VoIP Module
,QIRUPDWLRQLVFRQÀGHQWLDOLQQDWXUH
VoIP Module
Oxygen provides the Elements VoIP hardware components in a separate module that connects to Hydrogen as a clip-on, enabling
Internet telephony. Oxygen contains two RJ11 telephony ports for connecting standard analogue telephones, DECT/cordless base
stations or fax.
Oxygen does not contain software;; this is managed and run
using Hydrogen´s integrated processor, avoiding additional
ÀUPZDUHWKDWZRXOGUHTXLUHUHPRWHPDQDJHPHQW
Oxygen´s voice stacks and codecs are enhanced by a
packetloss and jitter reducing VoiceEngine. This dramatically
reduces customer complaints and support costs for the
operator, a common challenge as VoIP often originates from
Smart phones and Wi-Fi hotspots.
2[\JHQLVDEOHWRSULRULWLVHFDOOWUDIÀFVRWKDWYRLFHTXDOLW\LV
maintained.
In addition to the advanced VoIP client, Hydrogen monitors call
TXDOLW\DQGUHSRUWVLWLQUHDOWLPHWRWKH)XVLRQVHUYLFHTXDOLW\
reporting system.
When combined with Fusion management software, this
allows the monitoring of all calls deployment wide and
generates statistics, diagrams and reports displaying service
TXDOLW\ GHYLFHV JURXSV RI GHYLFHV DQGRU VHUYLFH EXQGOHG
GHYLFHVDVUHTXLUHG
47 mm
175 mm
47 mm
Oxygen VoIP module front view
Oxygen VoIP module back view
www.pingcom.net
,QIRUPDWLRQLVFRQÀGHQWLDOLQQDWXUH
Highlights
7KH9R,3VRIWZDUHLVDOZD\VSUHVHQWLQWKH+\GURJHQÀUPZDUH
however it only activates, when the Oxygen module is
connected to the Hydrogen router:
‡ Integrated voice engine. Will recover from 20% to
30% incoming packet loss, reduce jitter and delay to
a level that is not detected by the customer
Once connected:
‡ Industry standard SIP (RFC3261) enabled for both
IPv4 & IPv6 operations
Step 1:
‡ A wide variety of audio codecs, both narrow band
and wide band
Step 2:
Step 3:
Oxygen is detected and the voice
applic ation is initiated.
The TR-104 parameters are enabled
as part of the TR-069 provisioning.
7KHYRLFHFRQÀJXUDWLRQSDJHV
becomes visible in the web interface.
‡ Hydrogen sends SYSLOG messages notifying the
MOS levels (5 to 10 second internals)
‡ Monitors call connect, disconnect and SIP
registration
‡ High availability VoIP with ICE and multiple,
concurrent outbound proxies
Oxygen
Hydrogen
LAN4
LAN3
LAN2
LAN1
WAN
USB
eSATA
47 mm
reset
175 mm
205 mm
12V DC
on/off
PHONE 1
PHONE 2
www.pingcom.net
,QIRUPDWLRQLVFRQÀGHQWLDOLQQDWXUH
Oxygen Features
Signalling and Media negotiation for VoIP
‡ RFC 3261 Session Initiation Protocol, supporting
transports UDP/TCP/TLS over IPv4 and IPv6.
‡ RFC 3262 Reliability of provisional responses in
Session Initiation Protocol.
‡ RFC 3263 Locating SIP servers. The implementation
and usage of DNS NAPTR, SRV and A (IPv4) or AAAA
(IPv6) records.
‡ RFC 4566 SDP: Session Description Protocol
(obsoletes RFC 2327).
‡ RFC 3266 Support for IPv6 in Session Description
Protocol (SDP).
‡ RFC 3264 An Offer / Answer model with Session
Description Protocol (SDP)
‡ RFC 4317 Session Description Protocol (SDP) Offer/
Answer Examples.
‡ 5)&$FWLRQV$GGUHVVLQJ,GHQWLÀHG,VVXHVZLWK
the Session Initiation Protocol’s (SIP) Non-INVITE
Transaction.
‡ 5)&3UREOHPV,GHQWLÀHG$VVRFLDWHGZLWK
the Session Initiation Protocol’s (SIP) Non-INVITE
Transaction.
NAT traversal and keep-alive
‡ RFC 3489 STUN – Simple Traversal of User
Datagram Protocol (UDP) Through Network Address
Translators (NATs). (For backwards compatibility).
‡ RFC 5626 Managing Client-Initiated Connections in
the Session Initiation Protocol (SIP)
‡ RFC 5627 Obtaining and Using Globally Routable
User Agent URIs (GRUUs) in the Session Initiation
Protocol (SIP).
‡ RFC 3327 Session Initiation Protocol (SIP) Extension
Header Field for Registering Non-Adjacent Contacts
‡ RFC 3581 An Extension to the Session Initiation
Protocol (SIP) for Symmetric Response Routing.
‡ RFC 5245 Interactive Connectivity Establishment
(ICE): A Protocol for Network Address Translator
(NAT) Traversal for Offer/Answer Protocols.
Media transport
‡ RFC 3550 A Transport Protocol for Real-Time
Applications.
‡ 5)&5733URÀOHIRU$XGLRDQG9LGHR
Conferences with Minimal Control.
‡ RFC 5057 Multiple Dialog Usages in the Session
Initiation Protocol.
‡ RFC 3605 Real Time Control Protocol (RTCP)
attribute in Session Description Protocol (SDP).
‡ RFC 2976 The SIP INFO Method.
‡ RFC 3711 The Secure Real-Time Transport Protocol
(SRTP).
‡ RFC 3311 The Session Initiation Protocol (SIP)
UPDATE Method.
‡ RFC 3515 The Session Initiation Protocol (SIP)
REFER method.
‡ RFC 3891 The Session Initiation Protocol (SIP)
“Replaces” header.
‡ RFC 3892 The Session Initiation Protocol (SIP)
Referred-By Mechanism.
‡ RFC 5589 Session Initiation Protocol (SIP) Call
Control – Transfer.
‡ RFC 4579 Session Initiation Protocol (SIP) Call
Control – Conferencing for User Agents.
‡ RFC 3420 Internet Media Type message/sipfrag.
‡ RFC 3966 The tel URI for Telephone Numbers
‡ RFC 4028 Timers in the Session Initiation
Protocol (SIP)
‡ 5)&6HVVLRQ,QLWLDWLRQ3URWRFRO6,3²6SHFLÀF
(YHQW1RWLÀFDWLRQ
‡ RFC 3842 A Message Summary and Message
Waiting Indication Event Package for the Session
Initiation Protocol (SIP).
Signalling for IM
‡ RFC 3856 A Presence Event Package for the Session
Initiation Protocol (SIP).
‡ RFC 3863 Presence Information Data Format (PIDF)
‡ RFC 4568 Session Description Protocol (SDP)
Security Descriptions for Media Streams.
‡ RFC 2833 RTP Payload for DTMF Digits, Telephony
Tones, and Telephony Signals.
‡ RFC 4733 RTP Payload for DTMF Digits, Telephony
Tones, and Telephony Signals. (Obsoletes RFC 2833).
‡ RFC 3611 RTP Control Protocol Extended Reports
(RTCP XR).
‡ RFC 3952 Real-Time Transport Protocol (RTP)
Payload Format for internet Low Bit Rate Codec
(iLBC) Speech.
Description Protocol (SDP)
‡ RFC 3711 The Secure Real-Time Transport Protocol
(SRTP).
‡ RFC 4568 Session Description Protocol (SDP)
Security Descriptions for Media Streams.
‡ RFC 2833 RTP Payload for DTMF Digits, Telephony
Tones, and Telephony Signals.
‡ RFC 4733 RTP Payload for DTMF Digits, Telephony
Tones, and Telephony Signals. (Obsoletes RFC 2833).
‡ RFC 3611 RTP Control Protocol Extended Reports
(RTCP XR).
‡ RFC 3952 Real-Time Transport Protocol (RTP)
Payload Format for internet Low Bit Rate Codec
(iLBC) Speech.
‡ RFC 3903 Session Initiation Protocol (SIP) Extension
for Event State Publication.
‡ RFC 3428 Session Initiation Protocol (SIP) Extension
for Instance Messaging.
www.pingcom.net
,QIRUPDWLRQLVFRQÀGHQWLDOLQQDWXUH
Codecs and audio processing for voice
Calling features
‡ G.711 u-Law and G.711 A-Law codecs
‡ Call transfer (attended, unattended)
‡ G.729AB codec
‡ Call forwarding (unconditional, busy, no-answer)
‡ G.723.1 codec
‡ Call hold/release
‡ G.726 codec
‡ 3-way local conferencing
‡ G.722.1 wideband codec.
‡ Redial
‡ AMR-NB codec.
‡ Call return (call the last caller)
‡ RFC 3951 Internet Low Bit-Rate Codec (iLBC).
‡ Caller ID display (FSK, DTMF modulation)
‡ Voice Activity Detection (VAD) for codecs that do not
have this built-in.
‡ Call Waiting indication (tone and visual)
‡ Message Waiting Indication (tone and visual).
‡ Comfort Noise Generation (CNG) for codecs that do
not have this built-in.
‡ Three-way calling - local conferencing
‡ G.168 Line Echo Cancellation.
‡ Message waiting indication
‡ Tone generator.
‡ Dial plan support (as described in RFC 3435,
section 2.1.5)
‡ DTMF tone detector and automatic suppression.
‡ Flexible media handling for local conferencing.
Supports participants with different sample-rates,
as well as participants with different packet size /
packet time.
&RQÀJXUDEOHUHJLRQDOVHWWLQJV
‡ 7RQHGHÀQLWLRQV
‡ Caller ID presentation (DTMF, FSK-Belcore/ETSI, BT,
JAPAN-CLIP/JCLIP)
‡ Fixed and Adaptive jitter buffer, capable of triggering
Packet Loss Concealment (PLC) functionality.
‡ 5LQJVSHFLÀF6/,&SDUDPHWHUV
‡ Gain control
Codecs and processing for FAX
‡ Support for T.38 with V.17 (or slower) Fax
modulation.
‡ Support for T.38 with UDPTL network transport.
‡ Support for T.38 with RTP network transport.
FXS
‡ );6ZLWKFRQÀJXUDEOHUHJLRQDOVHWWLQJV
‡ RJ11 sockets
‡ Voice & fax capabilities
‡ Auto-detection of Fax tones, disable / enable media
and FXS features accordingly.
‡ G711 pass-through FAX.
www.pingcom.net
