Troubleshooting Guide:
Problem
Cause
Solution
1. No discharge
a. No water
b. Excessive water pressure
a. Open water supply
b. Install regulator if pressure
exceeds 85 PSI
c. Clean* or replace
c. Eductor clogged
2. No concentrate draw
a. Clogged check valve
b. Metering tip clogged
c.
d.
e.
f.
g.
h.
3. Excess concentrate draw
a. Clean or replace
b. Rinse in hot water or replace:
DO NOT REAM CLEAN!
Eductor clogged
c. Clean or replace
Clogged water inlet
d. Clean screen
Clogged foot strainer
e. Clean or replace
Low water pressure and/or
f. Minimum 25 PSI and 4 GPM
volume
flow required to operate unit
Discharge hose is the wrong size. g. Use 3/4" hose if length exceeds
25'.
Check valve not screwed into
h. Tighten, but DO NOT OVER
eductor firmly
TIGHTEN!
a. Metering tip not in place
(Or wrong metering tip)
a. Press correct tip firmly into barb
4. Water flow won't shut off
a. Ball valve defective
a. Replace
5. Low or no water flow
a. Inlet screen clogged
b. Supply source inadequate
c. Scaled eductor or fittings
a. Clean or replace
b. 4 GPM flow necessary to unit.
Move unit or replumb incoming
line.
c. Clean* or replace
a. Eductor check valve inoperable
a. Clean or replace check valve
6. Backflow into concentrate
* In hard water areas, scale (mineral deposits) may form at the discharge of the eductor. This scale may be
removed by running the descalant through the system.
Hydro Systems 3798 Round Bottom Road, Cincinnati, OH 45244 s Phone: (513) 271-8800 s Fax:(513) 271-0160
10089836
Rev. C 2/08
WorldChem
Multifunction Foaming and Spraying System
Wall mounted, high volume washing, foaming and/or sanitizing proportioner for one or two products.
THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS
Hydro Systems manufactures quality proportioning and dispensing equipment. Please use this equipment carefully and
observe all warnings and cautions.
************************************************************ NOTE ********************************************************
WEAR
protective clothing and eyewear when dispensing chemicals or other materials.
ALWAYS
observe safety and handling instructions of the chemical manufacturers.
ALWAYS
direct discharge away from you or other persons or into approved containers.
ALWAYS
dispense cleaners and chemicals in accordance with manufacturer's instructions. Exercise
CAUTION when maintaining your equipment.
CLEAN
equipment after each use in accordance with instruction sheet.
WEAR
protective clothing and eyewear when working in the vicinity of all chemicals, filling or emptying
equipment or changing metering tips.
ALWAYS
re-assemble equipment according to instruction procedures. Be sure all components are firmly
screwed or latched into position.
ATTACH
only to tap water outlets (85 PSI maximum).
Package includes:
-- complete unit
-- (2) 7-foot vinyl chemical inlet tubes with foot strainers and weights
-- (1) metering tip kit
-- (4) screws and (4) wall anchors for wall mounting (use 9/32" drill)
-- (1) 1/2" hose bracket and (1) 3/4" hose bracket and mounting screws
-- parts list and product structure diagram
Instructions for Operation:
1. Remove cover and attach unit to wall using hardware provided.
2. Select metering tip (see section on metering tip selection) and press firmly into check valve provided at the side
of the eductor. Install chemical inlet tube on hose barb. The strainer end of the suction tube can be dropped
directly into the concentrate container. Replace cover.
3. Connect water inlet hose with 3/4" male garden thread to female swivel at left side of unit. Tighten to avoid
leaking.
4. Connect discharge hose to male 3/4" discharge provided at bottom of unit. Using 1/2" or 3/4" bracket and screws
provided, secure discharge hose to wall about 12" below unit. This will help to prevent stress on the discharge
fitting when tugging on the hose occurs. Hose of 1/2" ID is recommended if the hose length will be 25 feet or
less. 3/4" ID hose may be needed if the total length of the hose will exceed 25 feet. Attach appropriate spraying
or foaming gun (and ball valve or quick connect) to end of discharge hose.
5. Turn on water supply to unit. Minimum 25 PSI water pressure is required to operate the unit.
6. Turn on product valve to begin proportioning and dispensing. Slide selector switch to either side for product
dispensing. Center position provides full volume rinse.
Metering Tip Selection:
The final concentration of the dispensed solution is related to the size of the metering tip orifice, the viscosity of the
liquid being siphoned, water pressure, water flow rate, and other factors in the application. A chart is provided on
the next page which can be used as a guideline for selecting a metering tip when proportioning water-thin
concentrates. Test the actually achieved dilution using the Measurement of Concentration procedure discussed
on the next page. If product viscosity is greater than that of water, choose a tip with a larger orifice than that which
would deliver the desired water-to-product ratio for a water-thin product. Test the actually achieved ratio using the
Measurement of Concentration procedure on the next page. Continue to choose and test tips until the desired
dilution is achieved. One clear, undrilled tip is supplied to permit drilling orifice sizes not listed if necessary.
CONVERSION CHART:
Ratio Equivalents to
Standard Measures
APPROXIMATE DILUTIONS
AT 40 PSI FOR WATER-THIN PRODUCTS (1.0 CP)
Tip Color
No Tip
Gray
Black
Beige
Red
White
Blue
Tan
Green
Orange
Brown
Yellow
Aqua
Purple
Pink
Lt. Purple
Orifice
Size
.187
.128
.098
.070
.052
.043
.040
.035
.028
.025
.023
.020
.018
.014
.010
.009
Std. Drill
Number)
Ratio
Oz./Gal.
Ratio
%
(3/16)
(30)
(40)
(50)
(55)
(57)
(60)
(65)
(70)
(72)
(74)
(76)
(77)
(79)
(87)
(89)
8:1
8:1
8:1
9:1
12:1
16:1
20:1
24:1
32:1
48:1
64:1
78:1
96:1
128:1
256:1
380:1
128
64
32
21
16
14
8
6
4
3
2
1
1/2
1/4
1:1
2:1
4:1
6:1
8:1
9:1
16:1
24:1
32:1
48:1
64:1
128:1
256:1
512:1
50.0
33.3
20.0
14.3
11.1
10.0
5.9
4.0
3.0
2.0
1.5
0.8
0.4
0.2
WorldChem Parts Diagram:
(2 product unit shown)
Measurement of Concentration:
You can determine the dispensed water-to-product ratio for any metering tip size and product viscosity. All that
is required is to operate the primed dispenser for a minute or so and note two things: the amount of dispensed
water/product mixture, and the amount of concentrate used in preparation of the solution dispensed. The
water-to-product ratio is then calculated as follows:
Dilution (X) = Amount of Mixed Solution -- Amount of Concentrate Drawn
Amount of Concentrate Drawn
Dilution ratio, then, equals X parts water to one part concentrate (X:1). If the test does not yield the desired
ratio, choose a different tip and repeat the test. Alternative methods to this test are 1) pH (using litmus paper),
and 2) titration. Contact your concentrate supplier for further information on these alternative methods and the
materials required to perform them.
PARTS LIST (Refer to diagram)
Key #
Part Number
1
10089824
2
10092102
3
10092105
4
10059204
5
10048302
6
10069270
7
10089826
8
10084080
9
10089838
10
10027209
11
500814
12
509900
13
609600
Not Shown:
10089837
Description
Cabinet back
Eductor Assembly
Gear & Bracket Assembly
Elbow
Connecting Tube
Check Valve, 3 psi, Viton
Handle, Ball Valve
Ball Valve
Handle Sleeve, Black
Metering tip kit
Tubing
Ceramic weight
Foot strainer
Cover
10
11
12
13
10
11
2
12
13
