4 Way Signal Splitter
Product Code:
BPAS4F
Barcode: 6002844007072
F-TYPE
Split TV signals.
F-connector type
Indoor use only.
4 Way Signal Splitter
A splitter is used to split a signal into four or more signal
paths, such as splitting the original signal from one aerial to
supply signal to more than one TV.
General cable stripping rule
Beware of shorts between cable braid and centre core.
10mm 5mm 7mm
BRAID
INSULATION
CENTRE CORE
F-connector assembly
• Screw F-connector over the braiding until the insulation goes
against the hole in the centre of the F-connector.
THE PACKAGE CONTAINS
The unit’s connection diagram
1 x BPAS4F
5 x APF
2 x Screws
(Antenna / DStv Dish)
(TV)
(TV)
POWER PASS
OUT
OUT2
IN
POWER PASS
IN
POWER PASS
4-WAY SPLITTER
5-1000MHz
OUT
OUT
OUT3
OUT4
(TV)
(TV)
OUT
For
indoor
use only .
PACKAGE DIMENSIONS
POWER PASS
OUT1
D
Height
Depth
Width
Weight
QTY
177
560
34
520
125
390
0.08
6.4
1
80
(mm)
Blister
Carton
www.ellies.co.za
(mm)
(mm)
(kg)
