catalogue

EXPORT

IN MOTION

PRODUCT CATALOGUE FOR PUMPING, METERING AND DOSING

FLUID TECHNOLOGY AT ITS BEST: A CUT ABOVE

EDITORIAL

WELCOME TO

“HALLBAUER” – A DIVISION

OF SAMOA-HALLBAUER

Withgreatpleasurewewouldliketopresenttoyouournewcatalogueforprofessionalequipmentforthehandlingofl uidsespeciallylubricants.Establishedin1919thebrandHALLBAUERof

Samoa-HallbauerGmbHstandseversinceforreliablepartnershipwhenitcomestoprofessional lubricationequipment.Asforwardlookinggroupofcompanieswerelyonourinnovativepower

andexperiencetoof eryoustateoftheartandindividualsolutionsforyourlubricationproblems.

We invite you to discuss your requirements with us, as communication is vital for tailor-made products and adequate service.

General management and staf are dedicated to achieve our goal: your entire satisfaction!

Qualitycombinedwithaconvincingprice/value-ratio:Thatiswhatweguaranteethroughaclose qualitycontrolandregulari eldtests.Whatyouasaprofessionalrequireisprofessionalquality!

OurexcellentlogisticsituationintheheartofthebusyRhine-Neckar-triangleallowsustoprovide bestserviceandpromptdeliveryforourcustomersworldwideinover80countries.Onthefollowing

pages you are invited to get to know our product range and performance. And do not forget:

We are just a phone call or e-mail away to learn about your individual needs!

We look forward to our future cooperation.

Dr. Albrecht Hallbauer, Managing Director of Samoa-Hallbauer GmbH

Good accessibility – even from distance: Our export sales and logistics team.

On Order: Quality and Service.

A Cut Above.

At Samoa-Hallbauer GmbH meet the decade long success story of

Hallbauer Metallwarenfabrik GmbH and the innovative strength and

worldwide production structure of Samoa S.A. Both together are the leading suppliers for pumping, metering and dosing technology of viscous liquids such as lubricants giving you the beneﬁt of high class, innovative and sustainable products attended by trusted service.

Please let us know your questions, requests, proposals, and concerns.

We will only be too happy to have the opportunity to assist you with advice, offers tailored to your needs and a reliable after sales

service. Just call or e-mail us and we will be with you. Thank you.

GET IN TOUCH WITH US:

Simply call ...

+49 6204 7095-40

or

... order via e-mail.

[email protected]

VISIT US ON FACEBOOK

CONTENTS

IN MOTION

01 Grease

Lubricating with grease

02 Fresh Oil

Electric and pneumatic pumps – powerful and highly versatile

03 Diesel

Diesel, biodiesel and AdBlue® –

Refuel with us!

04 Chemicals

Not easy, but feasible.

Our air-operated grease guns: time and cost saﬁng

GREASE

A LARGE FIELD – FROM

LOW-TECH TO HIGH-TECH.

For a easy lubricating with grease

Let’s start our trip to the lubrication universe with the ”classics” which are still the backbone in lubrication worldwide – the hand- and foot- operated lubrication equipment. They are literally independent from electric power and compressed air. However, they ask for your muscular strength – sometimes less, sometimes more.

If you have to lubricate e.g. the huge harvesting or construction machines which need quite a bit of grease your choice is the hand-operated bucket greaser HAG which gives you high-pressure lubrication directly out of the grease keg. The HAG bucket greasers are by the way also very popular for servicing cable cars and ski lifts in the mountains.

You need a free hand and would like to have a little extra exercise for your leg muscles? Fine, then just get yourself one of our high-pressure foot-operated grease pumps FHP or WH. They have a clear home ﬁeld advantage in industry, in shipping and railway companies.

Worldwide number one in the lubrication charts as second to none is still the good old lever-type grease gun – a real classic. Many million pieces are manufactured every year and the volume is still growing.

Watch out, though, when you buy a grease gun! If you have to lubricate your leisure time vehicles once or twice a year you could, if you want to do so, settle for one of the cheap grease guns, but if you or your customers are professional users you should look for quality – otherwise buying cheap could become very expensive in the end when you look at the enormous ﬁnancial damage a not properly lubricated bearing could cause when it comes to the very expensive machines which are used in industry, construction or agriculture.

As we consider ourselves to be professionals having been servicing for almost one century now professionals like yourself, we place special emphasis on quality products. This applies to our top of the line grease guns, the Variomatic special for the very rough applications and as well to our X-TRA line grease guns made completely out of steel, our workhorse for the everyday lubrication job. Latest examples to meet our commitment as professionals are our new grease gun lines with screw- in cartridges such as the one-hand grease gun PEP 500 VARIO-PAT and the push-type grease gun K 100 which ﬁnally make reﬁlling of grease guns a clean and easy job.

Worldwide number one in the lubrication charts is

lever-type grease gun.

01 Grease

Professional lever grease guns

Professional one-hand grease guns

Professional push-type grease guns

Professional manual ﬁller pumps for centralized lubrication

Accessories for FGZ plus, FGZ Combi plus and DPZ

11

15

17 Professional manual high pressure grease pumps 19

Professional battery-operated grease guns 21

22 Professional air-operated grease guns

Professional air-operated greasing unit “Schmiermeister”

Professional air-operated ﬁller pumps for centralized lubrication

23

24

25

26 Professional manual ﬁller pumps for grease guns 27

28 Accessories for “FG plus”

Professional manual ﬁller pumps for bearings

Accessories for ﬁller pumps “FGL plus”

29 Trolleys and accessories for ﬁller pumps and greasing units 30

43 Professional grease ﬁttings

Professional grease ﬁtting tools 63

Professional packaging for grease ﬁttings 63

Professional lever grease guns

› extremely reliable, also with high-pressure applications

› precisely worked piston, no need of additional sealings

› made of precision steel, robust and durable

› safe grip (non-slip knurled pump body, curved lever, extra-large piston knob for safe handling)

› working pressure 400 bar (5.800 psi)

Heavy-duty lever grease gun “Variomatic” special

40844 / 40843

81774 “Variomatic” special/M without accessories

81773 “Variomatic” special/BSP without accessories

40844 Set “Variomatic“ special/M

with extension pipe 103/M (DIN 1283), 150 mm / 6 inch, with 4-jaw Proﬁ-nozzle

40842 Set “Variomatic“ special/BSP

with extension pipe 103/BSP, 150 mm / 6 inch, with 4-jaw Proﬁ-nozzle

40843 Set “Variomatic“ special/M

with safety high-pressure rubber hose 110/M (DIN 1283), 300 mm / 12 inch, with 4-jaw Proﬁ-nozzle (DIN 1283)

40841 Set “Variomatic“ special/BSP

with safety high-pressure rubber hose 110/BSP, 300 mm / 12 inch, with 4-jaw Proﬁ-nozzle, 150 mm / 6 inch, with 4-jaw Proﬁ-nozzle

40736 Set “Variomatic“ special/M with safety high-pressure rubber hose 110/M (DIN 1283), 300 mm/12 inch, and extension pipe

103/M (DIN 1283), 150 mm / 6 inch, both with 4-jaw Proﬁ-nozzle (DIN 1283)

Characteristics

› heavy-duty lever grease gun made of precision steel with heavy-duty diecast aluminium head

› builds up very high pressure

› for application under tough conditions, especially in agriculture and construction

› variable and controlled lubrication with short-stroke system

› white plain carton

› safety handle

› filler nipple

› three-way loading with professional filler pump FG plus, 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› connecting thread M = M 10 x 1, 1/8" BSP = G 1/8"

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 11

Professional lever grease guns

› extremely reliable, also with high-pressure applications

› precisely worked piston, no need of additional sealings

› made of precision steel, robust and durable

› safe grip (non-slip knurled pump body, curved lever, extra-large piston knob for safe handling)

› working pressure 400 bar (5.800 psi)

Lever grease gun „X-TRA 701” with ﬁller nipple

01803

Lever grease gun „X-TRA 701”

Colour with ﬁller nipple

41274

Without accessories

40800 X-TRA 701/M (DIN 1283)

40801 X-TRA 701/BSP

With bent extension pipe 103, 150 mm/6 inch, with 4-jaw Proﬁ-nozzle

01801 Set “X-TRA 701”/M with 103/M (DIN 1283)

01831 Set “X-TRA 701”/R with 103/BSP

40641 Set “X-TRA 701”/NPT with 103/NPT

With safety high-pressure rubber hose 110, 300 mm/12 inch, with 4-jaw Proﬁ-nozzle

01803 Set “X-TRA 701”/M with 110/M (DIN 1283)

01833 Set “X-TRA 701”/R with 110/BSP

With high-pressure hose 910, 300 mm/12 inch, with 4-jaw Proﬁ-nozzle

40453 Set “X-TRA 701”/M with 910/M (DIN 1283)

40871 Set “X-TRA 701”/R with 910/BSP

40642 Set “X-TRA 701”/NPT with 910/NPT

With safety high-pressure rubber hose 110, 300 mm/12 inch, and bent extension pipe 103, 150 mm/6 inch, both with 4-jaw Proﬁ-nozzle

40408 Set “X-TRA 701”/M with 110/M (DIN 1283) and 103/M (DIN 1283)

40405 Set “X-TRA 701”/R with 110/BSP and 103/BSP

With high-pressure hose 910, 300 mm/12 inch, and bent extension pipe 103,

150 mm/6 inch, both with 4-jaw Proﬁ-nozzle

40546 Set „X-TRA 701”/M with 910/M (DIN 1283) and 103/M (DIN 1283)

40419 Set „X-TRA 701”/R with 910/BSP and 103/BSP

Characteristics

› ultimate suction power with full-stroke system

› made of precision steel, robust, durable and with curved lever and filler nipple

› three-way loading with professional filler pump FG plus, 400 g (14 oz) grease cartridges or bulk grease

› output 1 cm 3 /stroke

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› connecting thread M = M 10 x 1, 1/8" BSP = G 1/8", 1/8" NPT

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

41274 X-TRA 701/M Colour

without accessories

Characteristics

› five different safety handles (red, yellow, green, blue and black) for a better allocation of specially greases to the lubrication points of machinery and vehicles

› display carton with

› ultimate suction power with full-stroke system

› made of precision steel, robust and durable

› filler nipple

› three-way loading with professional filler pump FG plus, 400 g (14 oz) grease cartridges or bulk grease

› output 1 cm 3 /stroke

› capacity 500 cm

(17 oz) / 400 g (14 oz)

› connecting thread M = M 10 x 1

Lever grease gun

“X-TRA 709”

82024

Lever grease gun “X-TRA 709” with bent extension pipe

01851

Lever grease gun “X-TRA 709” with high-pressure rubber hose

01853

82024 “X-TRA 709”/M (DIN 1283)

82026 “X-TRA 709”/BSP

Characteristics

› display plastic bag (PE) with

› two-way loading with 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› working pressure 400 bar (5.800 psi)

› connecting thread M = M 10 x 1, 1/8"

BSP = G 1/8", 1/8" NPT on request

With bent extension pipe 103,

150 mm / 6 inch, with 4-jaw Proﬁ-nozzle

01851 Set “X-TRA 709”/M

with 103/M (DIN 1283)

01881 Set “X-TRA 709”/BSP

with 103/BSP

Characteristics

› display plastic bag (PE) with

› two-way loading with 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› working pressure 400 bar (5.800 psi)

› connecting thread M = M 10 x 1, 1/8"

BSP = G 1/8", 1/8" NPT on request

With high-pressure hose 910, 300 mm /

12 inch, with 4-jaw Proﬁ-nozzle

01853 Set “X-TRA 709”/M

with 910/M (DIN 1283)

01883 Set “X-TRA 709”/BSP

with 910/BSP

Characteristics

› display plastic bag (PE) with

› two-way loading with 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› working pressure 400 bar (5.800 psi)

› connecting thread M = M 10 x 1, 1/8"

BSP = G 1/8", 1/8" NPT on request

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 13

Professional lever grease guns

› extremely reliable, also with high-pressure applications

› precisely worked piston, no need of additional sealings

› made of precision steel, robust and durable

› safe grip (non-slip knurled pump body, curved lever, extra-large piston knob for safe handling)

› working pressure 400 bar (5.800 psi)

Lever grease gun “X-TRA 600” with ﬁller nipple

81712

Two-hand grease gun PZP

41037

Lever grease gun box PHK

07990

81712 “X-TRA 600” / M

without accessories

40437 Set “X-TRA 600”/M

with extension pipe 103/R with 4-jaw Proﬁ-nozzle

Characteristics

› display plastic bag (PE) with

› safety handle

› filler nipple

› three-way loading with filler pump FG, 400 g

(14 oz) (DIN 1284) and 500 g (7,5 oz) grease cartridges or bulk grease

› capacity 600 cm 3 (20 oz) / 500 g (17,5 oz)

› connecting thread M = M 10 x 1

41035 PZP/M

41037 Set PZP/M (DIN 1283) with high-pressure hose 910/M with 4-jaw

Proﬁ-nozzle

41038 Set PZP/M (DIN 1283) with saftey-high-pressure rubber hose 110/M with 4-jaw Proﬁ-nozzle

Characteristics

› environmentally sound due to use with refillable 500 g (17,5 oz) screw-in cartridges and reliable emptying of cartridges

› quick and clean changing of cartridge

› robust construction with zinc die cast head and sheet metal levers

› powerful suction capacity by full-stroke system

› controlled lubrication due to safe hand grip

› unbreakable retractable cartridge guide ring

› little operation effort required due to customer-oriented lever construction

› working pressure 400 bar (5.800 psi)

› output 1,4 cm 3 /stroke (0,05 oz)

› connecting thread M = M 10 x 1

07990 PHK/M

40044 PHK/BSP

Characteristics

› solid plastic box, with oil-proof insert

› connecting thread M = M 10 x 1, 1/8"

BSP = G 1/8", 1/8" NPT

Content:

› 1 professional lever grease gun “X-TRA 701”

› 1 safety high-pressure rubber hose 2200 with

4-jaw Profi-nozzle and quick coupler

› 1 extension pipe 103, bent, with 4-jaw

Profi-nozzle

› 1 extension pipe 2060 with cardan nozzle and quick coupler

› 1 extension pipe 2070/M1 with hook-on coupler for button-head grease fittings M1

ø 16 mm and quick coupler

› 1 all-purpose nozzle 36

› 1 pointed nozzle 23

› 1 reduction piece (only for PHK/NPT)

14 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional one-hand grease guns

› indispensable for difficult to reach greasing points

› connecting thread 1/8" BSP = G 1/8"

One-hand grease gun

“PEP 500”

01531

One-hand grease gun

“PEP 500 VARIO”

40700

One-hand grease gun “PEP

500 VARIO-PAT”

40700

01531 “PEP 500” D

with extension pipe 103/BSP with 4-jaw Proﬁ-nozzle

40511 “PEP 500” D – M 10 x 1

with extension pipe 103/M with 4-jaw Proﬁ-nozzle

01532 “PEP 500” G

with safety high-pressure rubber hose 110/BSP with 4-jaw Proﬁ-nozzle

40512 “PEP 500” G – M 10 x 1

with safety high-pressure rubber hose 110/M with 4-jaw Proﬁ-nozzle

40344 “PEP 500” H

with high-pressure hose 910/BSP with 4-jaw Proﬁ-nozzle

40527 “PEP 500” Econo

with high-pressure hose KS-E 300/BSP, with 4-jaw Proﬁ-nozzle

40832 “PEP 500”

with extension pipe 103/BSP and safety high-pressure rubber hose 110/BSP both with 4-jaw Proﬁ-nozzle

Characteristics

› made of precision steel

› display plastic bag (PE) with

› filler nipple

› three-way loading with filler pump FG, 400 g

(14 oz) cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

40700 “PEP 500 VARIO” H

with high-pressure hose 910/BSP with 4-jaw Proﬁ-nozzle

40777 “PEP 500 VARIO” D

with extension pipe 103/BSP with 4-jaw Proﬁ-nozzle

Characteristics

› integrated switch mode for high pressure or high output

› made of precision steel with heavy-duty diecast zinc head, high quality coated grease gun body and zinc-plated handle

› handle lockable in place for leak-proof storing

› display carton

› filler nipple and vent nipple

› three-way loading with filler pump FG, 400 g

(14 oz) cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

40733 “PEP 500 VARIO-PAT” 2

for 500 g (17,5 oz) screw-in cartridges with high-pressure hose 910 with 4-jaw Proﬁ-nozzle

40601 “PEP 500 VARIO-PAT” 4

for 500 g (17,5 oz) screw-in cartridges with high-pressure hose 910 with 4-jaw Proﬁ-nozzle specially for Kajo-cartridges

Characteristics

› display carton

› integrated switch mode for high pressure or high output

› made of precision steel with heavy-duty diecast zinc head, high quality coated grease gun body and zinc-plated handle

› handle lockable in place for leak-proof storing

› clean and quick refilling with 500 g (17,5 oz) screw-in cartridges

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 15

Professional one-hand grease guns

› indispensable for difficult to reach greasing points

› connecting thread 1/8" BSP = G 1/8"

Professional one-hand grease gun “PEP 200”

11211

Professional one-hand grease gun “PEP 100”

40483

11211 “PEP 200” D

with extension pipe 103/M with 4-jaw Proﬁ-nozzle and 2 screw-in cartridges PAT 100

11212 “PEP 200” H

with high-pressure hose with 4-jaw Proﬁ-nozzle and 2 screw-in cartridges PAT 100

Characteristics

› plain white carton

› with screw-in cartridge filled with 100 g (3,5 oz) lithium base multiple-purpose grease, consistency class NLGI 2, for a simple, quick and clean operation

› connecting thread M = M 10 x 1

40483 “PEP 100”

Characteristics

› plastic bag (PE)

› double-nozzle for hydraulic and cup-shaped grease fittings

› refilling with grease cartridge PAT 60 or bulk grease

› capacity 100 cm 3 (3,5 oz)

› connecting thread M = M 10 x 1

Please ﬁnd our choice of grease cartridges on page 31.

16 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional push-type grease guns made of

plastic

› multifunctional

› ideal for tool boxes or kits

› one-hand operation

“Serie K 60”

40557 / 40583 / 41078

“Serie K” – customized version “Serie K 100” with screw-in catridges

40625 / 40626 / 40627 / 41275

empty

40557 K 60/Na tube length 30 mm

with extra-pointed nozzle

40558 K 60/3 tube length 30 mm

with all-purpose nozzle

41078 K 60/3 tube length 100 mm

with all-purpose nozzle, for ﬁlling of cardan joins

preﬁlled with multiple-purpose grease

40582 K 60/Na

with extra-pointed nozzle

40583 K 60/3

with all-purpose nozzle

› refilling with grease cartridge PAT 60

› manufactured from high-quality plastic

materials withstanding changes in

temperature

› transparent, visual control of fill level

› suitable for high viscosity oils and greases of up to medium consistency (NLGI 2)

› capacity 60 cm 3 (2 oz)

› pointed nozzle for cup-shaped grease fittings

› all-purpose nozzle for hydraulic and ball-head grease fittings

› output max. 0,5 cm 3 /stroke (0,02 oz) - depent

on consistency of grease

stamping of grease gun body with your logo

One-time set-up cost for printing block and art work as well as printing cost and purchase minimum on request.

packaging in slide-in blister

(holding one grease gun) Cost for blister package and purchase minimum on request.

blistercard (6,5 cm x 24,5 cm)

One-time set-up cost for printing bloc and artwork as well as printing cost and purchase minimum on request.

40625 K 100/2 tube length 30 mm

with pointed nozzle and 1 screw-in cartridge

40626 K 100/3 tube length 30 mm

with all-purpose nozzle and 1 screw-in cartridge

40627 K 100/NA tube length 30 mm

with extra-pointed nozzle and 1 screw-in cartridge

41275 K 100/3 VL70 tube length 100 mm

with all-purpose nozzle and 1 screw-in cartridge

Characteristics

› quick and clean filling with screw-in cartridge

PAT 100 containing 100 g (3,5 oz) lithium base multiple purpose grease, consistency class NLGI 2

› including 1 cartridge

› capacity 100 cm 3 (2 oz)

› pointed nozzle for cup-shaped grease fittings

› all-purpose nozzle for hydraulic and ball-head grease fittings

› extra-pointed nozzle, e.g. for chain saws

› output max. 0,5 cm 3 /stroke (0,02 oz) - depent

on consistency of grease

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 17

Professional push-type grease guns

“Serie T”

03122 / 03332

› made of steel

› suitable for diffent types of grease

› capacity 60 cm 3 (2 oz) up to 180 cm 3 (6 oz)

“Serie F”

04121 / 04131

“Serie FO”

05122 / 05132

03122 T 100/2

with pointed nozzle

03132 T 100/3

with all-purpose nozzle

03322 T 180/2

with pointed nozzle

03332 T 180/3

with all-purpose nozzle

Characteristics

› suitable for greases of high consistency

(NLGI 3)

› telescopic piston tube

› capacity 100 cm 3 (3,5 oz) up to 180 cm 3

(6 oz)

04021 F 60/2

with pointed nozzle

04052 F 60/Na

with extra-pointed nozzle for chain saws

04032 F 60/3

with all-purpose nozzle

Characteristics

› suitable for greases of medium consistency

(NLGI 2) and high viscosity oils

› user-optimized design

› refilling with grease cartridge PAT 60 or bulk

grease

› easy removal of the empty grease cartridge

› capacity 60 cm 3 (2 oz) or 150 cm 3 (5 oz)

› output max. 0,3 cm 3 /stroke (0,01 oz) -

depent on consistency of greae

05122 FO 180/2

with pointed nozzle

05132 FO 180/3

with all-purpose nozzle

Characteristics

› especially suitable for low viscosity oils and aerosols

› capacity 180 cm

(6 oz)

Adapters for push-type grease guns (series T, F 150, FO 180)

07011 / 80366 / 07041 / 80492

04121 F 150/2

with pointed nozzle

04131 F 150/3

with all-purpose nozzle

40727 F 150/3+2

with pointed nozzle and all-purpose nozzle

Characteristics

› suitable for greases of medium consistency

(NLGI 2) and high viscosity oils

› capacity 60 cm

(2 oz) or 150 cm

(5 oz)

› output max. 0,3 cm 3 /stroke (0,01 oz) -

depent on consistency of greae

18 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

07011 23/M 9 x 1 pointed nozzle

80366 23/M 9 x 1 extra-pointed nozzle

07041 36/M 9 x 1 all-purpose nozzle

80492 M 9 x 1i – M 10 x 1a connection adaptor

Professional manual high pressure grease pumps

Bucket greaser “Serie HAG”

40110

› versatile, especially when higher amounts of grease are required and no connection to compressed air is available

› ideal for manual and economic lubrication in private and public vehicle fleets, in agriculture, construction, mines, workshops and the maritime sector

› one-hand operation allows secure seat of 4-jaw Profi-nozzle on grease fittings head

› units complete with greasing hose and extension pipe including 4-jaw Profi-nozzle

Grease bucket pump “Serie BMP”

150000

40110 HAG 15 for 15 kg grease kegs, suction tube length 300 mm, dust cover ø 310 mm, follower plate ø 260 – 290 mm

40111 HAG 20 for 20 kg grease kegs, suction tube length 360 mm, dust cover ø 330 mm, follower plate ø 260 – 306 mm

40112 HAG 25 for 25 kg grease kegs, suction tube length 360 mm, dust cover ø 342 mm, follower plate ø 285 – 341 mm

40126 HAG 50 for 50 kg grease kegs, suction tube length 660 mm, dust cover ø 405 mm, follower plate ø 360 – 405 mm

Characteristics

› for manual lubrication directly from grease keg

› suitable for greases up to consistency class NLGI 2

› manual lever pump with G 2" bung adaptor

› follower plate, dust cover with G 2" connection, 1,5 m high-pressure rubber hose with extension pipe and 4-jaw Profi-nozzle

› working pressure 350 bar (5.000 psi)

› output 2 cm 3 /stroke (0,06 oz)

› suction tube ø 32 mm

Delivery content without bucket.

150000 BMP 16

Characteristics

› heavy-duty manual grease pump for high output

› 3 alternative lever positions for different outputs: 10 g (0,35 oz), 15g

(0,50 oz), 20 g (0,70 oz)

› suitable for greases up to consistency class NGLI 2 and oils

› maximum pressure range between 80 bar (1.160 psi) and 200 bar

(2.900) psi depending on lever position

› including robust and stable steel container

› capacity 16 kg (565 oz)

› with 1,5 m high-pressure rubber hose with extension pipe and 4-jaw

Profi-nozzle

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 19

Professional high-pressure foot-operated grease pumps

› foot operated

› suitable for high pressures

› including high-pressure hose

Professional high-pressure foot-operated grease compressors “Serie WH”

41012

41012 WH 5 LP with 4 m greasing hose

41013 WH 5 LP with 7 m greasing hose

41014 WH 5 LP with 10 m greasing hose

41015 WH 5 DR with 4 m greasing hose

41016 WH 5 DR with 7 m greasing hose

41017 WH 5 DR with 10 m greasing hose

Characteristics

› suitable for greases up to consistency class NLGI 3 and for oils

(surcharge)

› grease pistol with swivel and hose adaptor

› safety high-pressure rubber hoses nom. diam. 6 are available in the standard lengths of 4 m, 7 m and 10 m

› grease follows by means of an air pump (WH 5 LP) or compressed air (WH 5 DR)

› mobile

› capacity 6,5 kg (230 oz)

› working pressure max. 400 bar (5.800 psi)

› bursting pressure 1.600 bar (23.200 psi)

› output 2 cm 3 /stroke (0,06 oz)

Professional high-pressure foot-operated grease pump

FHP

157000

157000 FHP 7

Characteristics

› suitable for greases up to consistency class

NLGI 2

› 5 kg-container with pedal and carrying handle

› 2 m high-pressure rubber hose with 4-jaw

Profi-nozzle

› working pressure approx. 500 bar (7.250 psi)

› output 2 cm 3 /stroke (0,06 oz)

20 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional battery-operated grease guns

› battery-operated grease guns with two Li-ION 18 V-batteries

› robust plastic case

› 400 bar working pressure

Rechargeable grease gun

“AFP-S 500”

160101400

Rechargeable grease gun

“AFP 500-PAT”

160101401

Accessories and spare parts

169009

160101400 “AFP-S 500“ with two Li-ION

18 V-batteries

160103400 “AFP-S 500“ with one Li-ION

18 V-batterie

Characteristics

› high-pressure hose 1.000 mm (39 inch) with

4-jaw Profi-nozzle

› one or two powerful 18 V rechargeable batteries 1.500 mAh (Li-ION)

› two-way loading with 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› express recharger – charging time 60 min

› working pressure 400 bar (5.800 psi)

› output approx. 100 cm

/min (3,5 oz) against

0 bar

› capacity 500 cm 3 (17,5 oz) / 400 g (14 oz)

Advantages of Li-ION batteries:

› faster loading times

› longer lifetime

› less weight

160101401 “AFP 500 PAT“ with two Li-ION

18 V-batteries

160103401 “AFP 500 PAT“ with one Li-ION

18 V-batterie

Characteristics

› high-pressure hose 1.000 mm (39 inch) with

4-jaw Profi-nozzle

› one or two powerful 18 V rechargeable batteries 1.500 mAh (Li-ION)

› clean and quick filling with eco-friendly 500 g

(17,5 oz) screw-in cartridges

› prefilled, ready for use

› express recharger – charging time 60 min

› working pressure 400 bar (5.800 psi)

› output approx. 100 cm 3 /min (3,5 oz) against

0 bar

Advantages of Li-ION batteries:

› faster loading times

› longer lifetime

› less weight

Batteries

169009 Battery for AFP-S 500 Li-ION

Characteristics

› voltage 18 V

› capacity 1.500 Ah

Chargers

169011 Charger for Li-ION-Akku

Characteristics

› input voltage 230 V, 50 Hz, 32 W

› output voltage 18V

› 1 h-battery-recharging

Hoses

169012 High-pressure hose,

1.000 mm / 39 inch

Extension pipes

40517 Extension pipe 150/NPT, straight

40518 Extension pipe 103/NPT, straight with 4-jaw Proﬁ-nozzle

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 21

Professional air-operated grease guns

“DFP 500”

10205 / 10206

10205 “DFP 500” D

with extension pipe 103/BSP with 4-jaw Proﬁ-nozzle

10206 “DFP 500” G

with safety high-pressure rubber hose 110/BSP with 4-jaw Proﬁ-nozzle

Characteristics

› display carton

› three-way loading with filler pump FG, 400 g (14 oz) grease cartridges (DIN 1284) or bulk grease

› capacity 500 cm 3 (17 oz) / 400 g (14 oz)

› practical one-hand operation

› controlled grease dispensing by single action – 1 cm 3 /stroke (0,03 oz) at 400 bar

(5.800 psi)

› air pressure 2 – 6 bar (29 – 87 psi)

› pressure ratio 1:60

› connecting thread 1/8" BSP = G 1/8"

“DFP 1000”

10210 / 10211

10210 “DFP 1000” D

with extension pipe 103/BSP with 4-jaw Proﬁ-nozzle

10211 “DFP 1000” G

with safety high-pressure rubber hose 110/BSP with 4-jaw Proﬁ-nozzle

Characteristics

› display carton

› two-way loading with filler pump FG or bulk grease

› capacity 1.000 cm 3 (34 oz) / 800 g (28 oz)

› grease follows by compressed air

22 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional air-operated greasing unit

“Schmiermeister”

› presupply system for safe delivery of long-time greases

› air-operated greasing units “Schmiermeister” you can use stationary or mobile with trolley, with high-pressure rubber hoses with 4, 7 or 10 m length

› including pressure reducer and drain valve for less wear and long lasting

› including 2" BSP adaptor for barrels

“Schmiermeister” – “Serie PM” stationary

40032

40032 PM 15/18 stationary with 4 m hose

40043 PM 15/18 stationary with 7 m hose

40047 PM 15/18 stationary with 10 m hose

40406 PM 20 stationary with 4 m hose

40407 PM 20 stationary with 7 m hose

40410 PM 20 stationary with 10 m hose

40336 PM 25 stationary with 4 m hose

40346 PM 25 stationary with 7 m hose

40351 PM 25 stationary with 10 m hose

40458 PM 50 stationary with 4 m hose

40478 PM 50 stationary with 7 m hose

40495 PM 50 stationary with 10 m hose

40541 PM 200 stationary with 4 m hose

40555 PM 200 stationary with 7 m hose

40568 PM 200 stationary with 10 m hose

40611 + 501300 PM 200 stationary with 10 m hose on a hose reel and with connecting hose

“Schmiermeister” – “Serie PM” mobile

40531

40260 PM 15/18 mobile with 4 m hose

40261 PM 15/18 mobile with 7 m hose

40265 PM 15/18 mobile with 10 m hose

40411 PM 20 mobile with 4 m hose

40415 PM 20 mobile with 7 m hose

40428 PM 20 mobile with 10 m hose

40361 PM 25 mobile with 4 m hose

40365 PM 25 mobile with 7 m hose

40383 PM 25 mobile with 10 m hose

40531 PM 50 mobile with 4 m hose

40536 PM 50 mobile with 7 m hose

40537 PM 50 mobile with 10 m hose

40574 PM 200 mobile with 4 m hose

40576 PM 200 mobile with 7 m hose

40581 PM 200 mobile with 10 m hose

40219 + 501300 PM 200 mobile with 10 m hose on a hose reel and with connecting hose

Characteristics

› high output achieved by pressure ratio 1:55 and safety high-pressure rubber hoses with large inner diameter

› suitable for oils and greases up to consistency class NLGI 2, also for biological greases

› follower plate, steel dust cover and high-pressure grease pistol with professional z-swivel with ball bearing, for easy use also under pressure

› air inlet 1/4" BSP

› grease outlet thread 1/4" BSP

› air pressure min. 3 bar (43 psi), max. 10 bar (143 psi)

› working pressure max. 400 bar (5.800 psi)

› capacity approx. 600 cm 3 /min with free discharge at 7 bar (100 psi)

› suction tube diameter 28 mm above, 41 mm below

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 23

Professional air- operated ﬁller pumps for centralized lubrication

› suitable for greases of consistency classes NLGI 0 – 3

› for all commercial grease kegs

Air-operated ﬁller pumps DPZ-2 for centralized lubrication systems

09847 / 09844

Without trolley

09847 DPZ – 2/25

09848 DPZ – 2/50

09849 DPZ – 2/200

With trolley

09844 DPZ – 2/25 mobile

09843 DPZ – 2/50 mobile

09850 DPZ – 2/200 mobile

Characteristics

› included: maintenance unit for less wear and long lasting

› follower plate, dust cover, 2 m grease hose nom. diam. 16, 3/4" BSP, ball valve and self-closing quick coupler

› output 700 g/min at 6 bar (87 psi)

› middle-pressure pump with pressure ratio 1:10

› air pressure min. 2 bar (29 psi), max. 7 bar (100 psi)

› suction tube diam. 38 mm

Delivery content without bucket.

24 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional manual ﬁller pumps for centralized lubrication

› suitable for all greases up to consistency class NLGI 2 (also soft greases)

› for all commercial grease kegs

Professional manual ﬁller pumps “Serie FGZ plus”

40673 / 40445

Filler pump FGZ Combi plus

08761

Without trolley

40653 FGZ plus 5

40784 FGZ plus 10

40400 FGZ plus 12.5

40671 FGZ plus 15/18

40673 FGZ plus 20

40675 FGZ plus 25

40683 FGZ plus 50

40551 FGZ plus 200

With trolley

40444 FGZ plus 10 mobile

40445 FGZ plus 15/18 mobile

40446 FGZ plus 20 mobile

40447 FGZ plus 25 mobile

40448 FGZ plus 50 mobile

Characteristics

› works also at temperatures as low as – 20° C

› extremely high suction capacity due to an especially adjusted lift of stroke and increased suction and valve openings

› robust and wear resisting by reinforced steel lever

› only low operating force (11 – 16 kp) required

› follower plate, dust cover, 2 m polyamide grease hose nom. diam. 16, nylon reinforced, self-closing quick coupler 3/8" BSP = G 3/8"

› output approx. 30 cm 3 /stroke (1 oz)

› suction tube diam. 40 mm

Without trolley

40662 FGZ Combi plus 15/18

08761 FGZ Combi plus 25

08765 FGZ Combi plus 50

With trolley

40449 FGZ Combi plus 25 mobile

40450 FGZ Combi plus 50 mobile

Characteristics

› see description for FGZ plus

› for centralized lubrication systems and centralized lubrication systems

› follower plate, dust cover and combi connector with ball valve, 2 m polyamide grease hose nom. diam. 16, nylon reinforced, self-closing quick coupler 3/8" BSP = G 3/8"

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 25

Accessories for

FGZ plus, FGZ

Combi plus and

DPZ

› filling tubes

› couplers

› filler guns

› retrofit kits

› hoses

› filler adaptors

Filling tube

40098

Couplers and accessories

80431 / 80317 / 80316

Filler gun FPZ for centralized lubrication systems

40534

For reﬁlling of grease containers of centralized lubrication systems

40098 Filling tube

with coupler plug for FGZ / DPZ

80332 Coupler socket

for 1/4" BSP = G 1/4" (f) with protection cap

80316 Coupler socket

for 3/8" BSP = G 3/8" (f) with protection cap

80333 Coupler plug

for 1/4" BSP = G 1/4" (f)

80317 Coupler plug

for 3/8" BSP = G 3/8" (f) with protection cap

80185 Double nipple 1/4" BSP = G 1/4"

80431 Reduction piece

3/8" BSP = G 3/8" to 1/4" BSP = G 1/4"

Retroﬁt kit

40005

Alternative hose

40258

40005 Retroﬁt kit

for converting FGZ into FGZ Combi plus, consisting of T-piece with ﬁller plug and ball valve

For higher ﬂow rate

40258 FGZ 2 m polyamide hose nom. diam. 16, nylon reinforced,

with FPZ connector and protection cap

40153 M20 x 1,5

with protection cap

40154 M22 x 1,5

with protection cap

40781 M26 x 1,5

with protection cap

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

40534 FPZ 500

41285 FPZ 500

with 0,4 m hose and coupling

Characteristics

› for quick and clean “off-site“ filling of centralized lubrication systems for trucks, construction and agricultural machinery

› suitable for standard 500 cm 3 (17 oz) / 400 g

(14 oz) grease cartridges (DIN 1284)

› protection cap

› made of zinc-plated precision steel, robust and durable

› with special rubber packing for 400 g (14 oz) grease cartridges

› extra-large piston knob for safe handling

Filler adaptor for ﬁller gun

FPZ

40154

Professional manual ﬁller pumps for grease guns

› suitable for greases up to consistency class NLGI 2 (also soft greases, biological lubricants and long-time greases with adhesive properties)

› for all commercial grease kegs

› clean, economic, air-free refilling

Manual ﬁller pumps

FG plus

08251

Manual ﬁller pumps

FG plus mobile

40390

08053 FG plus 5 follower plate Ø 171 – 200 mm

08101 FG plus 10 follower plate Ø 215 – 230 mm

40369 FG plus 12.5 follower plate Ø 215 – 266 mm

08151 FG plus 15/18 follower plate Ø 255 – 282 mm

08201 FG plus 20 follower plate Ø 275 – 300 mm

08251 FG plus 25 follower plate Ø 300 – 335 mm

08501 FG plus 50 follower plate Ø 355 – 387 mm

40530 FG plus 200 follower plate Ø 545 – 586 mm

Characteristics

› improved suction capacity by a longer lift of stroke and increased suction and valve openings

› solid and wear resisting by reinforced steel lever

› complete emptying of grease keg due to special follower plate

› dust cover and filler tube for European standard grease guns

› suction tube diam. 40 mm

› output approx. 50 cm

/stroke

40387 FG plus 10 mobile

40388 FG plus 15/18 mobile

40389 FG plus 20 mobile

40390 FG plus 25 mobile

40392 FG plus 50 mobile

Characteristics

› improved suction capacity by a longer lift of stroke and increased suction and valve openings

› solid and wear resisting by reinforced steel lever

› complete emptying of grease keg due to special follower plate´

› dust cover and filler tube for European standard grease guns

› suction tube diam. 40 mm

› output approx. 50 cm 3 /stroke

› with trolley

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 27

Accessories for ﬁller pumps

“Serie FG plus”

› filling adaptors

› filling plates

Filler tube adaptor for American standard grease guns

40548

Filler plate

11101

Filling adaptor for screw-in catridges

40542

40548 Filler tube adaptor

with chain and protection cap for

American standard grease guns

Characteristics

› makes your filler pump not only compatible to

European standard grease guns, but also to

American standard grease guns

› safely stored in rubber cap when not in use

11101 Filler plate 150

› attachment plate for FG plus

› for professional push-type grease guns and professional one-hand grease guns “PEP 100”

40699 FG/PAT 100

for 100 g screw-in catridges

40542 FG/PAT 500

for 500 g screw-in catridges

Characteristics

› helps avoiding waste due to refilling

› fast, clean, without air pockets

› cost-saving

› easy handling

28 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional manual ﬁller pumps for

bearings

Accessories for ﬁller pumps

“Serie FGL plus”

Manual ﬁller pumps FGL plus

40427

Bearing plate

11102

40427 FGL plus 20

40435 FGL plus 50

› improved suction capacity by a longer lift of stroke and increased suction and valve openings

› solid and wear resisting by reinforced steel lever

› clean, economic, air-free refilling

› complete emptying of grease keg due to special follower plate

› with dust cover and filler tube with bearing plate

› for bearings up to 18 cm outer diameter, minimum inner diameter 1,5 cm

› suction tube diam. 40 mm

› for all commercial grease kegs

› suitable for greases up to consistency class

NLGI 2 (also soft greases)

› output approx. 50 cm 3 /stroke (1,7 oz)

Delivery content without bucket.

11102 Bearing plate

Characteristics

› wheel bearing filling device for clean and quick refilling of roller bearings up to 18 cm outer diameter, minimum inner diameter

1,5 cm

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 29

Trolleys for

ﬁller pumps and

greasing units

› steel frame, powder coated

› floor open or closed

Trolleys without accessories

431001 / 431000 / 81043

431001 Trolley for 50 kg / 50 – 60 l kegs,

ﬂoor open, with 2 wheels and two height-adjustable hooks

431000 Trolley for 50 kg / 50 – 60 l kegs,

ﬂoor open, with 4 wheels and two height-adjustable hooks

81043 Trolley for 10 – 50 kg / 10 – 60 l kegs,

ﬂoor closed, with 2 wheels and height-adjustable pump holder

432000 Trolley for 185 kg / 200 l barrels,

ﬂoor open, with 2 tyred wheels in front and one wheel with rear brake

432100 Drum trolley for 200 l barrels

with 2 wheels

81222 Drum dolly for 60 / 200 l barrels

made of steel, with 4 wheels, load capacity per wheel min. 75 kg (total 300 kg)

Delivery content without barrel.

Trolleys with accessories

432814 / 40491

432814 Trolley for 185 kg / 200 l barrels, ﬂoor closed, with 2 tyred wheels in front and one swivelling rubber wheel with rear brake

40491 Trolley for 185 kg / 200 l barrels, ﬂoor closed, with 2 tyred wheels in front and 2 swivelling rubber wheels with rear brake

30 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Accessories for professional lever grease guns

› grease packs and catridges

› extension pipes and hoses

› adaptors

› snap-on kit

› filler nipple

60 g (2,1 oz) grease cartridge and grease pack

04082 / 04085

100 g (3,5 oz) screw-in grease cartridge

40144

04082 Grease pack GP 1

04085 Grease cartridge PAT 60

› 60 g (2,1 oz) grease cartridge and grease pack

› filled with lithium base multi-purpose grease, consistency class NLGI 2

› for clean and quick filling of professional push-type grease guns “F 60” and “K 60”

40144 Grease cartridge PAT 100

ﬁlled with multi-purpose grease

40357 Reﬁll set with 4 units of PAT 100

› 100 g (3,5 oz) screw-in cartridge

› filled with lithium base grease, consistency class NLGI 2

› for clean and quick filling of professional one-hand grease guns “PEP 200” and push-type grease guns “K 100”

Screw-in cartridge PAT 500

82049

400 g (14 oz) standard grease cartridge (DIN 1284)

01901

01901 Grease cartridge PAT 400

81908 Grease cartridge PAT 400 EP2

81093 Grease catridge PAT 400 graphite

› filled with lithium base multi-purpose grease, consistency class NLGI 2

› suitable for

- lever grease guns “X-TRA 701”

- lever grease guns “X-TRA 600”

- lever grease guns “X-TRA 709”

- lever grease guns “Variomatic” special

- one-hand grease guns “PEP 500”

- pneumatic grease guns “DFP 500”

- rechargeable grease guns “AFP 500”

Econo plus

82049 Screw-in cartridge PAT 500

Characteristics

› 500 g (17,5 oz) screw-in cartridge, suitable for

- Professional two-hand grease gun PZP

- Professional one-hand grease gun PEP 500

VARIO PAT

- Battery grease gun AFP 500 PAT

› filled with lithium base multiple purpose grease, consistency class NLGI 2

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 31

Accessories for professional lever grease guns

› grease packs and catridges

› extension pipes and hoses

› adaptors

› snap-on kit

› filler nipple

Bent extension pipes with nozzle

02007 / 02004 / 02002

Straight extension pipes with nozzle

02014 / 02006 / 02003

Extension pipes with nozzle and quick coupler

11501 / 11502 / 11503 / 11504 /

11505 / 40201

02007 103/M

with 4-jaw Proﬁ-nozzle (tested by DLG)

02037 103/BSP

with 4-jaw Proﬁ-nozzle

02004 102/M

with pointed nozzle

02034 102/BSP

with pointed nozzle

02002 101/M

with all-purpose nozzle

02032 101/BSP

with all-purpose nozzle

Characteristics

› 150 mm (6 inch)

Bent extension pipes without nozzle

40132 / 40131

40132 150/M, bent

40131 150/BSP, bent

02014 103/M

with 4-jaw Proﬁ-nozzle (tested by DLG)

02042 103/BSP

with 4-jaw Proﬁ-nozzle

40518 103/NPT

with 4-jaw Proﬁ-nozzle

02006 102/M

with pointed nozzle

02036 102/BSP

with pointed nozzle

02003 101/M

with all-purpose nozzle

02033 101/BSP

with all-purpose nozzle

Characteristics

› straight, 150 mm (6 inch)

Straight extension pipes without nozzle

40001 / 40002 / 40517

11501 2010 with all-purpose nozzle

11502 2020 with pointed nozzle

11503 2060 with cardan and propeller shaft nozzle

40201 SWK with double-nozzle for hydraulic and cup- shaped grease ﬁttings

11504 2070/M 1 with hook-on coupler for standard button-head grease ﬁttings ø 16 mm

40316 2070/M 1 with hook-on coupler for standard button-head grease ﬁttings ø 16 mm,

8 mm sealing cone

11505 2070/M 22 with hook-on coupler for giant button-head grease ﬁttings ø 22 mm

40378 2070/M22 with 150/M, bent

with hook-on coupler for standard button-head grease ﬁttings ø 22 mm, 6 mm sealing cone

40508 2070/M22 with 150/M, bent

with hook-on coupler for standard button-head grease ﬁttings ø 22 mm, 8 mm sealing cone

41283 2070/M22 with 60/M, bent

with hook-on coupler for standard button-head grease ﬁttings ø 22 mm, 4 mm sealing cone

41284 2070/M22 with 60/M, straight

with hook-on coupler for standard button-head grease ﬁttings ø 22 mm, 8 mm sealing cone

40701 2070/M22 with 60/M, bent

with hook-on coupler for standard button-head grease ﬁttings ø 22 mm, 8 mm sealing cone

40001 150/M, straight

40002 150/BSP, straight

40517 150/NPT, straight

Characteristics

› fast change of accessory

› no unscrewing required

32 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Adaptors with needle nozzles

80986 / 80987

Adaptors with needle nozzles and quick coupler

80643 / 80714 / 80618 / 80619

Adaptor set

40729

80986 Adaptor

with needle nozzle (35,5 mm, ø 10 mm) and rubber tip 1/8" BSP, total length 50 mm

80987 Adaptor

with needle nozzle (35,5 mm, ø 4 mm)

1/8" BSP, total length 60 mm

Adaptors with needle nozzles and quick coupler

81003

81003 Adaptor

with injector needle nozzle (40 mm, ø 1,6 mm) and quick coupler, total length 54 mm, incl. protection sleeve

80643 Adaptor

with injector needle nozzle (23 mm, ø 2 mm) and quick coupler, total length 60 mm

80714 Adaptor

with injector needle nozzle (45 mm, ø 1,4 mm) and quick coupler, total length 60 mm

80618 Adaptor

with needle nozzle (21 mm, ø 6 mm) and quick coupler, total length 51 mm

80619 Adaptor

with needle nozzle (21 mm, ø 6 mm), angled

45° and quick coupler, total length 51 mm

40729 Adaptor set

Characteristics

› consisting of:

- 4-jaw Profi-nozzle for hydraulic grease fittings

- pointed nozzle 23/M for hydraulic grease fittings

- all-purpose nozzle 36/M for hydraulic grease fittings

› connecting thread M = M 10 x 1

Accessory set M 10 x 1

41271

41271 Accessory set M 10 x 1

Characteristics

› consistign of:

- 4-jaw Profi-nozzle 120/M

- pointed nozzle M 10 x 1 with leather seal

- all-purpose nozzle M 10 x 1 with leather seal

- extension pipe 150/M, 150 mm (6 inch)

length, bent

- high-pressure rubber hose KS 300, 300 mm

(12 inch) lenght, bursting pressure 1.000 bar

(12.500 psi)

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 33

Accessories for professional lever grease guns

› grease packs and catridges

› extension pipes and hoses

› adaptors

› snap-on kit

› filler nipple

Safety high-pressure rubber hoses without nozzle

02601 / 02607 / 80487

Safety high-pressure rubber hoses with nozzle

02501 / 40347 / 02506 / 02508

Safety high-pressure rubber hoses with nozzle

02503 / 40441 / 02510 / 02512

300 mm / 12 inch

02601 PZ 300/M

02631 PZ 300/BSP

81605 PZ 300/NPT

500 mm / 20 inch

02607 PZ 500/M

02637 PZ 500/BSP

81606 PZ 500/NPT

1.000 mm / 39 inch

80487 PZ 1000/M

80488 PZ 1000/BSP

Characteristics

› high operational safety, bursting pressure

1.600 bar (23.200 psi)

› double-ply wire braid hose with identification

› safety tested according to DIN 1283

(M 10 x 1)

› very flexible

› diameter 13 mm

300 mm / 12 inch

02501 110/M with 4-jaw Proﬁ-nozzle

(tested by DLG)

02531 110/BSP with 4-jaw Proﬁ-nozzle

40734 110/NPT with 4-jaw Proﬁ-nozzle

40347 114/M with hook-on coupler M 4 for button-head grease ﬁttings ø 10 mm

40440 114/BSP with hook-on coupler M 4 for button-head grease ﬁttings ø 10 mm

02506 112/M with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02536 112/BSP with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02508 1120/M with hook-on coupler M 22 for button-head grease ﬁttings ø 22 mm

02538 1120/BSP with hook-on coupler M 22 for button-head grease ﬁttings ø 22 mm

Characteristics

› high operational safety, bursting pressure

1.600 bar (23.200 psi)

› double-ply wire braid hose with identification

› safety tested according to DIN 1283

(M 10 x 1)

› very flexible

› diameter 13 mm

500 mm / 20 inch

02503 111/M with 4-jaw Proﬁ-nozzle

(tested by DLG)

02533 111/BSP with 4-jaw Proﬁ-nozzle

40441 115/M with hook-on coupler M 4 for button-head grease ﬁttings ø 10 mm

40442 115/BSP with hook-on coupler M 4 for button-head grease ﬁttings ø 10 mm

02510 113/M with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02540 113/BSP with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02512 1130/M with hook-on coupler M 22 for button-head grease ﬁttings ø 22 mm

02542 1130/BSP with hook-on coupler M 22 for button-head grease ﬁttings ø 22 mm

1.000 mm / 39 inch

02505 1110/M with 4-jaw Proﬁ-nozzle

40318 1110/BSP with 4-jaw Proﬁ-nozzle

Characteristics

› high operational safety, bursting pressure

1.600 bar (23.200 psi)

› double-ply wire braid hose with identiﬁcation

› safety tested according to DIN 1283 (M 10 x 1)

› very ﬂexible

› diameter 13 mm

34 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Safety high-pressure rubber hoses with nozzle and quick coupler

02423 / 02425

High-pressure hoses without nozzle

02801 / 02803

High-pressure hoses with nozzle

02701 / 02703

300 mm / 12 inch

02423 2200 with 4-jaw Proﬁ-nozzle

02425 2210/M 1 with hook-on coupler

M 10 x 1 for standard button-head grease ﬁttings

ø 16 mm

02426 2210/M 22 with hook-on coupler

M 22 for giant button-head grease ﬁttings

ø 22 mm

500 mm/20 inch

40823 2500 with 4-jaw Proﬁ-nozzle and hook-on coupler M 10 x 1

Characteristics

› fast change of accessory

› no unscrewing required

› high operational safety, bursting pressure

1.600 bar (23.200 psi)

› double-ply wire braid rubber hose

› very flexible

› diameter 13 mm

300 mm / 12 inch

02801 KS 300/M

02831 KS 300/BSP

81397 KS 300/NPT

500 mm / 20 inch

02803 KS 500/M

02833 KS 500/BSP

82061 KS 500/NPT

1.000 mm / 39 inch

81295 KS 1000/M

Characteristics

› bursting pressure 1.000 bar (14.500 psi)

› double-ply textile thermoplastic hose

› identification according to DIN 1283

(M 10 x 1)

› diameter 10 mm

300 mm / 12 inch

02701 910/M with 4-jaw Proﬁ-nozzle

02731 910/BSP with 4-jaw Proﬁ-nozzle

40628 910/NPT with 4-jaw Proﬁ-nozzle

02738 9120/R with hook-on coupler M 22

500 mm / 20 inch

02703 911/M with 4-jaw Proﬁ-nozzle

02733 911/BSP with 4-jaw Proﬁ-nozzle

40475 9130/R with hook-on coupler M 22

Characteristics

› bursting pressure 1.000 bar (14.500 psi)

› double-ply textile braid polyethylene hose

› identification according to DIN 1283

(M 10 x 1)

› diameter 10 mm

High-pressure hoses without nozzle Econo plus

81944

Swivel ﬁtting

02640

300 mm / 12 inch

81944 KS 300/M Econo plus

81943 KS 300/BSP Econo plus 02640 640/M

02641 640/BSP

Characteristics

› for safety high-pressure rubber hoses and high-pressure hoses

› turning around longitudinal axle

Characteristics

› bursting pressure 1.000 bar (14.500 psi)

› single-ply textile braid polyethylene hose

› identification according to DIN 1283 (M 10 x 1)

› diameter 9,0 mm

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 35

Accessories for professional lever grease guns

› grease packs and catridges

› extension pipes and hoses

› adaptors

› snap-on kit

› filler nipple

Professional snap-on kit SWS

07991

Accessories set trade / accessories set industry

41272 / 41273

07991 SWS

Characteristics

› in solid plastic box with oil-proof insert

› content:

1 x extension pipe 103/M, straight, with 4-jaw Profi-nozzle

2 x 4-jaw Profi-nozzles 120/M

1 x snap-on high-pressure rubber hose 2200

1 x snap-on extension pipe with hook-on coupler 2070/M 1

1 x snap-on extension pipe with double nozzle

1 x adaptor with 1/8" BSP (f) and M 10 x 1

(m) thread

41272 Accessories set trade

content 75 Proﬁ-nozzles, 11 different types (see table)

41273 Accessories set industry

content 33 Proﬁ-nozzles, 8 different types (see table)

CONTENT

07122 4-jaw Proﬁ-nozzle 120/M

81486 4-jaw Proﬁ-nozzle 120/M with ball check valve

07131 angled nozzle 90°/M

07402 hook-on coupler 121/M

07422 hook-on coupler 12/M

07412 hook-on coupler 1210/M

07012 pointed nozzle 23/M 10 x 1

07042 all-purpose nozzle 36 / M 10 x 1

02640 swivel ﬁtting 640/M

80522 quick coupler SWK/M

65001 ﬁlling nipple 929/M

TRADE

INDUSTRY

36 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

4-jaw Proﬁ-nozzles

07122 / 07131

Other nozzles

07012 / 07042

Hook-on couplers

07422 / 80451 / 80644

07122 120/M

07123 120/BSP

07124 120/NPT

07131 Angled nozzle 90°/M

40459 Angled nozzle 90°/BSP

Characteristics

› for lubricating hydraulic grease fittings

(DIN 71412)

› 4 jaws turned out of a single piece of highly elastic quality steel forming a circle to ensure precise coupling and consistent jaw alignment with every use

› durable elastic interior plug and high-performance spring for leak-proof operation

› case-hardened steel jaws and upper part of coupler for less wear and more durability

› working pressure 400 bar (5.800 psi)

› bursting pressure 1.600 bar (23.200 psi)

As accessories for push-type grease guns series F (except F60), FO and T

07011 23/M 9x1 pointed nozzle

for cup-shaped grease ﬁttings

80366 23/M 9x1 extra-pointed nozzle

for e.g. sprocket noses on saw chains

07041 36/M 9x1 all-purpose nozzle

for hydraulic grease ﬁttings

As accessories for all other grease guns

07012 23/M 10 x 1 pointed nozzle

for cup-shaped grease ﬁttings

07013 23 1/8" BSP pointed nozzle

for cup-shaped grease ﬁttings

07042 36/M 10 x 1 all-purpose nozzle

for hydraulic grease ﬁttings

07043 36 1/8" BSP all-purpose nozzle

for hydraulic grease ﬁttings

07422 12/M hook-on coupler for button-head grease ﬁttings M4, ø 10 mm

07423 12/BSP hook-on coupler for button-head grease ﬁttings M4, ø 10 mm

07402 121/M hook-on coupler for standard button-head grease ﬁttings M1, ø 16 mm

07403 121/BSP hook-on coupler for standard button-head grease ﬁttings M1,

ø 16 mm

80451 122/BSP hook-on coupler, turnable, for giant button-head grease ﬁttings M16, ø 16 mm

07412 1210/M hook-on coupler for giant button-head grease ﬁttings M22, ø 22 mm, conical sealing nipple 8 mm

07413 1210/BSP hook-on coupler for giant button-head grease ﬁttings M22, ø 22 mm, conical sealing nipple 8 mm

80644 1210/BSP hook-on coupler for giant button-head grease ﬁttings M22, ø 22 mm, conical sealing nipple 4 mm

4-jaw Proﬁ-nozzle with check valve

81486 120/M with ball check valve

121020 120/NPT with ball check valve

81835 1/8" BSP with check valve

81836 NPT with check valve

Characteristics

› for lubricating hydraulic grease fittings

(DIN 71412)

› spring-loaded check valve

› avoid flowing-back of grease

Filler nipple for professional lever grease guns

65001

Grease gun holder

80707

65001 Filler nipple 929/M with spring

› as spare part for “X-TRA 701”, “X-TRA 600”,

“PEP 500”, “DFP 500” and “DFP 1000”

› thread M = M 10 x 1

80707 Grease gun holder

› for wall mounting of grease guns

› corrosion-resistant finish

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 37

Accesories for ﬁller pumps and greasing units

› greasing hoses and hose reels

› greasing pistols

› extension pipes

› flow meters

› follower plates and dust covers

› maintenance unit

Safety greasing hoses for HDS and WH

11374 / 40008

Automatic Single arm hose reels for grease

506300 / 507300

11374 HDS 570 4 m

11376 HDS 570 7 m

11377 HDS 570 10 m

Characteristics

› bursting pressure 1.600 bar (23.200 psi)

› working pressure 400 bar (5.800 psi)

› increased inside diameter, nom. diam. 6

› connecting thread to pistol and pump 1/4"

BSP = G 1/4" (f)

For WH-units please order hose adaptor:

40008 Hose adaptor WH

connecting thread 1/4" BSP = G 1/4" (f) / M 16 x 1,25 (f)

Open version

506300 Automatic Single arm hose reel

with 10 m delivery hose, nom. diam. 1/4" BSP = G 1/4"

506321 Automatic Single arm hose reel

with 15 m delivery hose, nom. diam. 3/8" BSP = G 3/8"

Compact version

507300 Automatic Single arm hose reel

with 10 m delivery hose, nom. diam. 1/4" BSP = G 1/4"

507321 Automatic Single arm hose reel

with 15 m delivery hose, nom. diam. 3/8" BSP = G 3/8"

Characteristics

› professional Single arm automatic hose reel, open or cased version, made of corrosion-proof

die-cast aluminium

› friction-free pressure-balanced swivels for all applications contribute to a smooth operation when pulling the entire hose length

› full 1/2" port swivel provides unrestricted flow for maximum delivery

› swivel and shaft are nickel coated for a wide fluid compatibility

› spool mounted on two ball bearings to reduce frictions and to assure a stable structure with no wobbling

› tangent outlet with six rollers for a smooth operation in any mounting position

› dual ratchet teeth provide positive and secure hose latch

› fully accessible swivel and latch mechanism for service eliminate the need to dismount the hose reel for service

› positionable arm for best operation in any mounting position: wall, ceiling, floor or trolley

› inlet thread 1/4" BSP (f/m) or 3/8" BSP (f/m), outlet thread 1/4" BSP (m)

› working pressure 350 bar / 5.000 psi (1/4" hose), 290 bar / 4.000 psi (3/8" hose)

› double-ply wire-braid greasing hose nom. diam. 1/4" BSP = G 1/4" and connecting hose

38 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Greasing pistol HDS

11304

11304 Greasing pistol HDS

with extension pipe 103/M

40373 Greasing pistol HDS 550

with extension pipe 103/M and Z-swivel

Characteristics

› ergonomic and robust constructed

› continuous flow of grease by actuating the lever

› connecting thread 1/4" BSP = G 1/4"(M)

Extension pipes and hoses with nozzle for HDS and WH

02007 / 02501 / 02701

Professional z-swivel for

greasing pistols

414300400

02007 103/M Extension pipe with 4-jaw Proﬁ-nozzle

02701 910/M High-pressure hose with 4-jaw Proﬁ-nozzle

02501 110/M Safety high-pressure rubber hose with 4-jaw Proﬁ-nozzle

Characteristics

› connecting thread M 10 x 1

414300400 Z-swivel

80185 Double nipple

1/4" BSP = G 1/4"

Characteristics

› connecting thread 1/4" BSP = G 1/4" (m)

› with ball bearing for smooth operation also

under pressure

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 39

Accesories for ﬁller pumps and greasing units

› greasing hoses and hose reels

› greasing pistols

› extension pipes

› flow meters

› follower plates and dust covers

› maintenance unit

Electronic grease ﬂow meter

40248 / 411100

Maintenance unit for HDS,

DPZ-2

40888

Follower plate adaptor

40397

411100 Electronic in-line grease ﬂow meter

for assembly G1/8" (f/f)

40783 Electronic grease ﬂow meter

with extension pipe and 4-jaw Proﬁ-nozzle

103/BSP and with full swivel

40248 Electronic grease ﬂow meter

with safety high-pressure rubber hose and

4-jaw Proﬁ-nozzle 110/BSP and with full swivel

Characteristics

› exact control of dispensed grease in g

› resettable LCD display, 4 digits up to 9.999 g

› display for total delivery in kg up to

999.999 kg for long term control of grease consumption

› working pressure 500 bar (7.250 psi)

› bursting pressure 1.000 bar (14.500 psi)

› maximum output up to 2 kg/min (70 oz)

› measuring accuracy +/– 3%

› easy on-site recalibration

› connecting thread 1/8" BSP = G 1/8" (f/f)

› runs with two standard batteries

40888 Maintenance unit

Characteristics

› protects against wearing

› consisting of water separator, pressure reducer and oiler

40396 FD-A 28

ø 28 mm suction tube diameter

40397 FD-A 30

ø 30 mm suction tube diameter

40398 FD-A 32

ø 32 mm suction tube diameter

40399 FD-A 35

ø 35 mm suction tube diameter

40 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Dust covers SD for ﬁller pumps and manual greasing units

40918

Suitable for following grease keg

outside diameters:

40916 SD 5 ø 160 mm – 212 mm

40917 SD 10 – 20 ø 240 mm – 300 mm

40918 SD 25 ø 312 mm – 342 mm

40919 SD 50 ø 365 mm – 415 mm

40920 SD 200 ø 570 mm – 625 mm

Dust covers SDF for ﬁller pumps with trolley

80018

Follower plates FD for ﬁller pumps

80007

Suitable for following grease keg

outside diameters:

80017 SDF 10 – 20 ø 240 mm – 310 mm

80018 SDF 25 ø 312 mm – 342 mm

80019 SDF 50 ø 365 mm – 415 mm

80020 SDF 200 ø 570 mm – 625 mm

Suitable for following grease keg inside diameters:

80003 FD 5 for 5 kg grease kegs

ø 171 mm – 200 mm

80004 FD 10 for 10 kg grease kegs

ø 215 mm – 236 mm

80005 FD 15/18 special 1 for 15/18 kg grease kegs

ø 230 mm – 266 mm

80006 FD 15 for 15 kg grease kegs

ø 255 mm – 282 mm

80007 FD 20 special 1 for 20 kg grease kegs

ø 275 mm – 300 mm

80010 FD 20 – 25 for 20 / 25 kg grease kegs

ø 300 mm – 341 mm

80008 FD 25 special 1 for 25 kg grease kegs

ø 285 mm – 332 mm

80009 FD 40 special 1 for 40 kg grease kegs

ø 285 mm – 356 mm

80011 FD 50 special 1 for 50 kg grease kegs

ø 315 mm – 352 mm

80013 FD 50 for 50 kg grease kegs

ø 355 mm – 387 mm

80014 FD 50 special 3 for 50 kg grease kegs

ø 385 mm – 410 mm

80015 FD 200 for 180 kg grease barrels

ø 560 mm – 586 mm

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 41

Accesories for ﬁller pumps and greasing units

› greasing hoses and hose reels

› greasing pistols

› extension pipes

› flow meters

› follower plates and dust covers

› maintenance unit

Dust cover for air-operated greasing units PM

418002

Suitable for following grease keg outside diameters:

418013 for 12,5 – 18 kg grease kegs

ø 265 mm – 310 mm

418002 for 20 kg grease kegs

ø 285 mm – 330 mm

418004 for 50 kg grease kegs

ø 360 mm – 405 mm

418006 for 180 kg grease barrels

ø 565 mm – 610 mm

418026 for 180 kg grease barrels

ø 580 mm – 620 mm

418016 for 50 kg grease barrels

ø 350 mm – 395 mm

360125 bracket for grease guns for dust cover PM

Follower plates for air-operated greasing units PM

417005

Suitable for following grease keg inside diameters:

417006 for 12,5 kg grease kegs

ø 230 mm – 260 mm

417001 for 18 kg grease kegs

ø 260 mm – 298 mm

417005 for 20 kg grease kegs

ø 300 mm – 340 mm

80012 for 25 kg grease kegs

ø 310 mm – 332 mm

417002 for 50 kg grease kegs

ø 330 mm – 370 mm

417003 for 50 kg grease kegs

ø 360 mm – 406 mm

417004 for 180 kg grease barrels

ø 550 mm – 590 mm

42 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› manufactured of precision steel, case hardened, zinc plated and blue (yellow) passivated

(chrome III)

Hydraulic grease ﬁttings (drive-ﬁt type) according to DIN 71412 manufactured of precision steel, case hardened, zinc plated, blue (yellow) passivated (chrome III)

Straight 180° – type A

12110

Angled 45° – type B

(hexagon type)

81027

80690 H1 a 5

12106 H1 a 6

12108 H1 a 8

12110 H1 a 10

81966 H1 a 3/16"

12118 H1 a 1/4"

Special types

81892 H1 a 6, collar depth 8 mm

81648 H1 a 6, yellow passivated (chrome III), for packer

81894 H1 a 6, shaft length 9,5 mm

81026 H2 a 6

81027 H2 a 8

81028 H2 a 10

Angled 90° – type C

(hexagon type)

81019

82143 H3 a 6

81061 H3 a 8

81019 H3 a 10

Angled 45° – type B

(square type)

12208

12206 H2 a 6

12208 H2 a 8

Angled 90° – type C

(square type)

12308

12306 H3 a 6

12308 H3 a 8

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 43

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› manufactured of precision steel, case hardened, zinc plated and blue (yellow) passivated

(chrome III)

Hydraulic grease ﬁttings according to DIN 71412 metric, with conical thread manufactured of precision steel, case hardened, zinc plated, blue (yellow) passivated (chrome III)

Straight 180° – type A

12151

12119 H1 M 5 x 0,8

80909 H1 M 6 x 0,75

12112 H1 M 6 x 1

81097 H1 M 8 x 0,75

12131 H1 M 8 x 1

12133 H1 M 8 x 1,25

12151 H1 M 10 x 1

81197 H1 M 10 x 1,25

12152 H1 M 10 x 1,5

81272 H1 M 12 x 1

80634 H1 M 12 x 1,25

12172 H1 M 12 x 1,5

80702 H1 M 12 x 1,75

80692 H1 M 14 x 1,5

81216 H1 M 16 x 1,5

Special types

81867 H1 M 5 x 0,5, thread length 2,8 mm

81056 H1 M 5 x 0,8, thread length 2,6 mm, cylindrical thread, not case hardened

81007 H1 M 5 x 0,8, low opening pressure type, with shortened spring, not case hardened

80978 H1 M 6 x 1, cylindrical thread, nickel plated

12115 H1 M 6 x 1, cylindrical thread, thread length 8 mm

80550 H1 M 6 x 1, cylindrical thread, ﬂush type, thread length 8 mm

81577 H1 M 6 x 1, cylindrical thread, ﬂush type, thread length 8 mm, not case hardened

80902 H1 M 6 x 1, cylindrical thread, nickel plated, thread length 8,5 mm

81005 H1 M 6 x 1, unmounted (without ball and spring)

81015 H1 M 7 x 1, hexagon 9 mm

81569 H1 M 7 x 1, hexagon 9 mm (without ball and spring)

81748 H1 M 7 x 1, hexagon 7 mm (without ball and spring)

81854 H1 M 8 x 1, yellow passivated (chrome III)

12132 H1 M 8 x 1, thread length 4 mm

80416 H1 M 8 x 1, low opening pressure type, with shortened spring

81301 H1 M 8 x 1, hexagon 11 mm

40834 H1 M 8 x 1, with 30 mm-prolongation

81855 H1 M 8 x 1,25, yellow passivated (chrome III)

81861 H1 M 8 x 1,25, hexagon 10 mm

81843 H1 M 10 x 1, yellow passivated (chrome III)

81994 H1 M 10 x 1, with 80 mm-prolongation, tube type

40895 H1 M 10 x 1, with 22 mm-prolongation

40896 H1 M 10 x 1, with 36 mm-prolongation

40835 H1 M 10 x 1, with 50 mm-prolongation

80194 H1 M 10 x 1, total length 59 mm

81859 H1 M 10 x 1,5, yellow passivated (chrome III)

81118 H1 M 6 x 0,75, cylindrical thread

81677 H1 M 6 x 1, yellow passivated (chrome III)

81656 H1 M 6 x 1, thread length 4 mm, yellow passivated (chrome III)

12114 H1 M 6 x 1, total length 23 mm

81008 H1 M 6 x 1, total length 28 mm

81004 H1 M 6 x 1, low opening pressure type, with shortened spring

81731 H1 M 6 x 1, hexagon 9 mm

81893 H1 M 6 x 1, hexagon 9 mm, collar depth 8 mm

80379 H1 M 6 x 1, with 32 mm-prolongation

12113 H1 M 6 x 1, shaft length 3,5 mm

81794 H1 M 6 x 1, hexagon 11, shaft length 5 mm

80681 H1 M 6 x 1, cylindrical thread

Grease ﬁttings – extensions

81758 M 6 x 1, thread length 32 mm

81759 M 8 x 1, thread length 30 mm

81760 M 10 x 1, thread length 50 mm

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Angled 45° – type B

(hexagon type)

12251

81336 H2 M 6 x 1

80904 H2 M 6 x 1, yellow passivated

(chrome III)

81202 H2 M 7 x 1

81338 H2 M 8 x 1

12232 H2 M 8 x 1, yellow passivated

(chrome III)

81611 H2 M 8 x 1,25

12234 H2 M 8 x 1,25, yellow passivated

(chrome III)

12251 H2 M 10 x 1

81857 H2 M 10 x 1, yellow passivated

(chrome III)

81191 H2 M 10 x 1,25

12252 H2 M 10 x 1,5

81205 H2 M 12 x 1

81089 H2 M 12 x 1,5

80703 H2 M 12 x 1,75

Angled 45° – type B

(square type)

81411

81411 H2 M5 x 0,8

81087 H2 M 6 x 0,75

12212 H2 M 6 x 1

12231 H2 M 8 x 1

40521 H2 M 8 x 1, yellow passivated

(chrome III)

12233 H2 M 8 x 1,25

12258 H2 M 10 x 1

Angled 30° / 67,5° / double-head – type B

80667

81752 H2 M 8 x 1 67,5°, hexagon type

81764 H2 M 10 x 1 67,5°, hexagon type

40864 H2 M 8 x 1 67,5°, square type

80667 H2 M 8 x 1 double-head, hexagon type, total length 20 mm

Angled 90° – type C

(hexagon type)

12351

Angled 90° – type C

(square type)

81412

80919 H3 M 6 x 0,75

81337 H3 M 6 x 1

80728 H3 M 6 x 1, yellow passivated

(chrome III)

81203 H3 M 7 x 1

80127 H3 M 8 x 0,75

81339 H3 M 8 x 1

12322 H3 M 8 x 1, yellow passivated

(chrome III)

81612 H3 M 8 x 1,25

12334 H3 M 8 x 1,25, yellow passivated

(chrome III)

81412 H3 M 5 x 0,8

12312 H3 M 6 x 1

12331 H3 M 8 x 1

12332 H3 M 8 x 1, yellow chromated

12333 H3 M 8 x 1,25

12358 H3 M 10 x 1

12351 H3 M 10 x 1

81385 H3 M 10 x 1, yellow passivated

(chrome III)

81204 H3 M 10 x 1,25

12352 H3 M 10 x 1,5

81273 H3 M 12 x 1

81090 H3 M 12 x 1,5

80704 H3 M 12 x 1,75

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 45

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› manufactured of precision steel, case hardened, zinc plated and blue (yellow) passivated

(chrome III)

Hydraulic grease ﬁttings according to DIN 71412 BSP (British Standard Pipe) with conical thread manufactured of precision steel, case hardened, zinc plated, blue (yellow) passivated (chrome III)

Straight 180° – type A

12153

Angled 45° – type B

(hexagon type)

12153

12153 H1 1/8" BSP

12171 H1 1/4" BSP

12181 H1 3/8" BSP

81918 H1 1/2" BSP

Special types

81856 H1 1/8" BSP, yellow passivated

(chrome III)

81810 H1 1/8" BSP, nickel plated

80688 H1 1/8" BSP, thread length 7 mm, not case hardened

81763 H1 1/8" BSP, thread length 7,6 mm, lowered ball seating

81341 H1 1/4" BSP, thread length 7,6 mm, yellow passivated (chrome III)

12253 H2 1/8" BSP

81858 H2 1/8" BSP, yellow passivated

(chrome III)

81811 H2 1/8" BSP, nickel plated

81864 H2 1/4" BSP

Angled 90° – type C

(hexagon type)

12371

12353 H3 1/8" BSP

12371 H3 1/4" BSP

Angled 67,5° – type B

81135

81135 H2 1/8" BSP 67,5°

Angled 90° – type C

(square type)

12381

12381 H3 3/8" BSP

46 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Hydraulic grease ﬁttings BSF / WWF (British Standard Fine / Whitworth Fine), with cylindrical thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Straight 180° – type A

81968

81968 H1 1/4" – 26 BSF/WWF

81076 H1 5/16" – 22 BSF/WWF

81016 H1 3/8" – 20 BSF/WWF

Angled 45° – type B (hexagon type)

81081

81081 H2 1/4" – 26 BSF/WWF

80139 H2 5/16" – 22 BSF/WWF

Angled 90° – type C (hexagon type)

81080

81080 H3 1/4" – 26 BSF/WWF

Hydraulic grease ﬁttings BSW / WW (British Standard Whitworth / Whitworth), with cylindrical thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Straight 180° – type A

80689

12116 H1 1/4" – 20 BSW/WW

81018 H1 5/16" – 18 BSW/WW

80689 H1 3/8" – 16 BSW/WW

Angled 45° – type B (hexagon type)

81030

81030 H2 5/16" – 18 BSW/WW

Angled 90° – type C (hexagon type)

81037

81037 H3 1/4" – 20 BSW/WW

81032 H3 5/16" – 18 BSW/WW

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 47

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› manufactured of precision steel, case hardened, zinc plated and blue (yellow) passivated

(chrome III)

Hydraulic grease ﬁttings SAE / UNF (Society of Automotive Engineers / Uniﬁed Fine), with conical / cylindrical thread manufactured of precision steel, case hardened, zinc plated, blue (yellow) passivated (chrome III)

Straight 180° – type A

80640

Angled 45° – type B

12256

Angled 90° – type C

(hexagon type)

12317

80640 H1 1/4" – 28 UNF

12117 H1 1/4" – 28 SAE

81045 H1 1/4" – 28 SAE, thread length 4,5 mm

81988 H1 1/4" – 28 SAE, total length

17,5 mm

81791 H1 1/4" – 28 SAE, yellow passivated

(chrome III), total length 17,5 mm

12121 H1 1/4" – 28 SAE, yellow passivated

(chrome III), total length 29 mm

81475 H1 1/4" – 28 SAE, unmounted, without ball and spring

12217 H2 1/4" – 28 SAE, hexagon type, yellow passivated (chrome III)

40543 H2 1/4" – 28 SAE, square type

81034 H2 1/4" – 28 SAE, half round

12218 H2 1/4" – 28 SAE, half round, thread length 7,5 mm, not case hardened

12256 H2 3/8 – 24 SAE, hexagon type

Angled 65° – type B

81951

12155 H1 5/16" – 24 SAE, yellow passivated

(chrome III)

12156 H1 3/8" – 24 SAE, yellow passivated

(chrome III)

81463 H1 1/2" – 20 SAE

12317 H3 1/4" – 28SAE

12355 H3 5/16" – 24 SAE

80838 H3 1/2" – 20 SAE

81951 H2 1/4" – 28 SAE, hexagon type

48 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Hydraulic grease ﬁttings NPT (National Pipe Thread), with conical thread manufactured of precision steel, case hardened, zinc plated, blue (yellow) passivated (chrome III)

Straight 180° – type A

81105

Angled 45° – type B

(hexagon type)

80668

Angled 90° – type C

(hexagon type)

80629

81105 H1 1/8" – 27 NPT

12154 H1 1/8" – 27 NPT, yellow passivated

(chrome III)

81834 H1 1/8" – 27 NPT, yellow passivated

(chrome III), total length 32 mm

81017 H1 1/4" – 18 NPT, yellow passivated

(chrome III)

81022 H1 1/4" – 18 NPT, thread length 11 mm

80668 H2 1/8" – 27 NPT

12254 H2 1/8" – 27 NPT, yellow passivated

(chrome III)

81024 H2 1/4" – 18 NPT

80629 H3 1/8" – 27 NPT

12354 H3 1/8" – 27 NPT, yellow passivated

(chrome III)

81035 H3 1/4" – 18 NPT

81036 H3 1/4" – 18 NPT, half round

Hydraulic grease ﬁttings with self-forming thread according to DIN 71412 manufactured of precision steel, case hardened, zinc plated, yellow (blue) passivated (chrome III)

Straight 180° – type A

12511

Angled 45° – type B

80263

Angled 90° – type C

80273

12511 H1 SFG 6 x 1

80943 H1 SFG 6 x 1, blue passivated

(chrome III)

12512 H1 SFG 8 x 1

12513 H1 SFG 8 x 1, thread length 3,5 mm

12514 H1 SFG 10 x 1

81000 H1 SFG 1/4" – 28 SAE

12521 H2 SFG 6 x 1, square type

81845 H2 SFG 6 x 1, hexagon type

80263 H2 SFG 8 x 1, hexagon type

12522 H2 SFG 8 x 1, square type

12524 H2 SFG 10 x 1, square type

81846 H2 SFG 10 x 1, hexagon type

80273 H3 SFG 6 x 1, hexagon type

12531 H3 SFG 6 x 1, square type

12532 H3 SFG 8 x 1, square type

81847 H3 SFG 8 x 1, hexagon type

12534-H H3 SFG 10 x 1, square type

12534-I

H3 SFG 10 x 1, hexagon type

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 49

ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Hydraulic grease ﬁttings (drive-ﬁt type) according to DIN 71412 manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

80926

80926 H1 a 6

80677 H1 a 8

Hydraulic grease ﬁttings according to DIN 71412 metric, with conical thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

80825

80825 H1 M 5 x 0,8

12612 H1 M 6 x 1

81040 H1 M 6 x 1, cylindrical thread

80867 H1 M 6 x 1, cylindrical thread, thread length 8,5 mm

12613 H1 M 8 x 1

81010 H1 M 8 x 1,25

12614 H1 M 10 x 1

81744 H1 M 10 x 1,5

81095 H1 M 12 x 1,5

Angled 45° – type B

(hexagon type)

12621

12621 H2 M 6 x 1

80541 H2 M 6 x 1, cylindrical thread, thread length 8,5 mm

81831 H2 M 8 x 1

81934 H2 M 8 x 1,25

12624 H2 M 10 x 1

81020 H2 M 10 x 1,5

81842 H2 M 12 x 1

Angled 90° – type C

(hexagon type)

81038

81038 H3 M 6 x 1

81039 H3 M 8 x 1

81428 H3 M 8 x 1,25

12634 H3 M 10 x 1

81031 H3 M 10 x 1,5

50 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Hydraulic grease ﬁttings according to DIN 71412 BSP (British Standard Pipe), with conical thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

12615

Angled 45° – type B

(hexagon type)

12625

Angled 90° – type C

(hexagon type)

12635

12615 H1 1/8" BSP

81234 H1 1/8" BSP, cylindrical thread, thread length 11 mm

12617 H1 1/4" BSP

12625 H2 1/8" BSP

12627 H2 1/4" BSP

12635 H3 1/8" BSP

12637 H3 1/4" BSP

Hydraulic grease ﬁttings BSW / WW (British Standard Whitworth / Whitworth), with cylindrical thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

81516

81516 H1 1/4" – 20 BSW/WW

› manufactured of stainless steel

› material no. 1.4305, AISI 303, A2

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 51

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Hydraulic grease ﬁttings SAE / UNF (Society of Automotive Engineers / Uniﬁed Fine), with conical / cylindrical thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

81754

81754 H1 1/4" – 28 SAE

82010 H1 5/16" – 24 UNF

Angled 90° – type C

(hexagon type)

81756

81756 H3 1/4" – 28 SAE

Hydraulic grease ﬁttings NPT (American Natonal Pipe Taper), with conical thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Straight 180° – type A

81283

81014 H1 1/8" – 27 NPT

81283 H1 1/4" – 18 NPT

Angled 45° – type B

(hexagon type)

81029

81029 H2 1/8" – 27 NPT

Angled 90° – type C

(hexagon type)

81001

81001 H3 1/8" – 27 NPT

52 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Hydraulic grease ﬁttings according to DIN 71412 manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Straight 180° – type A

81910

81910 H1 a 10

› manufactured of acid-proof steel

› material no. 1.4401, AISI 316, A4

Hydraulic grease ﬁttings according to DIN 71412 metric, with conical thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Straight 180° – type A

80869

80869 H1 M 6 x 1

80870 H1 M 8 x 1

80871 H1 M 8 x 1,25

81012 H1 M 10 x 1

81779 H1 M 10 x 1,5

81915 H1 M 12 x 1,5

Angled 45° – type B

(hexagon type)

81869

81869 H2 M 6 x 1

81082 H2 M 8 x 1

81796 H2 M 10 x 1

Angled 90° – type C

(hexagon type)

81608

81608 H3 M 6 x 1

80678 H3 M 8 x 1

80207 H3 M 10 x 1

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 53

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Hydraulic grease ﬁttings according to DIN 71412 BSP (British Standard Pipe), with conical thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Straight 180° – type A

12715

Agled 45° – type B

(hexagon type)

81152

Angled 90° – type C

81452

12715 H1 1/8" BSP

12717 H1 1/4" BSP

81009 H1 3/8" BSP

Hydraulic grease ﬁttings

UNF ( Uniﬁed Fine), with conical / cylindrical thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

81152 H2 1/8" BSP

81042 H2 1/4" BSP

Hydraulic grease ﬁttings NPT

(National Pipe Thread), with conical thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

81452 H3 1/8" BSP, hexagon type

81708 H3 1/4" BSP, square type

Straight 180° – type A

81941

Straight 180° – type A

80188

81941 H1 1/4" – 28 UNF 80188 H1 1/8" – 27 NPT

54 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional

hydraulic grease ﬁttings “Serie H”

› reliability and precision for Original Equipment Manufacturers and after-sales market

› manufactured of brass

Hydraulic grease ﬁttings according to DIN 71412 metric, with conical thread manufactured of brass

Straight 180° – type A

81006

Angled 90° – type C

(hexagon type)

12337

81006 H1 M 6 x 1

12134 H1 M 8 x 1

81713 H1 M 8 x 1,25

81002 H1 M 10 x 1

80246 H1 M 12 x 1,5

Hydraulic grease ﬁttings according to DIN 71412 BSP

(British Standard Pipe), with conical thread manufactured of brass

12337 H3 M 8 x 1

Straight 180° – type A

81066

81066 H1 1/8" BSP

80659 H1 1/8" BSP, nickel plated

80862 H1 3/8" BSP

Accessories for hydraulic grease ﬁttings choice of sizes, yellow or red

Protection caps for grease ﬁttings

80860 / 80858

80857 red, without hanger

80858 red, with hanger

80859 yellow, without hanger

80860 yellow, with hanger

Grease ﬁttings identiﬁcation rings

80499 / 80732 / 80731

80730 red, for grease ﬁttings with M 6 x 1 thread

80731 red, for grease ﬁttings with M 8 x 1 thread

80732 red, for grease ﬁttings with M 10 x 1 thread

80499 yellow, for grease ﬁttings with 10 x 1 thread

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 55

Professional

button-head

grease ﬁttings

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› cylindrical thread

Button-head grease ﬁttings “Serie M” according to DIN 3404, with metric thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Button-head grease ﬁttings “Serie M” according to DIN 3404, with BSP thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

M4 (head diameter 10 mm)

81579

81579 M4 M 8 x 1

81130 M4 M 10 x 1

M4 (head diameter 10 mm)

81730

81730 M4 1/8" BSP

M1 (head diameter 16 mm)

81070 M1 M 6 x 1

15172 M1 M 8 x 1

81071 M1 M 8 x 1,25

15173 M1 M 10 x 1

15178 M1 M 10 x 1,5

15174 M1 M 12 x 1,5

81072 M1 M16 x 1,5

M1 (head diameter 16 mm)

15175 M1 1/8" BSP

15176 M1 1/4" BSP

15177 M1 3/8" BSP

81074 M1 1/2" BSP

M22 (head diameter 22 mm)

15225 M22 M 16 x 1,5

M22 (head diameter 22 mm)

81041 M22 1/8" BSP

15226 M22 1/4" BSP

80856 M22 1/4" BSP, with conus and rod valve

15227 M22 3/8" BSP

15228 M22 1/2" BSP

56 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with other thread manufactured of precision steel, case hardened, zinc plated, blue passivated

(chrome III)

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with metric thread manufactured of stainless steel,

material no. 1.4305, AISI 303, A2

M1 (head diameter 16 mm)

81096

81096 M1 1/8" NPT

M1 (head diameter 16 mm)

81658

81658 M1 M 6 x 1

80642 M1 M 8 x 1,25

15663 M1 M 10 x 1

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with BSP thread manufactured of stainless steel, material no. 1.4305, AISI 303, A2

M1 (head diamter 16 mm)

15665

15665 M1 1/8" BSP

15666 M1 1/4" BSP

81077 M1 3/8" BSP

M22 (head diameter 22 mm)

81134 M22 3/8" BSP

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with metric thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with metric thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with BSP thread manufactured of acid-proof steel, material no. 1.4401, AISI 316, A4

M1 (head diameter 16 mm)

81776

81776 M1 M 10 x 1

M1 (head diameter 16 mm)

81013

M22 (head diameter 16 mm)

80109

81013 M1 1/8" BSP

80685 M1 1/4" BSP

80109 M22 M 16 x 1,5

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 57

Professional

button-head

grease ﬁttings

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

› RoHS compliance (trivalent chrome)

› cylindrical thread

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with metric thread manufactured of brass

Button-head grease ﬁttings

“Serie M” according to DIN

3404, with BSP thread manufactured of brass

Button-head grease ﬁttings

“Serie T1” manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

M4 (head diamter 10 mm)

81665

81665 M4 M 10 x 1

M1 (head diamter 16 mm)

15475

15475 M1 1/8" BSP

15476 M1 1/4" BSP

81088 M1 3/8" BSP

With metric thread

(head diameter 16 mm)

81086

81086 T1 M 8 x 1

81123 T1 M 10 x 1

80594 T1 M 12 x 1,25

M1 (head diamter 16 mm)

15461 M1 M 8 x 1

15473 M1 M 10 x 1

M2 (head diamter 22 mm)

81091 M22 3/8" BSP

With BSP thread

(head diameter 16 mm)

80885

80885 T1 1/8" BSP

80886 T1 1/4" BSP

58 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Button-head grease ﬁttings

“Serie T1B” manufactured of precision steel, case hardened, zinc plated, blue passivated

(chrome III)

Button-head grease ﬁttings

“Serie T1B” manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Button-head grease ﬁttings

“Serie T1B” manufactured of brass

With metric thread

(head diameter 16 mm)

81083

With BSP thread

(head diameter 16 mm)

81092

With BSP thread

(head diameter 16 mm)

80935

80935 T1B 1/8" BSP

81345 T1B 1/4" BSP

81083 T1B M 6 x 1

81125 T1B M 8 x 1,25

81084 T1B M 10 x 1

81969 T1B M 10 x 1,5

With BSP thread

(head diameter 16 mm)

80718

81092 T1B 1/4" BSP

80718 T1B 1/8" BSP

80719 T1B 1/4" BSP

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 59

Professional cup-shaped grease ﬁttings

“Serie D”

› manufactured according to DIN 3405

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

Cup-shaped grease ﬁttings (drive-ﬁt type) according to DIN 3405 manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Straight 180° – type A

14104

Angled 45° – type B

(square type)

14206

Angled 90° – type C

(square type)

14306

14104 D1 a 4, head diameter 5 mm

81866 D1 a 4, head diameter 6 mm

14704 D1 a 5, head diameter 6 mm

14706 D1 a 6

80081 D1 a 6, collar depth 1,5 mm

14708 D1 a 8

14110 D1 a 10

14206 D2 a 6

14208 D2 a 8

14306 D3 a 6

14308 D3 a 8

Cup-shaped grease ﬁttings

(drive-ﬁt type) according to

DIN 3405 manufactured of stainless steel, material no. 1.4305, AISI 303, A2

Cup-shaped grease ﬁttings

(drive-ﬁt type) according to

DIN 3405 manufactured of brass

Straight 180° – type A

14406

Straight 180° – type A

81393

81786 D1 a 3,5

81011 D1 a 4, head diameter 6 mm, collar depth 1,5 mm

81499 D1 a 4, head diam. 6 mm, collar depth 1,5 mm, nickel plated

81365 D1 a 5, head diameter 6 mm 14406 D1 a 6

81393 D1 a 6 14408 D1 a 8

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Cup-shaped grease ﬁttings according to DIN 3405, with metric thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Straight 180° – type A

14713

81260 D1 M5 x 0,8, hexagon 7 mm

14713 D1 M 6 x 1

14131 D1 M 8 x 1, hexagon 9 mm

80751 D1 M 8 x 1, hexagon 11 mm

14133 D1 M 8 x 1,25

14150 D1 M 10 x 1

Angled 45° – type B

(square type)

14212

14212 D2 M 6 x 1

14231 D2 M 8 x 1

14233 D2 M 8 x 1,25

14251 D2 M 10 x 1

81058 D2 M 10 x 1,5

Angled 90° – type C

(square type)

14312

14312 D3 M 6 x 1

14331 D3 M 8 x 1

81176 D3 M 10 x 1

Cup-shaped grease ﬁttings according to DIN 3405, with BSP thread manufactured of precision steel, case hardened, zinc plated, blue passivated (chrome III)

Straight 180° – type A

14153

14153 D1 1/8" BSP

14171 D1 1/4" BSP

14181 D1 3/8" BSP

Angled 45° – type B

(square type)

14253

14253 D2 1/8" BSP

14271 D2 1/4" BSP

Angled 90° – type C

(square type)

14353

14353 D3 1/8" BSP

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 61

› manufactured according to DIN 3405

› reliability and precision for Original Equipment Manufacturers and after-sales market

› high corrosion resistance (72 hours salt spray test)

grease ﬁttings

“Serie D”

Cup-shaped grease ﬁttings according to DIN

3405, with metric thread manufactured of stainless steel, material no. 1.4305,

AISI 303, A2

Straight 180° – type A

81745

81745 D1 M 6 x 1

81505 D1 M 8 x 1

80469 D1 M 8 x 1,25

Cup-shaped grease ﬁttings according to DIN

3405, with metric thread manufactured of brass

Straight 180° – type A

14412

14412 D1 M 6 x 1

14414 D1 M 8 x 1

14415 D1 M 8 x 1,25

14450 D1 M 10 x 1

Cup-shaped grease ﬁttings according to DIN

3405, with BSP thread manufactured of brass

Straight 180° – type A

14453

14453 D1 1/8" BSP

62 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional grease ﬁtting tools

Professional packaging for grease ﬁttings

› 10 up to 1.000 pieces of grease fittings

› plastic bags

› cardboard boxes

› plastic assortment boxes

Grease ﬁtting tools

80984 / 80925

Standard bulk plastic bags

80984 Grease ﬁtting tool for 1/4" 28 SAE

80868 Grease ﬁtting tool for 1/8" NPT

80925 Grease ﬁtting tool for 5",

125 mm for cleaning, with hose

“Serie H”

› Straight 180°: per 1.000 pieces in sturdy plastic bag, provided with Hallbauer-branded self-adhesive label indicating quantity, type description, article number, date of packaging.

› Angled 45° / 90°: per 500 pieces in sturdy plastic bag, labelling as above.

“Serie D“

› Straight 180°: per 1.000 pieces in sturdy plastic bag, provided with Hallbauer-branded self-adhesive label indicating quantity, type description, article number, date of packaging.

› Angled 45° / 90°: per 500 pieces in sturdy plastic bag, labelling as above.

“Serie M”, “Serie T1”, “Serie T1B”

› M4 (head diameter 10 mm): per 100 pieces in sturdy plastic bag, provided with Hallbauer-branded self-adhesive label indicating quantity, type description, article number, date of packaging.

› M1 (head diameter 16 mm), T1, T1B: per 250 pieces in sturdy plastic bag, labelling as above.

› M22 (head diameter 22 mm): per 500 pieces in sturdy plastic bag, labelling as above.

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 63

Professional packaging for grease ﬁttings

› 10 up to 1.000 pieces of grease fittings

› plastic bags

› cardboard boxes

› plastic assortment boxes

Standard retail plastic bags – ready to shelve

12995

Standard retail folding cardboard boxes

Standard retail bags are available for all grease ﬁtting types. Standard packaged bags consist of sturdy plastic bag according to packaging size

(per 10, 20 or 50 pieces of one type or assortment) and cardboard Euro slot hanger provided with self-adhesive label indicating article code, short description, symbolic photograph, quantity, colour Hallbauer logo and barcode. Standard cardboard Euro slot hangers are Hallbauer branded.

Standard retail plastic bags packaged by 100 pieces are without Euro slot hanger. Surcharge on bulk rate for packaging and branding applies.

M22 (head diameter 22 mm): per 500 pieces in sturdy plastic bag,

labelling as above.

Standard retail folding cardboard boxes are available for all grease ﬁttings types. Standard packaged boxes are made of sturdy white cardboard and are available in three sizes: box A (79 x 38 x 50 mm) box B (79 x 53 x 50 mm) box C (105 x 78 x 50 mm) according to packaging size

(per 10, 20, 50 or 100 pieces).

The folding cardboard boxes are provided with self-adhesive labels indicating article code, short description, symbolic photograph, quantity, colour

Hallbauer logo and barcode.

Surcharge on bulk rate for packaging applies.

Customized retail plastic bags – ready to shelve

Customer branded retail plastic bags are available for all grease ﬁtting types. Customized bags feature individually printed cardboard Euro slot hanger provided with self-adhesive label indicating Hallbauer article code and / or customized article code, Hallbauer and / or customized short description, symbolic photograph on request, quantity, colour company logo and barcode on request.

Customized retail plastic bags packaged by 100 pieces are without Euro slot hanger. Surcharge on bulk rate for packaging and branding applies.

Customized retail folding cardboard boxes

Customized retail folding cardboard boxes are available for all grease ﬁttings types. Customized packaged boxes are made of sturdy white cardboard and are available in three sizes: box A (79 x 38 x 50 mm) box B (79x 53 x 50 mm) box C (105 x 78 x 50 mm) according to packaging size

(per 20, 50 or 100 pieces).

The customized folding cardboard boxes are provided with self-adhesive labels indicating Hallbauer article code and / or customized article code,

Hallbauer and / or customized short description, symbolic photograph, quantity, colour company logo and barcode on request.

Surcharge on bulk rate for packaging applies.

64 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional packaging for grease ﬁttings

› 10 up to 1.000 pieces of grease fittings

› plastic bags

› cardboard boxes

› plastic assortment boxes

Standard retail assortment plastic boxes

12990

80298 SSK 110 Econo plus - hexagon type

(110 pieces / 10 different types of hydraulic grease ﬁttings DIN 71412, see list below)

40182 SSK 120 - hexagon type

(120 pieces / 12 different types of hydraulic grease ﬁttings DIN 71412, see list below)

40181 SSK 120 neutral - hexagon type

(120 pieces / 12 different types of hydraulic grease ﬁttings DIN 71412, see list below)

12991 SSK 230 - hexagon type

(230 pieces / 12 different types of hydraulic grease ﬁttings DIN 71412, see list below)

12992 SSK 475 - hexagon type

(475 pieces / 12 different types of hydraulic grease ﬁttings DIN 71412, see list below)

Customized retail assortment plastic boxes

Customer branded assortment boxes are available in four sizes (10 or 12 compartments for approx. 100 up to 500 grease ﬁttings).

Customized inlet cartons included.

Surcharge on standard assortment boxes for branding applies.

INHALT

H1 M 6 x 1

H1 M 8 x 1

H1 M 10 x 1

H1 R 1/8"

H2 M 6 x 1

H2 M 8 x 1

H2 M 10 x 1

H2 R 1/8"

H3 M 6 x 1

H3 M 8 x 1

H3 M 10 x 1

H3 R 1/8"

SSK 110

SSK 120

SSK 230

SSK 475

100

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 65

The multi-purpose pumps are suitable for a easy ﬁlling and dispensing.

FRESH OIL

SIMPLE, BUT ESSENTIAL –

THE LITTLE USEFUL

HELPERS.

Fresh oil technology – Powerful and versatile.

We all know the plastic measures, funnels, oil cans, hand pumps or suction guns which you ﬁnd in every garage, workshop, farm, manufacturing company and household. Agreed, they are technically not very demanding, but what would we do without them?

We would be pretty helpless. Therefore we start our fresh oil section with these “little useful helpers”.

Like the plastic measuring jugs which may carry your private label or the one of your customers if you want to use them as promotion item or the single and double acting suction guns for changing the oil of outdoor power equipment.

A wide range of hand pumps is waiting for you from low budget “Give away-pumps” to hand pumps for high-viscosity oils which still work when it is getting cold outside or else dispensers for motor and gear oil with electronic hose end meters. They are indeed very economic when operated with bulk oil.

A wide range of hand and other pumps waiting for you.

Lorem ipsum dolor

› lorem

› ipsum

› dolor

02 Fresh Oil

Professional suction and ﬁller guns

Professional multi-purpose pumps

Professional hand pumps for oils

Trolleys for manual, electric and pneumatic pumps

Professional measures

Professional metal funnels

Professional plastic funnels

Professional dispensing bottle

Professional oilers

Professional sets

Professional sprayers

69

71

79

80

81

73

74

75

76

guns

› made of steel

› choice of sizes and accessories

Professional multi-purpose pumps

Suction and ﬁller guns

06015 / 40498 / 40617 / 40618

Multiple-purpose pumps

“MZE-02” and “MZE-04”

80418

06010 SFP 250 – 250 cm 3

(8,5 oz) without accessories

06011 SFP 500 – 500 cm 3

(17 oz) without accessories

06014 SFP 1000 – 1.000 cm

(34 oz) without accessories

Sets

40472 Set SFP 250 with suction tube, straight, nom. diam. 9

40498 Set SFP 250 with plastic hose, nom. diam. 9

40473 Set SFP 500 with suction tube, straight, nom. diam. 9

40535 Set SFP 500 with plastic hose, nom. diam. 4

40617 Set SFP 500 with plastic hose, nom. diam. 9

40474 Set SFP 1000 with suction tube, straight, nom. diam. 9

40618 Set SFP 1000 with plastic hose, nom. diam. 9

06015 Set SFP 500 with double valve and 2 plastic hoses, nom. diam. 9, 500 mm, double-acting

Choice of accessories

40076 Plastic hose nom. diam. 4 x 1/8" BSP, 500 mm, for suction through dip stick tube

40077 Plastic hose nom. diam. 9 x 1/8" BSP, 300 mm

40078 Suction tube, straight, nom. diam. 6,5 x 1/8" BSP, 300 mm

40079 Suction tube, bent, nom. diam. 6,5 x 1/8 BSP, 300 mm

Characteristics

› made of steel

› choice of sizes and accessories

09500 MZE-02 with 0,75 m plastic hose, nom. diam 16, and metall suction tube

80418 MZE-04 with 1 m plastic hose and plastic suction tube

Characteristics

› hand pump for diesel fuel, heating oil, hydraulic, motor oil and undiluted radiator antifreeze

› for 200 l barrels

› lockable (only MZE-04)

› plastic hose and outlet spout

› suction tube

› output 0,2 l/stroke (MZE-02) or 0,4 l/stroke

(MZE-04)

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 69

Professional multi-purpose pumps

› hand-operated multi-purpose pumps

› suitable for oils and other different liquids (see below)

Multi-purpose pump “MZ-05”/

"MZA-03" Econo plus

09513

Lever pump "HP-05/25-200" for oils

09513

Multi-purpose impeller pump

“MZF-03”

40688

81769 MZA-05

output 0,5 l/stroke with bent outlet tube

09512 MZP-05

output 0,5 l/stroke with 1,5 m rubber hose and outlet spout

09513 MZG-05

output 0,5 l/stroke with outlet tube and

1,5 m plastic hose and ball valve

305000 MZA-03/200

for 20/25 l canisters, 50 l and 200 l barrels output 0,3 l/stroke with bent outlet tube

Characteristics

› easy ﬁlling and dispensing

› suitable for diesel fuel, heating-, hydraulic-, motor- and gear oil up to SAE 140 and undiluted radiator antifreeze

› for 50/60 l and 200 l barrels

› telescopic suction tube

› output 0,5 l/stroke or 0,3 l/stroke

300009 “HP-05/25–200“ for oils

Characteristics

› pump housing and telescopic suction tube made of polypropylen

› packings made of Viton ®

› suitable for oil, diesel and water

› for 20 / 25 l canisters, 50 l and 200 l barrels

› connecting thread 2", bent outlet spout

› output 0,5 l/cycle (approx. 16 l/min)

40688 MZF-03/200

40689 MZF-03/50

with barrel pump support 2" BSP for 50 / 60 l barrels

Characteristics

› very solid for permanent application

› double-acting impeller wheel pump

› suitable for diesel fuel, heating oil, hydraulic and motor oil

› for 50 / 60 l and 200 l barrels

› suction tube 3/4" BSP

› 2 m plastic hose with outlet spout

› output 0,3 l/double stroke

Delivery content without barrel.

70 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional hand pumps for oils

› for motor and / or gear oil

› for different types of barrels

Multiple-purpose rotary pump

“MZR-04” Econo plus

308300

Multi-purpose rotary pump

“MZR-04 Alu”

40207

308300 MZR-04/200

for 200 l barrels with adjustable bung adaptor with 1 m plastic hose with outlet spout

40493 1 m plastic hose

nom. diam. 25, with outlet spout

Characteristics

› made of cost iron

› solid, efﬁcient and leak-proof

› suitable for motor- and gear oil

› self-priming

› for 200 l barrels

› metal suction tube, bent spout

› output 0,4 l/rotation

Delivery content without barrel.

Professional lubricant

dispenser “Serie DA”

325000

80445 MZR-04/200 ALU

for 200 l barrels with adjustable bung adaptor

40207 Set MZR-04/200 ALU

for 200 l barrels with adjustable bung adaptor with 1 m plastic hose with outlet spout

Characteristics

› very solid and self-priming

› made of aluminium

› suitable for diesel fuel, heating oil, hydraulic, motor and gear oil

› for 200 l barrels

› metal suction tube (3 pieces), bent spout

› output 0,4 l/rotation

Delivery content without barrel.

With capacity of 25 l

325010 DAZ 25 – mobile

with electronic ﬂow meter

325000 DA 25 – mobile

With capacity of 70 l

326010 DAZ 70 – mobile

with electronic ﬂow meter

326000 DA 70 – mobile

Characteristics

› specially suitable for high-viscosity motor and gear oil up to SAE 140

› with lever piston pump, 1,5 m rubber delivery hose with shut-off valve and bent outlet tube

› mobile with wheels

› capacity 25 l and 70 l

› output 0,12 l/stroke

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 71

Professional hand pumps for oils

› for motor and / or gear oil

› for different types of barrels

Semi-rotary gear oil pump

“MZR-A”

41006

Mobile gear oil pump “DVM”

320200

Gear oil pump “DV”

320400

81937 MZR-A/50

41006 MZR-A/50 – mobile

with trolley and pump support

Characteristics

› solid and efficient

› for gear oil

› for 50 / 60 l barrels

› 2" BSP bung adaptor

› suction tube 570 mm

› 2 m delivery hose with shut-off valve and bent outlet spout

› output 0,25 l/stroke

320200 DVM-60

for 60 l barrels

Characteristics

› specially suitable for high-viscosity motor and gear oils up to SAE 140

› lever piston pump

› 1,5 m rubber delivery hose with shut-off valve and bent outlet spout

› trolley for 20 l or 50 / 60 l barrels

› pump support with 2" bung adaptor

› output 0,12 l/stroke

320400 DV-16

Characteristics

› container capacity 16 l

› portable

› 1,5 m delivery hose with shut-off valve and bent outlet spout for gear oil

› output 0,12 l/stroke

72 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Trolleys for

ﬁller pumps and

greasing units

› steel frame, powder coated

› floor open or closed

Trolleys without accessories

431001 / 431000 / 81043

Trolleys with accessories

432814 / 40491

431001 Trolley for 50 kg / 50 – 60 l kegs,

ﬂoor open, with 2 wheels and two height-adjustable hooks

431000 Trolley for 50 kg / 50 – 60 l kegs,

ﬂoor open, with 4 wheels and two height-adjustable hooks

81043 Trolley for 10 – 50 kg / 10 – 60 l kegs,

ﬂoor closed, with 2 wheels and height-adjustable pump holder

432000 Trolley for 185 kg / 200 l barrels,

ﬂoor open, with 2 tyred wheels in front and one wheel with rear brake

432100 Drum trolley for 200 l barrels

with 2 wheels

81222 Drum dolly for 60 / 200 l barrels

made of steel, with 4 wheels, load capacity per wheel min. 75 kg (total 300 kg)

Delivery content without barrel.

432814 Trolley for 185 kg / 200 l barrels, ﬂoor closed, with 2 tyred rubber wheels in front and one swivelling rubber wheel with rear brake

40491 Trolley for 185 kg / 200 l barrels, ﬂoor closed, with 2 tyred rubber wheels in front and 2 swivelling rubber wheels with rear brake

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 73

Professional measures

› made of polyethylen or galvanized sheet steel

› with handle

› with scaling

Measures “Serie KMF”

29410

Measures “Serie KMB”

82094 / 81420

Measures “Serie WMK”

29220 / 80989

29410 KMF 1000 – 1 l

29420 KMF 2000 – 2 l

29430 KMF 3000 – 3 l

29450 KMF 5000 – 5 l

Characteristics

› made of polyethylene

› temperature resistance -60° C up to +80° C

› handle and screwed-on flexible outlet spout

› transparent for visual control of filling level

› with black lid

Customized plastic measures

Characteristics

› see above

› choice of colours

› customized logo-print (1 to 4 colours)

› minimum order quantity 500 units

82094 KMB 100 – 100 ml

81417 KMB 250 – 250 ml

81418 KMB 500 – 500 ml

81419 KMB 1000 – 1.000 ml

81420 KMB 2000 – 2.000 ml

81421 KMB 3000 – 3.000 ml

81422 KMB 5000 – 5.000 ml

Characteristics

› made of polypropylene

› temperature resistance -10° C up to +100° C

› confort grip, pouring edge

› easy stackable

› transparent for visual control of filling level

› scale in millilitres

Plastic measures set

“Serie KMB”

40860

29110 WMK 1000 – 1 l

29220 WMK 2000 – 2 l

80988 WMK 5000 – 5 l

80989 WMK 10000 – 10 l

82054 WMK 20000 – 20 l

41298 Set WMK with WMK 1000 and

WMK 2000

Characteristics

› made of galvanized sheet steel

› appropriate for calibration

› deformation resistant due to improved wall thickness

› increased stability

› heat-resistant rigid metal outlet, funnel- shaped and stable in form

40860 Set KMB

Characteristics

› set consisting of

- KMB 500 – 500 ml

- KMB 1000 – 1.000 ml

- KMB 2000 – 2.000 ml

› temperature resistance -10° C up to +100° C

74 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional metal funnels

Funnel WTW 160

30320

30320 WTW 160 – ø 160 mm

Characteristics

› made of metal

› 45 cm bent metal outlet tube

› brass filter

› made of metal or galvanized sheet steel

› hand grip

› brass filter

› diameter from 160 up to 200 mm

Funnel “Serie WT”

30018

Funnel “Serie WKT”

30218

30018 WT 160 – ø 160 mm

81568 WT 200 – ø 200 mm

Characteristics

› made of metal

› rigid outlet tube made of polyethylene, orange

› removable brass filter

30218 WKT 160 – ø 160 mm

80960 WKT 200 – ø 200 mm

Characteristics

› made of galvanized sheet steel

› rigid outlet tube made of polyethylene, orange

› removable for WKT 160

› norigid outlet tube for WKT 200

› 28 cm flexible metal outlet tube, removable

› removable brass filter

› handle

Flexible outlet tube for metal funnels

82103

82103 Flexible outlet tube WFA

for WT, WKT und WKT 200

Characteristics

› 28 cm metal outlet tube

› removable

› 90° bendable

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 75

Professional plastic funnels yellow / white /

grey

› made of polyethylen

› funnels with outlet tube

› filter made of polyethylen, brass or stainless steel

› diameter from 100 up to 350 mm

Funnel KT 100, 190, 230 yellow or white

30100 / 30190

Funnel KT 300 grey

30300

Funnel KT 350 white

82055

30100 KT 100 yellow – ø 100 mm

round type

30190 KT 190 white – ø 190 mm

oval type, recessed grip, food-safe

30230 KT 230 white – ø 230 mm

oval type, recessed grip, food-safe

Characteristics

› temperature resistance -60° C up to +80° C

› transparent

› removable flexible outlet tube

› polyethylene filter

› food-safe

30300 KT 300 grey – 285 x 195

square type

Characteristics

› diameter of the feed opening in mm

285 x 195

› height 310 mm

› rigid outlet tube

› removable brass ﬁlter

› temperature resistance -10° C up to +75° C

› not food-safe

82055 KT 350 white – 350 mm x 210 mm

round type

Characteristics

› stable hand grip

› rigid outlet tube

› stainless steel filter

› temperature resistance -20° C up to +70° C

Flexible outlet tube for plastic measures and funnels

30331

Brass ﬁlter for funnels

30331

30331 Flexible outlet tube

for KMF 1000 - 3000, KT 100 and KT 190

170 mm length, incl. screw connect

30332 Flexible outlet tube

for KMF 5000 and KT 230

280 mm length, incl. screw connect

80983 Brass ﬁlter

suitable for KT 300

76 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional plastic funnels orange / yellow / red

› made of polyethylen

› suitable for oil and chemicals

› different funnels with or without filter

› diameter from 50 up to 275 mm

Funnel KT 50-150 orange

81544

81434 KT 50 orange – ø 50 mm

81435 KT 75 orange – ø 75 mm

81543 KT 100 orange – ø 100 mm

81544 KT 120 orange – ø 120 mm

81562 KT 150 orange – ø 150 mm

Characteristics

› rigid outlet tube

› grip tag

› food-safe

Funnel KTF160 orange

81161

Funnel KT 115 orange

82051

82051 KT 115 orange – ø 115 mm oil can funnel

Characteristics

› total height 160 mm

› suitable for oil cans

› rigid outlet tube, without filter

› grip tag

› temperature resistance -20° C up to +80° C

› food-safe

81563 KT 160 orange – ø 160 mm

Characteristics

› rigid outlet tube

› stable hand grip

› removable filter, made of stainless steel

› temperature resistance -20° C up to +80° C

Funnel KTW 160 orange

81160

Funnel KT 160 orange

81563

Funnel KT 195 orange

81564

81161 KTF 160 orange – ø 160 mm 81160 KTW 160 orange – ø 160 mm 81564 KT 195 orange – ø 195 mm

Characteristics

› removable bent rigid outlet tube (300 mm)

› stable hand grip

› removable filter, made of stainless steel

› temperature resistance -20° C up to +80° C

Characteristics

› rigid outlet tube (300 mm)

› grip tag

› removable filter, made of stainless steel

› temperature resistance -20° C up to +80° C

›

Characteristics

› rigid outlet tube

› grip tag

› removable filter, made of stainless steel

› temperature resistance -20° C up to +80° C

›

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 77

Professional plastic funnels orange / yellow / red

› made of polyethylen

› suitable for oil and chemicals

› different funnels with or without filter

› diameter from 50 up to 275 mm

Funnel KT 250 orange

81565

Plastic funnels set „Serie KT orange

81552

Funnel KT 275 yellow with cover

81559

81565 KT 250 orange – ø 250 mm

Characteristics

› rigid outlet tube

› stable hand grip

› removable filter, made of stainless steel

› temperature resistance -20° C up to +80° C

Funnel KTAÖ 250 red

80515

81162 Set KT 4 orange (4 sizes)

set consisting of ø 50, 75, 100 and 120 mm

81557 Set KT 5 orange (5 sizes)

set consisting of ø 50, 75, 100, 120 and

150 mm

81552 Set KT 6 orange (6 sizes)

set consisting of ø 50, 75, 100, 120, 150 and

160 mm

Characteristics

› KT 50 - 150 with rigid outlet tube and grip tag

› KT 160 with removable filter made of stainless steel, rigid outlet tube and hand grip

› food-safe

81559 KT 275 yellow – ø 275 mm with cover, without outlet tube

Characteristics

› temperature resistance -10° C up to +75° C

› protective cover and barrel venting

› suitable for 200 l barrels

› ideal for collecting waste oils or other used

liquids in existing containers

› height incl. cover 380 mm (barrel mounted

260 mm)

› ø cover 290 mm, height cover 55 mm

› without outlet tube

› connection thread 2" BSP

› suitable for oil and chemicals

› temperature resistance -10° C up to + 75° C

80515 KTAÖ 250 red – ø 250 mm without outlet tube

Characteristics

› cover and und grip tag, lockable

› connection thread G 2"a, zinc die-cast

› ideal for collecting waste oils or other used liquids in existing containers

82142 Filter for funnel orange

Eigenschaften

› made of stainless steel

› for funnel KT 160, KT 195, KT 250, KTF 160 and KTW 160

78 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional dispensing bottle

Professional oilers

› body made of polyethylene

› capacity 125 cm 3 (4,3 oz) up to

1.000 cm 3 (34 oz)

Dispensing bottle LAB

81168

Oiler “Serie D”

81050 / 82124

Oiler “Serie S” and "Serie SW"

27117 / 27217

81168 LAB 500 – 500 ml

Characteristics

› dispensing bottle made of polyethylene

› transparent

› with angled dispensing spout, transparent, made of polyethylene

› suitable for filling car batteries

27015 D 125 – 125 cm 3 (4,3 oz)

27030 D 250 – 250 cm 3 (8,5 oz)

81050 D 500 – 500 cm 3 (17 oz)

82137 D 125 – 125 cm 3 (4,3 oz) plastic

82124 D 250 – 250 cm

(8,5 oz) plastic

82138 D 500 – 500 cm 3 (17 oz) plastic

Characteristics

› squeeze oilers

› telescopic rigid outlet tube made of brass, with

closeable nozzle, or rigid plastic spout

› capacity up to 500 cm 3 (17 oz)

27117 S 200 – 200 cm 3 (7 oz)

27130 S 300 – 300 cm 3 (10 oz)

81147 S 500 – 500 cm 3 (17 oz)

27217 SW 200 – 200 cm 3 (7 oz)

27230 SW 300 – 300 cm

(10 oz)

81146 SW 500 – 500 cm 3 (17 oz)

Characteristics

› splash oilers

› pumping device

› rigid or flexible metal outlet tube

› closed handle for safe handling

› capacity 200 cm 3 (7 oz) up to 500 cm 3 (17 oz)

Oiler “Serie DW”

80949

Oiler “Serie DF”

81547

80949 DW 75 – 75 ml

Characteristics

› tool-box oiler

› transparent

› closeable brass spout with integral leather gasket

› capacity 75 ml

81547 DF 75 – 75 ml

Characteristics

› bellows-oiler

› transparent

› orange screw nozzle

› outlet and protection cap

› capacity 75 ml

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 79

Professional oilers

› body made of polyethylene

› capacity 200 cm 3 (7 oz) up to

1.000 cm 3 (34 oz)

Oiler “Serie MSK”

28125

Professional measures sets

Measures set

41299

28125 MSK 300 – 300 cm 3 (10 oz)

28140 MSK 500 – 500 cm 3 (17 oz)

Characteristics

› metal splash oiler, pumping device made of polyethylene

› rigid and flexible metal outlet tube

› closed handle for safe handling

› capacity 300 cm 3 (10 oz) or 500 cm 3 (17 oz)

Oiler “Serie MSM”

28025

41299 Plastic measure set

Characteristics

› funnel WT 200 (ø 200 mm, galvanized sheet

steel, rigid outlet tube)

› measure WMK 2000 (2 l, galvanized sheet

steel, increased stability)

› splash oiler MSM 500 (500 cm 3 / 17 oz,

metall, rigid and flexible outlet tube)

Measures set acid

41300

81187 MSM 200 – 200 cm 3 (7 oz)

28025 MSM 300 – 300 cm 3 (10 oz)

28040 MSM 500 – 500 cm

81261 MSM 750 – 750 cm

(17 oz)

(25,4 oz)

81262 MSM 1000 – 1.000 cm 3 (34 oz)

41300 Plastic measures set acid

Characteristics

› metal splash oiler

› pumping device made of brass

› rigid and flexible metal outlet tube

› closed handle for safe handling

› capacity 200 cm 3 (7 oz) up to 1.000 cm 3 (34 oz)

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Characteristics

› 3 x measure "serie KMB": 0,5 l, 1 l and 2 l

› 6 x funnel "serie KT": ø 50, ø 75, ø 100,

ø 120, ø 150 and ø 160 mm

› 1 x splash oiler SW 300, capacity 300 cm 3

(10 oz)

Professional car sets

Professional sprayers

› made of polyethylene

› sprayer head made of brass

› capacity 750 ml up to 2.000 ml

Set for car care and oil change

40368

“Serie KIZ“

81406 / 82065 / 82066

40368 Set for car care and oil change

Characteristics

› multi-purpose tube MZW 6, PE, 6 l, ø 350 mm

› measure KMF 1000, 1 l, flexible outlet tube

› oil can funnel KT 115, orange, ø 115 mm

› rigid outlet tube suitable for fill opening of car

motors

› sprayer KIZ 750

Filling set

41277

81406 KIZ 750 – 750 ml

sprayer head with closable nozzle made of brass (externel polyethylene), seals made of EPDM

82065 KIZ 1000 – 1.000 ml

air pressurized, sprayer head with nozzle and suction tube made of brass, seals made of Viton ®

82066 KIZ 2000 – 2.000 ml

air pressurized, sprayer head with nozzle and suction tube made of brass, seals made of Viton

Characteristics

› transparent

› sprayer head with adjustable and closeable nozzle

› KIZ 750 suitable for

- rust removers and low viscosity oils

- self-lubricating and not self-lubricating liquids

- For cleaning liquids

- less aggressive cleaners

› KIZ 1000 and KIZ 2000 suitable for

- self-lubricating liquids, i.e. low viscosity oils and diesel

- rust removers or antirust- and anticorrosion liquids

- liquids for impregnation, forming oils, release agents and wall paper solver

- contact spray liquids and other not self-lubricating liquids

- low aggressive solvents- and cleaning agents

- biological and chemical pesticides

- liquid weed killer

› suitable for non-explosive liquids only

41277 Filling set

Characteristics

› measure KMF 2000, 2 l, flexible outlet tube

› funnel KT 195, orange, ø 195 mm, with

removable filter, made of stainless steel, rigid

outlet tube and grip tag e

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 81

Usage of our Dieselmatic® plus pumps for fast ﬁlling with diesel fuel.

DIESEL

DIESEL FUEL OR ADBLUE®.

REFUEL WITH US!

Our diesel range: made for your requirements.

The agricultural and construction machines are growing bigger and their tanks accordingly. Therefore you have a need for electric pumps with an adequate output. This is why our 12 V / 24 V-electric pumps

“Diesel matic ® ” as well as their 230 V-versions with ﬂow rates between 35 and 80 liters diesel fuel per minute help you to reduce the time for refuelling, allowing you more working hours.

Almost all of our “Dieselmatic ® ” pumps are equipped with automatic delivery pistols which shut off automatically when the tank is full. Our electric pumps are self-priming, i.e. they do not need to be preﬁlled.

Design and configuration meet your professional requirements: oil-proof electric cable, foot valve and strainer, protection against self-emptying of your diesel container, professional hose end fittings, conically sealing fittings, diesel-proof hoses, integrated by-pass, support for automatic delivery pistol and – last but not least – easy mounting.

AdBlue ® has its share in the reduction of polluant emissions of diesel fuelled vehicles – an issue which we take very seriously. For this reason we have adapted and developed our hand and electric pump range to the specialized requirements of AdBlue

. By the way, these pumps are also suitable for IBC-tanks using a CDS-/SEC-connector.

Agricultural machines are

growing bigger and need

electric pumps.

03 Diesel

Professional electric pumps for diesel fuel with 12 or 24 V

Professional electric pumps for diesel fuel with 230 V

Professional pumps for urea solution AdBlue®

Delivery pistols

Delivery hose

Suction hose

Flow meter

Other accessories for diesel fuel pumps

85

86

87

90

91

Professional electric pumps for diesel fuel with 12 or 24 V

Dieselmatic® 35

35 l/min

80277

› self-priming electric pump without pre-filling

› suction hose with foot strainer

› delivery hose

› oil-proof connecting cable with alligator clips

Dieselmatic® 40

40 l/min

09866 with 40200

Dieselmatic® 80

80 l/min

40681

80277 Dieselmatic ® 35 type E 12 V

with plastic delivery pistol

40255 Dieselmatic ® 35 type S 12 V

with automatic delivery pistol AP 60

80493 Dieselmatic ® 35 type E 24 V

with plastic delivery pistol

40256 Dieselmatic ® 35 type S 24 V

with automatic delivery pistol AP 60

Characteristics

› self-priming electric pump without pre-filling

› plastic delivery pistol (type E) or automatic delivery pistol (type S)

› illuminated on- / off-switch

› 2" BSP connector for barrels and tanks

› 3,5 m suction hose with foot strainer, nom. diam. 19, 3 /4" BSP

› 1,25 m delivery hose, nom. diam. 19,

3 /4" BSP

› 1,25 m oil-proof connecting cable with alligator clips

› 9 A, IP 44, engine power 0,11 kW (12 V), 6 A,

IP 44, engine power 0,14 KW (24 V)

› output approx. 35 l/min with free discharge

09723 Dieselmatic ® 40 type E 12 V

with metal delivery pistol

09722 Dieselmatic ® 40 type S 12 V

with automatic delivery pistol AP 80

09865 Dieselmatic ® 40 type E 24 V

with metal delivery pistol

09866 Dieselmatic ® 40 type S 24 V

with automatic delivery pistol AP 80

40200 Digital ﬂ ow meter

for Dieselmatic ® 40

Characteristics

› self-priming electric pump without pre-filling with bypass for diesel fuel and heating oil

› specially designed for on-site refilling of agricultural and construction vehicles or machinery

› 2" BSP connector for barrels and tanks

› 1,5 m suction hose with foot strainer, nom. diam. 25, 1" BSP

› 4 m delivery hose, nom. diam. 25, 1" BSP

› 1,5 m oil-proof connecting cable with alligator clips

› 16 A, IP 55, engine power 0,14 KW (12 V),

› 13 A, IP 55, engine power 0,16 kW (24 V)

› output approx. 40 l/min with free discharge

40681 Dieselmatic ® 80 type S 12 V

with automatic delivery pistol AP 80

40155 Dieselmatic ® 80 type S 12 V

with automatic delivery pistol AP 80 and ﬂ ow meter

40266 Dieselmatic ® 80 type S 24 V

with automatic delivery pistol AP 80

40156 Dieselmatic

80 type S 24 V

with automatic delivery pistol AP 80 and ﬂ ow meter

40725 Digital ﬂ ow meter

for Dieselmatic

Characteristics

› self priming electric pump without pre-filling, with by-pass for diesel fuel

› operating cycle 30 min.

› automatic delivery pistol

› on-/off-switch

› 2" BSP connector for barrels and tanks

› 1,6 m suction hose with foot strainer, nom. diam. 25, 1" BSP

› 4 m delivery hose, nom. diam. 25, 1" BSP

› 2 m oil-proof connecting cable with alligator clips

› 24 A, IP 55, engine power 0,48 KW (12 V),

21 A, IP 55, engine power 0,72 kW (24 V)

› output approx. 80 l/min with free discharge

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 85

Professional electric pumps for diesel fuel with 230 V

› self-priming electric pump without pre-filling for refilling with diesel fuel

› suction tube or hose with foot strainer or foot valve

› delivery hose

› oil-proof connecting cable with alligator clips

Dieselmatic® plus 35

35 l/min

40159 with 40015

Dieselmatic® plus 60

60 l/min

40545

Dieselmatic® plus 70

70 l/min

40815

81891 Dieselmatic ® plus 35 type E

with plastic delivery pistol

40159 Dieselmatic ® plus 35 type S

with automatic delivery pistol AP 60

40015 Electronic ﬂow meter

for automatic delivery pistol AP 60 for

Dieselmatic ® plus 35

Characteristics

› self-priming electric pump without pre-filling for refilling with diesel fuel

› plastic delivery pistol (type E) or automatic delivery pistol (type S)

› 2" BSP connector for barrels and tanks

› illuminated on / off switch

› 1,5 m telescopig suction tube with filter, ø

17,5 mm, made of plastic

› 2,5 m rubber delivery hose with foot strainer,

nom. diam. 19, 3/4" BSP

› 2 m oil-proof connecting cable with plug, ready to use

› 230 V, 50 Hz, 1 A, IP 44, engine power

0,22 kW

› output approx. 35 l/min with free discharge

40544 Dieselmatic ® plus 60 type E

with metal delivery pistol

40545 Dieselmatic ® plus 60 type S

with automatic delivery pistol AP 60

40818 Dieselmatic ® plus 60 type S

with automatic delivery pistol AP 60 and digital ﬂow meter

40813 Digital ﬂow meter

for Dieselmatic ® plus 60

Characteristics

› self-priming electric pump without pre-filling, with by-pass for the fast filling with diesel fuel or heating oil

› built in: safety lifiting valve

› 2" BSP connector for barrels and tanks

› 1,6 m suction hose with foot valve and strainer, nom. diam. 25, 1" BSP

› 4 m delivery hose, nom. diam. 25, 3/4" BSP

› illuminated on / off switch

› delivery pistol support AP 60 for type S

› 3 m oil-proof connecting cable with plug, ready to use

› metal delivery pistol (type E) or automatic delivery pistol (type S)

› 230 V, 50 Hz, 2,2 A, IP 55, engine power 0,37 kW

› output approx. 60 l/min with free discharge

40831 Dieselmatic ® plus 70 type S

with automatic delivery pistol AP 90

40815 Dieselmatic ® plus 70 type S

with automatic delivery pistol AP 90 and digital ﬂow meter

40813 Digital ﬂow meter

for Dieselmatic ® plus 70

Characteristics

› self-priming electric pump without pre-filling, with by-pass for the fast filling with diesel fuel or heating oil

› automatic delivery pistol

› safety lifiting valve

› 2" BSP connector for barrels and tanks

› 1,6 m suction hose with foot valve and

strainer, nom. diam. 25, 1" BSP

› 4 m delivery hose, nom. diam. 25, 1" BSP with professional hose end fittings

› illuminated on / off switch

› delivery pistol support AP 90

› 3 m oil-proof connecting cable with plug, ready to use

› 230 V, 50 Hz, 2,2 A, IP 55, engine power 0,55 kW

› output approx. 70 l/min with free discharge

86 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional pumps for urea solution AdBlue®

› manual or electronic pumps

› suitable for AdBlue®

Stainless steel manual pump

“EP-02”

80746

Rotary pump

308200

Electric pump

“Bluematic” maxi type S

40240

80746 EP 02/20–60

with bung adaptor for plastic canisters with female thread

80747 EP 02/200

with 2" BSP bung adaptor

Characteristics

› for 20 – 60 l or 200 l barrels

› appropriate for aggressive chemicals

› teflon sealings

› output approx. 0,25 l/stroke

› 2" BSP connection

308200 MZR-04/200 Blue with suction tube

40298 MZR-04/200 Blue

with CDS-/SEC-adaptor for IBC-containers and

2 m PVC-hose (without suction tube)

40292 MZR-04/200 Blue

with Mauser-adaptor, 2 m PVC-hose and suction tube

For IBC-containers

40243 Bluematic maxi type S

40239 Bluematic maxi type S

with electronic ﬂow meter

40242 Bluematic maxi type S

with CDS-/SEC-connector for IBC-containers

40240 Bluematic maxi type S

with CDS-/SEC-connector for IBC-containers and electronic ﬂow meter 40724 2 m PVC-hose with pourer

41307 3 m PVC-hose with pourer

81990 Adaptor 2" BSP (f) x 2" BSP (m) for coarse thread type Mauser

09618 Tri-Sure 2 adaptor

Accessories Bluematic maxi

Für plastic barrels

41291 Bluematic maxi type E

41292 Bluematic maxi type E

with electronic ﬂow meter

41293 Bluematic maxi type S

41294 Bluematic maxi type S

with electronic ﬂow meter

Characteristics

› for 200 l barrels

› made of polypropylene

› output approx. 0,25 l/stroke

40520 Electronic ﬂow meter 1"

measuring accuracy +/– 0,5%, 8 - 110 l/min

366010 Electronic ﬂow meter 1/2",

measuring accuracy +/– 0,5%, 1 - 50 l/min

560901 CDS-/SEC connector

for IBC-containers

80289 Automatic delivery pistol

stainless steel, for Bluematic maxi, with swivel

Characteristics

› self-priming stainless steel pump

› automatic delivery pistol (type S) or plastic

delivery pistole (type E)

› version for plastic barrels with gun holder

› 4 m delivery plastic textile hose, nom. diam.

19, 3/4" with hose end fittings

› suction hose nom. diam. 19

- 1 m, with foot valve and hose end fittings

(40242, 40240, 40188), or

- 1 m, with hose end fittings (41291, 41292,

41293, 41294), or

- 2,5 m, with foot valve and hose end fittings

40243, 40239)

› 230 V, 50 Hz, 2,4 A, IP44, engine power

0,37 kW

› output approx. 40 l/min with free discharge

80937 Plastic delivery pistol

for Bluematic maxi, with swivel

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 87

Professional pumps for urea solution AdBlue®

› manual or electronic pumps

› suitable for AdBlue®

Lever pump “HP-05/25–200“

AdBlue®

300006

Elektropumpe Bluematic EMP

560304400

300006 HP-05/25–200 for AdBlue ®

40334 Set HP-05/25–200 for AdBlue ®

with G 2"a barrel adaptor and 2 m PVC-hose

(with pourer)

Characteristics

› pump housing and telescopic suction tube made of polypropylen

› packings made of EPDM

› suitable for water, windshield water fluid,

antifreeze, detergents, agricultural chemicals,

DEF and AdBlue ®

› extreme operational, extremely efficient

› for 20 / 25 l canisters, 50 l and 200 l barrels

› connecting thread 2", bent outlet spout

› output 0,5 l/cycle (approx. 16 l/min)

Bluematic EMP

Characteristics

› self priming multi-diaphragm pump with no mechanical seals designed for dispensing AdBlue

› Bluematic EMP with 12 V (engine power 0,14 kW), 24 V (engine power 0,2 kW) or 230 V (engine

power 0,4 kW)

› inlet/outlet connection 1" BSP (M)

› maximum continuous run 30 minutes

› maximum delivery up to 32 l/min with free discharge

› EDPM suction hose, 3/4", EDPM delivery hose 4,0 m x 3/4" and connecting clip

› automatic (stainless steel) or manual (thermoplastic) nozzle

› accessories listed in the following table

Bluematic EMP variations

2,5 m Fußventil plastic no

Accessories HP-05/25-200

40724 2 m PVC-hose with pourer

41307 3 m PVC-hose with pourer

2,5 m Fußventil plastic no

EMP-230 V Basic mobil

EMP 230 V für IBC/Fass (Stahl)

EMP-230 V Basic mobil

EMP-230 V für IBC/Fass (Stahl)

560304400

EMP-230 V Basic for IBC/barrel (steel)

2,5 m Fußventil plastic no

CDS- / SEC-

Adapter

CDS- / SEC-

Adapter

CDS- / SEC-

Adapter

CDS- / SEC-

Adapter

Kunststoff no

Kunststoff yes

Automatik Nein

Automatik Ja automatic yes

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Mobile dispenser for

AdBlue®

› fully compatibles with Urea/AdBlue solutions

› „Directﬂo

® “ double diaphragm air

® operated pump (polypropylene body and

PTE diaphragms) or electrical pump EMP

› optinoal with reel

Mobile dispenser for AdBlue®

557952400 / 560307400

with diaphragm pump „Directﬂo ® “ DF 30

557952 Mobile dispenser with DF 30, automatic nozzle and hose reel for air

automatic nozzle with reduced discharge, max. 10 l/min, 15 m hose reel for air, serie 500

557952400 Mobile dispenser with DF 30, nozzle Elaﬂex and hose reel for air

automatic nozzle, version Elaflex ZVA, 15 m hose reel for air, serie 500

557953 Mobile dispenser with DF 30 und automatic nozzle

automatic nozzle with with reduced discharge, max. 10 l/min

with electric pump EMP 230 V

560307 Mobile dispenser with EMP 200 V, automatic nozzle and cable reel

automatic nozzle with reduced discharge, max. 10 l/min, 15 m cable reel

560307400 Mobile dispenser with EMP 200 V, nozzle Elaﬂex and cable reel

automatic nozzle, version Elaflex ZVA, 15 m cable reel

560308 Mobile dispenser with EMP 200 V and automatic nozzle

automatic nozzle with reduced discharge, max. 10 l/min

Characteristics

› heavy-duty drum trolley for 200 l drums

› output approx. 4 - 30 l/min

› in-line meter with digital display

› automatic nozzle with limited outlet (max. 10 l/min)

› 0,7 m suction hose, G 3/4"

› 3 m delivery hose, G 3/4"

› drum connector

AdBlue®accessories

Accessories for AdBlue®

569003 / 569006 / 560905 /

40157 / 82148

Automatic nozzles

569003 Automatic nozzle for the fuelling of commerical vehicles and transporter

569005 Automatic nozzle with swivel, for the fuelling of cars, (max. 10 l/min.)

569006 Automatic nozzle version Elaﬂex, 1", suitable for DF pumps

Hoses / suction tubes

560905 Hose set for IBC

3 m, with PVC hose and IBC adaptor 1"

930505 EPDM hose ø 13 x 4

930507 EPDM hose ø 19 x 4,5

80477 EPDM hose ø 16 x 4

80727 PVC hose ø 19 x 4

Pump holder

360131 Holder DF for DF 30, 50, 100

360137 Holder for 200 l barrels

40157 Holder for IBC

82148 Holder for 200 l plastic container, including gun holder

Suction tube

560906 Suction tube for CDS-/ SEC connector with 2" Tri-Sure

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 89

Spare parts and accessories for diesel fuel pumps

› delivery pistols

› delivery and suction hoses

› flow meter

› hose reels

› adaptors

12/24 V

Dieselmatic®

12/24 V plus 35 plus 60 plus 70

Delivery pistols

40009

Metal delivery pistol, 3/4" BSP

40010

Metal delivery pistol, 1" BSP

40011

Automatic delivery pistol AP 60, ø 24 mm,

3/4" BSP with swivel

40519

Automatic delivery pistol AP 80, ø 27 mm,

1" BSP with swivel

40033

Automatic delivery pistol AP 90, ø 24 mm,

1" BSP with swivel

688100

Automatic delivery pistol AP 120, ø 29 mm,

1" BSP with swivel

Delivery hose

40017

4 m delivery hose,

nom. diam. 19, 3/4" BSP

80478 1 m additional

delivery hose

40018

4 m delivery hose,

nom. diam. 25, 1" BSP

80479 1 m additional

delivery hose

Suction hose

40021

1,6 m suction hose,

nom. diam. 25, 1" BSP

90 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Flow meter

40813

Digital ﬂow meter,

3/4" BSP mechanical,

resettable, display of ﬂow rate and total delivery, vertical ﬂow direction

40200

Digital ﬂow meter,

1" BSP mechanical,

resettable, display of ﬂow rate and total delivery, vertical ﬂow direction

40725

Digital ﬂow meter,

1" BSP mechanical,

resettable, display of ﬂow rate and total delivery, horizontal ﬂow direction

40015

Electronic ﬂow meter, 3/4" BSP

resettable, display of ﬂow rate and total delivery

Automatic hose reel

508225

Automatic hose reel

Single arm

with 15 m delivery hose, nom. diam. 25, 1" BSP

2" BSP (m) adaptor

81696

2" BSP (m) adaptor

for barrels and tanks

Delivery pistol

40595

Delivery pistol support AP 60

Wall mounting bracket

40030

Wall mounting

bracket with assembly kit, connection hose and 2" BSP adaptor

12 / 24 V

Dieselmatic®

12 / 24 V plus 35 plus 60 plus 70

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 91

Our Directﬂo ® pumps in action: trusty and easy to maintain.

CHEMICALS

NOT EASY, BUT

FEASIBLE.

Directﬂo®-pumps and much more.

In this section we would like to open a new chapter about pumping, measuring and dosing of fluids by presenting to you our range of new pneumatic pumps which can be used for automotive fluids like anti freeze and windshield cleaner or chemicals fluids like paint solvents, detergents, alcohols etc.

Before doing so, though, we would like to introduce you to our range of “little useful helpers” like measures made of polypropylene and multi-purpose pumps made of plastic for paint thinners, detergents, antifreeze, acids etc.

“Last but not least” you will ﬁnd at the end of this chapter our pro- gramme for the handling of epoxy resins as used in the concrete repair business.

For the usage of selected

chemical fluids.

04 Chemicals

Professional hand pumps for chemicals

Professional pneumatic pumps

“Fluidmaster” DP-C

Professional air-operated double diaphragm pumps “Fluidmaster” DF

Professional mixing pumps

Professional plastic measures

Professional delivery pistols and electronic ﬂow meters

Professional lever gun “X-TRA” for epoxy resins

Accessories for concrete repair business

95

97

99

100

101

102

103

› for different types of chemicals (please ask for list of suitable chemicals)

› for barrels up to 200 l

for chemicals

Siphon pump

300100 / 300101

Syphon pump for chemistry

300103 / 300104

Multi-pump “MP-04”

09604

300100 Syphon pump 25 l

for 25 l canisters with 0,5 m plastic hose and

390 mm suction tube

300101 Syphon pump 200 l

for 200 l barrels with 1,2 m plastic hose, hose holder, G 2"a barrel adaptor and 850 mm suction tube

Characteristics

› extreme operational, extremely efficient

› suitable for kerosene, light oils, light diesel,

light solvents, toluene, non drinking water, etc.

› wetted parts:

- Polyethylene (HD)

- Stainless Steel

- EVA

› barrel plug

› flow rate 0,1 l/stroke (300100) or 0,3 l/stroke

(300101)

› maximum flow rate 7 l/min (300100) or

19 l/min (300101) with siphoning effect

300103 Syphon pump chemistry 25 l

for 25 l canisters with 0,5 m plastic hose and

390 mm suction tube

300104 Syphon pump chemistry 200 l for 200 l barrels with 1,2 m plastic hose, hose holder, G 2"a barrel adaptor and 850 mm suction tube

Characteristics

› extreme operational, extremely efficient

› suitable for kerosene, light oils, light diesel,

light solvents, toluene, non drinking water,

thinner, hydrochloric acid (35 %), nitric acid

(35 %), sulfuric acid (35 %), acetic acid (35 %)

› wetted parts:

- Polyethylene (HD)

- Stainless Steel

› flow rate 0,1 l/stroke (300103) or 0,3 l/stroke

(300104)

› maximum flow rate 7 l/min (300103) or

19 l/min (300104) with siphoning effect

09604 MP-04/50

for strong acid-based chemicals and cleaners

09614 MP-04/200

for strong acid-based chemicals and cleaners

09605 MP-04/50 super

premium pump for special applications, e.g. for dissolvent, paint thinner

09615 MP-04/200 super

premium pump for special applications, e.g. for dissolvent, paint thinner

40082 2 m rubber hose

with outlet spout for MP-04 and MP-04 super

09619 Universal adaptor

for 50 / 60 l barrels and other containers without thread

Characteristics

› for special applications, extremely efficient

› for diluent, cleaner, antifreeze, acids, fertilizer etc. (please ask for list of suitable chemicals)

› bent spout, 2" BSP bung adaptor

› 470 mm (MP-04/50) or 950 mm (MP-04/200) suction tube length

› output 0,25 l/stroke

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 95

Professional hand pumps for chemicals

› for different types of chemicals (please ask for list of suitable chemicals)

› for barrels up to 200 l

Hand pump “LMP-05” and

“LVP-05”

09531

09531 LMP-05 for dissolvent

with 2 m rubber hose and ball valve with outlet spout

40371 LMP-05 electrically conductive

with 1,5 m electrically conductive hose for two-stroke fuel-oil mixture

40057 LVP-05 for paint thinner

with 2 m rubber hose and ball valve with outlet spout

Characteristics

› versatile, high output

› suitable for dissolvent, paint thinner etc.

(please ask for list of suitable chemicals)

› with Viton sealings

› for 200 l barrels

› telescopic suction tube

› output 0,5 l/stroke

Stainless steel hand pump

“EP-02”

80746

Lever pump “HP-05/25–200“

AdBlue®

300006

80746 EP 02/20–60

with bung adaptor for plastic canisters with female thread

80747 EP 02/200

with 2" BSP bung adaptor

Characteristics

› for 20 – 60 l or 200 l barrels

› appropriate for aggressive chemicals

› teflon sealings

› output approx. 0,2 l/stroke

› 2" BSP connection

300006 HP-05/25–200 for AdBlue ®

40334 Set HP-05/25–200 for AdBlue ®

with G 2"a barrel adaptor and 2 m PVC-hose

(with pourer)

Characteristics

› pump housing and telescopic suction tube made of polypropylen

› packings made of EPDM

› suitable for water, windshield water fluid,

antifreeze, detergents, agricultural chemicals,

DEF and AdBlue ®

› extreme operational, extremely efficient

› for 20 / 25 l canisters, 50 l and 200 l barrels

› connecting thread 2", bent outlet spout

› output 0,5 l/cycle (approx. 16 l/min)

Accessories HP-05/25-200

40724 2 m PVC-hose with pourer

41307 3 m PVC-hose with pourer

96 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

› very versatile pumps

› suitable for many liquids (please ask for list of suitable chemicals)

for chemicals

“Fluidmaster 1“ DP-C 1:1

330100

“Fluidmaster 2“ DP-C/NI 1:1

601202

330100 “Fluidmaster 1“ DP-C 1:1

Characteristics

“Fluidmaster 1” DP-C 1:1 is a low pressure transfer pump for slightly corrosive chemicals with low viscosity such as paint solvents, cleaning ﬂuids, antifreeze (glycol), detergents, grease removers, alcohols, turpentine, petrochemical products, anticorrosion products, light inks, lacquer, wood varnish etc.

› pressure ratio 1:1

› air piston diameter 36 mm

› air piston stroke 80 mm

› maximum output 15 l/min 1

› minimum air pressure 2 bar (29 psi)

› maximum air pressure 8 bar (115 psi)

› maximum fluid pressure 8 bar (115 psi)

› air inlet 1/4" BSP (f) with needle valve

› fluid outlet 3/8" BSP (m)

› fluid inlet 3/8" BSP (f) with adaptor for suction hose nom. diam.

1/2" BSP

› 3/4" BSP (m) bung adaptor

› wetted parts aluminum, stainless steel, chromium steel, PTFE, Viton

601202 “Fluidmaster 2“ DP-C/NI 1:1

Characteristics

“Fluidmaster 2” DP-C/NI 1:1 is a double-acting low pressure pump with high output. “Fluidmaster 2“ DP-C/NI 1:1 pneumatic pumps are suitable only for antifreeze solvents on base of glycol (diluted or undiluted). Pumps can be used as transfer pumps or in pipeline systems with automatic hose reels and electronic hose end meters.

› pressure ratio 1:1

› suction tube diameter 52 mm

› air piston diameter 51 mm

› air piston stroke 75 mm

› maximum output 55 l/min 1

› minimum air pressure 3 bar (45 psi)

› maximum air pressure 10 bar (145 psi)

› maximum fluid pressure 10 bar (145 psi)

› air inlet 1/4" BSPT(f)

› fluid outlet 3/4" BSP (f)

› fluid inlet 1" BSP (f)

› 2" BSP height-adjustable bung adaptor

› wetted parts nickel-coated aluminum, steel, stainless steel, acetal, polyurethane

with free discharge at 7 bar (100 psi) air inlet pressure, using water

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 97

Professional pneumatic pumps for chemicals

› very versatile pumps

› suitable for many liquids (please ask for list of suitable chemicals)

“Fluidmaster 2“ DP-C 1:1

331120

“Fluidmaster 4“ DP-C 3:1

333120

331120 “Fluidmaster 2“ DP-C 1:1

Characteristics

“Fluidmaster 2” DP-C 1:1 is a double-acting low pressure pump with high output manufactured in AISI 316 stainleess steel. “Fluidmaster 2”

DP-C 1:1 air-operated pumps can be used as transfer pumps or in pipeline systems with several outlets even with simultaneous operation.

Pumps are suitable for slightly corrosive ﬂuids with low viscosity such as paint solvents, cleaning ﬂuids, antifreeze (glycol), detergents, grease removers, alcohols, turpentine, petrochemical products, anticorrosion products, light inks, lacquer, wood varnish etc.

Technical data

› pressure ratio 1:1

› suction tube diameter 52 mm

› air piston diameter 51 mm

› air piston stroke 75 mm

› maximum output 38 l/min 1

› minimum air pressure 3 bar (45 psi)

› maximum air pressure 10 bar (145 psi)

› air inlet 3/4" BSP (f)

› fluid outlet 3/8" BSP (f)

› fluid inlet 1" BSP (f)

› 2" BSP height-adjustable bung adaptor

› wetted parts acid-proof steel AISI 316, PTFE, Viton ®

333120 “Fluidmaster 4“ DP-C 3:1

Characteristics

“Fluidmaster 4” DP-C 3:1 is a double-acting medium pressure pump with high output manufactured in AISI 316 stainless steel. “Fluidmaster 4" pneumatic pumps can be used in large pipeline systems with automatic hose reels and electronic hose end meters with several outlets even with simultaneous operation.

Technical data

› pressure ratio 3:1

› suction tube diameter 52 mm

› air piston diameter 88 mm

› air piston stroke 100 mm

› maximum output 45 l/min 1

› minimum air pressure 3 bar (45 psi)

› maximum air pressure 10 bar (145 psi)

› maximum fluid pressure 30 bar (435 psi)

› air inlet 3/8" BSP (f)

› fluid outlet 3/4" BSP (f)

› fluid inlet 1" BSP (f)

› 2" BSP height-adjustable bung adaptor

› wetted parts stainless steel, PTFE and Viton ®

1 with free discharge at 7 bar (100 psi) air inlet pressure, using water

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

double diaphragm pumps

› innovative and compact design

› reduced number of components

› extremely easy maintenance and longer service intervals

› reduced air consumption and flow pulsation

› quiet and almost vibration-free operation

› improved suction capacity, superior performance against back pressure

› longer lifetime of diaphragms

“Directﬂo”® DF 50

552010

“Directﬂo”® DF 100

551030

552010 DF 50

suitable for lubricants, waste oil, antifreeze (glycol) and water

Wetted parts: Aluminum, NBR, Hytrel ®

Pump body: Aluminum

Diaphragms: Hytrel ®

Balls: Acetal

Characteristics

“Directﬂo ® ” DF 50 is an air-operated double diaphragm pump with high output fully enclosed in an aluminium shield. “Directﬂo ® ” DF 50 pumps are designed to be used as both transfer and system pumps. As system pumps they can work on demand, e.g. starting immediately once a delivery valve is opened and stopping once it is closed.

› pressure ratio 1:1

› maximum output 50 l/min

› 0,1 l delivery/cycle 1

› minimum air pressure 1,5 bar (22 psi)

› maximum air pressure 8 bar (115 psi)

› maximum size of solids 3 mm

› maximum dry suction head 6 m 1

› maximum wet suction head 8 m 1

› weight 3,5 kg

› air inlet 3/8" NPSM (f)

› fluid outlet 1/2" BSP (f) and flange

› fluid intlet 1/2" BSP (f) and flange

551030 DF 100

suitable for lubricants, waste oil, antifreeze (glycol), transmission ﬂuid and water

Wetted parts: Aluminum, NBR, Hytrel ®

Pump body: Aluminum

Diaphragms: Hytrel

Balls: Acetal

Characteristics

“Directflo ® ” DF 100 is an air-operated double diaphragm pump with very high output fully enclosed in an aluminium shield and extremely robust. “Directflo ® ” DF 100 pumps can be used for fluid transfer, evacuation and within distribution systems. As system pumps they can work on demand, e.g. starting immediately once a delivery valve is opened and stopping once it is closed.

› pressure ratio 1:1

› maximum output 100 l/min 1

› delivery 0,25 l/cycle 1

› minimum air pressure 1,5 bar (22 psi)

› maximum air pressure 8 bar (115 psi)

› maximum size of solids 4 mm

› maximum dry suction head 4,5 m 1

› maximum wet suction head 7 m 1

› weight 7,2 kg

› air inlet 3/8" NPSM (f)

› fluid outlet 1" BSP (f) and flange

› fluid intlet 1" BSP (f) and flange

1 with free discharge at 7 bar (100 psi) air inlet pressure, using water 20° C

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 99

Professional mixing device

FAM

Professional plastic measures

› made of polypropylene

› with open handle, easy stackable

Mixing device FAM

81141

Plastic measures “Serie KMB”

89094 / 81420

Plastic measures set KMB

40860

81141 FAM-200

for 200 l barrels

Characteristics

The barrel or canister mounted mixing device

FAM can be used for producing stable and homogeneous emulsions within a certain concentrate range. A water ﬂow regulator and ﬁne control valve allow mixing ratios from 0 to 10 %.

› throughput up to 1.500 l/hour

› flow pressure 1,5 to 10 bar (22 to 145 psi)

› water connection 1/2" BSP

› suction tube

› ball valve, non-return valve

› 2 m delivery hose with outlet spout

82094 KMB 100 – 100 ml

81417 KMB 250 – 250 ml

ø bottom side 50 mm, height 120 mm

81418 KMB 500 – 500 ml

ø bottom side 70 mm, height 135 mm

81419 KMB 1000 – 1.000 ml

ø bottom side 90 mm, height 170 mm

81420 KMB 2000 – 2.000 ml

ø bottom side 105 mm, height 215 mm

81421 KMB 3000 – 3.000 ml

ø bottom side 120 mm, height 240 mm

81422 KMB 5000 – 5.000 ml

ø bottom side 150 mm, height 270 mm

Characteristics

› made of polypropylene

› temperature resistance -10° C up to +100° C

› confort grip, pouring edge

› easy stackable

› transparent for visual control of filling level

› scale in millilitres

40860 Set KMB

Characteristics

› temperature resistance -10° C up to +100° C

› set consisting of

- KMB 500 – 500 ml

- KMB 1000 – 1.000 ml

- KMB 2000 – 2.000 ml

100 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Professional delivery pistols and electronic ﬂow meters

Fluid pistol

186300

186300 Fluid pistol

Characteristics

› housing made of polypropylene, glass fiber coated

› valve mechanism made of stainless steel

› swivel

› including flexible outlet

› maximum flow rate 15 l/min

› for windscreen liquid, antifreeze concentrate and other water-soluble liquids

› connecting thread 1/2" BSP (f)

› maximum pressure 40 bar (580 psi)

Fluid pistol with electronic ﬂow meter

365675

365675 Fluid pistol

with electronic ﬂow meter

Characteristics

› fluid pistol as under 186300 described

› resettable LCD display, 4 digits and display of total delivery

› for liquids with operating temperature from - 10° C up to +55° C

› minimum flow rate 5 l/min, maximum flow rate 15 l/min

› measuring accuracy ± 0,5%, easy on-site calibration

› including two standard batteries, easy to replace

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 101

for epoxy resins

› concrete repair business

› capacity 500 cm 3 (17 oz) or 1.000 cm 3 (34 oz)

Lever gun “X-TRA”

40804

Lever gun “X-TRA” concrete repair

41046 / 41047 / 82114

40804 “X-TRA” oilproof/M (DIN 1283)

40805 “X-TRA” oilproof/BSP

40669 “X-TRA” oilproof/M (DIN 1283)

with extension pipe 150/M and 4-jaw Proﬁ-nozzle with check-valve 120/M

41280 "X-TRA" oilproof/BSP

with extension pipe 150/BSP

Characteristics

› display carton with

› for concrete repair business

› capacity 500 cm 3 (17 oz)

› professional lever oil gun made of precision steel, robust and durable

› ultimate suction power with full-stroke system

› for safety reasons with curved lever

› wall thickness of grease gun tube 1,2 mm

› air bleed valve and double seal

› working pressure 400 bar (5.800 psi)

› connecting thread M = M 10 x 1, 1/8" BSP = G 1/8"

41046 X-TRA 500 concrete repair

capacity 500 cm 3 (17 oz)

41305 X-TRA 500 concrete repair with manometer and 110/M

with safety high-pressure rubber hose 110/M with 4-jaw Proﬁ-nozzle capacity 500 cm

(17 oz)

41047 X-TRA 1000 concrete repair

capacity 1.000 cm 3 (34 oz)

82114 X-TRA 1000 concrete repair

capacity 1.000 cm 3 (34 oz), with screw cap made of metal at the end of the pipe

Characteristics

› display plastic bag (41046, 41047, 82114) or neutral cardboard

box, white (41305)

› capacity 500 cm 3 (17 oz) or 1.000 cm 3 (34 oz)

› for concrete repair business

› for suit runny expoxy resins, oils and low viscosity greases

› ultimate suction power with full-stroke system

› professional lever oil gun made of precision steel, robust and durable

› air bleed valve

› without inner parts

› 41046, 41305, 41047 with blue plastic cap

› 82114 with screw-cap, made of metal

› working pressure 400 bar (5.800 psi)

› connecting thread M = M 10 x 1

102 Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany)

Accessories for concrete repair business

› safety high-pressure rubber hoses

› profi-nozzles for epoxy resins

Safety high-pressure rubber hose with nozzle for epoxy resins

02501 / 02503 / 02505

4-jaw Proﬁ-nozzles for epoxy resins

07122 / 07131

300 mm / 12 inch

02501 110/M

with 4-jaw Proﬁ-nozzle (tested by DLG)

02531 110/BSP

with 4-jaw Proﬁ-nozzle

40734 110/NPT

with 4-jaw Proﬁ-nozzle

02506 112/M

with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02536 112/BSP

with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

500 mm / 20 inch

02503 111/M

with 4-jaw Proﬁ-nozzle

02533 111/BSP

with 4-jaw Proﬁ-nozzle

02510 113/M

with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

02540 113/BSP

with hook-on coupler M 1 for button-head grease ﬁttings ø 16 mm

1.000 mm / 39 inch

02505 1110/M

with 4-jaw Proﬁ-nozzle

40318 1110/BSP

with 4-jaw Proﬁ-nozzle

07122 120/M 4-jaw Proﬁ-nozzle

07123 120/BSP 4-jaw Proﬁ-nozzle

07124 120/NPT 4-jaw Proﬁ-nozzle

07131 Angled nozzle 90°/M

40459 Angled nozzle 90°/BSP

Characteristics

› for packers with hydraulic grease fittings (DIN 71412)

› 4 jaws turned out of a single piece of highly elastic quality steel forming a circle to ensure precise coupling and consistent jaw alignment with every use

› durable elastic interior plug and high-performance spring for leak-proof operation

› case-hardened steel jaws and upper part of coupler for less wear and more durability

› working pressure 400 bar (5.800 psi)

› bursting pressure 1.600 bar (23.200 psi)

Hallbauer-Industries – A Division of Samoa-Hallbauer GmbH, Industriestraße 18, 68519 Viernheim (Germany) 103

104

Headquarters of Samoa-Hallbauer GmbH in Viernheim.

A cut above.

Through the merger of Hallbauer, with over 90 years of experience, with Samoa Industrial S.A., founded 1958 in Gjion (Spain), the foundation stone for a comprehensive service and a versatile product portfolio, was laid.

As a full-range supplier for handling of ﬂuids especially of lubricants and greases, the Samoa group stands for fair partnership, sustainable manufacturing and ﬁrst-class product quality. Thereby our production base is state-of-the art, so that we produce products with the greatest per formance and most environmental sustainability.

The products of Samoa-Hallbauer and the Samoa Group are used in more than 100 countries all over the world, especially in industry, automotive and other areas. Our aim is to provide the best possible service to all users of our products.

Besides product quality and customer satisfaction employees and social engagement are of prime importance for Samoa-Hallbauer.

We offer a healthy and secure working environment for our employees and contribute to the future generation by being a training company.

Furthermore we commit ourselves socially by supporting non-proﬁt organizations such as Life Aid in Viernheim. We donate on a regular basis to the German blind people relief organization, Caritas, the local branch of the German Red Cross and the local voluntary ﬁre brigade. By doing so we would like to show our social engagement especially in our area.

QUESTIONS?

Hallbauer-Industries

A Division of Samoa-Hallbauer

Phone + 49 6204 7095-40

Fax + 49 6204 7095-33

P.O. Box 1340, 68503 Viernheim (Germany)

Industriestraße 18, 68519 Viernheim (Germany) [email protected]

www.hallbauer-viernheim.de

At your service worldwide

105

106

Part number index

04021 ............

04032 ............

04052 ............

04082 ............

04085 ............

04121 ............

04131 ............

05122 ............

05132 ............

06010 ............

06011 ............

06014 ............

06015 ............

07011 ............

07012 ............

07013 ............

07041 ............

07042 ............

07043 ............

07122 ............

07122 ..........

103

07123 ............

07123 ..........

103

07124 ............

07124 ..........

103

07131 ............

07131 ..........

103

07402 ............

07403 ............

02607 ............

02640 ............

02641 ............

02631 ............

02637 ............

02701 ............

02703 ............

02731 ............

02733 ............

02738 ............

02801 ............

02803 ............

02831 ............

02833 ............

03122 ............

03132 ............

03322 ............

03332 ............

02425 ............

02426 ............

02501 ............

02501 ..........

103

02503 ............

02503 ..........

103

02505 ............

02506 ............

02506 ..........

103

02508 ............

02510 ............

02510 ..........

103

02512 ............

02531 ............

02531 ..........

103

02533 ............

02533 ..........

103

02536 ............

02536 ..........

103

02538 ............

02540 ............

02540 ..........

103

02542 ............

02601 ............

01531 ............

01532 ............

01801 ............

01803 ............

01831 ............

01833 ............

01851 ............

01853 ............

01881 ............

01883 ............

01901 ............

02002 ............

02003 ............

02004 ............

02006 ............

02007 ............

02014 ............

02032 ............

02033 ............

02034 ............

02036 ............

02037 ............

02042 ............

02423 ............

12152 ............

12153 ............

12154 ............

12155 ............

12156 ............

12171 ............

12172 ............

12181 ............

12206 ............

12208 ............

12212 ............

12217 ............

12218 ............

12231 ............

12232 ............

12233 ............

12234 ............

12251 ............

12252 ............

12253 ............

12254 ............

12256 ............

12258 ............

12306 ............

11505 ............

121020 ..........

12106 ............

12108 ............

12110 ............

12112 ............

12113 ............

12114 ............

12115 ............

12116 ............

12117 ............

12118 ............

12119 ............

12121 ............

12131 ............

12132 ............

12133 ............

12134 ............

12151 ............

12308 ............

12312 ............

12317 ............

12322 ............

12331 ............

12332 ............

12333 ............

09605 ............

09614 ............

09615 ............

09618 ............

09619 ............

09722 ............

09723 ............

09843 ............

09844 ............

09847 ............

09848 ............

09849 ............

09850 ............

09865 ............

09866 ............

10205 ............

10206 ............

10210 ............

10211 ............

11101 ............

11102 ............

11211 ............

11212 ............

11304 ............

07412 ............

07413 ............

07422 ............

07423 ............

07990 ............

07991 ............

08053 ............

08101 ............

08151 ............

08201 ............

08251 ............

08501 ............

08761 ............

08765 ............

09500 ............

09512 ............

09513 ............

09531 ............

09604 ............

11374 ............

11376 ............

11377 ............

11501 ............

11502 ............

11503 ............

11504 ............

15172 ............

15173 ............

15174 ............

15175 ............

15176 ............

15177 ............

15178 ............

15225 ............

15226 ............

15227 ............

15228 ............

15461 ............

15473 ............

15475 ............

15476 ............

15663 ............

15665 ............

15666 ............

157000 ..........

160101400 ....

160101401 ....

160103400 ....

160103401 ....

169009 ..........

169011 ..........

169012 ..........

186300 ........

101

27015 ............

27030 ............

27117 ............

14251 ............

14253 ............

14271 ............

14306 ............

14308 ............

14312 ............

14331 ............

14353 ............

14406 ............

14408 ............

14412 ............

14414 ............

14415 ............

14450 ............

14453 ............

14704 ............

14706 ............

14708 ............

14713 ............

150000 ..........

12534-I .........

12534-H .........

12612 ............

12613 ............

12614 ............

12615 ............

12617 ............

12621 ............

12624 ............

12625 ............

12627 ............

12634 ............

12635 ............

12637 ............

12715 ............

12717 ............

12991 ............

12992 ............

14104 ............

14110 ............

14131 ............

14133 ............

14150 ............

12334 ............

12337 ............

12351 ............

12352 ............

12353 ............

12354 ............

12355 ............

12358 ............

12371 ............

12381 ............

12511 ............

12512 ............

12513 ............

12514 ............

12521 ............

12522 ............

12524 ............

12531 ............

12532 ............

14153 ............

14171 ............

14181 ............

14206 ............

14208 ............

14212 ............

14231 ............

14233 ............

30300 ............

30320 ............

30331 ............

30332 ............

305000 ..........

308200 ..........

308300 ..........

320200 ..........

320400 ..........

325000 ..........

325010 ..........

326000 ..........

326010 ..........

330100 ..........

331120 ..........

333120 ..........

360125 ..........

360131 ..........

360137 ..........

365675 ........

101

366010 ..........

40001 ............

40002 ............

40005 ............

40008 ............

27130 ............

27217 ............

27230 ............

28025 ............

28040 ............

28125 ............

28140 ............

29110 ............

29220 ............

29410 ............

29420 ............

29430 ............

29450 ............

300006 ..........

300009 ..........

300100 ..........

300101 ..........

300103 ..........

300104 ..........

30018 ............

30100 ............

30190 ............

30218 ............

30230 ............

40495 ............

40498 ............

40508 ............

40511 ............

40512 ............

40517 ............

40518 ............

40519 ............

40520 ............

40521 ............

40527 ............

40530 ............

40531 ............

40534 ............

40535 ............

40536 ............

40537 ............

40541 ............

40542 ............

40543 ............

40544 ............

40545 ............

40445 ............

40446 ............

40447 ............

40448 ............

40449 ............

40450 ............

40453 ............

40458 ............

40459 ............

40459 ..........

103

40472 ............

40473 ............

40474 ............

40475 ............

40478 ............

40483 ............

40491 ............

40493 ............

40546 ............

40548 ............

40551 ............

40555 ............

40557 ............

40558 ............

40568 ............

40371 ............

40373 ............

40378 ............

40383 ............

40387 ............

40388 ............

40389 ............

40390 ............

40392 ............

40396 ............

40397 ............

40398 ............

40399 ............

40400 ............

40405 ............

40406 ............

40407 ............

40408 ............

40410 ............

40411 ............

40415 ............

40419 ............

40424 ............

40427 ............

40428 ............

40435 ............

40437 ............

40440 ............

40441 ............

40442 ............

40444 ............

40261 ............

40265 ............

40266 ............

40292 ............

40298 ............

40316 ............

40318 ............

40334 ............

40336 ............

40344 ............

40346 ............

40347 ............

40351 ............

40357 ............

40361 ............

40365 ............

40368 ............

40369 ............

40098 ............

40110 ............

40111 ............

40112 ............

40126 ............

40131 ............

40132 ............

40144 ............

40153 ............

40154 ............

40155 ............

40156 ............

40157 ............

40159 ............

40181 ............

40182 ............

40200 ............

40201 ............

40207 ............

40219 ............

40239 ............

40240 ............

40009 ............

40010 ............

40011 ............

40015 ............

40017 ............

40018 ............

40021 ............

40030 ............

40032 ............

40033 ............

40043 ............

40044 ............

40047 ............

40057 ............

40076 ............

40077 ............

40078 ............

40079 ............

40082 ............

40242 ............

40243 ............

40248 ............

40255 ............

40256 ............

40258 ............

40260 ............

40918 ............

40919 ............

40920 ............

41006 ............

41012 ............

41013 ............

41014 ............

41015 ............

41016 ............

41017 ............

41037 ............

41038 ............

41046 ..........

102

41047 ..........

102

41078 ............

411100 ..........

41271 ............

41272 ............

41273 ............

41274 ..........

41275 ............

41277 ............

41280 ..........

102

40818 ............

40823 ............

40831 ............

40832 ............

40834 ............

40835 ............

40841 ............

40842 ............

40843 ............

40844 ............

40860 ............

40860 ..........

100

40864 ............

40871 ............

40888 ............

40895 ............

40896 ............

40916 ............

40917 ............

41283 ............

41284 ............

41285 ............

41291 ............

41292 ............

41293 ............

41294 ............

41298 ............

40699 ............

40700 ............

40701 ............

40724 ............

40725 ............

40727 ............

40729 ............

40733 ............

40734 ............

40734 ..........

103

40736 ............

40777 ............

40781 ............

40783 ............

40784 ............

40800 ............

40801 ............

40804 ..........

102

40805 ..........

102

40813 ............

40815 ............

40574 ............

40576 ............

40581 ............

40582 ............

40583 ............

40595 ............

40601 ............

40611 ............

40617 ............

40618 ............

40625 ............

40626 ............

40627 ............

40628 ............

40642 ............

40653 ............

40662 ............

40669 ..........

102

40671 ............

40673 ............

40675 ............

40681 ............

40683 ............

40688 ............

40689 ............

80018 ............

80019 ............

80020 ............

80081 ............

80109 ............

80127 ............

80139 ............

80185 ............

80188 ............

80194 ............

80207 ............

80246 ............

80263 ............

80273 ............

80277 ............

80289 ............

80298 ............

80316 ............

80317 ............

80332 ............

80333 ............

80366 ............

80379 ............

560310400 ....

560320400 ....

560901 ..........

560905 ..........

560906 ..........

569003 ..........

569005 ..........

569006 ..........

601202 ..........

65001 ............

688100 ..........

80003 ............

80004 ............

80005 ............

80006 ............

80007 ............

80008 ............

80009 ............

80010 ............

80011 ............

80012 ............

80013 ............

80014 ............

80015 ............

80017 ............

431000 ..........

431001 ..........

432000 ..........

432100 ..........

432814 ..........

506300 ..........

506321 ..........

507300 ..........

507321 ..........

508225 ..........

551030 ..........

552010 ..........

557952 ..........

557952400 ....

557953 ..........

557953400 ...

560300400 ....

560301400 ....

560303400 ....

560304400 ....

560305400 ....

560306400 ....

560307 ..........

560307400 ....

560308 ...........

560308400 ....

41299 ............

41300 ............

41305 ............

41307 ............

414300400 ....

417001 ..........

417002 ..........

417003 ..........

417004 ..........

417005 ..........

417006 ..........

418002 ..........

418004 ..........

418006 ..........

418013 ..........

418016 ..........

418026 ..........

431000 ..........

107

108

80904 ............

80909 ............

80919 ............

80925 ............

80926 ............

80935 ............

80937 ............

80943 ............

80949 ............

80960 ............

80978 ............

80984 ............

80983 ............

80986 ............

80987 ............

80988 ............

80989 ............

81000 ............

81001 ............

81002 ............

81003 ............

81004 ............

81005 ............

81006 ............

81007 ............

81008 ............

81009 ............

81010 ............

81011 ............

81012 ............

81013 ............

80747 ............

80751 ............

80825 ............

80838 ............

80856 ............

80857 ............

80858 ............

80859 ............

80860 ............

80862 ............

80867 ............

80868 ............

80869 ............

80870 ............

80871 ............

80885 ............

80886 ............

80902 ............

80634 ............

80640 ............

80642 ............

80643 ............

80644 ............

80659 ............

80667 ............

80668 ............

80677 ............

80678 ............

80681 ............

80685 ............

80688 ............

80689 ............

80690 ............

80692 ............

80702 ............

80703 ............

80704 ............

80707 ............

80714 ............

80718 ............

80719 ............

80416 ............

80418 ............

80431 ............

80445 ............

80451 ............

80469 ............

80478 ............

80479 ............

80487 ............

80488 ............

80492 ............

80493 ............

80499 ............

80515 ............

80541 ............

80550 ............

80594 ............

80618 ............

80619 ............

80629 ............

80727 ............

80728 ............

80730 ............

80731 ............

80732 ............

80746 ............

81092 ............

81093 ............

81095 ............

81096 ............

81097 ............

81105 ............

81118 ............

81123 ............

81125 ............

81130 ............

81134 ............

81135 ............

81141 ..........

100

81146 ............

81147 ............

81152 ............

81160 ............

81161 ............

81162 ............

81168

............

81176 ............

81187 ............

81191 ............

81197 ............

81202 ............

81203 ............

81204 ............

81205 ............

81216 ............

81222 ............

81234 ............

81260 ............

81261 ............

81262 ............

81272 ............

81273 ............

81283 ............

81295 ............

81301 ............

81336 ............

81337 ............

81338 ............

81339 ............

81341 ............

81345 ............

81365 ............

81385 ............

81393 ............

81397 ............

81463 ............

81475 ............

81486 ............

81499 ............

81505 ............

81516 ............

81543 ............

81544 ............

81547 ............

81552 ............

81557 ............

81559 ............

81562 ............

81563 ............

81564 ............

81565 ............

81568 ............

81569 ............

81577 ............

81579 ............

81605 ............

81606 ............

81608 ............

81406 ............

81411 ............

81412 ............

81417 ............

81417 ..........

100

81418 ............

81418 ..........

100

81419 ............

81419 ..........

100

81420 ............

81420 ..........

100

81421 ............

81421 ..........

100

81422 ............

81422 ..........

100

81428 ............

81434 ............

81435 ............

81452 ............

81611 ............

81612 ............

81648 ............

81656 ............

81658 ............

81665 ............

81677 ............

81696 ............

81037 ............

81038 ............

81039 ............

81040 ............

81041 ............

81042 ............

81043 ............

81045 ............

81050 ............

81056 ............

81058 ............

81061 ............

81066 ............

81070 ............

81071 ............

81072 ............

81074 ............

81076 ............

81077 ............

81080 ............

81081 ............

81082 ............

81083 ............

81014 ............

81015 ............

81016 ............

81017 ............

81018 ............

81019 ............

81020 ............

81022 ............

81024 ............

81026 ............

81027 ............

81028 ............

81029 ............

81030 ............

81031 ............

81032 ............

81034 ............

81035 ............

81036 ............

81084 ............

81086 ............

81087 ............

81088 ............

81089 ............

81090 ............

81091 ............

81894 ............

81908 ............

81910 ............

81915 ............

81918 ............

81934 ............

81937 ............

81941 ............

81943 ............

81944 ............

81951 ............

81966 ............

81968 ............

81969 ............

81988 ............

81990 ............

81994 ............

82010 ............

82024 ............

82026 ............

82049 ............

82051 ............

82055 ............

82061 ............

82065 ............

82066 ............

82094 ............

82094 ..........

100

82103 ............

82114 ..........

102

82124 ............

82137 ............

82138 ............

82142 ............

82143 ............

82148 ............

80477 ............

930505 ..........

930507 ..........

81779 ............

81786 ............

81791 ............

81794 ............

81796 ............

81810 ............

81811 ............

81831 ............

81834 ............

81835 ............

81836 ............

81842 ............

81843 ............

81845 ............

81846 ............

81847 ............

81854 ............

81855 ............

81856 ............

81857 ............

81858 ............

81859 ............

81861 ............

81864 ............

81866 ............

81867 ............

81869 ............

81891 ............

81892 ............

81893 ............

81708 ............

81712 ............

81713 ............

81730 ............

81731 ............

81744 ............

81745 ............

81748 ............

81752 ............

81754 ............

81756 ............

81758 ............

81759 ............

81760 ............

81763 ............

81764 ............

81769 ............

81773 ............

81774 ............

81776 ............

www.hallbauer-viernheim.de

Technical changes reserved. Pictures might be different to the original.

FLUID TECHNOLOGY AT ITS BEST: A CUT ABOVE

Phone + 49 6204 7095-40

Fax + 49 6204 7095-33

P.O. Box 1340, 68503 Viernheim (Germany)

Industriestraße 18, 68519 Viernheim (Germany) [email protected]

www.hallbauer-viernheim.de
