Quick Start Guide:
Utilizing GCOS with Windows XP Service Pack 2
P/N 702288 Rev. 1
For research use only.
Not for use in diagnostic procedures.
Trademarks
Affymetrix®, GeneChip®,
, HuSNP®, GenFlex®, Flying Objective™, CustomExpress®,
CustomSeq®, NetAffx™, Tools To Take You As Far As Your Vision®, The Way Ahead™, Powered by
Affymetrix™, GeneChip-compatible™, and Command Console™ are trademarks of Affymetrix, Inc.
All other trademarks are the property of their respective owners.
Limited License
Subject to the Affymetrix terms and conditions that govern your use of Affymetrix products, Affymetrix
grants you a non-exclusive, non-transferable, non-sublicensable license to use this Affymetrix product
only in accordance with the manual and written instructions provided by Affymetrix. You understand
and agree that, except as expressly set forth in the Affymetrix terms and conditions, no right or license
to any patent or other intellectual property owned or licensable by Affymetrix is conveyed or implied
by this Affymetrix product. In particular, no right or license is conveyed or implied to use this
Affymetrix product in combination with a product not provided, licensed, or specifically recommended
by Affymetrix for such use.
Patents
Arrays: Products may be covered by one or more of the following patents and/or sold under license
from Oxford Gene Technology: U.S. Patent Nos. 5,445,934; 5,700,637; 5,744,305; 5,945,334; 6,054,270;
6,140,044; 6,261,776; 6,291,183; 6,346,413; 6,399,365; 6,420,169; 6,551,817; 6,610,482; 6,733,977; and EP
619 321; 373 203 and other U.S. or foreign patents.
Use of the GeneChip® WT Amplified Double-Stranded cDNA Synthesis and Amplification Kit in
accordance with the instructions provided is accompanied by a limited license to U.S. Patent Nos.
5,716,785; 5,891,636; 6,291,170; and 5,545,522. Users who do not purchase this Kit may be required to
obtain a license under these patents or to purchase another licensed kit.
Copyright
© 2005-2006 Affymetrix Inc. All rights reserved.
INTRODUCTION
Microsoft® released Windows XP Service Pack 2 in August 2004. Workstations that
have the auto-update feature of Windows XP enabled will have the Service Pack 2
applied automatically. Service Pack 2 enables software features that help to enhance the
ability of computers running Windows XP to avoid malicious attacks, especially those
from viruses and worms.
The technologies include these improvements:
• Network protection
• Memory protection
• E-mail handling
• Web browsing security
• Computer maintenance
As part of the Network protection enhancements, Windows XP Service Pack 2 installs a
Windows software firewall and enables access control restrictions in Distributed
Component Object model (DCOM) settings.
The changes in DCOM settings and the installation of the firewall will directly impact
GeneChip Operating Software (GCOS) in the following areas:
Ability to control the GCS 3000 / GCS 3000 HR Scanner
The GeneChip Operating Software communicates with the Affymetrix GCS 3000 family
of scanners using TCP/IP. The firewall installed as part of the Microsoft Windows XP
SP2 enhancements will block TCP/IP traffic between the workstation and the scanner.
This will prevent the workstation from communicating properly with the GCS 3000
scanners.
Ability to receive status messages from the GCOS Server
The GeneChip Operating Software communicates with the GeneChip Operating
Software (GCOS) Server using DCOM. The firewall installed as part of the Microsoft
Windows XP SP2 enhancements will block traffic on DCOM port 135 as part of the
security enhancements. This will prevent the workstation from communicating properly
with the GCOS Server. In addition, SP2 changes machine-wide DCOM permissions.
2
Utilizing GCOS with Windows XP Service Pack 2
This prevents GCOS executables on the GCOS Server from providing status messages
to the GCOS client. The application impacted by the update to DCOM permissions
includes Data Transfer Tool and any custom user interface that makes use of the CAB
creation SDK.
To enable communication with the scanner and/or GCOS server, the Windows XP
firewall has to be disabled. In addition to communicate with the GCOS Server, the
DCOM permissions have to be reset to allow the software to receive status messages
from the GCOS Server. Section 1 and Section 2 provide instructions to disable the
Windows firewall and reset the DCOM permissions to those available under Windows
XP Service Pack 1a.
Follow the instructions in Section 1 – Disabling the XP SP2 firewall, if you have a GCS
3000 scanner or a GCOS Server.
Follow the instructions in Section 2 – Changing DCOM permissions only if you have a
GCOS Server.
If you have a stand alone analysis workstation then the instructions in this document do
not apply to you.
Section 1: Disabling the Windows Software Firewall
The Windows firewall will block all “unsolicited (on un-authenticated)” traffic on the
network interface card(s) from the internet/external network. It however allows all
traffic that is initiated locally from the workstation. The SP2 firewall blocks all traffic
on TCP and UDP ports. In doing so the firewall blocks all DCOM communications
arriving at TCP port 135. This will prevent the software from communicating with the
GCOS Server. The software firewall blocks all network traffic that occurs between the
scanner and the workstation over TCP. To re-enable the GCOS functionality for the
scanner and /or the GCOS server, the firewall has to be configured to allow the
instrument control drivers and DCOM to receive traffic from outside the workstation.
NOTE: It is necessary to have local administrative rights to make changes to
the Windows firewall or Windows DCOM permissions.
3
Enabling ScannerWorkstation Functionality Through a Firewall
1. Open the Windows Control Panel and click Security Center (Figure 1).
Figure 1 Windows Control Panel
The Windows Security Center window opens. It is from this window that you are
allowed to configure the Windows Firewall (Figure 2).
4
Utilizing GCOS with Windows XP Service Pack 2
Figure 2 Windows Security Center window
2. Click Windows Firewall to open the dialog box for changing the firewall settings
(Figure 3).
5
Figure 3 Windows Firewall dialog box
3. Click the Exceptions tab (Figure 4).
Figure 4 Windows Firewall dialog box
4. Click Add Program to add a program that will be allowed to receive network traffic
over TCP/IP (Figure 5).
6
Utilizing GCOS with Windows XP Service Pack 2
Figure 5 Add a Program dialog box
5. Click Browse and change the directory to the GCOS install directory.
6. Select MerScanCom.exe from the GCOS directory and click Open (Figure 6).
Figure 6 Browse dialog box
7. Click Open and select MerScanCom.exe.
8. Click OK on the next screen (see Figure 7).
7
This allows the scanner instrument control library to receive data packets from the
scanner through the firewall.
Figure 7 Windows Firewall dialog box
8
Utilizing GCOS with Windows XP Service Pack 2
Enabling Status Events From CAB Creation Component on GCOS Server
Follow the steps if you have a GCOS Server and use the CAB creation functionality of
Data Transfer Tool. To re-enable the CAB creation utility on the server to send status
events back to the GCOS client workstation perform the following steps on the GCOS
client workstation:
1. Open the Windows Control Panel and click Security Center (Figure 8).
Figure 8 Windows Control Panel
The Windows Security Center dialog box appears. It is from this dialog box that you
configure the Windows Firewall (Figure 9).
9
Figure 9 Windows Security Center dialog box
2. Click Windows Firewall to open the dialog box for changing the firewall settings
(Figure 10).
10 Utilizing GCOS with Windows XP Service Pack 2
Figure 10 Windows Firewall dialog box
3. Click the Exceptions tab (Figure 11).
Figure 11 Windows Firewall dialog box - Exceptions tab
4. Click Add Port to configure DCOM.
11
5. Type DCOM in the Name field and 135 in the Port number field as shown in
Figure 12. Click OK to close the dialog box.
Figure 12 Add a Port dialog box
6. Click OK in the Windows Firewall dialog box (Figure 13).
This allows the CAB creation component on the GCOS Server to communicate
through the firewall with the Data Transfer Tool on the client.
Figure 13 Windows Firewall dialog box - Exceptions tab
12 Utilizing GCOS with Windows XP Service Pack 2
Section 2: Changing DCOM permissions
XP Service SP2 updates the DCOM settings to enhance network security. The changes
in DCOM settings impact default impersonation and authentication level. The
permissions have to be updated to allow anonymous requests coming from CAB creation
application on the GCOS Server. It is not possible to limit change for authentication and
impersonation for a single component (i.e., to allow anonymous requests only from the
CAB creation application that resides on the server). The DCOM permissions for entire
workstation must to be changed to enable DTT to receive status messages from the CAB
creation component located on the server.
The two steps required to re-enable un-authenticated requests include:
1. Set the DCOM security on the client machine, and
2. Open up the firewall to DCOM (as explained in Section 1)
Perform the instructions in the following steps:
1. Select Start → Run and enter DCOMCnfg in the Run dialog box. Click OK
(Figure 14).
Figure 14 Run dialog box
The Component Services dialog box appears. It is from this dialog box that DCOM
permissions can be updated (Figure 15).
13
Figure 15 Component Services dialog box
2. Double-click the Component Services node under the Console Root to view the
Computers folder.
3. Select the Computers node to view My Computer in the right pane of the window.
4. Right-click My Computer and select Properties from the shortcut menu that appears
(Figure 16).
Figure 16 Component Services dialog box
14 Utilizing GCOS with Windows XP Service Pack 2
5. In the My Computer Properties dialog box, click the Default Properties tab (Figure 17).
Figure 17 Computer Properties dialog box - Default Properties tab
6. Change the Default Authentication Level from Connect to None and change the
Default Impersonation Level from Identify to Anonymous (Figure 18).
Figure 18 Computer Properties dialog box
7. Click Apply.
15
8. Click OK to close the dialog.
9. Click Start → Run and enter gpedit.msc (Figure 19). Click OK.
Figure 19 Run dialog box
This starts the Windows Group Policy console (Figure 20).
10. In the left pane select Local Computer Policy → Computer Configuration →
Windows Settings → Security Settings → Local Policies → Security Option.
The list of policies is displayed in the right pane (Figure 20).
Figure 20 Group Policy window
16 Utilizing GCOS with Windows XP Service Pack 2
11. In the right pane double-click “DCOM: Machine Access Restrictions ...” The
Machine Access Restrictions dialog box appears (Figure 21).
Figure 21 Machine Access Restrictions dialog box
12. Click Edit Security. The Access Permissions dialog box appears (Figure 22).
Figure 22 Access Permissions dialog box
13. Select the Allow option for both Local Access and Remote Access for both the
ANONYMOUS LOGON and Everyone.
14. Click Add.
The Select Users or Groups dialog box appears (Figure 23).
17
Figure 23 Select Users or Groups dialog box
15. Type Authenticated Users and click OK.
16. Select the Allow option for all permissions for the Authenticated Users user.
17. Click OK in the Access Permissions dialog box and Machine Access Restrictions
dialog box to apply the changes.
18. Double-click “DCOM: Machine Launch Restrictions ...”
The Machine Launch Restrictions dialog box appears (Figure 24).
Figure 24 Machine Launch Restrictions dialog box
19. Click the Edit Security button.
The Launch Permissions dialog box appears (Figure 25).
18 Utilizing GCOS with Windows XP Service Pack 2
Figure 25 Launch Permissions dialog box
20. Select the Allow option for all permissions for the Everyone user.
21. Click Add.
The Select Users or Groups dialog box appears (Figure 26).
Figure 26 Select Users or Groups dialog box
22. Type Authenticated Users and click OK.
23. Select the Allow option for all permissions for the Authenticated Users user.
19
24. Click OK in the both the Launch Permissions and Machine Launch Restrictions
dialogs boxes to apply the changes.
For more information on DCOM security go to
www.microsoft.com/technet/prodtechnol/winxppro/maintain/sp2netwk.mspx
25. Reboot the workstation.
Contact Information
Affymetrix, Inc.
3420 Central Expressway
Santa Clara, CA 95051
USA
E-mail: [email protected]
Tel: 1-888-362-2447 (1-888-DNA-CHIP)
Fax: 1-408-731-5441
Affymetrix UK Ltd
Voyager, Mercury Park,
Wycombe Lane, Wooburn Green,
High Wycombe HP10 0HH
United Kingdom
E-mail: [email protected]
UK and Others Tel: +44 (0) 1628 552550
France Tel: 0800919505
Germany Tel: 01803001334
Fax: +44 (0) 1628 552585
Affymetrix Japan, K. K.
Mita NN Bldg
16 Floor, 4-1-23 Shiba,
Minato-ku, Tokyo 108-0014
Japan
Tel: (03) 5730-8200
Fax: (03) 5730-8201
20 Utilizing GCOS with Windows XP Service Pack 2
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
