Digital Multimedia Projector, SVGA 1800 Technical Info

Digital Multimedia Projector, SVGA 1800 Technical Info
D418V
Digital Multimedia Projector, SVGA 1800
D418 Series is a projector with an amazing image quality because it's powered by superior technology which
enhances brightness, contrasts, tint, colour and clarity. There are several tools to help the user to reduce the
time of preparation for efficient presentation purposes.
Case, Cable and Remote Included!
• Independent 7-colour adjustment
• Light by OSRAM, quality lamp
• Bi-Modes selection: Eco & Standard
• 720p./1080i (HDTV Compatible)
• Digital Visual Interface (DVI)
• Picture-in-Picture
• Auto Source Detection
• Multiple OSD Languages
• Multi-Projection Methods
• Customized Flash Logo
• Zero radiation
• Smart Cooling System
• Carrying Case for travelling
Including accessories:
Projector with Lens cover
Remote control with batteries
Local Power Card
Soft Carrying Case
DVI to RGB Cable
S-Video Cable
Stereo Mini Jack Cable (for PC)
USB Cable
Quick Start Guide (hard copy)
User manual (CD)
Technical Info
Display Technology: 0.55" DMD, DDP 2000
Resolution: SVGA 800x600 (native), 1024X768 (compressed)
Pojection Distance: 1,5-7m.
Screen Size(diagonal): 0,93x5,16m.
Contrast Ratio: 2000:1
Brightness: 1800 Lumen
Throw Ratio(D/W): 1.16:1
Lamp: 200W(VIP-Type)
Aspect Ratio: 4:3 & 16:9
Lens: Carl Zeiss with Manual zoom(1:1,16) and Focus F2,6
Data Compatibility: IBM PC or Compatible (VGA, SVGA, XGA) and Macintosh
Video Compatibility: NTSC/NTSC 4,43, PAL, SECAM Composite & S-Video HDTV: 480i, 480p, 720p, 1080i
Digital Keystone Correction:+/- 15° (Vertical)
Input/Output: RGB Input DVIx1 S-Video in Mini DIN 4-pin x1 Composite video RCA jack x1 Audio in Mini Jack
x1 Component Video Through DVI-Input Rs232 Input PS/2 Mini Din x1 USB Input Type B receptacle x1
Security: Kensington® MicroSaver Security System
Weight: 2.0Kg
Dimensions(LxWxH): 280mm x 205mm x 97mm
Noise: 34dB
Remote control features: Power On/Off, Menu, OSD navigation, Freeze on-screen picture, Keystone
adjustment, Auto Key to optimize image performance, Mute to control built-in speaker, Volume control, Detect
input-source
Standard Accessories: Power cord, Remote control, carrying case, lens cap, DVI-RGB cable S-Video, QSG,
Manual in disk, Composite video cable, RCA audio cable
Optional Accessories: Lamp replacement module, component video cable
Special features: Eco Mode, Customized Flash Logo
Safety Certification: FCC-B, UL, C-UL, CE/TUV.CB, CCC
Lamp: 100151
