any other peripheral device) all over a single Cat6 cable up to 30 meters

Single-gang control plate offers HDMI source selection, audio source selection, audio volume control, and system power on or off, as well as IR sensor for

IR learning. USB-A port provided to copy your configuration for easy mass deployment

Single Cat6 connection from Control plate to AV plate, and from AV plate to receiver/processor. Control and AV plate remotely powered via PoC

Save IR or RS232 display power commands. Single button press to power on/ off entire system

Web base user GUI allows user to fully control system from PC or tablet

20 watt 4 ohm integrated audio amplifier as well as mic/line level audio input

Alarm/PA mute trigger

Package with appropriate length wire & cable, speakers, power products, and any other Liberty provided products to create a complete kit with a single part number

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

OPTIONAL ADDITIONS

TO THIS ROOM

1) If VGA with audio is needed, add the DL-VHD to convert

VGA w/audio to HDMI at the teacher station and use one of the HDMI inputs

2) Niveo wireless access point

NWA100 ceiling mount or

NWA200 in-wall solution

3) Length of cables to be determined and can be included with the package

4) Surge protection from Niveo

5) Atlas Sound Speakers

25

HDBASET EXTENDERS

DIGI-HD60-WP-S

60M HDMI WALL PLATE HDBASET TRANSMITTER

VALUE-ENGINEERED DIGITAL SOLUTIONS

The Intelix

DIGI-HD60-WP-S

extends HDMI over a single twisted pair cable by incorporating HDBaseT technology.

The DIGI-HD60-WP-S supports HDCP Encrypted

Content & DDC/EDID Transmission. DIGI-HD60-WP-S transmits Ultra HD (4K2K), HDTV Video Resolutions up to

720p/1080i/[email protected] and WUXGA (1920X1200 @60Hz) at distances of 60m (196ft). Diagnostic LED ensure hassle-free and robust installations. The DIGI-HD60 series extenders are compatible with all Intelix HDBaseT product offerings and any product that meets the HDBaseT specifications.

Need Help?

We offer technical assistance on all of our products or applications!

Call us at

800-530-8998 or email:

[email protected]

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

One (1) HDMI Type A Receptacle

Twisted Pair

One (1) 8P8C port (Shielded RJ45)

SUPPORTED AUDIO AND VIDEO

Maximum Video

Compatibility at 60 m

Deep Color 36/30/24 Bit at 1080p

Maximum Video

Compatibility at 35 m

Deep Color 48 Bit at 1080p, 3D, and 4k x 2k (UHD) up to 30 Hz: RGB, YCbCr 4:4:4, YCbCr 4:2:2; up to 60

Hz: YCbCr 4:2:0

Video Compliance

Embedded Audio

HDMI, HDCP 2.2, and CEC (Consumer Electronics

Control)

Up to PCM 8 channel, Dolby Digital TrueHD, and

DTS-HD Master Audio

HDBaseT SIGNAL CHARACTERISTICS

Maximum Distance

60 m

Cable Requirements

Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern

Bandwidth

10.2 Gbps

CHASSIS & ENVIRONMENTAL

Enclosure

Painted steel

Dimensions

45.72mm x 20.82mm x 104.14mm (1.80 in. x 0.82 in. x 4.10 in.)

Shipping Weight

Operating Temperature

(Environment)

0.22 kg (0.49 lbs.)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

0° to +55° C (+32° to +131° F)

Operating Humidity

(Environment)

20% to 90%, Non-condensing

Storage Temperature

(Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Maximum Power Consumption

24VDC @ 0.5 Amps (Max.)

ESD Protection

Regulatory

15kV

CE, RoHS, FCC

OTHER

Standard Warranty

Diagnostic Indicators

Included Items

Installation Guide

2 years

Link LED

26

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

HDBASET EXTENDERS

INT-HDX100-TX / INT-HDX100-RX

INT-HDXL100-TX / INT-HDXL100-RX

100M AND 150M HDMI, IR, RS232 AND ETHERNET HDBASET EXTENDERS

INT-HDX100-TX INT-HDX100-RX

The Intelix

INT-HDX100

and

INT-HDXL100

transmitters

(TX) and receivers (RX) extend HDMI over a single solid core shielded Category 5e or greater cable using the

Valens VS100TX HDBaseT chip, support 1080p, full 3D or 4k x 2k video signals including multichannel audio and HDCP 1.4/2.2. INT-HDX100 models support signal up to 100 meters (323 feet) and the HDXL100 models support signal up to 150 meters (492 feet). Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations.

INT-HDXL100-TX INT-HDXL100-RX

Key features of the new extender series include power over HDBaseT (PoH), bidirectional IR, bidirectional

RS232, and Ethernet pass-through with a 2-port network switch.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

HDBaseT Port

Ethernet

One (1) 8P8C port (Shielded RJ45)

Two (2) 8P8C port (Shielded RJ45)

Power

RS232 Port

IR Input

IR Output

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

One (1) 3-pin Removable Terminal Block Connector

One (1) 3.5 mm TRS Receptacle

One (1) 3.5 mm TRS Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p,

UHD/30 VESA: Resolutions up to 1920x1200

Color Depth: 24, 30, 36, 48bit

Deep Color 48/36/30/24 Bit at 1080p, 3D, UHD/30

Maximum Video

Compatibility at 100 m

Video Compliance

Embedded Audio

HDMI 1.4 and HDCP 1.4/2.2

Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio

ARC (Audio Return Channel) No

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

Supported Baud Rates

Supported IR Carrier

Frequencies

Ethernet

No

Yes (Pass-through Only)

2400, 4800, 9600, 19200, 38400, 57600, 115200

33 to 55 kHz

100BaseT

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

100 m (328 ft)

Cable Requirements

Continuous solid core Category 5e or greater with

TIA/EIA-568B crimp pattern (no couplers in-line)

Bandwidth

10.2 Gbps

HDBaseT Chipset

VS100TX

CHASSIS AND ENVIRONMENTAL

Construction

Black Alumininum

Dimensions (H x W x D)

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

16.2 mm x 152 mm x 84 mm (0.64 in x 5.98 in x 3.31 in)

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

24V DC 1.25A or 48V DC PoH (Power over HDBaseT)

Power Output

48V DC PoH (Power over HDBaseT)

Power over Ethernet (PoE)

Compatibility

802.3af Alternative A

Power Consumption

ESD Protection

Regulatory

5 watts

15kV air, 8kV contact

FCC, CE, RoHS

OTHER

Warranty

Diagnostic Indicators

2 years

HDCP, Link, and Power

HDBaseT Receiver (A/V, PoE,

Control) Compatibility

DIGI-HD60C-R, DIGI-HDX-R, FLX-64, INT-HD70-RX,

INT-HDX100-RX, DIGI-BSR-4K

HDBaseT Receiver (A/V,

Control) Compatibility

HDBaseT Receiver (A/V and

PoE) Compatibility

FLX-BI4

DIGI-HD60-R

Included Accessories

Installation Guide, Power Supply, 3-pin Removable Screw Terminal. Optional

Accessories: IR emitter (DIGIB-EMT), IR receiver (DIGIB-EYE), rack mount (RACK12-EXT), rack mounted power supply (PSU12)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. Intelix specifications are based on straight-through cabling with standard-grade Category 6 rating unless noted otherwise.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

27

HDBASET EXTENDERS

INT-HD70-TX / INT-HD70-RX

70M HDMI, IR AND RS232 HDBASET EXTENDER

INT-HD70-TX INT-HD70-RX

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

HDBaseT Port

Power

One (1) 8P8C port (Shielded RJ45)

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

RS232 Port

IR Input

IR Output

One (1) 3-pin Removable Terminal Block Connector

One (1) 3.5 mm TRS Receptacle

One (1) 3.5 mm TRS Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p,

UHD/30 VESA: Resolutions up to 1920x1200

Color Depth: 24, 30, 36, 48bit

Maximum Video

Compatibility at 70 m

Deep Color 36/30/24 Bit at 1080p

Maximum Video

Compatibility at 40 m

Video Compliance

Deep Color 48 Bit at 1080p, 3D (HDMI Input),

UHD/30

HDMI 1.4 and HDCP 1.4/2.2

Embedded Audio

Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio

ARC (Audio Return Channel) No

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

Supported Baud Rates

Supported IR Carrier

Frequencies

No

Yes (Pass-through Only)

2400, 4800, 9600, 19200, 38400, 57600, 115200

33 to 55 kHz

HDBaseT SIGNAL CHARACTERISTICS

Maximum Distance

70 m (229 ft)

Cable Requirements

Bandwidth

Continuous solid core Category 5e or greater with

TIA/EIA-568B crimp pattern (no couplers in-line)

10.2 Gbps

HDBaseT Chipset

VS010TX

The Intelix

INT-HD70-TX

(Transmitter) and

INT-HD70-RX

(Receiver) extend HDMI, IR, and

RS232 over a single solid core shielded Category

5e or greater cable using the Valens VS010TX

HDBaseT chip. The HD70 series extenders supports a 1080p video signal, including HDCP

2.2 and multichannel audio, up to 70m, as well as 3D and 4K x 2K (UHD) signals up to 40m.

Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations.

Flexible power design allows the units to be powered at either the TX or RX end, and only one power supply is required. The power supply is included; IR accessories (DIGIB-EMT and

DIGIB-EYE) are sold separately. The INT-HD70 series extenders are compatible with all Intelix

HDBaseT product offerings and any product that meets the HDBaseT specifications.

CHASSIS AND ENVIRONMENTAL

Construction

Black Alumininum

Dimensions (H x W x D)

16.2 mm x 115 mm x 84 mm (0.64 in x 4.73 in x 3.31 in)

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

24V DC 1.25A or 48V DC PoH (Power over HDBaseT)

Power Output

48V DC PoH (Power over HDBaseT)

Power over Ethernet (PoE)

Compatibility

802.3af Alternative A

Power Consumption

ESD Protection

Regulatory

5 watts

15kV air, 8kV contact

FCC, CE, RoHS

OTHER

Warranty

Diagnostic Indicators

2 years

HDCP, Link, and Power

HDBaseT Receiver (A/V, PoE,

Control) Compatibility

Installation Guide, Power Supply, 3-pin

Removable Screw Terminal

HDBaseT Receiver (A/V,

Control) Compatibility

HDBaseT Receiver (A/V and

PoE) Compatibility

FLX-BI4

DIGI-HD60-R

Included Accessories

Installation Guide, Power Supply, 3-pin Removable Screw Terminal. Optional Accessories

IR emitter (DIGIB-EMT), IR receiver (DIGIB-EYE), rack mount (RACK12-EXT), rack mounted power supply (PSU12)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

28

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

EXTENDER ACCESSORIES

RACK12 EXT

12 SLOT HDBASET EXTENDER RACK MOUNT KIT

The Intelix

RACK12-EXT

is a rack mounting kit for the INT-HD70,

INT-HDX100, and INT-HDXL100 series extenders. Measuring

5 rack units (5RU) high, the RACK12-EXT can hold up to 12 extenders. Two sizes of support brackets are included with the kit and allow installing the INT-HD70 series extenders next to

INT-HDX100 or INT-HDXL100 extenders. 11 panel blanks are included to finalize the clean, professional appearance of the installation.

TECH SPECS

CHASSIS

Construction

Dimensions (H x W x D)

Black Steel

220 mm x 480 mm x 170 mm

(8.66 in x 18.90 in x 6.69 in)

OTHER

Warranty

HDBaseT Extender

Compatibility

2 years

INT-HD70-RX, INT-HD70-TX, INT-HDX100-RX,

INT-HDX100-TX, INT-HDXL100-RX, INT-HDXL100-TX

PSU12

12 OUTPUT DC POWER SUPPLY UNIT

The Intelix

PSU12

is a rack mounted DC power supply unit with support for up to 12 devices. Output voltages available are 5V, 12V, and 24V DC. Each output can provide up to 15 watts of power. Front panel buttons can turn on or turn off individual outputs. The PSU12 also features RS232 and TCP/IP control, plus a web GUI for device control and configuration. The output voltages are set via RS232, TCP/IP or through the web GUI.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Power Output

Twelve (12) 2-pin Removable Terminal Block Connector

Power Input

One (1) IEC C14

RS232 Port

TCP/IP Port

One (1) 3-pin Removable Terminal Block Connector

One (1) 8P8C port (Shielded RJ45)

CHASSIS AND ENVIRONMENTAL

Construction

Black Steel

Dimensions (H x W x D)

43 mm x 480 mm x 275 mm (1.69 in x 18.90 in x 10.83 in)

Operating Temperature

0° to +40° C (+32° to +104° F)

Operating Humidity

Storage Temperature

Storage Humidity

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

100V-240VAC / 50-60 Hz

Power Output

Power Consumption

ESD Protection

Regulatory

5V DC, 12V DC, or 24V DC at 15 watts maximum

194 watts

15kV air, 8kV contact

FCC, CE, RoHS

OTHER

Warranty

2 years

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

29

HDBASET EXTENDERS

DL-HD60-ARC

HDBASET EXTENDER SET WITH AUDIO RETURN CHANNEL

The DigitaLinx

DL-HD60-ARC

HDBaseT extender set transmits HDMI (1080p and UHD/30) including HDCP 1.4,

Bi-directional IR control and High Bandwidth of 10.2Gps up to 70 meters away using a single Category 6 twisted pair cable. Built-in diagnostic LEDs ensure hassle-free and robust installations. The DL-HD60-ARC supports ARC providing a solution where users have flexibility to enable audio upstreaming from display to speakers.The 12V PoC integrated design allows the units to be powered at the

TX or RX, and only one power supply is required. The 12 volt power supply is secured with a screw-on connector to prevent the power from being accidentally disconnected.

30

LIBERTY INVENTORY SERVICES

It's like having a bigger workforce for free!

WHAT'S THE BENEFIT?

Reduced Procurement Costs & Increased Revenue

Easy Scan & Checkout

Pay only when you consume the materials.

No start-up costs or maintenance fees.

Possible Savings: Tens of thousands of dollars

THE PROGRAM

Pay only when you consume the materials

On-site consigned inventory management program for day-to-day install materials. Inventory is on-site, not "virtual" with an unknown vendor warehouse.

Dedicated LIS Service Coordinator & redundant back-up.

Live webinar demonstration available.

Open to the entire catalog of Liberty's products including custom cable, install kits, assemblies, connectors, racks, devices, fiber & more!

Initial launch package includes estimated two months supply.

Automated monthly replenishment of inventory with FREE surface freight. (Racks excluded)

Liberty provides on-site training synchronized with initial delivery.

JOIN THE CROWD!

The best companies in the Pro A/V industry use

LISyou should too!

TECH SPECS

SUPPORTED AUDIO AND VIDEO

Maximum Video

Compatibility

70m: 1080p/60 & 40m: 4k x 2k @30Hz (4:2:0)

Resolution Range

Video Compliance

[email protected] - [email protected]

HDMI 1.4, HDCP 1.4

Control Method

Bi-directional IR

HDBaseT SIGNAL CHARACTERISTICS

Transmission Distance

CAT 5e/6: 1080p: Max 70m; 3840x2160: Max 40m

Cable Requirements

Bandwidth

Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern

10.2 Gbps

CHASSIS AND ENVIRONMENTAL

Dimensions

84mm x 16.2mm x 115mm (3.31 in. x 0.64 in. x 4.53 in.)

Operating Temperature

0° to +50° C (+32° to +122° F)

Storage Temperature

Operating Humidity

(Environment)

-20° to +70° C (-4° to +158° F)

10 % to 90%, Non-condensing

POWER

Power Supply

Input Voltage

Power Supply

Output Rating

Regulatory

100-240V AC at 50-60 Hz

DC12V - 1A

CE, UL, FCC

OTHER

Standard Warranty

2 years

Included Items

Installation Guide, Power Supply, (4) Mounting Brackets with Screws, (8) Rubber

Feet

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

HDBASET EXTENDERS

DIGI-BSR-4K

100 M HDBASET SCALING RECEIVER WITH HDMI, IR, RS232 AND ETHERNET

The Intelix

DIGI-BSR-4K

extends HDMI over a single solid core shielded Category 5e or greater cable using the Valens VS100RX

HDBaseT chip and scales the source content up or down to the native resolution of the connected display. The DIGI-BSR-4K supports 1080p, full 3D or 4k x 2k video signals up to 100 meters

(328 feet) including multichannel audio and HDCP 1.4. Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations. Additional connections include bidirectional

IR, bidirectional RS232, and Ethernet pass-through with a 2-port network switch.

The DIGI-BSR-4K requires local power, but it can provide power to a compatible HDBaseT transmitter. The power supply is included with the extender. The bidirectional wideband IR, bidirectional RS232, and Ethernet pass-through capabilities make the DIGI-BSR-4K compatible with most control systems.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Output

One (1) HDMI Type A Receptacle

HDBaseT Port

Digital Audio Output

One (1) 8P8C port (Shielded RJ45)

One (1) RCA Connector

Analog Audio Output

Ethernet

Power

RS232 Port

IR Input

IR Output

USB

One (1) 3-pin Removable Terminal Block Connector

Two (2) 8P8C port (Shielded RJ45)

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

One (1) 3-pin Removable Terminal Block Connector

One (1) 3.5 mm TRS Receptacle

One (1) 3.5 mm TRS Receptacle

One (1) USB Type A Receptacle

SUPPORTED AUDIO, VIDEO AND CONTROL

Video Resolutions

SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p,

UHD/30 VESA: Resolutions up to 1920x1200

Color Depth: 24, 30, 36, 48bit

Maximum Video

Compatibility at 100 m

Deep Color 48/36/30/24 Bit at 1080p, 3D, UHD/30

Video Compliance

Embedded Audio

HDMI 1.4 and HDCP 1.4/2.2

Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-

HD Master Audio

ARC (Audio Return Channel) No

No

HEC (HDMI

Ethernet Channel)

CEC (Consumer

Electronics Control)

Supported Baud Rates

Supported IR Carrier

Frequencies

Ethernet

Yes (Pass-through Only)

2400, 4800, 9600, 19200, 38400, 57600, 115200

33 to 55 kHz

100BaseT

HDBASET SIGNAL CHARACTERISTICS

Maximum Distance

100 m (328 ft)

Cable Requirements

Continuous solid core Category 5e or greater with

TIA/EIA-568B crimp pattern (no couplers in-line)

Bandwidth

HDBaseT Chipset

10.2 Gbps

VS100RX

CHASSIS AND ENVIRONMENTAL

Construction

Black Steel

Dimensions (H x W x D)

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

25 mm x 234.4 mm x 143.2 mm (0.98 in x 9.23 in x

5.64 in)

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

12V DC 3A

Power Output

48V DC PoH (Power over HDBaseT)

802.3af Alternative A

Power over Ethernet (PoE)

Compatibility

Power Consumption

ESD Protection

Regulatory

15 watts

15kV air, 8kV contact

FCC, CE, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

HDCP, Link, and Power

HDBaseT Transmitter (A/V,

PoE, Control) Compatibility

DIGI-HD60C-R, DIGI-HDX-S, FLX-64, INT-HD70-TX,

INT-HDX100-TX, DIGI-1X4B-1H, FLX-44, INT-44HDX,

INT-66HDX, INT-88HDX, AS-1H1V, AS-1H1V-WP, AS-

1H1DP, AS-1H1DP-WP, AS-2H, AS-2H-WP, ASW-WP

FLX-BO4A, DIGI-P123, DIGI-44B, DIGI-88B

HDBaseT Transmitter (A/V,

Control) Compatibility

HDBaseT Transmitter (A/V and PoE) Compatibility

DIGI-HD60-S, DIGI-HD60-WP-S

Included Accessories

Installation Guide, Power Supply, 3-pin Removable Screw Terminal. Optional Accessories:

IR emitter (DIGIB-EMT), IR receiver (DIGIB-EYE), rack mount (RACK12-EXT), rack mounted power supply (PSU12)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

31

32

HDBASET EXTENDERS

DL-HDE100

HDMI OVER TWISTED PAIR SET WITH POWER, CONTROL, AND ETHERNET

HDMI transmission up to 330 feet (100m)

1080p, 4Kx2K (UHD) & 3D compatible

CEC supported

Built-in surge protection

Diagnostic LEDs

HDCP 2.2 compliant

Bidirectional Wideband IR and RS232 pass-through

100-BaseT Ethernet pass-through

Flexible power design (use power supply at TX or RX)

Locking Power Connector

The DigitaLinx

DL-HDE100

extender set transmits HDMI

(1080p, 4Kx2K (UHD) & 3D) including HDCP 2.2, Ethernet, bidirectional IR, and RS232 up to 100 meters away using a single twisted pair cable. Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations.

Flexible power design allows the units to be powered at either the TX or RX end, and only one power supply is required. The 12 volt power supply is secured with a screw-on connector to prevent the power from being accidentally disconnected. The DL-HDE100 is sold only as a set. Accessories are two IR emitters, two IR receivers, and two pairs of mounting brackets with screws. The individual transmitter and receiver are not compatible with other

HDBaseT devices due to proprietary PoE circuitry.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

One (1) HDMI Type A Receptacle

Twisted Pair

Ethernet

One (1) 8P8C port (Shielded RJ45)

One (1) 8P8C port (Shielded RJ45)

IR Input

IR Output

RS232

18V DC Power

One (1) 3.5mm TRS Jack

One (1) 3.5mm TS Jack

One (1) 3-Pole Euroblock connector

One (1) 5.5 mm Outside Diameter, 2.1 mm Inside

Diameter Barrel (Locking)

SUPPORTED AUDIO AND VIDEO

Maximum Video Compatibility

100 m: Deep Color 48/36/30/24 Bit at 1080p, 3D, and

4k x 2k (UHD) up to 30 Hz: RGB, YCbCr 4:4:4, YCbCr

4:2:2; up to 60 Hz: YCbCr 4:2:0

Video Compliance

Embedded Audio

HDMI, HDCP 2.2, and CEC (Consumer Electronics

Control)

Up to PCM 8 channel, Dolby Digital TrueHD, and

DTS-HD Master Audio

Input DDC Signal

Input Video Signal

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

IR Carrier Frequency Range

Ethernet

RS232 Baud Rate

33-55kHz at 5 volts

100BaseT

Up to 115200 baud

HDBaseT SIGNAL CHARACTERISTICS

Maximum Distance

100 m

Cable Requirements

Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern

Bandwidth

Gain

Signal to Noise Ratio (SNR)

Return Loss

Total Harmonic

Distortion (THD)

Min-Max Signal Level

Differential Phase Error

10.2 Gbps

0 dB – 10 dB at 100 MHz

>70 dB at 100 MHz over 100 m

< -30 dB at 5 KHz

< 0.005% at 1 KHz

< 0.3 V – 1.45 Vp-p

±10° at 135 MHz over 100 m

CHASSIS & ENVIRONMENTAL

Enclosure

Painted steel

Dimensions

135mm x 74mm x 15mm (5.31 in. x 2.91 in. x 0.59 in.)

Shipping Weight

Operating Temperature

(Environment)

0.82 kg (1.8 lbs.)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity

(Environment)

20% to 90%, Non-condensing

Storage Temperature

(Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER, ESD & REGULATORY

Maximum Power Consumption

3 watts (S), 6 watts (R)

Power Supply

ESD Protection

Regulatory

18vDC

15kV

CE, RoHS

OTHER

Standard Warranty

2 years

Diagnostic Indicators

Power, Status, Link, and HDCP LEDs

Included Items

Installation Guide, power supply, US power cord, IR emitters (2 ea), IR receivers (2 ea), mounting “L” brackets (4 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

HDBASET EXTENDERS

DL-HD70

HDMI OVER TWISTED PAIR SET WITH POWER AND CONTROL key features

HDMI transmission up to 230 feet (70m)

1080p, 4Kx2K (UHD) & 3D compatible

CEC supported

Built-in surge protection

Diagnostic LEDs

HDCP 2.2 compliant

Bidirectional Wideband IR and RS232 passthrough

Flexible power design (use power supply at TX or RX)

Locking Power Connector

The DigitaLinx

DL-HD70

extender set transmits HDMI

(1080p, 4Kx2K (UHD) & 3D) including HDCP 2.2, bidirectional

IR, and RS232 up to 70 meters away using a single twisted pair cable. Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations. Flexible power design allows the units to be powered at either the TX or RX end, and only one power supply is required. The 12 volt power supply is secured with a screw-on connector to prevent the power from being accidentally disconnected.

The DL-HD70 is sold only as a set. All accessories are included including two IR emitters, two IR receivers, and two pairs of mounting brackets with screws. The individual transmitter and receiver are not compatible with other

HDBaseT devices due to proprietary PoE circuitry.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

One (1) HDMI Type A Receptacle

Twisted Pair

IR Input

One (1) 8P8C port (Shielded RJ45)

One (1) 3.5mm TRS Jack

IR Output

One (1) 3.5mm TS Jack

RS232

18V DC Power

One (1) 3-Pole Euroblock connector

One (1) 5.5 mm Outside Diameter, 2.1 mm Inside

Diameter Barrel (Locking)

SUPPORTED AUDIO AND VIDEO

Maximum Video Compatibility

70 m: Deep Color 36/30/24 Bit at 1080p

40 m: Deep Color 48 Bit at 1080p, 3D, and 4k x 2k

(UHD) up to 30 Hz: RGB, YCbCr 4:4:4, YCbCr 4:2:2; up to 60 Hz: YCbCr 4:2:0

Video Compliance

Embedded Audio

HDMI, HDCP 2.2, and CEC

(Consumer Electronics Control)

Up to PCM 8 channel, Dolby Digital TrueHD, and

DTS-HD Master Audio

Input DDC Signal

Input Video Signal

5.0 volts p-p (TTL)

0.5 to 1.0 volts p-p

IR Carrier Frequency Range

RS232 Baud Rate

33-55kHz at 5 volts

Up to 115200 baud

HDBaseT SIGNAL CHARACTERISTICS

Maximum Distance

70 m

Cable Requirements

Bandwidth

Gain

Signal to Noise Ratio (SNR)

Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern

10.2 Gbps

0 dB – 10 dB at 100 MHz

>70 dB at 100 MHz over 100 m

Return Loss

< -30 dB at 5 KHz

Total Harmonic Distortion (THD)

< 0.005% at 1 KHz

Min-Max Signal Level

Differential Phase Error

< 0.3 V – 1.45 Vp-p

±10° at 135 MHz over 100 m

CHASSIS & ENVIRONMENTAL

Enclosure

Painted steel

Dimensions

135mm x 74mm x 15mm (5.31 in. x 2.91 in. x 0.59 in.)

Shipping Weight

Operating Temperature

(Environment)

0.82 kg (1.8 lbs.)

0° to +40° C (+32° to +104° F)

Operating Temperature (Chassis)

31° C (88° F) (S); 38° C (100° F) (R)

Operating Humidity

(Environment)

20% to 90%, Non-condensing

Storage Temperature

(Environment)

-10° to +60° C (+14° to +140° F)

Storage Humidity (Environment)

20% to 90%, Non-condensing

POWER, ESD & REGULATORY

Maximum Power Consumption

3 watts (S), 6 watts (R)

Power Supply

ESD Protection

18vDC

15kV

Regulatory

CE, RoHS

OTHER

Standard Warranty

Diagnostic Indicators

2 years

Power, Status, Link, and HDCP LEDs

Included Items

Installation Guide, power supply, US power cord, IR emitters (2 ea), IR receivers (2 ea), mounting “L” brackets (4 ea), mounting screws (4 ea)

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

33

ADDITIONAL EXTENDERS / CONVERTERS

DL-HDCOAX

HDMI AND IR EXTENSION OVER RG6/RG59

The Digitalinx

DL-HDCOAX

is an HDMI over Coax extender that accommodates distances up to 100 meters (328ft). The

DL-HDCOAX supports resolutions up to 1080p and 48KHz Digital

Audio. The DL-HDCOAX features IR capability allowing the user to control the source from the display. The DL-HDCOAX is HDMI 1.3 and HDCP 1.1 compliant. The transmitter and receiver are powered on both ends, power supplies are provided with the set.

key features

HDMI and IR extension over a single RG6 or RG59 cable

Extension up to 100 meters (328 feet)

Control the source device from the display

Locking BNC connectors

1080p compatible

Compact design

Power supplies and IR components are included

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI Input

One (1) HDMI Type A Receptacle

Coaxial connection

HDMI output

Coaxial connection

One (1) female BNC

One (1) HDMI Type A Receptacle

One (1) female BNC

SUPPORTED AUDIO AND VIDEO

Maximum Coaxial distance

100 meters (328ft)

Maximum Passive

HDMI Distance

5m (16 ft)

Deep Color Mode

Supported Audio

Video Compliance

36 bits (12 bits /color) bandwidth up to 225MHz

48KHz LPCM Digital Audio

HDMI 1.3, HDCP 1.1

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted steel

Dimensions

80 mm x 41 mm x 25 mm (3.14 in x 1.61 in x 0.98 in)

Shipping Weight

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0.54 kg (1.20lbs)

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-20°C to +60° C (-4° to +140° F)

20% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Power Supply

Input Voltage

100-240v at 50/60 Hz at 0.15 A

Power Supply

Output Rating

ESD Protection

Device Regulatory

5v DC at 1 A

15kV

CE, RoHS, FCC

Power Supply Regulatory

UL, FCC, LPS

OTHER

Warranty

Diagnostic Indicators

2 years

Power LED

Included Accessories

Installation guide, (2) power supplies, IR Tx cable, IR Rx cable

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

34

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

ADDITIONAL EXTENDERS / CONVERTERS

3G-12EQ

1 X 2 SDI EQUALIZER WITH DUAL OUTPUTS

The Intelix

3G-12EQ

is a splitter with an SDI repeater circuit to reach long distances. Using

RG59 cable, the 3G-12EQ can extend a 3G-SDI input signal up to 70m, an HD-SDI signal up to

110m, or an SD-SDI signal up to 240m.

key features

1

× 2 SDI splitter with built-in SDI repeater circuitry

Diagnostic LEDs

240m SD-SDI distance

110m SD-SDI distance

70m SD-SDI distance

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

SDI Input

One female BNC

SDI Output

Two female BNC

5V DC Power

One barrel (5.5mm OD; 2.6mm ID)

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Painted metal

Enclosure Dimensions

(H x W x D)

Shipping Weight

28mm × 78mm × 58mm

(1.14 in × 3.07 in × 2.28 in)

0.2 kg (0.44 lbs)

Operating Temperature

0° to +48° C (+32° to +120° F)

Operating Humidity

Storage Temperature

Storage Humidity

10% to 90%, non-condensing

-20° to +70° C (+14° to +158° F)

10% to 85%, non-condensing

OTHER

Warranty

Diagnostic Indicators

2 years

SDI input signal, power

Included Accessories

Wall mount power supply, power supply adapters (US,

EU, UK, AU), installation guide

VIDEO/AUDIO PERFORMANCE

SDI Resolutions

720 × 480i/p (4:3 and 16:9),

720 × 576i/p (4:3 and 16:9),

1280 × 720p: 50/60 Hz,

1920 × 1080i: 25/30 Hz,

1920 × 1080p: 50/60 Hz

SDI Compatibility

Maximum Input

Distance (RG59)

Supported Audio

SD-SDI (SMPTE 259M), HD-SDI

(SMPTE 292M), 3G-SDI

(SMPTE 424M)

SD-SDI: 240m, HD-SDI: 110m,

3G-SDI: 70m

Up to 8 channel PCM

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.8A

Power Supply Output

Power Consumption

ESD Protection

Product Regulatory

12VDC / 2.0A

24 watts (max)

±15 kV

FCC, CE, IC, RoHS

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

FULLY UPDATED TECH SPECS

For all products available online!

www.LibAV.com

UL, CUL, CE, PSE, GS, RoHS

Power Supply

Regulatory

SDI CABLE

SOLUTIONS

Liberty provides SMPTE Serial Digital Video cables from

Mini-RG59 to RG6 sized formats. All of our products are swept to 4.5 GHz and feature exceptional SRL ratios.

These cables support up to 3G-SDI formats & all analog

& digital audio formats that use coaxial cable.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

35

ADDITIONAL EXTENDERS / CONVERTERS

3G-14

1 X 4 SDI DISTRIBUTION AMPLIFIER

The Intelix

3G-14

is a high efficiency four output SDI splitter. The 3G-14 is compatible with SD-SDI, HD-SDI

& 3G-SDI signal formats, including

HDCCTV.

key features

1 × 4 SDI distribution amplifier/splitter

Supports SD-SDI, HD-SDI & 3G-SDI

Diagnostic LEDs

240m SD-SDI distance

110m SD-SDI distance

70m SD-SDI distance

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

SDI Input

One female BNC

SDI Output

5V DC Power

Four female BNC

One barrel

(5.5mm OD; 2.6mm ID)

VIDEO/AUDIO PERFORMANCE

SDI Resolutions

720 × 480i/p (4:3 and 16:9),

720 × 576i/p (4:3 and 16:9),

1280 × 720p: 50/60 Hz,

1920 × 1080i: 25/30 Hz,

1920 × 1080p: 50/60 Hz

SDI Compatibility

Maximum Input

Distance (RG59)

Supported Audio

SD-SDI (SMPTE 259M), HD-SDI

(SMPTE 292M), 3G-SDI

(SMPTE 424M)

SD-SDI: 240m, HD-SDI: 110m,

3G-SDI: 70m

Up to 8 channel PCM

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Painted metal

Enclosure Dimensions

(H x W x D)

Shipping Weight

30mm × 140.4mm × 61mm

(1.18 in × 5.23 in × 2.40 in)

0.3 kg (0.66 lbs)

Operating Temperature

0° to +48° C (+32° to +120° F)

Operating Humidity

10% to 90%, non-condensing

Storage Temperature

Storage Humidity

-20° to +70° C (+14° to +158° F)

10% to 85%, non-condensing

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.8A

Power Supply Output

5VDC / 2.0A

Power Consumption

10 watts (max)

ESD Protection

±15 kV

Product Regulatory

Power Supply

Regulatory

FCC, CE, IC, RoHS

UL, CUL, CE, PSE, GS, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

SDI input signal, SDI output signal, power

Included Accessories

Wall mount power supply, power supply adapters

(US, EU, UK, AU), installation guide

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

INTELIX DIGI-P52

THE MOST RELIABLE

PRESENTATION SWITCHER

YOU’LL NEVER SEE!

36

Provided by

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

ADDITIONAL EXTENDERS / CONVERTERS

3G-SH

3G-SDI TO HDMI CONVERTER

SDI TO HDMI CONVERTER

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

SDI Input

One female BNC

HDMI Output

SDI Output

One HDMI type A

One female BNC

5V DC Power

One barrel (5.5mm OD; 2.6mm ID)

VIDEO/AUDIO PERFORMANCE

SDI Resolutions

SDI Compatibility

720 × 480i/p (4:3 and 16:9),

720 × 576i/p (4:3 and 16:9),

1280 × 720p: 50/60 Hz,

1920 × 1080i: 25/30 Hz,

1920 × 1080p: 50/60 Hz

SD-SDI (SMPTE 259M), HD-SDI

(SMPTE 292M), 3G-SDI

(SMPTE 424M)

Maximum Input

Distance (RG59)

Supported Audio

HDMI Output

Reso lutions

HDMI Output

Compatibility

SD-SDI: 240m, HD-SDI: 110m,

3G-SDI: 70m

Up to 8 channel PCM

720x480i/p (4:3 and 16:9),

720x576i/p (4:3 and 16:9),

1280x720p: 50/60 Hz, 1920x1080i:

25/30 Hz, 1920 × 1080p: 50/60 Hz

HDMI 1.3a

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Painted metal

Enclosure Dimensions

(H x W x D)

Shipping Weight

30mm × 112mm × 88mm

(1.18 in × 4.41 in × 3.46 in)

0.3 kg (0.66 lbs)

Operating Temperature

0° to +48° C (+32° to +120° F)

Operating Humidity

10% to 90%, non-condensing

Storage Temperature

-20° to +70° C (+14° to +158° F)

Storage Humidity

10% to 85%, non-condensing

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.8A

Power Supply Output

5VDC / 2.0A

Power Consumption

10 watts (max)

ESD Protection

Product Regulatory

Power Supply

Regulatory

±15 kV

FCC, CE, IC, RoHS

UL, CUL, CE, PSE, GS, RoHS

The Intelix

3G-SH

is a professional broadcast video product capable of converting 3G-SDI,

HD-SDI or SD-SDI to HDMI. This allows viewing of broadcast content on standard consumer & commercial HDMI video displays.

The 3G-SH has one looping SDI output channel, which supports RGB & YUV color spaces & the

HDCCTV standard.

key features

SDI to HDMI converter

Supports SD-SDI, HD-SDI & 3G-SDI

Diagnostic LEDs

Looping SDI outputs

Supports unencrypted HDMI content up to 1080p

& 8 channel PCM audio

OTHER

Warranty

2 years

Diagnostic Indicators

SDI input signal, SDI output signal, power

Included Accessories

Wall mount power supply, power supply adapters (US,

EU, UK, AU), installation guide

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

FULLY UPDATED TECH SPECS

For all products available online!

www.LibAV.com

Intelix products are available to Liberty dealers on an introductory basis at tremendous savings!

Demo new items for 60 days RISK-FREE and purchase products at great savings off standard dealer pricing. Each Intelix SKU qualifies for a one-time single unit discounted purchase.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

37

ADDITIONAL EXTENDERS / CONVERTERS

3G-HS

HDMI TO 3G-SDI CONVERTER

HDMI TO SDI CONVERTER

The Intelix

3G-Hs

is a professional broadcast video product capable of converting HDMI to 3G-SDI, HD-SDI or

SD-SDI. This allows viewing of industry standard consumer & commercial HDMI video components such as video players, computers & more on broadcast products.

The 3G-SH has two SDI output channels, which support RGB & YUV color spaces & the HDCCTV standard.

key features

HDMI to SDI converter

Supports SD-SDI, HD-SDI & 3G-SDI

Diagnostic LEDs

Dual SDI outputs

Supports unencrypted HDMI content up to 1080p &

8 channel PCM audio

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

HDMI Input

One HDMI type A

SDI Output

Two female BNC

5V DC Power

One barrel (5.5mm OD; 2.6mm ID)

VIDEO/AUDIO PERFORMANCE

HDMI

Input Resolutions

HDMI

Input Compatibility

720 × 480i/p (4:3 and 16:9),

720 × 576i/p (4:3 and 16:9),

1280 × 720p: 50/60 Hz,

1920 × 1080i: 25/30 Hz,

1920 × 1080p: 50/60 Hz

HDMI 1.3a

HDCP Input Compliance

Unencrypted content only

SDI Output Resolutions

720 × 480i/p (4:3 and 16:9),

720 × 576i/p (4:3 and 16:9),

1280 × 720p: 50/60 Hz,

1920 × 1080i: 25/30 Hz,

1920 × 1080p: 50/60 Hz

SDI Compatibility

Supported Audio

SD-SDI (SMPTE 259M), HD-SDI

(SMPTE 292M), 3G-SDI (SMPTE

424M)

Up to 8 channel PCM

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Painted metal

Enclosure Dimensions

(H x W x D)

Shipping Weight

30mm

× 112mm × 88mm

(1.18 in

× 4.41 in × 3.46 in)

0.3 kg (0.66 lbs)

Operating Temperature

0° to +48° C (+32° to +120° F)

Operating Humidity

10% to 90%, non-condensing

Storage Temperature

Storage Humidity

-20° to +70° C (+14° to +158° F)

10% to 85%, non-condensing

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.8A

Power Supply Output

5VDC / 2.0A

Power Consumption

ESD Protection

Product Regulatory

Power Supply

Regulatory

10 watts (max)

±15 kV

FCC, CE, RoHS

UL, CUL, CE, PSE, GS, RoHS

OTHER

Warranty

2 years

Diagnostic Indicators

HDMI input signal, power,

SDI output signal (2 ea)

Included Accessories

Wall mount power supply, power supply adapters

(US, EU, UK, AU), installation guide

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

FULLY UPDATED TECH SPECS

For all products available online!

www.LibAV.com

future-proof your installations today with 4k matrix switching for an outrageously low price!

38

MEET LIBERTY'S CATEGORY7 CABLE

Perfect for 4K and HDBaseT infrastructures!

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

ADDITIONAL EXTENDERS / CONVERTERS

DL-FO-HDLC

HDMI OVER SINGLE MM OR SM LC END MODULE TX/RX SET

The DigitaLinx

DL-FO-HDLC

extender set transmits HDMI signal using a Fiber Optic cable. The DL-FO-HDLC supports up to 4k resolutions. The DL-FO-HDLC extends signals up to

300m via single mode or multi-mode cable. To achieve the best performance, it is recommend the product be used with

OM2 or greater multimode fiber. Built-in diagnostic LEDs ensure hassle-free and robust installations.

Extension up to 1000 ft (300m) over SM fiber

Bandwidth up to 10.2 Gbps

HDMI 1.4, HDCP 1.4 compliant

LC connectors

Compact design

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Video Input

One (1) HDMI

Input Connector

Outputs

Output Connector

19-pin Type A Male HDMI

(1) Optical Fiber

SimplexLC Connector

VIDEO PERFORMANCE

Video Resolution & Depth

Audio Format

HDMI Standard

Transmission Distance

[email protected] 8-bit, 1080P60 Deep Color, 3D

PCM. Dolby Digital, DTS, DTS-HD

Supports HDMI 1.4 and HDCP 1.4

300m single mode or multi-mode fiber

CHASSIS AND ENVIRONMENTAL

Enclosure Dimensions (H x W x D)

10 mm x 60 mm x 22 mm ( 0.39 in x 2.36 in x

0.86 in)

Shipping Weight

(1.2 kg) 2.64lbs

Operating Temperature

Storage Humidity

0°C to + 50°C (+32° to + 122° F)

10% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz

Power Supply Output

Power Consumption

Product Regulatory

5VDC / 1 A

2.5 watts

FCC, CE

OTHER

Warranty

Diagnostic Indicators (TX Side)

Diagnostic Indicators (RX Side)

2 years

Power, Link

Power, Link

Included Accessories

Installation guide, (2) power supplies, IR Tx cable, IR Rx cable

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

39

ADDITIONAL EXTENDERS / CONVERTERS

DL-HDCP-C DL-SP

The DigitaLinx

DL-HDCP-C

is a 1x1

HDCP 2.2 TO 1.4 CONVERTER HDMI SURGE PROTECTOR key features

Converts HDCP 2.2 to HDCP

1.4 for integration into legacy systems

HDMI input and HDMI output

Compact design

HDMI converter that features highdefinition HDMI transmission and HDCP conversion. The DL-

HDCP-C HDMI input supports HDMI 2.0 &

HDCP 2.2 along with

HDMI output support of HDMI 1.4 & HDCP

1.4. The DL-HDCP-C transmits signal up to 15m with a max resolution support of

[email protected]

The DigitaLinx

DL-SP

is an

HDMI Surge Protector. The

DL-SP is an ideal solution designed to protect HDMI devices against electrostatic discharge, surges

& spikes from mains, or lightning strikes that cause electrical transients up to

15000 Volts (air) and 8000

Volts (contact).

key features

Protects the input and output from ESD and lightning surges

HDMI 1.4 and HDCP compliant

Meets IEC 61000-4-2, 61000-4-4, and 61000-4-5 surge protection requirements

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Video Input

One (1) HDMI

Input Connector

Outputs

Outputs

19-pin Type A female HDMI

HDMI 1.4, HDMI 2.0 & HDCP 2.2

One (1) HDMI

Output Connector

HDMI Standard

19-pin Type A female HDMI

HDMI 1.4 & HDCP 1.4

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Video Input

One (1) HDMI

Input Connector

HDMI Standard

Input Video Signal

19-pin Type A female HDMI

HDMI 1.4 with 3D and HDCP compliant

0.5~1.2 V p-p

Outputs

Output Connector

One (1) HDMI

19-pin Type A female HDMI

VIDEO PERFORMANCE

Video Resolution

VIDEO PERFORMANCE

Video Resolution &

Transmission Distance

Bandwidth

Audio Format

Audio Sampling Rate

EDID Management

Up to 1080p / 20m and [email protected] / 15m

18Gbps

PCM. Dolby Digital, DTS, DTS-HD, DTS-ES

32k, 44.1k, 48k, 88.2k, 96k, 176.4k, 192k

Support pass-through EDID

CHASSIS AND ENVIRONMENTAL

Enclosure Dimensions (W x H x D)

45.5 mm x 12 mm x 75 mm ( 1.79 in x 0.47 in x 2.95 in)

Shipping Weight

Operating Temperature

Storage Humidity

(49g) 0.10lbs

0°C to + 50°C (+32° to + 122° F)

10% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz

Power Supply Output

Power Consumption

Product Regulatory

5VDC / 1 A

0.5watts

FCC, CE

OTHER

Warranty

2 years

Diagnostic Indicators (TX Side)

Power

Included Accessories

(1) Power Supply, Installation Guide, (2) Mounting Ears, (2) Screws and

(4) Plastic Cushions

Transmission Distance

Supported HDMI Features

VESA: 640x480, 800x600, 1024x768,

1280x1024, 1600x1200, 1920x1080, 1920x1200

HDTV: 480i, 576i, 480p, 576p, 720p, 1080i,

1080p

15m/ 49ft max

HDMI Ethernet Channel (HEC), Audio Return

Channel (ARC) passthrough

CHASSIS AND ENVIRONMENTAL

Enclosure Dimensions (W x H x D)

65 mm x 46 mm x 25 mm ( 2.6 in x 1.8 in x

1.0 in)

Shipping Weight

(80g) 0.17lbs

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0°C to + 45°C (+32° to + 113° F)

10% to 90%, Non-condensing

-20°C to + 70°C (-4° to + 140° F)

10% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

IEC Specifications

IEC 61000-1-2/ 4-2 (ESD) ±15kV (15000 Volts)

(Air), ±8kV (8000 Volts) (Contact)

Maximum Spike Protection

±8kV (8000 Volts)

ESD Protection

±15 kV (Air-gap discharge), ±8 kV

(Contact discharge)

OTHER

Warranty

Included Accessories

2 years

(1) Ground Wire and Installation Guide

Included Accessories

(C1) Power Supply, Installation Guide, (2) Mounting Ears, (2) Screws and (4) Plastic ushions

40

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

DL-SP

HDMI SURGE PROTECTOR

USB 3.0 EXTENSION

DL-USB3.0

DIGITALINX 15 M USB 3.0 ACTIVE EXTENSION CABLE

TECH SPECS

INPUT/OUTPUT CONNECTIONS

USB Connector on

Device Side

1 x USB 3.0 Type A Locking

Receptacle per AIA USB 3

Vision™ specification

USB Connectors on Host Side

1 x USB 3.0 host connector &

1 x USB 3.0 power connector

(recommended for devices drawing more than 2.5W)

The

DL-USB3.0

is a USB 3.0 active copper cable that offers extension up to 15 meters. The DL-USB3.0 is bus powered from the host PC side and USB 3.0 power connector is available if additional power is required. The DL-USB3.0 supports USB

3.0 throughputs up to 5Gbps, locking USB connector, rugged grade cabling and slot port for convenient cable tie mounting.

The DL-USB3.0 supports only USB 3.0 devices. USB 2.0 and 1.1 devices will not function using this extender.

SUPPORTED SIGNALS

USB 3.0

Up to 5Gbps (Not backward compatible with USB 2.0/1.1)

USB 2.0

Not Supported

USB 1.1

Not Supported

CABLE AND ENVIRONMENTAL

Shipping Weight

Shipping Weight 1.63kg

(3.60lbs)

Operating Temperature

0°C to 45°C (32°F to 113°F)

Operating Humidity

Storage Temperature

Storage Humidity

20% to 80% relative humidity, non-condensing

-20°C to 70°C (-4°F to 158°F)

10% to 90% relative humidity, non-condensing

POWER AND REGULATORY

Power Source

Bus Power

Available Power to Device

5V, 900mA

EMC

Environmental

Flammability

Machine Vision

FCC (Class B), CE (Class B)

RoHS2 (CE)

VW-1 (UL 1581)

Works with AIA USB3 Vision™ compliant devices

OTHER

Warranty

Included Accessories

2 years

USB 3.0 15m active extension cable & installation guide

DIGI-FO-USB3.0

USB 3.0 Fiber Optic Extender Set

The Intelix

DIGI-FO-USB3.0

is a two-port

USB 3.0 SuperSpeed extension solution, enabling USB 3.0 connections at up to 5

Gbps over 100m/330ft of OM3 multimode fiber optic cable. The DIGI-FO-USB3.0 features two locking USB 3.0 ports delivering 900mA power to each port and a true plug-and-play solution. The DIGI-

FO-USB3.0 is not backwards compatible with USB 2.0 and USB 1.1.

key features

Active USB 3.0 extension up to 100 meters (OM3 MM)

Supports USB 3.0, not backwards with USB 1.1/2.0

2-port hub on client end

Host-side powered via USB port from host PC

Includes client-side power supply with locking power connector

Transparent USB; Plug and Play (no software drivers needed)

Compatible with all major operating systems

TECH SPECS

CLIENT SIDE INPUT/OUTPUT CONNECTIONS

USB Input

Link Connector

One (1) USB 3.0 Type B

Receptacle

One (1) Duplex LC Connector

Shipping Weight

0.997kg (2.20 lbs)

Operating Temperature

0°C to 50°C (32°F to 122°F)

Operating Humidity

Storage Temperature

20% to 80%, Non-condensing

-20° to +70° C (-4° to +158° F)

HOST SIDE INPUT/OUTPUT CONNECTIONS

USB Outputs

Two (2) USB 3.0 Type A

Receptacles

Link Connector

5V DC Power

USB PERFORMANCE

Maximum Distance

One (1) Duplex LC Connector

5V DC, 3A, Locking, 2.5 mm, center-positive

100 m (328 ft) over 2-strand

50/125μm multimode (MMF) fiber optic cable with Duplex

LC connectors

Storage Humidity

10% to 90%, Non-condensing

POWER AND REGULATORY

Power Supply Input

100V-240VAC Brick, locking

Power Supply Output

Power Consumption

5VDC / 3.0A

15 watts (max)

Available Current

ESD Protection

900mA for each USB Port

±15 kV

Product Regulatory

FCC (Class B), CE (Class B),

RoHS2 (CE)

Power Supply Regulatory

UL, CUL, CE, GS

USB Device Support

USB Host Support

USB 3.0 up to 5 Gbps (Not backward compatible with USB

2.0/1.1) xHCI Controllers (Intel,

AMD, Renesas (NEC), Fresco,

AsMedia)

CHASSIS & ENVIRONMENTAL

Enclosure Material

Black Anodized Aluminum

Enclosure Dimensions

100mm x 76mm x 26mm (3.94” x

2.99” x 1.02”)

OTHER

Warranty

2 years

Diagnostic Indicators

(Host Side)

Diagnostic Indicators

(Client Side)

Power, Status, Host

Power, Status, Host

Included Accessories

(1) Power Supply, USB 3.0 Cable, Installation Guide

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

41

USB 2.0 EXTENSION

DIGI-HDUSB

HDMI with USB 2.0 100m Extention System

The Intelix

DIGI-HDUSB

extends HDMI

& computer USB 2.0 signals up to 100m

(330ft) over twisted pair cabling. The

DIGI-HDUSB 3-port USB/video extender system supports full uncompressed HD video & USB 2.0 (up to 30Mbps) suitable for video applications in conjunction with keyboards, mice & USB 1.1 web cameras.

The DIGI-HDUSB supports HDMI video features such as 1080p, 4K, deep color &

CEC/HDCP pass-through. The DIGI-HDUSB supports both USB 1.1 & 2.0 devices.

key features

Extension up to 100m over CAT5e or greater cable

Supports both USB 1.1 & 2.0 signals up to 30Mbps

HDMI supports 1080p, 3D & 4K

CEC/HDCP pass through

Plug-and-Play feature, no drivers required

Powered on both transmitter & receiver

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

USB Input

One USB Type B Receptacle

Video Input

Link Output

5V DC Power

One HDMI In

One 8P8C connector (RJ45 style)

One barrel (5.5mm OD; 1.7mm ID)

CLIENT INPUT/OUTPUT CONNECTION

USB Outputs

Three USB Type A Receptacles

Video Output

Link Input

5V DC Power

One HDMI Out

One 8P8C connector (RJ45 style)

One barrel (5.5mm OD; 1.7mm ID)

USB PERFORMANCE

Maximum Distance

100 m (328 ft) over Cat 5e or greater cable

USB Device Support

High-speed devices

(USB 2.0) - up to 30 Mbps

Full-speed devices

(USB 2.0 & 1.1) - up to 12 Mbps

Low-speed devices

(USB 2.0 & 1.1) - up to 1.5 Mbps

USB Hub Support

USB Host Support

Any single chain can include up to 4 USB hubs.

EHCI (USB 2.0) &

OHCI/UHCI (USB 1.1)

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Black Anodized Aluminum

Enclosure Dimensions

(H x W x D)

112mm x 175mm x 30mm

(4.4 in x 6.9 in x 1.18 in)

42

DIGI-HDUSB

Operating

Temperature

0° to +40° C (+32° to +104° F)

Operating Humidity

120% to 80%, Non-condensing

Storage Temperature

-20° to +70° C (-4° to +158° F)

Storage Humidity

10% to 90%, Non-condensing

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.6A

Power Supply Output

5VDC / 3.0A

Power Consumption

15 watts (max)

Power Available to USB device at REX

ESD Protection

500mA each port

±15 kV

Product Regulatory

Power Supply

Regulatory

FCC, CE, IC, RoHS

UL, CUL, CE, PSE, GS, RoHS

OTHER

Warranty

Diagnostic Indicators

(Host Side)

2 years

Power, Link, USB, Video

Diagnostic Indicators

(Client Side)

Power, Link, USB, Video

Included Accessories

Power Supply, USB cable,

HDMI cable, Installation Guide

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

USB 2.0 EXTENSION

DIGI-USB2-4P

USB 2.0 4-port Extension System

DIGI-USB2-4P

BLACK 4 PORT

USB 2.0 EXTENDER SET

The Intelix

DIGI-USB2-4P

extends computer

USB 1.1 signals up to 100m (330ft) over twisted pair cabling to four remote devices. The DIGI-USB2-4P utilizes inexpensive twisted pair cabling & has a throughput of up to 480Mbps.

The DIGI-USB2-4P is perfect for keyboard & mouse extension, remote data ports, up to 4 USB hugs, security applications & interactive white board applications.

Extension up to 100m over Cat 5e/Cat 6

Supports USB 1.1 and 2.0 signals up to 480Mbps

Integrated 4-port USB hub

Plug-and-play, no drivers required

Powered on port (client) end

VIDEO LIBRARY

Product & services overviews & highlights

HDMI ADAPTER RINGS

Learn all about Liberty's DL-AR HDMI Adapter

Rings.

PRODUCT SOLUTIONS

Liberty offers an extensive line of audio/video products through its core and distributed brands.

FIBER TERMINATION

Need to terminate fiber optic cables in the field?

The Fiber Optic Termination Kit is the answer for you. Watch the videos to learn all about it.

CABLE TERMINATION

Learn how to terminate your own cables in the field in a matter of minutes.

COOL SPOOL

Check out our unique, time-saving reel box system and versatile 3-in-1 hand truck.

LIBERTY CULTURE

Take a look at where Liberty is going and how our parent company, WESCO, will help us get there.

LATEST VIDEOS ONLINE

SEARCH BY PART NUMBER

• SSF Fiber Optic Solutions

• SP Controls Pixie Plus Configuration

• Product Training: FLX-44, FLX-88, FLX-1616, FLX-3232

• Product Video: DIGI-P122 & DIGI-P123

• Product Review: DIGI-HD60C www.libertycables.com

TECH SPECS

HOST INPUT/OUTPUT CONNECTIONS

USB Input

One USB Type B Receptacle

Link Output

One 8P8C connector (RJ45 style)

5V DC Power

One barrel (5.5mm OD; 1.7mm ID)

CLIENT INPUT/OUTPUT CONNECTION

USB Outputs

(500 mA max current)

Four USB Type A Receptacles

Link Input

5V DC Power

One 8P8C connector (RJ45 style)

One barrel (5.5mm OD; 1.7mm ID)

CHASSIS AND ENVIRONMENTAL

Enclosure Material

Anodized Aluminum

Enclosure Dimensions

(H x W x D)

Shipping Weight

Operating

Temperature

Operating Humidity

Storage Temperature

26 mm x 100 mm x 76 mm

(1.02 in x 3.94 in x 2.99 in)

0.9 kg (2.0 lbs)

0° to +50° C (+32° to +122° F)

10% to 90%, Non-condensing

-20° to +70° C (+14° to +158° F)

Storage Humidity

10% to 85%, Non-condensing

USB PERFORMANCE

Maximum Distance

100 m (328 ft) over Category 5e or greater cable

USB Device Support

High-speed devices

(USB 2.0) - up to 480 Mbps

Full-speed devices

(USB 2.0 & 1.1) - up to 12 Mbps

Low-speed devices

(USB 2.0 & 1.1) - up to 1.5 Mbps

USB Hub Support

USB Host Support

Maximum USB

Devices Supported

Any single chain can include up to 4 USB hubs plus one

DIGI-USB2-4P.

xHCI (USB 3.0) at USB 2.0 speed,

EHCI (USB 2.0) & OHCI/UHCI

(USB 1.1)

Up to 15 USB devices or 4 USB hubs with 11 USB devices.

POWER AND REGULATORY

Power Supply Input

100V-240VAC / 50-60 Hz / 0.6A

Power Supply Output

Power Consumption

ESD Protection

Product Regulatory

Power Supply

Regulatory

5VDC / 3.0A

15 watts (max)

±15 kV

FCC, CE, IC, RoHS

UL, CUL, CE, PSE, GS, RoHS

OTHER

Warranty

Included Accessories

2 years

Power supply

Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

43

AUDIO AMPLIFICATION

AUD-220

2 INPUT AUDIO AMPLIFIER, 2x20W (4 OHM)

The Intelix

AUD-220

is a 2x20 watt Class D amplifier with 8Ω speaker output. The amplifier features two analog audio inputs and a balanced microphone input with ducking functions. Additional features of the AUD-220 include input and microphone volume control, bass and treble adjustments, microphone mixing with source audio, and three modes of microphone input support (48 dB gain, 48 dB gain with 48V phantom power, and line level).

The AUD-220 has three methods of control: push button, RS232, and IR with the optional AUD-220-IR accessory kit.

key features

Two analog audio inputs

Microphone input with ducking or mixing

Bass, treble adjustments

Line input and/or microphone muting

Stereo, 2x mono, or bridged mono speaker output

Line level loop output to daisy chain

Front panel and optional IR control

44

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Analog Inputs

Two (2) RCA Connectors; One (1) 3.5mm TRS

Connector

Microphone Input

One (1) 3-Pole/3.5mm Euroblock

Control (Top Panel)

Push Button

Control (Input Panel)

Microphone Signal Type Selector

Output Signal Format Selector

RS232 via One (1) 3-Pole/3.5mm Euroblock; IR via One (1) 3.5mm TRS Connector

One (1) 3-Position Slider Switch

One (1) 3-Position Slider Switch

Analog Loop Output

Speaker Output

24V DC Power

One (1) 3-Pole/3.5mm Euroblock

One (1) 4-Pole/3.81mm Euroblock

One (1) Locking Barrel (5.5 mm OD, 2.1 mm ID)

AUDIO PERFORMANCE

Input Impedance

Output Impedance

Maximum Rated Power Output

Frequency Response

Common Mode Rejection

Ratio (CMRR)

Signal to Noise Ratio (SNR)

Total Harmonic Distortion +

Noise (THD+N)

Voltage Gain

>10k Ω

50 Ω Analog Output; 4/8 Ω Speaker Output

40 Watts

120 Hz to 20 kHz

>70 dB at 20 Hz to 20 kHz

80 dB (Max)

1% at 1 kHz; 0.3% at 20 kHz at Nominal Level

32 dB

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted Aluminum

Dimensions (H x W x D)

Shipping Weight

40 mm x 123 mm x 87 mm (1.57 in x 4.84 in x

3.48 in)

0.86 kg (1.90 lbs)

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Minimum Power Consumption

5 watts

Maximum Power Consumption

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

45 watts

100-240v AC at 50/60 Hz at 0.5 A

24V DC at 2 A

15kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

OTHER

Warranty

Diagnostic Indicators

2 years

Input Select LEDs, Signal Select LEDs, Up LED,

Down LED, Mute LED, Power LED

Included Accessories:

Installation guide, power supply, AC adapters (AU, EU, UK, and

US), RS232 cable, rubber feet. Optional Accessory: AUD-220-IR IR kit

Audio quality may be affected by cable grade, cable quality, source and destination equipment,

RF and electrical interference, and cable patches.

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

AUDIO AMPLIFICATION

AUD-340

3 INPUT AUDIO 70/100V AMPLIFIER, 40W

The Intelix

AUD-340

is a 40 watt Class D amplifier with 70V or 100V outputs. The amplifier features two analog audio inputs, one digital audio input, and a balanced microphone input with ducking functions. Additional features of the AUD-340 include input and microphone volume control, bass and treble adjustments, microphone mixing with source audio, and three modes of microphone input support (48 dB gain, 48 dB gain with 48V phantom power, and line level). The AUD-340 has three methods of control: push button, RS232, and IR with the optional AUD-340-IR accessory kit.

key features

Two analog audio inputs; one digital audio input

Microphone input with ducking or mixing

Bass, treble adjustments

Line input and/or microphone muting

70V or 100V output

Need Help?

We offer technical assistance on all of our products or applications!

Call us at

800-530-8998 or email:

[email protected]

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Analog Inputs

Two (2) RCA Connectors; One (1) 3.5mm TRS

Connector

Digital Input

One (1) EIAJ Optical Connector

Microphone Input

Control (Front Panel)

Control (Rear Panel)

RS232 ID Selector

One (1) 3-Pole/3.5mm Euroblock

Push Button

RS232 via One (1) 3-Pole/3.5mm Euroblock; IR via One (1) 3.5mm TRS Connector

One (1) 16-Position Rotary Switch

Microphone Signal Type Selector

70V or 100V Speaker Output

24V DC Power

One (1) 3-Position Slider Switch

One (1) 3-Pole/3.5mm Euroblock

One (1) Locking Barrel (5.5 mm OD, 2.1 mm ID)

AUDIO PERFORMANCE

Analog Input Impedance

Output Type

Maximum Rated Power Output

Frequency Response

Common Mode Rejection

Ratio (CMRR)

Signal to Noise Ratio (SNR)

Total Harmonic Distortion +

Noise (THD+N)

Voltage Gain

>10k Ω

Constant Voltage at 70V or 100V

40 Watts

120 Hz to 20 kHz

>70 dB at 20 Hz to 20 kHz

80 dB (Max)

1% at 1 kHz; 0.3% at 20 kHz at Nominal Level

26 dB

CHASSIS AND ENVIRONMENTAL

Enclosure

Painted Aluminum

Dimensions (H x W x D)

Shipping Weight

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

44 mm x 130 mm x 144 mm (1.73 in x 5.12 in x

5.67 in)

1.43 kg (3.15 lbs)

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER, ESD, AND REGULATORY

Minimum Power Consumption

5 watts

Maximum Power Consumption

45 watts

Power Supply Input Voltage

Power Supply Output Rating

ESD Protection

Device Regulatory

Power Supply Regulatory

100-240v AC at 50/60 Hz at 0.5 A

24V DC at 2 A

15kV

CE, RoHS

CE, RoHS, TUV, UL, SGS

OTHER

Warranty

Diagnostic Indicators

2 years

Input Select LEDs, Signal Select LEDs, Up LED,

Down LED, Mute LED, Power LED

Included Accessories:

Installation guide, power supply, AC adapters (AU, EU, UK, and

US), RS232 cable, rubber feet, mounting “L” brackets (2 ea), mounting screws (4 ea)

Optional Accessory:

AUD-340-IR IR kit

Audio quality may be affected by cable grade, cable quality, source and destination equipment,

RF and electrical interference, and cable patches.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

45

BROADATA

BROADATA PRODUCT OFFERING AT-A-GLANCE

LBC-HDBT-T : Stand-Alone Box HDMI HDBaseT Transmitter

Extend HDMI signals up to 100 meters

 over one CAT5e/CAT6 cable

Up to 100m at WUXGA (1920×[email protected]

Supports HDCP Encrypted Content

Supports DDC/EDID Transmission

Zero Compression and Zero Bit Reduction

Up to 720p/1080i/1080p HDTV Video

Video/Audio+IR+Data+LAN Over 1 CAT5E/

CAT6

LB-HDBT-T-Lite : HDBaseT (Lite) HDMI Transmitter

Extend HDMI signals up to 60 meters over

 one CAT5e/CAT6 cable

Up to 60m at up to 4K2K Ultra HD

Supports HDCP Encrypted Content

Supports DDC/EDID Transmission

Zero Compression and Zero Bit Reduction

Supports 720p/1080i/1080p HDTV Video

Resolution

Video/Audio+IR+Data Over 1 CAT5E/ CAT6

Cable

Compatible with our LBH/LBC Series

Products

LBC-H-T-WP : HDMI TX HDBT Wall Plate

Extend HDMI signals up to 70m over 1 shielded CAT5e/6

Compatible with our LBC & LBH Series

Products

Supports HDCP Encrypted Content & DDC/

EDID Transmission

Zero Compression and Zero Bit Reduction

HDTV Video Resolutions up to Ultra HD

(4K2K)@60 Hz

Supports PoH (Power over HDBT) on either Tx or Rx units

LBC-H-T-LPB-Lite : HDBT HDMI Transmitter with Loopback Video

Extend HDMI signals up to 60 m over one

CAT 5e/6 Cable Loopback video port

Supports Full HDTV Resolutions up to

[email protected]

Fully uncompressed video & audio provides zero loss of quality

Supports True DDC/EDID/HDCP

Transmission

Video/Audio+IR+Data, Over 1CAT 5e/6

Cable

Two-way 24V/POC Remote Powering

LBH-H/V-EAD-T : HDMI+VGA Video Transmitter with Embedded Audio and Data, HDBT (Standalone Box or Wall Plate)

Standalone Box or Decora Wall Plate

Format

Extend HDMI or VGA Signals up to 100 meters Over CAT 5e/6

Supports Video Resolutions up to Ultra HD

(4K2K)@30Hz

Fully Uncompressed Video/Audio Provides

Zero Quality Loss

Selectable manual or auto-switch for VGA and HDMI inputs

Video/Audio+Data over 1 Cable w/HDCP

LBC-HDBT-T-48 : HDBT HDMI Transmission with 48V POH Over 100m

Extend HDMI Signals up to 100m

Supports Full HDTV Video Resolutions up

 to 4K2K @ 30Hz

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission

Video/Audio+IR+Data+Ethernet

48V PoH with PSE/TX and PD/RX

HDMI 1.4 and HDCP 2.2 compliant

Supports both RS232 and IR Control Data

LBC-HDBT-T-48-KM : HDBT HDMI Transmission with 48V POH Over

100m and USB Keyboard/Mouse

Extend HDMI Signals up to 100m over one

CAT 5e/6 Cable

Supports Full HDTV Video Resolutions up to

[email protected]

Fully Uncompressed Video & Audio provides zero loss of quality

Supports True DDC/EDID/HDCP Transmission

Video/Audio+IR+Data+Ethernet, Over 1

CATR 5e/6 Cable

48V PoH with PSE/TX and PD/RX

HDMI 1.4 and HDCP 2.2 compliant

LBC-H/V-T-WP : HDMI+VGA/Audio Transmitter , HDBT,

Wall Plate Version

Extend HDMI/VGA signals up to 70m over

1 CAT5e/6

Manual or auto-switch between VGA and

HDMI inputs

Compatible with LBC & LBH Series

Products

Supports HDCP & DDC/EDID Transmission

Zero Compression and Zero Bit Reduction

Supports 4K2K 30Hz maximum resolution

Supports PoH (Power over HDBT)

LBH-H-EAD-T : HDMI Video Transmitter with Embedded Audio and

Data, HDBT (Standalone Box or Wall Plate)

Standalone box format

Supports Video Resolutions up to Ultra HD

(4K2K)@30Hz

Supports HDCP and DDC/EDID

Transmission

1 uni-direction HDMI Video 1 bi-directional audio 2 RS-232

Zero Compression and Zero Bit Reduction

LBC-HDBT2-T-48 : HDBT 2.0 HDMI Transmission with 48V POH over

100m

Compliant to HDBaseT 2.0 specs

Extend HDMI Signals up to 100 meters Over One CAT 5e/6 Cable

Supports Full HDTV Video Resolutions up to [email protected]

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission

Video/Audio+IR+Data+Ethernet+USB

+ARC, Over 1 CAT 5e/6 Cable

48V PoH with PSE/TX and PD/RX

LBC-HDV-T-Lite : HDBT HDMI/DisplayPort/VGA Transmission System

Switch & extend HDMI, DisplayPort or

VGA signals up to 70 meters over

CAT-5e/6

HDTV video resolutions up to 720p/

Fully uncompressed video with embed-

 ded audio provides zero loss of quality

Manual or auto-switching between

HDMI, DisplayPort and VGA inputs

Webserver for monitoring and configuration

LBC-H-R-DOP : HDBT HDMI Receiver with Dual Video Output

Extend HDMI Signals up to 100 meters

Over One CAT 5e/6 Cable with dual video output

Supports Full HDTV Video Resolutions

 up to [email protected]

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission

Video/Audio+IR+Data+Ethernet, Over 1

HDMI 1.14 and HDCP 2.2. compliant

LBC-H-DRP-Lite : HDBT HDMI Transmission with Dropping and

Repeating Video

Extend HDBaseT Signals up to 60m Over One

CAT 5e/6 Cable and Drop HDMI Video

Supports Full HDTV Video Resolutions up to

[email protected]

Fully Uncompressed Video & Audio Provides

Zero Loss of Quality

Supports True DDC/EDID/HDCP Transmission

Video/Audio+IR+Data, Over 1 CAT 5e/6

1-Way 24v/POC Remoting Power at HDBT

HDMI 1.4 and HDCP 2.2 compliant

LBH-DVI-EAD-T : DVI Video Transmitter with Embedded Audio and

Data, HDBaseT (Standalone Box or Wall Plate)

HDBT Standalone Box or Decora Wall

Plate formats

Single Transmitter Box

Resolutions up to [email protected] /

[email protected]

DDC/EDID/HDCP Compliant

100 meter / 328 feet over 1 shielded

Cat5E/6/6A/7 Cable

1 Audio Channel, 2 Serial Data Channels

POH power only required on one end or the other

LBC-HDBT-T-48-Lite : HDBT HDMI Transmission with 48V POH

Over 60m

Extend HDMI Signals up to 60m over

One CAT 5e/6 Cable

Supports Full HDTV Video

Resolutions up to [email protected]

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission

Video/Audio+IR+Data+Ethernet,

Over 1 CAT 5e/6 Cable

48V POH with PSE/TX and PD/RX

HDMI 1.14 and HDCP 2.2. compliant

46

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

BROADATA

BROADATA PRODUCT OFFERING AT-A-GLANCE

LBO-VH-EAD-T : Fiber Optic HDMI/VGA Transmission System

(Wall Plate or Stand Alone)

Extend HDMI/VGA signals up to 400m over multimode fiber

Ultra HD (4K2K) & HDTV video resolutions

 up to 720p/1080i/[email protected] Hz

Fully uncompressed video with embedded audio provides zero loss of quality between VGA and HDMI inputs

Video/Audio+Data over 1 cable with true

DDC/EDID/HDCP transmission

Built in signal conversion when used with

HDMI or DVI receivers

LBO-H2-T : Fiber Optic HDMI 2.0 Transmission System

Extend HDMI 2.0 signals up to 300m over multimode fiber

Video resolutions up to 4K (18 Gps) @

60Hz , 4:4:4

Fully uncompressed video & audio

 provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Video over 1 multimode fiber

HDCP 2.2 compliant

LBO-DVI-EAD-T : Fiber Optic HDMI Transmission Systems

Extend DVI Signals & embedded audio up

 to 300 meters over CAT 5e/6

720p/1080i/1080p @60Hz

Fully uncompressed video with embedded audio provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Audio/Video + Data, Over 1 multimode fiber

LBO-H-EAD-T : Fiber Optic HDMi Transmission Systems

(Wall Plate or Stand Alone)

Extend DVI Signals & embedded audio up to 300 meters over CAT 5e/6

4K2K & Full HDTB Video Resolutions of

720p/1080i/1080p @60Hz

Fully uncompressed video with embedded audio provides zero loss of quality

Supports true DDC/EDID/HDCP

 transmission over fiber

Audio/Video + Data, Over 1 multimode fiber

LBF-H-T : Link Bridge Fiber Optic HDMI 1.4 Transmitter

Extend HDMI Signals up to 3000m over multimode fiber

Ultra HD & Full HDTV video resolutions up

 to 720p/1080i/[email protected] Hz

Fully uncompressed video & audio provides zero loss of quality transmission over fiber

Video over 2 multimode fibers

Miniature form factor for ease of use and installation

LBO-DVI-T-4K : Link Bridge DVI Video Transmitter

DVI 1.0 Compliant

Up to 400m at WUXGA (1920×[email protected]

60Hz)

Automatic EDID (No EDID Learning)

Zero Compression andZero Bit Reduction

Up to 720p/1080i/1080p HDTV Video

Resolution

Over 1 Multimode Fiber Rear-mounted

Thumb Screws for Convenient Installation in Tight Spaces

LBO-H/DP-EAD-T : Fiber Optic HDMI/Display Port Transmission Systems

Switch and extend HDMI or Display Port

HDTV video resolutions up to

[email protected], as well as Ultra HD

([email protected])

Fully uncompressed video with embedded audio provides zero loss of quality

Selectable manual or auto-switching between display port (DP++) and HDMI inputs

LBO-DVI-T-4K3 : Fiber Optic DVI Transmission System

Extend DVI signals up to 400m over

 multimode fiber

Ultra HD (4K2K) & HDTV video resolutions up to 720p/1080i/[email protected]

Fully uncompressed video & audio provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Video over 1 multimode fiber

LBC-H-R-SCL : HDMI Video Scaler Receiver

Supports Input/Output PC resolutions up

 to [email protected]

Supports HDMI w/ embedded audio &

Optical audio extraction

RGB level, and scan size

Auto EDID support with connected display

Full HDBaseT 100m distance over single

CAT 5e/6 cable

Supports 5 play HDBaseT, Video/

Audio+LAN+IR+RS232+PoH

4890-SP-H-4-4K3 : HDMI Video Splitter, 1:2, Electrical, 4K2K

High performance two way and four way DVI/HDMI distribution amplifier

Maximum resolution bandwidth is 165

MHz (DVI) or 225MHz (HDMI)

HDMI 1.4 and DVI 1.0 Compliant

LBC-SPH8-1H7B-EIR : 1x7 HDMI Splitter to 1 HDMI & 7 CAT5e/6/7 with

LAN/IR, POH-TX

1 in 7 out HDBT Splitter

Video Resolutions up to Ultra HD (4K2K)

@60 Hz

Supports HDCP, DDC/EDID

Video/Audio+IR+LAN, Over 1 CAT 5e/6

Cable

Supports PoH (Power over HDBT) with compatible recievers

Fully Uncompressed Video/Audio Zero

Loss of Quality

LBC-H-R-SCL-4K3 : [email protected] HDMI HDBT Scaling Receiver

A high performance [email protected] HDMI

HDMI input ports & two simultaneous

HDMI output ports

Supports video resolutions up to 4Kx2K

([email protected]/25/30,

[email protected]/25/30)

Supports scale up and down HD video resolutions

Extend HDMI, IR,Ethernet signals up to

100m through CAT-5e/6/7 cable

4890-SP-H-2-4K3 : HDMI Video Splitter, 1:2, Electrical, 4K2k

High performance two way and four

 way DVI/HDMI distribution amplifier

Maximum resolution bandwidth is

165 MHz (DVI) or 225MHz (HDMI)

HDMI 1.4 and DVI 1.0 Compliant

4890-SP-D-2S : DVI Video Splitter, 1:2, Electrical

Phantom Powering to Fiber Optic

DVI or HDMi Module

Guaranteed interoperability between modules

Up to 1090p @ 60Hz or 1920x1200

@ 60Hz

5VDC @ 2A power

LBC-SPH4-1H3B-EIR : 1x4 HDMI Splitter to 1 HDMI & 3 CAT5e/6/7 with

LAN/IR, POH-TX

1 in 3 out HDBT Splitter

Video Resolutions up to Ultra HD (4K2K)

@60 Hz

Supports HDCP, DDC/EDID

Video/Audio+IR+LAN, Over 1 CAT 5e/6

Cable

Supports PoH (Power over HDBT) with compatible recievers

Fully Uncompressed Video/Audio Zero Loss of Quality

4890-SP-D-4S : DVI Video Splitter, 1:4, Electrical

Phantom Powering to Fiber Optic DVI or HDMi Module

Guaranteed interoperability between modules

Up to 1090p @ 60Hz or 1920x1200 @

60Hz

5VDC @ 2A power

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

47

BROADATA

BROADATA PRODUCT OFFERING AT-A-GLANCE

48

LBC-HDBT-R : Stand-Alone Box HDMI HDBaseT Receiver

Extend HDMI signals up to 100 meters over one CAT5e/CAT6 cable

Up to 100m at WUXGA (1920×[email protected]

60Hz)

Supports HDCP Encrypted Content

Supports DDC/EDID Transmission

Zero Compression and Zero Bit Reduction

Up to 720p/1080i/1080p HDTV Video

Resolution

Video/Audio+IR+Data+LAN Over 1 CAT5E/

CAT6

LBH-DVI-EAD-R : DVI Video Receiver with Embedded Audio and Data,

HDBaseT (Wall Plate or Stand Alone)

HDBT Standalone box or wall plate formats

Single Receiver Module

Resolutions up to [email protected] /

[email protected]

DDC/EDID/HDCP Compliant

100 meter / 328 feet over 1 shielded

Cat5E/6/6A/7 Cable

Compatible with the LBH Series

1 Audio Channel, 2 Serial Data Channels

POH power only required on one end or the other

LBO-H-EAD-R : Fiber Optic HDMI 1.4 Transmission Systems (Wall Plate or

Extend DVI Signals & embedded audio up to 300 meters over CAT 5e/6

Fully uncompressed video with embedded audio provides zero loss of quality

Supports true DDC/EDID/HDCP transmis-sion over fiber

Audio/Video + Data, Over 1 multimode fiber

LBC-HDBT-R-Lite : HDbaseT (Lite) HDMI Receiver

Extend HDMI signals up to 60 meters over

 one CAT5e/CAT6 cable

Up to 60m at up to 4K2K Ultra HD

Supports HDCP Encrypted Content

Supports DDC/EDID Transmission

Zero Compression and Zero Bit Reduction

Supports 720p/1080i/1080p HDTV Video

Resolution

Video/Audio+IR+Data Over 1 CAT5E/ CAT6

Cable

LBH-H-EAD-R : LB HDMI Video RX Embedded Audio (Wall Plate or

Stand Alone)

Standalone box format

Supports Video Resolutions up to Ultra HD

(4K2K)@30Hz

Supports HDCP and DDC/EDID Transmission

1 uni-direction HDMI Video 1 bi-directional audio 2 RS-232

Zero Compression and Zero Bit Reduction

Compatible with our LBH Series Products

LBO-DVI-EAD-R : Fiber Optic DVI Transmission System (Wall Plate or

Stand Alone)

Extend DVI Signls & embedded audio up to 300 meters over CAT 5e/6

4K2K & Full HDTB Video Resolutions of

720p/1080i/1080p @60Hz

Fully uncompressed video with embedded audio provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Audio/Video + Data, Over 1 multimode fiber

LBO-DVI-R : Link Bridge DVI Video Receiver

DVI 1.0 Compliant

Up to 400m at WUXGA (1920×[email protected] 60Hz)

Automatic EDID (No EDID Learning)

Zero Compression andZero Bit Reduction

Up to 720p/1080i/1080p HDTV Video

Resolution

Over 1 Multimode Fiber

Rear-mounted Thumb Screws for

Convenient Installation in Tight Spaces

LBF-H-R : Link Bridge Fiber Optic HDMI 1.4 Transmission System

Extend HDMI Signals up to 3000m over multimode fiber

Ultra HD & Full HDTV video resolutions up to 720p/1080i/[email protected] Hz

Fully uncompressed video & audio provides

 zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Video over 2 multimode fibers

Device power from USB port (500mA)

LB-ICP : Inline Control Processor

An inline control processor with multiple control I/O ports

Control I/O ports contain: two RS-232,

Control and monitor AV devices using a standard Ethernet network or keypad

Front panel port status indicators

User friendly customizable control configurations via built-in web server

LB-H-ICP : 5 Play HD-BaseT Receiver w/IR/RS-232/Ethernet and control

I/O Ports

Extend HDMI signals up to 100 meters

Supports full HDTV resolutions up to

[email protected]

ICP Supports 2 relays, 2 RS232 ports 2

Supports true DDC/EDID/HDCP transmission

Video/Audio+IT+Data+Ethernet, Over 1

CAT 5e/6 cable

LBH-H-EAD-R-ICP : HDMI Video Receiver with Embedded Audio and

Data, HDBT, Inline Control Ports

Standalone box format

Supports Video Resolutions up to Ultra HD

(4K2K)@30Hz

External Audio embedding and transport

Supports HDCP and DDC/EDID Transmission

2 RS232,2 Relay, 2 Digital I/O, 1 IR, and 1

Ethernet Port

Control via Ethernet (PC, Phone, Tablet), IR,

 or RS232

Over 1 CAT5E/6

Built in Web Server for ease of use and configuration

LB-KP8/KP4 : Keypad, 8 or 4 Keys with RS-232 Interface

8-key (or 4-key) keypad with RS-232 interface

Powered by LB-ICP

User configurable buttons with dual color and backlit

Replaceable button labels

LBC-HDBT-R-ICP : 5 Play HD-BaseT Receiver w/IR/RS-232/Ethernet and control I/O Ports

HDMI TX or RX 5-Play HD-BaseT +

Integrated Control Processor (ICP)

Bi-directional Power over HDBaseT (PoH)

ICP Supports 2 relays, 2 RS232 ports 2

Supports HDMI up to 4K2K

Extend up to 100 meter over 1 CAT 5e/6

LBH-H/O-EAD-R-ICP : HDBT/HDMI Receiver with Inline Control Processor

Receive HDMI, audio, IR, and RS-232 up to

100 meters over 1 CAT-5e/6 cable

Supports video resolutions up to 1080p 60Hz and 1920 x 1200 @ 60Hz, as well as [email protected]

Supports HDMI w/embedded audio extraction

2 RS232,2 Relay, 2 Digital I/O, 1 IR, and 1

Ethernet Port

EDID pass-through support, automatically detect the factory setting of the connected display

LBC-H-R-WP : HDMI Receiver, HDBT, Wall-Plate

Extend HDMI signals up to 70 meters over

 one CAT5e/CAT6 cable

Compatible with our LBC & LBH Series

Products

Supports HDCP Encrypted Content & DDC/

EDID Transmission

Zero Compression and Zero Bit Reduction

Ultra HD (4K2K) & HDTV Video Resolutions up to 720p/1080i/[email protected] Hz

Supports PoH (Power over HDBT) on either Tx or Rx units

LBC-H-R-DOP : HDBT HDMI Receiver with Dual Video Output

Extend HDMI signals up to 100m over CAT

5e/6 cable with dual video output

Supports Full HDTV video resolutions up to [email protected]

Fully uncompressed Video & Audio

 provides zero loss of quality

Supports true DDC/EDID/HDCP transmission

Video/Audio+IR+Data+Ethernet, Over 1

CAT 5e/6 Cable

Two-way 24V/POC Remoting Power

LBO-H2-R : Fiber Optic HDMI 2.0 Transmission System

Extend HDMI 2.0 signals up to 300m over multimode fiber

Video resolutions up to 4K (18 Gps) @

60Hz , 4:4:4

Fully uncompressed video & audio provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Video over 1 multimode fiber

HDCP 2.2 compliant

LBO-DVI-R-4K3 : Fiber Optic DVI Transmission System

Extend DVI signals up to 400m over multimode fiber

Ultra HD (4K2K) & HDTV video resolutions up to 720p/1080i/[email protected]

Fully uncompressed video & audio

 provides zero loss of quality

Supports true DDC/EDID/HDCP transmission over fiber

Video 1 multimode fiber

Built in signal conversion when used with

SDI, VGA, and S-video transmitters

LB-KP8E / LB-KP16E : Keypad, 8 or 16 keys with RS-232 Interface

1-gang wall plate Ethernet controller with

Comes with relays to control peripheral device on/off

Available with PoE function or DC power supply selection

Supports Telnet or WebGUI control

Supports scheduling control and settings

Adjustable LED dim light in keypad buttons

LBC-HDBT-T-ICP : HDBaseT Ethernet Transmitter Controller

Control of multiple Pro A/V devices while providing HDBaseT, HDMI,

Ethernet, RS232, IR, and power over

100m

Bidirectional Power over HDBaseT

True 4K resolutions

Two more RS232, digital I/O, and relays along with an IR output with IR learning

LBC-H-R-SCL-ICP : HDBaseT HDMi Scaling Receiver with Inline Control

Processor

An HDBaseT HDMI video scaling receiver with multiple control I/O ports

Not only scale HDMI video, but also provide in-line control I/O paths, over HDBaseT link

Extend HDMI, LAN, and RS-232/IR up to 100 meters over 1 CAT 5e/6 Cable

Supports input/output video scaling up to

1080p 60Hz and 1920 x 1200 @ 60Hz

High performance video scaler with OSD

Menu Control

Bi-directional PoC

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

BROADATA

BROADATA PRODUCT OFFERING AT-A-GLANCE

LBC-PSW84 : Multiformat Presentation Switch

8 video inputs: 4 HDMI inputs with

 corresponding L/R audio inputs, 2 HDBT

CAT5e/6/7 inputs, 1 PC (VGA) with L/R audio, one Composite Video with L/R audio

3 simultaneous video outputs of the

HDBT Outputs extend HDMI/VGA signals up to 100m over CAT 5e/6

Supports scaling of any input signal to a

LBS-0808 : Link Bridge System - 8 x 8 Matrix Switcher

HDMI 1.3, HDCP 1.1 and DVI 1.0 Compliant

Up to 8 Input and Output Ports with 4 or 8

Ports per I/O Card

Up to 400m over Fiber Optic cable

Up to 100m over CAT5e/6 cable between the Switch and a compatible receiver

LBS-MSWW88 : Link Bridge System - 8 x 8 Modular Switcher

An 8x8 modular matrix switcher

 with both HDMI and HDBaseT

HDBaseT I/O cards

Input cards have options for HDMI-only or combined

HDMI/HDBaseT input

Output cards are with mirrored HDMI

Supporting up to 4K2K UHD resolutions, plus all 3D

LBC-PSW52 : Presentation Scaling Switch with 5 Inputs and Two

Mirrored Outputs

Features 5 video inputs, two HDMI inputs, one

DisplayPort, & two VGA input

Two simultaneous video outputs of the selected source through the one HDBaseT and one HDMI output

HDBaseT outputs extend HDMI/VGA signals up to 70 meters over CAT-5e/6

Supports scaling of any output signal to a wide range of HDTV and VGA output resolutions up to 1080p and WUXGA

Supports control via RS-232, Telnet, WebGUI, front panel control, or contact closures

LBS-1616 : Link Bridge System - 16 x 16 Matrix Switcher

HDMI 1.3, HDCP 1.1 and DVI 1.0 Compliant

Up to 16 Input and Output Ports with 4 or

8 Ports per I/O Card

Options with HDBT Outputs, Optical or

Hybrid Optical/Electrical Ports (HDMI/DVI)

Up to 400m over Fiber Optic cable between the Switch and a compatible transmitter/ receiver

Up to 100m over CAT5e/6 cable between the Switch and a compatible receiver

LBS-8IN-H-4K3 : Link Bridge Matrix Switch, 8-Input Card, HDMI

8 Port HDMI Input Card

Compatible with LBS Series Modular

Matrix Switchers

Transmit HDMI Signals

Supports Resolutions up to WUXGA and

HDTV 1080P60

Full Uncompressed Video/Audio

Provides Zero Quality Loss

Supports True DDC/EDID Transmission

Over One Cable

LBS-8IN-HDBT-E : 8 Input Card, HDBT with Ethernet

Compatible with LBS Series Modular

Matrix Switchers

Transmit HDBT Signals up to 100

 meters Over One CAT 5e/6 Cable

Supports Ultra HD (4K/30Hz) & Full

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission Over One Cable

Supports PoH (Power over HDBT) @

24VDC

LBS-8OUT-HDBT-E : 8 Output Card, HDBT with Ethernet

Compatible with LBS Series Modular

Matrix Switchers

Transmit HDBT Signals up to 100 meters

Over One CAT 5e/6 Cable

Supports Ultra HD (4K/30Hz) & Full HDTV

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission Over One Cable

Supports PoH (Power over HDBT) @

24VDC

LBS-3232 : Link Bridge System - 32 x 32 Matrix Switcher

HDMI 1.3, HDCP 1.1 and DVI 1.0 Compliant

Up to 32 Input and Output Ports with 4 or 8

Ports per I/O Card

Options with HDBT Outputs, Optical or

Hybrid Optical/Electrical Ports (HDMI/DVI)

Up to 400m over Fiber Optic cable between the Switch and a compatible transmitter/ receiver

Up to 100m over CAT5e/6 cable between the Switch and a compatible receiver

LBS-8OUT-H-4K3 : Link Bridge Matrix Switch, 8-Output Card, HDMI

Compatible with LBS Series Modular

Matrix Switchers

Transmit HDMI 4K/30Hz Signals

Supports Ultra HD (4K/30Hz) & Full

720p/[email protected] Hz

Fully Uncompressed Video & Audio

Provides Zero Loss of Quality

Supports True DDC/EDID/HDCP

Transmission Over One Cable

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

49

NIVEO

NIVEO PRODUCT OFFERING AT-A-GLANCE

NR50 : Multi-WAN VPN Router

Multi WAN load balancing VPN Router

4 ports can be used as backup WAN or

Internet

Up to 30 IPsec tunnels for VPN use

Failover feature to manage 2 or more ISP connections

NNAS-D5 : 5 Bay SATA II Mini-NAS Subsystem

Intel Atom Dual Core 1.8G processor

Cache memory 2GB DDR II SDRAM

High Data Rates for flawless Video

Streaming

Supports five (5) 3.5" SATA II hard drives

Up to 15TB (3000 hrs of Blu-Ray data)

Two Gigabit Ethernet ports

Environmental monitoring unit

Supports RAID levels 0, 1, 5,6, 10 Linear

(JBOD)

NMC1012R : 10/100/1000BaseTX to 1000 BaseFX Managed Media

Converter

Transceiver box format with SFP Fiber

Connectivity

Multimode OM1, OM2, OM3, or OM4

Fiber up to 550M

Compliant with IEEE 802.3ab 1000BaseT

Compliant with IEEE802.3z 1000BaseSX/LX

Gigabit Ethernet

OM1 Fiber to 220m, OM2-4 Fiber to 550m

Supports Full Duplex Auto negotiation mode for Fiber port

NMC220PS : 10/100/1000BaseTX to 1000BaseFX PoE PSE Media

Converter

Transceiver box format with SFP Fiber

Multi Mode Fiber

Compliant with IEEE 802.3ab 1000BaseT

Compliant with IEEE802.3z 1000BaseSX/LX

Gigabit Ethernet

Single Mode fiber to 20Km

Supports Full Duplex Auto negotiation

NPD-MR8 : Switched 1U 19” PDU, 15A Load, 8 x NEMA 5-15/20R

Outlets

Monitors Total Current by Meter

Can be accessed over web and

SNMP

Includes free monitoring software tool

Uses the following protocols:

Http, Https, SNMP, DHCP, UDP

All outlets can be controlled individually

User defined Alarm thresholds or

Warning and Overload

N10GMM : 1-P 10GBase-SX Mini-GBIC Module (MM, SFP+, 850NM)

SFP+ format with Duplex LC Fiber Connectivity

Multimode OM3, or OM4 Fiber

Compliant with:

IEEE802.3ae 10G BASE SW/SR;

10G, 8.5G, 4.25G, 2.125G, 1.0625G Fiber CH;

Differential LVPECL inputs and CML outputs

NWA200 : In-wall low profile Fat Access Point

In-wall WAP with RJ45/USB Power/RJ11

Connectivity

2.4 GHz, 802.3af PoE, max power 9W, transmit 18dbm

Inconspicuous design for residential / commercial installs

2 3dbi omni-directional antennas

Multiple SSID

PoE

NNAS-R4 : 4 Bay SATA II Mini-NAS Subsystem

Intel Atom Dual Core 1.8G processor

Cache memory up to 4GB DDR3 SDRAM

High Data Rates for flawless Video

Streaming

Supports five (4) 3.5" SATA II hard drives

Two Gigabit Ethernet port

Environmental monitoring unit

Supports RAID levels 0, 1, 5,6, 10 Linear

(JBOD)

NMC1012RSM : 10/100/1000BaseTX to 1000BaseFX Manged Media

Converter

Transceiver box format with Duplex SC

Fiber Connectivity

Single Mode Fiber

Compliant with IEEE 802.3ab 1000BaseT

Compliant with IEEE802.3z 1000BaseSX/LX

Gigabit Ethernet

Single Mode fiber to 20Km

Supports Full Duplex Auto negotiation mode for Fiber port

Front panel diagnostic LED indications

NGS16MCR(S) : 16-Slot Media Converter Chassis for Redundant Power

Supply

Up to 16 slots of Media Converters

19” standard rack-mount size and 3U height

Hot-swappable replacement of Media

Converts and power supplies

Two redundant power supplies with two

 cooling fans (One power supply with

NGS16MCRS)

Power Isolation design to ensure each bay

NPD-MV16 : Switched oU Vertical PDU, 20A load, 16 x NEMA 15/20R

Outlets

Monitors Total Current by Meter

Can be accessed over web and

SNMP

Uses the following protocols:

Http, Https, SNMP, DHCP, UDP

Includes free monitoring software tool

All outlets can be controlled individually

User defined Alarm thresholds or

Warning and Overload

N10GSM : 1-P 10Gbase-SX Mini-GBIC Module (SM, SFP+, 1310NM)

SFP+ format with Duplex LC Fiber Connectivity

Multimode OM3, or OM4 Fiber

Compliant with:

IEEE802.3ae 10G BASE SW/SR;

10G, 8.5G, 4.25G, 2.125G, 1.0625G Fiber CH; diagnostic monitoring

Differential LVPECL inputs and CML outputs

NVMSX55OU : 1-P 1000Base-SX Mini-GBIC Module (MM, SFP)

Industry standard small form pluggable

(SFP) package

Multimode fiber required OM1,OM2,OM3 or OM4

Duplex LC receptacle

Differential LVPECL inputs and outputs

TTL signal detect indicator

NWA100 : 900 Dual-Band High Power Access Point

Dual Band, Dual Radio High Power Access

Point

2.4 & 5 GHz simultaneously

Inconspicuous design for residential/ commercial installs

Expanded wireless coverage up to 4500 sq. ft.

Speeds up to 900Mbps

Powered by PoE; Includes PoE injector

NMC220PR : 10/100/1000BaseTX to 1000BaseFX PoE PD Media

Converter

Transceiver box format with SFP Fiber

Multimode OM1, OM2, OM3, or OM4

Fiber

Compliant with IEEE 802.3ab 1000BaseT

Compliant with IEEE802.3z 1000BaseSX/LX

Gigabit Ethernet

OM1 Fiber to 220m, OM2-4 Fiber to 550m

Supports Full Duplex Auto negotiation mode for Fiber port

NPI-H1 : Gb 802.3at PoE+ (30W) Injector

Up to 30W of PoE Power

Compatible with IEEE 802.3af or Legacy

PoE applications

Safe on Low Power Devices Receive

Only the Power They Need

Safe and Reliable Power to WLAN

Access Points

Automatic Detection and Protection of

Non-standard Ethernet Terminals

Supports 10/100/1000Base-T LAN

NVSM55OU : 1-P 1000Base-SX Mini-GBIC Module (SM,SFP)

Digital Diagnostics are Internal Calibrated

Operation Temperature: 0~70C

850nm oxide VCSEL, Duplex LC receptacles

550m link distance(indicative only)

Hot pluggable

Metal enclosure, low EMI

50

800.530.8998 | www.LibAV.com | SPECIFICATIONS & IMAGES SUBJECT TO CHANGE | IMAGES NOT TO SCALE | L0230

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

NIVEO

NIVEO PRODUCT OFFERING AT-A-GLANCE

NUPS22-10000U : 10KVA True Sine-wave Double Conversion Rack/

Tower

True Sine Wave double-conversion online

Output power factor 0.9

Rack/Tower design

Output voltage regulation <1%

Higher output crest radio 5:1

Programmable power management outlets

Emergency power off function (EPO) with

NUPS22-SNMP

NUPS22-6000U : 6KVA True Sine-wave Double Conversion On-Line

UPS

3000 VA / 2700 W capacity

True double-conversion

Output power factor 0.9

Rack/Tower design

Output voltage regulation < 1%

Higher output crest radio 5:1

Programmable power management outlets

Emergency power off function (EPO) with

NUPS22-SNMP

NGSM16AVB : Layer 2 Gb Full Mang. AVB Ethernet Switch: 16 -port Gb

+ 2 Gb SFP Open Slots (Release Q2-2016)

Combining Full Enterprise Management with AVB for ultimate Flexibility

No ‘additional licenses’ or firmware needed for AVB

Use Dante and AVB simultaneously

Non-blocking architecture

Remote notifying options: ‘hands free management’

NUPS22-1000U : 1KVA True Sine-wave Double Conversion Rack/

Tower UPS

1000 VA / 900 W capacity

True double-conversion

Output power factor 0.9

Rack/Tower design

Output voltage regulation < 1%

Higher output crest radio 5:1

Programmable power management outlets with NUPS22-SNMP

NUPS22-SNMP : SNMP card for NUPS22-series

Allows control and monitoring of multiple

UPSs through RJ-45 network connection

Real-time dynamic graphs of UPS data

Warning notifications via audible alarm,

Historic data log stored in centralized PC database

Simple firmware upgrade with on click

Password security protection and remote access management

NGSME16AVB : Layer 2 Gb Full Mang. AVB Ethernet Switch: 16 -port

Gb + 2 Gb SFP Open Slots PoE+ (Release Q2-2016)

Combining Full Enterprise Management with AVB for ultimate Flexibility

No ‘additional licenses’ or firmware needed for AVB

Use Dante and AVB simultaneously

Non-blocking architecture

Remote notifying options: ‘hands free management’

NUPS22-3000U : 3KVA True Sine-wave Double Conversion On-Line

UPS

3000 VA / 2700 W capacity

True double-conversion

Output power factor 0.9

Rack/Tower design

Output voltage regulation < 1%

Higher output crest radio 5:1

Programmable power management outlets

Emergency power off function (EPO) with

NUPS22-SNMP

NUPS22-ENVC : Environmental Monitoring Device for NUPS22-series

Plug & use for simple installation with

SNMP manager

Monitor temperature and humidity to protect equipment

Allow 2 contact closure signals for userdefine usage

Management software to remote monitor

Measure temperatures between 0 to 100°

Measure relative humidity between 10 to

90% RH

NGSME8AVB : Layer 2 Gb Full Mang. AVB Ethernet Switch: 16 -port Gb

+ 2 Gb SFP Open Slots PoE+ (Release Q2-2016)

Combining Full Enterprise Management with AVB for ultimate Flexibility

No ‘additional licenses’ or firmware needed for AVB

Use Dante and AVB simultaneously

Non-blocking architecture

Remote notifying options: ‘hands free management’

NGSE8H-AV : 8-port Gb high power PoE+ Rear Facing Switch

Per PoE+ port of up to 30watt (max 120

Watt)

IEEE 802.3at compliant with 2-event classification

IEEE 802.3af backward compatible

Supply suitable power to PoE+ PD terminals

Safe and reliable power to WLAN APs

Automatic Detection and Protection of Non

-standard Ethernet Terminals

Supports 10/100/1000Base-T applications

NGSME24T2H-AV : 24-port Full L2 Manag. plus 2SFP open slot, Gb

PoE+ Switch Rear Facing

Gigabit Ethernet switch SFP and PoE+

Supports Dante

Dual PoE+ power board for ultimate stability and redundancy

24+2 ports, desktop or rack mount

Jumbo frame 9.6K support

Autosenses cable type, no crossover cables needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGSME16T2H-AV : 16-Rear Port 10/100/1000 Base -T + 2 Gb SFP L2+

Management PoE+ Switch

Supports Layer 2+ full management software features

Provides PoE Controls, Network Control,

Management, Monitor and Security features’ requests

IEEE 802.3at PoE ports

Features 9 physical queues

Able to convert standard 100~240V/AC power into low-voltage DC

NGS24TP-AV : 24-port Gb Ethernet Switch Rear Facing

24-port 10/100/1000Base-T RJ-45 UTP or

STP

Rear facing switch

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

NGSM24T2-AV : 24-port Managed Gb Ethernet Switch Rear Facing

24-port 10/100/1000Base-T RJ-45 UTP or

STP

Supports Dante

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

19” Rack Mount brackets included

800.530.8998 | www.LibAV.com | SPECIFICATIONS & IMAGES SUBJECT TO CHANGE | IMAGES NOT TO SCALE | L0230

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

51

NIVEO

NIVEO PRODUCT OFFERING AT-A-GLANCE

NGSME8H : 8-port Gb Switch with Full L2 Management, 2 SFP open slot, and PoE+ Switch (130W)

Gigabit Ethernet switch with SFP and PoE+

Supports Dante

8+2 ports, desktop or rack mount

Jumbo frame 9.6K support

Layer 2+ full software management

30 watts per port Power over Ethernet

Autosenses cable type, no crossover needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGS16TP : 16 Port Gb Ethernet Switch

16-port 10/100/1000Base-T RJ-45

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

NGSE8H : 8-port 10/1000M PoE+ Gb Ethernet Switch

Gigabit Ethernet switch with PoE+

8 ports, desktop or rack mount

Jumbo frame 9.6K support

30 watts per port Power over Ethernet

Autosenses cable type, no crossover needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGS18T16 : 16 Port Gb Fiber/Ethernet Combo Switch plus 2SFP open slot

16-port Gb Combo UTP/SFP ports + 2port

Gb SFP open slots

2 UTP or SFP ports for LAN-Fiber Media

Conversion and extension

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

NGS24TP : 24 Port Gb Ethernet Switch

24-port 10/100/1000Base-T RJ-45

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

Compact 13” Metal Case

Internal Power Supply

NGSME24G4S : 24-port Full L2 Management plus 2 10G SFP

24 Port Gb + 2 10G SFP + Ports, with PoE+

Supports Dante

Auto-MDI/MDI-X Auto Negotiation

IEEE 802.3az Energy Efficient Ethernet

(EEE)

Non-Blocking Switching Capability

Ethernet Port on the Rear Design

Supports 9K Jumbo Frames

Compact 13” Metal Case

Internal Power Supply

NGSM48T2 : 48-Port Gigabit Ethernet Switch with Full Layer 2 Management and 2-Port 10Gb SFP+ port

48-Port Gigabit Copper + 2-port 10Gb

SFP+ port Combo TP/SFP

Supports Dante

802.3az Energy Efficient Ethernet

100G Non-Blocking Switching Capability

Layer 2+ Full Managed Software Features

4K VLAN, 8 queues QoS, Advanced VLANs

MSTP, LACP, LLDP, sFlow

NGSM24T2 : 24-port Full L2 Management, plus 2 SFP open slot, Gb

Ethernet Switch

Gigabit Ethernet switch SFP expansion

Supports Dante

24+2 ports, desktop or rack mount

Jumbo frame 9.6K support

Layer 2+ full software management

Autosenses cable type, no crossover needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGS24U : 24-Port, Websmart Gb Ethernet Switch

Gigabit Ethernet switch

24 ports, desktop or rack mount

Jumbo frame 9.6K support

Autosenses cable type, no crossover needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGSME48T2H : 48-Port Gb Switch with 2-Port 10Gb SFP+ port Layer 2 and PoE+ Switch

48-Port PoE+ Gb Copper + 2-port 10Gb

SFP+ port

Supports Dante

Dual PoE+ power board for ultimate

 stability and redundancy

802.3az Energy Efficient Ethernet

100G Non-Blocking Switching Capability

Layer 2+ Full Managed Software Features

4K VLAN, 8 queues QoS, Advanced VLANs

MSTP, LACP, LLDP, sFlow,

802.1X, RADIUS, TACAS+, ACL

NGSME16T2H : 16-port Gb Switch with Full L2 Management, plus 2 SFP open slot, and PoE+ Switch (200W)

Gigabit Ethernet switch SFP and PoE+

Supports Dante

16+2 ports, desktop or rack mount

Jumbo frame 9.6K support

Layer 2+ full software management

Autosenses cable type, no crossover cables needed

Auto negotiation on each port

Non-blocking wire speed 2000Mbps/port

NGSM24G4S : 24-port Full L2 Manage. plus 2 10G SFP

24Port Gigabit Copper + 2port 10G SFP+

Supports Dante

2port 10G SFP+ for Stacking

1G SFP/10G SFP+ Available

Stack up to 16 switches into one single switch

802.3az Energy Efficient Ethernet

88G Non-Blocking Switching Capability

Layer 2+ Full Managed Software

NGSME24T2H : 24-port Full L2 Management, plus 2 SFP open slot,

PoE+ Switch (400W)

Gigabit Ethernet switch SFP and PoE+

Supports Dante

Dual PoE+ power board for ultimate stability and redundancy

24+2 ports, desktop or rack mount

Jumbo frame 9.6K support

Layer 2+ full software management

Autosenses cable type, no crossover

 needed

Auto negotiation on each port

52

800.530.8998 | www.LibAV.com | SPECIFICATIONS & IMAGES SUBJECT TO CHANGE | IMAGES NOT TO SCALE | L0230

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

NIVEO

Model

N-IPSW1104

N-IPSWG5

N-IPSW1108

NGSE8H

NGSME8H

NGS16TP

NGSME16T2H

NGS18T16

NGS24TP

NGSM24T2

NGSME24T2H

NGSM24G4S

NGSME24G4S

NGSM48T2

NGSME48T2H

NGSE8H-AV

NGSME16T2H-

AV

NGSM16AVB

NGSME16AVB

NGSME8AVB

NGSM24T2-AV

NGSME24T2H-

AV

NIVEO PRODUCT OFFERING AT-A-GLANCE


Front and Rear Port Facing Switches Matrix

Number of

Gb Ports

Management

PoE+

Budget

1Gb SFP-

Ports

10Gb SFP-

Ports

1Gb SFP - Ports

Stackable

Port Facing

4 FE-ports

5

8 FE-ports

8

-

-

-

-

65W

65W

130W

130W

-

-

-

-

-

-

-

-

-

-

-

-

Front

Front

Front

Front

Full Layer L2+

16

24

24

24

24

8

16

16

24

48

48

8

16

16

16

16

24

24

-

Full Layer L2+

Web Smart

Management

-

Full Layer L2+

Full Layer L2+

Full Layer L2+/

Stackable

Full Layer L2+/

Stackable

Full Layer L2+

Full Layer L2+

- 130W

Full Layer L2+

AVB & Full Layer L2+

250W

-

AVB & Full Layer L2+

AVB & Full Layer L2+

-

-

Full Layer L2+ -

Full Layer L2+ 430W

130W

-

250W

-

-

-

430W

-

430W

-

430W

18

-

2

2

-

2

-

2

-

-

-

-

-

-

-

2

-

-

-

-

2

2

2

2

2

2

2

2

2

-

-

-

-

-

-

-

800.530.8998 | www.LibAV.com | SPECIFICATIONS & IMAGES SUBJECT TO CHANGE | IMAGES NOT TO SCALE | L0230

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

-

-

-

-

2

-

-

-

2

-

-

-

-

-

-

-

-

-

Front

Front

Front

Front

Front

Front

Front

Front

Front

Front

Front

Rear

Rear

Rear

Rear

Rear

Rear

Rear

53

SP CONTROLS

SP CONTROLS PRODUCT OFFERING AT-A-GLANCE

PXE-DCM+ : PixiePlus - Single-Gang IR/RS2323 control system for AV systems

8-button Display Control Module

Single-gang decora form factor

Learns IR codes from almost any remote

Unique modular design allows for control

 of Power, Source, Volume and more

Elegant backlit LEDs in a variety of colors

A single button may be programmed with multiple remote codes

Learns IR codes from almost any remote using a paper clip

Decora faceplate available in: white, ivory, grey, and black

PXE-MOTVOL-CTL-A; PXE-MOTVOL-CTL-L : PixiePlus Motorized Volume Control - Audio and Linear

Passive 10K ohm stereo motorized potentiometer (Audio Taper)

Powered from the PXE-DCM+

Directly attenuates unbalanced stereo line level signals

For controlling Audio Amplifiers without

IR/RS232 control

Can be placed in an audio chain between a mixer/switcher/preamp and an amplifier

Linear version allows the PixiePLus to

PXE-DCM+Amber; PXE-DCM+Green : PixiePlus 8 Button Control

Module - Amber and Green

PixiePlus Device Control Module 8-Buttons

Simple, standardized control interface for

AV devices

White Background with Amber or Green backlit buttons

Wall mounted Single Gang Decora style faceplate

PXE-BIK50 : PixiePlus Basic Install Kit

50 ft 22 AWG 3 conductor plenum prestripped cable

1 single gang Decora Plate, 1 surface mount box

1 single gang mounting bracket

Quick install kit for labor saving and efficiency

PXE-PGM-TOOL : PixiePlus Programming Wand

Connects via IR interface and allows for

RS232 control

Eliminates the need to remove the con-

 troller from the wall to program

Connects to a PC via USB and contains an

Ability to clone commands to other

PixiePlus controllers

PixiePlus Accessories : Accessories for the Pixie Plus Control Module

PXE-EMIT-232/IR: RS232 and IR Emitter

PXE-EMIT-REL2: 2-Relay Output Emitter

PXE-DCM-RTC: Real Time Clock Module

PXE-DCM-CAT5-ADAPTOR: Phoenix-to-

CAT5 Adaptor

PXE-DCM-EMIT-CAT5-232/IR: RS232 and

IR Emitter with CAT5 Jack

Alternate 2 and 4 source buttons available

PXE-PL-BL : PixiePlus Tabletop Enclosure Black

Tabletop standalone enclosure

For PXE-DCM+ Panel Single Gang

Stylish Black Acrylic in a pleasing format

Angles for presentation and ease of access

PXE-RACK : PixiePlus 3RU Rack Mount

Rack Mount Kit to mount the PXE-

DCM+

Black Finish

3RU height

PX2-MP

-IR : Pixie Pro Control Module

Robust IR learning with 16 macros or round-robin commands per button

Security enable/disable feature allows the entrance code to prevent unauthorized use

Configurable inactivity shutdown timer

Up to 8 input sources

All blanks and labeling legend included

Easy to configure, customize, and use

PX2-PUC-IR-4 : NRC Control Puck (4 IR)

Four IR out

Ability to expand the (NRC) Networked

15 control pucks using CAT5 cabling.

Small form factor, allowing for remote installation anywhere

PX2-NRC-1142 : PixiePro (NRC) Networked Room Controller (1 RS232,

4 Relay, 2 Input)

One bidirectional RS-232 control port, one infrared (IR) control port, four low-voltage relays for screens or lifts, and two general purpose sense ports for security and theft detection

Includes adapters for common pinouts of

Configured through an AJAX-powered web interface

Expandable for virtually any room configuration and any budget

PX2-PUC-REL-4 : NRC Control Puck (4 Relay)

Four low-voltage relays

Ability to expand the (NRC) Networked

Room Controller by daisy chaining up to

15 control pucks using CAT5 cabling.

Small form factor, allowing for remote installation anywhere

PX2-PUC-232/IR : NRC Control Puck (1 RS232 and 1 IR)

One RS-232 port and one IR port

Ability to expand the (NRC) Networked

Small form factor, allowing for remote installation anywhere

PX2-PUC-MOTVOL-CTL-A and PX2-PUC-MOTVOL-CTL-L : Motorized

Volume Control Puck - Audio and Linear for us with NRC

10K Ohm stereo motorized potentiometer

(Audio Taper)

Powered from the PX2-NRC-1142

Directly attenuates unbalanced stereo line level signals

For controlling Audio Amplifiers without

IR/RS232 control

PixiePro Family Accessories : PixiePro IR Emitter / IR Emitter Hood /

Splitter

PXE-EMIT: 6 Volt IR Emitter for the

18 through 22 2C shielded cable. Connects to the PCE-DCM+. This is for use

PXE-EMIT-HOOD: Used with PXE-EMIT covering hood to cover and secure IR emitter

PX2-SPBUS-2WAY: PixiePro NRC BUS

Splitter 2-Way. Increases the amount of controlled equipment

PX2-PL-WH : PixiePro Tabeltop Enclosure White

Tabletop standalone enclosure

For PX2-MP-IR Panel Four Gang size

Stylish White Acrylic in a pleasing format

Angled for presentation and ease of access

PX2-RACK and PX2-RACK-MOD : Rack Mount Kits

PX2-RACK: Rack Mount Kit for the PixiePro

Line. 3 Rack Unit height. Black.

PX2-RACK-MOD: Rack Mount Kit for the

54

SP Controls core control (PixiePlus System and PixiePro Family) and audio products (AmpLinc Hub and Amp/Puck) are made in the USA.

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

SP CONTROLS

SP CONTROLS PRODUCT OFFERING AT-A-GLANCE

SP2-SMCHAS : Mini SmartPanel Control System

Small Profile Chassis for ease of mounting and location

Simple intuitive Projector/Display Control

No Programming needed, simply configure

Control Audio/Video, contact closure for screens and lifts

Available in: Black, White, Blue, Gold,

Red, Grey (added charge)

SP2-AFVP-EXT : AFVP Extender

Twisted Pair Extender Audio over Category Cable

Extend connection between SmartPanel and SP3-AFVP+

Extend up to 50 feet with standard

Category Cable

SP3-TCM+ : Transport Control Module (for DVD Players, VCRs, etc.)

TCM for extending the SmartPanel Control

System

Standard and extended control features for sources

Can learn IR codes direct or clone from another

TCM

Control up to 5 devices

SP2-CSB; SP2-BSB : SmartPanel Button Sets

SP2-CSB: Replacement SmartPanel Buttons; Full

Replacement set of selection buttons

SP2-BSB: Replacement SmartPanel Buttons; set of 4

SP3-TCM+1GANG-BL : Standalone Transport Control Module (Black)

TCM for extending the SmartPanel Control

System

Standard and extended control features for sources

Can learn IR codes direct or clone from another TCM

Also available in Grey

SP2-SMWE-B; SP3-SMPL-B; SP3-TCM+STD-BL : SmartPanel Enclosures

SP2-SMCHAS Wood Enclosure

SP2-SMCHAS Poly Enclosure

SP3-TCM+STD-BL: Transport Control

Module Tabletop Enclosure

For desktop or tabletop mounting

SP2-RACKSM; SP2-RACKSM-MOD : Rack Mount Kits

SP2-SMCHAS: Rack Mount Kit

SP2-SMCHAS: 2 Ru Rack Mount

Standard 19” Rack size

SmartPanel Accessories : Accessories for SmartPanel

SP2-ETH-M100: Lucent M100 Series CAT5 Jack

SP2-SMMR: Mud Ring For SP2-SMCHAS

SP2-SMAP-BL: SmartPanel Mini 5G Adapter

Plate

AmpLinc Hub : 65W Speaker Distribution Hub for AmpLinc Amp 10

Audio Distribution hub over Category

Cable

60 watts from 2 to 60 amplifier pucks

Small and scalable

3.5TRS or 2 RCA input and 4 RJ45 output

AmpLinc Hub-90W : 90W Speaker Distribution Hub for AmpLinc Amp

10

Audio Distribution hub over Category

Cable

90 watts permits 8 10W AmpLINC PUCS

Small and scalable

3.5TRS or 2 RCA input and 4 RJ45 output

AmpLinc Amp10 : AmpLinc Amp10 Remote Speaker Control Puck

Remote Amplifier device for 4/8

Ohm speakers

Control and Power with Category

Cable

Tap power from 0.3~10 watts

1 to 60 units can be daisy chained

For use with the AmpLinc Hub and

AmpLinc Hub-90W

SP3-AFVP+ : Audio Follow Video Preamplifier Plus

Audio Follow Video preamp addition for

SmartPanel or NRC

5 Video CH with 5 L/R unbalanced Audio

Channels

Fully adjustable gain (10dB), bass, and treble

Superior audio over built in projector speakers

Compatible with other OEM RS-232 control systems

SLB-SBOX II : SmartBox II Secure Equipment Enclosure

Secure and vented, locking storage box for

AV & IT equipment

Removable tray where equipment is mounted that slides into the main frame of the box

Removable lid with key lock and now screws

Flexible mounting options for wall, ceiling, or projector pole mount

Two cable exit holes for standard voltage

Optional cable cover and adjustable pole mount

SLB-1050B : Slide-Out Drawer for SP2-SMCHAS

SmartDrawer for SP2-SMCHAS mounting

Under Desk or under Table mounting of

AV Controls

Black finish, low profile

Can accommodate the SP3-AFVP+ Preamp

Includes ports for four Mini Modules

SP-BS5IN-W : 5.25” 2-way Bookshelf Speaker Pair

5.25” 2-way speaker system

90 dB @ 1w/m frequency response

200 Hz - 20 KHz frequency range

8 ohms impedance

250 watts max power handling

SLB-Box+ : SmartBox+ Flip-Down Equipment/Control Enclosure

Wall mounted SmartBox enclosure with flip down tray black

Equipment space for Blu-Ray/DVD player

Flat surface for laptop or other portable media source

SP2-SMCHAS mounting feature for control integration

Amplifier mounting and patching module features built in

Available white, black or custom color

SLB-SBOX 100W-WH; SLB-SBOX 70V-WH; SLB-SBOX 50W-WH : Smart-

Box+ Speaker Amplifiers

Designed to fit into the SLB-BOX+ enclosures

Easy match to the SP3-AFVP+ audio follow video preamp

120V convenience AC Outlet for Laptop power included

SLB-SBOX 100W-WH: 100 Watt Stereo

SLB-SBOX 70V-WH: 100 Watt 70V Mono

Audio Amp; 100 Watt 70 Volt Single Mono

Channel

SLB-SBOX 50W-WH: 50W SmartBox Amp

Available in black

SP-ICE5 : 4” Aimable Enclosed Ceiling Speaker (Single)

4” Co-Axial Speaker

160hms nominal impedance

100 Hz - 20 KHz frequency range

90dB @ 1w/1m sensitivity

25 watts max power handling

Mini Modules : Patch Modules for the SLB-SBOX+

AUXILLIARY Audio Enable Switch

Blank

Escutcheon and Dual Panduit

HDMI

RS232

S-Video Pass-thru

VGA and VGA out

Video on BNC and on RCA

Keylock

SmartBox Accessories : Accessories for SmartBox+

SLB-SBOX 1GANG - Pixie Face Cover

SLB-SBOX FACE - Blank Face Cover

SLB-SBOX MINIFACE - Modular Face

Cover

SLB-SBOX 1GANG-WH - PixiePlus

Face Cover. Also available in black.

SLB-SBOX PX2 - PixiePro Face Cover

SLB-SBOX PX2-BL-RM: Reverse mount for added security. (Black only.)

SP Controls core control (PixiePlus System and PixiePro Family) and audio products (AmpLinc Hub and Amp/Puck) are made in the USA.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

55

ACCESSORIES

FLEXBOX-WH

FLEXIBLE A/V SOLUTIONS ENCLOSURE SYSTEM

Patent pending removable tray for easy assembly and maintenance

UL 2043 compliant for Plenum installations.

FLEXBOX Benefits:

• The ability to custom brand this enclosure solution

• Ability to exchange parts or customize our solution to meet your customers specific needs, giving you an advantage over off the shelf solutions

• Allows to write custom specifications for these solutions

• Our solutions give you the flexibility of providing systems with a teacher/ microphone option or without

• All systems can be implemented into LIS

(Liberty Inventory Services). We can have safety stock in LIS for field swappable systems as a backup

• If you have deployments in other cities, we will be able to leverage

WESCO facilities for warehousing accommodations if needed

FLEXBOX Features:

The equipment enclosure has a sliding slotted shelf that requires no hardware or screws to secure it. The box can be populated with a number of devices on the slotted shelf with room for miscellaneous cables and power supplies conveniently tucked away. Equipment can be mounted using cable ties, Velcro or via self-tapping screws into the sliding shelf. Since the shelf is secure when in place, the enclosure can be mounted upside down allowing for easy service access to equipment once installed.

• Lightweight construction

• Vented design construction uses natural convection for cooling

• Install flexibility: above ceiling without relying on T-Bar placement; below the ceiling; pole mounted; or wall mounted

• Custom kitting to include enclosure with pre-installed equipment specifically designed with custom part number to create unique specification and protect your intellectual property

• Systems can be pre-assembled for large deployments

• Systems can be pre-configured for plug and play installations

• Secure key lock removable lid provides easy access to internal equipment

PRE-LOADED FLEXBOX OPTION PACKAGE

DESCRIPTION/LOCATION

Control processor with Doceri™ software support

Wall-mount control panel

Internal wiring

Mounting hardware

Local source wall plate

HDBaseT receiver

Digital switcher

Audio amplifier

Internal wiring

Ceiling speakers

MANUFACTURER

SP Controls

SP Controls

SP Controls

SP Controls

Broadata

Broadata

Digitalinx

Intelix

Liberty

Atlas

PART NUMBER

PX2-NRC-1142

PX2-MP-IR

PX2-PUC-232/IR

SLB-SBOX2

LBC-H/V-T-WP

LBC-HDBT-R-LITE

DL-S41

AUD-220

E-3.5SM-M-3

FAP42T

56

1

1

1

1

1

1

1

1

2

1

QUANTITY

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

ACCESSORIES

BYOD-PUCK

BYOD CONNECTION HUB - 6 INPUT TO HDMI AUTO-SWITCHER AND CONVERTER

The Digitalinx

BYOD-PUCK

is a multiformat video converter to connect mobile devices with the following outputs: HDMI, mini DisplayPort, micro USB, Lightning, and USB type C.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

Input Cables

HDMI Output

One (1) HDMI Type A Plug, One (1) Micro USB

Type B Plug, Two (2) USB Type C Plugs (MHL and

Mac), One (1) Mini DisplayPort Plug,

One (1) Lightning Plug

One (1) HDMI Type A Receptacle

Security

One (1) Kensington Lock Slot

Power

One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel

SUPPORTED AUDIO, VIDEO AND CONTROL

Input Video Resolutions

HDMI: Up to UHD/30

Micro USB: Up to 1080p/30 Lightning:

Up to 1080p/60

USB Type C (MHL): Up to 1080p/60 USB

Type C (Mac): Up to UHD/30 Mini Display

Port: Up to UHD/30

Output Video Resolutions

SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i,

1080p, UHD/30 VESA: Resolutions up to

1920x1200. Color Depth: 24, 30, 36, 48bit

Video Compliance

Embedded Audio

HDMI 1.4 and HDCP 1.4

Up to PCM 8 channel, Dolby Digital TrueHD, and

DTS-HD Master Audio

CHASSIS AND ENVIRONMENTAL

Construction

Black ABS

Dimensions (H x W x D)

Input Cable Length

25 mm x 100 mm x 100 mm (0.98 in x 3.94 in x

3.94 in)

300 mm (11.81 in)

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0° to +40° C (+32° to +104° F)

20% to 90%, Non-condensing

-10° to +60° C (+14° to +140° F)

20% to 90%, Non-condensing

POWER AND REGULATORY

Power Input

Power Output

Power Consumption

ESD Protection

Regulatory

12V DC 2A

5V DC 2.1A (Lightning, micro USB, and USB Type

C)

18 watts when powering mobile device

15kV air, 8kV contact

FCC, CE, RoHS

OTHER

Warranty

Diagnostic Indicators

2 years

Power

Included Accessories:

Installation Guide, Power Supply,

DON'T BE

A LOSER!

CREATE YOUR OWN CUSTOMIZED

UNIVERSAL HDMI

ADAPTER RING

®

Patent Pending

Provided by

dl-ar

Unbreakable stainless steel security ring

ARDPHD

Display Port male to HDMI female in-line adapter

ARMCHD

Micro-HDMI D male to HDMI female in-line adapter

ARMDHD

Mini-HDMI C male to HDMI female in-line adapter

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

ARMDPHD

Mini-Display

Port male to

HDMI female in-line adapter

DL-CL

BLACK clamp assembly

& foam inserts to securely fit any sized

HDMI cable

ARDVHD

DVI-D single link male to

HDMI A female

57

ACCESSORIES

TRB-2V1AD / TSPB-2V1AD / TDPB-2V1AD

ROUND TABLE BOX AV+N W/LID BLK

TECH SPECS

PORTS

1 HDMI connector, 1 15-pin HD connector, 1 3.5mm mini jack, 1 RJ-45 connector

OPERATING TEMPERATURE 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

HUMIDITY

POWER SOURCE

FUSE RATING

DIMENSIONS

WEIGHT

INCLUDED ACCESSORIES

-40° to +70°C (-49° to 158°F)

10% to 90%, RHL non-condensing

AC power limits: 115V AC, 50/60Hz, 5A Max

T 6.3A 250V

10.5cm x 16cm (4.1" x 6.3") Diameter, H

0.85kg (1.9lbs) approx.

1.2kg (2.6lbs) approx. with mounting brackets

Six self-locking ties

TRB-2V1AD

TSPB-2V1AD

TECH SPECS

PORTS

POWER SOURCE

1 HDMI connector, 1 Ethernet RJ-45 connector, 1 15-pin

HD connector, 1 3.5mm mini jack

100-240V AC, 50/60Hz, 5A Maximum 5A per power outlet

FUSE RATING

T 6.3A 250V

OPERATING

TEMPERATURE RANGE

OPERATING

HUMIDITY RANGE

+5 to +45 Deg. Centigrade

10 to 90% RHL, non-condensing

STORAGE

TEMPERATURE RANGE

-20 to +70Deg. C.

STORAGE HUMIDITY RANGE 5 to 95% RHL, non-condensing

DIMENSIONS

WEIGHT

ACCESSORIES

OPTIONS

Including the outer rim: 14.5cm x 13.2cm x 17.3cm (5.71" x 5.2" x 6.81") W, D, H , Without the outer rim: 13.3cm x

12.0cm x 17.3cm (5.24" x 4.72" x 6.81") W, D, H

0.85kg (1.87lbs) approx. , 1.2kg (2.65lbs) approx. with mounting brackets 1.4 kg (3.1lbs) approx. packed product

Cut out metal template

Power socket kits, power cord

58

TDPB-2V1AD

TECH SPECS

PORTS

POWER SOURCE

FUSE RATING

2 HDMI connector, 2 Ethernet RJ-45 connector,

2 15-pin HD connector, 2 3.5mm mini jack

AC power limits: 100-125V AC, 50/60Hz,

5A Maximum 5A per power outlet

T 6.3A 250V

OPERATING TEMPERATURE 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

-40° to +70°C (-40° to 158°F)

HUMIDITY

DIMENSIONS

WEIGHT

ACCESSORIES

OPTIONS

10% to 90%, RHL non-condensing

Including the outer rim: 28.5cm x 14.0cm x 16.5cm

(11.2" x 5.5" x 6.5") W, D, H . Without the outer rim:

26.5cm x 12.0cm x 16.0 cm (10.4" x 4.7" x 6.3") W, D, H

1.64kg (3.6lbs) approx., 1.88kg (4.1lbs) approx. with mounting clamps, 2.26kg (5lbs) approx. packed product

Cut out metal template

Power socket kits, power cord

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: HDMI MOLDED

HDPMM** HDMI PREMIUM 18.0G

HDMI PREMIUM® CERTIFIED CABLE ASSEMBLY key features

HDMI Premium® full 18G Certified

Full ATC Certification

High retention HDMI plugs

UL/CSA listed for in-wall use

Convenient cable lengths

Liberty’s

HDPMM

Series are our full ATC certified HDMI Premium® rated cables. The newest HDMI cable specification is for 18G applications. [email protected] with full Chroma sampling 4:4:4 and the newest High Dynamic Range (HDR) requirements. This line of

HDMI® cables supports every single HDMI requirements for cables and signal transport. These are completely traceable per the new HDMI requirements for the Premium certification.

The HDPMM series is robustly constructed with tinned annealed copper conductors on the shielded TMDS pairs. The overall cable is dual shielded with a full coverage foil shield and an 85% coverage braided shield. Unlike many cables on the market, the connectors feature full shielding over the solder joints instead of drain wire under a pre-mold. These cables are fully shielded from connector shroud to connector shroud. All contact surfaces are gold plated for conductivity, durability, and resistance to tarnish.

The high retention connectors increase the standard HDMI holding force up to 10 lbs. The jacketing is non-glossy extra flexible

PVC for more flexibility in bending and routing in Residential and light commercial applications.

Lengths from 15 to 24 feet long are passive cables. There are No equalization chipsets and directional requirements on

These lengths. These HDMI Premium® cables feature UL ratings on the bulk cable for CMG and Canadian CMG FT4, this is permissible for concealed installations per the requirements of the National Electric Code®. The product is Compliant to the requirements of the EU RoHS-2 2011/65/EU standard.

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

Male HDMI Type A connector

HDMI SUPPORTED VIDEO, AUDIO AND ETHERNET

HDMI Maximum Video

Compatibility

[email protected] 4:4:4 up to 3m, HDR Support

Video Compliance

Embedded Audio

Minimum Bandwidth

HDMI, HDCP, and CEC (Consumer Electronics

Control)

Up to 32 Audio Channels and up to 1536 KHz

Audio Sampling

18.0 Gbps

Ethernet

100 Mbps

CABLE CONSTRUCTION

HDMI Connector Features

HDMI Molded Hood Construction

HDMI “A” Male with up to 10 lbs high retention feature, gold plated

Copper Foil Shielded Pre-mold with PVC over mold. Over mold is two phase black with a gray nose

HDMI Molded Hood Dimensions

Jacket Material

Maximum Tensile Load

Available Cable Lengths

20.0x41x11.2mm

Flexible Flame rated PVC with a matte black finish

44Lbs | 20Kg

15, 20, and 24 feet

ENVIRONMENTAL REQUIREMENTS

Operating Temperature

0° to +75° C (+32° to +167° F)

Operating Humidity

20% to 85%, Non-condensing

Storage Temperature

-20° to +80° C (0° to +176° F)

POWER AND REGULATORY

Regulatory

HDMI®

NEC CMG, CEC CMG FT4, EU RoHS-2 2011/65/

EU Compliant

HDMI Premium® Certified

Check the website for specific product physical specifications

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

59

CABLES: HDMI MOLDED

HDMI SOLUTIONS

• WIDE SELECTION

• UL, CSA & ROHS

• HIGH QUALITY PRODUCT

• COMPETITIVE PRICING

• ECONOMY & PREMIUM LEVELS

• HIGH SPEED HDMI®

• COPPER & FIBER VERSIONS

• PLENUM, NON-PLENUM & AWM RATED

D2-HDSEM-M SERIES

LIBERTY D2 HIGH SPEED HDMI WITH ETHERNET

28 & 26 AWG TMDS pairs

Low profile molded head

High retention plugs up to 12 lbs

CL2 & CMG FT4 rated, RoHS compliant

5m & up feature RedMere® Chipsets

E2-HDSEM-M SERIES

LIBERTY E2 HIGH SPEED HDMI WITH ETHERNET

28 & 26 AWG TMDS pairs

Low profile molded head

High retention plugs up to 12 lbs

CL2 & CMG FT4 rated, RoHS compliant

5m & up feature RedMere® Chipsets

M2-HDSEM-M SERIES

LIBERTY M2 HIGH SPEED HDMI WITH ETHERNET

30 AWG copper TMDS pairs

Super low profile molded heads

High retention plugs up to 12 lbs

AWM rated, RoHS compliant

HOME THEATER GRADE

5m & longer are directional

10.2 Gbps, 4k video, all HDMI® audio formats

Supports CEC, audio return & Ethernet

Lengths from 1 to 10m

Black with black molded heads & blue highlights

COMMERCIAL GRADE

5m & longer are directional

10.2 Gbps, 4k video, all HDMI® audio formats

Supports CEC, audio return & Ethernet

Lengths from ½ to 20m

Black with blue molded heads

BEST

BETTER

PERFECT FOR PATCHING CABLES IN RACKS

Up to 8ft, 10.2 Gbps, up to 15ft 5.0 Gbps

Supports CEC, audio return & Ethernet

Available in 1,2,3,4,5,6,8,10,12 & 15ft

Ultra flexible black with black molded heads

BETTER

E-MHDM-M SERIES

LIBERTY HIGH SPEED MICRO HEAD HDMI WITH ETHERNET

HDMI® “A” male to “A” male connectivity

Ultra small flexible diameter cable 3.6mm in diameter

Flexible polyvinyl chloride jacket

AWM rated, RoHS compliant

MAXIMUM FLEXIBILITY PERFORMANCE

ATC certified HDMI® high speed with Ethernet

10.2 Gbps / 4k × 2k / 3D / CEC

Lengths 2m & longer are directional

4m length does not support Ethernet

GOOD

Z100HDE SERIES

LIBERTY HIGH SPEED HDMI WITH ETHERNET

28 AWG copper TMDS pairs

Economy public mold design

AWM rated, RoHS compliant

10.2 Gbps, 4k video, all HDMI® audio formats

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

Supports CEC, audio return & Ethernet

Available in 3, 6, 10, 15 & 25ft lengths

Quantity discounts

Black

VALUE

Z100HD SERIES

MARATHON HIGH SPEED HDMI

28 AWG copper TMDS pairs

Economy public mold design

AWM rated, RoHS compliant

10.2 Gbps, 4K video, all HDMI® audio formats

P-HDM-M SERIES

LIBERTY PLENUM HDMI WITH ETHERNET

24 AWG copper TMDS pairs

Super low profile molded heads

CMP FT6 rated, RoHS compliant

8m high speed HDMI® with Ethernet

10 & 12m passive standard HDMI®

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

Supports CEC, audio return

Available in 6, 10 & 12 foot lengths

Quantity discounts

Black

VALUE

PLENUM RATED COMMERCIAL GRADE

15m & longer feature RedMere® Chipsets

15m & longer are directional

Supports 1080P, audio return (8-12m CEC)

Available in 8,10,12, 15 & 23m

Black with black molded heads

GOOD

60

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: HDMI MOLDED

HDMI SOLUTIONS

DL-HFC SERIES

DIGITALINX PLENUM RATED OPTIC HDMI WITH DETACHABLE HEADS

Plenum rated cable for all installations

Ultra-small diameter cable

Detachable HDMI TX & RX units from main body

No external power needed, uses equipment power

HYBRID COPPER/FIBER

NEC CMP-OF, CEC FT6, HDCP 2.2, RoHS compliant

Lengths: 25, 35, 50 & 75ft

HDMI High Speed, 10.2Gpbs, [email protected] 4:2:0

3D, all audio

BEST

DL-AOCHP

SERIES LIBERTY PLENUM HYBRID FIBER HDMI

Polymer 4-fiber combined with copper wires

Super small flat profile cable

Extremely low bend radius

NEC CMP, CEC CMP FT6, RoHS compliant

HD-1000 SERIES

PPC® LOCKING HIGH SPEED HDMI WITH ETHERNET

28 AWG copper TMDS pairs

True Locking HDMI® feature up to 25lbs+

CL2, CMG FT4, RoHS compliant

10.2 Gbps, 4K video, all HDMI® audio formats

HD-700 SERIES

PPC® LOCKING HIGH SPEED HDMI WITH AUDIO RETURN

28 AWG copper TMDS pairs

True Locking HDMI® feature up to 25lbs+

CL2, CMG FT4, RoHS compliant

10.2 Gbps, 4K video, all HDMI® audio formats

HD-600 SERIES

PPC® HIGH RETENTION HIGH SPEED HDMI WITH ETHERNET

28 AWG copper TMDS pairs

High Retention plugs up to 12lbs

CL2, CMG FT4, RoHS compliant

10.2 Gbps, 4K video, all HDMI® audio formats

DFO-1000P

CELERITY PLENUM RATED FIBER OPTIC HDMI LONG DISTANCE CABLE

Fiber Optic Ribbon Cables

Detachable HDMI® TX and RX modules

Handles up to 60lbs of pull force

OFNP FT6 rated, RoHS Compliant

Miniature molded micro USB format (not USB)

Detachable HDMI connector makes pre-wiring of the fiber optic cable as easy as plug & play

HYBRID FIBER/COPPER HIGH SPEED

Directional Cables

6.75 Gbps, 1080P video, all HDMI® audio

Lengths from 10 to 60m

Gray jacket with black ABS heads

MAXIMUM LOCKING PERFORMANCE PACKAGE

Supports CEC, audio return & Ethernet

Available in 2,4,8,16,25,35 & 50ft lengths

16ft & up are active and directional

Gray with gloss nickel metal hoods

LOCKING PERFORMANCE PACKAGE

Supports CEC, audio return & Ethernet

Available in 2,4,8,16,25,35 & 50ft lengths

16ft & up are active & directional

Black with gun metal metallic hoods

BEST

BEST

BETTER

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

Supports CEC, audio return & Ethernet

Available in 3, 6 & 12ft lengths

Thumb latch and release feature

Black with black ABS hoods

GOOD

PLENUM RATED FIBER FEATURING DETACHABLE HEADS

21.0 Gbps, [email protected] ready, all HDMI® audio

Supports CEC, audio return

Lengths from 35 to 1000ft

Requires powered receptacles on both sides

Black cable and black ABS ends & modules

Detachable Fiber

Optic HDMI Connector

(USB power required on the receiver side of the installation)

BEST

HD TERMINATION

TERMINATE IN

5

MINUTES!

Perfect for HD custom cable lengths in the field!

Locking HDMI connector technology increases retention up to 400%

Customize your HD cable lengths to professionally dress racks & minimize excess cable

Supports HDMI with Ethernet, CEC and bi-directional audio formats

Send 1080p video up to 55ft with optional extender

RIBBON CABLE

DL-HDMCBL

CRIMP & CUTTING TOOL

DL-HDMHT

CONNECTORS & SHELLS

DL-HDMCPK

OPTIONAL EXTENDER

74-035-01

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

61

Align upper Left Corner

CABLES: HDMI AOC

DL-HDM-M *NEW* HDMI AOC RISER 18.0G

HDMI Maximum Performance AOC Hybrid Cable

Liberty’s

DL-HDM-M

Series are

Active Optical Cables (AOC) featuring a unique hybrid construction and construction the industry has been waiting for. The cable strain relief is anchored into the connector housings to prevent inadvertent damage so common in other AOC cables.

key features

True 18G Fiber Optic Performance

No external power required

Designed for Pulling

UL/CSA listed for in-wall use

Convenient cable lengths

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

Male HDMI Type A connector

HDMI SUPPORTED VIDEO,

AUDIO AND ETHERNET

HDMI Maximum

Video Compatibility

[email protected] 4:4:4 up to 100m,

HDR Support

Video Compliance

Embedded Audio

HDMI, HDCP, and CEC (Consumer

Electronics Control)

Up to 32 Audio Channels and up to 1536 KHz Audio Sampling

Minimum Bandwidth 18.0 Gbps

Ethernet

Not supported

Jacket Material

Flexible Flame rated PVC with a black finish

Cable Construction

4 Multimode OM2 equivalent fibers with 7 copper conductors

Overall Cable Size

0.142” | 3.6mm

Minimum Bend Radius

1.42” | 36mm

Maximum Tensile Load

100Lbs | 45Kg

Available Cable

Lengths

8, 10, 15, 23, 30, 50, 60, and 100 meters

ENVIRONMENTAL REQUIREMENTS

Operating

Temperature

0° to +60° C (+32° to +140° F)

Operating Humidity

20% to 85%, Non-condensing

CABLE CONSTRUCTION

HDMI Connector

Features

HDMI “A” Male

HDMI Hood

Construction

Metal Shell for extreme durability and proper cable strain relief

HDMI Molded Hood

Dimensions

19.6x40x10.0mm with a 14mm strain relief

Storage Temperature -20° to +80° C (0° to +176° F)

POWER AND REGULATORY

Regulatory

NEC CMR-OF, CEC CMG FT4, EU

RoHS-2 2011/65/EU Compliant

PF-HDM-M HDMI AOC PLENUM 10.2G

PLENUM HIGH-SPEED HDMI® ACTIVE OPTICAL CABLE

TECH SPECS

INPUT/OUTPUT CONNECTIONS

HDMI

Male HDMI Type A connector

HDMI "A" male to male connectivity

Polymer Optical Fiber (POF) for better flexibility

Ultra-Small diameter cable with reduced sized HDMI heads

Draws power from pin 18 of the source/display HDMI port

HDMI High Speed 10.2Gbps [email protected]

3D all Audio formats

Supports [email protected] with 4:2:0 Chroma Sampling

Does not support Ethernet or Audio Return

Lengths: 10, 15, 20, 23, and 30 meters

NEC/CEC rated CMP-OF Plenum, RoHS-2

Compliant

SUPPORTED AUDIO AND VIDEO

Maximum Video

Compatibility

[email protected] 4:4:4 Chroma or

[email protected] 4:2:0 Chroma

Video Compliance

HDMI, HDCP, and CEC

(Consumer Electronics Control)

Embedded Audio

Input DDC Signal

Up to PCM 8 channel, Dolby

Digital TrueHD, and DTS-HD

Master Audio

5.0 volts p-p (TTL)

Input Video Signal

0.5 to 1.0 volts p-p

Maximum Bandwidth

10.2 Gbps

CABLE CONSTRUCTION

HDMI Hood Material

Molded ABS

HDMI Hood

Dimensions

9.50 mm x 18.7 mm x 26.8 mm

(0.373 in. x 0.734 in. x 1.06 in.)

Fiber Jacket Material

Plenum Rated PVC

Cable Construction

Overall Cable

Diameter

Hybrid POF (Plastic Optical

Fiber) and Copper

5 mm

62

Minimum Bend Radius

5 mm

Maximum Tensile Load

20 kg (44 lbs.)

ENVIRONMENTAL REQUIREMENTS

Operating

Temperature

0° to +50° C (+32° to +122° F)

Operating Humidity

20% to 85%, Non-condensing

Storage Temperature

-30° to +50° C (-22° to +122° F)

Storage Humidity

20% to 85%, Non-condensing

POWER AND REGULATORY

Power Supply

Via HDMI pin 18

Power Consumption

Regulatory

0.07 watts

NEC® rated CMP-OF, CEC rated

CMP, RoHS Compliant

OTHER

Warranty

2 years

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: HDMI AOC

FIBER OPTIC GATEWAY

EXTENSION SYSTEM

Celerity

Fiber Optic Gateway (FOG

) is a breakthrough for high definition, long distance distribution of AV and control signals over fiber optic cable. HDMI, RS232, IR, 10/100BASE-T Ethernet and USB HID are supported up to 1000 feet over a single Celerity fiber optic cable. The combination of these functions in a sleek and slim component with fiber optic connectivity provides superior performance, bandwidth and flexibility for AV professionals to design and install high performance content and control signal distribution systems.

FOG-RXWP

RECEIVER

/ FOG-TXWP

TRANSMITTER key features

FOG Wall Plate mounted Transmitter & Receiver

Uses Mini connectors for Fiber interface

Ultra-Small diameter cable

Very low profile head for ease of pulling

Connect with the pre-made FOG umbilical cables

RS232, IR, 10/100BASE-T Ethernet and USB HID

HDMI 2.0 19.2 Gbps, supports [email protected], CEC, HDCP

FOG-1000P

Plenum rated cable for all installations

Ultra-Small diameter cable

Very low profile head for ease of pulling

Connects the FOG TX and RX units

Lengths: 40, 60, 80, 100, 160, 200, 500, 1000ft

HDMI 2.0 19.2 Gbps, supports [email protected]

The

Celerity Fiber Optic Gateway Cable

eliminates the time consuming and costly steps of fiber terminations.

With Celerity FOG, only 2 steps are required – pre-wire and connect. Using the Celerity mini digital connector on each end of the fiber optic cable, a fast and secure connection is made to the FOG-TXCB and FOG-RXCB. This saves time and ensures that ensures a perfect fiber connection is always available. The Celerity Fiber Optic Gateway cable includes a small module at each end of the cable which supports the connection between the FOG components over the fiber.

The small dimension of this module makes it easy to pull through conduit and concealed spaces. The Celerity Fiber

Optic Gateway cable is plenum-rated to meet required safety specifications and building codes. The Celerity FOG Cable is available in lengths of 35’ 40’ 50’ 60’ 80’ 100’ 160’ 200’ 500’ and

1000’. Custom lengths may be special-ordered. Celerity FOG cables are sold separately from the FOG-TXCB.

FOG-TXCB

TRANSMITTER

/ FOG-RXCB

RECEIVER key features

FOG Control Box Transmitter (TX) & Receiver (RX)

FOG-TXCB

USB power cable (1.5m)

USB-AC power adapter (5V/1A)

IR emitter cable with 3.5mm plug (TS, 5V)

IR receiver cable with 3.5mm plug (TRS, 5V)

User guide

TECH SPECS

FUNCTION

CELERITY FIBER OPTIC CABLE INPUT

CELERITY FIBER OPTIC

CABLE OUTPUT

CELERITY FIBER OPTIC

CABLE DISTANCE

HDMI INPUT

HDMI OUTPUT

RS232

IR INPUT (RX)

IR OUTPUT (TX)

IR CARRIER FREQUENCY RANGE

IR POWER

USB HID

ETHERNET (RJ45 CONNECTOR)

5V POWER

SUPPORTED RESOLUTIONS

HDMI CERTIFICATION

HDCP

EDID PASS-THROUGH

CEC

POWER ADAPTER

POWER

ENCLOSURE

DIMENSIONS (IN & MM)

SHIPPING WEIGHT (LBS & KG)

TRANSMITTER/RECEIVER

Celerity mini digital up to 1000 ft

HDMI Type-A

RJ45

3.5mm TRS

3.5mm TS below 100 kHz

5V

USB Type-A

10/100BASE-T

USB micro

4K @ 60Hz UltraHD

HDMI High Speed

Yes

Yes

Yes

USB 5V/1A

DC5V 200mA

Aluminum

16mm x 60mm x 136mm

0.62” x 2.36” x 5.35”

0.5 lbs / 0.23 kg

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

63

FIBER OPTIC CABLE SOLUTIONS

SSF

®

BULK FIBER

SOLUTIONS

Stronger, Safer and Faster than standard fiber optic cable!

· 10,000x’s THE FLEX LIFE OF STANDARD FIBER!

Extremely high mechanical fatigue rating. This makes SSF

®

Fiber 10,000x’s less susceptible to breaking due to bending.

SSF

® Fiber has a pull tension that is 2.5 – 4x’s that of UTP!

· NEARLY IMPOSSIBLE TO GENERATE GLASS SLIVERS

DURING STANDARD USE!

SSF

® Fiber is completely safe to

handle & will not present the inherent safety concerns that conventional glass fiber brings.

· 33% LABOR SAVINGS USING OUR FIELD TERMINABLE

SC PLUGS.

The termination process for SSF

® Fiber is very

simple; it does not require a trained / certified fiber technician.

· THE PATENTED POLYMER COATING ON SSF

®

FIBER.

Guarantees no contamination reaches the underlying glass.

Moisture, dirt & even human skin oils are kept from the signal carrying core & cladding by the proprietary coating.

This feature increases the lifetime of the fiber well above

& beyond standard fiber constructions.

· MICRO-DISTRIBUTION SSF

®

FIBER IS THE ULTIMATE IN

SMALL DIAMETER FIBER CABLE.

Have a small conduit?

Pull many more fibers than standard construction tight buffer fiber solutions.

64

WWW.LibAV.COM | 800.530.8998

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

FIBER OPTIC CABLE SOLUTIONS

SSF

®

CABLE SOLUTIONS

No stripping required | Incredible bend longevity assured for 10,000x’s longer lifetime than normal glass fibers

Liberty’s SSF® fiber solution by Cleerline Technology is a leap ahead for field installation! Increasing the speed,

safety & efficiency of fiber installations while reducing the tooling required to terminate fiber optic cables!

Features and Benefits

Integral proprietary & patented coating provides incredible glass protection

Very small diameter distribution fiber for maximum fiber counts in conduit limited installations

Simplified termination process designed for ease of use & installation efficiency gains

Bend longevity for 10,000x’s longer life time than normal fibers

Increased safety factor due to the incredible bend insensitivity

Glass fiber remains protected at all times from the elements

High mechanical strength & superior fatigue values

Ultra low attenuation loss on tight bend radius

Exclusive 250um Soft Peel® jacket identifier in standard fiber color codes

Products

OM3 50 micron Laser Optimized fiber cables. OM4, OM2 and singlemode available

Two (2), four (4), & six (6) fiber Micro-Distribution format cables with a maximum diameter of 3.2mm in both plenum and riser formats

One (1) & two (2) fiber assembly style format for simplex & duplex patch cords or one (1 ) & two (2) fiber installations

Two (2) and Four (4) fiber Breakout format cables with 2mm sub units in plenum indoor

& indoor/outdoor formats

Easy apply LC & SC connectors for quick & reliable field termination in convenient

10-packs

SC-SC, LC-LC & SC-LC duplex fiber jumpers in one (1), two (2), three (3), five (5) & 10m lengths

Micro-Distribution Style

FIBER OPTIC CABLE 1 FIBER OM3 50/125 MULTIMODE

1FPINSM10-D

Assembly Style

INDOOR/OUTDOOR FIBER OPTIC CABLE OM3 50/125 MULTIMODE

2FRINSM10-Z

Micro-Distribution Style

FIBER OPTIC CABLE 1 FIBER OM3 50/125 MULTIMODE

1FRINSM10-D

Micro-Distribution Style

INDOOR FIBER OPTIC CABLE 1 FIBER OM3 50/125 MULTIMODE

6FPINSM10-D

Breakout Style

INDOOR/OUTDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE

2FPINSM10-BO

Micro-Distribution Style

INDOOR FIBER OPTIC CABLE 6 FIBER OM3 50/125 MULTIMODE

6FRINSM10-D

Micro-Distribution Style

INDOOR/OUTDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE

2FPINSM10-D

Breakout Style

INDOOR FIBER OPTIC CABLE OM3 50/125

4FPINSM10-BO

Assembly Style

INDOOR/OUTDOOR FIBER OPTIC CABLE OM3 50/125 MULTIMODE

2FPINSM10-Z

Micro-Distribution Style

INDOOR FIBER OPTIC CABLE 1 FIBER OM3 50/125 MULTIMODE

4FPINSM10-D

Breakout Style

INDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE

2FRINSM10-BO

Breakout Style

INDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE

4FRINSM10-BO

Micro-Distribution Style

INDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE

2FRINSM10-D

Micro-Distribution Style

INDOOR FIBER OPTIC CABLE 1 FIBER OM3 50/125 MULTIMODE

4FRINSM10-D

SPECIFICATIONS & IMAGES SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

L0140

|

800.530.8998

|

www.LibAV.com

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

65

FIBER OPTIC CABLE SOLUTIONS

SSF

®

FIBER SOLUTIONS

No stripping required | Incredible bend longevity assured for 10,000 x’s longer lifetime than normal glass fibers

Liberty’s SSF® fiber by Cleerline Technology redefines how optical cables can

be installed and terminated. SSF® fiber optics incorporate a patented polymeric

coating that surrounds the glass fiber. SSF® fibers are stronger, safer and allow

for faster terminations compared to all other glass fibers.

SSF® fiber is compatible with all common connector systems for standard 50/125 multimode and 9/125 single mode fibers and are available in today’s most common cabling configurations for optical cables.

SSF® fiber optic cabling eliminates many of the processes involved in the termination of fiber optic cable while adding strength and safety that is unmatched by any other optical fiber. SSF’s coated fiber provides protection for bend longevity assured for 10,000 x’s longer lift times and superior mechanical strength compared to all other commercially available glass fibers. This allows the installer to quickly terminate mechanical splice style connections and eliminates the imperfections or scarring of the glass caused by stripping when terminating either mechanical or epoxy style connectors. SSF® supports all broadband applications.

SSF Fiber

Liberty’s SSF® fiber is compatible with all common connector systems on the market for

50/125um multimode and 9/125um single mode fiber optic cables. Get your connectors and the complete termination kit at Liberty!

125um

Hybrid Cladding

Normal Fiber

125um

Glass Cladding

STRONGER

SAFER

FASTER!

STRONGER, SAFER, FASTER (SSF

®

): TERMINATIONS

Terminate SSF Fiber in 30 Seconds or Less!

FALCM10 FASCM10 LWFOTKT

LC PLUG FIELD ASSY OM3 10PK

LC Plug Format

50/125 Multimode Fiber OM2/3/4

Sold in multiples of 10 only

Fits Breakout and Distribution style cable

I deal for Stronger, Safer, Faster (SSF) fiber terminations

TECH SPECS

FIELD ASSEMBLY SC FIBER

OPTIC CONNECTOR FOR OM3/4

MULTIMODE

SC Plug Format

50/125 Multimode Fiber OM2/3/4

Sold in multiples of 10 only

Fits Breakout and Distribution style

I cable deal for Stronger, Safer, Faster (SSF) fiber terminations

FIELD ASSEMBLY FIBER OPTIC

TERMINATION KIT

Termination Tooling Kit for SC, LC, and

ST Connectors

I ncludes VFL, cleaver, scissors, stripper

I deally set up for SSF fiber termination

Liberty SSF 50/125μm Specialty OM3 Multimode Optical Fiber Characteristics Conditions Specified Values Unit SSF conforms to the requirement of IEC 60793 A1a,

ISO/IEC 11801 & ITU-T G.651.1. 850 nm Laser-Optomized 50 μm-core multimode fiber for 10 Gb/s & above applications

PHYSICAL CHARACTERISTICS

Core Diameter 50.0 ± 2.5 (μm)

Core Non- circularity ≤ 5 (%)

Core / Hybrid Cladding Concentricity Error ≤ 3.0 (μm)

Hybrid Cladding Diameter 125 ± 1 (μm)

Hybrid Cladding Non-Circularity ≤ 3.0 (%)

Protective Coating Concentricity Error≤ 3.0 (μm)

Soft-Peel Jacket Identifier 245 ± 5

Coating Strip Force (typical) ≤ 100 (g)

Color Coating Diameter 250 ± 10 (μm)

Fiber Curl ≤ 2 (m)

Proof Test 100 (Kps)

Bend Induced Attenuation at 1300 nm ≤ 1.0 (dB)

(100 turns around a mandrel of 75 mm diameter)

Dynamic fatigue 23oC, 41%RH (nd) >30

Length (Typical) 1.0 – 8.8 (Km)

OVERFILLED MODAL BANDWIDTH

850 nm ≤ 1500 (MHzØkm)

1300 nm ≤ 500 (MHzØkm)

Differential Mode Delay 850nm ≤ 2000 (MHz•km)

BACKSCATTER CHARACTERISTICS

Attenuation Directional Uniformity ≤ 0.05 (dB/km)

Attenuation Uniformity ≤ 0.05 (dB)

Group Index of Refraction

850 nm 1.481

1300 nm 1.476

Attenuation Directional Uniformity ≤ 0.05 (dB/km)

Attenuation Uniformity ≤ 0.05 (dB)

Group Index of Refraction

850 nm 1.481

1300 nm 1.476

ENVIRONMENTAL CHARACTERISTICS

Temperature Dependence at 850 nm and 1300 nm ≤ 0.1 (dB/km)

Induced Attenuation – 40oC to +85oC

Water Soak Dependence at 850 nm and 1300 nm ≤ 0.2 (dB/km)

Induced Attenuation at 23oC for 30 days

Damp Heat Dependence at 850 nm and 1300 nm ≤ 0.2 (dB/km)

Induced Attenuation at 85oC, 85%R.H., 30 days

Dry Heat Dependence at 850 nm and 1300 nm ≤ 0.2 (dB/km)

Induced Attenuation at 85oC, 85%R.H., 30 days

OPTICAL CHARACTERISTICS*

Attenuation Coefficient

850 nm ≤ 3.0 (dB/km)

1300 nm ≤ 1.0 (dB/km)

Numerical Aperture 0.200 ± 0.015

* Ensured via minEMBC.per TIA/EIA 455-220A and IEC 60793-1-49, for high performance laser based systems.

SPECIFICATIONS & IMAGES SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

L0140

|

800.530.8998

|

www.LibAV.com

66

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

FIBER OPTIC CABLE SOLUTIONS

SSF

®

JUMPER SOLUTIONS

Stronger, Safer, Faster (SSF®) Lifetime Fiber Optic Patch Cables

DOM3NLCLC

Stronger, Safer, Faster (SSF®) Lifetime Fiber Optic Patch Cable OM3 Laser Optimized Multimode LC-LC

Features and Benefits

Duplex LC to Duplex LC FPC/SPC format connectors

Stronger, Safer, Faster (SSF) fiber bulk cable

10,000 times the flex life of standard fiber cables

Two (2) fiber 50/125 laser optimized multimode OM3 fiber

Standard lengths 1, 2, 3, 5 & 10m

NEC OFNR, CEC FT4 & RoHS compliant

Applications

Super strong long life duplex fiber patch cables

LAN 10/100/1000/10G ethernet

Digital multimedia patching & interconnection

Crestron, AMX & Savant standard fiber specification

TECH SPECS

MODEL

DOM3NLCLC-001M

DOM3NLCLC-002M

DOM3NLCLC-003M

DOM3NLCLC-005M

DOM3NLCLC-010M

Description

3.3’ Teal

6.6’ Teal

10’ Teal

16.5’ Teal

33’ Teal

DOM3NLCSC

Stronger, Safer, Faster (SSF®) Lifetime Fiber Optic Patch Cable OM3 Laser Optimized Multimode LC-SC

Features and Benefits

Duplex LC to Duplex SC format connectors

Stronger, Safer, Faster (SSF) fiber bulk cable

10,000 times the flex life of standard fiber cables

Two (2) fiber 50/125 laser optimized multimode OM3 fiber

Standard lengths 1, 2, 3, 5 & 10m

NEC OFNR, CEC FT4 & RoHS compliant

Applications

Super strong long life duplex fiber patch cables

LAN 10/100/1000/10G ethernet

Digital multimedia patching & interconnection

Crestron, AMX & Savant standard fiber specification

TECH SPECS

MODEL

DOM3NLCSC-001M

DOM3NLCSC-002M

DOM3NLCSC-003M

DOM3NLCSC-005M

DOM3NLCSC-010M

Description

3.3’ Teal

6.6’ Teal

10’ Teal

16.5’ Teal

33’ Teal

DOM3NSCSC

Stronger, Safer, Faster (SSF®) Lifetime Fiber Optic Patch Cable OM3 Laser Optimized Multimode

SC-SC

Features and Benefits

Duplex SC to SC format connectors

Stronger, Safer, Faster (SSF) fiber bulk cable

10,000 times the flex life of standard fiber cables

Two (2) fiber 50/125 laser optimized multimode OM3 fiber

Standard lengths 1, 2, 3, 5 & 10m

NEC OFNR, CEC FT4 & RoHS compliant

Applications

Super strong long life duplex fiber patch cables

LAN 10/100/1000/10G ethernet

Digital multimedia patching & interconnection

Crestron, AMX & Savant standard fiber specification

TECH SPECS

MODEL

DOM3NSCSC-001M

DOM3NSCSC-002M

DOM3NSCSC-003M

DOM3NSCSC-005M

DOM3NSCSC-010M

Description

3.3’ Teal

6.6’ Teal

10’ Teal

16.5’ Teal

33’ Teal

SPECIFICATIONS & IMAGES SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

L0140

|

800.530.8998

|

www.LibAV.com

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

67

MULTIMODE OM1: PLENUM AND NON-PLENUM

4FPIOMM6-BO

ORANGE BREAKOUT STYLE INDOOR/OUTDOOR PLENUM FIBER OPTIC CABLE 4 FIBER OM1 62.5/125 MULTIMODE REEL

4 fiber OM1 62.5/125 multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

UV stabilized PVC jacket

NEC OFNP, CEC FT6, Sunlight resistant,

RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

2FRIOMM6-D

BLACK DISTRIBUTION STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 2 FIBER OM1 62.5/125 MULTIMODE REEL

2 fiber OM1 62.5/125 multimode

Dual layer tight buffer 900 micron

Central strength member and kevlar yarn

Distribution construction

UV stabilized PVC jacket

Sunlight resistant, suitable for wet locations

NEC OFNR, CEC FT4, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

4FRIOMM6-BO

BLACK BREAKOUT STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 4 FIBER OM1 62.5/125 MULTIMODE REEL

4 Fiber 62.5 micron 62.5/125 Multimode OM1 Fiber

Dual Layer 900 micron tight buffer

Breakout Construction inner jackets with kevlar yarn

4 jacketed fibers around a central member

UV Stabilized Polyvinyl Chloride jacket

NEC OFNR, CEC FT4, Sunlight Resistant, RoHS Compliant

000 Foot Spools, Fiber is Cut-to-Order

6FRIOMM6-D

BLACK DISTRIBUTION STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 6 FIBER OM1 62.5/125 MULTIMODE REEL

6 fiber OM1 62.5/125 multimode

Dual layer tight buffer 900 micron

Central strength member and kevlar yarn

Distribution construction

UV stabilized PVC jacket

Sunlight resistant, suitable for wet locations

NEC OFNR, CEC FT4, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

MULTIMODE OM2: PLENUM AND NON-PLENUM

2FPIMM5-D

ORANGE FIBER 2F 50 OM2 OFNP DIST REEL

2 Fiber 50/125 micron OM2 Multimode Fiber

900 Micron Dual Layer Tight Buffer

Aramid Yarn Strength Members (Kevlar)

Distribution Format

Indoor Only Plenum rated PVC Alloy Orange Jacket

800m, 1600m Standard Spool Lengths, Fiber is cutto-order

NEC OFNP, CEC FT6, RoHS Compliant

4FRIOMM5-BO

BLACK BREAKOUT STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 4 FIBER OM2 50/125 MULTIMODE REEL

4 Fiber 50/125 Multimode OM2 Fibers

Dual Layer 900 micron tight buffer

Breakout Construction inner jackets with

kevlar yarn

4 jacketed fibers around a central member

UV Stabilized Polyvinyl Chloride jacket

Orange colored jacket indicates OM2

NEC OFNR, CEC FT4, ,Sunlight Resistant, RoHS

Compliant

3000 Foot Spools, Fiber is Cut-to-Order

MULTIMODE OM3: PLENUM AND NON-PLENUM

4FPIOMM10-BO

TEAL BREAKOUT STYLE INDOOR/OUTDOOR PLENUM FIBER OPTIC CABLE 4 FIBER OM3 50/125 MULTIMODE REEL

4 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

UV stabilized PVC jacket

NEC OFNP, CEC FT6, Sunlight resistant, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

2

68

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

MULTIMODE OM3: PLENUM AND NON-PLENUM

2FRIMM10-BO

TEAL BREAKOUT STYLE INDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE REEL

2 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

Indoor only flame rated rated PVC jacket

NEC OFNR, CEC FT4, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

2FRIOMM10-BO

TEAL BREAKOUT STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 2 FIBER OM3 50/125 MULTIMODE REEL

2 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

UV stabilized PVC jacket

NEC OFNR, CEC FT4, Sunlight resistant, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

4FRIMM10-BO

TEAL BREAKOUT STYLE INDOOR FIBER OPTIC CABLE 4 FIBER OM3 50/125 MULTIMODE REEL

4 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

Indoor flame rated PVC jacket

NEC OFNR, CEC FT4, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

4FRIOMM10-BO

TEAL BREAKOUT STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 4 FIBER OM3 50/125 MULTIMODE REEL

4 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

UV stabilized PVC jacket

NEC OFNR, CEC FT4, Sunlight resistant, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

4FRIOMM10-D

TEAL DISTRIBUTION STYLE INDOOR/OUTDOOR FIBER OPTIC CABLE 4 FIBER OM3 50/125 MULTIMODE REEL

4 fiber OM3 50/125 laser optimized multimode

Dual layer tight buffer 900 micron

Central strength member

Breakout construction

UV stabilized PVC jacket

NEC OFNR, CEC FT4, Sunlight resistant, RoHS compliant

Fiber is cut to order, 3,000 foot spools standard

CUSTOM & PREMADE FIBER OPTICS SOLUTIONS

CUSTOM FIBER INSTALL CABLES | CUSTOM FIBER PATCH CORDS

DATA CENTER CONFIGURATIONS | LEMO® BROADCAST CABLES | STANDARD FIBER PATCH CORDS

Liberty’s team of experienced sales professionals and highly trained fiber technicians can design solutions that will work for every type of fiber optic installation.

As a certified Fibertron

TM

and Corning Gold

TM

manufacturer, our custom fiber assemblies are unmatched in the AV industry for performance, reliability and value.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

3

69

95-000-41

CORNING: OM1

95-000-41

95-000-51

95-000-51

95-000-99

95-000-99

CORNING UNICAM SC FIBER OPTIC

CONNECTOR FOR OM1 62.5/125

CORNING UNICAM ST® COMPATIBLE

FIBER OPTIC CONNECTOR FOR OM1

CORNING UNICAM LC FIBER OPTIC

CONNECTOR FOR OM1 62.5/125

SC Plug Format

62.5/125 Multimode Fiber OM1

Individual Bag with Multiple strain relief boots

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

Specific for Corning Unicam PFC System

CONNECTORS: STRONGER, SAFER, FASTER (SSF

Individual Bag with Multiple strain relief boots

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

LC Plug Format

®

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

®

): OM1

FASCM10

) / KEYSTONE

KEYSTONE: MULTIMODE ALL

ISK-LC-WH

CORNING: OM2/3/4

CORNING: OM2/3/4

95-050-41 95-050-41-X 95-050-51-X

95-050-41 95-050-41-X 95-050-51-X

CORNING UNICAM SC FIBER OPTIC

CONNECTOR FOR OM2 50/125

SC Plug Format

50/125 Multimode Fiber OM2

Individual Bag with Multiple strain relief boots

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

LC PLUG FIELD ASSY OM3 10PK

LC Plug Format

50/125 Multimode Fiber OM2/3/4

Sold in multiples of 10 only

CORNING UNICAM SC FIBER OPTIC

CONNECTOR FOR OM3/4 50/125

SC Plug Format

50/125 Laser Optimized Multimode OM3 / OM4

Individual Bag with Multiple strain relief boots

Fits both Breakout and Distribution style cable

FIELD ASSEMBLY SC FIBER

OPTIC CONNECTOR FOR OM3/4

MULTIMODE

SC Plug Format

50/125 Multimode Fiber OM3 or OM4

Sold in multiples of 10 only

Fits Breakout and Distribution style cable

Ideal for Stronger, Safer, Faster (SSF)

ST Plug Format

50/125 Laser Optimized Multimode OM3 / OM4

Individual Bag with Multiple strain relief boots

TOOLING: CORNING / STRONGER, SAFER, FASTER (SSF

KEYSTONE COMPATIBLE LC DUPLEX

MULTIMODE FIBER COUPLER

INSERTS

LC Multimode fiber optic coupler in pass through format

Duplex format, 2 connectors per insert

Multimode OM1, OM2, or OM3 applications

Keystone snap in insert format

Non-recessed design

Compatible with Leviton plates and panels

®

) / PULL SOCK

95-050-99-X

95-050-99-X

CORNING

TKT-UNICAM-PFC FCC-CLEANER-FIBER FCC-WIPES

6

CORNING UNICAM LC FIBER OPTIC

CONNECTOR FOR OM3/4 50/125

LC Plug Format

LC Plug Format

50/125 Laser Optimized Multimode OM3 / OM4

50/125 Laser Optimized Multimode OM3 / OM4

Individual Bag with Multiple strain relief boots

Fits both Breakout and Distribution style cable

Specific for Corning Unicam PFC System

CORNING UNICAM FIBER

OPTIC TERMINATION SYSTEM

Termination Tooling Kit for SC, LC, and ST Connectors

Ergonomic Suitcase design can go anywhere

All Supplies included, DVD and printed instructions

6

Visual Fault Locator built into

Precision Cleaver

|

|

NEED HELP?

We offer technical assistance

Single Dispensing bottle of Fiber Cleaning Fluid

[email protected]

[email protected]

STRONGER, SAFER,

FASTER (SSF

LWFOTKT

SPECIFICATIONS SUBJECT TO CHANGE

|

®

)

|

IMAGES NOT TO SCALE

IMAGES NOT TO SCALE

CORNING FIBER OPTIC UNICAM

TERMINATION SYSTEM FIBER

CLEANING CLOTHS

Single Dispensing bottle of Fiber Cleaning cloths

Replenishment for the TKT-UNICAM-PFC tool kit

Can be used with any fiber or fiber tool kit

PULL SOCK

PS2-6

70

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

FULLY UPDATED TECH SPECS

For all products available online!

www.LibAV.com

FIELD ASSEMBLY FIBER OPTIC

TERMINATION KIT

Termination Tooling Kit for SC, LC, and

ST Connectors

Includes VFL, Cleaver, Scissors, Stripper

Ideally set up for SSF Fiber Termination

PULLING SHEATH FIBER/HDMI

1” Clear Heavy Duty Shrink Tubing body

6’ long

Eyelet formed with heavy duty pulling tape

Pulling tape wraps around bulk cable in an overlap

Reusable many times

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

7

CABLES: CATEGORY CABLE SOLUTIONS CABLES

• TRULY 3RD PARTY CERTIFIED BY UL OR ETL

• ABSOLUTELY COMPLIANT!

• HIGH QUALITY PRODUCT

• COMPETITIVE PRICING

• COOL SPOOL® REELS & PAYOUT BOXES

• CATEGORY 5E, 6, 6A & CATEGORY 7

• SHIELDED AND UNSHIELDED

• PLENUM AND RISER RATED

24-4P-L7SH

SHIELDED S/FTP ISO 11801 CLASS F CATEGORY 7

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Individually shielded pairs w/overall braid

CM rated, RoHS compliant

24-4P-P-L7SH

SHIELDED S/FTP ISO 11801 CLASS F CATEGORY 7 - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Individually shielded pairs w/overall braid

CMP rated, RoHS compliant

24-4P-L6ASH

SHIELDED F/UTP CATEGORY 6A

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMR rated, RoHS compliant

24-4P-P-L6ASH

SHIELDED F/UTP CATEGORY 6A - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMP rated, RoHS compliant

24-4P-L6-EN

EN SERIES CATEGORY 6

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & unshielded

CMR rated, RoHS compliant

24-4P-P-L6-EN

EN SERIES CATEGORY 6 - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & unshielded

CMP rated, RoHS compliant

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ISO 11801 Class F, AKA Cat 7

10GB Ethernet/4K HDBaseT

Blue jacket only

CONNECTOR(S)

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

Field Terminable:

1401405012-I

BEST

CRIMP TOOLING TOOL KIT

12516

-N/A-

-N/A-

90170

-N/A-

-N/A-

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ISO 11801 Class F, AKA Cat 7

10GB Ethernet/4K HDBaseT

Blue jacket only

CONNECTOR(S)

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

Field Terminable:

1401405012-I

BEST

CRIMP TOOLING TOOL KIT

12516

-N/A-

-N/A-

90170

-N/A-

-N/A-

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6a

10GB Ethernet/HDBaseT

White jacket only

CONNECTOR(S)

Standard:

111S08080016C34

Kitted:

RJ45-STP-L6

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

HIGH QUALITY FOR SUPERIOR PERFORMANCE

CONNECTOR(S)

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6a

10GB Ethernet/HDBaseT

White jacket only

Standard:

111S08080016C34

Kitted:

RJ45-STP-L6

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6

Positive ACR to 550 MHz

10 colors

CONNECTOR(S)

EZ-RJ45®:

100 011LW

Standard:

11108080034

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

12516

-N/A-

90131LW

90131LW

90170

-N/A-

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

12516

-N/A-

90131LW

90131LW

90170

-N/A-

BEST

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6

Positive ACR to 550 MHz

10 colors

CONNECTOR(S)

EZ-RJ45®:

100 011LW

Standard:

11108080034

BEST

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

71

CABLES: CATEGORY CABLE SOLUTIONS CABLES

24-4P-L6SH

SHIELDED F/UTP CATEGORY 6

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & unshielded

CMR rated, RoHS compliant

24-4P-P-L6SH

SHIELDED F/UTP CATEGORY 6 - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & unshielded

CMP rated, RoHS compliant

24-4P-L6-HT

HOMETRAX™ CATEGORY 6 CABLES

FEATURES

Solid annealed bare copper conductors

High Density Polyethylene

Insulation

Tightly twisted & unshielded

NEC CMR, CEC CMR FT4,

RoHS compliant

24-4P-L6SH-HT

SHIELDED F/UTP CATEGORY 6

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CM rated, RoHS compliant

24-4P-L5-EN

EN SERIES CATEGORY 5E

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMR rated, RoHS compliant

24-4P-P-L5-EN

EN SERIES CATEGORY 5E - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMP rated, RoHS compliant

24-4P-L5SH-EN

EN SERIES SHIELDED F/UTP CATEGORY 5E

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMR rated, RoHS compliant

72

HIGH QUALITY FOR SUPERIOR PERFORMANCE

CONNECTOR(S)

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6

Positive ACR to 550 MHz

3 colors

Standard:

111S08080016C34

Kitted:

RJ45-STP-L6

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

HIGH QUALITY FOR SUPERIOR PERFORMANCE

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6

Positive ACR to 550 MHz

3 colors

CONNECTOR(S)

Standard:

111S08080016C34

Kitted:

RJ45-STP-L6

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

CONNECTOR(S)

Nested box packaging only

ANSI/TIA-568C Verified Cat 6

Positive ACR to 275 MHz

4 colors

EZ-RJ45®:

100 011LW

Standard:

11108080034

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

12516

-N/A-

90131LW

90131LW

90170

-N/A-

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

12516

-N/A-

90131LW

90131LW

90170

-N/A-

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

HIGH QUALITY FOR SUPERIOR PERFORMANCE

CONNECTOR(S)

Cool Spool Reels

ANSI/TIA-568C Verified Cat 6

Positive ACR past 300 MHz

3 colors

Standard:

111S08080016C34

Kitted:

RJ45-STP-L6

Tele-TitanXg®:

106190 / 106192

Field Terminable:

OCCSFP6A

HIGH QUALITY FOR SUPERIOR PERFORMANCE

CONNECTOR(S)

EZ-RJ45®:

100 003B

Standard:

10005USOP

Cool Spool Reels

& Nested Boxes

ANSI/TIA-568C Verified Cat 5e

Positive ACR to 350 MHz

10 colors

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

12516

-N/A-

90131LW

90131LW

90170

-N/A-

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

HIGH QUALITY FOR SUPERIOR PERFORMANCE

CONNECTOR(S)

Cool Spool Reels

& Nested Boxes

ANSI/TIA-568C Verified Cat 5e

Positive ACR to 350 MHz

10 colors

EZ-RJ45®:

100 003B

Standard:

10005USOP

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

CONNECTOR(S)

Cool Spool Reels

ANSI/TIA-568C Verified Cat 5e

Positive ACR past 200 MHz

4 colors

EZ-RJ45®:

100 003B

Standard:

10005USOP

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: CATEGORY CABLE SOLUTIONS CABLES

24-4P-P-L5SH

EN SERIES SHIELDED F/UTP CATEGORY 5E - PLENUM

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted

& overall foil shielded

CMP rated, RoHS compliant

24-4P-L5-HT

HOMETRAX™ CATEGORY 5E CABLES

FEATURES

Solid annealed bare copper conductors

High Density

Polyethylene Insulation

Tightly twisted & unshielded

NEC CMR, CEC CMR FT4,

RoHS compliant

24-4P-L5SH-HT

HOMETRAX™ SHIELDED F/UTP CATEGORY 5E

FEATURES

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & overall foil shielded

CMR rated, RoHS compliant

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

CONNECTOR(S)

Cool Spool Reels

ANSI/TIA-568C Verified Cat 5e

Positive ACR past 200 MHz

4 colors

EZ-RJ45®:

100 003B

Standard:

10005USOP

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

CONNECTOR(S)

Nested box packaging only

ANSI/TIA-568C Verified Cat 5e

Positive ACR past 200 MHz

4 colors

EZ-RJ45®:

100 003B

Standard:

10005USOP

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

Plain wooden spools

ANSI/TIA-568C Verified Cat 5e

3 colors

CONNECTOR(S)

EZ-RJ45®:

100 003B

Standard:

10005USOP

BETTER

CRIMP TOOLING TOOL KIT

100054LW

100054LW

90131LW

90131LW

LAN TOOLS & TERMINATION KITS

90170

NCS TELE-TITANXG CAT6A/10GIG

CRIMP TOOL KIT

Large diameter Cat 6, 6A &

7 terminations

LAN up to 10G networking,

HDBaseT cable terminations

12516

TELE-TITANXG CAT6A/10GIG

STRAIN RELIEF CRIMP TOOL

Large diameter Cat 6, 6A &

7 terminations

LAN up to 10G networking,

HDBaseT cable terminations

90131LW

WHITE CATMASTER

TOOL KIT

Termination of RJ45 & RJ25

(RJ11, RJ12) plugs

Termination of EZ-RJ45 feed through plugs

LAN & Balun support

100054LW

HEAVY DUTY EZ-RJ45

CRIMP TOOL

Modular plug crimp & cut action for EZ-RJ45 connectors

4P4C through 8P8C formats

(RJ9/RJ11/RJ45)

75% better connector support to reduce issues

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

73

74

CABLES: RF COAXIAL SOLUTIONS

• MANUFACTURED TO SCTE REQUIREMENTS

• MATCHING C-TEC2 COMPRESSION PLUGS

• NO MAGNESIUM BRAID SHIELDS HERE

• COMPETITIVE PRICING

• COOL SPOOL® REELS AND PAYOUT BOXES

• SWEEP TESTED TO 3.0 GHZ

• DUAL AND QUAD SHIELDED

• UL OR ETL LISTED

RG6-CM

DUAL SHIELD NON-PLENUM RG6 FOR CATV & DBS

IDEAL FOR MOST RF VIDEO APPLICATIONS

WHERE DC POWER IS NOT NEEDED

Solid copper-clad steel conductors

Foamed Polyethylene Insulation

Bonded foil & 60% aluminum braid shields

NEC CM, CEC CM RoHS compliant

Cool Spool® Reels

Sweep Tested to 3.0 GHz

Excellent SRL ration

2 colors

RG6-P-CATV

DUAL SHIELD PLENUM RG6 FOR CATV & DBS

IDEAL FOR MOST RF VIDEO APPLICATIONS

WHERE DC POWER IS NOT NEEDED

Solid copper-clad steel conductors

Foamed Polyethylene Insulation

Bonded foil & 60% aluminum braid shields

NEC CM, CEC CM RoHS compliant

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

RG6-BC-CATV-DB

DUAL SHIELD OUTSIDE PLANT RG6 FOR CATV & DBS

IDEAL ALL AROUND RF VIDEO CABLE

FOR OUTDOOR & DIRECT BURIAL APPLICATIONS

Solid bare copper conductors

Foamed Polyethylene Insulation

Bonded foil & 60% aluminum braid shields

Braid shield flooded for water repellant gel

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

QUADFLEX

QUAD SHIELD NON-PLENUM RG6 FOR CATV & DBS

IDEAL FOR RF VIDEO NON-DC REQUIRED APPLICATIONS

WHERE EXTERNAL INTERFERENCE RESISTANCE IS NEEDED

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & unshielded

CM rated, RoHS compliant

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

QUADFLEX-BC

QUAD SHIELD NON-PLENUM RG6 FOR CATV & DBS

IDEAL FOR RF VIDEO DC REQUIRED APPLICATIONS

WHERE EXTERNAL INTERFERENCE RESISTANCE IS NEEDED

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & overall foil

CM rated, RoHS compliant shielded

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

RG6-QUAD-CMP

QUAD SHIELD PLENUM RG6 FOR CATV & DBS

IDEAL FOR RF VIDEO NON-DC REQUIRED APPLICATIONS

WHERE EXTERNAL INTERFERENCE RESISTANCE IS NEEDED

Solid annealed bare copper conductors

HDPE or FEP insulation

Tightly twisted & overall foil

CMP rated, RoHS compliant shielded

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

RG6-QUAD-DB

QUAD SHIELD OUTSIDE PLANT RG6 FOR CATV & DBS

IDEAL FOR RF VIDEO NON-DC REQUIRED APPLICATIONS

FOR OUTDOOR & DIRECT BURIAL

Solid annealed bare copper conductors

High Density Polyethylene Insulation

Tightly twisted & overall foil shielded

Braid shield flooded for water repellant gel

Cool Spool Reels

Sweep Test to 3.0 GHz

Excellent SRL ration

2 colors

RG6Q-CM-SIAM

QUAD SHIELD NON-PLENUM DUAL RG6 FOR CATV & DBS

IDEAL FOR RF VIDEO NON-DC REQUIRED APPLICATIONS

WHERE EXTERNAL INTERFERENCE RESISTANCE IS NEEDED

Solid copper-clad steel center conductor

Foamed Polyethylene Insulation

Two 100% foil & two braid shields

60/40%

NEC CM, CEC CMG FT4, RoHS compliant

Wooden spools

Sweep Tested to 3.0 GHz

Excellent SRL ratio

Black only

GOOD

GOOD

GOOD

BETTER

BETTER

BETTER

BETTER

BETTER

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: RF COAXIAL SOLUTIONS

RG11-CATV

DUAL SHIELD NON-PLENUM RG11 FOR CATV & DBS

RG11-P-CATV

DUAL SHIELD PLENUM RG11 FOR CATV & DBS

IDEAL FOR LONG RUN, LOW LOSS RF VIDEO APPLICATIONS

WHERE DC POWER IS NOT NEEDED

Solid copper-clad steel center conductor

Foamed Polyethylene Insulation

Bonded foil and 60% aluminum braid shields

NEC CM, CEC CMG FT4, RoHS compliant

Wooden spools

Sweep Tested to 3.0 GHz

Excellent SRL ratio

Black only

IDEAL FOR LONG RUN LOW LOSS RF VIDEO APPLICATIONS

WHERE DC POWER IS NOT NEEDED

Solid copper-clad steel center conductor

Foamed Polyethylene Insulation

Bonded foil and 60% aluminum braid

CMP, RoHS compliant shields

Wooden spools

Sweep Tested to 3.0 GHz

Excellent SRL ratio

White only

RG11-BC-CATV-DB

DUAL SHIELD OUTSIDE PLANT RG11 FOR CATV & DBS

IDEAL FOR ALL LONG RUN LOW LOSS RF VIDEO CABLE

FOR OUTDOOR AND DIRECT BURIAL APPLICATIONS

Solid copper-clad steel center conductor

Foamed Polyethylene Insulation

Bonded foil and 60% aluminum braid shields

Braid shield flooded for water repellent gel

Wooden spools

Sweep Tested to 3.0 GHz

Excellent SRL ratio

Black only

BEST

BEST

BEST

RG11-QUAD-PL

QUAD SHIELD PLENUM RG11 FOR CATV & DBS

IDEAL FOR RF VIDEO NON-DC REQUIRED APPLICATIONS

WHERE EXTERNAL INTERFERENCE RESISTANCE IS NEEDED

Solid copper-clad steel center conductor

Foamed Polyethylene Insulation

Two 100% foil and two braid shields 60/40%

CMP, RoHS compliant

Wooden spools

Sweep Tested to 3.0 GHz

Excellent SRL ratio

White only

BEST

C-TEC2

MATCHING UNIVERSAL CONNECTORS FOR ALL FORMATS

F PLUGS FOR ALL FORMATS

Ferrule-less F & M series design allows any sized cable constructions from virtually any manufacturer to fit these connectors

Significantly reduces the number of connectors required to terminate a variety of cable types

BEST

All-metal connectors with machined slots for ID bands

Perfect for RF video–CATV, MATV, direct broadcast satellite

Super-simple termination process, see the video at

LibAV.com or scan the QR code below

C-TEC

2

COMPLETE TOOL PACK

CM-TOOL-PAC

CHECK OUT OUR ENTIRE

VIDEO LIBRARY AT LIBAV.COM

TERMINATION SYSTEM

FOR RG59, RG6, RG11, MINI RGB & AUDIO CONNECTORS

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

75

CABLES: SERIAL DIGITAL SOLUTIONS

• SMPTE COMPLIANT FOR SD SIGNALS

• UL, CSA, AND ROHS COMPLIANT

• HIGH QUALITY LOW LOSS PRODUCT

• COMPETITIVE PRICING

• SDI, HD-SDI, 3G-SDI

• MATCHED CONNECTORS

• SWEEP TEST 4.5 GHZ

• PLENUM AND NON-PLENUM

23-MINI-SD

LIBERTY MINI-RG59 SERIAL DIGITAL HIGH RESOLUTION COAXIAL CABLE — IDEAL FOR SHORT LENGTH SDI RUNS & SDI PATCHING

23 AWG solid bare copper center conductor

Nitrogen injected cellular Polyethylene

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated rated CM, CEC rated CMG FT4

Standard colors black & white

GOOD

23-MINI-CMP

LIBERTY MINI-RG59 SERIAL DIGITAL HIGH RESOLUTION COAXIAL CABLE — IDEAL FOR SHORT LENGTH PLENUM SDI RUNS & SDI PATCHING GOOD

23 AWG solid bare copper center conductor

Nitrogen injected cellular Fluoropolymer

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated CMP, CEC rated CMP FT6

Standard colors black & white

20-CMR-VIDEO

LIBERTY RG59 SERIAL DIGITAL HIGH RESOLUTION COAXIAL RISER RATED CABLE — IDEAL FOR MEDIUM LENGTH SDI RUNS

20 AWG solid bare copper center conductor

Nitrogen injected cellular Fluoropolymer

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated CMR, CEC rated CMG FT4

Standard colors black & white

BETTER

20-CMP-VID-COAX

LIBERTY RG59 SERIAL DIGITAL HIGH RESOLUTION COAXIAL, PLENUM RATED CABLE — IDEAL FOR MEDIUM LENGTH PLENUM SDI RUNS BETTER

20 AWG solid bare copper center conductor

Nitrogen injected cellular Fluoropolymer

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated CMP, CEC rated CMP FT6

Standard colors black & white

18-CMR-SD

LIBERTY RG6 SERIAL DIGITAL HIGH RESOLUTION COAXIAL RISER RATED CABLE — IDEAL FOR MEDIUM LENGTH SDI RUNS

18 AWG solid bare copper center conductor

Nitrogen injected cellular Fluoropolymer

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated CMR, CEC rated CMG FT4

Standard colors black & white

BEST

18-CMP-VID-COAX

LIBERTY RG6 SERIAL DIGITAL HIGH RESOLUTION COAXIAL PLENUM RATED CABLE — IDEAL FOR MEDIUM LENGTH PLENUM SDI RUNS BEST

18 AWG solid bare copper center conductor

Nitrogen injected cellular Fluoropolymer

Full Aluminum/Poly/Aluminum inner foil shield

95% coverage tinned copper braid shield

NEC rated CMP, CEC rated CMP FT6

Standard colors black & white

76

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: SPEAKER CABLE SOLUTIONS

• UL, ETL, ROHS AND REACH

• MANY CHOICES FOR YOUR APPLICATION

• GOOD-BETTER-BEST IN MOST CATEGORIES

• COMPETITIVE PRICING

• COOL SPOOL® REELS AND PAYOUT BOXES

• CUSTOM PRINTING, SPOOLING AND CUT

GENERAL PURPOSE RISER

IDEAL FOR COMMERCIAL SOUND APPLICATIONS, TRADITIONAL AND 70 VOLT SYSTEMS

FEATURES

18, 16, 14 & 12 AWG 2 & 4 conductor

7, 19 or 29 strand annealed copper conductors

Semi-Rigid PVC insulation for lower capacitance

Riser rated PVC jacketing

UL listed CMR or CL3R, Canada FT4, RoHS

Cool Spool 1000ft put ups

18-2C

16-2C

18-4C

16-4C

12-4C

14-2C 14-4C

12-2C

GENERAL PURPOSE PLENUM

IDEAL FOR COMMERCIAL SOUND APPLICATIONS, TRADITIONAL AND 70 VOLT SYSTEMS

FEATURES

16, 14 & 12 AWG 2 & 4 conductor

19 or 29 strand annealed copper conductors

Plenum rated PVC insulation

Plenum rated PVC jacketing

UL listed CMP or CL3P, Canada FT6, RoHS

Cool Spool 1000ft put ups

18-2C-P

16-2C-P

18-4C-P

16-4C-P

12-2C-P 14-2C-P 14-4C-P

TIGHT TUBE PLENUM

(

TTP

™)

RUGGED HIGH QUALITY FOR SUPERIOR PERFORMANCE AND EASE OF INSTALLATION

Stranded Annealed Bare Copper Conductors

Plenum rated PVC Alloy insulation

Twisted, unshielded

Plenum rated PVC Jacket

NEC CL3P, CEC CMP FT6, RoHS Compliant

1000 Foot Spools

16-2C-TTP 16-4C-TTP

10-2C-TTP 12-2C-TTP 14-2C-TTP

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

GOOD

GOOD

BEST

77

78

CABLES: SPEAKER CABLE SOLUTIONS

• UL, ETL, ROHS AND REACH

• MANY CHOICES FOR YOUR APPLICATION

• GOOD-BETTER-BEST IN MOST CATEGORIES

• COMPETITIVE PRICING

HOMETRAX

IDEAL FOR BUDGET CONSCIOUS INSTALLATIONS

16-2C-HT 14-2C-HT

• COOL SPOOL® REELS AND PAYOUT BOXES

• COMPETITIVE PRICING

• CUSTOM PRINTING, SPOOLING AND CUTS

16-4C-HT 14-4C-HT

FEATURES

• 16 and 14 AWG 2 and 4 conductor

• 41 strand annealed copper conductors

• Semi-Rigid PVC insulation for lower capacitance

• Flame rated PVC jacketing

• UL listed CM or CL3, Canada FT4, RoHS

• Nested box packaging only

• White Jackets are standard

• 500 foot put ups

GOOD

KNOCKOUT PLUS

STRONGER & SMOOTHER THAN STANDARD

16-2C-KO+ 14-2C-KO+

FEATURES

• 16 and 14 AWG 2 and 4 conductor

• 41 strand annealed copper conductors

• Semi-Rigid PVC insulation for lower capacitance

• 20% thicker Flame rated PVC jacketing

• Cool Spool Reels and Nested Boxes

• UL listed CM or CL3, Canada FT4, RoHS

• 500 or 1000 foot put ups

• Custom Colors available with a 10,000 minimum

BETTER

16-4C-KO+ 14-4C-KO+

EXTRAFLEX PLUS

RUGGED HIGH QUALITY, SUPERIOR PERFORMANCE & EASE OF INSTALLATION FEATURES

16-4C-EX+ 16-2C-EX+

• 16, 14, and 12 AWG one and two pair formats

• High strand rope lay annealed copper conductors

• Foamed Polyethylene insulation

• Very thick and strong pressured PVC jacketing

• Cool Spool Reels

• UL listed CMR or CL3R, Canada FT4, RoHS

• THX® Certified, white jackets

• 500 and 1000 foot put ups

14-4C-EX+ 14-2C-EX+

BEST

12-4C-EX+ 12-2C-EX+ 10-2C-EX+

800.530.8998

|

www.LibAV.com

|

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

CABLES: SPEAKER CABLE SOLUTIONS

ULTRACAP

THX

®

CERTIFIED SPEAKER CABLES

FOR THE DISCERNING AUDIOPHILE

16-1P-UC 14-1P-UC

12-2P-UC 12-1P-UC

TIGHT TUBE PLENUM

®

16-2C-TTP

12-2C-TTP

16-4C-TTP

10-2C-TTP

FEATURES

• 16, 14, and 12 AWG one and two pair formats

• High strand rope lay annealed copper conductors

• Foamed Polyethylene insulation

• Very thick and strong pressured PVC jacketing

• Cool Spool Reels

• UL listed CMR or CL3R, Canada FT4, RoHS

• THX® Certified, white jackets

• 500 and 1000 foot put ups

14-2C-TTP

AWESOME

FEATURES

• 16, 14, and 12 AWG 2 and 4 conductor

• 19 or 29 strand annealed copper conductors

• Plenum rated PVC insulation

• Heavy Plenum rated PVC jacketing

• UL listed CMP or CL3P, Canada FT6, RoHS

• Cool Spool 1000 foot put ups

BEST

Audio

2 connectors slip on easily to the speaker cable conductor & compress on effortlessly with the easy-to-use

Audio crimp tools!

2

Works with all

Liberty speaker cable, for in-wall

& non in-wall audio applications.

SPECIFICATIONS SUBJECT TO CHANGE

|

IMAGES NOT TO SCALE

|

800.530.8998

|

www.LibAV.com

79

HEADQUARTERS

11675 Ridgeline Drive

Colorado Springs, Colorado

80921 USA

Phone: 719-260-0061

Fax: 719-260-0075

Toll-Free: 800-530-8998

Order E-Mail: [email protected]

EAST COAST OFFICE AND

WAREHOUSE FACILITY

5521 Lakeview Rd., Suite W

Charlotte, North Carolina

28269 USA

Phone: 719-260-0061

Fax: 719-260-0075

Toll-Free: 800-530-8998

Order E-Mail: [email protected]

WESCO ASSEMBLY

2202 S 7th Street, Suite 120

Phoenix, Arizona

85034 USA

Phone: 602-226-1625

Toll-Free: 800-263-6591

Email: [email protected]

L0235

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
