product catalog
High Performance Structured
Cabling Products and Solutions
2012|13
Product Catalog
HI GH P E R F O RM AN C E S T RU C T U RE D C A BLIN G
P R ODUCTS & S O L U T IO N S
Mighty Mo Cable
Physical
Support
Management
Systems
EuroLine
Cabinets
Mighty Mo
Cabinets
Mighty Mo
Air Control
Complete cable management maximizes your network’s
performance. It may be a small portion of your overall
Horizontal Cable
network investment, but the proper infrastructure layout
Management,
can yield enormous returns. The right cable management
Shelves & Access.
system can protect and extend the life of your network.
Ortronics® Mighty Mo® advanced cable management
systems provide strength and support, and flexibility for
system design and future expansion. No other system
makes it easier to install your network with standards
compliant bend radius, cable routing and strain relief,
Bonding &
Grounding
ensuring optimal network performance.
F E AT U R E D P R O D U C T S
Ortronics is a solution
developer partner
within the Cisco
Developer Network
Mighty Mo
Cable
Management
Racks
P.
80
P.80
Mighty Mo 10 Cable
Management Racks
& Accessories
P.84
Mighty Mo
Cable Management
Accessories
P.87
Mighty Mo 6
Horizontal
Management
and Equipment
Shelves
P.91
EuroLine
Network
Cabinets
P.92
EuroLine
Wall Mount
Cabinets
P.93
EuroLine
Cabinet
Accessories
P.96
Mighty Mo
Pre-Configured
Cabinets
P.99
Mighty Mo
Cabinet
Accessories
P.107
Mighty Mo Wall
Mount Cabinets
& Accessories
P.110
Air Curtain
System
P.113
Air Plugs
P.114
Air Disrupters
P.117
Cable
Management
Panels
P.120
Equipment
Shelves
P.122
Rack and
Cabinet
Accessories
P.126
Bonding &
Grounding
Mighty Mo
Cabinets
P.
96
Mighty Mo
Air Control
P.
109
MIGHTY MO® CABLE MANAGEMENT SYSTEM
The patented Mighty Mo advanced racking system is
specifically designed for higher density cabling system
applications such as data centers, SANs, and main cross
connect areas. It is easy to assemble and offers many
configuration options, extra vertical cable capacity, and
other functional and aesthetic elements. The Mighty Mo
system features an innovative vertical management “cage”
with individual 1-rack unit fingers and a double-hinged
door. Horizontal cable managers, available with covers, are
designed to match the layout of Ortronics® Clarity® patch
panels. Mighty Mo racks and accessories work together
to mount, manage and organize virtually any structured
cabling equipment and provide a unified, streamlined look.
Choose from the new Mighty Mo 10 rack, specifically
designed to improve airflow in data centers, or the
Mighty Mo 6 for standard lAN applications.
nPatented channel construction has built-in strain relief,
bend radius control, and cable routing with floor and
ceiling access to distribution cables
nTop trough with built-in waterfall provides bend radius
control and efficient patch cable routing
n
Vented double hinged front and rear doors are available for
additional security on Mighty Mo 6 and Mighty Mo 10 racks
nCan be assembled as a 19˝ or 23˝ rack. No additional
hardware required; no need for two sizes of racks
nUnless otherwise noted, all Mighty Mo 6 and Mighty
Mo 10 components are compatible with both racks
MIGHTY MO CABLE MANAGEMENT SYSTEM
Mighty Mo 10 Cable Management Racks
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM10716
Mighty Mo 10 Cable
Management Racks
Mighty Mo 10 racks are designed
to maximize the airflow of network
equipment. Honeycomb side rails
and baffles combine to manage
intake and exhaust air, creating cold
aisle/hot aisle air distribution from
side vented equipment. The bottom
flange turns inward, allowing it to fit
on a 2´ x 2´ floor tile. Black.
OR-MM107SVR
Mighty Mo 10 Server Rack
The Mighty Mo 10 Server Rack
works with all of the Mighty Mo 6 and
10 racks and cable management. The
mounting rails adjust from 12.5˝ to 30˝,
independent of the structural members
allowing the rails to be adjusted after
the rack is installed. Mighty Mo vertical
managers can be mounted front or
rear. Black.
PART NO.
DESCRIPTION
OR-MM10716
16.25˝ channel depth, 7´ high,
black, 45 rack units
OR-MM10816
16.25˝ channel depth, 8´ high,
black, 51 rack units
NOTE: Static capacity: 1,500 lbs. Assembly required. Patent pending.
Mighty Mo Speednut
Faster Assembly!
Included with every Mighty Mo
cable management rack! The
Mighty Mo Speednut increases
the speed and ease of assembly
while adding extra strength to your
racks. Hold the Speednut behind
the rack while hand tightening the
bolts in front. Speednut eliminates
the need for a second wrench!
PART NO.
DESCRIPTION
OR-MM107SVR
Four-post aluminum frame,
supplied with 50 #12-24 cage nuts
and screws, 45 rack units, 7´ high
OR-MM107SVRABR
Server rack baffle rail for mounting
16.25˝ airflow baffles to 7´ server
rack when rails are spaced at 30˝
OR-MM108SVR
Four-post aluminum frame,
supplied with 50 #12-24 cage nuts
and screws, 51 rack units, 8´ high
NOTE: Static capacity: 1,500 lbs. (evenly distributed)
Assembly required.
80
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo 10 Rack Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM10VMD712
OR-MM10AB71612
Mighty Mo 10 Cable
Management Cage
with Door
PART NO.
DESCRIPTION
OR-MM10VMD712
With door, 12.13˝ x 13˝ x 7´
Cage design promotes efficient routing
of patch cords between racks. Hinged
doors allow easy access during moves,
adds, and changes. 16˝ wide cage
creates a 12.25˝ gap between racks.
12˝ wide cage creates a 8.25˝ gap
between racks for front-to-back routing
of equipment cables and patch cords.
Both are supplied with four spools and
12 bend-limiting clips. Black.
OR-MM10VMD716
With door, 16.38˝ x 13˝ x 7´
OR-MM10VMD812
With door, 12.13˝ x 13˝ x 8´
OR-MM10VMD816
With door, 16.38˝ x 13˝ x 8´
Mighty Mo 10
Airflow Baffles
Mighty Mo 10 airflow baffles mount
between racks and direct intake and
exhaust air on side flow network
equipment from cold aisle to hot
aisle. Black.
NOTE: All cable managers include hardware necessary to mount the
cage on the face of two Mighty Mo 6 or 10 racks.
Patent Numbers 6,946,605, 6,968,647 and 7,026,553
PART NO.
DESCRIPTION
OR-MM10AB71612
For use with 7´ x 16˝ Mighty Mo 10
rack and 12˝ wide Mighty Mo 10 cage
OR-MM10AB71616
For use with 7´ x 16˝ Mighty Mo 10
rack and 16˝ wide Mighty Mo 10 cage
OR-MM10AB73012
For use with 7´ Mighty Mo 10 Server
Rack and 12˝ wide Mighty Mo 10 cage
when rails are spaced at 30˝ apart
OR-MM10AB73016
For use with 7´ Mighty Mo 10 Server
Rack and 16˝ wide Mighty Mo 10 cage
when rails are spaced at 30˝ apart
OR-MM10AB81612
For use with 8´ x 16˝ Mighty Mo 10
rack and 12˝ wide Mighty Mo 10 cage
OR-MM10AB81616
For use with 8´ x 16˝ Mighty Mo 10
rack and 16˝ wide Mighty Mo 10 cage
OR-MM10AB83012
For use with 8´ Mighty Mo 10 Server
Rack and 12˝ wide Mighty Mo 10 cage
when rails are spaced at 30˝ apart
OR-MM10AB83016
For use with 8´ Mighty Mo 10 Server
Rack and 16˝ wide Mighty Mo 10 cage
when rails are spaced at 30˝ apart
NOTE: Includes all hardware necessary to mount between two
Mighty Mo 10 racks. Not intended for use with Mighty Mo 6
racks. Patent pending.
OR-MM10VDA7248
Mighty Mo 10 Vented
Door Assemblies
Door design allows mounting to
the front or rear of any Mighty Mo 6
or Mighty Mo 10 rack. The doublehinged door pivots to the right or
left and is easily removed. Black.
PART NO.
DESCRIPTION
OR-MM10VDA7248
7´ x 24˝ with 8.38˝ of clearance
behind door for use with
VMD-style vertical managers
OR-MM10VDA7244
7´ x 24˝ with 4.38˝ of clearance
behind door for use without
vertical managers
OR-MM10VDA8248
8´ x 24˝ with 8.38˝ of clearance
behind door for use with
VMD-style vertical managers
OR-MM10VDA8244
8´ x 24˝ with 4.38˝ of clearance
behind door for use without
vertical managers
NOTE: Door designed to work with Mighty Mo racks assembled
in the 19˝ configuration.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
81
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo 10 Rack Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM1070206VCT
Vertical Cable Trays
for Mighty Mo 10
Server Rack
Vertical cable trays consist of a
pre-cut section of 2˝ x 6˝ Cablofil®
cable tray and mounting hardware
designed to mount on the rack and
manage distribution cables routing
from the patch panel and equipment
out of the rack. It mounts to the strut
on the rack and can be adjusted front
to back.
PART NO.
DESCRIPTION
OR-MM1070206VCT
Vertical cable tray 2˝ wide x 6˝
deep for the Mighty Mo 10 7 foot
server rack
OR-MM1080206VCT
Vertical cable tray 2˝ wide x 6˝
deep for the Mighty Mo 10 8 foot
server rack
MIGHTY MO CABLE MANAGEMENT SYSTEM
Mighty Mo 6 Cable Management Racks
OR-MM6710
Mighty Mo 6 Cable
Management Racks
Mighty Mo 6 racks are available
in 6.5˝, 10.5˝ and 16.25˝ channel
depths. The 16.25˝ size is designed
specifically for large and heavy
network equipment. The bottom
flange on the 16.25˝ standard rack
turns inward, allowing it to fit on
a 2´ x 2´ floor tile.
PART NO.
DESCRIPTION
OR-MM6706
6.5˝ channel depth, 7´, high,
black, 45 rack units
OR-MM6710
10.5˝ channel depth, 7´, high,
black, 45 rack units
OR-MM6716
16.25˝ channel depth, 7´, high,
black, 45 rack units
OR-MM6810
10.5˝ channel depth, 8´, high,
black, 51 rack units
OR-MM6816
16.25˝ channel depth, 8´, high,
black, 51 rack units
NOTE: Static capacity 1,500 lbs. Assembly required.
Patent No. D360,189
OR-MM6716
Mighty Mo Speednut
Faster Assembly!
Included with every Mighty Mo
cable management rack! The
Mighty Mo Speednut increases
the speed and ease of assembly
while adding extra strength to your
racks. Hold the Speednut behind
the rack while hand tightening the
bolts in front. Speednut eliminates
the need for a second wrench!
82
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo 6 Vertical Management
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM6VMD710
OR-MM6VMS704
OR-MM6VML706
Mighty Mo 6 Cable
Management Cage
with Door
PART NO.
DESCRIPTION
OR-MM6VMD706
With door, 6˝ x 8˝ x 7´
Cage design promotes efficient
routing of patch cords between
racks. Hinged doors allow easy
access during moves, adds, and
changes. 10˝ wide cage creates a
6.5˝ gap between racks. 6˝ wide
cage creates a 2.5˝ gap between
racks for front-to-back routing of
equipment cables and patch cords.
Both are supplied with four spools
and 12 bend-limiting clips. Black.
OR-MM6VMD710
With door, 10˝ x 13˝ x 7´
OR-MM6VMD806
With door, 6˝ x 8˝ x 8´
OR-MM6VMD810
With door, 10˝ x 13˝ x 8´
NOTE: All cable managers include hardware necessary to mount
the cage on the face of two Mighty Mo 6 racks. The 6˝ wide model
contains gusset brackets and is recommended for a single rack or
end of a row.
Patent Numbers 6,946,605, 6,968,647 and 7,026,553
Mighty Mo 6 Vertical
Cable Management
Cage with Cover
PART NO.
DESCRIPTION
OR-MM6VMS704
With cover, 4˝ x 7˝ x 7´
Cage design promotes efficient routing
of patch cords between racks. Dual
snap on hinged covers allow easy
access during moves, adds, and
changes. 6˝ wide cage creates a 2.5˝
gap between racks for front-to-back
routing of equipment cables and
patch cords. 6˝ wide cage is supplied
with four spools and 12 bend limiting
clips. Black.
OR-MM6VMS706
With cover, 6˝ x 7˝ x 7´
OR-MM6VMS804
With cover, 4˝ x 7˝ x 8´
OR-MM6VMS806
With cover, 6˝ x 7˝ x 8´
NOTE: Includes all hardware necessary to mount cage on face
of two Mighty Mo 6 racks, single rack or end of row.
Patent Numbers 6,946,605 and 7,026, 553
Mighty Mo 6 Vertical
Cable Management
Cage with Latches
PART NO.
DESCRIPTION
OR-MM6VML704
With latches, 4˝ x 6˝ x 7´
Patented design promotes efficient
routing of patch cords between racks.
Hinged latches allow easy access
during moves, adds, and changes.
6˝ wide cage creates a 2.5˝ gap
between racks for front-to-back
routing of equipment cables and
patch cords. Black.
OR-MM6VML706
With latches, 6˝ x 6˝ x 7’
NOTE: Includes all hardware necessary to mount cage on face
of two Mighty Mo 6 racks, single rack or end of row.
Patent No. 6,365,834
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
83
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo Cable Management Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM10WFE
Mighty Mo 10
Waterfall Extension
PART NO.
DESCRIPTION
OR-MM10WFE
Increases the height of the front
flange of the Mighty Mo waterfall
by 2.25˝ when additional cable
capacity is required. Black
NOTE: Fits all Mighty Mo 10, 6 and 3 waterfalls.
OR-60400614
Cable Management Rings
PART NO.
DESCRIPTION
These black plastic rings flex at the
end for easy insertion or removal of
cross connect cables. They snap in
place on the front and back of the
Mighty Mo racks. Black.
OR-60400614
Snap-type, 1.75˝ x 6˝, package of 14
OR-60400542
Snap-type, 1.75˝ x 6˝, package of 2
OR-60400314
Snap-type, 1.75˝ x 3˝, package of 14
OR-60400302
Snap-type, 1.75˝ x 3˝, package of 2
NOTE : No hardware needed.
OR-60400017
OR-MM6CMS8
Cable Management Rings
PART NO.
DESCRIPTION
These rings allow efficient routing
of patch or cross connect cables
between distribution racks. They
can be mounted where needed on
the front and back of the Mighty Mo
racks. Black.
OR-60400017
2˝ x 6˝, package of 14, Black
OR-60400062
2˝ x 6˝, package of 2, Black
Mighty Mo Cable
Management Spools
Cable management spools effectively
manage excess copper or fiber cable
slack. They mount at rack unit
intervals, providing flexibility and
proper bend radius for cables on the
front of the 6˝ wide cage with door or
on the front and rear of the 10˝ wide
cage with door. Set of four. Black.
OR-MM6BLC
Mighty Mo Bend
Limiting Clip
Bend limiting clips snap on to any
finger on the vertical management
cage to provide bend limitation for
fiber jumpers entering and exiting
the cage. Set of 12. Black.
84
NOTE : Includes mounting hardware.
PART NO.
DESCRIPTION
OR-MM6CMS10
11˝ long for 10˝ vertical
management cage with door
OR-MM6CMS8
8˝ long for 10˝ vertical
management cage with door
OR-MM6CMS6
6˝ long for 6˝ vertical
management cage with door
PART NO.
DESCRIPTION
OR-MM6BLC
3.25˝ long for vertical management
cages with door or cover
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo Cable Management Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MM6CBL10
PART NO.
DESCRIPTION
OR-MM6CBL06
For use with Mighty Mo racks
with 6.5˝ channels
OR-MM6CBL10
For use with Mighty Mo racks
with 10.5˝ channels
OR-MM6CBL16
For use with Mighty Mo racks
with 16.25˝ channels
PART NO.
DESCRIPTION
OR-MMPDUMBT
Mighty Mo PDU Mounting
Bracket Kit
PART NO.
DESCRIPTION
OR-60400687
Kit consists of 4 brackets,
8 panel mounting screws and
4 cage mounting screws
Mighty Mo Cable
Runway Mounting
Brackets
PART NO.
DESCRIPTION
OR-MM6CRB06
For rack with 6.5˝ channel depth
Mounts to top of either the
Mighty Mo 6 or Mighty Mo 10 racks.
Provides a mounting location for
6˝–18˝ ladder racking.
OR-MM6CRB10
For rack with 10.5˝ channel depth
OR-MM6CRB16
For rack with 16.25˝ channel depth
OR-MM10CRBSVR
For MM10 server rack
OR-MM10CRBRSVR
For rear of MM10 server rack
PART NO.
DESCRIPTION
OR-MM6BDC06
For 6.5˝ channel standard rack
OR-MM6BDC10
For 10.5˝ channel standard rack
OR-MM6BDC16
For 16.25˝ channel standard rack
Mighty Mo Channel
Bend Limiters
Mighty Mo channel bend limiters
clip onto the top edge of Mighty Mo
channels providing the proper bend
radius for cables entering the
channel. Set of 2. Black.
OR-MMPDUMBT
Mighty Mo PDU
Mounting Bracket Kit
Enables the mounting of toolless
(button mount) PDUs to the side
of a Mighty Mo rack.
OR-60400687
Mighty Mo Vertical
Management Bracket Kit
Vertical management bracket kit
includes 4 brackets and all the
hardware needed to mount 2
Mighty Mo 6 vertical managers
to a standard EIA rack. Black.
OR-MM6CRB06
OR-MM6CRB16
OR-MM6BDC10
OR-MM6CRB10
OR-MM10CRBSVR
OR-MM6BDC16
Mighty Mo Rack
Base Dust Cover
Prevents dust and debris from
accumulating in rack base. Scored
for bending to clear cables from
floor up to channel. Black.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
85
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo Rack Accessories
OR-MM6CEK10
Mighty Mo Runway
Ceiling Extension Kit
Mounts on the top of Mighty Mo 6
racks. The kit extends one channel
24˝ and is supplied with a cover to
hide the cables. Black.
PART NO.
DESCRIPTION
OR-MM6CEK06
For rack with 6.5˝ channel depth, one
per kit with cover
OR-MM6CEK10
For rack with 10.5˝ channel depth,
one per kit with cover
OR-MM6CEK16
For rack with 16.25˝ channel depth, one
per kit with cover
NOTE: Extension uses rack hardware for mounting.
OR-MM6EP710OR-MM6EP706
Mighty Mo End Panel
The end panel is used to finish the
end of a row of Mighty Mo racks. It
mounts flush and provides a surface
for the vertical cable management
channel while concealing cables in
the rack channel. Black.
Standard
For use with 6˝ Mighty Mo 6 vertical cable managers
PART NO.
DESCRIPTION
OR-MM6EP706
For 7´ rack with 6.5˝ channel depth
OR-MM6EP710
For 7´ rack with 10.5˝ channel depth
OR-MM6EP716
For 7´ rack with 16.25˝ channel depth
OR-MM6EP810
For 8´ rack with 10.5˝ channel depth
OR-MM6EP816
For 8´ rack with 16.25˝ channel depth
NOTE: Includes mounting hardware .
Narrow
For use with 4˝ Mighty Mo 6 vertical cable managers*
PART NO.
DESCRIPTION
OR-MM6EPN706
For 7´ rack with 6.5˝ channel
OR-MM6EPN710
For 7´ rack with 10.5˝ channel
OR-MM6EPN716
For 7´ rack with 16.25˝ channel
OR-MM10EPN730
For 7´ Mighty Mo 10 Server
rack rails set at 30˝
OR-MM6EPN810
For 8´ rack with 10.5˝ channel
OR-MM6EPN816
For 8´ rack with 16.25˝ channel
NOTE: Includes mounting hardware.
*To use the narrow end panels with 10˝ or 12˝ vertical managers,
the OR-MM10EPS end support bracket kit must be installed.
OR-MM6CT4RUK
PART NO.
DESCRIPTION
OR-MM10EPS
End panel support bracket kit
Mighty Mo 6 Cable Trough
PART NO.
DESCRIPTION
For supporting fiber cables at the
bottom of Mighty Mo racks. The kit
includes an extension that bridges
the space between racks. Black
OR-MM6CT4RU
Cable trough, 4 rack unit
OR-MM6CT4RUK
Cable trough kit, 4 rack unit
NOTE : Includes mounting hardware.
OR-MMIPK
Mighty Mo Isolation
Pad Kit
PART NO.
DESCRIPTION
OR-MMIPK
Isolation pad kit for Mighty Mo racks
Isolates Mighty Mo racks from
concrete floors for effective
bonding & grounding.
86
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo Horizontal Management
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Ortronics Mighty Mo cable management panels are optimized to organize patch cords vertically and horizontally on Mighty Mo
racks. They will also mount on any standard 19˝ rack. The finger design encourages defined and traceable routing of individual
patch cords.
®
Mighty Mo 6 Horizontal Management Panels
OR-MM6HMF1RU
OR-MM6HMF4RU
OR-MM6HM62RU
OR-MM6HM82RU
OR-MM6HMF2RU
PART NO.
DESCRIPTION
OR-MM6HMF1RU
Multiple fingers, cover, one rack
unit (1.75˝ x 19˝), Black
OR-MM6HMF2RU
Multiple fingers, cover, two rack
units (3.5˝ x 19˝), Black
OR-MM6HMF4RU
Multiple fingers, cover, four rack
units (7.0˝ x 19˝), Black
OR-MM6HM61RU
Six-port finger spacing, cover,
one rack unit (1.75˝ x 19˝), Black
OR-MM6HM62RU
Six-port finger spacing, cover,
two rack units (3.5˝ x 19˝), Black
OR-MM6HM81RU
Eight-port finger spacing, cover,
one rack unit (1.75˝ x 19˝), Black
OR-MM6HM82RU
Eight-port finger spacing, two
rack units (3.5˝ x 19˝), Black
OR-MM6HM61RU
OR-MM6HM81RU
OR-MM6HM6D2RU
Six-port finger spacing, doubleOR-MM6HM6D2RU sided, two rack units (3.5˝ x 19˝),
Black (includes cover)
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
87
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Equipment Shelves for Mighty Mo Racks
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-60400355
Double Equipment Shelves
for Mighty Mo Racks
Ortronics double equipment shelf supports miscellaneous
equipment, test gear, etc. The double shelves work with
Mighty Mo racks with 6.5˝ deep channels. Shelf width is
17˝. Black.
OR-60400517
Double Equipment Shelves
for Mighty Mo Racks
PART NO.
DESCRIPTION
OR-60400355
19˝ x 5.25˝ x 24˝, 150 lbs capacity
OR-60400517
23˝ x 5.25˝ x 24˝, 150 lbs capacity
OR-60400655
19˝ x 5.25˝ x 24˝, 150 lbs capacity
NOTE: Shelf is slotted to accept the Ortronics monitor strap kit
OR-70700126. Includes #12-24 mounting hardware.
Ortronics double equipment shelf supports miscellaneous
equipment or test gear. The double shelf works with
Mighty Mo racks with 6.5˝ deep channels when assembled
in a 23˝ configuration. Shelf width is 21.37˝. Black.
OR-60400655
Double Equipment Shelves
for Mighty Mo Racks
Ortronics extra width double equipment shelf is 18.75˝
wide in front and back; usable width between mounting
flanges is 17.5˝. This shelf works with Mighty Mo racks
with 6.5˝ deep channels. Black.
OR-604045681
Four Point Equipment Shelf for
Mighty Mo Racks and Cabinets
Ortronics four point equipment shelf supports
miscellaneous equipment or test gear. The one unit
shelf works with Mighty Mo racks with all depth
channels and Mighty Mo cabinets 24˝ and deeper.
Shelf is 17.25˝ wide. Black.
OR-60400538
Mighty Mo Server Rack
Equipment Shelf
The Mighty Mo server rack equipment shelf has a fixed
front flange with an infinitely adjustable rear flange that
allows for secure four point mounting as deep as 30˝.
Shelf width is 17.25˝. Black.
OR-70700126
88
PART NO.
DESCRIPTION
OR-604045681
19˝ x 1.72˝ x 20˝, 100 lbs capacity
NOTE: Shelf is slotted to accept the Ortronics monitor strap kit
OR-70700126. Includes #12-24 mounting hardware.
PART NO.
DESCRIPTION
OR-60400538
19˝ x 1.7˝ x 30˝, 200 lbs capacity
NOTE: Shelf is slotted to accept the Ortronics monitor strap kit
OR-70700126. Includes #12-24 mounting hardware.
Mighty Mo Monitor Strap Kit
PART NO.
DESCRIPTION
The monitor strap kit consists of hook and loop straps
which can secure a monitor with a base of any size
or shape to all equipment shelves on this page.
The monitor screen remains fully adjustable. Black.
OR-70700126
Hook and loop type strap kit
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABLE MANAGEMENT SYSTEM
Mighty Mo Overhead Cable Pathway Rack
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Mighty Mo overhead cable pathway racks provide cable management and an innovative mounting method for 19˝ rack mount
copper and fiber panels and fiber cabinets. The pathway racks allow horizontal connectivity to be supported by the overhead
pathway freeing up valuable rack or cabinet space below.
OR-60401001
Mighty Mo Overhead
Cable Pathway Rack
The Mighty Mo overhead cable
pathway racks come with everything
needed to mount the bracket to the
side of Homaco runway with 1-1/2˝
stringers or any Cablofil cable tray 2˝
or deeper. Black.
PART NO.
DESCRIPTION
OR-60401001
2 rack units, 23.6˝ W x 7.4˝ H x 9˝ D,
90 lbs. capacity
OR-60401015
5 rack units, 23.6˝ W x 12.6˝ H x 9˝ D,
90 lbs. capacity
OR-60401089
8 rack units,23.6˝ W x 18.1˝ H x 9˝ D,
90 lbs. capacity
MIGHTY MO CABLE MANAGEMENT
SYSTEM Mighty Mo Telecom Enclosure
The Mighty Mo telecom enclosure combines advanced cable management with security
and flexibility to change the way you bring high performance to the desktop. Based on
the foundation of Mighty Mo technology, the telecom enclosure provides capacity for
both active and passive equipment and can support up to 48 users.
OR-MMTECSG22
OR-MMTECFCBP
Mighty Mo Ceiling Mount
Telecom Enclosure
The Mighty Mo ceiling mount telecom
enclosure has a unique patent pending
swing gate design that allows for easy
access to patching and equipment by
simply opening the front cover. The
swing-out access supports easy
re-termination and includes dampening
cylinders to control the speed of opening.
The attractive exterior blends well with
office decor and a lockable front door
provides security and protection in public
areas. Built-in cable management
supports and organizes cables, ensuring
proper bend radius. Approved to UL-2043
for use in air handling spaces.
PART NO.
OR-MMTECSG22
DESCRIPTION
Mighty Mo telecom enclosure,
ceiling mount, 23.50˝ W x 23.50˝
H x 20.61˝ D, 10 rack units, 80 lbs.
capacity, Beige.
PART NO.
DESCRIPTION
OR-MMTECFCBP
Plate Kit - includes Fan Plate with
100 CFM fan, guard, 3 ft. cord
with plug, Cable Brush Plate, and
mounting hardware, Black.
OR-MMTECFSP
Fire Stop Cable Plate Kit includes
intumescent foam and mounting
hardware. Set of 2, Beige.
PART NO.
DESCRIPTION
OR-MMTEHMR2RU
Cable management panel for the
Mighty Mo telecom enclosure,
19.00˝ W x 3.47˝ H x 6.75˝ D,
2 rack units.
OR-MMTECFSP
OR-MMTEHMR2RU
Cable Management Panel
Double-sided cable management panel
with front rings to manage patch cords
and a rear trough with slots to protect
and route terminated cables.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
89
STANDARD EIA RACK
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Ortronics® 19˝ self supporting EIA rack is used for mounting a variety of telecommunications and data equipment. It consists
of two U-channel type uprights 7’ high, two base and two top support angle cross members, and is constructed of aluminum.
OR-604004600*
Self Supporting
EIA Racks
Ortronics standard EIA self supporting
rack with Mighty Mo universal pattern
uprights, extruded base angles and
top angles. Tapped EIA pattern front
and rear and supplied with 50 #12-24
pilot point mounting screws. Top
flange is pre-punched to accept
6˝-18˝ ladder racking. Assembly
required. Black.
OR-DVMS706
Standard Vertical Cable
Management Cage
with Cover
Mounts to the side of a standard
EIA rack. The fingers are spaced
to line up with rack units, promoting
efficient routing of patch cords
to patch panels and equipment
from the vertical manager. Dual
snap on hinged covers allow easy
access during moves, add, and
changes. Available in single-sided
and double-sided versions.
NOTE: Includes all hardware necessary to
mount to the side of a standard EIA rack.
90
PART NO.
DESCRIPTION
OR-604004600*
19˝ W x 7´ H, 44 rack units
* OR-604004600 standard rack is UL listed.
NOTE: Ortronics standard EIA rack is pre-drilled to accept
side mounting of all Mighty Mo vertical managers.
®
Single-sided
PART NO.
DESCRIPTION
OR-SVMS704
3.75˝ x 6.58˝ x 7´, single-sided
OR-SVMS706
6.00 ˝ x 6.58˝ x 7´, single-sided
OR-SVMS804
3.75˝ x 6.58˝ x 8´, single-sided
OR-SVMS806
6.00 ˝ x 6.58˝ x 8´, single-sided
Double-sided
PART NO.
DESCRIPTION
OR-DVMS704
3.75˝ x 13.17 ˝ x 7´, double-sided
OR-DVMS706
6.00 ˝ x 13.17 ˝ x 7´, double-sided
OR-DVMS804
3.75˝ x 13.17 ˝ x 8´, double-sided
OR-DVMS806
6.00 ˝ x 13.17 ˝ x 8´, double-sided
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
EUROLINE CABINETS
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
The Ortronics® EuroLine cabinets are designed to fit your
environment. EuroLine cabinets provide a secure housing for
your network and are made with a sturdy steel construction
for a high load carrying capacity. Heights range from
16U–47U, widths range from 600–800mm, and depths
range from 600–1000mm.
Features
n19˝ mounting angles 4ea. = (front/2 ea and back/2 ea)
allow for flexible configuration and adjustable depth
n 4 way access to equipment
nQuick release/lockable, removable side doors c/with
slam latches and locks
n Powder coat paint finish RAL 9005
n Leveling feet is included as a standard feature
nSecure, locking front and back doors with spring loaded
hinges offer best accessibility even when connecting
the cabinets
n Vented top panel
nGenerous cable access
nEasy mounting, fast assembly
n Grounding kit for door connections are given as standard
nRigid welded frame construction. Corner of bases have
welded sockets on each corner that tightly fixed into the
columns five maximum stability
nReversible doors: the door hinge is easily swapped from
one side to the other
PART NO.
DESCRIPTION
19˝ Free Standing
Network Cabinets
OR-EUCN22U66
22U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
These cabinets are manufactured
in Europe, for the EMEA market.
OR-EUCN26U66
26U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
They are all preconfigured cabinets,
with only some door options
as indicated.
OR-EUCN32U66
32U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN36U66
36U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN42U66
42U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN47U66
47U 19˝ 600x600mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN22U68
22U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN26U68
26U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN32U68
32U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN36U68
36U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN42U68
42U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN47U68
47U 19˝ 600x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN32U88
32U 19˝ 800x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN36U88
36U 19˝ 800x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN42U88
42U 19˝ 800x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
OR-EUCN47U88
47U 19˝ 800x800mm Free Standing
Cabinet RAL 9005 Black MOUNTED
n
n
n
n
n
Front door features a full length
smoked and shatterproof glass
door (t=4mm) reinforced with
decorative metal frame
Turning lever lock and single
point locking mechanism
Frames are made with 24 fold
design for increased stability
Rubber edge sliding cover
mechanism protects cables
both on roof and bottom frames
Lockable, removable solid rear
door with single point barrel
locking mechanism
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
91
EUROLINE CABINETS
Server Cabinets
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
19˝ Free Standing
Server Cabinets
n
n
n
n
n
n
Front door features a full length 63% vented
split-double opening monoblock front door
Turning lever lock and three point locking
mechanism in front door
Frames are made with 36 fold design for
increased stability with 6ea. main uprights
Multiple cable entry points provide
maximum versatility
Rubber edge sliding cover mechanism protects
cables both on roof and bottom frames
Split rear door - double opening,full length 63%
vented, lockable, removable, with three point
locking mechanism with a turning lever lock
PART NO.
DESCRIPTION
OR-EUCS26U610
26U 19˝ 600x1000mm
RAL 9005 Black MOUNTED
OR-EUCS36U610
36U 19˝ 600x1000mm
RAL 9005 Black MOUNTED
OR-EUCS42U610
42U 19˝ 600x1000mm
RAL 9005 Black MOUNTED
OR-EUCS47U610
47U 19˝ 600x1000mm
RAL 9005 Black MOUNTED
OR-EUCS42U810
42U 19˝ 800x1000mm
RAL 9005 Black MOUNTED
OR-EUCS47U810
47U 19˝ 800x1000mm
RAL 9005 Black MOUNTED
EUROLINE CABINETS
Wall Mount Cabinets
19˝ Wall Mounting Cabinets
19˝ wall mounting cabinets provide an economic solution for
cabling installations. This series of wall mount cabinets is used
in offices where a reduced amount of U height is required. The
esthetics create a pleasing and professional look.
n
n
n
n
n
n
n
n
n
n
n
n
n
92
Front door features a full length smoked and shatterproof
glass door (t=4mm) reinforced with decorative metal frame
19˝ mounting angles 2ea. in front and adjustable in depth
Generous cable access; multiple cable entry points provide
maximum versatility; rubber edge sliding cover mechanism
protects cables either on roof or bottom cases where cable
enters, the reverse side is being closed by dummy PVC plate
3 way access to equipment
Powder coat paint finish RAL 9005
Front door and side panels with Master lock key
Vented top panel for passive ventilation; Fan Modules units
can be installed for forced ventilation
Opening in 180° front door
Rear panel can be used as mounting plate
Grounding cable kit for door connections are given
as standard
Powder coat paint finish RAL 9005
Sturdy steel construction
Easy mounting, fast assembly
PART NO.
DESCRIPTION
OR-EUCWF7U45
7U 19˝ 600x470mm, RAL 9005 Black,
opening side panels
OR-EUCWF9U45
9U 19˝ 600x470mm, RAL 9005 Black,
opening side panels
OR-EUCWF12U45
12U 19˝ 600x470mm, RAL 9005 Black,
opening side panels
OR-EUCWF16U45
16U 19˝ 600x470mm, RAL 9005 Black,
opening side panels
OR-EUCWF20U45
20U 19˝ 600x470mm, RAL 9005 Black,
opening side panels
OR-EUCWF7U56
7U 19˝ 600x580mm, RAL 9005 Black,
opening side panels
OR-EUCWF9U56
9U 19˝ 600x580mm, RAL 9005 Black,
opening side panels
OR-EUCWF12U56
12U 19˝ 600x580mm, RAL 9005 Black,
opening side panels
OR-EUCWF16U56
16U 19˝ 600x580mm, RAL 9005 Black,
opening side panels
OR-EUCWF20U56
20U 19˝ 600x580mm, RAL 9005 Black,
opening side panels
OR-EUCWPF7U61
7U 19˝ 600x(470+160) mm double section cabinet,
RAL 9005 Black, opening side panels, load
capacity 100kgs
OR-EUCWPF9U61
9U 19˝ 600x(470+160) mm double section cabinet,
RAL 9005 Black, opening side panels, load
capacity 100kgs
OR-EUCWPF12U61
12U 19˝ 600x(470+160) mm double section
cabinet, RAL 9005 Black, opening side panels,
load capacity 100kgs
OR-EUCWPF16U61
16U 19˝ 600x(470+160) mm double section
cabinet, RAL 9005 Black, opening side panels,
load capacity 100kgs
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
EUROLINE CABINETS
Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Shelves
OR-EUCSHELFRM25
PART NO.
DESCRIPTION
OR-EUCSHELFFSB35
Fixed shelf 19˝ front: 1U - 1U adjustable sliding
bracket at back depth = 350mm. RAL 9005
BLACK
OR-EUCSHELFFSB45
Fixed shelf 19˝ front: 1U - 1U adjustable sliding
bracket at back depth = 450mm. RAL 9005
BLACK
OR-EUCSHELFFSB55
Fixed shelf 19˝ front: 2U - 1U adjustable sliding
bracket at back depth = 550mm. RAL 9005
BLACK
OR-EUCSHELFFSB65
Fixed shelf 19˝ front: 2U - 1U adjustable sliding
bracket at back depth = 650mm. RAL 9005
BLACK
OR-EUCSHELFF60
Fixed shelf suitable for cabinets depth=600mm.
RAL 9005 BLACK slotted
OR-EUCSHELFF80
Fixed shelf suitable for cabinets
depth = 800mm. RAL 9005 BLACK slotted
OR-EUCSHELFF10
Fixed shelf suitable for server cabinets
depth = 1000mm. RAL 9005 BLACK
OR-EUCSHELFRM25
19˝ 1U fixed - cantilever shelf depth = 250mm.
RAL 9005 BLACK slotted
OR-EUCSHELFRM30
19˝ 1U fixed - cantilever shelf depth = 300mm.
RAL 9005 BLACK slotted
OR-EUCSHELFRM35
19˝ 2U fixed - cantilever shelf depth = 350mm.
RAL 9005 BLACK slotted
OR-EUCSHELFS60
Sliding shelf suitable for cabinets
depth=600mm. RAL 9005 BLACK slotted
OR-EUCSHELFS80
Sliding shelf suitable for cabinets
depth = 800mm. RAL 9005 BLACK slotted
OR-EUCSHELFS10
Sliding shelf suitable for server cabinets
depth = 1000mm. RAL 9005 BLACK slotted with
rear cable management system
OR-EUCSHELFS10
OR-EUCSHELFS60
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
93
EUROLINE CABINETS
Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-EUCCMP1U
OR-EUCSFANT4
94
Cable Management
Fans
PART NO.
DESCRIPTION
OR-EUCCMP1U
Cable management panel 19˝ 1U
5 rings RAL 9005 BLACK
OR-EUCCMPCH1U
Cable management panel 19˝ 1U
trunking with cover RAL 9005 BLACK
OR-EUCCMR
45x60 cable management ring
RAL 9005 BLACK 1 Set = 5pcs
OR-EUCNVML32U
32U vertical cable management panel
for 32U 80x80 cabinets
OR-EUCNVML36U
36U vertical cable management panel
for 36U 80x80 cabinets
OR-EUCSVML42U
42U vertical cable management panel
for 42U 80x80 cabinets
OR-EUCNVML47U
47U vertical cable management panel
for 47U 80x80 cabinets
OR-EUCSVML42U
42U vertical cable management panel
for 42U 80x100 server cabinets
OR-EUCSVML47U
47U vertical cable management panel
for 42U 80x100 server cabinets
PART NO.
DESCRIPTION
OR-EUCNFANT2
Cooling unit with 2 fans for free
standing cabinets 220V RAL 9005
BLACK incl Thermostat
OR-EUCNFANT4
Cooling unit with 4 fans for free
standing cabinets 220V RAL 9005
BLACK incl Thermostat
OR-EUCWFANT1
Cooling unit with 1 fan for wall
mounting cabinets 220V RAL 9005
BLACK incl Thermostat
OR-EUCWFANT2
Cooling unit with 2 fan for wall
mounting cabinets 220V RAL 9005
BLACK incl Thermostat
OR-EUCRMFANT1U2
19˝ 1U cooling unit with 2 fans 220V
RAL 9005 BLACK incl Thermostat
OR-EUCRMFANT1U4
19˝ 1U cooling unit with 4 fans 220V
RAL 9005 BLACK incl Thermostat
OR-EUCSFANT4
Cooling unit with 4 fans for free
standing server cabinets 220V
RAL 9005 BLACK incl Thermostat
OR-EUCSFANT6
Cooling unit with 6 fans for free
standing server cabinets 220V
RAL 9005 BLACK incl Thermostat
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
EUROLINE CABINETS
Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-EUCLIGHT
OR-EUCWCAS
PART NO.
DESCRIPTION
OR-EUCSSR60
L support slide rail enclosure depth = 600mm.
Zinc plated
OR-EUCSSR80
L support slide rail enclosure depth = 800mm.
Zinc plated
OR-EUCSSR10
L support slide rail enclosure depth = 1000mm.
Zinc plated
OR-EUCNDRAW3U
19˝ 3U drawer RAL 9005 BLACK
OR-EUCNKDRAW1U
19˝ 1U keyboard drawer RAL 9005 BLACK
OR-EUCPS6S
19˝ Power strip 6 way with miniature circuit
breaker schuko type Aluminium Profile
OR-EUCNCAS
Castor group for free standing cabinets
OR-EUCWCAS
Castor group for wall mount racks
(one point fixing single wheel)
OR-EUCCN20
m6 caged nut, screw and fastener
(1set = 20pcs.)
OR-EUCCN50
m6 caged nut, screw and fastener
(1set = 50pcs.)
OR-EUCLIGHT
Lighting fixture automatic 220V with door switch
OR-EUCNLIGHT
Lighting fixture manual 220V with on/off switch
OR-EUCGKECB
Grounding kit and Equalization Copper Busbar
OR-EUCBP1U
Blank panel 1U 19˝ RAL 9005 BLACK
OR-EUCBP2U
Blank panel 2U 19˝ RAL 9005 BLACK
OR-EUCBP3U
Blank panel 3U 19˝ RAL 9005 BLACK
OR-EUCBP4U
Blank panel 4U 19˝ RAL 9005 BLACK
OR-EUCBP5U
Blank panel 5U 19˝ RAL 9005 BLACK
OR-EUCBP6U
Blank panel 6U 19˝ RAL 9005 BLACK
OR-EUCBPV1U
Blank panel 1U 19˝ vented RAL 9005 BLACK
OR-EUCBPV2U
Blank panel 2U 19˝ vented RAL 9005 BLACK
OR-EUCBASE66
Plinth 600x647mm. RAL 9005 BLACK
For use with 600x600mm cabinet frame
OR-EUCBASE68
Plinth 600x827mm. RAL 9005 BLACK
For use with 600x800mm cabinet frame
OR-EUCBASE88
Plinth 780x827mm. RAL 9005 BLACK
For use with 800x800mm cabinet frame
OR-EUCBAY
Baying Kit for Server cabinets, Free standing
cabinets Unique Type RAL 9005 BLACK
OR-EUCNDRAW3U
OR-EUCGKECB
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
95
MIGHTY MO® CABINETS
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Enhanced Cable Management with Superior Airflow
A solid foundation is critical for superior network performance in high density
applications. A poorly designed physical support system can have a devastating
®
effect on the performance of the network. Ortronics engineers have strategically
designed Mighty Mo cabinets from the ground up to protect network integrity.
Cable management is not just an add-on accessory, it is the basis for our design.
Ortronics’ full line of free standing cabinets specifically addresses the cable management needs of today’s
high performance networks by:
■■
Purposefully repositioning the caster rails out of the cable pathway
■■
Properly routing the cables to minimize bends and turns, reducing the number of failure points
■■
Effectively managing entry and exit points from within the cabinet frame
Offering advanced features such as bend limiting clips that snap on the rack unit spaced fingers
where needed to protect fiber jumpers
■■
The Mighty Mo cabinet is also ideal for maintaining cold-aisle/hot aisle airflow, whether your network equipment
is front-to-back, bottom or side venting. Mighty Mo cabinet air flow baffles provide separation of hot and cold
aisles and redirect air flow from side vented equipment so it matches the front to back airflow of servers.
Features:
HEAVY DUTY CONSTRUCTION: Heavy-duty 14 ga. construction
offers improved durability over conventional 16 ga. cabinets.
Mighty Mo doors are especially designed to eliminate the irritating
flex found in less well built cabinets.
■■
CABLE MANAGEMENT: Mighty Mo vertical and horizontal managers
provide improved management for both servers and high density
switches. Available bend limiters provide standards compliant protection
for fiber and 10G copper patch cords.
■■
PASSIVE THERMAL MANAGEMENT: Mighty Mo baffles redirect the
airflow of side vented equipment from front to rear ensuring the proper
flow of air from cold aisle to hot aisle.
■■
THERMAL PROTECTION: A wide selection of top panels, fans and
doors are available to ensure adequate ventilation is provided to keep
equipment at the optimal operating conditions.
■■
SECURITY: Doors include locking handles to prevent unauthorized
access and tampering. Side panels also come equipped with locks.
■■
MOBILITY: Levelers come standard with frames. Swivel casters are
optional for added mobility.
■■
180° DOOR SWING WITH SELF-CONTAINED HINGES: Self-contained
hinges used on our surface mount doors have no removable pins that
can be lost. These hinges eliminate aisle blockage when loading or
performing maintenance on equipment without removing the door.
■■
FULLY CONFIGURABLE: Mighty Mo cabinets are built to your configuration
and arrive fully assembled with all components installed and accessories included,
reducing equipment deployment time and overall costs. Consult your local
representative to configure a cabinet to your unique requirements.
96
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Pre-Configured Cabinets
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Ortronics has assembled some of the most popular cabinet sizes and accessories together into easy to order part numbers.
Pre-Configured
Server Cabinets
PART NO.
Divider Version
PART NO.
Side Panels Version
DESCRIPTION
Server Cabinet Sizes
MMC422440-00005 MMC422440-00006
42RU x 24˝ wide x 42˝ deep
MMC422446-00002 MMC422446-00003
42RU x 24˝ wide x 48˝ deep
Two pairs of RU labeled mounting
rails with 3/8˝ square holes
MMC472440-00003 MMC472440-00004
47RU x 24˝ wide x 42˝ deep
■■
Full profile mesh front door
MMC472446-00001 MMC472446-00002
47RU x 24˝ wide x 48˝ deep
■■
Split flat mesh rear door
■■
MMC423240-0000G MMC423240-0000H
42RU x 32˝ wide x 42˝ deep
MMC423246-00007 MMC423246-00008
42RU x 32˝ wide x 48˝ deep
MMC473240-00003 MMC473240-00004
47RU x 32˝ wide x 42˝ deep
MMC473246-00001 MMC473246-00002
47RU x 32˝ wide x 48˝ deep
Frame configured with cable
opening at bottom rear
■■
Frame levelers
■■
■■
Two “L” shaped finger managers
on rear rails
■■
Vertical PDU mount and lacing bar
■■
Divider or side panels as stated
to the right
■■
Solid top panel in front
■■
Cable entry top panel in rear
■■
Rack unit cage nuts #12-24
thread (package of 50)
■■
Two packages of 50 panel
mounting screws #12-24
(total of 100)
Additional adhesive rack unit labels
(mounted inside of rear set of rails)
■■
Black powder coat paint
■■
Pre-Configured
Network Cabinets
Frame configured with cable
opening at bottom front
■■
Frame levelers
■■
Two pairs of RU labeled mounting
rails with #12-24 tapped holes
■■
Full profile plexiglas front door
■■
Full flat solid rear door
■■
Two “L” shaped finger managers
on front rails
■■
Right and left locking side panels
■■
Fan top panel in front
■■
Cable entry top panel in rear
■■
Package of 50 panel mounting
screws #12-24
■■
Black powder coat paint
■■
“Divider” versions have a right side divider panel and ganging hardware (for within row).
“Side Panels” versions have a set of end panels (for stand alone or to create
ends of row).
PART NO.
DESCRIPTION
MMC422434-00004
42RU x 24˝ W x 36˝ D
MMC423234-0000A
42RU x 32˝ W x 36˝ D
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
97
MIGHTY MO® CABINETS
Mighty Mo Pre-Configured Cabinets
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
The Mighty Mo cabinets are designed around industry leading cable management systems that provide above the
standard performance and capabilities for handling and supporting Cisco Nexus 7010 Data Center Switches.
Pre-Configured Cabinets
for the Nexus 7010
Frame configured with cable
opening at bottom front
■■
Frame levelers
■■
Two pairs of RU labeled mounting
rails with #12-24 tapped holes
■■
■■
■■
Full profile perforated front door
and split flat mesh rear door
Pre-Configured Mighty Mo Cabinets with Air Dam Kit
PART NO.
DESCRIPTION
OR-MMC423240-0001J
42RU x 32˝ wide x 42˝ deep, black
OR-MMC423246-00016
42RU x 32˝ wide x 48˝ deep, black
OR-MMC473240-0000L
47RU x 32˝ wide x 42˝ deep, black
OR-MMC473246-0000H
47RU x 32˝ wide x 48˝ deep, black
Two “L” shaped finger managers
on front rails with 12 bend limiters
Mighty Mo Cabinet Air Dam Kits
for the Nexus 7010
■■
*Right side removed to
show interior of cabinet
■■
Right and left locking side panels
■■
Cable entry top panel on front and
rear with brush guards on front
Package of 50 panel mounting
screws #12-24
■■
Black powder coat paint
■■
98
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MMC42VPMLS,
OR-MMC42VPMLD
Vertical PDU
Mount and lacing Bars
Vertical PDU mount and lacing bars can
be used to mount PDUs or to manage
distribution cables routing from patch
panels and equipment out of the cabinet.
OR-MMC420206VCT
Vertical Cable Trays
Vertical cable trays consist of a
pre-cut section of 2˝ x 6˝ Cablofil tray
and mounting hardware designed to
mount inside the cabinet and manage
distribution cables routing from the patch
panels and equipment out of the cabinet.
It mounts to the strut inside the cabinet
and can be adjusted front to back.
®
PART NO.
DESCRIPTION
OR-MMC24VPMLS
Vertical PDU Mount and Lacing Bar
Single for 24U Frames
OR-MMC42VPMLS
Vertical PDU Mount and Lacing Bar Single
for 42U Frames
OR-MMC47VPMLS
Vertical PDU Mount and Lacing Bar Single
for 47U Frames
OR-MMC24VPMLD
Vertical PDU Mount and Lacing Bar Double
for 24U Frames
OR-MMC42VPMLD
Vertical PDU Mount and Lacing Bar Double
for 42U Frames
OR-MMC47VPMLD
Vertical PDU Mount and Lacing Bar
Double for 47U Frames
PART NO.
DESCRIPTION
OR-MMC420206VCT
Vertical Cable Tray 2˝ Wide X 6˝ Deep
for 42U Frames
OR-MMC470206VCT
Vertical Cable Tray 2˝ Wide X 6˝ Deep
for 47U Frames
Horizontal Cable Capacities for Vertical Cable Tray
USABLE
AREA
(SQ. IN.)
24 CNT
BUNDLE
CABLE
VERTICAL CABLE
TRAY CAPACITY
Cat 5e
Cat 6
Cat 6a
O.D. (in.)
1.125˝
1.25˝
1.625˝
PART NO.
DESCRIPTION
OR-MMC420206VCT
Vertical Cable Tray 2 ˝ Wide X 6 ˝ Deep for 42U
Frames
14
240
168
96
OR-MMC470206VCT
Vertical Cable Tray 2 ˝ Wide X 6 ˝ Deep for 47U
Frames
14
240
168
96
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
99
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MMCCTMB12-B
Cable Tray
Mounting Brackets
Cable tray mounting brackets mount
to the top of the cabinet and utilize
the Cablofil® FAS method to attach
cable tray without additional hardware.
Cable tray mounting brackets can be
used alone or with the cable troughs.
The mounting brackets are designed
to maintain an even height when using
Mighty Mo racks and cabinets together.
The 42U cabinet frame will line up
with the 7´ rack and the 47U cabinet
frame will line up with the 8´ rack.
Cable tray mounting brackets for 42U frames
PART NO.
DESCRIPTION
OR-MMCCTMB06-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
6˝ wide tray, Basic Black
OR-MMCCTMB12-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
12˝ wide tray, Basic Black
OR-MMCCTMB18-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
18˝ wide tray, Basic Black
NOTE: Replace ‘B’ with ‘G’ for Cool Gray.
Cable tray mounting brackets for 47U frames
PART NO.
DESCRIPTION
OR-MMCCTMB4706-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
6˝ wide tray, Basic Black
OR-MMCCTMB4712-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
12˝ wide tray, Basic Black
OR-MMCCTMB4718-B
Cable Tray Mounting Bracket with
Cablofil FAS style attachment for
18˝ wide tray, Basic Black
NOTE: Replace ‘B’ with ‘G’ for Cool Gray.
OR-MMC2412CTCE-B
Cable Troughs
PART NO.
DESCRIPTION
Cable troughs mount on top of the
cabinet frame and provide integrated
overhead routing for cable. They are
sized and pre-punched to interface
with 6˝, 12˝ and 18˝ Cablofil cable
tray directly, or can be used with
the cable tray mounting bracket.
OR-MMC2406CTCE-B
Cable Trough, Center Exit, 6˝
Wide for 24˝ W Frames, Basic Black
OR-MMC2412CTCE-B
Cable Trough, Center Exit, 12˝
Wide for 24˝ W Frames, Basic Black
OR-MMC2418CTCE-B
Cable Trough, Center Exit, 18˝
Wide for 24˝ W Frames, Basic Black
OR-MMC3206CTCE-B
Cable Trough, Center Exit, 6˝
Wide for 32˝ W Frames, Basic Black
OR-MMC3212CTCE-B
Cable Trough, Center Exit, 12˝
Wide for 32˝ W Frames, Basic Black
OR-MMC3218CTCE-B
Cable Trough, Center Exit, 18˝
Wide for 32˝ W Frames, Basic Black
NOTE: Replace ‘B’ with ‘G’ for Cool Gray.
Cable Trough
Panel Brackets
Cable trough panel brackets mount to
the underside of the cable trough and
provide 3RU of 19˝ mounting space.
PART NO.
DESCRIPTION
OR-MMC243UCTPB-B
Cable Trough Panel Bracket, 3U for use
with 24˝ wide cabinets, Basic Black
OR-MMC323UCTPB-B
Cable Trough Panel Bracket, 3U for use
with 32˝ wide cabinets, Basic Black
NOTE: Replace ‘B’ with ‘G’ for Cool Gray.
100
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
MMCCRMB12-B
Cable Runway
Mounting Brackets
Cable runway mounting brackets mount
to the top of the cabinet and provide a
surface for attaching 6˝, 12˝, 18˝ or 24˝
wide runway. The mounting brackets
are designed to maintain an even
height when using Mighty Mo racks and
cabinets together. The 42U frame will
line up with the 7´ racks and the 47U
frame will line up with the 8´ racks.
Cable runway mounting brackets for 42U frames
PART NO.
DESCRIPTION
OR-MMCCRMB06-B
Cable Runway Mounting Bracket for
6˝ wide runway, Basic Black
OR-MMCCRMB12-B
Cable Runway Mounting Bracket for
12˝ wide runway, Basic Black
OR-MMCCRMB18-B
Cable Runway Mounting Bracket for
18˝ wide runway, Basic Black
OR-MMCCRMB24-B
Cable Runway Mounting Bracket for
24˝ wide runway on 42U Frames,
Basic Black
NOTE: Replace ‘B’ with ‘G’ for Cool Gray.
Cable runway mounting brackets for 47U frames
OR-MMCMBK
OR-RU-1224CN
OR-MMCUN-1420-10
Hardware
The Ortronics® line of cabinet
hardware provides the products
needed to complete your installation.
Rack Unit Cage Nuts enable easy
and quick installation of three cage
nuts simultaneously.
PART NO.
DESCRIPTION
OR-MMCCRMB4706-B
Cable Runway Mounting Bracket for
6˝ wide runway, Basic Black
OR-MMCCTMB4712-B
Cable Runway Mounting Bracket
for 12˝ wide runway, Basic Black
OR-MMCCTMB4718-B
Cable Runway Mounting Bracket
for 18˝ wide runway, Basic Black
OR-MMCCTMB4724-B
Cable Runway Mounting Bracket
for 24˝ wide runway, Basic Black
PART NO.
DESCRIPTION
OR-60400533
Panel Mounting Screw, #12-24 x
.625˝, package of 50, Basic Black
OR-PS-M6X1-50
Panel Mounting Screw, M6X1 x
.625˝ long, package of 50, Clear
OR-RU-1224CN
Rack Unit Cage Nuts, #12-24
thread, package of 50, Clear
OR-RU-M6X1CN
Rack Unit Cage Nuts, M6X1
thread, package of 50, Clear
OR-PS-1224CN
Single Hole Cage Nuts, #12-24
thread, package of 50, Clear
OR-PS-M6X1CN
Single Hole Cage Nuts, M6X1
thread, package of 50, Clear
OR-MMCCNTOOL
Cage Nut Installation Tool
OR-MMCMBK
ORMMCUN-1420-10
Multi-Bay Hardware Kit,
6 each 1/4-20 bolts and nuts
Unistrut® Hardware Kit, 10 each
1/4-20 bolts and Unistrut nuts
OR-MMCRULBL-60-A
Adhesive Rack Unit Label,
60RU length
OR-MM6BLC
Mighty Mo Bend Limiting Clip,
3.25˝ long, snaps onto fingers
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
101
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MMCLVL-IP
OR-MMCDR2-1915
Levelers/Isolation
PART NO.
Levelers come standard with the cabinet
frame; however, additional parts may be
ordered. Isolation bushings are used to
isolate the anchoring hardware from the
frame of the cabinet.
OR-MMCLVL-IP
OR-MMCISOB-50
Isolation Bushing for 1/2˝ Hardware,
Quantity: 4
Shelves & Drawers
PART NO.
DESCRIPTION
Ortronics offers a full range of sturdy
equipment shelves and drawers to
protect and support valuable
equipment. Mounting hardware is
included. Basic black
OR-MMCCSS1-1912
Cantilevered Shelf, 1U, Solid, Steel,
19˝ x 12˝ D
OR-MMCCSS2-1915
Cantilevered Shelf, 2U, Solid, Steel,
19˝ x 15˝ D
OR-MMCCSS3-1915
Cantilevered Shelf, 3U, Solid, Steel,
19˝ x 15˝ D
OR-MMCCSV1-1912
Cantilevered Shelf, 1U, Vented, Steel,
19˝ x 12˝ D
OR-MMCCSV2-1915
Cantilevered Shelf, 2U, Vented, Steel,
19˝ x 15˝ D
OR-MMCCSV3-1915
Cantilevered Shelf, 3U, Vented, Steel,
19˝ x 15˝ D
OR-MMCFSV-1926
19˝ x 26˝ Deep, 4-point rackmount
vented fixed shelf
OR-MMCSSVL-1924
Sliding Shelf, 19˝ EIA, 24˝ D Vented,
4 Point, 100lb load rated
OR-MMCISOB-38
OR-MMCSSVM-1924
OR-MMCSSVH-1930
OR-MMCFPS-2-B
Filler Panels
Improve network performance with
improved separation of the hot and
cold aisle utilizing filler panels to
control airflow.
OR-MMCFANP19-4-2
102
DESCRIPTION
Levelers, 1/2-13 thread with Isolation
Pads, Quantity: 4
Isolation Bushing for 3/8˝ Hardware,
Quantity: 4
Sliding Shelf, 19˝ EIA, 24˝ D Vented,
4 Point, 150lb load rated
Sliding Shelf, 19˝ EIA, 30˝ D Vented,
4 Point, 300lb load rated
OR-MMCDR2-1915
Drawer, 2U, 19˝ x 15˝ D
OR-MMCDR4-1915
Drawer, 4U, 19˝ x 15˝ D
PART NO.
DESCRIPTION
OR-MMCFPS-1-B
1 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPS-2-B
2 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPS-3-B
3 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPS-4-B
4 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPS-5-B
5 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPS-6-B
6 Rack Unit, #12-24 Mounting Hardware
OR-MMCFPT-1-B
Tool-less for square mtg. holes, 1 Rack Unit
OR-MMCFPT-2-B
Tool-less for square mtg. holes, 2 Rack Unit
OR-MMCFPT-3-B
Tool-less for square mtg. holes, 3 Rack Unit
OR-MMCFPT-4-B
Tool-less for square mtg. holes, 4 Rack Unit
OR-MMCFPT-8-B
Tool-less for square mtg. holes, 8 Rack Unit
Fan Panels
PART NO.
DESCRIPTION
Use the 19˝ rack mount fan panel
to eliminate hot spots.
OR-MMCFANP19-4-2
Fan Panel, 19˝, (2) 4˝ 110 CFM ea.,
120 Volt, 24˝ Cord
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Airflow Baffles
OR-MMCAB421612
Airflow Baffles
Airflow baffles ensure the proper flow of
air from cold aisle to hot aisle, even with
side ventilated equipment. Air dam kits
prevent hot air from recirculating and
mixing with the cool air when used with
equipment that breathes front to rear.
PART NO.
DESCRIPTION
OR-MMCAB421612
Airflow Baffle, for 32˝ wide 42RU
frame when mounting rails are set at
16-1/4˝ front to rear and “U” shape
vertical is installed
OR-MMCAB423012
Airflow Baffle, for 32˝ wide 42RU
frame when mounting rails are set at
30˝ front to rear and “U” shape
vertical is installed
OR-MMCAB471612
Airflow Baffle, for 32˝ wide 47RU
frame when mounting rails are set at
16-1/4˝ front to rear and “U” shape
vertical is installed
OR-MMCAB473012
Airflow Baffle, for 32˝ wide 47RU
frame when mounting rails are set at
30˝ front to rear and “U” shape
vertical is installed
OR-MMCAB421632SA
Airflow Baffle, for 32˝ wide 42RU
frame when mounting rails are set at
16-1/4˝ front to rear and side panels
are installed
OR-MMCAB471632SA
Airflow Baffle, for 32˝ wide 47RU
frame when mounting rails are set at
16-1/4˝ front to rear and side panels
are installed
OR-MMC4232ADK
Air Dam Kit, for 32˝ wide 42RU frame
OR-MMC4732ADK
Air Dam Kit, for 32˝ wide 47RU frame
Fans & Blowers
OR-MMCFAN-6
Fans & Blowers
Replacement fans for the fan top plate.
Fans include the cord, finger guard
and mounting hardware.
PART NO.
DESCRIPTION
OR-MMCFAN-6
Replacement fan for top panels, 6˝ diameter,
120 Volt, 235 CFM, 24˝ Cord, Basic Black
OR-MMCFAN-6-2
Replacement fan for top panels, 6˝ diameter,
208 Volt, 235 CFM, 24˝ Cord, Basic Black
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
103
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MMCPB11518-01
Basic PDU
Increased processing speeds require
additional power distributed to each
cabinet. Managing the power while
minimizing the interference with the rack
equipment and airflow is critical.
The Ortronics® range includes 120V and
208V basic power distribution in 15, 20
and 30 amp sizes. Hardware is included
to mount to vertical PDU mounting bar.
104
PART NO.
DESCRIPTION
OR-MMCPB11510-01
Basic 17.5˝ Horizontal PDU, 120V 15A,
(10) NEMA 5-15 outlets, 5-15P input
plug w/10´ cord
OR-MMCPB11518-01
Basic 29.5˝ Vertical PDU, 120V 15A,
(18) NEMA 5-15 outlets, 5-15P input
plug w/10´ cord
OR-MMCPB11524-01
Basic 66.5˝ Vertical PDU, 120V 15A,
(24) NEMA 5-15 outlets, 5-15P input
plug w/10´ cord
OR-MMCPB12010-01
Basic 17.5˝ Horizontal PDU, 120V 20A,
(10) NEMA 5-20 outlets, L5-20P
input plug w/10´ cord
OR-MMCPB12018-01
Basic 29.5˝ Vertical PDU, 120V 20A,
(18) NEMA 5-20 outlets, L5-20P
input plug w/10´ cord
OR-MMCPB12024-01
Basic 66.5˝ Vertical PDU, 120V 20A,
(24) NEMA 5-20 outlets, L5-20P
input plug w/10´ cord
OR-MMCPB13016-01
Basic 29.5˝ Vertical PDU, 120V 30A,
(16) NEMA 5-20 outlets, L5-30P input
plug w/10´ cord
OR-MMCPB13024-01
Basic 66.5˝ Vertical PDU, 120V 30A,
(24) NEMA 5-20 outlets, L5-30P input
plug w/10´ cord
OR-MMCPB22012-01
Basic 17.5˝ Horizontal PDU, 208V 20A,
(12) IEC C13 outlets, L6-20P input plug
w/10´ cord
OR-MMCPB22018-01
Basic 29.5˝ Vertical PDU, 208V 20A,
(18) IEC C13 outlets, L6-20P input
plug w/10´ cord
OR-MMCPB22024-01
Basic 66.5˝ Vertical PDU, 208V 20A,
(24) IEC C13 outlets, L6-20P input
plug w/10´ cord
OR-MMCPB23016-01
Basic 29.5˝ Vertical PDU, 208V 30A,
(16) IEC C13 outlets, L6-30P input
plug w/10´ cord
OR-MMCPB23024-01
Basic 66.5˝ Vertical PDU, 208V 30A,
(24) IEC C13 outlets, L6-30P input
plug w/10´ cord
OR-MMCPB23024-02
Basic 66.5˝ Vertical PDU, 208V 30A,
(20) IEC (4) IEC C19 outlets, L6-30P
input plug w/10´ cord
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-MMCPM22018-01
Metered PDU
Increased processing speeds require
additional power distributed to each
cabinet. Monitoring and managing
the power while minimizing the
interference with the rack equipment
and airflow is critical. Ortronics® options
include 120V and 208V metered power
distribution in 20 and 30 amp sizes.
Hardware is included to mount to
vertical PDU mounting bar.
PART NO.
DESCRIPTION
OR-MMCPM12010-01
Metered 17.5˝ Horizontal PDU, 120V 20A,
(10) NEMA 5-20 outlets, L5-20P input
plug w/10´ cord
OR-MMCPM12018-01
Metered 29.5˝ Vertical PDU, 120V 20A,
(18) NEMA 5-20 outlets, L5-20P input
plug w/10´ cord
OR-MMCPM12024-01
Metered 66.5˝ Vertical PDU, 120V 20A,
(24) NEMA 5-20 outlets, L5-20P input
plug w/10´ cord
OR-MMCPM13016-01
Metered 29.5˝ Vertical PDU, 120V 30A,
(16) NEMA 5-20 outlets, L5-30P input
plug w/10´ cord
OR-MMCPM13024-01
Metered 66.5˝ Vertical PDU, 120V 30A,
(24) NEMA 5-20 outlets, L5-30P input
plug w/10´ cord
OR-MMCPM22012-01
Metered 17.5˝ Horizontal PDU, 208V 20A,
(12) IEC C13 outlets, L6-20P input
plug w/10´ cord
OR-MMCPM22018-01
OR-MMCPM22024-01
OR-MMCPM23016-01
OR-MMCPM23024-01
OR-MMCPM23024-02
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
Metered 29.5˝ Vertical PDU, 208V 20A,
(18) IEC C13 outlets, L6-20P input
plug w/10´ cord
Metered 66.5˝ Vertical PDU, 208V 20A,
(24) IEC C13 outlets, L6-20P input
plug w/10´ cord
Metered 29.5˝ Vertical PDU, 208V 30A,
(16) IEC C13 outlets, L6-30P input
plug w/10´ cord
Metered 66.5˝ Vertical PDU, 208V 30A,
(24) IEC C13 outlets, L6-30P input
plug w/10´ cord
Metered 66.5˝ Vertical PDU, 208V 30A,
(20) IEC (4) IEC C19 outlets, L6-30P
input plug w/10´ cord
105
MIGHTY MO® CABINETS
Mighty Mo Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-BCGSM6X7
Air Guard® Brush
Cable Grommets
PART NO.
DESCRIPTION
OR-BCGSM6X7*
Surface mount two piece
assembly designed to retrofit
around existing cables without
the need to disconnect cables.
Covers any shape or size up to
10˝ x 10˝.
OR-BCGFM3X9
Flush mount two piece assembly
designed for new installations
in data centers to maximize
energy efficiency. Designed with a
removable back brush that allows
for great versatility when floor
tiles need to be removed.
OR-BCGFMC3X9
Cover fits over the flush mount
brush cable grommet to provide
a solid surface for increased
durability and safety when cables
are not going through the floor.
Features:
■■
■■
OR-BCGFM3X9
■■
■■
OR-BCGFMC3X9
■■
■■
Provides an exceptional seal around
cables for an effective and economical
solution towards eliminating bypass air
through cable cutouts.
Provides an energy savings benefit
by reducing cool air loss while improving
the static pressure to cool data
center equipment.
Helps prevent network equipment
from overheating.
Seals cable openings with an
overlapping brush and/or EPDM
gaskets to help prevent under
floor contamination.
Floor tiles can be removed
without disconnecting equipment.
Flame retardant ABS polycarbonate
material provides a finished look.
Flush mount Extreme is a heavy
duty unit with a two stage,
integrated sealing system, EPDM
gasket material (UL94 HF-1 rated)
and standard Air Guard brush
technology, to provide the most
effective air seal.
OR-BCGFME5X7
OR-BCGFME5X7
A heavy duty, integrated safety
cover comes as a standard
component. OSHA jobsite
statutes require open holes in
floor panels to be covered. The
cover may remain in place until
cabling systems are installed and
maybe saved for future use.
*The OR-BCGSM6X7 can mount to any standard Mighty Mo
Cabinet cable entry top panel to provide a layer of protection
from dust and debris. One two piece grommet will cover both
openings in a cable entry top panel.
106
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® CABINETS
Mighty Mo Wall Mount Cabinets
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
The Mighty Mo wall mount cabinets utilize advanced cable
management to help secure, support and organize your network
where floor space is limited.
Providing capacity for both active and passive equipment, the cabinets feature one-rack unit finger
style vertical managers to ensure proper cable management for maximum network performance.
An optional rear horizontal mount bracket kit is designed to provide 2 additional fixed rack units on
the rear wall for mounting fiber, equipment or power distribution units. In addition, the cabinet center section swings out from the wall to
provide easy access to the equipment.
The front lockable wing turn latch allows you to secure the front door without having to lock the cabinet. This feature allows for easy
access into the front of the cabinet when you are in a secure environment.
The Mighty Mo wall mount cabinets are also an ideal choice for mounting in an open office environment. The cabinet’s heavy duty
construction minimizes sagging under heavy loads and the optional 50cfm fan is 50% quieter than most other leading cabinets.
Features & Benefits
Cable management to support and organize cables, ensuring proper cable management for minimum distortion
and maximum network performance
■■
Choice of solid or plexiglass door
■■
The cabinet can be mounted to open left or right
■■
Locking center section swings out to provide easy access to the equipment
■■
Front and center sections are keyed alike
■■
Includes one pair of fully adjustable 12-24 EIA mounting rails
■■
Brush cable entry plates standard on top rear
■■
Cable knockout plates standard on bottom rear
■■
3˝ hole with cap standard on top and bottom rear
■■
Vented sides for passive cooling of active equipment
■■
Optional 50cfm cooling fans are available to further protect active equipment
■■
Heavy duty 14 GA (.075˝) steel construction
■■
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
107
MIGHTY MO® CABINETS
Mighty Mo Wall Mount Cabinets
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Mighty Mo® Wall Mount Cabinets
OR-MMW122420P-B
Mighty Mo wall mount cabinets
PART NO.
DESCRIPTION
WEIGHT
CAPACITY
OR-MMW122420S-B
12U x 24˝ W x 20˝ D, Solid door,
height is 23.50˝, Basic Black
150 lbs
OR-MMW122420P-B
12U x 24˝ W x 20˝ D, Plexiglass
door, height is 23.50˝, Basic Black
150 lbs
OR-MMW192420S-B
19U x 24˝ W x 20˝ D, Solid door,
height is 35.75˝, Basic Black
200 lbs
OR-MMW192420P-B
19U x 24˝ W x 20˝ D, Plexiglass
door, height is 35.75˝, Basic Black
200 lbs
OR-MMW262420S-B
26U x 24˝ W x 20˝ D, Solid door,
height is 48.00˝, Basic Black
300 lbs
OR-MMW262420P-B
26U x 24˝ W x 20˝ D, Plexiglass
door, height is 48.00˝, Basic Black
300 lbs
OR-MMW122426S-B
12U x 24˝ W x 26˝ D, Solid door,
height is 23.50˝, Basic Black
150 lbs
OR-MMW122426P-B
12U x 24˝ W x 26˝ D, Plexiglass
door, height is 23.50˝, Basic Black
150 lbs
OR-MMW192426S-B
19U x 24˝ W x 26˝ D,Solid door,
height is 35.75˝, Basic Black
200 lbs
OR-MMW192426P-B
19U x 24˝ W x 26˝ D, Plexiglass
door, height is 35.75˝, Basic Black
200 lbs
OR-MMW262426S-B
26U x 24˝ W x 26˝ D, Solid door,
height is 48.00˝, Basic Black
300 lbs
OR-MMW262426P-B
26U x 24˝ W x 26˝ D, Plexiglass
door, height is 48.00˝, Basic Black
300 lbs
Mighty Mo wall mount cabinet accessories
108
PART NO.
DESCRIPTION
OR-MMCFAN-4-50
Fan Kit, 4˝, 50cfm
OR-MMWHMBM12-B
Rear Horizontal Mount Bracket Kit
OR-MMWBPK
Brush Plate Kit
OR-MMW12M12-B
12U Mounting Rail, 12-24, 1-pair
OR-MMW19M12-B
19U Mounting Rail, 12-24, 1-pair
OR-MMW26M12-B
26U Mounting Rail, 12-24, 1-pair
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® AIR CONTROL
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Mighty Mo Air Control Solutions
To improve data center cooling efficiency it is crucial to separate and contain cold air
and provide warmer air back to the cooling units. Mighty Mo Air Control products
significantly reduce cooling requirements by creating physical separation between the
cold and hot air aisles. Mighty Mo Air Control products can be used to reduce the amount of cold air
lost through unoccupied areas of equipment in hot and cold aisle environments, as well as balance
the underfloor pressure and reduce air leakage.
MIGHTY MO AIR CONTROL
Passive Cooling Solutions
NEW
Mighty Mo Air Cap Retractable Aisle Cover
The Air Cap is a retractable cover that attaches to the top of the rack/cabinet and creates a barrier that prevents hot air and cold
air from mixing. This retractable cover is spring loaded and designed to retract into a metal case should a fire suppression event
occur. Thermal links melt at 135ºF and release the cover into the housing should temperatures go beyond a certain level. This
ensures that the sprinkler pattern is not interrupted and also prevents the fire resistant cover from being exposed to the fire. The
retractable feature also allows easy access when overhead maintenance is needed.
Mighty Mo Air Cap Retractable Aisle Cover
PART NO.
DESCRIPTION
OR-MMACAP60X30
Air Cap, 60˝ W x 30´ L
OR-MMACAP84X30
Air Cap, 84˝ W x 30´ L
Contact customer service for lengths under 30 feet.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
109
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Mighty Mo Air Curtain System
The Mighty Mo Air Curtain is a containment system designed to separate hot and
cold airflow. The fire resistant vinyl hangs from aluminum tracks mounted to the drop
ceiling grid above the top of the racks/cabinets and forms a barrier between the hot
aisle and cold aisle. The aluminum tracks are connected to the ceiling grid by fusible
links that release should temperatures go beyond a certain level. This ensures that
the sprinkler pattern is not interrupted.
PART NO.
DESCRIPTION
OR-MMACNP29X12
Vinyl Panel, 29˝ H x 12˝ L
OR-MMACNP29X24
Vinyl Panel, 29˝ H x 24˝ L
OR-MMACNP29X36
Vinyl Panel, 29˝ H x 36˝ L
OR-MMACNP29X48
Vinyl Panel, 29˝ H x 48˝ L
OR-MMACNP29X60
Vinyl Panel, 29˝ H x 60˝ L
OR-MMACNP29X72
Vinyl Panel, 29˝ H x 72˝ L
OR-MMACNP56X12
Vinyl Panel, 56˝ H x 12˝ L
OR-MMACNP56X24
Vinyl Panel, 56˝ H x 24˝ L
OR-MMACNP56X36
Vinyl Panel, 56˝ H x 36˝ L
OR-MMACNP56X48
Vinyl Panel, 56˝ H x 48˝ L
OR-MMACNP56X60
Vinyl Panel, 56˝ H x 60˝ L
OR-MMACNP56X72
Vinyl Panel, 56˝ H x 72˝ L
OR-MMACNP98X12
Vinyl Panel, 98˝ H x 12˝ L
OR-MMACNP98X24
Vinyl Panel, 98˝ H x 24˝ L
OR-MMACNP98X48
Vinyl Panel, 98˝ H x 48˝ L
OR-MMACNP110X12
Vinyl Panel, 110˝ H x 12˝ L
OR-MMACNP110X24
Vinyl Panel, 110˝ H x 24˝ L
OR-MMACNP110X48
Vinyl Panel, 110˝ H x 48˝ L
OR-MMACNP122X12
Vinyl Panel, 122˝ H x 12˝ L
OR-MMACNP122X24
Vinyl Panel, 122˝ H x 24˝ L
OR-MMACNP122X48
Vinyl Panel, 122˝ H x 48˝ L
Linear feet – this is the length of
aluminum track needed to create
a rectangle around the aisle to be
contained. Kits are available
from 1´ to 6´ long and can be
connected to one another for
larger installations.
OR-MMACNP146X12
Vinyl Panel, 146˝ H x 12˝ L
OR-MMACNP146X24
Vinyl Panel, 146˝ H x 24˝ L
OR-MMACNP146X48
Vinyl Panel, 146˝ H x 48˝ L
OR-MMACNP182X12
Vinyl Panel, 182˝ H x 12˝ L
OR-MMACNP182X24
Vinyl Panel, 182˝ H x 24˝ L
Drop down length (in inches) –
this is the length of the vinyl panels
from the aluminum track to the top
of the racks and cabinets or floor.
Available lengths are from 29˝ to
182˝ high.
OR-MMACNP182X48
Vinyl Panel, 182˝ H x 48˝ L
Hanging Vinyl Panels
Fire resistant vinyl panels hang from
aluminum tracks mounted to the
drop ceiling grid above the racks and
cabinets. This curtain forms a barrier
between the hot aisle and cold aisle.
The aluminum tracks are connected
to the ceiling grid by fusible links that
release and drop to the floor when
temperatures go above 135°F, ensuring
that the fire sprinkler pattern is not
interrupted. Normal fire suppression
systems engage at 158°F.
The Hanging Vinyl Panel System
is sold in kits that include all the
necessary hangers, track and panels
to cover your specific area. The vinyl
panels are the length of the aluminum
track and overlap at the track
seams. Each panel has two inches
of additional width on each end to
overlap and create one continuous
partition.
The tracks are available in clear
anodized aluminum. To determine
the size of the Hanging Vinyl Panel
System required you will need the
following measurements:
■■
■■
110
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Hanging Vinyl
Corner Panels
PART NO.
DESCRIPTION
OR-MMACNCP29X12
Vinyl Corner Panel, 29˝ H x 12˝ L
The Hanging Vinyl Corner Panels
include a curved track, panels and all
the necessary hangers to make a 90
degree radius corner. The corner is
12 inches long in each direction.
OR-MMACNCP56X12
Vinyl Corner Panel, 56˝ H x 12˝ L
OR-MMACNCP98X12
Vinyl Corner Panel, 98˝ H x 12˝ L
OR-MMACNCP110X12
Vinyl Corner Panel, 110˝ H x 12˝ L
OR-MMACNCP122X12
Vinyl Corner Panel, 122˝ H x 12˝ L
OR-MMACNCP146X12
Vinyl Corner Panel, 146˝ H x 12˝ L
OR-MMACNCP182X12
Vinyl Corner Panel, 182˝ H x 12˝ L
Hanging Vinyl
Strip Doors
PART NO.
DESCRIPTION
OR-MMACNS98X12
Vinyl Strip, 98˝ H x 12˝ L
The Hanging Vinyl Strip Doors are
designed as an economical solution
for closing the end of an aisle. The
track sections are available in 1 foot
increments up to 6 feet. The 1 foot
wide vinyl strips have a 2 inch
overlap on each side for a total
width of 16 inches. The Hanging
Vinyl Strip Doors are sold in a
variety of sizes to fit virtually
every application.
OR-MMACNS98X24
Vinyl Strip, 98˝ H x 24˝ L
OR-MMACNS98X36
Vinyl Strip, 98˝ H x 36˝ L
OR-MMACNS98X48
Vinyl Strip, 98˝ H x 48˝ L
OR-MMACNS98X60
Vinyl Strip, 98˝ H x 60˝ L
OR-MMACNS98X72
Vinyl Strip, 98˝ H x 72˝ L
OR-MMACNS110X12
Vinyl Strip, 110˝ H x 12˝ L
OR-MMACNS110X24
Vinyl Strip, 110˝ H x 24˝ L
OR-MMACNS110X36
Vinyl Strip, 110˝ H x 36˝ L
OR-MMACNS110X48
Vinyl Strip, 110˝ H x 48˝ L
OR-MMACNS110X60
Vinyl Strip, 110˝ H x 60˝ L
OR-MMACNS110X72
Vinyl Strip, 110˝ H x 72˝ L
OR-MMACNS122X12
Vinyl Strip, 122˝ H x 12˝ L
OR-MMACNS122X24
Vinyl Strip, 122˝ H x 24˝ L
OR-MMACNS122X36
Vinyl Strip, 122˝ H x 36˝ L
OR-MMACNS122X48
Vinyl Strip, 122˝ H x 48˝ L
OR-MMACNS122X60
Vinyl Strip, 122˝ H x 60˝ L
OR-MMACNS122X72
Vinyl Strip, 122˝ H x 72˝ L
OR-MMACNS146X12
Vinyl Strip, 146˝ H x 12˝ L
OR-MMACNS146X24
Vinyl Strip, 146˝ H x 24˝ L
OR-MMACNS146X36
Vinyl Strip, 146˝ H x 36˝ L
OR-MMACNS146X48
Vinyl Strip, 146˝ H x 48˝ L
OR-MMACNS146X60
Vinyl Strip, 146˝ H x 60˝ L
OR-MMACNS146X72
Vinyl Strip, 146˝ H x 72˝ L
OR-MMACNS182X12
Vinyl Strip, 182˝ H x 12˝ L
OR-MMACNS182X24
Vinyl Strip, 182˝ H x 24˝ L
OR-MMACNS182X36
Vinyl Strip, 182˝ H x 36˝ L
OR-MMACNS182X48
Vinyl Strip, 182˝ H x 48˝ L
OR-MMACNS182X60
Vinyl Strip, 182˝ H x 60˝ L
OR-MMACNS182X72
Vinyl Strip, 182˝ H x 72˝ L
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
111
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Mighty Mo Sliding
Aisle End Door
The Sliding Aisle End Door installs at the
end of the row. The door frame is
constructed of extruded aluminum and
supports clear acrylic sliding doors,
bridging an aisle up to 84˝ wide. The
door is shipped fully assembled to make
installation easier. Simply tilt the door into
place, bolt it to the floor and attach the
turnbuckles on the top of the door to the
top of the end rack or cabinet. The
no-threshold design allows unfettered
access to the contained aisle. The
frames are available in clear or black
anodized aluminum.
DESCRIPTION
OR-MMADRS80X89DL
Air Door, Sliding, 80˝ H x 89˝ W,
dual 24˝ W doors, Clear
OR-MMADRS80X89DL-B
Air Door, Sliding, 80˝ H x 89˝ W,
dual 24˝ W doors, Black
PART NO.
DESCRIPTION
OR-MMADRH80X56LH
Air Door, Hinged, 80˝ H x 56˝ W,
left hand open, Clear
OR-MMADRH80X56LH-B
Air Door, Hinged, 80˝ H x 56˝ W,
left hand open, Black
OR-MMADRH80X56RH
Air Door, Hinged, 80˝ H x 56˝ W,
right hand open, Clear
OR-MMADRH80X56RH-B
Air Door, Hinged, 80˝ H x 56˝ W,
right hand open, Black
Mighty Mo Frame Panel
PART NO.
DESCRIPTION
The Frame Panel is used to create
containment when one row of racks
or cabinets is not the same length as
another row. It creates a right angle
from the aisle end door to the rack
or cabinet of the shorter row, effectively
closing the row and preventing the
mixing of hot and cold air. Each
frame support is two feet wide to
match the size of the standard floor
tiles. The frames are available in clear
or black anodized aluminum.
OR-MMADRF80X24
Air Door, Frame Support,
80˝ H x 24˝ W, Clear
OR-MMADRF80X24-B
Air Door, Frame Support,
80˝ H x 24˝ W, Black
Mighty Mo Hinged
Aisle End Door
The Hinged Aisle End Door is also
constructed of extruded aluminum and
clear acrylic and has the same ease of
installation as our sliding door.
The door can be purchased with a left
hand or right hand opening and has a
swing radius of 3 feet. The frames
are available in clear or black
anodized aluminum.
112
PART NO.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Mighty Mo Air Booth
PART NO.
DESCRIPTION
The Air Booth is a three sided containment
system that is placed directly over a
perforated tile, in front of a rack or cabinet.
This isolates the cold air provided from the
perforated tile, creating a dedicated supply
targeted specifically for the intake of active
equipment within individual racks or
cabinets. By providing exclusive access
to cold air, the Air Booth spot cools high
density and high powered equipment.
The Air Booth is an effective containment
system for isolated racks and cabinets.
The frames are available in clear or black
anodized aluminum.
OR-MMABTH802424
Air Booth, 3 sided,
80˝ H x 24˝ W x 24˝ D, Clear
OR-MMABTH802424-B
Air Booth, 3 sided,
80˝ H x 24˝ W x 24˝ D, Black
OR-MMABTH804824
Air Booth, 3 sided,
80˝ H x 48˝ W x 24˝ D, Clear
OR-MMABTH804824-B
Air Booth, 3 sided,
80˝ H x 48˝ W x 24˝ D, Black
OR-MMABTH807224
Air Booth, 3 sided,
80˝ H x 72˝ W x 24˝ D, Clear
OR-MMABTH807224-B
Air Booth, 3 sided,
80˝ H x 72˝ W x 24˝ D, Black
Mighty Mo Air Plug
PART NO.
DESCRIPTION
OR-MMAPL0404
Air Plug, 5˝ x 4˝ x 4˝, Black
OR-MMAPL0606
Air Plug, 5˝ x 6˝ x 6˝, Black
OR-MMAPL0612
Air Plug, 5˝ x 6˝ x 12˝, Black
OR-MMAPL0618
Air Plug, 5˝ x 6˝ x 18˝, Black
OR-MMAPL0624
Air Plug, 5˝ x 6˝ x 24˝, Black
OR-MMAPL0909
Air Plug, 5˝ x 9˝ x 9˝, Black
OR-MMAPL0914
Air Plug, 5˝ x 9˝ x 14˝, Black
OR-MMAPL0918
Air Plug, 5˝ x 9˝ x 18˝, Black
OR-MMAPL0924
Air Plug, 5˝ x 9˝ x 24˝, Black
OR-MMAPL1212
Air Plug, 5˝ x 12˝ x 12˝, Black
OR-MMAPL1218
Air Plug, 5˝ x 12˝ x 18˝, Black
OR-MMAPL1224
Air Plug, 5˝ x 12˝ x 24˝, Black
OR-MMAPL1414
Air Plug, 5˝ x 14˝ x 14˝, Black
OR-MMAPL1616
Air Plug, 5˝ x 16˝ x 16˝, Black
OR-MMAPL1620
Air Plug, 5˝ x 16˝ x 20˝, Black
OR-MMAPL1624
Air Plug, 5˝ x 16˝ x 24˝, Black
OR-MMAPL1818
Air Plug, 5˝ x 18˝ x 18˝, Black
OR-MMAPL2024
Air Plug, 5˝ x 20˝ x 24˝, Black
OR-MMAPL2424
Air Plug, 5˝ x 24˝ x 24˝, Black
Air Plugs are used to fill in cable
openings in the raised floor or any
gaps where airflow needs to be
blocked. Air Plugs are soft,
compressible and safe to use
around all types of cable, including
fiber optic cable.
They are made from Sandel™, a
fireproof material. Sandel originates
from sand, contains no asbestos
and is non-combustible at any
temperature. The Air Plugs are
available in several sizes to cover
most any opening and are easily
installed by simply squeezing the
plug and placing it in the opening
to be filled. All plugs have a height
of 5˝.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
113
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
OR-MMADIS0624
Mighty Mo Air Disrupter
PART NO.
DESCRIPTION
The Air Disrupter is a curtain designed
to modify the air velocity under a raised
floor. Low pressure areas above
perforated tiles are often a result of air
rushing past the tile opening at too great
a speed. By strategically placing the
Mighty Mo Air Disrupters under the raised
floor, air velocity is greatly reduced and
more air is allowed to permeate through
the tiles, ensuring a consistent supply of
cool air to each rack or cabinet.
OR-MMADIS0624
Air Disrupter, 6˝ H x 24˝ W
OR-MMADIS1224
Air Disrupter, 12˝ H x 24˝ W
OR-MMADIS1824
Air Disrupter, 18˝ H x 24˝ W
OR-MMADIS2424
Air Disrupter, 24˝ H x 24˝ W
The Mighty Mo Air Disrupters are made
from the fireproof material Sandel.
114
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
OR-MMAGCT2448
Mighty Mo Air Grille
The Air Grille is a ceiling vent that
is installed above the hot aisle.
This vent allows the hot exhaust air
to pass into the plenum instead of
recirculating throughout the
equipment room.
PART NO.
DESCRIPTION
OR-MMAGCT2424
Ceiling Vent, 24˝ x 24˝, pk of 30
OR-MMAGCT2448
Ceiling Vent, 24˝ x 48˝, pk of 30
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
115
MIGHTY MO® AIR CONTROL
Passive Cooling Solutions
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
Mighty Mo CRAC Unit Air Extension
The CRAC Unit Air Extension mounts to the top of the CRAC unit and extends to
the drop ceiling. The Air Extension then draws higher temperature return air from
the ceiling, back to the CRAC unit,increasing cooling capacity and resulting in
increased CRAC unit efficiency. The Air Extension can also be used in rooms without drop ceilings
as well, acting as a snorkel to pull warmer air from above the CRAC unit to increase efficiency.
Mighty Mo Air Extensions are made of high grade aluminum and are manufactured to meet the individual
requirements of your data center.
Mighty Mo Air Extensions are manufactured to meet the individual requirements of your data center.
To determine part number you will need the following measurements:
Part Number Formula
OR-MMAE-
X
XX
Part Number
Prefix
Width of
Height from
CRAC unit
top of CRAC
to drop ceiling
X
-G
XXXX
Depth of
CRAC unit
Color
G = Cool
Gray
Numerical
Suffix
The height, width and depth are rounded to the nearest foot. The maximum height for an air
extension is 8 feet. The width and depth are based on the rough dimensions of the CRAC unit.
The 4 digit numerical suffix will be assigned after the quantity and location of access doors and
exact dimensions for your unit are determined.
WIDTH
116
DE
PT
H
HEIGHT
Please contact your Ortronics Representative or Technical Support to help configure your Mighty
Mo Air Extension.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Cable Management Panels
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Complete cable management maximizes system performance. Ortronics has the largest selection of horizontal cable managers
in the industry. This wide array of panel styles will meet all cable management requirements.
OR-60400131
Cable Management
Panels
Ortronics cable management
panels provide organized movement
of patch cables horizontally and
vertically on 19˝ EIA distribution
racks. Black.
PART NO.
DESCRIPTION
OR-60400131
Five horizontal distribution rings,
1.7˝ H x 3.5˝ D, 1 rack unit
OR-60400057
Five horizontal distribution rings,
3˝ H x 4˝ D, 2 rack units
OR-808045590
Five horizontal polycarbonate plastic
distribution rings, 1.7˝ H x 6˝ D, 1 rack unit
OR-808004759
Five horizontal plastic distribution rings,
1.7˝ H x 2.70˝ D, 1 rack unit
OR-808004867
Five horizontal plastic distribution rings,
3.95˝ H x 2.4˝ D, 2 rack units
OR-808004818
Five horizontal plastic distribution rings,
3.95˝ H x 4.8˝ D, 2 rack units
OR-808044855
Four horizontal, four vertical distribution
rings, 2˝ H x 4˝ D, 24 routing clips,
.10˝ W x 2.63˝ D, 2 rack units
OR-808045768
Five horizontal polycarbonate plastic
distribution rings, 1.7˝ H x 3˝ D, 1 rack unit
®
OR-60400057
OR-808045590
OR-808004759
NOTE: Includes #12-24 mounting hardware.
OR-808004867
OR-808004818
OR-808044855
OR-808045768
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
117
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Cable Management Panels
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-60400129
OR-808044916
Feed-Through Cable
Management Panels
Ortronics® feed-through cable
management panels provide
organized management of patch
cables horizontally, vertically, and
from front to back on 19˝ EIA
distribution racks. Black.
PART NO.
DESCRIPTION
OR-60400129
Five horizontal distribution rings, 1.7˝ H x
3.5˝ D, four 1˝ x 2˝ cutouts, 1 rack unit
OR-808044916
Five horizontal distribution rings, 3˝ H x 2˝ D,
four 1.5˝ x 2˝ cutouts, 2 rack units
OR-60400426
Five horizontal distribution rings, 3˝ H x 4˝ D,
four 2.75˝ x 2.75˝ cutouts, 2 rack units
OR-808044915
Four horizontal, distribution rings, 2˝ H x 4˝ D,
24 routing clips, .10˝ W x 2.63˝ D, three
1.5˝ x 2˝ cutouts, 2 rack units
NOTE: Includes #12-24 mounting hardware.
OR-60400426
OR-808044915
118
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Cable Management Panels
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-60400189
OR-60400099
Bend Limiting Cable
Management Panels
Ortronics® bend limiting cable
management panels have curved
falls that protect against cable
crimping and also maintain proper
bend radius. The panels are ideal
at the top of standard 19˝ EIA
racks. Black.
PART NO.
DESCRIPTION
OR-60400189
1.7˝ H x 3.5˝ D rings with waterfall, 1 rack unit
OR-60400099
3.5˝ H x 3.5˝ D rings with waterfall, 2 rack units
OR-60400114
3.5˝ H x 6˝ D rings with waterfall, 2 rack units
OR-60400098
7˝ H x 4.5˝ D rings with waterfall, 4 rack units
OR-60400054
7˝ H x 7˝ D rings with waterfall, 4 rack units
NOTE: Includes #12-24 mounting hardware.
OR-60400114
OR-60400098
OR-60400054
OR-808000010
OR-808044508
Finger Duct Cable
Management Panels
Ortronics® closed cover finger duct
cable management panels provide organized movement for horizontal and
vertical routing of patch cables
on 19˝ EIA distribution racks. Black.
PART NO.
DESCRIPTION
OR-808000010
1.5˝ H x 1.5˝ D duct, 1 rack unit
OR-808044508
3˝ H x 1.5˝ D duct, 2 rack units
OR-808044549
3˝ H x 3˝ D duct, 2 rack units
OR-808045030
Front and rear ducts, 3˝ H x 3˝ D front duct,
2˝ H x 4˝ D rear duct, 2 rack units
NOTE: Includes #12-24 mounting hardware.
OR-808044549
OR-808045030
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
119
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Equipment Shelves
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Front-Mount
Equipment Shelf
ESV-19-FMB
Solid Version
Features:
■■
Cantilever shelf mounts in
several positions
DESCRIPTION
OR-ES-19-FMB
5.25˝ H x 17.25˝ W x 14.00˝ D,
rack spaces: 3, load rating: 50 lbs
OR-ES-23-FMB
5.25˝ H x 21.25˝ W x 14.00˝ D,
rack spaces: 3, load rating: 50 lbs
1/2˝ deep tray can be inverted
to create a flat surface for
deep equipment
■■
Mounts to 3˝ or 6˝ channel
PART NO.
DESCRIPTION
■■
Choose between standard or
vented version
OR-ESV-19-FMB
5.25˝ H x 17.25˝ W x 14.00˝ D,
rack spaces: 3, load rating: 50 lbs
■■
Mounting hardware included
OR-ESV-23-FMB
■■
Made of 16-gauge steel
5.25˝ H x 21.25˝ W x 14.00˝ D,
rack spaces: 3, load rating: 50 lbs
■■
Vented Version
Black finish.
Multi-Configuration
Equipment Shelf
ES-19-MCSB
PART NO.
Features:
■■ Mounts in at least 14
different ways
■■
■■
■■
DESCRIPTION
OR-ES-19-MCSB
5.25˝ H x 17.50˝ W x 12.00˝ D,
rack spaces: 3, load rating: 50 lbs
Black finish.
Mounts on 3˝ or 6˝ channel
equipment racks
Brackets invert to meet mounting
space requirements
Shelf can be inverted to create
a 3/4˝ deep tray
Mount two units back-to-back to
form a double-sided shelf
■■
Mounting hardware included
■■
Made of 16-gauge steel
■■
PART NO.
Multi-Configuration Equipment Shelf Mounting Options
Shelf back to
rack center
Shelf front flush
to rack front
Shelf front 1-1/2˝
beyond rack front
OR-60400523
Computer Tie Down Kit
Two units form a
24˝ double-sided
shelf
Ortronics® CPU tie down kit includes mounting plates with
rubber bumpers which can be quickly attached to the EIA
pattern on the front and rear of any rack with a rail depth
from 3˝ to 6.5˝. The hook and loop strap with elastic center
safely holds the CPU in place against the rubber bumpers.
The CPU can be easily removed for service. Black.
120
Brackets can be
inverted to meet
mounting space
requirements
Brackets can be
inverted to meet
mounting space
requirements
Shelf can be
inverted to make
a 3/4˝ deep tray
PART NO.
DESCRIPTION
OR-60400523
One hook and loop type strap, two brackets
NOTE: Includes #12-24 mounting hardware.
Patent No. 6,598,270
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Equipment Shelves
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-604044927
OR-60400550
OR-60400606
OR-60400575
Wall Mount Shelf
PART NO.
DESCRIPTION
Ortronics® wall mount shelf is designed
for smaller systems applications, or
where space is limited and a free
standing rack cannot be used. Black.
OR-604044927
20˝ x 4.875˝ x 18˝, 120 lbs capacity
Folding Keyboard Shelf
PART NO.
DESCRIPTION
This shelf has a keyboard tray which
folds up and locks in place. The tray
holds all full standard keyboards up
to 19˝ Wide. Black.
OR-60400550
19˝ rack mount, 1 rack unit
OR-60400551
23˝ rack mount, 1 rack unit
Rear Support Brackets
PART NO.
DESCRIPTION
Rear support brackets allow the
folding keyboard shelf to support any
standard computer monitor up to 35
lbs. The brackets adjust from 6.25˝
to 17˝. Black.
OR-60400606
For folding keyboard shelf
Mouse Tray with Pad
PART NO.
DESCRIPTION
OR-60400575
For folding keyboard shelf
The mouse tray slides underneath the
keyboard tray when not in use. Black.
OR-KTR19-DR
NOTE: Shelf has six keyholes in the rear for mounting.
Mounting hardware not included.
NOTE: Mounting hardware included.
Keyboard Tray
PART NO.
DESCRIPTION
Features:
Fits all standard keyboards and
mounts 19˝ equipment racks
OR-KTR19-DR
4.47˝ H x 20.38˝ W x 12.00˝ D,
load rating: 25 lbs
■■
Mouse pad tray slides beneath the
keyboard tray when not in use
■■
Mounting hardware is included
■■
Mouse pad can be mounted on left
or right side
■■
Constructed of 16-gauge steel
■■
OR-KTF-19-DR
Black finish.
Fold-Up Keyboard Tray
PART NO.
DESCRIPTION
Features:
Fits all standard keyboards and
mounts to 19˝ equipment racks
OR-KTF-19-DR
3.50˝ H x 20.38˝ W x 7.13˝ D,
load rating: 25 lbs
■■
■■
Mouse pad tray slides beneath the
keyboard tray when not in use
Keyboard tray folds upward against
uprights when not in use
■■
Mounting hardware is included
■■
Mouse pad can be mounted on left
or right side
■■
Constructed of 16-gauge steel
■■
Black finish. Mouse pad tray adds 7.28˝ to the direction extended.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
121
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Rack and Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
NEW
OR-BFPT-1RU-10
Tool Less
Snap-in Filler Panels
PART NO.
DESCRIPTION
OR-BFPT-1RU-10
19˝ W x 1.75˝ H, 1 rack unit, pack of 10
Ortronics tool less snap-in filler panels
are used to fill open rack units in racks
and cabinets where separation of cold
air and hot air is required. They are
designed to work with active equipment
and Ortronics flat, angled or curved
patch panels.
OR-BFPT-2RU-10
19˝ W x 3.75˝ H, 2 rack unit, pack of 10
®
OR-BFPT-2RU-10
The tool less snap-in filler panels
unique patent pending design allows
them to snap into 19˝ EIA/ECA310-E compliant tapped or square
hole mounting rails. Because no field
modification is required to fit a tapped
hole, the panel can be remounted in
a square hole in the future eliminating
the need to stock two different types
of panels. Black.
OR-401004789
OR-401004790
Blank Filler Panels
Ortronics blank filler panels fill in open
spaces on all standard 19˝ EIA racks
and cabinets. They are composed
of black powder coated aluminum
and have a blue silkscreened logo.
Includes #12-24 mounting hardware.
Black.
Flat Blank Filler Panels
PART NO.
DESCRIPTION
OR-401004788
19˝ W x 1.75˝ H, 1 rack unit
OR-401004789
19˝ W x 3.5˝ H, 2 rack units
OR-401004790
19˝ W x 5.25˝ H, 3 rack units
OR-401004791
19˝ W x 7˝ H, 4 rack units
OR-401045773
19˝ W x 38.5˝ H, 22 rack units
Angled Blank Filler Panels
OR-BFPA-2RU
PART NO.
DESCRIPTION
OR-BFPA-1RU
19˝ W x 1.75˝ H, 1 rack unit
OR-BFPA-2RU
19˝ W x 3.5˝ H, 2 rack units
Curved Blank Filler Panels
PART NO.
DESCRIPTION
OR-BFPC-1RU
19˝ W x 1.75˝ H, 1 rack unit
OR-BFPC-1RU
122
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Rack and Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-604045108
OR-60400383
Rack Adapter Kit
PART NO.
DESCRIPTION
Ortronics® rack adapter kits allow
19˝ equipment to be used on 23˝
EIA racks. Includes #12-24 mounting
hardware. Black.
OR-604045108
19˝ to 23˝, 1.75˝ H, 1 rack unit
OR-604045109
19˝ to 23˝, 3.5˝ H, 2 rack units
OR-604045110
19˝ to 23˝, 5.25˝ H, 3 rack units
OR-604045111
19˝ to 23˝, 7.0˝ H, 4 rack units
OR-604045112
19˝ to 23˝, 8.75˝ H, 5 rack units
PART NO.
DESCRIPTION
OR-60400383
19˝ W x 1.75˝ H x 1˝ D
PART NO.
DESCRIPTION
OR-50900051
19˝ W, 8 outlet, 20 AMP, circuit breaker,
switch
OR-50900051-TL
19˝ W, 8 outlet, 20 AMP, circuit breaker,
switch, twist-lock plug
OR-50900052
19˝ W, 8 outlet, 20 AMP, circuit breaker
OR-50900052-TL
19˝ W, 8 outlet, 20 AMP, circuit breaker,
twist-lock plug
Power Strip for
Mighty Mo Racks® and
Free Standing Cabinets
PART NO.
DESCRIPTION
OR-60400381
Vertical, 49˝, 16 outlet, 15 AMP, circuit
breaker, switch, 15´ cord
The 16-position power strip mounts
vertically on the back of the Mighty
Mo racks and on the inside frame
of the Mighty Mo cabinets. Includes
mounting hardware.
OR-60400681
Vertical, 49˝, 16 outlet, 20 AMP, circuit
breaker, switch, 15´ cord
19˝ Equipment
Support Bracket
Mounts on the rear of any 19˝ rack
to support the weight of heavy
equipment. The bracket is especially
effective on the Mighty Mo® racks
where the channel depth is 6.5˝ or
deeper. Includes #12-24 mounting
hardware. Black.
OR-50900051
19˝ Rack Mount
Power Strips
The 8 outlet 20 AMP rack mount
power strips are available with
or without a switch, and with a
standard 3 prong or twist-lock plug
design. All four power strips come
with 15´ of cord. Includes #12-24
mounting hardware. Black.
OR-60400381
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
123
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Rack and Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-60400013
OR-CMBFR0RU
Wire Distribution Spool
PART NO.
DESCRIPTION
This spool has a #12-24 stud molded in
place and can be threaded into the EIA
holes on any Ortronics® rack. Use it to
mount cable management panels, patch
panels or screw it in anywhere additional
cable management is desired. Black.
OR-60400013
#12-24 stud
Cable Management
Support Bar, Zero RU
PART NO.
DESCRIPTION
OR-CMBFR0RU
19.00˝ W x 4.00˝ D
PART NO.
DESCRIPTION
OR-60400046
U-Type, 1.5˝ D, 19˝ W
PART NO.
DESCRIPTION
OR-60400005
#12-24 x .625˝, package of 4
OR-60400533
#12-24 x .625˝, package of 50
Provides strain relief at the front or
rear of a standard 19 ˝ patch panel
that does not include rear management
panels. The support bar is mounted with
patch panel mounting screws to the
front or with the supplied additional nuts
to the rear. Black.
OR-60400046
Cable Management
Support Bar
Provides strain relief at the rear of
a standard 19 ˝ rack for horizontal
wiring cables that are terminated to
modular patch panels that do not
include this type of cable management.
Support bar is mounted with
thumbscrews to the rear upright
channels of a rack. Black.
OR-60400005
Panel Mounting Screws
Ortronics® mounting screws replace
lost or damaged screws for patch
panels and cable management panels.
These combination head screws
with #12-24 threads have a pilot
point for easy starting. Black.
124
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
HORIZONTAL CABLE MANAGEMENT,
SHELVES & ACCESSORIES Rack and Cabinet Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Ortronics® cable management straps and accessories provide an organized solution for the management of patch and horizontal
distribution cables.
OR-70800205
Saddles
Ortronics self-adhesive saddles will
attach to any smooth dry surface and
are designed to accept the hook and
loop straps shown below. Sold in
packages of 10. Black.
OR-70700080
Color-Coded Cable
Management Straps
Ortronics color-coded cable management
straps provide an organized solution for
the management of patch and horizontal
distribution cables. The 3/4˝ W straps
have a hook and loop type closure to
secure and administer cables without
damaging the construction of the copper
or fiber cable. Sold in packages of ten.
OR-70700143
Plenum-Rated
Cable Management Straps
Ortronics plenum cable management
straps provide an organized solution for
the management of cables in plenum
rated air handling spaces. These 1/2˝
wide hook and loop type straps are
reusable, easy to install and will not
damage high performance cabling. Sold
in 20 count rolls that are neat,convenient
and quick to use. Cranberry.
OR-70700084-00
OR-60400199
D-Ring Cable
Management Straps
PART NO.
DESCRIPTION
OR-70800205
Two-way, self-adhesive base,
for cable management straps up to
1.25˝ maximum width
PART NO.
DESCRIPTION
OR-70700080
6˝ L x .75˝ W,
grip range: .625˝ to 1.625˝ diameter
OR-70700079
12˝ L x .75˝ W,
grip range: 1.25˝ to 3.25˝ diameter
NOTE: To order colored straps, specify color by putting color code at
end of part number Color Code: -00=Black, -22=Red, -23=Orange,
-24=Yellow, -25=Green, -26=Blue (Example: To order a 6˝ red
OR-70700080 strap: OR-70700080-22).
PART NO.
DESCRIPTION
OR-70700143
8˝ L x .5˝ W,
grip range: .75˝–1.75˝ diameter
OR-70700144
12˝ L x .5˝ W,
grip range: .75˝–3˝ diameter
PART NO.
DESCRIPTION
OR-70700107-00
12˝ L, grip range: 1.5˝ to 2.5˝ diameter
Ortronics D-Ring Cable Management
OR-70700084-00
Straps provide an organized solution
for the management of horizontal
distribution cables. The 3/4˝ W straps
have a hook and loop type closure to secure
and administer cables without damaging the
construction of the copper or fiber cable.
Sold in packages of ten. Black.
18˝ L, grip range: 2˝ to 4˝ diameter
Bend Limiting Strain
Relief Bar
PART NO.
DESCRIPTION
OR-60400199
19˝ x 1˝ x 2.5˝, fills 1 rack unit
Ortronics bend limiting strain relief bar
has curved falls that prevent distribution
cable from crimping and maintain proper
bend radius. The panel mounts to the
rear of standard 19 ˝ EIA racks. Route
cable ties through the holes in the bar
to hold cables in place.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
125
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Ground Bars and Kits
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-GB4X12TMGB
OR-GB4X20TMGB
Telecommunications Main
Ground Bars and Kits
Manufactured of 1/4˝ thick electrolytic
tough pitch 110 alloy copper bar.
Includes 1-1/2˝ insulators and 1˝ offset
stainless steel mounting brackets.
Includes one 1/2 oz. tube of antioxidant
joint compound. Meets BICSI and
EIA/TIA 607 standards.
Telecommunications Main Ground Bars
PART NO.
DESCRIPTION
OR-GB4X12TMGB
Bar size: 12˝ W x 4˝ H, 12 5/16˝ hole
sets, 6 7/16˝ hole sets
OR-GB4X20TMGB
Bar size: 20˝ W x 4˝ H, 24 5/16˝ hole
sets, 6 7/16˝ hole sets
Kits include:
1 – Copper ground bar with
brackets and insulators
■■
6 – #6 compression lugs
■■
3 – #2 compression lugs
■■
1 – 2/0 compression lug
■■
1 – 4/0 compression lug
■■
12 – 1/4˝-20 x 3/4˝ SS hex
head cap screw
■■
12 – 1/4˝-20 SS lock washer
■■
12 – 1/4˝-20 SS hex nut
■■
6 – 3/8˝-16 x 1˝ SS hex
head cap screw
■■
6 – 3/8˝-16 SS lock washer
■■
6 – 3/8˝-16 SS hex nut
■■
OR-GB4X12TMGBKIT
OR-GB4X20TMGBKIT
126
Telecommunications Main Ground Bar Kits
PART NO.
DESCRIPTION
OR-GB4X12TMGBKIT
Bar size: 12˝ W x 4˝ H, 12 5/16˝ hole
sets, 6 7/16˝ hole sets
OR-GB4X20TMGBKIT
Bar size: 20˝ W x 4˝ H, 24 5/16˝ hole
sets, 6 7/16˝ hole sets
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Ground Bars and Kits
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-GB2X10TGB
OR-GB2X12TGB
Telecommunication
Ground Bars and Kits
Manufactured of 1/4˝ thick electrolytic
tough pitch 110 alloy copper bar.
Includes 1-1/2˝ insulators and 1˝ offset
stainless steel mounting brackets.
Includes one 1/2 oz. tube of antioxidant
joint compound. Meets BICSI and
EIA/TIA 607 standards.
Kits include:
1 – Copper ground bar with
brackets and insulators
■■
OR-GB2X12TGBKIT
OR-GB4X12J
OR-GBWMBKIT
■■
6 – #6 compression lugs
■■
3 – #2 compression lugs
■■
1 – 2/0 compression lug
■■
1 – 4/0 compression lug
■■
12 – 1/4˝-20 x 3/4˝ SS hex
head cap screw
■■
12 – 1/4˝-20 SS lock washer
■■
12 – 1/4˝-20 SS hex nut
■■
6 – 3/8˝-16 x 1˝ SS hex
head cap screw
■■
6 – 3/8˝-16 SS lock washer
■■
6 – 3/8˝-16 SS hex nut
Standard Ground Bars
Wall Mounting
Bracket Kit
Telecommunications Ground Bars
PART NO.
DESCRIPTION
OR-GB2X10TGB
Bar size: 10˝ W x 2˝ H, 4 5/16˝ hole sets,
3 7/16˝ hole sets
OR-GB2X12TGB
Bar size: 12˝ W x 2˝ H, 6 5/16˝ hole sets,
3 7/16˝ hole sets
Telecommunications Ground Bar Kits
PART NO.
DESCRIPTION
OR-GB2X12TGBKIT
Bar size: 12˝ W x 2˝ H, 6 5/16˝ hole sets,
3 7/16˝ hole sets
PART NO.
DESCRIPTION
OR-GB4X12J
Bar size: 12˝ W x 4˝ H, 27 holes
OR-GB4X20J
Bar size: 20˝ W x 4˝ H, 51 holes
PART NO.
DESCRIPTION
OR-GBWMBKIT
Set of two brackets with insulators and
hardware to mount to a ground bar.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
127
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Ground Bars and Kits
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-GBV36
OR-GBV72
Equipment Rack
Ground Bars and Kits
Vertical Ground Bars
Manufactured of 1/4˝ thick electrolytic
tough pitch 110 copper alloy bar.
Accommodates one hole lugs or two
hole lugs (5/8˝ on center). 36˝ bar has
2 PEM studs at one end and the 72˝
bar has 2 PEM studs at both ends for
ground conductor connection.
PART NO.
DESCRIPTION
OR-GBV36
5/8˝ x 36˝ vertical ground bar
OR-GBV72
5/8˝ x 72˝ vertical ground bar
OR-GBV36KIT
5/8˝ x 36˝ vertical ground bar kit
OR-GBV72KIT
5/8˝ x 72˝ vertical ground bar kit
Kits Include:
OR-GBV36KIT
OR-GBV72KIT
n1 – 1/4˝ thick electrolytic tough pitch 110
copper alloy bar
n 8 – 1/4˝ x 1/2˝ stainless steel hex head
cap screw
n 3 – white delrin insulators
n 4 – 5/16˝ stainless steel lock washer
n 8 – 1/4˝ stainless steel lock washer
n3 – #12-24 x 5/8˝ hex washer head screw
n 4 – 5/16˝ stainless steel hex nut
n1 – two hole long barrel compression lug
OR-GBH19KIT
Horizontal Ground
Bar Kit
PART NO.
DESCRIPTION
OR-GBH19KIT
1˝ X 19.25˝ horizontal ground bar kit
Kits Include:
n 1 – 1/4˝ thick electrolytic tough pitch 110
copper alloy bar
n 1 – 3˝ bar splice plate with 2 slotted holes
n 2 – white delrin insulators
n 2 – 12-24 x 5/8˝ hex washer head screw
n 2 – #12-24 x 3/4˝ copper flashed
brass screw
n 2 – #12 copper flat washer
n 8 – #6-32 x 1/4˝ copper flashed brass screw
n 8 – #6 ring terminal
n 1 - #6 long barrel compression lug,
3/4˝ o.c. for 1/4˝ hardware
n 2 - 1/4˝-20 x 3/4˝ stainless steel cap screw
n 2 - 1/4˝ stainless steel lock washer
n 2 - 1/4˝-20 stainless steel nut
128
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Compression Lugs and Taps
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-CL2LB6A
OR-CL2LB6C
OR-CL2LB2C
OR-CL2LB20C
OR-CL2LB6B
OR-CL2LB2A
Two Hole Long Barrel
Compression Lugs
Manufactured from electroplated
tinned copper. Long barrels maximize
number of crimps and are color coded.
Inspection port assures full conductor
insertion. Sold in packages of 10.
OR-CL2LB10C
PART NO.
CABLE
SIZE
OC
DIMENSION
BETWEEN
SCREW
HOLES
SIZE
OR-CL2LB6A
6
.625˝
1/4˝
Blue
OR-CL2LB6B
6
.75˝
3/8˝
Blue
OR-CL2LB6C
6
1˝
3/8˝
Blue
OR-CL2LB2A
2
.625˝
1/4˝
Brown
OR-CL2LB2C
2
1˝
3/8˝
Brown
OR-CL2LB10C
1/0
1˝
3/8˝
Pink
OR-CL2LB20C
2/0
1˝
3/8˝
Black
OR-CL2LB30C
3/0
1˝
3/8˝
Orange
OR-CL2LB40C
4/0
1˝
3/8˝
Purple
PART NO.
CONDUCTOR RUN
CONDUCTOR TAP
OR-CTHD4666
#4 Stranded
#6 Solid
#6 Stranded
#6 Solid
OR-CTHD4446
#4 Stranded
#6 Solid
#4 Stranded
#4 Solid
OR-CTHD2248
#2 Stranded
#2 Solid
#4 Stranded
#8 Solid
OR-CTHD2222
#2 Stranded
#2 Solid
#2 Stranded
#2 Solid
OR-CTHD220
2/0 Stranded
1/0 Solid
#2 Stranded
#8 Solid
COLOR
CODE
OR-CL2LB30C
OR-CL2LB40C
OR-CTHD4446
OR-CTHD4666
C-Type
Compression Taps
Connects two copper conductors
together with a hydraulic crimp tool.
Sold in packages of 10.
OR-CTHD2222
OR-CTHD2248
OR-CTHD220
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
129
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
Mechanical
Compression Tools
OR-MCT840
PART NO.
DESCRIPTION
OR-MCT840
Dieless adjustable compression tool with
steel handle. Works with copper conductor
sizes #8 through 250MCM and aluminum
conductors #8 through 4/0. For use with
compression lugs and compression taps.
OR-MCT810
Terminates copper compression connectors
in wire sizes #8 through 1/0. Dies included.
Insulated Ground
Jumper Kit
PART NO.
DESCRIPTION
OR-GJ8KIT
Ground jumper assembly kit, 6-7G, 8˝ length
Copper Offset
Terminal Lugs
PART NO.
DESCRIPTION
OR-COTL1014
Wire range: max 10 str, min 14 str,
bolt hole size: #8, ampere rating: 25
OR-COTL614
Wire range: max 6 str, min 14 str,
bolt hole size: #8, ampere rating: 50
OR-COTL28
Wire range: max 2 str, min 8 str,
bolt hole size: 1/4˝, ampere rating: 70
Grounding Kit for Racks
PART NO.
DESCRIPTION
This kit provides a reliable systems
ground for the distribution rack. One
grounding kit is recommended for
each rack.
OR-60400010
Single conductor ground lug for six AWG to
14 AWG conductors
Two Hole Ground Lug
PART NO.
DESCRIPTION
OR-GL2014
Bolt hole size: 1/4˝ O.C. Spacing 5/8˝
OR-MCT810
OR-GJ8KIT
OR-COTL1014
OR-COTL614
OR-COTL28
OR-60400010
OR-GL2014
Allows grounding of racks and
cabinets utilizing the standard
EIA/TIA hole pattern. Manufactured
of electro-tin plated aluminum and
allows attachment of copper or
aluminum conductor sizes from
14AWG to 2/0. Meets BICSI and
EIA/TIA 607 recommendations for two
hole mounting. Includes two 3/8˝ x 1˝
hex socket head set screws.
130
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-PCU575
OR-PCU152
OR-PCU354
OR-PCU1125
Pipe Clamps
PART NO.
DESCRIPTION
Manufactured from electroplated
tinned bronze. Conductor range:
#6 through 250 MCM PEM stud
ensures a flush mounting surface.
Sold in packages of 5.
OR-PCU575
Nominal pipe size range: .5˝ - .75˝,
pipe outside diameter: .375˝ – 1˝
OR-PCU1125
Nominal pipe size range: 1˝ – 1.25˝,
pipe outside diameter: .75˝ – 1.7˝
OR-PCU152
Nominal pipe size range: 1.5˝ – 2˝,
pipe outside diameter: 1˝ – 2.4˝
OR-PCU253
Nominal pipe size range: 2.5˝ – 3˝,
pipe outside diameter: 2.25˝ – 3.5˝
OR-PCU354
Nominal pipe size range: 3.5˝ – 4˝,
pipe outside diameter: 3.2˝ – 4.5˝
OR-PCU56
Nominal pipe size range: 5˝ – 6˝,
pipe outside diameter: 5.63˝ – 6.63˝
OR-PCU253
OR-PCU56
Antioxidant Joint Compound
Oxide inhibiting joint compound used to improve electrical conductivity and enhance the integrity of the connection.
OR-AJCA
OR-AJCA8
Aluminum Antioxidant
Synthetic base with suspended zinc
particles. Material is gray in color.
Recommended for aluminum to
aluminum, aluminum to copper
and aluminum conduit threads.
OR-AJCC
OR-AJCC8
Copper Antioxidant
Synthetic base compound with
suspended copper particles. Material
is copper in color. Recommended for
copper to copper connections, copper
threads and all ground applications.
PART NO.
DESCRIPTION
OR-AJCA
1/2 oz., package of 12
OR-AJCA8
8 oz.
PART NO.
DESCRIPTION
OR-AJCC
1/2 oz., package of 12
OR-AJCC8
8 oz.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
131
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-TR10-12B
Tubular Runway
Flexibility is the key to cable
management. Ortronics® Cable
Runway is designed to adapt to
each twist and turn cables must
make. Made of lightweight
rectangular steel tubing, the
runway reduces floor loading and
is easy to install and maintain. Steel
meets stringent specifications for
yield and tensile strength, assuring
a strong, light weight product that
easily supports and delivers
overhead cable.
Features:
n Tubular cross slats welded to the
top of stringers
PART NO.
DOVE GRAY
PART NO.
BLACK
OR-TR6-6D
OR-TR6-6B
Dimensions: 6.00˝ W x 5´
11.00˝ L, load rating: 115 lbs
OR-TR6-12D
OR-TR6-12B
Dimensions: 12.00˝ W x 5´
11.00˝ L, load rating: 115 lbs
OR-TR6-18D
OR-TR6-18B
Dimensions: 18.00˝ W x 5´
11.00˝ L, load rating: 115 lbs
OR-TR6-24D
OR-TR6-24B
Dimensions: 24.00˝ W x 5´
11.00˝ L, load rating: 115 lbs
OR-TR10-6D
OR-TR10-6B
Dimensions: 6.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TR10-12D
OR-TR10-12B
Dimensions: 12.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TR10-18D
OR-TR10-18B
Dimensions: 18.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TR10-24D
OR-TR10-24B
Dimensions: 24.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
n Cross slats feature rounded
edges for cable protection
DESCRIPTION
n Runway widths available from 6˝ to 24˝
n Two standard lengths:
5´11˝ or 9´ 8 1/2˝
Specifications:
n Stringers made of 3/8˝ x 1-1/2˝
high tensile tubular steel
n Cross slats are 1˝ x 1/2˝ tubular steel
n Rust-resistant dove gray, or black finish
n UL listed
OR-TRT10-6
Telco Style Tubular Runway
Features:
n Tubular cross slats are welded
between stringers
n Cross slats feature rounded
edges for cable protection
n Runway widths available from
6˝ to 24˝
PART NO.
PART NO.
BLACK
OR-TRT10-6
OR-TRT10-6B
Dimensions: 6.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TRT10-12
OR-TRT10-12B
Dimensions: 12.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TRT10-18
OR-TRT10-18B
Dimensions: 18.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
OR-TRT10-24
OR-TRT10-24B
Dimensions: 24.00˝ W x 9´
8.50˝ L, load rating: 115 lbs
DESCRIPTION
n Standard length is 9´ 8 1/2˝
Specifications:
n Stringers made of 3/8˝ x 1-1/2˝
high tensile tubular steel
n Cross slats are 1˝ x 1/2˝ tubular steel
n Rust-resistant dove gray, or black finish
n UL listed
132
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-TRTC-12D
Curved Runway
Radius curved runway permits
smooth vertical to horizontal
transitions. Stringers are
1-1/2˝ x 3/8˝ steel tubes;
cross slats are 1˝ x 1/2˝ x 1/8˝
steel tubes. UL listed.
Outside Curved Runway
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-TRTC-6D
OR-TRTC-6B
11.50˝ H x 6.00˝ W x 11.50˝ D
OR-TRTC-12D OR-TRTC-12B 11.50˝ H x 12.00˝ W x 11.50˝ D
OR-TRTC-18D OR-TRTC-18B 11.50˝ H x 18.00˝ W x 11.50˝ D
OR-TRTC-24D OR-TRTC-24B 11.50˝ H x 24.00˝ W x 11.50˝ D
Inside Curved Runway
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-TRTCI-6D
OR-TRTCI-6B
11.50˝ H x 6.00˝ W x 11.50˝ D
OR-TRTCI-12D OR-TRTCI-12B 11.50˝ H x 12.00˝ W x 11.50˝ D
OR-TRTCI-18D OR-TRTCI-18B 11.50˝ H x 18.00˝ W x 11.50˝ D
OR-TRTCI-24D OR-TRTCI-24B 11.50˝ H x 24.00˝ W x 11.50˝ D
OR-TRHR-12B
OR-TRTHR-12B
Horizontal Radius
Runway
Horizontal radius runway allows
cables to be routed around
horizontal corners. The horizontal
radius runway features stringers
made of 1-1/2˝ x 3/8˝ steel tubes;
cross slats are 1˝ x 1/2˝ x 1/8˝
steel tubes. UL listed.
TR Style
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-TRHR-12D OR-TRHR-12B
12.00˝ W x 18.03˝ IR x
29.66˝ OR*
OR-TRHR-18D OR-TRHR-18B
18.00˝ W x 18.03˝ IR x
35.66˝ OR*
TRC Style
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-TRTHR-12D OR-TRTHR-12B
12.00˝ W x 18.03˝ IR x
29.66˝ OR*
OR-TRTHR-18D OR-TRTHR-18B
18.00˝ W x 18.03˝ IR x
35.66˝ OR*
*IR= Inside radius; OR= Outside radius
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
133
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-P413512H-TB
End Closing Tubes
End closing tubes are used when
junctioning runway sections of
different widths, or closing the
stringers of a single piece of runway.
They are used together with corner,
edge or straight clamps. Made of
3/8˝ x 1-1/2˝ tubular steel.
OR-RECBK-12B
End Closing Kit
The end closing kit includes one end
closing tube and two corner clamps
for closing the stringers of a single
piece of runway.
OR-WRTRT-12B
Runway Wall to Rack Kit
The runway wall to rack kit provides
support for cable between the rack
and the wall.
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-P413511H-TD OR-P413511H-TB
1.50˝ H x 5.75˝ W x
0.38˝ D, use with 6˝
OR-P413512H-TD OR-P413512H-TB
1.50˝ H x 11.75˝ W x
0.38˝ D, use with 12˝
OR-P413530H-TD OR-P413530H-TB
1.50˝ H x 17.75˝ W x
0.38˝ D, use with 18˝
OR-P413531H-TD OR-P413531H-TB
1.50˝ H x 23.75˝ W x
0.38˝ D, use with 24˝
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-RECBK-6
OR-RECBK-6B
For use with 6˝ runway
OR-RECBK-12
OR-RECBK-12B
For use with 12˝ runway
OR-RECBK-18
OR-RECBK-18B
For use with 18˝ runway
OR-RECBK-24
OR-RECBK-24B
For use with 24˝ runway
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-WRTRT-12B
Kit of 1-4´ 5-1/2˝ long
runway, 1-wall angle
assembly, 1-runway
bracket kit and 1-set of
end caps
OR-WRTRT-12
Kit consists of:
n (1) 12˝ wide 4´ 5-1/2˝ long tubular
runway with channels
n (1) 12˝ wide wall angle assembly
n (1) Runway bracket kit
n (1) Set of end caps
Features:
n Works with standard equipment racks of all
channel depths and all Mighty Mo 3, Mighty
Mo 6 and Mighty Mo 10 rack systems
OR-GS-8
Ground Strap
Ground straps provide grounding
between spliced runway. Simply
pre-drill runway to accept the strap,
and connect to runway sections using
compression lugs.
PART NO.
DESCRIPTION
OR-GS-8
Dimensions* 8.75˝ L x 0.63˝ H
*Lug hole-to-lug hole length is 8.00˝. Runway clearance hole
for 1/4-20˝ is needed to mount ground strap.
Features:
n All compression lugs and 1/4-20˝ hardware
included: (1) 8˝ ground strap, (2) compression
lugs, (2) toothed lock washers, (2) hex nuts
n Constructed of flexible tinned copper flat braid
134
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-P820127H
OR-P820147H
Straight & Corner
Clamp Assemblies
Straight Clamp
PART NO.
DESCRIPTION
Clamps are used to junction runway
sections together in a variety of
configurations. Whether sections
are extended in-line or junctioned
perpendicularly or are transitioned
from horizontal to vertical, clamps
provide a solid connection to assure
the runway layout will provide the
necessary support for your cabling.
OR-P820127H
Straight clamp kit - 2 straight clamps
OR-P820367H
Straight clamp kit - For different
stringer widths - 2 clamps with filler
Corner Clamp
PART NO.
DESCRIPTION
OR-P820147H
Corner clamp kit - 2 corner clamps
Clear zinc plated.
OR-P820127HA
Adjustable Angle Splice Kit
Adjustable angle splices junction
runway sections from separate
horizontal planes for smooth
vertical transitions.
OR-P820287H
Edge Clamp Assemblies
Edge clamps junction runway of the
same width where horizontal-to-vertical
and horizontal-to-horizontal transitions
are needed.
PART NO.
DESCRIPTION
OR-P820127HA
Two adjustable angles
Clear zinc plated.
45° Edge Clamp
PART NO.
DESCRIPTION
OR-P820287H
45° edge clamp kit - 2 edge clamps
90° Edge Clamp
PART NO.
DESCRIPTION
OR-P820327H
90° edge clamp kit - 2 edge clamps
Clear zinc plated.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
135
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-CF-6D
Cable Fence
Cable fence is available in 6˝ or 12˝
and provides added cable capacity for
TR or TRT runway. One set includes
10 pieces that attach to runway as
needed. Ortronics® recommends
placing cable fence to every other
cross member to support large
cable piles.
OR-CFTRC-6
For use with TR runway
PART NO.
DOVE GRAY
PART NO.
BLACK
OR-CF-6D
OR-CF-6B
6.00˝ H x 2.63˝ W x 0.19˝ D
OR-CF-12D
OR-CF-12B
12.00˝ H x 2.63˝ W x 0.19˝ D
DESCRIPTION
For use with any 1-1/2˝ runway
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-CFTRC-6
OR-CFTRC-6B
6.00˝ H x 0.75˝ W x 1.15˝ D
OR-CFTRC-12 OR-CFTRC-12B 12.00˝ H x 0.75˝ W x 1.15˝ D
OR-P401750H-1D
Cable Runway Feet
Cable runway feet anchor runway to
the wall or floor. Feet are attached to
runway with clamps. Made of 3/8˝ x
1-1/2˝, steel bar. One foot included.
OR-P139240HD
Shelf Brackets
Shelf brackets attach to the wall and
extend up to 24˝ for heavy duty runway
support. Runway is secured to the
bracket with J-bolts (included). Made
of 3/16˝ x 1˝, steel bar. Hardware is
zinc plated and dichromated.
OR-P820527H
Cable Bracket
The Ortronics steel cable bracket
offers a separate channel for power
cables that must not contact primary
cables. Mounting hardware included.
Mounts on 1-1/2˝ and 2˝ stringers.
136
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-P401750H-1D OR-P401750H-1DB
6.00˝ H x 2.00˝ W x
1.50˝ D
OR-P820827H
OR-P820827HB
Kit of two 6˝ H cable
runway feet and 2
straight clamps
PART NO.
DOVE GRAY
PART NO.
BLACK
OR-P139240HD
OR-P139240HB
A 6.44˝, B 6.44˝,
runway width: 6.00˝
OR-P139340HD
OR-P139340HB
A 12.44˝, B 12.44˝,
runway width: 12.00˝
OR-P139540HD
OR-P139540HB
A 18.44˝, B 18.44˝,
runway width: 18.00˝
OR-P139740HD
OR-P139740HB
A 24.44˝, B 24.44˝,
runway width: 24.00˝
PART NO.
DOVE GRAY
PART NO.
BLACK
OR-P820527H
OR-P820527HB
DESCRIPTION
DESCRIPTION
4.50˝ H x 5.00˝ D,
1.30 lbs
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-TRP5-CM
Transition Pans
Assure the proper bend radius for
cables delivered from overhead runway
to equipment racks with our transition
pan. Each pan clamps to runway cross
members or runway stringers (TRP8-S).
Truss head screws with protective
covers assure cables aren’t damaged.
Provides 1.25˝ radius.
OR-P128040HD
Wall Angle Assemblies
DESCRIPTION
OR-TRP5-CM
2.00˝ H x 5.00˝ W x 4.13˝ D
OR-TRP8-CM
2.00˝ H x 8.00˝ W x 4.13˝ D
OR-TRP11-CM
2.00˝ H x 11.00˝ W x 4.13˝ D
OR-TRP17-CM
2.00˝ H x 17.00˝ W x 4.13˝ D
OR-TRP8-S
2.00˝ H x 7.50˝ W x 4.63˝ D
Black finish. CM= pan mounts on runway cross member;
S= pan mounts on runway stringer.
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-P128040HD
OR-P128040HB
For runway width: 6.00˝
OR-P128240HD
OR-P128240HB
For runway width: 12.00˝
OR-P128440HD
OR-P128440HB
For runway width: 18.00˝
OR-P128640HD
OR-P128640HB
For runway width: 24.00˝
Runway Ceiling Kit
PART NO.
DESCRIPTION
Kit consists of:
OR-RCBK-6
The Runway Ceiling Kit is used to suspend
cable runway from the ceiling.
PART NO.
DESCRIPTION
OR-REK-2-3
2˝, 2.5˝ or 3˝
OR-REK-4-6
4˝, 5˝ or 6˝
Wall angle assemblies attach to the
wall and provide a shelf or edge on
which runway can be anchored
using J-bolts. Anchoring can be either
parallel or perpendicular to the wall.
Includes 2˝ x 2˝ x 1/4˝ steel angle, two
J-bolts, two 1/4-20˝ hex nuts, and two
1/4˝ lock washers. Hardware is zinc
plated and dichromated.
OR-RCBK-6
PART NO.
n (1) Ceiling hanger bracket
n (1) Closed clip
n (1) 5/8-11 x 6ft threaded rod
n (4) 5/8-11 hex nuts
OR-REK-2-3
Runway Elevation Kit
Used to provide additional space
between the tops of racks or cabinets
and the runway. Can be mounted to
the runway junction plates, Mighty Mo®
runway support brackets or to the rear
flange of a Mighty Mo rack. Can also
be mounted to the Mighty Mo cabinets
simply by drilling two holes into the
cabinet’s removable top plates.
Black finish.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
137
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-P400298HD
Ceiling Hanger Brackets
PART NO.
DOVE GRAY
PART NO.
BLACK
When ceiling support is required, ceiling
hanger brackets are used with 5/8-11˝
threaded rods and open or closed clips
to suspend runway overhead.
OR-P400298HD OR-P400298HB (1) Bracket
DESCRIPTION
OR-P820667HD OR-P820667HB (1) Bracket; (2) nuts
OR-P820677HD OR-P820677HB
(1) Bracket; (2) nuts;
(1) plate*
* Plate color matches bracket.
OR-2-E1-25C-A
Protective Rubber
End Caps
Protective end caps conceal sharp
runway edges that may harm the
installation or injure those administering
the installation. Sold in pairs.
OR-RHB-12B
OR-P406395H
Runway Hanger Brackets
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-RHB-06D
OR-RHB-06B
OR-RHB-12D
OR-RHB-12B
12.00˝ H x 12.38˝ W x 2.00˝ D,
runway width: 12.00˝
Open Clips
PART NO.
DESCRIPTION
OR-P406395H
(1) clip
OR-P820547H
Two sides - (2) clips; (4) nuts
Closed Clips
Vertical Wall Bracket
Made of 1/8˝ x 2 steel, vertical wall
brackets fasten runway to the wall
and provide a secure route for cables
to channel vertically. Use 7/16˝
mounting hardware (not included).
One bracket included.
138
OR-2-E1-25C-A For 1-1/2˝ stringers
Black rubber.
12.00˝ H x 6.38˝ W x 2.00˝ D,
runway width: 6.00˝
Use closed clips with 1-1/2˝ stringers to
secure runway to threaded rods when
suspending runway from the ceiling.
Also use when stacking runway. Use
with 5/8-11˝ threaded rod. Made of
1/4˝ x 1-1/4˝ steel bar. UL classified.
OR-P982078HD
DESCRIPTION
Cable runway feet anchor runway to
the wall or floor. Feet are attached to
runway with clamps. Made of 3/8˝ x
1-1/2˝, steel bar. One foot included.
Use open clips with 1-1/2˝ stringers
to secure runway to threaded rods
when suspending runway from the
ceiling. Also use when stacking
runway. Use with 5/8-11˝ threaded
rod. Made of 3/16˝ x 1-1/2˝ steel bar.
UL classified.
OR-P429503H
PART NO.
Clear zinc plated.
PART NO.
DESCRIPTION
OR-P429503H
(1) clip
OR-P820477H
Two sides - (2) clips; (4) nuts
Clear zinc plated.
PART NO.
DOVE GRAY
PART NO.
BLACK
DESCRIPTION
OR-P982078HD OR-P982078HB 1.50˝ H x 2.00˝ W x 2.53˝ D
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
BONDING & GROUNDING | RUNWAY & ACCESSORIES
Tubular Runway & Accessories
NOTE: Product dimensions are listed by width, height and depth unless specified otherwise.
OR-P987650H
Threaded Rods (5/8-11˝)
Threaded rods are available in a variety
of lengths to support runway sections
suspended from the ceiling. Includes
two 5/8-11˝ hex nuts and two 5/8˝
flat washers.
OR-2-E1-75
Threaded Rod Coupler
PART NO.
DESCRIPTION
OR-P987650H
Length of rod 5´
OR-P987649H
Length of rod 6´
OR-P987645H
Length of rod 10´
Zinc plated and dichromated.
PART NO.
DESCRIPTION
OR-2-E1-75
Join two 5/8˝ threaded rods together,
kit contents: (1) 5/8˝ coupler,
(2) 5/8˝ x 11˝ hex nut
Protective Sleeve
PART NO.
DESCRIPTION
Slitted protective sleeves cover
threaded rods to protect cables from
damage. Field cut to desired size.
OR-2-E2-TRPC
10´ PVC protective sleeve for
5/8-11˝ threaded rod
J-Bolt Assemblies
PART NO.
DESCRIPTION
Each J-bolt assembly includes one
1/4-20˝ or 5/16-18˝ hex nut and
one 1/4˝ or 5/16˝ lock washer.
UL classified.
OR-P987529H
A = 1.75˝, B = 0.250˝, C = 0.50˝, D = 0.75˝,
thread size: 1/4-20
OR-P987528H
A = 3.25˝, B = 0.438˝, C = 0.75˝, D = 1.50˝,
thread size: 1/4-20
OR-P987527H
A = 2.25˝, B = 0.438˝, C = 0.75˝, D = 1.00˝,
thread size: 1/4-20
OR-P987526H
A = 3.75˝, B = 0.313˝, C = 0.75˝, D = 1.25˝,
thread size: 5/16-18
OR-P987525H
A = 3.25˝, B = 0.313˝, C = 0.75˝, D = 0.75˝,
thread size: 5/16-18
OR-P987524H
A = 3.25˝, B = 0.438˝, C = 0.75˝, D = 1.50˝,
thread size: 5/16-18
OR-P987523H
A = 2.25˝, B = 0.438˝, C = 0.75˝, D = 1.00˝,
thread size: 5/16-18
Features:
n Extend threaded rod length with
spliced coupling
n Yellow zinc dichromate finish
n Constructed of steel
OR-2-E2-TRPC
OR-P987527H
A
B
D
C
Clear zinc plated.
For additional product availability visit www.ortronics.com or contact sales at 860-405-2895
139
Europe/Middle East/Africa
Great King Street North
Birmingham, B19 2LF
United Kingdom
Phone: +44.01215.150.669
Fax: +44.01215.150.667
Latin America Headquarters
Montes Urales NO. 715 3er Piso
Col. Lomas de Chapultepec
MEXICO D.F. - C.P. 11000
Phone: +52.55.5201.6450
Asia Pacific Headquarters
125 Eugene O’Neill Drive
New London, CT 06320
Phone: 860.445.3900
Fax: 860.405.2992
Global Headquarters
125 Eugene O’Neill Drive
New London, CT 06320
Phone: 800.934.5432
or 860.445.3900
Fax: 860.405.2992
www.ortronics.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
