QUALITY PLUS QUANTITY

QUALITY PLUS QUANTITY
PRINT | COPY | SCAN | WIRELESS
WIRELESS MEGATANK ALL-IN-ONE PRINTER
QUALITY PLUS
QUANTITY
INCLUDED INK IS EQUAL TO ABOUT
30 INK CARTRIDGE SETS! 1
CANON MEGATANK
SYSTEM ADVANTAGES:
ADDITIONAL FEATURES:
3
4
5
6
• Print up to 6,000 crisp black pages and
7,000 magnificent color pages with the
included inks.2
• Easily monitor your ink levels by
checking the clear, front-mounted
reservoirs.
• Included inks is equivalent to 30
conventional ink cartridge sets.1
7
• Easy, mess-free ink refilling.
WIRELESS MEGATANK ALL-IN-ONE PRINTER
TECHNICAL INFORMATION
PRINT
Print Features
Print Speed12
PRODUCT INFO / INKS
Auto Photo Fix II, Borderless Printing,7 Business Card Printing, Canon
PRINT app,5 Document Printing, Easy PhotoPrint+,8 Full HD Movie Print,9
Google Cloud Print,6 High Page Yield, Image Cropping, My Image Garden,10
Photo Printing, PIXMA Cloud Link,11 Quiet Mode, Red-Eye Correction,
Special Filters, Square Media Printing Support, Wireless Printing3
4" x 6" Borderless Photo: Approx. 60 seconds
ESAT (Black): Approx. 8.8 ipm
ESAT (Color): Approx. 5.0 ipm
Number of Nozzles
Color: 1,152 / Pigment Black: 320 / Total: 1,472
Print Resolution13
Up to 4800 x 1200 dpi
Paper Sizes
4" x 6," 5" x 5" Square, 5" x 7," 8" x 10," Letter, Legal, U.S. #10 Envelope
Paper Tray Capacity
Rear Paper Tray: 100 Sheets of Plain Paper OR
Photo Paper: 20 Sheets of 4" x 6" / 10 Sheets of 5" x 7"
COPY
Standard Copy
Copy Speed12
FCOT (Color): Approx. 24 seconds
Reduction/Enlargement
25% – 400%
SCAN
Scan Features
Auto Scan Mode,14 Document Removal Reminder, Network Scan,
Wireless Scanning3
Scanner Type
Flatbed
Scanning Method
Contact Image Sensor (CIS)
Scanning Resolution4
600 x 1200 dpi (Optical), 19,200 x 19,200 dpi (Interpolated)
Maximum Color Depth
48-bit Internal / 24-bit External
Maximum Document Size
Flatbed: 8.5" x 11.7"
General Features
4-Color MegaTank Refillable Ink System, Auto Power On/Off, Canon
PRINT app,5 PIXMA Cloud Link11
Standard Interface
Hi-Speed USB, Wireless LAN (IEEE 802.11b/g/n)3
Size/Weight
17.6"(W) x 13.0"(D) x 6.5"(H) / 12.7 lbs.
Software (Windows®15/Mac®16)
PIXMA G3200 MegaTank All-In-One Printer Driver, Scan Utility, Master
Setup, My Image Garden10 (Full HD Movie Print,9 Special Filters, Image
Correction/Enhance, and scanning are accessed through My Image
Garden), Quick Menu
OS Compatibility
Warranty20
Computer Operating Systems:
Windows:15 Windows® 10, Windows 8, Windows 8.1, Windows 7 SP1,
Windows Vista® SP2, Windows XP SP3 (32-bit only)
Mac:16 Mac OS® X v10.8.5 – macOS v10.12 (Sierra)
Mobile Operating Systems:17 iOS®, Android, Windows 10 Mobile,
Windows RT,18 and Amazon Fire devices19
1-Year limited warranty with InstantExchange Program.
1-Year toll-free U.S.-based technical phone support
FOR MORE INFORMATION VISIT WWW.USA.CANON.COM/CONSUMER
Wireless MegaTank All-In-One Printer
GI-290 BK
GI-290 C
GI-290 M
GI-290 Y
Pigment Black Ink Bottle
Cyan Ink Bottle
Magenta Ink Bottle
Yellow Ink Bottle
0630C002AA
1595C001AA
1596C001AA
1597C001AA
1598C001AA
all viewscreen and printer output images are simulated.
GENERAL
PIXMA G3200
Compatible Inks
specifications are subject to change without notice.
Copy Features
Model No.
1Approximately 30 ink cartridges sets estimate is based on print yield of the included black and color ink bottles as
compared to the following standard-capacity cartridge sets: PG-245 Black Ink Cartridge and CL-246 Color Ink Cartridge
as of August 2016.
2Page yield of ink bottles used for initial setup is lower then the replacement, as a certain amount of ink is consumed
to fill into the print head during the setup (charging the print head initially). Page yield is the estimated value based on
Canon individual test method using the ISO/IEC 24712 chart and continuous printing simulation with the replacement
ink bottles after initial setup. Page yield of color inks is an average yield of cyan, magenta and yellow inks combined.
Page yield varies significantly depending on content printed and other factors. 6,000 (black) and 7,000 (color) printed
pages yields are approximate, based off document pages printed.
3Wireless printing and scanning requires a working network with wireless 802.11b/g or n capability. Wireless
performance may vary based on terrain and distance between the printer and wireless network clients.
4Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard.
5Requires an Internet connection and the Canon PRINT Inkjet/SELPHY app, available for free on the App Store and at
Google Play. Compatible with iPad, iPhone 3GS or later, and iPod touch 3rd generation or later devices running iOS
7.0 or later, and AndroidTM mobile devices running Android 2.3.3 or later. Your device must be connected to the same
working network with wireless 802.11 b/g/n capability as your printer. Requires an compatible social media account and
is subject to that social media account’s Terms of Service. Certain exceptions may apply.
6Requires an Internet connection and Google account. Subject to Google Terms of Service. Certain exceptions may apply.
7Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer,
Photo Stickers.
8Works edited by using this application cannot be displayed, edited, or printed without this application. Compatible with
Android device of 7 inches or more using Chrome (latest version compatible with your current version of AndroidTM OS),
iOS Devices of 7 inches or more using Safari 5.1 or later, Windows PC (excluding RT) using Internet Explorer 10 or later
of Microsoft Modern UI version, Microsoft Internet Explorer 9 or later, Mozilla Firefox 31 or later, or Google Chrome
version 36 or later, and with Mac OS X 10.6.8 or later using Safari 5.1 or later.
9“Full HD Movie Print” is available from “MOV” and “MP4” movie files created by select Canon EOS Digital SLRs,
PowerShot, and VIXIA digital cameras and camcorders. Requires PC or Mac with Intel® processor and Canon
ZoomBrowser EX 6.5 or later or Canon ImageBrowser 6.5 or later for “MOV” files, or Canon ImageBrowser EX 1.0 or later
for “MOV” or “MP4” files. Print quality is determined by the video resolution. Function does not upscale video resolution.
10To install using Windows OS .NET Framework 4 is required. Compatible still image formats are PDF (created using
Canon PDF Creator only), JPEG (Exif), TIFF, and PNG. Compatible video formats are MOV (from select Canon digital
cameras only) and MP4 (from select Canon digital camcorders only).
11Requires an Internet Connection.
12Document print speeds are the averages of ESAT in Office Category Test for the default simplex mode, ISO/IEC
24734. Photo print speed is based on the default setting using ISO/JIS-SCID N2 on Photo Paper Plus Glossy II and
does not take into account data processing time on host computer. Print speed may vary depending on system
configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Copy speeds are the average of sFCOT and sESAT, ISO/IEC 29183. Copy speed may vary depending on document
complexity, copy mode, page coverage, type of paper used etc. and does not take into account warming up time.
See www.usa.canon.com/ipm for additional details
13Resolution may vary based on printer driver setting. Color ink droplets can be placed with a horizontal pitch of 1/4800
inch at minimum.
14For network users, Auto Scan Mode is only available when scanning at a computer using My Image Garden software
and selecting the 1-click feature then “Save to PC.”
15Operation can only be guaranteed on a PC with pre-installed Windows 10, Windows 8.1, Windows 8, Windows 7, Vista
SP2 or Windows XP SP3 (32 bit only).
16Internet Connection required during software installation. For full compatibility macOS v10.12.1 or later is recommended.
17Some functions may not be available with these Operating Systems. Please refer to manual or our website for details.
18Requires a Windows RT compatible device and the Canon Easy-PhotoPrint app for Windows RT available for free in the
Windows Store.
19Requires “Canon Print Plug-in” available for free from the Amazon Appstore and an Amazon Fire Phone, Amazon Kindle
Fire HD6 or HDX7 device or later running Fire OS 4.0 or later.
20Warranty programs are subject to certain conditions and restrictions. See www.usa.canon.com/support for details.
For the name of the nearest dealer, call: 1-800-OK-CANON
©2016 Canon U.S.A., Inc. Canon and PIXMA are registered trademarks of Canon Inc. in the U.S. and may be registered trademarks or trademarks in other countries. Microsoft, Windows, the Windows logo and Internet Explorer are trademarks or registered trademarks of the Microsoft
group of companies in the U.S. and other countries. Apple, iPad, iPhone, iPod touch and Time Capsule are registered trademarks of Apple Inc. Android and Google Play are trademarks of Google Inc. The USB-IF logo is a trademark of Universal Serial Bus Implementers Forum, Inc. Wi-Fi is a
registered trademark of the Wi-Fi Alliance. The ‘Wi-Fi CERTIFIED’ logo is a certification mark of the Wi-Fi Alliance. The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance. All other product and brand names are trademarks of their respective owners. As an ENERGY STAR® partner,
Canon U.S.A., Inc. has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
0204W760
