ProxPass® II Active Tag

ProxPass® II Active Tag
ProxPass II Active Tag
®
125 kHz Proximity
Long Range Proximity for Vehicle Access Control • 1351
ACCESS reliability.
Application
The ProxPass® II is an active tag specifically designed for vehicle access control.
Providing convenient access control for parking and fleet management applications,
ProxPass II is an ideal augmentation to an existing or new HID proximity installation.
The ProxPass II can be encoded with any HID format and
numbering system used by HID proximity cards, including the Corporate 1000
format.
Features
w Access door permits convenient battery replacement.
w Provides up to six foot read range.
w Velcro backing attaches easily to interior of vehicle windshield.
w Attractive, durable sealed case.
w Compatible with MaxiProx® reader and all HID card formats.
w Two to five year battery life, depending on usage.
w Competitively priced as compared to VHF vehicle tags.
Description
Options
Easily
Administered
Security
Long Life
Features
Specifications
RF-programmable, customer specified ID numbers
*Read Range using
MaxiProx® reader
Up to 6’ (2 m)
*Depending on local installation conditions.
External numbering
A cross-reference list correlating the external card number and
the programmed ID number provides easy system
administration.
Mounting Location
Offers over 137 billion unique codes.
Note: Ideal mounting location is on interior windshield glass.
Mounting on metal will degrade performance.
Dual battery design and low current draw allows two to five
years with typical usage. (Replaceable battery)
Dimensions
Durability
Rugged, UV-resistant, sonic-welded polycarbonate case is also
weather resistant
Warranty
One year warranty against defects in materials and
workmanship (see complete sales policy for details).
Interior windshield, driver’s side, upper or lower corner
3.625” x 2.65” x 0.30”
(9.25cm x 6.75cm x .76cm)
Operating Temperature
-22° to 185° F (-30° to +85° C)
Battery
Two Panasonic lithium (Model BR2330)
Environmental
5 – 95% RH, non-condensing
(Not for marine usage)
Certifications
FCC Certification, Canada Certification, CE Mark (Europe,)
New Zealand, Australia c-Tick, Taiwan
(Please see “How to Order Guide” for a description of the
options and associated part numbers.)
© 2008 HID Global. All rights reserved. HID, and the HID logo are trademarks or
registered trademarks of HID Global in the U.S. and/or other countries. All other
trademarks, service marks, and product or service names are trademarks or registered
trademarks of their respective owners. Rev. 53/2008
MKT-PROXPASSII-DS-EN
ACCESS experience.
hidglobal.com
