the printer that has it all for those who want it all

the printer that has it all for those who want it all
TS9020
TS9020
WIRELESS INKJET ALL-IN-ONE PRINTER
PRINT | COPY | SCAN | WIRELESS
THE PRINTER
THAT HAS
IT ALL FOR
THOSE WHO
WANT IT ALL
YOUR EVERYDAY PRINTER FOR:
KEY FEATURES:
CONNECTIVITY:
5.0" Touch LCD Screen
6 Color Ink System
WIRELESS
PRINTING
3
NFC Printing1
2400x4800 Scan DPI2
Front & Rear Paper Feed
CANON
PRINT APP 4
5
Auto Expanding Output Tray
Square Photo Print Support
6
TS9020 WIRELESS INKJET ALL-IN-ONE PRINTER
TS9020
TECHNICAL INFORMATION
AVAILABLE COLORS:
White
Red
PRINT
PRODUCT INFO / INKS
Print FeaturesAirPrint,5 Auto Duplex Printing, Auto Photo Fix II, Borderless Printing,7
Business Card Printing, Canon PRINT app,4 Creative Filters, CD/DVD/
Blu-ray Disc Printing, Document Printing, Easy PhotoPrint+,8 Full HD
Movie Print,9 Google Cloud Print,6 Grayscale Printing, Image Cropping,
Mopria Device Printing,10 My Image Garden,11 Original Document Detector,
Photo Direct Printing (Memory Card),12 Photo Printing, PIXMA Cloud
Link,13 PIXMA Touch & Print (NFC),1 Quiet Mode, Red-Eye Correction,
Special Filters, Square Media Printing Support, Web Template Print,
Wireless PictBridge,14 Wireless Printing3
Model No.
PIXMA TS9020 White
PIXMA TS9020 Red
Wireless Inkjet All-In-One Printer
Wireless Inkjet All-In-One Printer
Compatible Inks
PGI-270 PGBK XL
CLI-271 BK XL
CLI-271 C XL
CLI-271 M XL
CLI-271 Y XL
CLI-271 GY XL
PGI-270 PGBK
CLI-271 BK
CLI-271 C
CLI-271 M
CLI-271 Y
CLI-271 GY
XL Pigment Black Ink Tank
XL Black Ink Tank
XL Cyan Ink Tank
XL Magenta Ink Tank
XL Yellow Ink Tank
XL Gray Ink Tank
Pigment Black Ink Tank
Black Ink Tank
Cyan Ink Tank
Magenta Ink Tank
Yellow Ink Tank
Gray Ink Tank
Print Speed15,16
4" x 6" Photo: Approx. 21 seconds (Borderless)
ESAT (Black): Approx. 15.0 ipm
ESAT (Color): Approx. 10.0 ipm
Number of Nozzles
Color: 5,632 / Pigment Black: 1,024 / Total: 6,656
Paper Sizes
4" x 6," 5" x 5" Square, 5" x 7," 8" x 10," Letter, Legal, U.S. #10 Envelope
Paper Tray Capacity
Rear Paper Tray: 100 Sheets of Plain Paper OR Photo Paper: 20 Sheets of 4" x 6" / 10 Sheets of 5" x 7"
Front Paper Cassette: 100 Sheets of Plain Paper
COPY
Copy Features
4-on-1 / 2-on-1 Copy, Auto Exposure Copy, Auto Photo Fix II, Borderless
Copy, Disc Label Copy, Document Removal Reminder, Fade Restoration,
Fit-to-Page, Frame Erase Copy, Preset Copy Ratios, Two-sided Copy
Copy Speed16
FCOT (Color): Approx. 19 seconds
Reduction/Enlargement
25% – 400%
Scan Features
Auto Scan Mode,17 Document Removal Reminder, Push Scan, Network
Scan, Wireless Scanning3
Scanner Type
Flatbed
Scanning Method
Contact Image Sensor (CIS)
Scanning Resolution2
2400 x 4800 dpi (Optical), 19,200 x 19,200 dpi (Interpolated)
Maximum Color Depth
48-bit Internal / 24-bit External
Maximum Document Size
8.5" x 11.7"
GENERAL
General Features
all viewscreen and printer output images are simulated.
5.0" Touch LCD, 6-Color Ink System with Gray Ink, CREATIVE PARK
PREMIUM,18 Auto Power On/Off, Auto Expandable Output Tray, Canon
PRINT app,4 PIXMA Cloud Link,13 QuickStart
Standard Interface
Hi-Speed USB, Ethernet, PictBridge (LAN/Wireless LAN),14 Wireless LAN
(IEEE 802.11b/g/n),3 Memory Card Slot,12 NFC (PIXMA Touch & Print)1
Size/Weight
14.7"(W) x 12.8"(D) x 5.6"(H) / 14.7 lbs.
Software (Windows®19/Mac®20)
PIXMA TS9020 Printer Driver, Scan Utility, Master Setup, My Printer
(Windows Only), Network Tool, My Image Garden11 (Full HD Movie Print,9
CREATIVE PARK PREMIUM,18 Special Filters, Image Correction/Enhance,
and scanning are accessed through My Image Garden), Quick Menu
OS Compatibility
Computer Operating Systems:
Windows:19 Windows® 10, Windows 8, Windows 8.1, Windows 7, Windows
7 SP1, Vista SP2
Mac:20 Mac OS®X v10.8.5–macOS v10.12 (Sierra)
Mobile Operating Systems: 21 iOS,® Android,™ Windows 10 Mobile,
Windows RT22 and Amazon Fire devices23
Warranty 24
1-Year limited warranty with InstantExchange Program.
1-Year toll-free U.S.-based technical phone support.
FOR MORE INFORMATION VISIT WWW.USA.CANON.COM/CONSUMER
For the name of the nearest dealer, call: 1-800-OK-CANON
0319C001AA
0336C001AA
0337C001AA
0338C001AA
0339C001AA
0340C001AA
0373C001AA
0390C001AA
0391C001AA
0392C001AA
0393C001AA
0394C001AA
specifications are subject to change without notice.
SCAN
1371C002AA
1371C022AA
1Requires an Android mobile device with NFC hardware running Android 2.3.3 or later, and the Canon PRINT Inkjet/
SELPHY app, available of free at Google Play. Canon PRINT Inkjet/SELPHY app must be open to use PIXMA Touch & Print.
2Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard.
3Wireless printing and scanning requires a working network with wireless 802.11b/g or n capability. Wireless
performance may vary based on terrain and distance between the printer and wireless network clients.
4Requires an Internet connection and the Canon PRINT Inkjet/SELPHY app, available for free on the App Store and at
Google Play. Compatible with iPad, iPhone 3GS or later, and iPod touch 3rd generation or later devices running iOS 7.0
or later, and Android mobile devices running Android 2.3.3 or later. Your device must be connected to the same working
network with wireless 802.11 b/g/n capability as your printer. For users of compatible Apple mobile devices, document
printing requires Apple AirPrint, which requires an AirPrint-enabled printer connected to the same network as your iOS
device. A printer connected to the USB port of your Mac, PC, AirPort Base station, or Time Capsule is not supported.
5AirPrint functionality requires an iPad, iPhone 3GS or later, or iPod touch 3rd generation or later device running iOS 4.2
or later, and an AirPrint-enabled printer connected to the same network as your iOS device. A printer connected to the
USB port of your Mac, PC, AirPort Base station, or Time Capsule is not supported.
6Requires an Internet connection and Google account. Subject to Google Terms of Service. Certain exceptions may apply.
7Envelopes and High Resolution Paper are NOT supported for borderless printing.
8Works edited by using this application cannot be displayed, edited, or printed without this application. Compatible with
Android device of 7 inches or more using Chrome (latest version compatible with your current version of Android OS),
iOS Devices of 7 inches or more using Safari 5.1 or later, Windows PC (excluding RT) using Internet Explorer 10 or later
of Microsoft Modern UI version, Microsoft Internet Explorer 9 or later, Mozilla Firefox 31 or later, or Google Chrome
version 36 or later, and with Mac OS X 10.6.8 or later using Safari 5.1 or later.
9“Full HD Movie Print” is available from “MOV” and “MP4” movie files created by select Canon EOS Digital SLRs,
PowerShot, and VIXIA digital cameras and camcorders. Requires PC or Mac with Intel® processor and Canon
ZoomBrowser EX 6.5 or later or Canon ImageBrowser 6.5 or later for “MOV” files, or Canon ImageBrowser EX 1.0 or
later for “MOV” or “MP4” files. Print quality is determined by the video resolution. Function does not upscale video resolution.
10Requires Android mobile device with Android 4.4 operating system or later with the Mopria Print Service pre-loaded with
that device and the compatible PIXMA printer on the same wireless network. The Mopria experience is also available on
Android 4.4 mobile devices with a download of the Mopria Print Service from Google Play.
11To install using Windows® OS, .NET Framework 4 is required. Compatible still image formats are PDF (created using
Canon PDF Creator only), JPEG (Exif), TIFF, and PNG. Compatible video formats are MOV (from select Canon digital
cameras only) and MP4 (from select Canon digital camcorders only).
12Compatible memory cards include SD™ Card, SDHC™ Card. The following can be used with the addition of a special
adapter sold separately: miniSD™ Card, miniSDHC™ Card, microSD™ Card, microSDHC™ Card.
13Requires an Internet connection.
14DPS over IP compatible device required.
15Photo print speeds are based on the standard mode driver setting using photo test pattern(s) and select Canon Photo
Paper. Print speed is measured as soon as first page begins to feed into printer and will vary depending on system
configuration, interface, software, document complexity, print mode, types of paper used, and page coverage.
See www.usa.canon.com/printspeed for additional information.
16ISO/IEC 24734, 24735 define the default print and copy speed measurement methods. Print speeds are the averages
of ESAT in Office Category Test for the default simplex mode, ISO/IEC 24734, excluding time to print the first set. Copy
speed is the average of FCOT, ISO/IEC 24735 Annex D. ADF copy speed is the average of ESAT in General Performance
Test for the default simplex mode, ISO/IEC 24735,excluding time to copy the first set.
See www.usa.canon.com/ipm for additional details.
17For network users, Auto Scan Mode is only available when scanning at a computer using My Image Garden software
and selecting the 1-click feature then “Save to PC.”
18CREATIVE PARK PREMIUM is a premium content service available exclusively to users only when all of the colors of
genuine Canon inks and all of the software that came with the printer are properly installed.
19Operation can only be guaranteed on a PC with pre-installed Windows 10, Windows 8.1, Windows 8, Windows 7 or Vista.
20Internet Connection required during software installation. For full compatibility macOS v10.12.1 or later is recommended.
21Some functions may not be available with these Operating Systems. Please refer to manual or our website for details.
22Requires a Windows RT compatible device and the Canon Easy-PhotoPrint app for Windows RT available for free in the
Windows Store.
23Requires “Canon Print Plugin” available for free from the Amazon Appstore and an Amazon Fire Phone, Amazon Kindle
Fire HD6 or HDX7 device or later running Fire OS 4.0 or later.
24Warranty programs are subject to certain conditions and restrictions. See www.usa.canon.com/support for details.
Discover Canon’s
Social Side:
©2016 Canon U.S.A., Inc. Canon and PIXMA are registered trademarks of Canon Inc. in the U.S. and may be registered trademarks or trademarks in other countries. Microsoft, Windows, the Windows logo and Internet Explorer are trademarks or registered trademarks of the Microsoft
group of companies in the U.S. and other countries. AirPort, Apple, iPad, iPhone, iPod touch and Time Capsule are registered trademarks of Apple Inc. AirPrint is a trademark of Apple Inc. App Store is a service mark of Apple Inc. iOS is a trademark or registered trademark of Cisco in the
U.S. and other countries and is used under license. Android and Google Play are trademarks of Google Inc. Mopria is a trademark of the Mopria Alliance Inc. Amazon, Amazon Kindle, Amazon Fire phone and Amazon Kindle Fire are trademarks of Amazon.com. Inc or its affiliates. The USB-IF
logo is a trademark of Universal Serial Bus Implementers Forum, Inc. Wi-Fi is a registered trademark of the Wi-Fi Alliance. The ‘Wi-Fi CERTIFIED’ logo is a certification mark of the Wi-Fi Alliance. The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance. All other product and brand
names are trademarks of their respective owners. As an ENERGY STAR® partner, Canon U.S.A., Inc. has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
0204W377
