CONTENTS

Warning & Caution

What’s in the Box?

General Features

Name of Each Part

Installation

Quick Operating Key

Diagnostic

OSD Menu Setting

Dip Switch Setting

Trouble Shooting

Specifications

Dimensions

7

11

14

15

34

5

6

3

4

37

38

39

2

WARNINGS & CAUTION

If you fail to read this information and handle the product incorrectly, death or serious injury may occur.

• The unit should be installed by the trained personnel.

• Switch off immediately if the product emits smoke

or abnormal heat.

• Never install the product in area exposed to oil or gas.

• Never touch the power cord with wet hands.

• Clean only with dry cloth.

• Ensure that the product is not subjected to strong

impacts and vibration.

3

WARNING & CAUTION

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of impotant operating and maintenance (servicing) instructions in the literature accompanying the appliance.

What’s in the Box ?

1. IR CAMERA 1 SET

2. MANUAL 1EA

4

GENERAL FEATURES

IR LED PTZ has been designed unique and strong with high quality for security applications that demand the very high performance both day and at night time.

The range offers numerous benefits over the use of traditional dome and

PTZ cameras, and comes with a variety of options in order to offer a best fit solution for virtually any application.

Rated to an industry leading IP66, the vandal resistant aluminum camera housing is suitable for installation in the harshest of environments.

Surveillance with optimum picture is possible owing to filter changeable

Day & Night function and DSS function.

Auto-IR cut filter removable function is the auto-controlling operation such as color picture plus infrared cut filter during the day and  black and white picture plus filter elimination at night.

• THE WORLD'S FIRST 360° ENDLESS PAN/TILT MOTION

TBT IR PTZ camera adopted the world's first 360° endless Pan/Tilt.

• AUTO LED BRIGHTNESS CONTROL BY DISTANCE RANGE

When it's on a wide angle(zoom out), illumination level of LED is automatically readjusted to a dimmer level by way of prevention against image saturation. When it's on a narrow angle(zoom in), illumination level of LED is automatically readjusted to get the maximum to have quantity of light enough for clear image display and reduction of energy consumption.

• PAN/TILT TORQUE COMPENSATION (STEP-OUT PREVENTION)

Pan/Tilt Torque vibration sensor keeps the Pan/Tilt Motor securely in place during strong winds.

• AUTO LED PULSE CONTROL BY SHUTTER SPEED

(2 TIMES BETTER LED BRIGHTNESS)

It automatically controls the pulse of LED electric current which is consumed most depending on shutter speed so that it produces 2 times better LED Brightness with same amount electric current as others.

5

NAME OF EACH PART

1

2

3

4

LA LA

B BE

LA

ABEL

5

6

LABEL

LABEL

RATE1

RATE2

ON

1 2 3 4 5 6 7 8

CAM ID

1 2 3 4 5 6 7 8

PROT1 PROT2

TERM

7

8

9

Base Cover Bottom

1. CAMERA

2. IR LED

3. MAIN BODY

4. BASE BODY

5. DIP SWITCH COVER

6. CABLE

7. DIP SWITCH 1 (Camera ID setting)

8. DIP SWITCH 2 (Termination/Baud Rate Setting)

9. MOUNT HOLE (M4*12 4EA )

6

INSTALLATION

A. CONNECTION METHOD

1

Explanation

Color

BLACK BNC

2

Explanation

Color

YELLOW

BROWN

RED

WHITE

GRAY

VERMILION

(AWG#20)

3

Explanation

Color

RED

WHITE

BLACK

USE

Video Cable

USE

AUX 1-A

AUX 1-B

AUX 2-A

AUX 2-B

GND

ALARM 1

USE

AC 24

AC 24

F . G .

7

1

LABEL

LA

BEL

2

3

VIOLET

PINK

SKY BLUE

BLACK

BLUE

GREEN

Color

(AWG#20)

USE

ALARM 2

ALARM 3

ALARM 4

GND

RS-485 D +

RS-485 D -

INSTALLATION

A. CEILING MOUNT BRACKET

1. CEILING MOUNT BRACKET 1EA

2. SET ANCHOR BOLT (W5/6) 4EA

3. SCREW M4*15 5EA

CONTENTS

4. SPRING WASHER Ø4 5EA

5. WRENCH (3mm) 1EA

6. MANUAL

1. When you install IR PTZ Camera on the ceiling, make 4 holes at the edge with Ø13 in diameter and

37mm in depth. If you want to connect the cables from the inside of the ceiling, also make a hole

for the cables with about Ø30~50 in diameter in the center of 4 edges. (FIG.1)

2. Connect the Ceiling Mount Bracket to the Camera with 4 pieces of M4X15 screws and spring washer . (FIG.2)

3. Connect the Safety wire of the Camera to the Bracket. In order to avoid getting entangled in the

Camera, fasten the Safety wire to the bracket with Cable tie. (FIG.3)

4. When you want to connect the cables from the inside of ceiling, pass the cables through the ceiling.

When you want to connect the cables from the outside of ceiling, remove the hole cap from the side

of the bracket and pass the cables through the hole.

5. Install 4 pieces of Anchor bolt in the holes at the edge and tight enough with NUTs. (FIG.4)

6. Connect the cables referring to the page 5. (FIG.5)

CEILING

215.6

Ø30~50mm

SCREW

(M4x15 4EA)

SPRING

WASHER

( Ø4 4EA )

Cable

Tie

Safety Wire

4-Ø13

136

FIG.1

FIG.2

FIG.3

1

<the cable into ceiling>

2

<the cable out of ceiling>

FIG.4

8

FIG.5

INSTALLATION

B. POLE STAND

1. POLE STAND

2. BOLT M10X30

3. NUT M10

4. FLAT WASHER

1EA

5EA

5EA

5EA

CONTENTS

4. SPRING WASHER Ø10 5EA

3. WRENCH (3mm) 1EA

4. MANUAL

1. When you install IR PTZ Camera on the pole, make 4 holes at the edge with Ø13 in diameter and

37mm in depth. Make also a hole for the cables with about Ø30~50 in diameter in the bottom

center of the bracket. (FIG.6)

2. Pass the cables of the Camera through the inside of Pole Stand and connect the Camera to the

Pole Stand with 4 pieces of M4*15 screws. (FIG.7)

3. Connect the Safety wire of the Camera to the Bracket. In order to avoid getting entangled in the

Camera, fasten the Safety wire to the bracket with Cable tie. (FIG.8)

4. Install 4 pieces of Anchor bolt in the Ø13 holes at the edge and connect the cables referring to

the page 9.

5. Adjust the Camera and Pole Stand to M10X30 Bolt and Flat Washer,Spring Washer.

and then tight enough with NUTs.(FIG.10)

110.0

110.0

FIG.6

Ø150

Ø13

Spring Washer

(Ø4 4EA)

Screw

(M4x15 4EA)

FIG.7

Safety Wire

Cable Tie.

FIG.8

Safety Wire

Cable Tie.

Pole

FIG.9

9

NUT

(M10 4EA)

Flat Washer

Spring Washer

(Ø10 4EA)

Pole

Bolt

(M10X30 4EA)

FIG.10

INSTALLATION

C. WALL MOUNT BRACKET

1. WALL MOUNT BRACKET 1EA

2. SET ANCHOR BOLT (W5/6) 4EA

3. SCREW M4X15 5EA

CONTENTS

4. SPRING WASHER Ø4

5. WRENCH (3mm)

6. MANUAL

5EA

1EA

1. When you install IR PTZ Camera on the wall, make 4 holes at the edge with Ø13 in diameter and

37mm in depth and install 4 pieces of Anchor bolt in the Ø13 holes at the edge. (FIG.11)

* If you want to connect the cables from the inside of the wall, also make a hole for the cables with

about Ø30~50 in diameter in the center of 4 edges.

* In order to avoid the impact of the Camera and Bracket when moving, set and drill in the long

side as length and the short side as height.

* Check also if the long side of the Bracket sets as length and the short side of the Bracket sets

as height.

2. Connect the Camera to Wall Mount Bracket with 4 pieces of M4*15 screws and Spring Washer. (FIG.12)

3. Connect the Safety wire of the Camera to the Bracket. In order to avoid getting entangled in the

Camera, fasten the Safety wire to the bracket with Cable tie. (FIG.13)

4. When you want to connect the cables from the inside of wall, pass the cables through the wall.

When you want to connect the cables from the outside of wall, remove the hole cap from the

side of the bracket and pass the cables through the hole.

5. Install 4 pieces of Anchor bolt in the holes at the edge and tight enough with NUTs. (FIG. 13)

6.Connect the cables referring to the page 14. (FIG.14)

Ø30~50mm

WALL

136

Screw

(M4*15 4EA)

Spring Washer

(Ø4 4EA) hole cover

4-Ø13

Cable Tie

215.6

FIG.11

<the cable in of wall>

FIG.12

Safety wire

FIG.13

<the cable out of wall>

10

FIG.14

QUICK OPERATING KEYS

The IR Camera supports Pelco D/P Protocols

The default setting of the IR Camera is Pelco D/P (Auto Detection) with

2400bps(Baud rate).

[PELCO D/P PROTOCOLS]

The comprehensive feature set of the camera is availale from Pelco Compatible controllers via quick operation keys as defined below.

1~64 + preset and 100~200 + preset are used for normal user presets.

Presets 65~99 + are reserved for special functions.

For Example, to enter OSD MENU, press the button 95 +Preset

<Quick Operation Key Table1>

Nomber Note

1~64, 100~200+PRESET

65+PRESET

66+PRESET

70+PRESET

71~78+PRESET

81~88+PRESET

91+PRESET

Preset

Preset Status

Auto Scan

VIB CORR

Group Tour

Pattern

92+PRESET

93+PRESET

94+PRESET

95+PRESET

96+PRESET

97+PRESET

98+PRESET

98+PRESET

Zero Position

Freeze

BLC

Day/Night

OSD

Focus Adjust

Alarm

AUX1

AUX2

Function

Executing Preset 1~64, 100~200

Display Preset Status

Executing Auto Scan

Selectable On/Off in picture Stabilization Function

Executing Group Tour #1~#8

Executing Pattern #1~#8

Searching Pan / Tilt Zero Position

Select Freeze image when camera is working

Selectable On/Off BLC function

Selectable Day / Night / Auto Mode

Entering OSD Main Menu

Focus adjust

Selectable Enable / Disable all Alarms

Selectable On/ Off Aux1

Selectable On/ Off Aux2

<Quick Operating Keys Table2>

Nomber

Tilt Up / Down

Pan Left / Right

Function

Sub menu cursor moves up/down

Enter to the sub menu or status change or decrement

Focus Near

Focus Far

Zoom Tele

Using for enter key when user select YES or NO

Using for funtion changing keys when set coordinate

Status cursor to the right

Zoom Wide Status cursor to the left

11

QUICK OPERATING KEYS

* 65+preset “Preset Status’is displayed, to remove this screen, press Focus Near button.

* 92+preset This feature freezes the current live image during tour, auto scan or pattern

operation. When you press 92+preset button, the image freezes but the

camera is still working as operation such as tour, pattern or auto scan.

To return to normal images, press 92+preset button again.

※ This feture is operated by preset number but not included in OSD main menu.

* Due to Zoom camera module. OSD Menu not provides every feature.

In this case, “Not available”is displayed on the monitor.

12

QUICK OPERATING KEYS

13

DIAGNOSTIC

Whenever the IR Camera is powerd on, a standard diagnostic is operated.

CAMERA ID : 001

BAUD RATE : 2400 BPS

WATING...

PAN ORIGIN TEST OK

TILT ORIGIN TEST OK

TX CONNECTION TEST OK

CAMERA COMM TEST OK

A. Pan Origin Test

Zero point of Pan is located during the Panning test.

B. Tilt Prigin Test

Zero point of Tilt is located during the Tilt test.

C. TX connection Test

Wait for 60 seconds for TX Connection Test.

During 60 seconds, the camera is must received a signal bty any control equipment as

DVR or controller.

Then OK is displayed then automatically verifying TX Connection Test.

* If “Not Tested” is displayed in the test.

-The result which is not received any signal from DVR or controller

-Wrong connecting way such as the protocol, baud rate or RS-485 connection.

The use may check the install way carefully.

D. Camera Comm. Test

Camera communication is also checked.

OK shoud be displayed in these four tests before installation.

If all the above Tests are OK, “NEW EEPROM CHECKING” and “ALL DATA INITIALIZING” is displayed and the camera is ready to operate.

14

OSD MENU SETTING

A. OSD MENU TABLE

MAIN MENU

DOME SETUP

CAMERA SET

PRESET

AUTO SCAN

TOUR

PRIVACY

PATTERN

ALARM

SECTOR

EXIT

DOME SET

CAMERA ID : CAM1

□□□□□□□□□

RECOVER : OFF

MANUAL SPEED : 150˚/S

ZOOM SPEED : FAST

ALARM : DISABLE

LANGUAGE : ENGLISH

[NEXT PAGE]

SAVE AND EXIT

EXIT

PRIVACY SET

PRIVACY NO : 01

DISPLAY : ON/OFF

ACTION : MOVE/ADJUST

SAVE

EXIT

CAMERA SET

FLICKER : OFF/ON

APERTURE : 10

D ZOOM : OFF/ON

WB MODE : AWB MODE

BLC : OFF/ON

D/N MODE : AUTO

DSS MODE : OFF/ON

EXIT

PATTERN SET

PATT NO : 01

PATT TITLE : PATTERN01

□□□

DATE FILL : 100%

SAVE

EXIT

PRESET SET

PRESET NO : 01

PRESET ID : PRESET01

□□□□□□□□□

PAN : XXX.X TILT : XX.X

SAVE

EXIT

DOME SET

[SYSTEM SET]

SYSTEM LOCK : OFF

[PASS WORD]

[OSD DISPLAY]

[SYSTEM STATUS]

[INITIALIZATION]

[PREVIOUS PAGE]

SYSTEM SET

FLIP STAUS : NOMAL

MOTOR TORQUE : LOW

IR BRIGHTNESS : 08

D/N LEVEL : 08

TEMPERATURE : CELSIUS

[PREVIOUS PAGE]

OSD DISPLAY

CAMERA ID : OFF / ON

PRESET ID : OFF / ON

SECTOR ID : OFF / ON

COORDINATE : ON / OFF

[PREVIOUS PAGE]

ALARM SET

ALARM NO : 01

ALARM INPUT : OFF / NO / NC

ALARM ACT : 001

AUX ACT : BLK

SAVE

EXIT

SECTOR

SECTOR NO : 01

SECTOR ID : SECTOR01

□□□□□□

SECTOR START : XXX.X.XX.X

SECTOR END : XXX.X.XX.X

SAVE

EXIT

AUTO SCAN SET

START ANGLE : XXX.X.XXX.X

END ANGLE : XXX.X.XXX.X

DIRECTION : CW

ENDLESS : OFF / ON

SPEED : 10˚/S

DWELL TIME : 03

SAVE AND EXIT

EXIT

TOUR SET

TOUR NO : 01

TOUR TITLE : TOUR01

□□□□□□

TOUR STEP : 01

PRESET NO : 01

DWELL TIME :03

SPEED : 300˚/S

SAVE

EXIT

15

[SYSTEM STATUS]

PROTOCOL : PELCO D/P

BAUD RATE : 2400BPS

FIRMWARE VER : 2.00

UPGRADED DATE :06.28.06

CAMERA MODULE :SDM100

[PREVIOUS PAGE]

[INITIALIZATION]

[TOUR CEAR]

[PRESET CLEAR]

[SECTOR LEAR]

[PRIVACY CLEAR]

[PATTERN CLEAR]

[LOAD OPTIMIZED DEFAULT]

[PREVIOUS PAGE]

OSD MENU SETTING

To enter OSD Menu, press the button 95+Preset then OSD Main Menu is displayed.

MAIN MENU

DOME SETUP

CAMERA SET

PRESET

AUTO SCAN

TOUR

PRIVACY

PATTERN

ALARM

SECTOR

EXIT

• Use the joystick up down to move the position and left right to make selection.

B. DOME SETUP

To enter dome setup, use the joystick right to move when cursor on dome setup.

DOME SETUP

CAMERA ID : CAM1□□□□□□□□□

RECOVER : OFF

MANUAL SPEED : 150º/S

ZOOM SPEED : FAST

ALARM : DISABLE

LANGUAGE : ENGLISH

[NEXT PAGE]

SAVE AND EXIT

EXIT

B-1. DOME SET - CAMERA ID

To set camera name, and select a title of up to 16 characters using left or right direction keys or joystick. Press ZOOM TELE button to move to the next character from left to right direction and ZOOM WIDE button to move to the next character from right to left direction. (Space displays when □Appears)

16

OSD MENU SETTING

B-2. DOME SET - RECOVER

This feature allows the dome to revert to a specific programmed action when the dome has not received a command for the recovery timer period.

Actions can be Auto scan, group tour, preset, and pattern. The recover time can be programmed from 15 second to 90 seconds. the default setting is OFF.

B-3. DOME SET - MANUAL SPEED

Manual speed of Pan/Tilt is selectable from 100˚/sec up to 200˚/sec.

The default setting is 150˚/sec

B-4. DOME SET - ZOOM SPEED

Move joystic right or left direction is for selecting FAST or SLOW.

The default setting is FAST.

B-5. DOME SET - ALARM

You must enable the alarms for them to operate. The default setting is DISABLED.

This function can be recalled by pushing 97+preset button.

B-6. DOME SET - LANGUAGE

Multiple languages are selectable here including english, Italian and Polish.

The default setting is ENGLISH.

B-7. DOME SET - [NEXT PAGE]

DOME SETUP

[SYSTEM SET]

SYSTEM LOCK : OFF

[PASS WORD]

[OSD DISPLAY]

[SYSTEM STATUS]

[INITIALIZATION]

[PREVIOUS PAGE]

[DEFAULT SETTING]

17

OSD MENU SETTING

B-6-1. DOME SET - [NEXT PAGE] -SYSTEM SET

To enter system set, use the joystick right to move when cursor on system set.

- Flip status available and the default setting is NORMAL.

Move joystick right or left direction is for selecting NORMAL or REVERSE.

- Motor torque available and the default setting is LOW.

Move joystick right or left direction is for selecting LOW or MIDDLE or HIGH.

- IR Brightness is selectable 0 to 15. The default setting is 08.

- D/N Level is selectable 0 to 15. The default setting is 08.

- Temperature available and the default setting is CELSIUS.

Move joystick right or left direction is for selecting CELSIUS or FAHRENHEIT.

SYSTEM SET

FLIP STATUS : NOMAL

MOTOR TORQUE : LOW

IR BRIGHTNESS : 08

D/N LEVEL : 08

TEMPERATURE : CELSIUS

[PREVIOUS PAGE]

B-6-2. DOME SET - [NEXT PAGE] -SYSTEM LOCK

All stored dome settings can be password protected to prevent unauthorized changes. In order to enter [PASSWORD] page, the system lock status must firstly be set as ON. The default setting is OFF

B-6-3. DOME SET - [NEXT PAGE] -[PASSWORD]

To enter this page to set a password. move joystick or pan key in the right direction.

The password must be set by preset number from 001 to 255 (Default 99).

18

OSD MENU SETTING

ENTER PASSWORD

BY ENTERING PRESET CODE

PASSWORD ***

CONFIRM ***

DEFAULT SETTING

Enter any number from 001~255 on the password blank area and again on the confirm blank area. Then “CONFIRMED” is displayed on the monitor and the menu will go back to the previous age automatically.

ENTER PASSWORD

BY ENTERING PRESET CODE

PASSWORD ***

CONFIRM *** CONFIRMED

ENTER PASSWORD

BY ENTERING PRESET CODE

PASSWORD ***

CONFIRM *** NOT CORRECT

[[CONFIRMED] [CANCELLED]

If you pess an incorrect number between PASSWORD and CONFIRMED,

“CANCELLED” is displayed on the monitor when you press FOCUS NEAR key.

“CANCELLED”will be displayed on the monitor, it goes to previous page.

* When a password has been set, the operator must enter the correct password

in order to enter OSD MAIN MENU, or to change any of the domes

configuration data.

* If tou set a password you must ensure that it does not get lost. If this happens

the dome must be returned for workshopp repair.

19

OSD MENU SETTING

To clear the memorized data. move the joystic or pan right key until the cursor is on the required item.

TOUR CLEAR

ARE YOU SURE? YES NO

TOUR CLEAR

Press FOCUS NEAR button when the cursor is at YES in order to clear memorized data. Then each item such as tour, preset, and sector will flicker for about 2~3 seconds. After this process, the menu is returned to the previous page.

Use the above method for [PRESET CLEAR], [SECTOR CLEAR],[PRIVACY CLEAR],

[PATTERN CLEAR].

LOAD OPTIMIZED DEFAULT

ARE YOU SURE? YES NO

NOW EEPROM

CHECKING

ALL DATA

INITIALIZING

-To Clear all data and return to factory defaults, move the joystick right or press

the pan light key to when the cursor is at [LOAD OPTIMIZED DEFAULT] to enter

the next page.

21

OSD MENU SETTING

-Move joysitc or the pan right key so that the cursor is over YES, then press the

FOCUS NEAR button.

“ALL DATA INITIALIZING”is then displayed for about 5~7 seconds and then the menu

is returned to the previous page automatically.

B-7. DOME SET - [NEXT PAGE] - SAVE AND EXIT

To saving the memorized data and escape this page, move joystick to the right direction when cursor is at SAVE AND EXIT.

B-8. DOME SET - [NEXT PAGE] - EXIT

In order not to save any data and wants to escape this page, move joystick to the right direction when cursor is at EXIT.

22

OSD MENU SETTING

C. CAMERA SET

CAMERA SET

FLICKER : OFF

APERTURE : 10

D ZOOM : OFF

WB MODE : AUTO

BLC : OFF

D/N MODE : AUTO

DSS MODE : OFF

EXIT

[DEFAULT SETTING]

C-1. CAMERA SET - FLICKERLESS

The flickerless feature has options of 50Hz and 60Hz. The default setting is OFF

(NTSC:60Hz/ PAL:50Hz). The flickerless mode only needs to be set when there is a mismatch between the power frequency and camera sync rate.

The default setting is OFF.

C-2. CAMERA SET - APERTURE

Aperture correction enhances the picture details and sharpness by increasing the gain of the camera. Increase the value to sharpen the image, decrease to soften it the default setting is 10.(the aperture level is from 01~15)

C-3. CAMERA SET - D ZOOM

Digital zoom is enabled to apply when the zoom lens has reached its maximum

Optical zoom in capability. The default setting is OFF.

C-4. CAMERA SET - WB MODE

White balance functions has 4 modes and may need to be changed depending on the situation.

* AWB Mode 3000ºK to 7,500ºK

* Indoor up to 3200ºK

* Outdoor up to 5,800ºK

* ATW Mode 2000ºK to 10,000ºK

23

OSD MENU SETTING

C-5. CAMERA SET - BLC (Back Light Compensation)

The default setting is Off and BLC modes can be OFF/ON.

* OFF- Back Light compensation is not activated.

* ON - Back Light compensation is activated.

C-6. CAMERA SET - D/N MODE

The dome camera can operate in day/night mode and will switch depending on lighting conditions. Alternatively it can be forced into color only mode.

The default setting is AUTO MODE. This function can be recalled by pushing

94+preset button.

C-7. CAMERA SET - DSS MODE

If digital slow shutter is enabled the exposure time of the camera is increased, thus allowing more light to be collected and improving low light response.

This setting should not be enabled if the dome is touring at night or fast moving objects are likely to be in the scene as smearing is also increased.

The default setting is OFF.

C-8. CAMERA SET - EXIT

To exit this page, move the joystick right or press the pan right key.

24

OSD MENU SETTING

D. PRESET SET

PRESET SET

PRESET NO : 001

PRESET ID : PRESET001□□□□□□□□□

PAN : XXX.X TILT : XX.X

SAVE

EXIT

[DEFAULT SETTING]

D-1. PRESET - PRESET NO

Up to 165 preset positions are available.

Use the joystick or pan left/right keys to select the number.

D-2. PRESET - PRESET ID

To create preset titles use the joystic or pan left/light keys to navigate the menu.

The ZOOM TELE button moves to the next charecter from left to right and

ZOOM WIDE button moves to the next character from right to left

(space displays when □Appears)

D-3. PRESET - PAN : XXX.X TILT : XX.X

Preset FOCUS FAR button in order to set preset position then, use the joystick or pan left/right keys to the osition where memorized preset numer is needed.

Then press FOCUS FAR button again after setting a preset location.

D-4. PRESET - SAVE

Move the joystick right or press the pan right key when the cursor is at SAVE and then the cursor will be located on Preset ID for the continuous preset No. setting.

D-5. PRESET - EXIT

To escape this page, move joystick to the right direction.

25

OSD MENU SETTING

E. AUTO SCAN SET

• 66+Preset button is working as AUTO SCAN after setting.

AUTO SCAN SET

START ANGLE : XXX.X.XX.X

END ANGLE : XXX.X.XX.X

DIRECTION : CW

ENDLESS : OFF

SPEED : 10°/S

DWEL TIME : 03

SAVE AND EXIT

EXIT

[DEFAULT SETTING]

E-1. AUTO SCAN - START ANGLE.

To set the start position, press FOCUS FAR button then move the dome to the required start position. press FOCUS FAR button again is to escape.

E-2. AUTO SCAN - END ANGLE

To set the end position, press FOCUS FAR button then move the dome to the required end position. press FOCUS FAR button again is to escape.

E-3. AUTO SCAN - DIRECTION

Auto Scan directions are availavle as CW or CCW.

* CW : Clock wise difection [Default]

* CCW : Count Clock Wise Direction.

E-4. AUTO SCAN - ENDLESS

Auto Scan can be set to endless rotation by enabling the endless option.

The default setting is OFF

E-5. AUTO SCAN - SPEED

The scan speed can be programmed from 05°/S up to 35°/S.

The default setting is 10°/S.

E-6. AUTO SCAN - DWELL TIME

The dwell time at the start and end points can be programmed from 1 second to 30 seconds. The default setting is 03 seconds.

26

OSD MENU SETTING

E-7. AUTO SCAN - SAVE AND EXIT

To save the memorized data and escape this page, move the joystick right or press the pan right key when the cursor is at SAVE AND EXIT.

E-8. AUTO SCAN - EXIT

To escape this page, move joystick to the right direction.

F. TOUR SET

8 Programmable tours can be set and each tour can bave up to 64 preset steps.

After setting up the tours the 71~78+Preset buttons launch group tours #1~8.

TOUR SET

TOUR NO : 001

TOUR TITLE : TOUR01□□□□□□□□□

TOUR STEP : 01

PRESET NO. : 01

DWEL TIME : 03

SPEED : 200º/S

SAVE

EXIT

[DEFAULT SETTING]

F-1. TOUR SET - TOUR NO.

Up to 8 group tours can be programmed.

F-2. TOUR SET- TOUR TITLE

To set a tour title, use the joystick left/right or pan left/right keys.

Each title can have up to 16 characters. Press ZOOM TELE button to move the next character from left to the right and ZOOM WIDE button to move the next character from right to left (Space displays when □appears) The tour title is not displayed on the monitor and is only for the reference of user.

F-3. TOUR SET - TOUR STEP

Each tour group consists of up to 60 preset steps with different dwell time and speed.

It is possible to match any preset # for any tour step.

27

OSD MENU SETTING

F-4. TOUR SET- PRESET NO.

For each tour step it is possible to select any preset number up to 64.

The default setting is BLK.

F-5. TOUR SET - DWELL TIME

Dwell time can be programmed from 1-99 seconds.

The default setting is 03 seconds.

F-6. TOUR SET - SPEED

Each tour step can be set with a different speed up to 200°/S.

F-7. TOUR SET - SAVE

To save the memorized data and escape this page, move the joystick right or press the pan right key when cursor is at SAVE.

F-8. TOUR SET - EXIT

To escape this page, move joystick to the right direction.

28

OSD MENU SETTING

G. PRIVACY SET

24 Privacy masking zones can be set.

PRIVACY SET

PRIVACY NO : 01

DISPLAY : OFF

ACTION : MOVE

SAVE

EXIT

[DEFAULT SETTING]

G-1. PRIVACY SET - PRIVACY NO.

Up to 8 Pprivacy masking zones can be set.

G-2. PRIVACY SET - DISPLAY

Move the joystick right or left or press pan right/left to set ON in order to show the selectable block in the center of the monitor. This block appears as a translucent square with blue color when set ON.

The default setting is OFF.

G-3. PRIVACY SET - ACTION (MOVE / ADJUST)

To set the blocking area, press FOCUS FAR button when MOVE MODE is displayed.

Then use the joystick or pan keys to the user defined area in order to set the blocking area. Then press FOCUS FAR button again to escape from Move mode.

To adjust tje size of the blocking area, move the joystick or use the pan keys when the cursor is on ACTION. After it has changed to ADJUST MODE, press

FOCUS FAR button in order to adjust the size of the blocking area. The size of the

blocking area can be adjusted by using joystick up/down or left right? or the pan and tilt keys.

After adjusting the size of the blocking area, press FOCUS FAR button to escape the

ADJUST mode.

* ADJUST : You Can cange the masking size by using the joystick or pan keys.

* MOVE : You can move the masking area by using the joystick or pan keys(Default)

29

OSD MENU SETTING

G-4. PRIVACY SET - SAVE.

After setting the privacy masking zone, to save the data, move the joystick right or pan right key when the cursor is on SAVE.

After saving th data, the cursor moves to PRIVACY NO.2 automatically to prepare for the next privacy masking zone.

G-5. PRIVACY SET - EXIT

To escape this page, movve the joystick right.

H. PATTERN SET

8Programmable patterns are available with 16 characters of title.

After set the data to the each pattern #1~8, 81~88+preset buttons are working as pattern #1~8.

PATTERN SET

PATT NO : 01

PATT TITLE : PATTERNNO.1□□□□□□□

DATA FILL : 100%

SAVE

EXIT

[DEFAULT SETTING]

H-1 PATTERN SET - PATT NO.

Up to 8 programmale user-defined patterns are available.

H-2. PATTERN SET - PATT TITLE.

To set PATTERN TITLE move Joystick left/right or use the pan keys.

Press ZOOM TELE button moves to the next character from the left /right and

ZOOM WIDE button moves to the next character from the right / left (Space displays when □ appears) The pattern title is not displayed on the monitor, but only for the reference of the user.

30

OSD MENU SETTING

H-3. PATTERN SET - DATA FILL

To memorize a pattern, press FOCUS FAR button in order to start the process.

The progress is shown as % filled. Press FOCUS FAR button again in order to escape.

H-4. PATTERN SET - SAVE

To save the memorized pattern data, move the joystick right or press the pan right key when the cursor is on SAVE. Then the cursor moves to the PATT NO.02

in order to prepare for the next pattern.

H-5. PATTERN SET - EXIT

To escape this page, move the joystick right or press the pan right key.

I. ALARM SET

4 Alarm inputs are available and each alarm is activating to presets, group tours or patterns.

ALARM SET

ALARM NO : 01

ALARM INPUT : OFF

ALARM ACT : 001

AUX ACT : BLK

SAVE

EXIT

[DEFAULT SETTING]

I-1. ALARM SET - ALARM NO.

Up to 4 alarms are selectable by using joystick right or pressing the pan right key when the cursor is on ALARM NO.

I-2. ALARM SET - ALARM INPUT

Alarm inputs can be programmed as NC(Normally Close) or NO (Normally Open)

The default setting is OFF.

I-3. ALARM SET - ALARM ACT

Active alarms can trigger modes such as presets, Group tours 1-8, and Patterns 1-8.

Use the joystick or pan keys to select any preset number, group tour no.

31

OSD MENU SETTING

I-4. ALARM SET - AUX ACT

You can select one of BLK (No AUX triggering)/AUX1(triggering AUX1)/AUX2

(triggering AUX2) and default value is BLK.

If ALARM triggers AUX, AUX will be off after 5 seconds. If many ALARMs trigger

AUX port one by one, the last one will be off after 5 seconds.

I-5. ALARM SET - SAVE

After setting up the alarm features, to save the data move the joystick right or press the pan right key when the cursor is on SAVE. After saving the data, the cursor moves to Alarm NO.2 automatically to prepare for the next alarm.

I-6. ALARM SET - EXIT

To escape this page, move the joystick right or press the pan right key.

* Before activating Alarms, you must set ALARM ENABLE at DOME SET ALARM

ENABLE.

J. SECTOR SET

Up to 8 programmable sectors are available with 16 characters.

This feature is useful to memory the certain location such as parking zone or so on.

SECTOR SET

SECTOR NO : 01

SECTOR ID : SECTOR01□□□□□□□□

SECTOR START : xxx.x.xx.x

SECTOR END : xxx.x.xxx.x

SAVE

EXIT

[DEFAULT SETTING]

J-1. SECTOR SET - SECTOR NO.

Up to 8 programmavle sectors are available.

32

OSD MENU SETTING

J-2. SECTOR SET - SECTOR ID

To set a SECTOR ID, use the joystick or pan left/right keys.

Press ZOOM TELE button to move to the next character from left to right and

ZOOM WIDE button to move to the next character from right to left (space displays when □ appears)

J-3. SECTOR SET - SECTOR START

To set a SECTOR START position press FOCUS FAR button then move the joystic or pan keys to set the position. Press FOCUS FAR button again to escape.

J-4. SECTOR SET - SECTOR END

To set a SECTOR END position press FOCUS FAR button then move the joystick or pan keys to set the position. To press FOCUS FAR button again to escape.

J-5. SECTOR SET - SAVE

After setting the SECTOR position, to save the data move the joystick right or press the pan right key when the cursor is on SAVE. After saving the data, the cursor moves to sector No, 2 automatically to prepare for the next sector.

J-6. SECTOR SET - EXIT

To escape this page, move joystick to the right or press the pan right key.

K. EXIT

To escape OSD Main Menu, move joystick to the right or left direction then this camera is ready to operate.

33

DIP SWITCH SETTING

A. ID SETTING

The camera has camera ID to be controlled by controller or DVR.

After opening, set ID using DIP SW1.

* Factory default : Camera ID = 1

RATE1

RATE2

ON

1 2 3 4 5 6 7 8

CAM ID

1 2 3 4 5 6 7 8

PROT1 PROT2

TERM

Dip switch 1

(Camera Setting)

Dip switch 2

(Termination/Baud Rate Setting)

* ( 1 : ON , 0 : OFF)

10000000

01000000

11000000

00100000

10100000

01100000

11100000

00010000

10010000

01010000

11010000

00110000

10110000

01110000

11110000

00001000

10001000

01001000

11001000

00101000

10101000

01101000

11101000

00011000

10011000

01011000

11011000

00111000

10111000

01111000

11111000

00000100

10000100

01000100

11000100

00100100

10100100

01100100

11100100

15

16

17

18

19

20

21

22

23

11

12

13

14

4

5

6

1

2

3

7

8

9

10

33

34

35

36

37

38

39

29

30

31

32

24

25

26

27

28

00010100

10010100

01010100

11010100

00110100

10110100

01110100

11110100

00001100

10001100

01001100

11001100

00101100

10101100

01101100

11101100

00011100

10011100

01011100

11011100

00111100

10111100

01111100

11111100

00000010

10000010

01000010

11000010

00100010

10100010

01100010

11100010

00010010

10010010

01010010

11010010

00110010

10110010

01110010

34

54

55

56

57

58

59

60

61

62

50

51

52

53

43

44

45

40

41

42

46

47

48

49

72

73

74

75

76

77

78

68

69

70

71

63

64

65

66

67

93

94

95

96

97

98

99

100

101

89

90

91

92

82

83

84

79

80

81

85

86

87

88

111

112

113

114

115

116

117

102

103

104

105

106

107

108

109

110

11110010

00001010

10001010

01001010

11001010

00101010

10101010

01101010

11101010

00011010

10011010

01011010

11011010

00111010

10111010

01111010

11111010

00000110

10000110

01000110

11000110

00100110

10100110

01100110

11100110

00010110

10010110

01010110

11010110

00110110

10110110

01110110

11110110

00001110

10001110

01001110

11001110

00101110

10101110

01101110

11101110

00011110

10011110

01011110

11011110

00111110

10111110

01111110

11111110

00000001

10000001

01000001

11000001

00100001

10100001

01100001

11100001

00010001

10010001

01010001

11010001

00110001

10110001

01110001

11110001

00001001

10001001

01001001

11001001

00101001

10101001

01101001

11101001

00011001

10011001

01011001

11011001

00111001

10111001

01111001

11111001

00000101

10000101

01000101

11000101

DIP SWITCH SETTING

147

148

149

150

151

152

153

154

139

140

141

142

143

144

145

146

155

156

1 5 7

1 5 8

1 5 9

1 6 0

1 6 1

1 6 2

1 6 3

124

125

126

127

128

129

130

131

132

133

134

118

119

120

121

122

123

135

136

137

138

01000011

11000011

00100011

10100011

01100011

11100011

00010011

10010011

01010011

11010011

00110011

10110011

01110011

11110011

0 0 0 0 1 0 1 1

1 0 0 0 1 0 1 1

00100101

10100101

01100101

11100101

00010101

10010101

01010101

11010101

00110101

10110101

01110101

11110101

00001101

10001101

01001101

11001101

00101101

10101101

01101101

11101101

00011101

10011101

01011101

11011101

00111101

10111101

01111101

11111101

00000011

10000011

194

195

196

197

198

199

200

201

186

187

188

189

190

191

192

193

202

2 0 3

2 0 4

2 0 5

2 0 6

2 0 7

2 0 8

2 0 9

170

171

172

173

174

175

176

177

178

179

180

164

165

166

167

168

169

181

182

183

184

185

01001011

11001011

00101011

10101011

01101011

11101011

00011011

10011011

01011011

11011011

00111011

10111011

01111011

11111011

00000111

10000111

01000111

11000111

00100111

10100111

01100111

11100111

00010111

10010111

01010111

11010111

00110111

10110111

01110111

11110111

00001111

10001111

01001111

11001111

00101111

10101111

01101111

11101111

00011111

10011111

01011111

11011111

00111111

10111111

01111111

11111111

240

241

242

243

244

245

246

247

232

233

234

235

236

237

238

239

248

2 4 9

2 5 0

2 5 1

2 5 2

2 5 3

2 5 4

2 5 5

216

217

218

219

220

221

222

223

224

225

226

210

211

212

213

214

215

227

228

229

230

231

35

DIP SWITCH SETTING

B. 485 TERMINATION

The 8th of DIP SW2 is used for 100 termination.

Set ON DIP SW2-1st of only the last looped camera from the controller.

JUNCTION

BOX

CAM 1 CAM 2 CAM n-1 CAM n

TERMINATION

SW1-ON

C. PROTOCAL

The 4th, 5th of DIP SW2 above are used for protocol setting.

Factory default : Pelco-D or Pelco-P (Auto detection)

DIP SW2-4th,5th

DIP SW2-4th

OFF

OFF

ON

ON

DIP SW2-5th

ON

OFF

ON

OFF

BAUD RATE

Pelco-D or Pelco-P

Not used

Not used

Not used

D. BAUD RATE SETTING

The 7th,8th SW of DIP SW2 above are used for BAUD RATE setting.

DIP SW can be changeable to 4800bps, 9600bps.

Factory default:2400bps.

DIP SW2-1st

OFF

ON

OFF

ON

* The 3th, 6th, 7th of DIP SW2 are not used.

DIP SW2-2nd

OFF

OFF

ON

ON

BAUD RATE

2400bps

4800bps

9600bps

Not used

36

TROUBLE SHOOTING

If you have trouble operating in your camera, refer to the fallowing.

PROGLEM

NO OPERATION

SOLUTION

* Check if the power supply is AC 24V.

* Check if RS-485 communication cable is connected

correctly.

* Check camera ID setting.

* Check the termination.

NO PICTURE

* Check if all the cables are connected correctly.

* Check the monitor is adjusted correctly.

* check if video signal line is cut.

DARK SCREEN

Abnormal camera operation status

Screen not clear

* Adjust the monitor status.

* Check if the voltage level is out of the specification.

* Check the termination.

* Check if there is dust on a lens.

* Adjust the monitor status.

* If excessive light is seen on a screen, change the

camera angle or location.

* Adjust the lens focus again.

37

SPECIFICATION

Pan/Tilt

Functions

Power

Other

Camera

Module

MODEL

Pan Rotation Angle

Pan Speed

Tilt Rotation Angle

Tilt Speed

System Accuracy

Presets

Group Tour

Auto Scan

Pattern

Sector

Password Protection

Privacy Zone

WDR

Alarm Input

Alarm Actions

Aux Output

Auto Flip

OSD Menu

Communication

Protocol

Power Consumption

Power Supply

Construction

Dimensions

Weight

Motor Type

Micro Steps

Temperature

Certifications

Image Sensor

Total image Pixels

Number of Effective

Horizontal Resolution

Lens

Day & Night (ICR)

Digital Slow Shutter

Min. Illumination

Luminance S/N Ratio

Video Output

BLC

Flickerless

IR-PTZ CAMERA

360° Endless

Manual : 0.5~100°/sec , Preset : 200°/sec (Max)

360° Endless

Manual : 0.5~100°/sec , Preset : 200°/sec (Max)

0.024°

165 Position with 16-Character lavel available for each position with different speed steps

Max8.programmable group tour

(eah one consisting of up to 60 preset steps with different step)

Programmable Auto Scan

8 Programmable Pattern

8 Selectable Sectors with 16 characters

Yes

8 Zone

Yes

4 alarms (without various programmable states)

Activate preset, Group scanning or output per alarm input

2 Replay Output

Digital Flip

Yes

RS-485

Pelco D/P

Max 47W

AC24V 2.5A (Max)

Pearl Gray

365 x 265 x 260(H)

5.5Kg ( 12.1 lbs)

Stepping Motor

1/8 Micro Step

Operating Temp -35°C~50°C Storage Temp -35°C~50°C

CE , FCC

1/4¨Super Exview HAD CCD

NTSC 811(H) * 508(V) 410K PAL 795(H) * 596(V) 470K

NTSC 811(H) * 508(V) 410K PAL 795(H) * 596(V) 470K

NTSC 530 TV line PAL 530 TV line

Optical Zoom 36X F1.6~4.5, f=3.4~122.4mm

Digital Zoom 12X (432X with optical)

Auto / Day / Night

On / Off

Color : 0.1Lux (50IRE) B/W : 0.01Lux(ICR ON)

Mor than 50dB

Composite video output 75 terminated

On / Off

On / Off

38

DIMENSIONS

300

100

200

142.36

70

45.6

39

UNITS : mm

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
