Productivity- and profit-enhancing
software utilities, too.
C9650 Series
C9650 Series
Specifications
Paper Handling
Performance
• Print Speed: Up to 36 ppm Color; up to 40 ppm Mono
• Time to First Page: 10.5 sec. Color; 9 sec. Mono 1
• Warm-Up Time: 85 sec. or less from Power On
• Resolution: Up to 1200 x 600 dpi resolution with
High Definition Color technology
• Processor: 800 MHz PowerPC 750
• Reliability/Duty Cycle: 150,000 pages/month
1
Standard Productivity Features
PrintSuperVision
Robust, scalable, Internet-based software that enables
administrators to access and distribute printer data
and control the functionality of all the OKI Printing
Solutions printers and most other SNMP-based
printers on their network.
• Direct PDF Printing: Receives and prints .pdf files through
Version 1.6 without opening an application, enhancing
productivity (Windows® environment only) 2
• Job Accounting: Track precise count of color and mono
pages printed by individual or department 2
• PrintSuperVision: Web-based software, printer
management tool
• Storage Device Manager: Stores and manages forms,
letterheads, logos and fonts 2
• Auto Media Detect: Automatic paper weight detection
• Auto Paper Tray Select: Automatically detects paper size
Color Controls
• Color Management: Color Matching software and Color
Correct from OKI Printing Solutions, PS Gamma Adjuster,
PostScript® CRD, Windows® ICM, Resident ICC Input/Output
Profiles (also create, download to printer, and manage new
profiles). Supports color management systems that utilize
ICC profiles (Apple®, ColorSync®, Microsoft® ICM, Adobe®
applications, QuarkXPress™, CorelDRAW®)
• Ink Simulations: SWOP®, Euroscale and others
• Color Matching Modes: sRGB, Monitor Simulations,
Digital Camera, PANTONE® Digital Color
Compatibility
Job Accounting Software
Enables tracking of color and black & white printing
costs, and easy monitoring and control of printer
usage—with both Server and Client components.
• Emulations: PCL® 5c, PCL 6, Adobe PostScript 3™
• Operating Systems: Windows – Vista®/Vista x64;
XP Home/Professional, XP Server 2003 x64; 2003 Server;
2000 Workstation/Professional/Server/Advanced Server
(all SP3 or later). Mac® – OS 9.2/OS 10.3 and higher.
• Network & Protocols: 10/100/1000 Base TX Ethernet
card with internal Web server for printer and network card
setup and management; includes POP3/APOP and SMTP
Mail client for submission of print jobs and for alerts. All
major network protocols supported – TCP/IP, Netware and
Ethertalk. TCP/IP includes ARP, IP, ICMP, TCP, UDP, LPR,
FTP, TELNET, HTTP(IPP), BOOTP, DHCP, SNMP, DNS, SSL/
TLS, JetDirect protocols; Netware includes 3.x, 4.x, 5.x
and 6 with full NDS and NDPS support – PServer, RPrinter,
NDPS supported via dedicated OKI NDPS Gateway.
Memory
• Standard RAM: 512 MB
• Maximum RAM: 1,024 MB
• Flash Memory: 4 MB standard
• Hard Disk Drive: 40 GB (standard on C9650hdn,
optional on C9650n and C9650dn)
• Standard Input: 760 sheets (530-sheet universal tray +
230-sheet multi-purpose tray)
• Optional Input: 2nd/3rd universal tray (530 sheets each);
High-Capacity Feeder (1,590 sheets); Banner Paper Tray
(20-banner-size sheets)
• Maximum Capacity: 2,880 sheets (Printer + 2nd tray +
High Capacity Feeder + Multi-Purpose Tray)
• Paper Sizes: Tabloid extra (12" x 18"), tabloid (11" x 17"),
legal, letter, executive, 3" x 5" index cards, 4" x 6" and
5" x 7" photo paper, A3, A4, A5, A6, B5, C5, DL, Com 10,
Monarch envelopes, and banners (up to 12.9" by 47.24")
• Paper Weight: Trays 1 thru 5 – 17 lb. bond–80 lb. cover
(64–216 gsm); Multi-purpose tray – 17 lb. bond–120 lb.
cover (64–307 gsm); duplex – 20 lb. bond–65 lb. cover
(75–188 gsm) for letter and tabloid sheets
• Duplex (2-sided printing): Standard on C9650dn and
C9650hdn; optional on C9650n
Typefaces
• Printer Fonts: 86 scalable PCL fonts, 1 bitmap font,
10 TrueType® fonts, 136 Adobe PostScript Type 1 fonts,
OCR A/B, USPS Barcode
Environmental
• Size (WxDxH): 23.6" x 24.6" x 18.5"
(59.9 cm x 62.5 cm x 46.9 cm)
• Weight: 167.5 lb. (76.0 kg) with consumables
• Power Consumption: Operating – Typical 780W,
Peak <1500W; Standby 200W (average); Power Save 33W
• Acoustic Noise: Operating – 54dB(A) or less; Standby:
42dB(A) or less; Power Save: 28dB(A) (background level)
• ENERGY STAR: Available on C9650dn and C9650hdn
Warranty
• Printer: 1-Year limited On-Site warranty 3, parts and labor
• Digital LED Printhead: 5-Year limited warranty
Important Consumables Information: This product
has been designed and engineered to operate only with
genuine OKI Printing Solutions consumables. Use of
non-genuine consumables will result in the loss of certain
printer enhancements, such as Auto Color Balance and
the Toner Sensor gauge.
For more information on Digital Color printers
and supplies from OKI Printing Solutions, including
OKIcare® Extended Service Programs: 1.800.OKI.DATA
(800.654.3282).3
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
Requires hard disk drive (standard on C9650hdn).
3 Available in the U.S. and Canada only.
4 ENERGY STAR compliant.
5 Based on 5% coverage, Letter-size sheet. Printers ship
with 7,500-page “starter” toner cartridges.
6 Declared yield in accordance with ISO/IEC 19798.
7 E stimated life, continuous printing (will vary depending on
number of printed pages per job).
2
Interface
• Standard Connectivity: 10/100/1000 Ethernet,
High-speed USB v2.0, Parallel
Ordering Information
Description
Part Numbers
C9650n 120V (Multilingual)
62430604
C9650n 230V (Multilingual)
62430605
C9650dn 120V (Multilingual) 4
62430606
C9650dn 230V (Multilingual) 4
62430607
C9650hdn 120V (Multilingual) 4
62430608
C9650hdn 230V (Multilingual) 4
62430609
Options
2nd and 3rd 530-sheet Paper Tray Mechanism
42831301
Duplex Unit 42797201
High-Capacity Feeder
42831501
Banner Paper Tray
42964903
4-Tray Finisher
70050701
5-Tray Finisher
70050801
2-/3-Hole Punch for Finisher
42872902
40 GB Hard Disk Drive
70050502
256 MB Memory Expansion DIMM
70051601
512 MB Memory Expansion DIMM
70051701
Printer Cabinet
70050901
Supplies
Toner Cartridges (Type C7)
Cyan Toner Cartridge 16,5005/22,000 pg.6 42918983
Magenta Toner Cartridge 16,5005/22,000 pg.6 42918982
Yellow Toner Cartridge 16,5005/22,000 pg.6 42918981
Black Toner Cartridge 18,5005/22,500 pg.6 42918984
Image Drums (Type C7)
Cyan Image Drum 42,000 pg.7
42918103
Magenta Image Drum 42,000 pg.7
42918102
Yellow Image Drum 42,000 pg.7
42918101
Black Image Drum 42,000 pg.7
42918104
Consumables
7
Fuser Kit (120V)
100,000 pg. 42931701
Fuser Kit (230V)
100,000 pg.7
42931702
7
Transfer Belt
100,000 pg. 42931601
5
Waste Toner Box 30,000 pg. 42869401
Finisher Staples
15,000 count
42937601
Print Media
Sheets Per Box
Premium Card Stock (8.5" x 11"):
60 lb. cover
250
52205601
90 lb. index
250
52205602
110 lb. index
250
52205603
Bright White Proofing Sheets (32 lb.):
8.5" x 11" 500 52206101
11" x 17" 500 52206102
12" x 18" 500 52206103
Ultra Gloss Paper (8 pt.):
4" x 6"
50
52208909
5" x 7"
50
52208910
8.5" x 11" 100 52208901
8.5" x 11" 250 52208902
11" x 17" 50 52208903
12" x 18" 50 52208904
Banner Paper:
12.9" x 35.4"
100
52206001
8.5" x 35.4"
100
52206002
SynFlex™ Paper (Waterproof and Tear-resistant):
8.5" x 11"
100
52205901
12.75" x 18"
100
52205904
Premium Envelopes (size #10):
100
52206301
500
52206302
Brilliant color. Unmatched media flexibility.
C9650n
C9650dn
C9650hdn
Oki Data Americas, Inc.
Color Matching Software from OKI Printing Solutions
An accurate color matching/job flow management
program that enables users to match the colors on
their monitor with their color output, and create
ICC input/output profiles for printers, monitors
and scanners.
USA
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: 856.222.5320
Canada
2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: 905.238.4250
Fax: 905.238.4421
Latin America
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 856.231.0002
Fax: 856.222.5071
Oki Data de México, S.A. de C.V.
Mariano Escobedo, 748 8º Piso
Col. Nueva Anzures C.P. 11590
México, D.F.
Tel: 55.5263.8780
Fax: 55.5250.3501
www.okiprintingsolutions.com/us
Specifications are subject to change without notice.
© 2009 Oki Data Americas, Inc. OKI Reg. T.M., M.D. M.R., OKIcare, OkiLAN Reg. T.M., Oki Electric Industry Co., Ltd. High Definition Color logo T.M., Single Pass Color T.M. and design
Reg. T.M., Oki Data Corp. SynFlex T.M., Oki Data Americas, Inc. SWOP T.M., SWOP, Inc. Adobe, PostScript, Acrobat Reg. T.M., PostScript 3 T.M., Adobe Systems Inc. Microsoft, Windows,
Windows NT Reg. T.M., Vista T.M., Microsoft Corp. PCL, Reg. T.M., Hewlett-Packard Co. Mac, ColorSync Reg. T.M., Apple Inc. PANTONE and Pantone Digital Color and design Reg. T.M.,
Pantone, Inc. QuarkXPress T.M., Quark Inc. CorelDraw Reg. T.M., Corel Corp. Intel Reg. T.M., Intel Corp. ENERGY STAR Reg. T.M., U.S. EPA. USB-Logo T.M. Universal Serial Bus Implementers
Forum, Inc.
Printed in the USA MS 15858-0709
Oki Data do Brasil Informática Ltda.
Av. Alfredo Egídio de Souza Aranha, 100
Bloco C – 4º andar
04726-170 – São Paulo – SP – Brasil
Tel: 11.3444.3500
Fax: 11.3444.3502
C9650 Series At-a-Glance
Time to first print: 10.5 seconds Color,
9 seconds Mono 1 – less time waiting for documents
Toner cartridges deliver up to 22,000 color pages
and up to 22,500 pages in black & white 3
Print speeds up to
36 ppm Color, 40 ppm Mono 1
for increased productivity
Available with integrated
duplex unit for doublesided printing 2
Single Pass Color™ Digital
technology delivers high
speed, superb reliability and
unmatched paper handling
Prints paper weights up to 307 gsm
for greater media flexibility
Unmatched media flexibility:
print letterhead, card stock, even
4-foot banners – up to 307 gsm!
Introducing the Signage Media Collection from
OKI Printing Solutions. The C9650 Series prints
them all—beautifully!
SynFlex™ Paper
Water-resistant and
tear-resistant
230-sheet Multi-purpose tray
(MPT) handles non-standard
and specialty media
High Definition Color
technology for sharper
graphics and crisper text
Graphical LCD display
panel for greater ease
of use
Premium Card Stock
3 different weights;
uniformly smooth surface
530-sheet standard
paper tray
Your business calls for productivity and versatility.
That’s what you get—and more—with the C9650 Series!
Optional 530-sheet 2nd paper
tray for fewer interventions
Color printing with exceptional
paper handling flexibility
Highlights:
• C
olor output at up to 36 ppm, Monochrome (black & white) at up to 40 ppm 1
• Single Pass Color™ Digital technology
for printing on media up to 307 gsm
• Tabloid extra/A3 (12" x 18"); prints on banner
sheets up to 12.9" wide by 47.24"
• High Definition Color technology for sharp detail
and rich color depth; up to 1200 x 600 dpi
resolution
• High-capacity, 2-piece consumables for low
Total Cost of Ownership
• 800 MHz PowerPC 750 processor
• 512 MB standard RAM, upgradable to 1 GB
• Holds up to 2,880 sheets with options
• Job Accounting software 2 and Web-based
printer management utility standard
• Direct PDF Printing – print .pdf files without
Adobe® Acrobat® or Acrobat Reader 2
• Available with duplexer 3, 40 GB Hard Disk Drive 4, banner paper tray, and Finisher/Stapler
• 1-Year On-Site limited warranty 5 on printer;
5-Year limited warranty on LED printheads
• Live, toll-free technical support 24/7/365 5
Digital color printers from OKI Printing Solutions
provide high-quality, tabloid extra (12" x 18")
High Definition Color output.
With the C9650 Series Digital Color printers,
you can improve the quality of your output
and increase productivity—even as you lower
your expenses.
These color printers are the efficient and
affordable answer, especially if tabloid-size
newsletters and brochures, ad layouts, large
illustrations, banners or specialty media are
essential parts of your business.
Your total in-house printing solution
No more having to run down to the corporate
or neighborhood copy center every time you need
color documents. From postcard- to banner-size
documents up to 12.9" by 47.24", you can simply
print them in-house.
C9650 Series printers come with Color Matching
software from OKI Printing Solutions and Auto
Color Balance, to ensure that color output
remains accurate and consistent from start to
finish. And features like Auto Media Detect
will automatically adjust the printer to your
required media type.
Optional saddle-stitch
finisher punches, staples,
folds and stacks up to
1,000 sheets
Single Pass Color™ Digital technology and
long-lasting, individually replaceable toner
cartridges and image drums translate into fewer
interventions—for increased productivity and
a lower cost per page than competitive color
printers and, especially, outside print-and-copy
services. Further, C9650 Series color printers have
a cost per black & white page comparable to that
of most mono laser printers—so you can use
them for all your business printing.
Optional high-capacity
feeder: 3 additional trays
(maximum paper capacity
2,880 sheets with options)
Connectivity and more
C9650 Series printers can be connected to the
network (PC- or Mac®-based) via a 10/100/1000
Base-T internal print server card. They also feature
high-speed USB v2.0 and parallel interfaces.
All C9650 Series models are equipped with Job
Accounting software 2 that allows for tracking
of color and monochrome pages, the types and
quantities of paper used, and a record of printing
activity by individual or department.
So go on, get as creative as you like—and expect
the superlative capabilities of C9650 Series Digital
Color printers from OKI Printing Solutions to make
you look great.
The easy-to-read operator panel of the C9650 Series
tilts up for user convenience, and displays current status
of the printer. A built-in toner gauge indicates the
remaining life of each toner cartridge.
Banner Paper
12.9" x 35.4" or 8.5" x 35.4" –
ideal for retail signage
C9650 Series Operator Panel in “flat” or “down” position.
Banner Paper Tray now available for
C9650 Series Printers
This tray, specifically created for long banners, easily
installs on the printer. Extending from the multi-purpose tray,
it allows the automatic feeding of up to 20 sheets of 32 lb.
banner paper. For added convenience, the tray also supports
the finished banners as they exit the printer.
1
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
2 Requires hard disk drive.
3 Standard on C9650dn and C9650hdn models.
4 Standard on C9650hdn model.
5 Available in the U.S. and Canada only.
Bright White
Proofing Sheets
In 8.5" x 11", 11" x 17" (tabloid)
and 12" x 18" (tabloid-extra)
Published performance results based on laboratory testing.
Individual results may vary.
Standard on C9650dn and C9650hdn models.
3 Declared yield in accordance with ISO/IEC 19798.
(16,500 pages CMY, 18,500 pages Black at 5% coverage,
letter-size sheets. Printers ship with 7,500-page “starter”
toner cartridges).
2
C9650 Series Operator Panel can be tilted upwards
to various angles (up to 90°) for greater convenience.
For more information or to order a Banner Paper Tray or any item from
the Signage Media Collection, call 1.800.OKI.DATA (800.654.3282).
C9650 Series At-a-Glance
Time to first print: 10.5 seconds Color,
9 seconds Mono 1 – less time waiting for documents
Toner cartridges deliver up to 22,000 color pages
and up to 22,500 pages in black & white 3
Print speeds up to
36 ppm Color, 40 ppm Mono 1
for increased productivity
Available with integrated
duplex unit for doublesided printing 2
Single Pass Color™ Digital
technology delivers high
speed, superb reliability and
unmatched paper handling
Prints paper weights up to 307 gsm
for greater media flexibility
Unmatched media flexibility:
print letterhead, card stock, even
4-foot banners – up to 307 gsm!
Introducing the Signage Media Collection from
OKI Printing Solutions. The C9650 Series prints
them all—beautifully!
SynFlex™ Paper
Water-resistant and
tear-resistant
230-sheet Multi-purpose tray
(MPT) handles non-standard
and specialty media
High Definition Color
technology for sharper
graphics and crisper text
Graphical LCD display
panel for greater ease
of use
Premium Card Stock
3 different weights;
uniformly smooth surface
530-sheet standard
paper tray
Your business calls for productivity and versatility.
That’s what you get—and more—with the C9650 Series!
Optional 530-sheet 2nd paper
tray for fewer interventions
Color printing with exceptional
paper handling flexibility
Highlights:
• C
olor output at up to 36 ppm, Monochrome (black & white) at up to 40 ppm 1
• Single Pass Color™ Digital technology
for printing on media up to 307 gsm
• Tabloid extra/A3 (12" x 18"); prints on banner
sheets up to 12.9" wide by 47.24"
• High Definition Color technology for sharp detail
and rich color depth; up to 1200 x 600 dpi
resolution
• High-capacity, 2-piece consumables for low
Total Cost of Ownership
• 800 MHz PowerPC 750 processor
• 512 MB standard RAM, upgradable to 1 GB
• Holds up to 2,880 sheets with options
• Job Accounting software 2 and Web-based
printer management utility standard
• Direct PDF Printing – print .pdf files without
Adobe® Acrobat® or Acrobat Reader 2
• Available with duplexer 3, 40 GB Hard Disk Drive 4, banner paper tray, and Finisher/Stapler
• 1-Year On-Site limited warranty 5 on printer;
5-Year limited warranty on LED printheads
• Live, toll-free technical support 24/7/365 5
Digital color printers from OKI Printing Solutions
provide high-quality, tabloid extra (12" x 18")
High Definition Color output.
With the C9650 Series Digital Color printers,
you can improve the quality of your output
and increase productivity—even as you lower
your expenses.
These color printers are the efficient and
affordable answer, especially if tabloid-size
newsletters and brochures, ad layouts, large
illustrations, banners or specialty media are
essential parts of your business.
Your total in-house printing solution
No more having to run down to the corporate
or neighborhood copy center every time you need
color documents. From postcard- to banner-size
documents up to 12.9" by 47.24", you can simply
print them in-house.
C9650 Series printers come with Color Matching
software from OKI Printing Solutions and Auto
Color Balance, to ensure that color output
remains accurate and consistent from start to
finish. And features like Auto Media Detect
will automatically adjust the printer to your
required media type.
Optional saddle-stitch
finisher punches, staples,
folds and stacks up to
1,000 sheets
Single Pass Color™ Digital technology and
long-lasting, individually replaceable toner
cartridges and image drums translate into fewer
interventions—for increased productivity and
a lower cost per page than competitive color
printers and, especially, outside print-and-copy
services. Further, C9650 Series color printers have
a cost per black & white page comparable to that
of most mono laser printers—so you can use
them for all your business printing.
Optional high-capacity
feeder: 3 additional trays
(maximum paper capacity
2,880 sheets with options)
Connectivity and more
C9650 Series printers can be connected to the
network (PC- or Mac®-based) via a 10/100/1000
Base-T internal print server card. They also feature
high-speed USB v2.0 and parallel interfaces.
All C9650 Series models are equipped with Job
Accounting software 2 that allows for tracking
of color and monochrome pages, the types and
quantities of paper used, and a record of printing
activity by individual or department.
So go on, get as creative as you like—and expect
the superlative capabilities of C9650 Series Digital
Color printers from OKI Printing Solutions to make
you look great.
The easy-to-read operator panel of the C9650 Series
tilts up for user convenience, and displays current status
of the printer. A built-in toner gauge indicates the
remaining life of each toner cartridge.
Banner Paper
12.9" x 35.4" or 8.5" x 35.4" –
ideal for retail signage
C9650 Series Operator Panel in “flat” or “down” position.
Banner Paper Tray now available for
C9650 Series Printers
This tray, specifically created for long banners, easily
installs on the printer. Extending from the multi-purpose tray,
it allows the automatic feeding of up to 20 sheets of 32 lb.
banner paper. For added convenience, the tray also supports
the finished banners as they exit the printer.
1
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
2 Requires hard disk drive.
3 Standard on C9650dn and C9650hdn models.
4 Standard on C9650hdn model.
5 Available in the U.S. and Canada only.
Bright White
Proofing Sheets
In 8.5" x 11", 11" x 17" (tabloid)
and 12" x 18" (tabloid-extra)
Published performance results based on laboratory testing.
Individual results may vary.
Standard on C9650dn and C9650hdn models.
3 Declared yield in accordance with ISO/IEC 19798.
(16,500 pages CMY, 18,500 pages Black at 5% coverage,
letter-size sheets. Printers ship with 7,500-page “starter”
toner cartridges).
2
C9650 Series Operator Panel can be tilted upwards
to various angles (up to 90°) for greater convenience.
For more information or to order a Banner Paper Tray or any item from
the Signage Media Collection, call 1.800.OKI.DATA (800.654.3282).
C9650 Series At-a-Glance
Time to first print: 10.5 seconds Color,
9 seconds Mono 1 – less time waiting for documents
Toner cartridges deliver up to 22,000 color pages
and up to 22,500 pages in black & white 3
Print speeds up to
36 ppm Color, 40 ppm Mono 1
for increased productivity
Available with integrated
duplex unit for doublesided printing 2
Single Pass Color™ Digital
technology delivers high
speed, superb reliability and
unmatched paper handling
Prints paper weights up to 307 gsm
for greater media flexibility
Unmatched media flexibility:
print letterhead, card stock, even
4-foot banners – up to 307 gsm!
Introducing the Signage Media Collection from
OKI Printing Solutions. The C9650 Series prints
them all—beautifully!
SynFlex™ Paper
Water-resistant and
tear-resistant
230-sheet Multi-purpose tray
(MPT) handles non-standard
and specialty media
High Definition Color
technology for sharper
graphics and crisper text
Graphical LCD display
panel for greater ease
of use
Premium Card Stock
3 different weights;
uniformly smooth surface
530-sheet standard
paper tray
Your business calls for productivity and versatility.
That’s what you get—and more—with the C9650 Series!
Optional 530-sheet 2nd paper
tray for fewer interventions
Color printing with exceptional
paper handling flexibility
Highlights:
• C
olor output at up to 36 ppm, Monochrome (black & white) at up to 40 ppm 1
• Single Pass Color™ Digital technology
for printing on media up to 307 gsm
• Tabloid extra/A3 (12" x 18"); prints on banner
sheets up to 12.9" wide by 47.24"
• High Definition Color technology for sharp detail
and rich color depth; up to 1200 x 600 dpi
resolution
• High-capacity, 2-piece consumables for low
Total Cost of Ownership
• 800 MHz PowerPC 750 processor
• 512 MB standard RAM, upgradable to 1 GB
• Holds up to 2,880 sheets with options
• Job Accounting software 2 and Web-based
printer management utility standard
• Direct PDF Printing – print .pdf files without
Adobe® Acrobat® or Acrobat Reader 2
• Available with duplexer 3, 40 GB Hard Disk Drive 4, banner paper tray, and Finisher/Stapler
• 1-Year On-Site limited warranty 5 on printer;
5-Year limited warranty on LED printheads
• Live, toll-free technical support 24/7/365 5
Digital color printers from OKI Printing Solutions
provide high-quality, tabloid extra (12" x 18")
High Definition Color output.
With the C9650 Series Digital Color printers,
you can improve the quality of your output
and increase productivity—even as you lower
your expenses.
These color printers are the efficient and
affordable answer, especially if tabloid-size
newsletters and brochures, ad layouts, large
illustrations, banners or specialty media are
essential parts of your business.
Your total in-house printing solution
No more having to run down to the corporate
or neighborhood copy center every time you need
color documents. From postcard- to banner-size
documents up to 12.9" by 47.24", you can simply
print them in-house.
C9650 Series printers come with Color Matching
software from OKI Printing Solutions and Auto
Color Balance, to ensure that color output
remains accurate and consistent from start to
finish. And features like Auto Media Detect
will automatically adjust the printer to your
required media type.
Optional saddle-stitch
finisher punches, staples,
folds and stacks up to
1,000 sheets
Single Pass Color™ Digital technology and
long-lasting, individually replaceable toner
cartridges and image drums translate into fewer
interventions—for increased productivity and
a lower cost per page than competitive color
printers and, especially, outside print-and-copy
services. Further, C9650 Series color printers have
a cost per black & white page comparable to that
of most mono laser printers—so you can use
them for all your business printing.
Optional high-capacity
feeder: 3 additional trays
(maximum paper capacity
2,880 sheets with options)
Connectivity and more
C9650 Series printers can be connected to the
network (PC- or Mac®-based) via a 10/100/1000
Base-T internal print server card. They also feature
high-speed USB v2.0 and parallel interfaces.
All C9650 Series models are equipped with Job
Accounting software 2 that allows for tracking
of color and monochrome pages, the types and
quantities of paper used, and a record of printing
activity by individual or department.
So go on, get as creative as you like—and expect
the superlative capabilities of C9650 Series Digital
Color printers from OKI Printing Solutions to make
you look great.
The easy-to-read operator panel of the C9650 Series
tilts up for user convenience, and displays current status
of the printer. A built-in toner gauge indicates the
remaining life of each toner cartridge.
Banner Paper
12.9" x 35.4" or 8.5" x 35.4" –
ideal for retail signage
C9650 Series Operator Panel in “flat” or “down” position.
Banner Paper Tray now available for
C9650 Series Printers
This tray, specifically created for long banners, easily
installs on the printer. Extending from the multi-purpose tray,
it allows the automatic feeding of up to 20 sheets of 32 lb.
banner paper. For added convenience, the tray also supports
the finished banners as they exit the printer.
1
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
2 Requires hard disk drive.
3 Standard on C9650dn and C9650hdn models.
4 Standard on C9650hdn model.
5 Available in the U.S. and Canada only.
Bright White
Proofing Sheets
In 8.5" x 11", 11" x 17" (tabloid)
and 12" x 18" (tabloid-extra)
Published performance results based on laboratory testing.
Individual results may vary.
Standard on C9650dn and C9650hdn models.
3 Declared yield in accordance with ISO/IEC 19798.
(16,500 pages CMY, 18,500 pages Black at 5% coverage,
letter-size sheets. Printers ship with 7,500-page “starter”
toner cartridges).
2
C9650 Series Operator Panel can be tilted upwards
to various angles (up to 90°) for greater convenience.
For more information or to order a Banner Paper Tray or any item from
the Signage Media Collection, call 1.800.OKI.DATA (800.654.3282).
Productivity- and profit-enhancing
software utilities, too.
C9650 Series
C9650 Series
Specifications
Paper Handling
Performance
• Print Speed: Up to 36 ppm Color; up to 40 ppm Mono
• Time to First Page: 10.5 sec. Color; 9 sec. Mono 1
• Warm-Up Time: 85 sec. or less from Power On
• Resolution: Up to 1200 x 600 dpi resolution with
High Definition Color technology
• Processor: 800 MHz PowerPC 750
• Reliability/Duty Cycle: 150,000 pages/month
1
Standard Productivity Features
PrintSuperVision
Robust, scalable, Internet-based software that enables
administrators to access and distribute printer data
and control the functionality of all the OKI Printing
Solutions printers and most other SNMP-based
printers on their network.
• Direct PDF Printing: Receives and prints .pdf files through
Version 1.6 without opening an application, enhancing
productivity (Windows® environment only) 2
• Job Accounting: Track precise count of color and mono
pages printed by individual or department 2
• PrintSuperVision: Web-based software, printer
management tool
• Storage Device Manager: Stores and manages forms,
letterheads, logos and fonts 2
• Auto Media Detect: Automatic paper weight detection
• Auto Paper Tray Select: Automatically detects paper size
Color Controls
• Color Management: Color Matching software and Color
Correct from OKI Printing Solutions, PS Gamma Adjuster,
PostScript® CRD, Windows® ICM, Resident ICC Input/Output
Profiles (also create, download to printer, and manage new
profiles). Supports color management systems that utilize
ICC profiles (Apple®, ColorSync®, Microsoft® ICM, Adobe®
applications, QuarkXPress™, CorelDRAW®)
• Ink Simulations: SWOP®, Euroscale and others
• Color Matching Modes: sRGB, Monitor Simulations,
Digital Camera, PANTONE® Digital Color
Compatibility
Job Accounting Software
Enables tracking of color and black & white printing
costs, and easy monitoring and control of printer
usage—with both Server and Client components.
• Emulations: PCL® 5c, PCL 6, Adobe PostScript 3™
• Operating Systems: Windows – Vista®/Vista x64;
XP Home/Professional, XP Server 2003 x64; 2003 Server;
2000 Workstation/Professional/Server/Advanced Server
(all SP3 or later). Mac® – OS 9.2/OS 10.3 and higher.
• Network & Protocols: 10/100/1000 Base TX Ethernet
card with internal Web server for printer and network card
setup and management; includes POP3/APOP and SMTP
Mail client for submission of print jobs and for alerts. All
major network protocols supported – TCP/IP, Netware and
Ethertalk. TCP/IP includes ARP, IP, ICMP, TCP, UDP, LPR,
FTP, TELNET, HTTP(IPP), BOOTP, DHCP, SNMP, DNS, SSL/
TLS, JetDirect protocols; Netware includes 3.x, 4.x, 5.x
and 6 with full NDS and NDPS support – PServer, RPrinter,
NDPS supported via dedicated OKI NDPS Gateway.
Memory
• Standard RAM: 512 MB
• Maximum RAM: 1,024 MB
• Flash Memory: 4 MB standard
• Hard Disk Drive: 40 GB (standard on C9650hdn,
optional on C9650n and C9650dn)
• Standard Input: 760 sheets (530-sheet universal tray +
230-sheet multi-purpose tray)
• Optional Input: 2nd/3rd universal tray (530 sheets each);
High-Capacity Feeder (1,590 sheets); Banner Paper Tray
(20-banner-size sheets)
• Maximum Capacity: 2,880 sheets (Printer + 2nd tray +
High Capacity Feeder + Multi-Purpose Tray)
• Paper Sizes: Tabloid extra (12" x 18"), tabloid (11" x 17"),
legal, letter, executive, 3" x 5" index cards, 4" x 6" and
5" x 7" photo paper, A3, A4, A5, A6, B5, C5, DL, Com 10,
Monarch envelopes, and banners (up to 12.9" by 47.24")
• Paper Weight: Trays 1 thru 5 – 17 lb. bond–80 lb. cover
(64–216 gsm); Multi-purpose tray – 17 lb. bond–120 lb.
cover (64–307 gsm); duplex – 20 lb. bond–65 lb. cover
(75–188 gsm) for letter and tabloid sheets
• Duplex (2-sided printing): Standard on C9650dn and
C9650hdn; optional on C9650n
Typefaces
• Printer Fonts: 86 scalable PCL fonts, 1 bitmap font,
10 TrueType® fonts, 136 Adobe PostScript Type 1 fonts,
OCR A/B, USPS Barcode
Environmental
• Size (WxDxH): 23.6" x 24.6" x 18.5"
(59.9 cm x 62.5 cm x 46.9 cm)
• Weight: 167.5 lb. (76.0 kg) with consumables
• Power Consumption: Operating – Typical 780W,
Peak <1500W; Standby 200W (average); Power Save 33W
• Acoustic Noise: Operating – 54dB(A) or less; Standby:
42dB(A) or less; Power Save: 28dB(A) (background level)
• ENERGY STAR: Available on C9650dn and C9650hdn
Warranty
• Printer: 1-Year limited On-Site warranty 3, parts and labor
• Digital LED Printhead: 5-Year limited warranty
Important Consumables Information: This product
has been designed and engineered to operate only with
genuine OKI Printing Solutions consumables. Use of
non-genuine consumables will result in the loss of certain
printer enhancements, such as Auto Color Balance and
the Toner Sensor gauge.
For more information on Digital Color printers
and supplies from OKI Printing Solutions, including
OKIcare® Extended Service Programs: 1.800.OKI.DATA
(800.654.3282).3
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
Requires hard disk drive (standard on C9650hdn).
3 Available in the U.S. and Canada only.
4 ENERGY STAR compliant.
5 Based on 5% coverage, Letter-size sheet. Printers ship
with 7,500-page “starter” toner cartridges.
6 Declared yield in accordance with ISO/IEC 19798.
7 E stimated life, continuous printing (will vary depending on
number of printed pages per job).
2
Interface
• Standard Connectivity: 10/100/1000 Ethernet,
High-speed USB v2.0, Parallel
Ordering Information
Description
Part Numbers
C9650n 120V (Multilingual)
62430604
C9650n 230V (Multilingual)
62430605
C9650dn 120V (Multilingual) 4
62430606
C9650dn 230V (Multilingual) 4
62430607
C9650hdn 120V (Multilingual) 4
62430608
C9650hdn 230V (Multilingual) 4
62430609
Options
2nd and 3rd 530-sheet Paper Tray Mechanism
42831301
Duplex Unit 42797201
High-Capacity Feeder
42831501
Banner Paper Tray
42964903
4-Tray Finisher
70050701
5-Tray Finisher
70050801
2-/3-Hole Punch for Finisher
42872902
40 GB Hard Disk Drive
70050502
256 MB Memory Expansion DIMM
70051601
512 MB Memory Expansion DIMM
70051701
Printer Cabinet
70050901
Supplies
Toner Cartridges (Type C7)
Cyan Toner Cartridge 16,5005/22,000 pg.6 42918983
Magenta Toner Cartridge 16,5005/22,000 pg.6 42918982
Yellow Toner Cartridge 16,5005/22,000 pg.6 42918981
Black Toner Cartridge 18,5005/22,500 pg.6 42918984
Image Drums (Type C7)
Cyan Image Drum 42,000 pg.7
42918103
Magenta Image Drum 42,000 pg.7
42918102
Yellow Image Drum 42,000 pg.7
42918101
Black Image Drum 42,000 pg.7
42918104
Consumables
7
Fuser Kit (120V)
100,000 pg. 42931701
Fuser Kit (230V)
100,000 pg.7
42931702
7
Transfer Belt
100,000 pg. 42931601
5
Waste Toner Box 30,000 pg. 42869401
Finisher Staples
15,000 count
42937601
Print Media
Sheets Per Box
Premium Card Stock (8.5" x 11"):
60 lb. cover
250
52205601
90 lb. index
250
52205602
110 lb. index
250
52205603
Bright White Proofing Sheets (32 lb.):
8.5" x 11" 500 52206101
11" x 17" 500 52206102
12" x 18" 500 52206103
Ultra Gloss Paper (8 pt.):
4" x 6"
50
52208909
5" x 7"
50
52208910
8.5" x 11" 100 52208901
8.5" x 11" 250 52208902
11" x 17" 50 52208903
12" x 18" 50 52208904
Banner Paper:
12.9" x 35.4"
100
52206001
8.5" x 35.4"
100
52206002
SynFlex™ Paper (Waterproof and Tear-resistant):
8.5" x 11"
100
52205901
12.75" x 18"
100
52205904
Premium Envelopes (size #10):
100
52206301
500
52206302
Brilliant color. Unmatched media flexibility.
C9650n
C9650dn
C9650hdn
Oki Data Americas, Inc.
Color Matching Software from OKI Printing Solutions
An accurate color matching/job flow management
program that enables users to match the colors on
their monitor with their color output, and create
ICC input/output profiles for printers, monitors
and scanners.
USA
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: 856.222.5320
Canada
2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: 905.238.4250
Fax: 905.238.4421
Latin America
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 856.231.0002
Fax: 856.222.5071
Oki Data de México, S.A. de C.V.
Mariano Escobedo, 748 8º Piso
Col. Nueva Anzures C.P. 11590
México, D.F.
Tel: 55.5263.8780
Fax: 55.5250.3501
www.okiprintingsolutions.com/us
Specifications are subject to change without notice.
© 2009 Oki Data Americas, Inc. OKI Reg. T.M., M.D. M.R., OKIcare, OkiLAN Reg. T.M., Oki Electric Industry Co., Ltd. High Definition Color logo T.M., Single Pass Color T.M. and design
Reg. T.M., Oki Data Corp. SynFlex T.M., Oki Data Americas, Inc. SWOP T.M., SWOP, Inc. Adobe, PostScript, Acrobat Reg. T.M., PostScript 3 T.M., Adobe Systems Inc. Microsoft, Windows,
Windows NT Reg. T.M., Vista T.M., Microsoft Corp. PCL, Reg. T.M., Hewlett-Packard Co. Mac, ColorSync Reg. T.M., Apple Inc. PANTONE and Pantone Digital Color and design Reg. T.M.,
Pantone, Inc. QuarkXPress T.M., Quark Inc. CorelDraw Reg. T.M., Corel Corp. Intel Reg. T.M., Intel Corp. ENERGY STAR Reg. T.M., U.S. EPA. USB-Logo T.M. Universal Serial Bus Implementers
Forum, Inc.
Printed in the USA MS 15858-0709
Oki Data do Brasil Informática Ltda.
Av. Alfredo Egídio de Souza Aranha, 100
Bloco C – 4º andar
04726-170 – São Paulo – SP – Brasil
Tel: 11.3444.3500
Fax: 11.3444.3502
Productivity- and profit-enhancing
software utilities, too.
C9650 Series
C9650 Series
Specifications
Paper Handling
Performance
• Print Speed: Up to 36 ppm Color; up to 40 ppm Mono
• Time to First Page: 10.5 sec. Color; 9 sec. Mono 1
• Warm-Up Time: 85 sec. or less from Power On
• Resolution: Up to 1200 x 600 dpi resolution with
High Definition Color technology
• Processor: 800 MHz PowerPC 750
• Reliability/Duty Cycle: 150,000 pages/month
1
Standard Productivity Features
PrintSuperVision
Robust, scalable, Internet-based software that enables
administrators to access and distribute printer data
and control the functionality of all the OKI Printing
Solutions printers and most other SNMP-based
printers on their network.
• Direct PDF Printing: Receives and prints .pdf files through
Version 1.6 without opening an application, enhancing
productivity (Windows® environment only) 2
• Job Accounting: Track precise count of color and mono
pages printed by individual or department 2
• PrintSuperVision: Web-based software, printer
management tool
• Storage Device Manager: Stores and manages forms,
letterheads, logos and fonts 2
• Auto Media Detect: Automatic paper weight detection
• Auto Paper Tray Select: Automatically detects paper size
Color Controls
• Color Management: Color Matching software and Color
Correct from OKI Printing Solutions, PS Gamma Adjuster,
PostScript® CRD, Windows® ICM, Resident ICC Input/Output
Profiles (also create, download to printer, and manage new
profiles). Supports color management systems that utilize
ICC profiles (Apple®, ColorSync®, Microsoft® ICM, Adobe®
applications, QuarkXPress™, CorelDRAW®)
• Ink Simulations: SWOP®, Euroscale and others
• Color Matching Modes: sRGB, Monitor Simulations,
Digital Camera, PANTONE® Digital Color
Compatibility
Job Accounting Software
Enables tracking of color and black & white printing
costs, and easy monitoring and control of printer
usage—with both Server and Client components.
• Emulations: PCL® 5c, PCL 6, Adobe PostScript 3™
• Operating Systems: Windows – Vista®/Vista x64;
XP Home/Professional, XP Server 2003 x64; 2003 Server;
2000 Workstation/Professional/Server/Advanced Server
(all SP3 or later). Mac® – OS 9.2/OS 10.3 and higher.
• Network & Protocols: 10/100/1000 Base TX Ethernet
card with internal Web server for printer and network card
setup and management; includes POP3/APOP and SMTP
Mail client for submission of print jobs and for alerts. All
major network protocols supported – TCP/IP, Netware and
Ethertalk. TCP/IP includes ARP, IP, ICMP, TCP, UDP, LPR,
FTP, TELNET, HTTP(IPP), BOOTP, DHCP, SNMP, DNS, SSL/
TLS, JetDirect protocols; Netware includes 3.x, 4.x, 5.x
and 6 with full NDS and NDPS support – PServer, RPrinter,
NDPS supported via dedicated OKI NDPS Gateway.
Memory
• Standard RAM: 512 MB
• Maximum RAM: 1,024 MB
• Flash Memory: 4 MB standard
• Hard Disk Drive: 40 GB (standard on C9650hdn,
optional on C9650n and C9650dn)
• Standard Input: 760 sheets (530-sheet universal tray +
230-sheet multi-purpose tray)
• Optional Input: 2nd/3rd universal tray (530 sheets each);
High-Capacity Feeder (1,590 sheets); Banner Paper Tray
(20-banner-size sheets)
• Maximum Capacity: 2,880 sheets (Printer + 2nd tray +
High Capacity Feeder + Multi-Purpose Tray)
• Paper Sizes: Tabloid extra (12" x 18"), tabloid (11" x 17"),
legal, letter, executive, 3" x 5" index cards, 4" x 6" and
5" x 7" photo paper, A3, A4, A5, A6, B5, C5, DL, Com 10,
Monarch envelopes, and banners (up to 12.9" by 47.24")
• Paper Weight: Trays 1 thru 5 – 17 lb. bond–80 lb. cover
(64–216 gsm); Multi-purpose tray – 17 lb. bond–120 lb.
cover (64–307 gsm); duplex – 20 lb. bond–65 lb. cover
(75–188 gsm) for letter and tabloid sheets
• Duplex (2-sided printing): Standard on C9650dn and
C9650hdn; optional on C9650n
Typefaces
• Printer Fonts: 86 scalable PCL fonts, 1 bitmap font,
10 TrueType® fonts, 136 Adobe PostScript Type 1 fonts,
OCR A/B, USPS Barcode
Environmental
• Size (WxDxH): 23.6" x 24.6" x 18.5"
(59.9 cm x 62.5 cm x 46.9 cm)
• Weight: 167.5 lb. (76.0 kg) with consumables
• Power Consumption: Operating – Typical 780W,
Peak <1500W; Standby 200W (average); Power Save 33W
• Acoustic Noise: Operating – 54dB(A) or less; Standby:
42dB(A) or less; Power Save: 28dB(A) (background level)
• ENERGY STAR: Available on C9650dn and C9650hdn
Warranty
• Printer: 1-Year limited On-Site warranty 3, parts and labor
• Digital LED Printhead: 5-Year limited warranty
Important Consumables Information: This product
has been designed and engineered to operate only with
genuine OKI Printing Solutions consumables. Use of
non-genuine consumables will result in the loss of certain
printer enhancements, such as Auto Color Balance and
the Toner Sensor gauge.
For more information on Digital Color printers
and supplies from OKI Printing Solutions, including
OKIcare® Extended Service Programs: 1.800.OKI.DATA
(800.654.3282).3
1
ublished performance results based on laboratory testing.
P
Individual results may vary.
Requires hard disk drive (standard on C9650hdn).
3 Available in the U.S. and Canada only.
4 ENERGY STAR compliant.
5 Based on 5% coverage, Letter-size sheet. Printers ship
with 7,500-page “starter” toner cartridges.
6 Declared yield in accordance with ISO/IEC 19798.
7 E stimated life, continuous printing (will vary depending on
number of printed pages per job).
2
Interface
• Standard Connectivity: 10/100/1000 Ethernet,
High-speed USB v2.0, Parallel
Ordering Information
Description
Part Numbers
C9650n 120V (Multilingual)
62430604
C9650n 230V (Multilingual)
62430605
C9650dn 120V (Multilingual) 4
62430606
C9650dn 230V (Multilingual) 4
62430607
C9650hdn 120V (Multilingual) 4
62430608
C9650hdn 230V (Multilingual) 4
62430609
Options
2nd and 3rd 530-sheet Paper Tray Mechanism
42831301
Duplex Unit 42797201
High-Capacity Feeder
42831501
Banner Paper Tray
42964903
4-Tray Finisher
70050701
5-Tray Finisher
70050801
2-/3-Hole Punch for Finisher
42872902
40 GB Hard Disk Drive
70050502
256 MB Memory Expansion DIMM
70051601
512 MB Memory Expansion DIMM
70051701
Printer Cabinet
70050901
Supplies
Toner Cartridges (Type C7)
Cyan Toner Cartridge 16,5005/22,000 pg.6 42918983
Magenta Toner Cartridge 16,5005/22,000 pg.6 42918982
Yellow Toner Cartridge 16,5005/22,000 pg.6 42918981
Black Toner Cartridge 18,5005/22,500 pg.6 42918984
Image Drums (Type C7)
Cyan Image Drum 42,000 pg.7
42918103
Magenta Image Drum 42,000 pg.7
42918102
Yellow Image Drum 42,000 pg.7
42918101
Black Image Drum 42,000 pg.7
42918104
Consumables
7
Fuser Kit (120V)
100,000 pg. 42931701
Fuser Kit (230V)
100,000 pg.7
42931702
7
Transfer Belt
100,000 pg. 42931601
5
Waste Toner Box 30,000 pg. 42869401
Finisher Staples
15,000 count
42937601
Print Media
Sheets Per Box
Premium Card Stock (8.5" x 11"):
60 lb. cover
250
52205601
90 lb. index
250
52205602
110 lb. index
250
52205603
Bright White Proofing Sheets (32 lb.):
8.5" x 11" 500 52206101
11" x 17" 500 52206102
12" x 18" 500 52206103
Ultra Gloss Paper (8 pt.):
4" x 6"
50
52208909
5" x 7"
50
52208910
8.5" x 11" 100 52208901
8.5" x 11" 250 52208902
11" x 17" 50 52208903
12" x 18" 50 52208904
Banner Paper:
12.9" x 35.4"
100
52206001
8.5" x 35.4"
100
52206002
SynFlex™ Paper (Waterproof and Tear-resistant):
8.5" x 11"
100
52205901
12.75" x 18"
100
52205904
Premium Envelopes (size #10):
100
52206301
500
52206302
Brilliant color. Unmatched media flexibility.
C9650n
C9650dn
C9650hdn
Oki Data Americas, Inc.
Color Matching Software from OKI Printing Solutions
An accurate color matching/job flow management
program that enables users to match the colors on
their monitor with their color output, and create
ICC input/output profiles for printers, monitors
and scanners.
USA
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: 856.222.5320
Canada
2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: 905.238.4250
Fax: 905.238.4421
Latin America
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 856.231.0002
Fax: 856.222.5071
Oki Data de México, S.A. de C.V.
Mariano Escobedo, 748 8º Piso
Col. Nueva Anzures C.P. 11590
México, D.F.
Tel: 55.5263.8780
Fax: 55.5250.3501
www.okiprintingsolutions.com/us
Specifications are subject to change without notice.
© 2009 Oki Data Americas, Inc. OKI Reg. T.M., M.D. M.R., OKIcare, OkiLAN Reg. T.M., Oki Electric Industry Co., Ltd. High Definition Color logo T.M., Single Pass Color T.M. and design
Reg. T.M., Oki Data Corp. SynFlex T.M., Oki Data Americas, Inc. SWOP T.M., SWOP, Inc. Adobe, PostScript, Acrobat Reg. T.M., PostScript 3 T.M., Adobe Systems Inc. Microsoft, Windows,
Windows NT Reg. T.M., Vista T.M., Microsoft Corp. PCL, Reg. T.M., Hewlett-Packard Co. Mac, ColorSync Reg. T.M., Apple Inc. PANTONE and Pantone Digital Color and design Reg. T.M.,
Pantone, Inc. QuarkXPress T.M., Quark Inc. CorelDraw Reg. T.M., Corel Corp. Intel Reg. T.M., Intel Corp. ENERGY STAR Reg. T.M., U.S. EPA. USB-Logo T.M. Universal Serial Bus Implementers
Forum, Inc.
Printed in the USA MS 15858-0709
Oki Data do Brasil Informática Ltda.
Av. Alfredo Egídio de Souza Aranha, 100
Bloco C – 4º andar
04726-170 – São Paulo – SP – Brasil
Tel: 11.3444.3500
Fax: 11.3444.3502
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
