Mighty Mo® 10 and Mighty Mo 6 Advanced Cable Management

Mighty Mo® 10 and Mighty Mo 6 Advanced Cable Management
Mighty Mo® 10
and Mighty Mo 6
Advanced Cable
Management
Systems for Data
Centers and LAN
Applications
the
MIGHTY MO
®
data center
T h r e e k e y fa c t o r s
are essential considerations when
evaluating cable management
7
6
5
4
systems for today’s data centers,
3
2
Layer
ZERO
storage area networks (SAN), and
1
0
large premise networks.
Airflow
The heat generated from increased server densities
and higher speed network equipment makes cooling
a top concern for today’s IT administrators and data
center managers. With heat being the most common
reason for equipment failures, proper cooling is
essential to reliable operations. Designed specifically
to improve airflow, Ortronics® Mighty Mo 10 cable
management system enables more efficient cooling
and reduces power consumption.
Density
APPLICATION LAYER
PRESENTATION LAYER
SESSION LAYER
TRANSPORT LAYER
Layer 0™
network design
Layer
ZERO
NETWORK LAYER
DATA LINK LAYER
PHYSICAL LAYER
INFRASTRUCTURE LAYER
7
6
5
4
3
2
1
0
03
Protection & Performance
To ensure maximum network performance, Mighty Mo
cable management systems protect patch cords, cable,
and equipment ports from damage by maintaining
proper bend radius requirements, reducing tension on
plugs and jacks, protecting network equipment ports,
and supporting large cable bundles within the rack.
www.ortronics.com
Ortronics/Legrand is revolutionizing networking by adding a new layer to the traditional network architecture.
The OSI network model is the accepted framework for network design and suggests seven layers to use for network planning. The bottom layer of this model is Layer One – the physical layer, which is the structured cabling
itself, but what Layer One does not include is the physical SUPPORT, or the infrastructure, for the cabling.
Ortronics/Legrand introduces Layer Zero as a new foundation for the OSI model to address the
critical role that infrastructure plays in network performance and provide a new level of stability to
the network. To ensure maximum network efficiency, we offer a complete range of Layer Zero solutions
designed to:
nReduce power consumption and cooling costs
nReduce the risk of equipment failure
nEnhance overall system performance
Mighty Mo cable management systems are fully
equipped to handle the density of today’s high
performance networks while allowing for easy moves,
adds, and changes. Both the Mighty Mo 10 and Mighty
Mo 6 systems provide ample capacity for a minimum
of 48 Category 6a patch cords per rack unit on a single
side of the equipment, which is often necessary to
avoid a fan tray, power supply or other removable part
of the equipment.
Maximum
airflow,
minimum
effort
Baffles redirect airflow
from side-vented
network equipment
from cold aisle
to hot aisle for
The Mighty Mo® 10, the next generation
maximum efficiency.
of Ortronics advanced cable management
system, is the first system to combine
enhanced cable management with
superior airflow in a rack.
For efficient cooling, proper airflow must be maintained in the
room, in underfloor and overhead plenums, and within the cable
management rack. The preferred method of cooling in today’s data
centers is the cold-aisle/hot-aisle approach.
rails remove the
barrier to network
equipment airflow.
05
www.ortronics.com
www.ortronics.com
04
The Mighty Mo 10 is ideal for maintaining cold-aisle/hot aisle
airflow, whether your network equipment is front-to-back, bottom
or side venting. The Mighty Mo 10 features honeycomb side rails and
baffles that redirect airflow from side vented equipment from the
cold aisle to the hot aisle. The perforated side rails allow ventilated
air to be exhausted, while the baffles ensure the proper flow of air
from cold aisle to hot aisle, even with side ventilation. This passive
system eliminates the additional 15 to 20 W of power that typical
fans consume, making for a more energy-efficient data center with
reduced power consumption and energy costs.
Honeycomb side
Mighty Mo ® Accessories
Mighty Mo 10 Cable
Management Cage with Door
Cage design promotes efficient
routing of patch cords between
racks. Hinged doors allow easy
mighty mo accessories
mighty mo 10
Mighty Mo ® 10
access during moves, adds, and
changes. 16” wide cage creates
a 12.25” gap between racks. 12”
Mighty Mo 10
wide cage creates a 8.25” gap
Cable Management Racks
between racks for front-to-back
Mighty Mo 10 racks are designed to maximize the airflow of network
routing of equipment cables and
equipment. Honeycomb side rails and baffles combine to manage
patch cords. Both are supplied
intake and exhaust air creating cold aisle/hot aisle air distribution
with four spools and 12 bend-
from side vented equipment. The bottom flange turns inward,
limiting clips.
allowing it to fit on a 2’x2’ floor tile.
Mighty Mo 10 Airflow Baffles
Mighty Mo 10 airflow baffles mount
OR-MM10716
between racks and direct intake and
16.25” channel depth, 7’, high, black, 45 rack units
exhaust air on side flow network
OR-MM10816
equipment from cold aisle to hot aisle.
16.25” channel depth, 8’, high, black, 51 rack units
Patent pending.
Note: Static capacity 1,500 lbs.
Assembly required.
Patent pending
Mighty Mo 10Vented Door Assemblies
Door design allows mounting to the front or
rear of any Mighty Mo 6 or Mighty Mo 10 rack.
The double-hinged door is lockable, pivots to
the right or left, and is easily removed.
06
Mighty Mo 10
Server Rack
The Mighty Mo 10 Server Rack works with all of the Mighty Mo 6 and 10
racks and cable management. The mounting rails adjust from 12.5” to 30”,
after the rack is installed. Mighty Mo vertical managers can be mounted
front or rear. Color is black.
OR-MM107SVR
Four-post aluminum frame with steel EIA rails, supplied with
50 #12-24 cage nuts and screws, 45 rack units, 7’ H
OR-MM107SVRABR
Server rack baffle rail for mounting airflow baffles
Note: Static capacity: 1,500 lbs. (evenly distributed). Assembly required.
OR-MM10AB71612
For use with 7’ x 16” Mighty Mo 10 rack
and 12” wide Mighty Mo 10 cage
OR-MM10AB71616
For use with 7’ x 16” Mighty Mo 10 rack
and 16” wide Mighty Mo 10 cage
OR-MM10AB81612
For use with 8’ x 16” Mighty Mo 10 rack
and 12” wide Mighty Mo 10 cage
OR-MM10AB81616
For use with 8’ x 16” Mighty Mo 10 rack
and 16” wide Mighty Mo 10 cage
OR-MM10AB73012
For use with 7’ Mighty Mo 10 server rack
and 12” wide Mighty Mo 10 cage
OR-MM10AB73016
For use with 7’ Mighty Mo 10 server rack
and 16” wide Mighty Mo 10 cage
Mighty Mo 10 Vented Door Assemblies
OR-MM10VDA7248
7’ x 24” with 8.38” of clearance behind
door for use with VMD-style vertical
managers
OR-MM10VDA7244
7’ x 24” with 4.38” of clearance behind
door for use without vertical managers
Mighty Mo 10 Cable
Management Cage with Door
OR-MM10VMD712
With door, 12.13” x 13” x 7’, 45 rack units
OR-MM10VMD716
With door, 16.38” x 13” x 7’, 45 rack units
OR-MM10VMD812
With door, 12.13” x 13” x 8’, 51 rack units
OR-MM10VMD816
With door, 16.38” x 13” x 8’, 51 rack units
Patent Numbers 6,946,605, 6,968,647 and
7,026,553
Note: Unless otherwise noted, all Mighty
Mo 6 and Mighty Mo 10 components are
compatible with both racks.
www.ortronics.com
www.ortronics.com
independent of the structural members allowing the rails to be adjusted
07
Mighty Mo 10 Airflow Baffles
Mighty Mo ® 6
Mighty Mo ® vertical management
mighty mo vertical management
mighty mo 6
Vertical Managers promote efficient routing of patch cords between racks.
Mighty Mo 6 Cable
Management Cage with Door
Hinged doors allow easy access
during moves, adds, and changes.
Mighty Mo 6
10” wide cage creates a 6.5” gap
Cable Management Racks
between racks. 6” wide cage cre-
Mighty Mo® 6 racks are available in 6.5”, 10.5” and 16.25” channel
front-to-back routing of equipment
depths. The 16.25” size is designed specifically for large and heavy
cables and patch cords. Both are
network equipment. The bottom flange on the 16.25” standard rack
supplied with four spools and 12
turns inward, allowing it to fit on a 2’ x 2’ floor tile.
bend-limiting clips.
ates a 2.5” gap between racks for
Mighty Mo 6
Vertical Management
Cage with Latches
OR-MM6706
6.5” channel depth, 7’ high, black, 45 rack units
OR-MM6710
Hinged latches allow easy
10.5” channel depth, 7’ high, black, 45 rack units
access during moves, adds,
OR-MM6810
and changes. 6” wide cage
10.5”channel depth, 8’ high, black, 51 rack units
creates a 2.5” gap between
OR-MM6716
racks for front-to-back
16.25” channel depth, 7’ high, black, 45 rack units
OR-MM6816
16.25” channel depth, 8’ high, black, 51 rack units
routing of equipment cables
Mighty Mo 6Vertical Management Cage with Cover
and patch cords.
Dual snap-on hinged covers allow easy access during moves,
Note: OR-MM6710 and OR-MM6716 are available in seismic
versions. For more information, contact an Ortronics/Legrand
sales representative or refer to the 2009/2010 full-line catalog.
adds, and changes. 6” wide cage creates a 2.5” gap between
Patent No. D360,189
12 bend-limiting clips.
racks for front-to-back routing of equipment cables and
patch cords. 6” wide cage is supplied with four spools and
08
09
Mighty Mo Speednut
Included with every Mighty Mo cable management rack!
The Mighty Mo Speednut increases the speed and ease of
assembly while adding extra strength to your racks. Hold the
Speednut behind the rack while hand-tightening the bolts in
front. Speednut eliminates the need for a second wrench!
Finish tightening with a wrench and your rack is ready to load.
Mighty Mo 6 Vertical Cable
Management Cage with Cover
Mighty Mo 6 Vertical Cable
Management Cage with Latches
OR-MM6VMD710
With door, 10” x 13” x 7’, 45 rack units
OR-MM6VMS704
With cover, 4” x 7” x 7’, rack units
OR-MM6VML704
With latches, 4” x 6” x 7’, rack units
OR-MM6VMD706
With door, 6” x 8” x 7’, 45 rack units
OR-MM6VMS706
With cover, 6” x 7” x 7’, rack units
OR-MM6VML706
With latches, 6” x 6” x 7’, rack units
OR-MM6VMD810
With door, 10” x 13” x 8’, 51 rack units
OR-MM6VMS804
With cover, 4” x 7” x 8’, rack units
OR-MM6VML804
With latches, 4” x 6” x 8’, rack units
OR-MM6VMD806
With door, 6” x 8” x 8’, 51 rack units
OR-MM6VMS806
With cover, 6” x 7” x 8’, rack units
OR-MM6VML806
With latches, 6” x 6” x 8’, rack units
Patent No. 6,946,605, 6,968,647 and
7,026,553
Patent No. 6,946,605, 7,026,553
Patent No. 6,365,834
Note: Unless otherwise noted, all Mighty Mo 6 and Mighty Mo 10 components are compatible with both racks.
www.ortronics.com
www.ortronics.com
Faster Assembly!
Mighty Mo 6 Cable
Management Cage with Door
Cable Management Rings
Mighty Mo Runway
Ceiling Extension Kit
These black plastic rings flex at the end for easy insertion or removal of cross connect cables. They snap in place on the front and
Cable Management Rings
back of the Mighty Mo racks. Black. Includes mounting hardware.
Mighty Mo® 6 Cable Trough
For supporting fiber cables at the
These rings allow efficient routing
of patch or cross connect cables
MightyMoCableManagementSpools
between distribution racks. They
Cable management spools effectively man-
can be mounted where needed on
age excess copper or fiber cable slack. They
the front and back of the Mighty Mo
bottom of Mighty Mo racks. The kit
includes an extension that bridges
the space between racks.
Mounts on the top of Mighty Mo
racks. The kit extends one channel
24” and is supplied with a cover
to hide the cables.
Extension uses rack
hardware for mounting.
One per kit with cover.
mount at rack unit intervals, providing flex-
racks. Black. Includes
ibility and proper bend radii for cables on the
mounting hardware.
mighty mo accessories
mighty mo accessories
Mighty Mo ® accessories
MightyMoEndPanel
front of the 6” wide cage with door
The end panel is used
or on the front and rear of the 10”
to finish the end of a
wide cage with door. Set of four.
row of Mighty Mo racks.
It mounts flush and
provides a surface for the
Mighty Mo
Vertical
Management
Bracket Kit
vertical cable manage-
MightyMo10WaterfallExtension
Vertical management
Mounting location for 6”–18”
4 brackets and all the
ladder racking on the side.
rack channel. Includes
mounting hardware.
Mighty Mo Bend Limiting Clip
Mighty Mo 6 vertical manag-
MightyMoRackBaseDustCover
Bend limiting clips snap on to any
ers to a standard EIA rack.
Prevents dust and debris from
finger on the vertical management
cage to provide bend limitation for
Mighty Mo Channel Bend Limiters
Rack Unit Cage Nuts
fiber jumpers entering and exiting the
Mighty Mo Channel Bend Limiters clip onto the top
edge of Mighty Mo channels providing the proper bend
Ortronics rack unit cage nuts provide steel nuts
cage. Set of 12.
Cable Management Rings
OR-60400017
2” x 6”, black, package of 14
OR-60400062
2” x 6”, black, package of 2
Mighty Mo Cable Management Spools
OR-MM6CMS10
11” long for 10” vertical management
cage with door
Mighty Mo 10 Waterfall Extension
OR-MM10WFE
Increases the height of the front flange
of the Mighty Mo waterfall by 2.25” when
additional cable capacity is required.
Mighty Mo Channel Bend Limiters
OR-MM6CBL06
For use with Mighty Mo racks
with 6.5” channels
OR-MM6CBL10
For use with Mighty Mo racks
with 10.5” channels
Mighty Mo Cable Runway
Mounting Brackets
OR-MM6EP710
For 7’ rack with 10.5” channel depth
OR-MM6CRB06
For rack with 6.5” channel depth
OR-MM6EP716
For 7’ rack with 16.25” channel depth
Mighty Mo 6 Cable Trough
OR-MM6CT4RU
Cable trough, 4RU
OR-MM6CT4RUK
Cable trough kit, 4RU
OR-MM6CRB10
For rack with 10.5” channel depth
OR-MM6EP810
For 8’ rack with 10.5” channel depth
OR-MM6CRB16
For rack with 16.25” channel depth
OR-MM6EP816
For 8’ rack with 16.25” channel depth
Mighty Mo Bend Limiting Clip
OR-MM6BLC
3.25” long for vertical management cages
with door or cover
up to channel.
the installation of a single multiple nut.
OR-MM6CBL16
For use with Mighty Mo racks
with 10.5” channels
Mighty Mo Vertical Management Bracket Kit
OR-60400687
Kit consists of 4 brackets, 8 panel mounting screws and 4 cage mounting screws.
for bending to clear cables from floor
OR-MM10CRBSVR
For Mighty Mo 10 server rack
OR-MM10CRBRSVR
For rear of Mighty Mo 10 server rack
Mighty Mo End Panel
Standard For use with 6” Mighty Mo 6
Narrow For use with 4” Mighty Mo 6
vertical cable managers
OR-MM6EPN706
For 7’ rack with 6.5” channel
Mighty Mo Rack Base Dust Cover
11
OR-MM6BDC06
For 6.5” channel standard rack
OR-MM6BDC10
For 10.5” channel standard rack
OR-MM6BDC16
For 16.25” channel standard rack
Mighty Mo Runway Ceiling Extension Kit
OR-MM6CEK10
For rack with 10.5” channel depth
OR-MM6CEK16
For rack with 16.25” channel depth
Rack Unit Cage Nuts
vertical cable managers
OR-MM6EPN710
For 7’ rack with 10.5” channel
OR-RU-1224CN
Thread size: 12-24 package of 50
OR-MM6EP706
For 7’ rack with 6.5” channel depth
OR-MM6EPN716
For 7’ rack with 16.25” channel
OR-RU-M6X1CN
Thread size: M6 (metric) package of 50
www.ortronics.com
Cable Management Rings
OR-60400614
Snap-type, 1.75” X 6”, package of 14
OR-60400542
Snap-type, 1.75” X 6”, package of 2
OR-60400314
Snap-type, 1.75” x 3”, package of 14
OR-60400302
Snap-type, 1.75” x 3”, package of 2
OR-MM6CMS8
8” long for 10” vertical management
cage with door
OR-MM6CMS6
6” long for 6” vertical management
cage with door
accumulating in rack base. Scored
in all three positions of a 1 3/4” rack unit with
radius for cables entering the channel. Set of 2. Black.
www.ortronics.com
concealing cables in the
Mounts to top of Mighty Mo racks.
bracket kit includes
hardware needed to mount 2
10
ment channel while
Mighty Mo Cable Runway
Mounting Brackets
Equipment shelves for mighty mo ® racks
MightyMoMonitorStrapKit
The monitor strap kit consists
of hook and loop straps which
can secure a monitor with a
base of any size or shape to
all equipment shelves on this
page. The monitor screen
Mighty Mo 6 Horizontal Management Panels
Double Equipment Shelves
for Mighty Mo Racks
Ortronics Mighty Mo cable management panels are optimized to
Ortronics double equipment shelf
Mighty Mo Server
Rack Equipment Shelf
supports miscellaneous equipment
The Mighty Mo server rack equip-
or test gear. The double shelves
ment shelf has a fixed front flange
work with Mighty Mo racks with
with an infinitely adjustable rear
6.5” deep channels. Color is black.
flange that allows for secure four
organize patch cords vertically and horizontally on our Mighty Mo racks.
They will also mount on any standard 19” rack. The finger design
encourages defined and traceable routing of individual patch cords.
®
remains fully adjustable.
Color is black.
equipment shelves for mighty mo racks
mighty mo accessories
Mighty Mo ® horizontal management
point mounting as deep as 30”.
Shelf width is 17.25”. Color is black.
Four Point Equipment Shelf
for Mighty Mo Racks and Cabinets
Ortronics four point equipment shelf supports
miscellaneous equipment or test gear. The one
unit shelf works with Mighty Mo racks with all
depth channels and Mighty Mo cabinets 24” and
deeper. Shelf is 17.25” wide. Color is black.
12
13
Mighty Mo 6 Horizontal
Management Panels
OR-MM6HMF2RU
Multiple fingers, cover, two rack units
(3.5” x 19”), black
OR-MM6HMF4RU
Multiple fingers, cover, four rack units
(7.0” x 19”), black
OR-MM6HM61RU
Six-port finger spacing, cover, one rack
unit (1.75” x 19”), black
OR-MM6HM81RU
Eight-port finger spacing, cover, two rack
units (1.75” x 19”), black
OR-MM6HM82RU
Eight-port finger spacing, two rack units
(3.5” x 19”), black
OR-MM6HM6D2RU
Six-port finger spacing, double-sided,
covers, two rack units (3.5” x 19”), black
Double Equipment Shelves
for Mighty Mo® Racks
Four Point Equipment Shelf
for Mighty Mo Racks and Cabinets
OR-60400355
19” x 5.25” x 24”, 150 lbs capacity,
Shelf width is 17”.
OR-604045681
19” x 1.72” x 20”, 100 lbs capacity
OR-60400517
23” x 5.25” x 24”, 150 lbs capacity,
Shelf width is 21.37”.
OR-60400655
19” x 5.25” x 24”, 150 lbs capacity,
Ortronics extra width double equipment
shelf is 18.75” wide in front and back;
usable width between mounting flanges
is 17.5”.
Note: Equipment shelf is slotted to
accept the Ortronics monitor strap kit
OR-70700126.
Mighty Mo Server Rack Equipment Shelf
OR-60400538
19” x 1.7” x 30”, 200 lbs capacity
Note: Shelf is slotted to accept the
Ortronics monitor strap kit OR-70700126.
Includes #12-24 mounting hardware.
Mighty Mo Monitor Strap Kit
OR-70700126
Hook and loop type strap kit
www.ortronics.com
www.ortronics.com
OR-MM6HMF1RU
Multiple fingers, cover, one rack unit
(1.75” x 19”), black
OR-MM6HM62RU
Six-port finger spacing, cover, two rack
units (3.5” x 19”), black
1
Four
easy steps
Assemble the racks and install the
speedbars at the spacing desired.
Part Number
Description
Usable
Area
(sq. in.)
at the bottom rear keep the racks
Included with every Mighty Mo cable
management rack! The Mighty Mo Speedbar
installs ahead of the vertical managers and
properly spaces the racks so that connectivity,
cable and equipment can be installed before
the vertical managers. With more room to
terminate and dress, your installation goes
faster and installing heavy equipment is
easier than ever.
Recommended Cable Fill (40%)
Maximum Cable Fill (60%)
Cable
Cat 5e
Cat 6
Cat 6a
Cat 5e
Cat 6
Cat 6a
O.D.(in.)
0.215
0.230
0.290
0.215
0.230
0.290
spaced and parallel as you fasten
MM10VMD716
MM10 Vertical Cable Management w/Door, 16" X 13" X 7'
134
1608
1340
938
2278
2010
1340
them to the floor. Install your
MM10VMD712
MM10 Vertical Cable Management w/Door, 12" X 13" X 7'
90
1080
900
630
1530
1350
900
connectivity and equipment with no
MM10VMD816
MM10 Vertical Cable Management w/Door, 16” X 13” X 8’
134
1608
1340
938
2278
2010
1340
managers to get in the way.
MM10VMD812
MM10 Vertical Cable Management w/Door, 12” X 13” X 8’
90
1080
900
630
1530
1350
900
2
Install the two hanging clips
MM6VMD710
MM6 Vertical Cable Management w/Door, 10" X 13" X 7'
73
876
730
511
1241
1095
730
MM6VMD706
MM6 Vertical Cable Management w/Door, 6" X 8" X 7'
25
300
250
175
425
375
250
MM6VMD810
MM6 Vertical Cable Management w/Door, 10" X 13" X 8'
73
876
730
511
1241
1095
730
MM6VMD806
MM6 Vertical Cable Management w/Door, 6" X 8" X 8'
25
300
250
175
425
375
250
MM6VMS704
MM6 Vertical Cable Management w/Split Covers, 4" X 7" X 7'
15
180
150
105
255
225
150
MM6VMS706
MM6 Vertical Cable Management w/Split Covers, 6" X 7" X 7'
25
300
250
175
425
375
250
MM6VMS804
MM6 Vertical Cable Management w/Split Covers, 4" X 7" X 8'
15
180
150
105
255
225
150
MM6VMS806
MM6 Vertical Cable Management w/Split Covers, 6" X 7" X 8'
25
300
250
175
425
375
250
MM6VML704
MM6 Vertical Cable Management Cage with Latches, 4" X 6" X 7'
16
192
160
112
272
240
160
that come with every Mighty Mo
MM6VML706
MM6 Vertical Cable Management Cage with Latches, 6" X 6" X 7'
26
312
260
182
442
390
260
vertical manager.
MM6VML804
MM6 Vertical Cable Management Cage with Latches, 4" X 6" X 8'
16
192
160
112
272
240
160
3
Hang the vertical manager in place
and secure with the blunt nose self
MM6VML806
MM6 Vertical Cable Management Cage with Latches, 6" X 6" X 8'
26
312
260
182
442
390
260
MM6HMF1RU
MM6 Horizontal Cable Management Panel, Multiple Fingers, 1RU
5
60
50
35
85
75
50
MM6HMF2RU
MM6 Horizontal Cable Management Panel, Multiple Fingers, 2RU
13.5
162
135
95
230
203
135
MM6HMF4RU
MM6 Horizontal Cable Management Panel, Multiple Fingers, 4RU
32.5
390
325
228
553
488
325
MM6HM61RU
MM6 Horizontal Cable Management Panel, Six-Port Spacing, 1RU
5
60
50
35
85
75
50
MM6HM62RU
MM6 Horizontal Cable Management Panel, Six-Port Spacing, 2RU
13.5
162
135
95
230
203
135
MM6HM81RU
MM6 Horizontal Cable Management Panel, Eight-Port Spacing, 1RU
5
60
50
35
85
75
50
MM6HM82RU
MM6 Horizontal Cable Management Panel, Eight-Port Spacing, 2RU
13.5
162
135
95
230
203
135
MM6HM6D2RU
MM6 Horizontal Cable Management Panel, Six-Port,
Double-Sided, 2RU
Front
12.5
150
125
88
213
188
125
Rear
5
60
50
35
85
75
50
threading fasteners. Install the slack
storage spools and the bend limiting
clips. Now the racks are ready for
patch cords and equipment cables.
Three speedbars are supplied with every
Mighty Mo rack. They are notched to provide
the correct rack spacing for all four widths of
vertical managers.
4
Unwrap and hang the doors in place
to complete the installation.
NetClear® Horizontal Cable Capacities for Ortronics Mighty Mo Racks
Part Number
Description
Usable
Area
(sq. in.)
24 CNT
Bundle
Single Channel Capacity
Total Rack Capacity
Cat 5e
Cat 6
Cat 6a
Cat 5e
Cat 6
Cat 6a
O.D. (In)
1.125”
1.25”
1.625”
1.625”
1.25”
1.625”
MM10716
MM10 Cable Management Rack, 16.25” channel depth, 7’, black
88
768
480
336
1536
960
672
MM10816
MM10 Cable Management Rack, 16.25” channel depth, 8’, black
88
768
480
336
1536
960
672
MM6706
MM6 Cable Management Rack, 6.5” channel depth, 7’, black
34
288
240
156
576
480
312
MM6710
MM6 Cable Management Rack, 10.50” channel depth, 7’, black
56
480
288
240
960
576
480
MM6810
MM6 Cable Management Rack, 10.50” channel depth, 8’, black
56
480
288
240
960
576
480
MM6716
MM6 Cable Management Rack, 16.25” channel depth, 7’, black
88
768
480
336
1536
960
672
MM6816
MM6 Cable Management Rack, 16.25” channel depth, 8’, black
88
768
480
336
1536
960
672
12.25”
8.25”
6.5”
2.5”
16”
12”
10”
6”
36”
32”
30.25”
26.25”
15
www.ortronics.com
www.ortronics.com
Cable Fill Capacities for Ortronics® Mighty Mo Cable Management Products
Two bars on the front and one bar
speed up
your spacing
14
mighty mo ® cable capacity
mighty mo cable capacity
mighty mo speedbar
Mighty Mo ® speedbar
REV 05/09
CANADA
570 Applewood Crescent
Vaughan, Ontario L4K 4B4
905.738.9195
125 Eugene O’Neill Drive
New London, CT 06320
800.934.5432
860.445.3900 (sales)
860.405.2992 (fax)
www.ortronics.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
