Operation of Tuner

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings.

Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.

A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

PORTABLE CART WARNING

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

2

Introduction

READ THIS BEFORE OPERATING YOUR UNIT

CAUTION

: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

Caution regarding installation

Note : For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure.

Do not block ventilation openings or stack other equipment on the top.

Note to CATV System Installer :

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.

CLASS 1

LASER PRODUCT

CAUTION

Invisible laser radiation when the unit is open.

Do not stare into beam.

CAUTION : USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN THOSE

SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

3

PRECAUTIONS

4

CONTENTS

• IMPORTANT SAFETY INSTRUCTIONS | 2

• Introduction

READ THIS BEFORE OPERATING YOUR UNIT | 3

• System Connections | 6

• Controls & Displays

FRONT PANEL CONTROLS

| 10

UNIVERSAL REMOTE CONTROLS | 12

ENTERING A SETUP CODE | 13

OPERATING COMPONENTS WITH REMOTE CONTROL | 14

REMOTE CONTROL OPERATION RANGE | 14

LOADING BATTERIES | 14

• Basic Operation

LISTENING TO A PROGRAM SOURCE | 15

• Operation of DVD player

PRELIMINARY KNOWLEDGE ABOUT DISCS | 17

SYMBOL ABOUT INVALID OPERATION | 17

AUDIO AND VIDEO FILES | 18

CARE AND HANDLING OF DISCS | 18

DEFINITION OF TERMS | 19

BASIC PLAYBACK | 21

DISPLAYING DISC INFORMATION DURING PLAYBACK | 25

PLAYING A SPECIFIC ITEM | 26

REPEAT PLAYBACK | 27

RANDOM PLAYBACK | 28

PROGRAMMED PLAYBACK | 28

CHANGING THE AUDIO LANGUAGE | 33

CHANGING THE SUBTITLE LANGUAGE | 33

CHANGING THE CAMERA ANGLE | 34

ZOOMING IN/OUT A SCENE | 34

CHANGING THE VIDEO SIGNAL FORMAT | 35

CHANGING THE RESOLUTION OF COMPONENT VIDEO OUTPUT SIGNAL | 35

• Initial Settings | 36

SETTING THE LANGUAGE SETUP | 37

SETTING THE VIDEO SETUP | 38

SETTING THE AUDIO SETUP | 40

SETTING THE OTHER SETUP | 41

• Operation of Tuner

LISTENING TO RADIO BROADCASTS | 46

• Operation of Other Functions

RECORDING WITH VIDEO | 48

SETTING THE CLOCK | 49

OPERATING THE TIMER | 50

ADJUSTING THE BRIGHTNESS OF THE DISPLAY | 52

OPERATING THE SLEEP TIMER | 52

• Troubleshooting Guide | 53

• Specifications | 55

• Setup Code Table | 57

5

System Connections

• Do not plug the AC input cord into the wall AC outlet until all connections are completed.

• Be sure to observe the color coding when connecting audio and video cords.

• Make connections firmly and correctly. If not, it can cause loss of sound, noise or damage to the unit.

1.

CONNECTING ANTENNAS

• Change the position of the FM indoor antenna until you get the best reception of your favorite FM stations.

• A 75

Ω outdoor FM antenna may be used to further improve the reception. Disconnect the indoor antenna before replacing it with the outdoor one.

• Place the AM loop antenna as far as possible from the receiver, TV set, speaker cords and the AC input cord and set it to a direction for the best reception.

• If the reception is poor with the AM loop antenna, an AM outdoor antenna can be used in place of the AM loop antenna.

6

2.

CONNECTING AUDIO COMPONENT

• The AUX 1 jacks can be connected to an audio component such as a CD player, tape deck, etc.

7

4.

CONNECTING TV

Pr Pb Y

8

Controls & DIsplays

10

UNIVERSAL REMOTE CONTROLS

12

OPERATING COMPONENTS WITH REMOTE

CONTROL

1.

Enter the setup code for each component other than this unit you wish to control. (For details, refer to "ENTERING A SETUP CODE" on page

13.)

2.

Turn on the component you want to operate.

3.

Press the DEVICE button on the remote control corresponding to the component you wish to operate.

Example) When selecting "MAIN" to operate this unit.

REMOTE CONTROL OPERATION RANGE

• Use the remote control unit within a range of about 5 meters (16 feet) and angles of up to 30 degrees aiming at the remote sensor.

4.

Aim the remote control at the REMOTE

SENSOR of the component you wish to control and press the button corresponding to the operation you want.

LOADING BATTERIES

• When the remote control does not operate, the old batteries should be replaced. In this case, load new batteries within several minutes after removing old batteries.

• If the batteries are removed or have been exhausted for a longer period of time, memorized contents will be cleared.

Should this happen, you should memorize them again.

1.

Remove the cover.

2.

Load two batteries ("AAA" size) matching the polarity.

14

• Remove the batteries when they are not used for a long time.

• Do not use the rechargeable batteries(Ni-Cd type).

• Be sure to use alkaline batteries.

Basic Operation

LISTENING TO A PROGRAM SOURCE

1.

Turn the power on.

3.

Turn on the source component for playback.

4.

Operate the selected component for playback.

5.

Adjust the(overall) volume to a comfortable listening level.

6.

To mute the sound.

2.

Select the desired input source.

7.

To listen with the headphones.

15

Adjusting the channel level(/setting the FM mode)

• The volume level of each channel can be adjusted as desired.

Selecting a surround mode

• While playing the selected input source

16

SYMBOL ABOUT INVALID OPERATION

AUDIO AND VIDEO FILES CARE AND HANDLING OF DISCS

18

DEFINITION OF TERMS

DVD Video

The format for storing MPEG-2 video on DVD, with interactive menus, multiple soundtracks, subtitles, camera angles, and so on.

MPEG(Moving Picture Expert Group)

It is regarded as an international standard for compressing and restoring digital video and audio signal. "MPEG" standards include MPEG-1, MPEG-2 and MPEG-4. Video

CD and MP3 are based on MPEG-1, while DVD Video is based on MPEG-2.

MP3

MP3 is an audio data compression format, which stands for

MPEG-1 Audio Layer 3. Using MP3, you can achieve a data reduction of about 1:10.

• MPEG Layer-3 audio coding technology licensed from

Fraunhofer IIS and Thomson.

WMA(Windows Media Audio)

WMA is an audio data compression format developed by

Microsoft Corporation. WMA file size is smaller than that of

MP3.

JPEG(Joint Photographic Experts Group)

JPEG is a papular file format for still image compression and storage.

There are three sub-types of the JPEG format as follows.

• baseline JPEG : used for digital cameras, the web, etc.

• progressive JPEG : used for the web.

• lossless JPEG : an old type, rarely used now.

DVD Video structure

DVD Video discs typically contain one or more titles, which may be subdivided into chapters.

Audio CD structure

Audio CDs contain tracks.

MP3/WMA/JPEG structure

On an MP3/WMA/JPEG disc, a folder can be a member of another folder, creating hierarchical folder layers. If you are familiar with a personal computer, you may easily understand the hierarchical file/folder construction.

Aspect ratio (DVD Video)

The aspect ratio is the ratio between the vertical and horizontal size of the picture displayed on a TV screen. The aspect ratio of normal TV screen is 4:3 while that of the wide-screen TV and HDTV screen is 16:9.

Subtitle (DVD Video)

Some DVD Videos contain the recording of more than one subtitle languages. With these discs, this unit can select one of the subtitle languages as desired during playback.

Angle (DVD Video)

Some DVD Videos contain scenes which have shot simultaneously from multiple camera angles. With these discs, the same scene can be viewed from each of these different angles.

19

BASIC PLAYBACK

21

To play files from USB mass storage device

23

24

Rapid playback during playback

Slow playback during playback

DISPLAYING DISC INFORMATION DURING PLAYBACK

• The unit features the on-screen display function showing disc information.

Press the DISPLAY button.

• Then the disc information is displayed on the TV screen.

• Each time this button is pressed, the disc information is changed depending on the disc types as follows :

• Depending on the disc and some operation status as playback of DVD Video using a title or DVD menu, etc., the disc information may not be displayed.

25

PLAYING A SPECIFIC ITEM

When using a title menu

• If some DVD Videos which contain more than one title may have the menu like as a list of the titles, the TITLE button can be used to select the desired title. (The details of operation differ depending on the disc used.)

1.

During playback, press the TOP MENU button.

• Then a list of titles on the disc is displayed on TV screen.

• If the disc does not have the menu such as a list of titles, this function does not work.

• The unit starts playback of the selected title.

• When the menu continues onto another screen, repeat this step until the desired title is selected.

When using a DVD menu

• Some DVD Videos have unique menu structures called DVD menus. For example, the discs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language.

Although the DVD menu’s contents and operation differ from disc to disc, the following explains basic operation when this feature is used.

1.

During playback, press the MENU button.

• Then the DVD menu available on the disc is displayed on

TV screen.

• If the disc does not have the DVD menu, this function does not work.

26

• The unit starts playback of the selected item.

• When the menu continues onto another screen, repeat this step until the desired item is selected.

REPEAT PLAYBACK

During playback of the desired title, chapter, folder, track or file, press the REPEAT button.

• Then the selected repeat mode is displayed on the TV screen.

• Each time this button is pressed, the repeat mode changes depending on the disc types as follows :

• To return to normal playback, press the REPEAT button repeatedly to select the Repeat off, Disc or Folder.

27

PROGRAMMED PLAYBACK

28

Continued

31

CHANGING THE VIDEO SIGNAL FORMAT

35

SETTING THE LANGUAGE SETUP

37

SETTING THE VIDEO SETUP

• TV DISPLAY : When selecting a picture size according to the aspect ratio of your TV's screen.

• TV SYSTEM : When selecting the desired video signal format to match that of your TV monitor and DVD Video to be played.

• SCAN TYPE : When outputting the video signals in the desired resolution from the unit's COMPONENT MONITOR

OUTs.

• Then the setting menu of the selected item is displayed.

38

39

SETTING THE AUDIO SETUP

40

• ON : When turing on the screen saver function.

• OFF : When turning it off.

41

Continued

When selecting the PASSWORD

44

Operation of Tuner

LISTENING TO RADIO BROADCASTS

Auto tuning

1.

Select the tuner.

Manual tuning

• The tuner will now search until a station of sufficient strength has been found. The display shows the tuned frequency and "TUNED" indicator lights up.

• If the station found is not the desired one, simply repeat this operation.

• Weak stations are skipped during auto tuning.

46

3.

Select the desired preset number (01~40) and press the PROGRAM button.

• When using the NUMERIC buttons on the remote control.

Examples)

For "3" :

For "21" :

For "40" :

4.

Repeat the above steps 1 to 3 to memorize other stations.

47

Operation of Other Functions

RECORDING WITH VIDEO

48

SETTING THE CLOCK

49

OPERATING THE TIMER

50

Continued

8.

(In case of DVD Video, at the scene to be played back,) turn the power off before on time.

52

Troubleshooting Guide

53

[TUNER SECTION]

PROBLEM

Stations cannot be received

Preset stations cannot be received

Poor FM reception

POSSIBLE CAUSE

• No antenna is connected.

• The desired station frequency is not tuned in.

• The antenna is in wrong position.

REMEDY

• Connect an antenna.

• Tune in the desired station frequency.

• Move the antenna and retry tuning.

• An incorrect station frequency has been memorized.

• The memorized stations are cleared.

• Memorize the correct station frequency.

• Memorize the stations again.

• No antenna is connected.

• The antenna is not positioned for the best reception.

• Connect an antenna.

• Change the position of the antenna.

54

Daewoo

Daytron

Denon

Dumont

Dwin

Electroband

Emerson

Envision

Fisher

Fujitsu

Funai

Futuretech

GE

Gibralter

Setup Code Table

TV

AOC

Admiral

Aiko

Akai

Alaron

Ambassador

America Action

Ampro

Anam

Audiovox

Baysonic

Belcor

Bell & Howell

Bradford

Brockwood

Broksonic

CXC

Candle

Carnivale

Carver

Celebrity

Cineral

Citizen

Concerto

Contec

Craig

Crosley

Crown

Curtis Mathes

005 003

041 031

014

005

026

024

027

043

027 047 048 049

030 027 014 034

027

003

019 001

027

003

028 031

027

005 011

005

010

050

030 014

012 005 011 006 014

011

027

027

010

027 006

007 010 019 008 030 041

012 005 016 011 001 006

022 032 038 040

030 003 006 014 034 035

003

016

002 003

044 036

050

019 028 031 027 029 025

003 026 006 024 034 035

005

019

026

027 026 023

027

007 008 030 041 029 025

004 015 038 040

002 005 003

Midland

Minutz

Mitsubishi

Motorola

Multitech

NAD

NEC

NTC

Nikko

Onwa

Optimus

Optonica

Orion

Panasonic

Penney

Pilco

Philips

JBL

JCB

JVC

KEC

KTV

Kenwood

LG

LXI

Logik

Luxman

MGA

Goldstar

Gradiente

Grunpy

Hallmark

Harley Davidson

Harman/Kardon

Havard

Hitachi

Infinity

Inteq

MTC

Magnavox

Majestic

Marantz

Matsushita

Magatron

Memorex

005 025 003 011

009 011

027 026

025

026

010

027

016 011 018

010

002

010

050

009 046

027

027 005 006

005 003

011

007 010 019 020 025

001

011

017 005 025 003

012 005 003 011

010 005 026

001

010 005

042

025 016

019 042 031 017 025 011

001

007 002 008 006 015

004

041 017 025 003

041

027

020 025 022

005 003 011

014

005 025 014

027

019 042 022

041 021

028 031 026

008 042

007 020 008 012 005 025

004 003 011 006 015 040

010 031 005 016 003

010

57

Realistic

Runco

SSS

Sampo

Samsung

Samsux

Sansei

Sansui

Sanyo

Scimitsu

Scotch

Scott

Sears

Pilot

Pioneer

Portland

Prism

Proscan

Proton

Pulsar

Quasar

RCA

Radio Shack

Semivox

Semp

Sharp

Sherwood

Shogun

Signature

Sony

Soundesign

Squareview

Starlite

Supreme

Sylvania

Symphonic

TMK

Tandy

Technics

Technoi Ace

Techwood

Teknika

Telefunken

Toshiba

Totevision

Vector Research

Victor

Vidikron

005 003 006

022

003 006 014

008

007

025 032

002 003

008 042 021

007 008 041 003 013 015

037 038 039 040

007 019 021 027 005 025

003 011 006

019 021 027 005 025 003

011 006

002 005 033

027 003

005 006

012 005 025 003 011 045

006

030

031

019

003

025

028 027 025 003 026

007 010 019 020 025 026

011 023

027

020

041 021 006

000

003

001

050

027 025 026

023

027

050

010 005

023

025 011 024

041

008 042

026

008 011

010 027 017 012 003 026

011 001 006 014

011

019 020 012

006

005

009

010

58

Vidtech

Wards

White Westinghouse

Yamaha

Zenith

025 003

010 021 005 025 004 003

026 011 001

031 034 035

005 003

002 031 001 014

VCR

Admiral

Adventura

Aiko

Aiwa

Akai

America Action

America High

Asha

Audiovox

Beaumark

Bell & Howell

Brocksonic

Broksonic

CCE

Calix

Canon

Carver

Cineral

Citizen

Colt

Craig

Curtis Mathes

Cybernex

Daewoo

Denon

Dynatech

Electrohome

Electrophonic

Emerex

Emerson

Fisher

Fuji

Funai

GE

Garrard

GoldStar

Gradiente

HI-Q

Harley Davidson

Harman/Kardon

Harwood

027 021

000

025

005 000

026

025

004

023

005

023

017

021

020 018 021 001

015 025

005

004

016

025

005 025

015

005 012 023 015 024

013 004 026 028

023

010 025

008

000

005

005

002

005 020 000 018 009 021

001 025

012 017

004 003

000

013 004 027 023

000

005 006

000

012

000

016 006

015

Headquarter

Hitachi

JVC

Jensen

KEC

KLH

Kenwood

Kodak

LXI

Lloyd’s

Logik

MEI

MGA

MGN Technology

MTC

Magnasonic

Magnavox

Magnin

Marantz

Marta

Matsushita

Memorex

Minolta

Mitsubishi

Motorola

Multitech

NEC

Nikko

Noblex

Olympus

Opimus

Orion

Panasonic

Penny

Pentax

Philco

Philips

Pilot

Pioneer

Profitronic

Proscan

Protec

Pulsar

Quarter

Quartz

Quasar

RCA

Radio Shack

Radix

Randex

011

000 008 026

014 026

026

005 025

015

014 026 006

004 005

005

000

015

004

023 009

023

023 000

025

004 007 016 000 019

023

004 016

005

004 028 029

004 005 027 007 012 023

000 017 021 011 031 032

008

027 014 009

004 016

000 015

017 014 026 006

005

023

004

005 027 017 028 029 030

031 032

020 021 001

004 028 022 029 031

004 005 023 008 006

008

004 021

004 016

005

014

023

013

015

007

011

011

004 028 029 031

013 004 027 023 008 019

000

005

005

Runco

STS

Samsung

Sanky

Sansui

Sanyo

Scott

Sears

Semp

Sharp

Shintom

Shogun

Singer

Sony

Syvania

Symphonic

TMK

Tatung

Teac

Technics

Teknika

Thomas

Toshiba

Totevision

Unitech

Vector

Vector Research

Video Concepts

Videosonic

Wards

Realistic

White WestingHouse

XR-100

Yamaha

Zenith

004 005 027 012 000 017

011

007

008

023 010 033

027 007

000 014 021 026 024

012 023 017 011

020 010 018 009

004 005 012 000 008 017

011

010

027

015

023

015

004 002 000 003

004 016 000 009

000

023

026

000 026

004 028

004 005 000

000

010 009

005 023

023

010

006

010

023

013 004 027 012 016 023

000 008 015 019

021 025

004 000 015

006

007 000 021 003

VCR - TV/VCR

Ameira High

Brocksonic

Colt

Cutis Mathes

Daewoo

Emerson

Funai

GE

Hitachi

004 (TV use 008)

001

015

004 (TV use 008)

025

001

000

004 (TV use 008) 013 (TV use 007)

027 (TV use 041) 023

004 (TV use 008) 000

59

HQ

Lloyds

MGA

Megavox

Magnin

Memorex

Mitsubishi

Orion

Panasonic

Penney

Quasar

RCA

Sansui

Sanyo

Sear

Sharp

Sony

Symphonic

Zenith

CBL

000

000

023

016 (TV use 010) 004 (TV use 008)

000

023

005 028 (TV use 042)

027 (TV use 041)

001

004 (TV use 008) 028 (TV use 042)

004 (TV use 008) 023

028 (TV use 042)

004 (TV use 008) 028 (TV use 042)

013 (TV use 007) 004 (TV use 008)

027 (TV use 041)

000

023

000 005

027 (TV use 041)

002 (TV use 050)

000

000

ABC 002 003 009 030 006 008

037 107 036 059 062 066

Adelphia

Allegro

Altrio

Americast

Archer

Armstrong

072

063

018

063

103

018

085

085

021

026

AT&T Broadband 085

Atlantic Broadband 063 085

038 040 047

Bell South

Bell&Howell

Blue Ridge

Bresnan

Bright House

Buckeye Comm

Cablevision

Centurion

Century

Charter

Citizen

Cogeco

Combano

Comcast

103

009

063

085

063

085

063

096

063

018

085

089

063

085

114

085

018 040

085

021

090

085

112

040

114

Comsat

Comtronics

Contec

Cox Digital

Digicable

Eagle

Eastern

Echostar

Electricord

Emerson

Everquest

Focus

Garrard

Gemini

General Electric

General Instrument

085

014

011

063 085

105

050 052 060

001 076 081

110

054

026

010 014

022

018

010 041 073

084

033 032 006 034 085 107

108

103 GNC

Golden Channel

GoldStar

Goodmind

Hamlin

Hitachi

Insight

Jasco

Jerrold

Magnavox

Massillon

Media One

Medicom

Memorex

Mitsubishi

Motorola

Movie Time

Moxi

Nctc

NSC

Oak

Optimus

Pace

Panasonic

Paragon

Philips

052

017 014

026

012 020 004 013 068 069

074

006 107 074

085

010 018 021

002 007 033 032 009 010

006 034 035 036 037 041

042 043 082 085 107

043

085

111

074

000

106

085

015

045

071

114

028

080

113

054

088

106

099 098

106

085

015 048 051 058 083

011 053 057 072

031

063 085

000 016 031 064 067

000 071

018 039 045 046 050 091

099

Pioneer 017 025 063 107 055 070

079 086 109

Popular Mechanics 022

Prucer 077

Pulsar 000 071

60

Quasar

RCA

Radio Shack

Recoton

Regal

Regency

Rembrandt

Rodgers

Runco

Samsung

Scientific Atlanta

Seren

Service Electric

Shaw

Sherwood

Sigecom

Signal

Signature

SL Marx

Sony

Sprucer

Starcom

Stargate

Starquest

Susquehanna

Teleview

Time Warner

Tocom

Toshiba

Tusa

TV86

Unika

United Cable

Universal

Videotron

Viewstar

Wide Open West

Zenith

Zentek

000

031 067

010 021 026 028

022 102

012 020 068 069

001 076

006

063

000

017 014 052

003 023 030 027 063 044

036 061 062 065 066

063

085

085

000

063

010 014

006

014

100 112

031 067 087

002 010 035 037 041 042

010 014 026 041 052 101

108

010

063 085

014

063 085

007 008 059 060 075

000 071

010

015

018

037 072

018 019 038 040 047 054

056

063

015 045 048 049 092 093

094 095

063 103

000 024 071 078 097 104

022

SAT

Primestar

Proscan

Radio Shack

RCA

Realistic

RSA

Samsung

Sherwood

SKY

Sony

Star Choice

Toshiba

Uniden

Zenith

AlphaStar

Cablevision/voom

Chaparral

Directv

Echostar/dish

Expreevu

Expressvu

General Electric

General Instrument

Goi

Hitachi

HTS

Hughes

Hughes Net.Sys

JVC

Jerrold

LG

Magnavox

Megavox

Memorex

Mitsubishi

Motorola

Next Level

Panasonic

Pansat

Philips

008

031

001

053

009 024 049 050

009

024

033 021 032

016 015 018 031

024

011 028 029

009 024

043 044 019 036 047 048

022 023

007

009 024

016 015

052

027

006 005

006

019 036

031

018 031

017 030 042

027

006 005 034 035 038 019

036 027 022 023

016 015

033 021 032

018 031

003 000 002 012

014

033 021 032

025 037 045 051 054

000

046

004 020

018 031

010 026 019 036 039 040

006 005 014 027

013 041

61

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
