portable jetters options
HIGH PRESSURE JETTING MACHINES
PORTABLE JETTERS
14
OPTIONS
OPTIONS VANPACK
155
MINIJET AND RIONED HD30
PROFESSIONAL CLEANING OF DRAINS UP TO 200MM
MINIJET
The MiniJet is a high pressure jetting machine for
residential- and light commercial use. Equipped with a
silent and powerful electric motor and professional pump
it is ideal for cleaning drains from 25 - 100 mm.
The MiniJet is easy to transport on stairs or in the
elevator. The motor/pump unit can be easily removed
and used independently (with a NW 5 hose) from the
hose reel meaning you can leave the hose reel section
behind if the workspace is limited.
RIONED HD30
The HD30 mobile high pressure jetting machine is fitted
with a petrol engine that guarantees optimal cleaning of
small drains and sewers up to 200 mm.
This machine is particularly suitable for jetting and
cleaning of house connections, roof water drains, sewers
blocked with grease and industrial sewers. It is also very
effective at cleaning street furniture and terraces. The
HD30 can be connected directly to a water supply
therefore eliminating the need for a separate water tank.
The HD30 is supplied with two nozzles and a high
pressure gun with lance.
RIOMOTE
With RioMote radio remote your jetting
machine can be controlled by a single man.
With the 5 channel RioMote radio remote
on our petrol driven jetters, you can switch
the pump on or off and increase or decrease
the engine revs.
In addition there is a 7 channel radio
remote available on our diesel machines
meaning you can also switch the engine on
or off.
There is also an emergency stop function
for maximum safety.
WINTER PROTECTION
Severe winter conditions can seriously
damage the critical components of your
jetting machine. Rioned offers an anti-frost
system with tank to prevent extreme
weather damage.
Rioned HD30
HD30 130 bar / 30 lpm
HD30 140 bar / 40 lpm
Operating range
25-100mm
40-200mm
40-200mm
Engine
1.8 kW electro engine 230V - 50Hz
Honda 8 kW petrol engine
Honda 8 kW petrol engine
Rioned/Speck
Rioned/Speck
Max. 110 bar / 10 lpm
Rioned/Speck P21
130 bar / 30 lpm
Rioned/Speck P30
100 bar / 40 lpm
20 metres NW 8 with 1/4”coupling
10 metres NW 5 hose with
1/8”coupling 1,5 metres suction hose
40 metres NW 8
40 metres NW 8
Engine and pump 30 kgs
Hosereel 26 kgs
85 kgs
HP hose
Weight
85 kgs
Water supply
Direct tap connenction or with
suction venturi
Direct tap connection
Direct tap connection
Nozzles
2 nozzles 1/4” (1 open, 1 blind)
1 nozzle 1/8”(blind)
2 nozzles 1/4” (1 open, 1 blind)
1 nozzle 1/8”(blind)
2 nozzles 1/4” (1 open, 1 blind)
1 nozzle 1/8”(blind)
Accessories
High pressure gun with 600mm
lance liquid suction hose with filter
High pressure gun with 600mm
lance liquid suction hose with filter
High pressure gun with 600mm
lance liquid suction hose with filter
FlexMote 3 channel
V
--
--
RioMote 5 channel
V
--
--
RioMote 7 channel
--
V
V
Pulsator
V
V
V
Run dry protection
V
•
•
Working light
V
V
V
Functionality
Anti freeze tank
V
V
V
Extra water tanks
400 l
600 l
800 l
V
V
V
FIXED VENTURY
The ventury system creates suction pressure
in the clean water tanks which allows you to
fill up with water from lakes and canals at
high speed.
Hydraulic drive
V
•
•
2nd High pressure hose reel
(instead of supply hose reel)
V
V
V
Mechanical freewheel
HP hose reel
V
•
V
Hydrant connection on tank
V
V
V
Speed regulation hydraulic
hose reel
V
V
V
Other colour
V
V
V
Others
V option possible
-- option not possible
•standard
all our machines are delivered with exhaust- and mounting package
OPTIONS RIONED TRAILERS
Water savings of up to 80% can be achieved
while time is saved because the pulsed
action feeds the high pressure hose quickly
and effectively into the pipework.
MiniJet 110 bar / 10 lpm
ProfiJet
Hose reel
PULSATOR
The Pulsator is an adjustment to the pump
that continuously interrupts the water flow
and sends pulses of water through the hose.
TECHNICAL SPECIFICATIONS
CityJet
Suction ventury mounted on
the tank
RioMote remote control has a massive
operating range and thanks to the extra
battery supplied you can work continuously.
MiniJet
AquaJet
Remote control
RIOFREE
The RioFree freewheel system ensures
that the hose reel can be coiled off without
friction of the hydraulic system, this feature
significantly reduces the effort required
to operate the hose reel.
RIONED ACCESSORIES
Enhance your efficiency with a range of
accessories. We offer a complete range of
jetting nozzles for all types of application.
From standard and rotating nozzles to
hydraulic root cutters and specialist nozzles
to remove soil.
To extend the life of your high pressure
hose we can supply hose inlet guidance
tubes and rollers. The suction ventury
device is a simple tool to empty flooded
cellars without having to use a separate
suction pump.
See www.rioned.com for more details.
FlexJet
FlexJet+
MultiJet
FlexMote 3 channel
V
V
--
RioMote 5 channel
V
V
--
RioMote 7 channel
--
--
V
Pulsator
V
V
V
Run dry protection
V
V
•
Working light
V
V
V
Anti freeze tank
--
--
V
Extra water tanks
--
--
--
Suction ventury mounted on
the tank
--
--
V
Hydraulic drive
--
V
•
2nd High pressure hose reel
(instead of supply hose reel)
--
V
V
Mechanical freehweel
HP hose reel
--
V
V
V
V
V
Rubber shock absorbers
V
•
•
Light metal wheels
V
V
V
Remote control
Funtionality
Hose reel
ELECTRIC WATER LEVEL CONTROL
The automatic water level control system
automatically opens the filling valve if the
water level is low and also shuts the supply
feed off if the tank level has reached its
maximum. This option allows the user to
continuously fill and work uninterrupted
when connected to a tap.
SPRAYBEAM (MULTIJET ONLY)
Spraybeam with rotating nozzles to clear
streets from oil spills etc.
Outfit
Other colour
V option possible
-- option not possible
•standard
