Features & Specifications
SSL VPN
Availability and Resilience
Capabilities
• Load balancing
- Traffic Management
- Protocol binding
• Automatic fail-over and VPN fail-over
BiGuard S5
BiGuard S10
BiGuard S20
• Recommended for small organizations to manage
remote Intranet access and seek a solution of minimal IT
investment
• 5 concurrent user access, up to 20 user access
• Recommended for small offices and SMBs with
50 to 200 employees
• 10 concurrent user access, up to 20 user access
• Recommended for small offices and SMBs with
50 to 200 employees
• Concurrent user access: maximum 20
Access Connections
(only for BiGuard S20)
S5
SSL VPN Starter Pack
Logging and Monitoring
SSL/IPSec VPN Security Gateway
• Centralized logs
• System log
• E-mail alerts and Intrusion logs
• System status monitoring
Dual-WAN SSL/IPSec VPN
Security Gateway
Network Protocols and Features
• Static IP, PPPoE and DHCP client connection to ISP
• NAT, static routing and RIP1/2
• Dynamic Domain Name System (DDNS)
• Router mode
• Virtual Server
• Hardware DMZ
• DHCP Server
• SNTP
• SNMP
• Multi-NAT (for BiGuard S20 only)
• Transparent Bridging
• Network Extender
• Standalone Network Extender client
• Transport Extender
• Application Proxy
• Personalized Web Portal
• Single Sign-On (SSO)
Applications & Management
BiGuard SSL VPN Security Appliance Series
In today’s rapid and dynamic business environment, small and medium businesses (SMBs) have to be flexible and
responsive to ever-changing issues in order to remain competitive. However, when it comes to IT infrastructure, SMBs
often lack the budget and resources to implement IT solutions the way large corporations usually do. For SMBs it is even
harder to manage remote access and security in a cost-effective way, especially when access to corporate resources is
not limited to the same location, but includes mobile workers and partners in different locations. For these situations
Billion's BiGuard SSL VPN Security Appliance series provide the perfect answer.
Hardware Specifications
• My Network Places (Web CIFS)
• SSL event log and monitor
• Citrix client
• Terminal services (RDP5, RDP6)
• File Transfer Protocol (FTP)
• Telnet
• Outlook Web Access (OWA)
• Virtual Network Computing (VNC)
• Secure Shell (SSH) support
• Web based data (HTTP, HTTPS)
• Granular User Policy Management
• Supports mobile devices
(Microsoft Windows Mobile 5.0/6.0 compatible)
Physical Interface
BiGuard S5
BiGuard S10
BiGuard S20
Security
• SSL encryption
• Web cache cleaner
• Local Database
• Digital Certificate
• Self-Signed Certificate
• User Access Control
• Authentication Domains: RADIUS, LDAP, Active Directory, NT Domain
• Host Security Checking
Physical Specifications
BiGuard S5
• Dimensions: 19" x 6.93" x 1.65"
BiGuard S10
• Dimensions: 19" x 6.93" x 1.65"
(482 x 176 x 42mm with bracket) (250 x 176 x 33.5mm without bracket)
(482 x 176 x 42mm with bracket) (250 x 176 x 33.5mm without bracket)
BiGuard S20
Compatible Web Browsers*1
• Microsoft Internet Explorer 6.0 and newer versions
• Netscape 7.0 and newer versions
• Opera 9.0 and newer versions
• Firefox 1.5 and newer versions
• Safari 2.0 and newer versions
• Mozilla 1.7 and newer versions
• Sun JRE 1.3 and newer versions
• 1 x 10/100Mbps WAN port
• 4 x 10/100Mbps LAN ports (1 port configurable as DMZ)
• Power switch
• Reset button
• 1 x 10/100Mbps WAN port
• 4 x 10/100Mbps LAN ports (1 port configurable as DMZ)
• Power switch
• Reset button
• 2 x 10/100Mbps WAN ports
• 8 x 10/100Mbps LAN ports (1 port can be configurable as DMZ)
• 1 x 10/100/1000Mbps Gigabit port
• 1 x RS232 Serial port
• Power switch
• Reset button
• 1U rack-mount
• Dimensions: 15.35" x 7.44" x 1.73"
(482 x 210 x 44mm with bracket) (390 x 210 x 44mm without bracket)
Power Requirements
BiGuard S5
BiGuard S10
BiGuard S20
• Input: 12V DC, 1A
• Input: 12V DC, 1A
• Power Supply: 100 to 240V AC / 50 to 60Hz
Great Mobility and Productivity
Billion’s BiGuard SSL VPN Security Appliance series integrate cutting-edge SSL VPN technology for small offices and SMBs to establish private
encrypted tunnels, without VPN software pre-installation in client PCs, through the public Internet to securely access corporate resources from any
location, such as a branch office, hotel, home, cyber café, or even a public kiosk. The BiGuard SSL VPN Security Appliance series offers
industry-advanced SSL VPN applications such as Network Extender and supports a wide range of browsers, platforms and operating systems, providing
remote users, mobile workers and external business partners with remote access to the corporate network to share files, check e-mail, and download
documents as if they never left the office. A business traveler can log in via a mobile device like PDA, the SOHO or a graphic freelancer on Macintosh can
even connect his Apple PC to customers’ networks to remotely collaborate on a project. Secure remote Intranet access with BiGuard SSL VPN Security
Appliance series is possible via any device from anywhere at anytime.
Single Box Access Management Solution
Billion’s BiGuard SSL VPN Security Appliance series is the world’s first gateway series which fully integrates SSL VPN encryption as well as firewall and
router functions in one box. It is very affordable for small and medium business operations. IT administrators no longer need to buy an extra device to
manage remote Intranet access, nor install and maintain additional equipment for data security. The integrated router functions provide administrators with
a perfect idea to manage all the connections and file sharing of remote access is easy just integrating into one BiGuard SSL VPN device. Instead of
buying three independent networking devices, the fully integrated BiGuard SSL VPN series fulfills all your networking needs.
Key Features
• SSL VPN gateway plus solid router
functions
• Clientless connectivity
• Network / Transport Extender
• Windows / Linux / Macintosh supported
• Microsoft Windows Mobile 5.0/6.0
Supported Operating Systems*1
Operating Environment
Comprehensive Security
Firewall & Content Filtering
• Operating temperature: 0 to 40°c
• Storage temperature: -20 to 70°c
• Humidity: 20 to 95% non-condensing
BiGuard SSL VPN Security Appliance series supports SSL encryption and authentication to ensure data transmission security and user authorization. The
device supports SSL VPN concurrent sessions with remarkable performance. Simultaneously, Firewall, Stateful Packet Inspection (SPI), Denial of Service
(DoS) prevention and URL filtering are all integrated to guard your network against malicious attacks. In addition the firewall features an e-mail alert
service, activated whenever an attack occurs.
• Granular Access Policy Management
Ease of Management
• Data encryption, user authentication
• Microsoft Windows, Linux, and Macintosh
• Stateful Packet Inspection (SPI)
• Denial of Service (DoS) prevention
• Packet Filter
• Intrusion Detection
• URL Filter
• Java Applet/Active X/Cookie Blocking
Front and Rear Panels
With the BiGuard SSL VPN Security Appliance series IT administrators can easily configure the gateway to control the resources and applications
available to different groups of users. In addition, access policy, authorization, and authentication mechanisms can be set up as well. All this can be done
through the easy-to-manage Personal Web Portal, which displays the applications by different groups of users.
Quality of Service Control
BiGuard S5 Front Panel
• Supports DiffServ approach
• Traffic prioritization and bandwidth management based on IP protocol, port
number and IP address
BiGuard S5 Rear Panel
Web-Based Management
• Easy-to-use web-based interface
• Firmware upgrade through web-based interface
• Local and remote management through HTTP and HTTPS
• Multi-language web interface
• Remote dial-in configuration (CLI for RS-232 port) (for BiGuard S20 only)
IPSec VPN
BiGuard S10 Front Panel
Both SSL VPN and IPSec VPN are well-known remote access solutions. They are not competing, but complementary technologies. Both the BiGuard S10
and BiGuard S20 offer IPSec VPN and SSL VPN capabilities together on a single platform. This combination provides excellent deployment flexibility to
small business operations for meeting the requirements of any remote access users. The need for, and additional cost of, deploying separate, extra
platforms for both SSL and IPSec VPN is eliminated.
Options for Growth and Management
• BiGuard S10 - 10 IPSec VPN tunnels
• BiGuard S20 - 30 IPSec VPN tunnels
• Manual key, Internet Key Exchange (IKE) authentication and Key Management
• Authentication (MD5 / SHA-1)
• DES/3DES encryption
• AES 128/192/256 encryption
• IP Authentication Header (AH)
• IP Encapsulating Security Payload (ESP)
• Dynamic VPN (FQDN) support
• Supports remote access and office-to-office IPSec connections
BiGuard S10 Rear Panel
BiGuard S20 Front Panel
BiGuard S20 Rear Panel
* Note:
1. Please refer to http://www.billion.com/product/biguard/sslvpnbrowser.htm for updates of all supported browsers and OS platforms. Users are strongly recommended to register at www.biguard.com
for updated firmware. All the specifications are subject to change without prior notice.
Copyright © Billion Electric Co., Ltd. All rights reserved.
8F, No. 192, Sec. 2, Chung Hsing Road,
Hsin Tien City, Taipei County, Taiwan
Dual integrated WAN ports for two broadband lines ensure optimal bandwidth sharing for multiple PCs in your office, or provide network redundancy in
case one connection should fail. The load balancing feature is designed to provide the ability to balance the workload by distributing outgoing traffic
across the two connections, and meet growing business needs requiring more bandwidth, network scalability and resilience for mission-critical or
Internet-business applications. The auto fail-over feature can be configured for a second connection to assure redundant connectivity when the primary
line fails.
Flexible Platform
(BiGuard S10 and BiGuard S20)
Billion Electric Co., Ltd.
Scalability and Resilience
TEL: +886-2-29145665
FAX: +886-2-29186731, +886-2-29182895
E-mail: [email protected]
www.billion.com
A total SSL VPN solution is made possible through optional support: SSL VPN Tunnel Upgrades, BiGuard’s Central Management System, and BiGuard’s
One-Time Password. In case of a growing need for remote access, just upgrade the BiGuard SSL VPN gateway by adding more SSL VPN tunnels. To
enforce management policy, administrators in the head office or service providers can deploy BiGuard’s Central Management System series, which
enables remote configuration from a central site to save on maintenance. In addition, the BiGuard OTP, a car-key sized dongle, is used to create a
two-factor authentication by using a dynamically generated 6-digit PIN. Combined with your existing static password this results in a greatly reduced risk
of unauthorized access to corporate network resources by intruders.
compatible mobile devices supported
• Personalized Web Portal
and access control
• Host Security Checking
• Robust Firewall security
• Quality of Service Control
• Hardware DMZ
• IPSec VPN capabilities
• Auto Fail-over and Load Balancing
• Dual WAN connectivity
Other Options
• BiGuard SSL VPN Tunnel Upgrades
• BiGuard Central Management System
• BiGuard One-Time Password
Technology & Applications
Network Extender
Application Proxy
Virtually extending your connection to the central office network allows you to access your office resources seamlessly from anywhere — as if
Supports most commonly used applications through a web-based interface. The great advantage of the application proxy is that there is no need to
you’d never left the office. You can remotely access office files and applications through your computer, desktop or laptop, as if you were using a
pre-install any client software for the applications users intend to download and share.
computer in your corporate network. A sales person on a business trip who needs to know the product inventory can use the Network Extender
technology in BiGuard SSL VPN series, to connect to the corporate network and access the stock database to check, instead of phoning back to
head office and asking.
The supported applications include:
• Remote desktop service such as Terminal Services (RDP5, RDP6), VNC
• HTTP- and HTTPS-based intranet data
• Remote control protocols: Telnet and SSH
• File Transfer Protocol (FTP)
• Network File sharing (CIFS)
• Citrix client
• Outlook Web Access (OWA)
Remote users will be able to access all the resources of the office network.
Transport Extender
Enables specific remote users or specific remote groups of users to use the SSL VPN tunnel to connect to the corporate network to access the
Remote users will be able to access applications through the Internet by simply using a web browser.
services as configured by IT administrators. Therefore the remote user does not have to change any specific settings in the web portal to make
the service work. When a user remotely accesses MS Outlook e-mail, for instance, the Transport Extender technology will transport the e-mail
service through the SSL VPN tunnel to the e-mail server in the corporate network, as configured by the IT administrator. Since the remote user
doesn’t have to modify any settings in the web portal, the remote user will feel as if they’re using MS Outlook in the office.
Personalized Web Portal
Easy Administration
Through the BiGuard SSL VPN series’ web management interface, grouping users and customizing applications becomes quick and easy. The web
portal interface enables administrators to configure the BiGuard SSL VPN appliance series and authorize application access to users according to
different authorization levels. The Quick Start Wizard provides administrators with a simple step-by-step guide to create, manage, and delete SSL
VPN user accounts for remote users. The BiGuard SSL VPN series also provides administrators with user-friendly tools such as SSL VPN logs to
monitor remote users’ access.
Remote users will be able to access the resources configured for the users.
My Network Places
Just like the Windows Network Neighborhood, My Network Places allows users to browse network files on the office network. From a home
computer or PDA, users can connect directly to My Network Places and access information inside the office — from now on there is no need to
go back to the office if users forget an important document.
Personalized Application Portal
Since the portal page is personalized for each individual, all the applications
each individual is allowed to access are all shown via the web portal. A simply
mouse click can start an application shown in the web portal. By using a
standard web browser, remote users can access their personalized portal
page.
Notes:
Some of the applications are available to Windows users only. The availability of
applications and features stated varies according to browser and OS. Please
Remote users will be able to access My Network Places via the Internet.
refer to http://www.billion.com/product/biguard/sslvpnbrowser.htm for details.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
